XinHuaMei Electronics BTS-C13 Bluetooth Speaker User Manual YM C13 English
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Speaker YM C13 English
User Manual
Bluetooth speaker
BTS-C13
INSTRUCTIONS MANUAL
PLEASE READ ALL INSTRUCTIONS
CAREFULLY AND RETAIN FOR FUTURE USE
Getting started
1
• Remove the Bluetooth speaker & accessories
from the box.
• Remove all packaging from the Bluetooth speaker.
• Place the packaging inside the box to either store
or dispose of safely.
In the Box
• Bluetooth Speaker
• USB Charging Cord
• AUX in cable
• Instructions Manual
Features
• Portable Bluetooth Speaker with carabiner
• Built-in hands free microphone.
• AUX input function
• Support TF card.
• Redial last number
• Every time the Bluetooth speaker is turned on, it
connects to last connected device automatically
Safety Instructions
Read this manual carefully before putting the
2
appliance into operation and keep this manual for
future reference.
l Do not insert any metal object into the device.
l To avoid a static charge, do not use the device in
an extremely dry climate.
l Do not attempt to repair the device yourself.
l Batteries (battery pack or batteries installed) shall
not be exposed to excessive heat such as
sunshine, fire or the like.
Description of Parts
3
1 Power On/Off
2 Vol-/Prev
3 Play/Pause/Phone button
4 Vol+/Next
5 DC5V micro USB charging port
6 AUX input jack
7 TF card slot
8 Mode (switch between Bluetooth pairing, TF
card, and AUX input mode)
Charging Instructions
This Bluetooth speaker comes with a built in
rechargeable battery. Before using it for the first time
we recommend you charge the battery fully.
1. Connect the USB cable to the USB port on the
unit.
2. Connect the other end of the USB cable to a USB
port on a PC or an AC/DC adapter, the LED on the
speaker turns red, the Bluetooth speaker is being
charged. When the battery is fully charged, the red
LED turns off.
4
Pairing the Bluetooth speaker with Bluetooth
devices (phone or music device)
1. Turn on the Bluetooth speaker.
2. Turn on your Bluetooth enabled device and
activate the Bluetooth function.
3. Search for the Bluetooth device, “BTS-C13” will
show up.
4. Pair your Bluetooth enabled device with BTS-C13.
If a password is needed, type in “0000”. After the
BTS-C13 is paired with your device, connect it to
your device.
Tips:
Once the speaker is paired and connected to your
Bluetooth device, it automatically connects the next
time as long as the Bluetooth on your device is on.
Control a phone call via speaker
Answer a call: Short press the button.
5
End a call: Short press the button.
Redial the last number: Press the phone button twice
quickly.
Specifications
Bluetooth profiles HSP, HFP, A2DP and
AVRCP
Bluetooth operating
distance
10 meters (equal to 33 feet)
Frequency 2402-2480MHz
Speaker output power 3w
Frequency response 100Hz-20kHz
Distortion ≤1%
Microphone sensitivity -40db
Playback time Approx 4 hours
Charging input power DC 5V
Charging time Approx 3 hours
Unit size 105*70*40 mm
Unit weight Approx. 176g
Note: Battery life & charging time may vary, based on
usage & types of devices used.
FCC Caution：
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
