Winplus BT50825 YD-V4 Headset + Direct Charger User Manual Yada manual R
Winplus Co., Ltd YD-V4 Headset + Direct Charger Yada manual R
Winplus >
user manual
www.letsyada.com
1 2
7 8
BATTERY OPERATIONS
HEADSET OPERATION
910
LED Status
1 x 3 sec. Blue Ready – can be accessed by paired devices
1 x 1 sec. Blue Talking
2 x 2 sec. Blue Incoming call
Solid Blue Fully charged
Solid Blue in 2 sec. Active Two-Link (Multipoint function)
Solid Red Under charging
Red LED off Fully charged
Blinking red Battery low (max. 15 Minutes left)
Red/Blue Blinking Pairing-Mode
11 12
It is recommended that you follow the pairing instructions provided
by your mobile phone to ensure you successfully pair the YD-V4
headset with your mobile phone. If you do not have your mobile
phone’s instruction manual available, follow the typical pairing
instructions below:
• Press and hold S1 until red and blue LED lights are flashing
alternately. It indicates that the Headset is in Pairing Mode
The following steps are general procedure
to access Bluetooth® Menu for your mobile
phone, please refer to your phone user
manual for detailed steps to pair your phone.
• Select BLUETOOTH, SET UP, or CONNECT
from your mobile phone menu
• Find and select prompt to search for, look for or add new device,
establishing a connection may take several minutes
• If found, phone display should indicate YD-V4 device was detected
• Phone should give you prompt asking if you want to pair the device
• Select “OK” and wait for prompt to enter passkey or PIN
• Enter the code 0000
• Check the headset LED for a flashing blue light every 3 seconds
to verify the pairing was successful
• Do not change the headset name if the phone gives you a
prompt to change the name, accept the YD-V4 as the name of
the device
NOTE: The YD-V4 can pair with more than one phone, however it
can only connect to one phone at a time. If you wish to pair to a
second phone, disable or turn off Bluetooth® on the phone already
paired.
CAUTION: Some phones put the Bluetooth® connection into Standby
Mode if it has not been used for some time. If an incoming call is
received, only the mobile phone will ring. It could take a few seconds
(2-3 ring tones) before the call is transferred to the headset. Wait until
the ring is heard on the headset before taking the call. Do not press
S1 before the call is transferred to the headset to avoid conflict with
the mobile phone.
Transferring The Calls
The YD-V4 is capable of transferring calls from your mobile phone to
YD-V4 headset or vice versa. Follow your mobile phone operating
instructions for transferring call to ensure successful transfer of calls
between the YD-V4 headset and your mobile phone. If instructions
are not available, use the typical instructions below to transfer your
calls.
• When in session, press and hold S1 for 3 seconds to transfer the
call from your mobile phone handset to the YD-V4 headset or
vice versa
Rejecting an incoming call
To reject a call:
• Press and hold S1 until you hear 2 tones while headset is ringing
• Call should be dropped once tone is heard
NOTE: This feature works on mobile phones with the “Handsfree”
profiles only
If the mobile phone failed to detect the YD-V4 and did not
successfully pair,
• Turn the headset and phone off, wait for 10 seconds
• Turn phone power on
• Repeat the pairing instructions from the beginning
Re- Establishing Bluetooth® Link:
You will need to re-establish a link between the YD-V4 Bluetooth®
headset and your mobile phone before you can make or receive
any calls. Follow instructions provided by your mobile phone to
ensure you can establish a successful link. If you do not have your
mobile phone operating instructions available, follow the typical
steps below:
• Depending on your mobile phone, the link will either be
established automatically and the LED status should have a blue
light flashing every 3 seconds indicating the device was linked
successfully
• Other mobile phones will give you a prompt to accept the link
request from the YD-V4 before establishing a link, select Yes or
OK if you get a prompt
13 14
15 16
Outgoing Calls
• Manual
• Voice Activated
• Redial
To make outgoing calls manually:
• Check if headset power is on and headset is linked
• Place headset in ear
• Use mobile phone handset to make call
• Talk directly to microphone once call is connected and answered
To make a new call using voice activated function:
• Press S1 briefly and wait for headset signal tones.
• Say recorded voice command set on your mobile phone
(e.g. Call “Name of Person”)
• Wait a few seconds for call to connect
• Talk directly to microphone once call is connected and answered
IMPORTANT: Verify mobile phone voice activated function is
properly set and headset is within range of the mobile phone
To Redial last number called
• Hold volume up (+) button until you hear 4 tones
• Handset will call last number dialed
NOTE: This feature works on mobile phones with the “Handsfree”
profiles only
17 18
The YD-V4 headset can be used with a desktop or laptop computer
that are Bluetooth® compatible, to make calls via Voice Over Internet
Protocols (VOIP).
To use this function, follow the instructions below:
NOTE: If your computer does not have built-in Bluetooth® capability,
you will need to install a Bluetooth® USB adapter to utilize the headset.
Follow instructions for installing adapter in your computer.
• Download from the corresponding websites and install Skype, MSN
messenger, Netmeeting, Yahoo messenger, or ICQ application
software in the PC
• Pair headset with computer
o Follow pairing instruction for YD-V4 Bluetooth® headset to set the
headset into "pairing" mode
o Start the computer Bluetooth® software and pair with the YD-V4
Headset
If computer prompts for a headset passkey enter 0000
• Connecting and Disconnecting:
o Press the S1 key briefly to connect the YD-V4 Headset with the
computer
o Press S1 briefly again to disconnect
o After turning off and turning on the headset, you just need to
press S1 briefly to establish the audio link if the computer was the
last used device.
• Testing the Bluetooth® link:
o After PC connects with the YD-V4 headset, the PC audio will be
automatically routed to the "Bluetooth Audio" driver
o Play some music on the PC by Windows Media Player or other
music application
o You should be able to hear the music on the headset
o If you can't hear it, then go to the "control Panel"-> "Sound and
Audio Device Properties"-> "Audio"-> "Sound playback" select
the "Bluetooth Audio" to activate the link
• Now you can start using the VOIP application and make calls
through your headset wirelessly
• To re-connect the YD-V4 to your mobile phone, find the “Paired
Devices” list in the “Bluetooth Settings” menu in your phone. Select
“YD-V4” and connect
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
IC statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may
cause undesired operation of the device.
This device has been designed to operate with an antenna having a maximum
gain of 0 dBi. Antenna having a higher gain is strictly prohibited per regulations of
Industry Canada. The required antenna impedance is 50 ohms.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules & RSS210. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
FCC/ICC
CUSTOMER SERVICE / CONTACT US PAGE
VOICE OVER INTERNET PROTOCOL (VOIP) APPLICATION
19 20
21 22
23 24
25 26
S1/LED
Volume down (–)
Volume up (+)
Reset
3 4
5 6
WINPLUS NORTH AMERICA
LIMITED WARRANTY
WINPLUS North America warrants, to the original purchaser, that its products
are free from defects in material and workmanship for 1 year from the date of
original purchase. Where permitted by law, WINPLUS North America’s liability
shall be limited to that set forth in this limited express warranty. This limited
express warranty shall be the exclusive remedy of the purchaser and WINPLUS
North America makes no other warranty of any kind aside from the limited
express warranty stated above.
Note: Warranty only applies for North American customers or purchases made
in the North America.
• Distracted driving is dangerous. Always use the Bluetooth® Device in a
manner that does not reduce your attention and ability to drive carefully
and safely.
• Adhere to all applicable traffic laws and motor vehicle regulations applicable
to the device.
• Consult local laws and regulations for any restrictions on installation or use.
• Do not install on or near an airbag. Such installation could interfere with
airbag deployment or could cause the product or another object to become
a projectile, which could result in serious personal injury to occupants.
• Ensure the product location will not obstruct your vision while driving.
• Turn off the headset prior to boarding an aircraft.
• Small parts may be a choking hazard. Do not allow children to play with the
headset.
• Observe all signs that require an electrical device to be switched off in
designated areas. These may include hospitals, blasting areas or potentially
explosive atmospheres.
DISCLAIMER
WARRANTY / LIABILITIES
CONDITIONS OF WARRANTY
If during the 1 year warranty period your new product is found to be defective,
WINPLUS North America will repair such defect, or replace the product, without
charge for parts or labor subject to the following conditions:
1. All repairs must be performed by WINPLUS North America.
2. All warranty claims must be accompanied by a copy of the sales receipt or
bill of sale.
3. The equipment must not have been altered or damaged through
negligence, accident, improper operation, or failure to follow the product
instructions for installation, use, or care.
4. The replacement of parts is excluded from the warranty when replacement
is necessary due to normal wear and tear.
5. Repair or replacement parts supplied by WINPLUS North America under this
warranty are protected only for the unexpired portion of the original
warranty.
6. This is a “repair or replace” warranty only, and does not cover the costs
incurred for the installation, removal or reinstallation of the product, or
damage to any mobile phone device or vehicle.
OWNER’S RESPONSIBILITIES:
WINPLUS North America will make every effort to provide warranty service
within a reasonable period of time. SHOULD YOU HAVE ANY QUESTIONS ABOUT
SERVICE RECEIVED OR IF YOU WOULD LIKE ASSISTANCE IN OBTAINING SERVICE,
PLEASE CALL TOLL FREE 1.866.294.9244 DURING REGULAR BUSINESS HOURS
MONDAY THROUGH FRIDAY 9:00 AM TO 5:00PM.
In order to provide you with the proper warranty service, we request that you
adhere to the following procedure:
1. Include a copy of your sales receipt or bill of sale with your unit when it is
returned for warranty service.
2. If it is necessary to return your product for service, please return it securely
packed, preferably in the original shipping box, and freight and insurance
prepaid to the following address:
ATTN: WINPLUS BLUETOOTH®PRODUCTS RETURNS
3. Please include a detailed explanation of the problem you are having.
4. If your product is found by WINPLUS North America to have a defect in material
or workmanship, within the warranty period, it will be repaired or replaced at no
charge and returned to you prepaid.
WINPLUS North America makes no other warranty of any kind aside from the limited
express warranty stated herein.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND
WARRANTY OF FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH
HEREIN, NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, IS MADE AS TO THE
YD-V4 BLUETOOTH® HEADSET. EXCEPT AS EXPRESSLY SET FORTH HEREIN, WINPLUS NORTH
AMERICA AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS, WITHOUT LIMITATION, ANY
STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
WINPLUS North America and/or its affiliates are not responsible for a user’s intended or
actual use of the YD-V4 Bluetooth® Headset. In no event shall WINPLUS North
America and/or its affiliates have any liability for any losses (whether direct or indirect,
in contract, tort or otherwise) incurred in connection with the YD-V4 Bluetooth®
Headset. Neither shall WINPLUS North America and/or its affiliates have any liability for
any decision, action or inaction taken by any person in reliance on the YD-V4
Bluetooth® Headset, or for any delays, inaccuracies and/or errors in connection with
the YD-V4 Bluetooth® Headset and its functioning.
WINPLUS North America and/or its affiliates shall have no responsibility or liability for
damage and/or injury resulting from accidents while user is utilizing the YD-V4
Bluetooth® Headset; and WINPLUS North America and/or its affiliates, the manufacturer,
distributor and seller shall not be liable for any injury, loss or damage, incidental or
consequential, arising out of the use or intended use of the product.
WINPLUS EUROPE
LIMITED WARRANTY
WINPLUS warrants, to the original purchaser, that its products are free from
defects in material and workmanship for 12 months from the date of original
purchase. Where permitted by law, WINPLUS liability shall be limited to that set
forth in this limited express warranty. This limited express warranty shall be the
exclusive remedy of the purchaser and WINPLUS makes no other warranty of
any kind aside from the limited express warranty stated above.
OWNER’S RESPONSIBILITIES:
In order to provide you with the proper warranty service, we request that you
adhere to the following procedure:
1. Include a copy of your sales receipt or bill of sale with your unit when it is
returned for warranty service.
2. If it is necessary to return your product for service, please return it securely
packed, preferably in the original shipping box, and freight and insurance
prepaid to the following address:
ATTN: WINPLUS BLUETOOTH® PRODUCTS RETURNS
Unit 4, Two Counties Estate, Falconer Road
Haverhill, Suffolk CB9 7XZ, UK
3. Please include a detailed explanation of the problem you are having.
4. If your product is found by WINPLUS to have a defect in material or
workmanship, within the warranty period, it will be repaired or replaced at
no charge and returned to you prepaid.
WINPLUS makes no other warranty of any kind aside from the limited express
warranty stated herein.
WINPLUS AUSTRALIA / HONG KONG
LIMITED WARRANTY
!
!
!
!
569;/(4,90*(
,<967,
(<:;9(30(
5,>A,(3(5+
(:0(
;LS!
-H_!
;LS!
-H_!
;LS!
-H_!
;LS!
-H_!
;LS!
-H_!
:V\[O>HUHTHRLY(]LU\L
<UP[;^V*V\U[PLZ,Z[H[L-HSJVULY9VHK
/H]LYOPSS:\MMVSR*) ?A<2
<UP[ 4V\U[HPU/^`)VYVUPH
=PJ[VYPH(\Z[YHSPH
6SP]L9VHK7LUYVZL
(\JRSHUK5L^ALHSHUK
:\P[LZ[O-SVVY*VYWVYH[PVU7HYR
6U3HP:[YLL[:OH[PU5;/VUN2VUN
6U[HYPV*(
820 South Wanamaker Avenue,
Ontario, CA 91761
This Yada product is warranted against faulty workmanship for a period of 2
years from date of purchase. Liability is limited to replacement of the product
and claims for associated or consequential loss or damage will not be
accepted. Warranty is void and does not apply if the product has been
damaged or rendered faulty by accident, abuse, misuse, incorrect application
or if the product has been modified or tampered with. Proof of purchase is
required to validate warranty claims. If this product is faulty, simply return it to the
place of purchase with your receipt for a replacement product. No refunds or
credits will be issued. Replacement is limited to a Yada product of the same or
similar model.
IMPORTANT: Do not leave YD-V4 Bluetooth® headset charging in
the vehicle unattended, unless your vehicle is equipped with a port
that is powered with key out of ignition.
NOTE: Actual talk time and standby time for the YD-V4 will vary with
different Bluetooth® mobile phones due to the different
implementation of power down modes.
Low Battery Indicator
Check for two indicators to determine if the headset battery is low
1. Flashing red LED light
2. Headset will beep periodically
Recharge the headset immediately after the low battery indicators
are detected. You will have maximum 15 minutes talk time before
the headset automatically powers off. The LED light will not turn on
indicating battery power is completely consumed.
NOTE: Follow instructions on page 9 for charging the headset
battery
The YD-V4 will not power on until it is connected to the direct
charger to recharge. It may take several minutes before the LED
light turns back on once connected. Recharge the headset
sufficiently before using or removing from the direct charger.
For questions or issues regarding the product, please visit
www.letsyada.com or contact Winplus in your area/region to speak
to our customer service representative, when contacting customer
service please have the manual to your YADA and phone available:
Winplus USA Tel. 866-294-9244
Tel. 909-752-3074
Winplus Europe Tel. 44-1440-713888
Winplus Australia Tel. 61-3-9720-4143
Winplus New Zealand Tel. 64-9-5254575
Winplus Asia Tel. 852-2798-8932
You can also contact us online by visiting www.winplus.com for more
information about the product.
IF YOU ARE EXPERIENCING ANY ISSUES WITH THE PRODUCT DURING
OPERATION, DO NOT RETURN THE PRODUCT TO THE STORE. CONTACT
WINPLUS DIRECTLY FOR INSTRUCTIONS ON HOW TO
RETURN/EXCHANGE THE PRODUCT.
Thank you for purchasing the hands-free Bluetooth® Headset, the
latest wireless technology product from Winplus. We hope you will
enjoy all the features and benefits offered by the YD-V4 Headset.
These features and benefits were designed with the goal of
making wireless communication more convenient for the user.
Winplus Australia
Unit 2, 991 Mountain Hwy Boronia,
Victoria, Australia, 3155
customercare@winplus.com.au
www.winplus.com.au
Winplus New Zealand
Griffiths Equipment
22-24 Olive Road, Penrose,
Auckland, New Zealand
web@griffiths.co.nz
www.types.co.nz
Winplus USA
820 South Wanamaker Avenue,
Ontario, CA 91761
customercare@winplususa.com
www.winplususa.com
Winplus Europe
Unit 4, Two Counties Estate, Falconer Road,
Haverhill, Suffolk CB9 7XZ, U.K.
info@winplus-europe.com
www.winplus.net
Winplus Asia
Suites 6-11, 7th Floor, Corporation Park,
11 On Lai Street, Shatin, N.T., Hong Kong
info@winplus.net
www.winplus.net
DISCLAIMER
WARRANTY / LIABILITIES
PACKAGE CONTENT
BATTERY OPERATIONS
HEADSET OPERATION
VOICE OVER INTERNET PROTOCOL (VOIP) APPLICATION
CUSTOMER SERVICE / CONTACT US PAGE
FCC/ICC
CONTENTS
- Bluetooth® Spec.: v2.1 + EDR Class 2
- Weight: 7gm
- Talk Time: 5 Hours
- Standby Time: 100 Hours
- Profiles Support: HSP, HFP
- Frequency Band: 2.402 GHz - 2.480 GHz, 2.4G ISM Band
- Operating Range: 10 Meters
- Pairing: up to 7 devices
- Battery: Lithium-ion Battery
- Charger Adapter Output: DC 5V, 200mA
- Operating Temperature: -10ºC to 50ºC
- Storage Temperature: -20ºC to 80ºC
YD-V4 Headset Specifications:
ML-50825
YD-V4 headset + direct charger
User Manual
Bluetooth®
Headset
Direct
Charger
Ear Buds
(different sizes)
PACKAGE CONTENT
IMPORTANT: The Bluetooth® headset comes pre-charged, but it is
recommended to charge the battery until the solid red light turns off
before using for the first time. Amount of time will be depend on current
charge level of battery.
Charging the YD-V4 Bluetooth® headset
using 12V/24V direct charger.
The YD-V4 Direct Charger can be adjusted
to fit any 12V power port. Make sure to
press the Lock Button to adjust.
• Plug 12V/24V direct charger into the
vehicle cigarette lighter socket
• Place Bluetooth® headset in the
direct charger
NOTE: Make sure the On/Off Switch
of the Direct Charger is on the “On”
positon for it to charge the YD-V4.
• Verify LED shows a steady red light,
indicating device is charging
• Headset will only charge while vehicle
ignition is in the “ON” or “ACC” position.
Do not leave the ignition in either of
these positions while not driving
• Device LED red light will turn off once
the battery is fully charged
To turn headset Off:
• Press and hold S1 until LED light turns red
• Listen for a high tone followed by a low tone will indicate that
the YD-V4 is powered down
Auto Off
Headset will automatically power off after 5 minutes if
• No Bluetooth® connection is detected and
• Headset is not connected for charging
IMPORTANT: Headset will not power off after 5 minutes when
recharging the battery.
Headset Pairing/Linking
Pairing Bluetooth® enabled devices like mobile phones and headsets
authorizes the devices to work with each other and only needs to be
performed once. Headset can be paired with up to 7 devices. Only 1
device can be used at a time. (Maximum 2 in Two-Link Mode)
Before Pairing the YD-V4 headset:
• Ensure the Bluetooth® on your mobile phone is activated
• Ensure that you have read the pairing steps in your phone user manual
• Ensure the headset is fully charged
• Direct charger is disconnected
• The headset is turned off
• If headset is powered down before linking, the headset will
automatically reconnect to the mobile phone after power is
turned on. Press and hold S1 to power on the headset and
establish the link with the mobile phone
• YD-V4 will automatically attempt to reconnect if link is
disconnected abruptly (e.g. out of range) within 5 minutes
NOTE: If the headset is used with multiple wireless devices or mobile
phones, the headset reconnects to the last used device.
Incoming Calls
To answer calls manually
• Check if headset power is on and headset is linked
• Place headset in ear
• Press S1 briefly when incoming call ring is received
• Talk and the inbuilt microphone will pick up your voice
To answer calls using auto-answer function
• Check if headset power is on and headset is linked
• Place headset on direct charger (charging)
• Remove headset from direct charger when incoming call ring
is received
• Place headset in ear
• Talk and the inbuilt microphone will pick up your voice
Ending Calls
To End Call manually:
• Press S1 briefly to disconnect call
• LED will show blue flashing light every 3 seconds indicating the
headset is in stand-by
To end call with auto-end function:
• Remove headset from ear and place in direct charger (charging)
• Call will automatically disconnect
• LED will show blue flashing light every 3 seconds indicating the
headset is in stand-by
Call Waiting
NOTE: Call Waiting is a network service, please consult your network
provider for details.
To accept an incoming call during a conversation:
• Press volume up (+) briefly and the phone will automatically
switch to Line 2
• Press volume up (+) briefly to switch between lines
• Press S1 briefly to disconnect the in session call
Power On/Off
To turn headset On:
• Press and hold S1 until LED light turns blue
• Low tone followed by a high tone indicates that the YD-V4
is powered up
• Blue LED will flash every 3 seconds
Auto On
Headset will automatically power on when placed into the direct
charger
NOTE: Auto On feature only works when headset is actively
charging
© 2009 Winplus North America Inc. All Rights Reserved. Winplus, the logo design, and yada are trademarks or registered
trademarks of Winplus North America Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by Winplus North America Inc. is under license.
Patents:
CN200720153817.8, PCT/CN2008/000960
Ear HookNeck Strap
Volume
To adjust the headset volume during a call:
• Press and release volume up (+) to increase headset speaker volume
• Press and release volume down (–) to decrease headset speaker volume
• Headset will give warning tone when maximum or minimum
volume is reached
To mute the microphone during an active call:
• Press volume up (+) and volume down (–) buttons simultaneously
for about a second
• Headset microphone will be muted until removed
• Headset will give periodic beep tone indicating mute function is active
To remove microphone mute function:
• Press volume up (+) and volume down (–) buttons simultaneously
• Headset disables periodic beep
• Microphone mute function is deactivated and microphone is
active again
Two-Link (Multipoint Function)
Using the YD-V4 with 2 mobile phones:
• Paired with your first phone
• Pair the second mobile phone by press and hold the volume
down (–) button until red and blue LED lights are flashing
alternately. It means the headset entered the pairing mode.
Pair your second phone with YD-V4
• Once the second phone is paired, active the Two-Link
(Multipoint Function) by long pressing the volume up (+) and
volume down (–) buttons simultaneously. When you see the
blue light turn on for about 3 seconds on the headset, it means
the Two-Link (Multipoint Function) is active
• After pairing the second mobile phone, the first mobile phone
will be disconnected with YD-V4, you will need to re-connect the
first mobile phone from the phone’s Bluetooth® setting and you
should have both phone connected to YD-V4
NOTE:
• In Two-Link mode (mulitpoint), your first connected phone will be
the priority phone
• In Two-Link mode (multipoint), only the first connected phone will
be able to use redial. The second connected phone will not be
able to use redial feature even when first connected phone
disconnected.
In order to use redial feature, make sure your phone is the first
connected phone during Two-Link (multipoint)
• Connect reaction time is different when using different mobile
phones. For example, if turn on YD-V4 after successful to use
multipoint function, it will try to make connection with paired
mobile phones. If the reaction time of phone A is faster than
phone B, it will connect with YD-V4 first as the first connected
phone, no matter it was paired with YD-V4 before or after phone B.
S1/LED
S1/LED
Maximum 220º
Lock Button
ON/OFF Switch
On Off
ON/OFF
v1.0
