Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz
MACHINE
SPECIFICATIONS
MOdEl W1736
bENCHTOP PIN rOuTEr
Table ................................................................. 19-3/4" W x 14" D x 1-3/8" Thick
Overall Height .................................................................................... 31-3/8 "
Overall Width ..................................................................................... 21-3/4"
Overall Depth ..................................................................................... 2 8-1/4 "
Footprint ......................................................................... 21-3/4" W x 28-1/4" D
Machine Weight .................................................................................... 56 lbs
Maximum Head Stroke .............................................................................5 -1/2"
Maximum Distance Spindle to Table .............................................................6-1/2"
Maximum Distance Housing to Table ............................................................8 -3/4 "
Throat Capacity ....................................................................................... 18"
Router Adapter Sizes ......................................................... 3.25", 3.328", 3.5", 4.2"
Router Housing Size ................................................................................4 -1/2"
Table Pins (3) .................................................3/16" x 1/4", 5/16" x 3/8", 7/16" x 1/2"
Table Construction ..............................................................Milled Cast Aluminum
Body Construction ......................................................................Cast Aluminum
Clamp Housing ...........................................................................Cast Aluminum
Required Operating Air Pressure ................................................................ 60 PSI
Maximum Air Pressure ........................................................................... 115 PSI
