XinHuaMei Electronics BTS-03 Bluetooth Speaker User Manual BTS 03
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Speaker BTS 03
User Manual
Thank you for choosing our product. You Product overview Accessories included
will enjoy its sound and form. 1. Line-in cable
2. USB charging cable
BLUETOOTH SPEAKER Safety instructions
Charge Integrated Battery
BTS-03 Read this manual carefully before putting
the appliance into operation and keep this This Bluetooth speaker is powered by
manual for future reference.
USER MANAL integrated rechargeable lithium battery.
Charge the battery as follows:
Do not use the device with wet hands. 1. Insert the Micro USB plug into the DC
To minimize the risk of fire or 5V socket on the unit. Connect the USB
electrical shock, subject the device plug into a PC or AC/DC adaptor. The
neither to rain nor to humidity. Do not DC 5V AUX LED indicator LED indicator turns red and the battery
operate the device in the direct is being charged.
proximity of water (e.g. bathroom, 2. When the battery is fully charged, the
swimming pool, etc.). red LED indicator goes out.
Keep the device away from heat,
direct sunlight and sharp edges. Pairing BTS-03 to mobile phone
Keep the device away from naked or other device
flames.
Do not insert any metal object into the
device. Risk of short circuit!
Do not use device in an extremely
humid or muggy environment.
To avoid a static charge, do not use
the device in an extremely dry climate.
Do not repair the unit yourself but On/Off switch
contact an authorised specialist.
1. Switch on the speaker.
2. Turn on your mobile phone and activate
the Bluetooth function.
3. Search for Bluetooth devices. BTS-03
will show up.
4. Pair your device with BTS-03. If
password is needed, type in “0000".
After BTS-03 is paired with your
device, connect it to your device.
Once this speaker is paired and connected Troubleshooting Technical Specifications
to your mobile phone, next time when you
switch on this speaker, it will connect to Audio connection: Bluetooth, and 3.5mm
your mobile phone automatically as long stereo jack plug
as the Bluetooth in your mobile phone is Bluetooth version: 3.0
on. Range: 10 meters
Transmitting frequency: 2.4G Hz
Power supply: DC5v/100-120mA
Button description Battery: 3.7v 400mAh lithium
Charging time: approx. 3 hours
Operating time: approx. 6 hours
Unit weight: approx. 0.229kg
Notes & tips:
1. When using line-in (AUX) function, the
volume control on the speaker has no
function.
- Volume down
+ Volume up
1. To pick up a phone call, press
this button quickly.
2. To reject a call, press and hold
this button for about 2 seconds.
3. To redial the latest phone
phone number, press this
button twice quickly.
Symptoms
Causes
Solutions
Can not
switch the
speaker on
Battery
empty
Charge the
battery
No sound
when
playback
via
Bluetooth
AUX cable
is
connected
Remove the
AUX cable
Volume
control no
function
You are
using
speaker
via AUX
Control the
volume through
the audio source
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment。
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The antenna(s) used for this device must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.
FCC ID: R8H-BTS-03
This device complies with Part 15 of
the FCC Rules. Operation is subject
to the following two conditions: (1)
this device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may
cause undesired operation.
