XinHuaMei Electronics BTH105 Bluetooth Headphones User Manual
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Headphones
User Manual
Bluetooth Headphones
BT-H105
INSTRUCTIONS MANUAL
PLEASE READ ALL INSTRUCTIONS
CAREFULLY AND RETAIN FOR FUTURE USE
1
Getting started
Remove the Bluetooth headphones & accessories
from the box.
Remove all packaging from the Bluetooth
headphones.
Place the packaging inside the box to either store
or dispose of safely.
In the Box
Bluetooth Headphones
USB Charging Cord
3.5mm AUX Cord
Instructions Manual
Features
Easy to switch between calls and music, you will
not miss the incoming call whilst listening to music
Answer & end a call at click of a button.
Redial last number
Volume control knob
Media Control (pause/play, previous track/next
track)
Every time the Bluetooth headphones is turned on,
2
it connects to last connected device automatically
Safety Instructions
Read this manual carefully before putting the
appliance into operation and keep this manual for
future reference.
Do not use the unit with wet hands.
To minimize the risk of fire or electrical shock,
avoid operating in wet conditions such as rain or
humidity. Do not operate around water (e.g.
bathroom, swimming pool, etc.)
Do not insert any metal object into the device.
To avoid a static charge, do not use the device in
an extremely dry climate.
Do not attempt to repair the device yourself.
Batteries (battery pack or batteries installed) shall
not be exposed to excessive heat such as
sunshine, fire or the like.
3
Description of Parts
1 Retractable headband
2 Vol-
3 Vol+
4 Power On/Off
5 Rotary Vol knob
6 PREV
7 NEXT
8 Play/Pause/Phone button
9 3.5mm AUX input jack
10 Micro USB charging port
11 Built-in Microphone
12 LED indicator
4
Charging Instructions
This Bluetooth headphones have a built in
rechargeable battery. Before using it for the first time
we recommend you charge the battery fully. Only use
the supplied USB cable to charge the Bluetooth
headphones.
1. Connect the USB cable to the USB port on the
unit.
2. Connect the other end of the USB cable to a USB
port on a PC or an AC/DC adapter. The LED
indicator turns red to indicate that the battery is
being charged. When the battery is fully charged,
the red LED indicator will turn off.
Pairing the Bluetooth headphones with
Bluetooth devices (phone or music device)
1. Turn on the headphones.
2. Turn on your Bluetooth enabled device and
activate the Bluetooth function.
3. Search for the Bluetooth device, “BT-H105” will
show up.
4. Pair your Bluetooth enabled device with BT-H105.
If a password is needed, type in “0000”. After the
5
BT-H105 is paired with your device, connect it to
your device.
Tips:
Once the headphones is paired and connected to your
Bluetooth device, it automatically connects the next
time as long as the Bluetooth on your device is turned
on.
Control a phone call via headphones
Answer a call: Short press the Phone button.
End a call: Short press the Phone button.
Redial the last number: Press the phone button twice
quickly.
6
Using AUX input
The AUX input function allows you to use your
headphones without using the battery and the
Bluetooth connection.
Note: Please switch off the headphones when using
AUX input.
Care and Maintenance
Read the following recommendations before using the
Bluetooth headphones. Following these you will be
able to enjoy the product for many years.
Do not expose the Bluetooth headphones to liquid,
moisture or humidity to avoid the product’s internal
circuit being affected.
Don’t use abrasive cleaning solvents to clean the
Bluetooth headphones.
Do not expose the Bluetooth headphones to
extremely high or low temperature as this will
shorten the life of electronic devices, destroy the
battery or distort certain plastic parts.
Don’t dispose of the Bluetooth headphones in a
fire as it will result in an explosion.
7
Don’t expose the Bluetooth headphones to contact
with sharp objects as this will cause scratches and
damage.
Don’t let the Bluetooth headphones fall on the floor.
The internal circuit might get damaged.
Don’t attempt to disassemble the Bluetooth
headphones as it may get damaged if you are not
professional.
In case the Bluetooth headphones doesn’t function
properly, send it to the store you bought it. The staff
will help you to the problem.
8
Specifications
Bluetooth profiles HSP, HFP, A2DP and
AVRCP
Bluetooth operating
distance
10 meters (equal to 33 feet)
Frequency range 2.4-2.48GHz
Frequency response 100Hz-20kHz
Distortion ≤1%
Microphone sensitivity -40db
Working time Up to 6 hours playing and 8
hours talk time
Charging input power DC 5V
Charging time Approx 3 hours
Unit size 165*80*175mm
Unit weight Approx. 200g
Note: Battery life & charging time may vary, based on
usage & types of devices used.
9
FCC Statement:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
10
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Note: Modifications to this product will void the
user’s authority to operate this equipment.
