Wonders Technology DS-1073 BLUETOOTH SPEAKER User Manual DS 1073 FCC

Wonders Technology Co., Ltd. BLUETOOTH SPEAKER DS 1073 FCC

Users Manual

USER’SGUIDE
CSMP135
Table of Contents
Safety information......................................................................................................................
Contents......................................................................................................................
Package contents .........................................................................
Features ..................................................................................................................
Main unit……………......................................................
Getting Started.........................................................................................................................
Pairing a Bluetooth Device......................................................................................................................
Playing Audio Wirelessly ........................................................................................................................
Playing Other Audio Devices (AUX In) ....................................................................................................................................................................
Powered .......................................................
LED indicator ........................................................................................................................
Charging Indicator Light .........................................................................................................................................
Pairing Indicator Lights ...........................................................................................................................
Specifications.........................................................................................................................
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Do not expose this apparatus to dripping or splashing and ensure that no objects filled with liquids, such
as vases, are placed on the apparatus.
16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from
the AC receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
18. Do not expose batteries to excessive heat such as sunshine, fire or the like.
Warnings and Precautions
• WARNING: To prevent fire or shock hazards, do not expose this unit to rain or moisture.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid damaging the surface. Use a
protective barrier between the unit and surface to protect the surface.
• WARNING : Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall
remain readily operable.
• Note : This device uses an internal rechargeable lithium-ion battery that should last the lifetime of the device. If you suspect
your battery may be dead after several attempts to charge, please contact COBY for support.
• Never disassemble the unit or attempt to remove the battery as that could cause leakage of an electrolytic substance.
FCC Warnings
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks is under license.
Contents.
Package contents
• CSMP135Bluetoothspeakerunit
• MiniUSBtoUSBchargingcable
• 3.5mmaudiocable
Features
• Built-inBluetoothspeaker
• 3.5mmaudioinput
• DCbatterypower:built-inrechargeablelithiumion 
• Batterylife:~4hours
• Wirelessrange:33feet
• SupportsBluetoothv2.1andEnhancedDataRate 
• Canbepairedupto8mobileoraudioplayers
Main unit
Introduction
A1:On‐Off
A2:LineIn
A3:ChargingIndicator
A4:USBport
A5:PairingIndicator
PairingaBluetoothDevice
1.TurnontheunitandpressthePairbutton.ThePairingIndicatorwillflashbluequickly.
Whenpairing,remainwithin3feetoftheunit. 
2.UsingthenativecontrolsonyourBluetoothdevice,selectthe“CSMP135”inyourBluetoothsettingstopair.
Ifyourdevicerequestsapassword,enterthedefaultpassword
“
0000
”
.Refertotheuser
’
smanualforyour
specificdeviceforinstructionsonpairingandconnectingBluetoothdevices.
3.Whensuccessfullypairedandconnected,thePairingIndicatorwilldisplayasolidbluelightandabeepwill
soundfromtheunit.
Afterinitialpairing,theunitwillstaypairedunlessunpairedmanuallybytheuserorerasedduetoaresetofthe
device. 
g 
PlayingAudioWirelessly
1.FollowtheinstructionsforPairingaBluetoothDevice.
2.UsethenativecontrolsontheconnectedBluetoothdevicetoselectatrack.
3.Toplaytheselectedtrack,usethenativecontrolsontheconnectedBluetoothdevicetoplay/pauseorskip.
4.AudioplayedthroughtheconnectedBluetoothdevicewillnowbeheardthroughthespeakers. 
5.UsethenativecontrolsontheconnectedBluetoothdevicetoadjustthevolume. 
6.PutBluetoothdeviseonspeakerdocking slot,theslotcanbesupportedthedevisethicknesswhichunder12.5mm.
Usingthe3.5mmAudioInput
1.Plugoneendofa3.5mmaudioinputcableintothe3.5mmAudioInputontheunit.
2.Plugtheotherendofthecableintotheaudiooutput/headphoneoutputonanMP3Playerorotheraudiosource.
3.Turntheuniton.
4.Audioplayedthroughtheconnecteddevicewillnowbeheardthroughthespeakers.
Note:AnyaudiobeingplayedthroughaconnectedBluetoothDevicewillceaseoncethe3.5mmAudiosourceisconnected.
Power
RequiresaMiniUSBtoUSBcable(included).
Note:PCmustnotbeinsleepmode.
Initialchargetime2-3hoursusingtheACadapter.Pleasemakesuretheunitisfullychargedbeforeuse. 
LED indicator
ChargingIndicatorLight
Status Indicator
PowerOff Nolight
Charging Redlight
FullyCharged  Redlightoff
Lowbattery Autopoweroff

PairingIndicatorLights
StatusPairingIndicator
PowerOff Nolight
ReadytoPair Quicklyflashingbluelight
BluetoothConnected Slowlyflashingbluelight
LineInMode Red  light 
Specification
FrequencyResponse120Hz-20KHz
Impedance4Ω
AuxInput3.5mm
OutputPower1.3x2(RMS)
Li-battery3.7V900mA
UnitDimensions(L*W*H)243x105x58mm
Troubleshooting & Support
Ifyouhaveaproblemwiththisdevice,pleasereadthetroubleshootingguidebelowandcheckourwebsiteat
www.cobyusa.comforFrequentlyAskedQuestions(FAQs)andfirmwareupdates.Iftheseresourcesdonotresolvethe
problem,pleasecontactTechnica l Support.
Address
COBYElectronicsCorporation
TechnicalSupport
150KnowltonWay
Savannah,GA31407
Email
techsupport@cobyusa.com
Web
www.cobyusa.com
Phone
800‐727‐3592:Weekdays:8:30AM‐9:00PMEST
Saturdays:9:00AM‐5:30PMEST
I cannot turn the unit on.
＊Ensure that the Li-battery of speaker unit is fully charged thru a USB cable connect to an AC
power or PC(PC must not be in sleep mode).
There is no sound during AUX In playback.
＊ If an Bluetooth devise is connected to the speaker, disconnect it.
＊ Ensure that the headphone jack of the audio device is connected securely to the AUX In
jack on the back of the speaker unit.
＊ Increase the volume level of the audio device; then increase the volume level of the speaker unit.
The sound is distorted.
Ensure that all connections are secure.
＊ Try reducing the volume level.
＊ If your device supports it, try reducing the bass level.
