USERS MANUAL
*** USER’S MANUAL ***
FCC ID : SRKWT100CR
The Federal Communication Commission Statement
This equipment has been tested and found to comply with the limits for a Class B Digital Device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction, may
cause harmful interference to radio communication. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of more of the following
measures: -
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced Radio/TV technician for help.
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that change
or modifications not expressly approved by the party responsible for compliance could void your
authority to operate the equipment.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERECE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may cause
undesired operation.
WT100CR operation manual
1, Touch remote controller battery install
Use AA size battery x 2
Note: DO NOT touch the “Touch Area” while placing the battery
2. Functions of Touch PAD
a. move coursor
touch and move touch-pad by finger
b. simulate mouse left button
a short touch (click)on touch pad
c. simulate mouse right button
a long touch(no moving approx. 1 second) on touch pad
3. Auto search RF receiver dongle
press and simultaneously until LED off then release keys ,
when you see blue LEDs keep ON, it means that the WT100CR is looking
for the RF dongle; when you see blue LEDs blinking quickly, it means that
both remote controller and RF dongle had been successfully connected!
Note : if you replace WT100CR battery, you have to reconnect RF dongle.
4. Key operation
mouse Left button
play/Pause in Windows Media Player
fast forward in Windows Media Player
fast backward in Windows Media Player
increase volume
mouse right button
Backspace
task window switching
Press , PC pop all active task iterm, or select
task, press switch to your task window
mute
decrease volume
arrow up
arrow right
arrow down
arrow left
ENTER
full screen in Windows Media Player
5. RF Receive Dongle install
Plugin RF receive dongle to your PC/NoteBook USB port, PC/NoteBook
find a new device and install driver automatically.
