1
Memory Stick Wireless LAN Card
User’s Manual
HNT-MSW1
2
Table of Contents
１． Software Terms of Use ……………………………………………………………………
２． Precautions for Use ………………………………………………………………………
３． About this Device………………………………………………………………
４． Uses of This Product…………………………………………………………………………
５． Nomenclature ………………………………………………………………………………
６． Installing the Software ………………………………………………………………………
７． Communicating via a Wireless LAN Access Point
(Infrastructure mode) ………………………………………………………………………
Setup …………………………………………………………………………………
Setting Details ………………………………………………………………………
Connecting to a Wireless LAN ……………………………………………………
８． Direct Communication between Compatible Devices
(Ad hoc mode) ……………………………………………………………………………
Setup …………………………………………………………………………………
Connecting to a Corresponding Device …………………………………………
９． Enabling Network HotSync via Wireless LAN ……………………………………………
１０． Method of Misusing Utilities …………………………………………………………
１１． Troubleshooting ………………………………………………………………………
１０． Specifications ……………………………………………………………………………
１１． Support …………………………………………………………………………………
3
Software Terms of Use
Be sure to read this manual before using the software bundled with this product.
Thank you very much for purchasing our product.
Our company has specified the following "Software Terms of Use" for the software bundled with
this product.
Please read these Terms of Use carefully before using the software. Opening the
bundled software package indicates your acknowledgment of and agreement to
these Terms of Use.
These Terms of Use additionally serve as a certificate affirming the customer’s rights to use this
software. A customer who is not in possession of these Terms of Use may be treated as if not
having the rights of use of this software. Please deal with these Terms of Use as your important
property.
Hagiwara Sys-Com Co., Inc. (hereafter "Our Company") licenses rights of use in Japan for the
bundled computer program (hereafter “Licensed Program”) accompanying the product
purchased by the Customer, based on the following terms. Customers shall abide by the
following terms.
1. Duration
（１） These Terms of Use shall take effect on the day when the Customer receives this
product.
（２） The Customer can terminate the rights of use of this Licensed Program based on
these Terms of Use by providing Our Company with notice in writing at least one
month in advance.
（３） Our company can terminate the rights of use of the Licensed Program when a
Customer violates any of these Terms of Use.
（４） The Terms of Use of the Licensed Program will remain in effect until it is terminated
To Our Customers
Software Terms of Use
4
based on the definition contained in the Terms of Use.
（５） When the rights of use of the Licensed Program are terminated, the Customer’s other
rights based on these Terms of Use shall also be ended simultaneously. After
termination of the rights of use of the Licensed Program, the Customer shall
immediately destroy the Licensed Program and all duplicates.
2. Copyright License
（１） Customers can duplicate the Licensed Program and use it only in the computer
(hereafter “Host Computer”) that is connected to this product.
（２） Customers can use the Licensed Program only in Japan or other countries within the
restrictions of use of the Radio Law.
3. Copyright Notice, Duplication, etc.
（１） Customers may make one duplicate of the Licensed Program only for the purposes of
backup in the case of failure or damage.
（２） Customers shall affix a copyright notice and other rights notices of the Licensed
Program on the duplicate of the licensed program.
（３） Customers must not use, duplicate, modify, combine, etc, the Licensed Program
except in the cases specified in these Terms of Use.
（４） These Terms of Use do not license the Customer to duplicate the reference materials
such as the user manual, etc, accompanying this Licensed Program.
4. Transfer of Rights, etc.
Customers may not license the use of the Licensed Program to a third party by
renting, leasing or any other means. However, a customer can transfer the rights of
use of the Licensed Program to a third party on the condition that the third party
agrees to comply with these Terms of Use. In this case, this product, the Licensed
Program and all related reference materials that a customer possesses shall be
handed over to the third party.
5. Decompiling, etc.
A customer may not reverse engineer, decompile, disassemble, or perform any similar
operations on the software.
6. Limited Warranty
（１） Our Company shall make no warranty at any time regarding the Licensed Program.
5
Any problems occurring related to the Licensed Program shall be disposed of at the
Customer’s responsibility and expense.
（２） In the case that there is a physical defect in the storage medium of the Licensed
Program that disrupts use of the licensed program, the customer can return the
Licensed Program to Our Company with the bill of sale (or a copy thereof), within 14
days of the purchase date, and Our Company shall exchange the product concerned
at no charge. This is the only warranty concerning this product and shall only be
offered in the case that Our Company accepts responsibility for the defect.
7. Limited Responsibility
In all cases, when Our Company is liable for damages arising from a Customer’s lost
profits or other special circumstances (including the case that Our Company foresees
or could have foreseen the occurrence of damages) or the Customer’s damages
caused by a third party, our company’s liability for the damages shall be limited to an
amount equivalent to the price of this product actually paid by the Customer.
8. Other
This license agreement shall be controlled by and interpreted under Japanese Law.
Even in the event that certain terms in this license agreement are judged to be invalid
by a court of law, the remaining terms shall remain in effect.
6
Warnings
○ Do not use this device when you are walking or driving a car, etc, as this may lead to an
accident.
○ Remain aware of the environment around you when using this device.
○ Do not use this device on an airplane, as the device may interfere with safe operation of the
aircraft.
○ Do not use this device around precision instruments, because there is a possibility that a
malfunction will occur.
○ Do not use this device in a zone where radio equipment is in use.
○ It may be unlawful to use this device when traveling abroad, since regulations regarding radio
usage differ from country to country.
Precautions for Use
This product is a precision device; please take note of the following precautions.
Use of this device near electronic equipment for medical use
Warnings Neglecting these warnings and using the device improperly may result in
accident, fire or injury.
Cautions Neglecting these cautions and using the device improperly may result in
damage to the device or personal injury.
Warnings
○ If you use an implantable cardiac pacemaker or an implantable cardioverter defibrillator, please
keep a safe distance between this product and the pacemaker before use.
○ Refrain from using this product in crowded places, such as a rush-hour train, etc, as there is a
possibility that a person using an implantable cardiac pacemaker or an implantable cardioverte
r
defibrillator may be near you.
○ Please observe the following guidelines when inside a medical facility.
・ Refrain from using this device in a hospital.
・ Do not use this device in an operating room, an intensive care unit (ICU) or a coronar
y
care unit (CCU).
・ Medical facilities may set up regulations such as “prohibitions of use”, “prohibited areas”,
etc, please follow the directions of each medical facility.
7
Cautions
○ This device is exclusively for the SONY personal entertainment organizer Palm OS5 (later than
Ver.5.0).
Malfunction will result from using it with other devices.
○ Do not disassemble or alter this product.
○ Do not subject it to a strong shock or impact.
○ If the unit becomes dirty, wipe it with a soft, dry cloth. Under no circumstances should you use
an organic solvent, such as benzene.
○ Refrain from using the device when your hands are dirty.
○ Securely attach all connectors.
Do not under any circumstances insert a piece of metal into the inside of the connector. Two o
r
more pins may short-circuit, resulting in damage to the device.
○ Do not leave the unit in the following types of environments for an extended period.
・ An area exposed to direct sunlight
・ A very moist place, such as a bathroom, etc.
・ A very hot place, such as close to a fire, etc.
・ In the vicinity of chemical agents, such as an organic solvents, etc.
・ Very dusty or smoky places.
8
About this Device
This product has received a certificate of conformance to technical standards, based on the
Radio Law, as radio equipment in a radio station of the power-saving communications system.
Therefore, when using this product, it is not necessary to obtain a radio station license.
Moreover, as described below, this product has also received the technical standard
authorization based on the Telecommunications Business Law.
Certified device name: HNT-MSW1
Accordingly, if you engage in any of the following activities you may be subject to prosecution
under the law.
・Disassembling or altering this product
・Covering over the authorization identification number on the back of the product or removing
the seal on which the identification number is inscribed.
Notes on Frequency Band Used
Although this device can use 2.412GHz ~ 2.462GHz in 2.4GHz band, in order to prevent
radio interference with other wireless devices, please consider the following matters when using
the device.
Within the frequency band (2.4GHz band) used by this device, equipment for industry, science
and medical treatment, microwave ovens, licensed in-plant radio stations that identify mobile
units in production lines, etc, low-power wireless stations not requiring a license, amateur radio
stations, etc, (hereafter “other wireless stations”) also operate.
１． Before using this device, please check if there are “other wireless stations" in operation
nearby.
２．If radio interference occurs between this device and “other wireless stations", please
promptly change the device’s location, or discontinue its operation (stop transmitting).
３．In addition, if you are bothered by problems such as radio interference between this device
9
and “other wireless stations", please contact us using the information below.
Contact information FAX 052-223-1328 E-mail : support@hscjpn.co.jp
This wireless device uses 2.4GHz band and uses the DS-SS modulation method. Its
interference distance is 40 m or less.
FCC WARNING
Changes or modifications not expressly approved by the manufacturer for compliance
could void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses, and can radiate radio frequency energy if not installed
and used in accordance with instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or re-locate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
10
cause undesired operation.
FCC RADIATION EXPOSURE STATEMENT
This transmitter complies with FCC radiation exposure limits set forth for uncontrolled
environment. To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change to the antenna or the device could
result in the device exceeding the RF exposure requirements and void user. In addition,
this transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Uses of This Product
This device is a wireless LAN card exclusively for the SONY personal entertainment organizer
(hereafter CLIE) Palm OS5 (later than Ver.5.0).
Since this device conforms with the IEEE802.11b standard, it is also possible to use it to
connect to the Internet in areas where there are wireless LAN access points.
Wi-Fi has already been authorized.
Getting HotSync
It is possible to use network HotSync between a CLIE and a personal computer (data is
synchronized by radio). For details on HotSync, please refer to the CLIE user manual.
Connecting to the Internet
It is possible to connect a CLIE into which this device is inserted to the Internet via a wireless
LAN access point and to then view Web pages or send and receive E-mail.
11
Cautions
・Connecting to the Internet via a wireless LAN access point also requires a line contract with
a telecommunications carrier and a contract with an Internet service provider (hereafter
provider).
・A personal computer may be required in order to set up a wireless LAN. For details, please
refer to the wireless LAN access point user manual.
PC System Requirements
Personal computer with processor running Microsoft Windows 98 Second Edition, Windows
Millennium Edition, Windows 200 Professional, Windows XP Home Edition operating system.
12
Names of Parts
Wireless LAN Card
Front
Back
Other items included
CD-ROM Warranty Card
User Manual (This Book) Software Licensing Agreement
LINK LED
This LED blinks when initialization of the card
is taking place or when connecting to the
network. When connection to the network is
completed, this LED remains lit.
MAC Address
Wireless LAN network administrators
may use this.
13
Inserting/Removing the Device
Inserting into a CLIE
Inserting this device into a CLIE memory stick slot
Cautions
Please insert this device straight into the CLIE memory stick slot.
Make sure this device is not in a reversed position when inserting it in a memory stick slot.
Do not excessive force, as this may cause damage resulting in malfunction.
This device may not be usable when the CLIE battery power is low. The battery should be
fully charged before use.
If the CLIE fails to recognize this device, please reinsert it.
Removing this device from a CLIE
When you finish using this device, end the communication function. Press the device
straight down once and then remove it by drawing it out.＊Please be careful, as drawing
it out without following these steps may result in damage to the device.
Caution
Do not remove this device or subject it to impact or other shock during communication.
Insert it firmly to
the end.
＊The position of the memory stick slot ma
y
differ depending on the model of CLIE.
＊In some cases, rotating the screen when
a memory stick is inserted may cause
damage to this device, depending on the
model of CLIE.
14
Troubleshooting
Problem This device is not recognized by the CLIE (the LED doesn’t blink when the
connection is established).
→Please check whether the card information is displayed with the MS WLAN Utility
application which is installed in to the CLIE. If the card information is not
displayed, please follow the instructions below.
・ Take the device out of the CLIE and then reinsert it.
・ There is a possibility that the Wireless LAN configuration utility for Memory stick
Wireless LAN may not be installed. Please install a Wireless LAN configuration
utility from the CD-ROM bundled with the device. Please refer to "Installing the
Software" (page ) for details about the installation method.
Problem Cannot establish connection to a wireless LAN access point.
Power to the wireless LAN access point is not on.
→Please turn on the power to the wireless LAN access point.
A service other than [MS Wireless LAN] is selected under [Network] in [Configuration].
→Select [MS Wireless LAN] from the available services.
The profile setting contents are not correct.
→Check the settings of SSID, WEP key, etc, and re-check the wireless LAN access
point settings.
An object that interrupts electric waves such as a metal plate, concrete, water, etc, is
located between the CLIE and the wireless LAN access point.
→Change the position of the CLIE or the wireless LAN access point.
→Disable the power-saving mode. Refer to "Advanced settings" (page ) for details.
The wireless LAN access point channel is set to other than 1 - 11.
→Change the wireless LAN access point settings.
A device such as a microwave oven, Bluetooth, etc, that is using the 2.4GHz band
frequency is in use nearby.
→Stop the use of these devices. If this is not possible, increasing their distance from the
CLIE may remedy the problem.
15
Problem Forgotten WEP (encryption) key.
→Set a new key according to the instructions in the wireless LAN access point user
manual.
Connection to the internet is not possible.
A wireless LAN access point is not connected to the network.
→The wireless LAN access point settings may be incorrect. Please set it up again
according to the instructions in the wireless LAN access point user manual.
When security such as a firewall is enabled, connection to the Internet may not be
possible.
→Check with the network administrator about the contents of these settings.
Problem E-mail cannot be sent or received.
→Check the settings of the E-mail software. For details about the E-mail software
settings, please refer to the E-mail software user manual.
Problem Web sites cannot be viewed.
→Check the settings of the web browser.
→For details about the web browser settings, please refer to the web browser user
manual.
Problem Data transmission speed is slow.
Interference with other wireless LAN access points.
→Change the channel number of the wireless LAN access point. For details about the
changing the settings, please refer to the wireless LAN access point user manual.
The wireless LAN access point connection is busy.
→Avoid connecting during peak usage hours.
An object that interrupts electric waves such as a metal plate, concrete, water, etc, is
located between the CLIE and the wireless LAN access point.
→Change the position of the CLIE or the wireless LAN access point.
→Disable the power-saving mode. Refer to "Advanced settings" (page ) for details.
Problem Network HotSync is not available.
→Check the HotSync settings.
Refer to "Enabling Network HotSync via Wireless LAN" (page ) for details about
HotSync settings.
Or refer to the CLIE main unit user manual.
If the personal computer firewall function is enabled, HotSync may not be available.
16
Other Instructions for Use
Safe storage
・Be sure to remove this device from the CLIE when it is not in use.
・If the CLIE is carried in a bag, etc, while this device is inserted, there is a possibility that
either the device or the memory stick slot of the CLIE may be damaged.
Places You Should Avoid Leaving the Device
This device must not be used or stored in any of the following types of environments.
Doing so will result in damage.
・Areas of extremely high temperature.
If this device is left in an area that is heated by strong sunlight, or in sun-heated cars, etc,
there is a possibility of the unit becoming deformed or otherwise damaged.
・Areas exposed to direct sunlight, near space heaters
There is a possibility of the unit becoming deformed or otherwise damaged.
・Areas where there is a lot of sand and dust, such as around sandy soil, the beach, etc.
Prevent sand from covering over the device at the beach, and other sandy areas, as this
may cause irreparable damage to the unit.
Handling the Unit
・Do not place anything on this device.
・Avoid sudden changes in temperature. Do not move the device from a cold place to a
hot/warm place, or use it immediately after raising the room temperature, as
condensation may occur inside the unit. Please wait a while before using it in such
conditions.
Handling the Disk
Please observe the following guidelines in order to protect the data on the disk.
・Do not adhere paper, etc, to the disk or otherwise damage it.
・When you hold the disk, do not touch the side that is not written on (playing side).
・Do not store the disk in a dusty area, an area exposed to direct sunlight, near a space
heater or an area exposed to moisture.
・Do not spill liquid on the disk.
・In order to protect important data, put the disk into a case, etc, and keep it somewhere
safe.
17
Cleaning
Cleaning the Device
Use a soft cloth to clean the device if it becomes dirty. For stubborn stains, wipe it with a
cloth moistened with a dilute neutral detergent solution. Do not use thinner, benzene or
alcohol they will damage the surface finish.
Cleaning the Disk
・Fingerprints or dust on the disk cause read errors. Please keep it clean.
・For regular maintenance, wipe the disk lightly with a soft cloth from the center of the disk
toward the outside.
Specifications
Power Supply Power is supplied from the CLIE main unit.
Power Consumption When transmitting:
Maximum Outside Dimensions W35mm x L75.85 mm x T 5.5 mm
Weight 9 g
Longest communication distance Indoor: 30 m Outdoor: 100 m
Compliance Standard IEEE 802.11b
Frequency Band 2.4 GHz band (1-11 channels, ISM band)
WEP （Data Encryption） 40 / 64 bits
104 / 128 bits
Modulation Method DS-SS （IEEE 802.11b Compliant）
Operating Temperatures 0 ~ 40℃ （condensation must be avoided）
Performance of this device may vary depending on obstacles between communication devices,
electromagnetic wave conditions, magnetic fields around microwave ovens, static electricity,
electromagnetic interference, the software in use, the OS, receiving sensitivity of communication
devices, antenna performance, etc.
Please note that the specifications and the appearance of the device are subject to change
without notice, due to improvements in design, etc.
18
Support
Inquiries regarding this product
Please use the contact information below for inquiries about this product.
＊
Hagiwara Sys-Com Co. Inc.
2-4-3 Nishiki, Naka-ku, Nagoya, Aichi 460-0003 Japan
About Repair
If a malfunction occurs, please refer to the user manual and check whether the settings and
connection are properly configured. If you still cannot get the device to work properly, send the
device to the following address, along with a note explaining the specific problem, connection
environment, the model of CLIE you are using, your return address, etc, and the product
warranty (or bill of sale).
＊ Address
＜Cautions＞
When shipping the device, please use a package delivery service that offers delivery
confirmation, etc. Please refrain from sending it via regular mail. In addition, the customer must
pre-pay all shipping charges. Our company shall accept no responsibility for loss or accidents in
transit. Completion of repairs usually requires about 7 days after receiving the product.
Exclusions
Our company shall accept no responsibility for damage occurring as the result of operating the
Hagiwara Sys-Com Support Center
Toll-free number: 0120-307-456 FAX:052-223-1328
Hours：Monday-Friday 10-12 am/1–5 pm (excluding Saturday, Sunday, Holidays and other days when our
company is closed)
URL: http://wwwhscjpn.co.jp/ E-mail address: support@hscjpn.co.jp
If the support line is busy, please wait for a while and try again.
E-mail and FAX can be received 24 hours a day.
Hagiwara Sys-Com Support Center
2-4-3 Nishiki, Naka-ku, Nagoya, Aichi 460-0003 Japan
0120−307−456
19
device in a manner not in accordance with the user manual.
Our company shall accept no responsibility for incidental damage resulting from loss or
alteration of memory contents, disruption of operation while using this device or unavailability of
use.
Our company shall accept no responsibility for any damage occurring under abnormal usage
conditions, including natural disasters, such as fire, earthquake, wind and flood, or damages
arising from the actions of a third party, other accidents, customer’s deliberate or intentional
negligence, etc.
Our company shall accept no responsibility for any damage resulting from a malfunction that is
caused by using this device with hardware or software manufactured by another, unrelated
company.
