WowWee Group 0280A 49.82-49.90 MHz WIRELESS R/CTX User Manual Astro Flex
WowWee Group Limited 49.82-49.90 MHz WIRELESS R/CTX Astro Flex
Users Manual
Item No.0280
Ages 4+
Item No.0280
Ages 4+
Contents
Driving the Astro-Flex Safety Precautions
Manufactured and Distributed by:
© 2004 WowWee
All Rights Reserved.
WowWee (Asia Office)
Unit 301A-C, 92 Granville Rd.,
T.S.T. East, Hong Kong
WowWee (North America Office)
4480 Cote de Liesse, Suite 320,
T.M.R. Quebec, H4N 2R1, Canada
Consumer Hotline: (514) 344-1250
www.wowwee.com
MADE IN CHINA
Packaging Printed in China.
Product and colors may vary.
We recommend that you retain
our address for future reference.
Manufactured and Distributed by:
© 2004 WowWee
All Rights Reserved.
WowWee (Asia Office)
Unit 301A-C, 92 Granville Rd.,
T.S.T. East, Hong Kong
WowWee (North America Office)
4480 Cote de Liesse, Suite 320,
T.M.R. Quebec, H4N 2R1, Canada
Consumer Hotline: (514) 344-1250
www.wowwee.com
MADE IN CHINA
Packaging Printed in China.
Product and colors may vary.
We recommend that you retain
our address for future reference.
DY0280US01
• Vehicle: 6 x "AA" LR06 UM3 (Battery not
included)
• Controller: 1 x 9V 6LR61 Battery (Battery
not included)
Power Indicator Light
Left Stick
Throttle Forward
Right Stick
Throttle Reverse
Cockpit Up
Cockpit Down
Drive Wheels Stabilizer Arm
Cockpit
Push Throttle Forward to
make the Astro-Flex
move forwards.
Push Throttle Reverse to
make the Astro-Flex
move backwards.
Forward Reverse Right Spin
Push the Right Stick to
make the Astro-Flex spin
to the right.
Push the Left Stick to
make the Astro-Flex spin
to the left.
While pushing Throttle
Forward or Throttle
Reverse, push the Right
Stick to make the Astro-
Flex turn to the right.
Left Spin Right Turn Left Turn
While pushing the
Throttle Forward or
Throttle Reverse, push
the Left Stick to make
the Astro-Flex turn to
the left.
Battery installation and Power On/Off
Attention: Important Battery Information
• Use only fresh batteries of the required size and
recommended type.
• Do not mix old and new batteries, different types of
batteries (standard alkaline, or rechargeable), or
rechargeable batteries of different capacities. We
recommend the use of rechargeable batteries.
• Remove rechargeable batteries from the toy before
recharging them.
• Rechargeable batteries are only to be charged under adult
supervision.
• Please respect the correct polarity, (+) and (-).
• Do not dismantle batteries of any type.
• Do not try to charge non-rechargeable batteries.
• Do not throw batteries into the fire.
• Replace all batteries of the same type/brand at the same
time.
• Do not short-circuit the battery contacts.
• Remove exhausted batteries from the toy.
• Batteries should be replaced by adults because of small
parts.
• Remove batteries if the toy is not going to be played with
for some time.
"AA"/
LR 6/
UM3/
1.5V
"AA"/
LR 6/
UM3/
1.5V
Bottom view
"9V"
6LR61
"9V"
6LR61
Top view
To replace battery,
unscrew the screw on
batteries case (as shown in
illustration) and replace
batteries.
1) Remove the battery compartment cover using
a Phillips or crosshead screwdriver (not
included).
2) Insert 1 x 9V battery (not included) into the
controller as shown in the diagram.
3) Replace the battery compartment cover and
the screw.
1) Remove the battery compartment cover using a Phillips
or crosshead screwdriver (not included).
2) Insert 6 x AA batteries (not included) into the car as
shown in the diagram.
3) Replace the battery compartment cover and the screw.
To replace
batteries,
unscrew
mutiple the
screw on
batteries case
(as shown in
illustration)
and replace
batteries.
To replace
batteries,
unscrew
mutiple the
screw on
batteries case
(as shown in
illustration)
and replace
batteries.
Short Mode Stretch
Mode
• Turn on the Jet Car and the controller using the On/Off switches.
• The power indicator light on the controller will glow as long as the battery has power.
• Turn on the Jet Car and the controller using the On/Off switches.
• The power indicator light on the controller will glow as long as the battery has power.
Cockpit Up Stretch Mode Cockpit Up Short Mode
While the Astro-
Flex is in Short
Mode, press and
hold the Cockpit
Up button to lift up
the cockpit. The
stabilizer arm is
now at the front.
While the Astro-
Flex is in Short
Mode, press and
hold the Cockpit
Down button to lift
up the stabilizer
arm and change
the car into
Stretch Mode.
While the Astro-
Flex is in Stretch
Mode, press and
hold the Cockpit
Up button to lift up
the cockpit. The
stabilizer arm is
now at the rear.
While the Astro-
Flex is in Stretch
Mode, press and
hold the Cockpit
Down button to lift
up the stabilizer
arm to return the
Astro-Flex to Short
Mode.
• Never drive your Astro-Flex on the streets.
• Do not pick up the vehicle while it is in motion.
• Keep fingers, hair and loose clothing away from the tires and wheels while the vehicle is in motion.
• Do not drive the vehicle through water.
• For best results, hold the antenna up, not pointing down towards the vehicle.
• Drive safely!
• When you have finished playing, make sure that you turn the On/Off switch on the controller and the Jet Car to "Off".
• Remember that when the vehicle is coming towards you, it will steer in the opposite direction to the way you turn the wheel. Try to imagine that you are in the driver’s seat to work out
the direction it will turn in.
• Keep fingers, hair and loose clothing away from the tires and wheels while the vehicle is in motion.
• Never drive your Jet Car on the streets.
• Do not pick up the vehicle while it is in motion.
• Do not drive the vehicle through water.
• For best results, hold the antenna up, not pointing down towards the vehicle.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Please keep these instructions as they contain important information
Driving Tips:
Practice using the Cockpit Up and Down buttons while driving for quick twists, spins, flips and stunts.
Remember that when the vehicle is coming towards you, it will steer in the opposite direction to the way you turn the wheel. Try to imagine that you are in the
driver’s seat to work out the direction it will turn in.
When you have finished playing, make sure that you turn the On/Off switch on the controller and Astro-Flex to "Off".
