Wonders Technology DS-1130 Bluetooth Speaker User Manual DS 1130
Wonders Technology Co., Ltd. Bluetooth Speaker DS 1130
user manual
1
BLUETOOTH SPEAKER
DS-1130
2
Thank you to have chosen our product. This product has been created by our
professional team and according to the USA regulation. For a better use of
your new device, we recommend you to read carefully this user manual and
keep it for record.
Product sketch map
1. Pair/Pause/Play/Hand Free
2. Skip previous
3. Skip next
4. Volume down
5. Volume Up
1 2 3 4 5
6 6. Battery Indicator
7. Power On/Off
7 8.Mode button
9.Aux-in mode
8 9 10.Bluetooth Mode
10
11 11.DC Jack(5V)
12.Aux-in Jack
12
3
Set up
1. To press the to turn on the speaker. The turns blue.
2. Speaker starts searching for Bluetooth device, and blue LED starts flashing.
3. Turn on your Bluetooth device, search “DS-1130” and press to pair your
Bluetooth device with the speaker. Password is “0000”.
4. Once paired, LED will change flashing rate from quick flashing to slow
flashing.
5. Once paired successfully, both the speaker and your Bluetooth device will
store the device. Next time, when you use the same Bluetooth device to
connect the speaker, then no need to use the password.
6. When not in use, please turn off the speaker.
Listening to Bluetooth device
1. Play music from your Bluetooth device and enjoy your time with it.
2. Adjust the volume by press or hold the Vol-/+ buttons or native controls on the
Bluetooth device.
3. Press Play/Pause on the speaker to play/pause the tune or just control the
tune by press Play/Pause on the Bluetooth device.
4. Change the songs by press or to play the previous song or next song.
5. Press and hold button to disconnect the previous Bluetooth device,the
blue light will flash fast and the speaker is searching for new Bluetooth device.
Hand-free function
1. Press to answer incoming calls, streaming music will pause
2. Press again to end calls,streaming music will resume.
3.5mm Audio Input
Requires a 3.5mm audio cable (Included).
1. Connect a 3.5mm audio cable to the 3.5mm audio input on the speaker and an
audio output on an MP3 player or other audio sources.
2. Speaker needs to switch to Aux In mode by press .The Aux-in mode indicator
light turns to red.
3. Press the Vol-/+ button or native controls on the connected MP3 player to
control volume.
4. If you want to Play/pause the tune, just control the native buttons on your MP3
player.
4
Quick understanding for the mode and lights
Trouble shooting
Symptom Possible problem and Solution
Can not pair successfully
Check whether the speaker is in standby and
searching mode.
Check whether there are too many Bluetooth
receivers around your Bluetooth device. Turn off
them to avoid any disturbance. And pair again.
The sound is small or
distorted
Check the volume setting on both the speaker and
your Bluetooth device and adjust the volume to a
suitable level.
Do not play properly, the
music is intermittently
Check whether the distance between the speaker
and your Bluetooth device is out of its working
distance, or whether there are some obstacles
block the communication between the speaker and
the Bluetooth device.
Specifications
• Model No.: DS-1130
• Speaker size : 165*68*45mm
• Bluetooth A2DP function
• Rechargeable Li-ion battery included
• Battery capacity: 3.7V 1200mAh
• Battery life: 4Hrs (Volume at 50%)
• Mini USB jack, power by USB cable (USB cable included)
• 3.5mm Aux jack for connection to other MP3, CD, Laptop…
• Output power: 2W X 2 (THD=10%)
• Working distance: ＜ 10 M
• Can be paired up to 6 mobile or audio players
Status Indicator
Bluetooth pairing Blue light flash quickly
Paired Blue light flash slowly
Aux-in mode Red
Battery Indicator White light (each light indicates 25% of the battery)
Power off No light
5
Important Safety Instructions
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
10. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Caution
Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
A warning that no objects filled with liquids, such as vased,shall be placed on the
apparatus.
The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
A warning that batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire, or the like.
Warning:
To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer
servicing to qualified service personnel.
Disposal
Batteries do not belong in household waste. As a consumer, you are required by
law to recycle used batteries. You can recycle your old batteries at public
collection points or wherever the product was sold.
For environmental reasons, do not dispose of the device in the household waste
at the end of their service life. Dispose of the unit at a suitable local recycling
point.
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
