Yaesu Musen Co., Ltd. HX270S MARINE HT RADIO USERS MANUAL
USERS MANUAL
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
1/14
Vertex Standard Co., Ltd.
HX270S Operating Manual
SAFETY TRANING INFORMATION
This Radio has been tested and complies with the Federal Communications Commission (FCC) RF
exposure limits for Occupational Use/Controlled exposure environment. In addition, it complies with the
following Standards and Guidelines:
- FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation.
- FCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating Compliance with FCC Guidelines for
Human Exposure to Radio Frequency Electromagnetic Fields.
- ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio
Frequency Electromagnetic Fields, 3kHz to 300 GHz.
- ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous
Electromagnetic Fields-RF and Microwave.
WARNING:
This radio generates RF electromagnetic energy during transmit mode. This radio is designed for and
classified as Occupational Use Only, meaning it must be used only during the course of employment by
individuals aware of the hazards, and the ways to minimize such hazards. This radio is not intended for use
by the General Population in an uncontrolled environment.
CAUTION:
To ensure that your expose to RF electromagnetic energy is within the FCC allowable limits for occupational
use, always adhere to the following guidelines:
- This radio is NOT approved for use by the general population in an uncontrolled environment. This
radio is restricted to occupational use, work related operations only where the radio operator
must have the knowledge to control its RF exposure conditions.
- When transmitting, hold the radio in a vertical position with its microphone 1 to 2 inches (2.5 to 5
cm) away from your mouth and keep the antenna at least 1 inch (2.5cm) away from your head and
body.
- The radio must be used with a maximum operating duty cycle not exceeding 50 %, in typical
Push-to-Talk (PTT) configurations.
DO NOT transmit for more than 50 % of total radio use time (50 % duty cycle). Transmitting more
than 50 % of the time can cause FCC RF exposure compliance requirements to be exceeded.
The radio is transmitting when the red LED on the top of the radio is illuminated. You can cause
the radio to transmit by pressing the PTT button.
- DO NOT transmit when the radio is used in Body Worn configuration with the following accessory:
belt-clip (CLIP-14).
It must be used ONLY for (1) there is a 4 cm distance from the body during transmitting, (2)
monitoring purposes, using the speaker only and (3) for carrying purposes.
- Always use Standard Horizon authorized accessories.
The information listed above provides the user with the information needed to make him or her aware of RF
exposure, and what to do to assure that this radio operates with the FCC RF exposure limits of this radio.
Electromagnetic Interference/Compatibility
During transmissions, this radio generates RF energy that can possibly cause interference with other
devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so.
Do not operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals,
health care facilities, aircraft, and blasting sites.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
2/14
Vertex Standard Co., Ltd.
FCC LICENSE INFORMATION
This radio operates on communications frequencies which are subject to FCC (Federal Communications
Commission) Rules and Regulations. FCC Rules require that all operators using Marine / Private Land
Mobile radio frequencies obtain a radio license before operating their equipment.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
3/14
Vertex Standard Co., Ltd.
1. GENERAL INFORMATION
1.1 INTRODUCTION
The HX270S is a handheld two-way VHF transceiver. The transceiver has marine, 10
weather (WX) channels. The marine and land channels are selectable to comply with either
USA, International, or Canadian regulations. It has an emergency channel 16 which can be
immediately selected from any channel by pressing the 16/9 key. Weather channels can
also be accessed immediately by pressing the WX key.
The transceiver includes following features: memory scanning, Priority Scanning, weather
alert, battery saver, easy-to-read large LCD display, EEPROM memory back-up, battery life
displayed on LCD, and a transmit time-out timer (TOT).
1.2 FCC/INDUSTRY CANADA INFORMATON
The following data pertaining to the transceiver is necessary to fill out the license
application.
FCC Type Accepted: Part 80
Output Power with FNB-83: 1 watt (Low), 2.5 watts (Mid), and 5 watts (High)
Emission: 16K0G3E (Voice) / 16K0G2B (ATIS)
Frequency Range: 156.025-157.425 MHz
FCC Type Number:
Industry Canada Type Approval:
Additional FCC and Industry Canada data, including licensing requirements, are contained
in the companion document titled OWNWER’S MANUAL SUPPLEMENT. The document
also contains charts for VHF channel assignments, transceiver operating procedures,
maintenance, factory service information, and warranty data.
2. ACCESSORIES
2.1 PACKING LIST
When the package containing the transceiver is first opened, please check it for the
following contents:
• HX270S Transceiver
• FNB-83 Ni-MH Battery Pack
• CD-26 Charger Cradle
• NC-88B 120VAC Wall Charger for CD-26
• CAT-460 Antenna
• CLIP-14 Belt Clip with screw
• Lanyard
• Owner’s Manual
• Owner’s Manual Supplement
2.2 OPTIONS
FBA-25A Alkaline Battery Case
E-DC-19 DC Cable with 12 V Cigarette Lighter Plug for CD-26
E-DC-6 DC Cable; plug and wire only for CD-26
MCC460 Soft Case
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
4/14
Vertex Standard Co., Ltd.
3. CONTROLS AND INDICATORS
NOTE: This section defines each control of the transceiver. For detailed operating
instructions refer to section 4 of this manual. Refer to Figure 1 for the location of the
following controls, indicators, and connections.
3.1 CONTROLS AND CONNECTIONS
1. POWER SWITCH/VOLUME CONTROL
Turn the transceiver on and off, and adjusts the volume.
2. SQ (SQUELCH CONTROL) SWITCH
Set the point at which random noise on the channel does not activate the audio circuits
but a received signal does. This point is called the Squelch threshold. Further adjustment
of the squelch control will degrade the reception of wanted transmissions.
3. PUSH-TO-TALK (PTT) SWITCH
Activates transmission.
4. UP KEY
Selects the desired channel. Each press increases the channel number. When held down,
the channels increase continuously.
5. DOWN KEY
Selects the desired channel. Each press decreases the channel number. When held down,
the channels decrease continuously.
6. 16/9 KEY
Immediately recalls channel 16 from any channel location. Holding down this key recalls
channel 9.
7. SCAN KEY
Starts scanning programmed channels. Press this key for at least 1 second to turn on and
off priority scan (scanning of programmed channels and priority channel) during scan.
8. PRESET KEY
Immediately recalls one of up to five user preset memories for operation. Pressing this
key repeatedly to select the desired preset memory.
9. WX KEY
Immediately recalls a weather channel from any channel location. Recalls the previous
channel when the WX key is pressed again.
Holding this key to toggles the mode between USA, International, and Canadian.
10. MEM KEY
Memorizes the selected channel. Holding this key deletes the memorized channel.
11. H/L KEY
Toggles the between high, mid, and low power. To change from low power to mid or high
power, hold down this key on Canadian channel 13, USA channel 13 or 67.
12. Antenna Connector
Connect the supplied CAT460 flexible antenna.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
5/14
Vertex Standard Co., Ltd.
3.2 INDICATORS
Channel Display
The operating channel in both transmission and reception mode.
A Indicator
Ship-ship channel in USA or Canadian mode whose counterpart in the International mode
is a public correspondence (marine operator) channel.
USA/CAN/INTL Indicator
The modes of operation for the particular channel. “USA” indicates USA mode. “CAN”
indicates Canadian mode and “INTL” indicates International mode.
H/M/L Indicator
“H” is high power. “M” is middle power and “L” is low power. Blank is a reception only
channel.
PRI Indicator
Priority Scan is activated.
SCN Indicator
Scan is activated.
TX Indicator
Indicates transmission
WX Indicator
NOAA weather channel.
MEM Indicator
The channel is in the transceiver’s scan memory.
Battery Indicator
Battery life, during transmission and reception, is as follows:
NOTE: The battery life indicator is accessed immediately by pressing the PTT switch. The
battery indicator should be used only as a guide in charging the FNB-83/ battery.
KEY Symbol Indicator
The channel is locked. All keys are disabled except for the H/L, PTT and LAMP keys
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
6/14
Vertex Standard Co., Ltd.
4. OPERATION
4.1 INITIAL PROCEDURE
NOTE: Never key the transceiver without an antenna connected. Damage may occur to the
transceiver. Do not operate the transceiver while charging.
1. Install the belt clip on the transceiver if desired. Use the one Phillips-head screws
included with the clip to mount the clip to the back of the transceiver.
2. Install the nylon-carrying strap on the belt clip if desired.
3. Install the battery pack on the transceiver (see figure X and section 5.1)
4. Install the antenna to the transceiver.
5. Turn the
POWER/VOLUME CONTROL knob clockwise to turn the transceiver.
NOTE: Water resistance of the transceiver is assured only when the battery pack and
antenna are attached to the transceiver.
4.2 RESEPTION
1. Turn the
POWER/VOLUME CONTROL knob clockwise to turn the transceiver on.
2. Turn up the POWER/VOLUME CONTROL knob until the noise or audio from the
speaker is at a desired level.
3. Select a channel that has no signal being received (no one is transmitting on the
channel) and only noise heard.
4. Press the
SQ key. Then press [UP] or [DOWN] key and stop immediately after the noise
disappears. This condition is known as the “Squelch Threshold.” If the knob is turned
clockwise past this point, weak signals may not be received. No noise or no signal is
heard until a signal is received that exceeds the squelch threshold.
5. To change channel, press the [UP] or [DOWN] key. Sometimes, a slight adjustment of
the squelch threshold is needed as some channels have a higher noise level than
others.
6. Please refer to the Owner’s Manual Supplement for a complete listing of all USA,
International and Canadian VHF Marine channels and their use.
4.3 TRANSMISSION
1. Perform steps 1 through 7 of RECEPTION.
2. Before transmitting, monitor the channel and make sure it is clear.
THIS IS AN FCC REQUIREMENT!
3. For communications over short distances, press the H/L key until “L” is displayed on the
LCD. This indicates low power, approximately 1 watt.
4. Note: Transmitting on 1 watt prolongs battery life. Low power (1 watt) should be
selected whenever possible.
5. If using low power is not effective, select mid power (2.5 watts) or high power (5 watts)
by pressing the H/L key until “M” (mid power) or “H” (high power) is displayed.
6. When receiving a signal, wait until the signal stops before transmitting. The transceiver
cannot transmit and receive simultaneously.
7. Press the
PTT (push-to-talk) switch. The “TX” indicator is displayed during
transmission.
8. Speak slowly and clearly into the microphone. Hold the microphone about 1/2 to 1 inch
away from your mouth.
9. When the transmission is finished, release the PTT switch.
10. Refer to the OWNWER’S MANUAL SUPPLEMENT for standard transceiver operating
procedures.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
7/14
Vertex Standard Co., Ltd.
4.4 TRANSMIT TIME - OUT TIMER (TOT)
While the PTT switch is held down, transmission time is limited to 5 minutes. This prevents
prolonged unintentional transmissions. About 10 seconds before automatic transmitter
shutdown, a warning beep is sounds from speaker. The transceiver automatically switches
to the receiving mode, even if the PTT switch is held down. Before transmitting again, the
PTT switch must first be released and press again. This time-out timer (TOT) prevents a
continuous transmission that would result from an accidentally stuck PTT switch.
4.5 USA, CANADIAN, AND INTERNATIONAL MODES
1. To change the mode of the transceiver, held down the 16/9 key and press the WX key.
The mode changes from USA, to International, to Canadian with each press.
2. “USA” appear on the LCD for the USA mode, “CAN” appears for Canadian mode, and
“INTL” appears in International mode.
3. Refer to marine channel charts in OWNER’S MANUAL SUPPLEMENT for allocated
channels in each mode.
4.6 NOAA WEATHER CHANNELS
1. To receive a weather channel, press the WX key. The transceiver changes to the
weather channel mode.
2. Press the [UP] or [DOWN] key to change to other weather channels.
3. To exit from the weather channels, press the WX key. The transceiver recalls the
previous non-weather channel.
4.7 SCAN
1. Select the desired channel to be scanned using the [UP] or [DOWN] key.
2. Press the
MEM key to store the channel into the transceiver’s memory. “MEM” is
displayed on the LCD.
3. Repeat steps 1 and 2 for all the channels to be scanned.
4. To delete a channel from the transceiver’s scan memory, press the MEM key again
while the memorized channel is displayed. “MEM” disappears.
5. All channels programmed remain in the transceiver’s scan memory even if the power is
turned off. See section “4.17 RESETTING THE TRANSCEIVER’S
MICROPROCESSOR” to clear all the transceiver’s scan memory.
6. Adjust the
SQUELCH CONTROL knob until background noise is eliminated.
7. To start scan, press the SCAN key. The scan proceeds from the lowest to the highest
programmed channel number and stops on channels when a transmission is received.
8. To stop the scan, press the SCAN key.
4.8 PRIORITY SCAN
1. The following channels can be set as the priority channel; 16, 09, and Preset Channels
1 through 5 (Preset Channel described section 4.14). To set the priority channel, hold
down the 16/9 key and press the MEM key. The channel changes from 16 to 09 to
Preset 1 to Preset 2 to Preset 3 to Preset 4 to Preset 5 channel with each press of the
MEM key. The displayed channel is set to the priority channel.
2. For priority scanning, hold down the SCAN key at least 1 second during normal
scanning. Scanning will proceed between the memorized channels and the priority
channel. The priority channel will be scanned after each programmed channel.
3. For example, channels 06, 07, 08 are memorized in the transceiver’s memory, Priority
scanning will proceed in the following sequence:
[CH06] Æ [Priority Channel] Æ [CH07] Æ [Priority Channel] Æ [CH08] Æ [Priority
Channel] Æ[CH06] Æ [Priority Channel] ………
4. Even when the transceiver stops and listens to the signal of a programmed channel, the
transceiver will dual watch between this channel and the priority channel.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
8/14
Vertex Standard Co., Ltd.
4.9 WEATHER ALERT
In the event of extreme weather disturbances such as storms and hurricanes, NOAA
(National Oceanic and Atmospheric Administration) sends a weather alert accompanied by
a 1050 Hz tone and subsequent weather reports on the weather channels. The transceiver
is capable of receiving this alert if the following is performed:
1. Program weather channels into the transceiver’s memory for scanning. Follow the
same procedure as for regular channels under Section 4.7.
2. Press the
SCAN key to start the scan.
3. The memorized weather channels are scanned along with the regular memorized
channels. Scan does not stop for normal weather broadcast.
4. When an alert is received on a weather channel, scanning stops and the transceiver
enters the WEATHER ALERT MODE.
5. When the transceiver is in the WEATHER ALERT MODE, a loud tone is sounded.
6. Press the
WX key to stop the alert tone and receive the voice information on the
weather channel.
4.10 EMERGENCY CHANNEL 16
1. To select the emergency channel, press the 16/9 key from any channel.
2. Transmit your emergency signal in the same manner as on regular channels. If you can
not contact anyone on channel 16, switch to another channel.
3. See the OWNER’S MANUAL SUPPLEMENT for additional emergency operating
practices.
4. To recall the previous channel from 16, press the 16/9 key.
4.11 CHANNEL 9
Channel 9 is used as a hailing channel for initial, non-emergency contact with other vessels.
Hold down the 16/9 key for 1 second to select channel 9.
4.12 OPERATING ON CHANNEL 13
Channel 13 is used at docks, bridges and for maneuvering in port. Messages on this
channel must concern navigation only, such as meeting and passing in restricted waters.
In emergencies and when approaching blind river bends, high power is allowed. Hold down
the H/L key to temporarily switch to high or mid power. High or mid power can only be
accessed in USA and Canadian modes. When the PTT switch released, the transceiver will
revert low power.
4.13 OPERATING ON CHANNEL 67
When channel 67 is used for navigational bridge-to-bridge traffic between ships, high or mid
power may be used temporarily in the USA mode by pressing the H/L key. When the PTT
switch released, the transceiver will revert low power.
4.14 PRESET CHANNEL (A ~ E) INSTANT ACCESS
Five user-assigned channels can be programmed for instant access. USA channel 70 and
weather channels should not be assigned into the preset channels. If the PRESET key is
pressed and no channels has been assigned, an alert signal will be emitted twice.
4.14.1 Programming
Hold down the PRESET key and press the [UP] or [DOWN] key until the desired channel
number is displayed.
With the desired channel number displayed, release the PRESET key. The “A” will appear
on the display, indicating that the displayed channel is now designated Preset
Channel A.
Repeat steps 1 and 2 to program the desired channel to the Preset Channels b ~ E.
To delete the Preset Channel, hold down the PRESET key and press the [UP] or [DOWN]
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
9/14
Vertex Standard Co., Ltd.
key until the Preset Channel number to be deleted is displayed, then release the
PRESET key.
4.14.2 Operation
Pressing the PRESET key toggles between Preset Channel A, b, C, d, E, and regular
channel. Preset Channel A is represented by “A” to the left of the channel number on the
LCD, and channel B is represented by “b” ……. Do not confuse this “A” with the one that
sometimes is displayed to the right of the channel number (described in the section 3.2 of
this Owner’s Manual).
4.15 SIMPLEX/DUPLEX CHANNEL USE
All channels are factory-programmed in accordance with FCC (USA), Industry Canada and
International regulations. Mode of operation cannot be altered from simplex to duplex or
vice-versa. Simplex or duplex mode is automatically activated, depending on the channel
and whether USA, International or Canadian operating mode is selected. Refer to the
channel charts in the OWNER’S MANUAL SUPPLEMENT.
4.16 SET MODE
The HX270S’s Set Mode system allows a number of transceiver operating parameters to be
custom-configured for your operating requirements.
The Set Mode is easy to activated and set, using the following procedure:
1. Turn the radio off.
2. Hold down the SQ switch and then turn on the transceiver.
3. The “SET” will appear on the display, indicate that activate the Set Mode.
4. Press the
SQ switch to select the Menu item to be adjusted.
5. Press the [UP] or [DOWN] key select the status or value of the Menu item. Then press
SQ switch to save the new setting.
6. After completing your adjustment, press the PTT switch to save the new setting and exit
to normal operation.
4.16.1 bEP (Key Beep)
Function: Enable/disable Keypad beeper.
Available Values: ON/OFF
Default: ON
4.16.2 CHF (Channel Frequency Display)
Function: Select the frequency of each channel.
Available Values: ON/OFF
Default: OFF
4.16.3 CHn (Channel Name)
Function: Input channel name of each channel.
Available Values: Alphanumeric
Default:
4.16.4 dUL (Dual Watch)
Function: Select the Dual Watch channel.
Available Values: SPL/NOR
Default: SPL
4.16.5 LP (Lamp Mode)
Function: Select the LCD/Keypad Lamp mode.
Available Values: KEY/CNT (Continuous)/OFF
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
10/14
Vertex Standard Co., Ltd.
Default: KEY
KEY: Illuminates the LCD/Keypad for 5 seconds when any key is pressed.
4.16.6 SCL (Scan Lamp)
Function: Enable/disable the Scan lamp while paused.
Available Values: ON/OFF
Default: OFF
4.16.4 SCn (Scan Display)
Function: Select the display mode while scanning.
Available Values: nor (Normal)/SPL (Special)
Default: nor (Normal)
nor (Normal): Changes the channel number accordance with scanning
SPL (Special): The channel number does not changed while scanning. However, the
channel number changes to the scan stop channel, when the scanner is stopped.
4.17 CLONNING
The HX270S includes a convenient “Clone” feature, which allows the memory and
configuration data from one transceiver to be transferred to another HX270S. Here is the
procedure for Cloning one radio’s data to another:
1. Turn both radio off.
2. Connect the Clone Cable between the MIC/SP jacks of the two transceivers.
3. Hold down the
PRESET key and then turn on the transceiver. Do this for both
transceivers (the order of switch on does not matter). “cLn” will appear on the display on
both transceivers.
4. On the Destination transceiver, press MEM key (“cr” will appear on the LCD).
5. Press the
16/9 key on the Source transceiver; “cS” will appear on the Source radio, and
the data is transferred.
6. If there is a problem during the cloning process, “cE” will displayed. Check your cable
connections and battery voltage, and try again.
7. If the data transfer is successful, the Destination transceiver will return to normal
operation; Turn both transceivers off and disconnect the Clone cable. You can then turn
the transceivers back on, and begin normal operation.
4.18 RESETTING THE TRANSCEIVER’S MICROPROCESSOR
Resetting the microprocessor restores the initial, factory supplied conditions in the
transceiver. These are called the default conditions. To reset the microprocessor, first the
transceiver off. Then while holding the WX and SCAN keys pressed, turn the transceiver on.
The default conditions are:
• No channel numbers are in memory.
• Channel 16 is the priority channel.
• Channel 16 will be selected when the transceiver is turned on.
• WX channel 01 will be recalled when the WX key is pressed.
• Preset Channels are unassigned.
Note: The above procedure also resets the microprocessor. Perform this procedure if an
operational problem occurs.
5. BATTERY
CAUTION: To avoid risk of explosion and injury, FNB-83 battery pack should only be
removed, charged or recharged in non-hazardous environments.
5.1 BATTERY REMOVAL/INSTALLATION
1. Turn the transceiver off.
2. To remove, open the Battery Pack Latch on the bottom of the transceiver, then slide the
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
11/14
Vertex Standard Co., Ltd.
battery downward and out from the transceiver.
3. To install, insert the battery pack into the battery compartment on the back of the
transceiver, then close the Battery Pack Latch until it locks in place with a “click.”
5.2 FBA-25A BATTERY CASE
FBA-25A is a battery case that holds two alkaline batteries and is used with the HX270S
transceiver. Alkaline batteries can be used for transmission in an emergency, but power
output will only be 0.9 W, and battery life will be shortened dramatically.
1. Slide the batteries into the FBA-25A with the Negative [–] side of the batteries touching
the spring connections inside the FBA-25A.
2. Insert the
FBA-25A into the battery compartment on the back of the transceiver, then
close the Battery Pack Latch until it locks in place with a “click.”
Note: The battery indicator on the transceiver is only applicable to the FNB-83/
rechargeable battery. Disregard this indication when using alkaline batteries.
5.5 BATTERY SAFETY
Battery packs for your transceiver contains Nickel-Metal Hydride (Ni-MH, FNB-83) battery.
This type of battery stores a charge powerful enough to be dangerous if misused or abused,
especially when removed from the transceiver. Please observe the following precautions:
DO NOT SHORT BATTERY PACK TERMINALS
Shorting the terminals that power to the transceiver can cause sparks, severe overheating,
burns, and battery cell damage. If the short is of sufficient duration, it is possible to melt
battery components. Do not place a loose battery pack on or near metal surfaces or objects
such as paper clips, keys, tools, etc. When the battery pack is installed on the transceiver,
the terminals that transfer current to the transceiver are not exposed. The terminals that are
exposed on the battery pack when it is mounted on the transceiver are charging terminals
only and do not constitute a hazard.
DO NOT INCINERATE
Do not dispose of any Ni-MH battery in a fire or incinerator. The heat of fire may cause
battery cells to explode and/or release dangerous gases.
DISPOSE OF BATTERY PACKS PROPERLY
Ni-MH battery must be recycled or disposed of properly. For requirements in your area,
check with the dealer from whom you purchased your transceiver. The symbol shown below
is a reminder that the battery packs are recyclable.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
12/14
Vertex Standard Co., Ltd.
6. MAINTENANCE
For preventive maintenance and instructions on obtaining factory service, please refer to the
OWNER’S MANUAL SUPPLEMENT. For general troubleshooting, refer to this
Troubleshooting Chart.
TROUBLESHOOTING CHART
SYMPTON PROBABLE CAUSE REMEDY
No channels memorized. Use the MEM key to enter
desired channels into the
transceiver’s memory.
The SCAN key does not
start the scan.
Squelch is not adjusted. Adjust the squelch to
threshold or to the point
where noise just
disappears. Further
adjustment of the squelch
control may eliminate
incoming signals.
The USA/INTL/CAN modes
do not function.
Proper operation not
followed.
HOLD down the 16/9 key
and press the WX key.
Rotating the SQUELCH
CONTROL knob does not
eliminate background noise.
Low battery. Charge battery. Refer to
section 5 of this manual.
Cannot change any function Key Lock is on. Turn Key Lock off.
Key Lock does not function. Proper operation not
followed.
Hold down the LAMP key
for 1 second.
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
13/14
Vertex Standard Co., Ltd.
7.SPECIFICATIONS
7.1 General
Frequency range (TX): 156.025-157.425 MHz
(RX): 156.050-163.275 MHz
Channel spacing: 25 kHz
Emission type: 16K0G3E
Power supply voltage (Rated): 7.5 V DC
Current consumption (RX @ 7.5 V, 0.5 W AF): 0.3 A
(TX @ 5 W): 2.1 A
Temperature range: -20 to +60 °C
Case size (W x H x D): 58 x 120 x 30.5 mm
Weight (Approx.): 340 g
Receiver
Circuit type: Double-conversion superheterodyne
Ifs (1st): 21.7 MHz
(2nd): 450 kHz
12dB SINAD Sensitivity 0.25 µV
Adjacent channel selectivity: 70 dB
Intermodulation: 70 dB
Spurious rejection: 70 dB
Speaker impedance: 8 Ω
AF Output (@ 10 % THD): 0.4 W
Transmitter
Power Output (High): 5 W
(Low): 1 W
Frequency stability: ± 5 ppm
Modulation system: Variable reactance
Maximum deviation: 5 kHz
FM Noise: better than 40 dB
Spurious emissions: better than 73 dB
AF distortion (@ 1 kHz) 10 %
Microphone type: Condenser
Microphone impedance: 2 kΩ
FCC ID: K6630073X20
IC ID: 511B-30073X20
Operating Manual
14/14
Vertex Standard Co., Ltd.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the condition that this device does not cause harmful
interference.
Part 15.21: Changes or modifications to this device not expressly approved by Vertex
Standard could void the user’s authorization to operate this device.
