Wintop Electronics BT-576 Bluetooth movement headset User Manual BT 576
Wintop Electronics Co., Limited Bluetooth movement headset BT 576
User manual
BT-576 SPORT BLUETOOTH HEADPHONE
User Manual
Get Started
To know more about BT-576 sport Bluetooth earphone！
Features&Specification
In-ear Sport&Gym Bluetooth Stereo headphone
Bluetooth V4.0
Battery status display on iOS
Operating range more than 10m
Standby Time: 150 hours
Talk Time: 4 hours
Operating Frequency: 2401MHz-2479MHz
Connect with two Bluetooth devices at the same time
2
1
3
How to use
1.L&R orientation
When worn under-ear,
controller on Right side
4
2.Great sound performance is in selecting the right size eartip
We love great sound.Make sure you hear it.
Because everyone's ears are different.
Be sure to try all sizes of eartips.
Only with the right size eartips with you
enjoy fit & premium sound quality.
L S 5
3.General Function
6
Volume Up/Next
Turn on/Pairing mode/
Play/Pause/
Turn off/Answer call/
End call/Reject call/
Last number redial
Volume Down/
Previous/Mute call
Operation LED Status
Power on Blue LED flashes 2 times
Power off Red LED flashes 2 times
Pairing Red LED&Blue LED flashes alternately
Standby Blue LED flashes 1 time every 4 seconds
Incoming call Blue LED flashes continuous
Low battery Red LED flashes 3 times every 20s
Charging Red LED keep lighting during charging
Blue LED flashes once charging finished
LED Indica tor
Micro USB charger
Mic
Snapshot function compatiable with Android 3.0/
iOS 5.0 or above
Warning
2.You must charge the headphone if it has not been used
for more than 12 months.
3.If any metal tooling inserted in your body, you should use
this headphone under doctor's instruction because there
is a magnet inside the headphone.
11
4.Basic Buttons Operation
Power on:Press multifuction button for 4 seconds.
Blue LED flashes 2 times.Headphone turn on.
Power off:Press multifuction button for 4 seconds.
Red LED turn off after flashes 2 times.Headphone turn off.
Volume adjust:Each press on “Volume up” or “Volume down”
buttons,one level voice volume changes.When Volume
reaches to Max or Minimum. “Tick” reminding voice occurs.
Play/Pause: Short press multifunction button,music
pause.Press it again,music continues.
Previous: in standby status, Long press 2 seconds
“Volume down”button,music turns to previous one.
Next: in standby status, Long press 2 seconds
“Volume up”button,music turns to next one.
Answer call：Short press multifunction button to answer
the phone call.
End call:Short press multifunction button,phone call ended.
Reject call: Long press the multifunction button for
2 seconds to reject a call.
Last number redial: in standby status,continuously press
headphone multifunction button twice to redial the last number.
Battery Capacity status:When headphone connects to iOS
devices show the headphone bettery power status on the
upper right corner.
Charging:New headphone has enough power for pairing
and dialing out for several times.When in low battery,
please charging via USB cable for 2 hours.Red LED keep
lighting during charging,blue LED keep lighting
charging finished.
78
9
5.Pairing (One headphone support connecting 2 phone devices)
Pairing with one phone or other device
Make sure the headphone is power off.
Press and hold the multifunction button for 7 seconds to
enter into the pairing mode.Red LED &Blue LED flashes
alternately,Activate your phone or device Bluetooth
function and search for headphone.From the list of found
devices on your mobile phone,select the headphone“BT-576”
to connect it.Follow the instruction to enter”oooo”as PIN if the
mobile phone reminder to need.Headphone or device can be
used to play your phone music or dial phone call etc.
Pairing with two phones or other devices at the same time
This headphone can support 2 devices multi-connection.
It can pair with two mobile phones simultaneously,talking
the call from any of them.After completing pairing with the
first phone, turns off the first phone and the headphone
in sequence,then re-do the pairing procedure with another
phone. Once finished the pairing,restart the first phone and
found the headphone”BT-576” in the bluetooth list to connect
it, then two phones can use with this headphone at the
same time.
10
1.You must charge the headphone by our matched MicroUSB
charger cable, if you use any other charger to cause any
issue,
you have to take responsibility by yourself.
Warning：
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
NOTE: This device and its antenna(s) must not be co-located or operation in
conjunction with any other antenna or transmitter.
