Wonders Technology SP58083 Bluetooth Speaker User Manual DS 1362 FCC
Wonders Technology Co., Ltd. Bluetooth Speaker DS 1362 FCC
user manual
Bluetooth Speaker
Pocket
Thank you to have chosen our product. This product has been created by our
professional team and according to the USA regulation. For a better use of
your new device, we recommend you to read carefully this user manual and
keep it for record.
Specifications
• Model No.: SP58083
• Speaker size : 165*58.5*27mm(L*W*H)
• Power by USB cable :DC 5V
• Rechargeable Li-ion battery included
• Battery capacity: 3.7V 1000MAH
• Battery life: 5Hrs (Volume at 75%)
• Output power: 1.5W X 2 (THD=10%)
• Working distance: ＜ 10 M (Distance differs from different cellphone Bluetooth
devices and the environments)
Product sketch map
1 2 3
1.Power button
2.Line in port
3.USB port
4.Pause, Volume control, Prev/Next tune button，hand free control
Status Indicator
Bluetooth pairing Blue light flash quickly
Paired Blue light keep lighting
Aux-in mode Red
Charging Red light
Fully Charged Green Light
5
5.bottom stand
Pairing Bluetooth Speaker
1. Push the power switch to turn on the speaker. The speaker is defaulted in
Bluetooth Mode, and blue LED starts flashing.
2. Turn on your bluetooth device, search “SLIM” in your bluetooth searching list,
then pair your bluetooth device with the speaker. (If your bluetooth device ask for
password, please insert “0000”.)
3. After paired successfully, there will be a “paired”sound out and you could play
songs.
Both the speaker and your Bluetooth device will store the device name. Next time, when you use the same
Bluetooth device to connect the speaker, no password is asked.
Playing Audio Wirelessly
1. Follow the instruction of Pairing Bluetooth Device
2. Push the button on the speaker up or down to adjust the volume ; or
native controls on the Bluetooth device.
3. Press Pause button on the speaker to Play/Pause the tune or just control
the tune by press Play/Pause on your Bluetooth device.
4. Push button to right to skip prev ,Push to left is the Next tune or
just control the tune by press prev/next on your bluetooth device.(SO PLS CONFIRM
THIS WITH YOUR SAMPLE,I AM NOT 100% SURE)
5.If there is a coming call on your phone, press to pick up or hang up call.
6. When do not play music, please push the power switch to turn off the speaker
Using the 3.5mm Audio Input
1. Plug one end of a 3.5mm Audio cable into the unit. The mode indicator light will
display a red light.
2. Plug the other end of the 3.5mm Audio cable into other audio devices.
3. Turn on the speaker, it will play music from the audio device.
4. If you want to Play/pause the tune,or want to change Previous/Next tune just
control the native buttons on your audio device.
