Users Manual
XceedID p/n 0093-01
INSTALLATION SHEET
Series 1100 (preliminary)
PARTS LIST:
• 1 - Installation Sheet
• 1 - Reader
• 2 - Mounting Screws
• 1 - Security Screw
Removal:
1. Remove unit from box.
2. Notice the connector on the inside of the cover plastic and the base unit plastic. The
connector will end up at the top side of the reader when mounted. (ILLUSTRATION)
Mounting the Reader:
1. Determine an appropriate mounting position on the door frame or wall, be sure to
account for any applicable ADA height requirements.
2. Drill two mounting holes a minimum of 3.2” apart on the mounting surface of the door
frame or wall. Drill one 3/4” diameter cable hole for the pigtail wire connection.
(ILLUSTRATION)
3. Following cable connection (see the cable connection diagram below), re-install the
plastic cover to the reader base. The base male connectors should align with the cover
connector holes and the bottom slot should easily slide over and snap into place over
the plastic dimple of the base. After ensuring connection, install the security screw on
the bottom of the reader.
Cable Connections:
1. XceedID readers are supplied with a 12 conductor cable pigtail. Connect this pigtail with
the host/panel being careful to match the color of each wire with the chart shown below.
(ILLUSTRATION)
Yellow = Beeper
Blue = Hold
Purple = Open Collector/Card present
Green = Data 0
White = Data 1
Orange = Green LED
Brown = Red LED
Red = Power +DC (6-16 VDC)
Black = Ground
Pink = RQE (Request to Exit input)
Grey = DI (Door DI Input)
Tan = Tamper Output
Drain = Shield Ground
XceedID p/n 0093-01
2. Use a linear DC power source between 6 volts and 16 volts.
3. Be sure the reader is properly grounded by attaching the ground wire to an earth ground
connection at the power supply or panel end of the cable.
Testing the Reader:
1. Power up the reader. The LED will light followed by a beeper tone. This indicates that
the reader is ready.
2. Present a proper card or token programmed to operate the reader and a green LED
flash will indicate successful operation. Note that a red flash could simply indicate an
incorrect match or mis-programmed card/token rather than a faulty reader installation.
Additional Notes:
• The voltage specification for these products is 6 volts to 16 volts. Higher voltage within
these specifications will result in better performance.
• Typical cable guage ranges from 18 to 22 guage. Check with your cable supplier to
determine the best choice for your application and installation distance.
Specifications:
• Power Supply: Linear DC
• Voltage Range: 6 – 16VDC
• Temperature Range: -25F to 125F
• Card Read Distance: Up to 4.5” – Distance can vary widely depending on installation
conditions and credential type.
• Cable Distance to Panel in Wiegand mode:
o 500 ft. maximum at 12 volts
o 200 ft. maximum at 6 volts
• Information Output: Wiegand = 64 bits; RS485 = 128k bits per second
• Tamper Output: Open Collector
• Regulatory Approvals and Standards
UL
ISO15693
ISO14443A
Europe: CE Listed.
Federal Communications Statement:
The FCC requires the following statement for your information:
This reader utilizes and radio frequency energy and has been tested and complies with the limits
of FCC testing. Changes, modifications or disregard of proper installation instructions not
expressly approved by XceedID Corporation is strictly prohibited by the FCC and could void the
user’s authority to operate the equipment.
For Canadian Users:
This unit has been tested and meets all applicable Industry of Canada technical specifications.
• This device may not cause radio frequency interference.
• This device must accept radio frequency interference.
In the unlikely event interference occurs, please contact the manufacturer.
XceedID p/n 0093-01
