XinHuaMei Electronics BTS-19 Bluetooth Shower Speaker User Manual WATERPROOF BLUETOOTH
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Shower Speaker WATERPROOF BLUETOOTH
Manual
WATERPROOF HYRID
BLUETOOTH® SHOWER SPEAKER
AUTO FM SHOWER RADIO
BTS-19 USER MANAL
Product Overview
Thank you for choosing our product. We hope you
will enjoy it very much.
Safety instructions
Read this manual carefully before putting the
appliance into operation and keep this manual for
future reference.
﹒Keep the device away from heat, direct sunlight
and sharp edges.
﹒Keep the device away from naked flames.
﹒Do not insert any metal object into the device.
Risk of short circuit!
﹒To avoid a static charge, do not use the device in
an extremely dry climate.
﹒Do not repair the unit yourself but contact an
authorised specialist.
Accessories included
1pc USB charging cable
Charge Integrated Battery
This shower speaker is powered by integrated
rechargeable polymer lithium battery. Charge the
battery as follows:
1 Insert the charging cable into the DC 5V socket
on the unit. Connect the USB plug into a PC or AC
/DC adaptor. The LED indicator turns red and the
battery is being charged.
2 When the battery is fully charged, the red LED
indicator goes out.
Tips:
Our speaker support to show remain battery
capacity in iOS devices.When Bluetooth conected,
please check remain battery on top of the iOS
devices:
Our speaker also support Siri talking in iOS devices,
please quickly press phone button twice to active
Siri and talk via our speaker microphone:
Pairing BTS-19 to mobile phone or other device
1. please press power button to turn on the speaker,
you a tinkle sound and see red|&pink&blue LED
twinkling.
2. now you can search and find the shower speaker
name BTS-19 on your mobilephone, pair your
device with BTS-19 (if password is needed please
tpye in “0000”.
3. After BTS-19 is paired with your device, play
music and enjoy it in wireless
Tips:
Once this speaker is paired and connected to your
mobile phone, next time when you switch on this
speaker, it will connect to your mobile phone
automatically as long as the Bluetooth in your
mobile phone is on
Button description
1. LED indicator: shows working status.
2. Multi button: power on/off, Bluetooth/FM
switch
3. Phone button: music play/pause, phone
answer/hangup/redial/active Siri
4. Micrphone: speak towards the microphone
5. Previous button: previous music, volume down,
frquency down search.
6. Next Button: next music, volume up, frequency
up search.
FM radio function:
When the speaker in power on, please press multi
function button to switch on FM radio function and
hold press on previous/next button to select local
broadcasting.
You may onect with accessory USB cable to
improve FM effect.
Troubleshooting
Symptoms Causes Solutions
Cannot
power on
the speaker
Battery
empty Recharge the
battery
Unable to
pair the
speaker
Speaker is
paird with
other
device
Trun other
device
Bluetooth off
then repair
No FM
radio FM signal
is too weak Connect with
accessory USB
charge cable to
increase signal
Cannot
active Siri Siri is not
turn on at
iOS device
Turn on iOS
Siri function
No music
sound Volume is
too small Turn volume
up by hold and
press
Technical Specifications
Bluetooth support: 3.0+EDR
Range: 10 meters
Bluetooth frequency: 2.4G Hz
FM Frequency: 87.8-108.0MHz
Power supply: DC5V/100-120mA
Battery: 3.7V 500mAh polymer lithium
Charging time: approx. 3 hours
Operating time: approx. 8 hour
IP grade: IPx4
Unit weight: approx. 0.16kg
FCC Statement:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: Modifications to this product will void the user’s authority to operate this equipment.
