Wonderware Mobile Solutions RFID System 70108
Users Guide
SAT CORPORATION
SRM RFID SYSTEM USERS GUIDE
DOC 70108 REV A 3/1/99 Page 1
INTRODUCTION
This document provides important information for using the SRM RFID System with Telxon
PTC-2134 and PTC-2234 handheld computers. The information provided here does not apply to
using any specific software programs.
The SRM RFID System uses Texas Instruments Radio Frequency Identification System (TIRIS)
technology. It emits low-level radio-frequency energy at 134.2KHz and receives signals from
TIRIS transponders in the same frequency range.
OPERATION
The SRM RFID System is fully installed and configured on delivery. No user installation or
tuning is required. Refer to your application software documentation for details on using the
system. Following are general guidelines:
ü The radio does not transmit except when initiated by the user. Read operations can be
initiated by pressing the READ button on the SRM RFID Handle or through application
software.
ü Range is dependent on the relative orientation of the SRM RFID Handle and the transponder.
Optimum range (5-6") is achieved when the edge of the RFID tag is visible through the
opening in the handle. Range is worst when the tag and the handle are in the same plane.
ü To achieve optimum performance, sight the RFID tag through the hole in the handle and hold
the computer so that the handle is less than 6" from the tag.
SAFETY INFORMATION
The Telxon PTC-2234 with SRM RFID System has been investigated by Underwriters
Laboratories for use in Class I, Division 2, Groups A,B,C and D Hazardous Locations. On the
rear of the PTC-2234 unit under the battery, the following decal indicates that the unit is Listed
with UL.
TELXON CORPORATION
DATA PROCESSING
EQUIPMENT FOR USE IN
HAZARDOUS LOCATIONS
CLASS I DIVISION 2
GROUPS A,B,C, & D
INPUT 15VDC 2.7A MAX
20BM
USE ONLY BAT. PACK MODEL 24172-002
If this decal is not present, the unit is not approved for use in hazardous locations. The following
instructions apply when using the UL Listed model in Division 2 hazardous locations:
ü Do not connect any device or accessory to the PTC-2234 unless it is specifically approved
for use in hazardous locations.
ü The battery charger and cradle are not approved for use in hazardous locations.
SAT CORPORATION
SRM RFID SYSTEM USERS GUIDE
DOC 70108 REV A 3/1/99 Page 2
ü At this time no devices are approved for connection to the Keyboard/Serial connector at the
bottom of the unit. Do not connect a keyboard or any other device to this connector unless
the area is known to be nonhazardous.
ü Do not install or remove PCMCIA cards or the Bar Code Scan Module unless the area is
known to be nonhazardous.
ü Use only Bar Code Scan Module part number 19391-103.
ü Use only Battery Pack part number 24172-002.
ü Do not disassemble the PTC-2234 or modify it in any way.
FCC NOTICE
FCC ID: OFZ990001
This equipment contains an intentional radiator approved by the FCC under the FCC ID number
shown above. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference in
which case the user will be required to correct the interference at his own expense.
NO MODIFICATIONS: Modifications to this device shall not be made without the written
consent of SAT Corporation. Unauthorized modifications may void the authority granted under
Federal Communications Commission Rules permitting the operation of this device.
