Thank you for purchasing Dragster from WowWee™!
Race the WowWee™ remote control Dragster to super fast speeds topping 8.5mph (13.7 km/h).
It even has a real drag parachute for braking and a vibrating engine — like a real dragster!
Take a few moments to look through this quick start guide to get Dragster running.
Package contents
1 x Dragster, 1 x Remote controller, 1 x Antenna,1 x Quick start guide
Quick overview
Dragster
Remote controller
Parachute reload
button
Parachute release
button
Parachute
funnel
Power switch and battery compartment
(located on the underside)
Vibrating engine
Rev meter
Power switch
Front of remote controller
Countdown
Gear shift Direction toggle
Clutch
Antenna Speaker
Battery compartment
Back of remote controller
3
Battery details
Battery details
Before you use Dragster for the rst time, or if you have depleted the batteries you will need to
insert fresh batteries. If Dragster slows down or is less responsive try changing the batteries; if it
does not respond to commands but moves quickly, try changing the batteries in the remote controller.
Battery requirements
Dragster requires 1 x “9.6V” size battery pack and the remote controller requires
1 x “9V” size battery. (The batteries are not included).
NOTE: Make sure the main power switch is set to OFF before changing the batteries.
To install the batteries in Dragster, do the following:
Locate the battery compartment door. Using a Phillips screwdriver (not included) remove 1.
the screw on the battery compartment door.
Insert the battery according to the diagram. Ensure that the orientation of the sockets 2.
are correct.
Replace the battery compartment door and replace the screw using the screwdriver. 3.
Do not over-tighten.
9.6V 800mAh
+
-
+
-
OR MORE
4
Battery details
To install the battery in the remote controller, do the following:
Locate and open the battery compartment door on the remote controller. Using a Phillips 1.
screwdriver (not included) remove the screw on the battery compartment door.
Insert the battery according to the diagram. Ensure that the positive and negative 2.
polarities match the illustrations inside the battery compartment.
Replace the battery compartment door and replace the screw using the screwdriver. 3.
Do not over-tighten.
Important battery information
Use only fresh batteries of the required size and recommended type•
Do not mix old and new batteries, different types of batteries [standard (Carbon-zinc), Alkaline or rechargeable] or •
rechargeable batteries of different capacities
Remove rechargeable batteries from the toy before recharging them•
Rechargeable batteries are only to be charged under adult supervision•
Respect the correct polarity, (+) and (-)•
Do not try to recharge non-rechargeable batteries•
Do not dispose batteries in a re•
Replace all batteries of the same type/brand at the same time•
The supply terminals are not to be short-circuited•
Remove exhausted batteries from the toy•
Batteries should be replaced by adults•
Remove batteries if the toy is not going to be played with for some time •
9V
5
Playing with Dragster
Playing with Dragster
Now you have power, you are ready to play with Dragster!
First, attach the antenna to the remote controller by turning it clockwise and turn the remote controller
on. Then, turn on Dragster using the power switch located on its underside. Dragster will vibrate —
ready for action!
Countdown
Before you can drive Dragster you have to wait for the countdown!
The red light on the remote controller will ash to indicate that the countdown has begun.1.
During countdown the lights change from red, to amber and nally ash green. 2.
A loud horn will also sound.
NOTE: Dragster can’t move until the countdown has nished but you can rev the engine
during countdown by pushing the Gear shift button.
When the horn sounds press the 3. Clutch button (back, left side) and push the Gear shift
button (front left side) downward to move into rst gear, as illustrated.
To change gear continue pressing down on the 4. Clutch button and then press the Gear shift
button twice simultaneously to change into second gear and three times to change into
third gear.
Driving control
To maneuver left and right, press on the Direction toggle. To drive in reverse,
press the Gear shift button upward as illustrated.
To stop Dragster, rst release the clutch and then press the Parachute release button to open the
parachute. Dragster will then come to a complete stop.
To reload the parachute, press the Parachute reload button and pack the parachute into its funnel.
THE ANTENNA PROVIDED IS A UNIQUE ANTENNA AND SHOULD ONLY BE USED WITH THE TRANSMITTER INTENDED FOR
ITS USE. UNAUTHORIZED INSTALLATION OF ANOTHER ANTENNA WILL VOID THE USER’S PERMISSION TO OPERATE THE
EQUIPMENT. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED
MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
Clutch button
(back, left side)
Gear shift button
(front, left side)
6
Safety and warnings
Safety and warnings
Take note of the following when playing with Dragster:
Do not immerse Dragster or any of its parts water or any other form of liquid. •
Do not drop, throw, or kick Dragster as this might damage the mechanical functions.•
If Dragster becomes dirty, you can clean the surface using a clean cloth slightly dampened with warm water.•
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause •
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try and correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna•
Increase the separation between the equipment and receiver•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected•
Consult the dealer or experienced radio/TV technician for help •
WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
