Wistron NeWeb DAUK-W8812 802.11 a/b/g/n/ac Module User Manual WLAN a b g Cardbus Adapter
Wistron NeWeb Corporation 802.11 a/b/g/n/ac Module WLAN a b g Cardbus Adapter
User Manual
Wireless LAN Module
DAUK-W8812
User Manual
Copyright Statement
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, whether electronic, mechanical, photocopying, recording or otherwise
without the prior writing of the publisher.
Pentium is trademark of Intel.
All copyright reserved.
1
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Country Code selection feature to be disabled for products marketed to the US/CANADA
2
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed
IMPORTANT NOTE
In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no
longer considered valid and the FCC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
ID: NKRDAUK-W8812
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remo
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
3
Industry Canada statement:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC éta
5
DNSA-GP1_G02
RF
378
5
1.32%
D896855109D8
D89685510805
D896855107D9
D896855107E5
D89685510746
8
DNSA-GP1_G02
RF
360
2
0.56%
D89685510A60
D89685510A4A
s pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un
minimum de 20 cm de distance entre la source de rayonnement et votre corps.
4
This device is intended only for OEM integrators under the following conditions: (For
module device use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and
users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions
suivantes: (Pour utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée
entre l'antenne et les utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur
l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours
responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.
5
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the Canada authorization is
no longer considered valid and the IC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines
configurations d'ordinateur portable ou de certaines co-localisation avec un autre
émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne peut
pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé
de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation
distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où
l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue
entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible
avec l'inscription suivante: "Contient des IC: ".
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
6
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur
final quant à la façon d'installer ou de supprimer ce module RF dans le manuel de
l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises
et avertissements comme indiqué dans ce manuel.
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce
the potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and
5470-5725 MHz shall comply with the e.i.r.p. limit; and
(iii) the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall
comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation
as appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary users
(i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these
radars could cause interference and/or damage to LE-LAN devices.
Avertissement:
précises sur les restrictions susmentionnées, notamment :
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement
systèmes de satellites mobiles utilisant les mêmes canaux;
(ii) le gain maxima-5 350
MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
-5 825
MHz) doit se conformer à
non point à point, selon le cas.
(iv) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de
haute puissance sont désignés utilisateurs principaux (c.-à-d
7
les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du
brouillage et/ou des dommages aux dispositifs LAN-EL.
8
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The
following test methods have been applied in order to prove presumption of conformity with the
essential requirements of the R&TTE Directive 1999/5/EC:
- EN60950-1:2006+A11:2009+A1:2010+A12:2011
- IEC60950-1:2005 (2nd Edition); Am 1:2009
Safety of Information Technology Equipment
- EN 62311: 2008 / Article 3(1)(a) and Article 2 2006/95/EC)
- Assessment of electronic and electrical equipment related to human exposure restrictions for
electromagnetic fields (0 Hz-300 GHz)
- EN 300 328 V1.8.1: 2012-06
- Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission
systems; Data transmission equipment operating using wide band modulation techniques;
Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive
-
- EN 301 893 V1.7.1: 2012-06
- Broadband Radio Access Networks (BRAN); 5 GHz high performance RLAN; Harmonized EN
covering the essential requirements of article 3.2 of the R&TTE Directive
-
- EN 301 489-1 V1.9.2: 2011
- Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic
Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical
requirements
-
- EN 301 489-17 V2.2.1 2012
- Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC)
standard for radio equipment; Part 17: Specific conditions for Broadband Data Transmission Systems
-
In Italy the end-user should apply for a license at the national spectrum authorities in order to
obtain authorization to use the device for setting up outdoor radio links and/or for supplying public
access to telecommunications and/or network services.
9
[Czech]
[Jméno výrobce] [typ zařízení]
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [udstyrets
typebetegnelse] overholder de væsentlige krav og øvrige relevante krav i direktiv
1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp = type
of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
English
Hereby, [name of manufacturer], declares that this [type of equipment] is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de equipo]
cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
[Greek]
[name of manufacturer] [type of equipment]
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme
aux exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è
conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Latviski
[Latvian]
[name of manufacturer / izgatavotāja nosaukums] [type of equipment
/ iekārtas tips]
[Lithuanian]
[manufacturer name] s [equipment type] atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederland
s [Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van
richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma
mal--Dirrettiva
1999/5/EC.
10
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] [nazwa wyrobu] jest zgodny z
1999/5/EC.
Português
[Portuguese]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme com os
requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in
i direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] [typ zariadenia]
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
12
1. Introduction
Thank you for purchasing the 802.11 a/b/g/n /ac module that provides the easiest way to wireless
networking. This User Manual contains detailed instructions in the operation of this product.
Please keep this manual for future reference.
2. Driver/Utility Installation
The driver should have been installed before the TV is shipped from the manufacturer. You can
start using its network function without installing driver or utility.
This module is associated product for TV host.
The following description provides a basic installation for wireless module.
For more information about the Wireless Module, please refer to your TV manual.
Installing Wi-Fi module :
1. Link cable with USB connector on wireless module
2. Link wireless module with USB connector to PC and install software in wireless module
3. Open the back lid of TV, lock wireless module on internal main board of TV
4. Power supply on internal main-board and allow TV to load fully.
3. Technical spec.
Item
Key specifications
Main
chipset
RTL
Compliance
Support 801.11a/b/g/n/ac data rate
Frequency
range
USA: 2.400 ~ 2.483GHz, 5.15 ~ 5.35GHz, 5.47 ~ 5.725GHz, 5.725 ~ 5.85GHz
Europe: 2.400 ~ 2.483GHz, 5.15 ~ 5.35GHz, 5.47 ~ 5.725GHz
Japan: 2.400 ~ 2.497GHz, 5.15 ~ 5.35GHz, 5.47 ~ 5.725GHz
China: 2.400 ~ 2.483GHz, 5.725 ~5.85GHz
Transmit
center
frequency
tolerance
Transmitted center frequency tolerance within ±20 ppm.
13
Modulation
technique
802.11 Legacy a/b/g/ac
DSSS (DBPSK, DQPSK, CCK)
OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
DSSS (Direct Sequence Spread Spectrum) with
DBPSK (Differential Binary Phase Shift Keying 1Mbps),
DQPSK (Differential Quaternary Phase Shift Keying 2Mbps), and
CCK (Complementary Code Keying 5.5&11Mbps), and
OFDM (Orthogonal Frequency Division Multiplexing with BPSK for 6,9Mbps、 QPSK for
12,18Mbps、 16QAM for 24,36Mbps、 64QAM for 48,54Mbps)
802.11n a/g
OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
Operation
voltage
5V +/- 5%
Power
consumption
@25 o C@5V
802.11n (2.4GHz) 802.11n (5GHz)
FTP TX (the worse average current) 400 mA 650 mA
AP scanning, no association with AP 188 mA 188 mA
***The maximum current consumption would be impacted by radiation environment and the
driver mechanism.
14
Output power
(dBm)
802.11a
Test Frequencies 6-24_Target 36_Target 48_Target 54_Target
5180 14 14 14 14
5320 14 14 14 14
5500 14 14 14 14
5600 14 14 14 14
5700 14 14 14 14
5825 14 14 14 14
802.11b
Test Frequencies 1/2_Target 5.5_Target 11_Target
2412 17 17 17
2472 17 17 17
2484 17 17 17
802.11g
Test Frequencies 6-24_Target 36_Target 48_Target 54_Target
2412 15 15 15 15
2437 15 15 15 15
2472 15 15 15 15
802.11n
Freq. Range: HT20
Test Freq MCS 0/8 MCS 1/9 MCS 2/10 MCS 3/11 MCS 4/12 MCS 5/13 MCS 6/14 MCS 7/15
5180 13 13 13 13 13 13 13 13
5240 13 13 13 13 13 13 13 13
5320 13 13 13 13 13 13 13 13
5500 13 13 13 13 13 13 13 13
5700 13 13 13 13 13 13 13 13
5745 13 13 13 13 13 13 13 13
5825 13 13 13 13 13 13 13 13
Freq. Range: HT40
Test Freq MCS 0/8 MCS 1/9 MCS 2/10 MCS 3/11 MCS 4/12 MCS 5/13 MCS 6/14 MCS 7/15
5190 13 13 13 13 13 13 13 13
5230 13 13 13 13 13 13 13 13
5270 13 13 13 13 13 13 13 13
15
5510 13 13 13 13 13 13 13 13
5670 13 13 13 13 13 13 13 13
5755 13 13 13 13 13 13 13 13
5795 13 13 13 13 13 13 13 13
Freq. Range: HT20
Test Freq MCS 0/8 MCS 1/9 MCS 2/10 MCS 3/11 MCS 4/12 MCS 5/13 MCS 6/14 MCS 7/15
2412 15 15 15 15 15 15 15 15
2437 15 15 15 15 15 15 15 15
2472 15 15 15 15 15 15 15 15
Freq. Range: HT40
Test Freq MCS 0/8 MCS 1/9 MCS 2/10 MCS 3/11 MCS 4/12 MCS 5/13 MCS 6/14 MCS 7/15
2412 15 15 15 15 15 15 15 15
2437 15 15 15 15 15 15 15 15
2472 15 15 15 15 15 15 15 15
802.11ac (Typical)
Freq. Range: 5GHz/VHT80:
Test Freq MCS 0 MCS 1 MCS 2 MCS 3 MCS 4 MCS 5 MCS 6 MCS 7 MCS 8 MCS 9
5210 10 10 10 10 10 10 10 10 10 10
5530 10 10 10 10 10 10 10 10 10 10
5775 10 10 10 10 10 10 10 10 10 10
16
Sensitivity
802.11a
Modulation Code Rate IEEE Spec (1Rx dBm) Typical(1Rx
dBm)
BPSK 1/2 -82 -90
BPSK 3/4 -81 -89
QPSK 1/2 -79 -88
QPSK 3/4 -77 -86
16-QAM 1/2 -74 -83
16-QAM 3/4 -70 -80
64-QAM 2/3 -66 -76
64-QAM 3/4 -65 -74
802.11b
Modulation EEE Spec (1Rx dBm) Typical/Maximum (1Rx dBm)
DBPSK not specified -95
DQPSK not specified -92
CCK not specified -90
802.11g
Modulation Code Rate IEEE Spec (1Rx dBm) Typical/Maximum (1Rx dBm)
BPSK 1/2 -82 -89
BPSK 3/4 -81 -89
QPSK 1/2 -79 -87
QPSK 3/4 -77 -85
16-QAM 1/2 -74 -82
16-QAM 3/4 -70 -79
64-QAM 2/3 -66 -75
64-QAM 3/4 -65 -73
802.11ng
Modulation Code Rate IEEE Spec (1Rx dBm) Typical/Maximum (2Rx dBm)
HT20
(MCS0) BPSK 1/2 -82 -90
(MCS1) QPSK 1/2 -79 -86
(MCS2) QPSK 3/4 -77 -84
(MCS3) 16-QAM 1/2 -74 -81
(MCS4) 16-QAM 3/4 -70 -78
(MCS5) 64-QAM 2/3 -66 -73
(MCS6) 64-QAM 3/4 -65 -72
(MCS7) 64-QAM 5/6 -64 -70
17
HT40
(MCS0) BPSK 1/2 -79 -87
(MCS1) QPSK 1/2 -76 -84
(MCS2) QPSK 3/4 -74 -82
(MCS3) 16-QAM 1/2 -71 -79
(MCS4) 16-QAM 3/4 -67 -76
(MCS5) 64-QAM 2/3 -63 -72
(MCS6) 64-QAM 3/4 -62 -69
(MCS7) 64-QAM 5/6 -61 -68
802.11na
Modulation Code Rate IEEE Spec (1Rx dBm) Typical/Maximum (2Rx dBm)
HT20
(MCS0) BPSK 1/2 -82 -90
(MCS1) QPSK 1/2 -79 -88
(MCS2) QPSK 3/4 -77 -86
(MCS3) 16-QAM 1/2 -74 -83
(MCS4) 16-QAM 3/4 -70 -79
(MCS5) 64-QAM 2/3 -66 -75
(MCS6) 64-QAM 3/4 -65 -74
(MCS7) 64-QAM 5/6 -64 -70
HT40
(MCS0) BPSK 1/2 -79 -88
(MCS1) QPSK 1/2 -76 -85
(MCS2) QPSK 3/4 -74 -82
(MCS3) 16-QAM 1/2 -71 -79
(MCS4) 16-QAM 3/4 -67 -76
(MCS5) 64-QAM 2/3 -63 -72
(MCS6) 64-QAM 3/4 -62 -70
(MCS7) 64-QAM 5/6 -61 -68
802.11ac
Modulation Code Rate IEEE Spec (1Rx dBm) Typical/Maximum (1Rx dBm)
VHT80
(MCS0) BPSK 1/2 -76 -85
(MCS1) QPSK 1/2 -73 -82
(MCS2) QPSK 3/4 -71 -80
18
(MCS3) 16-QAM 1/2 -68 -77
(MCS4) 16-QAM 3/4 -64 -73
(MCS5) 64-QAM 2/3 -60 -69
(MCS6) 64-QAM 3/4 -59 -67
(MCS7) 64-QAM 5/6 -58 -65
(MCS8) 256-QAM 3/4 -53 -61
(MCS9) 256-QAM 5/6 -51 -58
Operation
temperature
0o ~ 60o C
Storage
temperature
-20o ~ 80o C
Antenna Information:
Peak gain ( dBi )
Model
Type
Connector
2400~2483.5MHz
5150~5250MHz
5250~5350MHz
5470~5725MHz
5725~5850MHz
81.EEW15.GFV
PIFA
U.FL
-3.77
-4
-3.5
-3.56
-4.31
