DVX-S301/DVX-S302/DVX-S303

OWNER’S MANUAL

MODE D’EMPLOI

Printed in China 3139 246 16151

DVX-S300_CA_cv.fm Page 1 Tuesday, June 7, 2005 2:56 PM

English

Active Servo Processing Subwoofer System with a

built-in power amplifier. The subwoofer system

(NX-SW300 and NX-SW301) employs Advanced

Yamaha Active Servo Technology which YAMAHA

has developed for reproducing higher quality super-

bass sound. This super-bass sound adds a more

realistic, theater-in-the-home effect to your stereo

system.

Sound field features

Manufactured under license from Dolby

Laboratories. “Dolby”, “Pro Logic”, “MLP

Lossless” and the double-D symbol are

trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Surround” are

registered trademarks of Digital Theater

Systems, Inc.

“DivX”, “DivX Certified”, and associated logos

are trademarks of DivXNetworks, Inc and are

used under license.

Playable disc formats

This receiver can play the disc types associated with the

logos shown below. (Do not attempt to load any other type

of disc into the receiver, or the receiver may be damaged.)

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and other

rights owners. Use of this copyright protection

technology must be authorized by Macrovision

Corporation, and is intended for home and other

limited viewing uses only unless otherwise authorized

by Macrovision Corporation. Reverse engineering or

disassembly is prohibited.

DIGITAL VIDEO

SUPER VIDEO

Features

IMPORTANT SAFETY INSTRUCTIONS

* Explanation of Graphical Symbols

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

6Clean only with dry cloth.

7Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided plug

does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at the plugs, convenience receptacles, and the

point where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or

sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when unused

for a long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way,

such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

15 Be sure to allow spaces of at least 10 cm above, behind and on

both sides of DVR-S300, and at least 1m above, 30cm behind

and on both sides of NX-SW300 and NX-SW301.

16 Do not place the following objects on this unit:

A vessel with water in it.

If the vessel falls by vibrations and water spills, it may cause

damage to the unit, and/or you may get an electric shock.

Apparatus shall not be exposed to dripping or splashing.

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT

Please record the serial number of this unit in the

space below.

MODEL:

Serial No.:

The serial number is located on the bottom of

the unit.

Retain this Owner’s Manual in a safe place for

future reference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert you to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral

triangle is intended to alert you to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements.

Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables.

Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could

void your FCC authorization to use this product in the USA.

3NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B”

digital devices.

Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential

environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio

frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful

to the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur

in all installations. If this product is found to be the source of interference, which can be determined by turning the product

“OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the

lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type

of product. If you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., 6660 Orangethorpe Ave.

Buena Park, CA90622.

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

¶ The name plate is located on the bottom of the unit.

La plaquette signalétique est placée sur le panneau de fond de l’appareil.

LASER SAFETY

This unit employs a laser. Due to possible eye injury,

only a qualified service person should remove the

cover or attempt to service this device.

DANGER

This unit emits visible laser radiation when open. Avoid

direct eye exposure to beam. When this unit is plugged

into a wall outlet, do not place your eyes close to the

opening of the disc tray and other openings or look inside.

LASER

Type Semiconductor laser GaAlAs

Wave length 650 nm (DVD)

784 nm (VCD/CD)

Output Power 7 mW (DVD/VCD/CD)

Beam divergence 60 degrees

INVISIBLE LASER RADIATION WHEN OPEN

DO NOT STARE INTO BEAM

CAUTION:

INVISIBLE LASER RADIATION WHEN OPEN

AVOID DIRECT EXPOSURE TO THE BEAM

DANGER:

CAUTION

Use of controls or adjustments or performance of

procedures other than those specified herein may result

in hazardous radiation exposure.

SÉCURITÉ LASER

L'appareil utilise un laser. En raison des risques de

blessure des yeux, le retrait du couvercle ou les

réparations de l'appareil devront être confiés

exclusivement à un technicien d'entretien qualifié.

DANGER

Risque d'exposition au laser en cas d'ouverture. Eviter

toute exposition au faisceau. Lorsque cet appareil est

branché à la prise de courant, ne pas approcher les

yeux de l'ouverture du plateau changeur et des autres

ouvertures pour regarder à l'intérieur.

LASER

Type Laser à semi-conducteur

GaAIAs

Longueur d’onde 650 nm (DVD)

784 nm (VCD/CD)

Puissance de sortie 7 mW (DVD/VCD/CD)

Divergence de faisceau 60 degrés

AVERTISSEMENT

L’utilisation de commandes et l’emploi de réglages ou

de méthodes autres que ceux décrits ci-dessous,

peuvent entraîner une exposition à un rayonnement

dangereux.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

iii

1To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2Install this sound system in a well ventilated, cool, dry, clean place

with at least 10 cm on the top, 10 cm on the left and right, and 10

cm at the back of DVR-S300 and at least 1 m above, 30 cm

behind and on both sides of NX-SW300 or NX-SW301 for

adequate ventilation. — away from direct sunlight, heat sources,

vibration, dust, moisture, and/or cold.

3Locate this unit away from other electrical appliances, motors,

or transformers to avoid humming sounds.

4Do not expose this unit to sudden temperature changes from

cold to hot, nor locate this unit in an environment with high

humidity (i.e., a room with a humidifier) to prevent

condensation inside this unit, which may cause an electrical

shock, fire, damage to this unit, and/or personal injury.

5Avoid installing this unit in a location where foreign objects

may fall onto this unit or where this unit may be exposed to

liquid dripping or splashing. On the top of this unit, do not

place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e., candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall, spilling

the liquid and causing an electrical shock to the user and/

or damage to this unit.

6Do not cover this unit with a newspaper, tablecloth, curtain,

etc. in order not to obstruct heat radiation. If the temperature

inside this unit rises, it may cause fire, damage to this unit,

and/or personal injury.

7Do not plug in this unit to a wall outlet until all connections

are complete.

8Do not operate this unit upside-down. It may overheat,

possibly causing damage.

9Do not use excessive force on switches, knobs and/or cords.

10 When disconnecting the power cord from the wall outlet,

grasp the plug; do not pull the cord.

11 Do not clean this unit with chemical solvents; this might

damage the finish. Use a clean, dry cloth.

12 Use only the voltage specified on this unit. Using this unit

with a higher voltage than specified is dangerous and may

cause fire, damage to this unit, and/or personal injury.

YAMAHA will not be held responsible for any damage

resulting from use of this unit with a voltage other than as

specified.

13 To prevent damage by lightning, keep the power cord out and

outdoor antennas disconnected from a wall outlet or the unit

during a lightning storm.

14 Do not attempt to modify or fix this unit. Contact qualified

YAMAHA service personnel when any service is needed. The

cabinet should never be opened for any reason.

When not planning to use this unit for long periods of time (i.e.,

vacation), disconnect the AC power plug from the wall outlet.

16 Be sure to read the “TROUBLESHOOTING” section on

common operating errors before concluding that this unit is

faulty.

17 Before moving this unit, press STANDBY/ON to set the unit

in standby mode, then disconnect the AC power plug from the

wall outlet.

18 Condensation will form when the surrounding temperature

changes suddenly. Disconnect the power cable from the

outlet, then leave the unit alone.

19 When using the unit for a long time, the unit may become

warm. Turn the power off, then leave the unit alone for

cooling.

20 Install this unit near the AC outlet and where the AC power

plug can be reached easily.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to

wide slot and fully insert.

This Class B digital apparatus complies with Canadian

ICES-003.

This unit is not disconnected from the AC power

source as long as it is connected to the wall outlet,

even if this unit itself is turned off. This state is called

the standby mode. In this state, this unit is designed to

consume a very small quantity of power.

Laser component in this product is capable of emitting

radiation exceeding the limit for Class 1.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN

OR MOISTURE.

CAUTION

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

English

INTRODUCTION ......................................... 2

Supplied accessories........................................ 5

FUNCTIONAL OVERVIEW ......................... 6

Top and front panels (DVR-S300).................. 6

Rear panel (DVR-S300).................................. 7

Rear panel (NX-SW300)................................. 8

Rear panel (NX-SW301)................................. 8

Remote control (For DVR-S300).................... 9

CONNECTIONS ........................................ 11

Roles and layout of the speakers................... 11

Placing the center speaker............................. 12

Placing the front/surround speakers.............. 13

Placing the subwoofer................................... 13

SYSTEM CONNECTIONS........................ 14

Connecting the speakers (DVX-S301).......... 14

Connecting the speakers (DVX-S302).......... 15

Connecting the speakers (DVX-S303).......... 16

Connecting the speaker cables ...................... 17

Connecting the subwoofer............................. 17

Connecting the DVD receiver and the

subwoofer .................................................. 18

OTHER CONNECTIONS........................... 19

Connecting a TV ........................................... 19

Connecting the FM/AM antennas ................. 20

Connecting external AV components ........... 21

Connecting digital audio components........... 22

GETTING STARTED................................. 23

Inserting batteries into the remote control .... 23

Using the remote control............................... 23

Setting a TV .................................................. 24

Setting language preferences......................... 26

Setting speaker channels ............................... 27

DISC OPERATION ................................... 28

Playing discs.................................................. 28

Basic playback controls................................. 28

Selecting various repeat shuffle functions..... 29

Shuffle ........................................................... 29

Other operations for video playback

(DVD/VCD/SVCD)................................... 30

Playing MP3/JPEG/DivX® discs.................. 33

Playing Super Audio CDs ............................. 34

Special features for picture disc playback..... 35

DVD SETUP MENU OPTIONS................. 36

General setup menu ....................................... 36

Audio setup menu.......................................... 38

Video setup menu.......................................... 39

Preference setup menu................................... 41

TUNER OPERATIONS ............................. 44

Tuning radio stations ..................................... 44

Presetting radio stations................................. 44

SOUND CONTROLS ................................ 46

Selecting surround sound .............................. 46

Selecting digital sound effects....................... 46

Adjusting the treble/bass level....................... 46

Adjusting the volume level............................ 47

Night listening mode ..................................... 47

Switching to active mode .............................. 47

Switching to standby mode ........................... 47

OTHER FUNCTIONS................................ 48

Setting remote control codes ......................... 48

Controlling other components ....................... 48

Dimming the display screen .......................... 49

Setting the sleep timer ................................... 49

Recording on an external AV component ..... 49

TROUBLESHOOTING.............................. 50

GLOSSARY .............................................. 52

SPECIFICATIONS .................................... 54

CONTENTS

1.INTRODUCTION

2.PREPARATION

3.BASIC OPERATION

4.OPERATIONS

5.ON-SCREEN MENU

6.OTHER FEATURES

INTRODUCTION

Thank you for purchasing this unit. This Owner’s Manual

explains the basic operation of this unit.

Notes about discs

– This receiver is designed for use with the following

discs: Super Audio CD (Super Audio CD), DVD-

Video, Video CD, Super Video CD, Audio CD, CD-

R, CD-RW, DVD-Audio, DVD+RW, DVD+R,

DVD-R, DVD-RW and DVD-RW (VR format).

This receiver can play:

– MP3 and picture (Kodak, JPEG) files recorded on

CD-R(W).

– JPEG/ISO 9660 format

– Maximum 30 character display

–DivX

® disc on CD-R[W]/DVD+R[W]/

DVD-R[W](3.11, 4.x and 5.x)

– CD-R, CD-RW and DVD-RW (VR format) cannot

be played unless finalized.

– Some discs cannot be played depending on the

recording conditions, such as the PC environment

and application software. The characteristics and

condition of some discs; materials, scratches,

curvature, etc, may result in playback failure.

– Be sure to use only CD-R and CD-RW discs made

by reliable manufacturers.

– Do not use any non-standard shaped discs (heart-

shaped, etc.).

– Do not use discs with tape, seals, or paste on their

surface. Doing so may damage this receiver.

– Do not use discs affixed with labels printed by a

commercially available label printer.

Cleaning discs

– When a disc becomes dirty, clean it with a cleaning

cloth. Wipe the disc from the center out. Do not

wipe in a circlar motion.

– Do not use solvents such as benzine, thinner,

commercially available cleaners, or antistatic spray

intended for analog records.

Avoid high temperatures, moisture, water

and dust

– Do not expose the system, batteries or discs to

humidity, rain, sand or excessive heat (caused by

heating equipment or direct sunlight). Always keep

the disc tray closed to avoid getting dust on the lens.

Avoid condensation problem

– The lens may cloud over when the receiver is

suddenly moved from cold to warm surroundings,

making it impossible to play a disc. Leave the

receiver in the warm environment until the moisture

evaporates.

Disc care

– Write only on the printed side of a CD-R/

CD-RW and only with a soft felt-tipped pen.

– Handle the disc by its edge; do not touch the

surface.

Cabinet care

– Use a soft cloth slightly moistened with a mild

detergent solution. Do not use a solution containing

alcohol, spirits, ammonia, or abrasives.

Choosing a suitable location

– Place the receiver on a flat, hard, and stable surface.

INTRODUCTION

Notes

INTRODUCTION

English

INTRODUCTION

Region codes

The unit is designed to support the Region Management

System. Check the region code number on the disc

package. If the number does not match the unit’s region

number (see the table below or the back of the unit), the

unit may be unable to play the disc.

Sound field features

Manufactured under license from Dolby

Laboratories. “Dolby”, “Pro Logic”, “MLP

Lossless” and the double-D symbol are

trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Surround” are

registered trademarks of Digital Theater

Systems, Inc.

“DivX”, “DivX Certified”, and associated logos

are trademarks of DivXNetworks, Inc and are

used under license.

■We Want You Listening For A Lifetime

YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the

most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear

without annoying blaring or distortion - and, most importantly, without affecting your sensitive hearing.

Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the

Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged

exposure from excessive volume levels.

Destination

Region

code of

DVR-S300

Playable

discs

U.S.A. and

Canada models

U.K. and Europe

models

Australia

model

Korea, Asia and

Taiwan models

1 1 ALL

2 2 ALL

4 4 ALL

3 3 ALL

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and other

rights owners. Use of this copyright protection

technology must be authorized by Macrovision

Corporation, and is intended for home and other

limited viewing uses only unless otherwise authorized

by Macrovision Corporation. Reverse engineering or

disassembly is prohibited.

Active Servo Processing Subwoofer System with built-in

power amplifier.

This subwoofer system (NX-SW300, NX-SW301) employes

Advanced YAMAHA Active Servo Technology which

YAMAHA has developed for reproducing higher quality

super-bass sound. This super-bass sound adds a more

realistic, theater-in-the-home effect to your stereo syetem.

INTRODUCTION

DVX-S301 DVX-S302

DVD receiver

(DVR-S300)

Subwoofer

(NX-SW301)

Center speaker

(NX-C301)

Front/Surround

speakers (x4)

(NX-S301)

DVD receiver

(DVR-S300)

Subwoofer

(NX-SW301)

Center speaker

(NX-C302)

Front/Surround

speakers (x4)

(NX-S302)

INTRODUCTION

English

INTRODUCTION

DVX-S303

■Supplied accessories

DVD receiver

(DVR-S300)

Subwoofer

(NX-SW300)

Center speaker

(NX-C302)

Front/Surround

speakers (x 4)

(NX-S302)

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAGE

DIMMER

POWER POWER

SLEEP

NIGHT

System control cable

(4 m )

FM wire antenna

Video pin cable

Remote control

AM loop antenna

Speaker cables

(5 m x 3)

(15 m x 2)

Fasteners (2 sets)

Batteries (x 2)

Base(x 4)

(For NX-S302)

Screws (x 8)

Washers (x 8)

(For NX-S302)

Non-skid pad (1 set)

(For NX-SW301)

FUNCTIONAL OVERVIEW

■Top and front panels (DVR-S300)

1STANDBY/ON

Turns on the DVD receiver, or sets it to the standby

mode (see “Auto eco power standby mode” on

page 28).

Opens/closes the disc tray.

3b / a , w / f

DVD/CD mode: selects the previous/next track or

chapter. Press and hold to fast forward or fast reverse.

TUNER mode: tunes the radio preset up/down.

DVD/CD mode: pauses disc playback.

5INPUT

Selects and input source or sets the priority level for

the audio input signals.

6VOLUME

Adjusts the volume level.

7Disc tray

Load the disc in the disc tray.

8System display panel

Shows information about the operational status of the

unit.

MULTI

Lights up when you play a multi-channel audio

source.

DOWNMIX

Lights up when you play discs that allow down mixing

of multi-channel audio sources.

It does not light up for discs that prohibit down

mixing, even if you play a multi-channel audio source.

9 h

DVD/CD mode: starts disc playback.

TUNER mode: starts preset radio station installation

in Plug & Play mode.

Exits an operation.

DVD/CD mode: stops playback.

TUNER mode: erases a preset radio station in Preset

mode if held more than two seconds, or stops preset

radio station installation in Auto Preset mode.

ARemote control sensor

Point the remote control towards this sensor.

B Head phone jack

Connects headphones.

FUNCTIONAL OVERVIEW

654321

FUNCTIONAL OVERVIEW

INTRODUCTION

English

■Rear panel (DVR-S300)

(U.K. and Europe models)

1AC power cord

Connect to a standard AC outlet.

2AV MONITOR OUT terminal

(U.K. and Europe models only)

Connect to your TV (see page 19).

3VIDEO output terminal

Connect to the video (composite) jack on your TV

(see page 19).

4COMPONENT VIDEO OUT terminal

Connect the the Y PB/CB PR/CR jacks on your TV (see

page 19).

5LINE OUT terminal

Connect to the AUDIO IN jacks on your VCR.

6TV IN terminal

Connect to the corresponding AUDIO OUT jacks on

your TV (see page 19).

7AUX IN terminal

Connect to the AUDIO OUT jacks on your VCR or

cassette deck.

8FM ANT terminal

Connect the FM antenna.

9GND and AM ANT terminals

Connect the AM loop antenna.

0S VIDEO output terminal

Connect to the S-video jack on your TV or VCR.

AOPTICAL DIGITAL IN terminal

Connect to the DIGITAL OUT jack on your digital

audio component.

BSYSTEM CONNECTOR terminal

Connect the subwoofer.

SYSTEM

CONNECTOR

AUX INTV INLINE OUT

S VIDEO

AV MONITOR OUT

(DVD ONLY)

VIDEO

OPTICAL

COMPONENT

PRPB

PCM/DTS

DIGITAL

DIGITAL INVIDEO OUT (DVD ONLY)

ANT AM

ANT

GND

TO SUBWOOFER

75Ω UNBAL

9821 4 5 6 73

B0A

FUNCTIONAL OVERVIEW

■Rear panel (NX-SW300)

1SYSTEM CONNECTOR terminal

Connect to the DVD receiver.

2SPEAKER terminals

Connect to the speakers.

3AC power cord

Connect to a standard AC outlet.

■Rear panel (NX-SW301)

1SYSTEM CONNECTOR terminal

Connect to the DVD receiver.

2SPEAKER terminals

Connect to the speakers.

3AC power cord

Connect to a standard AC outlet.

123

FUNCTIONAL OVERVIEW

INTRODUCTION

English

■Remote control

(For DVR-S300)

For details on how to use the remote control, see page 23.

1POWER (TV)

Turns on the TV, or sets it to the standby mode.

2DIMMER

Selects different levels of brightness for the display

panel.

3Numeric keypad (0 – 9)

Enters a track/title number of the disc.

Enters a number of a preset radio station.

4REPEAT

Selects various repeat modes.

5PROG

DVD/CD mode: starts programming.

TUNER mode: starts automatic/manual preset

programming if held for more than two seconds.

6TOP MENU/RETURN

Returns to the previous menu.

Displays the top-level disc menu

(if available).

7Cursors ( / / / )

Selects movement direction in the menu.

TUNER mode: press left or right to tune the radio

frequency.

TUNER mode: press up or down to select auto

tuning.

8ENTER (OK)

Confirms a selection.

9MENU

Enters or exits the disc contents menu.

For VCD version 2.0 only:

In stop mode, turns on/off playback control (PBC)

mode.

During playback, returns to the main menu.

Exits an operation.

DVD/CD mode: stops playback.

DVD/CD mode: holding down the button will open

and close the disc tray.

TUNER mode: erases a preset radio station if held

for more than two seconds.

Ad PRESET u ( b / a )

DVD/CD mode: selects the previous/next track or

chapter. Press and hold to fast forward or fast

reverse.

TUNER mode: press to select a preset radio station.

BSUBTITLE

Selects a subtitle language.

Note

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

FUNCTIONAL OVERVIEW

CAUDIO

Selects an audio language (DVD) or an audio channel

(VCD).

DTV VOL (+ / –)

Adjusts the TV volume.

ETV CH (+ / –)

Switches the TV channel.

FTV INPUT

Switches the TV input.

GEFFECT

Selects a sound effect.

HInput selection buttons

Selects the appropriate active source mode.

TV mode: switches to TV input.

AUX mode: switches to AUX ANALOG/AUX

DIGITAL input.

TUNER mode: switches tuner (FM/AM) input.

DVD/CD mode: switches to DVD/CD mode.

IPOWER ( )

Turns on the DVD receiver, or sets it to the standby

mode.

JSLEEP

Sets the sleep timer.

KSCAN

Scans each track/chapter on the disc.

LPAGE

Turns the pages of DVD-Audio still pictures.

MREPEAT A-B

Repeats a specific section on a disc.

NSHUFFLE

Plays tracks in random order.

OON SCREEN

Displays the current status or disc information.

PSET UP

Enters or exits the system setup menu.

DVD/CD mode: starts disc playback.

DVD/CD mode: pauses disc playback.

SNIGHT

Turns the Night mode on or off.

TZOOM

Enlarges or reduces the TV screen picture.

UANGLE

Selects a DVD disc camera angle (if available).

VVOL (+ / –)

Adjusts the volume level.

WTRE/BASS

Selects the TREBLE (high tone) or BASS (low tone)

sound mode.

Use the VOLUME control to change the tone level.

XMUTE

Mutes or restores the volume.

YSURR

Selects multi-channel surround or stereo mode.

CONNECTIONS

English

PREPARATION

■Roles and layout of the speakers

To enjoy quality sounds you need to place the speakers in their appropriate positions and install them correctly.

The following show the recommended layout of the speakers.

For the best possible surround sound, all of the speakers (except the subwoofer) should be placed at the same distance

from the listening position.

1Front Speakers (L, R)

Place the front left/right speakers on both sides of your TV at equal distances.

Main roles: Produces front channel (stereo) sounds and effect sounds.

2Center Speaker

Place on top of the TV or inside the TV rack so that the speaker and TV are aligned vertically.

Main role: Produces sounds oriented toward the center of the screen such as dialogues or vocal sounds.

3Surround Speakers (L, R)

Place the surround left/right speakers behind the listening position. (For NX-S301, we recommend placing them at a height of 1.8 m

(6 feet) and pointing them at the listening position.)

Main roles: Produces surround sounds and effect sounds.

4Subwoofer

Place the subwoofer near a front speaker and turn it slightly toward the center of the room to reduce wall reflections.

Main roles: Produces bass sounds and low frequency (LFE) sounds contained in Dolby Digital or DTS.

To avoid magnetic interference, do not position the front speakers too close to your TV.

Allow adequate ventilation around the DVD receiver and subwoofer.

Bass sounds produced by the subwoofer may be heard differently depending on the listening position and subwoofer location.

To enjoy desired sounds, try to change the location of the subwoofer according to the listening position.

CONNECTIONS

343

–+

–

DVD receiver Center speaker

Front

speaker (R)

Surround

speaker (L) Subwoofer Surround

speaker (R)

Front

speaker (L)

DVX-S301

DVD receiver Center speaker

Front

speaker (R)

Subwoofer

Front

speaker (L)

Surround

speaker (R)

Surround

speaker (L)

DVX-S302/DVX-S303

Note

CONNECTIONS

■Placing the center speaker

When placing the center speaker on top of the TV, use the

supplied fasteners to secure the speaker.

1Peel off the seals on one side of the fasteners and

attach them to the bottom of the center speaker.

2Peel off the seals on the other side of the fasteners and

attach them to the top of the TV.

– Do not place the speaker on the TV if the top of the

TV is uneven or narrower than the bottom surface

of the speaker. Doing so may cause the speaker to

fall. In this case, place the speaker inside a TV rack

or on a level floor.

– Before attaching the fasteners to the TV, clean the

surface with a dry cloth. A dirty or wet surface may

weaken the adhesive force and cause the speaker to

fall.

– Do not touch the bonding surfaces of the fasteners

after peeling off the seals. Doing so may weaken

the adhensive force and cause the speaker to

fall.this installation. Use metric screw threads only.

Attaching to a wall

You can attach the speakers to a wall using commercially

available screws (Diameter: 3.5 to 4 mm, Length: 25 mm

or more). Each speaker requires two screws.

1Install two screws in the wall where you want to place

the speaker.

2Hang the speaker on the screws using the holes in the

back of the speaker.

– To attach a speaker to a wall using screws, the wall

must be firm. Do not attach a speaker to a wall that

is made of weak materials such as plaster or

veneered woods. Doing so may cause the speaker

to fall.

– When connectiong the speakers, fix the speaker

cables in place so that cables do not loosen. If your

foot or hand accidentally gets caught on a loose

speaker cable, the speaker may fall.

– After attaching each speaker, check that the

speaker is fixed securely. YAMAHA will bear no

reponsibility for any accidents caused by improper

installations.

Notes

Fastener

Peel off

the seal

NX-C301

Fastener

Peel off

the seal

NX-C302

Notes

–

5 mm

Screws (3.5

to 4 mm dia.,

commercially

available)

20 mm or more

110 mm

NX-C301

–

5 mm

Screws (3.5

to 4 mm dia.,

commercially

available)

20 mm or more

151 mm

NX-C302

CONNECTIONS

English

PREPARATION

■Placing the front/surround

speakers

Attaching to a wall

You can attach the speakers to a wall using commercially

available screws (Diameter: 3.5 to 4 mm, Length: 25 mm

or more). Each speaker requires two screws.

1Install two screws in the wall where you want to place

the speaker.

2Hang the speaker on the screws using the holes in the

back of the speaker.

– To attach a speaker to a wall using screws, the wall

must be firm. Do not attach a speaker to a wall that

is made of weak materials such as plaster or

veneered woods. Doing so may cause the speaker

to fall.

– When connectiong the speakers, fix the speaker

cables in place so that cables do not loosen. If your

foot or hand accidentally gets caught on a loose

speaker cable, the speaker may fall.

– After attaching each speaker, check that the

speaker is fixed securely. YAMAHA will bear no

reponsibility for any accidents caused by improper

installations.

Hanging on a wall (NX-S301)

You can hang the speakers on a wall using a commercially

available bracket and screws (Diameter: 6 mm). Attach a

bracket firmly to the rear of the speakers using screws.

Then mount a screw on the wall where the speaker is to be

hung and hook the speaker securely onto the mounted

screws.

Do not use screw threads neasured in inches for this

installation. Use metric screw threads only.

Attaching the base

Attach the base to the bottom of the front/surround

speakers (NX-S302) with the supplied base mounting

screws as shown below.

Placing the speakers (NX-S302) on the places such as hard

wooden floor may scratch the surface of the floor.

■Placing the subwoofer

Attach the non-skid pads to the bottom of the subwoofer

(NX-SW301), and then place the subwoofer on a level

hard floor.

Using non-skid pads prevents the subwoofer from sliding

when it vibrates, and ensure quality sound production.

Notes

Note

–

5 mm

Screws (3.5

to 4 mm dia.,

commercially

available)

20 mm or more

40 mm

NX-S301

Note

Base

mounting

screws

NX-S302

Base

Washer

Peel off

the seal

SYSTEM CONNECTIONS

■Connecting the speakers (DVX-S301)

– Do not connect the power cord of the subwoofer and DVD receiver into an AC outlet until all cable connections are completed.

– Please refer to the pages below for detailed information on how connect each speaker.

SYSTEM CONNECTIONS

Notes

SYSTEM

CONNECTOR

TO SUBWOOFER

–

–+

–

Front speaker (R)NX-S301

(page 17)

Surround

speaker (R)

NX-S301

(page 17)

Center speaker

NX-C301

(page 17)

Subwoofer

(NX-SW301)

DVD receiver (DVR-S300)

Front speaker (L) NX-S301

(page 17)

Surround

speaker (L)

NX-S301

(page 17)

Tab

Red

Green

Tab

Gray

White

Blue

SYSTEM CONNECTIONS

English

PREPARATION

■Connecting the speakers (DVX-S302)

– Do not connect the power cord of the subwoofer and DVD receiver into an AC outlet until all cable connections are completed.

– Please refer to the pages below for detailed information on how connect each speaker.

Notes

SYSTEM

CONNECTOR

TO SUBWOOFER

Front speaker (R)

NX-S302

(page 17)

Surround

speaker (R)

NX-S302

(page 17)

Center speaker

NX-C302

(page 17)

Subwoofer

NX-SW301

(page 17)

DVD receiver (DVR-S300)

Front speaker (L)

NX-S302

(page 17)

Surround

speaker (L)

NX-S302

(page 17)

Tab

Red Green

Tab

Gray

White

Blue

Black

Red

Black

Red

Red Red Red Black

Black

SYSTEM CONNECTIONS

■Connecting the speakers (DVX-S303)

– Do not connect the power cord of the subwoofer and DVD receiver into an AC outlet until all cable connections are completed.

– Please refer to the pages below for detailed information on how to connect each speaker.

Notes

FRONTCENTE R SURROUND

SYSTEM

CONNECTOR

TO SUBWOOFER

FRONT CENTER SURROUND

SPEAKERS

Subwoofer

NX-SW300

(page 17)

DVD receiver (DVR-S300)

Front speaker

(R)

NX-S302

(page 17)

Front speaker

(L)

NX-S302

(page 17)

Center speaker

NX-C302

(page 17)

Surround

speaker (R)

NX-S302

(page 17)

Surround

speaker (R)

NX-S302

(page 17)

To remove the speaker

cable plugs, see

“Connecting the

subwoofer” on page 17.

Red

Black

Black Black Black

Black Red

Red

Red Red

SYSTEM CONNECTIONS

English

PREPARATION

■Connecting the speaker cables

Connect the speaker cable with the color band to the plus

(Red (+)) connector on the front/center/surround speakers

and with the white line to the minus (Black (–)) connector.

■Connecting the subwoofer

Insert the cable plug of the speaker cable into the speaker

jack of the same color until you hear it click into place.

• FRONT R (Red), CENTER (Green), FRONT L

(White): Insert the cable plug facing the tub

upwards.

• SURROUND R (Gray), SURROUND L (Blue):

Insert the cable plug facing the tub downwards.

Before connecting the speaker cables to the subwoofer

(NX-SW300), remove the cable plugs from supplied

speaker cables.

Press and hold the release button and remove the supplied

speaker cable from the cable plug.

Be sure to twist the cable core firmly in a clockwise

direction. Twisting loosely may cause a short.

FRONT R (Red), CENTER (Green), FRONT L

(White):

SURROUND R (Gray), SURROUND L (Blue):

Do not use excessive force when inserting the cable

plug. Doing so may damage the cable plug or speaker

jack.

Lever

(Black)

Color

band

Press the lever down, then

insert the cable into the hole

and release the lever.

Lever

(Red)

Press the lever down, then

insert the cable into the hole

and release the lever.

Color

band

Lever

(Red)

Lever

(Black)

Tab

Red Green

Tab

Gray

White

Blue

NX-SW301

Note

Release button

Good No Good

FRONT CENTER SURROUND

SPEAKERS

Lift up the lever, then insert

the cable into the hole and

replace the lever.

Lever

color

band

NX-SW300

SYSTEM CONNECTIONS

■Connecting the DVD receiver and

the subwoofer

Connect the subwoofer to the DVD receiver using the

system control cable. Attach one end to the subwoofer and

the other to the SYSTEM CONNECTOR terminal at the

rear of the DVD receiver.

– After inserting the system control cable, be sure to

tighten the cable screws.

– Ensure that the speaker cables are correctly

connected. Improper connections may damage the

system due to a short-circuit.

– When connecting the speakers, fix the speaker

cables in place so that cables do not loosen. If your

foot or hand accidentally gets caught on a loose

speaker cable, the speaker may fall.

– To prevent unwanted noise, do not place the

subwoofer too close to the DVD receiver, AC

power adaptor, TV or other sources of radiation.

SYSTEM

CONNECTOR

TO NX-SW300

SYSTEM

CONNECTOR

SYSTEM

CONNECTOR

NX-SW301

SYSTEM

CONNECTOR

TO SUBWOOFER

SYSTEM

CONNECTOR

SYSTEM

CONNECTOR

NX-SW300

Notes

OTHER CONNECTIONS

English

PREPARATION

■Connecting a TV

– You only need to make one video connection from the following options (A,B,C, or D), depending on the

capabilities of your TV.

– Do not connect the power cords until all cable connections are completed.

AV MONITOR OUT terminal <A>

(U.K. and Europe models only)

The SCART cable, or “Euro AV cable”, supports AV

MONITOR OUT signal transmission, providing you with

the best possible picture and sound. If your TV has only

one terminal for video input, and you want to connect it

directly to the DVD receiver, you can use the AV

MONITOR OUT connector. Connect one end of the

SCART cable to the AV MONITOR OUT connector and

the other end to the SCART connector on your TV.

TV channels, if you use AV MONITOR OUT terminal to

connect the TV. To use AV MONITOR OUTterminal,

make sure to set the DVD receiver’s component setting to

“RGB” (see page 25).

S VIDEO output terminal<B>

S-(separate)video connections achieve a clearer picture

than composite video connections. Use an S-video cable

(not supplied) to connect the DVD receiver’s

S VIDEO jack to the S-video input jack (or Y/C or

S-VHS jack) on your TV.

VIDEO output terminal <C>

Use a composite video cable (yellow -supplied) to connect

the DVD receiver’s VIDEO jack to the video input jack

(or A/V In/Video In/Composite/ Baseband jack) on your

TV.

COMPONENT VIDEO OUT terminals

<D>

Use the component video cables (red/blue/green, not

supplied) to connect the DVD receiver’s Y PB PR jacks to

the corresponding component video input jacks (or the Y

Pb/Cb Pr/Cr/ YUV jacks) on your TV.

Progressive scan video quality is only available when

using Y PB PR in conjunction with a progressive scan TV.

To activate the progressive scan function see “Progressive

function” on page 39.

OTHER CONNECTIONS

Notes

S VIDEO

AV MONITOR OUT (DVD ONLY)

VIDEO

COMPONENT

PRPB

VIDEO OUT (DVD ONLY)

AUX INTV INLINE OUT

OPTICAL

PCM/DTS

DIGITAL

DIGITAL IN

DVR-S300

(U.K. and Europe models only)

<B>

Note

OTHER CONNECTIONS

TV IN terminal <E>

To listen to TV channels through this DVD receiver, use

the audio cables (white/red, not supplied) to connect the

TV IN jacks to the corresponding audio out jacks on your

TV.

– When using AV MONITOR OUT terminal to

listen to the TV channels, set the DVD receiver’s

component setting to “RGB” (see page 25).

– When using TV IN terminal, set the DVD

receiver’s component setting to“YUV” (see

page 25).

■Connecting the FM/AM antennas

1Connect the supplied AM loop antenna to the AM

ANT terminal. Place the AM loop antenna on a shelf

or attach it to a stand or wall.

2Connect the supplied FM wire antenna to the FM

ANT terminal. Extend the FM wire antenna and fix its

ends to the wall.

For better FM stereo reception, connect an external

FM antenna (not supplied).

– Adjust the position of the antennas for optimal

reception.

– Position the antennas as far as possible from your

TV, VCR or other sources of radiation to prevent

unwanted interference.

Notes

SYSTEM

CONNECTOR

ANT AM

ANT

GND

TO SUBWOOFER

Ground (GND terminal)

For minimum interference, connect

the antenna GND terminal to a good

earth ground. A good earth ground

is a metal stake driven into moist

earth.

FM wire

antenna

AM loop

antenna

OTHER CONNECTIONS

English

PREPARATION

■Connecting external AV components

If you connect external AV equipment such as a VCR, cassette deck or digital audio component to the following AV

jacks on the DVD receiver, you can enjoy those AV sources with the DVD receiver. Also, you can record AV sources

played on the DVD receiver using the recording equipment. This section provides some examples of other AV equipment

connections. For information on your AV equipment, refer to the manual provided.

Viewing and listening to

playback

1Connect the VCR to the TV as shown.

2Connect the DVD receiver’s AUX IN jack to the

AUDIO OUT jacks on your VCR.

Before starting operation, press AUX to select “AUX

ANALOG” in order to activate the input source.

Using the VCR for recording DVD

playback

Some DVDs are copy-protected. You cannot record or dub

protected discs using a VCR.

1Connect the DVD receiver’s S VIDEO jack output to

the S-VIDEO IN jack on your VCR.

2Connect the DVD receiver’s LINE OUT jacks to the

AUDIO IN jacks on your VCR.

This will allow you to make analog stereo (two

channels, right and left) recordings.

AUX INTV INLINE OUT

S VIDEO

VIDEO

OPTICAL

COMPONENT

PRPB

PCM/DTS

DIGITAL

DIGITAL INVIDEO OUT (DVD ONLY)

VCR (for example)

DVD receiver

OTHER CONNECTIONS

■Connecting digital audio components

Listening to playback

Connect the DVD receiver’s DIGITAL IN jack to the

DIGITAL OUT jack on a digital audio component.

Before starting operation, press AUX repeatedly to select

“AUX DIGITAL” in order to activate the input source.

– You cannot hear or record the Super Audio-CD or

MP3-CD playback if you use a digital connection.

– For playback through a digital connection, set the

digital output of that player to PCM format.

– Always refer to the owner’s manual of the

connected component for complete connection and

usage details.

AUX INTV INLINE OUT

S VIDEO

VIDEO

OPTICAL

COMPONENT

PRPB

PCM/DTS

DIGITAL

DIGITAL INVIDEO OUT (DVD ONLY)

Digital audio

component

DVD receiver

Notes

GETTING STARTED

English

BASIC OPERATION

■Inserting batteries into the

remote control

1Open the battery compartment.

2Insert two batteries type R06 or AA, following the

indications (+/–) inside the compartment.

3Close the battery compartment.

To replace the batteries

If the batteries grow old, the effective operation distance

of the remote control decreases considerably. If this

happens, replace the batteries with two new ones as soon

as possible.

– Do not use an old battery together with new one.

– Do not use different types of batteries (for

example, alkaline and manganese) together. Each

type of battery has its own characteristics even if

they are similar in shape.

– If the batteries run out, immediately remove them

from the remote control to prevent an explosion or

acid leak.

– Dispose of the batteries according to the regional

regulations.

– If a battery starts leaking, dispose of it

immediately.

Be careful not to let leaking battery acid come into

contact with your skin or clothing. Before inserting

new batteries, wipe the compartment clean.

– Replace the batteries within two minutes to

preserve the memory in the remote control.

■Using the remote control

Use the remote control within 6 m of the DVD receiver

and point it toward the remote control sensor.

1Use the input selection buttons on the remote control

to select the mode you wish to control (for example

TV, DVD/CD).

→ The selected source mode appears in the display

panel.

2Select the desired function (for example, h or b /

a).

The remote control can also operate a television, cable

TV or satellite connected to the DVD receiver.

However, it is first necessary to enter the remote

control code for the equipment in the remote control’s

memory (see “LIST OF REMOTE CONTROL

CODES” at the end of this manual).

– Be careful not to spill liquid on the remote control.

– Be careful not to drop the remote control.

– Do not leave the remote control in the following

places:

– hot or humid places, such as near a heater or in a

bathroom

– extremely cold places

– dusty places

GETTING STARTED

Notes

30˚ 30˚

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE Z OOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN PAGE

DIMMER

POWER POWER

SLEEP

NIGHT

Within 6 m

GETTING STARTED

■Setting a TV

Make sure you have completed all the necessary connections

(see “Connecting a TV” on page 19).

1Press DVD/CD.

→ “DVD/CD” appears in the display panel.

2Turn on the TV and set to the correct video-in channel.

→ You should see the background screen on the TV.

– Usually this channel is between the lowest and

highest channels and may be called FRONT, A/V IN

or VIDEO. See your TV manual for more details.

– Or, you may go to channel 1 on your TV, then press

the Channel down button repeatedly until you see the

Video In channel.

– Or, the TV remote control may have a button or

switch that chooses different video modes.

Selecting the TV type

In order for a DVD to play on this DVD receiver, the color

system of the DVD, the TV and the DVD receiver should

match. Before changing the TV system, determine the

color system of your TV.

1In DVD/CD mode, press SET UP.

2Press repeatedly to select [VIDEO SETUP PAGE].

3Press / to highlight [TV TYPE], then press

4Press / to highlight one of the options below:

PAL – Select this if the connected TV has the PAL

color system. It will change the video signal of an

NTSC disc and output it to PAL format.

NTSC – Select this if the connected TV has the NTSC

color system. It will change the video signal of a PAL

disc and output it to NTSC format.

MULTI – Select this if the connected TV is compatible

with both NTSC and PAL (multisystem). The output

format will be in accordance with the video signal of

the disc.

5Select a setting and press ENTER (OK).

– Follow the instructions shown on the TV to confirm

the selection (if any).

– If a blank/distorted TV screen appears, wait for 15

seconds for auto recovery to activate.

When you are selecting color system by using the remote

control, follow the procedure below.

1Open the disc tray.

2Press , then press AUDIO.

→ If the default setting of the color system is NTSC,

it will be changed to PAL.

→ If the default setting of the color system is PAL, it

will be changed to NTSC.

Note

TV TYPE

TV DISPLAY

PROGRESSIVE

PICTURE SETTING

COMPONENT

PAL

NTSC

MULTI

VIDEO SETUP PAGE

Note

GETTING STARTED

BASIC OPERATION

English

Setting the TV display

Set the aspect ratio of the DVD receiver according to the

TV you have connected. The format you select must be

available on the disc. If it is not, the TV display setting

will not affect the picture during playback.

1In DVD/CD mode, press SET UP.

2Press repeatedly to select [VIDEO SETUP PAGE].

3Press / to highlight [TV DISPLAY], then

press .

4Press / to highlight one of the options below:

4:3 PAN SCAN – Select this if you have a

conventional TV and want both sides of the picture to

be trimmed or formatted to fit your TV screen.

4:3 LETTER BOX – Select this if you have a

conventional TV. In this case, a wide picture with

black bands on the upper and lower portions of the TV

screen will be displayed.

16:9 – Select this if you have a wide-screen TV.

5Select a setting and press ENTER (OK).

Selecting the color system

(U.K. and Europe models only)

This setting allows you to toggle the video signal output

between YUV (Y PB PR or S-Video connections) and

RGB (AV MONITOR OUT connections).

AV MONITOR OUT (SCART ) connections are only

available for U.K and Europe models.

1In DVD/CD mode, press SET UP.

2Press repeatedly to select [VIDEO SETUP PAGE].

3Press / to highlight [COMPONENT], then

press .

4Press / to highlight one of the options below:

YUV – Select this for Y PB PR or S-Video

connections.

RGB – Select this for AV MONITOR OUT

connections.

5Select a setting and press ENTER (OK).

6To return to the previous menu, press .

To exit the menu, press SET UP.

Note

TV TYPE

TV DISPLAY

PROGRESSIVE

PICTURE SETTING

COMPONENT

4:3 PAN SCAN

4:3 LETTER BOX

16:9

VIDEO SETUP PAGE

TV TYPE

TV DISPLAY

PROGRESSIVE

PICTURE SETTING

COMPONENT YUV

RGB

VIDEO SETUP PAGE

GETTING STARTED

■Setting language preferences

You can select your preferred language settings so that this

receiver will automatically switch to your preferred

language whenever you load a disc. If the language

selected is not available on the disc, the disc’s default

setting language will be used instead. The OSD (on-screen

display) language for the system menu will remain as you

set it, regardless of various disc languages.

On-screen display (OSD) language

1In DVD/CD mode, press SET UP.

2Press to select [GENERAL SETUP PAGE].

3Press / to highlight [OSD LANGUAGE],

then press .

4Press / to select a language and press

ENTER (OK) to confirm.

5To return to the previous menu, press .

To exit the menu, press SET UP.

Audio, Subtitle and Disc menu

languages

1Press s twice to stop playback (if any), then press

SET UP.

2Press repeatedly to select [PREFERENCE PAGE].

3Press / to highlight one of the options below

at a time, then press .

–[AUDIO] (disc’s soundtrack)

–[SUBTITLE] (disc’s subtitles)

–[DISC MENU] (disc’s menu)

4Press / to select a language and press

ENTER (OK) to confirm.

If the language you want is not in the list, then select

[OTHERS].

Use the numeric keypad (0-9) on the remote control

to enter the 4-digit language code (see “LIST OF

LANGUAGE CODES” at the end of this manual”)

and press ENTER (OK) to confirm.

5Repeat steps 3 and 4 for other settings.

6To return to the previous menu, press .

To exit the menu, press SET UP.

DVD AUDIO

DISC LOCK

PROGRAM

OSD LANGUAGE

SCREEN SAVER

DiVX(R) VOD CODE

ENGLISH

FRANÇAIS

ESPAÑOL

GENERAL SETUP PAGE

AUDIO

SUBTITLE

DISC MENU

PARENTAL

PBC

MP3/JPEG NAV

VR LIST

PASSWORD

ENGLISH

CHINESE

FRENCH

SPANISH

PORTUGUESE

POLISH

ITALIAN

TURKISH

PREFERENCE PAGE

GETTING STARTED

BASIC OPERATION

English

■Setting speaker channels

You can adjust the delay times (for center and surround

speakers only) and volume level for individual speakers.

These adjustments let you optimize the sound of your system

to best suit your surroundings and setup.

Press SURR on the remote control to select the multi-

channel surround mode before adjusting the speaker settings.

1Press s to stop playback, then press SET UP.

2Press repeatedly to select [AUDIO SETUP PAGE].

3Press / to highlight [SPEAKER SETUP],

then press .

4Press / to highlight one of the options below,

then press .

[SPEAKER VOLUME] – Volume level setting for

individual speakers (–6dB to +6dB).

[SPEAKERS DELAY] – Delay time settings is in

relation to the listening position/distance for center

and surround speakers (0 MS to 15 MS).

5Press / to adjust the setting that best suit your

surround sound needs.

6Press ENTER (OK) to confirm.

7To return to the previous menu, press .

To exit the menu, press SET UP.

– Use a longer delay time settings when the surround

speakers are closer to the listener than the front

speakers.

– A test tone will be automatically generated to help

you judge the sound level of each speaker.

Note

SPEAKER SETUP

CD UPSAMPLING

NIGHT MODE

LIP SYNC

SPEAKERS VOLUME

SPEAKERS DELAY

AUDIO SETUP PAGE

SPEAKER SETUP PAGE

Notes

0dB

FRONT LEFT

FRONT RIGHT

CENTER

SUBWOOFER

SURROUND L

SURROUND R

SPEAKER VOLUME SETUP

0 MS

CENTER

SURROUND L

SURROUND R

SPEAKER DELAY SETUP

DISC OPERATION

IMPORTANT!

–If the inhibit icon ( or “X”) appears on the TV

screen when a button is pressed, the function for

that button is not available on the current disc or at

the current time.

–DVD discs and players are designed with regional

restrictions. Before playing a disc, make sure the

disc is for the same zone as your receiver.

–Do not push on the disc tray or put any objects other

than discs on the disc tray. Doing so may cause the

disc player to malfunction.

■Playing discs

1Press DVD/CD until “DVD/CD” appears in the display

panel.

2Turn on the TV power and set to the correct Video In

channel (see “Setting a TV” on page 24).

→ You should see the background screen on the TV.

3Press once to open the disc tray and load a disc,

then press the same button again to close the disc tray.

4Playback will start automatically.

→ If a disc menu shows on the TV, see “Using the

disc menu” on page 30.

→ If the disc is locked by parental control, you must

enter your six-digit password (see “Restricting

playback with parental control” on page 41).

Auto eco power standby mode

This is a power-saving feature. The receiver will

automatically switch to Eco Power standby mode if you

do not press any buttons for 30 minutes after a disc has

stopped playing.

■Basic playback controls

To pause playback

During playback, press e.

– To resume normal playback, press h.

To select another track/chapter

Press b / a or use the numeric keypad (0-9) to

enter a track/chapter number.

– During repeat playback of a track/chapter, pressing

b / a replays the same track/chapter.

To search backward/forward

Press and hold b / a. To resume normal chapter.

Searching backward/forward playback, press h.

– While searching, press b / a again to increase the

search speed.

To stop playback

Press s.

DISC OPERATION

VOLUME

INPUT

STANDBY/ON

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

Numeric

keypad (0-9)

dPRESETu

(b / a)

DISC OPERATION

OPERATIONS

English

■Selecting various repeat shuffle

functions

Repeat play mode

Repeat chapter/title/disc (DVD-V)

Each time you press REPEAT, the display changes as

follows:

CHAPTER*: repeats the current chapter.

TITLE: repeats the current title.

DISC*: repeats the entire disc.

REPEAT OFF: exits repeat mode.

* This feature may not be available with some discs.

Repeat track/disc

(except DVD-V/DVD-A)

Each time you press REPEAT, the display changes as

follows:

TRACK: repeats the current track.

DISC: repeats the entire disc.

REPEAT OFF: exits repeat mode.

Repeat track/group/disc (DVD-A)

Each time you press REPEAT, the display changes as

follows:

TRACK: repeats the current track.

GROUP: repeats the current group.

DISC: repeats the entire disc.

REPEAT OFF: exits repeat mode.

For VCD, repeat playback is not possible if the PBC

mode is selected.

Repeating a section within a chapter/

track

1While playing a disc, press A-B at your chosen

starting point.

2Press A-B again at your chosen end point.

→ The section will now repeat continuously.

3To exit the sequence, press A-B.

■Shuffle (except VR format disc)

With the Shuffle function, you can play tracks in random

order.

–During playback, press SHUFFLE repeatedly to

select between SHUFFLE, SHUFFLE REPEAT and

SHUFFLE OFF.

→ The selected mode appears in the display for

several seconds.

–In SHUFFLE mode, all tracks on the disc currently

playing are played in random order.

–In SHUFFLE REPEAT mode, all tracks are played

in random order and continuously.

–For Hybrid Super Audio CDs, tracks on the Super

Audio CD layer are played by default (see “Playing

Super Audio CDs” on page 34).

Note

CHAPTER TITLE

DISC

REPEAT OFF

TRACK DISC

REPEAT OFF

TRACK GROUP

DISC

REPEAT OFF

DISC OPERATION

■Other operations for video

playback

(DVD/VCD/SVCD)

Using the disc menu

Depending on the disc, a menu may appear on the TV

screen once you load the disc.

To select a playback feature or item

Use / / / or the numeric keypad

(0-9) on the remote control, then press ENTER (OK) to

start playback.

To access or remove the menu

Press MENU on the remote control.

Displaying disc information and the

current status

You can display disc information and the disc’s current

status (for example, title or chapter number, elapsed

playing time, audio/subtitle language). A number of

operations can be performed without interrupting disc

playback.

1During playback, press ON SCREEN.

→ A list of available disc information appears on the

TV screen.

2Press / to view the information and press

ENTER (OK) to access.

3Use the numeric keypad (0-9) to enter the number/

time or press / to make the selection, then

press ENTER (OK) to confirm.

→ Playback will change to the chosen time or to the

selected title/chapter/track.

Zooming in

This function allows you to enlarge the picture on the TV

screen and pan through the enlarged picture.

1During playback, press ZOOM repeatedly to select a

different zoom factor.

Use / / / to move through the zoomed

image.

→ Playback continues.

2Press ZOOM repeatedly to return to the original size.

Resuming playback from the last

stopped point

You can resume playback of the last 10 discs, even if the

disc was ejected or this receiver’s power switched off.

1Load one of the last played 10 discs.

→ “LOAD” appears.

2Press h and the disc will be played back from the last

stop point.

To cancel the resume mode

In stop mode, press s again.

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

ON SCREEN

ZOOM

ANGLE

TOP MENU/

RETURN

SUBTITLE

AUDIO

TITLE

CHAPTER

AUDIO

SUBTITLE

02/02

02/14

5.1CH

OFF

BITRATE 16 TITLE ELASPED 0:02:25

TRACK

TT TIME

CH TIME

REPEAT

02/14

0:49:17

0:03:43

OFF

BITRATE 16 TITLE ELASPED 0:02:25

DISC OPERATION

OPERATIONS

English

Advancing by frame

1During playback, press e on the remote control.

→ Play will pause and sound will be mute.

2Press e again to select the next picture frame.

3To resume normal playback, press h.

Changing sound track language

This operation works only on DVDs with multiple

soundtrack language, you can change the language you

want while playing a DVD.

Press AUDIO repeatedly to select the available audio

languages.

For VCD - changing the audio channel

Press AUDIO repeatedly to select the available audio

channels provided by the disc (STEREO, LEFT MONO,

RIGHT MONO or MIX MONO).

Changing subtitle language (DVD only)

This operation works only on DVDs with multiple subtitle

languages, you can change the language you want while

playing a DVD.

Press SUBTITLE repeatedly to select from the various

subtitle languages.

Viewing from another angle (DVD only)

If the disc contains sequences recorded from different

camera angles, this function allows you to view the picture

from a number of different angles.

Press ANGLE repeatedly to select the desired angle.

→ Playback changes to the selected angle.

Selecting a title (DVD only)

Some DVDs may contain several titles. If the disc has

been recorded with a title menu recorded on it, you can

start playback from the selected movie title.

1Press TOP MENU/RETURN.

→ The disc title menu appears on the TV screen.

2Use / / / or the numeric keypad

(0-9) to select a play option.

3Press ENTER (OK) to confirm.

Playback control (PBC) (VCD only)

PBC playback allows you to play Video CDs interactively,

following the menu on the display.

This function can also be accessed via the

‘PREFERENCE PAGE’ menu (see “PBC” on page 42).

For VCDs with Playback Control (PBC)

feature (version 2.0 only)

With playback stopped, press MENU to toggle between

‘PBC ON’ and ‘PBC OFF’.

→ If you select ‘PBC ON’, the disc menu (if available)

will appear on the TV. Use b / a or the numeric

keypad (0-9) to select a play option and press ENTER

(OK) to confirm.

→ If you select ‘PBC OFF’, the VCD will skip the index

menu and playback directly from the beginning.

DISC OPERATION

Preview function

Preview function includes the following 2 types.

Digest:

This function displays a thumbnail to help you to preview

the following sections of the disc.

TITLE, CHAPTER, GROUP, TRACK

Interval:

This function divides the following options at regular

intervals to help you preview the scene you want to see.

TITLE, CHAPTER, GROUP, TRACK, DISC

The menu appears on the TV screen differs depending on the

Disc or current status (playback or stop).

Preview title/chapter

(DVD for example)

1Press SCAN.

→ The menu appears on the TV screen.

2Press / to highlight [TITLE DIGEST],

[CHAPTER DIGEST], [TITLE INTERVAL] or [CHAPTER

INTERVAL] and press ENTER (OK) to open one

option.

3Use b / a to open the previous or next page.

4Use / / / to select a title/chapter or use

the numeric keypad (0-9) to input the selected title/

chapter number next to [SELECT].

5Press ENTER (OK) to start playback from the scene

you select.

To quit the preview function

Use / / / to highlight [EXIT] and press

ENTER (OK) to confirm.

To return to the preview menu

In step 3 and 4, use / / / to highlight

[MENU] and press ENTER (OK) to confirm.

Note

(Example of 6 thumbnails in the display)

SELECT DIGEST TYPE:

TITLE DIGEST

CHAPTER DIGEST

TITLE INTERVAL

CHAPTER INTERVAL

DISC OPERATION

OPERATIONS

English

■Playing MP3/JPEG/DivX® discs

This receiver can play DivX®, MP3, JPEG, VCD and

SVCD files on a personally recorded CD-R/RW disc or

commercial CD.

You have to turn on your TV and set to the correct Video In

channel (see “Setting a TV” on page 24).

1Load the disc.

→ The disc reading time may exceed 30 seconds due

to the complexity of the directory/file configuration.

→ The disc menu appears on the TV screen.

2Press / to select a desired folder and press

ENTER (OK) to open the folder.

3Press / to select a track/file.

4Press ENTER (OK) to confirm.

→ Playback will start from the selected file to the end

of the folder.

While the disc menu is displayed, you can:

–Press b / a to select another track/file in the

current folder.

– To select another folder from the current disc, press

to return to the root menu, then press / to

make your selection and press ENTER (OK) to

confirm.

–Press e to pause or h to resume playback.

If you press / / / during playback of

JPEG images, the picture rotates.

MP3 disc features

The MP3-CD formats (ISO9660 format)

support the following:

– MP3 files must have the extension “.MP3” or “.mp3”

– Max. 30 characters

– Max. nested directory is 8 levels.

– Max. album number is 99.

– Max. track number is 999.

– Supported sampling rates of 32, 44.1, 48/16, 22.05, and

24 kHz

The following features are not supported

for MP3 discs:

– The discs that have any types of file other than MP3

and JPEG.

– The simultaneous playback of the MP3 and JPEG files.

– Chinese filenames and text.

– Non-finalized closed discs.

– Discs recorded in UDF format.

Additional note for MP3 disc playback:

– The disc read time may exceed 10 seconds due to the

large number of songs compiled onto one disc.

– Multi-session discs are supported.

– The digital output signals of MP3 files are copy

protected.

Downloading MP3 file from the internet or copying songs

from your own legal discs is a delicate process.

Note

MP3

DISC OPERATION

Playing MP3 music and a JPEG picture

simultaneously

1Load an MP3 disc containing both music and picture

data.

→ The disc menu appears on the TV screen.

2Select an MP3 track and press h to start playback.

3During MP3 music playback, select a picture folder

from the TV screen and press h.

→ The picture files will be played back until end of

the folder.

4To quit simultaneous playback, press MENU followed

by s.

– It may not be possible to play certain MP3/JPEG/

DivX® discs due to the configuration and

characteristics of the disc or condition of the

recording.

– It is normal to experience an occasional “skip”

while listening to your MP3 disc.

– It is normal to experience an occasional pixelation

during DivX® playback due to poor clarity of

digital contents during internet downloading.

– For multi-session discs with different formats, only

the first session will be available.

■Playing Super Audio CDs

There are three types of Super Audio CD discs: single

layer, double layer and hybrid discs.

Each type may contain up to two areas of recorded

information: a High Quality Stereo area and a High

Quality Multi-channel area.

–A single layer disc can contain both information

areas.

–A dual layer disc can contain both information

areas. Double the information can be stored on the

disc, thanks to the second layer.

–A hybrid disc can contain both information areas,

and also a second, standard CD layer, making it

playable on standard CD players.

1Load the Super Audio CD.

→ The disc menu appears on the TV screen.

2Playback will start automatically.

– If the Super Audio CD consists of multi-channel and

stereo tracks, multi-channel tracks will have the

priority for playback.

– To playback stereo tracks, use / to make

your selection from the disc menu, then press h.

Programming Super Audio CD tracks is not possible.

Notes

Super Audio CD Disc

Single layer disc

HD layer

Dual layer disc

Hybrid layer disc

HD layer CD layer

HD layer

Note

Hybrid Super Audio CD Disc

CD layer that plays on any

CD player

- High Quality DSD Stereo

- High Quality DSD Multi-

channel

High Density layer containing:

DISC OPERATION

OPERATIONS

English

■Special features for picture disc

playback

1Load a picture disc (Kodak Picture CD/JPEG).

→ For Kodak discs, the slide show begins.

→ For JPEG discs, the picture menu appears on the TV

screen.

2Press h to start the slideshow.

You have to turn on your TV and set to the correct Video In

channel (see “Setting a TV” on page 24).

Preview function

This function shows the content of the current folder or

the entire disc.

1During playback, press s.

→ 12 thumbnail pictures will appear on the TV

screen.

2Press b / a to display the other pictures on the

previous/next page.

3Use / / / to highlight one of the picture

and press ENTER (OK) to start playback.

4Press MENU to return to the picture CD menu.

Zooming pictures

1During playback, press ZOOM repeatedly to select a

different zoom factor.

2Use / / / to move through the zoomed

image.

Multi-angle playback

During playback, use / / / to rotate/flip the

picture on the TV screen.

: flips the picture vertically.

: flips the picture horizontally.

: rotates the picture anti-clockwise.

: rotates the picture clockwise.

Scan effect

Press ANGLE repeatedly to choose a different scan effect.

→ Various scan effects appear in the top left corner of the

TV screen.

Note

DVD SETUP MENU OPTIONS

This setup is carried out via the TV,

enabling you to customize the DVD

receiver to suit your particular

requirements.

■General setup menu

1In DVD/CD mode, press SET UP.

2Press / to select the [GENERAL SETUP

PAGE].

3Press ENTER (OK) to confirm.

Selecting DVD-Audio/Video mode

1In [GENERAL SETUP PAGE], presss / to

highlight [DVD-AUDIO], then press .

DVD-AUDIO MODE

Select this to playback the contents of the DVD-Audio.

DVD-VIDEO MODE

Select this to playback the contents of the DVD-Video.

2Press / to select a setting, then press

ENTER (OK) to confirm your selection.

– The DVD-AUDIO indicator lights up when a

DVD-Audio disc is playing.

– When you select DVD-VIDEO MODE, the

DVD-AUDIO indicator goes out.

Locking/Unlocking discs for viewing

Not all discs are rated or coded by the manufucturer of the

disc. You can prevent playback of a specific disc by

locking the disc. You can lock up to 40 discs on this unit.

1In [GENERAL SETUP PAGE], press / to

highlight [DISC LOCK], then press .

UNLOCK

Select this to unlock the disc and allow future playback.

LOCK

Select this to block playback of the current disc.

Subsequent access to a locked disc requires a sixdigit

password. The default password is ‘000 000’ (see

“Changing the password” on page 43).

2Press / to select a setting and press ENTER

(OK) to confirm.

Programming disc tracks (except

picture CD/MP3/WMA/Super Audio CD

discs)

You can playback the contents of a disc in the order you

want by programming the tracks to be played. You can

store up to 20 tracks.

Program: Track (except for Picture CD/

MP3/ WMA/DivX®)

1Press PROG on the remote control.

In [GENERAL SETUP PAGE], press / to

highlight [PROGRAM], then press to select [INPUT

MENU].

2Press ENTER (OK) to confirm.

DVD SETUP MENU OPTIONS

Notes

DVD AUDIO

DISC LOCK

PROGRAM

OSD LANGUAGE

SCREEN SAVER

DiVX(R) VOD CODE

GENERAL SETUP PAGE

DVD SETUP MENU OPTIONS

ON-SCREEN MENU

English

To program your favorite tracks/chapters

3Use the numeric keypad (0-9) to enter a valid

track/chapter number.

4Use / / / to move the cursor to the next

position.

– If the track number is more than ten, press a to open

the next page and proceed with programming,

– Use / / / to highlight [NEXT] on the

program menu, then press ENTER (OK).

5Repeat steps 3 and 4 to input another track/chapter

number.

To remove a track

6Use / / / to move the cursor to the

track you want to remove.

7Press ENTER (OK) to remove this track from the

program menu.

8To exit the menu, press PROG.

OSD language

This menu contains various language options for

displaying languages on the screen. For details, see “On-

screen display (OSD) language” on page 26.

Screen saver

The screen saver helps prevent your TV display from

becoming damaged.

1In [GENERAL SETUP PAGE], press / to

highlight [SCREEN SAVER], then press .

Select this if you wish to turn off the TV screen when play

is stopped or paused for more than 15 minutes.

OFF

Select this to disable the screen saver function.

2Press / to select a setting and press ENTER

(OK) to confirm.

3To return to the previous menu, press .

To exit the menu, press SET UP.

DivX®VOD registration code

Yamaha provides you with the DivX®VOD (Video On

Demand) registration code that allows you to rent and

purchase videos using the DivX®VOD service. For more

information, go to www.divx.com/vod.

1In [GENERAL SETUP PAGE], press / to

highlight [DIVX(R) VOD CODE], then press .

→ The registration code appears.

2Press ENTER (OK) to exit.

Use the registration code to purchase or rent the videos

from DivX

VOD service at www.divx.com/vod. Follow

the instructions and download the video onto a CD-R/RW

for playback on this receiver.

– All the videos downloaded from DivX®VOD can

only be played back on this receiver.

– The time search function is not available during

DivX® movie playback.

Notes

DVD SETUP MENU OPTIONS

■Audio setup menu

1In DVD/CD mode, press SET UP.

2Press / to select [AUDIO SETUP PAGE].

3Press ENTER (OK) to confirm.

Speaker setup

This menu contains setup options for audio output so that

you can set your speakers to reproduce high quality

surround sound. For details, see “Setting speaker

channels” on page 27.

CD upsampling

This feature allows you to convert your music CD to a

higher sampling rate using sophisticated digital signal

processing for better sound quality.

If you have activated the upsampling function, the

receiver will automatically switch to stereo mode.

1In [AUDIO SETUP PAGE], press / to

highlight [CD UPSAMPLING], then press .

OFF

Select this to disable CD-upsampling.

88.2 kHz (X2)

Select this to convert the sampling rate of CDs to twice

that of the original.

2Press / to select a setting and press ENTER

(OK) to confirm.

If you select “Multi-Channel” mode, the CD

upsampling feature will be cancelled.

Night mode

When night mode is activated, high volume output is

softened and low volume output raised to an audible level

(for DVD playback only). This is useful for watching your

favorite action movie without disturbing others at night.

1In [AUDIO SETUP PAGE], press / to

highlight [NIGHT MODE], then press .

Playback continues at a more even volume and “NIGHT

ON” appears in the display panel.

OFF

Playback continues with the full dynamic range of

surround sound, and “NIGHT OFF” appears in the display

panel.

2Press / to select a setting and press ENTER

(OK) to confirm.

This function is only available for Dolby Digital.

Lip synchronization

This feature allows you to delay the sound output from the

center speaker in order to synchronize it with the video

image. This may be necessary when using certain LCD

monitors or projectors.

Choices: 0 to 200 ms

1In [AUDIO SETUP PAGE], press / to

highlight [LIP SYNC], then press .

2Press / to adjust the delay time (between 0 ms

and 200 ms) and press ENTER (OK) to confirm.

Note

SPEAKER SETUP

CD UPSAMPLING

NIGHT MODE

LIP SYNC

AUDIO SETUP PAGE

Note

DVD SETUP MENU OPTIONS

ON-SCREEN MENU

English

■Video setup menu

1In DVD/CD mode, press SET UP.

2Press / to select [VIDEO SETUP PAGE] icon.

3Press ENTER (OK) to confirm.

TV type

This menu contains the options for selecting the color

system that matches the connected TV. For details, see

“Selecting the TV type” on page 24.

TV display

This menu contains the options for matching the aspect

ratio of the receiver to the connected TV. For details, see

“Setting the TV display” on page 25.

Progressive function

The progressive scan display present 60 complete frames

per seconds, rather than 30 frames per second of interlaced

scanning (ordinary normal TV system). With nearly

double the number of lines, progressive scan offers higher

picture resolution and eliminates bothersome motion

artifacts those jagged edge on moving objects.

Before enabling the progressive scan function, you must

ensure:

1Turn on your TV progressive scan function (refer to

your TV owner’s manual).

2You have connected the DVD receiver to your TV

using Y PB PR (see “Connecting a TV” on page 19).

1In [VIDEO SETUP PAGE], press / to

highlight [PROGRESSIVE], then press .

OFF

Select this to disable progressive scan function.

Select this to enable progressive scan function.

2Press / to select a setting and press ENTER

(OK) to confirm.

→ Follow the instructions shown on the TV to

confirm the selection (if any).

– If a blank/distorted TV screen appears, wait for 15

seconds for auto recovery to activate.

If you are changing the setting to OFF by using the remote

control, follow the procedure below.

1Open the disc tray.

2Press , then press ANGLE.

Picture settings

This receiver comes with three predefined sets of picture

color settings and one personal setting that you can define

yourself.

1In [VIDEO SETUP PAGE], press / to

highlight [PICTURE SETTING], then press .

STANDARD

Select this for the standard picture setting.

BRIGHT

Select this to make the TV picture brighter.

SOFT

Select this to make the TV picture softer.

PERSONAL

Select this to personalize your picture color by

adjusting the brightness, contrast, tint and color

(saturation).

2Press / to select a setting and press ENTER

(OK) to confirm.

3If you selected [PERSONAL], proceed to step 4.

→ The [PERSONAL PICTURE SETUP] menu

appears.

Note

TV TYPE

TV DISPLAY

PROGRESSIVE

PICTURE SETTING

COMPONENT

BLACK LEVEL

CLOSED CAPTION

VIDEO SETUP PAGE

Note

DVD SETUP MENU OPTIONS

4Press / to highlight one of the following

options.

BRIGHTNESS

Increase the value to brighten the picture or vice versa.

Zero (0) is the average setting value.

CONTRAST

Increase the value to sharpen the picture or vice versa.

Zero (0) is the average contrast.

TINT

Increase or decrease the value to change the color

phase of the picture. Zero (0) is the average setting

value.

COLOR

Increase the value to enhance the color in your picture

or vice versa. Zero (0) is the average color setting

value.

5Press / to adjust the setting that best suits your

personal preference.

6Repeat steps 4 and 5 to adjust other color features if

desired.

7Press ENTER (OK) to confirm.

Component

(U.K and Europe models only)

This setting allows you to toggle the output of the video

signal between RGB (on SCART) and Y Pb Pr (YUV).

Selecting the black level (U.S. and

Canada models only)

If you set the TV type to NTSC, set black level shift to

ON. This will improve the color contrast during playback.

The black level setting has no effect if the TV type is set to

PAL.(See “Selecting the TV type” on page 24.)

Select this to enhance the black level.

OFF

Select this for the standard black level setting.

Closed captions

(U.S. and Canada models only)

Closed captions are data hidden in the video signals of

specific discs, and are invisible without the use of a

special decoder. The difference between subtitles and

captions is that subtitles are intended for hearing persons

and captions are for the hearing impaired. Subtitles rarely

show all of the audio. For example, captions show sound

effects (e.g., “phone ringing” and “footsteps”), while

subtitles do not. Before you select this function, please

ensure that the disc contains closed caption information

and your TV set also supports this function.

1In [VIDEO SETUP PAGE], press / to

highlight [CLOSED CAPTION], then press .

To enable the closed caption function.

OFF

To disable the closed caption function.

2Press / to select a setting, then press ENTER

(OK) to confirm your selection.

BRIGHTNESS

CONTRAST

TINT

COLOR

DVD SETUP MENU OPTIONS

ON-SCREEN MENU

English

■Preference setup menu

1Press s twice to stop playback (if necessary), then

press SET UP.

2Press / to select the ‘Preference Setup’ icon.

3Press ENTER (OK) to confirm.

Audio, subtitle and disc menus

These menus contain various language options for the

audio, subtitle and disc menus recorded on the DVD. For

details, see “Audio, Subtitle and Disc menu languages” on

page 26.

Restricting playback with parental

control

Some DVDs may have a parental level assigned to the

complete disc or to certain scenes on the disc. This feature

lets you set a playback limitation level. The rating levels

are from 1 to 8 and are country dependent. You can

prohibit the playing of certain discs that are not suitable

for your children, or play alternative scenes for certain

discs.

1In [PREFERENCE PAGE], press / to

highlight [PARENTAL], then press .

2Press / to highlight a rating level for the disc

inserted and press ENTER (OK).

3Use the numeric keypad (0-9) to enter the sixdigit

password (see “Changing the password” on page 43).

→ DVDs that are rated above the level you select

will not play unless you enter the six-digit password.

AUDIO

SUBTITLE

DISC MENU

PARENTAL

PBC

MP3/JPEG NAV

VR LIST

PASSWORD

PREFERENCE PAGE

AUDIO

SUBTITLE

DISC MENU

PARENTAL

PBC

MP3/JPEG NAV

VR LIST

PASSWORD

1 KID SAFE

2 G

3 PG

4 PG 13

5 PGR

6 R

7 NC 17

8 ADULT

PREFERENCE PAGE

DVD SETUP MENU OPTIONS

Rating explanation

1 KID SAFE

2 G

–General audience; recommended as acceptable for

viewers of all ages.

3 PG

–Parental guidance suggested.

4 PG13

–

Material is unsuitable for children under age 13.

5 PGR

6 R

–Parental guidance - restricted; recommended that

parents restrict children under 17 from viewing, or

allow to view only when supervised by a parent or

adult guardian.

7 NC-17

–Material is unsuitable for children under age 17.

8 ADULT

–Mature material; should be viewed only by adults

due to the inclusion of graphic sexual material,

violence or language.

– VCD, SVCD, CD have no level indication, so the

parental control function has no effect with these

types of discs. This also applies to most illegal

DVDs.

– Some DVDs are not encoded with a rating though

the movie rating may be printed on the disc cover.

The rating level feature does not prohibit play of

such discs.

PBC

You can set PBC to ON or OFF. This feature is available

only on Video CD 2.0 with the playback control (PBC)

feature. For details, see “Playback control (PBC)” on

page 31.

MP3/JPEG navigator

MP3/JPEG navigator can be set only if the disc was

recorded with a menu. It allows you to select different

display menus for easy navigation.

1In [PREFERENCE PAGE], press / to

highlight [MP3/JPEG NAV], then press .

WITH MENU

Select this to display only the folder menu of the MP3/

Picture CD.

WITHOUT MENU

Select this to display all the files contained in the MP3/

Picture CD.

2Press / to select a setting, then press ENTER

(OK) to confirm.

Playback VR format discs

There are two ways to play back a VR (Video Recording)

format discs: ORIGINAL LIST and PLAY LIST. This

feature is not available with non-VR format discs.

1In [PREFERENCE PAGE], press / to

highlight [VR LIST], then press . The following

settings appear:

ORIGINAL LIST

Select this to play the originally recorded titles on the

disc.

PLAY LIST

Select this to play the edited version of the disc. This

feature is only available when a play list has been

created.

2Press / to highlight a setting, then press

ENTER (OK) to confirm.

To play back a VR format disc

3Press SET UP to close the setup menu.

4Press PLAY. The setting you selected begins to play.

To preview VR format

5During playback, press SCAN.

6Press / to highlight either [TITLE DIGEST]

or [TITLE INTERVAL].

7Press ENTER (OK) to confirm.

Notes

DVD SETUP MENU OPTIONS

ON-SCREEN MENU

English

TITLE DIGEST

This function will display thumbnails of titles on the

screen. A maximum of six thumbnails are displayed

per page.

→ In ORIGINAL LIST mode, the originally recorded

titles on the disc are displayed.

→ In PLAY LIST mode, every title in the play list is

displayed.

TITLE INTERVAL

This function will divide and display the contents of

each title being played back in regular intervals,

making it easy to preview the recording. A maximum

of six thumbnails are displayed per page.

→ If the title being played back is short, the TITLE

DIGEST function will be performed instead.

Changing the password

The same password is used for both parental control and

disc lock. Enter your six-digit password to play a

prohibited disc or if prompted

for a password. The default password is ‘000 000’.

In [PREFERENCE PAGE], press

highlight [PASSWORD], then press

to select

[CHANGE].

2Press ENTER (OK) to enter the ‘Password Change

Page.

3Use the numeric keypad (0-9) to enter your old six-

digit password.

– When doing this for the first time, enter ‘000 000’.

– If you forget your old six-digit password, enter ‘000

000’.

4Enter the new six-digit password.

5Enter the new six-digit password a second time to

confirm.

→ The new six-digit password is now valid.

6Press ENTER (OK) to confirm.

Changing the DivX subtitle

If the video donwloaded from DivX®VOD has subtitles,

you can select its character code.

1In [PREFERENCE PAGE], press / to

highlight [DIVX SUBTITLE], then press to select

[STANDARD].

2Press ENTER (OK) to confirm.

If you can’t read the subtitle, select [CYRILLIC].

Restoring to the factory defaults

Setting the DEFAULT function will reset all options and

your personal settings to the factory defaults, except your

password for Parental Control and Disc Lock.

1In [PREFERENCE PAGE], press / to

highlight [DEFAULT], then press to select

[RESET].

2Press ENTER (OK) to confirm.

→ All settings are reset to the factory defaults.

AUDIO

SUBTITLE

DISC MENU

PARENTAL

PBC

MP3/JPEG NAV

VR LIST

PASSWORD CHANGE

PREFERENCE PAGE

Note

TUNER OPERATIONS

Make sure the FM and AM antennas are connected to this

receiver.

■Tuning radio stations

1Press TUNER to select “TUNER/FM” or “TUNER/

AM”.

2Press / briefly on the remote control.

→ “SEARCH” appears.

→ The next radio station is tuned automatically.

3Repeat step 2 (if necessary) until you find the desired

radio station.

4To tune weak stations, press / briefly and

repeatedly until the optimal reception is found.

If the FM station reception is weak, you can switch the

FM mode from stereo to mono. Press SURR to toggle

through:

DOLBY PL II FM STEREO

→ DOLBY PL II FM MONO

→ STEREO FM MONO

→ STEREO FM STEREO

(U.K. and Europe models only)

While receiving an FM station, the name of the station

you selected appears in the system display panel.

■Presetting radio stations

You can store up to 20 FM and 10 AM preset radio

stations in this receiver’s memory.

– The receiver will exit presetting mode if no button

is pressed within 20 seconds.

– If no valid frequency is detected during Plug and

Play, “CHECK ANTENNA” appears.

Using Plug and Play

Plug and Play allows you to store all available radio

stations automatically.

1Press TUNER.

→ “AUTO PRESET” and “PRESS PLAY” appear one

after the other if installation was not completed after

you purchased the DVD receiver.

2Press on the front panel to start installation.

→ “AUTO PRESET” appears.

→ Once complete, the last tuned radio station will

play.

→ All available FM stations are stored, followed by

all available AM stations.

To stop installation

Press s.

Automatic presetting

You can start automatic presetting by pressing a selected

preset number.

1Press TUNER to select “TUNER/FM” or “TUNER/

AM”.

2Press b / a or use the numeric keypad (0-9)

to select a preset number to begin.

TUNER OPERATIONS

Note

Notes

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

Numeric

keypad (0-9)

PROGRAM

dPRESETu

(b / a)

TUNER

TUNER OPERATIONS

OTHER FEATURES

English

3Press and hold PROG until “AUTO PRESET” appears.

→ If a radio station is stored in one of the earlier

presets, the same radio station will not store under

another preset number.

→ If no preset number is selected, automatic preset

will begin from preset (1) and all former presets will

be overridden.

Manual presetting

You can choose to store only your favourite radio stations.

1Tune the desired radio station (see “Tuning radio

stations” on page 44).

2Press PROG.

3Press b / a to select a preset number.

4Press PROG again to store.

Selecting a preset radio station

Press b / a or use the numeric keypad (0-9) to

select a preset number.

→ The waveband, preset number, then radio frequency

appears.

Deleting a preset radio station

Press and hold s on the front panel until “AM XX

DELTD” or “FM XX DELTD” (XX: preset number) appears.

→ The current preset radio station is deleted.

Setting frequency step

(Asia except Korea model)

The inter-station frequency spacing differs depending on

the areas. Set the frequency step according to the

frequency spacing in your area.

Choices:AM9kHz/FM50kHz, AM10kHZ/FM100kHz

Default setting: AM9kHz/FM50kHz

To change the AM band to 10kHz and the

FM band to 100kHz

1Unplug the AC power cord from the DVD receiver

and wait at least one minute.

2While pressing and holding INPUT and b on the

front panel, plug the AC power cord to the DVD

receiver.

3After “CINEMA STATION” scrolls in the display panel,

release the keys.

Repeat the above steps 1 to 3 to change AM band to 9kHz

and FM band to 50kHz.

Note

SOUND CONTROLS

For proper surround sound, make sure the speakers and

subwoofer are connected to this receiver (see “Connecting the

subwoofer” on page 17).

■Selecting surround sound

– Press SURR on the remote control to select:

MULTI-CHANNEL or STEREO.

– The availability of the various surround sound modes

depends on the number of speakers used and the sound

available on the disc.

– The center and surround speakers operate only in

multi-channel surround mode.

– Stereo broadcasts or recordings produce some

surround channel effects when played in a surround

mode. However, mono (single channel sound) sources

do not produce any sound from the surround speakers.

The surround sound mode cannot be selected if the system

setup menu is selected.

■Selecting digital sound effects

You can select preset digital sound effects that match the

content of your disc, or that optimize the sound of the

musical style you are playing.

Press EFFECT to select from the available sound

effects.

When playing movie discs or while in TV mode, you

can select:

CONCERT, DRAMA, ACTION or SCI-FI.

When playing music discs or while in TUNER or AUX

mode, you can select:

ROCK, DIGITAL, CLASSIC or JAZZ.

– Digital sound effects and the treble/bass features

cannot be activated at the same time.

– For flat sound output, select CONCERT or

CLASSIC.

■Adjusting the treble/bass level

The TREBLE (high tone) and BASS (low tone) features

enable you to define the sound-processor settings.

1Press TRE or BASS on the remote control.

2Within five seconds, press VOL (+/–) to adjust the

treble or bass level (MIN, –2, –1, 0, +1, +2 or MAX).

→ If the volume control is not used within five

seconds, it will resume its normal volume control

function.

SOUND CONTROLS

Note

TV VOL TV CH

EFFECT SURR

VOL

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

INPUT

MUTE

NIGHT

TRE

BASS

TRE/BASS

EFFECT

SURR

VOL (+/–)

Notes

SOUND CONTROLS

OTHER FEATURES

English

■Adjusting the volume level

Use the VOLUME control (or press VOL (+/–) on the

remote control) to increase or decrease the volume

level.

→ “VOL MIN” is the minimum volume level and

“VOL MAX” is the maximum volume level.

To mute the volume temporarily

Press MUTE on the remote control.

– Playback continues without sound and “MUTE”

appears.

– To restore the volume, press MUTE again or

increase/decrease the volume level.

■Night listening mode

When night listening mode is activated, high volume

output is softened and low volume output raised to an

audible level (for DVD playback only). This is useful for

watching your favorite action movie without disturbing

others at night.

This function is only available for Dolby Digital.

–Press NIGHT on the remote control to activate the

night listening mode.

→ Playback continues at a more even volume and

“NIGHT ON” appears in the display panel.

– To restore the volume, press NIGHT again.

→ Playback continues with the full dynamic range of

surround sound, and “NIGHT OFF” appears in the

display panel.

■Switching to active mode

–Press TUNER repeatedly on the remote control to

select the appropriate active mode.

Each time you press TUNER, the front display

changes as follows:

TUNER/FM

– Press AUX repeatedly on the remote control to select

the appropriate active mode.

Each time you press AUX, the front display changes as

follows;

AUX/ANALOG

AUX/DIGITAL

■Switching to standby mode

Press STANDBY/ON on the front panel or POWER

( ) on the remote control.

→ The display screen goes blank.

OTHER FUNCTIONS

■Setting remote control codes

Once you set the appropriate remote control codes, you

can use this remote to control your other components. The

remote control automatically switches to the appropriate

control mode for that component.

For TV, you can set a TV remote control code and for

AUX, you can set a cable or satellite tuner remote control

code.

1Press and hold TV or AUX.

2Press PROG, then release both keys.

3Press the numeric keypad (0-9) to enter the 4 digit

remote control codes (see “LIST OF REMOTE

CONTROL CODES” at the end of this manual).

4Press PROG again to store.

■Controlling other components

You can operate other components if you have set the

remote control code for your component in the remote

control. Note that some buttons may not correctly operate

the selected component.

TV operations

Press TV for TV operations.

Functions for TV operation

POWER (TV)*

Turns on the TV, or sets it to the standby mode.

TV VOL (+/–)*

Adjusts the TV volume level.

TV INPUT*

Switches the TV inputs.

Numeric keypad (0-9)

Enters a number of a TV channel.

TV CH (+/–) *

Switches TV channels.

* You can also operate these functions in DVD/ CD or

TUNER mode.

OTHER FUNCTIONS

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDI O ANGLE ZOOM

TV AUX TUNER DVD/CD

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

INPUT

Numeric

keypad (0-9)

PROG

TV AUX

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDI O ANGLE ZOOM

TV AUX TUNER DVD/CD

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

INPUT

Numeric

keypad (0-9)

POWER (TV)

TV INPUT

TV CH (+/–)

TV VOL (+/–)

OTHER FUNCTIONS

OTHER FEATURES

English

Cable and satellite tuner operations

Press AUX for the cable and satellite tuner operations.

Functions for cable and satellite tuners

POWER (TV)

Turns on the cable and satellite tuner, or sets them to the

standby mode.

ENTER (OK)

Confirms a selection.

Numeric keypad (0-9)

Cable: enters a number of a cable channel.

Satellite tuner: enters a number of a preset radio station.

TV CH (+/–)

Switches the cable or satellite tuner channel.

■Dimming the display screen

In any active mode, press DIMMER on the remote control

to select the desired brightness:

DIM 1: 70% brightness

DIM 2: 40% brightness

DIM OFF: normal brightness

■Setting the sleep timer

The sleep timer switches the receiver to Eco Power

standby mode automatically at the preset time.

1Press SLEEP on the remote control until “SLEEP XX”

appears in the display panel (XX: 15, 30, 45, 60 or

OFF).

2To select the next sleep timer value, continue pressing

SLEEP while in sleep timer mode until the desired

turn-off time is displayed.

→ “SLEEP” appears in the display panel, except when

“SLEEP OFF” is selected.

→ Before the receiver switches to Eco Power standby

mode, a countdown of 10 seconds is displayed.

“SLEEP 10” → “SLEEP 9”.... →

“SLEEP 2” → “SLEEP 1”

To cancel the sleep timer

Press SLEEP until “SLEEP OFF” appears.

■Recording on an external AV

component

1Connect the external recording component to LINE

OUT (see “Connecting external AV components” on

page 21).

2Select the source to record from this DVD receiver

(DVD/CD, TUNER, TV or AUX) and start playback

(if necessary).

3Start recording on the external recording device.

Refer to the owner’s manual of the connected

component for details.

TV VOL TV CH

EFFECT SURR

VOL

TRE

SET UP

PRESET

SUBTITLE AUDIO ANGLE ZOOM

TV AUX TUNER DVD/CD

MUTE

BASS

ENTER

TOP MENU/RETURN

ON SCREEN

PROG

REPEAT A - B

SHUFFLE

SCAN

PAG E

DIMMER

POWER POWER

SLEEP

NIGHT

INPUT

Numeric

keypad (0-9)

POWER (TV)

ENTER (OK)

TV CH (+/–)

Note

TROUBLESHOOTING

If there is any problem with your CinemaStation system, check the following items. If you cannot solve your problem

with the following remedies or if your problem is not listed below, turn off and unplug the CinemaStation, then

consult the nearest authorized YAMAHA dealer or service center.

TROUBLESHOOTING

Problem Solution

No power Check if the AC power cord is properly connected.

Press STANDBY/ON on the front of the receiver to turn on the power.

No picture Refer to your TV’s manual for correct Video In channel selection. Change

the TV channel until you see the DVD screen.

Press DVD/CD on the remote control in order to switch to DVD/CD mode.

Completely distorted picture or

black/white picture

If this happens when you are changing the setting of the ‘TV TYPE’, wait

for 15 seconds for auto recovery.

If this happens when you are turning on the progressive scan feature, wait

for 15 seconds for auto recovery.

Check the video connection.

Sometimes a small amount of pisture distortion may appear.

This is not a malfunction.

Clean a disc.

The aspect ratio of the screen cannot be charged

even though you have set the TV display

The aspect ratio is fixed on the DVD disc.

Depending on the TV, it may not be possible to change the aspect ratio.

No sound or distorted sound Adjust the volume.

Check if the system cable is properly connected.

Check if all speaker cables are properly connected.

Make sure that the audio cables are connected and press the Input selection

buttons to select the correct input source (TV or AUX, for example) to

choose the equipment that you want to hear through the DVD receiver.

Check if the AC power cord of the subwoofer is properly connected.

Make sure that you use a disc supported by the DVD Player.

No sound or picture Check that the RGB/SCART cable is connected to the correct device (see

“Connecting a TV” on page 19).

Sound is too low on one side Check if all cables are properly connected.

Cannot activate some features such as Angles,

Subtitles, or multi-language Audio

The features may not be available on the DVD.

Changing the language for the sound or subtitle is prohibited on the DVD.

DVD videos cannot be copied with the VCR Most commercially available DVD’s include copy protect features. You

cannot make a copy of these DVD’s.

The disc is ejected without an operation Make sure that you use a disc supported by the DVD receiver.

Not able to select some items in the setup/system

Press STOP twice before selecting the setup/system menu.

Depending on the disc availability, some menu items cannot be selected.

The DVD receiver does not start playback Insert a readable disc with the playback side facing down. The DVD-R/

DVD+R/DVD-RW/DVD+RW/CD-R/CD-RW/DVD-RW (VR format)

must be finalized.

Check the disc type, color system (PAL or NTSC) and region code.

Check for any scratches or smudges on the disc.

Press SET UP to turn off the setup menu screen.

You may need to enter the password in order to change the parental control

rating level or to unlock the disc for playback.

Moisture has condensed inside the player. Remove the disc and leave the

receiver turned on for about an hour.

TROUBLESHOOTING

OTHER FEATURES

English

Problem Solution

Sound played on the DVD receiver cannot be

recorded with an external recorder

Use proper audio sources.

Sounds played on the AV equipment connected to

the DVD receiver cannot be recorded with external

recording equipment

Connect those equipment to the DVD receiver with along connections.

The volume does not increase or sounds are

distorted

Turn on the power of the component connected to the DVD receiver.

There is no sound from the center, surround

speakers and subwoofer

Make sure the center, surround speakers and subwoofer are connected correctly.

Adjust the volume level in the setup menu.

Press SURR button to select a correct surround sound setting.

Make sure the source you are playing is recorded or broadcast in surround

sound (DTS, Dolby Digital, etc.).

“SPEAKER ERR” appears in the display panel Unplug the subwoofer, then make sure the front, center and surround speakers

are connected correctly.

Set the DVD receiver to the standby mode, then disconnected the power cord.

Wait for about 30 seconds, then reconnect the power cord and turn on the DVD

receiver.

Radio reception is poor If the signal is too weak, adjust the antenna or connect an external antenna for

better reception.

Increase the distance between the receiver and your TV or VCR.

Tune in to the correct frequency.

Place the antenna farther away from any equipment that may be causing the

noise.

The remote control does not function properly Select the source (DVD/CD or TUNER, for example) before pressing the

function button (h, b / a).

Reduce the distance between the remote control and the receiver.

Replace the batteries with new ones.

Point the remote control directly toward the remote control sensor.

Check that the batteries are loaded correctly.

The remote control does not work for operating

other equipment

Set the correct remote control code. Depending on the model and year of the

product, the DVD receiver’s remote control may not be able to operate it partly

or wholly. In this case, use the remote control supplied with each product.

Unable to play DivX® movies Check that the DivX® file was encoded in ‘Home Theater’ mode with a DivX®

5.x encoder.

The DVD receiver does not work Disconnect the power cord from the power outlet for a few minutes. Reconnect

the power cord and try to operate again as usual.

GLOSSARY

Analog

Sound that has not been turned into numbers.

Analog sound varies, while digital sound has specific

numerical values. These jacks send audio through two

channels, the left and right.

Aspect ratio

The ratio of vertical and horizontal sizes of a displayed

image. The horizontal vs. vertical ratio of conventional

TVs. is 4:3, and that of wide-screens is 16:9.

Bit

Short for binary digit. Represents the smallest unit of

information manipulated on a computer. In audio

systems, the bit size determines resolution to digitize

analog signals.

The larger the bit size, the larger the dynamic range (the

ratio of maximum and minimum frequency level) and

the finer the sounds. Generally, an audio CD is 16 bit

and DVD audio is 24 bit.

Bit rate

The amount of data used to hold a given length of

music; measured in kilobits per second, or kbps. Also,

the speed at which you record. Generally, the higher the

bit rate, or recording speed, the better the sound quality.

However, higher bit rates use more space on a disc.

COMPONENT VIDEO OUT

Jacks for inputting or outputting a component video

signal.Component video signal consists of three lines,

the luminance signal (Y) and two color difference

signals (P

, P

), which enable to provide high-

quality video.

Disc menu

A screen display prepared for allowing selection of

images, sounds, subtitles, multi-angles, etc. recorded on

a DVD.

DivX

is a video compression technology developed by

DivX

Networks, Inc. It compresses digital video data to

sizes small enough to be transported over the Internet

without reducing the original video quality. You need

DivX codec software to play back DivX movies or

convert data to the DivX format.

Dolby Digital

Digital surround sound system which is developed by

Dolby Laboratories provides completely independent

multi-channel audio. With 3 front channels (left, center,

and right) and 2 surround stereo channels, Dolby Digital

provides five full-range audio channels. With an

additional channel especially for bass effects (called

LFE, or low frequency effect), the system has a total of

5.1-channels (LFE is counted as 0.1 channel). By using

2-channel stereo for the surround speakers, more

accurate moving sound effects and surround sound

environment are possible than with Dolby Surround.

Dolby Surround Pro Logic II

It is an improved matrix decoding technology that

provides better spatiality and directionality on Dolby

Surround programme material; provides a convincing

three-dimensional soundfield on convertional stereo

music recordings; and is ideally suited to bring the

surround experience to automotive sound. While

conventional surround programming is fully compatible

with Dolby Surround Pro Logic II decoders,

soundtracks will be able to be encoded specifically to

take full advantage of Pro Logic II playback, including

separate left and right surround channels. (Such material

is also compatible with conventional Pro Logic

decoders).

DTS (Digital Theater Systems)

Digital surround sound system developed by Digital

Theater Systems, Inc., which provides 5.1 channel audio

(max). With an abundance of audio data, it is able to

provide authentic-sounding effects.

Interlace

The most common type of scanning used in televisions.

It divides a screen into even and odd numbered fields for

scanning, and then builds an image by combining them

into one image (frame).

JPEG (Joint Photographic Expert Group)

A standardized image compression system proposed by

the Joint Photographic Expert Group. It can reduce

image data sizes to 1 to 10% of their original sizes, and

works on digital photographs effectively.

MP3 (MPEG Audio Layer-3)

An audio file compression technology. It can reduce

audio data sizes to about 10% of their original sizes

while maintaining CD-level audio quality.

MPEG (Moving Pictures Experts Group)

International standard for digital video and audio

compression generated by ISO (International

Organization for Standardization) and IEC

(International Electrotechnical Commission).

Includes MPEG-1, MPEG-2, and MPEG-3. MPEG-1

offers VHS level video quality and is often used on

video CDs. MPEG-2 offers S-VHS level video quality

and is often used on DVDs.

GLOSSARY

OTHER FEATURES

English

Parental control

Limits Disc play according to the age of the users or the

limitation level in each country. The limitation varies

from disc to disc; when it is activated, playback will be

prohibited if the software’s level is higher than the user-

set level.

Playback control (PBC)

An on-screen menu recorded on a Video CD or SVCD

that enables interactive playback and searching.

Progressive Scan

A method of displaying all scanning lines in a frame at

once, reducing flicker noticeable on a larger screen and

creating a sharp and smooth image.

Region code

Many DVD discs include a region code so that the

only to regions where they are ready to distribute. There

are six regions codes, which restrict a DVD player to

playing a DVD disc with the same region code.

S-video output

A jack for inputting or outputting an S-video signal.

S-video signal consists of two lines, the luminance

signal (Y) and color signal (C), which enable to provide

high-quality video during playback or recording.

Super Audio CD

This audio format is based upon the current CD

standards but includes a greater amount of information

that provides higher quality sound. There are three types

of discs: single layer, double layer and hybrid discs. The

hybrid disc can be played on existing CD players as well

as Super Audio players since it contains both standard

audio CD and Super Audio CD information.

Surround

A receiver for creating realistic three-dimensional sound

fields full of realism by arranging multiple speakers

around the listener.

VR format (Video Recording format)

A DVD video recording format, which allows editing

DVD video data recorded onto a disc. You need a VR

format compatible player for playback.

SPECIFICATIONS

DVD RECEIVER DVX-S300

TUNER SECTION

FM Tuning Range 87.50 to 108.00 MHz

AM Tuning Range

- Canada model 530 to 1700 kHz

- Europe, U.K., Australia and Korea models

531 to1602 kHz

- Taiwan and Asia models 531 to 1602 kHz/530 to 1700 kHz

DISC SECTION

Laser Type Semiconductor

Disc Diameter 12 cm/8cm

Video Decoding MPEG-1 /MPEG-2/DivX 3.11, 4.x & 5.x

Video DAC 12 bits/108 MHz

Signal System PAL/NTSC

Video Format 4:3/16.9

Composite Video Output 1.0 Vp-p, 75 ohm

S-video Output Y - 1.0 Vp-p, 75 ohm

C - 0.3 Vp-p, 75 ohm

RGB (SCART) output 0.7 Vp-p, 75 ohm

Component Video Output Y - 1.0 Vp-p, 75 ohm

PB/CB PR/CR – 0.7 Vp-p, 75 ohm

Audio DAC 24 bits/192 kHz

Frequency Responce 4 Hz – 20 kHz (44.1 kHz)

4 Hz – 22 kHz (48 kHz)

4 Hz – 44 kHz (96 kHz)

Audio S/N 105 dB

Distortion 0.0035%

Dynamic Range 95 dB

AUDIO FORMAT

Digital Dolby Digital/DTS/MPEG Compressed Digital

PCM 16, 20, 24 bits

fs 44.1, 48, 88.2, 96, 176.4, 192 kHz

MP3 (ISO 9660) 24, 32, 56, 64, 96, 128, 256 kbps

fs 16, 22.05, 24, 32, 44.1, 48 kHz

WMA 32 to 192 kbps, mono, stereo

Full decoding of Dolby Digital and DTS multi-channel sound

Dolby Surround Compatible Downmix from Dolby Digital

multi-channel sound

Dolby Pro Logic II

GENERAL

Power Supply

- Canada model 120 V, 60 Hz

- Australia model 240 V, 50 Hz

- Europe and U.K. models

230 V, 50 Hz

- Taiwan model 110–120 V, 50/60 Hz

- Asia model 220–240 V, 50/60 Hz

- Korea model 220 V, 60 Hz

Power Consumption 15W

Frequency Response 20 Hz to 20 kHz/–3 dB

(Front, Center, Surround)

Signal-to-Noise Ratio > 95 dB

Input Sensitivity

- AUX In, TV In 300 mV

-SCART In

(Europe and U.K. models only)

500 mV

Dimensions (W x H x D) 360 x 53 x 310 mm

Weight 2.7 kg

CENTER SPEAKER

NX-C301

System 2-way system

Impedance 6 Ω

Speaker Drivers 7.0 cm woofer x 2 + 1.9 cm tweeter

Frequency Response 100 Hz – 20 kHz

Dimensions (W x H x D) 300 x 84 x 78 mm

Weight 1.0 kg

NX-C302

System Full range system

Impedance 6 Ω

Speaker Drivers 5.0 cm Full range x 3

Frequency Response 100 Hz – 20 kHz

Dimensions (W x H x D) 328 x 98 x 64 mm (with stand)

Weight 0.7 kg

FRONT AND SURROUND SPEAKERS

NX-S301

System 2-way system

Impedance 6 Ω

Speaker Drivers 7.0 cm woofer + 1.9 cm tweeter

Frequency Response 100 Hz – 20 kHz

Dimensions (W x H x D) 83 x 181 x 78 mm

Weight 0.6 kg

NX-S302

System Full range system

Impedance 6 Ω

Speaker Drivers 5.0 cm Full range + 2.5 cm piezo tweeter

Frequency Response 100 Hz – 20 kHz

Dimensions (W x H x D) 210 x 994 x 210 mm (with stand)

Weight 3.0 kg

SPECIFICATIONS

OTHER FEATURES

English

SUBWOOFER

NX-SW300

Power Supply Rating

- Taiwan model 110–120 V, 50/60 Hz

- Asia model 220–240 V, 50/60 Hz

- Korea model 220 V, 60 Hz

Power Consumption 360 W

System Bass Reflex System

Impedance 6 Ω

Speaker Driver 16 cm woofer

Frequency Response 40 Hz – 100 Hz

Dimensions (W x H x D) 178 x 402 x 461 mm

Weight 12 kg

Amplifire Section

Output Power

- Front 150 W (10% THD, 1 kHz)/channel

- Surround 150 W (10% THD, 1 kHz)/channel

- Center 150 W (10% THD, 1 kHz)

- Subwoofer 150 W (10% THD, 100 Hz)

NX-SW301

Power Supply Rating

- Canada model 120 V, 60 Hz

- Australia Model 240 V, 50 Hz

- Europe and U.K. models

230 V, 50 Hz

- Taiwan model 110–120 V, 50/60 Hz

- Asia model 220–240 V, 50/60 Hz

- Korea model 220 V, 60 Hz

Power Consumption 200 W

System Bass Reflex System

Impedance 6 Ω

Speaker Driver 16 cm woofer

Frequency Response 40 Hz – 100 Hz

Dimensions (W x H x D) 200 x 390 x 382 mm

Weight 11.5 kg

Amplifire Section

Output Power

- Front 75 W (10% THD, 1 kHz)/channel

- Surround 75 W (10% THD, 1 kHz)/channel

- Center 75 W (10% THD, 1 kHz)

- Subwoofer 75 W (10% THD, 100 Hz)

Specifications subject to change without prior notice.

LIST OF REMOTE CONTROL CODES

LISTE DES CODES DE COMMANDE

Yamaha 1009, 1011, 1036, 1068

Admiral 1033, 1080

Aiko 1032

Akai 1011

Alba 1005, 1013, 1014, 1064, 1076

AOC 1009, 1011

Audiovox 1032, 1053, 1079, 1083

Belcor 1009

Bell & Howell 1007, 1039

Blaupunkt 1055, 1056, 1059, 1082

Blue sky 1064

Bradford 1053

Brandt 1035, 1057, 1058

Brokwood 1009

Bush 1005, 1013, 1014, 1064, 1070, 1072, 1076, 1077

Candle 1011, 1021

Clatronic 1030, 1067, 1075

Contec 1053

Craig 1043, 1053

Croslex 1020

Crown 1016, 1053, 1078

Curtis Mathis 1007, 1011, 1016, 1017, 1018, 1020, 1021, 1022

CXC 1053

Daewoo 1009, 1016, 1023, 1032, 1039, 1079, 1083, 1084

Daytron 1009

Dual 1063

Dumont 1008, 1009

Emerson 1009, 1015, 1016, 1039, 1050, 1051, 1052, 1053, 1065,

1070,1080, 1083, 1084

Envision 1011

Ferguson 1004, 1014, 1028, 1035, 1054, 1066, 1071

First line 1005, 1062, 1063, 1067, 1072, 1074

Fisher 1039

Funai 1048, 1052, 1053, 1069

Futuretec 1053

GE 1010, 1017, 1018, 1033, 1051, 1070, 1079, 1088, 1090

Gibralter 1008, 1009, 1011

LG/Goldstar 1002, 1003, 1009, 1011, 1014, 1016, 1021, 1052

Goodmans 1013, 1014, 1027, 1063, 1076, 1077

Grundig 1026, 1055, 1056, 1082

Harvard 1024, 1053

Hitachi 1015, 1021, 1036

ICE 1063, 1069, 1076

Itt/Nokia 1044

JC Penny 1003, 1009, 1010, 1011, 1016, 1017, 1018, 1021, 1022,

1040, 1051, 1090

JVC (Victor) 1013, 1019, 1025, 1042

Kendo 1014

Kenwood 1009, 1011

KTV 1011, 1016, 1053

Loewe 1029

Magnavox 1011, 1013, 1020, 1052

Marantz 1011, 1014, 1020

Matsui 1005, 1012, 1013, 1014, 1027, 1060, 1063, 1072, 1076

MGA 1009, 1011, 1037, 1049

Mitsubishi 1009, 1033, 1034, 1038, 1081

MTC 1009, 1011, 1021, 1022, 1062, 1081

Multitec 1053

NEC 1009, 1011, 1013, 1021, 1047

Nikko 1011, 1032, 1051

Nokia 1044

Nordmende 1035, 1057, 1058, 1071

NTC 1062

Oceanic 1044, 1061

Onwa 1053

Panasonic 1018, 1043, 1068, 1086

Philco 1009, 1011, 1020, 1036, 1080

Philips 1014, 1020

Pilot 1009, 1011, 1016

Pioneer 1015, 1046, 1049, 1085, 1086

Portland 1009, 1016, 1032

Quasar 1018, 1045, 1068

Radio Shack 1009, 1011, 1016, 1017, 1021, 1038, 1044, 1049, 1051

RCA 1009, 1015, 1017, 1018, 1031, 1033, 1087, 1088, 1089,

1090, 1091

Realistic 1009, 1011, 1016, 1021, 1039, 1045, 1051, 1053

SABA 1029, 1035, 1044, 1057, 1058, 1071

Sampo 1011, 1016

Samsung 1009, 1011, 1014, 1021, 1022, 1031, 1051

Sanyo 1039, 1060, 1079

Schneider 1014, 1064, 1067, 1073, 1076

Scott 1009, 1051, 1052, 1053, 1065

Sharp 1016, 1033, 1045

Shogun 1009

Siemens 1014, 1041, 1055, 1056, 1059, 1082

Signature 1007

Sony 1001, 1006

Soundesign 1051, 1052, 1053

Starlite 1053

Sylvania 1011, 1020

Telefunken 1021

Thomson 1035, 1057, 1058, 1071

Toshiba 1012, 1013, 1022, 1039, 1040

Videch 1009, 1013, 1051

Wards 1007, 1009, 1010, 1011, 1020, 1021, 1045, 1051, 1052

CABLE

ABC 3002, 3003, 3004, 3006, 3008

Andover 3037

Bell & Howell 3006

Birgmingham Cable

3020

Communication

British Telecom 3002, 3012

Cabletime 3016, 3019, 3025, 3029

Contec 3009

Clyde 3011

Cryptovision 3038

Daehan 3043

Daeryung 3003

Decsat 3027

Everquesst 3007

Filmnet 3028

France Telecom 3030

GEC 3011

Gemini 3007

General Instrument

3004, 3020, 3031, 3046

Goldstar 3014, 3047

Grundig 3035

Hamlin 3052, 3067, 3050, 3057, 3068

Hitachi 3004

Jasco 3007

Jerrold 3002, 3004, 3005, 3006, 3007, 3020, 3031, 3046

LG Alps 3044

Magnavox 3055, 3071

Memorex 3001

Mnet 3009, 3028

Motorola 3074, 3075, 3076 3077, 3078, 3079, 3080, 3081, 3082,

3083, 3084, 3085, 3086, 3087, 3088, 3089, 3090, 3091

Now 3041

Oak 3009

Pacific 3039

Panasonic 3001, 3013

Paragon 3001

Philips 3061, 3054, 3055, 3056, 3065, 3069, 3071

Pulsar 3001

Pioneer 3010, 3014, 3018, 3036

PVP Stereo 3002

09_Code_DVX-C300_CA.fm Page ii Wednesday, June 8, 2005 1:10 PM

iii

Visual Matrix

Quasar 3001

Radio Shack 3051, 3070 3072 3073

Rembrandt 3004

Runco 3001

Salora 3026

Samsung 3014, 3040

Satbox 3024

Scientific 3003, 3032, 3049

Scientific Atlanta

3003, 3008, 3021

Seawoo 3045

Signal 3007

Signature 3004

Starcom 3002, 3007

Stargate 3007

Starquest 3007

STS 3015

Taihan 3043

Teleservice 3022

Tele+1 3028

Tudi 3023

Tusa 3007

Tocom 3005

Tongkook 3042, 3048

Toshiba 3001

United Cable 3002

Universal 3061, 3053, 3060, 3062, 3063

Videoway 3017

Viewstar 3059, 3055, 3058, 3064, 3066

Visicable+ 3033

Westminster 3012

Wolsey Gene 3037

Zenith 3001, 3034

SATELLITE TUNER

Absat 4006

AST 4027

Alba 4029, 4034, 4037, 4052

Aldes 4019

Amstrad 4003, 4016, 4025, 4038, 4039, 4042

Ankard 4013, 4019, 4030, 4044

Anttron 4009, 4034

Armstrong 4015

Astra 4005

Astro 4008, 4039, 4045

Avalon 4031

Axis 4030, 4046

Beko 4010

Best 4030

Blaupunkt 4008

Boca 4015, 4043

Brain Wave 4022

British Sky 4058

Broadcasting

BT 4053

Bush 4002

CNT 4045

Cambridge 4024

Canal Satellite 4059

Canal+ 4059

Channel Master 4029

Comlink 4019

Connexions 4031

Crown 4015

Cyrus 4011

D-Box 4054

DDC 4029

DNT 4011, 4031

Echostar 4031, 4036, 4061

Emanon 4034

Ferguson 4002, 4009, 4010, 4023

Fidelity 4016

Finlux 4005, 4024, 4032, 4037

Fracarro 4061

Freecom 4034

Fujitsu 4094 4012

FTE Humax 4060

Fube 4030, 4031, 4034

G-sat 4009

Galaxis 4019, 4057, 4060

General Instrument

4085, 4080, 4069, 4082, 4083, 4092

Gold Box 4059

Gooding 4048

Goodmans 4010

Grundig 4008, 4010, 4048

Hinari 4009

Hirschimann 4008, 4032, 4039, 4040, 4049

Hitachi 4037

Houston 4053

Hughes 4088

Huth 4013, 4015, 4019, 4026

ITT 4005

Invideo 4061

Intervision 4050

Johansson 4022

JVC 4048

Kathrein 4004, 4006, 4008, 4011, 4035, 4041

Kreiselmeyer 4008

Kyostar 4034

La Sat 4043, 4045

Lenco 4034

Lennox 4050

Lupus 4030

Luxor 4005, 4049

Magnavox 4087

Manhattan 4037, 4045, 4050

Marantz 4011

Maspro 4004, 4023

Matsui 4024, 4048

Mediasat 4059

Mediamarkt 4015

Minerva 4048

Morgan’s 4015, 4043

Navex 4022

Neuhaus 4039

Neusat 4057

Newhaus 4013

Nikko 4028

Nokia 4005, 4032, 4037, 4049, 4054, 4063

Nordmende 4029

Orbitech 4039

Oxford 4024

Pace 4002, 4009, 4014, 4023, 4037, 4055, 4058

Palladium 4048

Palsat 4039

Panda 4037

Panasonic 4086, 4077

Philips 4007, 4011, 4020, 4037, 4048, 4059

Phonotrend 4019, 4050

Pioneer 4021, 4059

Planet 4061

Promax 4037

Prosat 4019

Quadral 4029, 4044

Radio shack 4083

Radiola 4011

Radix 4031, 4064

RCA 4084, 4076, 4090

RFT 4011, 4013, 4019

Saba 4023, 4045

Sabre 4037

Sagem 4056

Salora 4005

Samsung 4066, 4067, 4068

SAT 4027, 4038

Satcom 4026, 4051

Satec 4009

Satmaster 4026

Satpartner 4022, 4034, 4040, 4045

09_Code_DVX-C300_CA.fm Page iii Wednesday, June 8, 2005 1:10 PM

Schwaiger 4009, 4041

Seemann 4031, 4046

SEG 4030, 4034

Siemens 4008

Skymaster 4019, 4044, 4051

Sony 4017, 4018

Strong 4062

Sunstar 4043

Tantec 4023, 4037

Technisat 4001, 4039

Techniland 4026

Telefunken 4034

Teleka 4015, 4052

Telesat 4051

Thomson 4037, 4059

Tonna 4026, 4053

Toshiba 4089, 4071, 4075

TPS 4056

Triad 4027

Triasat 4040

Uniden 4093, 4070, 4073, 4074, 4078, 4079, 4081, 4083

Unitor 4022, 4008, 4049

Universum 4011

Ventana 4034

Vortec 4027

Vtech 4022

Winersat 4008, 4027, 4031, 4037

Wisi 4033, 4045, 4047

Xsat 4006, 4065

Xcom Multimedia

4065

Zehnder 4033, 4045, 4047

Zenith 4071, 4072, 4091

09_Code_DVX-C300_CA.fm Page iv Wednesday, June 8, 2005 1:10 PM

YAMAHA ELECTRONICS CORPORATION, USA

6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.

YAMAHA CANADA MUSIC LTD.

135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA

YAMAHA ELECTRONIK EUROPA G.m.b.H.

SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, GERMANY

YAMAHA ELECTRONIQUE FRANCE S.A.

RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE

YAMAHA ELECTRONICS (UK) LTD.

YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND

YAMAHA SCANDINAVIA A.B.

J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN

YAMAHA MUSIC AUSTRALIA PTY, LTD.

17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA

DVX-S301/DVX-S302/DVX-S303

OWNER’S MANUAL

MODE D’EMPLOI

Printed in China 3139 246 16151

DVX-S300_CA_cv.fm Page 1 Tuesday, June 7, 2005 2:56 PM

Yamaha Dvx S301 Owners Manual S300_CA

Dvx-S301-Owners-Manual yamaha-dvx-s301-owners-manual-132918

DVX-S301 Owner's Manual DVX-S301_e

DVX-S302 Owner's Manual DVX-S302_e

DVX-S302 to the manual 445edced-c142-40cc-a004-c82d4706bf39

445edced-c142-40cc-a.. 445edced-c142-40cc-a004-c82d4706bf39

Navigation menu

Versions of this User Manual:

Views

Navigation
