Wistron NeWeb S705 Bluetooth Module User Manual DBUB S705 BT Module Manual for type approval
Wistron NeWeb Corporation Bluetooth Module DBUB S705 BT Module Manual for type approval
User Manual
DBUB-S705
Bluetooth Module
User’s Manual
This document provides safety instructions and describes the specifications. Read
this document carefully before installing to ensure your safety and product
performance.
Federal Communication Commission (FCC)
Interference Statement
This device complies with Part 15B and 15C of FCC Rules and RSS-210 of IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation of this device.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
Radiation Exposure Statement:Radiation Exposure Statement:
Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in this
manual. The further RF exposure reduction can be achieved if the product can be kept
as far as possible from the user body or set the device to lower output power if such
function is available.
Industry Canada statement:
Industry Canada statement:Industry Canada statement:
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions
suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce
dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
Radiation Exposure Statement:Radiation Exposure Statement:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Déclarati
DéclaratiDéclarati
Déclaration d
on don d
on d'
''
'exposition aux radiations:
exposition aux radiations:exposition aux radiations:
exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec
un minimum de 20
cm de distance entre la source de rayonnement et votre corps.
Taiwan
TaiwanTaiwan
Taiwan
statement
statementstatement
statement:
::
:
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、
加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停
用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
Caution:
Be aware of the following limits before using the Bluetooth Module .
Do not subject the Bluetooth Module to high temperatures, direct sunlight or
moisture.
Do not bend, or subject the Bluetooth Module to strong impacts.
Do not disassemble or alter the Bluetooth Module in any way.
Do not attempt to install the Bluetooth Module in any incompatible device.
Do not remove the Bluetooth Module from the TV’s during operations.
Data transmitted and received over radio waves may be intercepted and
monitored.
To avoid malfunctions caused by radio wave interface, keep the TV away from the
devices such as other wireless devices, microwaves and the devices that use 2.4
GHz signals when using the Bluetooth Module.
Depending on the area, this Bluetooth Module may not be available.
Setup the Bluetooth connection
The Bluetooth Module is pre-installed in the TV set. No extra installation steps are
required for users. Follow the steps below to start using the feature of this
adapter:
1. Turn on your TV.
2. Switch to the channel that delivers 3D contents. If you are watching a disc with
3D contents, you will also need to activate your player for playing the disc.
3. Turn on your 3D glasses.
4. The 3D glasses will pair with this Bluetooth Module automatically and are now
ready for use.
Specification
Power supply DC 3.3V 38.5mA
Antenna Tx 1, Rx 1
Host Interface USB 2.0 + GPIO x1
Standard Compliance Bluetooth 3.0
Frequency Range 2.4 GHz (2.40GHz-2.4835GHz)
Modulation
・GFSK
・Pi/4 QPSK
・8DPSK
Receiver Sensitivity
-88 dBm(typ.) GFSK, 0.1%BER
-85 dBm(typ.) for pi/4-DQPSK, 0.01%BER
Transfer rate (standard)
* 3.0Mbps(MAX, Theoretical Value)
Output Power Class 2,
0dBm typical, class 2 device (-6dBm < output power
<4dBm).
Antenna Type and Gain
Metal Antenna with Peak Gain at 4.34dBi
Security BT E0/AES/SAFER+
* Transfer rate are theoretical values; however, actual communication rate will
vary according to communication environment or connected equipment.
Specifications
SpecificationsSpecifications
Specifications
