Wonders Technology DS-1176 Bluetooth Speaker User Manual TABT01
Wonders Technology Co., Ltd. Bluetooth Speaker TABT01
user manual
1
BLUETOOTH
BLUETOOTH
BLUETOOTH
BLUETOOTH SPEAKER
SPEAKER
SPEAKER
SPEAKER
DS-1176
DS-1176
DS-1176
DS-1176
Thank you to have chosen our product . This product has been created by our
professional team and according to the American regulation. For a better use
of your new device, we recommend you to read carefully this user manual and
keep it for record.
2
S
S
S
S pecifications
pecifications
pecifications
pecifications
• Model No.: DS-1176
• Speaker size: 72 * 72*76mm
• Bluetooth A2DP function
• Rechargeable Li-ion battery included
• Battery capacity: 3.7V 500 mA h
• Battery life: 3 Hrs (Volume at 50%)
• Micro USB jack, power by USB cable (USB cable included)
• Battery charging indicator
• 3.5mm Aux jack for connection to other MP3, CD, Laptop …
• Output power: 1.5 W X 1 (THD=10%)
• Working distance: 33 Feet
Product
Product
Product
Product sketch
sketch
sketch
sketch map
map
map
map
1
1
1
1
2
2
2
2
3 4 5 6 7
1. Mode indicator
2. Charging indicator
3. Volume Down
4. Pause/Play/Hand-Free
5. Volume Up
6. Micro USB port
7. Aux-in Port
Status
Status
Status
Status Indicator
Indicator
Indicator
Indicator
Bluetooth pairing Blue light flash quickly
Paired Blue light flash slowly
Aux-in mode Red
Charging R ed light
Fully Charged Green Light
3
8 9
8. Microphone
9. Power On/Off Switch
Pairing
Pairing
Pairing
Pairing a
a
a
a Bluetooth
Bluetooth
Bluetooth
Bluetooth Speaker
Speaker
Speaker
Speaker
1.
To
push the to turn on the speaker, there is a Beep sound. The speaker is
defaulted in Bluetooth Mode.
2. Turn on your Bluetooth device, search “ BT Model NO ” and select the DS-1176
in your Bluetooth Setting and pair your Bluetooth device with the speaker.
3. When pairing, the Bluetooth indicator light flashes blue quickly.
4. When successfully paired and connected , there will be a Beep sound.
B oth the speaker and your Bluetooth device will store the device name. Next time, when you use the same
Bluetooth device to connect the speaker, no password is asked.
Note:
Note:
Note:
Note: Hold
Hold
Hold
Hold the
the
the
the button
button
button
button for
for
for
for more
more
more
more than
than
than
than 3
3
3
3 seconds,
seconds,
seconds,
seconds, the
the
the
the Bluet
Bluet
Bluet
Bluet o
o
o
o oth
oth
oth
oth
connection
connection
connection
connection will
will
will
will be
be
be
be terminated.
terminated.
terminated.
terminated.
Playing
Playing
Playing
Playing Audio
Audio
Audio
Audio Wirelessly
Wirelessly
Wirelessly
Wirelessly
1. Follow the instruction of Pairing
A
Bluetooth Device
2. Adjust the volume by press or hold the or buttons or native controls on
the Bluetooth device.
3. Press on the speaker to play/pause the tune or just control the tune by
press Play/Pause on the Bluetooth device.
4. Press the Hand-Free to answer incoming calls, streaming music will pause.
Then press the Hand-Free to end calls, streaming music will resume.
4
Using
Using
Using
Using the
the
the
the 3.5mm
3.5mm
3.5mm
3.5mm Audio
Audio
Audio
Audio Input
Input
Input
Input
1. Plug one end of a 3.5mm Audio input cable into the 3.5mm Audio Input on the
unit. The mode indicator light will display a red light.
2. Plug the other end of the 3.5mm Audio input cable into the audio
output/headphone output on an MP3 Player or other audio devices.
3. Turn on the speaker, the audio will play through the connected device will now
heard through the speakers.
4. Press and hold the or buttons to adjust the volume.
5. If you want to Play/pause the tune, just control the native buttons on your MP3
player.
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
