Wonders Technology Co., Ltd. Wireless Portable Bluetooth Speaker DS 1653
User manual
Wireless Portable Bluetooth Speaker
Model No.:Cloud Fox BS1
User Manual
Contents Controls Bluetooth connecon
Using auxiliary input
Trouble shoong
Number
1
2
3
4
5
6
7
8
Icon Funcon
Power
Mode
indicator
AUX IN
DC IN
Charging
indicator
Volume up/
Skip forward
Play/pause /
Hands free
Volume down/
Skip backward
Descripon
Long press to turn on/off the speaker
Paring: Blinking Blue
Paired: Solid Blue
Auxiliary in: Solid Red
Short press to adjust volume down
Long press to skip backward
Short press to play/pause tune
Short press to answer/end an
incoming call
Long press to reject an incoming call
Auxiliary in port
DC 5V IN
Charging: Solid Red
Fully charged: Solid Green
Short press to increase volume
Long press to skip forward
The sound is small
or distorted
Do not play properly,
the music is
intermiently
Check the volume seng on both the speaker
and your Bluetooth device and adjust the
volume to a suitable level.
Check whether the distance between the
speaker and your Bluetooth device is out of
its working distance, or whether there are
some obstacles block the communicaon
between the speaker and the Bluetooth
device.
Symptom
Can not pair
successfully
Possible problem and Soluon
Check whether the speaker is in standby and
searching mode.
Check whether there are too many Bluetooth
receivers around your Bluetooth device.
Turn off them to avoid any disturbance.
And pair again.
1. Turn on the speaker.Speaker enters to Bluetooth mode automacally.
2. Enabled Bluetooth on your device and choose Cloud Fox BS1 from
the list.
3. Paired.
4. Adjust a suitable volume to play music.
Requires a Φ3.5mm audio cable (Included).
1. Connect your audio device to the speaker.
2. Speaker switches to Line in mode automacally.
3. Adjust a suitable volume to play music.
Specificaons
Maintenance
• Model No.: Cloud Fox BS1
• Bluetooth A2DP funcon
• Rechargeable Li-ion baery included
• Baery capacity: 3.7V 500mAh
• Baery life: Up to 12Hrs (Volume at 50%)
• Φ3.5mm Auxiliary port for connecon to other device
• Output power: 3W X 1 (THD=10%)
• Working distance: 10 M
• USB Input: 5V 1A
• To Store
You may leave the unit on display, or you can store it in its box in a cool,
dry place.
• To Clean
Use only a so dry cloth to clean the enclosure of the unit. NEVER use
liquids or abrasive cleaner to clean. Modificaons not authorized by the
manufacturer may void users authority to operate this device.
正反面印刷
SIZE：95 X 148NN
Wireless Portable Bluetooth Speaker
BS1
User Manual
Charging the speaker
Charge 3 hours for up to
12 hours of play me.
AC adaptor not included
Auxiliary cable X 1PCSpeaker X 1PC User Manual X 1PC
Warranty card X 1PC
Contact card X 1PC
Micro USB cable X 1PC
3h
126
7
8
3
4
5
Cauon
• Danger of explosion if baery is incorrectly replaced. Replace only with
the same or equivalent type.
• The apparatus shall not be exposed to dripping or splashing. A warning
that no objects filled with liquids, such as vases, shall be placed on the
apparatus.
• A warning that baeries (baery pack or baeries installed) shall not be
exposed to excessive heat such as sunshine, fire, or the like.
• Baeries do not belong in household waste. As a consumer, you are
required by law to recycle used baeries. You can recycle your old
baeries at public collecon points or wherever the product was sold.
• For environmental reasons, do not dispose of the device in the
household waste at the end of their service life. Dispose of the unit at
a suitable local recycling point.
Warning
To reduce the risk of electric shock, do not remove cover (or back). Refer
servicing to qualified service personnel.
<
Disposal
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
