Wonders Technology DS1338 Home Theater Bluetooth Speaker User Manual DS 1338

Wonders Technology Co., Ltd. Home Theater Bluetooth Speaker DS 1338

user manul

1. Speaker*1 2. USB power cord*1 3.Certificate*1 4.Manual*1
1 2 3 4 5 6 7 8 9 10
Home Theater Bluetooth Speaker
Dear Customer
Thank you very much for choosing MINISO home theater bluetooth speakers.Please read this manual before use for
correct operation and better performance.
This product is with fashion & beautiful design, small, portable,multifunctional.Leading electroacoustic technology,brings
you excellent sound effects no matter at the home, outdoors or at work. Offers super perfect sound quality for your tablets,
mobile phones, digital music player,etc.
Store or use this product at room temperature
Do not expose this product in the rain or damp environment
Do not throw, to avoid the damage caused by falling
Do not disassemble, repair or modify this product
Built-in lithium battery products, please do not discard arbitrarily to advoid danger
1. Mode button: click press to switch bluetooth mode, TF card mode and USB mode
2. Last song: click this button, to play the last song.
3. Answer the phone, play and pause: short press to pause;When phone call comes,
short press to answer or hang up, long press to reject.
4.The next song: click this button,to play the next song.
5. On-off & volume button, knob and turn right to switch on.Knob and turn clockwise to
add volume, turn counterclockwise to reduce the volume.
Product Parameter
Model No.: MINISO DS-1338
Bluetooth specification: Bluetooth V4.1 + EDR
Transmission distance: 10M
USB charging power supply: DC 5V 1A
Built-in battery: lithium battery
Output power: 4W x 2
Frequency response: 100HZ - 18 KHZ
Sensitivity: 80 db 2 db
Signal to noise ratio: 55 db
Net weight: 910 g
Product size: 450 X 59 X 62.5 MM
6. USB socket
7. TF socket
8. AUX socket
9. Power socket
10.Charge indicator
1, To prolong the service life of the speaker and your physical and mental health, please don't listen at high volume for
long time,so as not to damage your hearing.
2, If malfunction occurs, please immediately shut off the power switch, unplug the USB plug, to prevent damage of the
speaker and other components.
3. Electricity shortages will affect bluetooth distance or cause disconnection, please recharge in time.
Cautions
Kindly reminder
Appearance and function keys
Product Parameter
Bluetooth Pairing and Connection:
1. Rotate clockwise to power on the volume button, the Bluetooth will be activated and flash, which means it enters
into search and pairing mode; the speaker is under standby mode.
2. Open the Bluetooth device settings and search (Note: Different Bluetooth device has diverse ways to activate
Bluetooth function). Your Bluetooth will search and find "MINISO DS-1338", and it will select and connect. If it is
required to input password, please enter 4 digits of "0000", and press to confirm; wait to be connected! The
Bluetooth device will make sounds if it is successfully connected. And the blue indicator light will become solid; the
whole pairing process takes about 1 minute (the pairing time will differ as different Bluetooth devices). The match
and pairing procedure needs to be done between your Bluetooth device and the speaker only for the first time use.
And the speaker will automatically connect the previously-paired device.
3. When connected successfully, you can play the music on the Bluetooth device.
Bluetooth 4.1 includes the following agreement: A2DP V1.2, AVRCP V1.4, AFPV1.5, SPPV1.2, AVDTPV1.
2. Smart phones, tablet, PC, and the vast majority of Bluetooth devices.
4. Hands-free function: If connected with smartphone, the speaker will make sounds if there is an incoming call. Short
press “ ” button to answer the call, and you can talk directly by the speaker. When the call is in progress, short
press “ ” button to hang up the call and long press “ ” button to reject the call.
5. Bluetooth automatic connection function: When Bluetooth connection is successful, but it reaches out of the valid
distance, the speaker can be automatically connected if it is back to the effective distance in 10 minutes.
External Audio Input Function
When the speaker is on, insert the external device (such as: mobile phone, computer, MP3 audio output device)into
"AUX", the speaker will automatically switch to external audio input mode and the red LED indicator light keeps on.Just
play the music!
USB disk play
When the speaker is on, insert the USB flash drive into the big USB socket, the speaker will automatically switch to read
U disk mode and automatically play music.
TF Card Play
When the speaker is on, insert TF card into TF booth, speakers will automatically switch to read TF card mode and
automatically play music.
When the battery is less than 10%, the sound makes a warning tone, please recharge in time. When the battery is lower
than 3%, the speaker will automatically power off.
Indicator light status
Bluetooth mode: during connected status, the blue light keeps on;
Audio input mode: the red light keeps on;
U disk mode: blue light blinks
TF card mode: the red light blinks
Finish Charging: the red light extinguish
Composition
Connection Direction
Common Function Direction
Problems
Multiple connection
failure
Low sound or
distortion
Indicator light is not
on under Bluetooth
status
1. Battery is not enough, please recharge and try again.
2. Restart
Staccato
1. Check the bluetooth device volume, adjust the volume to appropriate level.
2. Low voltage, please recharge.
1. The connection distance is beyond effective range, or there is obstacle
between speaker and bluetooth devices.
Solution
1. Check whether the speaker is in searching state, or restart.
2. There too many bluetooth devices around, turn off other bluetoooth devices.
Common problems & solution
Bluetooth protocol and compatibility
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
