Data List
Daten-Liste
Liste des données
Lista de datos
Data List
Daten-Liste
Liste des données
Lista de datos
CVP-210/208/206/204
CVP-210/208/206/204
Voice List
Voice-Liste
Liste des voix
Lista de voces .......................................................... 2
Drum/key Assignment List
Liste der Tastenzuordnungen der Schlaginstrumente
Liste d'assignation instrument de batterie/touche du clavier
Lista de asignación de teclas/batería ..............................13
Style List
Liste der Styles
Liste des styles
Lista de estilos ........................................................ 16
Effect Type List
Liste der Effekttypen
Liste des types d'effet
Lista de tipos de efecto .............................................. 18
Effect Parameter List
Liste der Effektparameter
Liste des paramètres d'effets
Lista de parámetros de efectos .................................... 21
Effect Data Assign Table
Effektdaten-Zuordnungstabelle
Tableau d'assignation des données d'effets
Tabla de asignación de datos para efectos ....................... 27
Harmony/Echo Type List
Liste der Harmony/Echo-Effekttypen
Liste des types d'harmonie/d’écho
Lista de tipos de ecos/armonías.................................... 28
Vocal Harmony Type List
Liste der Vocal-Harmony-Effekttypen
Liste des types d'harmonie vocale
Lista de tipos de armonía ........................................... 28
Parameter Chart
Parametertabelle
Tableau des paramètres
Gráfico de parámetros ............................................... 29
MIDI Data Format
MIDI-Datenformat
Format des données MIDI
Formato de datos MIDI .............................................. 35
Song System Exclusive Message List
Liste der System-Exclusive-Meldungen der Songs
Liste des messages exclusifs au système de morceaux
Lista de mensajes exclusivos del sistema de canciones ...... 51
Song Meta Event List
Liste der Meta-Events der Songs
Liste des méta-événements des morceaux
Lista de meta-eventos de canciones .............................. 51
MIDI Implementation Chart
MIDI-Implementierungstabelle
Tableau d'implémentation MIDI
Gráfico de implementacíon MIDI .................................. 52
2
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Piano & Harpsi GrandPiano1 Natural! 0 122 0
GrandPiano2 Live! 0 122 1
Piano&Str Natural! 0 125 0
Piano&Choir Natural! 0 126 0
Oct.Piano1 Natural! 0 123 3
Harpsichrd8' Natural! 0 122 6
Hc8'+4' Natural! 0 123 6
Harpsi&Str Natural! 0 124 6
Piano&EP Natural! 0 122 2
Oct.Piano2 Natural! 0 124 3
BrightPiano Natural! 0 123 0
MellowPiano Natural! 0 124 0
RockPiano Natural! 0 124 2
HonkyTonk Natural! 0 122 3
CP80 Natural! 0 123 2
GrandPiano Live! 0 113 0
GrandPiano Regular 0 112 0
BrightPiano Regular 0 112 1
RockPiano Regular 0 114 2
MidiGrand Regular 0 112 2
HonkyTonk Regular 0 112 3
Oct.Piano1 Regular 0 113 3
Oct.Piano2 Regular 0 114 3
Harpsichord Regular 0 112 6
GrandHarpsi Regular 0 113 6
CP80 Regular 0 113 2
E.Piano DX EP Natural! 0 122 5
DX BrightEP Natural! 0 123 5
E.Piano Natural! 0 122 4
TremoloEP Natural! 0 124 4
FunkyEP Natural! 0 123 4
GalaxyEP Regular 0 114 4
StageEP Regular 0 117 4
E.Piano Cool! 0 119 4
E.Clavichord Natural! 0 122 7
JazzChorus Regular 0 118 5
PolarisEP Regular 0 115 4
WahE.Clavi Natural! 0 123 7
HyperTines Regular 0 113 5
PhaseEP Regular 0 120 4
NewTines Regular 0 116 5
FunkEP Regular 0 112 4
DX Modern Regular 0 112 5
VintageEP Regular 0 116 4
Clavi Regular 0 112 7
WahClavi Regular 0 113 7
VenusEP Regular 0 114 5
ModernEP Regular 0 115 5
TremoloEP Regular 0 113 4
SuperDX Regular 0 117 5
SuitcaseEP Regular 0 118 4
Organ & Accordion PipeOrganP Natural! 0 123 19
PipeOrgFl1 Natural! 0 124 19
PipeOrgFl2 Natural! 0 125 19
PipeOrgTu Natural! 0 122 19
ChapelOrgn1 Regular 0 113 19
ChapelOrgn2 Regular 0 114 19
ChapelOrgn3 Regular 0 115 19
PipeOrgan Regular 0 112 19
Elec.Organ Cool! 0 118 18
RotorOrgan Regular 0 117 18
RockOrgan1 Regular 0 112 18
DanceOrgan Regular 0 113 17
GospelOrg Regular 0 119 16
JazzOrgan Cool! 0 117 16
PurpleOrg Regular 0 114 18
JazzOrgan1 Regular 0 112 16
RockOrgan2 Regular 0 113 18
RotaryDrive Regular 0 116 18
FullRocker Regular 0 115 18
Elec.Organ Regular 0 118 17
DrawbarOrg Regular 0 115 16
ClickOrgan Regular 0 112 17
StadiumOrg Regular 0 118 16
MellowDraw Regular 0 115 17
JazzOrgan2 Regular 0 113 16
BrightDraw Regular 0 116 16
60'sOrgan Regular 0 116 17
JazzOrgan3 Regular 0 120 16
TheatreOrg1 Regular 0 114 16
TheatreOrg2 Regular 0 114 17
Organ & Accordion ReedOrgan Regular 0 112 20
Musette Regular 0 112 21
TuttiAccrd Regular 0 113 21
SmallAccrd Regular 0 115 21
Accordion Regular 0 116 21
TangoAccrd Regular 0 112 23
Steirisch Regular 0 117 21
Bandoneon Regular 0 113 23
SoftAccrd Regular 0 114 21
Harmonica Sweet! 0 122 22
ModernHarp Regular 0 113 22
BluesHarp Regular 0 114 22
Harmonica Regular 0 112 22
Percussion Vibraphone Natural! 0 122 11
TremoloVibes Natural! 0 124 11
Marimba Natural! 0 122 12
Xylophone Regular 0 112 13
SteelDrums Natural! 0 122 114
Celesta Natural! 0 122 8
Glocken Regular 0 112 9
MusicBox Regular 0 112 10
TubularBell Regular 0 112 14
Kalimba Regular 0 112 108
Vibraphone Regular 0 112 11
JazzVibes Regular 0 113 11
Marimba Regular 0 112 12
SteelDrums Regular 0 112 114
Celesta Regular 0 112 8
Dulcimer Regular 0 112 15
Timpani Regular 0 112 47
ArabicKit SFX Kit 126 0 35
CubanKit Live!SFX 126 0 40
PopLatinKit Live!SFX 126 0 43
Std.Kit+P Live!Drums 127 0 83
FunkKit+P Live!Drums 127 0 84
BrushKit+P Live!Drums 127 0 85
StandardKit1 Drums 127 0 0
StandardKit2 Drums 127 0 1
StandardKit Live!Drums 127 0 80
FunkKit Live!Drums 127 0 81
Brushkit Live!Drums 127 0 82
JazzKit Drums 127 0 32
BrushKit Drums 127 0 40
HitKit Drums 127 0 4
RoomKit Drums 127 0 8
RockKit Drums 127 0 16
ElectroKit Drums 127 0 24
AnalogKit Drums 127 0 25
DanceKit Drums 127 0 27
SymphonyKit Drums 127 0 48
SFXKit1 SFX Kit 126 0 0
SFXKit2 SFX Kit 126 0 1
StyStd.Kit+P Live!Drums 127 0 125
StyFunkKt+P Live!Drums 127 0 126
StyStd.Kit Live!Drums 127 0 123
StyFunkKit Live!Drums 127 0 124
Guitar NylonGuitar Live! 0 116 24
JazzGuitar Cool! 0 115 26
Elec.Gtr Cool! 0 114 28
FolkGuitar Natural! 0 122 25
12StrGuitar Natural! 0 123 25
Mandolin Sweet! 0 124 25
12StrGuitar Regular 0 113 25
VintageAmp Regular 0 115 29
CrunchGtr Regular 0 113 30
AlohaGtr Regular 0 118 26
ClassicGtr Live! 0 115 24
JazzSolGtr Cool! 0 116 26
FolkGuitar Regular 0 112 25
SolidChord Regular 0 121 27
ChorusGtr Regular 0 124 27
SmoothLead Regular 0 119 26
VintageMute Regular 0 115 28
VintageOpen Regular 0 123 27
FunkGuitar Regular 0 113 28
SolidGuitar Regular 0 118 27
SpanishGtr Regular 0 113 24
OctaveGtr Regular 0 113 26
DeepChorus Regular 0 114 27
CampfireGtr Regular 0 115 25
Mandolin Regular 0 114 25
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Voice List / Voice-Liste / Liste des voix / Lista de voces
CVP-210
3
Guitar PedalSteel Regular 0 115 27
SmoothNylon Regular 0 114 24
VintageTrem Regular 0 120 27
LeadGuitar Regular 0 114 29
HawaiianGtr Regular 0 114 26
ClassicGtr Regular 0 112 24
DX JazzGtr Regular 0 117 26
60'sClean Regular 0 117 27
WahGuitar Regular 0 122 27
HeavyStack Regular 0 114 30
BrightClean Regular 0 116 27
Distortion Regular 0 112 30
Elec.12Str Regular 0 119 27
TremoloGtr Regular 0 113 27
FeedbackGtr Regular 0 113 29
SlideGuitar Regular 0 125 27
CleanGuitar Regular 0 112 27
MutedGuitar Regular 0 112 28
JazzGuitar Regular 0 112 26
Overdrive Regular 0 112 29
Bass WoodBass Natural! 0 122 32
ElectricBass Natural! 0 122 33
FingerBass Regular 0 112 33
UprightBass Regular 0 113 32
PickBass Regular 0 112 34
SuperFretles Regular 0 113 35
SlapBass Regular 0 112 36
AnalogBass Regular 0 112 39
DX FunkBass Regular 0 113 37
DrySynBass Regular 0 116 39
TouchBass Regular 0 115 39
HiQBass Regular 0 113 38
FunkBass Regular 0 112 37
Aco.Bass Regular 0 112 32
Fretless Regular 0 112 35
Bass&Cymbal Regular 0 114 32
FusionBass Regular 0 113 36
RaveBass Regular 0 114 38
DanceBass Regular 0 113 39
SynthBass Regular 0 112 38
SnapBass Regular 0 114 39
ClickBass Regular 0 115 38
Brass Trumpet Sweet! 0 115 56
Trombone Sweet! 0 117 57
MutedTrump Sweet! 0 114 59
FlugelHorn Sweet! 0 118 56
SoftTrumpet Regular 0 114 56
HyperBrass Live! 0 118 62
FrenchHorn Live! 0 122 60
BigBrass Regular 0 121 61
PopBrass Regular 0 118 61
BrassCombo Regular 0 115 66
Trumpet Regular 0 122 56
SoloTromb Regular 0 112 57
MutedTrump Regular 0 112 59
FlugelHorn Regular 0 113 56
AirTrumpet Regular 0 117 56
Sforzando Regular 0 125 61
OctaveBrass Live! 0 116 62
MoonLight Regular 0 115 71
BalladBrass Regular 0 119 66
SaxyMood Regular 0 120 66
SoloTrumpet Regular 0 112 56
Trombone Regular 0 116 57
SoftTromb Regular 0 115 57
MellowTromb Regular 0 114 57
FrenchHorn Regular 0 112 60
MellowBrass Regular 0 116 61
PopBrass Live! 0 117 62
BrassSection Regular 0 112 61
BigBandBrs Regular 0 113 61
StepBrass Regular 0 124 61
JazzTrumpet Regular 0 116 56
SmoothTromb Regular 0 118 57
BrightBrass Regular 0 120 61
TrumpetEns Regular 0 122 61
Trb.Section Regular 0 113 57
MellowHorns Regular 0 119 61
SoftBrass Regular 0 123 61
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Brass FullHorns Regular 0 114 61
HighBrass Regular 0 115 61
SmallBrass Regular 0 117 61
BallroomBrs Regular 0 113 59
BrassHit Regular 0 126 61
80'sBrass Regular 0 113 62
AnalogBrs Regular 0 112 63
SoftAnalog Regular 0 114 63
FunkyAnalog Regular 0 115 62
TechnoBrass Regular 0 114 62
SynthBrass Regular 0 112 62
OberBrass Regular 0 113 63
BaritonHorn Regular 0 113 58
BaritonHit Regular 0 114 58
Tuba Regular 0 112 58
AlpBass Regular 0 113 33
W.Wind TenorSax Sweet! 0 117 66
AltoSax Sweet! 0 114 65
SopranoSax Sweet! 0 113 64
Clarinet Sweet! 0 114 71
GrowlSax Regular 0 118 66
Flute Sweet! 0 114 73
PanFlute Sweet! 0 113 75
Oboe Sweet! 0 122 68
SaxSection Live! 0 122 66
BaritoneSax Regular 0 112 67
BreathTenor Regular 0 114 66
BreathyAlto Regular 0 113 65
SopranoSax Regular 0 112 64
Clarinet Regular 0 112 71
WoodwindEns Regular 0 113 66
Class.Flute Regular 0 115 73
PanFlute Regular 0 113 73
Piccolo Regular 0 112 72
EthnicFlute Regular 0 112 75
RockBari Regular 0 113 67
TenorSax Regular 0 112 66
AltoSax Regular 0 112 65
MelClarinet Regular 0 113 71
Oboe Regular 0 112 68
EnglishHorn Regular 0 112 69
Bassoon Regular 0 112 70
Flute Regular 0 112 73
Shakuhachi Regular 0 112 77
Whistle Regular 0 112 78
Recorder Regular 0 112 74
Ocarina Regular 0 112 79
SaxSection Regular 0 116 66
Bagpipe Regular 0 112 109
Strings Strings Natural! 0 122 48
Orchestra Live! 0 116 49
Allegro Live! 0 122 49
Strings Live! 0 117 49
Violin Sweet! 0 122 40
Cello Natural! 0 122 42
Orch.Brass Regular 0 118 49
Orch.Flute Regular 0 119 49
Orch.Fl.Br Regular 0 120 49
Orch.Oboe Regular 0 121 49
Strings Regular 0 112 48
SoloViolin Regular 0 112 40
SoftViolin Regular 0 113 40
Fiddle Regular 0 112 110
Viola Regular 0 112 41
Cello Regular 0 112 42
Contrabass Regular 0 112 43
ChamberStrs Regular 0 112 49
Str.Quartet Regular 0 114 49
ConcertoStr Regular 0 115 48
BowStrings Regular 0 116 48
MarcatoStrs Regular 0 115 49
Symphon.Str Regular 0 114 48
OrchStrings Regular 0 113 48
SlowStrings Regular 0 113 49
TremoloStrs Regular 0 112 44
PizzStrings Regular 0 112 45
AnalogStrs Regular 0 112 51
SynStrings Regular 0 112 50
OberStrings Regular 0 113 51
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
4
Strings Harp Regular 0 112 46
Hackbrett Regular 0 113 46
Banjo Regular 0 112 105
Sitar Regular 0 112 104
Koto Regular 0 112 107
Shamisen Regular 0 112 106
Orch.Hit Regular 0 112 55
Choir & Pad Choir Natural! 0 122 52
Vocal Live! 0 114 53
Doo Live! 0 117 53
Bah Live! 0 118 53
Dao Live! 0 119 53
Gospel Live! 0 116 52
Humm Live! 0 118 52
HahChoir Regular 0 114 52
GothicVox Regular 0 113 53
Sunbeam Regular 0 123 88
SweetHeaven Regular 0 118 88
DreamHeaven Regular 0 121 88
BellHeaven Regular 0 119 88
PanHeaven Regular 0 120 88
ProHeaven Regular 0 122 88
DooBaScats Regular 0 115 53
DaaChoir Regular 0 120 53
DooChoir Regular 0 122 53
DooomChoir Regular 0 120 52
Dooom Live! 0 116 53
Mmh Live! 0 117 52
BahChoir Regular 0 121 53
HuhChoir Regular 0 119 52
Choir Regular 0 112 52
AirChoir Regular 0 112 54
VocalEnsbl Regular 0 113 52
VoxHumana Regular 0 112 53
Voices Regular 0 113 54
UuhChoir Regular 0 115 52
Insomnia Regular 0 113 94
CyberPad Regular 0 113 99
Wave2001 Regular 0 112 95
NeoWarmPad Regular 0 115 89
Atmosphere Regular 0 112 99
XenonPad Regular 0 112 91
Skydiver Regular 0 112 101
FarEast Regular 0 112 97
Template Regular 0 114 95
Equinox Regular 0 112 94
GlassPad Regular 0 114 93
Fantasia Regular 0 112 88
DX Pad Regular 0 112 92
Symbiont Regular 0 113 88
Stargate Regular 0 114 88
Area51 Regular 0 112 89
DarkMoon Regular 0 113 89
Ionosphere Regular 0 115 94
GoldenAge Regular 0 115 88
Solaris Regular 0 114 94
TimeTravel Regular 0 116 88
Millennium Regular 0 117 88
Transform Regular 0 113 95
Dunes Regular 0 114 89
Synthesizer Oxygen Regular 0 122 81
Matrix Regular 0 123 81
WireLead Regular 0 120 81
HipLead Regular 0 113 80
HopLead Regular 0 117 80
SquareLead Regular 0 112 80
Saw.Lead Regular 0 112 81
FireWire Regular 0 116 81
Analogon Regular 0 115 81
FunkyLead Regular 0 121 81
Paraglide Regular 0 114 84
Robolead Regular 0 124 81
Fargo Regular 0 119 81
Portatone Regular 0 112 84
Blaster Regular 0 114 81
BigLead Regular 0 113 81
Warp Regular 0 117 81
Adrenaline Regular 0 113 84
Synchronize Regular 0 112 96
TinyLead Regular 0 118 80
Stardust Regular 0 112 98
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Synthesizer AeroLead Regular 0 112 83
MiniLead Regular 0 114 80
SynthFlute Regular 0 119 80
SubAqua Regular 0 118 81
Impact Regular 0 113 87
SunBell Regular 0 113 98
UnderHeim Regular 0 112 87
Rhythmatic Regular 0 113 96
HiBias Regular 0 116 80
Vinylead Regular 0 115 80
Skyline Regular 0 115 84
Clockwork Regular 0 114 96
Organ Flutes JazzDraw! Organ Flutes 0 126 16
BluesOrgan! Organ Flutes 0 126 16
SixteenOne! Organ Flutes 0 126 16
EvenBars! Organ Flutes 0 126 16
PopOrgan! Organ Flutes 0 126 16
RockingOrg! Organ Flutes 0 126 16
Percussive! Organ Flutes 0 126 16
GospelOrg! Organ Flutes 0 126 16
PadOrgan! Organ Flutes 0 126 16
FullRanks! Organ Flutes 0 126 16
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
5
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Piano & Harpsi GrandPiano1 Natural! 0 122 0
GrandPiano2 Live! 0 122 1
Piano&Str Natural! 0 125 0
RockPiano Natural! 0 124 2
Oct.Piano1 Natural! 0 123 3
Harpsichrd8' Natural! 0 122 6
Hc8'+4' Natural! 0 123 6
Harpsi&Str Natural! 0 124 6
Piano&EP Natural! 0 122 2
Oct.Piano2 Natural! 0 124 3
BrightPiano Natural! 0 123 0
MellowPiano Natural! 0 124 0
HonkyTonk Natural! 0 122 3
GrandPiano Live! 0 113 0
GrandPiano Regular 0 112 0
BrightPiano Regular 0 112 1
RockPiano Regular 0 114 2
MidiGrand Regular 0 112 2
Oct.Piano1 Regular 0 113 3
Oct.Piano2 Regular 0 114 3
HonkyTonk Regular 0 112 3
Harpsichord Regular 0 112 6
GrandHarpsi Regular 0 113 6
CP80 Regular 0 113 2
E.Piano DX EP Natural! 0 122 5
DX BrightEP Natural! 0 123 5
E.Piano Natural! 0 122 4
TremoloEP Natural! 0 124 4
FunkyEP Natural! 0 123 4
GalaxyEP Regular 0 114 4
StageEP Regular 0 117 4
E.Piano Cool! 0 119 4
Clavi Regular 0 112 7
WahClavi Regular 0 113 7
PolarisEP Regular 0 115 4
JazzChorus Regular 0 118 5
HyperTines Regular 0 113 5
PhaseEP Regular 0 120 4
NewTines Regular 0 116 5
FunkEP Regular 0 112 4
DX Modern Regular 0 112 5
VintageEP Regular 0 116 4
VenusEP Regular 0 114 5
ModernEP Regular 0 115 5
TremoloEP Regular 0 113 4
SuperDX Regular 0 117 5
SuitcaseEP Regular 0 118 4
Organ & Accordion PipeOrganP Natural! 0 123 19
PipeOrgan Regular 0 112 19
ChapelOrgn1 Regular 0 113 19
ChapelOrgn2 Regular 0 114 19
ChapelOrgn3 Regular 0 115 19
Elec.Organ Cool! 0 118 18
RotorOrgan Regular 0 117 18
RockOrgan1 Regular 0 112 18
DanceOrgan Regular 0 113 17
GospelOrg Regular 0 119 16
JazzOrgan Cool! 0 117 16
PurpleOrg Regular 0 114 18
JazzOrgan1 Regular 0 112 16
RockOrgan2 Regular 0 113 18
RotaryDrive Regular 0 116 18
FullRocker Regular 0 115 18
Elec.Organ Regular 0 118 17
DrawbarOrg Regular 0 115 16
ClickOrgan Regular 0 112 17
StadiumOrg Regular 0 118 16
MellowDraw Regular 0 115 17
JazzOrgan2 Regular 0 113 16
BrightDraw Regular 0 116 16
60'sOrgan Regular 0 116 17
JazzOrgan3 Regular 0 120 16
TheatreOrg1 Regular 0 114 16
TheatreOrg2 Regular 0 114 17
ReedOrgan Regular 0 112 20
Musette Regular 0 112 21
TuttiAccrd Regular 0 113 21
SmallAccrd Regular 0 115 21
Accordion Regular 0 116 21
TangoAccrd Regular 0 112 23
Organ & Accordion Steirisch Regular 0 117 21
Bandoneon Regular 0 113 23
SoftAccrd Regular 0 114 21
Harmonica Sweet! 0 122 22
ModernHarp Regular 0 113 22
BluesHarp Regular 0 114 22
Harmonica Regular 0 112 22
Percussion Vibraphone Natural! 0 122 11
TremoloVibes Natural! 0 124 11
Marimba Regular 0 112 12
Xylophone Regular 0 112 13
SteelDrums Regular 0 112 114
Celesta Regular 0 112 8
Glocken Regular 0 112 9
MusicBox Regular 0 112 10
TubularBell Regular 0 112 14
Kalimba Regular 0 112 108
Vibraphone Regular 0 112 11
JazzVibes Regular 0 113 11
Dulcimer Regular 0 112 15
Timpani Regular 0 112 47
Std.Kit+P Live!Drums 127 0 83
FunkKit+P Live!Drums 127 0 84
BrushKit+P Live!Drums 127 0 85
StandardKit Live!Drums 127 0 80
FunkKit Live!Drums 127 0 81
Brushkit Live!Drums 127 0 82
ArabicKit SFX Kit 126 0 35
CubanKit Live!SFX 126 0 40
PopLatinKit Live!SFX 126 0 43
StandardKit1 Drums 127 0 0
StandardKit2 Drums 127 0 1
HitKit Drums 127 0 4
RoomKit Drums 127 0 8
RockKit Drums 127 0 16
ElectroKit Drums 127 0 24
AnalogKit Drums 127 0 25
DanceKit Drums 127 0 27
JazzKit Drums 127 0 32
BrushKit Drums 127 0 40
SymphonyKit Drums 127 0 48
SFXKit1 SFX Kit 126 0 0
SFXKit2 SFX Kit 126 0 1
StyStd.Kit Live!Drums 127 0 123
StyFunkKit Live!Drums 127 0 124
StyStd.Kit+P Live!Drums 127 0 125
StyFunkKt+P Live!Drums 127 0 126
Guitar NylonGuitar Live! 0 116 24
JazzGuitar Cool! 0 115 26
Elec.Gtr Cool! 0 114 28
12StrGuitar Regular 0 113 25
SolidGuitar Regular 0 118 27
VintageAmp Regular 0 115 29
AlohaGtr Regular 0 118 26
CrunchGtr Regular 0 113 30
SmoothLead Regular 0 119 26
60'sClean Regular 0 117 27
ClassicGtr Live! 0 115 24
JazzSolGtr Cool! 0 116 26
VintageOpen Regular 0 123 27
FolkGuitar Regular 0 112 25
SolidChord Regular 0 121 27
VintageMute Regular 0 115 28
PedalSteel Regular 0 115 27
LeadGuitar Regular 0 114 29
Mandolin Regular 0 114 25
ChorusGtr Regular 0 124 27
VintageTrem Regular 0 120 27
SpanishGtr Regular 0 113 24
OctaveGtr Regular 0 113 26
DeepChorus Regular 0 114 27
CampfireGtr Regular 0 115 25
SmoothNylon Regular 0 114 24
TremoloGtr Regular 0 113 27
HawaiianGtr Regular 0 114 26
HeavyStack Regular 0 114 30
BrightClean Regular 0 116 27
WahGuitar Regular 0 122 27
ClassicGtr Regular 0 112 24
DX JazzGtr Regular 0 117 26
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
CVP-208
6
Guitar Distortion Regular 0 112 30
Elec.12Str Regular 0 119 27
FeedbackGtr Regular 0 113 29
SlideGuitar Regular 0 125 27
CleanGuitar Regular 0 112 27
MutedGuitar Regular 0 112 28
FunkGuitar Regular 0 113 28
JazzGuitar Regular 0 112 26
Overdrive Regular 0 112 29
Bass WoodBass Natural! 0 122 32
ElectricBass Natural! 0 122 33
FingerBass Regular 0 112 33
UprightBass Regular 0 113 32
PickBass Regular 0 112 34
SuperFretles Regular 0 113 35
SlapBass Regular 0 112 36
AnalogBass Regular 0 112 39
DX FunkBass Regular 0 113 37
DrySynBass Regular 0 116 39
TouchBass Regular 0 115 39
HiQBass Regular 0 113 38
FunkBass Regular 0 112 37
Aco.Bass Regular 0 112 32
Fretless Regular 0 112 35
Bass&Cymbal Regular 0 114 32
FusionBass Regular 0 113 36
RaveBass Regular 0 114 38
DanceBass Regular 0 113 39
SynthBass Regular 0 112 38
SnapBass Regular 0 114 39
ClickBass Regular 0 115 38
Brass Trumpet Sweet! 0 115 56
Trombone Sweet! 0 117 57
MutedTrump Sweet! 0 114 59
FlugelHorn Sweet! 0 118 56
SoftTrumpet Regular 0 114 56
HyperBrass Live! 0 118 62
MellowBrass Regular 0 116 61
BigBrass Regular 0 121 61
PopBrass Regular 0 118 61
BrassCombo Regular 0 115 66
SoloTrumpet Regular 0 112 56
SoloTromb Regular 0 112 57
MutedTrump Regular 0 112 59
FlugelHorn Regular 0 113 56
AirTrumpet Regular 0 117 56
Sforzando Regular 0 125 61
OctaveBrass Live! 0 116 62
MoonLight Regular 0 115 71
BalladBrass Regular 0 119 66
SaxyMood Regular 0 120 66
JazzTrumpet Regular 0 116 56
Trombone Regular 0 116 57
SoftTromb Regular 0 115 57
MellowTromb Regular 0 114 57
FrenchHorn Regular 0 112 60
PopBrass Live! 0 117 62
BrassSection Regular 0 112 61
BigBandBrs Regular 0 113 61
StepBrass Regular 0 124 61
BrightBrass Regular 0 120 61
TrumpetEns Regular 0 122 61
SmoothTromb Regular 0 118 57
Trb.Section Regular 0 113 57
MellowHorns Regular 0 119 61
SoftBrass Regular 0 123 61
FullHorns Regular 0 114 61
HighBrass Regular 0 115 61
SmallBrass Regular 0 117 61
BallroomBrs Regular 0 113 59
BrassHit Regular 0 126 61
80'sBrass Regular 0 113 62
AnalogBrs Regular 0 112 63
SoftAnalog Regular 0 114 63
FunkyAnalog Regular 0 115 62
TechnoBrass Regular 0 114 62
SynthBrass Regular 0 112 62
OberBrass Regular 0 113 63
BaritonHorn Regular 0 113 58
BaritonHit Regular 0 114 58
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Brass Tuba Regular 0 112 58
AlpBass Regular 0 113 33
W.Wind TenorSax Sweet! 0 117 66
AltoSax Sweet! 0 114 65
SopranoSax Sweet! 0 113 64
Clarinet Sweet! 0 114 71
GrowlSax Regular 0 118 66
Flute Sweet! 0 114 73
PanFlute Sweet! 0 113 75
Oboe Sweet! 0 122 68
SaxSection Regular 0 116 66
BaritoneSax Regular 0 112 67
BreathTenor Regular 0 114 66
BreathyAlto Regular 0 113 65
SopranoSax Regular 0 112 64
Clarinet Regular 0 112 71
WoodwindEns Regular 0 113 66
Class.Flute Regular 0 115 73
PanFlute Regular 0 113 73
Piccolo Regular 0 112 72
EthnicFlute Regular 0 112 75
RockBari Regular 0 113 67
TenorSax Regular 0 112 66
AltoSax Regular 0 112 65
MelClarinet Regular 0 113 71
Oboe Regular 0 112 68
EnglishHorn Regular 0 112 69
Bassoon Regular 0 112 70
Flute Regular 0 112 73
Shakuhachi Regular 0 112 77
Whistle Regular 0 112 78
Recorder Regular 0 112 74
Ocarina Regular 0 112 79
Bagpipe Regular 0 112 109
Strings Strings Live! 0 117 49
Orchestra Live! 0 116 49
Allegro Live! 0 122 49
Strings Regular 0 112 48
OrchStrings Regular 0 113 48
Violin Sweet! 0 122 40
Orch.Brass Regular 0 118 49
Orch.Flute Regular 0 119 49
Orch.Fl.Br Regular 0 120 49
Orch.Oboe Regular 0 121 49
SoloViolin Regular 0 112 40
SoftViolin Regular 0 113 40
Fiddle Regular 0 112 110
Viola Regular 0 112 41
Cello Regular 0 112 42
Contrabass Regular 0 112 43
ChamberStrs Regular 0 112 49
Str.Quartet Regular 0 114 49
ConcertoStr Regular 0 115 48
BowStrings Regular 0 116 48
MarcatoStrs Regular 0 115 49
Symphon.Str Regular 0 114 48
SlowStrings Regular 0 113 49
TremoloStrs Regular 0 112 44
PizzStrings Regular 0 112 45
AnalogStrs Regular 0 112 51
SynStrings Regular 0 112 50
OberStrings Regular 0 113 51
Harp Regular 0 112 46
Hackbrett Regular 0 113 46
Banjo Regular 0 112 105
Sitar Regular 0 112 104
Koto Regular 0 112 107
Shamisen Regular 0 112 106
Orch.Hit Regular 0 112 55
Choir & Pad Vocal Live! 0 114 53
Doo Live! 0 117 53
Bah Live! 0 118 53
Dao Live! 0 119 53
Gospel Live! 0 116 52
Humm Live! 0 118 52
HahChoir Regular 0 114 52
GothicVox Regular 0 113 53
Sunbeam Regular 0 123 88
Fantasia Regular 0 112 88
SweetHeaven Regular 0 118 88
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
7
Choir & Pad DreamHeaven Regular 0 121 88
BellHeaven Regular 0 119 88
PanHeaven Regular 0 120 88
ProHeaven Regular 0 122 88
DooBaScats Regular 0 115 53
DaaChoir Regular 0 120 53
DooChoir Regular 0 122 53
DooomChoir Regular 0 120 52
Dooom Live! 0 116 53
Mmh Live! 0 117 52
BahChoir Regular 0 121 53
HuhChoir Regular 0 119 52
Choir Regular 0 112 52
AirChoir Regular 0 112 54
VocalEnsbl Regular 0 113 52
VoxHumana Regular 0 112 53
Voices Regular 0 113 54
UuhChoir Regular 0 115 52
Insomnia Regular 0 113 94
CyberPad Regular 0 113 99
Wave2001 Regular 0 112 95
NeoWarmPad Regular 0 115 89
Atmosphere Regular 0 112 99
XenonPad Regular 0 112 91
Skydiver Regular 0 112 101
FarEast Regular 0 112 97
Template Regular 0 114 95
Equinox Regular 0 112 94
GlassPad Regular 0 114 93
DX Pad Regular 0 112 92
Symbiont Regular 0 113 88
Stargate Regular 0 114 88
Area51 Regular 0 112 89
DarkMoon Regular 0 113 89
Ionosphere Regular 0 115 94
GoldenAge Regular 0 115 88
Solaris Regular 0 114 94
TimeTravel Regular 0 116 88
Millennium Regular 0 117 88
Transform Regular 0 113 95
Dunes Regular 0 114 89
Synthesizer Oxygen Regular 0 122 81
Matrix Regular 0 123 81
WireLead Regular 0 120 81
HipLead Regular 0 113 80
HopLead Regular 0 117 80
SquareLead Regular 0 112 80
Saw.Lead Regular 0 112 81
FireWire Regular 0 116 81
Analogon Regular 0 115 81
FunkyLead Regular 0 121 81
Paraglide Regular 0 114 84
Robolead Regular 0 124 81
Fargo Regular 0 119 81
Portatone Regular 0 112 84
Blaster Regular 0 114 81
BigLead Regular 0 113 81
Warp Regular 0 117 81
Adrenaline Regular 0 113 84
Synchronize Regular 0 112 96
TinyLead Regular 0 118 80
Stardust Regular 0 112 98
AeroLead Regular 0 112 83
MiniLead Regular 0 114 80
SynthFlute Regular 0 119 80
SubAqua Regular 0 118 81
Impact Regular 0 113 87
SunBell Regular 0 113 98
UnderHeim Regular 0 112 87
Rhythmatic Regular 0 113 96
HiBias Regular 0 116 80
Vinylead Regular 0 115 80
Skyline Regular 0 115 84
Clockwork Regular 0 114 96
Organ Flutes JazzDraw! Organ Flutes 0 126 16
BluesOrgan! Organ Flutes 0 126 16
SixteenOne! Organ Flutes 0 126 16
EvenBars! Organ Flutes 0 126 16
PopOrgan! Organ Flutes 0 126 16
RockingOrg! Organ Flutes 0 126 16
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
Organ Flutes Percussive! Organ Flutes 0 126 16
GospelOrg! Organ Flutes 0 126 16
PadOrgan! Organ Flutes 0 126 16
FullRanks! Organ Flutes 0 126 16
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
8
Category Voice Name Voice Type Bank Select MIDI
Program
Namber
MSB LSB
Piano & Harpsi GrandPiano1 Natural! 0 122 0
GrandPiano2 Natural! 0 122 1
Piano&Str Natural! 0 125 0
RockPiano Natural! 0 124 2
Oct.Piano1 Natural! 0 123 3
Harpsichrd8' Natural! 0 122 6
Hc8'+4' Natural! 0 123 6
Harpsi&Str Natural! 0 124 6
Piano&EP Natural! 0 122 2
Oct.Piano2 Natural! 0 124 3
BrightPiano Natural! 0 123 0
MellowPiano Natural! 0 124 0
HonkyTonk Natural! 0 122 3
GrandPiano Regular 0 112 0
BrightPiano Regular 0 112 1
RockPiano Regular 0 114 2
MidiGrand Regular 0 112 2
HonkyTonk Regular 0 112 3
Oct.Piano1 Regular 0 113 3
Oct.Piano2 Regular 0 114 3
Harpsichord Regular 0 112 6
GrandHarpsi Regular 0 113 6
CP80 Regular 0 113 2
E.Piano DX EP Natural! 0 122 5
DX BrightEP Natural! 0 123 5
E.Piano Natural! 0 122 4
TremoloEP Natural! 0 124 4
FunkyEP Natural! 0 123 4
GalaxyEP Regular 0 114 4
StageEP Regular 0 117 4
E.Piano Cool! 0 119 4
Clavi Regular 0 112 7
WahClavi Regular 0 113 7
PolarisEP Regular 0 115 4
JazzChorus Regular 0 118 5
HyperTines Regular 0 113 5
PhaseEP Regular 0 120 4
NewTines Regular 0 116 5
FunkEP Regular 0 112 4
DX Modern Regular 0 112 5
VintageEP Regular 0 116 4
VenusEP Regular 0 114 5
ModernEP Regular 0 115 5
TremoloEP Regular 0 113 4
SuperDX Regular 0 117 5
SuitcaseEP Regular 0 118 4
Organ & Accordion PipeOrganP Natural! 0 123 19
PipeOrgan Regular 0 112 19
ChapelOrgn1 Regular 0 113 19
ChapelOrgn2 Regular 0 114 19
ChapelOrgn3 Regular 0 115 19
RotorOrgan Regular 0 117 18
RockOrgan1 Regular 0 112 18
DanceOrgan Regular 0 113 17
GospelOrg Regular 0 119 16
PurpleOrg Regular 0 114 18
JazzOrgan1 Regular 0 112 16
RockOrgan2 Regular 0 113 18
RotaryDrive Regular 0 116 18
FullRocker Regular 0 115 18
Elec.Organ Regular 0 118 17
DrawbarOrg Regular 0 115 16
ClickOrgan Regular 0 112 17
MellowDraw Regular 0 115 17
JazzOrgan2 Regular 0 113 16
BrightDraw Regular 0 116 16
60'sOrgan Regular 0 116 17
BluesOrgan Regular 0 117 17
16+1Organ Regular 0 121 16
16+2Organ Regular 0 122 16
16+4Organ Regular 0 123 16
JazzOrgan3 Regular 0 120 16
TheatreOrg1 Regular 0 114 16
TheatreOrg2 Regular 0 114 17
ReedOrgan Regular 0 112 20
Bandoneon Regular 0 113 23
Musette Regular 0 112 21
TuttiAccrd Regular 0 113 21
SmallAccrd Regular 0 115 21
Accordion Regular 0 116 21
TangoAccrd Regular 0 112 23
SoftAccrd Regular 0 114 21
Organ & Accordion Harmonica Sweet! 0 122 22
ModernHarp Regular 0 113 22
BluesHarp Regular 0 114 22
Harmonica Regular 0 112 22
Percussion Vibraphone Natural! 0 122 11
TremoloVibes Natural! 0 124 11
Marimba Regular 0 112 12
Xylophone Regular 0 112 13
SteelDrums Regular 0 112 114
Celesta Regular 0 112 8
Glocken Regular 0 112 9
MusicBox Regular 0 112 10
TubularBell Regular 0 112 14
Kalimba Regular 0 112 108
Vibraphone Regular 0 112 11
JazzVibes Regular 0 113 11
Dulcimer Regular 0 112 15
Timpani Regular 0 112 47
StandardKit1 Drums 127 0 0
StandardKit2 Drums 127 0 1
HitKit Drums 127 0 4
RoomKit Drums 127 0 8
RockKit Drums 127 0 16
ElectroKit Drums 127 0 24
AnalogKit Drums 127 0 25
DanceKit Drums 127 0 27
JazzKit Drums 127 0 32
BrushKit Drums 127 0 40
SymphonyKit Drums 127 0 48
ArabicKit SFX Kit 126 0 35
SFXKit1 SFX Kit 126 0 0
SFXKit2 SFX Kit 126 0 1
StyStd.Kit Drums 127 0 80
StyBrushKit Drums 127 0 82
Guitar NylonGuitar Regular 0 115 24
E.Guitar Cool! 0 114 28
12StrGuitar Regular 0 113 25
SolidGuitar Regular 0 118 27
VintageAmp Regular 0 115 29
PedalSteel Regular 0 125 27
CrunchGtr Regular 0 113 30
FunkGuitar Regular 0 113 28
60'sClean Regular 0 117 27
VintageOpen Regular 0 123 27
FolkGuitar Regular 0 112 25
SolidChord Regular 0 121 27
VintageMute Regular 0 115 28
LeadGuitar Regular 0 114 29
ChorusGtr Regular 0 124 27
VintageTrem Regular 0 120 27
SpanishGtr Regular 0 113 24
OctaveGtr Regular 0 113 26
DeepChorus Regular 0 114 27
CampfireGtr Regular 0 115 25
SmoothNylon Regular 0 114 24
TremoloGtr Regular 0 113 27
HawaiianGtr Regular 0 114 26
HeavyStack Regular 0 114 30
BrightClean Regular 0 116 27
WahGuitar Regular 0 122 27
ClassicGtr Regular 0 112 24
Distortion Regular 0 112 30
Elec.12Str Regular 0 119 27
FeedbackGtr Regular 0 113 29
Mandolin Regular 0 114 25
CleanGuitar Regular 0 112 27
MutedGuitar Regular 0 112 28
JazzGuitar Regular 0 112 26
Overdrive Regular 0 112 29
FolkGw_pick1 Regular 0 116 25
FolkGw_pick2 Regular 0 117 25
FolkGw_pick3 Regular 0 118 25
Bass FingerBass Regular 0 112 33
UprightBass Regular 0 113 32
PickBass Regular 0 112 34
SuperFretles Regular 0 113 35
SlapBass Regular 0 112 36
AnalogBass Regular 0 112 39
DrySynBass Regular 0 116 39
TouchBass Regular 0 115 39
HiQBass Regular 0 113 38
FunkBass Regular 0 112 37
Category Voice Name Voice Type Bank Select MIDI
Program
Namber
MSB LSB
CVP-206/204 Voice List
9
Bass Aco.Bass Regular 0 112 32
Fretless Regular 0 112 35
Bass&Cymbal Regular 0 114 32
FusionBass Regular 0 113 36
RaveBass Regular 0 114 38
DanceBass Regular 0 113 39
SynthBass Regular 0 112 38
SnapBass Regular 0 114 39
ClickBass Regular 0 115 38
Brass Trumpet Sweet! 0 115 56
Trombone Sweet! 0 117 57
MutedTrump Regular 0 112 59
FlugelHorn Regular 0 113 56
SoftTrumpet Regular 0 114 56
BrassSection Regular 0 112 61
MellowBrass Regular 0 116 61
BigBandBrs Regular 0 113 61
PopBrass Regular 0 118 61
BrassCombo Regular 0 115 66
SoloTrumpet Regular 0 112 56
SoloTromb Regular 0 112 57
JazzTrumpet Regular 0 116 56
FrenchHorn Regular 0 112 60
AirTrumpet Regular 0 117 56
StepBrass Regular 0 124 61
BrightBrass Regular 0 120 61
SoftBrass Regular 0 123 61
FullHorns Regular 0 114 61
HighBrass Regular 0 115 61
TrumpetEns Regular 0 122 61
Trombone Regular 0 116 57
SoftTromb Regular 0 115 57
MellowTromb Regular 0 114 57
SmoothTromb Regular 0 118 57
MellowHorns Regular 0 119 61
BallroomBrs Regular 0 113 59
Trb.Section Regular 0 113 57
SmallBrass Regular 0 117 61
BrassHit Regular 0 126 61
80'sBrass Regular 0 113 62
AnalogBrs Regular 0 112 63
SoftAnalog Regular 0 114 63
FunkyAnalog Regular 0 115 62
TechnoBrass Regular 0 114 62
SynthBrass Regular 0 112 62
OberBrass Regular 0 113 63
Tuba Regular 0 112 58
W.Wind TenorSax Sweet! 0 117 66
AltoSax Sweet! 0 114 65
SopranoSax Sweet! 0 113 64
Clarinet Sweet! 0 114 71
GrowlSax Regular 0 118 66
Flute Sweet! 0 114 73
PanFlute Sweet! 0 113 75
Oboe Sweet! 0 122 68
SaxSection Regular 0 116 66
BaritoneSax Regular 0 112 67
BreathTenor Regular 0 114 66
BreathyAlto Regular 0 113 65
SopranoSax Regular 0 112 64
Clarinet Regular 0 112 71
WoodwindEns Regular 0 113 66
Class.Flute Regular 0 115 73
PanFlute Regular 0 113 73
Piccolo Regular 0 112 72
EthnicFlute Regular 0 112 75
RockBari Regular 0 113 67
TenorSax Regular 0 112 66
AltoSax Regular 0 112 65
MelClarinet Regular 0 113 71
Oboe Regular 0 112 68
EnglishHorn Regular 0 112 69
Bassoon Regular 0 112 70
Flute Regular 0 112 73
Shakuhachi Regular 0 112 77
Whistle Regular 0 112 78
Recorder Regular 0 112 74
Ocarina Regular 0 112 79
Bagpipe Regular 0 112 109
Strings Orchestra Live! 0 116 49
Strings Regular 0 112 48
OrchStrings Regular 0 113 48
Category Voice Name Voice Type Bank Select MIDI
Program
Namber
MSB LSB
Strings Symphon.Str Regular 0 114 48
SlowStrings Regular 0 113 49
Violin Sweet! 0 122 40
AnalogStrs Regular 0 112 51
Orch.Brass Regular 0 118 49
Orch.Flute Regular 0 119 49
Orch.Oboe Regular 0 121 49
SoloViolin Regular 0 112 40
SoftViolin Regular 0 113 40
Viola Regular 0 112 41
Cello Regular 0 112 42
Contrabass Regular 0 112 43
ChamberStrs Regular 0 112 49
Str.Quartet Regular 0 114 49
ConcertoStr Regular 0 115 48
BowStrings Regular 0 116 48
MarcatoStrs Regular 0 115 49
TremoloStrs Regular 0 112 44
PizzStrings Regular 0 112 45
SynStrings Regular 0 112 50
TechStrings Regular 0 113 50
Fiddle Regular 0 112 110
Harp Regular 0 112 46
Hackbrett Regular 0 113 46
Banjo Regular 0 112 105
Sitar Regular 0 112 104
Koto Regular 0 112 107
Shamisen Regular 0 112 106
Orch.Hit Regular 0 112 55
Choir & Pad HahChoir Regular 0 114 52
GothicVox Regular 0 113 53
VocalEnsbl Regular 0 113 52
VoxHumana Regular 0 112 53
Choir Regular 0 112 52
AirChoir Regular 0 112 54
SweetHeaven Regular 0 118 88
Insomnia Regular 0 113 94
CyberPad Regular 0 113 99
Fantasia Regular 0 112 88
Wave2001 Regular 0 112 95
NeoWarmPad Regular 0 115 89
Atmosphere Regular 0 112 99
XenonPad Regular 0 112 91
Equinox Regular 0 112 94
DX Pad Regular 0 112 92
Symbiont Regular 0 113 88
Stargate Regular 0 114 88
Area51 Regular 0 112 89
DarkMoon Regular 0 113 89
Ionosphere Regular 0 115 94
GoldenAge Regular 0 115 88
Solaris Regular 0 114 94
Millennium Regular 0 117 88
Transform Regular 0 113 95
Dunes Regular 0 114 89
Synth Oxygen Regular 0 122 81
Matrix Regular 0 123 81
WireLead Regular 0 120 81
HipLead Regular 0 113 80
SquareLead Regular 0 112 80
Saw.Lead Regular 0 112 81
FireWire Regular 0 116 81
Analogon Regular 0 115 81
FunkyLead Regular 0 121 81
Fargo Regular 0 119 81
Portatone Regular 0 112 84
Blaster Regular 0 114 81
BigLead Regular 0 113 81
Warp Regular 0 117 81
Adrenaline Regular 0 113 84
TinyLead Regular 0 118 80
Stardust Regular 0 112 98
AeroLead Regular 0 112 83
MiniLead Regular 0 114 80
SynthFlute Regular 0 119 80
SubAqua Regular 0 118 81
SunBell Regular 0 113 98
UnderHeim Regular 0 112 87
HiBias Regular 0 116 80
Vinylead Regular 0 115 80
Skyline Regular 0 115 84
Category Voice Name Voice Type Bank Select MIDI
Program
Namber
MSB LSB
10
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
PIANO GrandPiano Regular 0 0 0
GrndPianoKSP Regular 0 1 0
MellowGrPno Regular 0 18 0
PianoStrings Regular 0 40 0
Dream Regular 0 41 0
BrightPiano Regular 0 0 1
BritePnoKSP Regular 0 1 1
ElecGrandPno Regular 0 0 2
ElecGrPnoKSP Regular 0 1 2
DetunedCP80 Regular 0 32 2
LayeredCP1 Regular 0 40 2
LayeredCP2 Regular 0 41 2
Honkytonk Regular 0 0 3
HonkytonkKSP Regular 0 1 3
El.Piano1 Regular 0 0 4
El.Piano1KSP Regular 0 1 4
MellowEP1 Regular 0 18 4
ChorusEP1 Regular 0 32 4
HardEl.Piano Regular 0 40 4
VXfadeEl.P1 Regular 0 45 4
60sEl.Piano1 Regular 0 64 4
El.Piano2 Regular 0 0 5
El.Piano2KSP Regular 0 1 5
ChorusEP2 Regular 0 32 5
DXEPHard Regular 0 33 5
DXLegend Regular 0 34 5
DXPhaseEP Regular 0 40 5
DX+AnalogEP Regular 0 41 5
DXKotoEP Regular 0 42 5
VXfadeEl.P2 Regular 0 45 5
Harpsichord Regular 0 0 6
Harpsi.KSP Regular 0 1 6
Harpsichord2 Regular 0 25 6
Harpsichord3 Regular 0 35 6
Clavi. Regular 0 0 7
Clavi.KSP Regular 0 1 7
Clavi.Wah Regular 0 27 7
PulseClavi. Regular 0 64 7
PierceClavi. Regular 0 65 7
CHROMATIC PERC. Celesta Regular 0 0 8
Glockenspiel Regular 0 0 9
MusicBox Regular 0 0 10
Orgel Regular 0 64 10
Vibraphone Regular 0 0 11
VibesKSP Regular 0 1 11
HardVibes Regular 0 45 11
Marimba Regular 0 0 12
MarimbaKSP Regular 0 1 12
SineMarimba Regular 0 64 12
Balimba Regular 0 97 12
LogDrums Regular 0 98 12
Xylophone Regular 0 0 13
TubularBells Regular 0 0 14
ChurchBells Regular 0 96 14
Carillon Regular 0 97 14
Dulcimer Regular 0 0 15
Dulcimer2 Regular 0 35 15
Cimbalom Regular 0 96 15
Santur Regular 0 97 15
ORGAN DrawbarOrgan Regular 0 0 16
DetDrawOrgan Regular 0 32 16
60sDrawOrg1 Regular 0 33 16
60sDrawOrg2 Regular 0 34 16
70sDrawOrg1 Regular 0 35 16
DrawbarOrg2 Regular 0 36 16
60sDrawOrg3 Regular 0 37 16
EvenBarOrg Regular 0 38 16
16+2'2_3Org Regular 0 40 16
OrganBass Regular 0 64 16
70sDrawOrg2 Regular 0 65 16
CheezyOrgan Regular 0 66 16
DrawbarOrg3 Regular 0 67 16
Perc.Organ Regular 0 0 17
70sPercOrg1 Regular 0 24 17
DetPercOrgan Regular 0 32 17
LightOrgan Regular 0 33 17
Perc.Organ2 Regular 0 37 17
RockOrgan Regular 0 0 18
RotaryOrgan Regular 0 64 18
SlowRotary Regular 0 65 18
ORGAN FastRotary Regular 0 66 18
ChurchOrgan Regular 0 0 19
ChurchOrgan3 Regular 0 32 19
ChurchOrgan2 Regular 0 35 19
NotreDame Regular 0 40 19
OrganFlute Regular 0 64 19
Trem.OrganFl Regular 0 65 19
ReedOrgan Regular 0 0 20
PuffOrgan Regular 0 40 20
Accordion Regular 0 0 21
AccordIt Regular 0 32 21
Harmonica Regular 0 0 22
Harmonica2 Regular 0 32 22
TangoAccord Regular 0 0 23
TangoAccord2 Regular 0 64 23
GUITAR NylonGuitar Regular 0 0 24
NylonGuitar2 Regular 0 16 24
NylonGuitar3 Regular 0 25 24
VelGtrHarmo Regular 0 43 24
Ukulele Regular 0 96 24
SteelGuitar Regular 0 0 25
SteelGuitar2 Regular 0 16 25
12StrGuitar Regular 0 35 25
Nylon&Steel Regular 0 40 25
Steel&Body Regular 0 41 25
Mandolin Regular 0 96 25
JazzGuitar Regular 0 0 26
MellowGuitar Regular 0 18 26
JazzAmp Regular 0 32 26
CleanGuitar Regular 0 0 27
ChorusGuitar Regular 0 32 27
MutedGuitar Regular 0 0 28
FunkGuitar1 Regular 0 40 28
MuteSteelGtr Regular 0 41 28
FunkGuitar2 Regular 0 43 28
JazzMan Regular 0 45 28
Overdriven Regular 0 0 29
GuitarPinch Regular 0 43 29
Distortion Regular 0 0 30
FeedbackGtr Regular 0 40 30
FeedbackGtr2 Regular 0 41 30
GtrHarmonics Regular 0 0 31
GtrFeedback Regular 0 65 31
GtrHarmonic2 Regular 0 66 31
BASS AcousticBass Regular 0 0 32
JazzRhythm Regular 0 40 32
VXUprghtBass Regular 0 45 32
FingerBass Regular 0 0 33
FingerDark Regular 0 18 33
FlangeBass Regular 0 27 33
Bass&DistEG Regular 0 40 33
FingerSlap Regular 0 43 33
FingerBass2 Regular 0 45 33
Mod.Bass Regular 0 65 33
PickBass Regular 0 0 34
MutePickBass Regular 0 28 34
FretlessBass Regular 0 0 35
Fretless2 Regular 0 32 35
Fretless3 Regular 0 33 35
Fretless4 Regular 0 34 35
Syn.Fretless Regular 0 96 35
SmthFretless Regular 0 97 35
SlapBass1 Regular 0 0 36
ResonantSlap Regular 0 27 36
PunchThumb Regular 0 32 36
SlapBass2 Regular 0 0 37
Velo.Sw.Slap Regular 0 43 37
SynthBass1 Regular 0 0 38
SynBass1Dark Regular 0 18 38
FastResoBass Regular 0 20 38
AcidBass Regular 0 24 38
ClaviBass Regular 0 35 38
TechnoBass Regular 0 40 38
Orbiter Regular 0 64 38
SquareBass Regular 0 65 38
RubberBass Regular 0 66 38
Hammer Regular 0 96 38
SynthBass2 Regular 0 0 39
MellowSyBass Regular 0 6 39
SequenceBass Regular 0 12 39
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
XG
11
BASS ClickSynBass Regular 0 18 39
SynBass2Dark Regular 0 19 39
SmoothSyBass Regular 0 32 39
ModulrSyBass Regular 0 40 39
DXBass Regular 0 41 39
XWireBass Regular 0 64 39
STRINGS Violin Regular 0 0 40
SlwAtkViolin Regular 0 8 40
Viola Regular 0 0 41
Cello Regular 0 0 42
Contrabass Regular 0 0 43
Trem.Strings Regular 0 0 44
SlwAtTremStr Regular 0 8 44
SuspenseStr Regular 0 40 44
PizzicatoStr Regular 0 0 45
Orch.Harp Regular 0 0 46
YangChin Regular 0 40 46
Timpani Regular 0 0 47
ENSEMBLE Strings1 Regular 0 0 48
StereoStrngs Regular 0 3 48
SlwAtkStrngs Regular 0 8 48
ArcoStrings Regular 0 24 48
60'sStrings Regular 0 35 48
Orchestra Regular 0 40 48
Orchestra2 Regular 0 41 48
TremOrchstra Regular 0 42 48
Velo.Strings Regular 0 45 48
Strings2 Regular 0 0 49
S.SlowStrngs Regular 0 3 49
LegatoStrngs Regular 0 8 49
WarmStrings Regular 0 40 49
Kingdom Regular 0 41 49
70'sStrings Regular 0 64 49
Strings3 Regular 0 65 49
SynStrings1 Regular 0 0 50
ResoStrings Regular 0 27 50
SynStrings4 Regular 0 64 50
SynStrings5 Regular 0 65 50
SynStrings2 Regular 0 0 51
ChoirAahs Regular 0 0 52
StereoChoir Regular 0 3 52
ChoirAahs2 Regular 0 16 52
MellowChoir Regular 0 32 52
ChoirStrings Regular 0 40 52
VoiceOohs Regular 0 0 53
SynthVoice Regular 0 0 54
SynthVoice2 Regular 0 40 54
Choral Regular 0 41 54
AnalogVoice Regular 0 64 54
OrchestraHit Regular 0 0 55
OrchestrHit2 Regular 0 35 55
Impact Regular 0 64 55
BRASS Trumpet Regular 0 0 56
Trumpet2 Regular 0 16 56
BriteTrumpet Regular 0 17 56
WarmTrumpet Regular 0 32 56
Trombone Regular 0 0 57
Trombone2 Regular 0 18 57
Tuba Regular 0 0 58
Tuba2 Regular 0 16 58
MutedTrumpet Regular 0 0 59
FrenchHorn Regular 0 0 60
Fr.HornSolo Regular 0 6 60
FrenchHorn2 Regular 0 32 60
HornOrchestr Regular 0 37 60
BrassSection Regular 0 0 61
Tp&TbSection Regular 0 35 61
BrassSect2 Regular 0 40 61
HighBrass Regular 0 41 61
MellowBrass Regular 0 42 61
SynthBrass1 Regular 0 0 62
QuackBrass Regular 0 12 62
ResoSynBrass Regular 0 20 62
PolyBrass Regular 0 24 62
SynthBrass3 Regular 0 27 62
JumpBrass Regular 0 32 62
AnaVelBrass1 Regular 0 45 62
AnalogBrass1 Regular 0 64 62
SynthBrass2 Regular 0 0 63
SoftBrass Regular 0 18 63
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
BRASS SynthBrass4 Regular 0 40 63
ChoirBrass Regular 0 41 63
AnaVelBrass2 Regular 0 45 63
AnalogBrass2 Regular 0 64 63
REED SopranoSax Regular 0 0 64
AltoSax Regular 0 0 65
SaxSection Regular 0 40 65
HyperAltoSax Regular 0 43 65
TenorSax Regular 0 0 66
BreathyTenor Regular 0 40 66
SoftTenorSax Regular 0 41 66
TenorSax2 Regular 0 64 66
BaritoneSax Regular 0 0 67
Oboe Regular 0 0 68
EnglishHorn Regular 0 0 69
Bassoon Regular 0 0 70
Clarinet Regular 0 0 71
PIPE Piccolo Regular 0 0 72
Flute Regular 0 0 73
Recorder Regular 0 0 74
PanFlute Regular 0 0 75
BlownBottle Regular 0 0 76
Shakuhachi Regular 0 0 77
Whistle Regular 0 0 78
Ocarina Regular 0 0 79
SYNTH LEAD SquareLead Regular 0 0 80
SquareLead2 Regular 0 6 80
LMSquare Regular 0 8 80
Hollow Regular 0 18 80
Shroud Regular 0 19 80
Mellow Regular 0 64 80
SoloSine Regular 0 65 80
SineLead Regular 0 66 80
SawtoothLead Regular 0 0 81
SawtoothLd2 Regular 0 6 81
ThickSaw Regular 0 8 81
DynamicSaw Regular 0 18 81
DigitalSaw Regular 0 19 81
BigLead Regular 0 20 81
HeavySynth Regular 0 24 81
WaspySynth Regular 0 25 81
PulseSaw Regular 0 40 81
Dr.Lead Regular 0 41 81
VelocityLead Regular 0 45 81
Seq.Analog Regular 0 96 81
CalliopeLead Regular 0 0 82
PurePad Regular 0 65 82
ChiffLead Regular 0 0 83
Rubby Regular 0 64 83
CharangLead Regular 0 0 84
DistortedLd Regular 0 64 84
WireLead Regular 0 65 84
VoiceLead Regular 0 0 85
SynthAahs Regular 0 24 85
VoxLead Regular 0 64 85
FifthsLead Regular 0 0 86
BigFive Regular 0 35 86
Bass&Lead Regular 0 0 87
Big&Low Regular 0 16 87
Fat&Perky Regular 0 64 87
SoftWhirl Regular 0 65 87
SYNTH PAD NewAgePad Regular 0 0 88
Fantasy Regular 0 64 88
WarmPad Regular 0 0 89
ThickPad Regular 0 16 89
SoftPad Regular 0 17 89
SinePad Regular 0 18 89
HornPad Regular 0 64 89
RotaryStrngs Regular 0 65 89
PolySynthPad Regular 0 0 90
PolyPad80 Regular 0 64 90
ClickPad Regular 0 65 90
AnalogPad Regular 0 66 90
SquarePad Regular 0 67 90
ChoirPad Regular 0 0 91
Heaven Regular 0 64 91
Itopia Regular 0 66 91
CCPad Regular 0 67 91
BowedPad Regular 0 0 92
Glacier Regular 0 64 92
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
12
SYNTH PAD GlassPad Regular 0 65 92
MetallicPad Regular 0 0 93
TinePad Regular 0 64 93
PanPad Regular 0 65 93
HaloPad Regular 0 0 94
SweepPad Regular 0 0 95
Shwimmer Regular 0 20 95
Converge Regular 0 27 95
PolarPad Regular 0 64 95
Celestial Regular 0 66 95
SYNTH EFFECTS Rain Regular 0 0 96
ClaviPad Regular 0 45 96
HarmoRain Regular 0 64 96
AfricanWind Regular 0 65 96
Carib Regular 0 66 96
SoundTrack Regular 0 0 97
Prologue Regular 0 27 97
Ancestral Regular 0 64 97
Crystal Regular 0 0 98
SynthDr.Comp Regular 0 12 98
Popcorn Regular 0 14 98
TinyBells Regular 0 18 98
RoundGlocken Regular 0 35 98
GlockenChime Regular 0 40 98
ClearBells Regular 0 41 98
ChorusBells Regular 0 42 98
SynthMallet Regular 0 64 98
SoftCrystal Regular 0 65 98
LoudGlocken Regular 0 66 98
ChristmasBel Regular 0 67 98
VibeBells Regular 0 68 98
DigitalBells Regular 0 69 98
AirBells Regular 0 70 98
BellHarp Regular 0 71 98
Gamelimba Regular 0 72 98
Atmosphere Regular 0 0 99
WarmAtmos. Regular 0 18 99
HollwRelease Regular 0 19 99
NylonElPiano Regular 0 40 99
NylonHarp Regular 0 64 99
HarpVox Regular 0 65 99
Atmos.Pad Regular 0 66 99
Planet Regular 0 67 99
Brightness Regular 0 0 100
FantasyBells Regular 0 64 100
Smokey Regular 0 96 100
Goblins Regular 0 0 101
GoblinsSynth Regular 0 64 101
Creeper Regular 0 65 101
RingPad Regular 0 66 101
Ritual Regular 0 67 101
ToHeaven Regular 0 68 101
Night Regular 0 70 101
Glisten Regular 0 71 101
BellChoir Regular 0 96 101
Echoes Regular 0 0 102
Echoes2 Regular 0 8 102
EchoPan Regular 0 14 102
EchoBells Regular 0 64 102
BigPan Regular 0 65 102
SynthPiano Regular 0 66 102
Creation Regular 0 67 102
StarDust Regular 0 68 102
Reso&Panning Regular 0 69 102
Sci-Fi Regular 0 0 103
Starz Regular 0 64 103
ETHNIC Sitar Regular 0 0 104
DetunedSitar Regular 0 32 104
Sitar2 Regular 0 35 104
Tambra Regular 0 96 104
Tamboura Regular 0 97 104
Banjo Regular 0 0 105
MutedBanjo Regular 0 28 105
Rabab Regular 0 96 105
Gopichant Regular 0 97 105
Oud Regular 0 98 105
Shamisen Regular 0 0 106
Koto Regular 0 0 107
Taisho-kin Regular 0 96 107
Kanoon Regular 0 97 107
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
ETHNIC Kalimba Regular 0 0 108
Bagpipe Regular 0 0 109
Fiddle Regular 0 0 110
Shanai Regular 0 0 111
Shanai2 Regular 0 64 111
Pungi Regular 0 96 111
Hichiriki Regular 0 97 111
PERCUSSIVE TinkleBell Regular 0 0 112
Bonang Regular 0 96 112
Altair Regular 0 97 112
GamelanGongs Regular 0 98 112
StereoGamlan Regular 0 99 112
RamaCymbal Regular 0 100 112
AsianBells Regular 0 101 112
Agogo Regular 0 0 113
SteelDrums Regular 0 0 114
GlassPerc. Regular 0 97 114
ThaiBells Regular 0 98 114
Woodblock Regular 0 0 115
Castanets Regular 0 96 115
TaikoDrum Regular 0 0 116
GranCassa Regular 0 96 116
MelodicTom Regular 0 0 117
MelodicTom2 Regular 0 64 117
RealTom Regular 0 65 117
RockTom Regular 0 66 117
SynthDrum Regular 0 0 118
AnalogTom Regular 0 64 118
ElectroPerc. Regular 0 65 118
Rev.Cymbal Regular 0 0 119
SOUND EFFECTS GtrFretNoise Regular 0 0 120
BreathNoise Regular 0 0 121
Seashore Regular 0 0 122
BirdTweet Regular 0 0 123
TelephonRing Regular 0 0 124
Helicopter Regular 0 0 125
Applause Regular 0 0 126
Gunshot Regular 0 0 127
SFX CuttingNoise Regular 64 0 0
CuttingNoiz2 Regular 64 0 1
StringSlap Regular 64 0 3
Fl.KeyClick Regular 64 0 16
Shower Regular 64 0 32
Thunder Regular 64 0 33
Wind Regular 64 0 34
Stream Regular 64 0 35
Bubble Regular 64 0 36
Feed Regular 64 0 37
Dog Regular 64 0 48
Horse Regular 64 0 49
BirdTweet2 Regular 64 0 50
Ghost Regular 64 0 54
Maou Regular 64 0 55
PhoneCall Regular 64 0 64
DoorSqueak Regular 64 0 65
DoorSlam Regular 64 0 66
ScratchCut Regular 64 0 67
ScratchSplit Regular 64 0 68
WindChime Regular 64 0 69
TelphonRing2 Regular 64 0 70
CarEngineIgn Regular 64 0 80
CarTiresSqel Regular 64 0 81
CarPassing Regular 64 0 82
CarCrash Regular 64 0 83
Siren Regular 64 0 84
Train Regular 64 0 85
JetPlane Regular 64 0 86
Starship Regular 64 0 87
Burst Regular 64 0 88
RollrCoaster Regular 64 0 89
Submarine Regular 64 0 90
Laugh Regular 64 0 96
Scream Regular 64 0 97
Punch Regular 64 0 98
Heartbeat Regular 64 0 99
FootSteps Regular 64 0 100
MachineGun Regular 64 0 112
LaserGun Regular 64 0 113
Explosion Regular 64 0 114
Firework Regular 64 0 115
Category Voice Name Voice Type Bank Select MIDI
Program
Number
MSB LSB
13
Drum/key Assignment List
Liste der Tastenzuordnungen der Schlaginstrumente
Liste d’assignation instrument de batterie/touche du clavier
Lista de asignación de teclas/batería
• Key Off: Keys marked “O” stop sounding the instant they are released.
• Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number
Bank Select MSB (0-127) 127 127 127 127 127 127 127 127
Bank Select LSB (0-127) 0 0 0 0 0 0 0 0
Program Change (0-127) 0 1 4 8 16 24 25 27
MIDI
Keyboard
Note
Key
Off
Alternate
Group
Standard Kit1 Standard Kit2 Hit Kit Room Kit Rock Kit Electro Kit Analog Kit Dance Kit
Note# Note
13 C
-1 (C
0) 3Surdo Mute
14 D-1 (D0) 3Surdo Open
15 D
-1 (D
0) Hi Q
16 E-1 (E0) Whip Slap
17 F-1 (F0) 4Scratch H
18 F
-1 (F
0) 4Scratch L
19 G-1 (G0) Finger Snap
20 G
-1 (G
0) Click Noise
21 A-1 (A0) Metronome Click
22 A
-1 (A
0) Metronome Bell
23 B-1 (B0) Seq Click L
24 C0 C1 Seq Click H
25 C
0C
1Brush Tap
26 D0 D1 OBrush Swirl
27 D
0D
1Brush Slap
28 E0 E1 OBrush Tap Swirl Reverse Cymbal Reverse Cymbal Reverse Cymbal
29 F0 F1 O Snare Roll
30 F
0F
1Castanet Hi Q 2 Hi Q 2 Hi Q 2
31 G0 G1 Snare Soft Snare Soft 2 Snare Electro Snare Noisy Snare Snappy Electro Snare Noisy 4 Snare Techno
32 G
0G
1Sticks
33 A0 A1 Kick Soft Kick Tight L Kick 3 Kick 3 Kick Techno Q
34 A
0A
1Open Rim Shot Open Rim Shot H Short Snare Pitched Rim Gate
35 B0 B1 Kick Tight Kick Wet Kick 2 Kick Gate Kick Analog Short Kick Techno L
36 C1 C2 Kick Kick Short Kick Tight H Kick Gate Kick Gate Heavy Kick Analog Kick Techno
37 C
1C
2Side Stick Side Stick Light Stick Ambient Side Stick Analog Side Stick Analog
38 D1 D2 Snare Snare Short Snare Ambient Snare Snappy Snare Rock Snare Noisy 2 Snare Analog Snare Clap
39 D
1D
2Hand Clap
40 E1 E2 Snare Tight Snare Tight H Snare Tight 2 Snare Tight Snappy Snare Rock Tight Snare Noisy 3 Snare Analog 2 Snare Dry
41 F1 F2 Floor Tom L Hybrid Tom 1 Tom Room 1 Tom Rock 1 Tom Electro 1 Tom Analog 1 Tom Analog 1
42 F
1F
21Hi-Hat Closed Hi-Hat Closed 2 Hi-Hat Closed Analog Hi-Hat Closed 3
43 G1 G2 Floor Tom H Hybrid Tom 2 Tom Room 2 Tom Rock 2 Tom Electro 2 Tom Analog 2 Tom Analog 2
44 G
1G
21Hi-Hat Pedal Hi-Hat Pedal 2 Hi-Hat Closed Analog 2 Hi-Hat Closed Analog 3
45 A1 A2 Low Tom Hybrid Tom 3 Tom Room 3 Tom Rock 3 Tom Electro 3 Tom Analog 3 Tom Analog 3
46 A
1A
21Hi-Hat Open Hi-Hat Open 2 Hi-Hat Open Analog Hi-Hat Open 3
47 B1 B2 Mid Tom L Hybrid Tom 4 Tom Room 4 Tom Rock 4 Tom Electro 4 Tom Analog 4 Tom Analog 4
48 C2 C3 Mid Tom H Hybrid Tom 5 Tom Room 5 Tom Rock 5 Tom Electro 5 Tom Analog 5 Tom Analog 5
49 C
2C
3Crash Cymbal 1 Crash Analog Crash Analog
50 D2 D3 High Tom Hybrid Tom 6 Tom Room 6 Tom Rock 6 Tom Electro 6 Tom Analog 6 Tom Analog 6
51 D
2D
3Ride Cymbal 1
52 E2 E3 Chinese Cymbal
53 F2 F3 Ride Cymbal Cup
54 F
2F
3Tambourine Tambourine Light
55 G2 G3 Splash Cymbal
56 G
2G
3Cowbell Cowbell Analog Cowbell Analog
57 A2 A3 Crash Cymbal 2
58 A
2A
3Vibraslap
59 B2 B3 Ride Cymbal 2
60 C3 C4 Bongo H
61 C
3C
4Bongo L
62 D3 D4 Conga H Mute Conga Analog H Conga Analog H
63 D
3D
4Conga H Open Conga Analog M Conga Analog M
64 E3 E4 Conga L Conga Analog L Conga Analog L
65 F3 F4 Timbale H
66 F
3F
4Timbale L
67 G3 G4 Agogo H
68 G
3G
4Agogo L
69 A3 A4 Cabasa
70 A
3A
4Maracas Maracas 2 Maracas 2
71 B3 B4 O Samba Whistle H
72 C4 C5 O Samba Whistle L
73 C
4C
5Guiro Short
74 D4 D5 O Guiro Long
75 D
4D
5Claves Claves 2 Claves 2
76 E4 E5 Wood Block H
77 F4 F5 Wood Block L
78 F
4F
5Cuica Mute Scratch H 2 Scratch H 2 Scratch H 2
79 G4 G5 Cuica Open Scratch L 2 Scratch L 2 Scratch L 2
80 G
4G
52Triangle Mute
81 A4 A5 2Triangle Open
82 A
4A
5Shaker
83 B4 B5 Jingle Bells
84 C5 C6 Bell Tree
85 C
5(C
6)
86 D5 (D6)
87 D
5(D
6)
88 E5 (E6)
89 F5 (F6)
90 F
5(F
6)
91 G5 (G6)
Same as Standard Kit
1
No Sound
14
Bank Select MSB (0-127) 127 127 127 127 127 127 127 127
Bank Select LSB (0-127) 0 0 0 0 0 0 0 0
Program Change (0-127) 32 40 48 80 / 123 80 81 / 124 82 82
MIDI
Keyboard
Note
Key
Off
Alternate
Group
Jazz Kit Brush Kit Symphony Kit Standard Kit
Sty Std.Kit
(CVP-210/208)
Sty Std.Kit
(CVP-206/204)
Funk Kit
Sty Funk Kit
(CVP-210/208)
Sty BrushKit
(CVP-210/208)
Sty BrushKit
(CVP-206/204)
Note# Note
13 C
-1 (C
0) 3
14 D-1 (D0) 3
15 D
-1 (D
0)
16 E-1 (E0)
17 F-1 (F0) 4
18 F
-1 (F
0) 4
19 G-1 (G0)
20 G
-1 (G
0)
21 A-1 (A0)
22 A
-1 (A
0)
23 B-1 (B0)
24 C0 C1
25 C
0C
1Brush Tap Stereo Brush Tap Style Std Brush Tap Stereo Brush Tap Stereo Brush Tap Style Brush
26 D0 D1 O Brush Swirl Stereo Brush Swirl Style Std Brush Swirl Stereo Brush Swirl Stereo Brush Swirl StyleBrush
27 D
0D
1Brush Slap Stereo Brush Slap Style Std Brush Slap Stereo Brush Slap Stereo Brush Slap Style Brush
28 E0 E1 O Brush Tap Swirl Stereo BrushTapSwirlStyleStd Brush Tap Swirl Stereo Brush Tap Swirl Stereo BrushTapSwirlStyleBrsh
29 F0 F1 O Snare Roll Stereo Snare Roll Stereo Snare Roll Stereo
30 F
0F
1
31 G0 G1 Snare Jazz H Brush Slap 2 Snare L Stereo Snare Soft Style Std Snare Funk L Stereo Brush Slap 2 Stereo Snare Soft Style Brush
32 G
0G
1
33 A0 A1 Kick Soft 2 Kick Soft Stereo Kick Soft Style Std Kick Soft Stereo Kick Soft Stereo Kick Soft Style Brush
34 A
0A
1
Open Rim Shot Light
Open Rim Shot Stereo
Open Rim Shot Style Std
Open Rim Shot Stereo Open Rim Shot Stereo
OpenRimShot StyleBrush
35 B0 B1 Gran Cassa Kick Light Stereo Kick Tight Style Std Kick Std Stereo Kick Std Stereo Kick Tight Style Brush
36 C1 C2 Kick Jazz Kick Jazz Gran Cassa Mute Kick Std Stereo Kick Style Std Kick Funk Stereo Kick Funk Stereo Kick Style Brush
37 C
1C
2Side Stick Light Side Stick Light Side Stick Stereo Side Stick Style Std Side Stick Stereo Side Stick Stereo Side Stick Style Brush
38 D1 D2 Snare Jazz L Brush Slap 3 Band Snare Snare M Stereo Snare Style Std Snare Funk M Stereo Snare Brush M Stereo Snare Style Brush
39 D
1D
2
40 E1 E2 Snare Jazz M Brush Tap 2 Band Snare 2 Snare H Stereo Snare Tight Style Std Snare Funk H Stereo Snare Brush H Stereo Snare Tight StyleBrush
41 F1 F2 Tom Brush 1 Floor Tom L Stereo Floor Tom L Style Std Floor Tom L Stereo
Brush Floor Tom L Stereo
Floor Tom L StyleBrush
42 F
1F
21 Hi-Hat Closed Stereo Hi-Hat Closed StyleStd Hi-Hat Closed Stereo Hi-Hat Closed Stereo Hi-HatClosedStyleBrush
43 G1 G2 Tom Brush 2 Floor Tom H Stereo Floor Tom H Style Std Floor Tom H Stereo
Brush Floor Tom H Stereo
Floor Tom H StyleBrush
44 G
1G
21 Hi-Hat Pedal Stereo Hi-Hat Pedal Style Std Hi-Hat Pedal Stereo Hi-Hat Pedal Stereo Hi-HatPedal StyleBrush
45 A1 A2 Tom Brush 3 Low Tom Stereo Low Tom Style Std Low Tom Stereo Brush Low Tom Stereo Low Tom Style Brush
46 A
1A
21 Hi-Hat Open Stereo Hi-Hat Open Style Std Hi-Hat Open Stereo Hi-Hat Open Stereo Hi-HatOpen StyleBrush
47 B1 B2 Tom Brush 4 Mid Tom L Stereo Mid Tom L Style Std Mid Tom L Stereo Brush Mid Tom L Stereo Mid Tom L Style Brush
48 C2 C3 Tom Brush 5 Mid Tom H Stereo Mid Tom H Style Std Mid Tom H Stereo Brush Mid Tom H Stereo Mid Tom H Style Brush
49 C
2C
3Hand Cymbal
Crash Cymbal 1 Stereo CrashCymbal 1 StyleStd
Crash Cymbal 1 Stereo
Brush Crash Cymbal 1 Stereo
CrashCymbal1StyleBrush
50 D2 D3 Tom Brush 6 High Tom Stereo High Tom Style Std High Tom Stereo Brush High Tom Stereo High Tom Style Brush
51 D
2D
3Hand Cymbal Short Ride Cymbal 1 Stereo Ride Cymbal 1 StyleStd Ride Cymbal 1 Stereo
Brush Ride Cymbal 1 Stereo
RideCymbal1 StyleBrush
52 E2 E3
Chinese Cymbal Stereo ChineseCymbal StyleStd
Chinese Cymbal Stereo Chinese Cymbal Stereo
ChineseCymbalStyleBrsh
53 F2 F3
Ride Cymbal Cup Stereo RideCymbalCup StyleStd Ride Cymbal Cup Stereo
Brush Ride Cymbal Cup Stereo
RideCymbalCupStyleBrsh
54 F
2F
3
55 G2 G3 Splash Cymbal Stereo Splash Cymbal StyleStd Splash Cymbal Stereo Splash Cymbal Stereo
SplashCymbalStyleBrush
56 G
2G
3
57 A2 A3 Hand Cymbal 2
Crash Cymbal 2 Stereo CrashCymbal 2 StyleStd
Crash Cymbal 2 Stereo
Brush Crash Cymbal 2 Stereo
CrashCymbal2StyleBrush
58 A
2A
3
59 B2 B3
Hand Cymbal 2 Short
Ride Cymbal 2 Stereo Ride Cymbal 2 StyleStd Ride Cymbal 2 Stereo
Brush Ride Cymbal 2 Stereo RideCymbal2 StyleBrush
60 C3 C4
61 C
3C
4
62 D3 D4
63 D
3D
4
64 E3 E4
65 F3 F4
66 F
3F
4
67 G3 G4
68 G
3G
4
69 A3 A4
70 A
3A
4
71 B3 B4 O
72 C4 C5 O
73 C
4C
5
74 D4 D5 O
75 D
4D
5
76 E4 E5
77 F4 F5
78 F
4F
5
79 G4 G5
80 G
4G
52
81 A4 A5 2
82 A
4A
5
83 B4 B5
84 C5 C6
85 C
5(C
6)
86 D5 (D6)
87 D
5(D
6)
88 E5 (E6)
89 F5 (F6)
90 F
5(F
6)
91 G5 (G6)
15
Bank Select MSB (0-127) 127 127 127 126 126 126 126 126
Bank Select LSB (0-127) 0 0 0 0 0 0 0 0
Program Change (0-127) 83 / 125 84 / 126 85 35 0 1 40 43
MIDI
Keyboard
Note
Key
Off
Alternate
Group
Std.Kit+P
StyStd.Kit+P
(CVP-210/208)
Funk Kit+P
StyFunk Kt+P
(CVP-210/208)
Brush Kit+P
(CVP-210/208)
Arabic Kit SFX Kit1 SFX Kit2 Cuban Kit
(CVP-210/208)
PopLatin Kit
(CVP-210/208)
Note# Note
13 C
-1 (C
0) 3
14 D-1 (D0) 3
15 D
-1 (D
0)
16 E-1 (E0)
17 F-1 (F0) 4
18 F
-1 (F
0) 4Hand Clap Stereo
19 G-1 (G0)
20 G
-1 (G
0)
21 A-1 (A0)
22 A
-1 (A
0) Conga H Tip Stereo Conga H Tip Stereo
23 B-1 (B0) Conga H Heel Stereo Conga H Heel Stereo
24 C0 C1 Nakarazan Dom Conga H Open Stereo Conga H Open Stereo
25 C
0C
1Brush Tap Stereo Brush Tap Stereo Brush Tap Stereo Cabasa Conga H Mute Stereo Conga H Mute Stereo
26 D0 D1 OBrush Swirl Stereo Brush Swirl Stereo Brush Swirl Stereo Nakarazan Edge
Conga H Slap Open Stereo
Conga H Slap Open Stereo
27 D
0D
1Brush Slap Stereo Brush Slap Stereo Brush Slap Stereo Hager Dom Conga H Slap Stereo Conga H Slap Stereo
28 E0 E1 O
Brush Tap Swirl Stereo
Brush Tap Swirl Stereo Brush Tap Swirl Stereo Hager Edge
Conga H Slap Mute Stereo
Conga H Slap Mute Stereo
29 F0 F1 O Snare Roll Stereo Snare Roll Stereo Snare Roll Stereo Bongo H Conga L Tip Stereo Conga L Tip Stereo
30 F
0F
1Bongo L Conga L Heel Stereo Conga L Heel Stereo
31 G0 G1 Snare L Stereo Snare L Stereo Brush Slap 2 Stereo Conga H Mute Conga L Open Stereo Conga L Open Stereo
32 G
0G
1Conga H Open Conga L Mute Stereo Conga L Mute Stereo
33 A0 A1 Kick Soft Stereo Kick Soft Stereo Kick Soft Stereo Conga L
Conga L Slap Open Stereo
Conga L Slap Open Stereo
34 A
0A
1
Open Rim Shot Stereo
Open Rim Shot Stereo Open Rim Shot Stereo Zagrouda H Conga L Slap Stereo Conga L Slap Stereo
35 B0 B1 Kick Light Stereo Kick Std Stereo Kick Std Stereo Zagrouda L Conga L Slide Stereo Conga L Slide Stereo
36 C1 C2 Kick Std Stereo Kick Funk Stereo Kick Funk Stereo Kick Soft Cutting Noise Phone Call
Bongo H Open 1 Finger Stereo Bongo H Open 1 finger Stereo
37 C
1C
2Side Stick Stereo Side Stick Stereo Side Stick Stereo Side Stick Cutting Noise 2 Door Squeak
Bongo H Open 3 Finger Stereo Bongo H Open 3 finger Stereo
38 D1 D2 Snare M Stereo Snare Funk M Stereo Snare Brush M Stereo Snare Soft Door Slam Bongo H Rim Stereo Bongo H Rim Stereo
39 D
1D
2Hand Clap Stereo Hand Clap Stereo Hand Clap Stereo Arabic Hand Clap String Slap Scratch Cut Bongo H Tip Stereo Bongo H Tip Stereo
40 E1 E2 Snare H Stereo Snare Funk H Stereo Snare Brush H Stereo Snare Scratch H 3 Bongo H Heel Stereo Bongo H Heel Stereo
41 F1 F2 Floor Tom L Stereo Floor Tom L Stereo
Brush Floor Tom L Stereo
Floor Tom L Wind Chime Bongo H Slap Stereo Bongo H Slap Stereo
42 F
1F
21Hi-Hat Closed Stereo Hi-Hat Closed Stereo Hi-Hat Closed Stereo Hi-Hat Closed Telephone Ring 2
Bongo L Open 1 Finger Stereo Bongo L Open 1 finger Stereo
43 G1 G2 Floor Tom H Stereo Floor Tom H Stereo
Brush Floor Tom H Stereo
Floor Tom H
Bongo L Open 3 Finger Stereo Bongo L Open 3 finger Stereo
44 G
1G
21Hi-Hat Pedal Stereo Hi-Hat Pedal Stereo Hi-Hat Pedal Stereo Hi-Hat Pedal Bongo L Rim Stereo Bongo L Rim Stereo
45 A1 A2 Low Tom Stereo Low Tom Stereo Brush Low Tom Stereo Low Tom Bongo L Tip Stereo Bongo L Tip Stereo
46 A
1A
21Hi-Hat Open Stereo Hi-Hat Open Stereo Hi-Hat Open Stereo Hi-Hat Open Bongo L Heel Stereo Bongo L Heel Stereo
47 B1 B2 Mid Tom L Stereo Mid Tom L Stereo Brush Mid Tom L Stereo Mid Tom L Bongo L Slap Stereo Bongo L Slap Stereo
48 C2 C3 Mid Tom H Stereo Mid Tom H Stereo Brush Mid Tom H Stereo Mid Tom H Timbale L Open Stereo Timbale L Open Stereo
49 C
2C
3
Crash Cymbal 1 Stereo
Crash Cymbal 1 Stereo
Brush Crash Cymbal 1 Stereo
Crash Cymbal 1
50 D2 D3 High Tom Stereo High Tom Stereo Brush High Tom Stereo High Tom
51 D
2D
3Ride Cymbal 1 Stereo Ride Cymbal 1 Stereo
Brush Ride Cymbal 1 Stereo
Ride Cymbal 1
52 E2 E3
Chinese Cymbal Stereo
Chinese Cymbal Stereo Chinese Cymbal Stereo Crash Cymbal 2 Flute Key Click
Car Engine Ignition
53 F2 F3
Ride Cymbal Cup Stereo
Ride Cymbal Cup Stereo
Brush Ride Cymbal Cup Stereo
Duhulla Dom Car Tires Squeal
54 F
2F
3Tambourine Stereo Tambourine Stereo Tambourine Stereo Tambourine Car Passing Timbale H Open Stereo Timbale H Open Stereo
55 G2 G3 Splash Cymbal Stereo Splash Cymbal Stereo Splash Cymbal Stereo Duhulla Tak Car Crash
56 G
2G
3Cowbell Stereo Cowbell Stereo Cowbell Stereo Cowbell Siren
57 A2 A3
Crash Cymbal 2 Stereo
Crash Cymbal 2 Stereo
Brush Crash Cymbal 2 Stereo
Duhulla Sak Train
58 A
2A
3Claves Jet Plane
59 B2 B3 Ride Cymbal 2 Stereo Ride Cymbal 2 Stereo
Brush Ride Cymbal 2 Stereo
Doff Dom Starship
60 C3 C4 Bongo H Stereo Bongo H Stereo Bongo H Stereo Katem Dom Burst Cowbell Top Stereo Cowbell Top Stereo
61 C
3C
4Bongo L Srereo Bongo L Srereo Bongo L Srereo Katem Tak Roller Coaster
62 D3 D4 Conga H Mute Stereo Conga H Mute Stereo Conga H Mute Stereo Katem Sak Submarine
63 D
3D
4Conga H Open Stereo Conga H Open Stereo Conga H Open Stereo Katem Tak
64 E3 E4 Conga L Stereo Conga L Stereo Conga L Stereo Doff Tak Guiro Short Stereo Guiro Short Stereo
65 F3 F4 Timbale H Stereo Timbale H Stereo Timbale H Stereo Tabla Dom Guiro Long Stereo Guiro Long Stereo
66 F
3F
4Timbale L Stereo Timbale L Stereo Timbale L Stereo Tabla Tak1
67 G3 G4 Tabla Tik
68 G
3G
4Tabla Tak2 Shower Laugh Tambourine Stereo Tambourine Stereo
69 A3 A4 Cabasa Stereo Cabasa Stereo Cabasa Stereo Tabla Sak Thunder Scream
70 A
3A
4Maracas Stereo Maracas Stereo Maracas Stereo Tabla Roll of Edge Wind Punch
71 B3 B4 O Tabla Flam Stream Heart Beat
72 C4 C5 O Sagat 1 Bubble Foot Steps Maracas Stereo Maracas Stereo
73 C
4C
5Guiro Short Stereo Guiro Short Stereo Guiro Short Stereo Tabel Dom Feed Shaker Stereo Shaker Stereo
74 D4 D5 O Guiro Long Stereo Guiro Long Stereo Guiro Long Stereo Sagat 3 Cabasa Stereo Cabasa Stereo
75 D
4D
5Tabel Tak Cuica Mute Stereo
76 E4 E5 Sagat 2 Cuica Open Stereo
77 F4 F5 Rik Dom
78 F4F
5Cuica Mute Stereo Cuica Mute Stereo Cuica Mute Stereo Rik Tak 2
79 G4 G5 Cuica Open Stereo Cuica Open Stereo Cuica Open Stereo Rik Finger 1
80 G4G
52Triangle Mute Stereo Triangle Mute Stereo Triangle Mute Stereo Rik Tak 1
81 A4 A5 2Triangle Open Stereo Triangle Open Stereo Triangle Open Stereo Rik Finger 2 Triangle Mute Stereo
82 A4A
5Shaker Stereo Shaker Stereo Shaker Stereo Rik Brass Tremolo Triangle Open Stereo
83 B4 B5 Rik Sak
84 C5 C6 Wind Chime Stereo Wind Chime Stereo Wind Chime Stereo Rik Tik Dog Machine Gun Wind Chime Stereo
85 C5(C6) Horse Laser Gun
86 D5 (D6) Bird Tweet 2 Explosion
87 D5(D6) Firework
88 E5 (E6)
89 F5 (F6)
90 F5(F6) Ghost
91 G5 (G6) Maou
16
Category Style Name CVP-210 CVP-208 CVP-206 CVP-204
8Beat Cool8Beat ●● --
8BeatModern ●●●●
OrganBallad ●●●●
Unplugged ●●●●
8BeatAdria ●●●●
HeartBeat ●●●●
60'sGtrPop ●●●●
60's8Beat ●●●●
8Beat1 ●●●●
8Beat2 ●●●●
BubblegumPop ●●●●
PianoBallad ●●●●
RomanticBallad ●●●●
RomanticPiano ●●●●
LoveSong ●●●●
AcousticBallad ●●●●
6-8ModernEP ●●●●
6-8Orchestral ●●●●
6-8SlowRock1 ●●●●
6-8SlowRock2 ●●●●
OffBeat ●●●●
60'sRock1 ●●●●
60'sRock2 ●●●●
60'sRock3 ●● --
BritPop ●---
RockBallad ●●●●
HardRock ●● --
Rock+HalfTime ●●●●
SwedishPopShfl ●● --
RockShuffle ●●●●
RootRock ●●●●
8BeatRock ●●●●
SynthRock ●●● -
8BeatPiano ●●●●
J-Ballad1 ●●●●
J-Ballad2 ●●●●
16Beat 16Beat ●●●●
PopBallad ●●●●
70'sPopBallad ●● --
16BeatBallad1 ●●●●
16BeatBallad2 ●●●●
SlowBallad ●●● -
FusionShuffle ●● --
PopShuffle1 ●●●●
PopShuffle2 ●●●●
GuitarPop ●●●●
16BtUptempo ●●●●
Slow&Easy ●●●●
AnalogBallad ●●●●
R&B ●●●●
HipHopLight ●●●●
KoolShuffle ●●●●
FunkyFusion ●●●●
JazzRock ●●●●
JazzPop ●●●●
16BeatFunk ●●● -
Piano16Beat ●●●●
J-16Ballad ●●●●
Dance Ibiza2003 ●● --
RetroPop ●●●●
DreamDance ●● --
EuroTrance ●●●●
HouseMusik ●●●●
Ibiza2000 ●●●●
SwingHouse ●●●●
TechnoPolis ●---
Clubdance ●●●●
ClubLatin ●●●●
Garage1 ●●●●
Garage2 ●---
TechnoParty ●●●●
USPop ●● --
UKPop ●●●●
Groundbeat ●● --
HipHopGroove ●●●●
TripHop ●---
CoolBlues ●● --
HipShuffle ●● --
DanceShuffle ●●●●
HipHopPop ●●●●
6-8Trance ●● --
80'sDance ●●●●
Disco DiscoPhilly1 ●● --
70'sDisco1 ●●●●
70'sDisco2 ●●●●
70'sDisco3 ●●● -
Disco LatinDisco ●●●●
DiscoPhilly2 ●---
SaturdayNight ●●●●
DiscoChocolate ●●● -
DiscoHands ●●●●
DiscoFunk ●●●●
DiscoSamba ●● --
DiscoParty ●●●●
DiscoFox ●●●●
FunkyDisco ●●●●
DiscoVenus ●●● -
BigBand BigBandFast1 ●●●●
BigBandMid1 ●●●●
30'sBigBand ●● --
JungleDrum ●●●●
OrchestraSwing ●● --
BigBandFast2 ●●●●
BigBandMid2 ●●●●
40'sBigBand ●●●●
CatGroove ●●●●
OrchJazzBallad ●●● -
EasyListening ●● --
BigBandBallad ●●●●
MidnightSwing ●●● -
MoonlightBallad ●●●●
BigBandShfl1 ●●●●
BigBandShfl2 ●●●●
BigBandBoogie ●● --
Swing&Jazz AcousticJazz ●● --
JazzClub ●●●●
MediumJazz ●●●●
Swing1 ●●●●
Swing2 ●●●●
ModernJazzBld ●● --
DixieJazz ●●●●
JazzPiano1 ●●●●
JazzBallad1 ●●●●
GypsySwing ●●●●
Dixieland1 ●●●●
Ragtime1 ●●●●
AfroCuban ●●●●
Bebop ●●●●
LoungePiano ●●● -
ElectricJazz ●●●●
StrideSwing ●●●●
PianoShuffle ●●●●
JazzVocal ●---
Charleston ●●●●
Dixieland2 ●●●●
Ragtime2 ●---
Five-Four ●●●●
R&B BluesRock ●● --
FranklySoul ●● --
Soul ●●●●
DetroitPop1 ●●●●
DetroitPop2 ●●●●
GospelSwing ●● --
GospelSisters ●● --
GospelBrothers ●●●●
GospelFunk ●● --
GospelShuffle ●---
NewGospel ●---
AmazingGospel ●●●●
Twist ●●● -
CrocoTwist ●●●●
ComboTwist ●●●●
60'sRock&Roll ●●●●
Rock&Roll ●●●●
DenimBlues ●● --
6-8Blues ●●●●
BlueberryBlues ●●●●
BluesPiano1 ●●●●
BluesPiano2 ●●●●
BluesBallad ●●●●
BluesShuffle ●●●●
4-4Blues ●●●●
6-8Soul ●●●●
ModernR&B ●● --
SoulBeat ●●●●
SoulShuffle ●●●●
Funk ●● --
CoolFunk ●●●●
R&BBallad ●●●●
Swingin'Boogie ●●●●
BoogieWoogie ●●●●
ComboBoogie ●●●●
Category Style Name CVP-210 CVP-208 CVP-206 CVP-204
Style List / Liste der Styles / Liste des styles / Lista de estilos
●: available
17
R&B LovelyShuffle ●---
Country Country8Beat1 ●●●●
CountryPop1 ●●●●
CountryRock ●●●●
CntrySing-along ●●● -
CountrySwing1 ●●●●
ModCntryBld ●● --
ModCntryPop ●●●●
CountryBallad ●●●●
Country2-4 ●●●●
CowboyBoogie ●●●●
Country8Beat2 ●●●●
CountryPop2 ●●●●
CntryBrothers ●●●●
CountryShuffle ●●●●
CountrySwing2 ●● --
Bluegrass1 ●●●●
Bluegrass2 ●● --
Hoedown ●●●●
FingerPickin ●●●●
CntryUnplugged ●---
CntryTwoStep ●●●●
SingrSngWriter ●● --
CountrySlide ●●● -
Latin BrazilianSamba ●●●●
PopSamba ●●●●
BossaNova ●●●●
PopBossa1 ●●●●
PopBossa2 ●● --
BigBandSamba ●● --
BigBandMambo ●●●●
BigBandSalsa ●●●●
CoolBossa ●● --
SlowBossa ●●●●
Tijuana ●●●●
DiscoLatin ●●●●
LatinPop ●---
RockChaCha ●●●●
FastBossa ●●●●
Mambo1 ●●●●
Mambo2 ●---
Salsa ●●●●
Montuno ●●●●
Merengue ●● --
GuitarBossa1 ●●●●
GuitarBossa2 ●●●●
ComboSamba ●●●●
Beguine ●●●●
ComboRumba ●●●●
GypsyRumba ●●●●
RmbFlamenca ●●●●
RumbaIsland ●●● -
PopRumba ●---
Espagnole ●● --
Carnival ●●● -
Caribbean ●●●●
HappyReggae ●●●●
SheriffReggae ●● --
JumboReggae ●●●●
Bolero ●● --
March USMarch ●●●●
6-8March ●●●●
ChildrensMarch ●●●●
GermanMarch1 ●●●●
GermanMarch2 ●● --
BandMarch ●●● -
PolkaPop ●●●●
OberPolka ●●●●
Tarantella ●●●●
PubPiano ●●●●
Waltz GuitarSerenade ●●●●
SwingWaltz ●●●●
PopWaltz ●●●●
JazzWaltz1 ●●●●
JazzWaltz2 ●●●●
BandWaltz ●● --
CountryWaltz ●●●●
TraditionalWaltz ●● --
OberWalzer ●●●●
Musette ●●●●
ClassicWaltz ●●●●
MidnightWaltz ●●●●
Ballroom VienneseWaltz1 ●●●●
VienneseWaltz2 ●● --
EnglishWaltz ●●●●
Slowfox ●●●●
Category Style Name CVP-210 CVP-208 CVP-206 CVP-204
Ballroom Foxtrot ●●●●
Quickstep ●●●●
OrgQuickstep ●●●●
Tango1 ●●●●
Tango2 ●●●●
Swingfox ●●●●
Pasodoble ●●●●
Samba ●●●●
ChaChaCha ●●●●
Rumba ●●●●
Jive ●●●●
SchlagerBeat ●●●●
SchlagerPop ●●●●
SchlagerRock ●● --
SchlagerAlp ●●●●
SchlagerRumba ●●●●
Movie&Show MovieBallad ●●●●
MovieSwing ●● --
MoviePanther ●●●●
SecretService ●●●●
WildWest ●● --
OrchestralMarch ●●●●
OrchestralBolero ●● --
OrchestralPolka ●●●●
ClassicMoon6-8 ●● --
ClassicPianoBld ●●●●
PopClassics ●● --
BroadwayBallad ●---
TapDanceSwing ●●●●
Santa'sSwing ●●●●
ChristmasSwing ●●●●
ChristmasWaltz ●●●●
Showtune ●●●●
World IrishDance ●● --
ScottishReel ●●●●
Jig ●●● -
Hawaiian ●●●●
FrenchMusette ●●● -
MariachiWaltz ●●●●
LimboRock ●●●●
HullyGully ●●●●
Cumbia ●●●●
CumbiaTejana ●● --
Enka1 ●●●●
Enka2 ●●●●
Enka3 ●● --
JapaneseFolk ●●● -
FolkRock ●●●●
NewAge ●●●●
PopEnka ●●●●
DanceGroove ●●● -
Pianist Stride1 ●●●●
Stride2 ●●●●
PianoSwing1 ●●●●
PianoSwing2 ●●●●
PianoSwing3 ●●●●
PianoRag1 ●●●●
PianoRag2 ●●●●
Arpeggio1 ●●●●
Arpeggio2 ●●●●
Arpeggio3 ●●●●
PianoOrchBld ●●●●
Musical ●●●●
Traditional1 ●●●●
Traditional2 ●●●●
Traditional3 ●●●●
PianoBoogie ●●●●
PianoRock&Roll ●●●●
SlowRock ●●●●
2BeatSwing ●●●●
JazzBallad2 ●●●●
8Beat ●●●●
8BeatBallad1 ●●●●
8BeatBallad2 ●●●●
4Stroke ●●●●
Nocturne ●●●●
PianoMarch1 ●●●●
PianoMarch2 ●●●●
6-8PianoMarch ●●●●
Waltz ●●●●
JazzWaltz ●●●●
PianoBossa ●●●●
PianoSamba ●●●●
PianoChaCha ●●●●
PianoBeguine ●●●●
PianoRumba ●●●●
SlowWaltz ●●●●
Category Style Name CVP-210 CVP-208 CVP-206 CVP-204
18
Effect Type List / Liste der Effekttypen / Liste des types d’effet /
Lista de tipos de efecto
■ Effect Type (for Natural Voices)
■ XG Effect Type
❍ Reverb Type
❍ Chorus Type
●: CVP-210/208 only
❍ DSP Type
DSP Block
CVP-210 Variation/Insertion1-4
CVP-208 Variation
Reverb Chorus DSP Brilliance
ROOM CHORUS DELAY LCR DARK
HALL 1 CELESTE DELAY LR MELLOW
HALL 2 FLANGER ECHO NORMAL
STAGE CRS-DELAY BRIGHT
PLATE SYMPHONIC METALLIC
ROTARY SP
TREMOLO
VIB ROTER
AUTO PAN
PHASER
AUTO WAH
PIANO REV
NO EFFECT
Effect Name Type MSB Type LSB
HALL1 1 0
HALL2 1 16
HALL3 1 17
HALL4 1 18
HALL5 1 1
HALL M 1 6 ●
HALL L 1 7 ●
ROOM1 2 16
ROOM2 2 17
ROOM3 2 18
ROOM4 2 19
ROOM5 2 0
ROOM6 2 1
ROOM7 2 2
ROOM S 2 5 ●
ROOM M 2 6 ●
ROOM L 2 7 ●
STAGE1 3 16
STAGE2 3 17
STAGE3 3 0
STAGE4 3 1
PLATE1 4 16
PLATE2 4 17
PLATE3 4 0
GM PLATE 4 7 ●
WHITE ROOM 16 0
TUNNEL 17 0
CANYON 18 0
BASEMENT 19 0
NO EFFECT 0 0
Effect Name Type MSB Type LSB
CHORUS1 66 17
CHORUS2 66 8
CHORUS3 66 16
CHORUS4 66 1
CHORUS5 65 2
CHORUS6 65 0
CHORUS7 65 1
CHORUS8 65 8
GM CHORUS1 65 3 ●
GM CHORUS2 65 4 ●
GM CHORUS3 65 5 ●
GM CHORUS4 65 6 ●
FB CHORUS 65 7 ●
CELESTE1 66 0
CELESTE2 66 2
FLANGER1 67 8
FLANGER2 67 16
FLANGER3 67 17
FLANGER4 67 1
FLANGER5 67 0
GM FLANGER 67 7 ●
SYMPHONIC1 68 16 ●
SYMPHONIC2 68 0 ●
PHASER1 72 0 ●
ENS DETUNE (ENSEMBLE DETUNE) 87 0 ●
NO EFFECT 0 0
CVP-210 CVP-208 CVP-206/204
Variation DSP 1 DSP 1 DSP 1
Insertion 1 DSP 3 DSP 3
Insertion 2 DSP 4 DSP 4
Insertion 3 DSP 5 DSP 5
Insertion 4 DSP 6
Insertion 5 DSP 7
Effect Name Type MSB Type LSB
HALL1 1 0
HALL2 1 16
HALL3 1 17
HALL4 1 18
HALL5 1 1
HALL M 1 6
HALL L 1 7
ROOM1 2 16
ROOM2 2 17
ROOM3 2 18
ROOM4 2 19
ROOM5 2 0
ROOM6 2 1
ROOM7 2 2
ROOM S 2 5
ROOM M 2 6
ROOM L 2 7
STAGE1 3 16
STAGE2 3 17
STAGE3 3 0
STAGE4 3 1
PLATE1 4 16
PLATE2 4 17
PLATE3 4 0
GM PLATE 4 7
WHITE ROOM 16 0
TUNNEL 17 0
CANYON 18 0
BASEMENT 19 0
CHORUS1 66 17
CHORUS2 66 8
CHORUS3 66 16
CHORUS4 66 1
CHORUS5 65 2
CHORUS6 65 0
CHORUS7 65 1
CHORUS8 65 8
GM CHORUS1 65 3
GM CHORUS2 65 4
GM CHORUS3 65 5
GM CHORUS4 65 6
FB CHORUS 65 7
CELESTE1 66 0
CELESTE2 66 2
SYMPHONIC1 68 16
SYMPHONIC2 68 0
ENS DETUNE (ENSEMBLE DETUNE) 87 0
KARAOKE1 20 0
KARAOKE2 20 1
KARAOKE3 20 2
ER1 9 0
ER2 9 1
GATE REVERB 10 0
REVERS GATE 11 0
EQ DISCO 76 16
EQ TEL 76 17
2BAND EQ 77 0
3BAND EQ 76 0
HM ENHANCE1 (HARMONIC ENHANCER 1) 81 16
HM ENHANCE2 (HARMONIC ENHANCER 2) 81 0
FLANGER1 67 8
FLANGER2 67 16
FLANGER3 67 17
FLANGER4 67 1
FLANGER5 67 0
GM FLANGER 67 7
DELAY LCR1 5 16
DELAY LCR2 5 0
DELAY LR 6 0
ECHO 7 0
CROSS DELAY 8 0
TEMPO DELAY 21 0
TEMPO ECHO 21 8
TEMPO CROSS 22 0
DIST HEAVY 73 0
ST DIST (STEREO DISTORTION) 73 8
COMP+DIST1 (COMPRESSOR+DISTORTION 1) 73 16
COMP+DIST2 (COMPRESSOR+DISTORTION 2) 73 1
OVERDRIVE 74 0
ST OD (STEREO OVER DRIVE) 74 8
DIST HARD (DISTORTION HARD) 75 16
DIST SOFT (DISTORTION SOFT) 75 17
ST DIST HARD (STEREO DISTORTION HARD) 75 18
ST DIST SOFT (STEREO DISTORTION SOFT) 75 19
V_DIST HARD (V DISTORTION HARD) 98 0
19
CVP-210 Insertion5
CVP-208 Insertion1-3
V_DIST SOFT (V DISTORTION SOFT) 98 2
AMP SIM (AMP SIMULATOR) 75 0
ST AMP1 (STEREO AMP SIMIULATOR 1) 75 20
ST AMP2 (STEREO AMP SIMIULATOR 2) 75 21
ST AMP3 (STEREO AMP SIMIULATOR 3) 75 8
DST+DELAY1 (DISTORTION+DELAY 1) 95 16
DST+DELAY2 (DISTORTION+DELAY 2) 95 0
OD+DELAY1 (OVERDRIVE+DELAY 1) 95 17
OD+DELAY2 (OVERDRIVE+DELAY 2) 95 1
CMP+DST+DLY1 (COMPRESSOR+DISTORTION+DELAY 1) 96 16
CMP+DST+DLY2 (COMPRESSOR+DISTORTION+DELAY 2) 96 0
CMP+OD+DLY1 (COMPRESSOR+OVERDRIVE+DELAY 1) 96 17
CMP+OD+DLY2 (COMPRESSOR+OVERDRIVE+DELAY 2) 96 1
V_DST H+DLY (V DISTORTION HARD+DELAY) 98 1
V_DST S+DLY (V DISTORTION SOFT+DELAY) 98 3
DST+TDLY (DISTORTION+TEMPO DELAY) 100 0
OD+TDLY (OVERDRIVE+TEMPO DELAY) 100 1
CMP+DST+TDL (COMPRESSOR+DISTORTION+TEMPO DELAY) 101 0
CMP+OD+TDLY (COMPRESSOR+OVERDRIVE+TEMPO DELAY) 101 1
V_DST H+TDLY (V DISTORTION HARD+TEMPO DELAY) 103 0
V_DST S+TDLY (V DISTORTION SOFT+TEMPO DELAY) 103 1
COMPRESSOR 83 0
NOISE GATE 84 0
VCE CANCEL 85 0
AMBIENCE 88 0
TALKING MOD 93 0
LO-FI 94 0
PHASER1 72 0
PHASER2 72 8
EP PHASER1 72 17
EP PHASER2 72 18
EP PHASER3 72 16
PITCH CHG1 (PITCH CHANGE 1) 80 16
PITCH CHG2 (PITCH CHANGE 2) 80 0
PITCH CHG3 (PITCH CHANGE 3) 80 1
ROTARY SP1 69 16
ROTARY SP2 71 17
ROTARY SP3 71 18
ROTARY SP4 70 17
ROTARY SP5 66 18
ROTARY SP6 69 0
2WAY ROT SP (2WAY ROTARY SP) 86 0
DST+ROT SP (DISTORTION+ROTARY SP) 69 1
DST+2ROT SP (DISTORTION+2WAY ROTARY SP) 86 1
OD+ROT SP (OVERDRIVE+ROTARY SP) 69 2
OD+2ROT SP (OVERDRIVE+2WAY ROTARY SP) 86 2
AMP+ROT SP (AMP SIMULATOR+ROTARY SP) 69 3
AMP+2ROT SP (AMP SIMULATOR+2WAY ROTARY SP) 86 3
DUAL ROT SP1 (DUAL ROTOR SPEAKER 1) 99 0
DUAL ROT SP2 (DUAL ROTOR SPEAKER 2) 99 1
AUTO PAN1 71 16
AUTO PAN2 71 0
EP AUTOPAN 71 21
TREMOLO1 70 16
TREMOLO2 71 19
TREMOLO3 70 0
EP TREMOLO 70 18
GT TREMOLO1 71 20
GT TREMOLO2 70 19
AUTO WAH1 78 16
AUTO WAH2 78 0
AT WAH+DST1 (AUTO WAH+DISTORTION 1) 78 17
AT WAH+DST2 (AUTO WAH+DISTORTION 2) 78 1
AT WAH+OD1 (AUTO WAH+OVERDRIVE 1) 78 18
AT WAH+OD2 (AUTO WAH+OVERDRIVE 2) 78 2
TOUCH WAH1 82 0
TOUCH WAH2 82 8
TC WAH+DST1 (TOUCH WAH+DISTORTION 1) 82 16
TC WAH+DST2 (TOUCH WAH+DISTORTION 2) 82 1
TC WAH+OD1 (TOUCH WAH+OVERDRIVE 1) 82 17
TC WAH+OD2 (TOUCH WAH+OVERDRIVE 2) 82 2
CLAVI TC WAH (CLAVI TOUCH WAH) 82 18
EP TC WAH (EP TOUCH WAH) 82 19
WH+DST+DLY1 (WAH+DISTORTION+DELAY 1) 97 16
WH+DST+DLY2 (WAH+DISTORTION+DELAY 2) 97 0
WH+DST+TDLY (WAH+DISTORTION+TEMPO DELAY) 102 0
WH+OD+DLY1 (WAH+OVERDRIVE+DELAY 1) 97 17
WH+OD+DLY2 (WAH+OVERDRIVE+DELAY 2) 97 1
WH+OD+TDLY (WAH+OVERDRIVE+TEMPO DELAY) 102 1
THRU 64 0
NO EFFECT 0 0
Effect Name Type MSB Type LSB
Effect Name Type MSB Type LSB
HALL1 1 0
HALL2 1 16
HALL3 1 17
HALL4 1 18
HALL5 1 1
ROOM1 2 16
ROOM2 2 17
ROOM3 2 18
ROOM4 2 19
ROOM5 2 0
ROOM6 2 1
ROOM7 2 2
STAGE1 3 16
STAGE2 3 17
STAGE3 3 0
STAGE4 3 1
PLATE1 4 16
PLATE2 4 17
PLATE3 4 0
CHORUS1 66 17
CHORUS2 66 8
CHORUS3 66 16
CHORUS4 66 1
CHORUS5 65 2
CHORUS6 65 0
CHORUS7 65 1
CHORUS8 65 8
CELESTE1 66 0
CELESTE2 66 2
SYMPHONIC1 68 16
SYMPHONIC2 68 0
ENS DETUNE (ENSEMBLE DETUNE) 87 0
KARAOKE1 20 0
KARAOKE2 20 1
KARAOKE3 20 2
EQ DISCO 76 16
EQ TEL 76 17
2BAND EQ 77 0
3BAND EQ 76 0
HM ENHANCE1 (HARMONIC ENHANCER 1) 81 16
HM ENHANCE2 (HARMONIC ENHANCER 2) 81 0
FLANGER1 67 8
FLANGER2 67 16
FLANGER3 67 17
FLANGER4 67 1
FLANGER5 67 0
DELAY LCR1 5 16
DELAY LCR2 5 0
DELAY LR 6 0
ECHO 7 0
CROSS DELAY 8 0
TEMPO DELAY 21 0
TEMPO ECHO 21 8
TEMPO CROSS 22 0
DIST HEAVY 73 0
OVERDRIVE 74 0
DIST HARD (DISTORTION HARD) 75 16
DIST HARD2 75 22
DIST SOFT (DISTORTION SOFT) 75 17
DIST SOFT2 75 23
AMP SIM (AMP SIMULATOR) 75 0
ST AMP2 75 21
COMPRESSOR 83 0
NOISE GATE 84 0
PHASER1 72 0
EP PHASER1 72 17
EP PHASER2 72 18
EP PHASER3 72 16
ROTARY SP1 69 16
ROTARY SP2 71 17
ROTARY SP3 71 18
ROTARY SP4 70 17
ROTARY SP5 66 18
ROTARY SP6 69 0
ROTARY SP7 71 22
AUTO PAN1 71 16
AUTO PAN2 71 0
EP AUTOPAN 71 21
TREMOLO1 70 16
TREMOLO2 71 19
TREMOLO3 70 0
EP TREMOLO 70 18
GT TREMOLO1 71 20
GT TREMOLO2 70 19
AUTO WAH1 78 16
AUTO WAH2 78 0
TOUCH WAH1 82 0
TOUCH WAH2 82 8
THRU 64 0
20
CVP-206/204 Variation
Effect Name Type MSB Type LSB
HALL1 1 0
HALL2 1 16
HALL3 1 17
HALL4 1 18
HALL5 1 1
ROOM1 2 16
ROOM2 2 17
ROOM3 2 18
ROOM4 2 19
ROOM5 2 0
ROOM6 2 1
ROOM7 2 2
STAGE1 3 16
STAGE2 3 17
STAGE3 3 0
STAGE4 3 1
PLATE1 4 16
PLATE2 4 17
PLATE3 4 0
CHORUS1 66 17
CHORUS2 66 8
CHORUS3 66 16
CHORUS4 66 1
CHORUS5 65 2
CHORUS6 65 0
CHORUS7 65 1
CHORUS8 65 8
CELESTE1 66 0
CELESTE2 66 2
SYMPHONIC1 68 16
SYMPHONIC2 68 0
KARAOKE1 20 0
KARAOKE2 20 1
KARAOKE3 20 2
ER1 9 0
ER2 9 1
GATE REVERB 10 0
REVERS GATE 11 0
EQ DISCO 76 16
EQ TEL 76 17
2BAND EQ 77 0
3BAND EQ 76 0
FLANGER1 67 8
FLANGER2 67 16
FLANGER3 67 17
FLANGER4 67 1
FLANGER5 67 0
DELAY LCR1 5 16
DELAY LCR2 5 0
DELAY LR 6 0
ECHO 7 0
CROSS DELAY 8 0
DIST HEAVY 73 0
OVERDRIVE 74 0
DIST HARD (DISTORTION HARD) 75 16
DIST HARD2 75 22
DIST HARD3 75 25
DIST SOFT (DISTORTION SOFT) 75 17
DIST SOFT2 75 23
AMP SIM (AMP SIMULATOR) 75 0
ST AMP2 75 21
ST AMP3 75 24
PHASER1 72 0
PHASER2 72 8
EP PHASER1 72 17
EP PHASER2 72 16
ROTARY SP1 69 16
ROTARY SP2 71 17
ROTARY SP3 71 18
ROTARY SP4 70 17
ROTARY SP5 66 18
ROTARY SP6 69 0
ROTARY SP7 71 22
ROTARY SP8 69 17
ROTARY SP9 66 19
ROTARY SP10 71 25
AUTO PAN1 71 16
AUTO PAN2 71 0
AUTO PAN3 71 23
EP AUTOPAN 71 21
EP AUTOPAN2 71 24
TREMOLO1 70 16
TREMOLO2 71 19
TREMOLO3 70 0
TREMOLO4 70 20
EP TREMOLO 70 18
EP TREMOLO2 70 21
GT TREMOLO1 71 20
AUTO WAH1 78 16
AUTO WAH2 78 0
AUTO WAH3 78 19
AUTO WAH4 78 20
THRU 64 0
21
Effect Parameter List / Liste der Effektparameter /
Liste des paramètres d’effets / Lista de parámetros de efectos
If a table has no LSB number specified, the table applies for any LSB numbers.
Parameters marked with a ● in the Control column can be controlled from an AC1 (assignable controller 1) etc. However, this is valid only for a Variation effect (when selected for Insertion).
MSB = 1
MSB = 2
MSB = 3
MSB = 4
MSB = 5
MSB = 6
MSB = 7
MSB = 8
MSB = 9
MSB = 10
MSB = 11
MSB = 16
MSB = 17
MSB = 18
MSB = 19
No. Parameter Display Value See Table Control
1Reverb Time 0.3 – 30.0s 0 – 69 table#4
2Diffusion 0 – 10 0 – 10
3Initial Delay 0.1mS – 99.3mS 0 – 63 table#5
4HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
5LPF Cutoff 1.0k – Thru 34 – 60 table#3
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Rev Delay 0.1mS – 99.3mS 0 – 63 table#5
12 Density 0 – 4 (*2) 0 – 4
0 – 2 (*3) 0 – 2
13 Er/Rev Balance E63>R – E=R – E<R63 1 – 127
14 High Damp (*1) 0.1 – 1.0 1 – 10
15 Feedback Level -63 – +63 1 – 127
16
No. Parameter Display Value See Table Control
1Lch Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
2Rch Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
3Cch Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
4Feedback Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
5Feedback Level -63 – +63 1 – 127
6Cch Level 0 – 127 0 – 127
7High Damp 0.1 – 1.0 1 – 10
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1Lch Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
2Rch Delay 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
3Feedback Delay 1 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
4Feedback Delay 2 0.1 – 1486.0ms (*4) 1 – 14860
0.1 – 715.0ms (*5) 1 – 7150
5Feedback Level -63 – +63 1 – 127
6High Damp 0.1 – 1.0 1 – 10
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1Lch Delay1 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
2Lch Feedback Level -63 – +63 1 – 127
3Rch Delay1 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
4Rch Feedback Level -63 – +63 1 – 127
5High Damp 0.1 – 1.0 1 – 10
6Lch Delay2 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
7Rch Delay2 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
8Delay2 Level 0 – 127 0 – 127
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1L
→R Delay 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
2R
→L Delay 0.1 – 743.0ms (*4) 1 – 7430
0.1 – 355.0ms (*5) 1 – 3550
3Feedback Level -63 – +63 1 – 127
4Input Select L, R, L&R 0 – 2
5High Damp 0.1 – 1.0 1 – 10
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 – 5
2Room Size 0.1 – 7.0 0 – 44 table#6
3Diffusion 0 – 10 0 – 10
4Initial Delay 0.1mS – 200.0mS 0 – 127 table#5
5Feedback Level -63 – +63 1 – 127
6HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
7LPF Cutoff 1.0k – Thru 34 – 60 table#3
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Liveness 0 – 10 0 – 10
12 Density 0 – 3 0 – 3
13 High Damp 0.1 – 1.0 1 – 10
14
15
16
No. Parameter Display Value See Table Control
1Type TypeA, TypeB 0 – 1
2Room Size 0.1 – 7.0 0 – 44 table#6
3Diffusion 0 – 10 0 – 10
4Initial Delay 0.1mS – 200.0mS 0 – 127 table#5
5Feedback Level -63 – +63 1 – 127
6HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
7LPF Cutoff 1.0k – Thru 34 – 60 table#3
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Liveness 0 – 10 0 – 10
12 Density 0 – 3 0 – 3
13 High Damp 0.1 – 1.0 1 – 10
14
15
16
No. Parameter Display Value See Table Control
1Reverb Time 0.3 – 30.0s 0 – 69 table#4
2Diffusion 0 – 10 0 – 10
3Initial Delay 0.1mS – 99.3mS 0 – 63 table#5
4HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
5LPF Cutoff 1.0k – Thru 34 – 60 table#3
6Width 0.5 – 10.2m 0 – 37 table#11
7Heigt 0.5 – 20.2m 0 – 73 table#11
8Depth 0.5 – 30.2m 0 – 104 table#11
9Wall Vary 0 – 30 0 – 30
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Rev Delay 0.1mS – 99.3mS 0 – 63 table#5
12 Density (*1) 0 – 4 0 – 4
13 Er/Rev Balance (*1) E63>R – E=R – E<R63 1 – 127
14 High Damp (*1) 0.1 – 1.0 1 – 10
15 Feedback Level (*1) -63 – +63 1 – 127
16
22
MSB = 20
MSB = 21
MSB = 22
MSB = 65
MSB = 66
MSB = 67
MSB = 68
MSB = 69, LSB = 0, 16, 17
MSB = 69, LSB = 1
MSB = 69, LSB = 2
MSB = 69, LSB = 3
MSB = 70
No. Parameter Display Value See Table Control
1Delay Time 0.1mS – 400.0mS 0 – 127 table#7
2Feedback Level -63 – +63 1 – 127
3HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
4LPF Cutoff 1.0k – Thru 34 – 60 table#3
5
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Delay Time 64th/3 – 4thx6 0 – 19 table#14
2Feedback Level -63 – +63 1 – 127
3Feedback High Dump 0 – 1.0 0 – 10
4L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
5Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●
11
12
13 EQ Low Frequency 32 – 2.0kH 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500 – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1Delay Time L>R 64th/3 – 4thx6 0 – 19 table#14
2Delay Time R>L 64th/3 – 4thx6 0 – 19 table#14
3Feedback Level -63 – +63 1 – 127
4Input Select L, R, L&R 0 – 2
5Feedback High Dump 0 – 1.0 0 – 10
6Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●
11
12
13 EQ Low Frequency 32 – 2.0kH 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500 – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Feedback Level -63 – +63 1 – 127
4Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15 Input Mode mono/stereo 0 – 1
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Feedback Level -63 – +63 1 – 127
4Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124
15
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Delay Offset 0.0mS – 50mS 0 – 127 table#2
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ●
2LFO Depth 0 – 127 0 – 127
3
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15
16
No. Parameter Display Value See Table Control
1LFO Frequenct 0.0 – 39.7Hz 0 – 127 ●
2LFO Depth 0 – 127 0 – 127
3
4
5
6EQ Low Frequency 32 – 2.0kHz 4 – 40
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500 – 16.0kHz 28 – 58
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127
11
12
13
14 Drive 0 – 127 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127
No. Parameter Display Value See Table Control
1LFO Frequenct 0.0 – 39.7Hz 0 – 127 ●
2LFO Depth 0 – 127 0 – 127
3AMP Type Off, Stack, Combo, Tube 0 – 3
4
5
6EQ Low Frequency 32 – 2.0kHz 4 – 40
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500 – 16.0kHz 28 – 58
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127
11
12
13
14 Drive 0 – 127 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ●
2AM Depth 0 – 127 0 – 127
3PM Depth 0 – 127 0 – 127
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124
15 Input Mode mono/stereo 0 – 1
16
23
MSB = 71
MSB = 72, LSB = 0, 16, 17, 18
MSB = 72, LSB = 8
MSB = 73, LSB = 0
MSB = 74
MSB = 73, LSB = 1, 16
MSB = 73, LSB = 8
MSB = 74, LSB = 8
MSB = 75
MSB = 76
MSB = 77
MSB = 78, LSB = 0, 16, 19, 20
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ●
2L/R Depth 0 – 127 0 – 127
3F/R Depth 0 – 127 0 – 127
4PAN Direction L↔R, L→R, L←R, Lturn, Rturn, L/R 0 – 5
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Phase Shift Offset 0 – 127 0 – 127
4Feedback Level -63 – +63 1 – 127
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Stage 4, 5, 6 (*6) 4 – 6
4 – 12 (*4) 4 – 12
6, 7, 8, 9, 10 (*7) 6 – 10
12 Diffusion (*1) mono/stereo 0 – 1
13
14
15
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Phase Shift Offset 0 – 127 0 – 127
4Feedback Level -63 – +63 1 – 127
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Stage 3, 4, 5, 6 (*1) 3 – 6
3, 4, 5 (*7) 3 – 5
12
13 LFO Phase Difference -180deg – +180deg (resolution=3deg.) 4 – 124
14
15
16
No. Parameter Display Value See Table Control
1Drive 0 – 127 0 – 127 ●
2EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
3EQ Low Gain -12 – +12dB 52 – 76
4LPF Cutoff 1.0k – Thru 34 – 60 table#3
5Output Level 0 – 127 0 – 127
6
7EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3
8EQ Mid Gain -12 – +12dB 52 – 76
9EQ Mid Width 1.0 – 12.0 10 – 120
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1Drive 0 – 127 0 – 127 ●
2EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
3EQ Low Gain -12 – +12dB 52 – 76
4LPF Cutoff 1.0k – Thru 34 – 60 table#3
5Output Level 0 – 127 0 – 127
6
7EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3
8EQ Mid Gain -12 – +12dB 52 – 76
9EQ Mid Width 1.0 – 12.0 10 – 120
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127
12 Attack 1ms – 40ms 0 – 19 table#8
13 Release 10ms – 680ms 0 – 15 table#9
14 Threshold -48dB – -6dB 79 – 121
15 Ratio 1.0 – 20.0 0 – 7 table#10
16
No. Parameter Display Value See Table Control
1Drive 0 – 127 0 – 127 ●
2EQ Low Frequency 32 – 2.0kHz 4 – 40 table#3
3EQ Low Gain -12 – +12dB 52 – 76
4LPF Cuttoff 1kHz – Thru 34 – 60
5Output Level 0 – 127
6
7EQ Mid Frequency 100 – 10.0kHz 14 – 54 table#3
8EQ Mid Gain -12 – +12dB 52 – 76
9EQ Mid Width 1 – 12 10 – 120
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Edge (Clip Curve) 0 – 127 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1Drive 0 – 127 0 – 127 ●
2AMP Type Off, Stack, Combo, Tube 0 – 3
3LPF Cutoff 1.0k – Thru 34 – 60 table#3
4Output Level 0 – 127 0 – 127
5
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1EQ Low Gain -12 – +12dB 52 – 76
2EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3
3EQ Mid Gain -12 – +12dB 52 – 76
4EQ Mid Width 1.0 – 12.0 10 – 120
5EQ High Gain -12 – +12dB 52 – 76
6EQ Low Frequency 50Hz – 2.0kHz 8 – 40 table#3
7EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
8
9
10
11
12
13
14
15 Input Mode mono/stereo 0 – 1
16
No. Parameter Display Value See Table Control
1EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
2EQ Low Gain -12 – +12dB 52 – 76
3EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
4EQ High Gain -12 – +12dB 52 – 76
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Cutoff Frequency Offset 0 – 127 0 – 127 ●
4Resonance 1.0 – 12.0 10 – 120
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Drive (*4) 0 – 127 0 – 127
12
13
14
15
16
24
MSB = 78, LSB = 1, 17
MSB = 78, LSB = 2, 18
MSB = 80, LSB = 0, 16
MSB = 80, LSB = 1
MSB = 81
MSB = 82, LSB = 0
MSB = 82, LSB = 1, 16
MSB = 82, LSB = 8
MSB = 82, LSB = 2, 17, 18, 19
MSB = 83
MSB = 84
MSB = 85
MSB = 86, LSB = 0
No. Parameter Display Value See Table Control
1LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2LFO Depth 0 – 127 0 – 127
3Cutoff Frequency Offset 0 – 127 0 – 127 ●
4Resonance 1.0 – 12.0 10 – 120
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Drive 0 – 127 0 – 127
12 EQ Low Gain (distortion) -12 – +12dB 52 – 76
13 EQ Mid Gain (distortion) -12 – +12dB 52 – 76
14 LPF Cutoff 1.0kHz – thru 34 – 60 table#3
15 Output Level 0 – 127 0 – 127
16
No. Parameter Display Value See Table Control
1Pitch -24 – +24 40 – 88
2Initial Delay 0.1mS – 400.0mS 0 – 127 table#7
3Fine 1 -50 – +50 14 – 114
4Fine 2 -50 – +50 14 – 114
5Feedback Level -63 – +63 1 – 127
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Pan 1 L63 – R63 1 – 127
12 Output Level 1 0 – 127 0 – 127
13 Pan 2 L63 – R63 1 – 127
14 Output Level 2 0 – 127 0 – 127
15
16
No. Parameter Display Value See Table Control
1Pitch -24 – +24 40 – 88
2Initial Delay 0.1mS – 400.0mS 0 – 127 table#7
3Fine 1 -50 – +50cent 14 – 114
4Fine 2 -50 – +50cent 14 – 114
5Feedback Level -63 – +63 1 – 127
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Pan 1 L63 – R63 1 – 127
12 Output Level 1 0 – 127 0 – 127
13 Pan 2 L63 – R63 1 – 127
14 Output Level 2 0 – 127 0 – 127
15
16
No. Parameter Display Value See Table Control
1HPF Cutoff 500Hz – 16.0kHz 28 – 58
2Drive 0 – 127 0 – 127
3Mix Level 0 – 127 0 – 127
4
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Sensitive 0 – 127 0 – 127
2Cutoff Frequency Offset 0 – 127 0 – 127 ●
3Resonance 1.0 – 12.0 10 – 120
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Drive 0 – 127 (var/ins1 – 4 block) 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1Sensitive 0 – 127 0 – 127
2Cutoff Frequency Offset 0 – 127 0 – 127 ●
3Resonance 1.0 – 12.0 10 – 120
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127
11 Drive 0 – 127 (var/ins 1 – 4 block) 0 – 127
12 EQ Low Gain(distortion) -12 – +12dB (var/ins 1 – 4 block) 52 – 76
13 EQ Mid Gain(distortion) -12 – +12dB (var/ins 1 – 4 block) 52 – 76
14 LPF Cutoff 1.0kHz – thru (var/ins 1 – 4 block) 34 – 60 table#3
15 Output Level 0 – 127 (var/ins 1 – 4 block) 0 – 127
16 Release 10 – 680mS (var/ins 1 – 4 block) 52 – 67 table#12
No. Parameter Display Value See Table Control
1Attack 1 – 40ms 0 – 19 table#8
2Release 10 – 680ms 0 – 15 table#9
3Threshold -48 – -6dB 79 – 121
4Ratio 1.0 – 20.0 0 – 7 table#10
5Output Level 0 – 127 0 – 127
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Attack 1 – 40ms 0 – 19 table#8
2Release 10 – 680ms 0 – 15 table#9
3Threshold -72 – -30dB 55 – 97
4Output Level 0 – 127 0 – 127
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1
2
3
4
5
6
7
8
9
10
11 Low Adjust 0 – 26 0 – 26
12 High Adjust 0 – 26 0 – 26
13
14
15
16
No. Parameter Display Value See Table Control
1Rotor Speed 0.0Hz – 39.7Hz 0 – 127 table#1 ●
2Drive Low 0 – 127 0 – 127
3Drive High 0 – 127 0 – 127
4Low/High L63>H – L=H – L<H63 1 – 127
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 – 54 table#3
12 Mic L-R Angle 0deg – 180deg (resolution=3deg.) 0 – 60
13
14
15
16
25
MSB = 86, LSB = 1
MSB = 86, LSB = 2
MSB = 86, LSB = 3
MSB = 87
MSB = 88
MSB = 93
MSB = 94
MSB = 95
MSB = 96
MSB = 97
MSB = 98, LSB = 0
MSB = 98, LSB = 2
No. Parameter Display Value See Table Control
1Rotor Speed 0.0 – 39.7Hz 0 – 127 ●
2Drive Low 0 – 127 0 – 127
3Drive High 0 – 127 0 – 127
4Low/High Balance L63>H – L=H – L<H=63 1 – 127
5
6EQ Low Frequency 32 – 2.0kHz 4 – 40
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500 – 16.0kHz 28 – 58
9EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100 – 10.0kHz 14 – 54
12 Mic L-R Angle 0 – 180deg 0 – 60
13
14 Drive 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127
No. Parameter Display Value See Table Control
1Rotor Speed 0.0 – 39.7Hz 0 – 127 ●
2Drive Low 0 – 127 0 – 127
3Drive High 0 – 127 0 – 127
4Low/High Balance L63>H – L=H – L<H=63 1 – 127
5
6EQ Low Frequency 32 – 2.0kHz 4 – 40
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500 – 16.0kHz 28 – 58
9EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100 – 10.0kHz 14 – 54
12 Mic L-R Angle 0 – 180deg 0 – 60
13 AMP Type Off, Stack, Combo, Tube (AMPSIM only) 0 – 3
14 Drive 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127
No. Parameter Display Value See Table Control
1Detune -50 – +50cent 14 – 114
2Lch Init Delay 0.0mS – 50mS 0 – 127 table#2
3Rch Init Delay 0.0mS – 50mS 0 – 127 table#2
4
5
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 EQ Low Frequency 32Hz – 2.0kHz (variation, insertion block) 4 – 40 table#3
12 EQ Low Gain -12 – +12dB (variation, insertion block) 52 – 76
13 EQ High Frequency 500Hz – 16.0kHz (variation, insertion
block) 28 – 58 table#3
14 EQ High Gain -12 – +12dB (variation, insertion block) 52 – 76
15
16
No. Parameter Display Value See Table Control
1Delay Time 0.0mS – 50mS 0 – 127 table#2
2Output Phase normal/invers 0 – 1
3
4
5
6EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7EQ Low Gain -12 – +12dB 52 – 76
8EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Vowel a, i, u, e, o 0 – 4 ●
2Move speed 1 – 62 1 – 62
3Drive 0 – 127 0 – 127
4Output Level 0 – 127 0 – 127
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Sampling Freq Control 44.1kHz – 345Hz 0 – 127 table#13
2Word Length 1 – 127 1 – 127
3Output Gain -6 – +12dB 0 – 18
4LPF Cutoff 63Hz – Thru 10 – 60 table#3
5Filter Type Thru, PowerBass, Radio, Tel, Clean, Low 0 – 5
6LPF Resonance 1.0 – 12.0 10 – 120
7Bit Assign 0 – 6 0 – 6
8Emphasis Off/On 0 – 1
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13
14
15 Input Mode mono/stereo
16
No. Parameter Display Value See Table Control
1Lch Delay Time 0.1 – 1486.0ms 1 – 14860
2Rch Delay Time 0.1 – 1486.0ms 1 – 14860
3Delay Feedback Time 0.1 – 1486.0ms 1 – 14860
4Delay Feedback Level -63 – +63 1 – 127
5Delay Mix 0 – 127 0 – 127
6Dist Drive 0 – 127 0 – 127
7Dist Output Level 0 – 127 0 – 127
8Dist EQ Low Gain -12 – +12dB 52 – 76
9Dist EQ Mid Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Delay Time 0.1 – 1486.0ms 1 – 14860
2Delay Feedback Level -63 – +63 1 – 127
3Delay Mix 0 – 127 0 – 127
4Dist Drive 0 – 127 0 – 127
5Dist Output Level 0 – 127 0 – 127
6Dist EQ Low Gain -12 – +12dB 52 – 76
7Dist EQ Mid Gain -12 – +12dB 52 – 76
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Comp. Attack 1ms – 40ms 0 – 19 table#8
12 Comp. Release 10ms – 680ms 0 – 15 table#9
13 Comp. Threshold -48dB – -6dB 79 – 121
14 Comp. Ratio 1.0 – 20.0 0 – 7 table#10
15
16
No. Parameter Display Value See Table Control
1Delay Time 0.1 – 1486.0ms 1 – 14860
2Delay Feedback Level -63 – +63 1 – 127
3Delay Mix 0 – 127 0 – 127
4Dist Drive 0 – 127 0 – 127
5Dist Output Level 0 – 127 0 – 127
6Dist EQ Low Gain -12 – +12dB 52 – 76
7Dist EQ Mid Gain -12 – +12dB 52 – 76
8
9
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Wah Sensitive 0 – 127 0 – 127
12 Wah Cutoff Freq Offset 0 – 127 0 – 127
13 Wah Resonance 1.0 – 12.0 10 – 120
14 Wah Release 10 – 680ms 52 – 67 table#12
15
16
No. Parameter Display Value See Table Control
1Overdrive 0 – 100% 0 – 100
2Device Transister/Vintage Tube/ 0 – 4
Dist1/Dist2/Fuzz
3Speaker Flat/Stack/Combo/Twin/ 0 – 5
Radio/Megaphone
4Presence 0 – 20 0 – 20
5Output Level 0 – 100% 0 – 100
6
7
8
9
10 Dry/Wet Balance Balance D63>W – D=W – D<W63 1 – 127 ●
11
12
13
14
15
16
26
MSB = 98, LSB = 1
MSB = 98, LSB = 3
MSB = 99
MSB = 100
MSB = 101
MSB = 102
MSB = 103
MSB = 0
MSB = 64
Parameter 10 Dry/Wet Balance only affects insertion type effects.
*1
CVP-210/208 only
*2
CVP-210: Reverb, Variation, Insertion 1 – 4
CVP-208/206/204: Reverb, Variation
*3
CVP-210/208 only
CVP-210: Insertion 5
CVP-208: Insertion 1 – 3
*4
CVP-210/208 only
CVP-210: Variation, Insertion 1 – 4
CVP-208: Variation
*5
CVP-210: Insertion 5
CVP-208: Insertion 1 – 3
CVP-206/204: Variation
*6
CVP-210/208 only
CVP-210: Chorus, Insertion 5
CVP-208: Chorus, Insertion 1 – 3
*7
CVP-206/204 only
No. Parameter Display Value See Table Control
1Overdrive 0 – 100% 0 – 100
2Device Transister/Vintage Tube/ 0 – 4
Dist1/Dist2/Fuzz
3Speaker Flat/Stack/Combo/Twin/ 0 – 5
Radio/Megaphone
4Presence 0 – 20 0 – 20
5Output Level 0 – 100% 0 – 100
6Delay Time L 0.1ms – 1486.0ms 1 – 14860
7Delay Time R 0.1ms – 1486.0ms 1 – 14860
8Delay Feedback Time 0.1ms – 1486.0ms 1 – 14860
9Delay Feedback Level -63 – +63 1 – 127
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Delay Mix 0 – 127 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1Rotor Speed Slow 0.0 – 2.65Hz 0 – 63 table#1
2Horn Speed Slow 0.0 – 2.65Hz 0 – 63 table#1
3Rotor Speed Fast 2.69 – 39.7Hz 64 – 127 table#1
4Horn Speed Fast 2.69 – 39.7Hz 64 – 127 table#1
5Slow-Fast Time of R 0 – 127 0 – 127
6Slow-Fast Time of H 0 – 127 0 – 127
7Drive Low 0 – 127 0 – 127
8Drive High 0 – 127 0 – 127
9Low/High Balance L63>H – L=H – L<H=63 1 – 127
10
11 EQ Low Frequency 32 – 2.0kH 4 – 40 table#3
12 EQ Low Gain -12 – +12dB 52 – 76
13 EQ High Frequency 500 – 16.0kHz 28 – 58 table#3
14 EQ High Gain -12 – +12dB 52 – 76
15 Mic L-R Angle 0 – 180deg 0 – 60
16 Speed Control Slow/Fast 0/1 ●
No. Parameter Display Value See Table Control
1Delay Time 64th/3 – 4thx6 0 – 19 table#14
2Delay Feedback Level -63 – +63 1 – 127
3Delay Mix 0 – 127 0 – 127
4Dist Drive 0 – 127 0 – 127
5Dist Output Level 0 – 127 0 – 127
6Dist EQ Low Gain -12 – +12dB 52 – 76
7Dist EQ High Gain -12 – +12dB 52 – 76
8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
9Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1Delay Time 64th/3 – 4thx6 0 – 19 table#14
2Delay Feedback Level -63 – +63 1 – 127
3Delay Mix 0 – 127 0 – 127
4Dist Drive 0 – 127 0 – 127
5Dist Output Level 0 – 127 0 – 127
6Dist EQ Low Gain -12 – +12dB 52 – 76
7Dist EQ High Gain -12 – +12dB 52 – 76
8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
9Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●
11 Comp. Attack 1ms – 40ms 0 – 19
12 Comp. Release 10ms – 680ms 0 – 15
13 Comp. Threshold -48dB – -6dB 79 – 121
14 Comp. Ratio 1.0 – 20.0 0 – 7
15
16
No. Parameter Display Value See Table Control
1Delay Time 64th/3 – 4thx6 0 – 19 table#14
2Delay Feedback Level -63 – +63 1 – 127
3Delay Mix 0 – 127 0 – 127
4Dist Drive 0 – 127 0 – 127
5Dist Output Level 0 – 127 0 – 127
6Dist EQ Low Gain -12 – +12dB 52 – 76
7Dist EQ High Gain -12 – +12dB 52 – 76
8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
9Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●
11 Wah Sensitive 0 – 127 0 – 127
12 Wah Cutoff Freq Offset 0 – 127 0 – 127
13 Wah Resonance 1.0 – 12.0 10 – 120
14 Wah Release 10 – 680mS 52 – 67
15
16
No. Parameter Display Value See Table Control
1Overdrive 0 – 100% 0 – 100
2Device Transister/Vintage Tube/ 0 – 4
Dist1/Dist2/Fuzz
3Speaker Flat/Stack/Combo/Twin/ 0 – 5
Radio/Megaphone
4Presence 0 – 20 0 – 20
5Output Level 0 – 100% 0 – 100
6Delay Time 64th/3 – 4thx6 0 – 19 table#14
7Delay Feedback Level -63 – +63 1 – 127
8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
9Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●
11 Delay Mix 0 – 127 0 – 127
12
13
14
15
16
No. Parameter Display Value See Table Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
27
Effect Data Assign Table / Effektdaten-Zuordnungstabelle /
Tableau d’assignation des données d’effets /
Tabla de asignación de datos para efectos
Table#1
LFO Frequency
Table#2
Modulation Delay Offset
Table#3
EQ Frequency
Data Value Data Value Data Value Data Value
00.00 321.35 642.69 968.41
10.04 331.39 652.78 978.75
20.08 341.43 662.86 989.08
30.13 351.47 672.94 999.42
40.17 361.51 683.03100 9.76
50.21 371.56 693.11101 10.1
60.25 381.60 703.20102 10.8
70.29 391.64 713.28103 11.4
80.34 401.68 723.37104 12.1
90.38 411.72 733.45105 12.8
10 0.42 42 1.77 74 3.53 106 13.5
11 0.46 43 1.81 75 3.62 107 14.1
12 0.51 44 1.85 76 3.70 108 14.8
13 0.55 45 1.89 77 3.87 109 15.5
14 0.59 46 1.94 78 4.04 110 16.2
15 0.63 47 1.98 79 4.21 111 16.8
16 0.67 48 2.02 80 4.37 112 17.5
17 0.72 49 2.06 81 4.54 113 18.2
18 0.76 50 2.10 82 4.71 114 19.5
19 0.80 51 2.15 83 4.88 115 20.9
20 0.84 52 2.19 84 5.05 116 22.2
21 0.88 53 2.23 85 5.22 117 23.6
22 0.93 54 2.27 86 5.38 118 24.9
23 0.97 55 2.31 87 5.55 119 26.2
24 1.01 56 2.36 88 5.72 120 27.6
25 1.05 57 2.40 89 6.06 121 28.9
26 1.09 58 2.44 90 6.39 122 30.3
27 1.14 59 2.48 91 6.73 123 31.6
28 1.18 60 2.52 92 7.07 124 33.0
29 1.22 61 2.57 93 7.40 125 34.3
30 1.26 62 2.61 94 7.74 126 37.0
31 1.30 63 2.65 95 8.08 127 39.7
Data Value Data Value Data Value Data Value
00.0323.2 64 6.4 96 9.6
10.1333.3 65 6.5 97 9.7
20.2343.4 66 6.6 98 9.8
30.3353.5 67 6.7 99 9.9
40.4363.6 68 6.8 100 10.0
50.5373.7 69 6.9 101 11.1
60.6383.8 70 7.0 102 12.2
70.7393.9 71 7.1 103 13.3
80.8404.0 72 7.2 104 14.4
90.9414.1 73 7.3 105 15.5
10 1.0 42 4.2 74 7.4 106 17.1
11 1.1 43 4.3 75 7.5 107 18.6
12 1.2 44 4.4 76 7.6 108 20.2
13 1.3 45 4.5 77 7.7 109 21.8
14 1.4 46 4.6 78 7.8 110 23.3
15 1.5 47 4.7 79 7.9 111 24.9
16 1.6 48 4.8 80 8.0 112 26.5
17 1.7 49 4.9 81 8.1 113 28.0
18 1.8 50 5.0 82 8.2 114 29.6
19 1.9 51 5.1 83 8.3 115 31.2
20 2.0 52 5.2 84 8.4 116 32.8
21 2.1 53 5.3 85 8.5 117 34.3
22 2.2 54 5.4 86 8.6 118 35.9
23 2.3 55 5.5 87 8.7 119 37.5
24 2.4 56 5.6 88 8.8 120 39.0
25 2.5 57 5.7 89 8.9 121 40.6
26 2.6 58 5.8 90 9.0 122 42.2
27 2.7 59 5.9 91 9.1 123 43.7
28 2.8 60 6.0 92 9.2 124 45.3
29 2.9 61 6.1 93 9.3 125 46.9
30 3.0 62 6.2 94 9.4 126 48.4
31 3.1 63 6.3 95 9.5 127 50.0
Data Value Data Value
0THRU(0) 32 800
12233900
225341.0k
328351.1k
432361.2k
536371.4k
640381.6k
745391.8k
850402.0k
956412.2k
10 63 42 2.5k
11 70 43 2.8k
12 80 44 3.2k
13 90 45 3.6k
14 100 46 4.0k
15 110 47 4.5k
16 125 48 5.0k
17 140 49 5.6k
18 160 50 6.3k
19 180 51 7.0k
20 200 52 8.0k
21 225 53 9.0k
22 250 54 10.0k
23 280 55 11.0k
24 315 56 12.0k
25 355 57 14.0k
26 400 58 16.0k
27 450 59 18.0k
28 500 60
THRU(20.0k)
29 560
30 630
31 700
Table#4
Reverb Time
Table#5
Delay Time (200.0ms)
Table#6
Room Size
Data Value Data Value Data Value
00.3323.5 64 17.0
10.4333.6 65 18.0
20.5343.7 66 19.0
30.6353.8 67 20.0
40.7363.9 68 25.0
50.8374.0 69 30.0
60.9384.1
71.0394.2
81.1404.3
91.2414.4
10 1.3 42 4.5
11 1.4 43 4.6
12 1.5 44 4.7
13 1.6 45 4.8
14 1.7 46 4.9
15 1.8 47 5.0
16 1.9 48 5.5
17 2.0 49 6.0
18 2.1 50 6.5
19 2.2 51 7.0
20 2.3 52 7.5
21 2.4 53 8.0
22 2.5 54 8.5
23 2.6 55 9.0
24 2.7 56 9.5
25 2.8 57 10.0
26 2.9 58 11.0
27 3.0 59 12.0
28 3.1 60 13.0
29 3.2 61 14.0
30 3.3 62 15.0
31 3.4 63 16.0
Data Value Data Value Data Value Data Value
00.1 32 50.5 64 100.8 96 151.2
11.7 33 52.0 65 102.4 97 152.8
23.2 34 53.6 66 104.0 98 154.4
34.8 35 55.2 67 105.6 99 155.9
46.4 36 56.8 68 107.1 100 157.5
58.0 37 58.3 69 108.7 101 159.1
69.5 38 59.9 70 110.3 102 160.6
711.1 39 61.5 71 111.9 103 162.2
812.7 40 63.1 72 113.4 104 163.8
914.3 41 64.6 73 115.0 105 165.4
10 15.8 42 66.2 74 116.6 106 166.9
11 17.4 43 67.8 75 118.2 107 168.5
12 19.0 44 69.4 76 119.7 108 170.1
13 20.6 45 70.9 77 121.3 109 171.7
14 22.1 46 72.5 78 122.9 110 173.2
15 23.7 47 74.1 79 124.4 111 174.8
16 25.3 48 75.7 80 126.0 112 176.4
17 26.9 49 77.2 81 127.6 113 178.0
18 28.4 50 78.8 82 129.2 114 179.5
19 30.0 51 80.4 83 130.7 115 181.1
20 31.6 52 81.9 84 132.3 116 182.7
21 33.2 53 83.5 85 133.9 117 184.3
22 34.7 54 85.1 86 135.5 118 185.8
23 36.3 55 86.7 87 137.0 119 187.4
24 37.9 56 88.2 88 138.6 120 189.0
25 39.5 57 89.8 89 140.2 121 190.6
26 41.0 58 91.4 90 141.8 122 192.1
27 42.6 59 93.0 91 143.3 123 193.7
28 44.2 60 94.5 92 144.9 124 195.3
29 45.7 61 96.1 93 146.5 125 196.9
30 47.3 62 97.7 94 148.1 126 198.4
31 48.9 63 99.3 95 149.6 127 200.0
Data Value Data Value Data Value Data Value
00.1325.1 64 10.1 96 15.1
10.3335.3 65 10.3 97 15.3
20.4345.4 66 10.4 98 15.5
30.6355.6 67 10.6 99 15.6
40.7365.7 68 10.8 100 15.8
50.9375.9 69 10.9 101 15.9
61.0386.1 70 11.1 102 16.1
71.2396.2 71 11.2 103 16.2
81.4406.4 72 11.4 104 16.4
91.5416.5 73 11.5 105 16.6
10 1.7 42 6.7 74 11.7 106 16.7
11 1.8 43 6.8 75 11.9 107 16.9
12 2.0 44 7.0 76 12.0 108 17.0
13 2.1 45 7.2 77 12.2 109 17.2
14 2.3 46 7.3 78 12.3 110 17.3
15 2.5 47 7.5 79 12.5 111 17.5
16 2.6 48 7.6 80 12.6 112 17.6
17 2.8 49 7.8 81 12.8 113 17.8
18 2.9 50 7.9 82 12.9 114 18.0
19 3.1 51 8.1 83 13.1 115 18.1
20 3.2 52 8.2 84 13.3 116 18.3
21 3.4 53 8.4 85 13.4 117 18.4
22 3.5 54 8.6 86 13.6 118 18.6
23 3.7 55 8.7 87 13.7 119 18.7
24 3.9 56 8.9 88 13.9 120 18.9
25 4.0 57 9.0 89 14.0 121 19.1
26 4.2 58 9.2 90 14.2 122 19.2
27 4.3 59 9.3 91 14.4 123 19.4
28 4.5 60 9.5 92 14.5 124 19.5
29 4.6 61 9.7 93 14.7 125 19.7
30 4.8 62 9.8 94 14.8 126 19.8
31 5.0 63 10.0 95 15.0 127 20.0
Table#7
Delay Time (400.0ms)
Data Value Data Value Data Value Data Value
00.1 32 100.9 64 201.6 96 302.4
13.2 33 104.0 65 204.8 97 305.5
26.4 34 107.2 66 207.9 98 308.7
39.5 35 110.3 67 211.1 99 311.8
412.7 36 113.5 68 214.2 100 315.0
515.8 37 116.6 69 217.4 101 318.1
619.0 38 119.8 70 220.5 102 321.3
722.1 39 122.9 71 223.7 103 324.4
825.3 40 126.1 72 226.8 104 327.6
928.4 41 129.2 73 230.0 105 330.7
10 31.6 42 132.4 74 233.1 106 333.9
11 34.7 43 135.5 75 236.3 107 337.0
12 37.9 44 138.6 76 239.4 108 340.2
13 41.0 45 141.8 77 242.6 109 343.3
14 44.2 46 144.9 78 245.7 110 346.5
15 47.3 47 148.1 79 248.9 111 349.6
16 50.5 48 151.2 80 252.0 112 352.8
17 53.6 49 154.4 81 255.2 113 355.9
18 56.8 50 157.5 82 258.3 114 359.1
19 59.9 51 160.7 83 261.5 115 362.2
20 63.1 52 163.8 84 264.6 116 365.4
21 66.2 53 167.0 85 267.7 117 368.5
22 69.4 54 170.1 86 270.9 118 371.7
23 72.5 55 173.3 87 274.0 119 374.8
24 75.7 56 176.4 88 277.2 120 378.0
25 78.8 57 179.6 89 280.3 121 381.1
26 82.0 58 182.7 90 283.5 122 384.3
27 85.1 59 185.9 91 286.6 123 387.4
28 88.3 60 189.0 92 289.8 124 390.6
29 91.4 61 192.2 93 292.9 125 393.7
30 94.6 62 195.3 94 296.1 126 396.9
31 97.7 63 198.5 95 299.2 127 400.0
Table#8
Compressor
Attack Time
Data Value
01
12
23
34
45
56
67
78
89
910
10 12
11 14
12 16
13 18
14 20
15 23
16 26
17 30
18 35
19 40
Table#9
Compressor
Release Time
Table#10
Compressor Ratio
Data Value
010
115
225
335
445
555
665
775
885
9100
10 115
11 140
12 170
13 230
14 340
15 680
Data Value
01.0
11.5
22.0
33.0
45.0
57.0
610.0
720.0
Table#11
Reverb Width; Depth; Height
Data Value Data Value Data Value Data Value
00.5328.8 64 17.6 96 27.5
10.8339.1 65 17.9 97 27.8
21.0349.4 66 18.2 98 28.1
31.3359.6 67 18.5 99 28.5
41.5369.9 68 18.8 100 28.8
51.83710.2 69 19.1 101 29.2
62.03810.4 70 19.4 102 29.5
72.33910.7 71 19.7 103 29.9
82.64011.0 72 20.0 104 30.2
92.84111.2 73 20.2
10 3.1 42 11.5 74 20.5
11 3.3 43 11.8 75 20.8
12 3.6 44 12.1 76 21.1
13 3.9 45 12.3 77 21.4
14 4.1 46 12.6 78 21.7
15 4.4 47 12.9 79 22.0
16 4.6 48 13.1 80 22.4
17 4.9 49 13.4 81 22.7
18 5.2 50 13.7 82 23.0
19 5.4 51 14.0 83 23.3
20 5.7 52 14.2 84 23.6
21 5.9 53 14.5 85 23.9
22 6.2 54 14.8 86 24.2
23 6.5 55 15.1 87 24.5
24 6.7 56 15.4 88 24.9
25 7.0 57 15.6 89 25.2
26 7.2 58 15.9 90 25.5
27 7.5 59 16.2 91 25.8
28 7.8 60 16.5 92 26.1
29 8.0 61 16.8 93 26.5
30 8.3 62 17.1 94 26.8
31 8.6 63 17.3 95 27.1
Table#12
Wah Release Time
Data Value
52 10.0
53 15.0
54 25.0
55 35.0
56 45.0
57 55.0
58 65.0
59 75.0
60 85.0
61 100.0
62 115.0
63 140.0
64 170.0
65 230.0
66 340.0
67 680.0
Table#13
Sampling Freq Control
Table#14
Tempo Delay
Data Value Data Value Data Value Data Value
044.1K 32 1.34K 64 678.0 96 455.0
122.1K 33 1.30K 65 668.0 97 450.0
214.7K 34 1.26K 66 658.0 98 445.0
311.0K 35 1.23K 67 649.0 99 441.0
48.8K 36 1.19K 68 639.0 100 437.0
57.4K 37 1.16K 69 630.0 101 432.0
66.3K 38 1.13K 70 621.0 102 428.0
75.5K 39 1.10K 71 613.0 103 424.0
84.9K 40 1.08K 72 604.0 104 420.0
94.5K 41 1.05K 73 596.0 105 416.0
10 4.0K 42 1.03K 74 588.0 106 412.0
11 3.7K 43 1.00K 75 580.0 107 408.0
12 3.4K 44 980.0 76 573.0 108 405.0
13 3.2K 45 959.0 77 565.0 109 401.0
14 2.9K 46 938.0 78 558.0 110 397.0
15 2.8K 47 919.0 79 551.0 111 394.0
16 2.6K 48 900.0 80 544.0 112 390.0
17 2.5K 49 882.0 81 538.0 113 387.0
18 2.3K 50 865.0 82 531.0 114 383.0
19 2.2K 51 848.0 83 525.0 115 380.0
20 2.1K 52 832.0 84 519.0 116 377.0
21 2.0K 53 817.0 85 513.0 117 374.0
22 1.92K 54 802.0 86 507.0 118 371.0
23 1.84K 55 788.0 87 501.0 119 368.0
24 1.76K 56 774.0 88 496.0 120 364.0
25 1.70K 57 760.0 89 490.0 121 361.0
26 1.63K 58 747.0 90 485.0 122 359.0
27 1.58K 59 735.0 91 479.0 123 356.0
28 1.52K 60 723.0 92 474.0 124 353.0
29 1.47K 61 711.0 93 469.0 125 350.0
30 1.42K 62 700.0 94 464.0 126 347.0
31 1.38K 63 689.0 95 459.0 127 345.0
Data Value Data Value Data Value
064th/3 32 4thX19 64 4thX51
164th. 33 4thX20 65 4thX52
232th 34 4thX21 66 4thX53
332th/3 35 4thX22 67 4thX54
432th. 36 4thX23 68 4thX55
516th 37 4thX24 69 4thX56
616th/3 38 4thX25 70 4thX57
716th. 39 4thX26 71 4thX58
88th 40 4thX27 72 4thX59
98th/3 41 4thX28 73 4thX60
10 8th. 42 4thX29 74 4thX61
11 4th 43 4thX30 75 4thX62
12 4th/3 44 4thX31 76 4thX63
13 4th. 45 4thX32 77 4thX64
14 2nd 46 4thX33
15 2nd/3 47 4thX34
16 2nd. 48 4thX35
17 4thX4 49 4thX36
18 4thX5 50 4thX37
19 4thX6 51 4thX38
20 4thX7 52 4thX39
21 4thX8 53 4thX40
22 4thX9 54 4thX41
23 4thX10 55 4thX42
24 4thX11 56 4thX43
25 4thX12 57 4thX44
26 4thX13 58 4thX45
27 4thX14 59 4thX46
28 4thX15 60 4thX47
29 4thX16 61 4thX48
30 4thX17 62 4thX49
31 4thX18 63 4thX50
#8-10, 12-14: CVP-210/208
28
Harmony/Echo Type List / Liste der Harmony/Echo-Effekttypen /
Liste des types d’harmonie/d’écho / Lista de tipos de ecos/armonías
Vocal Harmony Type List / Liste der Vocal-Harmony-Effekttypen /
Liste des types d’harmonie vocale / Lista de tipos de armonía
(CVP210/208)
CVP-210 CVP-208
Vocal harmony types that have "Chordal/Vocoder" in the Mode column can be used in either
Chordal or Vocoder Mode.
STANDARD DUET
STANDARD TRIO
FULL CHORD
ROCK DUET
COUNTRY DUET
COUNTRY TRIO
BLOCK
4-WAY CLOSE 1
4-WAY CLOSE 2
4-WAY OPEN
1+5
OCTAVE
STRUM
MULTI ASSIGN
ECHO
TREMOLO
TRILL
Display Name Harmony Type Mode
CountryQuar CountryQuartet Chordal/Vocoder
ClsdMenQuar ClosedMenQuartet Chordal/Vocoder
MixAcapQuar MixAcapQuartet Chordal/Vocoder
WomenChoir Women Choir Chordal/Vocoder
JazzSisters Jazz Sisters Chordal/Vocoder
Std Duet Standard Duet Chordal/Vocoder
MenChoir Men Choir Chordal/Vocoder
ClosedChoir Closed Choir Chordal/Vocoder
Girl Duet Girl in Duet Chordal/Vocoder
SpdyMouse Speedy Mouse Chromatic
HighMaleQua HighMaleQuartet Chordal/Vocoder
JazzQuartet Jazz Quartet Chordal/Vocoder
MixedChoir Mixed Choir Chordal/Vocoder
CntryGirls Country Girls Chordal/Vocoder
SistersTrio Sisters Trio Chordal/Vocoder
CountryMen Country Men Chordal/Vocoder
ACapellBoy A Capella Boy Chordal/Vocoder
ACapellaMix A Capella Mix Chordal/Vocoder
GospelDiva Gospel Diva Chordal/Vocoder
Lisa&Tina Lisa and Tina Chordal/Vocoder
AcapMenQuar AcapMenQuartet Chordal/Vocoder
JazzMenCho JazzMenChoir Chordal/Vocoder
J_CloseCho JazzClosedCho Chordal/Vocoder
J_WomenCho JazzWomenCho Chordal/Vocoder
LadiesQuart LadiesQuartet Chordal/Vocoder
SingB+G Sing B+G Chordal/Vocoder
Barbershop Barbershop Chordal/Vocoder
J_MixedCho JazzMixedCho Chordal/Vocoder
Dream Girls Dream Girls Chordal/Vocoder
SingBass Sing the Bass Chromatic
FalsetDuet Falsetto Duet Chordal/Vocoder
FalsettTrio Falsetto Trio Chordal/Vocoder
FalsettoDia Falsetto Dia Chordal/Vocoder
FalACapella Fal A Capella Chordal/Vocoder
FalsetJazz Falsetto Jazz Chordal/Vocoder
2UnisonLow 2 Unison Low Chordal/Vocoder
3UnisonLow 3 Unison Low Chordal/Vocoder
DiatncJazz Diatonic Jazz Chordal/Vocoder
DiatncGirl Diatonic Girl Chordal/Vocoder
ACapellaDia A Capella Dia Chordal/Vocoder
ChordalXG ChordalXG Chordal/Vocoder
KaraokAuto Karaoke Auto Chordal/Vocoder
KaraokMode Karaoke Mode Chordal/Vocoder
KaraokGirl Karaoke Girl Chordal/Vocoder
KaraokPich Karaoke Pitch Chordal/Vocoder
2UnisonHigh 2 Unison High Chordal/Vocoder
3UnisonHigh 3 Unison High Chordal/Vocoder
VocodAutoU Vocoder Auto Upper Chordal/Vocoder
VocodAutoL Vocoder Auto Lower Chordal/Vocoder
DetuneXG DetuneXG Detune
VocoderXG VocoderXG Chordal/Vocoder
VocodModeU Vocoder Mode Upper Chordal/Vocoder
VocodModeL Vocoder Mode Lower Chordal/Vocoder
VocodGirlU Vocoder Girl Upper Chordal/Vocoder
VocodGirlL Vocoder Girl Lower Chordal/Vocoder
VocodPichU Vocoder Pitch Upper Chordal/Vocoder
VocodPichL Vocoder Pitch Lower Chordal/Vocoder
ChromatXG ChromaticXG Chromatic
Voice&Inst Voice & Inst Chordal/Vocoder
Thru Thru -
Display Name Harmony Type Mode
Std Duet Standard Duet Chordal/Vocoder
Girl Duet Girl in Duet Chordal/Vocoder
Lisa&Tina Lisa and Tina Chordal/Vocoder
Sing B+G Sing B+G Chordal/Vocoder
Dream Girls Dream Girls Chordal/Vocoder
MenChoir Men Choir Chordal/Vocoder
WomenChoir Women Choir Chordal/Vocoder
ClosedChoir Closed Choir Chordal/Vocoder
MixedChoir Mixed Choir Chordal/Vocoder
CountryMen Country Men Chordal/Vocoder
CntryGirls Country Girls Chordal/Vocoder
Barbershop Barbershop Chordal/Vocoder
JazzMenCho JazzMenChoir Chordal/Vocoder
J_WomenCho JazzWomenCho Chordal/Vocoder
J_CloseCho JazzClosedCho Chordal/Vocoder
J_MixedCho JazzMixedCho Chordal/Vocoder
DiatncJazz Diatonic Jazz Chordal/Vocoder
DiatncGirl Diatonic Girl Chordal/Vocoder
ACapellBoy A Capella Boy Chordal/Vocoder
ACapellaMix A Capella Mix Chordal/Vocoder
ACapellaDia A Capella Dia Chordal/Vocoder
FalsetDuet Falsetto Duet Chordal/Vocoder
FalsettTrio Falsetto Trio Chordal/Vocoder
FalsettoDia Falsetto Dia Chordal/Vocoder
FalsetJazz Falsetto Jazz Chordal/Vocoder
FalACapella Fal A Capella Chordal/Vocoder
2UnisonLow 2 Unison Low Chordal/Vocoder
2UnisonHigh 2 Unison High Chordal/Vocoder
3UnisonLow 3 Unison Low Chordal/Vocoder
3UnisonHigh 3 Unison High Chordal/Vocoder
Voice&Inst Voice & Inst Chordal/Vocoder
ChordalXG ChordalXG Chordal/Vocoder
VocodAutoU Vocoder Auto Upper Chordal/Vocoder
VocodAutoL Vocoder Auto Lower Chordal/Vocoder
VocodModeU Vocoder Mode Upper Chordal/Vocoder
VocodModeL Vocoder Mode Lower Chordal/Vocoder
VocodGirlU Vocoder Girl Upper Chordal/Vocoder
VocodGirlL Vocoder Girl Lower Chordal/Vocoder
VocodPichU Vocoder Pitch Upper Chordal/Vocoder
VocodPichL Vocoder Pitch Lower Chordal/Vocoder
KaraokAuto Karaoke Auto Chordal/Vocoder
KaraokMode Karaoke Mode Chordal/Vocoder
KaraokGirl Karaoke Girl Chordal/Vocoder
KaraokPich Karaoke Pitch Chordal/Vocoder
VocoderXG VocoderXG Chordal/Vocoder
SingBass Sing the Bass Chromatic
SpdyMouse Speedy Mouse Chromatic
ChromatXG ChromaticXG Chromatic
DetuneXG DetuneXG Detune
Thru Thru -
29
Parameter Chart / Parametertabelle / Tableau des paramètres /
Gráfico de parámetros
Settings are saved/called up for each type.
If parameters belonging to more than one type are set, the new settings take priority over the old.
Data Type The data is saved... The data is called up... Saved Location
Setup When you change settings in a display page and then exit from
the page. When you turn off the power and then
turn on the power. System area of the internal
memory (Flash Memory)
Voice When you change settings in the Voice Set display and then
save the data as Voice file. When you call up a voice. Voice File
Song When you save the recorded or edited (current) song as a Song
file. When you call up a song, play a song or
move the song position. Song File
Style When you save the recorded or edited data as a Style file. When you call up a style. Style File
OTS When you memorize settings with the REGISTARATION
buttons and then save the current style as a Style file. When you call up an OTS by pressing
one of OTS buttons.
Regist. When you memorize settings with the REGISTARATION
buttons and then save the data as a Registaration Bank File. When you call up an Regist. by pressing
one of REGISTRATION MEMORY
buttons.
Registration Bank File
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
MainWindow
Transpose X X - X - X X O Tune/Trans -
SplitPoint (Accomp) O X - O Guide Setting X X O Style Split
SplitPoint (Left) O X - X - X X O Style Split
SongFile X X - X - X X O Song -
StyleFile X X - O - X X O Style -
IntroEndingSection X X - X - O X X - -
VoiceFile (Main, Layer, Left) X X - X - X X X - - The data that is saved to Regist./OTS is not actual
Voice, but Program Change.
RegistrationBankFile X X - X - X X X - -
PartSelect X X - X - X X X - -
PartOnOff (Main, Layer) X X - O Keyboard Voice X O O Voice - Main Part is always on.
PartOnOff (Left) XX -OKeyboard Voice X O O Style -
BalancePopup
SongVolume X X - X - X X O Song -
StyleVolume X X - O - X X O Style -
MicVolume X X - O Mic. Setting X X O Mic - CVP-210/208/206 only
MainVolume X X - O Keyboard Voice X O O Voice -
LeftVolume XX -OKeyboard Voice X O O Style -
LayerVolume X X - O Keyboard Voice X O O Voice -
Channel OnOffPopup
ChannelOnOff (Song) X X - X - X X X - - For songs that have no channel on/off message, all are
set to on.
ChannelOnOff (Style) X X - O - O X O Style -
VoiceEffect
Reverb O X - X - X X X - -
LeftHoldXX-OKeyboard Voice X O O Style -
Dsp (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
Dsp (Left) X O Effect O Keyboard Voice X O O Style -
Variation (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
Variation (Left) XOEffect O Keyboard Voice X O O Style -
Harmony/Echo X X - O Keyboard Voice X O O Harmony -
Poly/Mono (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Poly/Mono (Left) X O Voice O Keyboard Voice X O O Style -
Registration
FreezeOnOff X X - X - X X X - -
RegistMemoryPopupSetting O X - X - X X X - - Filter settings when registering Registration.
RegistNumber X X - X - X X X - -
RegistContentsName X X - X - X X O - -
Piano
PianoLock O X - X - X X X - -
Menu>Function
MasterTune/ScaleTune
MasterTune
MasterTune O X - X - X X X - -
ScaleTune
Scale X X - X - X X O Scale -
Tune X X - X - X X O Scale -
BaseNote X X - X - X X O Scale -
ScalePart X X - X - X X O Scale -
SongSetting
GuideLampOn/Off O X - X - X X X - -
GuideLampTiming O X - O Guide Setting X X X - - Reset to its default setting when song data doesn't
include this data.
Guide Mode O X - O Guide Setting X X X - - Reset to its default setting when song data doesn't
include this data.
QuickStart O X - X - X X X - -
SongChainPlay O X - X - X X X - -
Channel Setting
Track1 Channel O X - O - X X X - -
Track2 Channel O X - O - X X X - -
Vocal Harmony Channel ➞Mic>MicSetup>VH Song Track
Auto Ch Set O X - X - X X X - -
Phrase Mark X X - X - X X X - -
Lyrics Language O X - O Lyrics Language X X X - -
StyleSetting/SplitPoint/ChordFingering
StyleSetting/SplitPoint
StopAcmp O X - X - X X X - -
SynchroStopWindow O X - X - X X X - -
AccompTouch O X - X - X X X - -
SectionSet O X - X - X X X - -
SplitPoint(Accomp) ➞MainWindow
SplitPoint(Left) ➞MainWindow
ChordFingering
FingeringType O X - X - X X O Style -
TutorRoot X X - X - X X X - -
TutorType X X - X - X X X - -
O: Memorized
X: Not Memorized
30
Controller
Pedal
PedalType X O (Left only) LPDL O
(Left only) Keyboard Voice X O (Left only) O Pedal -
PedalSettings X O (Left only) LPDL O
(Left only) Keyboard Voice X O (Left only) O Pedal -
PedalTypeDefaultSetting X X X X - X X X X -
PedalPolarity O X - X - X X X - -
Keyboard/Panel
TouchSense O X - X - X X X - -
TouchOffLevel X X - X - X X O Voice -
TouchOnOff X X - X - X X O Voice -
TransposeAssign O X - X - X X X - -
Regist.Sequence/Freeze/VoiceSet
RegistrationSequence
RegistSequenceData X X - X - X X O - - Memorized as a single Registration Bank file.
RegistSequenceEnable O X - X - X X X - -
Regist(+)Pedal O X - X - X X X - -
Regist(-)Pedal O X - X - X X X - -
SequenceEnd X X - X - X X O - - Memorized as a single Registration Bank file.
Freeze
FreezeGroupSetting O X - X - X X X - -
VoiceSet
VoiceSetEnable Main O X - X - X X X - -
VoiceSetEnable Layer O X - X - X X X - -
VoiceSetEnable Left O X - X - X X X - -
Harmony/Echo
Type X O Harm O Keyboard Voice X O O Harm -
Volume XOHarm O Keyboard Voice X O O Harm -
Speed X O Harm O Keyboard Voice
(Included in Type) XOOHarm -
Assign X O Harm O Keyboard Voice X O O Harm -
ChordNoteOnly X O Harm O Keyboard Voice X O O Harm -
TouchLimit X O Harm O Keyboard Voice X O O Harm -
Utility
Configuration
Speaker O X - X - X X X - -
DisplayVoiceNumber O X - X - X X X - -
MetronomeVolume O X - X - X X X - -
MetronomeSound O X - X - X X X - -
TimeSignature X X - O - O X X - -
ParameterLock O X - X - X X X - -
TapCountPercussion X X - O Keyboard Voice X O O Style -
TapCountVelocity X X - O Keyboard Voice X O O Style -
LCDContrast O X - X - X X X - - Cannot be reset with Factory Reset. CVP-210/208 only.
LCDBrightness O X - X - X X X - - Cannot be reset with Factory Reset.
FadeInTime O X - X - X X X - -
FadeOutTIme O X - X - X X X - -
FadeOutHoldTime O X - X - X X X - -
Disk
FloppyDiskSongAutoOpen O X - X - X X X - -
Owner
OwnerName O X - X - X X X - - Cannot be reset with Factory Reset.
Language O X - X - X X X - - Cannot be reset with Factory Reset.
MainPicture O X - X - X X X - - Cannot be reset with Factory Reset.
SystemReset
FactoryResetSetting X X - X - X X X - - Cannot be reset with Factory Reset.
MIDI
System
Local Control X X - X - X X X - -
Clock X X - X - X X X - -
Transmit Clock X X - X - X X X - -
Receive Transpose X X - X - X X X - -
Receive Start/Stop X X - X - X X X - -
SysEx Transmit X X - X - X X X - -
SysEx Receive X X - X - X X X - -
Chord SysEx Transmit X X - X - X X X - -
Chord SysEx Receive X X - X - X X X - -
Transmit
Part (Ch1 – 16) X X - X - X X X - -
Filter (Ch1 – 16) X X - X - X X X - -
Receive
Mode (Ch1 – 32) X X - X - X X X - -
Filter (Ch1 – 32) X X - X - X X X - -
Root X X - X - X X X - -
Chord Detect X X - X - X X X - -
MIDI Template
Template No. O X - X - X X X - -
Template Name X X - X - X X X - -
VideoOut (CVP-210/208/206)
NTSC/PAL O X - X - X X X - - Cannot be reset with Factory Reset.
Size (CVP-206) O X - X - X X X - - Cannot be reset with Factory Reset.
ScreenContent (CVP-210/208) O X - X - X X X - - Cannot be reset with Factory Reset.
CharactrorColor (CVP-206) O X - X - X X X - - Cannot be reset with Factory Reset.
BackgroundColor (CVP-206) O X - X - X X X - - Cannot be reset with Factory Reset.
Lyrics
BackGround (Panel Setting) O X - X Lyrics Language X X X - - Cannot be reset with Factory Reset.
BackGround (Song Setting) X X - O Lyrics Language X X X - - Reset to default background with Factory Reset.
MusicScore
Left on/offOX-OScore Setting X X X - -
Right on/offOX-OScore Setting X X X - -
Lyric on/offOX-OScore Setting X X X - -
Chord on/off O X - O Score Setting X X X - -
NoteName on/off O X - O Score Setting X X X - -
Size OX -OScore Setting X X X - -
Left ch. XX -OScore Setting X X X - -
Right ch. XX -OScore Setting X X X - -
KeySignature X X - O Score Setting X X X - -
Quantize O X - O Score Setting X X X - -
NoteName O X - O Score Setting X X X - -
ColorNoteOX-OScore Setting X X X - -
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
31
Song
Track1, 2 On/Off X X - O Guide Setting X X X - - Setting is linked to Channel on/off.
ExtraTracks On/Off X X - X - X X X - - Setting is linked to Channel on/off.
Synchro Start X X - X - X X X - -
StartStop X X - X - X X X - -
A-B Repeat X X - X - X X X - -
DigitalStudio>DigitalRecording>Song Creator
Rec Mode
Rec Start X X - X - X X X - -
PunchInAt X X - X - X X X - -
Rec Stop X X - X - X X X - -
PunchOutAt X X - X - X X X - -
Pedal Punch In/Out X X - X - X X X - -
Quantize
Track X X - X - X X X - -
Size X X - X - XXX - -
Strength X X - X - X X X - -
Delete X X - X - X X X - -
Mix
Source1 X X - X - X X X - -
Source2 X X - X - X X X - -
Destination X X - X - X X X - -
Channel Transpose X X - X - X X X - -
SetUp O X - X - X X X - -
Filter
Main Filter O X - X - X X X - -
Control Change Filter O X - X - X X X - -
Accompaniment Filter O X - X - X X X - -
Tempo
Tempo X X - O - O X O Tempo -
Transpose ➞MainWindow
UpperOctave ➞MainWindow
DigitalStudio>DigitalRecording>Style Creator
Basic
Section X X - X - X X X - -
Pattern Length X X - X - O X X - -
Tempo X X - X - O X X - -
Beat X X - X - O X X - -
Assembly
Source Pattern X X - X - X X X - -
Section X X - X - X X X - -
Part X X - X - X X X - -
Play Type X X - X - X X X - -
Groove
Original Beat X X - X - X X X - -
Beat Converter X X - X - X X X - -
Swing X X - X - X X X - -
Fine X X - X - XXX - -
Dynamics
Part X X - X - X X X - -
Accent Type X X - X - X X X - -
Strength X X - X - X X X - -
Expand/Comp. X X - X - X X X - -
Boost/Cut X X - X - X X X - -
Quantize
Part X X - X - X X X - -
Size X X - X - XXX - -
Strength X X - X - X X X - -
Velocity Change
Part X X - X - X X X - -
Boost/Cut X X - X - X X X - -
Measure Copy
Part X X - X - X X X - -
Measure Top X X - X - X X X - -
Measure Last X X - X - X X X - -
Destination X X - X - X X X - -
Measure Clear
Part X X - X - X X X - -
Measure Top X X - X - X X X - -
Measure Last X X - X - X X X - -
Remove Event
Part X X - X - X X X - -
Event X X - X - X X X - -
Parameter
Part X X - X - X X X - -
Source Root X X - X - O X X - -
Source Chord X X - X - O X X - -
NTR X X - X -OXX- -
NTT X X - X -OXX- -
High Key X X - X - O X X - -
Note Limit X X - X - O X X - -
RTR X X - X -OXX- -
Filter
Main Filter O X - X - X X X - -
Control Change Filter O X - X - X X X - -
Style
AccompanimentOnOff X X - X - X O (On) O Style -
AutoFillOnOff O X - X - X X X - -
OTS Link X X - X - X X X - -
Section X X - O - XXOStyle -
SynchroStart X X - X - X O (On) X - -
SynchroStop X X - X - X X X - -
StartStop X X - O - X X X - -
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
32
MusicFinder
SortKind O X - X - X X X - -
SortOrder O X - X - X X X - -
TempoLock O X - X - X X X - -
Search1/2
Music O X - X - X X X - -
Keyword O X - X - X X X - -
FileNumber O X - X - X X X - -
Beat O X - X - X X X - -
SearchArea O X - X - X X X - -
Tempo O X - X - X X X - -
Genre O X - X - X X X - -
Search results X X - X - X X X - -
Record(=Property settings) X X - X - X X X - -
Mic (CVP-210/208 only)
VocalHarmonyOnOff X X - O Mic. Setting X X O Mic Mic
TalkOnOff X X - X - X X X - -
EffectOnOff X X - O Mic. Setting X X O Mic Mic
VHType X X - O Mic. Setting X X O Mic Mic
VHParameters X X - O Mic. Setting X X X - Mic Current VH Type settings and Type name
MicSetting (CVP-210/208 only)
OverallSetting
EQ Low Freq. O X - X - X X X - -
EQ Low Gain O X - X - X X X - -
EQ Mid Freq. O X - X - X X X - -
EQ Mid Gain O X - X - X X X - -
EQ High Freq. O X - X - X X X - -
EQ High Gain O X - X - X X X - -
Noise Gate SW O X - X - X X X - -
Noise Gate TH O X - X - X X X - -
Compressow SW O X - X - X X X - -
Compressor TH O X - X - X X X - -
Compressor RAT O X - X - X X X - -
Compressor OUT O X - X - X X X - -
VH Song Track Mute X X - X - X X O Mic Mic
VH Song Track X X - X - X X O Mic Mic
VH Keyboard X X - O Mic. Setting X X O Mic Mic
VH Balance X X - X - X X O Mic Mic
VH Mode X X - X - X X O Mic Mic
VH Chord Detect X X - X - X X O Mic Mic
Mute X X - X - X X X - -
MicVol ➞BalancePoup>MicVolume
TalkSetting
Volume O X - X - X X X - -
Pan O X - X - X X X - -
ReverbDepth O X - X - X X X - -
ChorusDepth O X - X - X X X - -
TotalVolumeAttenuator O X - X - X X X - -
DSPOnOff O X - X - X X X - -
DSPDepth O X - X - X X X - -
DSPType O X - X - X X X - -
DigitalStudio>SoundCreator
Voice (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Voice (Left) XOVoice O Keyboard Voice X O O Style -
Volume for Balance (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Volume for Balance (Left) X O Voice O Keyboard Voice X O O Style -
Touch Sens (Main, Layer) X O Voice X Keyboard Voice X O O Voice -
Touch Sens (Left) X O Voice X Keyboard Voice X O O Style -
Octave for Left X O Voice X - X X X - -
Octave for Main/Layer X O Voice X - X X X - -
Mono/Poly ➞Voice Effect
Portament Time ➞DigitalStudio>Mixing Console
Left Pedal
Left Pedal Type ➞Controller-Pedal
Left Pedal Settings ➞Controller-Pedal
Filter Brightness ➞DigitalStudio>Mixing Console
Filter Resonance ➞DigitalStudio>Mixing Console
EG Attack (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
EG Attack (Left) X O Voice O Keyboard Voice X O O Style -
EG Decay (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
EG Decay (Left) X O Voice O Keyboard Voice X O O Style -
EG Release (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
EG Release (Left) X O Voice O Keyboard Voice X O O Style -
Vibrato Depth (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Vibrato Depth (Left) X O Voice O Keyboard Voice X O O Style -
Vibrato Speed (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Vibrato Speed (Left) X O Voice O Keyboard Voice X O O Style -
Vibrato Delay (Main, Layer) X O Voice O Keyboard Voice X O O Voice -
Vibrato Delay (Left) XOVoice O Keyboard Voice X O O Style -
Reverb Depth ➞DigitalStudio>Mixing Console
Chorus Depth ➞DigitalStudio>Mixing Console
DSP On/Off ➞Voice Effect
DSP Depth ➞DigitalStudio>Mixing Console
DSP Type (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
DSP Type (Left) X O Effect O Keyboard Voice X O O Style -
LastSelectedDSP X X - X - X X X - - Memorized only when Sound Creator opened
DSP Variation ➞Voice Effect
DSP Fast Value (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
DSP Fast Value (Left) X O Effect O Keyboard Voice X O O Style -
EQ Low Freq (Main, Layer) X O EQ O Keyboard Voice X O O Voice - CVP-210/208 only
EQ Low Freq (Left) X O EQ O Keyboard Voice X O O Style - CVP-210/208 only
EQ Low Gain ➞DigitalStudio>Mixing Console CVP-210/208 only
EQ High Freq (Main, Layer) X O EQ O Keyboard Voice X O O Voice - CVP-210/208 only
EQ High Freq (Left) XOEQ O Keyboard Voice X O O Style - CVP-210/208 only
EQ High Gain ➞DigitalStudio>Mixing Console CVP-210/208 only
Harmony/Echo
Type ➞Harmony/Echoe
Volume
Speed ➞Harmony/Echoe
Assign ➞Harmony/Echoe
ChordNoteOnly ➞Harmony/Echoe
TouchLimit ➞Harmony/Echoe
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
33
Natural Voice Reverb Type (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
Natural Voice Reverb Type (Left) X O Effect O Keyboard Voice X O O Style -
Natural Voice Chorus Type (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
Natural Voice Chorus Type (Left) X O Effect O Keyboard Voice X O O Style -
Natural Voice DSP Type (Main, Layer) X O Effect O Keyboard Voice X O O Voice -
Natural Voice DSP Type (Left) X O Effect O Keyboard Voice X O O Style -
Natural Voice Brilliance Type (Main, Layer) X O EQ O Keyboard Voice X O O Voice -
Natural Voice Brilliance Type (Left) X O EQ O Keyboard Voice X O O Style -
Natural Voice VibeSustain O X - X - X X X - -
Natural Voice VibeRotorSpeed (Main, Layer)
XOEffect O Keyboard Voice X O O Voice -
Natural Voice VibeRotorSpeed (Left) X O Effect O Keyboard Voice X O O Style -
Natural Voice Piano SR Depth O X - X - X X X - -
Natural Voice Piano SS Depth O X - X - X X X - -
Piano Tuning Curve O X - X - X X X - -
Organ Flutes Footage (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Footage (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ FlutesType (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ FlutesType (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Vib On/Off (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Vib On/Off (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Flutes Attack Footage (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Attack Footage (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Flutes Attack Mode (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Attack Mode (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Flutes Attack length (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Attack length (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Flutes Response (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Response (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
Organ Flutes Volume (Main, Layer) X O Voice O Keyboard Voice X O O Voice - CVP-210/208 only
Organ Flutes Volume (Left) X O Voice O Keyboard Voice X O O Style - CVP-210/208 only
DigitalStudio>Mixing Console
Auto Revoice
On/Off O X - X - X X X - -
Setup O X - X - X X X - -
Volume
Acmp Part X X - O - O X O Style -
Song Part X X - O Volume X X X - -
Main, Layer ➞MainWindow>BalancePopup>MainVolume/LayerVolume
Left ➞MainWindow>BalancePopup>LeftVolume
Acmp (Offset) ➞MainWindow>BalancePopup>StyleVolume
Song (Offset) ➞MainWindow>BalancePopup>SongVolume
Multi Pad ➞MainWindow>BalancePopup>M.PadVolume
Mic ➞MainWindow>BalancePopup>MicVolume
Voice
Acmp Part X X - X - O X O Style -
Song Part X X - O Voice X X X - -
PanPot
Acmp Part X X - O - O X O Style -
Song Part X X - O Pan X X X - -
Main, Layer X X - O Keyboard Voice X O O Voice -
LeftXX-OKeyboard Voice X O O Style -
Acmp (Offset) X X - X - X X O Style -
Song (Offset) X X - X - X X X - -
MicXX-OMic. Setting X X O Mic - CVP-210/208/206 only
Brightness
Acmp Part X X - X - O X O Style -
Song Part X X - O Filter X X X - -
Main, Layer X O Voice O Keyboard Voice X O O Voice -
LeftXOVoice O Keyboard Voice X O O Style -
Harmonic Contents
Acmp Part X X - X - O X O Style -
Song Part X X - O Filter X X X - -
Main, Layer X O Voice O Keyboard Voice X O O Voice -
LeftXOVoice O Keyboard Voice X O O Style -
Octave
Main, Layer X O Voice O Keyboard Voice X O O Voice -
LeftXOVoice O Keyboard Voice X O O Style -
Tune
Main, Layer X X - O Keyboard Voice X O O Voice -
LeftXX-OKeyboard Voice X O O Style -
Portamento Time
Main, Layer X O Voice O Keyboard Voice X O O Voice -
LeftXOVoice O Keyboard Voice X O O Style -
Pitch Bend Range
Main, Layer X X Voice X - X X O Voice -
Left X X Voice X - X X O Style -
Transpose
Master X X - X - X X O Tune Trans -
Song X X - X - X X O Tune Trans -
Keyboard X X - X - X X O Tune Trans -
Reverb Type X X - X - O X O Style/Song Reverb Type
Reverb Return Level X X - X - X X O Style/Song Reverb Return
Level
Natural Voice Reverb Type X O Effect X - O X O Voice/Style/
Song
Reverb Depth
Acmp Part X X - X - O X O Style -
Song Part X X - O Effect X X X - -
Main, Layer X O Effect O Keyboard Voice X O O Voice -
LeftXOEffect O Keyboard Voice X O O Style -
Acmp (Offset) X X - X - X X O Style -
Song (Offset) X X - X - X X X - -
MicXX-OMic. Setting X X O Mic - CVP-210/208/206 only
Chorus Type X X - X - O X O Style/Song -
Chorus Return Level X X - X - X X O Style/Song Chorus Return
Level
Natural Voice Chorus Type X O Effect X - O X O Voice/Style/
Song
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
34
Chorus Depth
Acmp Part X X - X - O X O Style -
Song Part X X - O Effect X X X - -
Main, Layer X O Effect O Keyboard Voice X O O Voice -
LeftXOEffect O Keyboard Voice X O O Style -
Acmp (Offset) X X - X - X X O Style -
Song (Offset) X X - X - X X X - -
MicXX-OMic. Setting X X O Mic - CVP-210/208/206 only
DSP1 Type X O Effect O Keyboard Voice X O O Voice/Song - CVP-206/204 only
DSP1 Type X X - X - O X O Style/Song - CVP-210/208 only
DSP1 Return Level X X - X - X X O Voice/Song DSP1 Return
Level CVP-206/204 only
DSP1 Return Level X X - X - X X O Style/Song DSP1 Return
Level CVP-210/208 only
Natural Voice DSP Type X O Effect X - O X O Voice/Style/
Song -
DSP Depth
Style Part X X - X - O X O Style -
Song Part X X - O Effect X X X - -
Main, Layer X O Effect O Keyboard Voice X O O Voice -
LeftXOEffect O Keyboard Voice X O O Style -
MicXX-OMic. Setting X X O Mic - CVP-210/208/206 only
DSP Type
Main, Layer X O Effect O Keyboard Voice X O O Voice - CVP-210/208 only
LeftXOEffect O Keyboard Voice X O O Style - CVP-210/208 only
Song X X - O - X X O Song - CVP-210/208 only
Effect Parameter X X - X - X X X - -
MasterEQ Type O X - X - X X X - Master EQ CVP-210/208 only
MasterEQ Parameter X X - X - X X X - Master EQ CVP-210/208 only
EQ Low Gain
Acmp Part X X - X - O X O Style - CVP-210/208 only
Song Part X X - O Filter X X X - - CVP-210/208 only
Main, Layer X O EQ O Keyboard Voice X O O Voice - CVP-210/208 only
LeftXOEQOKeyboard Voice X O O Style - CVP-210/208 only
Acmp (Offset) X X - X - X X O Style - CVP-210/208 only
Song (Offset) X X - X - X X X - - CVP-210/208 only
EQ High Gain
Acmp Part X X - X - O X O Style - CVP-210/208 only
Song Part X X - O Filter X X X - - CVP-210/208 only
Main, Layer X O EQ O Keyboard Voice X O O Voice - CVP-210/208 only
LeftXOEQOKeyboard Voice X O O Style - CVP-210/208 only
Acmp (Offset) X X - X - X X O Style - CVP-210/208 only
Song (Offset) X X - X - X X X - - CVP-210/208 only
Parameter System
SetUp
Voice Voice Set
Group
Song Song Setup Group Style OTS Registration Param Lock
Group
Notes
Regist Freeze/Memory
Group
35
MIDI Data Format / MIDI-Datenformat / Format des données MIDI /
Formato de datos MIDI
Many MIDI messages listed in the MIDI Data Format are expressed in decimal numbers, binary numbers and hexadecimal numbers. Hexadecimal numbers may
include the letter “H” as a suffix. Also, “n” can freely be defined as any whole number.
To enter data/values, refer to the table below.
•Except the table above, for example 144-159(decimal)/9nH/1001 0000-1001 1111(binary) denotes the Note On Message for each channel (1-16). 176-191/BnH/
1011 0000-1011 1111 denotes the Control Change Message for each channel (1-16). 192-207/CnH/1100 0000-1100 1111 denotes the Program Change Message
for each channel (1-16). 240/FOH/1111 0000 denotes the start of a System Exclusive Message. 247/F7H/1111 0111 denotes the end of a System Exclusive Mes-
sage.
• aaH (hexidecimal)/0aaaaaaa (binary) denotes the data address. The address contains High, Mid, and Low.
• bbH/0bbbbbbb denotes the byte count.
• ccH/0ccccccc denotes the check sum.
• ddH/0ddddddd denotes the data/value.
CVP-210 CVP-208 CVP-206 CVP-204
Regular Voice O O O O
Organ (Organ Flutes) Voice O O - -
Mic O O O -
Vocal Harmony O O - -
Natural Voice O O O O
Decimal Hexadecimal Binary
0000000 0000
1010000 0001
2020000 0010
3030000 0011
4040000 0100
5050000 0101
6060000 0110
7070000 0111
8080000 1000
9090000 1001
10 0A 0000 1010
11 0B 0000 1011
12 0C 0000 1100
13 0D 0000 1101
14 0E 0000 1110
15 0F 0000 1111
16 10 0001 0000
17 11 0001 0001
18 12 0001 0010
19 13 0001 0011
20 14 0001 0100
21 15 0001 0101
22 16 0001 0110
23 17 0001 0111
24 18 0001 1000
25 19 0001 1001
26 1A 0001 1010
27 1B 0001 1011
28 1C 0001 1100
29 1D 0001 1101
30 1E 0001 1110
31 1F 0001 1111
32 20 0010 0000
33 21 0010 0001
34 22 0010 0010
35 23 0010 0011
36 24 0010 0100
37 25 0010 0101
38 26 0010 0110
39 27 0010 0111
40 28 0010 1000
41 29 0010 1001
42 2A 0010 1010
43 2B 0010 1011
44 2C 0010 1100
45 2D 0010 1101
46 2E 0010 1110
47 2F 0010 1111
48 30 0011 0000
49 31 0011 0001
50 32 0011 0010
51 33 0011 0011
52 34 0011 0100
53 35 0011 0101
54 36 0011 0110
55 37 0011 0111
56 38 0011 1000
57 39 0011 1001
58 3A 0011 1010
59 3B 0011 1011
60 3C 0011 1100
61 3D 0011 1101
62 3E 0011 1110
63 3F 0011 1111
Decimal Hexadecimal Binary
64 40 0100 0000
65 41 0100 0001
66 42 0100 0010
67 43 0100 0011
68 44 0100 0100
69 45 0100 0101
70 46 0100 0110
71 47 0100 0111
72 48 0100 1000
73 49 0100 1001
74 4A 0100 1010
75 4B 0100 1011
76 4C 0100 1100
77 4D 0100 1101
78 4E 0100 1110
79 4F 0100 1111
80 50 0101 0000
81 51 0101 0001
82 52 0101 0010
83 53 0101 0011
84 54 0101 0100
85 55 0101 0101
86 56 0101 0110
87 57 0101 0111
88 58 0101 1000
89 59 0101 1001
90 5A 0101 1010
91 5B 0101 1011
92 5C 0101 1100
93 5D 0101 1101
94 5E 0101 1110
95 5F 0101 1111
Decimal Hexadecimal Binary
96 60 0110 0000
97 61 0110 0001
98 62 0110 0010
99 63 0110 0011
100 64 0110 0100
101 65 0110 0101
102 66 0110 0110
103 67 0110 0111
104 68 0110 1000
105 69 0110 1001
106 6A 0110 1010
107 6B 0110 1011
108 6C 0110 1100
109 6D 0110 1101
110 6E 0110 1110
111 6F 0110 1111
112 70 0111 0000
113 71 0111 0001
114 72 0111 0010
115 73 0111 0011
116 74 0111 0100
117 75 0111 0101
118 76 0111 0110
119 77 0111 0111
120 78 0111 1000
121 79 0111 1001
122 7A 0111 1010
123 7B 0111 1011
124 7C 0111 1100
125 7D 0111 1101
126 7E 0111 1110
127 7F 0111 1111
Decimal Hexadecimal Binary
O: available
36
MIDI CHANNEL MESSAGE (1)
MIDI Events Status byte 1st Data byte 2nd Data byte Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)
Status Data (HEX) Parameter Data (HEX) Parameter Regular/
Organ
Voice
Mic/Vocal Harmony Natural
Voice
Song Main
Layer
Left
Keyboard Style Extra Panel
(main generation
method
)
Upper
Lower
Style Song MIDI
Key Off 8nH (n: Channel
Number) kk Key no.
(0 – 127) vv Velocity
(0 – 127) OO
(Harmony Channel/
Melody Channel)
OOO O OO X XXOX
Key On 9nH (n: Channel
Number) kk Key no.
(0 – 127) vv Key On:
vv=1 – 127
Key Off: vv=0
OO
(Harmony Channel/
Melody Channel)
OOO O OO O
(Keyboard) OOOX
Control
Change BnH (n: Channel
Number) 0(00H) Bank Select
MSB 0(00H) Normal O X O O O O
(Main) OO O
(Voice) XOOX
64 (40H) SFX voice
126 (7EH) SFX kit
127 (7FH) Drum kit
1(01H) Modulation 0 – 127 (00H – 7FH) Data O X X O O O
(Main/Layer/
Left)
OO O
(Pedal) OOOX
5(05H) Portamento
Time 0 – 127 (00H – 7FH) Data O X X O O O
(Main/Layer/
Left)
XO O
(Mixing Console) XXOX
6(06H) Data Entry
MSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
7(07H) Main Volume 0 – 127 (00H – 7FH) Data O O
(Mic) OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
10 (0AH) Panpot 0 – 127 (00H – 7FH) L64 – C – R63 O O
(Mic) OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
11 (0BH) Expression 0 – 127 (00H – 7FH) Data O X O O O O
(Main/Layer/
Left)
OO O
(Pedal) OOOX
32 (20H) Bank Select
LSB 0 – 127 (00H – 7FH) Data O X O O O O
(Main) OO O
(Voice) XOOX
38 (26H) Data Entry
LSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
XO O
(Mixing Console) XXOX
64 (40H) Sustain
(Damper) 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
XO O
(Pedal) OXOX
65 (41H) Portamento 0 – 127 (00H – 7FH) 0 – 63,
64 – 127
(OFF, ON)
OXXOOO
(Main/Layer/
Left)
XO O
(Poly/Mono Sw) OXOX
66 (42H) Sostenuto 0 – 127 (00H – 7FH) 0 – 63,
64 – 127
(OFF, ON)
OXOOO O
(Main/Layer/
Left)
XO O
(Pedal) OXOX
67 (43H) Soft Pedal 0 – 127 (00H – 7FH) 0 – 63,
64 – 127
(OFF, ON)
OXOOO O
(Main/Layer/
Left)
XO O
(Pedal) OXOX
71 (47H) Harmonic
Content 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
72 (48H) Release Time 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O
(Main/Layer/
Left)
OO O
(Sound Creator) XOOX
73 (49H) Attack Time 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O
(Main/Layer/
Left)
OO O
(Sound Creator) XOOX
74 (4AH) Brightness 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O
(Main/Layer/
Left)
XO O
(Sound Creator) XOOX
84 (54H) Portamento
Control 0 – 127 (00H – 7FH) Key no.
(0 – 127) OXXOOXOOO
(Auto
Accompaniment)
XXOX
91 (5BH) Effect1 Depth
(Reverb Send
Level)
0 – 127 (00H – 7FH) Data O O
(Mic) OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
93 (5DH) Effect3 Depth
(Chorus Send
Level)
0 – 127 (00H – 7FH) Data O O
(Mic) OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
94 (5EH) Effect4 Depth
(Variation
Send Level)
0 – 127 (00H – 7FH) Data O O
(Mic) XOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
96 (60H) RPN
Increment --*1 OO
(Harmony Channel/
Melody Channel)
OOO X OO X XXOX
97 (61H) RPN
Decrement --*1 OO
(Harmony Channel/
Melody Channel)
OOO X OO X XXOX
98 (62H) NRPN LSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
XOO X OO O
(Sound Creator) XOOX
99 (63H) NRPN MSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
XOO X OO O
(Sound Creator) XOOX
100 (64H) RPN LSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
101 (65H) RPN MSB 0 – 127 (00H – 7FH) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
OO O
(Mixing Console) XOOX
Mode
Message BnH (n: Channel
Number) 120 (78H) All Sound Off 0 (00H) Data O X O O O O
(Main/Layer/
Left)
OO X X XOX
121 (79H) Reset All
Controllers 0(00H) Data O X O O X X X X X X X O X
122 (7AH) Local Control 0
127 (00H)
(7FH) OFF
ON ---OOOOO X X XXX
123 (7BH) All Note Off 0 (00H) Data O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
OO X X XOX
124 (7CH) Omni Off 0 (00H) Data O X X O X X X X X X X O X
125 (7DH) Omni On 0 (00H) Data O X X O X X X X X X X O X
126 (7EH) Mono 0 – 16 (00H – 10H) Data O X X O X X X X X X X O X
127 (7FH) Poly 0 (00H) Data O X X O X X X X X X X O X
O: available
37
*1 The data byte is ignored.
*2 Received when the Clock is set to External.
*3 Transmitted when the Clock is set to Internal and Transmit Clock is set to on.
*4 Transmitted when the Transmit Clock is set to on.
About Mic/Vocal Harmony column:
The relevant parameters are received by the song part designated by the Effect's Harmony Channel Parameter or Melody Parameter.
MIDI CHANNEL MESSAGE (2)
NRPN
NRPN MSB: 14H – 1FH (for drums) message is accepted as long as the channel is set with a drum voice.
Data Entry LSB: Ignored.
Program
Change CnH (n: Channel
Number) pp (00H – 7FH) Voice Number
(0 – 127) - - -OXOOO O
(Main) OO O
(Voice) XOOX
Channel
After Touch DnH (n: Channel
Number) vv (00H – 7FH) Data - - -OXXOOO
(Main/Layer/
Left)
XO X X XOX
Polyphonic
After Touch AnH (n: Channel
Number) kk (00H – 7FH) Key no.
(0 – 127) vv (00H – 7FH) Data X X X X X X X X X X X O X
Pitch Bend
Change EnH (n: Channel
Number) cc (00H – 7FH) LSB dd (00H – 7FH) MSB O O
(Harmony Channel/
Melody Channel)
OOO O
(Main/Layer/
Left)
OO O
(Pedal) OOOX
Realtime
Message F8H MIDI Clock - - - ----O (*2) O (*3)
FAH Start - - - ----O (*2) O (*4)
FBH Continue - - - ----X X
FCH Stop - - - ----O (*2) O (*4)
FEH Active Sens - - - ----O O
FFH System
Reset - - - ----X X
NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)
MSB LSB MSB LSB Regular/
Organ Voice
Mic/Vocal Harmony Natural
Voice
Song Main
Layer
Left
Keyboard Style Extra Panel
(main generation
method)
Upper
Lower
Style Song MIDI
01H 08H mmH -- Vibrato Rate mm: 00H – 40H – 7FH
(-64 – 0 – +63) OO
(Harmony Channel/
Melody Channel)
XOOXOO O
(Sound Creator) XOOX
01H 09H mmH -- Vibrato Depth mm: 00H – 40H – 7FH
(-64 – 0 – +63) OO
(Harmony Channel/
Melody Channel)
XOOXOO O
(Sound Creator) XOOX
01H 0AH mmH -- Vibrato Delay mm: 00H – 40H – 7FH
(-64 – 0 – +63) OO
(Harmony Channel/
Melody Channel)
XOOXOO O
(Sound Creator) XOOX
01H 20H mmH -- Low Pass Filter Cutoff
Frequency mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
01H 21H mmH -- Low Pass Filter Resonance mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
01H 30H mmH -- EQ BASS (*1) mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
01H 31H mmH -- EQ TREBLE (*1) mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
01H 34H mmH -- EQ BASS Frequency (*1) mm: 04H – 28H (32 – 2.0k[Hz]) O X X O X X X X X X X O X
01H 35H mmH -- EQ TREBLE Frequency (*1) mm: 1CH – 3AH (500 – 16.0k[Hz]) O X X O X X X X X X X O X
01H 63H mmH -- EG Attack Time mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
01H 64H mmH -- EG Decay Time mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOOXOO O
(Sound Creator) XOOX
01H 66H mmH -- EG Release mm: 00H – 40H – 7FH
(-64 – 0 – +63) OXXOXXOX X XXOX
14H rrH mmH -- Drum Low Pass Filter Cutoff
Frequency rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
O
(Drum Only)
XXOXXXXXXOOX
15H rrH mmH -- Drum Low Pass Filter
Resonance rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
XXOXXXXXXOOX
16H rrH mmH -- Drum EG Attack Rate rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
XXOXXXXXXOOX
17H rrH mmH -- Drum EG Decay Rate rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
XXOXXXXXXOOX
18H rrH mmH -- Drum Pitch Coarse rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
XXOXXXXXXOOX
19H rrH mmH -- Drum Pitch Fine rr: drum instrument note number
mm: 00H – 40H – 7FH
(-64 – 0 – +63)
XXOXXXXXXOOX
1AH rrH mmH -- Drum Level rr: drum instrument note number
mm: 00H – 7FH (0 – 127) XXOXXXXXXOOX
1CH rrH mmH -- Drum Pan rr: drum instrument note number
mm: 00H, 01H – 40H – 7FH
(RND, L63 – C – R63)
XXOXXXXXXOOX
1DH rrH mmH -- Drum Reverb Send Level rr: drum instrument note number
mm: 00H – 7FH (0 – 127) XXOXXXXXXOOX
1EH rrH mmH -- Drum Chorus Send Level rr: drum instrument note number
mm: 00H – 7FH (0 – 127) XXOXXXXXXOOX
1FH rrH mmH -- Drum Variation Send Level rr: drum instrument note number
mm: 00H – 7FH (0 – 127)
(Variation Connection=SYSTEM)
mm: 00H, 01H – 7FH (OFF, ON)
(Variation Connection=
INSERTION)
XXOXXXXXXOOX
MIDI Events Status byte 1st Data byte 2nd Data byte Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)
Status Data (HEX) Parameter Data (HEX) Parameter Regular/
Organ
Voice
Mic/Vocal Harmony Natural
Voice
Song Main
Layer
Left
Keyboard Style Extra Panel
(main generation
method
)
Upper
Lower
Style Song MIDI
38
NRPN (Vocal Harmony)
Data Entry LSB: Ignored.
RPN
*1 CVP-210/208 only
*2 CVP-210 only
About Mic/Vocal Harmony column:
The relevant parameters are received by the song part designated by the Effect's Harmony Channel Parameter or Melody Parameter.
NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)
MSB LSB MSB LSB Regular/
Organ Voice
Mic/Vocal Harmony Natural
Voice
Song Main
Layer
Left
Keyboard Style Extra Panel
(main generation
method)
Upper
Lower
Style Song MIDI
00H 00H mmH -- Harmony Mute (*1) 0 – 63, 64 – 127 (Off, On) X O
(Harmony Channel) XXXXXX X XXOX
01H 1AH mmH -- Detune Modulation (*1) mm: 00H – 7FH (0 – 127) X O
(Harmony Channel) XXXXXX X XXOX
02H 10H mmH -- Harmony1 Volume (*1) mm: 00H – 7FH (0 – 127) X O
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 11H mmH -- Harmony2 Volume (*1) mm: 00H – 7FH (0 – 127) X O
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 12H mmH -- Harmony3 Volume (*2) mm: 00H – 7FH (0 – 127) X O
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 20H mmH -- Harmony1 Pan (*1) mm: 00H, 01H – 40H – 7FH
(RND, L63 – C – R63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 21H mmH -- Harmony2 Pan (*1) mm: 00H, 01H – 40H – 7FH
(RND, L63 – C – R63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 22H mmH -- Harmony3 Pan (*2) mm: 00H, 01H – 40H – 7FH
(RND, L63 – C – R63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 30H mmH -- Harmony1 Detune (*1) mm: 00H – 40H – 7FH
(-64 – 0 – +63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 31H mmH -- Harmony2 Detune (*1) mm: 00H – 40H – 7FH
(-64 – 0 – +63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
02H 32H mmH -- Harmony3 Detune (*2) mm: 00H – 40H – 7FH
(-64 – 0 – +63) XO
(Harmony Channel) XXXXXX O
(Vocal Harmony
Type Edit)
XXOX
NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)
MSB LSB MSB LSB Regular/
Organ Voice
Mic/Vocal Harmony Natural
Voice
Song Main
Layer
Left
Keyboard Style Extra Panel
(main generation
method)
Upper
Lower
Style Song MIDI
00H 00H mmH -- Pitch Bend Sensitivity mm: 00H – 18H
(0 – +24[semitones]) OO
(Harmony Channel/
Melody Channel)
OOOO
(Main/
Layer/
Left)
OO O
(Mixing Console) XOOX
00H 01H mmH llH Fine Tune mm ll : 00H 00H -100[cent]
...
mm ll : 40H 00H 0[cent]
...
mm ll : 7FH 7FH 100[cent]
OXOOOO
(Main/
Layer/
Left)
OO O
(Mixing Console) XOOX
00H 02H mmH -- Coarse Tune mm: 28H – 40H – 58H
(-24 – 0 – +24[semitones]) OXOOOO
(Main/
Layer/
Left)
OO X XOOX
7FH 7FH -- -- Null - O O O O O O
(Main/
Layer/
Left)
OO X XOOX
39
MIDI PARAMETER CHANGE TABLE
* Not Received when Receive System Exclusive Message Parameters is set to off.
* Not transmitted when Transmit System Exclusive Message Parameters is set to off.
MIDI Parameter Change table (XG SYSTEM)
TOTAL SIZE 07
MIDI Parameter Change table (SYSTEM INFORMATION)
TOTAL SIZE 10
Transmitted in response to Dump Request. Not received.
MIDI Parameter Change table (EFFECT1)
TOTAL SIZE 0E
TOTAL SIZE 06
Address Size Data Parameter Description XG Default Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main Layer
Left
Keyboard Style Extra Panel
(main
generation method)
Style Song MIDI
00 00 00 4 00 – 0F MASTER TUNE -102.4 – 0 – +102.3[cent] *Panel setting
value OXOO O (Function) X O X
01 00 – 0F 1st bit 3-0→bit 15-12
02 00 – 0F 2nd bit 3-0→bit 11-8
03 00 – 0F 3rd bit 3-0→bit 7-4
4th bit 3-0→bit 3-0
04 1 00 – 7F MASTER VOLUME 0 – 127 7F O X O O X X X X X X O X
05 1 00 – 7F MASTER ATTENUATOR 0 – 127 00 X X X X X X X X X X X X
06 1 28 – 58 TRANSPOSE -24 – 0 – +24[semitones] 40 O X O O X X X X X X O X
7D 1NDRUM SETUP RESET N: Drum setup number - O
(Drum only) XXOX XXX X XOX
7E 100XG SYSTEM ON 00=XG system ON - O X O O X X X O X X O X
7F 100ALL PARAMETER RESET 00=ON - O X O O X X X O X X O X
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/Organ
Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main Layer
Left
Keyboard Style Extra Panel (main generation
method)
Style Song MIDI
01 00 00 E 20 – 7F Model Name 1 32 – 127 (ASCII CHARACTER) - - - - - - - - X X X O
... ... ... ...
0D 20 – 7F Model Name 14 32 – 127 (ASCII CHARACTER)
0E 1 NOT USED
0F 1 NOT USED
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
02 01 00 2 00 – 7F REVERB TYPE MSB Refer to Effect Parameter
List 01 (=HALL1) O O X O O (Mixing Console) O O X
00 – 7F REVERB TYPE LSB ˝ 00
02 1 00 – 7F REVERB PARAMETER 1 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console O O X
03 1 00 – 7F REVERB PARAMETER 2 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
04 1 00 – 7F REVERB PARAMETER 3 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
05 1 00 – 7F REVERB PARAMETER 4 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
06 1 00 – 7F REVERB PARAMETER 5 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
07 1 00 – 7F REVERB PARAMETER 6 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
08 1 00 – 7F REVERB PARAMETER 7 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
09 1 00 – 7F REVERB PARAMETER 8 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
0A 1 00 – 7F REVERB PARAMETER 9 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
0B 1 00 – 7F REVERB PARAMETER 10 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
0C 1 00 – 7F REVERB RETURN -∞dB – 0dB – +6dB
(0 – 96 – 127) 40 OOXO O (Mixing Console) O O X
0D 1 01 – 7F REVERB PAN L63 – C – R63 40 O O X O X O O X
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel (main generation
method)
Style Song MIDI
02 01 10 1 00 – 7F REVERB PARAMETER 11 Refer to Effect Parameter
List Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
11 1 00 – 7F REVERB PARAMETER 12 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
12 1 00 – 7F REVERB PARAMETER 13 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
13 1 00 – 7F REVERB PARAMETER 14 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
14 1 00 – 7F REVERB PARAMETER 15 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console
*Depends on Reverb Type) OOX
15 1 00 – 7F REVERB PARAMETER 16 ˝ Depends on
Reverb Type OOXO (*Depends on Reverb Type) O (Mixing Console *Depends
on Reverb Type) OOX
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
02 01 20 2 00 – 7F CHORUS TYPE MSB Refer to Effect Parameter
List
41 (=CHORUS1)
OOXO O (Mixing Console) O O X
00 – 7F CHORUS TYPE LSB ˝ 00
22 1 00 – 7F CHORUS PARAMETER 1 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
23 1 00 – 7F CHORUS PARAMETER 2 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
24 1 00 – 7F CHORUS PARAMETER 3 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
O: available
40
TOTAL SIZE 0F
TOTAL SIZE 06
TOTAL SIZE 21
25 1 00 – 7F CHORUS PARAMETER 4 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
26 1 00 – 7F CHORUS PARAMETER 5 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
27 1 00 – 7F CHORUS PARAMETER 6 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
28 1 00 – 7F CHORUS PARAMETER 7 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
29 1 00 – 7F CHORUS PARAMETER 8 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
2A 1 00 – 7F CHORUS PARAMETER 9 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
2B 1 00 – 7F CHORUS PARAMETER 10 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
2C 1 00 – 7F CHORUS RETURN -∞dB – 0dB – +6dB
(0 – 96 – 127) 40 OOXO O (Mixing Console) O O X
2D 1 01 – 7F CHORUS PAN L63 – C – R63 40 O O X O X X O X
2E 1 00 – 7F SEND CHORUS TO
REVERB -∞dB – 0dB – +6dB
(0 – 96 – 127) 00 O O X O X XOX
02 01 30 1 00 – 7F CHORUS PARAMETER 11 Refer to Effect Parameter
List Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
31 1 00 – 7F CHORUS PARAMETER 12 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
32 1 00 – 7F CHORUS PARAMETER 13 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
33 1 00 – 7F CHORUS PARAMETER 14 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
34 1 00 – 7F CHORUS PARAMETER 15 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
35 1 00 – 7F CHORUS PARAMETER 16 ˝ Depends on
Chorus Type OOXO (*Depends on Chorus Type) O (Mixing Console
*Depends on Chorus Type) OOX
02 01 40 2 00 – 7F VARIATION TYPE MSB Refer to Effect Parameter
List
05 (=DELAY L,
C, R)
OOXO O (Mixing Console) O O X
00 – 7F VARIATION TYPE LSB ˝ 00
42 2 00 – 7F VARIATION PARAMETER
1 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
1 LSB ˝
44 2 00 – 7F VARIATION PARAMETER
2 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
2 LSB ˝
46 2 00 – 7F VARIATION PARAMETER
3 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
3 LSB ˝
48 2 00 – 7F VARIATION PARAMETER
4 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
4 LSB ˝
4A 2 00 – 7F VARIATION PARAMETER
5 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
5 LSB ˝
4C 2 00 – 7F VARIATION PARAMETER
6 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
6 LSB ˝
4E 2 00 – 7F VARIATION PARAMETER
7 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
7 LSB ˝
50 2 00 – 7F VARIATION PARAMETER
8 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
8 LSB ˝
52 2 00 – 7F VARIATION PARAMETER
9 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
9 LSB ˝
54 2 00 – 7F VARIATION PARAMETER
10 MSB ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
00 – 7F VARIATION PARAMETER
10 LSB ˝
56 1 00 – 7F VARIATION RETURN -∞dB – 0dB – +6dB
(0 – 96 – 127) 40 OOXO O (Mixing Console) O O X
57 1 01 – 7F VARIATION PAN L63 – C – R63 40 O O X O X O O X
58 1 00 – 7F SEND VARIATION TO
REVERB -∞dB – 0dB – +6dB
(0 – 96 – 127) 00 O O X O X O O X
59 1 00 – 7F SEND VARIATION TO
CHORUS -∞dB – 0dB – +6dB
(0 – 96 – 127) 00 O O X O X O O X
5A 1 00 – 01 VARIATION CONNECTION INSERTION, SYSTEM 00 O O X O X O O X
5B 1 00 – 7F VARIATION PART
NUMBER Reception:
Part 1 – 16 (0 – 15)
Transmission:
Part 1 – 16 (0 – 15)
AD (64)
OFF (127)
7F OOXO O (Mixing Console) O O X
5C 1 00 – 7F MW VARIATION
CONTROL DEPTH -64 – 0 – +63 40 O O X O X O O X
5D 1 00 – 7F BEND VARIATION
CONTROL DEPTH -64 – 0 – +63 40 O O X O X O O X
5E 1 00 – 7F CAT VARIATION
CONTROL DEPTH -64 – 0 – +63 40 O O X O X O O X
5F 1 00 – 7F AC1 VARIATION
CONTROL DEPTH -64 – 0 – +63 40 X X X X X X X X
60 1 00 – 7F AC2 VARIATION
CONTROL DEPTH -64 – 0 – +63 40 X X X X X X X X
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
41
TOTAL SIZE 06
MIDI Parameter Change table (MULTI EQ) (CVP-210/208 only)
TOTAL SIZE 5 The MULTI EQ Parameter cannot be reset to its factory setting with XG SYSTEM ON.
MIDI Parameter Change table (EFFECT2) (CVP-210/208 only)
TOTAL SIZE 12
TOTAL SIZE 6
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
72 1 00 – 7F VARIATION PARAMETER
13 ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
73 1 00 – 7F VARIATION PARAMETER
14 ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
74 1 00 – 7F VARIATION PARAMETER
15 ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
75 1 00 – 7F VARIATION PARAMETER
16 ˝Depends on
Variation Type OOXO (*Depends on Variation Type) O (Mixing Console
*Depends on Variation Type) OOX
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel (main generation
method)
Style Song MIDI
02 40 00 1 00 – 04 EQ TYPE flat, jazz, pops, rock, classic O O X O X X O X
01 1 34 – 4C EQ GAIN1 -12 – 0 – +12[dB] O O X O O (Mixing Console) X O X
02 1 04 – 28 EQ FREQUENCY1 32 – 2.0k[Hz] O O X O O (Mixing Console) X O X
03 1 01 – 78 EQ Q1 0.1 – 12.0 O O X O O (Mixing Console) X O X
04 1 00 – 01 EQ SHAPE1 shelving, peaking O O X O X X O X
05 1 34 – 4C EQ GAIN2 -12 – 0 – +12[dB] O O X O O (Mixing Console) X O X
06 1 0E – 36 EQ FREQUENCY2 100 – 10.0k[Hz] O O X O O (Mixing Console) X O X
07 1 01 – 78 EQ Q2 0.1 – 12.0 O O X O O (Mixing Console) X O X
08 1 NOT USED - - - - - - - -
09 1 34 – 4C EQ GAIN3 -12 – 0 – +12[dB] O O X O O (Mixing Console) X O X
0A 1 0E – 36 EQ FREQUENCY3 100 – 10.0k[Hz] O O X O O (Mixing Console) X O X
0B 1 01 – 78 EQ Q3 0.1 – 12.0 O O X O O (Mixing Console) X O X
0C 1 NOT USED - - - - - - - -
0D 1 34 – 4C EQ GAIN4 -12 – 0 – +12[dB] O O X O O (Mixing Console) X O X
0E 1 0E – 36 EQ FREQUENCY4 100 – 10.0k[Hz] O O X O O (Mixing Console) X O X
0F 1 01 – 78 EQ Q4 0.1 – 12.0 O O X O O (Mixing Console) X O X
10 1 NOT USED - - - - - - - -
11 1 34 – 4C EQ GAIN5 -12 – 0 – +12[dB] O O X O O (Mixing Console) X O X
12 1 1C – 3A EQ FREQUENCY5 0.5k – 16.0k[Hz] O O X O O (Mixing Console) X O X
13 1 01 – 78 EQ Q5 0.1 – 12.0 O O X O O (Mixing Console) X O X
14 1 00 – 01 EQ SHAPE5 shelving, peaking O O X O X X O X
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel (main generation
method)
Style Song MIDI
03n00200 – 7F INSERTION EFFECT TYPE
MSB Refer to Effect Parameter
List OOXO O (Mixing Console) X O X
00 – 7F INSERTION EFFECT TYPE
LSB ˝
02 1 00 – 7F INSERTION EFFECT
PARAMETER 1 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
03 1 00 – 7F INSERTION EFFECT
PARAMETER 2 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
04 1 00 – 7F INSERTION EFFECT
PARAMETER 3 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
05 1 00 – 7F INSERTION EFFECT
PARAMETER 4 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
06 1 00 – 7F INSERTION EFFECT
PARAMETER 5 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
07 1 00 – 7F INSERTION EFFECT
PARAMETER 6 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
08 1 00 – 7F INSERTION EFFECT
PARAMETER 7 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
09 1 00 – 7F INSERTION EFFECT
PARAMETER 8 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
0A 1 00 – 7F INSERTION EFFECT
PARAMETER 9 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
0B 1 00 – 7F INSERTION EFFECT
PARAMETER 10 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
0C 1 00 – 7F INSERTION EFFECT PART
NUMBER Reception:
Part 1 – 16 (0 – 15)
Transmission:
Part 1 – 16 (0 – 15)
AD (64)
OFF (127)
OOXO O (Mixing Console) X O X
0D 1 00 – 7F MW INSERTION CONTROL
DEPTH -64 – 0 – +63 O O X O X X O X
0E 1 00 – 7F BEND INSERTION
CONTROL DEPTH -64 – 0 – +63 O O X O X X O X
0F 1 00 – 7F CAT INSERTION CONTROL
DEPTH -64 – 0 – +63 O O X O X X O X
10 1 00 – 7F AC1 INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X
11 1 00 – 7F AC2 INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X
03n20100 – 7F INSERTION EFFECT
PARAMETER 11 Refer to Effect Parameter
List OOXO (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
21 1 00 – 7F INSERTION EFFECT
PARAMETER 12 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
22 1 00 – 7F INSERTION EFFECT
PARAMETER 13 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
23 1 00 – 7F INSERTION EFFECT
PARAMETER 14 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
24 1 00 – 7F INSERTION EFFECT
PARAMETER 15 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
25 1 00 – 7F INSERTION EFFECT
PARAMETER 16 ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
42
TOTAL SIZE 14 The EFFECT 2 Parameter cannot be reset to its factory setting with XG SYSTEM ON.
The second byte of the address is considered as an Insertion effect number.
n: insertion effect number
For effect types that do not require MSB, the Parameters for Address 02 – 0B will be received and the Parameters for Address 30 – 42 will not be received.
For effect types that require MSB, the Parameters for Address 30 – 42 will be received and the Parameters for Address 02 – 0B will not be received.
When Bulk Dumps that include Effect Type data are transmitted, the Parameters for Address 02 – 0B will always be transmitted. But, effects that require MSB, when the bulk dump is received the Parameters for
Address 02 – 0B will not be received.
CVP-210: n=0 – 4
CVP-208: n=0 – 2
MIDI Parameter Change table (SPECIAL EFFECT) (CVP-210/208 only)
TOTAL SIZE 12
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
03n30200 – 7F INSERTION EFFECT
PARAMETER 1 MSB Refer to Effect Parameter
List OOXO (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 1 LSB ˝
32 2 00 – 7F INSERTION EFFECT
PARAMETER 2 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 2 LSB ˝
34 2 00 – 7F INSERTION EFFECT
PARAMETER 3 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 3 LSB ˝
36 2 00 – 7F INSERTION EFFECT
PARAMETER 4 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 4 LSB ˝
38 2 00 – 7F INSERTION EFFECT
PARAMETER 5 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 5 LSB ˝
3A 2 00 – 7F INSERTION EFFECT
PARAMETER 6 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 6 LSB ˝
3C 2 00 – 7F INSERTION EFFECT
PARAMETER 7 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 7 LSB ˝
3E 2 00 – 7F INSERTION EFFECT
PARAMETER 8 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 8 LSB ˝
40 2 00 – 7F INSERTION EFFECT
PARAMETER 9 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 9 LSB ˝
42 2 00 – 7F INSERTION EFFECT
PARAMETER 10 MSB ˝OOX O (*Depends on Insertion Type) O (Mixing Console
*Depends on Insertion Type) XOX
00 – 7F INSERTION EFFECT
PARAMETER 10 LSB ˝
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
04 00 00 2 00 – 7F INSERTION EFFECT TYPE
MSB Vocoder (89), Chordal (90),
Detune (91), Chromatic (92),
Thru (0 – 88, 93 – 127)
XOXXX XXXO (VH Type Select) X O X
00 – 7F INSERTION EFFECT TYPE
LSB
02 1 00 – 7F INSERTION EFFECT
PARAMETER 1
Harmony Mode
XOXXX XXXO (VH Type Select) X O X
03 1 00 – 7F INSERTION EFFECT
PARAMETER 2
Harmony Gender Type
Off (0), Auto (1)XOXXX XXXO (VH Type Select) X O X
04 1 00 – 7F INSERTION EFFECT
PARAMETER 3
Lead Gender Type
Off (0), Unison (1), Male (2),
Female (3) XOXXX XXXO (VH Type Select) X O X
05 1 00 – 7F INSERTION EFFECT
PARAMETER 4
Lead Gender Depth
-64 – 0 – +63 (0 – 127) X O X X X X X X O (VH Type Select) X O X
06 1 00 – 7F INSERTION EFFECT
PARAMETER 5
Lead Pitch Correction
Free (0), Correct (1)XOXXX XXXO (VH Type Select) X O X
07 1 00 – 7F INSERTION EFFECT
PARAMETER 6
Auto Upper Gender Threshold
0 – 12 (0 – 12) XOXXX XXXO (VH Type Select) X O X
08 1 00 – 7F INSERTION EFFECT
PARAMETER 7
Auto Lower Gender Threshold
0 – 12 (0 – 12) XOXXX XXXO (VH Type Select) X O X
09 1 00 – 7F INSERTION EFFECT
PARAMETER 8
Upper Gender Depth
-64 – 0 – +63 (0 – 127) X O X X X X X X O (VH Type Select) X O X
0A 1 00 – 7F INSERTION EFFECT
PARAMETER 9
Lower Gender Depth
-64 – 0 – +63 (0 – 127) X O X X X X X X O (VH Type Select) X O X
0B 1 00 – 7F INSERTION EFFECT
PARAMETER 10 L63>H – L=H – L<H63
(1 – 64 – 127) XOXXX XXX O (MicSetting) X O X
0C 1 00 – 7F INSERTION EFFECT PART
NUMBER AD (64),
OFF (0 – 63, 65 – 127) XOXXX XXXO (Vocal Harmony Sw) X O X
0D 1 00 – 7F MW INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X X X X X
0E 1 00 – 7F BEND INSERTION
CONTROL DEPTH -64 – 0 – +63 X X X X X X X X X X X X
0F 1 00 – 7F CAT INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X X X X X
10 1 00 – 7F AC1 INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X X X X X
11 1 00 – 7F AC2 INSERTION CONTROL
DEPTH -64 – 0 – +63 X X X X X X X X X X X X
43
TOTAL SIZE 2
TOTAL SIZE 6 The SPECIAL EFFECT Parameter cannot be reset to its factory setting with XG SYSTEM ON.
MIDI Parameter Change table (MULTI PART)
TOTAL SIZE 29
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
04 00 14 1 00 – 7F UNIQUE INSERTION
EFFECT EXTERNAL
CONTROL CH1 (HARMONY
CHANNEL)
1 – 16 (0 – 15), OFF (127) X O X X X X X X O (MicSetting) X O X
15 1 00 – 7F UNIQUE INSERTION
EFFECT EXTERNAL
CONTROL CH1 (MELODY
CHANNEL)
1 – 16 (0 – 15), OFF (127) X O X X X X X X X X O X
04 00 20 1 00 – 7F INSERTION EFFECT
PARAMETER 11
Vibrate Depth
0 – 100cent (0 – 127) X O X X X X X X O (VH Type Select) X O X
21 1 00 – 7F INSERTION EFFECT
PARAMETER 12
Vibrate Rate
0Hz (0),
0.1 – 12.7Hz (1 – 127) XOXXX XXXO (VH Type Select) X O X
22 1 00 – 7F INSERTION EFFECT
PARAMETER 13
Vibrate Delay
0 – 2.54sec (0 – 127) X O X X X X X X O (VH Type Select) X O X
23 1 00 – 7F INSERTION EFFECT
PARAMETER 14 XXXXX XXX X XXX
24 1 00 – 7F INSERTION EFFECT
PARAMETER 15 XXXXX XXX X XXX
25 1 00 – 7F INSERTION EFFECT
PARAMETER 16 XXXXX XXX X XXX
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
08 nn 00 1 00 – 20 ELEMENT RESERVE 0 – 32 part10=00,
other parts=02 OXXOX XXX X XOX
01 1 00 – 7F BANK SELECT MSB 0 – 127 part10=7F,
other parts =00 OXOOO XOO X XOX
02 1 00 – 7F BANK SELECT LSB 0 – 127 00 O X O O O X O O X X O X
03 1 00 – 7F PROGRAM NUMBER 0 – 127 00 O X O O O X O O X X O X
04 1 00 – 0F,
7F Rcv CHANNEL 1 – 16, OFF Part No. O X X O X X X X X X O X
05 1 00 – 01 MONO/POLY MODE MONO, POLY 01 O X X O X X X X X X O X
06 1 00 – 02 SAME NOTE NUMBER
KEY ON ASSIGN SINGLE, MULTI, INST
(for Drum) 01 O X XOX XOX X XOX
07 1 00 – 03 PART MODE NORMAL, DRUM,
DRUMS1 – 2 part10=02,
other parts=00 OXOOXXXXO (Drum Voice) X O X
08 1 00 – 7F CHANNEL TRANSPOSE -24 – 0 – +24[semitones] 40 O X O O O X O O X X O X
09
0A 200 – 0F
00 – 0F DETUNE -12.8 – 0 – +12.7[Hz]
1st bit3-0→bit7-4
2nd bit3-0→bit3-0
08 00 O X O O O X O O X X O X
0B 1 00 – 7F VOLUME 0 – 127 64 O X O O O X O O X X O X
0C 1 00 – 7F VELOCITY SENSE DEPTH 0 – 127 40 O X O O O X X O O (Sound Creator) X O X
0D 1 00 – 7F VELOCITY SENSE
OFFSET 0 – 127 40 OXOOO XXOO (Sound Creator) X O X
0E 1 00 – 7F PAN RND, L63 – C – R63 40 O X O O O X O O X X O X
0F 1 00 – 7F NOTE LIMIT LOW C-2 – G8 00 O X X O X X X X X X O X
10 1 00 – 7F NOTE LIMIT HIGH C-2 – G8 7F O X X O X X X X X X O X
11 1 00 – 7F DRY LEVEL 0 – 127 7F O X X O O X O O O (Sound Creator) X O X
12 1 00 – 7F CHORUS SEND 0 – 127 00 O X O O O X O O X X O X
13 1 00 – 7F REVERB SEND 0 – 127 28 O X O O O X O O X X O X
14 1 00 – 7F VARIATION SEND 0 – 127 00 O X X O O X O O X X O X
15 1 00 – 7F VIBRATO RATE -64 – 0 – +63 40 O X X O O X O O X X O X
16 1 00 – 7F VIBRATO DEPTH -64 – 0 – +63 40 O X X O O X O O X X O X
17 1 00 – 7F VIBRATO DELAY -64 – 0 – +63 40 O X X O O X O O X X O X
18 1 00 – 7F FILTER CUTOFF
FREQUENCY -64 – 0 – +63 40 O X X O O X O O X X O X
19 1 00 – 7F FILTER RESONANCE -64 – 0 – +63 40 O X X O O X O O X X O X
1A 1 00 – 7F EG ATTACK TIME -64 – 0 – +63 40 O X X O O X O O X X O X
1B 1 00 – 7F EG DECAY TIME -64 – 0 – +63 40 O X X O O X O O X X O X
1C 1 00 – 7F EG RELEASE TIME -64 – 0 – +63 40 O X X O O X O O X X O X
1D 1 28 – 58 MW PITCH CONTROL -24 – 0 – +24[semitones] 40 O X X O O X O O X X O X
1E 1 00 – 7F MW LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 O X X O O X O O X X O X
1F 1 00 – 7F MW AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 O X X O O X O O X X O X
20 1 00 – 7F MW LFO PMOD DEPTH 0 – 127 0A O X X O O X O O X X O X
21 1 00 – 7F MW LFO FMOD DEPTH 0 – 127 00 O X X O O X O O X X O X
22 1 00 – 7F MW LFO AMOD DEPTH 0 – 127 00 O X X O O X O O X X O X
23 1 28 – 58 BEND PITCH CONTROL -24 – 0 – +24[semitones] 42 O X O O O X O O X X O X
24 1 00 – 7F BEND LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 O X X O O X O O X X O X
25 1 00 – 7F BEND AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 O X X O O X O O X X O X
26 1 00 – 7F BEND LFO PMOD DEPTH 0 – 127 00 O X X O O X O O X X O X
27 1 00 – 7F BEND LFO FMOD DEPTH 0 – 127 00 O X X O O X O O X X O X
28 1 00 – 7F BEND LFO AMOD DEPTH 0 – 127 00 O X X O O X O O X X O X
08 nn 30 1 00 – 01 Rcv PITCH BEND OFF, ON 01 X X X X X X X X X X X X
31 1 00 – 01 Rcv CH AFTER TOUCH
(CAT) OFF, ON 01 X X X X X X X X X X X X
32 1 00 – 01 Rcv PROGRAM CHANGE OFF, ON 01 X X X X X X X X X X X X
33 1 00 – 01 Rcv CONTROL CHANGE OFF, ON 01 X X X X X X X X X X X X
34 1 00 – 01 Rcv POLY AFTER TOUCH
(PAT) OFF, ON 01 X X X X X X X X X X X X
35 1 00 – 01 Rcv NOTE MESSAGE OFF, ON 01 O X O O X X X X X X O X
36 1 00 – 01 Rcv RPN OFF, ON 01 X X X X X X X X X X X X
37 1 00 – 01 Rcv NRPN OFF, ON XG mode=01,
GM mode=00 XXXXX XXX X XXX
38 1 00 – 01 Rcv MODULATION OFF, ON 01 X X X X X X X X X X X X
39 1 00 – 01 Rcv VOLUME OFF, ON 01 X X X X X X X X X X X X
3A 1 00 – 01 Rcv PAN OFF, ON 01 X X X X X X X X X X X X
3B 1 00 – 01 Rcv EXPRESSION OFF, ON 01 X X X X X X X X X X X X
44
TOTAL SIZE 3F
TOTAL SIZE 04
TOTAL SIZE 0C
nn = PART NUMBER
If there is a Drum Voice assigned to the part, the following parameters are ineffective.
• BANK SELECT LSB
• MONO/POLY MODE
• SCALE TUNING
• PORTAMENTO
• PITCH EG
• FILTER MODULATION DEPTH (FMOD DEPTH)
• AMPLITUDE MODULATION DEPTH (AMOD DEPTH)
*1 On CVP-206/204 the following parameters are not accepted, or are not transmitted by the Panel operations.
• EQ BASS GAIN
• EQ TREBLE GAIN
• EQ BASS FREQUENCY
• EQ TREBLE FREQUENCY
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
3C 1 00 – 01 Rcv HOLD1 OFF, ON 01 X X X X X X X X X X X X
3D 1 00 – 01 Rcv PORTAMENTO OFF, ON 01 X X X X X X X X X X X X
3E 1 00 – 01 Rcv SOSTENUTO OFF, ON 01 X X X X X X X X X X X X
3F 1 00 – 01 Rcv SOFT PEDAL OFF, ON 01 X X X X X X X X X X X X
40 1 00 – 01 Rcv BANK SELECT OFF, ON 01 X X X X X X X X X X X X
41 1 00 – 7F SCALE TUNING C -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
42 1 00 – 7F SCALE TUNING C -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
43 1 00 – 7F SCALE TUNING D -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
44 1 00 – 7F SCALE TUNING D -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
45 1 00 – 7F SCALE TUNING E -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
46 1 00 – 7F SCALE TUNING F -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
47 1 00 – 7F SCALE TUNING F -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
48 1 00 – 7F SCALE TUNING G -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
49 1 00 – 7F SCALE TUNING G -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
4A 1 00 – 7F SCALE TUNING A -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
4B 1 00 – 7F SCALE TUNING A -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
4C 1 00 – 7F SCALE TUNING B -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X O X
4D 1 28 – 58 CAT PITCH CONTROL -24 – 0 – +24[semitones] 40 O X X O O X X O X X O X
4E 1 00 – 7F CAT LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 O X X O O X X O X X O X
4F 1 00 – 7F CAT AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 O X X O O X X O X X O X
50 1 00 – 7F CAT LFO PMOD DEPTH 0 – 127 00 O X X O O X X O X X O X
51 1 00 – 7F CAT LFO FMOD DEPTH 0 – 127 00 O X X O O X X O X X O X
52 1 00 – 7F CAT LFO AMOD DEPTH 0 – 127 00 O X X O O X X O X X O X
53 1 28 – 58 PAT PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X X X X
54 1 00 – 7F PAT LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 X X X X X X X X X X X X
55 1 00 – 7F PAT AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 X X X X X X X X X X X X
56 1 00 – 7F PAT LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
57 1 00 – 7F PAT LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
58 1 00 – 7F PAT LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
59 1 00 – 5F AC1 CONTROLLER
NUMBER 0 – 95 10 X X X X X X X X X X X X
5A 1 28 – 58 AC1 PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X X X X
5B 1 00 – 7F AC1 LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 X X X X X X X X X X X X
5C 1 00 – 7F AC1 AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 X X X X X X X X X X X X
5D 1 00 – 7F AC1 LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
5E 1 00 – 7F AC1 LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
5F 1 00 – 7F AC1 LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
60 1 00 – 5F AC2 CONTROLLER
NUMBER 0 – 95 11 X X X X X X X X X X X X
61 1 28 – 58 AC2 PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X X X X
62 1 00 – 7F AC2 LOW PASS FILTER
CONTROL -9600 – 0 – +9450[cent] 40 X X X X X X X X X X X X
63 1 00 – 7F AC2 AMPLITUDE
CONTROL -100 – 0 – +100[%] 40 X X X X X X X X X X X X
64 1 00 – 7F AC2 LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
65 1 00 – 7F AC2 LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
66 1 00 – 7F AC2 LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X X X X
67 1 00 – 01 PORTAMENTO SWITCH OFF, ON 00 O X X O O X X O X X O X
68 1 00 – 7F PORTAMENTO TIME 0 – 127 00 O X X O O X X O X X O X
69 1 00 – 7F PITCH EG INITIAL LEVEL -64 – 0 – +63 40 X X X X X X X X X X X X
6A 1 00 – 7F PITCH EG ATTACK TIME -64 – 0 – +63 40 X X X X X X X X X X X X
6B 1 00 – 7F PITCH EG RELEASE
LEVEL -64 – 0 – +63 40 X X X X X X X X X X X X
6C 1 00 – 7F PITCH EG RELEASE TIME -64 – 0 – +63 40 X X X X X X X X X X X X
6D 1 01 – 7F VELOCITY LIMIT LOW 1 – 127 01 X X X X X X X X X X X X
6E 1 01 – 7F VELOCITY LIMIT HIGH 1 – 127 7F X X X X X X X X X X X X
08 nn 70 1 NOT USED - - - - - - - - - - - - -
71 1 NOT USED - - - - - - - - - - - - -
72 1 00 – 7F EQ BASS GAIN -12dB – +12dB 40 O (*1) X X O (*1) O (*1) X O (*1) O (*1) O (Mixing Console) (*1) O O X
73 1 00 – 7F EQ TREBLE GAIN -12dB – +12dB 40 O (*1) X X O (*1) O (*1) X O (*1) O (*1) O (Mixing Console) (*1) O O X
08 nn 74 1 NOT USED - - - - - - - - - - - - -
75 1 NOT USED - - - - - - - - - - - - -
76 1 04 – 28 EQ BASS FREQUENCY 32 – 2.0k[Hz] 0C O (*1) X X O (*1) O (*1) X X O (*1) O (Sound Creator) (*1) X O X
77 1 1C – 3A EQ TREBLE FREQUENCY 500 – 16.0k[Hz] 36 O (*1) X X O (*1) O (*1) X X O (*1) O (Sound Creator) (*1) X O X
78 1 NOT USED - - - - - - - - - - - - -
79 1 NOT USED - - - - - - - - - - - - -
7A 1 NOT USED - - - - - - - - - - - - -
7B 1 NOT USED - - - - - - - - - - - - -
7C 1 NOT USED - - - - - - - - - - - - -
7D 1 NOT USED - - - - - - - - - - - - -
7E 1 NOT USED - - - - - - - - - - - - -
7F 1 NOT USED - - - - - - - - - - - - -
45
MIDI Parameter Change table (A/D PART) (CVP-210/208/206 only)
TOTAL SIZE 15
TOTAL SIZE 31 The A/D PART Parameter cannot be reset to its factory setting with XG SYSTEM ON.
MIDI Parameter Change table (DRUM SETUP)
Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
(H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
10 00 00 1 00 – 01 INPUT GAIN MIC, LINE X X X X X X X X X X X X
01 1 00 – 7F BANK SELECT MSB 0 – 127 X X X X X X X X X X X X
02 1 00 – 7F BANK SELECT LSB 0 – 127 X X X X X X X X X X X X
03 1 00 – 7F PROGRAM NUMBER 0 – 127 X X X X X X X X X X X X
04 1 00 – 1F,
7F Rcv CHANNEL 1 – 16, OFF X O X X X X X X X X O X
05 1 NOT USED - - - - - - - - - - - -
06 1 NOT USED - - - - - - - - - - - -
07 1 NOT USED - - - - - - - - - - - -
08 1 NOT USED - - - - - - - - - - - -
09 1 NOT USED - - - - - - - - - - - -
0A 1 NOT USED - - - - - - - - - - - -
0B 1 00-7F VOLUME 0 – 127 X O X X X X X X O (Mixing Console) X O X
0C 1 NOT USED - - - - - - - - - - - -
0D 1 NOT USED - - - - - - - - - - - -
0E 1 01-7F PAN L63 – C – R63 X O X X X X X X O (Mixing Console) X O X
0F 1 NOT USED - - - - - - - - - - - -
10 1 NOT USED - - - - - - - - - - - -
11 1 00-7F DRY LEVEL X O X X X X X X O (Mixing Console)
(CVP-206 only)XOX
12 1 00-7F CHORUS SEND X O X X X X X X O (Mixing Console) X O X
13 1 00-7F REVERB SEND X O X X X X X X O (Mixing Console) X O X
14 1 00-7F VARIATION SEND X O X X X X X X O (Mixing Console)
(CVP-206 only)XOX
10 0n 30 1 NOT USED - - - - - - - - - - - -
31 1 NOT USED - - - - - - - - - - - -
32 1 00-01 Rcv PROGRAM CHANGE OFF, ON X X X X X X X X X X X X
33 1 00-01 Rcv CONTROL CHANGE OFF, ON X X X X X X X X X X X X
34 1 NOT USED - - - - - - - - - - - -
35 1 00-01 MUTE ON, OFF X X X X X X X X X X X X
36 1 NOT USED - - - - - - - - - - - -
37 1 NOT USED - - - - - - - - - - - -
38 1 NOT USED - - - - - - - - - - - -
39 1 00-01 Rcv VOLUME OFF, ON X X X X X X X X X X X X
3A 1 00-01 Rcv PAN OFF, ON X X X X X X X X X X X X
3B 1 00-01 Rcv EXPRESSION OFF, ON X X X X X X X X X X X X
3C 1 NOT USED - - - - - - - - - - - -
3D 1 NOT USED - - - - - - - - - - - -
3E 1 NOT USED - - - - - - - - - - - -
3F 1 NOT USED - - - - - - - - - - - -
40 1 00-01 Rcv BANK SELECT OFF, ON X X X X X X X X X X X X
41 1 NOT USED - - - - - - - - - - - -
42 1 NOT USED - - - - - - - - - - - -
43 1 NOT USED - - - - - - - - - - - -
44 1 NOT USED - - - - - - - - - - - -
45 1 NOT USED - - - - - - - - - - - -
46 1 NOT USED - - - - - - - - - - - -
47 1 NOT USED - - - - - - - - - - - -
48 1 NOT USED - - - - - - - - - - - -
49 1 NOT USED - - - - - - - - - - - -
4A 1 NOT USED - - - - - - - - - - - -
4B 1 NOT USED - - - - - - - - - - - -
4C 1 NOT USED - - - - - - - - - - - -
4D 1 NOT USED - - - - - - - - - - - -
4E 1 NOT USED - - - - - - - - - - - -
4F 1 NOT USED - - - - - - - - - - - -
50 1 NOT USED - - - - - - - - - - - -
51 1 NOT USED - - - - - - - - - - - -
52 1 NOT USED - - - - - - - - - - - -
53 1 NOT USED - - - - - - - - - - - -
54 1 NOT USED - - - - - - - - - - - -
55 1 NOT USED - - - - - - - - - - - -
56 1 NOT USED - - - - - - - - - - - -
57 1 NOT USED - - - - - - - - - - - -
58 1 NOT USED - - - - - - - - - - - -
59 1 00 – 5F AC1 CONTROLLER
NUMBER 0 – 95 X X X X X X X X X X X X
5A 1 NOT USED - - - - - - - - - - - -
5B 1 NOT USED - - - - - - - - - - - -
5C 1 NOT USED - - - - - - - - - - - -
5D 1 NOT USED - - - - - - - - - - - -
5E 1 NOT USED - - - - - - - - - - - -
5F 1 NOT USED - - - - - - - - - - - -
60 1 00 – 5F AC2 CONTROLLER
NUMBER 0 – 95 X X X X X X X X X X X X
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
3n rr 00 1 00 – 7F PITCH COARSE -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
01 1 00 – 7F PITCH FINE -64 – 0 – +63[cent] 40 O
(Drum only) XXOX XXX X OOX
02 1 00 – 7F LEVEL 0 – 127 Depends on
the note
O
(Drum only) XXOX XXX X OOX
03 1 00 – 7F ALTERNATE GROUP OFF, 1 – 127 Depends on
the note O
(Drum only) XXOX XXX X XOX
04 1 00 – 7F PAN RND, L63 – C – R63 Depends on
the note O
(Drum only) XXOX XXX X OOX
05 1 00 – 7F REVERB SEND 0 – 127 Depends on
the note O
(Drum only) XXOX XXX X OOX
06 1 00 – 7F CHORUS SEND 0 – 127 Depends on
the note O
(Drum only) XXOX XXX X OOX
46
TOTAL SIZE 10
TOTAL SIZE 0E
n: Drum Setup Number (0 – 1)
rr: note number (0D – 5B)
In the following cases, the Clavinova will initialize all Drum Setups.
XG SYSTEM ON received
GM SYSTEM ON received
DRUM SETUP RESET received (only when in XG mode)
[Note]
When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized.
If the same Drum Setup is assigned to two or more parts, changes in Drum Setup parameters (including program changes) will apply to all parts to which it is assigned.
07 1 00 – 7F VARIATION SEND 0 – 127 7F O
(Drum only) XXOX XXX X OOX
08 1 00 – 01 KEY ASSIGN SINGLE, MULTI 00 O
(Drum only) XXOX XXX X XOX
09 1 00 – 01 Rcv NOTE OFF OFF, ON Depends on
the note O
(Drum only) XXOX XXX X XOX
0A 1 00 – 01 Rcv NOTE ON OFF, ON 01 O
(Drum only) XXOX XXX X XOX
0B 1 00 – 7F LOW PASS FILTER
CUTOFF FREQUENCY -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
0C 1 00 – 7F LOW PASS FILTER
RESONANCE -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
0D 1 00 – 7F EG ATTACK RATE -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
0E 1 00 – 7F EG DECAY1 RATE -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
0F 1 00 – 7F EG DECAY2 RATE -64 – 0 – +63 40 O
(Drum only) XXOX XXX X OOX
20 1 00 – 7F EQ BASS GAIN -12 – +12[dB] 40 X X X X X X X X X X X X
21 1 00 – 7F EQ TREBLE GAIN -12 – +12[dB] 40 X X X X X X X X X X X X
22 1 NOT USED - - - - - - - - - - - - -
23 1 NOT USED - - - - - - - - - - - - -
24 1 04 – 28 EQ BASS FREQUENCY 32 – 2.0k[Hz] 0C X X X X X X X X X X X X
25 1 1C – 3A EQ TREBLE FREQUENCY 500 – 16.0k[Hz] 36 X X X X X X X X X X X X
26 1 NOT USED - - - - - - - - - - - - -
27 1 NOT USED - - - - - - - - - - - - -
28 1 NOT USED - - - - - - - - - - - - -
29 1 NOT USED - - - - - - - - - - - - -
2A 1 NOT USED - - - - - - - - - - - - -
2B 1 NOT USED - - - - - - - - - - - - -
2C 1 NOT USED - - - - - - - - - - - - -
2D 1 NOT USED - - - - - - - - - - - - -
Address Size Data Parameter Description XG Default Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Transmission (generated data)
(H) (H) (H) (H) Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation method)
Style Song MIDI
47
SYSTEM EXCLUSIVE MESSAGES
* Not received when the Receive System Exclusive Message is set to off.
* Not transmitted when the Transmit System Exclusive Message is set to off.
System Exclusive Messages
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
Section
Control F0 43 7E 00 ss dd F7 ----- ---O (Section LED) O (Section Sw) X O X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000000 00 =
0sssssss ss = Switch No.
00H INTRO A
01H INTRO B
02H INTRO C
03H INTRO D
08H MAIN A
09H MAIN B
0AH MAIN C
0BH MAIN D
10H FILL IN AA
11H FILL IN BB
12H FILL IN CC
13H FILL IN DD
18H BREAK FILL
20H ENDING A
21H ENDING B
22H ENDING C
23H ENDING D
0ddddddd dd = Switch On/Off
00H (Off)
7HF (On)
11110111 F7 = End of Exclusive
Tempo
Control F0 43 7E 01 t4 t3 t2 t1 F7 ----- ---O (Tempo
indication)
O (Tempo Sw) X O X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000001 01 =
0ttttttt t4 = tempo4
0ttttttt t3 = tempo3
0ttttttt t2 = tempo2
0ttttttt t1 = tempo1
11110111 F7 = End of Exclusive
Chord
Control F0 43 7E tt d1 d2 d3 d4 F7 ----- ---O (Chord
indication)
O (Keyboard) X O X
Type 1 (tt=2)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000010 02 = type 1
0ddddddd d1 = chord root(cr)
0ddddddd d2 = chord type(ct)
0ddddddd d3 = bass note(bn)
0ddddddd d4 = bass type(bt)
11110111 F7 = End of Exclusive
cr: Chord Root 0fffnnnn
fff: b or #, nnnn: note(root)
0000nnnn 0n bbb 0fff0000 x0 reserved
0001nnnn 1n bb 0fff0001 x1 C
0010nnnn 2n b 0fff0010 x2 D
0011nnnn 3n natural 0fff0011 x3 E
0100nnnn 4n # 0fff0100 x4 F
0101nnnn 5n ## 0fff0101 x5 G
0110nnnn 6n ### 0fff0110 x6 A
0fff0111 x7 B
ct: Chord Type 0 – 34,127
00000000 00 0 Maj 00010010 12 18 dim7
00000001 01 1 Maj6 00010011 13 19 7th
00000010 02 2 Maj7 00010100 14 20 7sus4
00000011 03 3 Maj7(#11) 00010101 15 21 7b5
00000100 04 4 Maj(9) 00010110 16 22 7(9)
00000101 05 5 Maj7(9) 00010111 17 23 7(#11)
00000110 06 6 Maj6(9) 00011000 18 24 7(13)
00000111 07 7 aug 00011001 19 25 7(b9)
00001000 08 8 min 00011010 1A 26 7(b13)
00001001 09 9 min6 00011011 1B 27 7(#9)
00001010 0A 10 min7 00011100 1C 28 Maj7aug
00001011 0B 11 min7b5 00011101 1D 29 7aug
00001100 0C 12 min(9) 00011110 1E 30 1+8
00001101 0D 13 min7(9) 00011111 1F 31 1+5
00001110 0E 14 min7(11) 00100000 20 32 sus4
00001111 0F 15 minMaj7 00100001 21 33 1+2+5
00010000 10 16 minMaj7(9) 00100010 22 34 cc
00010001 11 17 dim
bn : On Bass Chord Same as Chord root
127: No bass chord
bt : Bass Chord Same as Chord type
127: No bass chord
* Not received when Receive Chord System Exclusive Message is set to
off.
* Not transmitted when Transmit Chord System Exclusive Message is set
to on.
Type2 (tt=3) ----- ---O (Chord
indication)
XXXX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000011 03 = type 2
0ddddddd dd = note1
0ddddddd dd = note2
0ddddddd dd = note3
: :
0ddddddd dd = ... note10
11110111 F7 = End of Exclusive
O: available
48
System Exclusive Messages (Universal Realtime messages)
System Exclusive Messages (Universal Non Realtime messages)
System Exclusive Messages (XG)
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
Master
Volume F0 7F 7F 04 01 ll mm F7 O-OOXXXX X X XXX
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
01111111 7F = ID of target device
00000100 04 = Sub-ID #1=Device Control Message
00000001 01 = Sub-ID #2=Master Volume
0lllllll ll = Volume LSB
0mmmmmmm mm= Volume MSB
11110111 F7 = End of Exclusive
or
(Output as
XG Master
Volume )
F0 7F XN 04 01 ll mm F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0 – F, whichever is received.
X=ignored
00000100 04 = Sub-ID #1=Device Control Message
00000001 01 = Sub-ID #2=Master Volume
0lllllll ll = Volume LSB
0mmmmmmm mm= Volume MSB
11110111 F7 = End of Exclusive
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
General MIDI
System On F0 7E 7F 09 01 F7 O-OOXXXO O
(Mixing Console)
XXOX
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
01111111 7F = ID of target device
00001001 09 = Sub-ID #1=General MIDI Message
00000001 01 = Sub-ID #2=General MIDI On
11110111 F7 = End of Exclusive
or
F0 7E XN 09 01 F7
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0 – F,whichever is received.
X=ignored
00001001 09 = Sub-ID #1=General MIDI Message
00000001 01 = Sub-ID #2=General MIDI On
11110111 F7 = End of Exclusive
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
XG
Parameter
Change
F0 43 1n 4C hh mm ll dd ... F7 *Refer to Parameter Change
Table
*Refer to Parameter Change Table - *Refer to
Parameter
Change Table
O
(When
receiving
the XG
Parameter
Request)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n = Device Number n=always 0 (when transmit), n=0 – F
(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
11110111 F7 = End of Exclusive
XG Bulk
Dump F0 43 0n 4C aa bb hh mm ll dd ... dd cc F7 *Refer to Parameter Change
Table
*Refer to Parameter Change Table - X X X
(Output as
Parameter
Change )
O
(When
receiving
the XG
Dump
Request)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0000nnnn 0n = Device Number n=always 0 (when transmit), n=0 – F
(when recieve)
01001100 4C = Model ID
0aaaaaaa aa = Byte Count MSB
0bbbbbbb bb = Byte Count LSB
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
0ddddddd dd = Data
0ccccccc cc = Checksum
11110111 F7 = End of Exclusive
XG
Parameter
Request
F0 43 3n 4C hh ll F7 --------O
(-)
XXX X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0011nnnn 3n = Device Number n=always 0 (when transmit), n=0 – F
(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
XG Dump
Request F0 43 2n 4C hh mm ll F7 --------O
(-)
XXX X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0010nnnn 2n = Device Number n=always 0 (when transmit), n=0 – F
(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
49
System Exclusive Messages (Clavinova compliance)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
: :
11110111 F7 = End of Exclusive
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
Internal
Clock F0 43 73 01 02 F7 ---X XXXXO (Function) X X X X
00000001 01 = Model ID (Clavinova common ID)
00000010 02 = Internal Clock Substatus
External
Clock F0 43 73 01 03 F7 ---X XXXXO (Function) X X X X
00000001 01 = Model ID (Clavinova common ID)
00000011 03 = External Clock Substatus
Organ
Flutes data
Bulk Dump
(CVP-210/
208 only)
F0 43 73 01 06 0B 00 00 01 06 0n [Bulk Data] sum F7 O (Organ
Flute)
XXOO XXO O
(Sound Creator)
O
(Sound Creator)
XOX
01H Model ID (Clavinova common ID)
06H Bulk ID
0BH Bulk No. (Organ Flutes data Bulk Dump)
00H, 00H, 01H, 06H Data Length: 16bytes
1st Channel No. 0nH
2nd Footage [1'] 00 – mmH mm : maximum
3rd [1 1/3'] 00 – mmH
4th [1 3/5'] 00 – mmH (*CVP-210 only)
5th [2'] 00 – mmH
6th [2 2/3'] 00 – mmH
7th [4'] 00 – mmH
8th [5 1/3'] 00 – mmH
9th [8'] 00 – mmH
10th [16'] 00 – mmH
11th [Attack 2'] 00 – mmH
12th [Attack 2 2/3'] 00 – mmH
13th [Attack 4'] 00 – mmH
14th Settings [Attack Length] 00 – mmH
15th [Response] 00 – mmH
16th [Attack Mode] 00 – 01H 00H: Each, 01H: First
17th [Wave Variation] 00 – 01H 00H: Sine, 01H: Tone Wheel
18th [Volume] 01 – vvH vv: maximum
19th [aux] 00H
20th [aux] 00H
21th [aux] 00H
22th [aux] 00H
sum Check Sum = 0 – sum(BULK DATA)
CVP-210: mm=8, vv=8
CVP-208: mm=7, vv=9
Natural
Voice
Reverb
Type
F0 43 73 01 31 0n 00 dd F7 XXO O O
(Sound Creator)
O
(Sound Creator)
OOX
00000001 01 = Model ID (Clavinova common ID)
00110001 31 = Natural Voice Exclusive data
0000nnnn 0n = Channel No. (Always 00)
00000000 00 = Natural Voice Reverb Type Substatus
0ddddddd dd = data (0: Room, 1: Hall1, 2: Hall2, 3: Stage, 4: Plate)
Natural
Voice
Chorus
Type
F0 43 73 01 31 0n 01 dd F7 XXO O O
(Sound Creator)
O
(Sound Creator)
OOX
00000001 01 = Model ID (Clavinova common ID)
00110001 31 = Natural Voice Exclusive data
0000nnnn 0n = Channel No. (Always 00)
00000001 01 = Natural Voice Chorus Type Substatus
0ddddddd dd = data (0: Chorus,1: Celeste, 2: Flanger)
Natural
Voice
Variation
Type
F0 43 73 01 31 0n 02 dd F7 XXO O O
(Sound Creator)
O
(Sound Creator)
OOX
00000001 01 = Model ID (Clavinova common ID)
00110001 31 = Natural Voice Exclusive data
0000nnnn 0n = Channel No. (Always 00)
00000010 02 = Natural Voice Variation Type Substatus
0ddddddd dd = data (00H: DelayLCR, 01H: DelayLR, 02H: Echo,
03H: CrossDelay, 04H: Symphonic,
05H: RotarySpeaker, 06H:Tremolo, 07H: VibeRotor,
08H: AutoPan, 09H: Phaser, 0AH: AutoWah,
0BH: SoundBoardRev, 0CH: Off)
Natural
Voice Vibe
Rotor
Control
F0 43 73 01 31 0n 08 dd F7 XXO
(If the
Type is
set to
Vibe
Rotor)
OO
(Sound Creator)
O
(Sound Creator)
XOX
00000001 01 = Model ID (Clavinova common ID)
00110001 31 = Natural Voice Exclusive data
0000nnnn 0n = Channel No. (Always 00)
00001000 08 = Natural Voice Vibe Rotor Control Substatus
0ddddddd dd = data (00H:Off, 7FH:On)
Natural
Voice
Variation
Send Level
F0 43 73 01 50 11 0n 00 dd F7 XXOOOXOO O
(Mixing Console)
O
(Mixing Console)
OOX
00000001 01 = Model ID (Clavinova common ID)
01010000 50 = Common Model data
00010001 11 = Song Track related
0000nnnn 0n = Channel No.
00000000 00 = Natural Voice Variation Send Level Substatus
0ddddddd dd = data (00H – 7FH)
Natural
Voice Dry
Level
F0 43 73 01 50 11 0n 01 dd F7 XXOOOXOO O
(Mixing Console)
O
(Mixing Console)
OOX
00000001 01 = Model ID (Clavinova common ID)
01010000 50 = Common Model data
00010001 11 = Song Track related
0000nnnn 0n = Channel No.
00000001 01 = Natural Voice Dry Level Substatus
0ddddddd dd = data (00H – 7FH)
50
System Exclusive Messages Special Operators
System Exclusive Messages Special Operators (Vocal Harmony Additional Parameters)
System Exclusive Messages (Others)
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
Volume &
Expression
& Pan
Realtime
control off
(Voice
Reserve)
F0 43 73 01 11 0n 45 dd F7 O-OOXXXX X X XOX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
00000001 01 = Model ID (Clavinova common ID)
00010001 11 = Special Operators
0000nnnn 0n = Channel No.
01000101 45 = Volume & Expression Control No. Substatus
0ddddddd dd = data (00H : Realtime On, 7FH : Realtime Off)
11110111 F7 = End of Exclusive
MIDI Key
LED Mode
On/Off
F0 43 73 01 11 0n 47 dd F7 ----- --- O
(Keyboard LED
lights when
receiving the note
messages)
XXXX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
00000001 01 = Model ID (Clavinova common ID)
00010001 11 = Special Operators
0000nnnn 0n = Channel No.
01000111 47 = MIDI Key LED Mode On Off Substatus
0ddddddd dd = data 00H : Key LED Mode Off
01H : Key LED Mode On+no notes sound
02H : Key LED Mode On+notes sound
11110111 F7 = End of Exclusive
When Key LED Mode is set to On, key note on messages via designated
channnel turns the LED on/off.
9n, note, Vel=0 : off
9n, note, Vel=1 : flush
9n, note, Vel=2 – : on
When selecting whether notes sound or not, you should turn off the Key
LED Mode once.
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
Vocal
Harmony
Pitch to Note
ON/OFF
(CVP-210/
208 only)
F0 43 73 01 11 0n 50 00 ss F7 XOXXX XXX O
(Vocal Harmony
Edit)
O
(Vocal Harmony
Edit)
XOX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
00000001 01 = Model ID (Clavinova common ID)
00010001 11 = Special Operators
0000nnnn 0n = Channel No. (Always 00)
01010000 50 = Vocal Harmony Additional Parameter Control No.
00000000 00 = Pitch to Note Parameter No.
0ddddddd dd = data (00H: Off, 01H: On)
11110111 F7 = End of Exclusive
Vocal
Harmony
Pitch to Note
Part
(CVP-210/
208 only)
F0 43 73 01 11 00 50 01 ss F7 XOXXX XXX O
(Vocal Harmony
Edit)
O
(Vocal Harmony
Edit)
XOX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
00000001 01 = Model ID (Clavinova common ID)
00010001 11 = Special Operators
0000nnnn 0n = Channel No. (Always 00)
01010000 50 = Vocal Harmony Additional Parameter Control No.
00000001 01 = Pitch to Note Part Parameter No.
0ddddddd dd = data 00H: Main
01H: Layer
02H: Left
04H: Upper
11110111 F7 = End of Exclusive
Vocal
Harmony
Vocoder
Part
(Harmony
Part (Panel))
(CVP-210/
208 only)
F0 43 73 01 11 00 50 10 ss F7 XOXXX XXX O
(Mic Setting)
O
(Mic Setting)
XOX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
00000001 01 = Model ID (Clavinova common ID)
00010001 11 = Special Operators
0000nnnn 0n = Channel No. (Always 00)
01010000 50 = Vocal Harmony Additional Parameter Control No.
00010000 10 = Vocoder Part Parameter No.
0ddddddd dd = data 00H: Off
01H: Upper
02H: Lower
11110111 F7 = End of Exclusive
MIDI Event Data Format Corresponding Voice/Part
MIDI Reception (effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular/
Organ Voice
Mic/Vocal
Harmony
Natural
Voice
Song Main
Layer Left
Keyboard Style Extra Panel
(main generation
method)
Style Song MIDI
MIDI Master
Tuning F0 43 1n 27 30 00 00 mm ll cc F7 OXOOO (Function) X X X X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n n= always 0(when transmit), n=0 – F(when receive)
00100111 27 = Model ID of TG100
00110000 30 = Address High
00000000 00 = Address Mid
00000000 00 = Address Low
0000mmmm 0m = Master Tune MSB
0000llll 0l = Master Tune LSB
0ccccccc cc = don't care
11110111 F7 = End of Exclusive
51
Song System Exclusive Message List / Liste der System-Exclusive-
Meldungen der Songs / Liste des messages exclusifs au système de
morceaux / Lista de mensajes exclusivos del sistema de canciones
Guide
Panel Setting
Score
Style
Song Meta Event List / Liste der Meta-Events der Songs / Liste des méta-
événements des morceaux / Lista de meta-eventos de canciones
SMF META Event
YAMAHA META Event
YAMAHA XF META Event
[Phrase mark]
FF 7F 05 43 7B 03 xx 08 Phrase mark
xx Phrase mark 0hfccccc
bit6(h)
0:Right, 1:Left Right hand/Left hand
bit5(f)
0:Channel available, 1:Channel not available
Flag for whether channel information (bit 4 - 0) is valid or not
Phrases common to all channels assigned to 1
bit4-0(ccccc)
CH(0:1ch – 31:32ch) Channel information whose phrase mark is available
Data Format Parameter Description
F0 43 73 01 1F 00 cc dd F7 Guide Mode cc = Part Select No
00H: Track1=ON, Track2=ON
01H: Track1=OFF, Track2=ON
02H: Track1=ON, Track2=OFF
03H: Track1=OFF, Track2=OFF
dd = Mode
00H: Guide OFF, 01H: Next Note,
02H: Any Key, 03H: Karao Key, 04H: Vocal CueTime
F0 43 73 01 21 00 00 mm F7 Guide Lamp Timing 00H=Next, 01H/02H=Just
F0 43 73 01 22 00 0n mm ll pp F7 Panel Program Change mm=Bank Select MSB, ll=Bank Select LSB,
pp=Program Change, On=Channel
F0 43 73 01 22 01 0n vv F7 Panel Voice Volume 00H – 07FH, On=Channel
F0 43 73 01 22 02 0n vv F7 Panel Voice Reverb Depth 00H – 07FH, On=Channel
F0 43 73 01 22 03 0n vv F7 Panel Voice Effect Depth 00H – 07FH, On=Channel
F0 43 73 01 50 12 00 00 dd F7 Left Part indication On/Off 00H: OFF, 7FH: ON
F0 43 73 01 50 12 00 01 dd F7 Right Part indication On/Off 00H: OFF, 7FH: ON
F0 43 73 01 50 12 00 02 dd F7 Lyrics indication On/Off 00H: OFF, 7FH: ON
F0 43 73 01 50 12 00 03 dd F7 Chord indication On/Off 00H: OFF, 7FH: ON
F0 43 73 01 50 12 00 04 dd F7 N.Name indication On/Off 00H: OFF, 7FH: ON
F0 43 73 01 50 12 00 05 dd F7 Size designation 00H: SMALL, 01H: MIDDLE, 02H: LARGE, 03H: Xlarge
F0 43 73 01 50 12 00 06 dd F7 Left Ch 00H – 0FH=CH, 7EH=OFF, 7FH=AUTO
F0 43 73 01 50 12 00 07 dd F7 Right Ch 00H – 0FH=CH, 7EH=OFF, 7FH=AUTO
F0 43 73 01 50 12 00 08 dd F7 Quantize triplet On/Off 00H: Triplet OFF, 7FH: Triplet ON
F0 43 73 01 50 12 00 09 dd F7 Quantize 00H: quarter, 01H: eighth, 02H: sixteenth, 03H: thirty-second
F0 43 73 01 50 12 00 0A dd F7 NoteName 00H: ABC, 01H: FixedDo, 02H: MovableDo
F0 43 73 01 50 12 00 0B dd F7 Color Note 00H: OFF, 7FH: ON
F0 43 73 dd 11 00 16 dd dd F7 Style No. dd dd=StyleNo.
CVP-210: 7F 3A
CVP-208: 7F 39
CVP-206: 7F 38
CVP-204: 7F 37
F0 43 73 01 51 05 00 00 08 Rhy1 Rhy2
Bass Chd1 Chd2 Pad Phr1 Phr2 7F
Style Part On / Off 00H: OFF, 01H:ON
F0 43 73 01 51 00 00 00 03 10 00 dd F7 ACMP SPLIT POINT 00H – 7FH
Data Format Parameter Description
FF 01 len [Data] TEXT len=Data length, [Data]=Text data
FF 02 len [Data] Copyright len=Data length, [Data]=Copyright data
FF 03 len [Data] Sequence Name len=Data length, [Data]=Sequence Name
FF 05 len [Data] Lyrics len=Data length, [Data]=Lyrics data
FF 2F 00 End Of Track
FF 51 03 t1 t2 t3 Set Tempo t1 t2 t3 = B71B00H – 01D4C0H (5 – 500)
FF 58 04 nn dd cc bb Beat (Time signature) nn =Denominator (2n), dd=Numerator,
CC=MIDI clock per metronome click,
dd=Number of thirty-second notes in MIDI quarter note
FF 59 02 sf mi Key Signature sf=-7 – 7 (7 – 7)
mi=0:Major key, 1:Minor key
FF 7F 07 43 73 0A 00 07 dd Song Offset Measure -100 – -1, 1 – 100
FF 7F len 43 73 0C 00 [Data] Style Name len=Data length, [Data]=Style Name
FF 7F len 43 73 0D 00 [Data] Song OTS len=Data length, [Data]=OTS Data
FF 7F 07 43 7B 01 cr ct bn bt Chord Name Refer to "Chord Control" in the MIDI Data Format (System
Exclusive Messages)
FF 7F 05 43 7B 03 dd 08 Phrase Mark See below
FF 7F 04 43 7B 04 dd Max Phrase Number 01H – 7FH
FF 7F 05 43 7B 0C rr ll Guide Track Flag rr=Melody Track 1 Ch, ll=Melody Track 2 Ch
FF 7F len 43 7B 21 00 pp [Data] Lyrics Bitmap pp=Display type
00H: Center
01H: Tile
len=Data length, [Data]=File Path
52
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
: All Sound Off
Aux :
Reset
All
Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0,32
1,5
7,10,11
6,38
64,66,67
65
71-74
84
91,93
94
96-97
98-99
100-101
120
121
1 - 16
1 - 16
Ø 9nH,v=1-127
˛ 9nH,v=0
˛
˛
Ø
˛
Ø
Ø
Ø
˛
˛
˛
Ø
˛
˛
˛
Ø
˛
˛
Ø
˛
Ø
Ø
Ø
˛
˛
˛
Ø
˛
Ø
˛
Ø
Ø
Ø
Ø 0 - 127
**************
˛
˛
˛
Ø
Ø
˛
˛
˛
˛
Ø
˛
3
˛
**************
0 - 127
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø
1 - 16
1 - 16
Ø 9nH,v=1-127
˛
Ø 0 - 24 semi
˛
˛
˛
˛
˛
Ø
Ø
Ø (120,126-127)
Ø (121)
Ø
Ø (123-125)
Ø
˛
3
˛
˛
0 - 127
0 - 127
Ø
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Clavinova ]
(Natural sound source)
Date : 10,Sep 2002
Model CVP-210/208/206/204 MIDI Implementation Chart
Version : 1.00
Bank Select
Data Entry
Portamento
Sound Controller
Portament Cntrl
RPN Inc,Dec
NRPN LSB,MSB
RPN LSB,MSB
All Sound Off
Reset All Cntrls
Ø0 - 127
53
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
: All Sound Off
Aux :
Reset
All
Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0,32
1,5,7,10,11
6,38
64,65,66,67
71-74
84
91,93,94
96-97
98-99
100-101
120
121
1 - 16
1 - 16
Ø 9nH,v=1-127
˛ 9nH,v=0
˛
˛
Ø
Ø
Ø
Ø
Ø
Ø
Ø
˛
Ø
Ø
˛
˛
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø 0 - 127
**************
˛
˛
˛
Ø
Ø
˛
˛
˛
˛
Ø
˛
3
˛
**************
0 - 127
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø
1 - 16
1 - 16
Ø 9nH,v=1-127
˛
Ø 0 - 24 semi
˛
Ø
˛
˛
˛
Ø
Ø
Ø (120,126-127)
Ø (121)
Ø
Ø (123-125)
Ø
˛
3
˛
˛
0 - 127
0 - 127
Ø
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Clavinova ]
(XG sound source)
Date : 10,Sep 2002
Model CVP-210/208/206/204 MIDI Implementation Chart
Version : 1.00
Bank Select
Data Entry
Sound Controller
Portament Cntrl
Effect Depth
RPN Inc,Dec
NRPN LSB,MSB
RPN LSB,MSB
All Sound Off
Reset All Cntrls
Ø0 - 127
54
Memo
55
M.D.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation
© 2003 Yamaha Corporation
WA55490 ???MW?????.?-01A0 Printed in Indonesia
