Wonders Technology CLOUDFOXB7 Wireless Portable Bluetooth Speaker User Manual DS 1622

Wonders Technology Co., Ltd. Wireless Portable Bluetooth Speaker DS 1622

User manual

Wireless Portable Bluetooth Speaker
Mode No.:Cloud Fox BS7
User Manual
I. Introducon
Status indicators
II. Package content
III. Product overview
IV. Preparaon
V. Pairing the wireless speaker with your smart device
VI. Answering and ending a call using your speaker or
mobile phone
6. Power buon: Long press to turn the device on and off.
7. Auxiliary Φ3.5mm jack : Use it for cabled playback with compable
devices.
8. Charging port: Plug the supplied USB cable into this port to recharge
the built-in baery.
9. LED charging indicator.
• Charing : Steady Red.
• Fully charged : Steady Green.
Thank you for purchasing the CLOUD FOX BS7 Wireless Portable Bluetooth
Speaker with Bluetooth and Hands free funcon. We encourage you to
read this installaon guide thoroughly to get the most of this innovave
wireless portable speaker.
• One wireless portable speaker
• USB charging cable
• Φ3.5mm auxiliary cable
• Travel velour bag
• User manual,Warranty card,Contact card
1. Mode switch: Touch to toggle between a Bluetooth and an
Aux-in connecon(Only work when an Aux-in cable is connected to
the speaker.)
2. In Bluetooth mode,touch to skip backward.
3. Play/Pause and handset buon
• In Bluetooth mode,touch to answer or end a call.Touch for 3
seconds to reject a call.
• In Bluetooth mode, touch to play/pause your tune. Touch for 3
seconds to disconnect or reconnect with your device.
4. In Bluetooth mode,touch to skip forward.
5. Volume control:
Clockwise rotaon to increase the volume.
Counterclockwise rotaon to decrease the volume.
Center indicator/
Control buon
Baery status
indicator
Flashing blue
Steady blue
Steady red
Steady green
Indicates that the speaker
has entered into the pairing
mode and it is ready to be
the first me
Indicates that the device is
successfully paired
Steady red
Indicates that the device has
switched to the auxiliary
input mode
Baery is charging
Baery is fully charged
• Use the supplied USB cable to charge your portable speaker directly
from your computer or device with a micro USB port.
Make sure that the speaker is fully charged before using it for the
first me.
• The portable speaker baery has to be inially charged for at least
12 hours. Thereaer, the baery will take from 2 to 3 hours to recharge.
• While charging, the LED glows red. When the baery has reached full
capacity, the LED will change to green.
• To turn on the speaker, press and hold the power buon for several
seconds. Press and hold the power buon once more to turn off
the device.
Note： The speaker will automacally shut down without any audio
input in 15 minutes.
1. Place your smart device and wireless speaker no more than one meter
away from each other.
2. Press the power buon located on the back of the speaker for several
seconds to turn it on.
3. Set your smart device to “discover” the wireless speaker.Upon
powering on, a tone will be heard, the blue LED will start flashing,
accompanied by a prompt nofying that the speaker has entered into
the pairing mode.
4. Enabled Bluetooth on your device and choose Cloud Fox BS7 from
the list.
5. If pairing is successful, the LED will change to steady blue and your
phone will confirm that the connecon has been established. If the
pairing process fails aer 60 seconds, please repeat steps 1 through
5 described above.
1. When there is an incoming call, the speaker will generate a tone and
a verbal noficaon to alert you of this event.
2. Briefly press the Handset buon to pick up, long press to reject.
You may also press the answer buon on your smart phone to take the
call using the speaker.
3. Speak with a clear voice right into the built-in microphone located on
the front secon of the speaker.
4. To end a call, tap the Handset buon once again. Likewise, you
may also end the call directly using the command on your cell phone.
5. When listening to music using your smart phone, playback will resume
automacally once the call has ended.
VII. Product specificaons
Product type: Wireless Portable Bluetooth Speaker with Built-in
Microphone
Output power (RMS): 4W x 2
Driver unit: 1.75 inch X 2
Frequency response: 75Hz-18kHz
Signal to noise rao: ≤ 55dB
Status indicators: pairing, operaon mode
Unit weight: 400 g
Unit dimension: 7.0 x 2.2 x 2.1 inch
Warranty: One-year limited
VIII. Power
X. Warning
IX.Wireless/Networking
• Baery type: Li-ion: 3.7V, 2200mAh
• Input:5V 1A
• Baery charge up me: 3.5 hours approximately.(when fully depleted)
• Baery playback me: up 12 hours.(duraon me may vary depending
on the volume level used and usage paerns)
• Bluetooth specificaon: V4.0+EDR, backwards compable with previous
Bluetooth versions
• Profiles supported
• A2DP (Advanced Audio Distribuon Profile)
• Maximum operaon range: 10 meters / 33 
• Do NOT drop, hit or shake the device.
• Do NOT disassemble, repair or modify the Bluetooth speaker by yourself.
• Do NOT use cleaning products that contain benzene, solvents or alcohol.
• Do NOT expose the Bluetooth speaker to excessive heat or to direct
sunlight for long periods of me.
• Do NOT store the device in a place with high humidity or dust.
• Do NOT place heavy objects on top of the Bluetooth speaker.
• Do NOT use near a microwave oven or wireless LAN products.
正反面印刷
SIZE：95 X 148NN
1
2
6 7 8 9
3 5 4
Backlit touch-sensive buons
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
