VX-3R Operating Manual
General Description
The VX-3R is a micro-miniature multiband FM transceiver with extensive receive frequency coverage,
providing local-area two-way amateur communications along with unmatched monitoring capability.
The VX-3R’s incredibly small size allows you to take it anywhere - hiking, skiing, or while walking around
town - and its operating flexibility brings the user many avenues of operating enjoyment. Its incredibly tiny
FNB-82LI Lithium-Ion Battery Pack provides up to 1.5 Watts of transmit power on VHF, and 1 Watt on UHF.
Besides 144- and 430-MHz transceive operation, the VX-3R provides receive coverage of the AM (MF)
which provide the internal bar antenna and FM broadcast bands, HF Shortwave Bands, VHF and UHF TV
bands, the VHF AM aircraft band, and a wide range of commercial and public safety frequencies!
Furthermore, the VX-3R provides the internal bar antenna for the good receiving the AM broadcast.
Additional features include an Enhanced Paging and Code Squelch (EPCS), which allows you to page a
particular station and only receive calls from that station, if desired; a security Password feature, which will
allow you to turn on and operate your transceiver only after you enter your Password; a convenient access
key for Vertex Standard’s WIRES™ (Wide-Coverage Internet Repeater Enhancement System); Emergency
Automatic ID (EAI) function, that will automatically cause your VX-3R to transmit your callsign and engage
your rig’s microphone, even if you are disabled and unable to press the PTT switch; a transmit Time-Out
Timer (TOT); Automatic Power-Off (APO); Automatic Repeater Shift (ARS); Yaesu’s exclusive ARTS™
(Auto-Range Transponder System) which “beeps” the user when you move out of communications range
with another ARTSTM equipped station, plus provision for reduction of the TX deviation in areas of high
channel congestion. And an S-meter squelch circuit allows the owner to set the squelch to open at a
programmable setting of the S-Meter, thus reducing guesswork in setting the squelch threshold.
We appreciate your purchase of the VX-3R, and encourage you to read this manual thoroughly, so as to
learn about the many exciting features of your exciting new Yaesu hand-held transceiver!
Accessories & Options
Supplied Accessories
FNB-82LI 3.7 V, 1000 mAh Rechargeable Lithium Ion Battery Pack
NC-85A/B, C, U* 2.5-Hour Charger
YHA-66 Antenna
Operating Manual
Warranty Card
Available Options
FNB-82LI 3.7 V, 1000 mAh Rechargeable Lithium Ion Battery Pack
FBA-37 Dry Cell Battery Case for 3 x “AA” Alkaline Cells
Vertex Standard Co., Ltd.
1
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
NC-85A/B, C, U* 2.5-Hour Charger
CN-3 BNC-to-SMA Adapter
CT-27 Cloning Cable
CT-44 Microphone Adapter
E-DC-21 DC Cable w/ Cigarette-Lighter Adapter
MH-34B4B Speaker/Microphone
MH-37A4B Earpiece/Microphone
VC-25 VOX Headset
* “A/B” suffix is for use with 100-120 VAC, “C” suffix is for use with 230-240 VAC, and “U” suffix is for use
with 230 VAC.
Availability of accessories may vary. Some accessories are supplied as standard per local requirements,
while others may be unavailable in some regions. Consult your Yaesu dealer for details regarding these
and any newly-available options Connection of any non-Yaesu-approved accessory, should it cause
damage, may void the Limited Warranty on this apparatus.
Control & Connections
ANTENNA Jack
Connect the supplied rubber flex antenna (or another antenna presenting a 50-Ohm impedance) here.
MIC/SP Jack
This four-conductor miniature jack provides connection points for microphone audio, earphone audio, PTT,
and ground.
DIAL Knob
The main tuning Dial is used for setting the operating frequency, and also is used for audio volume level,
menu selections, and other adjustments.
To rotate this Dial knob, pull the knob to unlock the mechanical dial lock, and then rotate the Dial knob.
TX/BUSY Indicator
This indicator glows green when the squelch opens, and turns red during transmit. During “Emergency”
operation (see page ??), this indicator will glow (or flash) white.
PTT (Push To Talk) Switch
Press this switch to transmit, and release it (to receive) after your transmission is completed.
MONI Switch
Pressing this key disables the noise squelching action, allowing you to hear very weak signals near the
background noise level.
Vertex Standard Co., Ltd.
2
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
POWER Switch
Press and hold this switch in for one second to toggle the transceiver’s power on and off.
KEYPAD
These nine keys select many of most important operating features on the VX-3R. The functions of the keys
are described in detail on the pages to follow.
SPEAKER
The internal speaker is located here.
MIC
The internal microphone is located here.
EAR Jack
This 3-pin miniature jack provides connection points for stereo earphone.
This 3-pin miniature jack allows connection to stereo earphone. When insert the after-market stereo
earphone into this jack, you may enjoy the FM broadcast with a stereo.
EXT DC
This coaxial DC jack allows connection to an external DC power source (2.5 - 7.0V DC). The center pin of
this jack is the Positive (+) connection.
Keypad Functions
Key Primary Function
(Press Key)
Secondary Function
(Press [FW] + Key)
Third Function
(Press and Hold Key)
MODE Switches the operating
mode.
Activates CTCSS or
DCS operation.
Activates the Smart
Search™ and Channel
Counter features.
BAND Moves operation to the
next-highest frequency
band.
Activates the “Memory
Bank” feature while in
the Memory Recall
mode.
Moves operation to the
next-lowest frequency
band.
Holding this key after
pressing the [FW] key to
activates the key
lockout feature.
Activates the Scanner
Upward (toward a higher
frequency or a higher
channel number).
TXPO Switches the transmit
power output between
“HI” and “LOW.”
Selects the synthesizer
steps to be used during
VFO operation.
Enters the Set (Menu)
Mode.
V/M Switches frequency
control between the
VFO and Memory
Activates the “Memory
Tune” function while in
the Memory Recall
Activates the Dual Watch
feature.
Vertex Standard Co., Ltd.
3
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Systems. mode.
FW Activates the “Alternate”
key function.
Disables the “Alternate”
key function.
Activates the “Memory
Write” mode (for memory
channel storage).
HM/RV Reverses transmit and
receive frequencies
while working through a
repeater.
Switches operation to
the “Home” (favorite
frequency) channel.
Activates the
“Emergency” Function.
See page ??.
% Activates the WIRES™
(Internet Connection)
feature.
Recalls the “Weather
Broadcast” channels
and Short-wave
broadcast station
channels.
Activates the ARTS™
feature.
RADIO Enter the Broadcast
Reception mode.
While in the Broadcast
Reception mode, press
the [BAND] key toggle
the receiving band
between “AM”
broadcast band and
“FM” broadcast band.
Enables the antenna
selection to be used.
Activates the AF Priority
function. See page ??.
VOL N.A. Toggle the DIAL knob
function between the
“Frequency Control”
and “Receiver Audio
Control”.
Rotate the DIAL knob
while holding the VOL key
to adjust the audio volume
level.
Installation of Accessories
Antenna Installation
The supplied antenna provides good results over the entire frequency range of the transceiver. However,
for enhanced base station medium-wave and shortwave reception, you may wish to connect an external
(outside) antenna, as the supplied antenna is very small and cannot be expected to provide high
performance at these frequencies.
To install the supplied antenna, hold the bottom end of the antenna, then screw it onto the mating connector
Vertex Standard Co., Ltd.
4
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
on the transceiver until it is snug. Do not over-tighten by use of extreme force.
Notes:
Never transmit without having an antenna connected.
When installing the supplied antenna, never hold the upper part of the antenna while screwing it onto
the mating connector on the transceiver.
If using an external antenna for transmission, ensure that the SWR presented to the transceiver is 1.5:1
or lower, to avoid excessive feedline loss.
Installation of FNB-82LI Battery Pack
The FNB-82LI is a high-performance Lithium-Ion battery providing high capacity in a very compact package.
Under normal use, the FNB-82LI may be used for approximately 300 charge cycles, after which operating
time may be expected to decrease. If you have an old battery pack which is displaying capacity which has
become diminished, you should replace the pack with a new one.
Installation of the battery is easy and quick:
Slide the Battery Cover Latch to the Unlock position, then slide the Battery Cover toward the bottom to
remove it.
Install the FNB-82LI into the Battery Compartment.
Replace the Battery Cover, then slide the Battery Cover Latch into the “Lock” position.
Important Note: There is a small stud in the Battery Compartment of the VX-3R. This stud is a switch for the
battery detection. Please be careful not to break this stud while battery changing.
Battery Charging
If the battery has never been used, or its charge is depleted, it may be charged by connecting the NC-85
Battery Charger, as shown in the illustration, to the EXT DC jack. If only 12 ~ 16 Volt DC power is available,
the optional E-DC-21 DC Adapter (with its cigarette lighter plug) may also be used for charging the battery.
While the battery is being charged, the display will indicate “CHGING” and the TX/BUSY indicator will glow
red. The S-meter will deflect according to the charging status.
When charging is finished, the display will change to indicate “CHGFUL” and the TX/BUSY indicator will
glow green.
The NC-85 is only designed for the charging of the VX-3R’s battery, and is not suitable for other purposes.
Please be advised that the NC-85 may contribute noise to TV and radio reception in the immediate vicinity,
so we do not recommend its use adjacent to such devices.
Important Note: 1) Perform the battery charging where the ambient temperature range is 41 °F to 95 °F
(+5 °C to +35 °C). Charge out of this range could cause damage to the battery pack.
Vertex Standard Co., Ltd.
5
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
2) When charge is not finished even if it passes for three hours, appears “CHGERR” in the display and
finishes the charging forcibly. In this case, there is the possibility that battery becomes deterioration. Please
contact your yaesu dealer.
3) If you do not use the VX-3R for a long time, remove the FNB-82LI Lithium-Ion battery pack from the
VX-3R, as battery leakage could cause damage to the VX-3R and FNB-82LI.
4) When a FNB-82LI Lithium-Ion battery pack is not used for a long time, please remove it from the
transceiver. Also, while in storage, the charge will drain slightly over time and the battery should be
recharged 50% each six months.
Installation of FBA-37 Alkaline Battery Case (option)
The optional FBA-37 Battery Case allows operation of the VX-3R using three “AA” size alkaline batteries.
When installing batteries, insert the (–) end first, then press in the (+) end so the battery snaps into place.
Always replace all three batteries at the same time, paying attention to the polarity indicated inside the
case.
The FBA-37 must not be used with rechargeable cells. The FBA-37 does not contain the thermal and
over-current protection circuits (provided in the FNB-82LI Lithium-Ion Battery Pack) required when utilizing
Ni-Cd and Ni-MH cells.
Note that the power output and battery life will be much shorter when using Alkaline AA cells. They should
be considered an emergency backup power source only, for this reason.
The VX-3R is smart, when the FBA-37 Battery Pack is installed to the VX-3R, a charge circuit does not
work even if the external DC power supply is connected to the EXT DC IN Jack.
Important Note: 1) The FBA-37 is designed for use only with AA-type Alkaline cells (LR6).
2) If you do not use the VX-3R for a long time, remove the alkaline batteries from the FBA-37, as battery
leakage could cause damage to the VX-3R and FBA-37.
Battery Life Information
When the battery charge is almost depleted, a “Battery” icon will appear on the display. When the “Battery”
icon appears, it is recommended that you charge the battery soon.
Battery Life (Approx.) Operating Band
FNB-82LI FBA-37
Low Voltage Indicator
144 MHz*1
430 MHz*1
Other Band*2
*1) TX: 6 seconds, RX: 6 seconds, and Squelched: 48 seconds.
*2) Continuous signal reception.
The current battery voltage can be displayed manually on the display,
Vertex Standard Co., Ltd.
6
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Battery capacity may be reduced during extremely cold weather operation. Keeping the radio inside your
parka may help preserve the full charge capacity.
Interface of Packet TNCs
The VX-3R may be used for Packet operation, using the optional CT-91 microphone adapter (available
from your Yaesu dealer) for easy interconnection to commonly-available connectors wired to your TNC. You
may also build your own cable, using a four-conductor miniature phone plug, per the diagram below.
The audio level from the receiver to the TNC may be adjusted by the transceiver’s volume control (rotate
the DIAL knob while press and holding the [VOL] key, do not forget to pull the DIAL knob to rotate the DIAL
knob), as with voice operation. The input level to the VX-3R from the TNC should be adjusted at the TNC
side; the optimum input voltage is approximately 5 mV at 2000 Ohms.
Be sure to turn the transceiver and TNC off before connecting the cables, so as to prevent voltage spikes
from possibly damaging your transceiver.
When you are operating on Packet, switch the Receive Battery Saver OFF, as the “sleep” cycle may
“collide” with the beginning of an incoming Packet transmission, causing your TNC not to receive the full
data burst. See page ?? for details regarding Battery Saver setup.
Operation
R.F. says: Hi! I’m R. F. Radio, and I’ll be helping you along as you learn the many features of the VX-3R. I
know you’re anxious to get on the air, but I encourage you to read the “Operation” section of this manual as
thoroughly as possible, so you’ll get the most out of this fantastic new transceiver. Now. . .let’s get
operating!
Switching Power On and Off
1. Be sure the Battery Pack is installed, and that the battery is fully charged. Connect the antenna to the
top panel ANTENNA jack.
2. Press and hold in the orange POWER switch (on the left side of the transceiver) for one second. Two
beeps will be heard when the switch has been held long enough, and the current DC supply voltage
will indicated on the display for 2 seconds; if you are using the FNB-82LI Battery Pack, the small “Lit”
icon at the top of the display confirms that the Lithium-Ion Battery Pack has been detected. After this
2-second interval, the display will resume its normal indication of the operating frequency.
3. To turn the VX-3R off, press and hold in the orange POWER switch again for one second.
R.F. says: 1) If you don’t hear the two “Beep” tones when the radio comes on, the Beeper may have been
disabled via the Set Mode Item 14: BP SEL. See page ??, which tells you how to reactivate the Beeper.
2) You can change the Opening Message (DC supply voltage indication) to any desired message (up to 6
Vertex Standard Co., Ltd.
7
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
characters) via Set Mode Item 57: OPN.MSG; see page ?? for details.
Adjusting the Volume Level
Pull the DIAL knob to unlock the mechanical dial lock, then rotate the DIAL knob while pressing and holding
the [VOL] key to set the desired audio level. Clockwise rotation increases the volume level.
R.F. Says: 1) You may set the audio level by the Speaker Output Level and the Earphone Output Level
individually. The “SP” notation (which means Speaker) appears in the Memory Channel Number display slot
while adjusting the Speaker Output Level. The “HP” notation (which means Headphone) appears in the
Memory Channel Number display slot while adjusting the Earphone Output Level.
2) When press the [F/W] key followed by the [VOL] key, the DIAL knob function change to the Volume Level
selection instead of the frequency control. In this case, the “VOL” notation on the display is blinked. Press
the [F/W] key followed by the [VOL] key again, the DIAL knob function returns to the frequency control.
Squelch Adjustment
The VX-3R’s Squelch system allows you to mute the background noise when no signal is being received.
Not only does the Squelch system make “standby” operation more pleasant, it also significantly reduces
battery current consumption.
The Squelch system may be adjusted independently for the FM and Wide-FM (FM Broadcast) modes.
1. Press the [F/W] key, then press the [MONI] switch on the left side of the radio. This provides a
“Short-cut” to Set Mode Item 78: SQ LVL.
2. Now, rotate the DIAL knob to set the Squelch so that the background noise is just silenced (typically at
a setting of about “1” or “2” for AM/FM, and “2” or “3” for Wide-FM/FM Broadcast/AM Broadcast); this is
point of maximum sensitivity to weak signals.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. When you are satisfied with the Squelch threshold setting, press the PTT switch momentarily to save
the new setting and exit to normal operation.
R.F. Says: 1) The VX-3R can set the squelch threshold level on the AM mode, FM mode, Wide FM mode,
and AM Broadcast individually.
2) A special “S-meter Squelch” feature is provided on the VX-3R. This feature allows you to set the squelch
so that only signals exceeding a certain S-meter level will open the squelch. See page ?? for details.
3) If you’re operating in an area of high RF pollution, you may need to consider “Tone Squelch” operation
using the built-in CTCSS Decoder. This feature will keep your radio quiet until a call is received from a
station sending a carrier which contains a matching (subaudible) CTCSS tone. Or, if your friends have
radios equipped with DCS (Digital Coded Squelch) like your VX-3R has, try using that mode for silent
monitoring of busy channels.
Vertex Standard Co., Ltd.
8
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Selecting the Operating Band
The VX-3R covers an incredibly wide frequency range, over which a number of different operating modes
are used. Therefore, the VX-3R’s frequency coverage has been divided into different operating bands, each
of which has its own pre-set channel steps and operating modes. You can change the channel steps and
operating modes later, if you like (see page ??).
Operating Bands
BAND BAND NUMBER FREQUENCY RANGE
SW Band 1 1.8 - 30 MHz
50 MHz Ham Band 2 30 - 59 MHz
Air Band 3 108 - 137 MHz
144 MHz Ham Band 4 137 - 174 MHz
VHF-TV Band 5 174 - 222 MHz
Information Band 1 6 222 - 420 MHz
430 MHz Ham Band 7 420 - 470 MHz
UHF-TV Band 8 470 - 800 MHz
Information Band 2 9 803 - 999 MHz
To Change Operating Bands:
1. Press the [BAND] key repetitively. You will see the LCD indication move toward a higher frequency
band each time you press the [BAND] key.
Indicates a Band Number according with the receiving frequency in the Memory Channel Number
Display Slot of the display.
2. If you wish to move the operating band selection downward (toward lower frequencies), press the
[F/W] key first, then press the [BAND] key.
3. Once you have selected the desired band, you may initiate manual tuning (or scanning) per the
discussion in the next chapter.
R.F. Says: 1) The VX-3R has an AM broadcasting band and an FM broadcast band with these bands and
can receive it independently. See page ?? for details.
2) You may skip (omit) the several bands from the band selection loop for fast recalling the operating band,
if you desired. See page ?? for details.
Frequency Navigation
The VX-3R will initially be operating in the “VFO” mode, a channelized system which allows free tuning
Vertex Standard Co., Ltd.
9
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
throughout the currently-selected operating band.
Two basic frequency navigation methods are available on the VX-3R:
1) Tuning Dial
Rotation of the DIAL knob allows tuning in the pre-programmed steps established for the current operating
band. Clockwise rotation of the DIAL knob causes the VX-3R to be tuned toward a higher frequency, while
counter-clockwise rotation will lower the operating frequency.
If you press the [F/W] key momentarily, then rotate the DIAL knob, frequency steps of 1 MHz will be
selected. This feature is extremely useful for making rapid frequency excursions over the wide tuning range
of the VX-3R.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
2) Scanning
From the VFO mode, press and hold in the [BAND] key for one second, and rotate the DIAL knob while
holding in the [BAND] key to select the bandwidth for the VFO scanner, then release the [BAND] key to
begin scanning toward a higher frequency. The scanner will stop when it receives a signal strong enough to
break through the Squelch threshold. The VX-3R will then hold on that frequency according to the setting of
the “RESUME” mode (Set Mode Item 75: SCN.RSM). See page ?? for details regarding Scan Operation.
If you wish to reverse the direction of the scan (i.e. toward a lower frequency, instead of a higher frequency),
just rotate the DIAL knob one click in the counter-clockwise direction while the VX-3R is scanning. The
scanning direction will be reversed. To revert to scanning toward a higher frequency once more, rotate the
DIAL knob one click clockwise.
Press the PTT switch momentarily to cancel the scanning. This only stops the scan; it does not cause
transmission to occur.
Notice: The VX-3R may receive very strong signals on the Image frequency. If you experience
interference that you suspect may be coming in via an “image” path, you may calculate the
possible frequencies using the formulas below. This information may be used in the design of
effective countermeasures such as traps, etc.
3.579545 MHz x n
11.7 MHz x n (n is an integer: 1, 2, 3, …..)
Transmission
Once you have set up an appropriate frequency inside one of the 144 MHz or 430 MHz Amateur bands on
which the VX-3R can transmit, you’re ready to go on the air! These are the most basic steps; more
advanced aspects of transmitter operation will be discussed later.
Vertex Standard Co., Ltd.
10
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
1. To transmit, press the PTT switch, and speak into the front panel microphone (located in the upper
left-hand corner of the speaker grille) in a normal voice level. The TX/BUSY indicator will glow red
during transmission.
2. To return to the receive mode, release the PTT switch.
3. During transmission, the relative power level will be indicated on the bar graph at the bottom of the
LCD; full scale deflection confirms “High Power” operation, while deflection of two bars indicates “Low
Power” operation. Additionally, the “LOW” icon will appear at the bottom of the display while operating
on the “Low Power” setting.
4. If you’re just talking to friends in the immediate area, you’ll get much longer battery life by switching to
Low Power operation. To do this, press the [TXPO] key so that the “LOW” icon appears at the bottom
of the display. And don’t forget: always have an antenna connected when you transmit.
Transmission is possible only on the 144 MHz and 430 MHz bands.
R.F. Says: 1) The VX-3R is smart! You can set up Low power on 144 MHz band, while leaving 430 MHz on
High power, and the radio will remember the different settings on both bands. And when you store
memories, you can store High and Low power settings separately in each memory, so you don’t waste
battery power when using very close-in repeaters!
2) When you are operating on the Low power setting, you can press the [F/W] key, when press the PTT
switch, to cause the VX-3R to transmit (temporarily) on High power. After one transmission, the power level
will revert to the previously-selected (Low power) setting.
AM and FM Broadcast Reception
The VX-3R includes provision for reception of AM and FM broadcasts. With an FM broadcasts reception,
utilizing a wide-bandwidth filter and stereo decoder which provides excellent fidelity.
1. Press the [RADIO] key momentarily to enter the Broadcast Reception mode.
2. Press the [BAND] key to toggle the receiving band between “AM broadcast” and “FM broadcast”.
The AM broadcast coverage is 510 to 1790 kHz with AM mode. The “[A]” notation (which means AM)
appears in the Memory Channel Number display slot and “AM” icon appears on the bottom left of the
LCD.
The FM broadcasts coverage is 76.00 to 107.90 MHz with Wide-FM mode. The “[F]” notation (which
means AM) appears in the Memory Channel Number display slot and “WFM” icon appears on the
bottom left of the LCD.
3. Rotate the DIAL knob to select the desired station. When receive the FM stereo signal, “))I((” icon will
appear at the bottom left of the display.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press and hold the [RADIO] key for one second to enable the antenna selection to be used by rotating
the DIAL knob. Available selections are:
Vertex Standard Co., Ltd.
11
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
AM: “BARANT” (Uses the Rubber Flex Antenna) or “BAREXT” (Uses both the internal Bar Antenna
and the Rubber Flex Antenna).
FM: “EXTANT” (Uses the Rubber Flex Antenna) or “EARPHO” (Uses the Earphone Antenna).
5. When finish the selection, press the [RADIO] key momentarily to exit from the antenna selection mode.
6. Press the [RADIO] key momentarily again to exit from the AM and FM Broadcast Reception mode and
return to normal operation.
R.F. Says: If you wish to output the audio of the FM Broadcast station to the VX-3R internal speaker using
with an earphone antenna, select Set Mode Item 77: SP OUT to “SPKR”.
SUB-RX Operation
The SUB-RX Operation allows you to monitor your desired amateur band frequency while receiving AM or
FM broadcast stations. Furthermore, you may transmit on the amateur frequency by pressing the PTT
switch.
When a signal is received in the amateur band, the audio is output instead of the AM or FM Broadcast
station. When the amateur band signal drops, the SUB-RX Operation is resumed determine from the user
setting.
1. Set the VX-3R to the desired amateur band frequency by the VFO or Memory channel selection.
2. Press the [F/W] key then press the [RADIO] key.
3. Rotate the DIAL knob to select the resume mode of the AF Priority feature. Available selections are:
TX 1S - TX 10S: When passes the selected time after the transmission was over on the amateur band,
the AM or FM Broadcast station will be heard from the speaker and the SUB-RX Operation is resumed.
However, when the signal received in the amateur band, the SUB-RX Operation will halt on the
amateur band frequency (the SUB-RX Operation does not resume.)
TRX 1S - TRX 10S: When passes the selected time after the amateur band signal drops or
transmission was over, the AM or FM Broadcast station will be heard from the speaker and the
SUB-RX Operation is resumed.
HOLD: When the signal received in the amateur band or transmit on the amateur band, the SUB-RX
Operation will halt on the amateur band frequency (the SUB-RX Operation does not resume.). You
must manually re-initiate the SUB-RX Operation, if you wish to resume.
OFF: Disable the SUB-RX Operation.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [RADIO] key to activate the SUB-RX Operation. The “PRI” icon appears at the above of the
volume level indicator on the display.
5. Press the [BAND] key to toggle the receiving band between “AM broadcast” and “FM broadcast”.
6. Rotate the DIAL knob to select the desired Broadcast station.
7. When the signal received in the amateur band, the amateur band audio output to the speaker instead
Vertex Standard Co., Ltd.
12
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
of the AM or FM Broadcast station. When the amateur band signal drops, the AM or FM Broadcast
station will be heard from the speaker, and SUB-RX Operation is resumed (the amateur band
frequency is monitored while the AM broadcast station is heard from the speaker) according to the
SUB-RX Operation Resume mode selected in step 3 above.
8. You may monitor the amateur band forcibly while holding the [MONI] key.
To disable the AF Priority function, just repeat the above procedure, rotating the DIAL knob to select “OFF”
in step 3 above.
R.F. Say: 1) You may transmit the VX-3R on the frequency set in step1 above by pressing the PTT switch,
even if the SUB-RX Operation is activated.
2) You may change the frequency of the amateur band by rotating the DIAL knob while pressing the [MONI]
key.
Advanced Operation
Now that you’re mastered the basics of VX-3R operation, let’s learn more about some of the really neat
features.
Keyboard Locking
In order to prevent accidental frequency change or inadvertent transmission, various aspects of the
VX-3R’s keys and switches may be locked out. The possible lockout combinations are:
KEY: The front panel keys are locked out
PTT: The PTT switch is locked (TX not possible)
KY+PTT: Both the keys and PTT switch are locked out
To lock out some or all of the keys:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 46: LOCK.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to choose between one of the locking schemes as outlined above.
5. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
To activate the locking feature, press the [F/W] key, then press and hold in the [BAND] key for one second.
The “Key Lock” icon will appear on the LCD. To cancel locking, repeat this process.
Vertex Standard Co., Ltd.
13
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Keypad/LCD Illumination
Your VX-3R includes a reddish illumination lamp which aids in nighttime operation. The red illumination
yields clear viewing of the display in a dark environment, with minimal degradation of your night vision.
Three options for activating the lamp are provided:
KEY 2S - KEY10S: Illuminates the Keypad/LCD for the selected illumination time when any key pressed.
CONT: Illuminates the Keypad/LCD continuously.
OFF: Disables the Keypad/LCD lamp.
Here is the procedure for setting up the Lamp mode:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 44: LAMP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select one of the three modes described above.
5. When you have made your choice, press the PTT switch to save the new setting and return to normal
operation.
Adjusting the Keypad Beeper Volume Level
A keypad beeper provides useful audible feed back whenever a keypad is pressed. The keypad beeper
level changes according to the receiver audio volume level setting. However, you may adjust the volume
balance between the receiving audio and keypad beeper via Set Mode Item 13: BP LVL.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 13: BP LVL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select the desired level.
5. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
Additionally, if you want to turn the beep off:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 14: BP SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to change the setting to “OFF”.
5. Press the PTT switch to save the new setting and return to normal operation.
6. If you wish to re-enable the Beeper, just repeat the above procedure, rotating the DIAL knob to select
Vertex Standard Co., Ltd.
14
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
“KEY” or “KY+SCN” in step “4” above.
KEY: The beeper sounds when you press any key.
KY+SCN: The beeper sounds when you press a key or when the scanner stops.
Checking the Battery Voltage
The VX-3R’s microprocessor includes programming which will detect the battery type and measure the
current battery voltage.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 23: DC VLT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to display the battery type and the current DC voltage being
supplied.
Lit: FNB-82LI is in use.
Edc: An external DC source is in use.
4. Press and hold in the [TXPO] key for one second to return to normal operation.
Changing the Channel Steps
The VX-3R’s synthesizer provides the option of utilizing channel steps of 5/8.33/9/10/12.5/15/20/25/50/100
kHz per step (optional values are different by a operating band), as well as an automatic step selection
based on the current operating frequency (“AUTO”), any number of which may be important to your
operating requirements. The VX-3R is set up at the factory in the “AUTO” configuration, which probably is
satisfactory for most operation. However, if you need to change the channel step increments, the procedure
to do so is very easy.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 82: STEP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select the new channel step size.
5. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
R.F. Says: 1) 9 kHz steps are available only when receiving on the BC band.
2) 8.33 kHz steps are available only when receiving on the Air band.
3) While operating on the BC band, you may only select channel steps of 9 kHz or 10 kHz; the other step
selections are disabled.
4) 5 kHz steps are not available for use on 250 - 300 MHz, nor above 580 MHz.
Vertex Standard Co., Ltd.
15
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Changing the Receiving Mode
The VX-3R provides for automatic mode changing when the radio is tuned to different operating
frequencies. However, should an unusual receiving situation arise in which you need to change to other
receiving mode, just press the [MODE] key. The receiving modes available are:
AUTO: Automatic mode setting per default values for the selected frequency range.
FM: Narrow-bandwidth FM (used for voice communication)
W-FM: Wide-bandwidth FM (used for high-fidelity broadcasting)
AM: Amplitude Modulation
R.F. Says: Unless you have a compelling reason to do so, leave the Automatic Mode Selection feature on
so as to save time and trouble when changing bands. If you make a mode change for a particular channel
or station, you can always store that one channel into memory, as the mode setting will be memorized
along with the frequency information.
S-meter Squelch
A special S-meter Squelch feature is provided on this radio. This feature allows you to set the squelch so
that only signals exceeding a certain S-meter level will open the squelch.
To set up the S-meter squelch circuit for operation, use the following procedure:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 80: SQSMTR.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select the desired signal strength level for the squelch threshold (LVL 1 - LVL8
or OFF).
5. Press the PTT switch to save the new setting and return to normal operation.
R.F. Says: 1) When the S-meter squelch is activated, blink the S-meter segment corresponding with the
squelch threshold which set by step 4 above.
2) The receiver’s squelch will open based on the higher of the levels set by the two squelch systems (Noise
Squelch and S-meter Squelch).
For example:
a) If the Noise Squelch (SQL control) is set so that signals at a level of “S-3” will open the squelch, but the
S-meter Squelch (Set Mode Item 80) is set to “LVL 5,” the squelch will only open on signals which are “S5”
or stronger on the S-meter.
b) If the S-meter Squelch is set to “S3,” but the Noise Squelch is set to a high level which will only pass
signals which are Full Scale on the S-meter, the squelch will only open on signals which are Full Scale on
the S-meter. In this case, the Noise Squelch overrides the action of the S-meter Squelch.
Vertex Standard Co., Ltd.
16
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Checking the Temperature
The VX-3R can display the radio’s inside-the case temperature, measured by internal sensor.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 85: TEMP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to indicate the current temperature inside the transceiver’s case.
4. Press the [MODE] key to select the preferred unit (F (°F) or C (°C)).
5. Press the PTT switch to save the new setting and exit to normal operation.
Repeater Operation
Repeater stations, usually located on mountaintops or other high locations, provide a dramatic extension of
the communication range for low-powered hand-held or mobile transceivers. The VX-3R includes a number
of features which make repeater operation simple and enjoyable.
Repeater Shifts
Your VX-3R has been configured, at the factory, for the repeater shifts customary in your country. For the
144 MHz band shift will be 600 kHz; on the 430 MHz band, the shift may be 1.6 MHz, 7.6 MHz, or 5 MHz
(USA version).
Depending on the part of the band in which you are operating, the repeater shift may be either downward
(–) or upward (+), and one of these icons will appear at the top of the LCD when repeater shifts have been
enabled.
Automatic Repeater Shift (ARS)
The VX-3R provides a convenient Automatic Repeater Shift feature, which causes the appropriate repeater
shift to be applied automatically whenever you tune into the designated repeater sub-bands in your country.
These sub-bands are shown below.
If the ARS feature does not appear to be working, you may have accidentally disabled it.
To re-enable ARS:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 5: ARS.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select “ON” (to enable Automatic Repeater Shift).
5. When you have made your selection, press the PTT switch to save the new setting and return to
Vertex Standard Co., Ltd.
17
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
normal operation.
Manual Repeater Shift Activation
If the ARS feature has been disabled, or if you need to set a repeater shift direction other than that
established by the ARS, you may set the direction of the repeater shift manually.
To do this:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 68: RPT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Item.
4. Rotate the DIAL knob to select the desired shift among “–RPT,” “+RPT,” and “SIMP.”
5. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
R.F. Says: If you make a change in the shift direction, but still have Automatic Repeater Shift still engaged
(see previous section), when you change frequency (by rotating the DIAL knob, for example) the ARS will
over-ride your manual setting of the shift direction. Turn ARS off if you do not wish this to happen.
Changing the Default Repeater Shifts
If you travel to a different region, you may need to change the default repeater shift so as to ensure
compatibility with local operating requirements.
To do this, follow the procedure below:
1. Set the VX-3R’s frequency to the band on which you wish to change the default repeater shift (144
MHz or 430 MHz Ham Band).
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 69: RPT.SFT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Item.
5. Rotate the DIAL knob to select the new repeater shift magnitude.
6. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
R.F. Says: If you just have one “odd” split that you need to program, don’t change the “default” repeated
shifts using this Set Mode Item! Enter the transmit and receive frequencies separately, as shown on
page ??.
Vertex Standard Co., Ltd.
18
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Checking the Repeater Uplink (Input) Frequency
It often is helpful to be able to check the uplink (input) frequency of a repeater, to see if the calling station is
within direct (“Simplex”) range.
To do this, just press the [HM/RV] key. You’ll notice that the display has shifted to the repeater uplink
frequency. Press the [HM/RV] key again to cause operation to revert to normal monitoring of the repeater
downlink (output) frequency.
R.F. Says: The configuration of this key may be set either to “RV” (for checking the input frequency of a
repeater), or “HM” (for instant switching to the “Home” channel for the band you are operating on). To
change the configuration of this key, use Set Mode Item 36: HM/RV. See page ??.
CTCSS/DCS/EPCS Operation
CTCSS Operation
Many repeater systems require that a very-low-frequency audio tone be superimposed on your FM carrier
in order to activate the repeater. This helps prevent false activation of the repeater by radar or spurious
signals from other transmitters. This tone system, called “CTCSS” (Continuous Tone Coded Squelch
System), is included in your VX-3R, and is very easy to activate.
R.F. Says: CTCSS setup involves two actions: setting the Tone Frequency and then setting of the Tone
Mode. These actions are set up by using the [MODE] key or Set Mode Items 79: SQ TYP and 86: TN FRQ.
1. Press the [F/W] key, then press the [MODE] key. This provides a “Short-cut” to Set Mode Item 79: SQ
TYP.
2. Rotate the DIAL knob so that “TONE” appears on the display; this activates the CTCSS Encoder,
which allows repeater access.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Rotation of the DIAL knob one more “click” in step “2” above will cause the “T SQL” notation to appear.
When “TSQL” is displayed, this means that the Tone SQueLch system is active, which mutes your
VX-3R’s receiver until it receives a call from another radio sending out a matching CTCSS tone. This
can help keep your radio quiet until a specific call is received, which may be helpful while operating in
congested
R.F. Says: 1) You may notice an additional “DCS” icon appearing while you rotate the DIAL knob in this
step. We’ll discuss the Digital Code Squelch system shortly.
2) You may notice “RV TN” indication on the display while you rotate the DIAL knob in this step, this
means that the Reverse Tone Squelch system is active, which mutes your VX-3R’s receiver when it
receives a call from the radio sending a matched CTCSS tone. The “TSQ” icon will blink on the display
when the Reverse Tone Squelch system is activated.
3) You may notice “PR FRQ” indication on the display while you rotate the DIAL knob in this step, this
means that User programmed Reverse CTCSS Decoder mutes your VX-3R’s receiver when it receives
Vertex Standard Co., Ltd.
19
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
a call from the radio sending a matched your programmed matching tone (determine from Set Menu
Item: 63: PR FRQ) is received. The “SQ” icon will appear on the display when the User programmed
Reverse CTCSS Decoder is activated.
4) You may notice “PAGER” and “MESSAGE” indication on the display while you rotate the DIAL knob
in this step, these means that activating the “User programmed Reverse CTCSS Decoder”, “Enhanced
Paging & Code Squelch”, and the “Message Feature”. We’ll discuss later these functions.
4. When you have made your selection of the CTCSS tone mode, press the PTT switch to save the new
setting.
5. Press and hold in the [TXPO] key for one second to enter the Set mode.
6. Rotate the DIAL knob to select Set Mode Item 86: TN FRQ.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
7. Press the [TXPO] key momentarily to enable adjustment of the CTCSS frequency.
8. Rotate the DIAL knob until the display indicates the Tone Frequency you need to be using (ask the
repeater owner/operator if you don’t know the tone frequency).
9. When you have made your selection, press the [TXPO] key momentarily, then press the PTT switch, to
save the new settings and exit to normal operation. This is different than the usual method of restoring
normal operation, and it applies only to the configuration of the CTCSS/DCS frequencies.
R.F. Says: 1) Your repeater may or may not re-transmit a CTCSS tone - some systems just use CTCSS to
control access to the repeater, but don’t pass it along when transmitting. If the S-Meter deflects, but the
VX-3R is not passing audio, repeat steps “1” through “4” above, but rotate the DIAL so that “TSQ”
disappears - this will allow you to hear all traffic on the channel being received.
2) During CTCSS operation, you may set up the VX-3R such that a ringing “bell” sound alerts you to the fact
that a call is coming in. See page ?? for details.
DCS Operation
Another form of tone access control is Digital Code Squelch, or DCS. It is a newer, more advanced tone
system which generally provides more immunity from false paging than does CTCSS. The DCS
Encoder/Decoder is built into your VX-3R, and operation is very similar to that just described for CTCSS.
Your repeater system may be configured for DCS; if not, DCS is frequently quite useful in Simplex operation
if your friend(s) use transceivers equipped with this advanced feature.
R.F. Says: Just as in CTCSS operation, DCS requires that you set the Tone Mode to DCS and that you
select a tone code.
1. Press the [F/W] key, then press the [MODE] key. This provides a “Short-cut” to Set Mode Item 79: SQ
TYP.
2. Press the [TXPO] key momentarily to enable adjustment of this Item.
Vertex Standard Co., Ltd.
20
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
3. Rotate the DIAL knob until “DCS” appears on the display; this activates the DCS Encoder/Decoder.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the PTT switch to save the new setting.
5. Press and hold in the [TXPO] key for one second to enter the Set mode.
6. Rotate the DIAL knob to select Set Mode Item 24: DCS CD.
7. Press the [TXPO] key momentarily to enable the adjustment of the DCS code.
8. Rotate the DIAL knob to select the desired DCS Code (a three-digit number). Ask the repeater
owner/operator if you don’t know DCS Code; if you are working simplex, just set up the DCS Code to
be the same as that used by your friend(s).
9. When you have made your selection, press the [TXPO] key momentarily, then press the PTT switch to
save the new settings and exit to normal operation.
R.F. Says: 1) Remember that the DCS is an Encode/Decode system, so your receiver will remain muted
until a matching DCS code is received on an incoming transmission. Switch the DCS off when you’re just
tuning around the band!
2) During DCS operation, you may set up the VX-3R such that a ringing “bell” sound alerts you to the fact
that a call is coming in. See page ?? for details.
DCS Code Inversion
The DCS system was first introduced in the commercial LMR (Land Mobile Radio) service, where it is now
in widespread use. DCS is sometime referred to by its different proprietary names, such as DPL® (Digital
Private Line®, a registered trademark of Motorola, Inc.).
DCS uses a codeword consisting of a 23-bit frame, transmitted (subaudible) at a data rate of 134.4 bps
(bit/sec). Occasionally, signal inversion can result in the complement of a code being sent or received. This
prevents the receiver’s squelch from opening with DCS enabled, as the decoded bit sequence would not
match that selected for operation.
Typical situations that might cause inversion to occur are:
Connection of an external receiver preamplifier.
Operating through a repeater.
Connection of an external linear amplifier.
Note that code inversion does not mean that any of the above listed equipment is defective!
In certain amplifier configurations, the output signal (phase) is inverted from the input. Small signal or power
amplifiers having an odd number (1, 3, 5, etc.) of amplification stages may result in inversion of a
transmitted or received DCS code. While under most circumstances this should not occur (amplifier
designs and industry standards take this into account), if you find that your receiver squelch does not open
when both you and the other station are using a common DCS code, you or the other station (but not both)
can try the following:
Vertex Standard Co., Ltd.
21
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 25: DCS RV.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select one of the following modes:
R-N.T-N: Receive and transmit the Normal DCS Tone.
R-I.T-N: Receive the Inverted DCS Tone and transmit the Normal DCS Tone.
R-B.T-N: Receive the both Normal and Inverted DCS Tones and transmit the Normal DCS Tone.
R-N.T.I: Receive the Normal DCS Tone and transmit the Inverted DCS Tone.
R-I.T-I: Receive and transmit the Inverted DCS Tone.
R-B.T-I: Receive the both Normal and Inverted DCS Tones and transmit the Inverted DCS Tone.
5. When you have made your selection, press the [TXPO] key momentarily, then press the PTT switch, to
save the new settings and exit to normal operation.
This is different than the usual method of restoring normal operation, and it applies only to the configuration
of the CTCSS/DCS frequencies. Remember to restore the default setting “R-N.T-N” (Receive and transmit
the Normal DCS Tone) to when done.
Tone Search Scanning
In operating situations where you don’t know the CTCSS or DCS tone being used by another station or
stations, you can command the radio to listen to the incoming signal and scan in search of the tone being
used. Two things must be remembered in this regard:
You must be sure that your repeater uses the same tone type (CTCSS vs. DCS).
Some repeaters do not pass the CTCSS tone; you may have to listen to the station(s) transmitting on
the repeater uplink (input) frequency in order to allow Tone Search Scanning to work.
To scan for the tone in use:
1. Set the radio up for either CTCSS or DCS Decoder operation (see the previous discussions). In the
case of CTCSS, “T SQ” will appear on the display; in the case of DCS, “DCS” will appear on the
display.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 86: TN FRQ when TONE SQL is selected, or Set Mode
Item 24: DCS CD during DCS operation.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of the selected Set Mode Item.
5. Press and hold in the [BAND] key for one second, appear “T SRCH” (for CTCSS Tone Search) or “D
SRCH” (for DCS Tone Search) on the display, then release the [BAND] key to start scanning for the
Vertex Standard Co., Ltd.
22
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
incoming CTCSS or DCS tone/code.
6. When the radio detects the correct tone or code, it will halt on that tone/code, and audio will be allowed
to pass. Press the [BAND] key to lock in that tone/code, then press PTT to exit to normal operation.
R.F. Says: If the Tone Scan feature does not detect a tone or code, it will continue to scan indefinitely. When
this happens, it may be that the other station is not sending any tone. You can press the PTT switch to halt
the scan at any time.
You may listen to the (muted) signal from the other station during Tone Scanning when Set Mode Item 88:
TS MUT is set to “OFF.” See page ?? for details. You can also change the Tone Search scanning speed,
using Set Mode Item 89: TS SPD. See page ??.
Tone Scanning works either in the VFO or Memory modes.
EPCS (Enhanced Paging & Code Squelch)
The VX-3R includes an Enhanced CTCSS tone encoder/decoder and a dedicated microprocessor
providing paging and selective calling features. This allows you to place a call to a specific station (Paging),
and to receive calls of your choice directed only to you (Code Squelch).
The paging and code squelch systems use two pairs of (alternately switched) CTCSS tones which are
stored in the pager memories. Basically, your receiver remains silent until it receives the CTCSS tone pair
that matches those stored in the Receiving Pager Memory. The squelch then opens so the caller is heard,
and the paging ringer immediately sounds, if activated. When you close the PTT switch to transmit, the
CTCSS tone pair which is stored in the Transmitting Pager Memory will be transmitted automatically.
On the paged radio, the squelch will close automatically after the incoming page ends. Meanwhile, on the
paging radio, the Enhanced Paging and Code Squelch system will be disabled after the PTT switch is
released after the paging transmission. You may re-activate the Enhanced Paging and Code Squelch
system again.
Storing the CTCSS Tone Pairs for EPCS Operation
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 61: PAG.CDR for the Receiving CTCSS Tone Pair or Set
Mode Item 62: PAG.CDT for the Transmitting CTCSS Tone Pair.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set the CTCSS Tone number which corresponds to the first tone of the CTCSS
Tone Pair.
5. Press the [V/M] key, then rotate the DIAL knob to set the CTCSS Tone number which corresponds to
the second tone of the CTCSS Tone Pair.
Vertex Standard Co., Ltd.
23
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
6. Press the PTT switch to save the new setting and exit to normal operation.
R.F. Says: The VX-3R does not recognize the order of the 1st tone and the 2nd tone. In other words, for
example, the VX-6R considers both CTCSS pairs “10, 35” and “35, 10” to be identical.
Activating the Enhanced Paging & Code Squelch System
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 79: SQ TYP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “PAGER”.
5. Press the PTT switch to save the new setting and activate the Enhanced Paging & Code Squelch.
To disable the Enhanced Paging & Code Squelch, just repeat the above procedure, rotate the DIAL knob to
select “OFF” in step 4 above.
When the Enhanced Paging & Code Squelch feature is activated, the “P” notation will appear at the 100
MHz digit of the frequency display.
R.F. Says: During Enhanced Paging & Code Squelch operation, you may set up the VX-3R such that a
ringing “bell” sound alerts you to the fact that a call is coming in. See page ?? for details.
Paging Answer Back
When you press the PTT switch to respond to a page call, the VX-3R transmits the same CTCSS tone pair.
This tone pair will open the Code Squelch of the calling station. If you prefer, you can have the VX-3R
respond to page calls automatically (“transpond”).To enable this feature:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 60: PAG.ABK.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “ON”.
5. Press the PTT switch to save the new setting and exit to normal operation.
R.F. Says: The Paging Answer Back feature constitutes a form of “remote control” operation that may be
restricted to certain frequencies. U.S. users should confirm the current status of $97.201(b) of the FCC’s
rules governing the Amateur service before utilizing this feature on the 144 MHz band.
CTCSS/DCS/EPCS Bell Operation
During CTCSS Decode, DCS, or EPCS operation, you may set up the VX-3R such that a ringing “bell”
sound (or user programmed beep) alerts you to the fact that a call is coming in. Here is the procedure for
activating the CTCSS/DCS/EPCS Bell:
Vertex Standard Co., Ltd.
24
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
1. Set the operating frequency to the desired channel.
2. Set the transceiver up for CTCSS Decode (“Tone Squelch”), DCS, or EPCS operation, as described
previously.
3. Press and hold in the [TXPO] key for one second to enter the Set mode.
4. Rotate the DIAL knob to select Set Mode Item 10: BEL.SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
5. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
6. Rotate the DIAL knob to set the desired “bell” sound. The available choices are ON (rings “bell” ringer),
USERBP1, USERBP2, USERBP3 or OFF (disable the Bell function).
Note: When User Beep (described later) does not register, USERBP1, USERBP2, or USERBP3 does
not appear.
7. Press the [TXPO] key momentarily, then rotate the DIAL knob one click counter-clockwise to select Set
Mode Item 9: BEL.RNG.
8. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
9. Rotate the DIAL knob to set the desired number of rings of the Bell. The available choices are 1
through 20 rings or CONT (continuous ringing).
10. Press the PTT switch momentarily to save the new setting and exit to normal operation.
When you are called by a station whose transceiver is sending a CTCSS tone, DCS code, or CTCSS tone
pair which matches that set into your Decoder, the Bell will ring in accordance with this programming.
When the CTCSS/DCS/EPCS Bell is activated, the “Bell” icon will appear in the display.
To disable the CTCSS/DCS/EPCS Bell function, select the setting of Set Mode Item 10: BEL.SEL to “OFF”.
Programming the User Beep
Three User Beep Memories are provided, allowing you to create your original beep tone.
Each User Beep Memory can be stored up to 64 steps with three octaves (“C1” through “B3”).
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 10: BP SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the memory slot into which you wish to store your programmed beep.
Available selections are BP1, BP2, and BP3. Display the previous stored beep.
5. Press the [V/M] key to enable programming the beep. Press and hold the [HM/RV] key for one second
to clear any previous beep, if desired.
6. Rotate the DIAL knob to select the first beep tone of the User Beep.
7. Press the [V/M] key, then rotate the DIAL knob to set the length of the first beep tone. Available
selections are 1 (0.1 sec) - 250 (2.5 sec).
Vertex Standard Co., Ltd.
25
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
8. Press the [V/M] key to accept the first beep tone of the User Beep.
9. If you mistake, press the [BAND] key to back-space the cursor, then re-enter the correct beep tone or
length.
10. Repeat steps 6 - 9 until you have completed the User Beep.
11. When there is a beep tone which you wish to delete, bring the cursor to that beep tone using the
[BAND]/[V/M] key, then press the [MODE] key repeatedly till to display the “dEL” notation in the
Memory Channel Number display slot, press and hold in the [MODE] key for one second to delete that
beep tone.
12. When you wish to add the beep tone into the beep tone strings, bring the cursor to the beep tone to the
desired place using the [BAND]/[V/M] key, then press the [MODE] key repeatedly till to display the
“InS” notation in the Memory Channel Number display slot, press and hold in the [MODE] key for one
second to add the beep tone.
13. Press and hold the [HM/RV] key for one second to delete all data after the current position that may
have been previously stored beep.
14. When you have programmed User Beep, press the [TXPO] key momentarily to confirm the User Beep.
R.F. Says: You may check your work by monitoring the programmed User Beep. To do this, repeat steps 1 -
4 above, then press the [F/W] key.
Split Tone Operation
The VX-2R can be operated in a Split Tone configuration via the Set mode.
1. Press and hold in the [H/L] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 81: SQSPLT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [H/L] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “ON” (to enable the Split Tone feature).
5. Press the PTT switch momentarily to save the new setting and exit to normal operation.
When the Split Tone feature is activated, you can see the following additional parameters after the
“MESSAGE” parameter while selecting the Set Mode Item 79: SQ TYP:
D CODE: DCS Encode only
(the “DCS” icon will blink during operation)
T DCS: Encodes a CTCSS Tone and Decodes a DCS code
(the “T” icon will blink and the “DCS” icon will appear during operation)
D TONE: Encodes a DCS code and Decodes a CTCSS Tone
(the “TSQ” icon will appear and the “DCS” icon will blink during operation)
Select the desired operating mode, from the selections shown above, within Set Mode Item 79.
Vertex Standard Co., Ltd.
26
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Tone Calling (1750 Hz)
If the repeaters in your country require a 1750-Hz burst tone for access (typically in Europe), you can set
the MONI key to serve as a “Tone Call” switch instead. To change the configuration of this switch, we again
use the Set Mode to help us.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 47: M/T-CL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “T-CALL” on the display.
5. Press the PTT switch to save the new setting and exit to normal operation.
To access a repeater, press and hold in the MONI key for the amount of time specified by the repeater
owner/operator. The transmitter will automatically be activated, and a 1750-Hz audio tone will be
superimposed on the carrier. Once access to the repeater has been gained, you may release the MONI key,
and use the PTT switch for activating the transmitter thereafter.
Memory Mode
The VX-3R provides a wide variety of memory system resources. These include:
“Regular” Memory Channels, which include:
• 900 “Standard” memory channels, numbered “1” through “900.”
• 100 “Frequency Skip Memories,” numbered “901” through “999” and “000.”
• 11 “Home” channels, providing storage and quick recall of one prime frequency on each operating
band.
• 50 sets of band-edge memories, also known as “Programmable Memory Scan” channels, labeled
“L01/U01” through “L50/U50.”
• 24 Memory Banks, labeled “b 1” through “b24.” Each Memory Bank can be assigned up to 100
channels from the “regular” memory channels.
Special Memory Channels, which include:
• 10 “Weather Broadcast” Channels.
• 281 VHF Marine Channels
• 89 popular Short-wave Broadcast Station Memory Channels.
Vertex Standard Co., Ltd.
27
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Regular Memory Channel Operation
Memory Storage
1. Select the desired frequency, while operating in the VFO mode. Be sure to set up any desired CTCSS
or DCS tones, as well as any desired repeater offset. The power level may also be set at this time, if
you wish to store it.
2. Press and hold in the [F/W] key for 1/2 seconds.
3. Within five seconds of releasing the [F/W] key, you need to make a decision regarding channel storage.
The microprocessor will automatically select the next-available “free” channel (a memory register on
which no data has been stored), so you may not wish to make any change; if this is the case, proceed
to step 4. If you wish to select a different channel number into which to store the data, rotate the DIAL
knob to select the desired memory channel.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
You may jump 100 memory channels, if you’re in a hurry (101 201 301 …), by pressing the
[TXPO] key (multiple times, if necessary). Any channel that you see with a blinking channel number
currently has no data written on it (i.e. the channel is “free”).
4. Press the [F/W] key once more to store the frequency into memory.
5. You still will be operating in the “VFO” mode, so you may now enter other frequencies, and store them
into additional memory locations, by repeating the above process.
R.F. Says: 1) You may change the automatic memory channel selection feature to select the “next-highest
memory channel above the last-stored memory channel” instead of the “next-available ‘free’ channel” via
the Set Mode Item 50: MW WMD; see page ??.
2) You may disable the memory write function which to prevent memory write by wrong operation via the
Set Mode Item 53: MRPTCT. See page ?? for details. When the memory write protect is activated,
“PROTCT” notation appear on the display while memory write operation.
Important Note: On rare occasions the memorized data may become corrupted by miss operation, or static
electricity. When repairs are made the memory data may be lost. Please write down or record the
memorized information so you will be able to restore it if needed.
Storing Independent Transmit Frequencies (“Odd Splits”)
All memories can store an independent transmit frequency, for operation on repeaters with non-standard
shift. To do this:
1. Store the receive frequency using the method already described under MEMORY STORAGE (it
doesn’t matter if a repeater offset is active).
2. Turn to the desired transmit frequency, then press and hold in the [F/W] key for 1/2 seconds.
3. Within five seconds of releasing the [F/W] key, rotate the DIAL knob to select the same memory
channel number as used in step “1” above.
Vertex Standard Co., Ltd.
28
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press and hold in the PTT switch, then press the [F/W] key once more momentarily while holding the
PTT switch in (this does not key the transmitter).
R.F. Says: Whenever you recall a memory which contains independently-stored transmit and receive
frequencies, the “–+” indication will appear in the display.
Memory Recall
1. While operating in the VFO mode, press the [V/M] key to enter the Memory mode.
2. Rotate the DIAL knob to select the desired channel.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. If you press the [F/W] key momentarily, then rotate the DIAL knob, the memory channel will be selected
in 10 channels per step.
4. To return to the VFO mode, press the [V/M] key.
R.F. Says: You may change the step of the fast channel selection mode ([F/W] key + DIAL knob) via Set
Mode Item 51: MRFSTP. See page ?? for details.
HOME Channel Memory
A special one-touch “HOME” channel is available for each of operating bands, to allow quick recall of a
favorite operating frequency on each band.
HOME Channel Recall
1. Press the [F/W] key then press the [HM/RV] key to recall the Home Channel on the band group where
you currently are operating.
2. Press the [F/W] key then press the [HM/RV] key again to return to the previous-used frequency (either
a VFO or a memory channel).
The transceiver switches to VFO mode if the DIAL knob is turned.
R.F. Says: You may disable the above function (automatically switched to the VFO mode) via Set Mode
Item 37: HM>VFO.
Home Channel Frequency Change
The factory default for the Home channel is listed below. You may re-program the Home channel in a
manner identical to that used for the regular memories:
1. Select the desired frequency, while operating in the VFO mode. Be sure to set up any desired CTCSS
or DCS tones, as well as any desired repeater offset. The power level may also be set at this time, if
you wish to store it.
2. Press and hold in the [F/W] key for 1/2 seconds.
Vertex Standard Co., Ltd.
29
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
3. While the memory channel number is blinking, just press the [HM/RV] key. The frequency and other
data (if any) will now be stored in the special HOME channel register.
4. You may repeat this process on the other operating bands.
R.F. Says: The UHF HOME channel is the one used during “Emergency” operation. See page ?? for details
regarding this feature.
Default Home Channels
BAND FREQUENCY BAND FREQUENCY
BC Band 0.540 MHz VHF-TV Band 174.000 MHz
SW Band 1.800 MHz Information Band 1 230.000 MHz
50 MHz Ham Band 30.000 MHz 430 MHz Ham Band 446.000 MHz
FM BC Band 59.000 MHz VHF-TV Band 470.000 MHz
Air Band 108.000 MHz Information Band 2 860.000 MHz
144 MHz Ham Band 146.520 MHz – –
Labeling Memories
You may wish to append an alpha-numeric “Tag” (label) to a memory or memories, to aid in recollection of
the channel’s use (such as a club name, etc.). This is easily accomplished using the Set Mode.
1. Recall the memory channel on which you wish to append a label.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select the Set Mode Item 52: MRNAME.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
5. Rotate the DIAL knob to select the first digit of the desired label.
6. Press the [V/M] key to move to the next character.
7. Repeat steps 5 and 6 to program the remaining letters, numbers, or symbols of the desired label. A
total of six characters may be used in the creation of a label.
8. If you make a mistake, press the [BAND] key to back-space the cursor, then re-enter the correct letter,
number, or symbol.
9. When you have completed the creation of the label, press the PTT switch to save the label and returns
to memory mode with alpha-numeric “Tag” (label) display.
R.F. Says: You may check the frequency of the “Tagged” memory channel temporarily by press and holding
the [MONI] key. Release the [MONI] key to return to “Tag” display.
To disable the alpha-numeric Tag (enabling the frequency display):
1. Set the VX-3R to the “MR” (Memory Recall) mode, and recall the memory channel on which you wish
to disable the alpha-numeric Tag.
Vertex Standard Co., Ltd.
30
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select the Set Mode Item 49: MR DSP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Item’s setting.
5. Rotate the DIAL knob to set this Set Mode Item to “FREQ” (thus disabling the alpha-numeric display).
6. Press the PTT switch to save the new setting and returns to memory mode with frequency display.
To enable the alpha-numeric Tag (label) display again, just repeat above procedure, rotating the DIAL knob
to select “ALPHA” in step 5 above.
R.F. Says: You may set up some memory channels to have their frequencies displayed, while others may
be set to have their Name Tag displayed; the selection within Set Mode Item 49 is not applied to all memory
channels at once.
Memory Offset Tuning
Once you have recalled a particular memory channel, you may easily tune off that channel, as though you
were in the “VFO” mode.
1. With the VX-3R in the “MR” (Memory Recall) mode, select the desired memory channel.
2. Press the [F/M] key, then press the [V/M] key to activate the “Memory Tuning” feature. The Memory
Channel number will be replaced by “tun.”
3. Rotate the DIAL knob, as desired, to tune to a new frequency. The synthesizer steps selected for VFO
operation on the current band will be the steps used during Memory Tuning.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. If you wish to return to the original memory frequency, just press the [V/M] key momentarily.
5. If you wish to store a new frequency set during Memory Tuning, just press and hold in the [F/W] key for
1/2 seconds, per normal memory storage procedure. The microprocessor will automatically set itself to
the next-available clear memory location, and you then press [F/W] again to lock in the new frequency.
R.F. Says: 1) If you want to replace the original memory contents with those of the new frequency, be sure
to rotate the DIAL knob to the original memory channel number!
2) Any required CTCSS/DCS changes, or repeater offset modifications, must be done before storing the
data into the new (or original) memory channel location.
Masking Memories
There may be situations where you want to “Mask” memories so they are not visible during memory
selection or scanning. For example, several memories used only in a city you visit infrequently may be
stored, then “Masked” until you visit that city, at which time you can “Unmask” them for normal use.
1. Press the [V/M] key, if needed, to enter the MR mode.
2. Press and hold in the [F/W] key for one second, then rotate the DIAL knob to select the memory
Vertex Standard Co., Ltd.
31
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
channel to be “Masked” from view.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [%] key. The confirmation massage (M-DEL?) will appear on the display. Press the [F/W] key
to cancel the Masking Memory procedure, if desired.
4. Press the [%] key once more. The display will revert to memory channel #1. If you rotate the DIAL knob
to the location you just “Masked,” you will observe that it is now invisible.
5. To Unmask the hidden memory, repeat the above procedure: press and hold in the [F/W] key for one
second, rotate the DIAL knob to select the masked memory’s number, then press the [%] key to restore
the memory channel’s data.
R.F. Says: Watch out! You can manually store data over a “Masked” memory, deleting previous data, if
you’re not careful. Use the “next available memory” technique storage technique to avoid over-writing a
masked memory.
Memory Bank Operation
The large number of memories available in the VX-3R could be difficult to utilize without some
means of organizing them. Fortunately, the VX-3R includes provision for dividing the memories
into as many as twenty Memory Groups, so you can categorize the memories in a manner
convenient to you. You may enter and exit the “Memory Group” mode by a single press of the
[BAND] key, as we shall see below.
Assigning Memories to a Memory Bank
1. Recall the memory channel to be assigned to a Memory Bank.
2. Press and hold in the [F/W] key for one second, then rotate the DIAL knob to select the Memory Bank
number you want as the Memory Bank for this channel (“b 1” ~ “b24,” which is found before memory
channel “1”).
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [F/W] key momentarily.
4. At this point, the memory channel data is copied into the Memory Bank.
Memory Bank Recall
1. Press the [V/M] key, if needed, to enter the MR mode.
2. Press the [BAND] key to activate the “Memory Bank” mode. The Memory Bank number will appear on
the display.
3. Press the [F/W] key, then press the [BAND] key.
4. Rotate the DIAL knob to select the desired Memory Bank (“BANK 1” through “BANK 24”).
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
Vertex Standard Co., Ltd.
32
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
5. Press the [BAND] key; now, as you rotate the DIAL knob to select memories, you will observe that you
can only select memory channels in the current memory bank.
6. To change to another Memory Bank, press the [F/W] key, then press the [BAND] key; now rotate the
DIAL knob to select the new Memory Bank.
7. To exit from Memory Bank operation, just press the [BAND] key. “MEMORY” will appear on the display,
indicating that you are now in the “regular” Memory Recall mode, without utilization of the Memory
Banks. The memories stored in the various Banks will remain in those banks, however; you do not
need to store them again.
Removing Memories from a Memory Bank
1. Recall the memory channel to be removed from a Memory Bank.
2. Press and hold the [F/W] key for one second, then press the [%] key to remove the memory channel
data from the Memory bank.
Changing a Memory Bank’s Name
You may change the default Memory Bank Name which is indicates on the display while selecting the
Memory Bank to your desired.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select the Set Mode Item labeled 11: BNK.NAM.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the memory bank on which you wish to change a label.
5. Press the [TXPO] key momentarily to enable changing of the name tag.
6. Rotate the DIAL knob to select the first digit of the desired label.
7. Press the [V/M] key to move to the next character.
8. Repeat steps 6 and 7 to program the remaining letters, numbers, or symbols of the desired label. A
total of six characters may be used in the creation of a label.
9. If you make a mistake, press the [BAND] key to back-space the cursor, then re-enter the correct letter,
number, or symbol.
10. When you have completed the changing of the label, press the PTT switch to save the label and exit.
Moving Memory Data to the VFO
Data stored on memory channels can easily be moved to the VFO, if you like.
1. Select the memory channel containing the frequency data to be moved to VFO.
2. Press and hold in the [F/W] key for one second, then press the [V/M] key. The confirmation massage
(V-WRT?) will appear on the display. Press the [F/W] key to cancel the Moving Memory Data
Vertex Standard Co., Ltd.
33
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
procedure, if desired.
3. Press the [V/M] key once more. The data will now have been copied to the VFO, although the original
memory contents will remain intact on the previously-stored channel.
R.F. Says: If a Split Frequency Memory channel was transferred, the Tx frequency will be ignored (you will
be set up for Simplex operation on the Receive frequency).
Memory Only Mode
Once memory channel programming has been completed, you may place the radio in a “Memory Only”
mode, whereby VFO operation is impossible. This may be particularly useful during public-service events,
where a number of operators may be using the radio for first time, and ultimate simplicity of channel
selection is desired.
To place the radio into the Memory Only mode, turn the radio off. Now press and hold in the [V/M] key while
turning the radio on. To return to normal operation, repeat the above power-on procedure.
Special Memory Channel Operation
The VX-3R provides Special Memory Channels, which made up of:
10 “Weather Broadcast” Channels.
281 VHF Marine Channels
89 popular Short-wave Broadcast Station Memory Channels.
R.F. Says: You may assign a Weather Broadcast channel to a Memory Bank. See page ?? regarding
Memory Bank Operation for details.
Weather Broadcast Channels
The VHF Weather Broadcast Station Memory Channel Bank has been pre-programmed at the factory, for
quick selection of NOAA weather information stations.
1. Press the [F/W] key, then press the [%] key, to recall the Special Memory Menu.
2. Press the [BAND] key, repeatedly if necessary to select the “WX CH” (thus recalling the Weather
Broadcast Memory Bank).
3. Rotate the DIAL knob to select the desired Weather Broadcast channel.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. If you wish to scan this bank to search for louder stations, just press the PTT switch. When the scanner
pauses on a station, press the PTT switch once to halt the scan, or press it twice to restart the scan.
5. To exit to normal operation, press the [V/M] key, or press [F/W] key followed by the [%] key.
<<WX channel list>>
R.F. Says: 1) In the event of extreme weather disturbances, such as storms and hurricanes, the NOAA
Vertex Standard Co., Ltd.
34
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
(National Oceanic and Atmospheric Administration) sends a weather alert accompanied by a 1050 Hz tone
and subsequent weather report on one of the NOAA weather channels. You may disable the Weather Alert
tone via Set Mode Item 93: WX ALT, if desired. See page ??.
2) You may append and display an alpha-numeric “Tag” (label) to a Weather Broadcast channel or channels.
See page ?? regarding the labeling of a memory for details.
VHF Marine Channels
Another special Memory Bank contains VHF Marine Channels, pre-programmed at the factory, for quick
selection.
1. Press the [F/W] key, then press the [%] key, to recall the Special Memory Menu.
2. Press the [BAND] key, repeatedly if necessary, to select “MARINE” (thus recalling the Marine Channel
Memory Bank).
3. Rotate the DIAL knob to select any of 281 available VHF Marine Channels.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. To exit to normal operation, press the [V/M] key, or press [F/W] key followed by the [%] key.
Short-Wave Broadcast Station Memory Channels
A large number of Short-Wave Broadcast Station Memory Channels have also been pre-programmed at the
factory, for convenient selection of broadcast stations.
1. Press the [F/W] key, then press the [%] key, to recall the Special Memory Menu.
2. Press the [BAND] key to select “RADIO” (thus recalling the Broadcast Station Channel Memory Bank).
3. Rotate the DIAL knob to select any of 89 available Broadcast Stations.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press and hold the [MONI] key to display the receiving frequency “Station’s Frequency” (and disabling
the squelch). Release the [MONI] key to return to “Station Name” display.
5. To exit to normal operation, press the [V/M] key, or press the [F/W] key followed by the [%] key.
Scanning
The VX-3R allows you to scan just the memory channels, the entire operating band, or a portion of that
band. It will halt on signals encountered, so you can talk to the station(s) on that frequency, if you like.
Scanning operation is basically the same in each of the above modes. Before you begin, take a moment to
select the way in which you would like the scanner to resume scanning after it halts on a signal.
Setting the Scan-Resume Technique
Five options for the Scan-Resume mode are available:
2 SEC - 10 SEC: In this mode, the scanner will halt on a signal it encounters, and will hold there for the
Vertex Standard Co., Ltd.
35
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
selected resume time. If you do not take action to disable the scanner within that time period, the scanner
will resume even if the stations are still active.
BUSY: In this mode, the scanner will halt on a signal it encounters. When the carrier has dropped because
the other station(s) ceased transmission, the scanner will resume. In the case of constant-carrier signals
like Weather Station broadcasts, the scanner will likely remain on this frequency indefinitely. The Scan
Re-start Delay time (default interval: 2 seconds) is set by the Set Mode Item 76: SCN.STR.
HOLD: In this mode, the scanner will halt on a signal it encounters. It will not restart automatically; you must
manually re-initiate scanning if you wish to resume.
To set the Scan-Resume mode:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 75: SCN.RSM.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired scan-resume mode described above.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: The default condition for this Set Mode Item is “5 SEC.”
To set the Scan-Restart Delay Time:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 76: SCN.STR.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired Scan-Restart Delay Time. Available selections are 100 -
1000 MS (100 MS/step) and 1 - 10 SEC (0.5 SEC/step).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: The default condition for this Set Mode Item is “2 SEC.”
VFO Scanning
This mode allows you to scan on the VFO mode.
1. Select the VFO mode by pressing the [V/M] key, if necessary.
2. Press and hold in the [BAND] key for one second, and rotate the DIAL knob while holding in the
[BAND] key to select the bandwidth for the VFO scanner. Available selections are ±1 MHz, ±2 MHz, ±5
MHz, BAND, ALL, and PMS-X.
Vertex Standard Co., Ltd.
36
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
±1 MHz, ±2 MHz, ±5 MHz: The scanner will sweep frequencies within the selected bandwidth.
BAND: The scanner will sweep frequencies only on the current band.
ALL: The scanner will sweep all frequencies between 0.5 MHz and 999 MHz.
PMS-X: The scanner will sweep frequencies within the currently-selected PMS frequency pair. See
page ?? for details.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Release the [BAND] key to start scanning.
4. If and when the scanner encounters a signal strong enough to open the squelch, the scanner will halt
temporarily; the decimal point of the frequency display will blink during this “Pause” condition.
5. The scanner will then resume according to the Scan-Resume mode selected in the previous section.
6. To cancel scanning, press the PTT switch or [V/M] key.
R.F. Says: 1) When you start scanning, the VX-3R will be changing frequency in the upward direction. If you
want to change direction of the scan while it is underway, rotate the DIAL knob one click in the opposite
direction (in this case, one click counter-clockwise). You’ll see the scanner turn around and change
frequency downward!
2) You may change the scanner’s method of operation so that the VFO frequency will jump to the low band
edge of the next band when the VFO frequency reaches the high edge of the current band (or vice versa).
See page ?? regarding Set Mode Item 90: VFO MD.
Setting the Squelch Level during active Scanning operation
The VX-3R allows adjustment of the Squelch level “on the fly” while you are scanning.
1. While the scanner is engaged, press the [F/W] key, then press the MONI key (the current squelch level
will appear below the frequency display).
2. Rotate the DIAL to select the desired Squelch level.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the PTT switch momentarily to save the new setting and exit to normal operation. In this case,
pressing the PTT switch this one time will not causing scanning to stop.
How to Skip (Omit) a Frequency during VFO Scan
If the VFO scan stops on a frequency or frequencies that you do not need (such as a spurious radiation
from a television), such frequencies can be “skipped” during VFO scanning. This accomplished by storing
these frequencies in a special “Frequency Skip Memory” bank reserved for this purpose.
To skip a frequency during VFO scanning:
1. While VFO scanning is stopped on the frequency that you do not need, press and hold the [F/W] key
for 1/2 seconds, then rotate the DIAL knob to select the desired Frequency Skip Memory channel (901
Vertex Standard Co., Ltd.
37
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
- 999, and 000). The microprocessor will automatically select the next-available “free” Frequency Skip
Memory channel (a memory register on which no data has been stored). If you see that any blinking
channel number, it means that the channel currently has no data written on it (i.e. the channel is “free”).
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
2. Press the [F/W] key to store the frequency into the Frequency Skip Memory; it now is programmed to
be ignored during VFO scanning.
R.F. Says: The VX-3R has 100 VFO Frequency Skip Memory Channels.
To re-institute a frequency into the VFO scan loop:
1. Press the [V/M] key, if needed, to enter the MR mode.
2. Press and hold in the [F/W] key for 1/2 seconds, then rotate the DIAL knob to select the memory
channel to be re-instituted.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [%] key to delete the channel from the Frequency Skip Memory; this will re-institute the
frequency into the VFO scan loop.
Memory Scanning
Memory scanning is similarly easy to initiate:
1. Set the radio to the Memory mode by pressing the [V/M] key, if necessary.
2. Press and hold in the [BAND] key for one second, and rotate the DIAL knob while holding in the
[BAND] key to select the desired Memory Scan mode. Available selections are ALL CH, TAG1, TAG2,
BAND, and PMS-X.
ALL CH: The scanner sweeps all Memory channels.
TAG1: The scanner sweeps only those Memory channels with the same first digit of the
alpha/numeric tag as the first channel on which scanning started.
TAG2: The scanner sweeps only those Memory channels with the same first and second digits
of the alpha/numeric tag as the first channel on which scanning started.
BAND: The scanner sweeps only those Memory channels which are memorized on the same
operating band as the first channel on which scanning started.
PMS-X: The scanner will sweep frequencies within the currently-selected PMS frequency pair. See
page ?? for details.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Release the [BAND] key to initiate scanning.
4. As with VFO scanning, the scanner will halt on any signal encountered that is strong enough to open
the squelch; it will then resume scanning according to the Scan-Resume mode set previously.
5. To cancel scanning, press the PTT switch or [V/M] key.
Vertex Standard Co., Ltd.
38
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
How to Skip (Omit) a Channel during Memory Scan Operation
As mentioned previously, some continuous-carrier stations like a Weather Broadcast station will seriously
impede scanner operation if you are using the “Carrier Drop” Scan-Resume mode, as the incoming signal
will not pause long enough for the transceiver to resume scanning. Such channels may be “Skipped” during
scanning, if you like:
1. Recall the Memory Channel to be skipped during scanning.
2. Press and hold the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select the Set Mode Item 54: MRSKIP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
5. Rotate the DIAL knob so as to select “SKIP.” The current Memory Channel will now be ignored during
scanning. The “ONLY” selection is used for “Preferential Memory Scan,” described in the next column.
6. When you have made your selection, press the PTT switch to save the setting and exit to normal
operation.
When you recall the “skipped” memory channel manually, a small “” icon will appear at the above of the
volume level indicator, indicating it is to be ignored during scanning.
To re-institute a channel into the scanning loop, select “OFF” in step 5 above (the “Skipped” channel will, of
course, still be accessible via manual channel selection methods using the DIAL knob in the MR mode,
whether or not it is locked out of the scanning loop).
One Touch Memory Skip
If the scanner repeatedly stops on a channel due to temporary noise or interference while Memory Channel
Scan is activating, you can mark it to be skipped (except for Memory Channel “1”) By simple operation.
To skip a channel temporarily, press the [F/W] key, then press the [V/M] key while the scanner has stopped
on the channel to be skipped. The scanner will instantaneously resume, and that channel will be assigned
to the “skipped” memory channel.
To re-institute a channel into the scanning loop, perform the “How to Skip (Omit) a Channel during Memory
Scan Operation” described previously, then select “OFF” in step 5.
Preferential Memory Scan
The VX-3R also allows you to set up a “Preferential Scan List” of channels which you can “flag” within the
memory system. These channels are designated by a blinking “” icon when you have selected them, one
by one, for the Preferential Scan List.
When you initiate memory scanning, beginning on a channel with the blinking “” icon appended, only
those channels bearing the blinking “” icon will be scanned. If you initiate scanning on a channel which
Vertex Standard Co., Ltd.
39
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
does not have the blinking “” icon appended, you will scan all channels including those with the blinking
“” icon appended.
Here is the procedure for setting up and using the Preferential Scan List:
1. Recall the Memory Channel which you wish to add to the Preferential Scan List.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 54: MRSKIP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
5. Rotate the DIAL knob so as to select “ONLY.”
6. When you have made your selection, press the PTT switch to save the settings and exit to normal
operation.
To initiate Preferential Memory Scan:
1. Press the [V/M] key momentarily to enter the Memory Recall mode, if you are not using memories
already.
2. Rotate the DIAL to select any channel which has a blinking “” icon appended to the channel number.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press and hold in the [BAND] key for one second, and rotate the DIAL knob while holding in the
[BAND] key, to select the desired Memory Scan mode.
4. ALL CH: The scanner sweeps all Memory channels.
TAG1: The scanner sweeps only those Memory channels with the same first digit of the
alpha/numeric tag as the first channel on which scanning started.
TAG2: The scanner sweeps only those Memory channels with the same first and second digits
of the alpha/numeric tag as the first channel on which scanning started.
BAND: The scanner sweeps only those Memory channels which are memorized on the same
operating band as the first channel on which scanning started.
PMS-X: The scanner will sweep frequencies within the currently-selected PMS frequency pair. See
page ?? for details.
5. Release the [BAND] key to initiate Preferential Memory Scanning. Only the channels which have a
blinking “” icon appended to the channel number will be scanned.
Programmable (Band Limit) Memory Scan (PMS)
This feature allows you to set sub-band limits for either scanning or manual VFO operation. For example,
you might with to set up a limit (in North America) of 144.300 MHz to 148.000 MHz so as to prevent
encroachment into the SSB/CW “Weak Signal” portion of the band below 144.300 MHz. Here’s how to do
Vertex Standard Co., Ltd.
40
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
this:
1. Set the radio to the VFO mode by pressing the [V/M] key, if necessary.
2. Using the techniques learned earlier, store (per the above concept) 144.300 MHz into Memory
Channel #L1 (the “L” designates the Lower sub-band limit).
3. Likewise, store 148.000 MHz into Memory Channel #U1 (the “U” designates the Upper sub-band limit).
4. Switch to the Memory mode by pressing the [V/M] key once, then rotate the DIAL to select Memory
Channel # L1.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
5. Press the [F/W] key, then press the [V/M] key to start PMS operation; the Memory Channel number will
be replaced by “P 1.” Tuning and scanning (engaged by pressing and holding in the [BAND] key for
one second) will now be limited within the just-programmed range.
6. 50 pairs of Band Limit memories, labeled L1/U1 through L50/U50 are available. You therefore can set
upper and lower operation limits on a number of bands, if you like.
Priority Channel Scanning (Dual Watch)
The VX-3R’s scanning features include a two-channel scanning capability which allows you to operate on a
VFO or Memory channel, while periodically checking a user-defined Memory Channel for activity. If a
station is received on the Memory Channel which is strong enough to open the Squelch, the scanner will
pause on that station in accordance with the Scan-Resume mode set via Set Mode Item 75: SCN.RSM.
See page ??.
Here is the procedure for activating Priority Channel Dual Watch operation:
1. Press the [V/M] key momentarily to enter the Memory Recall mode, if you are not using memories
already.
2. Press and hold in the [F/W] key for one second, then rotate DIAL knob to select the memory channel
you wish to be the “Priority” channel.
3. Press the [BAND] key. The “PRI” icon will appear at the above of the volume level indicator, indicating it
is the Priority channel.
4. Now set the VX-3R for operation on another memory channel, or on a VFO frequency.
5. Press and hold in the [V/M] key for one second. The display will remain on the VFO or memory channel
selected; however, the “DW” icon will appear on the display, and every five seconds the VX-3R will
check the Priority Channel for activity. If a station appears on the Priority Channel, the radio will pause
on that channel, as described previously.
R.F. Says: The receiving time interval (ratio) between the current channel (or VFO frequency) and Priority
channel may be customized via Set Mote Item 65: PRI.TMR.
Vertex Standard Co., Ltd.
41
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
To set the receiving time interval:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 65: PRI.TMR.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired time interval. Available selections are 0.1S - 0.5S
(0.5S/step) and 1.0S - 10S (0.5S/step).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: The default condition for this Set Mode Item is “5.0S.”
Priority Revert Mode
During Priority channel operation (Dual Watch), a special feature is available which will allow you to move
to the Priority Channel instantly, without waiting for activity to appear on the Priority Channel.
When this feature is enabled, and priority monitoring is engaged, just press the microphone’s PTT switch.
Operation will instantly revert to the Priority Channel.
To enable Priority Revert operation:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 65: PRI.RVT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob so as to select “ON.”
5. When you have made your selection, press the PTT switch to save the settings and exit to normal
operation.
To disable Priority Revert operation, select “OFF” in step 4 above.
Automatic Lamp Illumination on Scan Stop
The VX-2R will automatically illuminate the LCD Lamp whenever the scanner stops on a signal; this allows
you to see the frequency of the incoming signal better at night. Note that this will, of course, increase the
battery consumption, so be sure to switch it off during the day (the default condition for this feature is “ON”).
The procedure for disabling the Scan Lamp is:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 74: SCN.LMP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
Vertex Standard Co., Ltd.
42
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
4. Rotate the DIAL knob to set this Set Mode Item to “OFF.”
5. When you have made your selection, press the PTT switch to save the setting and exit to normal
operation.
Band Edge Beeper
The VX-3R will automatically “beep” when a band edge is encountered during scanning (either in standard
VFO scanning or during PMS operation). You may enable this feature (band edge beeper) when the
frequency reaches the band edge while selecting the VFO frequency by the DIAL knob.
The procedure for enabling the Band-Edge Beeper is:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 12: BP EDG.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “ON.”
5. When you have made your selection, press the PTT switch to save the setting and exit to normal
operation.
Smart Search Operation
The Smart Search feature allows you to load frequencies automatically according to where activity is
encountered by your radio. When Smart Search is engaged, the transceiver will search above and below
your current frequency, storing active frequencies as it goes (without stopping on them even momentarily);
these frequencies are stored into a special Smart Search memory band, consisting of 31 memories (15
above the current frequency, 15 below the current frequency, plus the current frequency itself).
Two basic operating modes for Smart Search are available:
SINGLE: In this mode, the transceiver will sweep the current band once in each direction starting on the
current frequency. All channels where activity is present will be loaded into the Smart Search memories;
whether or not all 31 memories are filled, the search will stop after one sweep in each direction.
CONT: In this mode, the transceiver will make one pass in each direction as with One-Shot searching; if all
31 channels are not filled after the first sweep, however, the radio will continue sweeping until they are all
filled.
Setting the Smart Search Mode
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 71: S SRCH.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
Vertex Standard Co., Ltd.
43
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired Smart Search mode (see above).
5. When you have made your selection, press the PTT switch to save the setting and exit to normal
operation.
Storing Smart Search Memories
1. Set the radio to the VFO mode. Be sure that you have the Squelch adjusted properly (so that band
noise is quieted).
2. Rotate the DIAL, while pressing and holding in the [MODE] key, to select the “S SRCH (Smart Search)
Mode.”
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Release the [MODE] key to enter the Smart Search mode.
4. Press and hold the [BAND] key for one second to begin the Smart Search scanning.
5. As active channels are detected, you will observe the number of “loaded” channels increasing in the
regular memory channel window.
6. Depending on the mode you set for Smart Search operation (“SINGLE” or “CONT”), the Smart Search
scan will eventually terminate, and the LCD will revert to Smart Search Memory Channel “C.”
7. To recall the Smart Search memories, rotate the DIAL knob to choose from among the Smart Search
memories.
8. To return to normal operation, just press the [MODE] key.
R.F. Says: Smart Search is a great tool when visiting a city for the first time. You don’t need to spend hours
looking up repeater frequencies from a reference guidebook…just ask your VX-3R where the action is!
Channel Counter Operation
The Channel Counter allows measuring of the frequency of a nearby transmitter, without knowing that
frequency in advance. The frequency can be measured by bringing the VX-3R close to the transceiver
which is transmitting.
The VX-3R performs a high-speed search within a ±5 MHz range from the frequency displayed on the LCD.
When the strongest signal in that range is identified, the VX-3R displays the frequency of that (strongest)
signal, and writes it into the special “Channel Counter” memory.
Note: This Channel Counter is designed to provide an indication of the operating frequency of the incoming
signal, one that is close enough to allow the user, thereafter, to tune precisely to the other station’s
frequency. This feature is not, however, designed to provide a precise determination of the other station’s
frequency.
1. Set the radio to the VFO mode in the predicted frequency range for the transmitter to be measured.
Vertex Standard Co., Ltd.
44
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
2. Bring the VX-3R into close proximity to the transmitter to be measured.
3. Rotate the DIAL, while pressing and holding in the [MODE] key, to select the “CH CNT (Channel
Counter) mode.”
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Release the [MODE] key to begin the Channel Counter; the frequency of the nearby station will be
displayed. When the channel counter is active, a 50 dB receiver front-end attenuator will be engaged.
Therefore, only stations in close proximity may have their frequencies measured using this feature.
5. If it isn’t possible to determine the signal’s frequency, the transceiver will return to the frequency on
which you were operating when you started Channel Counter operation.
6. When you are finished, just press the [MODE] key. The radio will exit from Channel Counter operation.
Setting the Channel Counter Sweep Width
You may change the bandwidth of the Channel Counter. Available selections are ±5, ±10, ±50, and ±100
MHz (default: ±5 MHz).
Here is the procedure for setting the Channel Counter Bandwidth:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 17: CH CNT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired bandwidth.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
Message Feature
The VX-3R provides a message feature, which sent a message (up to 16 characters) instead of sending a
voice. 20 kinds of messages can be programmed, and one of them can be selected and transmitted with
your ID.
Note
The Message Feature requires that all members (1) use the VX-3R or Vertex Standard FTM-10R
transceiver, (2) store the same messages into the message slot, (3) store the same member list into
the member box, and (4) set the same frequency.
Does not send the Message through the repeater.
Programming a Message
(Requires all members set the same message into the same message slot in the same order.)
The VX-3R has 20 message slots, including a factory-programmed message (EMERGENCY). The
Vertex Standard Co., Ltd.
45
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
factory-programmed message of course can be overwritten at any time with personalized messages.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 57: MSG.SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired Message slot into which you wish to store a message. The
LCD displays the previously stored message.
5. Press the [TXPO] key momentarily to enable programming of the message.
6. Press the [HM/RV] key to clear the previously stored message, if desired.
7. Rotate the DIAL knob to select the first character of the message you wish to store, and then press the
[V/M] key to save the first character of the message and move on to the next place.
8. Repeat the previous step to complete the message (up to 16 characters). If you make a mistake, press
the [BAND] key to move back to the incorrect character, then re-enter the correct character.
9. Press the [HM/RV] key to delete all data after the cursor that may have been previously stored
erroneously.
10. When the Message entry is complete, press the [TXPO] key momentarily.
11. If you wish to store another message, repeat steps 3 through 10 above.
12. Press the PTT switch to exit to normal operation.
Programming a Member List
(Requires all members set the same member list (includes own ID) into the same member box in the same
order.)
It is possible to register a maximum of 20 persons, in order to identify the sender. When you receive a
message transfer, you can know who sent the message by the ID in the register. In addition, your ID can be
sent to the members when you transmit any messages to them.
If all the members share the register information (ID), the message sender ID will be shown on the display
when receiving the message.
Even if no IDs are registered, the function can work. However, in this case, “message sender ID” will be not
displayed when receiving a message.
We recommend that you use your call sign for the member list.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 50: MSG.LST.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired member box (01 ~ 20) into which you wish to store a
member ID. The LCD will display the previously stored personal ID.
Vertex Standard Co., Ltd.
46
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
5. Press the [TXPO] key momentarily to enable programming of the personal ID.
6. Press the [HM/RV] key to clear the previously stored personal ID, if desired.
7. Rotate the DIAL knob to select the first character of the personal ID you wish to store, and then press
the [V/M] key to save the first character of the personal ID and move on to the next place.
8. Repeat previous step to complete the personal ID (up to 8 characters). If you make a mistake, press
the [BAND] key to move back to the incorrect character, then re-enter the correct character.
9. Press the [HM/RV] key to delete all data after the cursor that may have been previously stored
erroneously.
10. When the personal ID entry is complete, press the [TXPO] key momentarily.
11. If you wish to store another personal ID, repeat steps 3 through 10 above.
12. Press the PTT switch to exit to normal operation.
Set your Personal ID
You choose your personal ID from the member list.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 56: MSG.REG.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the member box (1 ~ 20) where your ID is stored.
5. Press the PTT switch to save the new setting and exit to normal operation.
Sending a Messages
The registered message can be sent to the members who are receiving the coordination frequency.
When a message is sent, the transmitter’s ID will be sent also, and the receiver can identify who sent the
message.
Note: The “Personal ID” setting (described previous paragraph) is required for the transmitter’s ID to be
shown with the received message.
1. Set the radio to the coordination frequency.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 79: SQ TYP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
5. Rotate the DIAL knob to select “MESSAGE” (to activate the Message feature).
6. Press the [TXPO] key momentarily, then rotate the DIAL knob to select Set Mode Item 57: MEG.SEL.
7. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
8. Rotate the DIAL to select the message you wish to send.
Vertex Standard Co., Ltd.
47
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
9. Press the PTT switch to exit from the Set Mode and activates the Message feature.
10. When the Message feature is activated, the “M” notation will appear at the 100 MHz digit of the
frequency.
11. Press the PTT switch again (without the voice message) to transmit the selected message on the
coordination frequency. It takes approximately 6 seconds to transmit the message.
Receiving a Message
1. Set the radio to the coordination frequency.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 79: SQ TYP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
5. Rotate the DIAL knob to select “MESSAGE” (to activate the Message feature).
6. Press the PTT switch to exit from the Set Mode and activates the Message feature.
7. When you receive a message: a beep sounds, the TX/BUSY indicator blinks white, and [“Message”
FROM “sending station’s ID”] scrolls on the display.
8. Press any key (except [VOL] key) to clear the received message, and wait for a new message.
R.F. Say: If you enable the CTCSS/DCS/EPCS Bell feature (described previously), you can confirm that a
message is coming in by a ringing “bell” sound alert.
To disable the Message feature, repeat the above procedure, rotating the DIAL knob to select “OFF” in step
5 above.
Emergency Feature
Emergency Channel Operation
The VX-3R includes an “Emergency” feature which may be useful if you have someone monitoring on the
same frequency as your transceiver’s UHF “Home” channel. See page ?? for details on setting the Home
channel.
The “Emergency” feature is activated by pressing and holding in the [HM/RV] key for one second.
When this is done, (A) the radio is placed on the UHF amateur band Home channel, (B) it emits a loud
“Alarm” sound (the volume is controlled by the rotating the DIAL knob while press and holding the [VOL]
key), (C) it flashes the TX/BUSY indicator in white, (D) if you press the PTT switch, you will disable the
Emergency feature temporarily; you can then transmit on the UHF Home channel, and (E) two seconds
after the PTT release, the Emergency feature will resume.
To disable the “Emergency” feature, press and hold the [HM/RV] key for one second or turn the radio Off by
Vertex Standard Co., Ltd.
48
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
pressing and holding in the [POWER] switch for one second.
Use this feature if you are out for a walk and want a quick way of alerting a family member as to a
dangerous situation. The alarm sound may discourage an attacker and allow you to escape.
R.F. Says: 1) Be sure to arrange with a friend or family member to be monitoring on the same frequency, as
there will be no identification sent via the Emergency alarm sound. And do not transmit the alarm tone
except in a true emergency!
2) The TX/BUSY indicator may be changed to another function via Set Mode Item 32: EMG.SEL; see
page ??.
Emergency Automatic ID (EAI) Feature
The Emergency Automatic ID (EAI) feature can be used for searching for persons who are incapacitated in
disasters like earthquakes, especially search-and-rescue personnel who may have become injured in a
debris field. In such cases, if another searcher sends out a unique command (CTCSS tone pair), the radio
of the incapacitated party, who may not be able to speak or even press the PTT switch, will automatically
cause the injured party’s radio to transmit, so others may perform direction-finding and effect a rescue. The
callsign of the incapacitated person will also be transmitted, to assist the rescue team.
If an emergency group is working in a dangerous area, all members should engage the EAI feature on their
transceiver, so that others can provide assistance to a fallen team member, if necessary.
The Emergency Automatic ID (EAI) Feature has two operating modes: (1) Interval mode and (2)
Continuous mode.
In the Interval mode, when the VX-3R receives the CTCSS tone pair which is stored in the Receiving Pager
Code Memory (configured via Set Mode Item 61: PAG.CDR) on the frequency which is stored in Memory
Channel “EAI” for more than five seconds, the radio will automatically transmit a brief (0.5 second) beep
tone every 2.5 seconds until the EAI timer expiration at the power level stored in that memory channel; it is
NOT necessary for the incapacitated person to press the PTT switch.
In the Continuous mode, when the VX-3R receives the CTCSS tone pair which is stored in the Receiving
Pager Code Memory (configured via Set Mode Item 61: PAG.CDR) on the frequency which is stored in
Memory Channel “EAI” for more than five seconds, the radio will automatically transmit (with maximum
microphone gain) continuously, until the EAI timer expiration, at the power level stored in that memory
channel; it is NOT necessary for the incapacitated person to press the PTT switch.
Furthermore, if your call sign is stored in the radio and enabling the CW identifier via Set Mode Item 19: CW
ID, the radio will transmit your callsign on the air when the EAI feature is first engaged by the remote page,
and every 10 minutes thereafter. The “callsign” ID can be changed to any desired sequence of characters,
such as a name. After sending the callsign or name, the radio will repeatedly transmit three tones for a
user-defined period of time (between 1 and 30 minutes). The callsign or name will be transmitted every 10
minutes.
Vertex Standard Co., Ltd.
49
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
The Emergency Automatic ID (EAI) Feature requires that you (1) store the CTCSS Tone Pair into the
Receiving Pager Memory (see page ?? for procedure), and (2) store the desired UHF coordination
frequency into Memory Channel “EAI” (see page ?? for procedure).
Selecting the EAI mode and its Transmit Time
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 31: EAI.TMR.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired EAI mode (Interval EAI “INT” or Continuous EAI “CON”) and
its transmit time (1-10, 15, 20, 30, 40, and 50 minutes).
5. Press the PTT switch to save the new setting and exit to normal operation.
Activating the EAI feature
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 30: EAI.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “ON” (thus activating the EAI feature).
5. Press the PTT switch to save the new setting and exit to normal operation (with EAI feature “ON”).
When the EAI feature is activated, the “EAI” notation and the Band Number (or memory channel
number) will appear alternately in the Memory Channel Number Display Slot of the display.
To disable the EAI feature, just repeat above procedure, rotating the DIAL knob to select “OFF” in step “4”
above.
R.F. Says: The VX-3R will ignore the EAI feature when the (1) the squelch is open, (2) there is an incoming
the signal on the operating frequency, (3) the operating frequency is the same as the frequency which is
stored in the Memory Channel “EAI,” or (4) a VHF frequency is stored in Memory Channel “EAI.”
To Locate an Unresponsive Operator Using the EAI feature
1. Recall the Memory Channel “EAI” (of the searched person’s radio), which is found to next to the last
“regular” memory channel.
2. Set the CTCSS tone pair which is the same CTCSS tone pair stored in the Receiving Pager Code
Memory of the missing person’s radio.
A. Press and hold in the [TXPO] key for one second to enter the Set mode.
B. Rotate the DIAL knob to select Set Mode Item 62: PAG.CDT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob
Vertex Standard Co., Ltd.
50
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
C. Press the [TXPO] key to enable adjustment of this Set Mode Item.
D. Rotate the DIAL knob to select the first tone.
E. Press the [V/M] key.
F. Rotate the DIAL knob to select the second tone.
G. Press the PTT switch to save the new setting and exit from setting mode.
3. Press and hold in the PTT switch for five seconds to find out the persons who are activating the EAI
feature. The lost operator’s radio will beep loudly, and its transmitter will respond repetitively. You may
now begin direction-finding efforts.
4. You may select the ATT (Front End Attenuator) level among “ATT 1 (10 dB),” “ATT 2 (50 dB),” and “ATT
OFF” by pressing the [BAND] key to reduce the signal. The ATT is often useful in helping you locate the
missing person’s radio, as peaks in weaker signals are more easily observed.
5. Press the [V/M] key to exit to normal operation.
ARTS™ (Automatic Range Transponder System)
The ARTS™ feature uses DCS signaling to inform both parties when you and another ARTS™-equipped
station are within communications range. This may be particularly useful during Search-and Rescue
situations, where is important to stay in contact with other members of your group.
Both stations must set up their DCS codes to the same code number, then activate their ARTS™ feature
using the command appropriate for their radio. Alert ringers may be activated, if desired.
Whenever you push the PTT, or every 25 (or 15) seconds after ARTS™ is activated, your radio will transmit
a signal which includes a (subaudible) DCS signal for about 1 second. If the other radio is in range, the
beeper will sound (if enabled) and the display will show “IN RNG” as opposed to the out of range display
“OUT RNG” in which ARTS™ operation begins.
Whether you talk or not, the polling every 15 or 25 seconds will continue until you de-activate ARTS™.
Every 10 minutes, moreover, you can have your radio transmit your callsign via CW, so as to comply with
identification requirements. When ARTS™ is de-activated, DCS will also be deactivated (if you were not
using it previously in non-ARTS™ operation).
If you move out of range for more than one minute (four pollings), your radio will sense that no signal has
been received, three beeps will sound, and the display will revert to “OUT RNG.” If you move back into
range, your radio will again beep, and the display will change back to the “IN RNG” indication.
During ARTS™ operation, your operating frequency will continue to be displayed, but no changes may be
made to it or other settings; you must terminate ARTS™ in order to resume normal operation. This is a
safety feature designed to prevent accidental loss of contact due to channel change, etc.
Basic ARTS™ Setup and Operation
1. Set your radio and the other radio(s) to the same DCS code number, per the discussion on page ??.
Vertex Standard Co., Ltd.
51
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
2. Press and hold in the [%] key for one second. You will observe the “OUT RNG” display on the LCD
below the operating frequency. ARTS™ operation has now commenced.
3. Every 25 seconds, your radio will transmit a “polling” call to the other station. When that station
responds with its own ARTS™ polling signal, the display will change to “IN RNG” to confirm that the
other station’s polling code was received in response to yours.
4. Press and hold in the [%] key for one second to exit ARTS™ operation and resume normal functioning
of the transceiver.
ARTS™ Polling Time Options
The ARTS™ feature may be programmed to poll every 25 seconds (default value) or 15 seconds. The
default value provides maximum battery conservation, because the polling signal is sent out less frequently.
To change the polling interval:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 7: ARTSIT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired polling interval (15 or 25 seconds).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
ARTS™ Alert Beep Options
The ARTS™ feature allows two kinds of alert beeps (with the additional option of turning them off), so as to
alert you to the current status of ARTS™ operation. Depending on your location and the potential
annoyance associated with frequent beeps, you may choose the Beep mode which best suits your needs.
The choices are:
IN RANG: The beeps are issued only when the radio first confirms that you are within range, but does not
re-confirm with beeps thereafter.
ALWAYS: Every time a polling transmission is received from the other station, the alert beeps will be heard.
OFF: No alert beeps will be heard; you must look at the display to confirm current ARTS™ status.
To set the ARTS™ Beep mode, use the following procedure:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 6: ARTSBP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired ARTS™ Beep mode (see above).
Vertex Standard Co., Ltd.
52
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
CW Identifier Setup
The ARTS™ feature includes a CW identifier, as discussed previously. Every ten minutes during ARTS™
operation, the radio can be instructed to send “DE (your callsign) K” if this feature is enabled. The callsign
field may contain up to 16 characters.
Here’s how to program the CW Identifier:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 19: CW ID.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Item to “ON” (to enable the CW ID function).
5. Press the [V/M] key momentarily to display any previously-stored callsign.
6. Press and hold the [HM/RV] key for 2 seconds to clear any previous callsign.
7. Rotate the DIAL knob to select the first letter/number of your callsign, then press the [V/M] key
momentarily to save the first letter/number and move on to the next character.
8. Repeat the previous step, as many times as necessary, to complete your callsign. Note that the “slant
bar” (– • • – •) is among the available characters, should you be a “portable” station.
9. If you mistake, press the [BAND] key to back-space the cursor, then re-enter the correct letter/number.
10. Press and hold the [HM/RV] key for 2 seconds to delete all data after the cursor that may have been
previously stored erroneously.
11. When you have entered your entire callsign, press the [TXPO] key momentarily to confirm the callsign,
then press the PTT switch to save the settings and exit to normal operation.
R.F. Says: 1) You may check your work by monitoring the entered callsign. To do this, repeat steps 1- 3
above, then press the [F/W] key.
2) You may adjust the monitoring tone (CW sidetone pitch) via Set Mode Item 18: CW PIT. Available
selections are 400 - 1000 Hz (50 Hz/step).
Internet Connection feature
The VX-3R can be used to access a “node” (repeater or base station) which is tied into the Vertex Standard
WIRES™ (Wide-Coverage Internet Repeater Enhancement System) network, operating in the “SRG”
(Sister Radio Group) mode. Details may be found at the WIRES-II Web site:
http://www.vxstd.com/en/wiresinfo-en/. This feature may also be used to access other systems, as
described below.
Vertex Standard Co., Ltd.
53
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
SRG (“Sister Radio Group”) mode
1. Press the [%] key to activate the Internet Connection feature. The “%” icon will appear in the upper
right corner of the display.
2. Rotate the DIAL knob, while pressing and holding in the [%] key, to select the access number (“DTMF
1” - “DTMF 1”, “DTMF A”, “DTMF B”, “DTMF C”, “DTMF D”, “DTMF E(*)”, “DTMF F(#)”) corresponding
to the WIRES™ repeater to which you wish to establish an Internet link (ask your repeater
owner/operator if you don’t know the access numbers in the network). Now press the PTT switch to
exit from the selection mode.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. With the Internet Connection feature activated (as in step 1 above), the VX-3R will generate a brief (0.1
second) DTMF tone according to your selection in step 2. This DTMF tone is sent at the beginning of
every transmission to establish or maintain the link to the remote WIRES™ repeater operating in the
SRG mode.
4. To disable the Internet Connection feature, press the [%] key again (The “Internet” icon disappear from
the display.
R.F. Says: If other users report that you always have a DTMF “beep” at the beginning of each transmission,
and you are not operating in conjunction with Internet access, disable this function via step 4 above.
FRG (“Friendly Radio Group”) mode
You may access other Internet Link Systems (including WIRES™ in the FRG mode) that use a DTMF string
for access.
Programming the FRG code
Load the DTMF tones which you wish to use for Internet-link access into an Internet Memory Resister. For
purposes of this example, we will use “#(F)1101D” as the access code (the “#” key is denoted by the letter
“F”).
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 41: INT.SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the DTMF Memory register (“F 0” - “F63”) into which you wish to store
the access code.
5. Press the [V/M] key momentarily. The first digit will blink.
6. Rotate the DIAL knob to select “F” (representing DTMF “#”: the first digit of the DTMF string).
7. Press the [V/M] key momentarily to accept the first digit and move to the second digit of the DTMF
string.
8. If you make a mistake, press the [BAND] key to back-space the cursor, then re-enter the correct letter
Vertex Standard Co., Ltd.
54
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
or number.
9. Repeat steps 6 through 8 until you have completed the access code (“F(#)1101D”).
10. If you wish to attach an alpha/numeric name “Tag” to the Internet Memory, proceed to the next step;
otherwise press the PTT switch to save the settings and exit to normal operation.
11. Press the [V/M] key twice. The DTMF Memory register number blinks.
12. Press the [MODE] key momentarily (the “-ALPHA-” notation appear in the display for 2 seconds), then
press the [V/M] key momentarily to enable programming of the name tag.
13. Rotate the DIAL knob to select the first digit of the desired label.
14. Press the [V/M] key to move to the next character.
15. If you make a mistake, press the [BAND] key to back-space the cursor, then re-enter the correct letter,
number, or symbol.
16. Repeat steps 13 through 15 to program the remaining letters, numbers, or symbols of the desired label.
A total of six characters may be used in the creation of a label.
17. When you have programmed a label which is under 6 characters, press the [TXPO] key to confirm the
label.
18. Repeat steps 3 through 17 to store other access codes, if so desired.
19. Press the PTT switch to save the settings and exit to normal operation.
Operation (Accessing an FRG Node)
1. Press and hold in the [TXPO] key for one second to enter the Set mode again.
2. Rotate the DIAL knob to select Set Mode Item 39: INT MD.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “FRG” (thus activating the “Other Internet Link
System” mode).
5. Press the PTT switch to save the new settings.
6. Press the [%] key momentarily to activate the Internet Connection feature. The “%” icon will appear in
the upper right corner of the display.
7. Rotate the DIAL knob while pressing the [%] key to select the Internet Memory register number (“F 0” -
“F63”) corresponding to the Internet link repeater to which you wish to establish an Internet link, then
press the PTT switch momentarily to lock in the selected access number.
8. Once the Internet Connection feature is activated per step 7 above, you may now press the [%] key,
while you are transmitting, to send out the selected DTMF string (to establish the link to the desired
Internet-link mode).
9. To return to the WIRESTM SRG mode, repeat steps 1 - 5 above, selecting “SRG” in step 4.
Vertex Standard Co., Ltd.
55
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
DTMF Operation
Despite the lack of a DTMF keypad, you can still transmit DTMF tones with the VX-3R for repeater control
or autopatch use.
Manual DTMF Tone Generation
1. Press and hold the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 26: DT A/M.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select “MANUAL.”
5. Press the PTT switch to return to normal display.
6. Hold the PTT switch in to continue transmitting during the following steps.
A. Press the [TXPO] key momentarily.
B. Rotate the DIAL knob to select the number to be sent, then press the [TXPO] key momentarily to
send the number.
C. Repeat step B as many times as needed until you have completed the number string.
D. Release the PTT switch.
R.F Says: The DTMF “*” code is displayed as “E,” and the DTMF code “#” is displayed as “F” on the display.
DTMF Autodialer
Nine DTMF Autodial memories are provided, allowing you to store telephone numbers for autopatch use.
You can also store short autopatch or Internet-link access code streams so as to avoid having to send them
manually.
Here is the DTMF Autodial storage procedure:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 28: DT SEL.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the DTMF Memory register (“CH0” - “CH9”) into which you wish to store
this DTMF string.
5. Press the [V/M] key to begin DTMF Memory entry into the selected register. The first digit location will
blink.
6. Press and hold the [HM/RV] key for 2 seconds to clear any previous stored telephone number.
7. Rotate the DIAL knob to select the first digit of the DTMF string. Selectable entries are 1 - 9, and A - F,
with E and F representing DTMF “*” and “#” tones respectively.
Vertex Standard Co., Ltd.
56
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
8. Press the [V/M] key momentarily to accept the first digit and move on to the second digit of the DTMF
string.
9. Repeat the previous steps until you have completed the telephone number string.
10. If you make a mistake, press the [BAND] key to back-space the cursor, then re-enter the correct digit.
11. Press the [TXPO] key momentarily to store the string into the DTMF memory.
12. To store another number, press the [TXPO] key again, then rotate the DIAL knob to select another
DTMF Memory register, and repeat this procedure.
Press the [F/W] key to check (monitoring) the entered telephone number.
13. When finished storing DTMF Memories, press the PTT switch to return to normal display.
To send the telephone number:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 26: DT A/M.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Item to “AUTO.”
5. Press the PTT switch to return to normal display.
6. Hold the PTT switch to continue transmitting during following steps.
A. Press the [TXPO] key momentarily.
B. Rotate the DIAL knob to select the DTMF Memory register (CH 0 through CH 9) you wish to send.
C. Press the [TXPO] key momentarily to transmit the tone string. Once the string begins, you may
release the PTT switch, as the transmitter will be held “on the air” until the DTMF string is
completed.
The speed at which the DTMF digits are sent can be changed. Two speed levels are available: Low (10
digits per second) and High (20 digits per second: default). To toggle between Low and High speed, use the
following procedure:
1. Press and hold the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 29: DT SPD.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired speed (“50MS”: High speed or “100 MS”: Low speed).
5. Press the PTT switch to save the new setting and exit to normal operation.
You can also set a longer delay between the time your transmitter is keyed and the first DTMF digit is sent.
To set the delay time, use the following procedure:
Vertex Standard Co., Ltd.
57
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
1. Press and hold the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 27: DT DLY.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired speed (50/250/450/750/1000 ms).
5. Press the PTT switch to save the new setting and exit to normal operation.
CW Learning Feature
The VX-3R provides a CW learning function, which sends the designated Morse Code via the sidetone
(heard in the speaker) to help your CW learning.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 20: CWLRNG.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Press the [MODE] key to select the Training mode (displayed in fine print at the upper edge of the
LCD):
A: Sends the Alphabet characters
A_r: Sends the Alphabet characters (move to next character automatically)
n: Sends the Numeric characters
n_r: Sends the Numeric characters (move to next character automatically)
S: Sends the Symbol characters
S_r: Sends the Symbol characters (move to next character automatically)
5. Rotate the DIAL knob to select the Morse speed. You may select the units of the code speed between
“CPM: characters per minute)” and “WPM (Words per minute)” by pressing the [V/M] key.
6. Press the [BAND] key to switch the flashing of the LED (white) on and off; a “dot” by the CW speed
indicates that the LED is on.
7. Press the [HM/RV] key, then rotate the DIAL knob to select the CW code which you want to learn and
press the [V/M] key select the repetition time (1 - 9) of the sending.
8. Press the [F/W] key to begin generation of the selected code characters (CW sidetone only, the radio
does not transmit) with selected times.
9. If one of the “r” modes is selected in step 4 above, you may change the direction of the character
change by rotating the DIAL knob.
10. You may adjust the CW sidetone outputs level by rotating the DIAL knob while press and holding the
[VOL] key.
11. If one of the “r” modes is not selected in step 4 above, press the [F/W] key to send again, or select
another code by rotating the DIAL knob and press the [F/W] key to begin generation.
Vertex Standard Co., Ltd.
58
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
If one of the “r” modes is selected in step 4 above, press the [F/W] key to stop the CW generation.
12. To stop the CW generation, press the [F/W] key again.
13. To disable the CW learning feature, press the PTT switch.
R.F. Says: 1) The “CPM” selection is based on the international “PARIS” standard, which stipulates five
characters per word.
2) You may adjust the CW sidetone pitch via Set Mode Item 21: CWPTCH. Available selections are 400 -
1000 Hz (50 Hz/step).
CW Training Feature
The VX-3R provides another CW learning function; call it a CW Training feature, which sends random
Morse Code via the sidetone (heard in the speaker), so you can improve your CW proficiency.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 22: CWTRNG.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Press the [MODE] key to select the Training mode (displayed in fine print at the upper edge of the
LCD):
A: Sends five Alphabet characters only
A_r: Sends Alphabet characters only (Repeatedly)
n: Sends five Numeric characters only
n_r: Sends Numeric characters only (Repeatedly)
An: Sends five Alphabet, Numeric, “?,” and “/” characters (Mixed)
Anr: Sends Alphabet, Numeric, “?,” and “/” characters (Mixed, Continuously in groups of five)
5. Rotate the DIAL knob to select the Morse speed. You may select the units of the code speed between
“CPM: characters per minute)” and “WPM (Words per minute)” by pressing the [V/M] key.
6. Press the [BAND] key to switch the flashing of the LED (white) on and off; a “dot” by the CW speed
indicates that the LED is on.
7. Press the [F/W] key to begin generation of the code characters (CW sidetone only, the radio does not
transmit); the transmitted characters will appear on the display. If one of the “r” modes is not selected in
step 4 above, press the [F/W] key to send another code group.
If one of the “r” modes is selected in step 4 above, press the [F/W] key to stop the CW generation.
8. Rotate the DIAL knob while press and holding the [VOL] key to adjust the CW sidetone outputs level.
9. Press the PTT switch to disable the CW Training feature and exit to normal operation.
R.F. Says: 1) The “CPM” selection is based on the international “PARIS” standard, which stipulates five
characters per word.
2) You may adjust the CW sidetone pitch via Set Mode Item 21: CWPTCH. Available selections are 400 -
1000 Hz (50 Hz/step).
Vertex Standard Co., Ltd.
59
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Miscellaneous Setting
Password
The VX-3R provides a password feature which can minimize the chance that your transceiver could be
used by an unauthorized party.
When the password feature is activated, the radio will ask for the four digit password to be entered when
the radio is first turned on. You must enter the four digit password using the DIAL knob and [V/M] key
(pressing the [V/M] key to select the password digit and rotating the DIAL knob to select the password in
each digit). If the wrong password is entered, the microprocessor will shut down the radio automatically.
To enter the password and activating this feature, use the following procedure:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 66: PSWD.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Press the [V/M] key momentarily to display any previously-stored password.
5. Rotate the DIAL knob to select the first digit of the desired number/letter (0-9, A, B, C, D, E (substitute
for “*,” and F (substitute for “#”).
6. Press the [V/M] key to move to the next digit.
7. Repeat steps 5 and 6 to program the remaining numbers/letters of the desired password.
8. If you make a mistake, press the [BAND] key to move back to the previous digit, then re-select the
correct number/letter.
9. When you have finished entering the password, press the [V/M] key then rotating the DIAL knob to
select “ON” (to activate the password feature).
10. Press the PTT switch to save the new setting and exit to normal operation.
If you wish to disable the Password feature, repeat steps 1 - 3 above, then rotating the DIAL knob to select
“OFF”, then press the PTT switch.
R.F. Says: 1) We recommend that you to write down the password number, and keep it in a safe place you
can easily find if you forget your password.
2) If you forget the password number, you may turn on the transceiver by performing the “All Reset”
procedure (see page ??). However, the VX-3R will clear the password, as well as all memories, and will
restore all other settings to factory defaults.
Programming the “%” Key
In the factory default, the “primary” (press key) function of the [%] key is assigned to the internet key.
However, you may change the “primary” (press key) function of the [%] key to another function via the Set
Mode.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
Vertex Standard Co., Ltd.
60
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
2. Rotate the DIAL knob to select Set Mode Item 42: INTKEY.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired function:
INTNET: Activates/Disable the internet feature.
INT MR: Recall the Internet Access Number (SRG) or Access Cord (FRG). Determine the selection
of the SRG or FRG via Set Mode Item 41: INT MD.
SET MD: Short-cut path for recall of one of Set Mode Items. See below box for programming.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
6. If you wish to disable the attenuator, just repeat the above procedure, rotating the DIAL knob to select
“OFF” in step “4” above.
R.F. Say: When assign the [%] key besides INTNET function, you may activate/disable the Internet
Connection feature via Set Mode Item 43: INTNET.
Assign the Set Mode Item to the [%] key.
1. Sets the Set Mode Item 42: INTKEY to “SET MD”, descried above.
2. Press and hold in the [TXPO] key for one second to enter the Set mode again.
3. Rotate the DIAL knob to select the Set Mode Item which you wish to assign to the [%] key as a Menu
short-cut.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press and hold in the [%] key for one second to assign the Set Mode Item to the [%] key. “MY KEY” will
appear on the display, to confirm that the command was executed.
5. Press the PTT switch to save the new setting and exit to normal operation.
Now, momentary press of the [%] key will immediately recall the selected Set Mode Item. You must press
the [%] key again to exit to normal operation.
ATT (Front End Attenuator)
The attenuator will reduce all signals (and noise) by 20 dB, and it may be used to make reception more
pleasant under extremely crowded conditions.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 3: ANT.ATT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to change the setting from “OFF” to “ON”.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
Vertex Standard Co., Ltd.
61
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
operation.
6. If you wish to disable the attenuator, just repeat the above procedure, rotating the DIAL knob to select
“OFF” in step “4” above.
R.F. Says: When the attenuator is activated, the Operating Mode icon (AM or FM) will blink on the display.
Receive Battery Saver Setup
An important feature of the VX-3R is its Receive Battery Saver, which “puts the radio to sleep” for a time
interval, periodically “waking it up” to check for activity. If somebody is talking on the channel, the VX-3R will
remain in the “active” mode, then resume its “sleep” cycles. This feature significantly reduces quiescent
battery drain, and you may change the amount of “sleep” time between activity checks using the Set Mode:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 72: SAVERX.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired “sleep” duration. The selections available are 200 - 1000 ms
(100 ms/step), 1 - 10 seconds (1 sec/step), or OFF. The default value is 200 ms.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: When you are operating on Packet, switch the Receive Battery Saver OFF, as the sleep cycle
may “collide” with the beginning of an incoming Packet transmission, causing your TNC not to receive the
full data burst.
Wakeup Feature
The Wakeup feature is similarly to the Receive Battery Saver. However, it is a newer, more advanced
feature which conserves battery life by providing a longer “sleep” time than the regular Receive battery
Saver. The Wakeup feature, once engaged, operates while the transceiver is turned off (“WAKEUP” will
appear on the LCD).
To set up the Wakeup feature:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 92: WAKEUP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired “sleep” duration.
5 - 60SEC (5 second/step): Based on the selected time value, the radio will periodically check the
operating frequency which it was on when the radio was turned off for activity. If a signal is received on
the frequency which is strong enough to open the Squelch, the radio will turn itself on fully. If the EAI
Vertex Standard Co., Ltd.
62
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
feature is activated when the radio was turned off, the radio also checks on the EAI frequency (Memory
Channel “EAI”) for activity.
EAI: Checks the EAI frequency (Memory Channel “EAI”) every 5 seconds. If a properly-coded signal is
received on the EAI frequency, the radio will turn itself on and then automatically transmit in
accordance with the setting of Set Mode Item 29: EAI.
OFF: Disables the Wakeup feature.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
If you wish to disable the Wakeup feature, just repeat the above procedure, rotating the DIAL knob to select
“OFF” in step 4 above.
When the radio is turned off, the Wakeup feature will be engaged, and the “WAKEUP” notation will be seen
on the display.
You may cancel the Wakeup feature (complete power off) temporarily by pressing the [POWER] switch
while the Wakeup feature is engaged.
TX Battery Saver
The VX-3R also includes a useful Transmit Battery Saver, which will automatically lower the power output
level when the last signal received was very strong. For example, when you are in the immediate vicinity of
a repeater station, there generally is no reason to use the High Power output in order to achieve
full-quieting access to the repeater. With the Transmit Battery Saver, the automatic selection of Low Power
operation conserves battery drain significantly.
To activate the Transmit Battery Saver:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 73: SAVETX.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “ON” (thus activating the Transmit Battery Saver).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
Disabling the BUSY Indicator
Further battery conservation may be accomplished by disabling the BUSY indicator while receiving a signal.
Use the following procedure:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 16: BSY.LED.
Vertex Standard Co., Ltd.
63
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “OFF” (thus disabling the BUSY lamp).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
Automatic Power-Off (APO) Feature
The APO feature helps conserve battery life by automatically turning the radio off after a user-defined
period of time within which there has been no dial or key activity. The available selections for the time
before power-off are 0.5 - 12 hours (0.5 hour/step), as well as APO Off. The default condition for the APO is
OFF, and here is the procedure for activating it:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 4: APO.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired time period after which the radio will automatically shut
down.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
When the APO is activated, the “TIMER” icon will appear at the center bottom on the LCD. If there is no
action by you within the time interval programmed, a ringer sounds 3 minutes before the APO shutdown
time. Three minutes thereafter, the microprocessor will shut down the radio automatically.
Just press and hold in the POWER switch for one second to turn the transceiver back on after an APO
shutdown, as usual.
Transmitter Time-Out Timer (TOT)
The TOT feature provides a safety switch which limits transmission time to a pre-programmed value. This
will promote battery conservation by not allowing you to make excessively-long transmissions, and in the
event of a stuck PTT switch (perhaps if the radio or a Speaker/Mic is wedged between car seats) it can
prevent interference to other users as well as battery depletion. As configured at the factory the TOT
feature is set to OFF, and here is the procedure for activating it:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 87: TOT.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set the Time-Out Timer to the desired “Maximum TX” time. The available
Vertex Standard Co., Ltd.
64
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
selections are 1 - 30 minutes (0.5 minute/step).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: 1) When your transmission time is within 10 seconds of the Time-Out Timer expiration, an Alert
bell will provide an audible warning from the speaker.
2) Since brief transmissions are the mark of a good operator, try setting up your radio’s TOT feature for a
maximum transmission time of one minute. This will significantly improve battery life, too!
Automatic Power-On Feature
The VX-3R also includes the capability to turn itself on after a programmed time interval.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 58: ON TMR.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set the desired time period after which the radio will automatically turn on.
Note that this is not the time of day when the radio will turn on; it is the number of hours and minutes
until the radio turns on. The available selections are 10 minutes - 24 hours (10 minute/step).
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
When the radio is turned off, this activates the Automatic Power-On feature; a count-down timer in the
display will show the time remaining until automatic switch-on.
You may cancel the Automatic Power-On feature (to turn off the radio) by pressing and holding the POWER
switch for one second while the Automatic Power-On feature is engaged.
R.F. Says: The Automatic Power-On feature will be ignored if the Wakeup feature is activated.
Busy Channel Lock-Out (BCLO)
The BCLO feature prevents the radio’s transmitter from being activated if a signal strong enough to break
through the “noise” squelch is present. On a frequency where stations using different CTCSS or DCS codes
may be active, BCLO prevents you from disrupting their communications accidentally (because your radio
may be muted by its own Tone Decoder). The default setting for the BCLO is OFF, and here is how to
change that setting:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 8: BCLO.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “ON” (thus activating the BCLO feature).
Vertex Standard Co., Ltd.
65
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
Changing the TX Deviation Level
In many areas of the world, channel congestion has required that operating channels be closely spaced. In
such operating environments, it often is required that operators use reduced deviation levels, so as to
reduce the potential for interference to users on adjacent channels. The VX-3R includes a simple method of
accomplishing this:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select the Set Mode Item 35: HLF.DEV.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to set this Set Mode Item to “ON.” In this configuration (HALF DEVIATION
active), the transmitter’s deviation will be approximately ±2.5 kHz.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
R.F. Says: The “normal” setting for the deviation (when this Menu Item is set to “OFF”) is ±5 kHz.
Changing the Microphone Gain
At the factory, a microphone gain has been programmed that should be satisfactory for the internal
microphone. If you use an after-market microphone, you may wish to set a different microphone gain level.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select Set Mode Item 48: MCGAIN.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of this Set Mode Item.
4. Rotate the DIAL knob to select the desired microphone gain.
5. When you have made your selection, press the PTT switch to save the new setting and exit to normal
operation.
My Bands Operation
The “My Bands” feature allows you to select several operating bands, and make only those bands available
for selection via the [BAND] buttons.
For example, if you do not need the reception of the SW and Air bands, you may skip (omit) these bands
from the band selection loop.
My Bands Setup
Vertex Standard Co., Ltd.
66
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
1. Set the VX-3R to the VFO mode.
2. Press and hold in the [TXPO] key for one second to enter the Set mode.
3. Rotate the DIAL knob to select Set Mode Item 91: VFO.SKP.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
4. Press the [TXPO] key momentarily to enable adjustment of this Item.
5. Rotate the DIAL knob to choose a band number (see chart below) you wish to skip (omit) form the
band selection loop.
6. Press the [V/M] key, then rotate the DIAL knob to select “OFF” (to skip (omit) from the band selection
loop).
Note: The band presently in use cannot select “OFF”.
7. Press the [V/M] key again.
8. Repeat steps 4 through 6 above to select as many bands as you like.
9. When you have made your selection, press the PTT switch to save the new setting and return to
normal operation.
To re-institute a band into the band selection loop, repeat the above procedure, rotating the DIAL knob to
select “ON” in step 5.
R.F. Say: If you wish to skip (omit) the AM or FM Broadband, enter the Broadcast Reception mode by
pressing the [RADIO] key momentarily at first, then perform the above procedure.
Band Number Chart
BAND NUMBER BAND FREQUENCY RANGE
1 SW Band 1.8 - 30 MHz
2 50 MHz Ham Band 30 - 59 MHz
3 Air Band 108 - 137 MHz
4 144 MHz Ham Band 137 - 174 MHz
5 VHF-TV Band 174 - 222 MHz
6 Information Band 1 222 - 420 MHz
7 430 MHz Ham Band 420 - 470 MHz
8 UHF-TV Band 470 - 800 MHz
9 Information Band 2 803 - 999 MHz
A AM Broadcast Band 510 – 1790 kHz
F FM Broadcast Band 76 - 107.9 MHz
Reset Procedures
In some instances of erratic or unpredictable operation, the cause may be corruption of data in the
Vertex Standard Co., Ltd.
67
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
microprocessor (due to static electricity, etc.). If this happens, resetting of the microprocessor may restore
normal operation. Note that all memories will be erased if you do a complete microprocessor reset, as
described below.
Microprocessor Resetting
To clear all memories and other settings to factory defaults:
1. Turn the radio off.
2. Press and hold in the [BAND], [H/L] and [V/M] keys while turning the radio on.
3. Press the [F/W] key momentarily to reset all settings to their factory defaults (press any other key to
cancel the Reset procedure).
Set Mode Resetting
To reset the Set Mode Item settings to their factory defaults:
1. Turn the radio off.
2. Press and hold in the [BAND] and [V/M] keys while turning the radio on.
3. Press the [F/W] key momentarily to reset the Set (Menu) mode settings to their factory defaults (press
any other key to cancel the Reset procedure).
Cloning
The VX-3R includes a convenient “Clone” feature, which allows the memory and configuration data from
one transceiver to be transferred to another VX-3R. This can be particularly useful when configuring a
number of transceivers for a public service operation. Here is the procedure for Cloning one radio’s data to
another:
1. Turn both radios off.
2. Connect the optional CT-27 Clone Cable between the MIC/SP jacks of the two radios.
3. Press and hold in the [F/W] key while turning the radios on. Do this for both radios (the order of
switch-on does not matter). “CLONE” will appear on the displays of both radios when the Clone mode
is successfully activated in this step.
4. On the Destination radio, press the [V/M] key (“-WAIT-” will appear on the LCD).
5. Press the [BAND] key on the Source radio; “--TX--” will appear on the Source radio, and the data from
this radio will be transferred to the other radio.
6. If there is a problem during the cloning process, “ERROR” will be displayed. Check your cable
connections and battery voltage, and try again.
7. If the data transfer is successful, “CLONE” will reappear on both displays. Turns both radios off and
disconnects the cloning cable. You can then turn the radios back on, and begin normal operation.
Vertex Standard Co., Ltd.
68
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Set (Menu) Mode
The VX-3R Set Mode, already described in parts of many previous chapters, is easy to activate and set. It
may be used for configuration of a wide variety of transceiver parameters, some of which have not been
detailed previously. Use the following procedure to activate the Set Mode:
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select the Set Mode Item to be adjusted.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of the Set Mode Item.
4. Rotate the DIAL knob to adjust or select the parameter to be changed on the Set Mode Item selected in
above step.
5. After completing your selection and adjustment, press the PTT switch momentarily to save the new
setting and exit to normal operation.
R.F. Says: Some Set Mode Items (like Set Mode Item 86: TN FRQ) require that the [TXPO] key be pressed
after setting of the parameter, and before exiting to normal operation.
Masking the Set Mode Items
There may be situations where you want to “Mask” Set Mode Items so they are not recall during Set Mode
Item selection.
1. Press and hold in the [TXPO] key for one second to enter the Set mode.
2. Rotate the DIAL knob to select the Set Mode Item 33: EXT.MNU.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob.
3. Press the [TXPO] key momentarily to enable adjustment of the Set Mode Item.
4. Rotate the DIAL knob to select “ON”, then press the [TXPO] key momentarily.
5. Rotate the DIAL knob to select the Set Mode Item to be “Masked”.
6. Press the [F/W] key momentarily. A small “” icon will appear at the above of the volume level indicator
on the display; indicating it is to be Masked Set Mode Item.
7. Rotate the DIAL knob; the previously-selected Set Mode Item will be “Masked”.
8. Repeat steps 5 - 7 above, to append the “” icon to any other Set Mode Item you wish to “Masked”.
9. Press the PTT switch momentarily to save the new setting and exit to normal operation.
To unmask the hidden Set Mode Item, repeat above procedure: select “OFF” in step 4 above and disappear
the “” icon in step 6 above from the Set Mode Item you wish to unmasked.
Set Mode Summary
Note: A Set Mode Item with a * mark can set/select a selection to the memory channel individually.
Set Mode Item 1 [ANT AM]
Function: Select the antenna to be used in the AM Broadcast listening.
Vertex Standard Co., Ltd.
69
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Available Values: BAREXT/BARANT
Default: BAREXT
BAREXT: Uses both the internal Bar Antenna and the Rubber Flex Antenna.
BARANT: Uses the internal Bar Antenna only.
The Bar Antenna is directional; rotate the VX-3R for best reception.
Set Mode Item 2 [ANT FM]
Function: Select the antenna to be used in the FM Broadcast listening.
Available Values: EXTANT/EARPHO
Default: EXTANT
EXTANT: Uses the Rubber Flex Antenna.
EARPHO: Uses the Earphone Antenna. When receiving a weak signal, reception may be noisy.
Set Mode Item 3 [ANT.ATT]*
Function: Enables/Disables the receiver Front-end Attenuator.
Available Values: ON/OFF
Default: OFF
Set Mode Item 4 [APO]
Function: Setting of the Automatic Power-Off feature.
Available Values: OFF/0.5H - 12.0H (0.5H/steps)
Default: OFF
Set Mode Item 5 [ARS]
Function: Enables/Disables the Automatic Repeater Shift function.
Available Values: ON/OFF
Default: ON
Set Mode Item 6 [ARTSBP]
Function: Selects the Beep option during ARTS operation.
Available Values: OFF/IN RNG/ALWAYS
Default: IN RNG
OFF: No alert beeps sound.
IN RNG: Beeps sound only when the radio first detects that you are within range.
ALWAYS: Beeps sound every time a polling transmission is received from the other station (every
15 or 25 seconds when in range).
Set Mode Item 7 [ARTSIT]
Function: Selects the Polling Interval during ARTS operation.
Available Values: 15SEC/25SEC
Default: 25SEC
Set Mode Item 8 [BCLO]
Vertex Standard Co., Ltd.
70
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Function: Enables/Disables the Busy Channel Lock-Out feature.
Available Values: ON/OFF
Default: OFF
Set Mode Item 9 [BEL.RNG]
Function: Selects the number of Bell ringer repetitions.
Available Values: 1T - 20T/CONT (Continuous ringing)
Default: 1T
Set Mode Item 10 [BEL.SEL]*
Function: Enables/Disables the Bell ringer function and its sound selection.
Available Values: OFF/BELL/USRBP1/ USRBP2/ USRBP3
Default: OFF
Set Mode Item 11 [BNK.NAM]
Function: Stores Alpha-Numeric “Tags” for the Memory Banks.
See page ?? for details.
Set Mode Item 12 [BP EDG]
Function: Enables/Disables the Band-edge beeper while selecting the frequency by the DIAL
knob.
Available Values: ON/OFF
Default: OFF
Set Mode Item 13 [BP LVL]
Function: Adjust the Beep volume level.
Available Values: LVL 1 - LVL 9
Default: LVL 5
Set Mode Item 14 [BP SEL]
Function: Enables/Disables the Keypad beeper.
Available Values: OFF/KY+SCN/KEY
Default: KY+SCN
OFF: The Beeper is disabled.
KY+SCN: The beeper sounds when you press a key or when the scanner stops.
KEY: The beeper sounds when you press any key.
Set Mode Item 15 [BP USR]
Function: Create the beep melody for Bell ringer function.
See page ?? for details.
Set Mode Item 16 [BSY.LED]
Function: Enables/Disables the BUSY LED while the Squelch is open.
Available Values: ON/OFF
Vertex Standard Co., Ltd.
71
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Default: ON
Set Mode Item 17 [CH CNT]
Function: Selects the Channel Counter Search Width.
Available Values: ±5 MHz/±10 MHz/±50 MHz/±100 MHz
Default: ±5 MHz
Set Mode Item 18 [CLK.SFT]*
Function: Shifting of the CPU clock frequency.
Available Values: ON/OFF
Default: OFF
This function is only used to move a spurious response “birdie,” should it fall on a desired
frequency.
Set Mode Item 19 [CW ID]
Function: Programs and activates the CW Identifier (used during ARTS operation).
See page ?? for details.
Set Mode Item 20 [CWLRNG]
Function: Enables/Disables the CW Learning feature.
See page ?? for details.
Set Mode Item 21 [CWPICT]
Function: Select the CW tone pitch for the CW Learn, CW training, and CW Identifier functions.
Available Values: 400 - 1000 Hz (50 Hz/step)
Default: 700 Hz
Set Mode Item 22 [CWTRNG]
Function: Enables/Disables the CW Training feature.
See page ?? for details.
Set Mode Item 23 [DC VLT]
Function: Indicates the DC Supply Voltage.
Set Mode Item 24 [DCS CD]*
Function: Setting of the DCS code.
Available Values: 104 standard DCS codes
Default: DCS.023
Set Mode Item 25 [DCS RV]*
Function: Enables/Disables the “Inverted” DCS Tone.
Available Values: R-N.T-N/R-I.T-N/R-B.T-N/R-N.T.I/R-I.T-I/R-B.T-I
Default: R-N.T-N
R-N.T-N: Receive and transmit the Normal DCS Tone.
R-I.T-N: Receive the Inverted DCS Tone and transmit the Normal DCS Tone.
Vertex Standard Co., Ltd.
72
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
R-B.T-N: Receive the both Normal and Inverted DCS Tones and transmit the Normal DCS Tone.
R-N.T.I: Receive the Normal DCS Tone and transmit the Inverted DCS Tone.
R-I.T-I: Receive and transmit the Inverted DCS Tone.
R-B.T-I: Receive the both Normal and Inverted DCS Tones and transmit the Inverted DCS Tone.
Set Mode Item 26 [DT A/M]
Function: Enables/Disables the DTMF Autodial feature.
Available Values: MANUAL/AUTO
Default: MANUAL
Set Mode Item 27 [DT DLY]
Function: Selects the DTMF Autodialer Delay Time.
Available Values: 50MS/250MS/450MS/750MS/1000MS
Default: 450MS
Set Mode Item 28 [DT SEL]
Function: Programming of the DTMF Autodialer.
See page ?? for details.
Set Mode Item 29 [DT SPD]
Function: Selects the DTMF Autodialer Sending Speed.
Available Values: 50MS/100MS
Default: 100MS
Set Mode Item 30 [EAI]
Function: Enables/Disables the Emergency Automatic ID (EAI) feature..
Available Values: ON/OFF
Default: OFF
Set Mode Item 31 [EAI.TMR]
Function: Setting of the Emergency Automatic ID (EAI) operating mode and its Transmit Time.
Available Values:
INT. 1M through INT.10M, INT.15M, INT.20M, INT.30M, INT.40M, INT. 50M,
CON. 1M through CON.10M, CON.15M, CON.20M, CON.30M, CON.40M, and CON. 50M
Default: CON. 5M
Set Mode Item 32 [EMG.SEL]
Function: Select the alarms utilized when the Emergency function is engaged.
Available Values: BEEP/STROBE/BP+STR/BEAM/BP+BEM/CW/BP+CW/CWT
Default: BP+STR
BEEP (BP): Loud “Alarm” sounds.
STROBE (STB): Flashes the BUSY/TX indicator in bright white color.
BP+STB: Loud “Alarm” sounds along with flashing of the BUSY/TX indicator in white.
Vertex Standard Co., Ltd.
73
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
BEAM: The BUSY/TX indicator glows continuously in white.
BP+BEM: Loud “Alarm” sounds and the BUSY/TX indicator glows continuously in white.
CW: The BUSY/TX indicator flashes according to the programmed Emergency message (Morse
Code)* at a rate of five words per minute.
BP+CW: Sounds tones via the speaker, and flashes the BUSY/TX indicator, according to the
programmed Emergency message (Morse Code)* at a rate of five words per minute.
CWT: Transmits the programmed Emergency message (Morse Code)* and flashes the
BUSY/TX indicator, according to the programmed Emergency message (Morse Code)*
on the air beginning one minute after activation of the Emergency function.
*The internationally-recognized Morse Code “S.O.S” message (•••– – –•••) is programmed at the
factory for the Emergency message.
Here’s how to program the Emergency Message:
1. Set this Set Mode Item to “CW” or “BP+CW.”
2. Press the [V/M] key to display any previously-stored emergency message.
3. Press the [HM/RV] key to clear any previous emergency message, if desired.
4. Rotate the DIAL knob to select the first letter/number of the message, then press the [V/M]
key momentarily to save the first letter/number and move on to the next character.
5. Repeat the previous step as necessary to complete the message (up to 16 characters).
6. If you make a mistake, press the [BAND] key to back-space the cursor; now re-enter the
correct letter/number.
7. Press the [HM/RV] key to delete all data after the cursor that may have been previously
stored erroneously.
8. When you have entered the message, press the [TXPO] key momentarily to confirm the
message, then press the PTT switch to save the settings and exit to normal operation.
Set Mode Item 33 [EXT.MNU]
Function: Enables/Disables the extended Set Mode Menu.
Available Values: ON/OFF
Default: OFF
Set Mode Item 34 [FW KEY]
Function: Set the duration that a secondary function of the [F/W] key (press and holding the [F/W]
key) is held determines the function they activate.
Available Values: FW0.3S/FW0.5S/FW0.7S/ FW1.0S/FW1.5S
Default: FW0.5S
Set Mode Item 35 [HLF.DEV]*
Function: Reducing the Deviation level by 50 %.
Available Values: ON/OFF
Vertex Standard Co., Ltd.
74
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Default: OFF
Set Mode Item 36 [HM/RV]
Function: Selects the function of the [HM/RV] key.
Available Values: HOME/REV
Default: REV
HOME: Pressing the [HM/RV] key instantly recalls a favorite “Home” channel.
REV: Pressing the [HM/RV] key reverses the transmit and receive frequencies during repeater
operation.
Set Mode Item 37 [HM>VFO]
Function: Enables/Disables the function that is automatically switched to the VFO mode when the
DIAL knob is turned while in the Home Channel mode.
Available Values: DISABL/ENABLE
Default: ENABLE
Set Mode Item 38 [INT CD]
Function: Selects the Access Number (DTMF digit) for the SRG operation of the Internet
Connection feature (WIRESTM).
Available Values: DTMF 0 - DTMF F
Default: DTMF 1
Set Mode Item 39 [INT MD]
Function: Selects the operating mode of the Internet Connection feature (WIRESTM).
Available Values: SRG/FRG
Default: SRG
Set Mode Item 40 [INT.A/M]
Function: Enables/Disables the DTMF Autodialer feature while operating using the Internet
Connection feature (WIRESTM).
Available Values: MANUAL/AUTO
Default: MANUAL
Set Mode Item 41 [INT.SEL]
Function: Programming of the Access Number (DTMF code) for the FRG station of the WIRESTM
(or non WIRESTM Internet Link System) access.
See page ?? for details.
Set Mode Item 42 [INTKEY]
Function: Selects the function of the [%] key.
Available Values: INTNET/INT MR/SET MD
Default: INTNET
INTNET: Activates/Disable the internet feature.
Vertex Standard Co., Ltd.
75
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
INT MR: Recall the Internet Access Number (SRG) or Access Cord (FRG). Determine the
selection of the SRG or FRG via Set Mode Item 41: INT MD.
SET MD: Short-cut path for recall of one of Set Mode Items. See page ?? for programming.
Set Mode Item 43 [INTNET]
Function: Enables/Disables the Internet Connection feature (WIRESTM).
Available Values: ON/OFF
Default: OFF
Set Mode Item 44 [LAMP]
Function: Selects the LCD/Keypad Lamp mode.
Available Values: KEY 2S - KEY10S/CONT/OFF
Default: KEY
KEY 2S - KEY10S: Illuminates the LCD/Keypad for the selected illumination time when any key is
pressed.
CONT: Illuminates the LCD/Keypad continuously.
OFF: Disables the LCD/Keypad illumination
Set Mode Item 45 [LED LT]
Function: Illuminates the TX/BUSY indicator glows continuously white (useful as emergency
flashlight at night).
Set Mode Item 46 [LOCK]
Function: Selects the Control Locking lockout combination.
Available Values: KEY/PTT/KY(KEY)+PTT
Default: KEY
Set Mode Item 47 [M/T-CL]
Function: Selects the MONI key (just below the PTT switch) function.
Available Values: MONI/T-CALL
Default: Depends on the transceiver version.
MONI: Pressing the MONI key causes the Noise/Tone Squelch to be over-ridden, allowing you to
listen for weak (or non-encoded) signals.
T-CALL: Pressing the MONI key activates a 1750-Hz burst tone, used for repeater access in many
countries (especially in Europe).
Set Mode Item 48 [MCGAIN]
Function: Adjust the microphone gain level.
Available Values: LVL 1 - LVL 9
Default: LVL 5
This Set Mode setting is affect to both internal and external microphone.
Set Mode Item 49 [MR DSP]*
Vertex Standard Co., Ltd.
76
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Function: Toggles the display indication between “frequency” and the channel’s “Alpha/Numeric
Tag.”
Available Values: ALPHA/FREQ
Default: FREQ
Set Mode Item 50 [MR WMD]
Function: Selects the method of selection of channels for Memory Storage.
Available Values: NEXT/LOWER
Default: NEXT
NEXT: Stores the data into the memory channel which is next-highest from the last-stored memory
channel.
LOWER: Stores the data into the next-available “free” channel.
Set Mode Item 51 [MRFSTP]
Function: Selects the channel step for the fast channel selection mode while in the Memory Recall
mode.
Available Values: 10CH/20CH/50CH/100CH
Default: 10CH
Set Mode Item 52 [MRNAME]*
Function: Stores Alpha-Numeric “Tags” for the Memory channels.
See page ?? for details.
Set Mode Item 53 [MRPTCT]
Function: Enables/Disables the Memory Write Protector.
Available Values: ON/OFF
Default: OFF
When this function is set to “ON”, the memory write operation is ignored.
Set Mode Item 54 [MRSKIP]*
Function: Selects the Memory Scan channel-selection mode.
Available Values: OFF/SKIP/ONLY
Default: OFF
OFF: All memory channels will be scanned (the “flag” will be ignored).
SKIP: The scanner wills “skip” the flagged channels during scanning.
ONLY: The scanner wills only scan channels that are flagged (Preferential Scan List).
Set Mode Item 55 [MSG.LST]
Function: Programming a Member List for the Message feature.
See page ?? for details.
Set Mode Item 56 [MSG.REG]
Function: Selects your Personal ID for the Message feature.
Vertex Standard Co., Ltd.
77
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
See page ?? for details.
Set Mode Item 57 [MSG.SEL]
Function: Programming a Message for the Message feature.
See page ?? for details.
Set Mode Item 58 [ON TMR]
Function: Set the On Timer Time.
Available Values: OFF/00H.10M(00:10) 24H.00M(24:00) (10 minutes/step)
Default: OFF
The On Timer turns on the radio at the programmed time.
Set Mode Item 59 [OPN.MSG]
Function: Selects the Opening Message that appears when the radio is powered on.
Available Values: OFF/DC/MSG
Default: DC
OFF: No Opening Message
DC: DC supply voltage
MSG: Set by user. See below.
Here’s how to program the Opening Message:
1. Select this Set Mode Item to “MSG.”
2. Press the [V/M] key momentarily to enable programming of the opening message. You will
notice the first character entry’s location blinking.
3. Rotate the DIAL knob to select the first letter/number of the message, then press the [V/M]
key momentarily to save the first letter/number and move on to the next character.
Note: Do not forget to pull the DIAL knob to rotate the DIAL knob
4. Repeat the steps 3 and 4 as necessary to complete the message (up to six characters).
5. If you make a mistake, press the [BAND] key to back-space the cursor; now re-enter the
correct letter/number.
6. When you have entered the desired opening message, press the [TXPO] key momentarily to
confirm the message, then press the PTT switch to save the settings and exit to normal
operation.
Set Mode Item 60 [PAG.ABK]
Function: Enables/Disables the Answer Back function of the Enhanced CTCSS Paging & Code
Squelch.
Available Values: ON/OFF
Default: OFF
Set Mode Item 61 [PAG.CDR]
Function: Sets the Receiver Pager Code for the Enhanced CTCSS Paging & Code Squelch.
Vertex Standard Co., Ltd.
78
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
See page ?? for details.
Set Mode Item 62 [PAG.CDT]
Function: Sets the Transmitting Pager Code for the Enhanced CTCSS Paging & Code Squelch.
See page ?? for details.
Set Mode Item 63 [PR FRQ]*
Function: Program the CTCSS Tone frequency for the User programmed Reverse CTCSS
Decoder.
Available Values: 300Hz - 3000Hz (1000 Hz/step)
Default: 1600 Hz
Set Mode Item 64 [PRI.RVT]
Function: Enables/Disables the Priority Revert feature.
Available Values: ON/OFF
Default: OFF
See page ?? for details.
Set Mode Item 65 [PRI.TMR]
Function: Select the periodically checking time for the Priority (Dual Watch) feature.
Available Values: 0.1 - 0.9S (0.1S/step) or 1.0S - 10.0S (0.5S/step)
Default: 5.0S
See page ?? for details.
Set Mode Item 66 [PSWD]
Function: Programs and activates the Password feature.
See page ?? for details.
Set Mode Item 67 [PTT.DLY]
Function: Select the time delay between the PTT switch is pressed and the carrier is transmitted.
Available Values: OFF/20MS/50MS/100MS/200MS
Default: OFF
Set Mode Item 68 [RPT]*
Function: Sets the Repeater Shift Direction.
Available Values: SIMP/-RPT/+RPT
Default: Depends on the transceiver version, as well as the setting of Set Mode Item 5 [ARS].
Set Mode Item 69 [RPT.SFT]*
Function: Sets the magnitude of the repeater Shift.
Available Values: 0.00 - 150.00 MHz (50 kHz/step)
Default: Depends on the operating band and transceiver version.
If you press the [F/W] key momentarily, then rotate the DIAL knob, frequency steps of 1 MHz will
be selected.
Vertex Standard Co., Ltd.
79
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Set Mode Item 70 [RX MD]*
Function: Selects the Receiving mode.
Available Values: AUTO/N-FM/AM/W-FM
Default: AUTO (Mode automatically changes according to operating frequency.)
Set Mode Item 71 [S SRCH]
Function: Selects the Smart Search Sweep mode.
Available Values: SINGLE/CONT
Default: SINGLE
SINGLE: The transceiver sweeps the current band once in each direction starting on the current
frequency. All channels where activity is present (up to 15 in each direction) are loaded into the
Smart Search memories. Whether or not all 31 memories are filled, the search stops after one
sweep in each direction.
CONT: The transceiver makes a sweep in each direction as with the “SINGLE” mode, but if all 31
channels are not filled after the first sweep, the radio continues sweeping until they are all filled.
Set Mode Item 72 [SAVERX]
Function: Selects the Receive-mode Battery Saver interval (“sleep” ratio)
Available Values: 0.2 - 0.9S (0.1S/step) or 1.0S - 10.0S (0.5S/step)
Default: 0.2 S (1:1)
Set Mode Item 73 [SAVETX]
Function: Enables/Disables the Transmitter Battery Saver.
Available Values: ON/OFF
Default: OFF
Set Mode Item 74 [SCN.LMP]
Function: Enables/Disables the Scan lamp while paused.
Available Values: ON/OFF
Default: ON
Set Mode Item 75 [SCN.RSM]
Function: Selects the Scan Resume mode.
Available Values: 2SEC - 10SEC/BUSY/HOLD
Default: 5 SEC
2 SEC - 10 SEC: The scanner will halt on a signal it encounters, and will hold there for the
selected resume time. If you do not take action to disable the scanner within that time period, the
scanner will resume even if the stations are still active.
BUSY: The scanner will halt on a signal it encounters. When the carrier has dropped because the
other station(s) ceased transmission, the scanner will resume. The Scan Re-start Delay time
(default interval: 2 seconds) is set by the Set Mode Item 67: RES.TIM.
Vertex Standard Co., Ltd.
80
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
HOLD: The scanner will halt on a signal it encounters. It will not restart automatically; you must
manually re-initiate scanning if you wish to resume.
Set Mode Item 76 [SCN.STR]
Function: Select the Scan Re-start Delay time.
Available Values: 0.1-0.4S (0.1S/step) or 1.0S - 10.0S (0.5S/step)
Default: 2.0S
Set Mode Item 77 [SP OUT]
Function: Enables/Disables the FM Broadcast audio output to the internal speaker when using the
earphone antenna.
Available Values: AUTO/SPKR
Default: AUTO
AUTO: The FM Broadcast audio output is selected automatically depending on the connection of
the earphone antenna.
SPKR: Outputs the FM Broadcast audio output to the internal speaker any time.
Set Mode Item 78 [SQ LVL]
Function: Sets the Squelch threshold level.
Available Values: LVL 0 - LVL 15 (AM and Narrow FM), LVL 0 - LVL 8 (Wide FM and AM
Broadcast)
Default: LVL 1 (AM and Narrow FM), LVL 2 (Wide FM and AM Broadcast)
Set Mode Item 79 [SQ TYP]*
Function: Selects the Sub Audible Squelch Type.
Available Values: OFF/TONE/TSQL/DCS/RV TN/PR FRQ/PAGER/MESSAGE
Default: OFF
TONE: Activates the CTCSS Encoder
TSQ: Activates the CTCSS Encoder/Decoder
DCS: Activates the Digital Coded Encoder/Decoder
RV TN: Activates the Reverse CTCSS Decoder (Mutes the receiver when matching tone is
received)
PR FRQ: Activates the User programmed Reverse CTCSS Decoder (Mutes the receiver when
user programmed matching tone* is received)
PAGER: Activates the Enhanced Paging & Code Squelch
MESSAGE: Activates the Message feature
Note: See also Set Mode Item 81: SQSPLT regarding additional selections available during “Split
Tone” operation.
* Determine from the Set Mode Item 63: PR FRQ.
Set Mode Item 80 [SQSMTR]*
Vertex Standard Co., Ltd.
81
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Function: Adjusts the S-meter Squelch threshold level.
Available Values: OFF/LVL 1 - LVL 8
Default: OFF
Set Mode Item 81 [SQSPLT]
Function: Enables/Disables split CTCSS/DCS coding.
Available Values: ON/OFF
Default: OFF
When this Set Mode Item is set to “ON,” you can see the following additional parameters after the
“MESSAGE” parameter while selecting the Set Mode Item 79: SQ TYP.
D CODE: DCS Encode only.
T DCS: Encodes a CTCSS tone and Decodes a DCS code.
D TONE: Encodes a DCS code and Decodes a CTCSS tone.
Select the desired operating mode from the selections shown above.
Set Mode Item 82 [STEP]*
Function: Setting of the synthesizer steps.
Available Values: AUTO/5/8.33/9/10/12.5/15/20/25/50/100 kHz
Default: AUTO (Step automatically changes according to operating frequency.)
R.F. Says: 1) 9 kHz steps are available only when receiving on the BC band.
2) 8.33 kHz steps are available only when receiving on the Air band.
3) While operating on the BC band, you may only select channel steps of 9 kHz or 10 kHz; the
other step selections are disabled.
4) 5 kHz steps are not available for use on 250 - 300 MHz, nor above 580 MHz.
Set Mode Item 83 [STEREO]*
Function: Enables/Disables the stereo receiving while receiving the FM Broadcast band.
Available Values: STEREO/MONO
Default: STEREO
Set Mode Item 84 [SUB-RX]
Function: Set the switching time before it being changed for the reception of Broadcast after a
signal disappeared in an amateur band when the AF Priority function is activated.
Available Values: OFF/TRX 1S - TRX 10S (1S/step)/HOLD/ TX 1S - TX 10S (1S/step)
Default: OFF
Set Mode Item 85 [TEMP]
Function: Indicates the current temperature inside the transceiver’s case and selects the
measurement units (“°F” or “°C”) for the temperature sensor.
Press the [MODE] key toggle the measurement units between “°F” and “°C”.
Set Mode Item 86 [TN FRQ]*
Vertex Standard Co., Ltd.
82
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Function: Setting of the CTCSS Tone Frequency.
Available Values: 50 standard CTCSS tones
Default: 100.0 Hz
Set Mode Item 87 [TOT]
Function: Setting of the TOT time
Available Values: OFF/0.5M - 30M (0.5M/step)
Default: OFF
The time-out timer shuts off the transmitter after continuous transmission of the programmed time.
Set Mode Item 88 [TS MUT]
Function: Enables/Disables the receiver audio output while the Tone Search Scanner is activated.
Available Values: ON/OFF
Default: ON
Set Mode Item 89 [TS SPD]
Function: Selects the Tone Search Scanner speed.
Available Values: SLOW (1.25 tone/sec)/FAST (2.5 tone/sec)
Default: FAST
Set Mode Item 90 [VFO MD]
Function: Selects or disables the VFO band edge limiting for the current band.
Available Values: ALL/BAND
Default: BAND
BAND: When the VFO frequency reaches the high band edge of the current band, the VFO
frequency will jump to the low band edge of the current band (or vice versa).
ALL: When the VFO frequency reaches the high edge of the current band, the VFO frequency will
jump to the low band edge of the next band (or vice versa).
Set Mode Item 91 [VFO.SKP]
Function: Set the My Band.
Available Values: ON/OFF
Default: OFF
The “My Band” feature allows you to select several operating bands, and make only those bands
available for selection via the [BAND] key.
ON: Only the bands that are turned on will be shown when pushing the [BAND] key.
OFF: When the [BAND] key is pressed, the bands that are turned “OFF” will not be shown.
See page ?? for details.
Set Mode Item 92 [WAKEUP]
Function: Setting of the Wakeup feature.
Available Values: OFF/5SEC - 60SEC(5SEC/step)/EAI
Vertex Standard Co., Ltd.
83
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Default: OFF
Set Mode Item 92 [WX ALT]
Function: Enables/Disables the NOAA Weather Alert Feature.
Available Values: OFF/ON
Default: OFF
Vertex Standard Co., Ltd.
84
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could
void the user’s authorization to operate this device.
DECLARATION BY MANUFACTURER
The scanner receiver is not a digital scanner and is incapable of being converted or modified to a
digital scanner receiver by any user.
Vertex Standard Co., Ltd.
85
