User manual
Wireless Bluetooth Speaker
Pocket
Thank you to have chosen our product. This product has been created by our
professional team and according to the USA regulation. For a better use of
your new device, we recommend you to read carefully this user manual and
keep it for record.
Specifications
• Model No.: DS-1362
• Speaker size : 165*58.5*27mm(L*W*H)
• Power by USB cable :DC 5V
• Rechargeable Li-ion battery included
• Battery capacity: 3.7V 1000MAH
• Battery life: 5Hrs (Volume at 75%)
• Output power: 1.5W X 2 (THD=10%)
• Working distance: ＜ 10 M (Distance differs from different cellphone Bluetooth
devices and the environments)
Product sketch map
1 2 3
1.Power button
2.Line in port
3.USB port
4.Pause, Volume control, Prev/Next tune button，hand free control
Status Indicator
Bluetooth pairing Blue light flash quickly
Paired Blue light keep lighting
Aux-in mode Red
Charging Red light
Fully Charged Green Light
5
5.bottom stand
Pairing Bluetooth Speaker
1. Push the power switch to turn on the speaker. The speaker is defaulted in
Bluetooth Mode, and blue LED starts flashing.
2. Turn on your bluetooth device, search “SLIM” in your bluetooth searching list,
then pair your bluetooth device with the speaker. (If your bluetooth device ask for
password, please insert “0000”.)
3. After paired successfully, there will be a “paired”sound out and you could play
songs.
Both the speaker and your Bluetooth device will store the device name. Next time, when you use the same
Bluetooth device to connect the speaker, no password is asked.
Playing Audio Wirelessly
1. Follow the instruction of Pairing Bluetooth Device
2. Push the button on the speaker up or down to adjust the volume ; or
native controls on the Bluetooth device.
3. Press Pause button on the speaker to Play/Pause the tune or just control
the tune by press Play/Pause on your Bluetooth device.
4. Push button to right to skip prev ,Push to left is the Next tune or
just control the tune by press prev/next on your bluetooth device.(SO PLS CONFIRM
THIS WITH YOUR SAMPLE,I AM NOT 100% SURE)
5.If there is a coming call on your phone, press to pick up or hang up call.
6. When do not play music, please push the power switch to turn off the speaker
Using the 3.5mm Audio Input
1. Plug one end of a 3.5mm Audio cable into the unit. The mode indicator light will
display a red light.
2. Plug the other end of the 3.5mm Audio cable into other audio devices.
3. Turn on the speaker, it will play music from the audio device.
4. If you want to Play/pause the tune,or want to change Previous/Next tune just
control the native buttons on your audio device.
Contact Information:
Manufacturer: Wonders Technology Co., Ltd.
DOSS Industrial Zone, Qiping Kengdu Industrial Area Guihua Village, Guanlan
Town Baoan District, Shenzhen, China
Telephone No: 86-755-2752-0683
Fax No: 86-755-2752-0228
E-mail: LIANGBO8899@126.COM
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
