Xoopar XP62002 PunchBOX Bluetooth Speaker User Manual PunchBox
Xoopar Limited PunchBOX Bluetooth Speaker PunchBox
Xoopar >
User Manual
3.5mm Stereo
LaptopsTabletsPhones Music Players
User Manual
Patent Information
EU Design: 002148601-0001 PRC Design: 201230484688.70
HK Design: 1202080.4M001 Others Patent Pending
All products are protected by Patent and Copyright. To protect our Intellectual Property (IP) ,
we would enforce the IP rights in court against infringers.
PATENTED PRODUCT
www.xoopar.com Made in China
3.5mm stereo cable
Micro-USB charging cable High quality monomer
LED light Micro USB
Micro USB
2000 mAh battery
Bass diaphragm
Power ON/OFFAUX-IN
PunchBox
Bluetooth Speaker
www.xoopar.com
OVERVIEW01
OVERVIEW03
05
OVERVIEW
02
CHARGE
04
06
07 08
09 10
WELCOME CONTENTS
OVERVIEW
CHARGE
CONNECT
LISTEN
SPEAKER PHONE
SPECIFICATIONS
TROUBLE SHOOTING
SAFETY INFORMATION
01-03
04
05
06
07
08
09
10
Thank you for purchasing Xoopar PunchBox speaker and speakerphone.
This innovative product uses intelligent Bluetooth wireless technology matching with an exciting design.
You can easily pair PunchBox with any Bluetooth digital devices to share music and movies.
It is also a Speakerphone for your mobile.
PunchBox is designed for home and oce use.
It delivers you amazing sound quality.
Built-in rechargeable battery provides you up to 15 hours play time !
It is a great companion to your smartphones and tablets.
Enjoy your PunchBox and having fun, NON-STOP !
1. Please connect it with your wall charger or computer via Micro USB cable.
2. It takes about 4 hours to fully charge.
3. PunchBox supports 15-hour play time.
4. Battery Status indicated by LED light.
Can connect PunchBox wirelessly with any Bluetooth device
Press
Spin
Charging
Full
Via PC
Via A/C Adapter
- Turn on Bluetooth function of your device.
- Switch on your PunchBox.
- Press and Hold the Volume button for 3 seconds until you hear "it is ready to pair" .
- Go to Bluetooth setting of your device and Select "Xoopar PunchBox" .
- Enter "0000" if a passcode is requested (normally not required).
* To Pair another devices, repeat the above processes.
CONNECT
1. For Bluetooth Pairing, follow one-time setting processes below:
2. Pairing is required for the rst time use only.
3. If your device does not support Bluetooth, you can play wired audio by connecting
PunchBox via 3.5mm stereo input.
4. 3.5mm stereo cable is included in package.
Volume Button
Power ON/OFF
LISTEN
1. To get the best sound, make sure Punch-
Box is resting on a at base.
2. If the song is too loud creating hearing
distortion, it is recommend to lower the
volume.
3. Bluetooth connection range is up to 10
meters, make sure your device is within
this eective range from your PunchBox.
4. For Bluetooth, incoming and outgoing
calls will always take connection priority
over audio playback.
Spin
SPEAKER PHONE
1. Speaker phone only works on
Bluetooth connection.
2. To pick up and end a call, simply
press the volume button.
Press
or
Press to answer End a call
Hands-free Speaker Phone
SPECIFICATIONS
Bluetooth Version：
Bluetooth Range：
Protocol：
Language (voice instructions)：
Output power：
Respond frequency：
Resolution：
SNR：
Microphone：
Battery type：
Battery life：
Power input：
Input current：
Interface：
Accessories included：
V3.0 + EDR Class 2
Up to 10m (33ft)
A2DP/HST/HFP/AVRCP
English/ Mandarin/ French/ German/ Spanish
2.5W x 2
40Hz ~ 20KHz
85db
90db
Yes
Li-ion 2000mAh, Rechargeable
Up to15-hour play time
DC 5V +/- 5% 500mAh
500mAh
Bluetooth/3.5mm Stereo/Micro USB
3.5mm cable, Micro USB cable
TROUBLE SHOOTING
Make sure you have turned on Bluetooth of your device
Turn o other device that has paired and connected with PunchBox
Check if battery is empty and recharge it
It might be too loud, slightly lower the volume on your PunchBox
Check for low battery and recharge it
Make sure your Bluetooth device is within 10M eective range of Bluetooth connection
Hearing Distortion
Cannot Connect
SAFETY INFORMATION
1. Do not expose the speaker to water, liquid, or humidity. Electric shock
could be resulted.
2. Keep the speaker in a ventilate place and away from any heat source to
prevent a risk of re.
3. Do not attempt to disassemble the speaker and replace the built-in
rechargeable battery by yourself. Electric shock could be resulted.
4. Always unplug the charger rst and clean the speaker with a dry cloth.
5. Do not place the speaker on high surface. Strong music may cause the
speaker to move and fall o from the shelf.
FCC warning statements:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
.Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
.
.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
.Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
