DVD Recorder

Enregistreur DVD

DRX-2

OWNER’S MANUAL

MODE D’EMPLOI

U

i

General information

General information

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions — All the safety and operating instructions should be

read before the appliance is operated.

2. Retain Instructions — The safety and operating instructions should be

retained for future reference.

3. Heed Warnings — All warnings on the appliance and in the operating

instructions should be adhered to.

4. Follow Instructions — All operating and use instructions should be followed.

5. Cleaning — Unplug this product from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners.

Use a damp cloth for cleaning.

Exception: A product that is meant for uninterrupted service and that for

some specific reason, such as the possibility of the loss of an authorization

code for a CATV converter, is not intended to be unplugged by the user for

cleaning or any other purpose, may exclude the reference to unplugging the

appliance in the cleaning description otherwise required in item 5.

6. Attachments — Do not use attachments not recommended by the

video product manufacturer as they may cause hazards.

7. Water and Moisture — Do not use this video product near water - for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet

basement, or near a swimming pool, and the like.

8. Accessories — Do not place this video product on an unstable cart,

stand, tripod, bracket, or table. The video product may fall, causing serious

injury to a child or adult, and serious damage to the appliance. Use only

with a cart, stand, tripod, bracket, or table recommended by the

manufacturer or sold with the video product. Any mounting of the

appliance should follow the manufacturer’s instructions and should use a

mounting accessory recommended by the manufacturer.

8A.

9. Ventilation — Slots and openings in the cabinet are provided for

ventilation, to ensure reliable operation of the video product, and to

protect it from overheating. These openings must not be blocked or

covered. The openings should never be blocked by placing the video

product on a bed, sofa, rug,

or other similar surface. This video product should never be placed near or

over a radiator or heat register. This video product should not be placed in

a built-in installation such as a bookcase or rack unless proper ventilation is

provided or the manufacturer’s instructions have been adhered to.

10. Power Sources — This video product should be operated only from

the type of power source indicated on the marking label. If you are not

sure of the type of power supply to your home, consult your appliance

supplier or local power company. For video products intended to operate

from battery power, or other sources, refer to the operating instructions.

11. Polarization — This product may be equipped with a polarized

alternating-current line plug (a plug having one blade wider than the

other). This plug will fit into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into the outlet, try

reversing the plug.

If the plug should still fail to fit, contact your electrician to replace your

obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power-Cord Protection — Power supply cords should be routed so that

they are not likely to be walked on or pinched by items placed upon or against

them, paying particular attention to cords at plugs, convenience receptacles,

and the point where they exit from the appliance.

13. Outdoor Antenna Grounding — If an outside antenna or cable system

is connected to the video product, be sure the antenna or cable system is

grounded so as to provide some protection against voltage surges and

built-up static charges.

Section 810 of the National Electrical Code, ANSI/NFPA 70, provides

information with regard to proper grounding of the mast and supporting

structure, grounding of the lead-in wire to an antenna discharge unit, size

of grounding conductors, location of antenna-discharge unit, connection

to grounding electrodes, and requirements for the grounding electrode.

See Fig.A.

Fig.A.

14. Lightning — For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect the antenna or cable system.

This will prevent damage to the product due to lightning and power surges.

15. Power lines — An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits. When installing an

outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be fatal.

16. Overloading — Do not overload wall outlets and extension cords as

this can result in a risk of fire or electric shock.

17. Object and Liquid Entry — Never push objects of any kind into this

product through openings as they may touch dangerous voltage points or

short-out parts that could result in a fire or electric shock. Never spill

liquid of any kind on the product.

18. Servicing — Do not attempt to service this product yourself, as

opening or removing covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service — Unplug this product from the wall outlet

and refer servicing to qualified service personnel under the following

conditions:

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled on, or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating

instructions as an improper adjustment of other controls may result in

damage and will often require extensive work by a qualified technician to

restore the product to its normal operation.

e. If the product has been dropped or the cabinet has been damaged.

f. When the product exhibits a distinct change in performance - this

indicates a need for service.

20. Replacement Parts — When replacement parts are required, be sure the

service technician has used replacement parts specified by the manufacturer

or which have the same characteristics as the original part. Unauthorized

substitutions may result in fire, electric shock or other hazards.

21. Safety Check — Upon completion of any service or repairs to this

product, ask the service technician to perform safety checks to determine

that the product is in proper operating condition.

22. Carts and Stands — The appliance should be used only with a cart or

stand that is recommended by the manufacturer.

23. Heat — The product should be situated away from heat sources such

as radiators, heat registers, stoves, or other products that produce heat.

This “bolt of lightning” indicates uninsulated material within

your unit may cause an electrical shock. For the safety of

everyone in your household, please do not remove product

covering.

The “exclamation point” calls attention to features for which

you should read the enclosed literature closely to prevent

operating and maintenance problems.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION:

To prevent electric shock, match wide blade of plug to wide slot,

and fully insert.

ATTENTION:

Pour éviter les chocs électriques, introduire la lame la plus large

de la fiche dans la borne correspondante de a prise et pousser

jusqu’au fond.

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTSINSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

An appliance and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces

may cause the appliance and cart combination to overturn.

For Customer Use:

Enter below the Serial No. which is located on the rear of the cabi-

net.Retain this information for future reference.

Model No.

DRX-2

Serial No.__________________________

ANTENNA LEAD

IN WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING

CONDUCTORS

(NEC SECTION 810-21)

GROUND

CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

EXAMPLE OF ANTENNA GROUNDING AS

PER NATIONAL ELECTRICAL CODE (NEC)

General information

ii

English

Laser safety

This unit employs a laser.To prevent possible eye injury, only a qualified

service person should remove the cover or attempt to service this device.

CAUTION

Use of controls or adjustments or performance of procedures other

than those specified herein may result in hazardous radiation

exposure.

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID

EXPOSURE TO BEAM.

ATTENTION

L’emploi de commandes, de réglages ou un choix de procédures

différents des spécifications de cette brochure peut entraîner une

exposition à d’éventuelles radiations pouvant être dangereses.

RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS

D’OUVERTURE EXPOSITION DANGEREUSE AU FAISCEAU

LASER

Type InGaAlP semiconductor laser (DVD)

AlGaAs semiconductor laser (CD)

Wavelength 660 nm (DVD)

780 nm (CD)

Output Power 20 mW (DVD writing)

(out of objective) 0.8 mW (DVD reading)

0.3 mW (CD reading)

Beam divergence 82 degrees (DVD)

54 degrees (CD)

CAUTION:

Visible and invisible laserradiation

when open. Avoid exposure to beam.

CLASS 1

LASER PRODUCT

CAUTION:

Visible and invisible laser radiation

when open. Avoid exposure to beam.

COMPLIANCE INFORMATION STATEMENT

(DECLARATION OF CONFORMITY PROCEDURE)

Responsible Party : Yamaha Electronics Corporation

Address : 6660 Orangethorpe Avenue

Buena Park, CA90620

Telephone : 714-522-9105

Fax : 714-670-0108

Type of Equipment : DVD Recorder

Model Name : DRX-2

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received including

interference that may cause undesired operation.

See the user manual instructions if interference to radio reception is

suspected.

FCC INFORMATION (for US customers)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly

approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s supplied with this

product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in

the USA.

3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices.

Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not

result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used

according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices. Compliance

with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of

interference, which can be determined by turning the product “OFF” and “ON”, please try to eliminate the problem by using one of the following

measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial

type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If

you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., 6600 Orangethorpe Ave. Buena Park, CA90620.

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B

LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS

AS SET OUT IN THE RADIO INTERFERENCE REGULATIONS OF

THE CANADIAN DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMÉRIQUE N’ÉMET PAS DE BRUITS

RADIOÉLECTRIQUES DÉPASSANT LES LIMITES APPLICABLES

DANS LA RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUES

ÉDICTÉ PAR LE MINISTÈRE DES COMMUNICATIONS DU

CANADA.

NOTE TO CABLE TV SYSTEM INSTALLER:

This reminder is provided to call the Cable TV (CATV) system

installer’s attention to Article 820-40 of the NEC (National Electrical

Code) that provides guidelines for proper grounding and, in particular,

specifies that the cable ground shall be connected to the grounding

system of the building, as close to the point of cable entry as practical.

iii

General information

Caution

Read this before operating your unit.

1

To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2

The recommended operating temperature range for the

Recorder is from 15˚C-35˚C (Celsius). Exceeding these

ranges may cause unstable recording results. Do not expose

this unit to sudden temperature changes from cold to hot,

nor locate this unit in an environment with high humidity

(i.e., a room with a humidifier) to prevent condensation

inside this unit, which may cause an electrical shock, fire,

damage to this unit, and/or personal injury.

3

Locate this unit away from other electrical appliances,

motors, or transformers to avoid humming sounds.

4

Install this unit in a well ventilated, cool, dry, clean place —

away from direct sunlight, heat sources, vibration, dust, mois-

ture, or cold. In a cabinet, allow about 2.5cm (1 inch) of free

space all around this unit for adequate ventilation.

5

Avoid installing this unit in a location where foreign objects

may fall onto this unit or where this unit may be exposed to

liquid dripping or splashing. On the top of this unit, do not

place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e., candles), as they may cause fire, damage

to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall, spilling the

liquid and causing an electrical shock to the user and/or

damage to this unit.

6

Do not cover this unit with a newspaper, tablecloth, curtain,

etc. in order not to obstruct heat radiation. If the tempera-

ture inside this unit rises, it may cause fire, damage to this

unit, and/or personal injury.

7

Do not plug in this unit to a wall outlet until all connections

are complete.

8

Do not operate this unit upside-down. It may overheat, pos-

sibly causing damage.

9

Do not use excessive force on switches, knobs and/or cords.

10

When disconnecting the power cord from the wall outlet,

grasp the plug; do not pull the cord.

11

Do not clean this unit with chemical solvents; this might dam-

age the finish. Use a clean, dry cloth.

12

Use only the voltage specified on this unit. Using this unit

with a higher voltage than specified is dangerous and may

cause fire, damage to this unit, and/or personal injury.

YAMAHA will not be held responsible for any damage result-

ing from use of this unit with a voltage other than as speci-

fied.

13

To prevent damage by lightning, disconnect the power cord

from the wall outlet during an electrical storm.

14

Do not attempt to modify or fix this unit. Contact qualified

YAMAHA service personnel when any service is needed. The

cabinet should never be opened for any reason.

15

When not planning to use this unit for long periods of time

(i.e., vacation), disconnect the AC power plug from the wall

outlet.

16

Be sure to read the “Before you call an engineer” section on

common operating errors before concluding that this unit is

faulty.

17

Before moving this unit, press STANBY/ON to set the unit in

standby mode, then disconnect the AC power plug from the

wall outlet.

Simple programming system for DVD

recorders. Simply enter the number

code associated with your television pro-

gram. This number is located in your

television listings magazine.

Manufactured under license from Dolby Laboratories.“Dolby

”,“Pro Logic ”and the double-D symbol are trademarks of

Dolby Laboratories.Confidential Unpublished Works.

©1992-1997 Dolby Laboratories,Inc.All rights reserved.

“DTS” and “DTS Digital Out” are trademarks of Digital The-

ater Systems, Inc.

This product incorporates copyright protection technology

that is protected by method claims of certain U.S.patents and

other intellectual property rights owned by Macrovision Cor-

poration and other rights owners.

Use of this copyright protection technology must be autho-

rized by Macrovision Corporation, and is intended for home

and other limited viewing uses only unless otherwise autho-

rized by Macrovision Corporation.Reverse engineering or dis-

assembly is prohibited.

The unit is not disconnected from the AC power source as

long as it is connected to the wall outlet,even if this unit itself is

turned off.This state is called the standby mode.In this

state,this unit is designed to consume a very small quantity of

power.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to wide

slot and fully insert.

This Class B digital apparatus complies with Canadian ICES-003.

This digital apparatus does not exceed the Class B limits for

radio noise emissions from digital apparatus as set out in the

Radio Interference Regulations of the Canadian Department of

Communications.

General information

iv

English

Features

Digital Home Cinema

Introducing YAMAHA DVD recorder in your home theater environment!

Dolby Digital and DTS are supported. You can enjoy super dynamic theatrical sound by

connecting to AV receiver/amplifier.

Dolby Digital

Dolby Laboratories standard for transmitting 5.1 channels. Five full-value channels are

transmitted in this acoustic playback system. A further channel is used for low frequen-

cies (effects). The loudspeakers are arranged front left, front middle, front right, rear left

and rear right. This system is currently the most common system and is used in cinemas.

With this DVD recorder each sound track in 2-channel Dolby Digital is recorded onto

a DVD+RW.

DTS digital out

Transmission standard for 5.1 channels from Digital Theatre Systems Inc. This is the

second most wide-spread system after Dolby Digital.

Linear PCM

Audio

Recording

M1 & M2 recording modes offer high quality picture and sound enabled by linear PCM

recording.

Six Recording Modes

You have six recording modes to choose from: M1, M2, M2x, M3, M4, M6.

Select the one best suited for your need.

Six Hours of

Recording Time

You can record up to six hours in M6 recording mode.

Fit to Space Recording

Your DVD recorder calculates the best suitable bit rates from your programmed

recording time and an available disc space.

Simple programming system for DVD recorders. Simply enter the programming num-

ber associated with your television programme. You will find this number in your favor-

ite listings magazine.

Safe Record

Normally a recording is made at the current disc position. This is the same as for a

video cassette, in the middle of the tape for example. By holding down the

REC

S

button, the recording will be made at the end of all the other recordings to avoid over-

writing previous recordings.

New recordings on DVD+R discs are always added after all existing recordings.

Index Picture Screen

This screen tells you what’s on the disc. Each index screen represents a recording. On

the right hand side of the screen you can also see a disc indicator that shows the posi-

tion and length of the current recording on the disc in a graphic format. You can

choose and make your own index pictures from the title in playback.

EDIT

DVD makes it so easy to delete titles, split titles, insert chapters automatically and

manual, and do many more things. It enables you to simply delete commercials and

unwanted scenes.

Many Playable Disc Types

The following types of disc are supported: DVD-Video, DVD-R, DVD-RW, CD, SVCD,

VCD, CD-R, and CD-RW.

Your DVD recorder can play back pre-recorded DVDs and CDs. DVDs recorded using

this DVD recorder can be played back on current and future DVD players.

MP3-CD

PLAYBACK

MP3 files are highly compressed music files. The data is compressed to 1/10 of the vol-

ume of the original audio material using a special process. This means that 10 hours of

music can be stored on a single CD.

These music CDs can be played on this machine.

ID3 Tag

When playing MP3, your DVD recorder will display on TV the name of the albums,

tracks, and artists if ID3 Tag information is recorded on the disc.

This connector is also known as a “FireWire” or “IEEE 1394”. This connector is used

to transmit wide digital broadband signals that are used for digital video camcorders.

Using this connector, you can so easily capture and save video onto DVD from your

digital video camera.

1

Table of contents

Table of contents

A quick preview ............................3

The remote control.................................................................................3

Additional TV functions..........................................................................4

Front of the device ..................................................................................5

Back of the unit.........................................................................................6

The symbols on your DVD recorder display ....................................7

Messages in the DVD recorder display...............................................7

1.

Introduction.............................9

Common questions .................................................................................9

Discs you can use.................................................................................. 10

Regional code......................................................................................... 11

Accessories............................................................................................. 11

Cleaning the discs.................................................................................. 11

2.

Connecting your DVD

recorder.......................................12

Preparing the remote control............................................................ 12

Connection notes.................................................................................. 12

Connecting your antenna.................................................................... 12

Connecting your TV to get the best picture.................................. 13

Connecting a VCR ................................................................................ 15

Connecting your camcorder .............................................................. 15

3.

Connecting an AV receiver

..16

Basic playback connections................................................................. 16

Surround sound connections ............................................................. 17

Recording connections ........................................................................ 18

Power supply.......................................................................................... 19

Switching on ........................................................................................... 19

4.

Installing your DVD

recorder.......................................20

Initial installation.................................................................................... 20

Automatic TV channel search ............................................................ 22

Adding and clearing TV channels manually...................................... 23

Setting the language .............................................................................. 24

Assigning the VCR Plus+® Guide channel numbers..................... 25

Setting the time and date automatically........................................... 26

Manually setting the time & date ....................................................... 27

5.

On-screen information......... 28

Symbols in the menu bar..................................................................... 28

Field for temporary messages ............................................................ 28

Status field............................................................................................... 29

Tuner information box ........................................................................ 30

Timer information box ........................................................................ 30

6.

Playback................................. 31

General notes on playback.................................................................. 31

Inserting a disc ....................................................................................... 31

Playing a DVD video disc..................................................................... 32

Playing a DVD+RW/ +R disc.............................................................. 32

Playing an audio CD.............................................................................. 33

Playing an MP3 CD................................................................................ 33

Playing a (Super) Video CD ................................................................ 34

7.

Additional playback

features ....................................... 35

Changing to another title/chapter..................................................... 35

Searching a disc...................................................................................... 35

Still picture.............................................................................................. 36

Slow motion ........................................................................................... 36

Search by time........................................................................................ 36

Repeat play.............................................................................................. 37

Shuffle....................................................................................................... 37

Scan feature ............................................................................................ 37

Camera angle.......................................................................................... 38

Zoom feature......................................................................................... 38

Select the audio language .................................................................... 39

Subtitles ................................................................................................... 39

8.

Manual recording.................. 40

General.................................................................................................... 40

Recording without automatic switch-off ......................................... 41

Interrupt recording (Pause) ................................................................ 42

Recording with automatic switch-off

(OTR one-touch-recording)............................................................... 43

Preventing accidental erasing of discs............................................... 44

Lining up recordings within a title (assemble cut)......................... 45

Selecting the recording type (Quality) ............................................. 46

Table of contents

2

English

9.

Managing the disc

contents.......................................47

General.....................................................................................................47

EDIT..........................................................................................................47

Editing recording titles (name)............................................................50

Playing the entire title...........................................................................50

Deleting recordings/titles.....................................................................50

Disc settings ............................................................................................51

10.

Programming a recording

(TIMER) .......................................53

General.....................................................................................................53

Programming recordings with the VCR Plus+® System ..............54

Programming recordings without the VCR Plus+® System........55

How to change or delete a programmed recording (TIMER).....56

Problem solving for programmed recordings .................................57

11.

User preferences................58

Picture settings .......................................................................................58

Sound settings.........................................................................................59

Language settings....................................................................................60

Additional settings .................................................................................60

Disc feature menu..................................................................................61

12.

Access control

(Child Lock).................................62

Child lock (DVD and VCD) ................................................................62

Parental level control (DVD video only)..........................................63

Changing the PIN code.........................................................................64

13.

Before you call an

engineer.......................................65

Appendix .....................................68

Using DRX-2 remote control for your TV set...............................68

Specifications...........................................................................................70

3

A quick preview

A quick preview

The remote control

BB

BB/I Switch on or off: Press to switch set on or off, interrupt

menu function, interrupt a programmed recording (TIMER)

MONITOR This button lets you switch between the TV receiver (internal

tuner) in the DVD recorder (TV picture on the TV set) and

playback on the DVD recorder

A/CH (Alternate

Channel) Switches to the previous TV channel

CH +/– Turns programs and inputs

0-9 Numerical key pad

VOL +/– TV volume up/down

SELECT Switches between different values in a menu

CLEAR Deletes last entry/clear timer and programmed recordings

MUTE TV Mute ON/OFF

TIMER Press to make a TIMER programming with VCR Plus+® /with-

out VCR Plus+® or to alter or clear a programmed TIMER

wvt u Down/up/left/right cursor movement

ENTER/OK Confirms menu selection

TOP MENU Displays DVD disc menu or Index Picture Screen

EDIT Displays Edit menu for DVD+RW or DVD+R disc

SYSTEM MENU Displays recorder system menu bar

TITLE/CHAP Selects title

Selects chapter

SUBTITLE Subtitle language selector

AUDIO Audio language selector

ANGLE Selects DVD camera angle

ZOOM Enlarges video image

REPEAT Repeats chapter, track, title, disc

A-B Repeats a specific segment

SHUFFLE Plays tracks in random order

SCAN Playback of the first 10 seconds of each chapter within a title

(DVD) or the first 10 seconds of each track on a disc (VCD/

CD)

tt

tt

SKIP Selects previous title/search backwards :

Briefly press the button during playback: Goes to previous

chapter/film or previous title

Hold down the button: Searches backwards

Hold down the button during still picture: Slow motion back-

wards

A quick preview 4

English

This remote control can also operate TV set made by different manufacturers.

For more information, see “Using DRX-2 remote control for your TV set”.

yy

yy

SKIP Selects next title/search forwards :

Briefly press the button during playback: Goes to next chapter/

film or next title

Hold down the button: Searches forwards

Hold down the button during still picture: Slow motion for-

wards

PLAY Starts playback

ee

ee

SEARCH/

SLOW

Searches backward

Slow motion

rr

rr

SEARCH/

SLOW

Searches forward

Slow motion

PAUSE If this button is pressed during playback, the DVD recorder

switches to pause. You will see a still picture.

If this button is pressed during recording, the DVD recorder

will also switch to pause.

STOP Stops playback/recording, except with programmed recordings

(TIMER)

Hold down button, opens and closes the disc tray

DIMMER Changes brightness settings of the display

TV SHIFT Press and hold while using other buttons to work the TV

SS

SS REC Direct recording of the currently selected programme

REC MODE Switches recording modes

Additional TV functions

VOL+ Increase TV volume

VOL – Reduce TV volume

For the following functions you need to hold down the button

at the side TV/SHIFT and then select the function you need

with the appropriate button.

/I Turns the TV on / off

0..9 Number buttons: 0 - 9

CH+ Turns up the programme in numeric order

To select a higher programme number

CH- Turns down the programme in numeric order

To select a lower programme number

MUTE TV Mute on / off

BB

BB

5A quick preview

Auxiliary jacks on the front panel

Front of the device

STANDBY/ON Switches the unit on or off, interrupt a function, interrupt a

programmed recording (TIMER)

FF

FF (Open/Close) Open/close disc tray

REC Records the current TV channel

WW

WW Plays a recorded disc

TT

TT Selects previous title/search backwards

YY

YY Selects next title/search forwards

AA

AA Interrupt playback/recording

S-VIDEO S Video jack: Connection of SVHS/Hi8 camcorders or SVHS/

Hi8 video recorders (programme number “CAM1”)

Yellow jack VIDEO Video input jack: Connection of camcorders or video

recorders (programme number “CAM1”)

White/red jack left

AUDIO right

Audio input jack left/right : Connection of camcorders or

video recorders (programme number “CAM1”)

DV IN i Link/DV jack (digital video input, IEEE 1394,

FireWire):

Connecting a digital camcorder or other suitable device (pro-

gramme number “CAM2”).

Tip

Switching between the S-VIDEO and VIDEO jacks takes place automatically. If

both jacks are in use, the signal at the S-VIDEO jack has priority.

A quick preview 6

English

Input (IN-EXT2)

Input (IN-EXT1)

Output (OUT-2)

Output (OUT-1 480p/480i)

Back of the unit

MAINS Mains jack: Connection to the mains supply (120V/60Hz)

ANTENNA Aerial input : Connection of the aerial

TV Aerial output : Connection of the TV set

S-VIDEO IN S-Video input: Connection for an additional device (channel

number “EXT2”). Switching between jack S-VIDEO IN and

Video in is done automatically.

Video in Video input (yellow): Connection for an additional device

(channel number “EXT2”)

IN L AUDIO R Analog audio input (red/white) underneath jack Video in.

Audio for jack Video in : Connection for an additional device

(channel number “EXT2”)

IN AUDIO LR Analog audio input (red/white) next to jack IN COMPO-

NENT VIDEO: Connection for an additional device. Audio

input for component video (channel number “EXT1”)

IN COMPONENT

VIDEO

Component video input (red/blue/green): Connection

for an additional device with component video output (channel

number “EXT1”)

S-VIDEO OUT S-Video output: Connection for a S-video-compatible TV

OUT VIDEO

(CVBS)

Video output (yellow): Connection to a TV with video input

(CVBS, Composite Video)

OUT L AUDIO R Analog audio output (red/white) underneath jack Video

in.

Audio for jack OUT VIDEO (CVBS) : Connection for an addi-

tional device

OUT AUDIO LR Analog audio output (red/white): Connection for an addi-

tional device. Audio output for component video/progressive

scan

OUT

COMPONENT

VIDEO

Component video output (red/blue/green): Connection

for an additional device with component video/progressive

scan output

7A quick preview

Output (DIGITAL AUDIO OUT)

The following symbols may appear on your DVD Recorder display:

The following messages may appear in your DVD recorder display:

COAXIAL

OUTPUT

Connection of a digital audio device (amplifier/receiver) using a

coaxial digital cable

OPTICAL

OUTPUT

Connection of a digital audio device (amplifier/receiver) using a

fiber optic cable

The symbols on your DVD recorder

display

Multifunction display/text line

•) Clock

•) Disc/Title play time

•) OTR time

•) Title name

•) Display of the TV channel number / playing time / function

•) Display of information, warnings

IIIIIIIIIIIIIII Disc bar: Displays the current position on the disc (disc

pointer).

Record: single flashing segment at the current position.

Pause: flashing segment on both sides of the current position.

Stop: flashing segment at the current position.

TIMER A recording (Timer) has been programmed

TV Modulator is switched off (NAFTA). The antenna signal (RF sig-

nal) is only connected to the TV when the modulator is

switched off.

PRO Component Video output set to “Progressive Scan”. If this is

not displayed, the Component Video output is set to “Inter-

laced”.

Remote control command has been sent

SAP Second audio program from the tuner is selected (NAFTA)

Messages in the DVD recorder dis-

play

IS TV ON? The DVD recorder is in initial installation mode. Switch the TV

on, then read the paragraph on “Initial installation” in “Installing

your DVD recorder”.

NO SIGNAL No input signal available (signal inadequate or unstable)

MENU The menu on the screen is active

OPENING Disc tray opening

TRAY OPEN Disc tray open

CLOSING Disc tray closing

TV PROTIMER SAP

A quick preview 8

English

READING Disc being read

MENU UPDT Once recording has been successfully completed the table of

contents is created

INIT MENU The menu structure is created after the first recording has

been made on a new disc

COPY PROT You have tried to copy a copy-protected DVD/video cassette

WAIT Please wait until this message disappears. The DVD recorder is

busy performing a task

NO DISC A disc has not been inserted for recording. If a disc has been

inserted, it cannot be read

INFO Information about the inserted DVD is displayed on the screen

BUSY The DVD recorder is processing to make the disc DVD com-

patible

ERASING The entire information of the disc is erased

EMPTYDISC The disc inserted is either new or has been completely erased

(not recorded)

PROTECTED The disc is protected against recording

MAX TITLE The maximum number of titles per disc has been reached. The

maximum number of titles per disc is 48

MAX CHAP The maximum number of chapters per title/disc has been

reached. The maximum number of chapters per title is 124

DISC FULL The disc is full. There is no space for new recordings

PAL DISC A disc with PAL recordings has been inserted. The machine is

trying to record an NTSC signal. Insert a new disc or one that

contains NTSC recordings

NTSC DISC A disc with NTSC recordings has been inserted. The machine

is trying to record a PAL signal. Insert a new disc or one that

contains PAL recordings

RECORDING An illegal action (e.g. F Open/Close button) was attempted

during recording

FREETITLE Playback was started for an empty title or the following title is

empty

DISC LOCK An attempt has been made to record during playback of a pro-

tected disc. This message appears if an attempt is made to

insert a chapter marker (EDIT button)

DISC ERR An error occurred when writing the title. If this error keeps

occurring, please clean the disc or use a new one

For instructions on how to clean a disc, read the section on

“Cleaning the discs” in the next chapter

DISC WARN An error occurred when writing the title. Recording was con-

tinued; the error was skipped

SETUP After the automatic search the menu for setting the date/time

will appear on the screen

WAIT 01 During the automatic search the TV channels found are

counted

BLOCKED The disc tray cannot be closed/opened

SAFE REC The new recording will be added at the end of all the other

recordings (SAFE RECORD)

9Introduction

1. Introduction

What is a DVD?

DVD (Digital Versatile Disc) is a new storage medium that combines the convenience of

the compact disc with the latest digital video technology. DVD video uses modern

MPEG2 data compression technology that enables an entire feature film to be stored

on a single five inch disc.

How good is the resolution of DVD compared with VHS?

The razor-sharp digital images have a resolution of more than 500 lines of 720 pixels

per line. This is more than twice as high as VHS and is even better than the laser disc. Its

picture quality is easily comparable to the digital masters produced in recording studios.

What can DVD+RW do?

DVD+ReWritable uses phase change media, the same technology on which rewritable

CDs are based. A high-performance laser is used to change the reflective properties of

the recording layer; this process can be repeated more than a thousand times.

What can the DVD+R do?

DVD+R (write-once DVD). Unlike a DVD+RW disc, this disc can only be written once.

If it is not finalized after a recording, further recordings can be added to it. Old record-

ings can be deleted but can no longer be overwritten. The deleted titles are marked

“Deleted title”.

Before this disc can be played in a DVD player, it must be finalised in the DVD recorder.

Once this process is complete, no further recordings can be added.

What can my DVD recorder do?

Your DVD recorder is a machine for recording and playing back digital video discs with

“two-way” compatibility with the universal DVD video standard. This means:

•) existing DVD video discs can be played on the recorder.

•) Recordings made on your DVD recorder can be played on other DVD video players

and DVD ROM drives.

Common questions

Introduction 10

English

The following discs can be used in your DVD recorder for playback and recording:

Playback and recording

Playback only:

Discs you can use

DVD+RW (Digital Versatile Disc + rewritable)

DVD+R (Digital Versatile Disc + Recordable)

DVD Video (Digital Versatile Disc)

DVD-R (DVD-Recordable)

DVD-RW (DVD-Rewritable) These discs can only be played back if the recording was

made in video mode and the recording was finalised.

Audio CD (Compact Disc Digital Audio)

Super Audio CD (Only plays the CD layer of a hybrid SACD disc)

Video CD (Format 1.0, 1.1, 2.0)

Super Video CD

CD-R (CD-Recordable) Audio/MP3 content

CD-RW (CD-Rewritable) Audio/MP3 content

Recordable

ReWritable

SUPER VIDEO

DIGITAL VIDEO

11 Introduction

Because DVD films are usually not released at the same time in all regions of the world,

all DVD players are keyed to a specific region code. Discs can be assigned an optional

region code. If the region codes of the player and disc do not coincide, playback is not

possible.

This device will only play Region 1 DVDs or DVDs manufactured to be played in all

regions (“ALL”).

DVDs from other regions cannot be played in this DVD Recorder.

The number within the globe represents the region of the world.

Region 1 represents:

U.S, Canada, upper regions of North America, Bermuda, U.S. Virgin Islands and smaller

regions near Australia.

Remote control and batteries

Power cable

Component video cable

Video cable

Antenna cable

Audio cable

DVD + RW disc

Some malfunctions (frozen or distorted picture and broken sound for example) are due

to dirt on the disc. To avoid such problems you should clean your discs regularly.

1Dirty discs should be cleaned with a soft cloth. Always wipe from the middle to

the edge.

2Do not use any solvents such as benzine, thinners, commercially available cleaning

agents or antistatic sprays designed for vinyl records.

Regional code

Accessories

Cleaning the discs

Question

Can I use a CD lens cleaner in the DVD recorder?

This optical unit (laser) of the DVD recorder operates at a higher power level than

the ones in normal DVDs and CD players so CD lens cleaner discs may actually

damage it.

CD lens cleaner discs should therefore not be used.

1

ALL

Connecting your DVD recorder 12

English

2. Connecting your DVD recorder

You must install the supplied batteries into the remote control before you can use it.

1Unpack the remote control and the two AA (LR-6) batteries.

2Open the battery compartment, insert the batteries in accordance with the polar-

ity markings, and then close the battery compartment.

The remote control is now ready to use.

The remote control has a range of approximately 5 to 10 meters.

•) Before connecting your TV, VCR, AV amp, or any other equipment to your DVD

recorder, refer to the relevant manuals first.

•) Do not connect the power cord until all connections are complete.

•) For the best results when playing DVDs, connect the DVD recorder’s video output

directly to your TV. If you connect your TV via your VCR, the DVD copy protection

system may affect the picture quality.

•) To enjoy the surround sound capabilities offered by DVD (Dolby Digital, DTS,

MPEG-2), you need to connect one of the DVD recorder’s digital audio outputs to

an AV amp with an appropriate surround-sound decoder built-in. See “Surround

sound connections” on page 17.

•) For synchronized recordings to other components connected with digital audio

cables, the length of each track and track numbers of the recorded materials may

become different from the originals. Occasionally, it does not start recording.

Connecting your antenna as shown will allow you to record a program on your DVD

recorder while watching another program on your TV.

1Disconnect the antenna plug (1) from your TV and connect it to the DVD

recorder’s ANTENNA socket.

2Using the supplied antenna cable (2), connect the DVD recorder’s TV socket to

your TV’s antenna input.

Preparing the remote control

Caution

Do not mix old and new batteries. Never mix different types of batteries

(standard, alkaline, etc.). Doing so may reduce the life of the batteries.

Connection notes

Caution

Do not connect the DVD recorder’s audio outputs to your audio system’s

turntable (phono) inputs. Doing so may damage your equipment.

Connecting your antenna

TV

2

1

Antenna In

13 Connecting your DVD recorder

To enjoy the best picture quality when playing DVDs, you need to connect the DVD

recorder to your TV using one of the following connection (the connection you choose

will most likely depend on the connections supported by your TV).

COMPONENT VIDEO (best picture quality)

Component video connections offer the best picture quality, so if your TV has a

COMPONENT VIDEO input, use it.

S-Video (very good picture quality)

S-Video connections offer better picture quality than composite video, so if your

TV has an S-Video input, use it.

Composite video (good picture quality)

If your TV has neither COMPONENT VIDEO nor S-Video inputs, use a composite

video connection.

Using a Component video cable

1Connect the supplied Component video cable (3) to the DVD recorder’s COM-

PONENT VIDEO outputs socket.

2Connect the other end of the Component video cable to a COMPONENT

VIDEO input on your TV.

3Using the supplied AUDIO L/R cable (4), connect the DVD recorder’s AUDIO L/

R outputs to the analog audio inputs on your TV. (Connect white-to-white and

red-to-red).

Connecting your TV to get the best


TV

2

1

4

3

Connecting your DVD recorder 14

English

Using an S-Video cable

Since S-Video cables carry only video signals, separate audio connections are necessary.

1Using an S-Video cable (5), connect the DVD recorder’s S-VIDEO output to an

S-Video input on your TV.

2Using the supplied AUDIO L/R cable (4), connect the DVD recorder’s AUDIO L/

R outputs to the analog audio inputs on your TV. (Connect white-to-white and

red-to-red).

Using a composite video cable

1Using the supplied composite video cable (6), connect the DVD recorder’s

VIDEO (CVBS) output to a composite video input on your TV.

2Using an AUDIO L/R cable (4), connect the DVD recorder’s AUDIO L/R outputs

to the analog audio inputs on your TV. Connect white-to-white and red-to-red).

TV

5

4

2

1

S-video In

Antenna In

Analog

audio In

TV

6

4

2

1

Antenna In

Analog

audio In

Composite

video In

15 Connecting your DVD recorder

You can connect a VCR to the DVD recorder’s IN-EXT 2 and OUT 2 sockets.

If you have an S-VHS VCR, you could connect the DVD recorder’s S-VIDEO output

to an S-Video input on the VCR, and connect the DVD recorder’s AUDIO L/R outputs

to analog audio inputs on the VCR.

You can transfer your home movies to DVD by connecting your camcorder to the AV

sockets on the DVD recorder’s front panel, as shown.

Best picture quality

If you have a DV or Digital 8 camcorder, using its i-link cable (7), connect the cam-

corder’s i-link DV output to the DVD recorder’s DV input.

During the transfer, the original recording dates and times of your home movies will be

recorded on the DVD as subtitles. During DVD playback, you can view this information

by using the Subtitle function.

Very good picture quality

If you have a Hi-8 or S-VHS-C camcorder, using an S-Video cable (5), connect the cam-

corder’s S-Video output to the DVD recorder’s S VIDEO input. And, using an AUDIO

L/R cable (4), connect the camcorder’s analog audio outputs to the DVD recorder’s

AUDIO L/R inputs.

Good picture quality

If your camcorder only has a composite video output, using a composite video cable,

connect the camcorder’s composite video output to the DVD recorder’s VIDEO input.

And, using an AUDIO L/R cable (4), connect the camcorder’s analog audio outputs to

the DVD recorder’s AUDIO L/R inputs.

Connecting a VCR

Notes

Most prerecorded video cassettes and DVDs are copy protected. If you

try to copy them, the message “COPY PROT” will appear on the DVD

recorder’s display.

If the DVD recorder displays the message “NO SIGNAL” when copying a

video cassette:

• Check that the cables are connected securely.

• Try adjusting the VCR’s tracking function.

• The DVD recorder may not recognize the video signal if it’s weak or does not

conform to normal video standards.

When copying DVD-Video discs or prerecorded video cassettes, the pic-

ture is fuzzy and the brightness changes continuously?

• This happens when you copy a DVD or video cassette that uses copy protection.

Playback of the original is OK, but the DVD+R(W) recording will be unwatch-

able. This is normal with copy-protected DVDs and video cassettes.

Connecting your camcorder

6

57

Video camera

4

Connecting an AV receiver 16

English

3. Connecting an AV receiver

The following connections allow you to enjoy DVD playback via your AV receiver.

1Connect an S-Video cable (7) from the DVD recorder’s S-VIDEO output to an

S-Video input on your AV receiver.

2Connect a composite video cable (8) from the DVD recorder’s VIDEO (CVBS)

output to a composite video input on your AV receiver.

3Connect an AUDIO L/R cable (9) from the DVD recorder’s AUDIO L/R outputs

to a pair of analog audio inputs on your AV receiver.

4If your AV receiver has an S-Video output and your TV has an S-Video input, con-

nect an S-Video cable (10) from the AV receiver’s output to an S-Video input on

your TV.

5If your AV receiver has no S-Video output or your TV has no S-Video input, con-

nect a composite video cable (11) from the AV receiver’s composite video output

to a composite video input on your TV.

Basic playback connections

Note

If your AV amp has several video inputs and outputs, you can connect your VCR,

set-top box, LD player, etc., to its video inputs and connect your TV to its video

output. Then you can select your various video sources by using the input selector

on your AV amp.

43

AV Receiver

TV

Antenna In

7

8

9

21

S video In

11

10

Composite

video In

Component

video In

17 Connecting an AV receiver

To enjoy surround sound (Dolby Digital, DTS, MPEG-2), you need to connect one of

the DVD recorder’s digital audio outputs to a multichannel AV amp with an appropriate

surround-sound decoder built-in.

Your DVD recorder has both coaxial and optical digital audio outputs. The format you

choose will most likely depend on the formats supported by your AV amp. You don’t

need to connect both cables, and their sound quality is identical.

1Connect a coaxial (12) or optical (13) digital audio cable from the DVD

recorder’s COAX OUT or OPTICAL OUT to a coaxial or optical digital

audio input on the AV receiver.

You can use a composite video cable instead of a dedicated coaxial digital audio cable.

Surround sound connections

Note

An unpleasant digital noise may be heard if you select a DVD soundtrack that uses

an audio format that is not supported by your AV amp. For example, you select a

DTS soundtrack and your AV amp does not support DTS. The format of the cur-

rently selected soundtrack can be displayed onscreen in the menu bar. Six-channel

(5.1) surround-sound playback is only possible with a multichannel AV amp that sup-

ports Dolby Digital, DTS, or MPEG-2.

AV Receiver

TV

12

13

7

S video In

11

10

21

Composite

video In

43

Component

video In

8

Connecting an AV receiver 18

English

The following connections allow you to record programs from your VCR or set-top

box to your DVD recorder via your AV receiver.

1If your VCR or set-top box is connected to your AV receiver with an S-Video

cable, connect an S-Video cable (10) from your AV receiver’s S-Video output to

the S-Video input on your TV.

2If your VCR or set-top box is connected to your AV receiver with a composite

video cable, connect a composite video cable (11) from the AV receiver’s com-

posite video output to the composite video input on your TV.

You don’t need to connect both the S-Video and composite video cables to your TV.

S-Video offers better picture quality.

1Using the supplied composite video cable (13), connect the DVD recorder’s

VIDEO (CVBS) input to a composite video output on your AV receiver.

2Using an AUDIO L/R cable (14), connect the DVD recorder’s AUDIO L/R inputs

to the analog audio outputs on your AV receiver. (Connect white-to-white and

red-to-red).

3Using an S-Video cable (12), connect the DVD recorder’s S-VIDEO input to an

S-Video output on your AV receiver.

Recording connections

AV Receiver

Antenna In

Set top box

VCR

21

43

Component

video In

12

13

14

S video In

11

10

Composite

video In

19 Connecting an AV receiver

•) Make sure that all necessary connections are made before connecting the DVD

recorder to the power supply.

•) Plug the power cable supplied into the Power connector on the rear of the

recorder.

•) Plug the mains plug into an AC outlet.

•) Switch on the TV set and select the programme number that you have chosen for

video playback (see operating manual for your TV set).

•) Press STANDBY/ON.

– The recorder display lights up. If you have not yet installed your DVD recorder, it

will enter ‘Initial Setup mode.’ In this mode you will have to set your personal

preferences.

Power supply

Note

Always check if the local mains voltage matches the required 100V - 120V.

When the recorder is in the Standby position, it is still consuming some power.

If you wish to disconnect your DVD recorder completely from the mains, withdraw the plug

from the AC Outlet.

Switching on

Installing your DVD recorder 20

English

4. Installing your DVD recorder

After successfully connecting your DVD recorder to the TV set and other additional

devices as described in the previous chapters, this chapter will show you how to start

the initial installation.

The DVD recorder automatically seeks out and stores all available TV channels.

1Select the desired language for the on-screen menu by pressing w or v.

2Confirm with ENTER/OK.

3Select the desired audio language using w or v.

4Confirm with ENTER/OK.

5Select the desired language for the subtitles by pressing w or v.

6Confirm with ENTER/OK.

Initial installation

Tip

Connecting additional devices

If you have connected additional devices such as a satellite receiver to the aerial

cable, switch them on. The automatic channel search will recognise it and save it.

No aerial connected

Even if you only want to use the DVD recorder to play back or have only connected

a satellite receiver, you must still complete the initial installation.

This is necessary so that the basic settings are stored correctly. Once initial installa-

tion is complete you can use the DVD recorder as normal.

Question

What is an on-screen menu?

The multi-language on-screen menu takes the mystery out of using your new DVD

recorder. All settings and/or functions are displayed on your TV screen in the rele-

vant language.

Question

What is an audio language?

The DVD audio will play in the selected language if it is available. If this language is

not available on the DVD, the audio will play in the first language on the DVD. The

DVD disc menu will appear in the selected language if it is available on the disc.

Question

What is the subtitle language?

DVD subtitles will be in the selected language if it is available. If this language is not

available, subtitles will be in the first language on the DVD.

Initial Setup

Menu Language

Press OK to continue

English

Español

Français

Initial Setup

Audio Language

Press OK to continue

English

Español

Français

Português

Italiano

Initial Setup

Press OK to continue

English

Español

Français

Português

Italiano

Subtitle Language

21 Installing your DVD recorder

7Select the desired screen format position using w or v.

These settings will only be used if you insert a DVD that contains this information.

8Confirm with ENTER/OK.

9After you connect the aerial (or cable TV, satellite receiver, etc.) to the DVD

recorder, press ENTER/OK.

The automatic TV channel search starts. “WAIT” will appear on the display.

0When the automatic TV channel search is complete after several minutes of wait,

“Auto ch. search complete” will appear on the TV screen.

ATo remove the menu, press the SYSTEM-MENU button on the recorder’s

remote control.

The initial installation is now complete.

Question

Which screen formats can I select?

“4:3 letterbox” for a “wide-screen” (cinema format) picture with black bars at the

top and bottom.

“4:3 panscan” for a full-height picture with the sides trimmed.

“16:9” for a wide-screen TV set (screen edge ratio 16:9)

Problem

✘The DVD recorder cannot find any TV stations

✓ Select channel 1 on the TV set. Can you see the stored TV channel on the TV

set?

If not, check the cable connection from the aerial (aerial jack) to the DVD

recorder and to the TV set.

✓ Please have patience.

The DVD recorder searches the entire frequency range in order to find and save

the largest possible number of TV channels.

✓ If you have not connected an aerial, go through all the basic settings right to the

end and then, if you wish, start the automatic search (see “Automatic TV station

search”).

Initial Setup

TV Shape

Press OK to continue

4:3 letterbox

4:3 panscan

16:9

Installation

Auto Ch. Programming

Searching for TV channels

000 Channels found

Please wait

Installing your DVD recorder 22

English

During installation, all available TV channels are searched for and stored. If the channel

assignments of your cable or satellite TV provider change or if you are reinstalling the

DVD recorder, e.g. after moving house, you can start this procedure again. This will

replace the stored TV channels with the new ones.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU on the remote control. The menu bar appears.

4Select “ ” symbol with t or u.

5Select “Installation” using w or v and confirm with u.

6Select “Auto Ch. Programming” using w or v.

7Press u.

8The automatic TV channel search starts. This allows the DVD recorder to save all

available TV channels. This procedure may take several minutes.

9When all the TV channels have been found, “Auto ch. search complete” will

appear on the TV screen.

0To end, press SYSTEM-MENU.

You can read about how to search for a TV channel manually in “Adding and clearing TV

channels manually”.

Automatic TV channel search

Question

Cannot select “ ”?

You need to stop the disc to select “ ’.

Problem

✘Very few TV channels were found

✓ During “Automatic channel search” the DVD Recorder detects whether an

antenna or a cable TV signal is connected. If you have connected a cable TV signal

but found very few TV channels, you must search the channels manually.

1To do so, select “Cable/Antenna” instead of line “Auto Ch. Programming” in

step 6 and confirm with u.

2If you select “Cable”, channels 1-125 will be available.

If you select “Anten.”, channels 2-69 will be available.

Select your type of connection by pressing u repeatedly:

“Anten.”, “Cable” or “Auto.” automatically detects which one you have.

3Confirm the setting with OK.

4Press SYSTEM-MENU to go to the next menu. Press OK to start channel

search as prompted by the on-screen message. When the channel search is com-

plete, press SYSTEM-MENU repeatedly to remove all the menus.

Installation

Auto Ch. Programming

Searching for TV channels

000 Channels found

Please wait

23 Installing your DVD recorder

After you have performed the automatic channel search you may not agree with the

sequence in which the individual TV channels have been allocated to the programme

positions (programme numbers). You can use this function to rearrange the TV channels

already stored or to delete TV channels you don’t want or those with poor reception.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder. Press the SYSTEM-MENU button on the remote

control. The menu bar appears.

3Select “ ” symbol with t or u.

4Select “Installation” using w or v and confirm with u.

5Select “Add/Delete Channels” using w or v and confirm with u.

6Using v or w select the TV channel that you want to add or delete.

7Confirm with u.

8To store, press ENTER/OK.

9To end, press SYSTEM-MENU.

Adding and clearing TV channels

manually

Tip

Deleting TV channels

Unwanted channels or those with poor reception can be deleted using CLEAR.

Proceed at step 6 to continue or at 8 to finish.

Installation

Add/Delete Channels

...

Channel 001 Add

Channel 002 Add

Channel 003 Delete

Channel 004 Delete

Channel 005 Delete

Channel 006 Delete

...

To exit press

SYSTEM MENU

Installing your DVD recorder 24

English

You can select the country and, for DVD playback, the language for the subtitles and

the audio language. Please note that with some DVDs the audio language and/or subti-

tle language can be changed only via the DVD menu.

Moreover, when recording the sound of a TV channel, you can switch between stereo

and an additional language (SAP - Secondary Audio Program). See the following section

on “Switching audio recording (stereo, SAP)”.

You also have the option of setting one of the displayed languages for the on-screen

menu (OSD). However, the DVD recorder display will only display English text regard-

less of this setting.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU on the remote control. The menu bar appears.

4Select “ ” symbol with t or u.

5Select line “Language” with w or v and confirm with the u button.

6Select the appropriate line and confirm with u.

7Select the appropriate setting using w or v and confirm with ENTER/OK.

8To end, press SYSTEM-MENU.

Switching audio recording (Stereo, SAP)

Some TV programs broadcast additional audio (SAP - Secondary Audio Program). In

most cases this means that an additional language is available. For example, if a program

is available in English and Spanish, Spanish can be broadcast as the additional audio pro-

gram (SAP).

To record TV programs in stereo or SAP, you can select Stereo or SAP as the default

setting.

This setting does not become active until the sound of a TV program is transmitted in

Stereo or SAP.

When you playback the recording, you can playback the sound only in the setting you

selected for recording (a recording in SAP can be played back only in SAP).

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU on the remote control. The menu bar appears.

4Select “ ” symbol with t or u.

5Select line “Language” with w or v and confirm with the u button.

6Select line “Recording audio” and confirm with u.

Setting the language

Tip

Which settings can I choose?

Playback audio: language of the playback (audio language)

Recording audio: Type of audio recording “Stereo” or “SAP”

Subtitle: Subtitle language

Menu: Language of the OSD menu

n

Playback audio English

Recording audio Stereo

Subtitle English

Menu English

Language

n

Playback audio English

Recording audio Stereo

Subtitle English

Menu English

Language

25 Installing your DVD recorder

7Select “Stereo” or “SAP” with w or v and confirm with ENTER/OK.

8To end, press SYSTEM-MENU.

If you intend to use the VCR Plus+® programming system, you must first assign Guide

channel numbers to the TV channels.

1Press SYSTEM-MENU on the remote control. The menu bar will appear.

2Select “ ” using t or u.

3Select line “Installation” using w or v and confirm with u.

4Select the line “VCR Plus+ Ch.” using w or v and confirm with u.

5Use w or v to select the Guide channel number you want to assign to a TV chan-

nel.

6Use t or u, or use the number buttons 0..9 to select the TV channel correspond-

ing to this Guide channel number. An overview of guide numbers/TV channels can

be found in your daily newspaper or in your TV listings.

7Confirm the allocation with ENTER/OK.

8To end, press SYSTEM-MENU.

Assigning the VCR Plus+® Guide

channel numbers

Installation

VCR Plus+ Ch.

VCR Plus+ Ch. Channel

... ---

001 ---

002 ---

003 ---

004 ---

005 ---

... To exit press

SYSTEM MENU

Installing your DVD recorder 26

English

This function uses the information sent via the local PBS channel to automatically set

the time/date. For this reason, you must enter the PBS channel that sends this addi-

tional information.

When the DVD Recorder chooses a wrong PBS channel or the displayed time/date is

wrong, you must manually set the date/time (see section “Manually setting the time &

date”).

1Press SYSTEM-MENU on the remote control. The menu bar appears.

2Select “ ” symbol with t or u.

3Select “Installation” using w or v and confirm with u.

4Select “Time/date” using w or v and confirm with u.

5Select “Automatic” with w or v and confirm with u.

6Select the corresponding line with w or v.

7Select the channel which sends the time/date information in the line “PBS Chan-

nel” and confirm with ENTER/OK. The DVD Recorder will check whether or

not the information transfer is possible.

8Select one of the following settings in line “Daylight Saving”:

“On”: The time set corresponds to summer time (summer time activated)

“Off”: The time set corresponds to the winter time (summer time is off)

9In the line “Time Zone”, select your time zone if the PBS channel entered was for

a different time zone. This is the only way to set the time correctly, or, if neces-

sary, to correct it.

If you want to use the time zone of the PBS channel, select “Auto.”.

0Confirm the changes with ENTER/OK.

ATo end, press SYSTEM-MENU.

Setting the time and date

automatically

Problem

✘“Clock not set, check channel” will appear on the TV screen

✓ No time/date data can be received from this TV channel.

Select a different channel or “Auto.” in line “PBS Channel”.

Time/date

Automatic

PBS Channel Auto.

Daylight Saving Off

Time Zone Auto.

To exit press

SYSTEM MENU

27 Installing your DVD recorder

If the time is incorrect, this could be due to a weak or disrupted TV signal. If this is the

case, switch off the automatic function.

1Press SYSTEM-MENU on the remote control. The menu bar will appear.

2Select “ ” using t or u.

3Select line “Installation” using w or v and confirm with u.

4Select line “Time/date” using w or v and confirm with u.

5Select “Manual” with w or v.

6Confirm with ENTER/OK.

7Change the time in line “Time” using the number buttons 0..9 on your remote

control.

8Check “AM/PM”, “Year”, “Month”, and “Date” in the same way.

To select between the fields, use w or v.

Change the information with t, u or the number buttons 0..9.

9Select one of the following settings in line “Daylight Saving”:

“On”: The time set corresponds to the summer time (summer time is on)

“Off”: The time set corresponds to the winter time (summer time is off)

0 When all settings are correct, confirm with ENTER/OK.

ATo end, press SYSTEM-MENU.

If the setting has been confirmed with OK the automatic system is disabled.

Manually setting the time & date

Time/date

Manual

Time 09:02

AM/PM AM

Year 01

Month 01

Date 01

Daylight Saving Off

To exit press

SYSTEM MENU

On-screen information 28

English

5. On-screen information

You can check or change many of the functions and settings of your DVD recorder via

the system menu bar. The menu bar cannot be displayed during recording.

Press SYSTEM-MENU to open and close the menu bar (main menu). Use t and u to

select the relevant function. Use w to confirm the function and go either to another

menu or execute the function directly.

Some functions may not be available, depending on the disc inserted.

Menu bar 1

Menu bar 2

While menu bar 1 is being displayed you can go to menu bar 2 by pressing u again.

The top left corner of the menu line contains a field for temporary messages relating to

the various operating modes. This information appears briefly on the screen when cer-

tain disc functions have been activated:

Symbols in the menu bar

User preferences

Title/track

Chapter/index

Audio language

Subtitle language

Camera angle

Zoom

dSound

Frame advance

HSlow motion

RFast forward

Search by time

Field for temporary messages

Shuffle

Scan

Repeat entire disc

Repeat title

29 On-screen information

The status field shows the current operating mode (status) of the DVD recorder and

the type of disc inserted. This display can be disabled.

Disc type symbols

Repeat track

Repeat chapter

Repeat from A to the end

Repeat from A to B

Camera angle

Child lock enabled

Resume playback

Illegal action

Status field

DVD+RW

DVD+R

DVD-Video

Video-CD

No disc

Error

On-screen information 30

English

Operating mode symbols

This field is located in the bottom left-hand corner of the screen. The aerial signal, the

TV channel and the TV channel name for the selected programme are displayed.

This box appears above the tuner information box. When a timer recording is set, it

shows the timer icon and the start time or date of the first programme to be recorded.

If no timer recording is scheduled, the current time is displayed.

This box disappears during playback of a disc or after a recording starts. However, you

can access it during an OTR recording by pressing SYSTEM-MENU.

Recording

Stop

Playback

Playback-Pause

Record-Pause

Search forwards (8x speed)

Search backwards (8x speed)

Slow motion

Tuner information box

Current channel/selected input jack

No signal

The TV channel is not available/the additional device is not con-

nected or it is switched off

Copy-protected signal

Timer information box

Timer starts on the day shown

OTR recording runs until the stop time displayed

Current time

No timer event programmed

31 Playback

6. Playback

With this DVD recorder you can play back the following systems:

•) DVD Video

•) (Super) Video CD Disc

•) DVD+RW Disc

•) DVD+R Disc

•) DVD-RW (video mode, finalized)

•) DVD-R

•) CD-R

•) CD-RW

•) Audio CD

•) MP3 CD

You can operate the video recorder using the remote control or the buttons on the

front of the DVD recorder.

1Press the F (Open/Close) button on the front. The disc tray will open. While

the disc tray is opening, “OPENING” and then “TRAY OPEN” when the tray is

fully open.

2Carefully place the disc in the tray with the label facing up and press PLAY or

F (Open/Close) “CLOSING” and then “READING” will appear in the display.

The information on the disc will be read.

3Playback starts automatically.

General notes on playback

Problem

✘The display will read “PIN”

✓ The child lock has been activated for the inserted disc. Read the sections on

“Child lock” and “Releasing a disc” in the chapter on “Access control (child

lock)”.

✘The menu on the screen is showing an “X”

✓ Some DVD discs can be manufactured so that certain steps are required before

the disc can be played, or so that only limited operation is possible during play-

back. When an “X” appears on the screen the selected feature is not possible.

✘The screen is showing regional code information

✓ Since DVD films are not normally released in all parts of the world at the same

time, all DVD players have a specific regional code. Discs can be given a regional

code. If the regional codes differ between the player and the disc, playback is not

possible.

✓ The regional code is shown on the label on the back of the machine.

✓ The regional code does not apply to recordable DVD discs.

Inserting a disc

Question

How do I insert a double-sided DVD?

Double-sided discs do not have labelling over the whole surface. The labelling for

each side is in the centre of the disc. To play a side its label must be facing up.

Tip

Opening/closing the tray using the remote control

You can open and close the disc tray using the remote control.

Press and hold the STOP button on the remote control until the dialog box

shows “OPENING” or “CLOSING”.

Playback 32

English

1If playback does not start automatically, press PLAY .

This will appear on the display:

title, chapter, elapsed time.

2To stop playback, press STOP on the remote control or A on the DVD

recorder.

3To eject the disc, press F (Open/Close) on the front of the DVD recorder.

1If the disc is write-protected or a finalised DVD+R disc, playback starts automati-

cally.

2If playback does not start automatically, use the w or v button to select the title

you want to play on the index screen.

You can also use the t or y button on the front.

3Press the PLAY button.

This will appear on the display:

title number, recording quality.

4To stop playback, press STOP on the remote control or A on the DVD

recorder.

5To eject the disc, press F (Open/Close) on the front of the DVD recorder.

A menu may appear when a DVD is played back. If the titles and chapters are num-

bered, press a number button on the remote control. You can also use the t, u, v, w

buttons or number buttons 0..9 to select a menu item and confirm with ENTER/OK.

You can also access the menu using TOP-MENU on the remote control.

For further information see “Playing a DVD video disc”.

When a DVD+RW is played back the index overview appears. Using w, v, t, y

select the title you want to play back.

Confirm with ENTER/OK.

For further information see “Playing back a DVD+RW/+R Disc”.

If playback does not start automatically, press PLAY .

For further information see “Playing an audio CD”.

If the “A” symbol appears in the display, start playback by pressing PLAY .

If a menu appears on the screen, use the remote control buttons indicated on the

screen to select the menu option you want (PREV=t, NEXT=y) or with the num-

ber buttons 0..9.

For further information see “Playing a (Super) Video CD”.

Playing a DVD video disc

Playing a DVD+RW/ +R disc

Problem

✘I can see the message “EMPTYDISC”

✓ The disc does not contain any recordings.

DIGITAL VIDEO

33 Playback

You can also use the DVD recorder to play audio CDs

1Insert an audio CD. Playback starts automatically.

2Stop playback using STOP . The number of tracks and the total time are dis-

played.

MP3 (MPEG1 Audio Layer-3) files are highly compressed music files. Using this technol-

ogy the data volume can be compressed by a factor of 10. This means it is possible to

record 10 hours of music in CD quality on a single CD-ROM.

When creating MP3 CDs please note the following:

File system: ISO9660

Directory structure: maximum of 8 levels

Formats: *.mp3

Filenames: maximum of 12 characters (8+3)

Maximum of 32 albums, 999 titles

Supported sampling frequencies: 32, 44.1, 48 (kHz). Music with sampling frequencies

other than these will be skipped.

Supported bit rates: 32, 64, 96, 128, 192, 256 (kbit/s)

ID3 Tag: Version 1, 1.1. In later versions the directory name is displayed as the album

and the filename as the title.

Question

What should I note when playing back different recording types (quali-

ties)?

The correct recording quality “M1, M2, M2x, M3, M4, M6, FR” will automatically

be selected during playback.

For more information see the section on “Selecting the recording type (quality)” in

the chapter on “Manual recording”.

Playing an audio CD

Tip

Audio CD display

If the TV is on, the audio CD screen appears automatically.

During playback, the current track number and its elapsed playing time will show on

the TV screen and on the recorder display.

Playing an MP3 CD

Playback 34

English

Important notes for playback:

In accordance with SDMI (Secure Digital Music Initiative), the digital audio output is

turned off during MP3 playback.

Only the first session of a multi-session CD will play back.

1Insert an MP3 CD. Playback starts automatically.

2Stop playback using STOP . The number of albums is displayed in the display.

(Super) Video CDs may be equipped with PBC (Play Back Control). This means that

special playback functions (menus) can be directly selected. The video CD must be PBC

compatible (see CD case). When PBC is active, no information will be shown on the

DVD recorder display.

“PBC” is active in the default settings.

1Insert a (Super) Video CD.

If the “ ” symbol appears in the display, start playback by pressing PLAY .

2If a menu appears on the screen, use the remote control buttons indicated on the

screen to select the menu option you want (PREV=t, NEXT=y) or with the

number buttons 0..9.

If a PBC menu consists of a list of titles, you can select a title directly.

3Use RETURN to go back to the previous menu.

4Stop playback using STOP .

Tip

MP3 CD display

If the TV is on, the MP3 CD screen appears automatically.

During playback, the current track number and its elapsed playing time will show on

the TV screen and on the recorder display.

Further information on the album, track and artist will also be displayed if included

in the ID tag.

Tip

Additional playback features

Using t or y select the next or previous title.

You can also use the TITLE/CHAP button to select titles and albums.

1Press the TITLE/CHAP button and use the u or t button to select the “T”

symbol for title or “C” for chapter.

2Use the w or v buttons or the number buttons 0..9 on the remote control to

select the number of the title/chapter.

You can also use the repeat functions (REPEAT button).

Playing a (Super) Video CD

35 Additional playback features

7. Additional playback features

If there is more than one title or chapter on a disc you can change to another title or

chapter as follows. However if there are several chapters within a title, these will be

selected. The title can then still be selected via the menu bar.

1During playback, press y to go to the next title/chapter. Press t to return to

the start of the current title/chapter. Press t twice to return to the start of the

previous title/chapter.

You can search the disc at 4x or 32x playback speed. Other speeds can only be selected

via the menu bar (“R”).

1During playback, press and hold e (reverse) or r (forwards) to switch to the

search feature. You can switch between the playback speeds using e/r.

2To continue playback, press PLAY at your chosen location.

Changing to another title/chapter

Tip

Use the TITLE/CHAP (title/chapter) button

1Press TITLE/CHAP (title/chapter) and then use v or w to select the appropri-

ate title.

Make sure the symbol “ ” (title) is selected in the menu bar.

2Use TITLE/CHAP to select chapters within a title. Press TITLE/CHAP and

use u to select the “ ” symbol (chapter).

Now select the appropriate chapter with v, w or digit keys 0..9.

Searching a disc

Problem

✘No sound

✓ The sound is switched off in search mode. This is not a fault in your machine.

Tip

Search feature via menu bar

1During playback press SYSTEM-MENU on the remote control. The menu bar

will appear at the top of the screen.

2Select the “R” symbol using u or t and confirm with w.

3You can now use the t or u button to select different forward and backward

search speeds.

4If necessary, switch the menu bar off with the SYSTEM-MENU button.

5To continue playback, press PLAY .

Additional playback features 36

English

1During playback, press PAUSE to stop playback and display a still picture.

It will proceed to a next frame when you press PAUSE again.

2To continue playback, press PLAY .

1During playback press PAUSE on the remote control. Now press e or r

to switch to slow motion.

2You can switch between different speeds using e or r.

3To continue playback, press PLAY .

Using this feature you can select where playback should start (select elapsed time).

1During playback press SYSTEM-MENU on the remote control. The menu bar

will appear at the top of the screen.

2Select the “ ” symbol using u or t and confirm with w.

Playback is stopped and a box appears on the screen showing the elapsed time.

3Enter the start time with the digit keys 0..9 from where playback should start.

4Confirm with ENTER/OK.

5Playback starts at the time you entered.

Still picture

Tip

Frame advance via menu bar

1During a still picture press SYSTEM-MENU on the remote control.

The menu bar will appear at the top of the screen.

2Select the “ ” symbol using u or t and confirm with w.

3You can now use the t or u button to go forwards or backwards one frame at a

time.

4If necessary, switch the menu bar off with the SYSTEM-MENU button.

Slow motion

Tip

Slow motion via menu bar

1During playback press PAUSE and then SYSTEM-MENU on the remote

control. The menu bar will appear at the top of the screen.

2Select the “H” symbol using u or t and confirm with w.

3You can now use the t or u button to select different forward and backward

slow motion speeds.

4If necessary, switch the menu bar off with the SYSTEM-MENU button.

Search by time

Problem

✘The time entered will flash on the screen

✓ The selected title is shorter than the time entered. Enter a new time.

37 Additional playback features

You can mark entire sections or the whole disc for endless playback. Depending on the

type of disc (DVD video, DVD+RW, video CD) you can select a chapter, title or the

entire disc. DVD+RW and DVD+R cannot repeat an entire disc.

1Select the desired chapter, title or the entire disc and start playback.

2During playback, press REPEAT. By pressing REPEAT recurrently you can make

a choice from the following options:

•) “ ”: repeat chapter (DVD only)

•) “ ”: repeat track/title

•) “ ”: repeat entire disc

•) Display disappears: no repeat

3To end the repeat, press the STOP button.

You can also keep pressing the REPEAT button until the displays disappear.

Repeating a passage (A-B)

To repeat or loop a sequence in a title:

1Press A-B at your chosen starting point;

appears on screen.

2Press A-B again at your chosen end point;

repeat appears on screen, and the repeat sequence begins.

3To exit the sequence, press A-B.

DVD Discs

This shuffles the playing order of chapters within a title, if the title has more than one

chapter.

1Press SHUFFLE during playback.

2To return to normal playback, press SHUFFLE again.

Video CDs

This shuffles the playing order of tracks within a disc, if the disc has more than one

tracks.

1Press SHUFFLE during playback.

2To return to normal playback, press SHUFFLE again.

This feature plays back the first 10 seconds of each chapter (DVD) or track (CD).

1During playback, press SCAN.

2After 10 seconds the DVD recorder switches to the next chapter/index. To start

playback at the relevant chapter/index press PLAY .

Repeat play

Shuffle

Scan feature

Additional playback features 38

English

If the disc contains sequences recorded from different camera angles, the angle box

appears, showing the number of available angles, and the angle being shown. You can

then change the camera angle if you wish.

1Press ANGLE.

2Use w or v to select the required angle in the angle box.

3To go to any angle directly, enter the angle number using the numerical keys 0..9.

After a small delay, play changes to the selected angle. The angle box remains dis-

played until multiple angles are no longer available.

The Zoom function allows you to enlarge the video image and to pan through the

enlarged image.

1Press Zoom.

2Press w or v to activate the Zoom function and select the required zoom factor;

1.33 or 2 or 4.

The recorder will go into pause mode.

The selected zoom factor appears below the Zoom icon in the system menu bar

and “Press OK to pan” appears below the system menu bar.

The picture will change accordingly.

3Press ENTER/OK to confirm the selection.

The panning icons appear on the screen.

4Use v, w, u, t to pan all over the screen.

5When ENTER/OK is pressed only the zoomed picture will be shown on the

screen.

6Press to exit zoom mode.

Camera angle

Tip

You can also use this function through an on-screen menu (a system menu bar).

Zoom feature

Tip

You can access to Zoom function by an on-screen menu (a system menu bar).

39 Additional playback features

Many pre-recorded DVD discs have more than one audio language. The language ini-

tially selected for playback will be the one you selected when you first set up the DVD

recorder. However you can change the audio language of the inserted disc at any time.

You can change the audio language either using the menu of the inserted disc

(TOP MENU button) or the AUDIO button. The audio languages for DVD playback

in the two menus may be different. Please note that with some DVDs the audio lan-

guage and/or subtitle language can be changed only via the DVD menu.

1During playback press AUDIO.

2Select the required audio language by pressing AUDIO repeatedly.

3Play continues in the new audio language.

Many pre-recorded DVD discs have more than one subtitle language. The language ini-

tially selected for playback will be the one you selected when you first set up the DVD

recorder.

However you can change the subtitle language of the inserted disc at any time.

The subtitle languages in the menus may differ.

1During playback press SUBTITLE.

2Select the required subtitle language by pressing SUBTITLE repeatedly.

3Playback continues in the new subtitle language.

Select the audio language

Tip

You can select an audio language in an on-screen menu (a system menu bar).

Subtitles

Tip

An access to SUBTITLE function through the on-screen menu

1During playback press SYSTEM-MENU and select the “Z” icon using u.

2Select the required subtitle language using SUBTITLE or w, v. You can also

enter the number directly using the number buttons 0..9.

You can switch off subtitles by pressing 0 or by selecting “off”.

3Playback continues in the new subtitle language.

Tip

An access to SUBTITLE function through the top menu of the disc

1Press TOP MENU to go to the top menu of the disc.

2Follow the disc’s instruction.

Manual recording 40

English

8. Manual recording

Use the “Manual recording” function to spontaneously start recording (e.g. to record a

TV show already in progress).

In the “index display” select the title to be overwritten or “Empty title” with w, v.

If you insert recordings between existing recordings, check the lengths of the old and

new recordings. If the new recording is too long the subsequent recording (title/chap-

ter) will be overwritten.

General

Question

Which discs can I use for recording?

With this DVD recorder, you can record on two types of DVD:

DVD+RW

This disc can be written to and then the contents deleted.

DVD+R

This type of disc can only be recorded once.

If you want to play this DVD in a DVD player it must be finalized using the “Finalise

disc” function. It is not possible to make further recordings using this disc.

If this disc is to be played in a DVD recorder it must not be finalised.

Recordings can be added and deleted. The disc space (playback time) from the

deleted recording cannot be recovered for further recordings

Tip

Insert new recordings at the end of all existing recordings (Safe Record)

To add a new recording at the end of the last recording on the disc, hold down the

REC S button until the message “SAFE REC” appears on the display.

For DVD+R discs each new recording is always added at the end of all previous

recordings as existing recordings cannot be overwritten.

End of disc is reached

If the end of a disc is reached during recording, recording will stop and the

Recorder will turn itself off automatically.

Please refer to section “Recording without automatic switch-off”, if you want to

manually start and stop your own recording.

If you want to start a recording manually but have it stopped automatically, read the

section “Recording with automatic switch-off”. (e.g. not to record to the end of

the disc)

Read the section “Direct record” if you want to record a programme currently

being shown.

41 Manual recording

1Switch on the TV set and select the programme number for the DVD recorder.

2Insert a disc on which the recording is to be made. This disc is then checked for

content and system. “READING” will appear on the display.

3If necessary, use the MONITOR button on the remote control to switch to the

internal tuner in the DVD recorder.

4Use CH+ or CH- to select the programme number (station name) you want to

record. This will appear on the display:

5To start recording, press REC S on the remote control or REC on the DVD

recorder.

If you want to start the recording at the end of the existing recordings, hold down

the REC S button until the message “SAFE REC” appears on the display.

For DVD+R discs each new recording is always added at the end of all previous

recordings as existing recordings cannot be overwritten.

This will, for example, appear in the display:

Recording without automatic

switch-off

Problem

✘Index display

✓ A DVD+RW disc has been inserted that already contains recordings. Use the v

or w button to select the point where the recording is to start.

✘The message “EMPTYDISC” appears in the display

✓ The disc inserted is a blank DVD disc.

✘A dialog box appears asking you whether you want to delete the

contents or eject the disc

✓ The disc inserted is a DVD+RW but its contents are not DVD video-compatible

(e.g. a data disc). Recordings on this disc can only be made if the entire disc is

first deleted with the REC S button.

✘The message “Too many titles” appears on the screen if a record-

ing is to be made

✓ A disc may contain a maximum of 48 titles (including blank titles). Delete titles

or change the disc.

Tip

Programme number of the external inputs:

“EXT2”SVHS jack (Y/C) S-VIDEO IN Video jack (CVBS) Video in, Audio jack

IN L AUDIO R for SVHS-jack and Video jack.

Switching between jack S-VIDEO IN and Video in is done automatically.

In case both jacks are occupied, the signal at jack S-VIDEO IN is given

priority.

“EXT1”Component Video jacks on the back IN COMPONENT VIDEO, Audio

jacks IN AUDIO LR for Component Video

“CAM1”SVHS-/Audio front jacks S-VIDEO / left AUDIO right

“CAM1”Video/Audio front jacks A/V VIDEO / left AUDIO right Switching

between jack S-VIDEO and VIDEO is done automatically. In case both

jacks are occupied, the signal at jack S-VIDEO is given priority

“CAM2”Digital video (i.Link) front jack DV IN

Manual recording 42

English

6Use the STOP button on the remote control or A on the machine to stop

the recording. “MENU UPDT” will appear on the display.

The DVD recorder is writing the list of contents. Wait until the message disap-

pears from the display. The recording is then complete.

1During recording press PAUSE , for example to avoid recording the commer-

cials.

2To continue recording, press REC S.

Tip

Insert chapter markers

During recording you can mark scenes so you can find them or hide them later.

During recording, press EDIT at the start point. “Inserting chapter marker”

appears on the TV screen. In the display, the number of the “CHAPTER” increases

by one.

For further information on titles and chapters, see the section on “Changing to

another title/chapter” in “Additional playback features”.

Problem

✘The display will read “DISC ERR”

✓ Recording could not be completed correctly because of a disc error. Check the

disc and clean it if necessary.

Tip

Making recordings on DVD+R discs compatible

If you want to play back the recording on a DVD player, you need to finalise the disc

in the DVD recorder. You can prepare your DVD for use in a DVD player using the

“Finalising” feature. See “Finalising DVD+R discs” in “Managing the disc contents”.

Interrupt recording (Pause)

Tip

End recording

To end the recording, press the STOP button. Wait until “MENU UPDT” disap-

pears from the display.

43 Manual recording

1Insert a disc.

2If necessary, use the MONITOR button on the remote control to switch to the

internal tuner in the DVD recorder.

3Use CH+ or CH- to select the programme number (channel name) you want to

record.

4Press REC S on the remote control.

5Each time you press REC S you will add 30 minutes to the recording time.

Recording with automatic switch-off

(OTR one-touch-recording)

Question

How can I cancel the recording time I have just entered?

To delete an entry, press CLEAR while the display shows the recording time.

How can I check the remaining recording time?

Press SYSTEM-MENU while an OTR is in progress. The time at which the

recording will end will appear on the TV screen in the timer info box.

Manual recording 44

English

m

To ensure you don’t accidentally delete a recording you can protect the entire disc. You

can only ever protect the entire disc. You cannot protect individual recordings.

1Insert the disc to be protected.

2Press DISC-MENU. The index screen will appear.

3While the index screen is displayed press STOP on the remote control. The

first title is highlighted.

4Press v. This takes you to the disc info screen.

5Press the u button.

Select the “Protection” line.

Confirm with u.

6Select “Protected” with the w button and confirm with ENTER/OK.

7Press t and then TOP MENU to terminate.

The entire disc is now protected.

If an attempt is made to record on a protected disc, “DISC LOCK” will appear on the

display and “Disc locked” will appear on the screen.

Preventing accidental erasing of

discs

Question

What happens with DVD+R discs?

As long as these discs are not finalised, they can be protected against accidental era-

sure in the same way as DVD+RW discs.

Tip

If you later decide to record on the disc, follow these steps but select “Unpro-

tected” at step 6.

45 Manual recording

On a recorded DVD+RW disc you can add another recording to an existing title. This

recording is added to the title as a “chapter”. The existing information will be overwrit-

ten starting from this point. Titles will also be overwritten that follow the current title

depending on the length of the new recording. The recording type (Quality) will be

taken from the current title.

To play back this recording, press SYSTEM-MENU and use the u button to select the

“C” (Chapter) symbol. You can also use the TITLE/CHAP key.

For further information, see “Changing to another title/chapter” in “Additional playback

features”.

1In the index display, find the title to which the new recording is to be added.

2Look at the last minute of the old recording.

3Press PAUSE on the remote control at the position where the new recording

is to go. “D” will appear on the screen.

4To monitor the recording you can press MONITOR to switch to the internal

tuner.

5Now start recording as usual by pressing REC S on the remote control.

The new recording will be inserted.

6Stop recording with STOP .

Lining up recordings within a title

(assemble cut)

Question

What happens with DVD+R discs?

New recordings on “DVD+R” discs can only be added after existing recordings.

It is not possible to overwrite existing recordings on “DVD+R” discs.

Manual recording 46

English

You can select the picture quality of the recording using the recording quality feature

and hence the maximum recording time per disc.

You can check the quality by changing the recording mode and then watching the pic-

ture from the built-in tuner (MONITOR button).

When you playback the recorded material, the adequate playback mode for the

selected recording type will apply automatically.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

Select the record mode with the button REC MODE on the remote control.

Selecting the recording type

(Quality)

Tip

Which recording types can I choose?

“M1”: High Quality offers the best picture and sound quality and a recording time

of 1 hour.

“M2”: This mode offers the best quality audio and standard play (close to pre-

recorded DVD) quality video.

“M2x”: Standard Play plus (better than S-VHS quality) offers standard picture qual-

ity and a recording time of 2.5 hours.

“M3”: Long Play (S-VHS picture quality). Recording time of 3 hours.

“M4”: Extended Play (better than VHS picture quality). Recording time of 4 hours.

“M6”: Super Long Play (VHS picture quality). Recording time of 6 hours.

Can I select the recording type via a menu as well?

1Press the SYSTEM-MENU button.

2Select “ ” symbol with t or u.

3Select “Record settings” using v or w and confirm with u.

4In the line “Record mode” select the recording type with t or u.

5Confirm using ENTER/OK and SYSTEM.

6If you have selected the recording mode “M4” or “M6”, you can select the set-

tings “Stndrd” (Standard) or “Sport” (for rapid movements) in the “Filter

mode” line.

47 Managing the disc contents

9. Managing the disc contents

When a recording is made to disc, the following additional information is also stored at

the beginning of the recording:

•) Name of the recording

If the TV station does not transmit a name, only the channel number and time will be

stored as the name

•) Length of the recording

•) Record type (Quality)

•) Date of the recording

•) Index picture of the recording

A marker will be set every 5-6 minutes if the “Auto chapters” function is activated in

the “Record settings” menu. This marker is known as a “chapter”.

These markers can be changed when the recording has finished.

It is also possible to add “chapters” later. This means that scenes you do not want to

see during playback, such as commercials, can be hidden or skipped. During playback

you can watch your recording as a continuous sequence without the hidden chapters.

Select from the following chapters:

In this menu you can adapt a title to suit your particular needs.

You can insert/delete chapter markers, hide chapters, select a new index, or split up a

title.

General

Question

Can markers be set on a DVD+R disc?

Markers can be set on these discs if they have not been finalised.

“EDIT”,

to divide the title into chapters or to manage the chapters.

“Editing recording titles (name)”,

to change the recording names.

“Play complete title”,

to play the entire title including the hidden chapters.

“Delete recording/title” to delete the relevant title and therefore also the record-

ing.

“Disc settings” to change the general settings of the disc.

EDIT

Empty title

01:30:01

Charly 1

00:29:59•M1

Fri15/02/2003

Managing the disc contents 48

English

Insert chapter markers

During playback, you can set or delete chapter markers within a title.

The maximum number of chapters per disc is 124 and 99 per title. If one of these limits

is reached the following message will appear on the screen: “Too many chapters”. You

need to delete some markers before you can insert new ones or make recordings.

1During playback, press EDIT on the remote control at the appropriate point. The

“EDIT” menu appears on the TV screen.

2Press v or w to select “Inserting Chapter marker” and confirm with ENTER/

OK. “Inserting chapter marker” appears on the TV screen.

3To stop this function, press EDIT.

Hiding chapters

Initially, all the chapters are visible. You can hide chapters for playback (e.g. advertise-

ments) or make them visible again. In editing mode, hidden chapters are shown as

dimmed.

1While the relevant chapter is playing, press EDIT on the remote control. The

“EDIT menu” appears on the TV screen.

2Select “Current chapter” using w.

3Using u select “Hidden”. The picture is shown darker.

4To end, press EDIT.

During playback this chapter will be skipped.

If the chapter is not visible, select “Visible” in step 3 with u.

Tip

“X” will appear on the screen:

This DVD is write-protected or the disc is a finalised DVD-R. Subsequent changes

cannot be made.

Tip

How can I select different chapters?

1Press the TITLE/CHAP button on the remote control. Titles and chapters are

displayed at the top of the screen.

2Select title (T) or chapter (C) with u or t.

3Use v or w to select the title/chapter channel you want to edit.

Tip

Switching quickly

You can switch between show chapters (“Visible”) and hide chapters (“Hidden”)

quickly and easily using SELECT.

11

EDIT menu

Insert chapter marker

Current chapter

Delete chapter marker

Delete all markers

New index picture

Divide title

Press OK

Visible

Press EDIT to exit

11

EDIT menu

Insert chapter marker

Current chapter

Delete chapter marker

Delete all markers

New index picture

Divide title

Press OK

Visible

Press EDIT to exit

49 Managing the disc contents

Deleting chapter markers

Within a title you can delete either all markers or individual markers.

1While the relevant chapter is playing, press EDIT on the remote control. The

“EDIT menu” appears on the TV screen.

2Use w to select either “Delete chapter marker” for this chapter or “Delete all

markers” for all chapters within the selected title.

3Confirm with ENTER/OK.

4To end, press EDIT.

Changing the index picture

As an index picture, the first picture of a recording is normally used, however, you can

choose any picture from the recorded material.

1During playback, search for location of the new index picture. Press the

PAUSE button.

2Press the EDIT button. The “EDIT menu” appears on the TV screen.

3Select line “New index picture” and confirm with ENTER/OK.

4Start the change with ENTER/OK. “Updating menu” appears on the TV screen.

Once the revision has been completed successfully the DVD recorder reverts to the

index overview.

Splitting titles

You can split a title into several sections (titles) of any size. Each of these sections

(titles) is identified by its own index.

Note: This split cannot be undone.

1While the relevant title is playing, press EDIT on the remote control. The “EDIT

menu” appears on the TV screen.

2Select “Divide title” and confirm with the ENTER/OK button.

3If you are sure, press ENTER/OK to start the process. “Dividing title” appears

on the TV screen.

4Wait until the new title is displayed with an index picture in the index picture

overview.

The process of splitting the title is now complete.

Tip

How can I select different chapters?

1Press the TITLE/CHAP button on the remote control. Titles and chapters are

displayed at the top of the screen.

2Select title (T) or chapter (C) with u or t.

3Use v or w to select the title/chapter channel you want to edit.

Question

Can I split titles on DVD+R discs?

As recordings on DVD+R discs cannot be overwritten, it is not possible to split

titles.

11

EDIT menu

Insert chapter marker

Current chapter

Delete chapter marker

Delete all markers

New index picture

Divide title

Press OK

Visible

Press EDIT to exit

11

EDIT menu

Insert chapter marker

Current chapter

Delete chapter marker

Delete all markers

New index picture

Divide title

Press OK

Visible

Press EDIT to exit

11

EDIT menu

Insert chapter marker

Current chapter

Delete chapter marker

Delete all markers

New index picture

Divide title

Press OK

Visible

Press EDIT to exit

Managing the disc contents 50

English

Some TV stations transmit the title (name) of a programme. In this case, the name will

be included automatically (e.g. “ROCKY”). Otherwise, the only the programme number

(programme name) and the time are stored as the name of the recording. The name of

the recording can only be changed after the recording has been completed.

1Press the STOP button to stop playback if necessary.

2Using v or w select the title whose name you want to edit and confirm with u.

The menu for editing names appears.

3Select “Name” using v or w and confirm with u.

4Using u or t select the position where the letter/number/icon is to be changed/

re-entered.

5Change the icon using v or w. You can switch between upper and lowercase using

SELECT. You can delete the character using CLEAR.

6Repeat 4 and 5 until you have made the changes you want.

7Save the new name with ENTER/OK. “Storing name” appears on the TV screen

for confirmation.

8To end, press t.

If you have hidden certain sections (chapters) of a title, this setting lets you watch the

entire title including the hidden sections. To do this, proceed as follows:

1Press the STOP button or during playback press TOP MENU.

2Using v or w select the title you want to play entirely and confirm with u. The

title editing menu will appear.

3Select “Play full title” using v or w and confirm with ENTER/OK.

4Playback starts automatically. The full title plays, including the hidden chapters.

You can delete specific recordings from a disc. To do this, proceed as follows:

1Press the STOP button or during playback press TOP MENU.

2Using v or w select the title you want to delete and confirm with u. The title

editing menu will appear.

3Select “Erase this title” using v or w and confirm with ENTER/OK. “This will

completely erase this title” appears on the TV screen.

4If you want to delete this title, press ENTER/OK to confirm. Otherwise press t.

5“Erasing title” may appears on the TV screen.

6At this point “Empty title” may appears in the “index picture display”. A new

recording can now be made here.

If the deleted title was very short (less than 1 minute) “Empty title” will not

appear at this point.

Editing recording titles (name)

Playing the entire title

Deleting recordings/titles

Setting for title Charly 1

Name

Play full title

Erase this title

Charly 1

Setting for title Charly 1

Name

Play full title

Erase this title

Charly 1

Press OK

Setting for title Charly 1

Name

Play full title

Erase this title

Charly 1

Press OK

51 Managing the disc contents

This screen appears before the first title and contains general information about the

current disc.

You can:

•) change the name of the disc

•) activate or deactivate write protection on the disc

•) Finish editing (make the disc DVD compatible)

•) finalise a DVD+R

•) delete a DVD+RW

To get to this display, proceed as follows:

1Press the STOP button or during playback press TOP MENU.

2Select the first title with v or press STOP .

3Press the v button. The disc info display will appear.

Changing the disc name

1In the “Disc info display” press u. The “Settings for” menu appears on the TV

screen.

2Select “Disc name” using v or w and confirm with u.

3Using u or t select the position where the letter/number/icon is to be changed/

re-entered.

4Change the icon using v or w. You can switch between upper and lowercase using

SELECT. You can delete the character using CLEAR.

5Repeat 3 and 4 until you have made the changes you want.

6Save the new title with ENTER/OK. “Storing name” appears on the TV screen

for confirmation.

7To end, press t.

Finishing editing

If one or more titles have been edited a DVD player may still display the original titles.

You can prepare your disc in such a way that a DVD player will be able to play the

edited version.

1In the “Disc info display” press u. The “Settings for” menu appears on the TV

screen.

2Select “Make edits compatible” using v or w and confirm with ENTER/OK.

Question

Can titles be deleted from a DVD+R disc?

Titles on DVD+R discs are only marked as deleted. “Deleted title” will appear in

the display instead of “Empty title”. During playback the “deleted” title is skipped.

The space used for this title cannot be used again as the title has not been physically

deleted. Once the disc has been finalised no further changes can be made.

Disc settings

Yamaha 1

00:35:59 used

Fri15/02/2003

NTSC

DVD playback

Locked

Edit

Settings for Yamaha 1

Disc name

Protection

Erase disc

Make edits compatible

Yamaha1

Unprotected

Managing the disc contents 52

English

3The screen displays “This will take” to show how long the process will last.

4To confirm press ENTER/OK. “Working” appears on the TV screen. A bar will

move from left to right indicating progress.

Finalising DVD+R discs

This feature is required to play back a DVD+R disc in a DVD player. Once the disc has

been finalised no further recordings or changes can be made.

1In the “Disc info display” press u. The “Settings for” menu appears on the TV

screen.

2Select “Finalise disc” using v or w and confirm with ENTER/OK.

3When finalizing is complete, you will return to index picture screen.

Delete DVD+RW discs

1In the “Disc info display” press u. The “Settings for” menu appears on the TV

screen.

2Select “Erase disc” using v or w and confirm with ENTER/OK.

“This will erase all titles” appears on the TV screen. Press ENTER/OK to con-

firm. Otherwise press t.

3“Erasing disc” appears on the TV screen.

4After deletion, the index picture display shows the free space on the disc.

Problem

✘“Make edits compatible” does not appear

✓ Your disc is already compatible. There is no need for conversion.

To end, press SYSTEM-MENU.

Problem

✘“Finalise disc” does not appear

✓ Either there is no DVD+R disc inserted or the disc is already finalized.

To end, press SYSTEM-MENU.

✘The “Settings for” menu does not appear

✓ The menu may not appear if the disc has been recorded on another DVD

recorder. In this case, use the “Finalise disc” feature in the “ ” menu, under

“Disc features”.

Tip

If the disc is empty already, you cannot select “Erase disc”.

Settings for Yamaha 1

Disc name

Protection

Erase disc

Yamaha1

Unprotected

Press OK

53 Programming a recording (TIMER)

10. Programming a recording (TIMER)

Use “Programming a recording (TIMER)”, to automatically start and stop a recording at

a later date.

The DVD recorder will switch to the right programme number and begin recording at

the correct time.

With this DVD recorder, you can pre-programme up to six recordings within a period

of one month.

To make a programmed recording, your DVD recorder needs to know:

* the date you want to make the recording

* the programme number of the TV channel

* the start and stop time of the recording

* the recording mode (“M1/M2/M2x/M3/M4/M6/FR”)

This information is saved in a “TIMER block”.

Before you begin, make sure the clock is set. If the clock is not set, the “Time/Date”

menu will appear when you press the TIMER button.

General

Question

What is “FR mode”?

FR mode is used when you want to record a certain length of program but you

don’t know how much room remaining on the recording disc. By using this mode,

this unit automatically selects the best suitable recording mode for the length of the

program. You cannot select FR mode, when you set the recording timer of Mo-Fr/

Weekly, and when you set PDC/VPS on. We strongly recommend that you do not

use this function combined with VPS/PDC. In such a condition this DVD recorder

may not perform the task properly.

Programming a recording (TIMER) 54

English

Thanks to this programming system, you no longer need to tediously enter the date, TV

channel, start and end times. All the information needed for programming is contained

in the PlusCode programming number. This 8-digit PlusCode number is found in most

TV listings for magazines.

1Switch on the TV. Select the channel number for the DVD Recorder (channel 3 or

4 or the Audio/Video In channel).

2With the Recorder on, press TIMER on the remote control.

The programming method selected last is marked.

3Select line “VCR Plus+ system” using w or v and confirm with u.

4Enter the entire PlusCode number. This number is up to 9 digits long and can be

found next to the start time of the TV program in your TV listings magazine.

e.g.: 5-234-89 or 5 234 89

Enter 523489 for the PlusCode number.

If you make a mistake, you can clear the entry with CLEAR.

5Confirm with ENTER/OK.

6The decoded data appears after confirmation. You can go back and change the

data. Select the appropriate input field with u or t. If required, make changes

using w, v or the number buttons 0..9.

Programming recordings with the

VCR Plus+® System

Tip

Selecting daily/weekly recordings

Using SELECT, select from the following options:

“Mo-Fr”: Repeated daily recordings (Monday to Friday).

“Weekly”: Repeated weekly recordings (every week on the same day).

Problem

✘The following message appears on the screen: “Please enter chan-

nel number”

✓ The channel number of the TV channel has not yet been assigned to the Plus-

Code number. Using u, t or the number buttons 0..9 on the remote control,

select the corresponding channel number (name) of the TV channel and confirm

with ENTER/OK.

✘The following message appears on the screen: “PlusCode number

wrong”

✓ The entered PlusCode number is incorrect. Repeat your entry or cancel using

the SYSTEM-MENU button.

✓ Check the time/date (see “Setting the time & date” in “Installing your DVD

recorder”).

✘The following message appears on the screen: “Date does not

match Mon-Fri”

✓ A daily recording was entered for the wrong day. Daily programming can only be

used for recordings to be made from Monday to Friday.

Timer

Mo-Fr/Weekly

Press SELECT To store

Press OK

VCR Plus+system

PlusCode number

- - - - - - - - -

Timer

To store

Press OK

VCR Plus+system Rec

Date Ch. Start End Mode

01/22 001 08:30AM 10:00PM M1

55 Programming a recording (TIMER)

7If all information is correct, press the ENTER/OK button. The programming

information is stored in a TIMER block.

8To end, press TIMER.

9Insert a recordable disc (one without write protection).

The disc you have inserted will be checked.

0Switch the DVD recorder off with B/I.

The programmed recording will only function properly if the DVD recorder has

been switched off using the B/I button.

If any of the TIMER blocks are in use, “TIMER” will light up on the recorder display.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Press TIMER on the remote control.

The programming method selected last is marked.

3Select line “Timer programming” with w or v. and confirm with the u button.

The information will appear on the screen.

4Select the input field with t or u.

5Enter information with w or v or with the number buttons 0..9.

6If all information is correct, press the ENTER/OK button. The programming

information is stored in a TIMER block.

7To end, press TIMER.

8Insert a DVD (one without write protection).

The disc you have inserted will be checked.

Tip

Change “AM/PM”

Use the SELECT button to select “AM” or “PM” in the input fields “Start” and

“End”.

Changing the recording mode

Select “RecMode” using u.

Using w, select the recording mode “M1, M2, M2x, M3, M4, M6, FR”.

Programming recordings without

the VCR Plus+® System

Tip

Selecting daily/weekly recordings

In “Date” use SELECT to select from the following options:

“Mo-Fr”: Repeated daily recordings from Monday to Friday

“Mo”: Repeated weekly recordings (every week on the same day, e.g. Monday).

Program numbers of the “EXT1” and “EXT2” cinch jack

You can also program recordings from external sources via S-VIDEO IN, Video in

(“EXT1”) or IN COMPONENT VIDEO (“EXT2”).

Change “AM/PM”

Use the SELECT button to select “AM” or “PM” in the input fields “Start” and

“End”.

Changing the recording quality

Select the “RecMode” input field using u.

Use w, v to select the recording mode.

Timer

Mo-Fr/Weekly

Press SELECT To store

Press OK

Timer programming Rec

Date Ch. Start End Mode

01/22 01 08:30AM 10:00PM M1

Programming a recording (TIMER) 56

English

9Switch off with B/I.

The programmed recording will only function properly if the DVD recorder has

been switched off using the B/I button.

If any of the TIMER blocks are in use, “TIMER” will light up on the recorder display.

1Switch on the TV set. If required, select the programme number for the DVD

recorder (channel 3 or 4).

2Press TIMER on the remote control.

The programming mode selected last is marked.

3Select “Timer List” using w or v and confirm with u.

4Select the programmed recording (TIMER) you want to check, change or delete

with w or v.

5Press u.

Select the input field with t or u.

If required, change the information with v, w or the number buttons 0..9.

6Confirm with ENTER/OK.

7To end, press TIMER.

8Switch off with B/I.

How to change or delete a

programmed recording (TIMER)

Tip

Delete programmed recording

1Press the CLEAR button.

2Confirm with ENTER/OK. “Timer Cleared” will briefly appear on the TV

screen.

“-- ---” appears rather than the displayed values

3To end, press TIMER.

Timer

To change

Press > To exit

Press TIMER

Timer List

Total record time: 01:40

Rec

Date Ch. Start End Mode

01/22 01 04:25PM 06:05PM M2

--/-- ----- --:-- --:-- ---

57 Programming a recording (TIMER)

Problem solving for programmed

recordings

PROBLEM SOLUTION

The DVD recorder is not responding ✓While a programmed recording is being made, you cannot operate your DVD

recorder manually. If you want to cancel the programmed recording, press B/I.

“Switch off, timer recording” flashes on the

TV screen.

✓The DVD recorder was switched on several minutes before the start of a pro-

grammed recording. Switch off the DVD recorder using B/I. A programmed

recording (timer) will only function if the DVD recorder is switched off (B/I but-

ton).

Error message: “Insert recordable disc”✓Either a disc has not been inserted or the disc cannot be used for recording. Insert

a disc on which recordings can be made. Switch off the DVD recorder using B/I.

The error message “Disc locked” appears

briefly on the screen.

✓A write-protected disc has been inserted. Undo the write protection (see “Pre-

venting accidental erasing of discs” in “Manual recording”) or insert a different disc.

Error message:

“Memory full”

✓If this error message appears after pressing TIMER, then all TIMER blocks are

already programmed. No more recordings can be programmed. Press the u button.

If you want to clear or check a programmed recording (TIMER block), select it with

v or w.

The “Data error” message appears on the

screen.

✓The data for the recording could not be transferred. Please check date, start time

and end time of the programmed recording.

The “Collision” message appears on the

screen.

✓Two programmed recordings overlap.

✓If you ignore this error message the show with the earlier start time will be

recorded first. The start of the second show will not be recorded.

✓Change the setting for either of the two recordings.

✓Clear either of the two recordings

User preferences 58

English

11. User preferences

In this section you will learn how to set your user preferences on the DVD recorder.

The symbols have the following meanings:

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Press SYSTEM-MENU on the remote control. The menu bar appears.

3Select “ ” using t or u and confirm with w.

4Select the appropriate function with w or v and confirm with u.

5Select the appropriate line using w or v and confirm with u.

6Select the appropriate function using w or v or the setting with t or u.

7Confirm the new setting by pressing ENTER/OK.

8To close the menu item, press t.

You can choose the following features in this menu:

“TV Shape”

The picture signal from your DVD Recorder can be set to match your TV screen.

“4:3 letterbox”: for a “wide-screen” picture with black bars at the top and bottom

“4:3 panscan”: for a full-height picture with the sides trimmed.

“16:9” : for a wide-screen TV set (screen edge ratio 16:9)

“Black level shift”

Adapts the colour dynamics for NTSC playback

“Video shift”

Use this feature to adjust the position of the picture on your TV left or right using t, u

to suit your TV set.

“EXT1 video attenuation”

Adjusts the brightness level for recording when connected with YPbPr.

“Optimize video output”

This allows you to switch the Component Video signal between “Interlaced” and “Pro-

gressive Scan”.

Warning: If your TV has separate connections for “Interlaced” and “Progressive

Scan” or it does not switch automatically between the two, it is possible that no pic-

ture will appear on the TV after it is switched from one to the other.

Picture settings

Sound settings

Language settings

Additional settings

Disc settings

Recording settings

Installation

Picture settings

n

TV Shape 16:9

Black level shift Off

Video shift

EXT1 video attenuation

Optimize video output Interlaced

Picutre

59 User preferences

Depending on which audio outputs are used, you can select the settings in this menu.

If you only use the analogue audio output (AUDIO L, R), select the settings “Off” in

the “Digital output” menu.

“Digital output”

For devices connected to the DIGITAL AUDIO OUT jack, you can select from the

following settings.

“All”: Unalterned signals of Dolby Digital and DTS are fed to the digital out-

put. MPEG-2 multi-channel signals are converted to PCM (Pulse Code

Modulation).

For receivers/amplifiers with digital multi-channel sound decod-

ers.

“PCM only”: Dolby Digital and MPEG-2 multi-channel signals are converted to PCM

(Pulse Code Modulation).

For receivers/amplifiers without digital multi-channel sound

decoders.

“Off”: Digital output switched off.

For devices with analogue audio input.

“Analog output”

For devices connected to the analogue audio output (AUDIO L, R), you can select

from the following settings.

“Stereo”:For devices without DolbySurround, use this setting if the DVD

recorder is only connected to a stereo TV set.

“Surround”: Dolby Digital and MPEG-2 multi-channel are mixed down to a Dolby

surround-compatible two-channel output signal. For devices with

Dolby Surround Pro Logic decoder.

“Night mode”

Night mode optimises the sound for playback at low volume. You are therefore less

likely to disturb your neighbours. This only works for Dolby Digital audio on DVD

video discs.

Problem

✘No picture appears on the TV after switching

Check the display of your DVD recorder.

“PRO”: “Progressive Scan” is on

No display: “Interlaced” is on. Switch your TV to the corresponding input jack

or select the corresponding connection. You can also switch the Component

video output signal as follows:

1Disconnect the recorder’s power cord.

2Hold down t on the DVD Recorder while reconnecting the power cord.

“PRO” (progressive scan) appears on the display.

3If you want to switch back, repeat steps 1 and 2. “PRO” disappears from the dis-

play. The DVD Recorder is switched to “Interlaced.”

Sound settings

n

Digital output All

Analog output Stereo

Night mode Off

Sound

User preferences 60

English

You can choose the following settings in this menu:

“Playback audio”

Playback audio language

“Recording audio”

A choice between Stereo and SAP

“Subtitle”

Subtitle language

“Menu”

Screen menu language

You can select the following functions in this menu:

“Status box”

Along with the on screen menu, the OSD (On Screen Display) also displays information

on the current operating status (counter, playback, recording, TV channel, etc.) on the

TV screen.

You can switch off the information about the operating status so that the on screen dis-

play (OSD) is not recorded during copying.

“On”: The OSD information appears in every selected mode for a few sec-

onds and disappears again.

“Off”: The OSD information is switched off. It is no longer displayed on the

screen.

“Standby”

To save power, you can switch off the clock display on the DVD recorder. Programmed

(TIMER) recordings will still take place.

In addition, you can present the most important features of the DVD recorder in scroll-

ing text in the display (demo).

“Low power”: If the DVD-Recorder is switched off (button B/I), the clock display is

also switched off.

“Normal”:If the DVD-Recorder is switched off (button B/I), the clock display is

visible.

“Demo mode”: If the DVD recorder is switched off with the B/I button, a list of the

most important features is shown in the display.

“Display”

You can change the brightness of the display on the DVD recorder. This setting only

affects the DVD recorder when it is switched on.

“Bright”: The display appear with normal brightness.

“Dimmed”: The display appears less bright.

“Off”: The display is switched off.

Language settings

Additional settings

n

Playback audio English

Recording audio Stereo

Subtitle English

Menu English

Language

n

Status box On

Standby Normal

Display Bright

Features

61 User preferences

In this menu you can make the changes that relate to the disc:

“Access control”

Please read the next chapter on “Access control (child lock)”.

“Auto resume”

If playback of a pre-recorded DVD video disc or video CD is interrupted (button

STOP or F Open/Close) when the disc is reloaded (disc is started) playback

starts at the precise location where it stopped. This applies not only to the current disc

but to the last 20 discs played.

This feature can be switched off if not required.

“PBC”

This line appears only if a VCD is loaded.

This function lets you activate or deactivate the PBC menu (Playback Control) for video

CDs.

See “Playing a (Super) Video CD”.

“Finalise disc”

This feature allows you to finalise DVD+R discs. If the disc has already been finalised

this line will appear darker.

“Adapt disc format”

If a DVD+RW has been recorded in a computer drive or in another DVD recorder the

index screen may not be displayed correctly.

This feature allows you to change the format of the disc.

It is therefore only visible if the disc format is different.

Disc feature menu

n

Access cntrol Enter code...

Auto resume On

Disc features

Access control (Child Lock) 62

English

12. Access control (Child Lock)

This feature enables discs to be locked for children.

When Child Lock is on, a 4-digit code (PIN) needs to be entered before a disc can be

played.

You can also decide whether the inserted disc should always be played or should be

played only once, despite the child lock

•) “Play always”:

This disc is stored in a memory with space for 50 child-safe discs. If more than 50 discs

are stored, the last disc in the list is removed and the new disc is added. The screen

shows “Child safe” at the start of playback.

•) “Play once”:

This disc is only authorised for single playback. If the recorder is switched off, the PIN

code must be re-entered.

Activating/deactivating child lock

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU. The menu bar appears.

4Select the “ ” icon using t or u.

5Select “ (Disc features)” using w or v and confirm with u.

6Confirm “Access control” using u.

7Enter a 4-digit code of your choice. If the code is new, you may have to enter the

code a second time as confirmation.

8Select “Child lock” using v or w and confirm with u.

9Select the “Ç” icon using w or v.

0Confirm with ENTER/OK.

AQuit the feature using t and SYSTEM-MENU.

Unauthorised discs can only be played by entering the four-digit PIN code.

To deactivate the child lock, select the “É” icon in 9.

Authorising a disc

1Insert a disc. The access control box will appear after a short delay.

2Using v or w select “Play once” or “Play always”.

3Enter your PIN code using the number buttons 0..9.

Double-sided DVDs may have a different ID for each side. For these discs, each side

must be authorised. Multi-volume video CDs may have a different ID for each volume.

For these CDs, each volume must be authorised.

Child lock (DVD and VCD)

63 Access control (Child Lock)

Locking unlocked discs

To lock a disc that was formerly authorised follow the instructions below.

1Insert a disc. Playback starts automatically. If the playback does not start automat-

ically, press PLAY .

2Press the STOP button while the “ ” icon is visible. The icon changes to

“”. The disc is now locked.

Films on pre-recorded DVD discs may contain scenes not suitable for children. There-

fore, some discs may contain “Parental Control” rating information that applies to the

entire disc or to certain scenes on the disc.

The appropriate scenes have filter values that reach from 1-8. If such a scene is

detected during playback, the filter value set on the DVD recorder is compared to the

scene. If the filter value is higher than the setting, an alternative scene will be played (if

available).

Most DVDs apply the rating to an entire DVD. Therefore, if certain scenes exceed the

rating you select, the entire disc will be blocked from viewing.

Activating/deactivating parental level control

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU. The menu bar appears.

4Select the “ ” icon using t or u.

5Select “ (Disc features)” using w or v and confirm with u.

6Confirm “Access control” using u.

7Enter a 4-digit code of your choice. If the code is new, you may have to enter the

code a second time as confirmation.

8Select the “Parental level” using v or w and confirm with u. A bar appears to

select the parental level.

9Select the appropriate rating using w, v or the number buttons 0..9.

0Confirm with ENTER/OK. Quit using t and SYSTEM-MENU.

Parental level control (DVD video

only)

Tip

What do the ratings mean?

Rating 0 (displayed as “--”) parental control not active.

Rating 1 (suitable for children)

Rating 8 (only suitable for adults)

What happens if a DVD scene contains a higher level than the rating set?

If the recorder does not find a suitable alternative, playback will stop and you must

enter the four-digit code.

n

Access control Enter code . . .

Auto resume On

Disc features

Access control (Child Lock) 64

English

Changing the country

The set filter values depend on the respective country. It is therefore necessary to

enter the country to which these filter values apply.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU. The menu bar appears

4Select the “ ” icon using t or u.

5Select line “ (Disc features)” using w or v and confirm with u.

6Confirm the line “Access control” using u.

7Enter your four-digit code. If the code is new, you may have to enter the code a

second time as confirmation.

8Select “Change country” using w or v and confirm with u.

9Select the corresponding country using v or w and confirm with ENTER/OK.

0To end, press t and then SYSTEM-MENU.

1Switch on the TV set. If required, select the programme number for the DVD

recorder.

2Switch on the DVD recorder using B/I.

3Press SYSTEM-MENU. The menu bar appears

4Select the “ ” icon using t or u.

5Select “ (Disc features)” using w or v and confirm with u.

6Confirm “Access control” using u.

7Enter your four-digit PIN code. If the code is new, you may have to enter the code

a second time as confirmation.

8Select “Change code” using v or w and confirm with u.

9Enter the new code using the number buttons 0..9. Enter the same code again as

confirmation.

0Quit using t and SYSTEM-MENU.

Changing the PIN code

Tip

I have forgotten my code

Press STOP four times (step 7), then press ENTER/OK. Access control is

now switched off. You can now enter a new code as described above.

n

Access control Enter code . . .

Auto resume On

Disc features

n

Access control Enter code . . .

Auto resume On

Disc features

65 Before you call an engineer

13. Before you call an engineer

If you have any problems using this DVD recorder, the reason may be one of the follow-

ing. You can also call the customer service centre in your country.

If the problem is not listed below, or if the instructions fail to help, turn off the power

to the unit, disconnect the power cable, and contact the nearest authorized YAMAHA

dealer or service center.

PROBLEM SOLUTION

Your recorder does not respond to any

button being pressed and the display shows

“IS TV ON?”:

✓Recorder in initial installation mode: Switch on the TV, switch over to the DVD

recorder jack. Now the menu for language selection should appear. Please read

paragraph “Initial Installation” in the chapter “Installing your DVD Recorder”.

The device does not react when you press a

button, although the remote control

works:

✓“Dealer-Mode” is switched on: All buttons on the front of the set are locked.

Switch off the function:

1Pull out the mains plug from the wall outlet.

2Press and hold down A and F (Open/Close) and put back the mains plug into

the wall outlet.

3As soon as the time or “--:--” appears in the display (ca. 6 - 10 seconds), release

A and F (Open/Close).

Your DVD recorder does not respond to

any button being pressed:

✓There is no power supply: check the power supply

✓A programmed recording (Timer) is currently being made: If desired, cancel the

programmed recording (Timer) with B/I.

✓There is a technical problem: disconnect from the mains power supply for 30 sec-

onds, then connect again.

If this doesn’t help, you can reset your DVD recorder to the default factory set-

tings.

Resetting the machine to the default

factory settings:

✓Important:

All the information stored (TV channels, time and date, TIMER) will be lost.

1Disconnect from the mains power supply.

2Press and hold down the B/I button on the device and reconnect to the mains

power supply.

3Release the B/I button when “IS TV ON?” appears on the display. All the infor-

mation stored (TV channels, time and date, TIMER) will be lost.

Please read paragraph “Initial Installation” in the chapter “Installing your DVD

Recorder”.

Remote control does not work: ✓Remote control not pointed toward the DVD recorder: Point the remote control

at the machine.

See if the “o(((” appears on the display briefly each time you press a remote control

button. If it does, the Recorder is receiving information from the remote correctly.

✓There is a technical problem: Take out the batteries, wait for 10 seconds and put

them in again.

✓Batteries are flat: Change the batteries.

No playback on DVD recorder: ✓There is no recording on the disc: Change disc.

✓You inserted the wrong disc type: Your recorder can play back the following disc

types: DVD Video, (Super) Video CD, DVD+R(W), Audio CD, MP3-CD’s

✓You inserted the disc the wrong way: Insert the disc with the label facing upwards

✓Disc is dirty: Clean the disc

✓Wrong region code: The region code of the DVD and the DVD recorder must

match.

✓Parental control is on: Read chapter “Access control (child lock)”

✓You have selected the wrong programme number for the DVD recorder on the TV:

on the TV, select the correct programme number for the DVD recorder.

✓The cable connecting the TV set and the DVD recorder has come loose: check the

cable.

Before you call an engineer 66

English

I cannot playback (Super) Video CDs ✓It is possible that this (Super) Video CD contains a menu and the “PBC” is switched

off. You can see this in status field “PBC OFF”. To activate this function, proceed as

follows:

1Press SYSTEM-MENU while the (Super) Video-CD is inserted.

2Select “ ” using t or u.

3Select line “Features” using w or v and confirm with u.

4Select “On” in line “PBC” using w or v.

5Confirm with ENTER/OK and end with SYSTEM-MENU.

Poor playback on DVD recorder: (distorted

picture/distorted sound)

✓Your TV set is not properly adjusted.

✓Disc is dirty: Clean the disc

✓Sometimes the picture may be temporarily distorted. This is not a defect of your

DVD recorder.

No recording possible: ✓The TV channel you want to record is not stored or you selected the wrong pro-

gramme number:

Check TV channels stored.

✓Disc write-protected (recording protected): Remove write-protection or change

the disc. For more information, please see “Preventing accidental erasing of discs”

in chapter “Manual Recording”.

✓An already finalised DVD+R has been inserted: Change disc.

Programmed recording does not work: ✓You have programmed the wrong time or date: Check time/date.

✓You have not set the TIMER properly: Check the programmed recordings (TIMER

block).

✓Locked disc inserted: Remove disc lock.

✓An already finalised DVD+R has been inserted: Change disc.

The wrong TV channel was decoded

(entered) after you programmed a

recording using VCR Plus+ System.

1Enter the VCR Plus+ programming number of the TV channel you want.

2Confirm with ENTER/OK.

3Check the programme number/channel name in the “Prog.” input field.

4If this does not correspond to the desired TV channel, select the input field and

change the programme number/channel name.

5Confirm with ENTER/OK.

There is picture or sound interference on

TV reception:

✓Have your aerial checked.

✓You will find information on how to change the TV system in “Manual TV channel

search” in “Installing your DVD recorder”.

Distorted sound coming from a connected

hi-fi amplifier

✓The DVD recorder is connected to the “Phono-input” of your amplifier: This jack is

provided only for record players without a preamplifier. Select a different audio

input.

The picture is distorted or black-and-white

during playback

✓The TV system of the disc does not match that of your TV set (PAL/NTSC).

✓The recording can be made in colour only when the TV channels or the connected

additional device send a colour signal. Black-and-white signals containing no color

information (colour subcarriers) cannot be recorded.

No sound signal at the digital output ✓Check whether the sound settings match the selected inputs and connected addi-

tional devices.

PROBLEM SOLUTION

67 Before you call an engineer

A DVD+RW disc cannot be played on

certain DVD players

✓If a recording is too short, it is possible that a DVD player cannot detect it: Please

observe the following “Minimum recording times”:

Recording mode “M1”: 5 minutes, “M2”: 10 minutes, “M2x”: 13 minutes, “M3”: 15

minutes, “M4”: 20 minutes, “M6”: 30 minutes

✓Some DVD players cannot play back DVD+RW recordings. You can solve this prob-

lem by using a special function:

1Open the disc tray with F (Open/Close). Insert the disc but do not close the

tray.

2Hold down the number button 2 on the remote control until the tray closes.

The disc is modified.

3If this fails to produce the desired result, repeat the procedure using the number

button 3 on the remote control.

4You can restore the disc to its original condition by pressing 1.

Warning!

There is a risk that you can no longer play the disc on other DVD players after this

procedure.

Therefore, apply this function with particular care.

Other disc errors ✓If it is impossible to play back a disc, you can try and repair it for new recordings

using the following function. This will only prepare the disc for erasing. It will not be

erased, however, until the recording has been completed.

1Clean the disc

2Open the disc tray with F (Open/Close). Insert the disc but do not close the

tray.

3Hold down CLEAR on the remote control until the tray closes. The disc is pre-

pared for erasing.

4Start recording as with an empty disc.

PROBLEM SOLUTION

Appendix 68

English

Appendix

Your DVD recorder remote control can transmit several commands to TV sets of dif-

ferent brands.

The following keys will operate the TV set:

- VOL + increase TV volume

- VOL - decrease TV volume

- MUTE mute TV

Some other keys normally operate the DVD recorder, but will operate the TV set when

you keep TV SHIFT pressed:

- CH + next TV programme number

- CH - previous TV programme number

- 0..9 choose TV channel

- B/I switch TV set to standby

If your TV set does not respond to the remote control, you can re-programme your

remote control. Below you will find a list of all available remote control codes for vari-

ous TV brands. The following procedure re-programmes your remote control:

1Look up the set-up code for your TV set in the code list in the following page.

2Press and hold the t and u simultaneously for at least 3 seconds.

3Release both keys.

4Enter, within 30 seconds, the correct four-digit code with the digit keys 0..9.

5If the selected code does not work with your TV set, or if the brand of your TV

set is not in the list, try out the codes one after the other.

Using DRX-2 remote control for

your TV set

69 Appendix

Remote control set-up

codes for television

Abex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1066

Admiral . . . . . . . . . . . . . . . . . 1013, 1028, 1075

Aiko . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1012

Akai . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1005

Alaron . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1022

American Action . . . . . . . . . . . . . . . . . . . . 1023

Anam . . . . . . . . . . . . . . . . . . . . . . . . 1023, 1079

AOC . . . . . . . . . . . . . . . . . . . 1003, 1005, 1048

Audiovox . . . . . . . . . . . 1012, 1023, 1027, 1029

Baysonic . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Belcor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1003

Bell & Howell. . . . . . . . . . . . . . . . . . 1016, 1075

Bradford. . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Brocksonic. . . . . . . . . . . . . . . . . . . . 1024, 1028

Brockwood . . . . . . . . . . . . . . . . . . . . . . . . 1003

Candle . . . . . . . . . . . . . . . . . . . . . . . 1005, 1009

Carnivale . . . . . . . . . . . . . . . . . . . . . . . . . . 1005

Carver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Celebrity . . . . . . . . . . . . . . . . . . . . . . . . . . 1001

Cineral . . . . . . . . . . . . . . . . . . . . . . . 1012, 1027

Citizen . . . . . . . .1005, 1009, 1010, 1012, 1044,

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1046, 1064

Concerto . . . . . . . . . . . . . . . . . . . . . . . . . . 1009

Contec. . . . . . . . . . . . . . . . . . 1023, 1063, 1065

Craig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Crosley. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Crown . . . . . . . . . . . . . . . . . . . . . . . 1023, 1064

Curtis Mathes . . . . . . 1000, 1005, 1006, 1007,

. . . . . . . . . . . . . .1009, 1010, 1013, 1014, 1016,

. . . . . . . . . 1019, 1027, 1034, 1036, 1046, 1064

CXC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Daewoo . . . . . . . . . . . .1003, 1012, 1027, 1029,

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1030, 1064

Daytron . . . . . . . . . . . . . . . . . . . . . . 1003, 1064

Denon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1014

Dumont . . . . . . . . . . . . . . . . . . . . . . 1002, 1003

Electroband . . . . . . . . . . . . . . . . . . . . . . . . 1001

Electrohome . . . . . . . . . . . . . . . . . . . . . . . 1079

Emerson. . . . . . 1003, 1016, 1021, 1022, 1023,

. . . . . . . . .1024, 1026, 1028, 1029, 1030, 1044,

. . . . . . . . . 1045, 1063, 1064, 1067, 1068, 1069

Envision . . . . . . . . . . . . . . . . . . . . . . . . . . . 1005

Fisher . . . . . . . . . . . . . . . . . . . 1016, 1055, 1056

Fujitsu. . . . . . . . . . . . . . . . . . . . . . . . 1022, 1032

Funai. . . . . . . . . . . . . . . . . . . . 1020, 1022, 1023

Futuretech . . . . . . . . . . . . . . . . . . . . . . . . . 1023

GE . . . . . . . . . . .1004, 1006, 1007, 1013, 1021,

. . . . . . . . . . . . . .1026, 1027, 1034, 1036, 1047,

. . . . . . . . . . . . . . . . . . . 1060, 1061, 1062, 1079

Gibralter . . . . . . . . . . . 1002, 1003, 1005, 1063

Goldstar. . . . . . . . . . . .1003, 1005, 1009, 1021,

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1064, 1066

Gradiente. . . . . . . . . . . . . . . . . . . . . 1008, 1009

Grundy. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1064

Grunpy. . . . . . . . . . . . . . . . . . . . . . . 1022, 1023

Hallmark . . . . . . . . . . . . . . . . . . . . . . . . . . 1021

Hardvard . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Harley Davison . . . . . . . . . . . . . . . . . . . . . 1022

Harman Kardon. . . . . . . . . . . . . . . . . . . . . 1000

Hitachi . . . . . . . . . . . . . 1009, 1014, 1063, 1065

Infinity . . . . . . . . . . . . . . . . . . . . . . . 1000, 1077

Inteq . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1002

JBL . . . . . . . . . . . . . . . . . . . . . . . . . . 1000, 1077

JCB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1001

JVC . . . . . . . . . . . . . . . 1008, 1060, 1063, 1065

JVC RMC383. . . . . . . . . . . . . . . . . . . . . . . 1043

KEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Kenwood . . . . . . . . . . . . . . . . . . . . . 1003, 1005

Kloss . . . . . . . . . . . . . . . . . . . 1057, 1058, 1059

KTV . . . . . . . . . . . . . . . 1005, 1023, 1044, 1064

LG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1009

Loewe . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1077

Luxman . . . . . . . . . . . . . . . . . . . . . . . . . . . 1009

LXI. . . . . . 1000, 1006, 1016, 1017, 1021, 1077

Magnavox. . . . . . . . . . . 1000, 1005, 1022, 1049,

. . . . . . . . . . . . . . 1050, 1057, 1058, 1059, 1077

Marantz . . . . . . . . . . . . . . . . . 1000, 1005, 1077

Matsushita . . . . . . . . . . . . . . . . . . . . . . . . . 1025

Megatron. . . . . . . . . . . . . . . . . . . . . 1014, 1021

Memorex. . . . . . . . . . . 1009, 1015, 1016, 1021,

. . . . . . . . . . . . . . . . . . . . . . . . 1025, 1028, 1075

MGA . . . . . . . . . 1003, 1005, 1015, 1021, 1056

Midland . . 1002, 1006, 1007, 1060, 1064, 1066

Minutz . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1004

Mitsubishi . . . . . 1003, 1013, 1015, 1021, 1056

Motorola . . . . . . . . . . . . . . . . . . . . . 1013, 1079

MTC . . . . . . . . . 1003, 1005, 1009, 1010, 1046

Multitech . . . . . . . . . . . . . . . . . . . . . 1019, 1023

NAD . . . . . . . . . . . . . . . . . . . . . . . . 1017, 1021

NEC. . . . . . . . . . . . . . . 1003, 1005, 1009, 1079

Nikko. . . . . . . . . . . . . . . . . . . 1005, 1012, 1021

NTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1012

Onwa. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Optimus. . . . . . . . . . . . . . . . . 1016, 1019, 1025

Optonica . . . . . . . . . . . . . . . . . . . . . 1013, 1018

Orion. . . . . . . . . . . . . . . . . . . 1022, 1024, 1028

Panasonic. . . . . . 1007, 1025, 1060, 1077, 1079

Penney . . . . . . . 1003, 1004, 1005, 1006, 1007,

. . . . . . . . . . . . . . 1009, 1010, 1017, 1021, 1036,

. . . . . . . . . 1046, 1060, 1063, 1064, 1066, 1076

Philco. . . . 1000, 1003, 1005, 1014, 1028, 1049,

. . . . . . . . . 1057, 1058, 1059, 1059, 1077, 1079

Philips . . . . . . . . . . . . . 1000, 1049, 1050, 1057,

. . . . . . . . . . . . . . 1058, 1063, 1073, 1077, 1079

Pilot . . . . . . . . . . . . . . . . . . . . 1003, 1005, 1064

Pioneer . . . . . . . . . . . . . . . . . . . . . . 1019, 1031

Price Club . . . . . . . . . . . . . . . . . . . . . . . . . 1046

Portland. . . . . . . . . . . . . . . . . 1003, 1012, 1064

Prism . . . . . . . . . . . . . . . . . . . . . . . . 1007, 1060

Proscan . . . . . . . . . . . . . . . . . . . . . . . . . . . 1006

Proton . . . . . . . . . . . . . . . . . . . . . . . 1021, 1063

Pulsar. . . . . . . . . . . . . . . . . . . . . . . . 1002, 1003

Quasar. . . . . . . . 1007, 1018, 1025, 1060, 1079

Radio Shack. . . . . . . . . 1003, 1005, 1006, 1009,

. . . . . . . . . . . . . . 1016, 1018, 1021, 1023, 1063,

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1064, 1066

RCA. . . . . . . . . . 1003, 1006, 1007, 1011, 1013,

. . . . . . . . . . . . . . 1033, 1034, 1035, 1036, 1037,

. . . . . . . . . 1038, 1048, 1052, 1071, 1072, 1079

Realistic . . . . . . . . . . . . 1003, 1005, 1009, 1016,

. . . . . . . . . . . . . . 1018, 1021, 1023, 1063, 1064

Runco . . . . . . . . . . . . . . . . . . . . . . . .1002, 1005

Sampo . . . . . . . . . . . . . . . . . . .1005, 1064, 1066

Samsung . . . . . . 1003, 1005, 1009, 1010, 1021,

. . . . . . . . . . . . . 1046, 1063, 1064, 1066, 1078

Samsunx . . . . . . . . . . . . . . . . . . . . . . . . . . .1064

Sansei . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1027

Sansui . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1028

Sanyo. . . . . . . . . . . . . . . . . . . . . . . . .1016, 1055

Scimitsu. . . . . . . . . . . . . . . . . . . . . . . . . . . .1003

Scotch . . . . . . . . . . . . . . . . . . . . . . . .1021, 1063

Scott . . . . . . . . . 1003, 1021, 1022, 1023, 1024

Sears . . . . 1000, 1006, 1009, 1016, 1017, 1020,

. . . . . . . . 1021, 1022, 1053, 1055, 1056, 1065

Semivox. . . . . . . . . . . . . . . . . . . . . . . . . . . .1023

Semp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1017

Sharp . . . . 1013, 1018, 1031, 1051, 1063, 1064

Shogun. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1003

Signature . . . . . . . . . . . . . . . . . . . . . . . . . . .1075

Sony. . . . . . . . . . . . . . . . . . . . . . . . . .1001, 1042

Sounddesign . . . . . . . . . . . . . .1021, 1022, 1023

Squareview . . . . . . . . . . . . . . . . . . . . . . . . .1020

SSS. . . . . . . . . . . . . . . . . . . . . . . . . . .1003, 1023

Starlite. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1023

Supreme . . . . . . . . . . . . . . . . . . . . . . . . . . .1001

Sylvania . . . . . . . 1000, 1005, 1049, 1050, 1054,

. . . . . . . . . . . . . . . . . . . . . . . .1058, 1059, 1077

Symphonic. . . . . . . . . . . . . . . . . . . . . . . . . .1020

Tandy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1013

Tatung . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1079

Technics. . . . . . . . . . . . .1007, 1025, 1060, 1063

Technol Ace. . . . . . . . . . . . . . . . . . . . . . . . .1022

Techwood . . . . . . . . . . . . . . . .1007, 1009, 1060

Teknika . . . . . . . 1000, 1003, 1009, 1010, 1012,

. . . . . . . . 1015, 1022, 1023, 1046, 1064, 1065

Telecaption . . . . . . . . . . . . . . . . . . . . . . . . .1074

Telefunken. . . . . . . . . . . . . . . . . . . . . . . . . .1009

Thomson. . . . . . . . . . . . . . . . . . . . . . . . . . .1039

TMK . . . . . . . . . . . . . . . . . . . . . . . . .1009, 1021

Toshiba . . . . . . . 1010, 1016, 1017, 1040, 1041,

. . . . . . . . . . . . . . . . . . .1046, 1054, 1070, 1074

Totevision . . . . . . . . . . . . . . . . . . . . . . . . . .1064

Vector Research . . . . . . . . . . . . . . . . . . . . .1005

Victor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1008

Vidikron . . . . . . . . . . . . . . . . . . . . . . . . . . .1000

Vidtech . . . . . . . . . . . . . . . . . . . . . . .1003, 1021

Wards . . . . . . . 1000, 1003, 1004, 1005, 1009,

. . . . . . . . 1018, 1021, 1022, 1049, 1050, 1054,

. . . . . . . . . . . . . . . . . . .1057, 1058, 1075, 1077

White_Westinhouse. . . . . . . .1029, 1028, 1030

Yamaha . . . . . . . . . . . . . . . . . . . . . . .1003, 1005

Zenith . . . . . . . . . . . . . . . . . . .1002, 1012, 1028

Appendix 70

English

Disc Formats Supported

Disc type Playback Recording

DVD+RW • •

DVD+R • •

DVD-RW (Video mode) • –

DVD-R • –

DVD-Video • –

Super Video CD • –

Video CD • –

Audio CD • –

CD-R • –

CD-RW • –

Recordable Disc Formats

Medium

DVD+RW: Phase-Change ReWritable

DVD+R: dye-based

Diameter 12 cm

Capacity (single side) 4.7 Gbyte

Recording time M1 60’9.72 Mbit/s

M2 120’5.07 Mbit/s

M2x 150’4.06 Mbit/s

M3 180’3.38 Mbit/s

M4 240’2.54 Mbit/s

M6 360’1.69 Mbit/s

TV Standard PAL NTSC

Scan Frequency 50Hz 60Hz

Number of lines 625 525

Playback • •

Recording • •

Internal tuner • –

Video RESOLUTION 50Hz 60Hz

DVD-Video/DVD+RW/DVD+R (M1/M2/M2x)

-Horiz. Resolution 720 pixels1 720 pixels1

-Vertical Resolution 576 lines 480 lines

DVD+RW/DVD+R (M3/M4/M6)

-Horiz. Resolution 360 pixels2 360 pixels2

-Vertical Resolution 576 lines 480 lines

VCD

-Horiz. Resolution 352 pixels 352 pixels

-Vertical Resolution 288 lines 288 lines

1 equivalent to 500 lines on your TV

2 equivalent to 250 lines on your TV

Video Performance

DA Converter 10-bit

AD Converter 9-bit

Signal handling Components

Video Output 1 Vpp into 75 Ohm

S-video Output Y: 1 Vpp into 75 Ohm

C: 0.286 Vpp into 75 Ohm

Component Output Y: 1 Vpp into 75 Ohm

Pb: 0.7 Vpp into 75 Ohm

Pr: 0.7 Vpp into 75 Ohm

Audio format

Compressed Digital Playback Recording

-Dolby Digital Multi-channel 2-channel

(AC-3) 16-bit, fs 48 kHz

-DTS Multi-channel –

-MPEG1 2-channel –

SPdif

-PCM 2-channel 2-channel

16, 20, 24 bit 16-bit, fs 48 kHz

fs 48 kHz

Audio Performance

DA Converter 24-bit

AD Converter 16-bit

DVD fs 96 kHz 4 Hz - 44 kHz

fs 48 kHz 4 Hz - 22 kHz

Video CD fs 44.1 kHz 4 Hz - 20 kHz

Audio CD fs 44.1 kHz 4 Hz - 20 kHz

Front Connections

i.LINK DV IEEE 1394 4-pin

S-video Input Hosiden 4-pin

Video Input Cinch (yellow)

Audio Left/Right Input Cinch (white/red)

Rear Connections

Component Video In Cinch (green/blue/red)

Component Video Out Cinch (green/blue/red)

S-video In Hosiden 4-pin

S-video Out Hosiden 4-pin

Video In Cinch (yellow)

Video Out Cinch (yellow)

Audio L/R In Cinch (white/red)

Audio L/R Out Cinch (white/red)

Digital Audio Out 1 coaxial, 1 optical

IEC958 for CDDA / LPCM

IEC1937 for MPEG2, Dolby Digital

RF Antenna In Coaxial 75 ohms

RF TV Out Coaxial 75 ohms

Power Standard (IEC type)

Power Supply

Power Inlet 120 V, 60 Hz

Power consumption Operation 27 W

Low-power Standby 3 W

Cabinet

Dimensions (w x h x d) 435 x 82 x 347 mm

Net Weight 4.0 kg

Operating environment

Operating position

maximum 10 degree inclination in all directions

Ambient temperature 15 C - 35 C

Humidity 25% - 75%

Specifications

YAMAHA ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.

YAMAHA CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA

YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, F.R. OF GERMANY

YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE

YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND

YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN

YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA

3139 246 13152 Printed in Hungary

IP
