36" Gas Rangetops

Wolf gas rangetops offer that professional

look but give you the flexibility to use

ovens in other locations in the kitchen.

Wolf gas rangetops have standard features

such as dual brass surface burners and

our signature large red control knobs.

Optional infrared charbroiler and infrared

griddle give you the freedom to customize

your gas rangetop. Wolf gas rangetops are

available in natural or LP gas.

FEATURES

•Stainless steel exterior finish.

•Optional infrared charbroiler and infrared

griddle configurations.

•Distinctive red control knobs with chrome

bezels—black knobs optional.

•Dual brass burners with automatic

reignition at all settings.

•Porcelain-coated cast iron grates.

•Stainless steel drip tray. ACCESSORIES

•101/2" stainless steel riser.

•Black control knobs.

•2 or 3 piece trim.

•Porcelain-coated cast iron wok grate.

•Porcelain-coated cast iron S-grates.

•Hardwood cutting board

(griddle model only).

•Griddle cleaning kit.

Accessories are available through your authorized

Wolf dealer. For local dealer information, visit the

find a showroom section of our website,

wolfappliance.com.

Model RT366

Model RT364C

Model RT364G

FEATURES

Model RT366 RT364C RT364G

Surface Burners

16,000 Btu high / 500 Btu simmer 644

Infrared Charbroiler – 16,000 Btu •

Infrared Griddle – 18,000 Btu •

Model numbers are for natural gas rangetops, add (-LP) to the model number for LP gas.

This appliance is certified by Star-K

to meet strict religious regulations in

conjunction with specific instructions

found on www.star-k.org.

Model RT364G shown.

Dual brass burner.Infrared griddle.

36" (914)

20" (508)

101/2"

RISER

24" (610)

271/4"(692)

23/4"(70)

101/2"(267)

TO COOKING

SURFACE

91/2"

(241)

2"

(51)

INSTALLATION NOTES

•A 101/2" riser is required for installations

against a combustible surface.

•A Wolf pro wall, chimney, island ventila-

tion hood or hood liner is recommended.

Unit dimensions may vary by ±1/8".

361/4"(921)

OPENING WIDTH

30" (762) TO 36" (914)

TO BOTTOM OF

VENTILATION HOOD**

*Minimum clearance from rough opening to combustible materials up to 18" (457) above countertop.

**36" (914) minimum clearance, 44" (1118) for charbroiler, from countertop to combustible materials without ventilation hood.

NOTE: For island installations, 12" (305) minimum clearance from back of rangetop to combustible rear wall above countertop.

6" (152) TO

COMBUSTIBLE*

6" (152) TO

COMBUSTIBLE*

18" (457) min

36" (914)

FLOOR TO

COUNTERTOP

13" (330)

max

8" (203) 14" ( 356)

PLATFORM

TOP VIEW

EG

8"

(203)

3" (76)

BACKWALL

1/2"

(13)

91/2"(241)

OPENING

HEIGHT

PLATFORM

PLATFORM

GAS AND ELECTRICAL

THROUGH BOTTOM OF

PLATFORM

SPECIFICATIONS

Exterior Finish Stainless Steel

Overall Width 36"

Overall Height

(to cooking surface) 101/2"

Overall Depth 271/4"

Opening Width 361/4"

Opening Height

(to countertop) 91/2"

Opening Depth 24"

Electrical Requirements 110/120 V AC

60 Hz, 15 amp circuit

Shipping Weight 190–220 lbs

INSTALLATION SPECIFICATIONS

OVERALL DIMENSIONS

36" Gas Rangetops

Dimensions in parentheses are in

millimeters unless otherwise specified.

©Wolf Appliance, Inc. all rights reserved. Features and specifications are subject to change at any time without notice. 1/10
