XinHuaMei Electronics BTS518C Bluetooth Speaker User Manual 15 BTS 518C UserMan
Shenzhen XinHuaMei Electronics Limited Company Bluetooth Speaker 15 BTS 518C UserMan
15_BTS-518C UserMan
COLOR CHANGING
OUTDOOR
BLUETOOTH SPEAKER
USER MANUAL
Model No.: BTS-518C
Please kindly read this user manual before using the product carefully, and keep it for
future reference.
In the box
1. Bluetooth Speaker: x 1
2. Charging Cable: x 1
3. Remote control x 1
4. User Manual: x 1
Descriptions of parts
1
Power ON/OFF button
2
DC 5v input port
3
Bluetooth connect/disconnect
4
Light on/off
5
Power off (Standby)
6
Power on (Valid only when the speaker is in Standby mode)
7
Color selection
8
White light
9
Increase the light (valid for R/G/B light only)
10
Decrease the light (valid for R/G/B light only)
11
Light mode 1
Note: To save power consumption, please use the ON/OFF button on the bottom to turn off
the speaker completely. When you use the remote controller to turn off the speaker, the
speaker is actually in Standby mode.
Charging the speaker
To charge the Bluetooth speaker, connect the supplied micro USB cable to the USB charging
port and the other end to your computer or USB charging device.
Before using it for the first time we recommend you charge the battery fully.
Pairing your device with bluetooth speaker
1. Turn on the Bluetooth speaker.
2. Open Bluetooth function on your device and search for ”YM-518C”.
3. If required, enter the password ‘0000’ to confirm to finalize pairing.
4. Connect it with your bluetooth enabled device .
TECHNICAL SPECIFICATIONS
Bluetooth® version : V 4.2
Working distance : Up to 10 meters in open space
Speaker Output : 6 W
Frequency response : 80 Hz – 20 Khz
Charging input : DC 5 V
Playback time : Approx. 2-3hours
Charging time : Approx. 3-4hours
Rechargeable Battery : 1800mAh
Unit size : 200x200x223mm
12
Light mode 2
13
Light mode 3
14
One color light dances to the music
15
Multicolor light dances to the music
16
Mute the speaker
17
Play/Pause
18
Volume decrease
19
Volume increase
20
Previous
21
Next
Note: Battery life & charging time may vary, based on usage & types of devices used.
The product design and specifications may be changed subject of without prior
notice!
FCC Instructions
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
