Operating Manual

FT-2900R Operating Manual

Introduction

The Yaesu FT-2900R is a deluxe, rugged FM mobile transceiver providing high power

output and outstanding receiver performance for the 144 MHz Amateur band. Included

in the FT-2900R’s feature complement are:

 75 Watts of power output, with selection of four power levels for every operating

situation.

 Expanded receiver coverage: 136-174 MHz.

 Keyboard entry of operating frequencies from the microphone.

 Excellent protection from receiver intermodulation distortion, thanks to Yaesu’s

renowned Advanced Track Tuning front end.

 221 memories which can store repeater shifts, odd repeater shifts, CTCSS/DCS

tones, and 6-character Alpha-Numeric labels for easy channel recognition.

 10 NOAA Weather Broadcast Channels, with Weather Alert.

 Built-in CTCSS and DCS Encoder/Decoder circuits.

 The Smart SearchTM feature, which automatically sweeps a band and loads active

frequencies into dedicated memory banks, is ideal for identifying active repeaters

when visiting a city for the first time.

 Extensive Menu system, which allows customization of a number of transceiver

performance characteristics.

 The Yaesu-exclusive multi-function LCD display.

Additional features include a transmit Time-Out-Timer (TOT), Automatic Power-Off

(APO), Automatic Repeater Shift (ARS), plus provision for reduction of the Tx deviation

in areas of high channel congestion. And an RF Squelch circuit allows the owner to set

the squelch to open at a programmable setting of the S-Meter, thus reducing guesswork

in setting the squelch threshold.

Congratulations on your purchase of the FT-2900R! Whether this is your first rig, or if

Yaesu equipment is already the backbone of your station, the Vertex Standard

organization is committed to ensuring your enjoyment of this high-performance

transceiver, which should provide you with many years of satisfying operation. Our

dealer network and technical support personnel stand behind every product we sell,

and we invite you to contact us should you require technical advice or assistance.

We recommend that you read this manual in its entirety prior to installing the FT-2900,

so that you fully understand the capabilities of your new transceiver.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Specifications

General

Frequency Range: TX:144 - 148 MHz

RX:136 - 174 MHz

Channel Step: 5/10/12.5/15/20/25/50/100 kHz

Standard Repeater Shift: ±600 kHz

Frequency Stability: Better than ±10 ppm

(–20 °C to +60 °C)

Modes of Emission: F2 / F3

Antenna Impedance: 50 Ohms, unbalanced

Supply voltage: 13.8 V DC ±15%, negative ground

Current Consumption (typical): Rx: less than 0.7 A, less than 0.3 A (squelched)

Tx: 16 A (75 W) /10 A (30 W) /6 A (10 W) /4.5 A (5 W)

Operating Temperature Range: –4 °F to +140 °F (–20 °C to +60 °C)

Case Size (WxHxD): (160 x 50 x 185 mm) (w/o knobs)

Weight (Approx.): 1.8 kg

Transmitter

Output Power: 75 W/30 W/10 W/5 W

Modulation Type: Variable Reactance

Maximum Deviation: ±5 kHz/±2.5 kHz

Spurious Radiation: Better than –60 dB

Microphone Impedance: 2000 Ohms

Receiver

Circuit Type: Double Conversion Superheterodyne

Ifs: 21.7 MHz & 450 kHz

Sensitivity (for 12dB SINAD): Better than 0.2 uV

Selectivity (–6/–60dB): 12 kHz/28 kHz

IF Rejection: Better than 70 dB

Image Rejection: Better than 70 dB

Maximum AF Output: 3 W into 4 Ohms @10 % THD

Specifications subject to change without notice or obligation. Specifications guaranteed

only within Amateur band.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Accessory & Options

Supplied Accessories

Microphone MH-48A6J 1

Mobile Mounting Bracket MMB-36 1

DC Power Cord w/Fuse 1

Spare Fuse 20 A 2

Operating Manual 1

Warranty Card 1

Optional Accessories

High-Power External Speaker MLS-100

AC Power Supply FP-1023 (25 A: USA only)

AC Power Supply FP-1025A (25 A)

AC Power Supply FP-1030A (35 A)

Installation

This chapter describes the installation procedure for integrating the FT-2900R into a

typical amateur radio station. It is presumed that you possess technical knowledge and

conceptual understanding consistent with your status as a licensed radio amateur.

Please take some extra time to make certain that the important safety and technical

requirements detailed in this chapter are followed closely.

Preliminary Inspection

Inspect the transceiver visually immediately upon opening the packing carton. Confirm

that all controls and switches work freely, and inspect the cabinet for any damage.

Gently shake the transceiver to verify that no internal components have been shaken

loose due to rough handling during shipping.

If any evidence of damage is discovered, document it thoroughly and contact the

shipping company (or your local dealer, if the unit was purchased over-the-counter) so

as to get instructions regarding the prompt resolution of the damage situation. Be

certain to save the shipping carton, especially if there are any punctures or other

evidence of damage incurred during shipping; if it is necessary to return the unit for

service or replacement, use the original packing materials but put the entire package

inside another packing carton, so as to preserve the evidence of shipping damage for

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

insurance purposes.

Installation Tips

To ensure long life of the components, be certain to provide adequate ventilation

around the cabinet of the FT-2900.

Do not install the transceiver on top of another heat-generating device (such as a power

supply or amplifier), and do not place equipment, books, or papers on top of the

FT-2900R. Avoid heating vents and window locations that could expose the transceiver

to excessive direct sunlight, especially in hot climates. The FT-2900R should not be

used in an environment where the ambient temperature exceeds +140 °F (+60 °C).

Safety Information

The FT-2900R is an electrical apparatus, as well as a generator of RF (Radio

Frequency) energy, and you should exercise all safety precautions as are appropriate

for this type of device. These safety tips apply to any device installed in a well-designed

amateur radio station.

 Never allow unsupervised children to play in the vicinity of your transceiver or

antenna installation.

 Be certain to wrap any wire or cable splices thoroughly with insulating electrical

tape, to prevent short circuits.

 Do not route cables or wires through door jambs or other locations where, through

wear and tear, they may become frayed and shorted to ground or to each other.

 Do not stand in front of a directional antenna while you are transmitting into that

antenna. Do not install a directional antenna in any location where humans or pets

may be walking in the main directional lobe of the antenna’s radiation pattern.

 In mobile installations, it is preferable to mount your antenna on top of the roof of

the vehicle, if feasible, so as to utilize the car body as a counterpoise for the antenna

and raise the radiation pattern as far away from passengers as possible.

 During vehicular operation when stopped (in a parking lot, for example), make it a

practice to switch to Low power if there are people walking nearby.

 Never wear dual-earmuff headphones while driving a vehicle.

 Do not attempt to drive your vehicle while making a telephone call on an autopatch

using the DTMF microphone. Pull over to the side of the road, whether dialing

manually or using the auto-dial feature.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Antenna Consideration

The FT-2900R is designed for use with antennas presenting an impedance of near 50

Ohms at all operating frequencies. The antenna (or a 50 Ohm dummy load) should be

connected whenever the transceiver is turned on, to avoid damage that could otherwise

result if transmission occurs accidentally without an antenna.

Ensure that your antenna is designed to handle 75 Watts of transmitter power. Some

magnetic-mount mobile antennas, designed for use with hand-held transceivers, may

not be capable of withstanding this power level. Consult the antenna manufacturer’s

specification sheet for details.

Most all FM work is performed using vertical polarization. When installing a

directional antenna such as a Yagi or Cubical Quad, be certain to orient it so as to

produce vertical polarization, unless you are engaged in a special operating situation

where horizontal polarization is used. In the case of a Yagi antenna, orient the

elements vertically for vertical polarization; for a Cubical Quad, the feedpoint should

be at the center of one of the vertical sides of the driven element (or at a side corner, in

the case of a diamond-shaped Cubical Quad).

Excellent reference texts and computer software are available for the design and

optimization of VHF antennas. Your dealer should be able to assist you with all aspects

of your antenna installation requirements.

Use high-quality 50 Ohm coaxial cable for the lead-in to your FT-2900R transceiver. All

efforts at providing an efficient antenna system will be wasted if poor quality, lossy

coaxial cable is used. Losses in coaxial lines increase as the frequency increases, so an

8-meter-long (25’ coaxial line with 1/2 dB of loss at 29 MHz may have a loss of 1.8 dB or

more at 146 MHz; choose your coaxial cable carefully based on the installation location

(mobile vs. base) and the overall length of the cable required (for very short runs of

cable in a mobile installation, the smaller, more flexible cable types may be acceptable).

For reference, the chart at the right shows approximate loss figures for

typically-available coaxial cables frequently used in VHF installations.

In outdoor installations, be certain to weatherproof all connectors thoroughly, as water

entering a coaxial cable will cause losses to escalate rapidly, thus diminishing your

communications effectiveness. The use of the shortest possible length of the highest

quality coaxial cable that fits within your budget will ensure the best performance from

your FT-2900R.

Mobile Installation

The FT-2900R must only be installed in vehicles having a 13.8 Volt negative ground

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

electrical system. Mount the transceiver where the display, controls, and microphone

are easily accessible, using the supplied MMB-83 mounting bracket.

The transceiver may be installed in almost any location, but should not be positioned

near a heating vent nor anywhere where it might interfere with driving (either visually

or mechanically). Make sure to provide plenty of space on all sides of the transceiver so

that air can flow freely around the radio’s case. Refer to the diagrams showing proper

installation procedures.

Mobile Power Connections

To minimize voltage drop and avoid blowing the vehicle’s fuses, connect the supplied

DC power cable directly to the battery terminals. Do not attempt to defeat or bypass

the DC cable’s fuse - it is there to protect you, your transceiver, and your vehicle’s

electrical system.

Warning!

Never apply AC power to the power cable of the FT-2900R, nor DC voltage greater than

15.8 Volts. When replacing the fuse, only use a 25-A fuse. Failure to observe these

safety precautions will void the Limited Warranty on this product.

 Before connecting the transceiver, check the voltage at the battery terminals while

revving the engine. If the voltage exceeds 15 Volts, adjust the vehicle’s voltage

regulator before proceeding with installation.

 Connect the RED power cable lead to the POSITIVE (+) battery terminal, and the

BLACK power cable lead to the NEGATIVE (–) terminal. If you need to extend the

power cable, use #12 AWG or larger insulated, stranded copper wire. Solder the

splice connections carefully, and wrap the connections thoroughly with insulating

electrical tape.

 Before connecting the cable to the transceiver, verify the voltage and polarity of the

voltage at the transceiver end of the DC cable using a DC voltmeter. Now connect

the transceiver to the DC cable.

Mobile Speakers

The optional MSL-100 External Speaker includes its own swivel-type mounting

bracket, and is available from your Yaesu dealer.

Other external speakers may be used with the FT-2900R, if they present the specified

4-Ohm impedance and are capable of handling the 3 Watts of audio output supplied by

the FT-2900R.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Base Station Installation

The FT-2900R is ideal for base station use as well as in mobile installations. The

FT-2900R is specifically designed to integrate into your station easily, using the

information to follow as a reference.

AC Power Supplies

Operation of the FT-2900R from an AC line requires a power source capable of

providing at least 15 Amps continuously at 13.8 Volts DC. The FP-1023 and FP-1030A

AC Power Supplies are available from your Yaesu dealer to satisfy these requirements.

Other well-regulated power supplies may be used, as well, if they meet the above

voltage and current specifications.

Use the DC power cable supplied with your transceiver for making power connections

to the power supply. Connect the RED power cable lead to the POSITIVE (+) power

supply terminal, and connect the BLACK power cable lead to the NEGATIVE (–) power

supply terminal.

Front Panel Controls & Switches

1. VOL Knob

This control adjusts the audio volume level. Clockwise rotation increases the

volume level.

2. SQL Knob

This control is used to silence background noise on the receiver. It should be

advanced clockwise just to the point where the noise is silenced (and the “BUSY”

indicator on the display turns off), so as to provide the best sensitivity to weak

signals.

3. Microphone Jack

Connect the supplied MH-48A6J Hand Microphone to this jack.

4. PWR Key

Press and hold this key for one second to toggle the transceiver’s power on and off.

5. [%] Key

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

This key allows operation in conjunction with the Internet Connection feature.

6. [MHz(SET)] Key

This key allows tuning in 1-MHz steps (the MHz digits will blink on the display). If

receiving on a memory, pressing this key the first time activates the Memory

Tuning mode, and pressing it again enables 1-MHz steps.

Press and hold in this key for one second to activate the “Set” (Menu) mode.

7. [REV(DW)] Key

During split-frequency operation, such as through a repeater, this key reverses the

transmit and receive frequencies.*

Press and hold in this key for one second to activate the Dual Watch feature,

described in the Operation chapter (“PRI” will be displayed on the LCD, indicating

“Priority Channel” monitoring).

* Using the Menu, the “Reverse” feature may be disabled in favor of one-touch a

access to the “Home” Channel. See page 33 for details.

8. [LOW(A/N)] Key

Press this key momentarily to select the transmitter power output level.

The available power levels are:

HIGH (75W) Æ MID (30W) Æ LOW2 (10W) Æ LOW1 (5W)

To toggle the display between indication of the frequency and the channel’s

Alpha/Numeric label, press and hold in this key for one second while receiving on

that memory channel.

9. [D/MR(MW)] Key

Press this key momentarily to switch the frequency control among the VFO,

Memory System, and Home channel.

Press and hold in this key for one second to activate the Memory Storage mode.

10. DIAL Knob

This 24-position detented rotary switch is used for tuning, memory selection and

most function settings. The microphone [UP]/[DWN] buttons duplicate the

functions of this knob.

11. Display

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

The main digits on the display may show operating frequency, memory name, or

any of many parameters during Menu setup.

Microphone Switches

1. PTT Switch

Press this switch to transmit, and release it to receive.

2. Keypad

These 16 keys generate DTMF tones during transmission.

In the receive mode, these 16 keys can be used for direct frequency entry and/or

direct numeric recall of the Memory channels.

The [A], [B], [C], and [D] keys, on receive, replicate the functions of the front panel

keys ([MHz(SET)], [REV(D/W)], [LOW(A/N)], and [D/MR(MW)]). See the previous

discussion.

3. [P1]/[P2]/[P3]/[P4] Buttons

These four keys are user programmable, allowing quick access to features used

often. The default functions are described below.

[P1] button (SQL OFF)

Press this button to disables the noise and tone squelch systems.

[P2] button (S SRCH)

Press this button to activate the Smart Search feature.

[P3] button (C SRCH)

Press this button to activate the Tone Search feature.

[P4] button (WX CH/T.CALL)

In the USA version, pressing this button recall the “Reather” broadcast channel

bank. In the EXP version, pressing this button activates T.CALL (1750 Hz) for

repeater access.

You can reprogram the [P1], [P2], [P3], and [P4] buttons for other functions, if

desired. See page ?? for details.

4. LAMP Switch

This switch illuminates the Microphone’s keypad.

5. LOCK Switch

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

This switch locks out the Microphone’s buttons (except for the keypad and PTT

switch).

6. [UP]/[DWN] Button

Press (or hold in) either of these buttons to tune (or scan up or down) the operating

frequency or through the memory channels. In many ways, these buttons emulate

the function of the (rotary) DIAL knob.

Rear Panel Connectors

1. 13.8V DC Cable Pigtail w/Fuse

This is the power supply connection for the transceiver. Use the supplied DC cable

to connect this pigtail to the car battery or other DC power supply capable of at

least 10 Amperes (continuous duty). Make certain that the red lead connects to the

positive side of the supply. The fuse is 25-A.

2. ANT Coaxial Socket

Connect a 144-MHz antenna to this type-M (SO-239) socket using 50-ohm coaxial

cable and a type-M (pl-259) plug. Male sure the antenna is designed specifically for

use on the operating frequency.

3. EXT SP Jack

This 2-contact mini 3.5-mm mini phone jacks provide receiver audio output for an

optional external speaker. The audio impedance is 4 Ohms, and the level varies

according to the setting of the front panel’s VOL control. Inserting a plug into this

jack disables audio from the transceiver’s internal speaker.

Basic Operation

R.F. Says: Hi! I’m R. F. Radio, and I’ll be helping you along as you learn the many

features of the FT-2900R. I know you’re anxious to get on the air, but I encourage you

to read “Basic Operation” section of this manual as thoroughly as possible, so you’ll get

the most out of this fantastic new transceiver. Now. . .let’s get operating!

Turning the Transceiver On and Off

1. To turn the transceiver on, press and hold in the PWR key for one second.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

When you turn on the FT-2900R, the current DC supply voltage is indicated on the

LCD for 2 seconds. After this interval, the display will switch its normal indication

of the operating frequency.

2. To turn the transceiver off, again press and hold in the PWR key for one second.

R.F. Says: You can change the Opening Message (DC supply voltage indication) to any

desired message (up to 6 characters) via Set Mode Item “31 OPN.MSG;” see page xx

for details.

Adjusting the Audio Volume Level

Rotate the VOL control to adjust the receiver volume. Clockwise rotation increases the

audio output level.

Adjusting the Squelch Setting

Rotate the SQL control just to the point where the noise is silenced and the “BUSY”

indicator on the display turns off. If the SQL control is set further clockwise, sensitivity

to weak signals is reduced.

A special “RF Squelch” feature is provided on this radio. This feature allows you to set

the squelch so that only signals exceeding a certain S-meter level will open the squelch.

See page 15 for details

Frequency Navigation

1) Tuning Dial

Rotating the DIAL knob allows tuning in the pre-programmed steps. Clockwise

rotation of the DIAL knob causes the FT-2900R to be tuned toward a higher frequency,

while counter-clockwise rotation will lower the operating frequency.

Press the [MHz(SET)] key momentarily, then rotate the DIAL knob, to change the

frequency steps to 1 MHz per step. This feature is extremely useful for making rapid

frequency excursions over the wide tuning range of the FT-2900R. Instead of pressing

the [MHz(SET)] button, you may also press the [A] key on the Microphone’s keypad to

engage tuning in 1 MHz steps.

2) Direct Keypad Frequency Entry

The keypad of the MH-48A6J DTMF Microphone may be used for direct entry of the

operating frequency.

To enter a frequency from the MH-48A6J keypad, just press the numbered digits in the

proper sequence. There is no “decimal point” key on the MH-48A6J keypad. However,

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

there is a short-cut for frequencies ending in zero: press the [#] key after the last

non-zero digit.

Examples: To enter 146.520 MHz, press [1] Æ [4] Æ [6] Æ [5] Æ [2] Æ [0]

To enter 146.000 MHz, press [1] Æ [4] Æ [6] Æ [#]

R.F. Says: If you cannot get the radio to accept the frequency entry, it is possible that

the channel steps are set to an incompatible value (e.g. if you have 25 kHz steps set,

you cannot set a frequency of 146.520 MHz). See page 19 to learn how to change the

channel step size.

3) Scanning

From the VFO mode, press the microphone’s [UP]/[DWN] keys momentarily to initiate

scanning toward a higher- or lower frequency, respectively. The FT-2900R will stop

when it receives a signal strong enough to break through the squelch threshold. The

FT-2900 will then hold on that frequency according to the setting of the “Resume” mode

(Menu “41 SCAN)”; see page 34).

If you wish to reverse the direction of the scan (i.e. toward a lower frequency, instead of

a higher frequency), just rotate the DIAL knob one click in the counter-clockwise

direction while the FT-2900R is scanning. The scanning direction will be reversed. To

revert to scanning toward a higher frequency once more, rotate the DIAL knob one

click clockwise.

Press the [UP]/[DWN] keys again to cancel scanning. You may also press the PTT

button momentarily; scanning will stop, but you will not transmit until you release the

PTT button, and press it again.

R.F. Says: If you have enabled the “Severe Weather Alert” feature, you will occasionally

notice “WX” channels interspersed with the regular channels you are scanning. This is

normal, because your radio is constantly monitoring for weather alerts. See page 17.

Transmission

To transmit, simply close the PTT (Push To Talk) switch on the microphone when the

frequency is clear. Hold the microphone approximately 1” (25 mm) from your mouth,

and speak into the microphone in a normal voice level. When your transmission is

complete, release the PTT switch; the transceiver will revert to the receive mode.

During transmission, the “TX” indicator will appear at the upper left corner on the

display.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Changing the Transmitter Power Level

You can select from among a total of four transmit power levels on your FT-2900R.

To change the power level, press the [LOW(A/N)] key (or the microphone’s [C] key to

select one of four power settings. These power levels will be stored, in memory registers,

at the time of memory storage (see page 30 for details on Memory operation).

During transmission, the Bar Graph will deflect in the display, according to the power

output selected.

Weather Broadcast Reception

The FT-2900 includes a unique feature which allows reception of weather broadcasts in

the 160-MHz frequency range. Ten standard Weather Broadcast channels are

pre-loaded into a special memory bank.

To listen to a Weather Broadcast Channel:

1. Press the Microphone’s [P4] button to recall the Weather Broadcast channels.

2. Turn the DIAL knob to select the desired Weather Broadcast channel.

3. If you wish to check the other channels for activity by scanning, just press the

Microphone’s PTT switch.

4. To exit to normal operation, press the [P4] button again. Operation will return to

the VFO or Memory channel you were operating on before you began Weather

Broadcast operation.

Severe Weather Alert Feature

In the event of extreme weather disturbances, such as storms and hurricanes, the

NOAA (National Oceanic and Atmospheric Administration) sends a weather alert

accompanied by a 1050 Hz tone and subsequent weather report on one of the NOAA

weather channels.

Advanced Operation

LOCK Feature

To order to prevent accidental frequency change or inadvertent transmission, various

aspects of the FT-2900R’s keys and knob may be locked out. The possible lockout

combinations are:

KEY: Just the front panel keys are locked out

DIAL: Just the front panel DIAL knob is locked out

K+D: Both the keys and DIAL knob are locked out

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

PTT: The PTT switch is locked (TX not possible)

K+P: Both keys and PTT switch are locked out

D+P: Both DIAL knob and PTT switch are locked out

ALL: All of the above are locked out

OFF: The Lock feature is disabled

To lock out some or all of the keys, use the “Set” (Menu) mode, described in detail

beginning on page 51:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “26 LOCK.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set the display to one of

the selections shown above.

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

When the Lock feature is activated, the “KEY” icon will appear on the LCD.

To disable the Lock feature, repeat the above process, selecting “OFF” in step 2 above.

Keypad Beeper

A key/button beeper provides useful audible feedback whenever a key/button is pressed.

If you want to turn the beeper off (or back on again):

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “6 BEEP.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set the display to “OFF.

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

Channel Step Selection

Tuning steps are factory preset to default increments which are appropriate for the

country to which this radio is exported. You may have a reason to use a different step

size, however, and here is the procedure for changing the channel steps:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “50 STEP.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired step

size (5/10/12.5/15/20/25/50/100 kHz).

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Display Brightness

The FT-2900R display illumination has been specially engineered to provide high

visibility with minimal disruption of your “night vision” while you are driving. The

brightness of the display is manually adjustable, using the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “16 DIMMER.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select a comfortable

brightness level (0 - 10).

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

RF Squelch

A special RF Squelch feature is provided on this radio. This feature allows you to set

the squelch so that only signals exceeding a certain S-meter level will open the squelch.

To set up the RF squelch circuit for operation, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “42 RF SQL.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired signal

strength level for the squelch threshold (S1 - S9 or OFF).

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

R.F. Says: The receiver’s squelch will open based on the highest level set by the two

squelch system “Noise Squelch” and “RF Squelch.” For example:

1) If the

Noise Squelch

(SQL control) is set so that signals at a level of S-3 will open the

squelch, but the

RF Squelch

(Menu #42) is set to “S-9,” the squelch will only open on

signals which are S-9 or stronger on the S-meter.

2) If the

RF Squelch

is set to “S-3,” but the

Noise Squelch

is set to a high level which

will only pass signals which are Full Scale on the S-meter, the squelch will only open

on signals which are Full Scale on the S-meter. In this case, the Noise Squelch

overrides the action of the RF Squelch.

Repeater Operation

The FT-2900R includes a host of convenience features which makes operation on

amateur repeaters both efficient and enjoyable.

This transceiver offers three methods of setting up split-frequency operation on

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

repeaters:

 Manual selection of preset repeater shifts (Standard Repeater Shift);

 Automatic Repeater Shift (ARS), providing automatic activation of repeater shifts

during designated repeater frequency subbands; and

 Independently stored transmit and receive frequencies (typically not corresponding

to established repeater frequency shifts).

Standard Repeater Shift

To activate the standard shift manually, you may use the Set (Menu) mode:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “43 RPT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired shift

direction (–RPT, +RPT, or SIMP).

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

R.F. Says: You also may program one of the Microphone’s programmable keys ([P1] ~

[P4]) to allow quick access to the above procedure. See page 45 for details on the setup

of the programmable keys.

With repeater shift activated, you can temporarily reverse the transmit and receive

frequencies by pressing the [REV(DW)] key (or microphone’s [B] key). Use this feature

to display the transmit frequency without transmitting, and to check the strength of

signals on a repeater uplink frequency (so as to determine whether or not a particular

station is within “Simplex” range, for example).

The repeater offset is fixed to 600 kHz from the factory. You can change the offset by

the following procedure, if needed for vacation travel or other purposes:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “46 SHIFT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set the desired offset.

Note that the resolution of the “Standard” repeater shift is to the nearest 50 kHz

multiple.

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

R.F. Says: Do not use this procedure for programming of an “odd split” type repeater

pair! The process for programming odd splits is shown on page 23.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Automatic Repeater Shift

The ARS (Automatic Repeater Shift) feature in this transceiver allows easy and

convenient repeater operation by automatically activating the repeater shift function

whenever you tune to a standard repeater subband. The ARS function is preset at the

factory to conform to the standards for the country to which it is exported.

The ARS function is enabled at the factory. To disable it:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “4 ARS.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to change the display to

“OFF.

3. Press and hold in the [MHz(SET)] key for one second to save your new setting and

exit to normal operation.

To enable the ARS function again, select to “ON” in step 2 above.

Separate Transmit Frequency Memories (“Odd Splits”)

All memory channels can store independent receive and transmit frequencies, to

accommodate occasional non-standard offsets with greater frequency resolution than is

available using the “standard” shift feature.

1. First store the receive (repeater output) frequency. In the VFO mode, tune the

transceiver to the desired receive frequency. Now press and hold in the

[D/MR(MW)] key on the front panel for one second.

2. Within five seconds of pressing the [D/MR(MW)] key, use the DIAL knob or

microphone’s [UP]/[DWN] buttons to select the desired memory channel into which

you wish to store this frequency pair.

3. Now press the [D/MR(MW)] key momentarily to store the receive frequency into

the selected memory.

4. Next store the transmit (repeater input) frequency. Since you are still in the VFO

mode, tune the transceiver to the desired transmit frequency.

5. Now press and hold in the [D/MR(MW)] key for one second.

6. Press and hold in the PTT switch, and press the [D/MR(MW)] key momentarily

while holding in the PTT switch. This will not cause transmission, but rather it

will instruct the transceiver that you are programming a separate transmit

frequency into memory.

When you have finished the above procedure, press the [D/MR(MW)] key momentarily.

The channel number and repeater downlink frequency will appear on the display. If

you press the PTT switch, you will observe the display changing to indicate the

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

repeater’s uplink frequency. Note also that the display shows “–+” in the upper

left-hand corner; this indicates that an “odd” (non-standard) shift has been stored on

this channel.

CTCSS/DCS/EPCS Operation

CTCSS Operation

Many repeater systems require that a very-low-frequency audio tone be superimposed

on your FM carrier in order to activate the repeater. This helps prevent false activation

of the repeater by radar or spurious signals from other transmitters. This tone system,

called “CTCSS” (Continuous Tone Coded Squelch System), is included in your

FT-2900M, and is very easy to activate.

CTCSS setup involves two actions: setting the Tone Mode and then setting of the Tone

Frequency. These actions are set up by using the Set (Menu) mode, selections #49 (SQL.

TYP) and #52 (TN FRQ).

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “49 SQL.TYP.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob so that “TONE” appears on

the display; this activates the CTCSS Encoder, which allows repeater access.

3. Rotating the DIAL knob one more click clockwise in the above step will cause

“TSQL” to appear. When “TSQL” appears, this means that the Tone Squelch

system is active, which mutes your FT-2900M’s receiver until it receives a call from

another radio sending out a matching CTCSS tone. This can help keep your radio

quiet until a specific call is received, which may be helpful while operating in

congested areas.

R.F. Says: 1) You may notice a “RV TN” indication on the display while you rotate

the DIAL knob in this step; this means that the Reverse Tone Squelch system is

active, which mutes your FT-2900R’s receiver (instead of opening the squelch)

when it receives a call from the radio sending a matched CTCSS tone. The “T SQ”

icon will blink on the display when the Reverse Tone Squelch system is activated.

2) You may notice a “DCS” indication on the display while you rotate the DIAL

knob still more. We’ll discuss the Digital Code Squelch system shortly.

4. When you have made your selection of the CTCSS tone mode, press the

[MHz(SET)] key momentarily, then rotate the DIAL knob one click

counter-clockwise to select Menu “52 TN FRQ.” This Menu selection allows setting

of the CTCSS tone frequency to be used.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

5. Press the [MHz(SET)] key to enable adjustment of the CTCSS frequency.

6. Rotate the DIAL knob until the display indicates the Tone Frequency you need to

be using.

7. When you have made your selection, press and hold in the [MHz(SET)] key for one

second to save the new setting and exit to normal operation.

R.F. Says: Your repeater may or may not re-transmit a CTCSS tone - some systems just

use CTCSS to control access to the repeater, but don’t pass it along when transmitting.

If the S-Meter deflects, but the FT-2900R is not passing audio, repeat steps “1” through

“3” above, but rotate the DIAL knob so that “TONE” appears - this will allow you to

hear all traffic on the channel being received.

You may use the Menu to re-program one of the Microphone’s programmable keys for

quick access to Menu #52 (TN FRQ), from which you can perform the above setup

procedure. See page 45 for details on the setup of the programmable keys.

DCS Operation

Another form of tone access control is Digital Code Squelch, or DCS. It is a newer, more

advanced tone system which generally provides more immunity from false paging than

does CTCSS. The DCS Encoder/Decoder is built into your FT-2900R, and operation is

very similar to that just described for CTCSS. Your repeater system may be configured

for DCS; if not, it is frequently quite useful in Simplex operation if your friend(s) use

transceivers equipped with this advanced feature.

Just as in CTCSS operation, DCS requires that you set the Tone Mode to DCS and that

you select a Tone Code.

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “49 SQL.TYP.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob until “DCS” appears on the

display; this activates the DCS Encoder/Decoder.

3. Now press the [MHz(SET)] key momentarily, then rotate the DIAL knob to select

Menu “14 DCS CD.”

4. Press the [MHz(SET)] key momentarily to enable the adjustment of the DCS code.

5. Rotate the DIAL knob to select the desired DCS Code (a three-digit number).

6. When you have made your selection, press and hold in the [MHz(SET)] key for one

second to save the new setting and exit to normal operation.

R.F. Says: Remember that the DCS is an Encode/Decode system, so your receiver will

remain muted until a matching DCS code is received on an incoming transmission.

Switch the DCS off when you’re just tuning around the band!

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Tone Search Scanning

In operating situations where you don’t know the CTCSS tone or DCS code being used

by another station or stations, you can command the radio to listen to the incoming

signal and scan in search of the tone being used. Two things must be remembered in

this regard:

 You must be sure that your repeater uses the same tone type (CTCSS vs. DCS).

 Some repeaters do not pass the CTCSS tone or DCS code; you may have to listen to

the station(s) transmitting on the repeater uplink (input) frequency in order to

allow Tone Search Scanning to work.

To scan for the tone in use:

1. Set the radio up for either CTCSS or DCS Decoder operation (see the previous

discussion). In the case of CTCSS, “T SQ” will appear on the display; in the case of

DCS, “DCS” will appear on the display.

2. Press the Microphone’s [P3] key momentarily to start scanning for the incoming

CTCSS or DCS tone/code.

3. When the radio detects the correct tone or code, it will halt on that tone/code, and

audio will be allowed to pass.

4. Press and hold in the [MHz(SET)] key for one second to lock in that tone/code and

exit to normal operation.

R.F. Says: If the Tone Scan feature does not detect a tone or code, it will continue to

scan indefinitely. When this happens, it may be that the other station is not sending

any tone. You can press the Microphone’s [P3] key to halt the scan at any time.

You may listen to the (muted) signal from the other station during Tone Scanning when

Set Mode Item “54 TS MUT” is set to “OFF.” See page ?? for details. You can also

change the Tone Search scanning speed, using Set Mode Item “55 TS SPD.” See page ??

for details.

Tone Scanning works either in the VFO or Memory modes.

EPCS (Enhanced Paging & Code Squelch) Operation

The FT-2900M includes an Enhanced CTCSS tone encoder/decoder and a dedicated

microprocessor providing paging and selective calling features. This allows you to place

a call to a specific station (Paging), and to receive calls of your choice directed only to

you (Code Squelch).

The paging and code squelch systems use two pairs of (alternately switched) CTCSS

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

tones which are stored in the pager memories. Basically, your receiver remains silent

until it receives the CTCSS tone pair that matches those stored in the Receiving Pager

Memory. The squelch then opens so the caller is heard, and the paging ringer

immediately sounds, if activated. When you close the PTT switch to transmit, the

CTCSS tone pair which is stored in the Transmitting Pager Memory will be

transmitted automatically.

On the paged radio, the squelch will close automatically after the incoming page ends.

Storing the CTCSS Tone Pairs for EPCS Operation

1. Press and hold in the [MHz(SET)] key for one second to enter the Set mode.

2. Rotate the DIAL knob to select “34 PAG.CDR” for the Receiving CTCSS Tone Pair

or “35 PAG.CDT” for the Transmitting CTCSS Tone Pair.

3. Press the [MHz(SET)] key momentarily to enable adjustment of this Set Mode

Item.

4. Rotate the DIAL knob to set the CTCSS Tone number which corresponds to the

first tone of the CTCSS Tone Pair.

5. Press the [REV(DW)] or [LOW(A/N)] key, then rotate the DIAL knob to set the

CTCSS Tone number which corresponds to the second tone of the CTCSS Tone

Pair.

6. Press and hold in the [MHz(SET)] key for one second to lock in that tone/code and

exit to normal operation.

R.F. Says: The FT-2900R does not recognize the order of the 1st tone and the 2nd tone.

In other words, for example, the FT-2900 considers both CTCSS pairs “10, 35” and “35,

10” to be identical.

Activating the Enhanced Paging & Code Squelch System

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “32 PAGER.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Menu item to

“ON.”

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

4. To disable the Enhanced Paging & Code Squelch, just repeat the above procedure,

rotating the DIAL knob to select “OFF” in step 2 above.

When the Enhanced Paging & Code Squelch feature is activated, the “P” notation will

appear at the 100 MHz digit of the frequency display.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Paging Answer Back

When you press the PTT switch to respond to a page call, the FT-2900 transmits the

Transmitting CTCSS Tone pair. This tone pair will open the Code Squelch of the calling

station. If you prefer, you can have the FT-2900M respond to page calls automatically

(“transpond”).

To enable this feature:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “33 PAG.ABK.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Menu item to

“ON.”

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

4. To disable the Paging Answer Back feature, just repeat the above procedure,

rotating the DIAL knob to select “OFF” in step 2 above.

CTCSS/DCS/EPCS Bell Operation

During CTCSS Decode, DCS, or EPCS operation, you may set up the FT-2900R such

that a ringing “bell” sound alerts you to the fact that a call is coming in. Here is the

procedure for activating the CTCSS/DCS/EPCS Bell:

1. Set the transceiver up for CTCSS Decode (“Tone Squelch”), DCS, or EPCS

operation, as described previously.

2. Adjust the operating frequency to the desired channel.

3. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “7 BELL.”

4. Rotate the DIAL knob to set the desired number of rings of the Bell. The available

choices are 1, 3, 5, or 8 rings, CNTNUE (continuous ringing), or OFF.

5. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

When you are called by a station whose transceiver is sending a CTCSS tone, DCS code,

or CTCSS code pair which matches that set into your Decoder, the Bell will ring in

accordance with this programming.

When the CTCSS/DCS/EPCS Bell is activated, the “Bell” icon will appear on the

display.

Split Tone Operation

The FT-2900R can be operated in a “Split Tone” configuration, to enable operation on

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

repeaters using a mix of both CTCSS and DCS control via the Set mode.

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “48 SPLIT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Menu item to

“ON” (to enable the Split Tone feature).

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

When the Split Tone feature is activated, you can see the following additional

parameters following the “RV TN” parameter (while selecting the tone mode by Set

mode item “49 SQL.TYP”):

T CODE: DCS Encode only (the “DCS” icon will blink during operation)

T DCS: Encodes a CTCSS Tone and Decodes a DCS code (the “T” icon will

blink and the “DCS” icon will appear during operation)

D TONE: Encodes a DCS code and Decodes a CTCSS Tone (the “T SQ” icon will

appear and “DCS” icons will blink during operation)

Select the desired operating mode from the selections shown above.

DTMF Autodialer Operation

Nine DTMF Autodialer memories are available on the FT-2900R. These DTMF

Autodialer memories can store up to 16 digits of a telephone number for repeater

autopatch or other use.

To load DTMF Autodialer memories, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “19 DT SET.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the DTMF

Autodialer memory channel number into which you wish store a telephone number

(“C0” to “C9”).

3. Press the [REV(DW)] key momentarily, then rotate the DIAL knob to select the

first digit of the telephone number you wish to store.

4. When you have selected the correct digit, press the [LOW(A/N)] key momentarily.

Now, rotate the DIAL knob to select the second of 16 available numbers in the

current DTMF Autodialer memory register.

5. Repeat this procedure for each digit in the telephone number. If you a mistake,

press the [REV(DW)] key to move back to the first digit, then re-enter the correct

number.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

6. When entry of all digits is complete, press the [MHz(SET)] key.

7. If you wish to store another DTMF string, repeat steps 2 through 6 above.

8. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

To transmit the memorized telephone number, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “17 DT A/M.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Set Mode Item

to “AUTO.”

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

4. In the Autodialer mode, which you just engaged, first press the PTT switch, then

press the microphone’s numeric key ([0] through [9]) corresponding to the DTMF

memory string you wish to send. Once the string begins, you may release the PTT

switch, as the transmitter will be held “on the air” until the DTMF string is

completed.

To disable the Autodialer function mode, select “MANUAL” in step 2 above.

The speed at which the DTMF digits are sent can be changed. Two speed levels are

available: Low (10 digits per second) and High (20 digits per second: default). To toggle

between Low and High speed, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “20 DT SPD.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired speed

(“50”: High speed or “100”: Low speed).

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

You can also set a longer delay between the time your transmitter is keyed and the first

DTMF digit is sent. To set the delay time, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “28 DT DLY.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired speed

(50/250/450/750/1000 ms).

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

exit to normal operation.

Memory Operation

Memory Storage

A wide array of memory resources are available on the FT-2900R. A total of 221

memories are available, and each may be appended with an alpha-numeric label of up

to six characters, for quick channel recognition.

The “basic” memory bank for the FT-2900R consists of 200 memories. Let’s learn the

simple procedure for storing and recalling a frequency, then we can move on to some of

the more advanced memory features.

To store a frequency into memory:

1. In the VFO mode, select the desired frequency, repeater shift, CTCSS/DCS tone,

and TX power level.

2. Press and hold in the [D/MR(MW)] key for one second. A memory number will

appear in the bottom right-hand corner of the display. If the channel number is

blinking, there currently is no data stored on that channel; if the channel number

is not blinking, that channel is currently “occupied” by other frequency data, and

you won’t want to use that channel unless the data is no longer of interest.

3. Within five seconds of pressing the [D/MR(MW)] key, use the DIAL knob to select

the desired memory into which you wish to store the frequency.

4. Press the [D/MR(MW)] key again, this time momentarily, to store the displayed

data into the selected memory channel slot. The memory label will disappear

(since you are still operating in the VFO mode).

5. To store other frequencies, repeat steps 1 through 4, remembering to set the

repeater shift, CTCSS/DCS tone, and TX power level, as appropriate.

R.F. Says: The above procedure will be used for virtually all memory storage

circumstances. If you need to program a frequency pair that uses a non-standard shift

(“odd split”), use the procedure described on page 23.

Memory Recall

Once you have stored the memory or memories desired, you must now switch from the

“VFO” mode to the “Memory Recall” mode, so you can operate on the just-stored

memory channels.

1. Press the [D/MR(MW)] key, repeatedly if necessary, until the “MR” icon and a

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

memory channel number appear on the display; this indicates that the “Memory

Recall” mode is now engaged.

2. When more than one memory has been stored, use the DIAL knob to select any of

the programmed memories for operation. Alternatively, the microphone’s [UP] or

[DWN] button may be used to step or scan through the available memories. When

using the microphone’s buttons, press the button momentarily to move one step up

or down; press and hold in the [UP] or [DWN] button for one second to begin

memory scanning.

Memory Recall from the Microphone’s Keypad:

While operating in the Memory Recall mode, the keypad of the MH-48A6J Microphone

may be used for direct recall of memory channels.

To do this, press the Channel Number you wish to recall, then press the [#] key. For

example, to recall Memory Channel “5,” press [5] Æ[*]. To recall Memory Channel

“118,” press [1] Æ [1] Æ [8].

You may also recall Programmable Memory Scan (PMS) channels (“L0/U0” through

“L9/U9”) using the following numbers: Programmable Memory channels #L0 = “200,”

U0 = “201,” L9 = “218,” and U9 = “219.”

Labeling Memories

You may wish to append an alpha-numeric “Tag” (label) to a memory or memories, to

aid in recollection of the channel’s use (such as club name, etc.). This is easily

accomplished using the Set (Menu) mode.

1. Recall the memory channel on which you wish to append a label.

2. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “30 NM SET.”

3. Press the [MHz(SET)] key. You will notice the first character location blinking,

indicating that you are now in the Alpha-Numeric (“A/N”) entry mode. Within the

A/N entry mode, rotate the DIAL knob to select characters; pressing the

[LOW(A/N)] key will move the character’s entry location to the right.

4. Rotate the DIAL knob to select the desired number, letter, or symbol, then press

the [LOW(A/N)] key to move the next character’s location. Move two slots if you

want to put in a space.

5. Repeat step 4, as necessary, to complete the name tag (up to six characters) for

your memory, then press the [MHz(SET)] key momentarily to save the A/N name

just entered.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

6. Press and hold in the [MHz(SET)] key for one second to exit to normal operation.

7. While operating in the Memory Recall mode, press and hold in the [LOW(A/N)] key

for one second to toggle the display between indication of the frequency and the

channel’s Alpha/Numeric label.

Memory Tuning

Once you have recalled a particular memory channel, you may easily tune off that

channel, as though you were in the VFO mode.

1. With the FT-2900R in the Memory Recall mode, select the desired memory

channel.

2. Press the [MHz(SET)] key momentarily. The “MR” indicator will blink and

disappear the Memory Channel Number; these indicates that the “Memory

Tuning” mode has been engaged.

3. Rotate the DIAL knob, or press the [UP] or [DWN] keys, to tune to a new frequency.

The synthesizer steps you have selected for “VFO” operation will be the steps used

during Memory Tuning.

4. If you wish to return to the original memory frequency, press the [D/MR(MW)] key

momentarily. The “MR” indicator will stop blinking and the Memory Channel

Number will be appears.

5. If you wish to store into memory a new frequency set during Memory Tuning, just

press and hold in the [D/MR(MW)] key for one second, then complete the normal

memory storage procedure. Be sure to select an open memory channel when doing

so.

Masking Memories

There may be situations where you want to “Mask” memories so they are not visible

during memory selection or scanning. For example, several memories used only in a

city you visit infrequently may be stored, then “Masked” until you visit that city, at

which time you can “Unmask” them for normal use. (except the Memory Channel “1,”

Priority Channel, and Home Channel).

1. With the FT-2900R in the Memory Recall mode, press and hold in the [D/MR(MW)]

key for one second, then rotate the DIAL knob to select the memory channel you

wish to delete.

2. Press the [LOW(A/N)] key momentarily. The display will revert to memory channel

“1.” The previously-selected memory will be deleted.

3. To Unmask the hidden memory, repeat the above procedure: press and hold in the

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

[D/MR(MW)] key for one second, rotate the DIAL to select the masked memory’s

number, then press the [LOW(A/N)] key to restore the memory channel’s data.

R.F. Says: Watch out! You can manually store data over a “Masked” memory, deleting

previous data, if you’re not careful. Use the “next available memory” technique (look for

the blinking memory channel number) storage technique to avoid over-writing a

masked memory.

Memory Bank Operation

The large number of memories available in the FT-2900R could be difficult to utilize

without some means of organizing them. Fortunately, the FT-2900R includes provision

for dividing the memories into as many as eight Memory Banks, so you can categorize

the memories in a manner convenient to you. You may enter and exit the “Memory

Bank” mode by a single press of the Microphone’s [#] key, as we shall see below.

Assigning Memories to a Memory Bank

1. Recall the memory channel to be assigned to a Memory Bank.

2. Press and hold in the [D/MR(MW)] key for one second, then rotate the DIAL knob

to select the Memory Bank number (“b1” ~ “b8”) you want as the Memory Bank for

this channel.

3. Press the [D/MR(MW)] key momentarily to copy the memory channel data into the

Memory Bank.

R.F. Says: 1) You may assign one memory channel into several Memory Banks.

2) The PMS memory channels (L0/U0 through L9/U9) may not be assigned to a

Memory Bank.

Memory Bank Recall

1. Press the [D/MR(MW)] key, if needed, to enter the Memory mode.

2. Press the Microphone’s [*] key to activate the “Memory Bank” mode. The Memory

Bank number will appear on the display.

3. Press the [#] key to increment the Memory Bank (“b1” through “b8”).

4. Rotate the DIAL knob to select memories, you will observe that you can only select

memory channels in the current memory bank. The small memory bank number

will appear at the above of the frequency display while operating within a Memory

Bank.

5. To change to another Memory Bank, press the [#] key to increase the Memory

Bank to next-highest bank.

6. To exit from Memory Bank operation, just press the Microphone’s [*] key. The

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Memory Channel number will appear on the display, indicating that you are now

in the “standard” Memory Recall mode, without utilization of the Memory Banks.

The memories stored in the various Banks will remain in those banks, however;

you do not need to store them again.

Removing Memories from a Memory Bank

1. Recall the memory channel to be removed from a Memory Bank.

2. Press and hold in the [D/MR(MW)] key for one second, then press the [A/N(LOW)]

key to remove the memory channel data from the Memory Bank.

Changing a Memory Bank’s Name

You may change the default Memory Bank Name which is indicates on the display

while selecting the Memory Bank to your desired name.

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “9 BNK NM.”

2. Press the [MHz(SET)] key momentarily, then rotate the DIAL knob to recall the

memory bank on which you wish to change a label.

3. Press the [A/N(LOW)] key to enable changing of the name tag.

4. Rotate the DIAL knob to select the first digit of the desired label.

5. Press the [A/N(LOW)] key to move to the next character.

6. If you make a mistake, press the [REV(DW)] key to back-space the cursor, then

re-enter the correct letter, number, or symbol.

7. Repeat steps 5 through 7 to program the remaining letters, numbers, or symbols of

the desired label. A total of six characters may be used in the creation of a label.

8. When you have programmed a name which is under 6 characters, press and hold

in the [MHz(SET)] key for one second to confirm the label and exit to normal

operation.

Home Channel Memory

A Convenient one-touch “Home” channel memory is available to simplify return to your

most-often-used frequency. This memory does not appear in the regular memory bank,

to simplify operation and speed recall of this important channel.

To recall the Home channel, just press the [D/MR(MW)] key, repeatedly if necessary,

until the “HM” icon appears on the display; this indicates that the Home Channel has

been recalled.

The factory default frequency for the Home channel is 146.520 MHz (USA version, EXP

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

version: 144.000 MHz). You can re-program the Home channel in a manner identical to

that used for the regular memories:

1. From the VFO mode, tune in the frequency you wish to store, and set all repeater

shifts and other data just the way you do for “normal” memory channel storage.

2. Press and hold in the [D/MR(MW)] key for one second, then press the [REV(DW)]

key to store the displayed data into the Home channel. The memory label will

disappear (since you are still operating in the VFO mode).

You may also append an alpha-numeric “Tag” (label) to a Home channel, as described

previously. be sure to recall the Home channel first, then enter the Menu (selection “30

NM SET” to program the label’s contents.

R.F. Says: From the Home channel, you may tune off (as in the Memory Tune mode)

without doing anything more than rotating the main DIAL knob. This automatically

shifts control to the VFO, making it a good idea to program in your area’s “Calling

Frequency” as the Home channel. Once contact is established, you may then tune off

the Calling Frequency to an open simplex frequency to carry on your QSO.

Memory-Only Mode

Once memory channel programming has been completed, you may place the radio in a

“Memory Only” mode, whereby VFO and Home Channel operation are impossible. This

may be particularly useful during public-service events where a number of operators

may be using the radio for first time, and ultimate simplicity of channel selection is

desired.

To place the radio into the Memory Only mode, turn it off. Now press and hold in the

[D/MR(MW)] key while turning the radio on. The VFO and Home Channel will now be

disabled.

To return to normal operation, repeat the above power-on procedure.

Scanning

The FT-2900R’s scanning capability provides the operator with many convenient

methods of rapid frequency navigation.

Basic Scanner Operation

Before activating the scanner, make sure that the Squelch is set to silence the

background noise when no signal is present. Scanning is not possible while the Squelch

is open (if noise or signals are being heard).

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Scanning may be started or stopped using the microphone’s [UP] or [DWN] button. The

following techniques are used for scanning:

 Pressing and holding in either the [UP] or [DWN] button for one second in the VFO

mode will cause upward or downward band scanning, respectively, to begin.

 Pressing and holding in either the [UP] or [DWN] button for one second in the

Memory mode will cause memory channel scanning toward a higher- or

lower-numbered memory channel, respectively.

 Scanning pauses when a signal opens the squelch, and the decimal point on the

display will blink. You can choose one of three scan-resume modes (described later).

 To halt the scan manually, the easiest way is to push the PTT switch on the

microphone momentarily (no transmission will occur while you are scanning). The

scan may also be halted manually by pressing the microphone’s [UP] or [DWN]

button, or the [D/MR(MW)] key.

R.F. Says: In the factory default setting, the scanner sweep all frequencies while the

VFO mode and all memory channels while the Memory mode. You may change the

sweep range of the VFO mode to ±1 MHz, ±2 MHz, or ±5 MHz, and sweeps only those

Memory Channels with the same “first” digit of the alpha/numeric tag or same “first”

and “second” digits of the alpha/numeric tag as the first channel on which scanning

started.

Scan-Resume Options

Three scan-resume modes are available on the FT-2900R:

 In the “BUSY” mode, the scanner will remain halted for as long as there is carrier

present on the channel; after the carrier drops at the end of the other station’s

transmission, scanning will resume.

 In the “HOLD” mode, the scanner will halt on a signal it encounters. It will not

restart automatically; you must manually re-initiate scanning if you wish to

resume.

 In the “3SEC/5SEC/10SEC” mode, the scanner will halt for selected resume time,

after which scanning will resume (whether or not the other station is still

transmitting).

The default scan-stop mode is “BUSY.” To change the scan-resume mode, use the

following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “41 RESUME.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

scan-resume mode.

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

Memory Skip Scanning

When you have some continuously-active channels in memories, you may wish to skip

them for scanning, but still have them available for manual selection.

To mask a memory to be skipped during scanning, use the following procedure:

1. Set the radio to Memory Recall mode by pressing the [D/MR(MW)] key repeatedly,

as necessary, until “MR” and a channel number appear on the right side of the

display.

2. Rotate the DIAL knob to select the Memory Channel to be skipped during

scanning.

3. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “47 SKIP.”

4. Press the [MHz(SET)] key, then rotate the DIAL knob so as to select “SKIP.” The

current Memory Channel will now be ignored during scanning. The “ONLY”

selection is used for “Preferential Memory Scan,” described in the next section.

5. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

A “SKIP” icon will appear when you recall the “skipped” memory channel manually.

To re-institute a channel into the scanning loop, select “OFF” in step 4 above, after first

recalling the currently-blocked channel (the “skipped” channel is accessible via manual

channel selection methods using the DIAL knob in the Memory mode, whether or not it

is locked out of the scanning loop).

Preferential Memory Scan

The FT-2900 also allows you to set up a “Preferential Scan List” of channels which you

can “flag” within the memory system. These channels are designated by a blinking

“SKIP” icon when you have selected them, one by one, for the Preferential Scan List.

When you initiate memory scanning, beginning on a channel with the Blinking “SKIP”

icon appended, only those channels bearing the Blinking “SKIP” icon will be scanned. If

you initiate scanning on a channel which does not have the Blinking “SKIP” icon

appended, you will scan all channels including those with the Blinking “SKIP” icon

appended.

Here is the procedure for setting up and using the Preferential Scan List:

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

1. Set the radio to the Memory Recall mode by pressing the [D/MR(MW)] key

repeatedly, if necessary.

2. Rotate the DIAL knob to select the Memory Channel which you wish to add to the

Preferential Scan List.

3. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “47 SKIP.”

4. Press the [MHz(SET)] key, then rotate the DIAL knob so as to select “ONLY.”

5. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

To initiate Preferential Memory Scanning:

1. Set the radio to the Memory Recall mode by pressing the [D/MR(MW)] key

repeatedly, if necessary.

2. Rotate the DIAL knob to select any memory channel which has a Blinking “SKIP”

icon appended to the channel number.

3. Press and hold either the microphone’s [UP] or [DWN] button for one second to

initiate Preferential Memory Scanning. Only the channels which have a Blinking

“SKIP” icon appended to the channel number will be scanned.

Memory Bank Link Scan

When the Memory Bank feature is engaged, the scanner sweeps only memory channels

in the current Memory Bank. However, if the Memory Bank Link Scan feature is

enabled, you may sweep the memory channels in several Memory Banks which you

have selected.

To enable the Memory Bank Link Scan feature:

1. Set the radio to the Memory mode by pressing the [D/MR(MW)] key, if necessary.

2. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “8 BNK.LNK.”

3. Press the [MHz(SET)] key momentarily, then rotate the DIAL knob to select the

first Memory Bank (“b1” ~ “b8”) you wish to sweep using Memory Bank Link Scan.

4. Press the [D/MR(MW)] key momentarily. A “SKIP” icon will appear at the above the

Memory Bank number, indicating this Memory Bank will now be swept during

Memory Bank Scan.

5. Repeat steps 3 and 4 above, to append the “SKIP” icon to any other Memory Banks

you wish to sweep.

6. Now, press and hold in the [MHz(SET)] key for one second to initiate the Memory

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Bank Link Scan.

7. To remove a Memory Bank from the Memory Bank Link Scan, repeat steps 2 - 4

above, to delete the “SKIP” icon from the Memory Bank number indication.

Programmable Band-Scan Limits

Besides band and memory scanning, this transceiver can be set to tune or scan only the

frequencies between user-defined lower and upper limits. For example, you may wish

to limit tuning/scanning to 144.3 - 148.0 MHz, to avoid encroachment on the SSB/CW

sub-band between 144.0 and 144.3 MHz

These scanning limits are stored in special “Sub-Band Limit Memories,” labeled L0/U0

through L9/U9, with “L” and “U” designations representing the Lower and Upper

limits, respectively.

To utilize this feature, use the following steps:

1. Store the lower edge of the desired scanning/tuning range in memory “L0” and the

upper edge in memory “U0” (or, alternatively, in memories “L1/U1” through

“L9/U9”).

2. With any of these memories recalled, press the [MHz(SET)] key momentarily to

activate the Programmable Band-Scan Limits. The “PMS” icon will appear. Tuning

and scanning will now be limited within the just-programmed range.

To cancel the Sub-Band Limits and return to normal memory operation, press the

[D/MR(MW)] key momentarily.

Priority Channel Scanning (Dual Watch)

The FT-2900R’s scanning features include a two-channel scanning capability which

allows you to operate on a VFO, Memory channel, or Home channel, while periodically

checking a user-defined Memory Channel for activity. If a station is received on the

Memory Channel which is strong enough to open the Squelch, the scanner will pause

on that station in accordance with the Scan-Resume mode set via Menu mode “41

RESUME.” See page 34.

Here is the procedure for activating Priority Channel Dual Watch operation:

1. Set the radio to the Memory Recall mode by pressing the [D/MR(MW)] key

repeatedly, if necessary.

2. Press and hold in the [D/MR(MW)] key for one second (the Memory Channel

number will blink), then select the memory channel you wish to be the “Priority”

channel.

3. Press the [%] key momentarily. The “PRI” icon will appear to the upper right

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

corner on the display; indicating it is the Priority channel.

4. Now set the FT-2900 for operation on another memory channel, Home channel, or

on a VFO frequency.

5. Press and hold in the [REV(DW)] key for one second. The display will remain on

the VFO, selected memory channel, or Home channel, but every five seconds the

FT-2900 will check the Priority Channel for activity.

6. To cancel Dual Watch operation, press the [D/MR(MW)] key momentarily.

Priority Revert Mode

During Priority channel operation (Dual Watch), a special feature is available which

will allow you to move to the Priority Channel instantly, without waiting for activity to

appear on the Priority Channel.

When this feature is enabled, and priority monitoring is engaged, just press the

microphone’s PTT switch. Operation will instantly revert to the Priority Channel.

To enable Priority Revert operation:

1. Press and hold the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “44 RVRT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select “ON.”

3. Press and hold the [MHz(SET)] key for one second to save the new setting and exit

to normal operation.

To disable Priority Revert operation, select “OFF” in step 2 above.

Weather Alert Scan

This feature allows you to check the Weather Broadcast Memory Channels for the

presence of the NOAA Alert Tone while operating using VFO scan or Memory channel

scan.

When the Weather Alert Scan feature is engaged, the FT-2900R will check the Weather

Broadcast Memory Channels for activity every five seconds while scanning. If you

watch the display carefully, you’ll observe the scanner periodically shifting to the

Weather Broadcast bank, scanning the Weather channels quickly in search of the Alert

Tone, after which regular scanning will resume for another five seconds.

To enable the Weather Alert Scan feature:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “57 WX ALT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Menu item to

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

“ON.”

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

4. To disable the Weather Alert Scan feature, select “OFF” in step 2 above.

You can change the Weather Alert Tone volume level to maximum regardless the VOL

knob setting, using Set Mode Item “58 WX VOL.” See page 57 for details.

R.F. Says: 1) When the Weather Alert Scan feature is engaged, the Scan-Resume mode

is fixed to “HOLD.”

2) If you are just scanning the Weather Broadcast Channels, the FT-2900R’s receiver

will remain muted indefinitely unless the Alert Tone is received. This yields a long

period of monitoring time, as no power will be consumed via audio output while

scanning for the Alert Tone is in progress.

Band Edge Beeper

The FT-2900R will automatically “beep” when the receiver’s band edge is encountered

during scanning (either in standard VFO scanning or during PMS operation). You may

additionally enable this feature (band edge beeper) when the frequency reaches the

band edge while selecting the VFO frequency manually, using the DIAL knob.

The procedure for enabling the Band-Edge Beeper (during manual tuning) is:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “21 EDG.BEP.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to set this Menu item to

ON.”

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

Smart Search Operation

The Smart Search feature allows you to load frequencies automatically according to

where activity is encountered by your radio. When Smart Search is engaged, the

transceiver will search above and below your current frequency, storing active

frequencies as it goes (without stopping on them even momentarily); these frequencies

are stored into a special Smart Search memory band, consisting of 31 memories (15

above the current frequency, 15 below the current frequency, plus the current frequency

itself).

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Two basic operating modes for Smart Search are available:

SINGLE: In this mode, the transceiver will sweep the current band once in each

direction starting on the current frequency. All channels where activity is present will

be loaded into the Smart Search memories; whether or not all 31 memories are filled,

the search will stop after one sweep in each direction.

CONT: In this mode, the transceiver will make one pass in each direction as with

One-Shot searching; if all 31 channels are not filled after the first sweep, however, the

radio will continue sweeping until they are all filled.

Setting the Smart Search Mode

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “45 S SRCH.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired Smart

Search mode (see above).

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

Storing Smart Search Memories

1. Set the radio to the VFO mode. Be sure that you have the Squelch adjusted

properly (so that band noise is quieted).

2. Press the Microphone’s [P2] key to enter the Smart Search mode. The “S SRCH”

notation is appeared on the display. for 2 seconds.

3. Press the Microphone’s [A] key to begin Smart Search scanning.

4. As active channels are detected, they will automatically be stored into the Smart

Search memory bank without causing the sweep to halt.

5. Depending on the mode you set for Smart Search operation (“SINGLE” or “CONT”),

the Smart Search scan will eventually terminate, and the LCD will revert to

Smart Search Memory Channel “C.”

6. To recall the Smart Search memories, just rotate the DIAL knob to choose from

among the Smart Search memories.

7. To return to normal operation, press the [D/MR(MW)] key.

R.F. Says: Smart Search is a great tool when visiting a city for the first time. You don’t

need to spend hours looking up repeater frequencies from a reference guidebook: Just

ask your FT-2900R where the action is!

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Internet Connection Feature

The FT-2900R can be used to access a “node” (repeater or base station) which is tied

into the Vertex Standard WIRESTM (Wide-Coverage Internet Repeater Enhancement

System) network. Details may be found at the WIRES-II Web site:

http://www.vxstd.com/en/wiresinfo-en/. This feature may also be used to access other

systems, as described below.

SRG (“Sister Radio Group”) mode

1. Press the [%] key momentarily to activate the Internet Connection feature. The

“Int” notation will appear at the right of the frequency.

2. Rotate the DIAL knob while pressing the [%] key to select the access number

(DTMF “0” ~ “9,” “A,” “B,” “C,” “D,” “E(*),” “F(#))” corresponding to the WIRES・

node to which you wish to establish an Internet link (ask the node or repeater

owner/operator if you don’t know the access number in the network). Now press

the PTT switch to exit from the selection mode.

3. With the Internet Connection feature activated (as in step 1 above), the FT-2900M

will generate a brief (0.1 second) DTMF tone according to your selection in step 2.

This DTMF tone is sent at the beginning of every transmission to establish or

maintain the link to the local WIRES・node operating in the SRG mode.

4. To disable the Internet Connection feature, press the [%] key momentarily (the

“Int” notation will disappear from the display).

R.F. Says: If other users report that you always have a DTMF “beep” at the beginning

of each transmission, and you are not operating in conjunction with Internet access,

disable this function via step (4) above.

FRG (“Friendly Radio Group”) mode

You may access other Internet Link Systems (including WIRESTM in the “FRG” mode)

that use a DTMF string for access.

Programming the FRG code

Load the DTMF tones which you wish to use for Internet-link access into a Internet

Memory register. For purposes of this example, we will use “#(F)1101D” as the access

code (the “#” key is denoted by the letter “F”).

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “25 INT.SET.”

2. Press the [0(SET)] key, then rotate the DIAL knob to select the Internet Memory

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

3. Press the [LOW(A/N)] key momentarily. The first digit will blink.

4. Rotate the DIAL knob to select “F” (representing DTMF “#” the first digit of the

DTMF string).

5. Press the [LOW(A/N)] key momentarily to accept the first digit and move to the

second digit of the DTMF string.

6. Repeat the previous steps until you have completed the access code (“#(F)1101D”).

7. If you attach an alpha/numeric name “Tag” to the Internet Memory, proceed to the

next step; otherwise press and hold in the [MHz(SET)] key for one second to save

the setting.

8. Press the [MHz(SET)] key twice to enable programming of the name tag (The

Internet Memory register number will blink).

9. Press the [LOW(A/N)] key momentarily. The first digit will blink.

10. Rotate the DIAL knob to select the first digit of the desired label.

11. Press the [LOW(A/N)] key to move to the next character.

12. If you make a mistake, press the [REV(DW)] key to back-space the cursor, then

re-enter the correct letter, number, or symbol.

13. Repeat steps 10 and 11 to program the remaining letters, numbers, or symbols of

the desired label. A total of six characters may be used in the creation of a label.

14. When you have programmed a label which is under 6 characters, press and hold in

the [MHz(SET)] key for one second to confirm the label.

15. Repeat steps 1 through 14 to store other access codes, if so desired.

16. Press the PTT switch to save the setting and exit to normal operation.

Operation (Accessing an FRG Node)

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “23 INT MD.”

2. Press the [0(SET)] key, then rotate the DIAL knob to set this Set Mode Item to

“FRG” (thus activating the “Other Internet Link System” mode).

3. Press and hold in the [MHz(SET)] key for one second to save the new settings.

4. Press the [%] key momentarily to activate the Internet Connection feature. The

“Int” notation will appear in the upper right corner of the display.

5. Rotate the DIAL knob while pressing the [%] key to select the Internet Memory

which you wish to establish an Internet link, then press the PTT switch

momentarily to lock in the selected access number.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

6. Once the Internet Connection feature is activated per step 4 above, you may now

press the [%] key, while you are transmitting, to send out the selected DTMF

string (to establish the link to the desired Internet-link mode).

7. To return to the WIRESTM mode, repeat steps 1 - 3 above, selecting “SRG” in step

CW Training Feature

The FT-2900r provides a CW Training feature, which sends random Morse Code via the

sidetone (heard in the speaker), so you can improve your CW proficiency.

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “12 CWTRNG.”

2. Press the [MHz(SET)] key momentarily to enable adjustment of this Set Mode

Item.

3. Press the [LOW(A/N)] key to select the Training mode (displayed in fine print at

the upper edge of the LCD):

1A: Sends five Alphabet characters only

A: Sends Alphabet characters only (Repeatedly)

1n: Sends five Numeric characters only

n: Sends Numeric characters only (Repeatedly)

1An: Sends five Alphabet, Numeric, “?,” and “/” characters (Mixed)

An: Send Alphabet, Numeric, “?,” and “/” characters (Mixed, Continuously in

group of five)

4. Rotate the DIAL knob to select the Morse speed. You may select the units of the

code speed between “WPM (Words per minute)” and “CPM: characters per minute)”

by pressing the [D/MR(MW)] key.

5. Press the [REV(DW)] key to begin generation of the code characters (CW sidetone

only, the radio does not transmit); the transmitted characters will appear on the

display. If one of the “1” modes is selected in step 4 above, press the [F/W] key to

send another code group.

6. To disable the CW Training feature, press the [MHz(SET)] key momentarily.

7. Press and hold in the [MHz(SET)] key for one second to exit to normal operation.

R.F. Says: The “WPM” selection is based on the international “PARIS” standard, which

stipulates five characters per word.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Packet Operation

The FT-2900R may be used for 1200 bps Packet operation, using most all

commonly-available Terminal Node Controllers (TNCs). Connections between the

transceiver and the TNC are accomplished via the front panel Microphone connector

and rear panel External Speaker jack, per the diagram below.

The audio level from the receiver to the TNC may be adjusted by using the VOL knob,

as with voice operation. The input level to the FT-2900 from the TNC may be adjusted

via Set Mode Item “27 MCGAIN;” see page ?? for details.

Be sure to turn the transceiver and TNC off before connecting the cables, so as to

prevent voltage spikes from possibly damaging your transceiver.

Remember to readjust the default microphone input level to “LVL 5” (Set Mode Item

“27 MCGAIN”) when Packet operation is finished.

Miscellaneous Settings

Password

The FT-2900R provides a password feature which can minimize the chance that your

transceiver could be used by an unauthorized party.

When the password feature is activated, the radio will ask for the four digit password

to be entered when the radio is first turned on. You must enter the four digit password

from the Microphone’s keypad. If the wrong password is entered, the microprocessor

will shut down the radio automatically.

To enter the password and activating this feature, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “40 PSWD.”

2. Press the [MHz(SET)] key momentarily to enable adjustment of this Set Mode

Item.

3. Press the [LOW(A/N)] key momentarily to display any previously-stored password.

4. Rotate the DIAL knob to select the first digit of the desired number/letter (0-9, A, B,

C, D, E (substitute for “*”), and F (substitute for “#”).

5. Press the [LOW(A/N)] key to move to the next digit.

6. Repeat steps 5 and 6 to program the remaining numbers/letters of the desired

password.

7. If you make a mistake, press the [REV(DW)] key to move back to the previous digit,

then re-select the correct number/letter.

8. When you have finished entering the password, press and hold in the [MHz(SET)]

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

key for one second to save the new setting and exit to normal operation.

9. If you wish to disable the Password feature, repeat steps 1 - 3 above, now rotate

the DIAL knob to select “OFF,” then press and hold in the [MHz(SET)] key for one

second.

R.F. Says: 1) We recommend that you to write down the password number, and keep it

in a safe place you can easily find if you forget your password.

2) If you forget the password number, you may turn on the transceiver by performing

the “Microprocessor Resetting” procedure (see page 85). However, the FT-2900 will

clear the password, as well as all memories, and will restore all other settings to

factory defaults.

Time-Out Timer (TOT)

The “Time-Out Timer” (TOT) feature is designed to force the transceiver into the

“Receive” mode after a preset time period of continuous transmission (the default is 6

minutes). This feature prevents your transceiver from transmitting a “dead carrier” for

a long period of time in the event that the microphone PTT switch is accidentally

locked in the “TX” condition.

The Time-Out Timer’s “switch-to-receive” time may be adjusted, in one minute

increments, for any period between 1 and 60 minutes.

To change the default (6 minutes) time setting:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “53 TOT.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired interval

(1/3/5/10 minutes), or OFF.

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

Automatic Power-Off (APO)

The “Automatic Power-Off” (APO) feature will turn the radio completely off after a

user-defined period of PTT or key/button inactivity. If you do not press any front panel

keys or buttons, rotate the DIAL knob, use the microphone’s keys and buttons, or

transmit, and so long as the transceiver is not scanning or engaged in priority

monitoring, the radio will shut itself off after the specified time period. The available

selections for the time before power-off are 0.5/1/3/5/8 hours, as well as APO Off. This

feature is useful in minimizing battery drain in a mobile installation if you forget to

turn the transceiver off when you leave your vehicle.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

To activate the APO feature:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “1 APO.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the desired

“switch-off” time or OFF.

3. Press and hold in the [MHz(SET)] key for one second to save the new setting and

exit to normal operation.

Busy Channel Lock-Out (BCLO)

The BCLO feature prevents the radio’s transmitter from being activated if a signal

strong enough to break through the “noise” squelch is present. On a frequency where

stations using different CTCSS or DCS codes may be active, BCLO prevents you from

disrupting their communications accidentally (because your radio may be muted by its

own Tone Decoder). The default setting for the BCLO is OFF, and here is how to change

that setting:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “5 BCLO.”

2. Press the [MHz(SET)] key momentarily to enable adjustment of this Set Mode

Item.

3. Rotate the DIAL knob to set this Set Mode Item to “ON” (thus activating the

BCLO feature).

4. When you have made your selection, press and hold in the [MHz(SET)] key for one

second to save the new setting and exit to normal operation.

Remember that BCLO is controlled by the Noise Squelch; if you have DCS or TSQ

engaged, BCLO will inhibit transmission if a station is on frequency but not

transmitting the proper tone; BCLO will thus prevent you from interfering with the

other station’s transmission.

Programming the Key Assignments

Default FT-2900R key functions have been assigned to the Microphone’s

[P1]/[P2]/[P3]/[P4] buttons at the factory. These may be changed by the user, if you

wish to assign quick access to another function.

To change the assignments for the programmable keys:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select the Menu Item to be configured (“36 PRG P1,” “37 PRG P2,” “38 PRG P3,” or

“39 PRG P4”).

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

2. Press the [MHz(SET)] key, then rotate the DIAL knob to select the function you

wish to assign to the button you selected in the previous step. The available

choices are:

ARTS: Engages the ARTS・operation.

SQLOFF: Opens the Squelch to allow un-muted reception.

WX CH: Switches operation to the Weather channels bank.

S SRCH: Engages the Smart Search operation.

C SRCH: Engages the Tone Search Scanning feature.

SCAN: Engages the Scan operation

T CALL: Activates 1750 Hz Tone Burst

3. Press the [MHz(SET)] key momentarily to save the new setting, then rotate the

DIAL knob to select another programmable button to modify, if desired, and repeat

the above steps.

4. Press and hold in the [MHz(SET)] key for one second to exit to normal operation.

You may assign the Set Mode item to the Microphone’s [P1]/[P2]/[P3]/[P4] buttons, as

well, to do this:

1. Press and hold in the [MHz(SET)] key for one second to enter the Set mode.

2. Rotate the DIAL knob to select the Set Mode Item which you wish to assign to the

key as a Menu short-cut.

3. Press and hold in the Microphone’s [P1], [P2], [P3], or [P4] button for one second

to assign the Set Mode Item to the [P1], [P2], [P3], or [P4] button.

4. Now you can recall this preferred Set Mode Item by simply pressing the

Microphone’s button momentarily.

FM Bandwidth & TX Deviation Level

You can reduce the receiver bandwidth and microphone deviation level when operating

on tightly-clustered frequencies (channel spacing of 12.5 or 15 kHz). This will reduce

the transmitter deviation, thus minimizing interference to other users.

To configure for the narrower bandwidth, use the following procedure:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “59 W/N DV.”

2. Press the [MHz(SET)] key, then rotate the DIAL knob to change the display to

“NARROW (±2.5 kHz Deviation, 6 kHz Bandwidth).”

3. Press and hold the [MHz(SET)] key for one second to save the new setting and exit

to normal operation.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

4. To return to wide deviation, repeat the above procedure, selecting “WIDE (±5 kHz

Deviation, 15 kHz Bandwidth)” in step 2 above.

DCS Code Inversion

The DCS system was first introduced in the commercial LMR (Land Mobile Radio)

service, where it is now in widespread use. DCS is sometime referred to by its different

proprietary names, such as DPL® (Digital Private Line®, a registered trademark of

Motorola, Inc.).

DCS uses a codeword consisting of a 23-bit frame, transmitted (subaudible) at a data

rate of 134.4 bps (bit/sec). Occasionally, signal inversion can result in the complement

of a code to be sent or received. This prevents the receiver’s squelch from opening with

DCS enabled, as the decoded bit sequence would not match that selected for operation.

Typical situations that might cause inversion to occur are:

 Connection of an external receiver preamplifier.

 Operating through a repeater.

 Connection of an external linear amplifier.

Note that code inversion does not mean that any of the above listed equipment is

defective!

In certain amplifier configurations, the output signal (phase) is inverted from the input.

Small signal or power amplifiers having an odd number (1, 3, 5, etc.) of amplification

stages may result in inversion of a transmitted or received DCS code.

While under most circumstances this should not occur (amplifier designs and industry

standards take this into account), if you find that your receiver squelch does not open

when both you and the other station are using a common DCS code, you or the other

station (but not both) can try the following:

1. Press and hold in the [MHz(SET)] key for one second, then rotate the DIAL knob to

select “15 DCS RV.”

2. Press the [MHz(SET)] key momentarily, then rotate the DIAL knob to set this Set

Mode Item to “ENABLE” (thus inverting the DCS Code).

3. When you have made your selection, press and hold the [MHz(SET)] key for one

second to save the new setting and exit to normal operation.

4. Remember to restore the default setting to “DISABLE” when done.

Reset Procedure

In some instances of erratic or unpredictable operation, the cause may be corruption of

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

data in the microprocessor (due to static electricity, etc.). If this happens, resetting of

the microprocessor may restore normal operation. Note that all memories will be

erased if you do a complete microprocessor reset, as described below.

Microprocessor Resetting

To clear all memories and other settings to factory defaults:

1. Turn the radio off.

2. Press and hold in the [REV(DW)], [LOW(A/N)], and [D/MR(MW)] keys while

turning the radio on. The “ALL RESET PUSH D/MR KEY” notation will scroll on

the display.

3. Press the [D/MR(MW)] key momentarily to reset all settings to their factory

defaults (press any other key to cancel the Reset procedure).

Set Mode Resetting

To reset the Set (Menu) mode settings to their factory defaults, while leaving other

settings unchanged:

1. Turn the radio off.

2. Press and hold in the [LOW(A/N)] and [D/MR(MW)] keys while turning the radio

on. The “SET MODE RESET PUSH D/MR KEY” notation will scroll on the display.

3. Press the [D/MR(MW)] key momentarily to reset the Set (Menu) mode settings to

their factory defaults (press any other key to cancel the Reset procedure).

Cloning

The FT-2900R includes a convenient “Clone” feature, which allows the memory and

configuration data from one transceiver to be transferred to another FT-2900R. This

can be particularly useful when configuring a number of transceivers for a public

service operation. Here is the procedure for Cloning one radio’s data to another:

1. Turn both radios off.

2. Connect the user-constructed cloning cable between the MIC jacks of the two

radios.

3. Press and hold in the [LOW(A/N)] key while turning the radios on. Do this for both

radios (the order of switch-on does not matter). “CLONE” will appear on the

displays of both radios when the Clone mode is successfully activated in this step.

4. On the Destination radio, press the [D/MR(MW)] key (“--WAITE--”will appear on

the LCD).

5. Press the [MHz(SET)] key on the Source radio; “---TX----” will appear on the Source

radio, and the data from this radio will be transferred to the other radio.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

6. If there is a problem during the cloning process, “ERROR” will be displayed. Check

your cable connections and battery voltage, and try again.

7. If the data transfer is successful, “CLONE” will appear on both displays.

8. Press any key to exit to normal operation.

9. Turn both radios off and disconnect the cloning cable.

“Set” (Menu) Mode

The FT-2900R Set (Menu) mode, already described in parts of many previous chapters,

is easy to activate and set. It may be used for configuration of a wide variety of

transceiver parameters, some of which have not been detailed previously. Use the

following procedure to activate the Set (Menu) mode:

1. Press and hold in the [MHz(SET)] key for one second to enter the Set mode.

2. Rotate the DIAL knob to select the Menu Item to be adjusted.

3. Press the [MHz(SET)] key momentarily to enable adjustment of the selected Menu

item, then rotate the DIAL knob to perform the actual adjustment.

4. After completing your selection and adjustment, press and hold in the [MHz(SET)]

key for one second to exit the Set mode and exit to normal operation.

Menu Selection Details

1 APO

Function: Enables/Disables the Automatic Power Off feature.

Available Values: 30MIN / 1HOUR / 3HOUR / 5HOUR / 8HOUR / OFF

Default: OFF

2 AR BEP

Function: Selects the Beep option during ARTS operation.

Available Values: IN RNG / ALWAYS / OFF

Default: IN RNG

IN RNG: Beeps sound only when the radio first detects that you are within range.

ALWAYS: Beeps sound every time a polling transmission is received from the other

station (every 15 or 25 seconds when in range).

OFF: No alert beeps sound.

3 AR INT

Function: Selects the Polling Interval during ARTS operation.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Available Values: 25SEC / 15SEC

Default: 25SEC

4 ARS

Function: Activates/Deactivates the Automatic Repeater Shift feature.

Available Values: ON / OFF

Default: ON

5 BCLO

Function: Enables/Disables the Busy Channel Lock-Out feature.

Available Values: ON / OFF

Default: OFF

6 BEEP

Function: Enables/Disables the key beeper.

Available Values: KY+SCN / KEY / OFF

Default: KY+SCN

KY+SC: The beeper sounds when you press any key, or when the scanner stops.

KEY: The beeper sounds when you press any key.

OFF: Beeper is disabled.

7 BELL

Function: Selects the CTCSS/DCS Bell Ringer repetitions.

Available Values: 1 / 3 / 5 / 8 / CNTNUE (Continuous ringing) / OFF

Default: OFF

8 BNK.LNK

Function: Select the Memory Bank for the Memory Bank Link Scan.

See page ** for details.

9 BNK NM

Function: Programming an Alpha/Numeric label for a Memory Bank.

See page ** for details.

10 CLK.SFT

Function: Shifting of the CPU clock frequency.

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Available Values: ON / OFF

Default: OFF

This function is only used to move a spurious response “Birdie” should it fall on a

desired frequency.

11 CW ID

Function: Enables/Disables the CW identifier during ARTS Operation.

Available Values: ON / OFF

Default: OFF

12 CWTRNG

Function: Enables/Disables the CW Training feature and selects the sending speed of

the morse Code.

Available Values: 4 / 5 / 6 / 7 / 8 / 9 / 10 / 11 / 12 / 13 / 15 / 17 / 20 / 24 / 30 / 40 WPM /

OFF or 20 / 25 / 30 / 35 / 40 / 45 / 50 / 55 / 60 / 65 / 75 / 85 / 100 / 120 / 150 / 200 CPM

Default: OFF

Note: To switch units between “WPM” and “CPM,” just press the [MHz(SET)] key.

13 DC VLT

Function: Indicates the DC Supply Voltage.

14 DCS CD

Function: Setting of the DCS code.

Available Values: 104 standard DCS codes

Default: 023

15 DCS RV

Function: Enables/Disables “Inverted” DCS code decoding.

Available Values: ENABLE / DISABL

Default: DISABL

16 DIMMER

Function: Setting of the front panel display7s illumination level.

Available Values: 0 (OFF) - 10

Default: 5

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

17 DT A/M

Function: Enables/Disables the DTMF Autodialer feature.

Available Values: MANUAL / AUTO

Default: MANUAL

18 DT DLY

Function: Setting of the DTMF Autodialer 痴 TX Delay Time.

Available Values: 50 / 250 / 450 / 750 / 1000 ms

Default: 450 ms

19 DT SET

Function: Loading of the DTMF Autodialer Memories.

See page ** for details.

20 DT SPD

Function: Setting of the DTMF Autodialer Sending Speed.

Available Values: 50 (high speed) / 100 (low speed) ms

Default: 50 ms

21 EDG.BEP

Function: Enables/disable the Band-edge beeper while scanning.

Available Values: ON / OFF

Default: ON

22 INT CD

Function: Selects the Access Number (DTMF digit) for WIRES operation.

Available Values: DTMF 0 - DTMF 9 / DTMF A - DTMF F

Default: DTMF 1

23 INT MD

Function: Selects the Internet Link Connection mode.

Available Values: SRG / FRG

Default: SRG

24 INT.A/M

Function: Enables/Disables DTMF Autodialer feature while operating on the Internet

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Connection feature.

Available Values: MANUAL / AUTO

Default: MANUAL

25 INT.SET

Function: Selects the memory register for an Access Number (DTMF code) for

non-WIRES Internet Link System access.

Available Values: F0 - F9

Default: F1

26 LOCK

Function: Selects the Control Locking Lockout combination.

Available Values: KEY / DIAL / K+D / PTT / K+P / D+P / ALL / OFF

Default: OFF

Note: “K” = “Key;” “D” = “Dial;” and “P” = “PTT.”

27 MCGAIN

Function: Adjust the microphone gain level.

Available Values: 1 - 9

Default: 5

28 MEM.SCN

Function: Selects the Memory Scan mode.

Available Values: TAG1 / TAG2 / ALL CH

Default: ALL CH

ALL CH: The scanner sweeps all Memory channels.

TAG1: The scanner sweeps only those Memory channels with the same “First” digit of

the alpha/numeric tag as the first channel on which scanning started.

TAG2: The scanner sweeps only those Memory channels with the same “First” and

“Second” digits of the alpha/numeric tag as the first channel on which scanning started.

29 MW MD

Function: Selects the method of selection of channels for Memory Storage.

Available Values: NEXT / LOWER

Default: NEXT

NEXT: Stores the data into the memory channel which is next-highest from the

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

last-stored memory channel.

LOWER: Stores the data into the lowest-available “Free” channel.

30 NM SET

Function: Programming an Alpha/Numeric label for a Memory Channel.

See page ** for details.

31 OPN.MSG

Function: Selects the Opening Message that appears when the radio is powered on.

Available Values: DC / MSG / OFF

Default: DC

DC: DC supply voltage

MSG: Set by user. See below.

OFF: No Opening Message

Here’s how to program the Opening Message:

1. Set this Set Mode Item to “MSG.”

2. Press the [LOW(A/N)] key momentarily to enable programming of the opening

message. You will notice the first character entry’s location blinking.

3. Rotate the DIAL knob to select the first letter/number of the message, then press

the [LOW(A/N)] key momentarily to save the first letter/number and move on to

the next character.

4. Repeat the previous step as necessary to complete the message (up to six

characters).

5. If you make a mistake, press the [DW(REV)] key to back-space the cursor; now

re-enter the correct letter/number.

6. When you have entered the desired opening message, press the [MHz(SET)] key

momentarily to confirm the message, then press and hold in the [MHz(SET)] key

for one second to save the settings and exit to normal operation.

32 PAGER

Function: Enables/Disables the Enhanced CTCSS Paging & Code Squelch function.

Available Values: ON / OFF

Default: OFF

33 PAG.ABK

Function: Enables/Disables the Answer Back function of the Enhanced CTCSS Paging

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

& Code Squelch function.

Available Values: ON / OFF

Default: OFF

34 PAG.CDR

Function: Setting the Receiver Pager Code for the Enhanced CTCSS Paging & Code

Squelch function.

See page ** for details.

35 PAG.CDT

Function: Setting the Transmitting Pager Code for the Enhanced CTCSS Paging &

Code Squelch function.

See page ** for details.

36 PRG P1

Function: Programming the function assigned to Microphone’s [P1] key.

Available Values: ARTS / SQL OFF / WX CH / S SRCH / C SRCH / SCAN / T CALL or

all Set mode items (except Set mode item #36 through 39).

Default: Set mode item #13 DC VLT

37 PRG P2

Function: Programming the function assigned to Microphone’s [P2] key.

Available Values: ARTS / SQL OFF / WX CH / S SRCH / C SRCH / SCAN / T CALL or

all Set mode items (except Set mode item #36 through 39).

Default: Set mode item #16 DIMMER

38 PRG P3

Function: Programming the function assigned to Microphone’s [P3] key.

Available Values: ARTS / SQL OFF / WX CH / S SRCH / C SRCH / SCAN / T CALL or

all Set mode items (except Set mode item #36 through 39).

Default: Set mode item #27 MCGAIN

39 PRG P4

Function: Programming the function assigned to Microphone’s [P4] key.

Available Values: ARTS / SQL OFF / WX CH / S SRCH / C SRCH / SCAN / T CALL or

all Set mode items (except Set mode item #36 through 39).

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Default: Set mode item #47 SKIP

40 PSWD

Function: Programs and activates the Password feature.

Available Values: ON / OFF

Default: OFF

41 RESUME

Function: Selects the Scan Resume mode.

Available Values: BUSY / HOLD / 3SEC / 5SEC / 10SEC

Default: BUSY

BUSY: The scanner will hold until the signal disappears, then will resume when the

carrier drops.

HOLD: The scanner will stop when a signal is received, and will not restart.

3SEC/5SEC/10SEC: The scanner will hold for the selected resume time, then resume

whether or not the other station is still transmitting.

42 RF SQL

Function: Adjusts the RF Squelch threshold level.

Available Values: S1 - S9 / OFF

Default: OFF

43 RPT

Function: Sets the Repeater Shift direction.

Available Values: –RPT / + RPT / SIMP

Default: SIMP

44 RVRT

Function: Enables/disables the “Priority Channel Revert” feature.

Available Values: ON / OFF

Default: OFF

45 S SRCH

Function: Selects the Smart Search Sweep mode.

Available Values: SINGLE / CNTNUE

Default: SINGLE

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

SINGLE: The transceiver sweeps the current band once in each direction, starting on

the current frequency. All channels where activity is present (up to 15 in each

direction) are loaded into the Smart Search memories. Whether or not all 31 memories

are filled, the search stops after one sweep in each direction.

CNTNUE: The transceiver makes a sweep in each direction as with the “SINGLE”

mode, but if all 31 channels are not filled after the first sweep, the radio continues

sweeping until they are all filled.

46 SHIFT

Function: Sets the magnitude of the Repeater Shift.

Available Values: 0.00 - 99.95 MHz

Default: 0.60 MHz

47 SKIP

Function: Selects the Memory Scan mode.

Available Values: SKIP / ONLY / OFF

Default: OFF

SKIP: The scanner will “Skip” the flagged channels during scanning.

ONLY: The scanner will only scan channels that are flagged (Preferential Scan List).

OFF: All memory channels will be scanned (the “Flag” will be ignored).

48 SPLIT

Function: Enables/Disables the split CTCSS/DCS coding.

Available Values: ON / OFF

Default: OFF

When this Set Mode Item is set to “ON,” you will see the following additional

parameters after the “RV TN” parameter while configuring Set Mode Item “49

SQL.TYP.”

D CODE: DCS Encode only.

T DCS: Encodes a CTCSS tone and Decodes a DCS code.

D TONE: Encodes a DCS code and Decodes a CTCSS tone.

49 SQL.TYP

Function: Selects the Tone Encoder and/or Decoder mode.

Available Values: TONE / TSQL / DCS / RV TN / OFF

Default: OFF

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

TONE: CTCSS Encoder

TSQL: CTCSS Encoder/Decoder

DCS: Digital Coded Encoder/Decoder

RV TN: Reverse CTCSS Decoder (Mutes receiver when matching tone is received)

Note: See also Set Mode Item “48 SPLIT” regarding additional selections available

during “Split Tone” operation.

50 STEP

Function: Sets the Synthesizer steps.

Available Values: 5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz

Default: 5 kHz

51 TEMP

Function: Indicates the current temperature inside the transceiver’s case.

52 TN FRQ

Function: Setting of the CTCSS Tone Frequency.

Available Values: 50 standard CTCSS tones

Default: 100.0 Hz

53 TOT

Function: Sets the Time-Out Timer.

Available Values: 1MIN / 3MIN / 5MIN / 10MIN / OFF

Default: 3MIN

The time-out timer shuts off the transmitter after continuous transmission of the

programmed time.

54 TS MUT

Function: Enables/Disables the receiver audio output during the Tone Search Scanner

is activated.

Available Values: ON / OFF

Default: ON

55 TS SPD

Function: Selects the Tone Search Scanner speed.

Available Values: FAST / SLOW

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Default: FAST

56 VFO.SCN

Function: Select the VFO Scanner Width.

Available Values: ±1MHz / ±2MHz / ±5MHz / ALL

Default: ALL

±1 MHz, ±2 MHz, ±5 MHz: The scanner will sweep frequencies within the selected

bandwidth.

ALL: The scanner will sweep all frequencies.

57 WX ALT

Function: Enables/disables the Weather Alert feature.

Available Values: ON / OFF

Default: OFF

58 WX VOL

Function: Selects the audio output level of the Weather Alert Tone.

Available Values: NOR.VOL / MAX.VOL

Default: NOR.VOL

59 W/N DV

Function: Reduction of the Microphone Gain/Deviation and receiver bandwidth.

Available Values: WIDE (±5 kHz Deviation, 15 kHz Bandwidth) / NARROW (±2.5 kHz

Deviation, 6 kHz Bandwidth)

Default: WIDE (±5 kHz Deviation, 15 kHz Bandwidth)

FCC ID:K6620393X50

IC: 511B-20393X50

Operating Manual

Yaesu Musen 20393X50 AMATEUR RADIO WITH SCANNING RECEIVER User Manual

Yaesu Musen Co., Ltd. AMATEUR RADIO WITH SCANNING RECEIVER Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
