Wuxi iData Technology IDATA95W New Mobile Computer User Manual iData 95W
WUXI IDATA TECHNOLOGY COMPANY LTD. New Mobile Computer iData 95W
User Manual
iData 95W Datasheet
Wuxi iData Technology Company Ltd.
iData 95W
The iData 95W is a new mobile computer developed by Wuxi iData
Technology Company Ltd. for mobile field service. It is designed to
connect your mobile workforce to the enterprise for real-time access to
business information and data exchange.
Adopting Android 4.4 operating system, the iData 95W provides user
friendly operation interface, supports versatile functions like 1D/2D
barcode scanning, RFID tag reading, NFC, infrared communication
modules, GPS, photographing, voice communication, and Wi-Fi, and is
widely used in various fields, such as retail, manufacturing, fast moving
consumer goods, clothing, food safety tracing, logistics, warehousing,
governments and public utilities. Featuring high performance and high
reliability, the iData 95W can help enterprises boost productivity and
gain a higher return on investment.
Five strengths
Advanced configuration
Android 4.4 operating system for more compatibility and better user experience;
High-performance quad-core 1.3 GHz processor and 8GB ROM + 1GB RAM memory
for higher running speed;
Supporting the G-sensor function to use corresponding software according to users’
actions.
Industrial-grade capacitive touch panel
Industrial-grade capacitive touch panel for easy operation and higher flexibility;
Supporting operation with gloves and meeting the requirements for mobile operation
in complex environments such as low temperature and field;
Equipped with a 3.5-inch RETINA display screen with higher resolution (640 x 960
pixels).
Powerful data collection
Equipped with advanced scanning engines to read not only 1D/2D barcodes normally
printed on traditional media, stained, or covered with plastic film but also barcodes
displayed on mobile phones and computer screens;
Exit window made of Corning Gorilla glass for a better scratch-resistance, a higher
light transmittance, and more quick and accurate scanning;
Equipped with built-in RFID read/write modules to quickly and accurately read RFID
tags in batches.
Multiple wireless communication modes
Supporting WCDMA/ GPRS/HSPA+/GSM in a wireless wide area network (WAN) and
other wireless communication modes;
Supporting Wi-Fi transmission in a local area network (LAN);
iData 95W Datasheet
Wuxi iData Technology Company Ltd.
Supporting NFC transmission, convenient pairing;
Supporting a high performance GPS navigation chip for more accurate positioning.
Fast charging scheme
Supporting fast charging scheme for higher work efficiency;
Adopting a 3.7V 4000 mAh rechargeable lithium polymer battery (6000 mAh battery
optional) for long time mobile operation.
Main Functions
Supporting Android 4.4 operating system
Supporting WCDMA / HSPA+ / GPRS / GSM, Wi-Fi, NFC and other wireless
communication modes
Supporting 1D/2D barcode scanning or image scanning
Supporting a 13.56 MHz HF RFID read/write module for RFID tag reading
Supporting an IR communication module for data collection
Supporting a built-in autofocus 5 Mega pixel camera for photographing and video
recording
Technical Specifications
System Configuration
CPU
High-performance quad-core 1.3 GHz processor
Operating System
Android 4.4
Memory
8 GB ROM+1 GB RAM
Expansion Slot
Mini SD card, up to 32 GB
Display
3.5-inch RETINA display (640 x 960)
Touch Panel
Industrial-grade capacitive touch panel (supporting operation
with gloves)
Camera (optional)
5 Mega pixel, autofocus lens, LED flash
Exit Window
Corning Gorilla glass
Keypad
Durable industrial keypad with interior transmission light
Battery
3.7 V 4000 mAh rechargeable lithium polymer battery
(6000 mAh battery optional)
Audio
Built-in microphone
Notification
Vibrator alerts/LED/Audio notification
Vibration Motor
Built-in programmable vibration motor
Sensor
Built-in G-sensor
Operating Environment
Development Tools
Android SDK + JDK + Eclipse
Programming Language
Java, C
Management Tools
iData tools
Operating Temp.
-10℃ to 50℃
Storage Temp.
-20℃ to 60℃
Relative Humidity
0 to 95% (non-condensing)
iData 95W Datasheet
Wuxi iData Technology Company Ltd.
Drop Specification
1.5-meter drops to concrete ground
Tumble Specification
500 0.5-m tumbles (1000 hits)
Sealing
IP65
Electrostatic Discharge
Conforms to 15 kV air discharge, 8 kV direct discharge
Structural Parameters
Dimensions (LxWxD)
152 mm x 68 mm x 24 mm
Weight
255 g (standard battery included)
Communication Transmission
Wireless Voice
Communication
3G: WCDMA 850/2100MHz
2G: GSM 850/900/1800/1900MHz
Wireless WAN
WCDMA/ GPRS/ HSPA+
Wireless LAN
Wi-Fi 802.11b/g/n
GPS
High performance GPS navigation chip
Input/Output Ports
USB Port
1 ( Micro USB port)
Charger Port
1(Charging interface at the bottom)
Headset Port
1
Serial Port
1(TTL)
1D Laser Scanner
Optical Resolution
4 mil
Scan Depth of Field
3.81 cm - 60.98 cm
Scan Angle
47° 3° (Standard)
Scan Speed
102 12 scans/sec. (Bidirectional)
1D Linear Imager
Reading Mode
CCD
Reading Accuracy
4 mil
Decoding Speed
300 times/sec. (Max.)
2D Area Imager
Optical Resolution
3 mil
Scan Angle
Omnidirectional
Scan Speed
300 scans/sec.
Infrared Communication Module
Built-in Infrared
Communication Module
Structure with two emitting tubes, meter reading distance of up
to 5 meters, fully supporting DL/T645 protocol and
communication protocols of worldwide mainstream meter
manufacturers
Interface
Initial rate: 1200 bps, supported rates: 1200, 2400, 4800, and
9600 bps
RFID
iData 95W Datasheet
Wuxi iData Technology Company Ltd.
Frequency
13.56 MHz
Reading Distance
Within 50 mm
Protocol
ISO14443A/14443B/15693
NFC
Optional
Accessories
Standard
Battery, Bottom charging cable , Hand strap
Optional
1-slot charging & communication stand, 4-slot battery charger,
Silicon Case, Smart pen
Wuxi iData Technology Company Ltd.
Add: Floor 11, Building B1, Wuxi (Binhu) National Sensing Information
Center, No.999 East Gaolang Road, Wuxi City, P.R.C.
E-mail: idata@idatachina.com
Website: www.idatachina.com
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
iData 95W Datasheet
Wuxi iData Technology Company Ltd.
Specific Absorption Rate (SAR) information:
This New Mobile Computermeets the government's requirements for exposure to radio
waves. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety of all
persons regardless of age or health.
FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg
averaged over one gram of tissue. Device types: iData 95W (FCC ID:
2ADE3IDATA95W) has also been tested against this SAR limit. The highest SAR value
reported under this standard during product certification for use at the ear is
0.28W/kg and when properly worn on the body is 0.68W/kg. This device was tested
for typical body-worn operations with the back of the handset kept 1.0cm from the
body. To maintain compliance with FCC RF exposure requirements, use accessories
that maintain a 1.0cm separation distance between the user's body and the back of
the handset. The use of belt clips, holsters and similar accessories should not contain
metallic components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and should be
avoided.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF
exposure requirements, a minimum separation distance of 1.0 cm must be
maintained between the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do not meet these
requirements may not comply with RF exposure requirements and should be
avoided. Use only the supplied or an approved antenna.
