Wonders Technology DS-456 IPOD WIRELESS SPEAKER User Manual YB017002
Wonders Technology Co., Ltd. IPOD WIRELESS SPEAKER YB017002
USERS MANUAL
Ready for use:
The sound comes from two balls which has rechargeable battery
built-in with individual amplifier, wireless function to be automatically
activated as soon as balls leave from base station, turn on the
speaker then enjoy the music everywhere in your house.
Note: Rechargeable lithium battery built in, when the ball placed on
the base station under power on mode, it starts to charge itself.The
charging light is red and will become green if fully charged.
1. Select a proper docking adaptor enclosed in your own iPod and
place it into the docking station, then dock your iPod gently.
2. Plug the AC adaptor into the DC in port at the rear of the base
station, then into a power supply.(100-240V/50Hz AC electrical outlet)
3. Press the power button on the base station to turn on the unit, also
switch on the balls to play iPod.Then choose the best channel through
the “channel” button at the rear of the base station until the balls
receive the right signal.
4. Use “Vol +” or “Vol -” to adjust to a proper volume level, then you can take it
anywhere in your house.
Remark: After the channel chosen,the two balls will remember the frequency to
be used, if the unit receives any interference while playing,please put back the
balls into the station to adjust to other channel.
Each speaker has its own separate amplifier and receiving system.
Purified sound from 2pcs of 2.75 full range speaker.
Rechargeable lithium batteries built in, which can last 5 hours after
fully charged.
Wireless working distance: 30m
AC adaptor included.
Not only compatible with iPod, but also compatible with other MP3,
Mobile phone by 3.5mm Aux input jack.
Output power: 6W x 2
Product specification:To play iPod To play iPod To play iPod To play iPod
Connect one end of 3.5mm audio cable to the audio output port of
auxiliary audio devices(MP3,PC,CD player,etc) and connect the other
end of the cable to Aux input port at the rear of the base station, then it
plays.
To play auxiliary audio sources
9 10 11 12 13
8
7
Wireless Speaker System
Model No.:DS-456
OPERATING INSTRUCTIONS
B1. AUX
B2. DC IN
B3. CH1、CH2、CH3
B1 B2 B3
B.Station(rear)
A1
A1. VOL-
A2. POWER
A3. VOL+
A2 A3
A.Station (top)
C1. Power and Vol-/+
C2. Charging pin
C1C2
C.Speaker unit
Congratulations on the purchase of your new wireless speaker
system, to get the most from your speaker system, please take a few
minutes to read the following instructions and familiarize yourself with
the operation of the unit.
Before setting up the unit, check that the following items are included
within the box:
1. Wireless speaker system
2. AC power adaptor
3. 3.5mm audio cable for aux input
1 2 3 4 5
Unpacking and Installation
For Your Safety
Unpack your unit carefully. We recommend that you save the box and packing
materials, in case you wish to store the unit or if you ever need to return it for
service. To avoid damage to the unit, never place it near heat sources such as
radiators, in front of heating vents or in direct sunlight. Keep it away from water.
When disconnecting the DC power cord from a socket, pull the plug itself.
Never try to remove the plug from the socket by pulling the cord.
Never handle the DC power plug with wet hands - this can cause electric shock.
When cleaning the unit, you should first unplug it from the power supply. Use only a
damp cloth to wipe the unit. Never allow water or any other liquids to get inside the
unit while cleaning.
Unplug the unit if you are not using it for an extended period of time.
Care and Maintenance for the Unit
CAUTION:
WARNING:
Servicing should be carried out by qualified personnel only. To reduce the risk of
fire or electric shock, do not expose this appliance to rain or moisture. Dangerous
high voltages are present inside the unit; do not try to open it up.
To prevent risk of fire or electric shock, do not leave any objects filled with liquids,
near the product, such as vases . Never put lighting candles near the unit.
If the plug or the power supply cord needs to be replaced, ensure that the
replacement complies with the manufacturer’s recommendations and specifica
tions.
Do not attempt to repair the unit yourself. All repairs should be done by a qualified
service technician.
To avoid risk of electric shock, ensure that the plug is fully inserted into the wall
socket. Power supply source: AC 100～240V/50Hz
If the Unit Requires Servicing
6
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC NOTE：
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY NAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
This device complies with RSS 210 of Industry Canada. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
