Xinguodu Technology T2 POS terminal User Manual
Shenzhen Xinguodu Technology Co., Ltd. POS terminal Users Manual
User manual
1
NEXGO
T2 POS Terminal
User Guide
2
Version Information
Shenzhen Xinguodu Technology Co., Ltd.
Warning: No part of this publication may be reproduced, transmitted, stored in a retrieval system,
nor translated into any human or computer language, in any form or by any means, electronic,
mechanical, manual, or otherwise, without the prior written permission of Shenzhen Xinguodu
Technology Co., Ltd.
All trademarks mentioned are proprietary of their respective owners.
Version number：V 1.00
Notice
1. Install software well in this terminal;
2. Set up related number and password well in this terminal:
System manager number：99
Password of system manager：82112711
Merchant manager number：0
Password of merchant manager number：123456
operator：01, 02, 03, 04, 05
password of operator：0000
security password：12345678
3
Contents
SPECIFICATION OF POS TERMINAL ..................................................................................... 4
BASIC SETTING ............................................................................................................................ 5
Power on/off .................................................................................................................................. 5
Self-checking ................................................................................................................................ 6
Apps download ............................................................................................................................. 7
T2 setting of China UnionPay ............................................................................................... 8
Setting on T2 by Appointed merchants’ manager ....................................................................... 11
GENERAL FUNCTION OPERATION ...................................................................................... 12
Operator sign-in .......................................................................................................................... 12
Sales ............................................................................................................................................ 12
Void ............................................................................................................................................. 13
Refund ......................................................................................................................................... 13
Pre-authorization ......................................................................................................................... 13
Offline ......................................................................................................................................... 15
Query .......................................................................................................................................... 16
Response Test .............................................................................................................................. 16
Settlement ................................................................................................................................... 16
GENERAL MANAGEMENT OPERATION ............................................................................. 17
Reprint......................................................................................................................................... 17
Chargeback.................................................................................................................................. 17
Operation query .......................................................................................................................... 17
Outline......................................................................................................................................... 18
System standby ........................................................................................................................... 18
System information ..................................................................................................................... 18
4
Specification of pos terminal
Item Specifications
Processor Qualcomm CPU & Operating frequency of 500 MHz
Memory The large capacity 256MB FLASH, 128MB DDR3L SDRAM. Option to
be extended to 512M, 256M FLASH/DDR3L SDRAM.
OS Linux
Power Supply
External switch power
Input: 100V～240V AC，50/60Hz
Output: 8.5VDC, 2.5A
Working electric
current
power on current:50mA～150mA，printing average current:1A
Connectivity
1 power port，1 telephone line port,1 LAN port, 1 RS232,1 PINPAD port,
2 USB port(Only for data transmission)，1 SAM card，1 dual function
PSAM card，1 SD.
Magnetic Stripe
Reader
Track 1/2/3, bi-directional swipe, speed is 10mm/s-100 mm/s， GB/T
14916、GB/T 15120、GB/T 15694-1、ISO7812-2、GB/T 17552 compliant ,
High Coercively , Life cycle: above 500,000
IC Card Reader
Can read ISO7816 IC with card voltage range of 1.8V, 3V, 5V, can read
standard EMV card and memory card, with EMV 2000, PBOC 2.0
certifications approved
PSAM Slots 1 PSAM slot, Option to be extended to 2 slots, compliant to ISO7816
Printer
High-speed thermal printer, 20lines/second, resolution 8
dots/mm & paper end detection；average print without malfunction
over 10 kilometers（over 50,000 POS sheet）， Life cycle：the length of
paper is over 50 kilometers（over 250,000 POS sheet）
LCD 320*240 LCD with adjustable backlit
Keypad
20 keys with waterproof and dustproof, 10 alphanumeric keys，9 function
keys，1 on/off switch, supports to input figure and letter，
the life cycle of
key is over 300.000 times
Pin pad Embedded pin pad, supports alphanumeric input and display, 3DES、
ANSIX9.9、ANS9.8，above 100 secret keys
Modem
Sync (SDLC, 1200/2400/9600bps), handshake time is about 5 seconds;
asynchronous ( 33.6Kbps) (55.6Kbps optional), handshake time is about
7-8 seconds;
Communication
mode
GPRS
Wi-Fi
SDK Software for all
needed Application
Standard C, support Second Development and at least 20 apps for
multi-application
Complete Set Development Tools For Application Development Through
5
Item Specifications
Library
And Software simulation on PC
TMS
Remote Downloading ( App. & Configuration)
-Scheduling
-Full feature license
-Independ to the special router
- Unlimited connection POS to the TMS
- running many operation in according program in a connection for
some POS to the TMS
( scenario)
-Key Management system
-keeping security methods for DATA between POS and TMS
Ability implement Hotlist or Black list
Language Multi-language, such as English, Chinese, Farsi, Cyrillic, Russia etc.
Update RS232 from PC, terminal to terminal, remote download, USB Drive
Size & Weight 175(L) X 81(W）X 70(H)mm 0.312KG
Certifications
China Union Pay POS test, 3C,EMV LEVEL1/LEVEL2,PBOC2.0
LEVEL1/LEVEL2,China telecom Access Net license, China Union Pay
Magnetic Stripe/IC card POS Access Net license, Visa ADVT , Master Tip,
PCI PED 2.0
Basic setting
Power on/off
power on：
Please connection T2 with power by power adapter, press “on/off” for 3 seconds to boot up
T2;
Power off：
Under status of power on, please press “on/off” for 3 seconds, then it will prompt “ press OK
to power off, other keys to return”, then press “OK”, then it will prompt “ in powering off,
waiting…”, after 2 seconds, it will finally power off.
6
Self-checking
1. Press “on/off”, “F” and “3” at the same time to power on, then it will prompt “please input
password”;
2. Input password “556677” and press “OK” to enter self-checking menu; please “OK”
(1) Keypad: to check if every button works well, here you can press arrow keys to
adjust frequency of buzzer;
(2) LCD: to check if LCD works well, as below:
① Test LCD: to play WAV file;
② Test LCD backlit: adjust the light of backlit;
③ Test LCD contrast: adjust the current contrast of LCD;
④ Test charging battery: not support;
(３) Mag-card: to check if read/write mag-card working well;
(４) print: to check if printer works well, as below picture:
① Test print: printing according to the types of printers: thermal or matrix dot;
② Test aging print: POS will print a time at every hour and the LCD will prompt the current
batch receipt number;
③ Test LAN; input IP address to check if the LAN works well or not;
Test app
T2 V1.01 20070622
Pls press “OK” to continue—→
2007-6-25 15:10:00
Jun 22 2007 10:27:50
Test app
1.keypad 5.comm
2.LCD 6.IC card
3.Mag-card 7.accessories
4.print 8.clock
1. Test LCD
2. Test LCD backlit
3. Test LCD contrast
4. Test charging battery
Test Print
1. Test print
2. Test aging print
3. Test LAN
7
(５) Comm: to test MODEM, GPRS;
(６) IC card: to test IC cards slot 1,2 3 and initialization key card;
(７) Accessories: to test fingerprint, barcode scanner, voice(not support in T2)
and USB and serial port;
(８) Clock: to set the current time.
Apps download
I Kernel download:
Note: please prepare both USB and serial port cable before kernel
download.
1. please install driver apps according to your PC OS ：Secbulk_2000.msi(OS
2000 )/Secbulk_2003(OS 2003).msi/Secbulk_XP.msi(OS XP)
2. connect T2 with K3209 (please take care, the side with ACH of backbox should be
upwards, the other side with arrow sign should be downward)
3. connect PC and K3209 by serial port cable, and please take care of connecting with
K3209 by “POS/PINPAD”, and USB cable to plug into “USB D”;
4. Open “T2DL_3.6.7.exe” download tool on your PC, and click “start download”, it
will prompt “BIOS is booting…”;
5. Press “2, 5,0” and “on/off” to boot POS, then it will prompt input password
“888888”, when download tool prompt “ waiting for BIOS booting..” again, it will
means finishing to download kernel.
II Apps download
Note: T2 POS can support USB, serial port and remote download to download apps.
a.USB download: using USB to upgrade apps;
Note: please install USB simulated serial port communication driver well in your
PC before connection USB and K3209, otherwise, POS will prompt“please check
USB cable connect well or not, please plug USB again, and retry by pressing
“OK”, or cancel to exit”;
1. Open “T2DL_3.6.7.exe” by your PC；
2. Click “read configuration file” to select“apps.INI” file, and click “add” to tick
“√”at the option of “USB simulated serial port”;
3. Operation method: press “F” + “1” and press “CNL” at the same time to boot up
POS until you see “apps download (USB), please input your password”;
4. Input password “556677” and press “OK”, then it will prompt “apps
download (USB), downloading, baud rate=115200”
5. Click “start” to download apps, after finishing, it will prompt “ download success”;
6. Press “CNL” to exit apps to enter “sign in” interface.
8
b. Serial port apps download: using PC serial port to upgrade apps.
Note: directly connect PC with K3209 by“POS/PINPAN”, don’t need to install USB
driver
1. Operation method: press “F” and “6”, and press “CNL” to start pos until it prompt
“apps download(COM), please input password”;
2. Input password “556677” and press “OK”, then it will prompt “apps
download (COM), downloading, baud rate=115200”
3. Open “T2DL_3.6.7.exe” by PC；
4. Click “read configuration file” to select“app.INI”, then click “add” and select
“single port download”, and tick“√” the “don’t need USB simulated serial port”;
5. Click “start” to download apps, after finishing, it will prompt “ download success”;
6. Press “CNL” to exit apps to enter “sign in” interface.
T2 setting of China UnionPay
China UnionPay will set system parameter of T2 like bellows:
System setting
⑴ input operator 99 to enter sign in interface and input
system manager password;
⑵ Input system manager password（82112711）, and press
“OK” to enter system setting page;
⑶ After setting, press “OK”, then it means finishing
system parameter setting, system will prompt if write
card, only if cards is written, the parameter is valid.
1. POS parameter setting:
Please input 15 bits merchant number by order, 8 bits POS number, Merchants’
name (maximum more than 20 Chinese characters), merchants’ English name
(maximum more than 30 English characters), after finishing please enter next
setting items.
Merchants’ number: must ensure to input 15 bits
terminal number： must ensure to input 8 bits
merchants’ name： the Chinese and English name of merchants, press
“OK” to input Chinese or English, for Chinese, it allows to
input 20 characters, for English, it allows to input 30 characters.
Under Chinese input method to input section code, press
“alphabet” to input pinyin; under English input method, press
“alphabet” to switch number and alphabet.
Current year： set current year
Serial number： set current serial number
Batch number： set current batch number
System management
1. POS parameter setting ↑
2. Comm. Parameter setting
3. Transaction function setting
4. Pos key management ↓
POS parameter setting
Please input merchant No.
(15bits)
555555555555555
System management
5. Modify management password ↑
6. Other functions
7. PC parameter download
8. MODEM parameter setting ↓
9
Verify version： if set verify version，（1-YES，0-NO）
Refund amount： set refund amount
Set settlement print： set if print details（1-YES，0-NO）
Commercial banks’ code： set bank code
Local area code:： set local area code
If print English receipt： Set if print English receipt
Select receipt： Set if print new receipt or old one
Default transaction ： set default transaction (1-sales ，
0-pre-authorization），under the main menu of this
function, you could directly enter transaction by
brushing card;
Key length： set key length（1-single ，0-double）
Sales void： set if need brushing card when sales void
Pre-authorization completion void: set if need brushing card when
pre-authorization completion void
Sales void password： set if need input password when sales void
Pre-authorization void password: set if need input password when
pre-authorization void
pre-authorization completion void password： set if need input password when
pre-authorization completion void
pre-authorization completion (online) password: set if need input password when
pre-authorization completion (online)
2. comm. setting
1. comm. method select： 0-cable 1-GPRS
2.dial-up setting
Outside call number： set the phone number of outside call, maximum 4 bits;
Transaction call 1：Directly call China unionpay, maximum 20 bits. At the same time, you can
set 3 different phone numbers, if dial-up the first number is overtime, then POS
will automatically select the second one, if second one is overtime too, then
automatically select the third one;
Transaction call 2：same as above；
Transaction 3：same as above；
Manage callings：set manage callings, online download apps, maximum
20 bits;
Pre-dailup setting：set if need pre-dailup；
Dial-up time：set time of dial-up
overtime：set time of overtime
Redial-up times：set times of redial-up
2. Wireless setting (please parse GPRS SIM card)
Input APN1：set APN1
Comm. setting
1. comm. method
2. dial-up setting
3. Wireless setting
43.TPDU setting
10
Input APN2：set APN2
If needing users： 0-No 1-Yes
User name 1： input user name 1
User password 1：input user password 1
User name 2：input user name 2
User password 2：input user password 2
Host IP1：input Host IP1
Host port1：input host port1
Host IP2：input Host IP2
Host port2：input Host port2
Select APN：select using APN（0 or 1）
Dynamic IP：set if select dynamic IP
Automatic switch：set if automatically switch to dial-up or Ethernet
Link method：select link method 0-long link 1-short link
Calling times：set calling times
4.TPDU setting：banking cards TPDU, total 10 bits, the first 2 bits are
TPDU ID, generally they are 60, and the middle 4 bits are the target
address of TPDU, the last 4 bits are source address of ；
3. Transaction functions setting:
shield transaction ： set function of shield transaction to stop
transaction
Chargeback setting：set if automatic chargeback after settlement
Tip setting： set if support tip, if support, then you should set
the proportion of tip
Resend times: set if fail to do transaction, it will resend automatically, and
press “CLR” to delete previous data and input the required
number.
Print pages: set pages number of printing receipts
Maximum transaction:set if storing maximum transaction times at this batch, when
transaction times of this batch ≥ the setting number, system will
remind settlement, if transaction number is 1~500, then the default
is 300 transactions.
Other parameter：input card No. by hand: set if support transaction by inputting
card No. by hand
Offline upload: set offline transaction if uploads before next
online transaction or settlement
Password keypad: if having password keypad
Completion methods of Magnetic card pre-authorization：
set completion methods of magnetic card
pre-authorization
printer：select the printer types
No center: select if no center area
Transaction functions setting
1. shield transaction 5.print page number
2.chargeback setting 6.maximum transaction
3.tip setting 7. Other parameter
4.resend times 8.IC card parameter
11
Online points：set if support online points
Points TPDU：set online points of TPDU
IC card parameter：set if support IC cards
4、Terminal key management
Key load-in：currently not available。
Key input by hand：set key by hand。
Transaction key index：set transaction key index。
TMS key index：remote download index。
5、change password
1、change administration password
2、change security password
3、reset dominating password
6、other functions
Erase transaction batch：Delete all transaction record
TMS download：Remote download
Parameter printing：Print key parameter
POS introduction：POS brief introduction
7、PC parameter download
Use computer and POS terminal for communication and parameter
setting.
8、MODEM parameter setting
Set MODEM parameter, set whether online checking、test
dialing tone, and testing time etc.
Setting on T2 by Appointed merchants’ manager
Upon getting T2 from China union pay, the appointed merchants’
manager will set T2 parameter and accredit operation rights
accordingly. (At the very first, get merchant administration
password of T2 from CUP)
Main setting：
1、under main interface, choose “7, management” option；
2、choose “4, counter staff” option；
3、all settings are valid on confirmation. Setting complete,
system will prompt whether read-in card. Parameter is valid
after read-in.
1、director revise password：revise director password。
2、add operator：Add operators, to 30 at most.
3、inquiry operator：inquiry current operator ID。
4、delete operator：delete operator account。
5、operator revise password：operator revise their access password。
12
6、director setting：after inputting director password, can change
time display。
7、energy-saving setting：(not support in T2)
1. enter energy-saving model（15-180s）
Set energy-saving time, default 15S.
2. Wehther keyboard locked
Set whether keyboard lockable
3. Wehther auto shut-off allowed
Set whether auto shut-off allowed.
4.auto shut-off time（3-999m）
Under this menu, set auto shut-off in regulated time。
General function operation
Operator sign-in
Function：Sign-in means the operator start to use POS terminal, and to make sure it’s
valid.
Operation steps： 1、when start, system will prompt sign-in, and input operation ID number；
2、input operator ID number（0~30）and press enter；
3、input operator password and enter；
4、T2 will upload data to central host and ask for response, it shows “sign-in success” when
succeed; or else shows “sign-in failure”;；
5、enter main interface。
Sales
Function：cardholders make online transaction by credit cards at merchants’ place。
Operation steps：1、in main menu, choose “1, sales” to enter payment interface；
2、swipe card by instruction on device screen；
3、when default is consumption, the above two steps can be replaced as a shortcut to make
payments；
4、follow instruction, enter value amount and press enter；
5、Input password in Pin pad, no password, press enter directly；
6、Use T2 to make payment, screen shows payment success at last, and print receipt.
13
Void
Function：Transaction withdraws including transaction withdraw, pre-authorization
void and pre-authorization complete void, which are operated by
administrations sometimes are needed because of operation error and other
reasons.
Operation steps：1、in main menu, choose “2, void” and enter withdraw interface；
2、merchants administration input password and press enter；
3、follow instructions, input authorized number, press enter ；
4、swipe card by instruction, check whether card number is correct；
5、input password in pin pad, no password, press enter directly；
6、use T2 to withdraw transaction, it shows success at the end, meanwhile print receipt。
Refund
Function：Transaction refund is used to withdraw transaction made in previous days or
batches. Operator need to verify the transaction receipt from cardholder,
and make sure transaction is in valid period (like, within 3 months). Follow
instructions, operator need to input data regarding original transaction,
then send to POS center and applying for refund.
Operation steps：1、in main menu choose “3, refund”；
2、input administration password, and press enter；
3、swipe card by instruction, make sure card number is correct；
4、input system reference number and press enter；
5、input original transaction date（m-d）；
7、input refund amount and press enter；
8、Use T2 to refund, it shows success at the end, meanwhile to print receipt.
Pre-authorization
I pre-authorization：
Function：It refers to the transaction made by cardholders to deposit by swiping cards
at appointed merchants’ place. Then the bank hosts that issuing the cards
will freeze authorized amount, and name the transaction a authorization
code.
Operation steps：1、Under main menu choose “4, pre-authorization” then “1, pre-authorization”；
2、swipe card by instruction and make sure card number is correct；
3、input pre-authorized amount and press enter；
3、input password in pin pad, no password, press enter directly；
14
4、Use T2 to make pre-authorization transaction, it shows success at the end,
meanwhile print authorization receipt。
II Superadd pre-authorization ：
Function：after pre-authorization transaction succeed, super addition is available。
Operation steps：
1. under main menu choose “4, pre-authorization” then “2, superadd pre-authorization”；
2. swipe card by instruction, and make sure card number is correct；
3. input pre-authorization code( the code corresponding to receipt) and press enter；
4. input amount, press enter；
5. input password in pin pad, no password, press enter；
6. Use T2 to make pre-authorization transaction, it shows success at the end, meanwhile print
pre-authorization receipt
III pre-authorization completion online：
Function：Merchants frozen cards of cardholder and credit fee, but this transaction is revocable.
Operation steps:1、under main menu to press“4、pre-authorization”，and select“3、pre-authorization
completion online”
2、brushing card according to screen prompt or input card No. by hand；
3、input original transaction date；
4、input original authorization code and press “OK”.
5、input amount and press OK;
6、input password, if no password please directly press “OK”;
7、pre-authorization success and print receipt..
IV pre-authorization completion offline：
Function：Merchants frozen cards of cardholder and credit fee, but this transaction is not revocable
Operation steps:1、under main menu to press“4、pre-authorization”，and select“4、pre-authorization
completion offline”;
2、brushing card according to screen prompt or input card No. by hand；
3、input original transaction date；
4、input original authorization code and press “OK”.
5、input amount and press OK;
6、input password, if no password please directly press “OK”;
7、pre-authorization completion success and print receipt..
V pre-authorization void：
Function：Pre-authorization void when cardholder likes to claim back their deposit.
Operation steps:：1、under main menu to press“4、pre-authorization”，and select“5、
pre-authorization void”;
2、merchants manager input his password and press “OK”;
2、brushing card according to screen prompt or input card No. by hand；
3、input original transaction date；
4、input original authorization code and press “OK”.
15
5、input amount and press OK;
6、input password, if no password please directly press “OK”;
7、pre-authorization void success and print receipt.
VI pre-authorization completion void:
Function：Void the actual sales amount which cardholder buys something from
merchants.
Operation steps:1、under main menu to press“4、pre-authorization”，and select“6、pre-authorization
completion void”；
2. Merchants manager input his password and press “OK”;
2、brushing card according to screen prompt or input card No. by hand；
3、input original transaction date；
4、input original authorization code and press “OK”.
5、input amount and press OK;
6、input password, if no password please directly press “OK”;
7、pre-authorization completion void success and print receipt.
Note: pre-authorization completion offline is not revocable.
Offline
I offline settlement：
Function：Do offline settlement by POS, currently it’s only allowed for visa and mastercard cards.
Operation steps:1、under main menu to select “5. Settlement”；
2、select “1 offline settlement”；
3、input card No. and press “OK”；
4、input validity of card and press “OK”；
5、input original authorization method, there are 3 methods：1. POS，2. pre-authorization by
phone，3. cash stand-in authorization.
POS：
Input authorization code and press “OK”
Input international organization code and press “OK”;
Print purchasing receipt and upload when next POS online or before next batch
settlement online;
Pre-authorization by phone：
Input authorization code and press “OK”
Input international organization code and press “OK”;
Input actual settlement amount and press “OK”;
Print purchasing receipt and upload when next POS online or before next batch
settlement online;。
II settlement adjustment：
16
Function：
Adjust the current batch settlement amount, or supperadd tip of current batch sales, which is only available for
visa, mastercard ect. Banking cards.
Operation steps:1、under main menu to select “5. Settlement”；
2、select“2. Settlement adjustment” and press “OK”；
3、input original transaction receipt No. and press “OK’;
4、after figuring out original transaction, handle them again again:
Original is sales, then input sales amount and press “OK”;
If original is not sales, then input adjusted amount and press “OK”;
5、print receipt;
Query
Function：Cardholder inquiry his balance by POS. this transaction don’t attend
settlement.
Operation steps:1、under main menu to select “8. Other operation” and select “1. Balance inquiry”；
2、swiping card；
3、input password, if no password, please press “OK”；
4、pos will return the balance of banking card.
Response Test
Under main menu to select “8. Other operation”, then select “2. Response test, then you can test the
Ethernet between POS and banking switch, if connecting success, POS will prompt “comm. Line works
well”.
Settlement
Function：When pos go on batch settlement, POS will upload debit amount, load amount in
batch to banking switch center to handle response message of batch settlement.
When POS in batch settlement, it will do settlement according to different RMB
account and foreign currency account separately. After finishing, it will
implement reconciliation between POS and banking switch center. Then POS
will print settlement receipt automatically and clear cache at the same time.
Operation steps:1、under main menu to select “7. Management”, and then select “6. Settlement”；
2、T2 will show debit and load times and amount according to different banking cards;
3、please press upward key and downward key to switch showing RMB or other foreign
currency;
4、press “OK”, then T2 will upload settlement command, then T2 will start uploading
settlement, until screen prompts “settlement success” and print receipt automatically;
Note：If settlement is not correct, T2 will upload report. If uploading report stops, T2 will continue to upload report after
17
next online until finish uploading.
General management operation
Reprint
Under main menu to press “6. reprint” to enter reprint interface.
I reprint the last sales receipt：Reprint the last successful sales receipt, if last sales receipt is not
completed then need reprint the last one.
II Reprint any sales receipt: input receipt No. to reprint any receipt you want
III reprint sales details: reprint all unsettlement sales record by time of sales happen
IV reprint sales summary: reprint china unionpay card and visa marstercad debit or load data
separately.
Chargeback
Under main menu to select “7. Management” and then to select “chargeback”.
If no any settlement available on this POS, please select this option to close the current working status
of POS.
Operation query
Under main menu to select “7. Management”, then to select “3. Operation query” to enter query
interface.
I inquiry sales details:
T2 will display the last sales details. please press upward key and downward key to inquiry the last sales
details and the previous sales details.
II inquiry sales summary：
Inquiry sales amount, times and total void sales amount and times.
III Inquiry by receipt No.
Input existing receipt No. to inquiry sales records before settelement.
18
Outline
Under main menu to select “7. Management”, then to select “5. Outline”
When merchants need to change phone line and having outline, merchants can set outline number by
themselves, after setting please save by pressing “OK”, print important parameter list, you can check if
setting is ok by important parameter list.
System standby
Under main menu to select “7. Management”, then “7. Lock POS”, then it will enter system closing
interface temporary.
If operator need to leave POS temporary, he can use this function to lock T2 POS temporary, and the
screen will prompt “system close temporary”, that means the whole system will be closed temporary, if
need withdraw close, then press “return” to input current operator password or merchant management
password.
System information
Under main menu to select “7. Management, then select “8. Version
It will provide related version information of T2 and communication success rate
19
USA Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Certification information (SAR)
This device is also designed to meet the requirements for exposure to radio waves established
by the Federal Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over one gram of tissue. The highest
SAR value reported to the FCC for this device type complies with this limit.
The highest SAR value reported to the FCC for this device type when properly worn on the
body is 0.543 W/kg
Body worn operation
The device complies with RF specifications when used at a distance of 0 cm from your body.
Ensure that the device accessories, such as a device case and device holster, are not
composed of metal components. Keep the device away from your body to meet the distance
requirement
20
We hereby declare that (all essential radio test suites have been carried out and that)
the above named product is in conformity to all the essential requirements of Directive
1999/5/EC.
The product carries the CE Mark:
