Xiaomi Communications H2X819 Mobile Phone User Manual H2X EN A 20150109
Xiaomi communications Co., Ltd Mobile Phone H2X EN A 20150109
User manual
![](/img.php?id=2793309&img=bg1.png)
Redmi 2 User Guide
USB Port
LED Indicator
Home Button
Task Button Back Button
Front Camera
Power Button
Volume Button
Long press this button to turn the device on or off.
Adjust the sound volume. Press this button when there is
an incoming call to switch to silent mode.
Supports USB On-The-Go function.
Power Button
Volume Button
USB Port
Xiaomi's ofcial website: www.mi.com.
This user guide will take you through the basic steps to
set up your Redmi 2.
For more information, see:
Thank you for choosing Redmi 2
![](/img.php?id=2793309&img=bg2.png)
1. Insert a memory card, contact area
facing downwards, into the card slot;
2. You will hear a clicking sound when
the memory card is locked in place.
The installation is complete.
Warning: Please safely uninstall or switch off the
device before inserting or removing the memory card.
Otherwise system problems may occur.
Insert or Remove a Memory Card
Make sure the Micro SIM or UIM card's metal contacts
are facing down and its cut-off corner is facing the left.
Warning: Redmi 2 Micro SIM or UIM card is
positioned above the battery.
You need to remove the battery before inserting
or removing the SIM/UIM card.
Insert the Micro SIM or UIM Card
Align the battery's exposed copper contacts with
the battery compartment, and insert the battery
by pressing down gently;
Remove the battery by pulling outward gently
from the notch at the base of the battery compartment.
Insert or Remove the Battery
To remove your phone's back cover, press down on
the middle of the back cover while pulling up gently
at the notch as indicated.
Removing the Back Cover
A-P-XXXX
