Xhorse Electronics S01 Universal Remote Key User Manual 10003 2002
Shenzhen Xhorse Electronics Co., Ltd. Universal Remote Key 10003 2002
User Manual
Universal Remote Key User Manual
Overview：
Xhorse universal remote key is suitable for vehicle and garage door which contains the Xhorse receiver.
Button Description:
Item
Description
1
switch button for mechanical key
2
lock button of vehicle or garage door
3
unlock button of vehicle boot
4
unlock botton of vehicle or garage door
Change battery：
First use or when the battery runs out need to change new battery, following steps:
1, pull the cover as the picture remarked
direction
2, remove the plastic as the picture remarked
direction
3, take the battery out and replace new one
（Notes:the battery type is 2032 with 3
voltage,ensure the positive and negative of
battery is correct）
4, install the key same as before
While holding the lock and unlock key, the radio frequency of the remote control can be switched between
433.92MHz and 315MHz so to change to control the vehicle and garage door, as shown in the figure below;
Pairing method：
1)Pairing with vehicle: Referring to the corresponding vehicle models to match.
2) Pairing with garage door: Press the “learn” button of receiver for 2-3 seconds, then you can see the receiver led
light on, press your remote 4-5 time, after that, the receiver led light will continuous flashing, when it off, pairing
successes. If failed to match the receiver, please repeat the above method.
If you want to control both vehicle and garage, please separate the frequency.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
