Wonders Technology DS-988 WIRELESS SPEAKER User Manual DS 988
Wonders Technology Co., Ltd. WIRELESS SPEAKER DS 988
Users Manual
User Manual
Model No.:DS-988
Listening to your iPod/iPhone/MP3
1.. Plug the AC adaptor into the DC in port at the rear of the base
, then into a power supply. And put the battery into the compartment of the speaker.
2.Connect 3.5mm audio cable which located on the base to the audio output port of an
auxiliary audio device (iPod /MP3,PC,CD player,etc)
3.Press both of the power button on the base and speaker to turn the unit on.
4.Press MP3 button on the speaker to turn to the audio mode.
5..Press corresponding“ channel” button1/2/3 both on the top of the base and right hand of the
speaker until it receives the right signal.
Noted:The unit would default to be channel 1 when at the beginning.
4. Use “VOLUME+” or “VOLUME-” on the right hand of the unit to adjust to a proper volume
level,
5.Press the PLAY/PAUSE button on your iPod/iPhone to playback,press again to pause play.
Charging for the battery
1. Put recharging battery into the compartment of the base.Make sure it fit the two charging
contact points well.Then the indicator turned to be green to show the status of charging and
turned to be red when full charged.
Noted:The indicator will be only on when the battery have been put into the recharging area of the
base.
Using LED clock
Press the button on the bottom of the speaker to turn the LED on and after 3 seconds will auto off.
Setting clock time
1. Press hour button on the right hand of the speaker,hour digits will begin flashing,Press the
hour button again to adjust your desired hour and after 5 seconds the display will stop flashing
to indicate the hour is set.
2. Press minute button on the right hand of the speaker,minute digits will begin flashing,Press
the minute button again to adjust your desired minute and after 5 seconds the display will stop
flashing to indicate the minute is set.
Using shelf inside the speaker
Push the mirror to open the door and then you store your razors and etc.
Radio operation:
1. Press the radio button to turn to the radio mode.
2. To press the STATION+ or STATION- button for 2 seconds,the unit will automatically scan
and store radio station.
3. To press the STATION+ or STATION- button to tune the radio station.
FCC NOTE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1)this device may not cause harmful interference,and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC NOTE
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
