User Manual-Draft
Floating Bluetooth
speaker
BTS-21
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS
CAREFULLY AND RETAIN FOR FUTURE USE
1
Getting started
Remove the Bluetooth speaker & accessories
from the box.
Remove all packaging from the Bluetooth speaker.
Place the packaging inside the box to either store
or dispose of safely.
In the Box
Bluetooth Speaker
USB Charging Cord
Instruction Manual
Features
Enjoy music wirelessly
Floating above water.
Built-in FM radio
Volume Control
Media Control (pause/play, previous track/next
track)
Every time the Bluetooth speaker is turned on, it
connects to last connected device automatically
2
Safety Instructions
Read this manual carefully before putting the
appliance into operation and keep this manual for
future reference.
Do not insert any metal object into the device.
To avoid a static charge, do not use the device in
an extremely dry climate.
Do not attempt to repair the device yourself.
Batteries (battery pack or batteries installed) shall
not be exposed to excessive heat such as
sunshine, fire or the like.
WARNING!
In order to avoid damage to the product, make sure
the upper part and the lower part of the product is
screwed firmly before putting this product into the
water.
3
Description of buttons
Power on/off, Mode (switch between Bluetooth
function and FM radio).
Previous track, volume down (press and hold)
Play/Pause/Mute
Next track, volume up (press and hold)
Charging Instructions
This Bluetooth speaker comes with a built in
rechargeable battery. Before using it for the first time
we recommend you charge the battery fully.
1. Screw off the top of the speaker.
2. Connect the USB cable to the micro USB port on
the unit.
3. Connect the other end of the USB cable to a USB
port an AC/DC adapter. The red LED turns on
indicating the battery is being charged. When the
battery is fully charged, the LED will turn off.
4. The USB port not transfer data with PC.
4
Illustration of USB charging port
Pairing the Bluetooth speaker with Bluetooth
devices (phone or music device)
1. Turn on the Bluetooth speaker.
2. Turn on your Bluetooth enabled device and
activate the Bluetooth function.
3. Search for the Bluetooth device, “BTS-21” will
show up.
4. Pair your Bluetooth enabled device with BTS-21. If
a password is needed, type in “0000”. After the
BTS-21 is paired with your device, connect it to
your device.
5
Tips:
Once the speaker is paired and connected to your
Bluetooth device, it automatically connects the next
time as long as the Bluetooth on your device is turned
on.
How to use the FM radio
This Bluetooth speaker comes with a FM radio. Button
function is as below:
Switch between Bluetooth function and FM
radio.
Short press to choose radio station, long press
to reduce volume.
Short press to choose radio station, long press
to increase volume.
Press once to mute the radio, press and hold for
3 seconds to auto scan radio stations.
6
Specifications
Bluetooth version 3.0
Bluetooth operating
distance
10 meters (equal to 33 feet)
Frequency range 2.4-2.48GHz
Output power 5 watts
Frequency response 100Hz-20kHz
Distortion ≤1%
FM frequency 87.5-108 MHz
Microphone sensitivity -40db
Playback time 4 hours
Charging input power DC 5V
Charging time Approx 3 hours
Unit size 96*96*150 mm
Unit weight Approx. 400g
Waterproof grade IPx7
Note: Battery life & charging time may vary, based on
usage & types of devices used.
7
FCC Statement:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
8
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
This device complies with part 15 of the FCC rules.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Note: Modifications to this product will void the
user’s authority to operate this equipment.
