Owner’s Record
The model and serial numbers are located at the side of
the unit. Record the serial number in the space provided
below. Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No. NSZ-GU1
Serial No.______________
Batteries or batteries installed apparatus shall not be
exposed to excessive heat such as sunshine, fire or the
like.
Precautions
The nameplate is located on the side of the player.
FCC WARNING
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
The shielded Interface cable (LAN cable) must be used
with the equipment in order to comply with the limits for
a digital device pursuant to Subpart B of Part 15 of FCC
Rules.
NOTE
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
WARNING
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
For Internet Player
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines
in Supplement C to OET65. This equipment should be
installed and operated keeping the radiator at least 20 cm
or more away from person’s body (excluding extremities:
hands, wrists, feet and ankles).
For remote control
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines
in Supplement C to OET65. This equipment has very low
levels of RF energy that are deemed to comply without
testing of specific absorption ratio (SAR).
Precautions
On placement
Place the player in a location with adequate
ventilation to prevent heat build-up in the player.
Do not place the player in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust, or mechanical shock.
If the player is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture
may form on the outer surface and on interior of the
player.
Should this occur, the player may not operate
properly. In this case, leave the player turned on for
about half an hour until the moisture evaporates.
Do not place the player in a place where medical
equipment is in use. It may cause a malfunction of
medical instruments.
If you use a pacemaker or other medical device,
consult your physician or the manufacturer of your
medical device before using the wireless LAN
function or the remote control.
On adjusting volume
Do not turn up the volume while listening to a section
with very low level inputs or no audio signals. If you
do, your ears and the speakers may be damaged
when a peak level section is played.
On cleaning
Clean the cabinet, panel, and controls with a soft
cloth. Do not use any type of abrasive pad, scouring
powder or solvent such as alcohol or benzine.
On replacement of parts
In the events that this player is repaired, repaired parts
may be collected for reuse or recycling purposes.
Others
Do not hold the player when moving the TV.
If you have any questions or problems concerning
your player, please consult your nearest Sony dealer.
Reference Guide
Internet Player
NSZ-GU1
4-471-309-11(1)
Printed in China
© 2013 Sony Corporation
Sony Customer Support
http://esupport.sony.com/ | 1-800-222-SONY
Please Call Before Returning the Product to the Store
Specifications
*1Use the supplied Micro USB cable.
*2Bluetooth profiles are standardized according to the purpose of the Bluetooth device.
*3Alkaline batteries. Do not use manganese or lithium batteries when replacing old batteries.
Additional Information
About wireless LAN security
Since communication via the wireless LAN
function is established by radio waves, the
wireless signal may be susceptible to interception.
To protect wireless communication, this player
supports various security functions. Be sure to
correctly configure the security settings in
accordance with your network environment.
•No Security
Although you can easily make settings, anyone
can intercept wireless communication or intrude
into your wireless network, even without any
sophisticated tools. Keep in mind that there is a
risk of unauthorized access or interception of data.
•WEP
WEP applies security to communications to
prevent outsiders from intercepting
communications or intruding into your wireless
network. WEP is a legacy security technology that
enables older devices, which do not support TKIP/
AES, to be connected.
• WPA-PSK (TKIP), WPA2-PSK (TKIP)
TKIP is a security technology developed to correct
for the deficiencies of WEP. TKIP assures a higher
security level than WEP.
• WPA-PSK (AES), WPA2-PSK (AES)
AES is a security technology that uses an advanced
security method that is distinct from WEP and TKIP.
AES assures a higher security level than WEP or
TKIP.
Input/Output jacks
MHL OUT HDMI 19-pin standard connector
MHL version: MHL 2
Video: 720/60p
Audio: Linear PCM, Dolby Digital, Dolby Digital Plus
HDMI IN HDMI 19-pin micro connector
Video: 480p, 720/60p
Audio: Linear PCM, Dolby Digital
USB USB jack (For power supply from BRAVIA)*1
IR Blaster 2.5 mm jack (For connecting the IR Blaster cable)
Power and others
Power requirements 5 V DC supplied from the MHL connector and the Micro USB connector
Dimensions (approx.) 109 mm × 42 mm × 22.5 mm (4 3⁄8 in. × 1 11⁄16 in. × 29⁄32 in.)
(length/width/height) incl. projecting parts
Mass (approx.) 0.07 kg (2.5 oz)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 25% to 80%
Wireless LAN
Wireless LAN standard IEEE 802.11b/g/n
Frequency range 2.4 GHz band: Channels 1-11
Modulation DS-SS Modem and OFDM Modem
Bluetooth
Communication system Bluetooth Specification version 3.0
Frequency range 2.4 GHz band: 79 channels with 1 MHz BW
Modulation FHSS
Compatible Bluetooth profiles*2HID (Human Interface Device Profile), SPP (Serial Port Profile)
Accessories
Supplied accessories Remote control NSG-MR9U (1)/Size AA batteries*3 (2)/Micro HDMI cable (1)/
Micro USB cable (1)/IR Blaster cable (1)/
Quick Start Guide, Reference Guide and Warranty card
Trademark Information
• MPEG Layer-3 audio coding technology and patents
licensed from Fraunhofer IIS and Thomson.
• The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries/regions.
• MHL™, Mobile High-Definition Link and the MHL
Logo are trademarks or registered trademarks of
MHL Licensing, LLC.
• Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
• The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Sony Corporation is under
license.
• WPA™ and WPA2™ are marks of the Wi-Fi Alliance.
• Music and video recognition technology and related
data are provided by Gracenote®. Gracenote is the
industry standard in music recognition technology
and related content delivery. For more information,
please visit www.gracenote.com.
CD, DVD, Blu-ray Disc, and music and video-related
data from Gracenote, Inc., copyright ©
2000-present Gracenote. Gracenote Software,
copyright © 2000-present Gracenote. One or more
patents owned by Gracenote apply to this product
and service. See the Gracenote website for a
nonexhaustive list of applicable Gracenote patents.
Gracenote, CDDB, MusicID, MediaVOCS, the
Gracenote logo and logotype, and the “Powered by
Gracenote” logo are either registered trademarks or
trademarks of Gracenote in the United States and/
or other countries/regions.
• Windows Media is either a registered trademark or
trademark of Microsoft Corporation in the United
States and/or other countries/regions.
This product is protected by certain intellectual
property rights of Microsoft Corporation. Use or
distribution of such technology outside of this
product is prohibited without a license from
Microsoft or an authorized Microsoft subsidiary.
•Contains Flash
®, Flash® Lite® and/or Reader®
technology by Adobe Systems Incorporated. This
Sony Product contains Adobe® Flash® player
software under license from Adobe Systems
Incorporated, Copyright© 1995-2013 Adobe Systems
Incorporated. All rights reserved. Adobe, Flash, Flash
Lite and Reader are either registered trademarks or
trademarks of Adobe Systems Incorporated in the
United States and/or other countries/regions.
• Designed with UEI Technology™
Under License from Universal Electronics Inc.
Portions © UEI 2000 - 2012
• Other system and product names are generally
trademarks or registered trademarks of the
manufacturers. ™ and ® marks are not indicated in
this document.
