Wistron NeWeb CCOBD2S GPS Tracker User Manual
Wistron NeWeb Corporation GPS Tracker Users Manual
Users Manual
Car Connection OBDII
User Manual
1 Car Connection OBDII User Manual
Introduction
Car Connection OBDII device complies with OBDII standard, which has been
adopted for most vehicles on the road. It integrates multiples applications
such as Usage Based Insurance (UBI), data mining, driver assistance,
roadside assistance, and fleet management that allow you to manage those
features using one device. Users can easily install the Car Connection OBDII
product on their own by simply plugging the device in. Enable your service in
the air with Car Connection OBDII device now!
Key Features
Flexible antenna and housing design
Compact device size meeting OBD Industry requirement
Over-the-Air update capability
Simple plug-in installation
Specifications
Physical
60mm (w) x 48mm (H) x 24mm (D)
Weight: <60g
Operating Voltage
9V ~ 18V (13.5V nominal)
Power Consumption
150mA @ 12V
2 Car Connection OBDII User Manual
Installation
Note! Keep the distance at least 20cm from all persons.
3 Car Connection OBDII User Manual
Federal Communication Commission Interference
Statement
This device (Model Name: UOC-AVX1-S; FCC ID: NKRCCOBD2S) complies
with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
4 Car Connection OBDII User Manual
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
