GAIN CH.2 CH.4 CH.6 CH.7 CH.9 CH.11 CH.13 CH.14 CH.32 CH.50 CH.69

dB over reference

dipole

beamwidth at half

power points

front-to-back

ratio

Shpg. Weight

Carton Dimensions 17 lbs.

6.25"x6.25"x122"

7 7.7 6.4 10.4 12.6 11 12 14.2 13.7 12.2 13

68° 68° 66° 29° 34° 42° 41° 40° 41° 33° 23°

19dB 18dB 13dB 20dB 10.5dB

POLAR PATTERNS

Clearly the World's Best®

engineering specifications Model HD8200P

Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4/02

Output Impedance:

Recommended Preamp: 75 ohm

AP Series

71

37

34

177.5"

100"

110"

31.5"

3/8"

Active Elements

UHF Elements

VHF Elements

Boom Length

Turning Radius

Maximum Width

Vertical Height

Element Diameter

Made in U.S.A.

greater

than

20dB

greater

than

20dB

greater

than

20dB

greater

than

20dB

greater

than

20dB

greater

than

20dB

PLATINUM SERIES

HIGH DEFINITION

VHF/UHF

ANTENNA
