XinHuaMei Electronics BTS-25 Bluetooth Speaker User Manual BTS 25 generic
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Speaker BTS 25 generic
User Manual
Bluetooth speaker
BTS-25
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS
CAREFULLY AND RETAIN FOR FUTURE USE
1
Getting started
Remove the Bluetooth speaker & accessories
from the box.
Remove all packaging from the Bluetooth speaker.
Place the packaging inside the box to either store
or dispose of safely.
In the Box
Bluetooth Speaker
USB Charging Cord
Instruction Manual
Features
Enjoy music wirelessly
Easy to switch between calls and music, you will
not miss the incoming call whilst listening to music
Answer & end a call at click of a button.
Redial last number
Volume Control
Media Control (pause/play, previous track/next
track)
Every time the Bluetooth speaker is turned on, it
connects to last connected device automatically
2
Safety Instructions
Read this manual carefully before putting the
appliance into operation and keep this manual for
future reference.
Do not insert any metal object into the device.
To avoid a static charge, do not use the device in
an extremely dry climate.
Do not attempt to repair the device yourself.
3
Description of Parts
1 Power ON/OFF button
2 Phone button
3 Long press: volume up; short press: next track
4 LED indicator
5 USB charging port
6 Long press: volume down; short press: previous
track
7 Built-in mic
4
Charging Instructions
This Bluetooth speaker comes with a built in
rechargeable battery. Before using it for the first time
we recommend you charge the battery fully. Only use
the supplied USB cable to charge the Bluetooth
speaker.
1. Connect the USB cable to the USB port on the
unit.
2. Connect the other end of the USB cable to a USB
port on a PC or an AC/DC adapter. The LED
indicator turns red to indicate that the battery is
being charged. When the battery is fully charged,
the red LED indicator will turn off.
Pairing the Bluetooth speaker with Bluetooth
devices (phone or music device)
1. Turn off the speaker. Make sure the speaker is
power off before going to the next step.
2. Press and hold the Power ON/OFF button until the
red LED light flashes, now the Bluetooth speaker
is ready for pairing.
3. Turn on your Bluetooth enabled device and
activate the Bluetooth function.
5
4. Search for the Bluetooth device, “BTS-25” will
show up.
5. Pair your Bluetooth enabled device with BTS-25. If
a password is needed, type in “0000”. After the
BTS-25 is paired with your device, connect it to
your device.
Tips:
Once the speaker is paired and connected to your
Bluetooth device, it automatically connect the next
time as long as the Bluetooth on your device is turned
on.
Control a phone call via speaker
Answer a call: Short press the Phone button.
End a call: Short press the Phone button.
Reject a call: Press and hold the Phone button for
around 2 seconds.
Redial the last number: Press the phone button twice
quickly.
6
Care and Maintenance
Read the following recommendations before using the
Bluetooth speaker. Following these you will be able to
enjoy the product for many years.
Do not expose the Bluetooth speaker to extremely
high or low temperature as this will shorten the life
of electronic devices, destroy the battery or distort
certain plastic parts.
Don’t dispose of the Bluetooth speaker in a fire as
it will result in an explosion.
Don’t expose the Bluetooth speaker to contact
with sharp objects as this will cause scratches and
damage.
Don’t let the Bluetooth speaker fall on the floor.
The internal circuit might get damaged.
Don’t attempt to disassemble the Bluetooth
speaker as it may get damaged if you are not
professional.
In case the Bluetooth speaker doesn’t function
properly, send it to the store you bought it. The staff
will help you to the problem.
7
Specifications
Bluetooth profiles HSP, HFP, A2DP and
AVRCP
Bluetooth operating
distance
10 meters (equal to 33 feet)
Frequency range 2.4-2.48GHz
Frequency response 100Hz-20kHz
Distortion ≤1%
Microphone sensitivity -40db
Working time Music time 6 hours, talk
time 10 hours
Charging input power DC 5V
Charging time Approx 3 hours
Unit size 96*96*41mm
Unit weight Approx. 150g
Note: Battery life & charging time may vary, based on
usage & types of devices used.
8
FCC Statement:
This equipment has been tested and found to comply with the
limits for Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference
in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
9
This device complies with part 15 of the FCC rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: Modifications to this product will void the user’s authority to
operate this equipment.
