Install Guide
Rev 1.1 4/15/2002
USER’S GUIDE
FOR THE
IDEN IN BUILDING
BI-DIRECTIONAL
AMPLIFER/REPEATER
MODEL: BD800NB
Rev 1.1 PAGE 2
The information provided by Wilson Electronics, Inc. is believed to be complete and
accurate. However, no responsibility is assumed by Wilson Electronics, Inc. for any
business or personal losses arising from its use, or for any infringements of patents or
other rights of third parties which may result from its use.
WARNING:
A lightning rod should be added if the outside antenna is in any danger of being
hit by lightning.
FCC ID: PWOBD800NB
Copyright © 2002 Wilson Electronics, Inc.
Rev 1.1 PAGE 3
1. PACKAGE CONTENTS
1.1 Amplifier/Repeater
1.2 AC-to-DC Transformer
1.3 Antennas: 800MHz Magnet Mount (outside), Short 800MHz Magnet (inside)
1.4 2 N-Male To FME-Male Adapters
2. OPTIONAL ACCESSORIES
2.1 RF Splitter
2.2 Coax Cable Extensions 50Ω
