Wonders Technology DS-1178 Bluetooth Speaker User Manual FH DOSS008DS 1178 2
Wonders Technology Co., Ltd. Bluetooth Speaker FH DOSS008DS 1178 2
user manual
1. Speaker view:
1.1: + Volume up
1.2: - Volume down
1.3: ►II Shortly press: play/pause; Long press: bluetooth pairing
1.4: Bluetooth/Aux audio input mode indicator
1.5: Main/Auxiliary speaker connecting indicator
1.6: Charing indicator
1.7: DC in
1.8: Aux audio input
1.9: Power on/off switch
1.10: Main/Auxiliary speaker connecting button
2. LED indicator:
2.1: Main/auxiliary speakers connection status: green/blue lights
flashing in turn
2.2: Main/auxiliary speakers connect OK: green light on
2.3: Bluetooth pairing status: red/blue lights flashing in turn
2.4: Bluetooth pairing OK: blue lights on
2.5: AUX mode: red light on
3. Charging and Low-power indicator:
3.1: Charging: Red light on
3.2: Charge OK: Green light on
3.3: When low power, there will be a prompt, please insert the
matched USB cable.
4. Bluetooth Pairing
4.1: First time to play surround stereo speakers, please turn on
the speakers, and long press “STEREO” button on the bottom
of each speaker, to make the connection of the speakers. At
the same time, blue/green lights flashing in turn, indicates the
speakers are connecting. When connection ok, green light is on.
The first time playing with stereo speakers, there needs time
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
(about 1min) to search and confirm necessary information.
From second time use, the speakers will always acquiesce
in connection and auto-connected quickly.
4.2: After two speakers connect complete, select one speaker
to long press the “Play/Pause” button on the top of it,
connecting speaker with audio sources. At the same time
red/blue flashing in turn. When connection OK, blue light
is on and you can playing music.
4.3: After two speakers connect OK, if music stop suddenly,
this is caused by wrong exchanged info between two
speakers. Please repeat the above steps.
5. Notice
5.1: Main speaker which connect with smartphone or other
bluetooth devices, it is the “L” channel; the other one will
be auxiliary speaker and the “R”channel.
5.2: When speakers are playing, if you turn off the main
speaker, the music will be off; if you turn off the auxiliary
speaker, the main speaker will still play(R/L mixed).
5.3: If you want to replay auxiliary speaker, you should turn off
main speaker first, then restart search connection between
two speakers. Otherwise the auxiliary speaker cannot play.
5.4: This model can be used two speakers(surround stereo
sound) together, also be used independently(R/L mixed line
out).
5.5: The efficient distance is within 10meters, if beyond 10m, the
signal will be broken.
6. Notice when using AUX mode.
6.1: Playing music, please connect the stereo speakers and audio
source(like iPhone, laptop, etc) with the USB cable.
6.2: The volume can be adjusted separately, not synchronized.
Specifications:
• Model No.: DS-1178
• Output power: 2W (THD=10%)
• Bluetooth A2DP, AVRCP function
• Rechargeable Li-ion battery included
• Battery capacity: 1050mAh
• Frequency Response: 80Hz--18KHz
• S/N Ratio: Line in/bluetooth ›65dB
• Mini USB jack, power by USB cable (USB cable included)
• 3.5mm Aux jack for connection to other MP3, CD, Laptop…
• Efficient working distance: within 10meters
Caution:
1. It’s dangerous if you replace the battery improperly.
2. You can only use the same type or equivalent type of battery
to replace the damage one .
3. Battery shall not be exposed to overheating environment such
as sunshine and fire .
Warning:
To reduce the risk of electric shock, do not remove cover (or
back). Refer servicing to qualified service personnel.
290
Warranty Card
back to
Company or Name
Address
Postal code
Product name and Model no.
Retailer’s name
Purchase date
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
