Yamaha EX7 DATA LIST 2nd Ed. EX7F2
User Manual: Yamaha EX7 DATA LIST
Open the PDF directly: View PDF
.
Page Count: 55
- EX7 DATA LIST
- EX7 Voice List
- Drum Voice List
- Sample List
- Wave List
- EX7 Performance List
- Controller List (Dest. Param: Destination Parameters)
- FDSP Parameter List
- Effect Type List
- Effect Parameter List
- Groove Template List
- Arpeggio List
- Controll Change List
- About MIDI
- MIDI Data Format
- MIDI Data Table
- MIDI Implementation Chart
EX7 Voice List
Liste der EX7 Voices
Liste des voix EX7..........................................................2
Drum Voice List
Liste mit Schlazeug-Voices
Liste des voix de batterie..............................................24
Sample List
Liste mit Samples
Liste des échantillons ..................................................26
Wave List
Liste der Wellenformen
Liste des ondes............................................................29
EX7 Performance List
Liste der EX7 Performances
Liste des performances EX7 ........................................30
Controller List (Dest. Param: Destination Parameters)
Liste mit Controllern (Dest Param: Zielparameter)
Liste des contrôleurs (Paramètres de destination)
..............31
FDSP Parameter List
FDSP Parameter-Liste
Liste des Paramètres FDSP..........................................32
Effect Type List
Liste mit Effekt-Typen
Liste des type d'effets ..................................................34
Effect Parameter List
Liste mit Effekt-Parametern
Liste des Paramètres d'effets ......................................36
Groove Template List
Groove Template-Liste
Liste des modèles d'expressions rythmiques ..............41
Arpeggio List
Liste mit den Arpeggio-Typen
Liste des types arpèges................................................41
Controll Change List
Liste mit Controll Change-Daten
Liste des changements de commande ........................41
About MIDI ..................................................................42
MIDI Data Format ........................................................42
MIDI Data Table ..........................................................45
MIDI Implementation Chart..........................................52
EX7 DL Cover/E 00.2.8 1:47 PM ページ 1
2
■EX7 Voice List ■Liste der EX7 Voices
■Liste des voix EX7
Preset 1 (1-64)
MSB=63
LSB=0
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Natural Grnd Pf AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off COM Cho Send off AWM FEG Depth off off AWM Pitch
2 A2 Stereo Piano Pf AWM 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off COM Cho Send off AWM DCF Freq off off AWM DCF Freq
3 A3 Brite Rock Pf AWM 017:Exciter 058:3Band EQ 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 AMD off COM Cho Send off off AWM Pitch
4 A4 Rocking Bose Pf AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 003:Chorus 3 off AWM Pitch off InsL EQ H-Gain off off AWM Pitch
5 A5 Dark Grand Pf AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 009:Celeste 4 off AWM LFO1 PMD off AWM FEG Depth off off AWM Pitch
6 A6 For Ballads Pf AWM 003:Chorus 3 058:3Band EQ 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
7 A7 Jazz Grand Pf AWM 000:THRU 058:3Band EQ 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
8 A8 CP80 Pf AWM 000:THRU 058:3Band EQ 007:Rev Stage 2 015:Ensemble Detune off AWM LFO1 AMD,AWM LFO1Speed off AWM PAN off off AWM Pitch
9 A9 CP80 2 Pf AWM 024:3Band EQ 021:Auto Pan 007:Rev Stage 2 001:Chorus 1 off COM Cho Send off InsL L/R Depth off off AWM Pitch
10 A10 Georgia Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off COM Cho Send,InsL D/W Bal off AWM DCF Freq off off AWM Pitch
11 A11 VintgCondns Pf AWM 024:3Band EQ 021:Auto Pan 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsL L/R Depth off off AWM Pitch
12 A12 Tine EP Pf AWM 013:Auto Pan 058:3Band EQ 002:Rev Hall 2 002:Chorus 2 off InsS L/R Depth off COM Cho Send off off AWM Pitch
13 A13 Jazz Chorus Pf AWM 016:AMP Simulator 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off InsL LFO Freq,InsL L/R Depth off InsS D/W Bal,COM Cho Send,
InsL L/R Depth off off AWM Pitch
14 A14 Soulful Pf AWM 024:3Band EQ 021:Auto Pan 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsL L/R Depth off off AWM Pitch
15 A15 Valise Pf AWM 024:3Band EQ 021:Auto Pan 006:Rev Stage 1 015:Ensemble Detune off InsL L/R Depth off InsL LFO Freq off off AWM DCF Freq
16 A16 Early Fusion Pf AWM 021:Touch WAH 058:3Band EQ 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off InsS Sensitive off off AWM Pitch
17 B1 Chorus Bell Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off InsL D/W Bal off AWM DCF Freq off off AWM Pitch
18 B2 Made in USA Pf AWM 001:Chorus 1 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
19 B3 Rich EP Pf AWM 013:Auto Pan 058:3Band EQ 003:Rev Room 1 002:Chorus 2 off InsS L/R Depth off COM Cho Send off off AWM Pitch
20 B4 Rhodesia Pf AWM 013:Auto Pan 000:THRU 007:Rev Stage 2 001:Chorus 1 off InsS L/R Depth off AWM DCF Freq off off AWM Pitch
21 B5 Ring Mod EP Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off FDSP Main Freq. off off FDSP Main Mod.
22 B6 Tornado EP Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off FDSP Drive off FDSP Ceiling off off FDSP Drive
23 B7 Wurli 1 Pf AWM 016:AMP Simulator 020:Tremolo 008:Rev Plate 001:Chorus 1 off InsL LFO Freq off InsL AM Depth off off AWM Pitch
24 B8 Wurli 2 Pf AWM 018:Compressor 020:Tremolo 007:Rev Stage 2 001:Chorus 1 off InsL AM Depth off InsL EQ M-Gain off off AWM DCF Freq
25 B9 Dist Wurli Pf AWM 015:Overdrive 020:Tremolo 007:Rev Stage 2 001:Chorus 1 off InsL AM Depth,InsL LFO Freq off InsS EQ M-Freq off off InsS Drive
26 B10 Glass EP Pf AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
27 B11 Glastick Pf AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
28 B12 Stone EP Pf AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
29 B13 Ring Road Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 AMD off AWM DCF Freq off off AWM DCF Freq
30 B14 Glass Tine Pf AWM 017:Exciter 055:Ensemble Detune 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM AEG AtTim
31 B15 Early Tines Pf AWM 013:Auto Pan 058:3Band EQ 001:Rev Hall 1 010:Flanger 1 off InsS LFO Freq off InsS L/R Depth off off AWM DCF Freq
32 B16 Vic's Roads Pf AWM 012:Tremolo 058:3Band EQ 001:Rev Hall 1 007:Celeste 2 off InsS AM Depth,COM Cho Send,
InsS PM Depth off InsS LFO Freq,InsS PM Depth off off AWM DCF Freq
33 C1 Wonder Why Pf AWM 016:AMP Simulator 058:3Band EQ 005:Rev Room 3 014:Phaser off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
34 C2 Wah Clav Pf AWM 021:Touch WAH 058:3Band EQ 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
35 C3 Stereo Clav Pf AWM 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
36 C4 Electro Clav Pf FDSP 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AWM LFO1 PMD off FDSP LFO Speed,FDSP LFO Depth,
FDSP Pitch off off AWM Pitch
37 C5 JazzyBallad Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,AWM Volume,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,AWM Volume,
InsS LPF Cutoff
38 C6 Fullx4 Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM DCF Freq off off InsL LFO Freq
39 C7 Augmented Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff
40 C8 70's Organ1 Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 004:Chorus 4 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff
41 C9 Thank You Or AWM 016:AMP Simulator 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq off InsS Drive off off InsL LFO Freq
42 C10 Flutey Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
43 C11 EXseption Or AWM 000:THRU 018:Rotary Speaker 1 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off AWM Volume off off AWM DCF Freq
44 C12 Jazz Organ Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
45 C13 Left Manual Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off AWM Pitch
46 C14 Gospler Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 004:Chorus 4 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff,AWM Volume off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff,AWM Volume
47 C15 Fast Organ Or AWM 000:THRU 018:Rotary Speaker 1 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off AWM Volume off off AWM DCF Freq
48 C16 English Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,InsS Drive,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsS Drive,
InsS LPF Cutoff
49 D1 Jazz Perc Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
50 D2 Swing Bar Or AWM 000:THRU 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
51 D3 Glass Swish Or AWM 016:AMP Simulator 019:Rotary Speaker 2 002:Rev Hall 2 004:Chorus 4 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff,AWM Volume off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff,AWM Volume
52 D4 Cathedral Or AWM 000:THRU 043:Exciter 002:Rev Hall 2 004:Chorus 4 off COM Cho Send off InsL HPF Cutoff off off AWM DCF Freq
53 D5 Tube Crunch Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff
54 D6 Rock Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
55 D7 Hard Rock Or AWM 015:Overdrive 018:Rotary Speaker 1 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsS D/W Bal off off AWM DCF Freq
56 D8 70's Organ2 Or AWM 016:AMP Simulator 019:Rotary Speaker 2 003:Rev Room 1 004:Chorus 4 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff
57 D9 Smoky Organ Or FDSP 000:THRU 000:THRU 007:Rev Stage 2 013:Symphonic off COM Cho Send,AWM LFO1 FMD,
AWM LFO1Speed off FDSP Main Mod. off off FDSP Sub Freq.
58 D10 Fuzzier Or AWM 016:AMP Simulator 023:Phaser 1 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off InsL LFO Freq off off AWM LFO2Depth
59 D11 Combos Or AWM 000:THRU 039:Overdrive 004:Rev Room 2 001:Chorus 1 off AWM LFO1 PMD off AWM Volume off off AWM LFO1 PMD
60 D12 Transistor Or AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
61 D13 Vibe Cp AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
62 D14 Tubular Bell Cp FDSP 000:THRU 000:THRU 003:Rev Room 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Main Freq. off off AWM Pitch
63 D15 Stone Harp Cp FDSP 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic off AWM LFO1 AMD off FDSP Pitch off off AWM Pitch
64 D16 WoodSequence Cp AWM 024:3Band EQ 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
3
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
InsS EQ L-Gain,InsL EQ L-Gain InsS EQ H-Gain,InsL EQ H-Gain InsS EQ M-Gain,InsL EQ M-Gain AWM AEG AtTim AWM AEG R2Tim AWM FEG Depth off
AWM DCF Freq AWM DCF Reso AWM AEG D2Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ M-Gain InsS Drive,InsS Mix Level COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM FEG D3Tim,AWM FEG D2Tim AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume InsL EQ L-Gain,InsS EQ L-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG AtTim InsS D/W Bal COM Rev Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsS EQ H-Gain InsL LFO Freq COM Cho Send,InsL L/R Depth off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send InsL D/W Bal,COM Cho Send off
AWM DCF Freq AWM Volume InsL L/R Depth InsL LFO Freq COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain InsS LFO Freq COM Cho Send,InsS L/R Depth,
COM Volume off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send InsS D/W Bal,InsL L/R Depth off
InsS EQ L-Gain InsS EQ H-Gain InsL L/R Depth InsL LFO Freq COM Rev Send AWM Volume off
InsS EQ L-Gain InsS EQ M-Gain InsL EQ H-Gain AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsS Resonanse InsS D/W Bal InsS Sensitive COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain InsS LFO Freq COM Cho Send,InsS L/R Depth off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Sub Mod. AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Drive FDSP Ceiling AWM LFO1 AMD AWM LFO1 PMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL AM Depth InsL LFO Freq COM Rev Send COM Cho Send off
AWM DCF Freq InsL LFO Freq AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ M-Freq InsS Drive COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 PMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Pitch FDSP Sub Freq. AWM AEG D3Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsS HPF Cutoff AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal COM Rev Send InsS Drive off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain InsS LFO Freq COM Cho Send,InsS L/R Depth,
COM Volume off
AWM DCF Freq InsL EQ M-Gain InsL EQ H-Gain,AWM DCF Freq InsL EQ L-Gain COM Rev Send COM Cho Send off
InsL EQ M-Gain InsL EQ M-Freq InsS LPF Cutoff AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsS Resonanse,AWM Volume InsS Sensitive InsS Cutoff Freq AWM AEG D1Tim,AWM AEG D2Tim COM Cho Send off
AWM DCF Freq AWM DCF Reso,AWM Volume InsS EQ L-Gain InsS EQ H-Gain AWM AEG D1Tim,AWM AEG D2Tim InsL D/W Bal off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM LFO1 FMD,AWM AEG D3Tim FDSP Pitch COM Cho Send off
AWM Volume AWM Volume AWM Volume InsL L/H Bal COM Rev Send InsL Rotor,AWM Volume,
InsS LPF Cutoff off
AWM Volume AWM Volume AWM Volume AWM Volume InsL LFO Depth,InsL EQ H-Gain,
AWM Volume COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off
AWM Volume AWM Volume AWM Volume COM Cho Send COM Rev Send InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off
AWM Volume AWM Volume AWM Volume InsL LFO Depth COM Rev Send AWM AEG AtTim off
AWM Volume AWM Volume AWM Volume AWM Volume InsS EQ H-Gain,InsL EQ H-Gain COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL D/W Bal off
AWM Volume AWM DCF Freq InsS EQ L-Gain InsS EQ H-Gain InsL LFO Depth,AWM Volume COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off
AWM Volume AWM Volume AWM Volume COM Cho Send COM Rev Send InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff,AWM Volume off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL D/W Bal off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL Rotor,InsS Drive,
InsS LPF Cutoff off
AWM Volume AWM DCF Freq InsS EQ L-Gain InsS EQ H-Gain InsL LFO Depth,AWM Volume,
InsL EQ H-Gain COM Rev Send off
InsL EQ H-Gain InsL LFO Freq AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume InsL L/H Bal COM Rev Send COM Cho Send,AWM Volume off
AWM DCF Freq AWM Volume AWM Volume AWM Volume COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send off off
AWM Volume AWM DCF Freq,COM Volume InsS EQ L-Gain InsS EQ H-Gain InsL LFO Depth,AWM Volume COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL D/W Bal off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off
AWM DCF Freq FDSP Main Freq. AWM AEG AtTim AWM AEG AtTim,AWM AEG R2Tim COM Rev Send COM Cho Send off
InsS D/W Bal InsS Drive InsL D/W Bal AWM AEG AtTim AWM AEG R2Tim COM Rev Send off
AWM DCF Freq AWM Volume AWM Volume AWM LFO1 PMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM PAN AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso FDSP Main Freq. AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Pitch EG Dpt FDSP Sub Freq. AWM LFO1 PMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
4
Preset 1 (65-128)
MSB=63
LSB=0
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
65 E1 Sect Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
66 E2 Hi Sect Br AWM 000:THRU 000:THRU 003:Rev Room 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Volume
67 E3 FunkySect Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
68 E4 MyBigSectn Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
69 E5 Pop Brass Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
70 E6 Section Br AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Rev Send off off AWM Pitch
71 E7 Sforzando Br AWM 000:THRU 058:3Band EQ 009:Rev White Room 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
72 E8 ClassicBrass Br AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off COM Cho Send,COM Rev Send off off AWM Pitch
73 E9 ClassicBras2 Br AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off COM Rev Send off off AWM Pitch
74 E10 VeloTrbSect Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
75 E11 Smooth Brass Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
76 E12 Solo Trumpet Br AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq
77 E13 Trumpet Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
78 E14 SoloTrpSwtch Br AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq
79 E15 SoftTrombone Br AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq
80 E16 Jazz Trump Br AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD,
AWM LFO1 FMD AWM DCF Freq AWM DCF Freq off off AWM Pitch
81 F1 Big Brass Br AWM 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
82 F2 Mutation Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD AWM LFO1 PMD AWM LFO1 PMD off off AWM Pitch
83 F3 Mute Trumpet Br AWM 000:THRU 000:THRU 009:Rev White Room 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD AWM Volume AWM DCF Freq off off AWM Pitch
84 F4 SoloTrombone Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq
85 F5 Trombone Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD AWM Volume AWM DCF Freq off off AWM Pitch
86 F6 SoftFlgLead Br AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq
87 F7 Obersync Br FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
88 F8 AnaBrass Br AWM 000:THRU 058:3Band EQ 006:Rev Stage 1 001:Chorus 1 off AWM LFO2Depth AWM LFO1 PMD COM Cho Send off off AWM Pitch
89 F9 Stabrass Br AWM 017:Exciter 055:Ensemble Detune 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsS Mix Level off off AWM Pitch
90 F10 Riff Brass Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM DCF Freq off off COM Rev Send
91 F11 SynthClassic Br AWM 006:Celeste 2 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
92 F12 Matrix Br AWM 024:3Band EQ 004:Chorus 4 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
93 F13 OberBrass Br AWM 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
94 F14 Oberhorns Br AWM 000:THRU 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
95 F15 Jupiter Br AWM 000:THRU 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM Pitch off off AWM Pitch
96 F16 HotSynBrass Br AWM 000:THRU 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM Volume,AWM DCF Freq,
AWM DCF Reso off off AWM Pitch
97 G1 Swell String St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
98 G2 MellowStrngs St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM DCF Freq,AWM Pitch
99 G3 EnsembleMix St AWM 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
100 G4 Brite String St AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
101 G5 Kemuri St AWM 024:3Band EQ 041:Compressor 007:Rev Stage 2 004:Chorus 4 off AWM LFO1 AMD,AWM LFO1Speed off AWM Volume off off AWM Pitch
102 G6 StereoString St AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
103 G7 Big Strings+ St AWM 000:THRU 055:Ensemble Detune 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
104 G8 Agitato St AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
105 G9 Veloci Ens St AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
106 G10 Tremolo St AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth,
AWM LFO1 AMD off AWM LFO1Speed,AWM LFO2Speed off off AWM Pitch
107 G11 AnaOrch St AWM 000:THRU 004:Chorus 4 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
108 G12 Analog Str St AWM 000:THRU 000:THRU 001:Rev Hall 1 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
109 G13 Soft String Pd AWM 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
110 G14 Peace Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 015:Ensemble Detune off FDSP PWM AWM LFO1 PMD AWM DCF Freq,AWM AEG AtTim,
AWM AEG R2Tim,AWM FEG R1Tim off off AWM Pitch
111 G15 AN Layer Pd AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic off AN VCO1 PMD off AN VCF Freq off off AN Pitch
112 G16 Abendstern Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
113 H1 Pulse String Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 002:Chorus 2 off FDSP LFO Speed,AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
114 H2 Apollo Pd AWM 022:Phaser 021:Auto Pan 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
115 H3 Bottled Out Pd AWM 000:THRU 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off AWM LFO2Depth off AWM Volume off off InsL LFO Freq,InsL LFO Depth
116 H4 Clear Bell Pd AWM 000:THRU 001:Chorus 1 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
117 H5 Dreamsphere Pd AWM 004:Chorus 4 017:Cross Delay 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
118 H6 Tine PWM Pd AWM 012:Tremolo 055:Ensemble Detune 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsS AM Depth,InsS PM Depth off off InsS LFO Freq
119 H7 Fifth Rise Pd AWM 013:Auto Pan 053:Pitch Change 1 001:Rev Hall 1 013:Symphonic off AWM LFO1 FMD off AWM Volume off off InsL D/W Bal
120 H8 Freeze Pad Pd AWM 000:THRU 010:Flanger 1 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
121 H9 Glass Man Pd AWM 005:Celeste 1 006:Celeste 1 009:Rev White Room 001:Chorus 1 off InsS LFO Freq,InsL LFO Freq,
InsS LFO Depth,InsL LFO Depth AWM LFO1 PMD AWM DCF Freq off off AWM Pitch
122 H10 Glass Choir Pd AWM 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
123 H11 Hollow Pad Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off FDSP Pitch off off AWM DCF Freq
124 H12 Luminosity Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Feedback off off AWM Pitch
125 H13 Mystery Pad Pd AWM 004:Chorus 4 050:Stage 1 002:Rev Hall 2 013:Symphonic off AWM LFO1 FMD,AWM LFO1 AMD,
AWM LFO1Speed off AWM Volume off off AWM PEG Depth
126 H14 Oberweich Pd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
127 H15 Orion Pd AWM 022:Phaser 021:Auto Pan 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
128 H16 Pray Pd AWM 000:THRU 001:Chorus 1 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM Volume off off AWM Pitch
5
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM PEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 AMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM AEG D2Tim AWM AEG D3Tim InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq,AWM AEG D2Tim AWM AEG D3Tim InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume,
AWM DCF Reso InsS EQ L-Freq InsL EQ M-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG AtTim COM Cho Send off
AWM FEG D1Tim,AWM AEG D2Tim AWM FEG D2Tim,AWM AEG D3Tim InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume,
AWM DCF Reso InsL EQ L-Gain,AWM Volume InsL EQ M-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG R2Tim COM Rev Send off
AWM DCF Freq,AWM Volume,
AWM DCF Reso InsL EQ L-Gain,AWM Volume InsL EQ M-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG R2Tim COM Cho Send,COM Rev Send off
AWM DCF Freq,AWM DCF Freq Assign Off InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain AWM Volume COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain AWM DCF Reso COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM FEG D2Tim AWM AEG R2Tim,AWM FEG R1Tim COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM FEG R1Tim,AWM AEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim,
AWM AEG D2Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send,InsL D/W Bal AWM Pitch off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send,InsL D/W Bal AWM Volume,AWM DCF Freq,
AWM DCF Reso off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume AWM DCF Reso InsS EQ L-Gain,InsL EQ L-Gain InsS EQ H-Gain,InsL EQ H-Gain AWM AEG AtTim AWM AEG R2Tim off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send InsS EQ L-Gain,InsS EQ H-Gain,
InsL Out Level off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq Assign Off AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM LFO1 PMD,AWM LFO2Depth,
AWM LFO1 AMD AWM LFO1Speed,AWM LFO2Speed AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso,AWM Volume AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim FDSP LFO Speed COM Cho Send off
AWM DCF Freq AN Volume,AWM Volume AWM AEG AtTim,AN AEG At Tim AN AEG Rl Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Wet AWM Volume AWM Volume FDSP Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim InsL LFO Freq COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq COM Port SW AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume AWM AEG AtTim AWM AEG R2Tim InsS LFO Depth,InsL LFO Depth off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume FDSP Pitch FDSP LFO Depth,FDSP LFO Speed AWM AEG AtTim,AWM AEG R2Tim off
AWM DCF Freq AWM Pitch AWM AEG AtTim AWM LFO1 FMD COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM Volume COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
6
Preset 2 (1-64)
MSB=63
LSB=1
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 PW Pad Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off FDSP LFO Speed AWM LFO1 PMD AWM DCF Freq off off AWM DCF Freq
2 A2 Warmer Pd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
3 A3 Silverlake Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
4 A4 Soft Obi Pd AWM 004:Chorus 4 017:Cross Delay 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
5 A5 Space Zoo Pd AWM 000:THRU 023:Phaser 1 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
6 A6 VFEX Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Feedback off off AWM DCF Freq
7 A7 Velvet Choir Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 008:Celeste 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
8 A8 Futopia Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
9 A9 Oo Choir En AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off AWM DCF Freq
10 A10 BreathChoir En AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off InsL Vowel
11 A11 Choir Attack En AWM 024:3Band EQ 043:Exciter 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
12 A12 V-Choir En AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
13 A13 Aah Choir En AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off InsL Vowel
14 A14 Nightchoir En AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
15 A15 Straight Sc AWM 008:Celeste 4 017:Cross Delay 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
16 A16 CallioTron Sc AWM 012:Tremolo 013:Symphonic 009:Rev White Room 009:Celeste 4 off AWM LFO1 PMD,AWM LFO1Speed AWM LFO1 PMD,AWM LFO1Speed InsS LFO Freq off off InsS EQ H-Gain,InsS EQ H-Gain
17 B1 Angelica Sc AWM 009:Flanger 1 055:Ensemble Detune 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD off AWM Pitch,AWM Volume off off AWM DCF Freq
18 B2 Punch Boy Sc AWM 017:Exciter 055:Ensemble Detune 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsS Mix Level off off AWM DCF Freq
19 B3 Sebastian Sc AWM 000:THRU 014:Delay LCR 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
20 B4 Shinywire Sc AWM 024:3Band EQ 055:Ensemble Detune 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
21 B5 DigiClav Sc AWM 001:Chorus 1 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off COM Cho Send,InsS D/W Bal off off AWM Pitch
22 B6 PW Comp Sc FDSP 000:THRU 000:THRU 006:Rev Stage 1 014:Phaser off AWM LFO2Depth AWM LFO1 PMD COM Cho Send off off AWM Pitch
23 B7 Gronk Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
24 B8 Ring EP Sc AWM 009:Flanger 1 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
25 B9 Spitter Sc FDSP 000:THRU 000:THRU 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 PMD AWM LFO1 PMD FDSP Pitch off off AWM Pitch
26 B10 Funk DX Sc FDSP 000:THRU 000:THRU 003:Rev Room 1 010:Flanger 1 off AWM LFO1 PMD off FDSP Sub Freq. off off AWM Pitch
27 B11 Combi Comp Sc AWM 004:Chorus 4 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM LFO1 FMD off off AWM DCF Freq
28 B12 Pulse Clavi Sc AWM 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
29 B13 Pulse Comp Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
30 B14 Pulse OrgBrs Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
31 B15 Pulse EP Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
32 B16 Fat Oct Sc AWM 000:THRU 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM Pitch off off AWM Pitch
33 C1 Brite Steel Gt AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
34 C2 Steel Guitar Gt AWM 024:3Band EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
35 C3 Steel Gt AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
36 C4 18 String Gt AWM 023:EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
37 C5 18 Steel Gt AWM 023:EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
38 C6 Clear Nylon Gt AWM 024:3Band EQ 048:Room 2 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
39 C7 Flamenco Gt AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
40 C8 SingleChrs Gt AWM 000:THRU 006:Celeste 1 001:Rev Hall 1 016:Delay L,R off InsL LFO Depth off InsL EQ H-Gain off off AWM Pitch
41 C9 Harpsi Gtr Gt AWM 018:Compressor 058:3Band EQ 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off COM Cho Send,AWM Volume off off AWM Pitch
42 C10 Strat 4-Way Gt AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
43 C11 Clean Lead Gt FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
44 C12 VintStrat Gt FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
45 C13 Snapper Gt FDSP 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
46 C14 Single Comp Gt AWM 003:Chorus 3 042:Comp Distortion 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off InsS D/W Bal off off AWM Pitch
47 C15 R&B Lead Gt AWM 018:Compressor 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
48 C16 Pedal Steel Gt FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off FDSP Flet Pos.
49 D1 Big Mute Gt AWM 016:AMP Simulator 058:3Band EQ 009:Rev White Room 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
50 D2 EX Guitar Gt FDSP 000:THRU 000:THRU 006:Rev Stage 1 015:Ensemble Detune off AWM LFO1 PMD off FDSP Pickup Pos. off off AWM Pitch
51 D3 Jazzy Gt AWM 023:EQ 040:AMP Simulator 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
52 D4 Edgy Strat Gt AWM 018:Compressor 040:AMP Simulator 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off InsL Drive off off AWM Pitch
53 D5 Lo Distort 2 Gt AWM 016:AMP Simulator 042:Comp Distortion 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
54 D6 Distort Mute Gt AWM 016:AMP Simulator 042:Comp Distortion 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL Attack off off AWM Pitch
55 D7 Kunimotone Gt AWM 016:AMP Simulator 042:Comp Distortion 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
56 D8 Grunger Gt AWM 024:3Band EQ 040:AMP Simulator 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off InsL LPF Cutoff off off AWM AEG AtTim
57 D9 L.A.Dist Gt AWM 000:THRU 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM Volume off InsL LPF Cutoff off off AWM Pitch
58 D10 Lead Switch Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
59 D11 Black Magic Gt AWM 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD,AWM LFO1Speed off InsL Over Drive off off AWM Pitch
60 D12 BritishStack Gt AWM 016:AMP Simulator 079:Overdrive+Delay 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off InsS LPF Cutoff off off AWM Pitch
61 D13 Old Strings Ba AWM 024:3Band EQ 016:Echo 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
62 D14 Thump 1 Ba AWM 018:Compressor 061:DPCM 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
63 D15 Thump 2 Ba AWM 018:Compressor 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
64 D16 Snazz Bass Ba AWM 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM Pitch,AWM Volume
7
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM DCF Reso,AWM Volume FDSP PWM AWM AEG AtTim AWM AEG R2Tim FDSP Balance off
AWM DCF Freq AWM LFO1 AMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL LFO Freq AWM Pitch InsL FB Level COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Phase AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL Vowel AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsS EQ M-Gain,InsL Mix Level AWM AEG AtTim AWM AEG R2Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL Vowel AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ H-Gain,AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsL D/W Bal,COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL D/W Bal InsL FB Level COM Rev Send AWM AEG AtTim off
AWM DCF Freq AWM AEG AtTim AWM AEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Rev Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsL EQ H-Gain InsS LFO Depth COM Cho Send off
AWM DCF Freq AWM DCF Reso,AWM Volume AWM FEG D2Tim AWM FEG R1Tim,AWM Volume FDSP Pitch COM Rev Send,FDSP LFO Depth off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim FDSP Ceiling COM Rev Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain,InsS EQ L-Gain InsL EQ H-Gain,InsS EQ H-Gain COM Rev Send COM Cho Send,COM Volume off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D2Tim FDSP Pitch COM Cho Send,FDSP LFO Depth off
AWM DCF Freq FDSP Main Mod. AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM FEG D1Tim FDSP PW COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send,InsL D/W Bal AWM Pitch off
InsL EQ L-Gain InsL EQ H-Gain InsS HPF Cutoff InsS Mix Level COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume InsS EQ L-Gain COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain InsS HPF Cutoff InsS Mix Level COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ L-Freq InsS EQ H-Gain AWM DCF Reso COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ H-Gain AWM DCF Reso AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG D2Tim InsS EQ M-Gain InsL D/W Bal COM Cho Send AWM Volume off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM Pitch AWM AEG AtTim AWM LFO1 AMD COM Rev Send InsL FB Level off
AWM DCF Freq AWM Volume InsL EQ L-Gain InsL EQ H-Gain AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim off
InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain InsS EQ M-Freq COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume FDSP Picking Pos. FDSP Flet Pos. COM Rev Send COM Cho Send off
FDSP Cutoff AWM Volume FDSP Flet Pos. off COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Cutoff off COM Rev Send COM Cho Send AWM LFO1 AMD off
AWM DCF Freq InsS EQ L-Gain,COM Volume InsS EQ H-Gain,COM Volume InsL Out Level,InsL D/W Bal,
InsL EQ M-Gain InsS D/W Bal COM Cho Send off
AWM DCF Freq InsL Drive InsL LPF Cutoff InsL D/W Bal COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Cutoff FDSP Flet Pos. AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ M-Gain AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Pickup Pos. FDSP Flet Pos. AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL D/W Bal AWM Volume COM Rev Send COM Cho Send off
AWM FEG Depth InsL LPF Cutoff AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL Attack,COM Volume,
InsS LPF Cutoff InsL Out Level,InsL D/W Bal,
InsL EQ M-Gain InsS Drive InsL Threshold COM Cho Send off
AWM DCF Freq InsS Drive,InsS Out Level InsL Threshold InsL Drive InsL Out Level,InsL D/W Bal,COM Volume COM Cho Send off
InsL EQ L-Gain InsL Attack,COM Volume,
InsS LPF Cutoff InsL Out Level,InsL D/W Bal,
InsL EQ M-Gain InsS Drive InsL Attack,COM Cho Send COM Rev Send off
InsS EQ L-Gain InsS EQ M-Freq InsS EQ M-Gain InsL LPF Cutoff COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 AMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq InsL Over Drive InsS EQ M-Gain AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL Dst Lo G InsL Dst Mid G InsL Dst Drive AWM AEG AtTim InsL Delay Mix,InsL Dly FB Lev COM Rev Send off
AWM DCF Freq AWM AEG AtTim AWM AEG D2Tim InsS EQ M-Gain InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS Threshold,InsS Ratio,
InsS Out Level InsL LPF Reso. COM Cho Send COM Rev Send off
AWM FEG Depth,AWM DCF Freq InsL EQ L-Gain InsL EQ H-Gain AWM AEG AtTim AWM AEG R2Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth,AWM FEG D1Tim,
AWM FEG D2Tim AWM AEG R1Tim COM Rev Send COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
8
Preset 2 (65-128)
MSB=63
LSB=1
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
65 E1 Fingered Ba AWM 016:AMP Simulator 058:3Band EQ 009:Rev White Room 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
66 E2 Flatwound Ba AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
67 E3 Pickit Ba AWM 016:AMP Simulator 058:3Band EQ 009:Rev White Room 000:Off off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
68 E4 Slapit Ba AWM 018:Compressor 058:3Band EQ 003:Rev Room 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
69 E5 Hopin'Slap Ba AWM 000:THRU 000:THRU 003:Rev Room 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
70 E6 Boiled Ba AWM 024:3Band EQ 015:Delay LR 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
71 E7 FretlessLead Ba AWM 024:3Band EQ 004:Chorus 4 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
72 E8 Fretless 1 Ba AWM 024:3Band EQ 016:Echo 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM LFO1 PMD
73 E9 Fretless 2 Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Cutoff off off AWM Pitch
74 E10 Eddie Ba AWM 018:Compressor 058:3Band EQ 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
75 E11 Wood Bass Ba AWM 000:THRU 025:Early Ref 1 003:Rev Room 1 001:Chorus 1 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
76 E12 The FM Bass Ba AWM 017:Exciter 063:V-Flanger 003:Rev Room 1 014:Phaser off AWM LFO1 PMD off AWM Volume off off AWM Pitch
77 E13 Boogie Ba AN+AWM 000:THRU 000:THRU 009:Rev White Room 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD,
AWM LFO1 PMD off AWM Volume off off AN Pitch
78 E14 Dry Bass Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
79 E15 Pulse Bass 1 Ba AN+AWM 000:THRU 000:THRU 003:Rev Room 1 002:Chorus 2 off AN VCO1 PMD,AN VCO2 PMD off COM Cho Send off off AN Pitch
80 E16 ResBassComp Ba AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AN VCO1 PMD,AWM LFO1 PMD off AN VCF Freq,AWM DCF Freq off off AWM Pitch,AN Pitch
81 F1 Pulse Bass 2 Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
82 F2 Pulse Smack Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
83 F3 AnaChorus Ba AWM 017:Exciter 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off InsS Drive off off AWM Pitch
84 F4 Mondo Bass Ba AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
85 F5 Stevie Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Reso off off AN Pitch
86 F6 UniPulser Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
87 F7 P5 Sync Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off FDSP Pitch
88 F8 Squaw Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off FDSP Phase off off AWM Pitch
89 F9 Saw Lead Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off COM Cho Send,COM Volume off off AN Pitch
90 F10 Quick 5ths Ld AWM 024:3Band EQ 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 PMD off COM Cho Send,COM Volume off off AWM Pitch
91 F11 Oberlead Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
92 F12 Singleline Ld AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM FEG Depth off off AWM Pitch
93 F13 TriLead Ld AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
94 F14 Earth Lead Ld AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
95 F15 New Drone Ld AWM 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
96 F16 Sync Lead 1 Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
97 G1 Tennor Sax Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM Volume AWM DCF Freq off off AWM Pitch
98 G2 Tenor Soft Rd AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 AMD,AWM Volume,
AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq,AWM Volume
99 G3 Tenor medium Rd AWM 023:EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 AMD,AWM Volume,
AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq,AWM Volume
100 G4 Sax Section Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM Pitch off off AWM Pitch
101 G5 Alto Sax Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD AWM Volume AWM DCF Freq off off AWM Pitch
102 G6 BigSax Rd AWM 023:EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 AMD,AWM Volume,
AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq,AWM Volume
103 G7 Soft Reeds Rd AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
104 G8 Soprano Sax Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM Volume AWM DCF Freq off off AWM Pitch
105 G9 Soprano Soft Rd AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 AMD,AWM Volume,
AWM LFO1 PMD AWM LFO1 PMD off off AWM DCF Freq,AWM Volume
106 G10 Mouth Keys Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD COM Volume,AWM DCF Freq AWM DCF Freq off off AWM Pitch
107 G11 Mizu Horny Rd AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD AWM Volume AWM DCF Freq off off AWM Pitch
108 G12 Flute Rd AWM 023:EQ 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD,
AWM Volume AWM LFO1 AMD AWM LFO1 PMD off off AWM DCF Freq,AWM Volume
109 G13 Jazz Flute Pi AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
110 G14 Metal Piper Pi FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
111 G15 Bamboo Pi AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD,AWM LFO1 AMD AWM Volume AWM DCF Freq off off AWM Pitch
112 G16 Shakuhachi Et AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 AWM Volume AWM LFO1 PMD,AWM LFO1 AMD,
AWM DCF Freq off AWM Volume off off AWM Pitch
113 H1 Rising High Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
114 H2 Fractal Fx AWM 000:THRU 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off AWM DCF Freq off AWM LFO2Depth off off AWM Pitch
115 H3 Busy Brass Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off COM Cho Send,AWM Volume off AWM DCF Freq off off AWM Pitch
116 H4 Flange Wrap Fx AWM 022:Phaser 010:Flanger 1 001:Rev Hall 1 010:Flanger 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
117 H5 Kosmik Fluid Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Pitch off off AWM LFO1 FMD
118 H6 Morphyum Fx AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AN VCO1 PMD off off AN Pitch
119 H7 Asian Rain Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 007:Celeste 2 off AWM LFO1 AMD off FDSP Pitch off off AWM Pitch
120 H8 Going Down Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM Volume off off AWM Pitch
121 H9 Foam Fx AWM 000:THRU 001:Chorus 1 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL LFO Freq off off AWM Pitch
122 H10 Megawave Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM LFO1 PMD off AWM DCF Freq off off FDSP PWM
123 H11 Pop Kit Dr Drum 000:THRU 000:THRU 004:Rev Room 2 001:Chorus 1 off off off off off off off
124 H12 Velocity Kit Dr Drum 000:THRU 000:THRU 009:Rev White Room 001:Chorus 1 off off off off off off off
125 H13 Rock Kit Dr Drum 000:THRU 000:THRU 004:Rev Room 2 001:Chorus 1 off off off off off off off
126 H14 Jazzy Kit Dr Drum 000:THRU 000:THRU 005:Rev Room 3 001:Chorus 1 off off off off off off off
127 H15 House Kit Dr Drum 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off off off off off off off
128 H16 Tech Kit Dr Drum 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off off off off off off off
9
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM DCF Reso InsS D/W Bal AWM Volume COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain InsL LPF Cutoff InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Freq InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain,InsS LPF Cutoff off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain InsS Threshold InsS Out Level COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG D1Tim AWM Tune Fine COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG D2Tim InsS EQ M-Gain InsL D/W Bal COM Cho Send COM Rev Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain AWM Volume COM Cho Send,InsL D/W Bal,
COM Rev Send off
AWM DCF Freq AWM AEG AtTim InsS EQ M-Gain InsL D/W Bal COM Cho Send COM Rev Send off
FDSP Cutoff FDSP Picking Pos. AWM Volume FDSP Flet Pos. COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send AWM Volume off
AWM DCF Freq AWM DCF Reso InsL D/W Bal,InsL LFO Depth InsS HPF Cutoff AWM Volume,AWM Volume COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl AN VCO2 Edge,AN VCO1 Edge COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG Depth AN FEG DcyTim AN VCO1 PW,AN VCO2 PW COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG At Tim AN FEG DcyTim AN VCO2 Edge,AN VCO1 Edge AN VCO1 PWM,AN VCO2 PWM off
AN VCF Freq,AWM DCF Freq AN VCF Reso,AWM DCF Reso AN FEG Depth,AWM FEG Depth AN FEG DcyTim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM FEG D1Tim FDSP PW COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM FEG D1Tim FDSP PW COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume,AWM Volume AWM FEG D1Tim AWM FEG Depth COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Cho Send COM Rev Send off
AN VCF Freq AN VCF FMD AN AEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl,AN VCO1 Edge COM Rev Send COM Cho Send off
FDSP Pitch FDSP Feedback FDSP LFO Depth FDSP LFO Speed COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Drive AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG At Tim AN AEG Rl Tim AN AEG DcyTim,AN AEG SusLvl COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send InsL D/W Bal off
AN VCF Freq AN VCF Reso AN FEG At Tim AN FEG DcyTim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim,AWM FEG D1Tim AWM Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim AWM FEG D2Tim COM Cho Send off
AN VCF HPF AN VCF Reso AN AEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D3Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG At Tim AN AEG Rl Tim AN AEG SusLvl AN VCF HPF off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM Pitch AWM Volume AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain AWM Volume AWM AEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim,AWM KeyOnDly AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO2Depth AWM AEG AtTim AWM LFO2Speed COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume,AWM Volume AWM LFO1Speed AWM AEG AtTim AWM AEG R2Tim off
AWM DCF Freq AWM AEG AtTim,AWM FEG Hold,
AWM FEG D2Tim AWM Volume,AWM FEG D3Tim,
AWM AEG D3Tim COM Cho Send InsS D/W Bal COM Rev Send off
AWM DCF Freq AWM AEG AtTim AWM AEG AtTim AWM AEG R2Tim FDSP PAN COM Cho Send off
AN VCF Freq AN VCF Reso AN VCO2 PMD AWM LFO1 FMD COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Pitch AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM Volume,AWM Volume COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM LFO1 AMD AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send FDSP LFO Speed off
off off off off off off off
off off off off off off off
off off off off off off off
off off off off off off off
off off off off off off off
off off off off off off off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
10
Internal 1-1 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Made in USA Pf AWM 001:Chorus 1 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
2 A2 Jazz Grand Pf AWM 000:THRU 058:3Band EQ 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
3 A3 Georgia Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off COM Cho Send,InsL D/W Bal off AWM DCF Freq off off AWM Pitch
4 A4 Lead Switch Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
5 A5 Pulse Smack Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
6 A6 Snoop Bass Ba AWM 024:3Band EQ 071:Attack Lofi 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
7 A7 Hardstep Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN Sync Pitch off AN VCO2 Edge off off AN Feedback
8 A8 Hardsequence Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off FDSP Drive off FDSP Ceiling off off FDSP Egde Bias
9 A9 Swell String St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
10 A10 BreathChoir En AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off InsL Vowel
11 A11 Trumpet Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
12 A12 Matrix Br AWM 024:3Band EQ 004:Chorus 4 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
13 A13 Mean Lead Ld AWM 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL D/W Bal off off AWM Pitch
14 A14 Earth Lead Ld AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
15 A15 Pro Lead Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF Freq
16 A16 Minor Vocals Ld AWM 017:Exciter 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off off off AWM DCF Freq off off AWM DCF Freq
17 B1 Bottled Out Pd AWM 000:THRU 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off AWM LFO2Depth off AWM Volume off off InsL LFO Freq,InsL LFO Depth
18 B2 ComeOnHigh Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 FMD,AWM LFO1 AMD off FDSP Pitch off off FDSP LFO Speed
19 B3 AN Layer Pd AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic off AN VCO1 PMD off AN VCF Freq off off AN Pitch
20 B4 Adventure Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
21 B5 Shakuhachi Et AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 AWM Volume AWM LFO1 PMD,AWM LFO1 AMD,
AWM DCF Freq off AWM Volume off off AWM Pitch
22 B6 Seven Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM DCF Freq off AWM Volume off off AWM Pitch
23 B7 Pulse EP Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
24 B8 Loved Up Sc AWM 004:Chorus 4 055:Ensemble Detune 006:Rev Stage 1 016:Delay L,R off AWM LFO1 PMD off InsS EQ H-Gain off off InsL EQ H-Gain
25 B9 Stonk Sc AWM 018:Compressor 058:3Band EQ 007:Rev Stage 2 003:Chorus 3 off AWM LFO1 FMD off AWM Volume off off AWM Pitch
26 B10 Ring EP Sc AWM 009:Flanger 1 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
27 B11 Futopia Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
28 B12 Gronk Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
29 B13 Straight Sc AWM 008:Celeste 4 017:Cross Delay 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
30 B14 Sync Echo Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 014:Phaser off AWM FEG D1Tim off InsL D/W Bal off off AWM DCF Freq
31 B15 Down Spiral Se AWM 000:THRU 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off off off off COM Cho Send
32 B16 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 000:THRU 000:THRU 008:Rev Plate 005:Chorus 5 off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off AN FEG Depth,AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off AN VCF Freq,AN VCF Reso
51 D3 Blue Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD,AN VCO1 PMD off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc AWM 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off AWM DCF Freq off off AWM Pitch
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off InsS LFO Freq,InsS D/W Bal
56 D8 Merapi Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off FDSP Sub Mod.,FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AWM 000:THRU 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
11
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM Volume InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send InsL D/W Bal,COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM FEG D1Tim FDSP PW COM Cho Send off
InsS EQ L-Gain AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF HPF AN VCF Reso AN AEG At Tim AN FEG Rl Tim COM Rev Send off
FDSP Drive FDSP Egde Bias FDSP Ceiling FDSP Overtone COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL Vowel AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AN VCF HPF AN VCF Reso AN AEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AN VCF Freq AN AEG At Tim AN AEG Rl Tim AN FEG Rl Tim AN Sync Pitch COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG D2Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim FDSP Pitch,AWM Volume COM Rev Send FDSP Feedback off
AWM DCF Freq AN Volume,AWM Volume AWM AEG AtTim,AN AEG At Tim AN AEG Rl Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM FEG D1Tim FDSP PW COM Rev Send COM Cho Send off
InsL EQ H-Gain AWM PEG Depth AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain,InsS EQ L-Gain InsL EQ H-Gain,InsS EQ H-Gain COM Rev Send COM Cho Send,COM Volume off
AWM Volume AWM Volume AWM Volume AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim FDSP Ceiling COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq,InsL Presence InsL D/W Bal AWM Volume AWM Volume COM Rev Send Arp tempo off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM Volume AWM KeyOnDly AWM KeyOnDly InsL D/W Bal InsS D/W Bal InsS LPF Cutoff off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso FDSP Flet Pos. AWM FEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN Sync Depth AN VCO1 PMD,AN VCO2 PMD AN AEG At Tim AN FEG At Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send off off
AN VCF Freq AN VCF Reso,AWM DCF Reso AN AEG At Tim AN AEG Rl Tim AN FEG At Tim AN VCF HPF off
FDSP EG Depth AWM Pitch AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim,InsL D/W Bal COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsL D/W Bal InsS D/W Bal InsS LFO Freq COM Rev Send off
InsL LPF Cutoff AWM AEG AtTim InsL D/W Bal InsS LFO Freq InsS FB Level COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq InsS EQ L-Gain InsS LFO Freq InsS LFO Depth AWM Pitch COM Rev Send off
AWM DCF Freq AWM AEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG AtTim InsL LFO Depth InsL LFO Freq,InsL EQ M-Gain AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG Rl Tim AN Sync Pitch AN VCO2 Edge COM Cho Send off
InsS Drive InsS Out Level InsS LPF Cutoff InsS D/W Bal COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Cho Send InsL D/W Bal off
AN VCF Freq AWM DCF Reso AWM LFO1 FMD AN LFO1 Speed COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsS LFO Freq,AWM LFO1Speed COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG R2Tim AWM KeyOnDly COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM FEG D1Tim InsL D/W Bal,InsL FB Level L off
AWM AEG AtTim FDSP PW FDSP LFO Speed FDSP LFO Depth COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL FB Level COM Rev Send COM Cho Send off
AN VCF FMD AN PEG Depth AN FM Depth AN Sync Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
12
Internal 1-2 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Rising High Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
2 A2 Pulse Bass 2 Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
3 A3 Jazz Perc Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
4 A4 Swell String St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
5 A5 Natural Grnd Pf AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off COM Cho Send off AWM FEG Depth off off AWM Pitch
6 A6 18 String Gt AWM 023:EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
7 A7 Sect Br AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
8 A8 Oberhorns Br AWM 000:THRU 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
9 A9 Orion Pd AWM 022:Phaser 021:Auto Pan 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
10 A10 Boogie Ba AN+AWM 000:THRU 000:THRU 009:Rev White Room 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD,
AWM LFO1 PMD off AWM Volume off off AN Pitch
11 A11 Tube Crunch Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,InsL EQ H-Gain,
InsS LPF Cutoff
12 A12 Pulse String Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 002:Chorus 2 off FDSP LFO Speed,AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
13 A13 Chorus Bell Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off InsL D/W Bal off AWM DCF Freq off off AWM Pitch
14 A14 Lead Switch Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
15 A15 Obersync Br FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
16 A16 Shakuhachi Et AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 AWM Volume AWM LFO1 PMD,AWM LFO1 AMD,
AWM DCF Freq off AWM Volume off off AWM Pitch
17 B1 Equi 1998 Sq AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN FEG DcyTim off AN VCF HPF off off AN Pitch
18 B2 Mean Bass Ba AWM 014:Distortion 062:V-Distortion 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off InsL Over Drive off off AWM DCF Freq
19 B3 Oasis Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Ceiling off off FDSP Drive
20 B4 HPF Attack Ld AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 017:Ctrl. Delay off AWM FEG D2Tim,AWM FEG D1Tim off AWM PEG Depth,AWM PEG D1Tim off off COM Cho Send
21 B5 Huge Machine Se AWM 000:THRU 073:Jump 010:Rev Tunnel 001:Chorus 1 off AWM LFO1Speed off AWM Volume off off AWM Pitch
22 B6 Lately Bass Ba AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM PEG Depth off off AWM Pitch
23 B7 FullChargeAT Se AWM 000:THRU 040:AMP Simulator 008:Rev Plate 014:Phaser off InsL LPF Cutoff AWM Volume AWM LFO2Speed off off InsL LPF Cutoff
24 B8 Drumnotized Se AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
25 B9 Broken Arp Se AWM 000:THRU 073:Jump 011:Rev Basement 012:Flanger 3 off AWM LFO1 AMD off InsL Speed off off AWM Pitch
26 B10 BasslineB Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN Sync Pitch off AN Sync Pitch off off AN VCO1 Edge
27 B11 Vortex Pd FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD off AWM LFO1Speed off off FDSP Pitch
28 B12 Chemistry Ld AWM 000:THRU 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1Speed off AWM Volume off off AWM DCF Freq
29 B13 LunaPad MW Pd AWM 000:THRU 000:THRU 009:Rev White Room 014:Phaser off AWM LFO1 PMD off AWM LFO2Depth off off AWM DCF Freq
30 B14 Sync Lead 2 Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Sync Pitch
31 B15 Generator Se AWM 022:Phaser 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off off off AWM Volume off off AWM Volume
32 B16 Slipmat Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 000:THRU 000:THRU 008:Rev Plate 005:Chorus 5 off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off AN FEG Depth,AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off AN VCF Freq,AN VCF Reso
51 D3 Blue Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD,AN VCO1 PMD off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc AWM 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off AWM DCF Freq off off AWM Pitch
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off InsS LFO Freq,InsS D/W Bal
56 D8 Merapi Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off FDSP Sub Mod.,FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AWM 000:THRU 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
13
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim,AWM KeyOnDly AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM FEG D1Tim FDSP PW COM Cho Send off
AWM Volume AWM DCF Freq InsS EQ L-Gain InsS EQ H-Gain InsL LFO Depth,AWM Volume,
InsL EQ H-Gain COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsS EQ L-Gain,InsL EQ L-Gain InsS EQ H-Gain,InsL EQ H-Gain InsS EQ M-Gain,InsL EQ M-Gain AWM AEG AtTim AWM AEG R2Tim AWM FEG Depth off
InsS EQ L-Gain InsS EQ L-Freq InsS EQ H-Gain AWM DCF Reso COM Rev Send COM Cho Send off
AWM DCF Freq AWM PEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM Volume COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl AN VCO2 Edge,AN VCO1 Edge COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send off off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG At Tim,AWM AEG AtTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsS EQ L-Gain InsS LPF Cutoff,InsS EQ M-Gain InsL Presence COM Cho Send,COM Volume COM Rev Send off
FDSP Drive FDSP Ceiling AWM AEG AtTim AWM LFO1 FMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal InsS EQ M-Gain off
AWM DCF Freq AWM LFO1 PMD AWM DCF Freq,AWM AEG AtTim AWM DCF Reso,AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL D/W Bal InsS EQ M-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Cho Send COM Rev Send off
AWM Volume,AWM DCF Reso AWM Volume AWM Volume InsS D/W Bal COM Rev Send off off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim AWM AEG D1Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN AEG Rl Tim COM Rev Send COM Cho Send off
FDSP Pitch AWM AEG AtTim FDSP LFO Speed FDSP LFO Depth FDSP PAN COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN Sync Pitch AN FEG DcyTim AN FEG SusLvl COM Rev Send COM Cho Send off
InsS EQ H-Gain InsL Over Drive InsS D/W Bal InsS LFO Freq COM Rev Send Arp tempo off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R1Tim,AWM FEG R2Tim FDSP Drive FDSP Over Drive off
AWM Volume AWM KeyOnDly AWM KeyOnDly InsL D/W Bal InsS D/W Bal InsS LPF Cutoff off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso FDSP Flet Pos. AWM FEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN Sync Depth AN VCO1 PMD,AN VCO2 PMD AN AEG At Tim AN FEG At Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send off off
AN VCF Freq AN VCF Reso,AWM DCF Reso AN AEG At Tim AN AEG Rl Tim AN FEG At Tim AN VCF HPF off
FDSP EG Depth AWM Pitch AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim,InsL D/W Bal COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsL D/W Bal InsS D/W Bal InsS LFO Freq COM Rev Send off
InsL LPF Cutoff AWM AEG AtTim InsL D/W Bal InsS LFO Freq InsS FB Level COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq InsS EQ L-Gain InsS LFO Freq InsS LFO Depth AWM Pitch COM Rev Send off
AWM DCF Freq AWM AEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG AtTim InsL LFO Depth InsL LFO Freq,InsL EQ M-Gain AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG Rl Tim AN Sync Pitch AN VCO2 Edge COM Cho Send off
InsS Drive InsS Out Level InsS LPF Cutoff InsS D/W Bal COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Cho Send InsL D/W Bal off
AN VCF Freq AWM DCF Reso AWM LFO1 FMD AN LFO1 Speed COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsS LFO Freq,AWM LFO1Speed COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG R2Tim AWM KeyOnDly COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM FEG D1Tim InsL D/W Bal,InsL FB Level L off
AWM AEG AtTim FDSP PW FDSP LFO Speed FDSP LFO Depth COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL FB Level COM Rev Send COM Cho Send off
AN VCF FMD AN PEG Depth AN FM Depth AN Sync Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
14
Internal 1-3 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 For Ballads Pf AWM 003:Chorus 3 058:3Band EQ 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD off AWM Volume off off AWM Pitch
2 A2 Jazz Chorus Pf AWM 016:AMP Simulator 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off InsL LFO Freq,InsL L/R Depth off InsS D/W Bal,COM Cho Send,
InsL L/R Depth off off AWM Pitch
3 A3 Electro Clav Pf FDSP 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AWM LFO1 PMD off FDSP LFO Speed,FDSP LFO Depth,
FDSP Pitch off off AWM Pitch
4 A4 Jazz Perc Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM Volume off off InsL LFO Freq
5 A5 Fullx4 Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM DCF Freq off off InsL LFO Freq
6 A6 Cathedral Or AWM 000:THRU 043:Exciter 002:Rev Hall 2 004:Chorus 4 off COM Cho Send off InsL HPF Cutoff off off AWM DCF Freq
7 A7 Flamenco Gt AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
8 A8 EX Guitar Gt FDSP 000:THRU 000:THRU 006:Rev Stage 1 015:Ensemble Detune off AWM LFO1 PMD off FDSP Pickup Pos. off off AWM Pitch
9 A9 Lead Switch Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
10 A10 Boogie Ba AN+AWM 000:THRU 000:THRU 009:Rev White Room 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD,
AWM LFO1 PMD off AWM Volume off off AN Pitch
11 A11 FretlessLead Ba AWM 024:3Band EQ 004:Chorus 4 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
12 A12 Slapit Ba AWM 018:Compressor 058:3Band EQ 003:Rev Room 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
13 A13 Mean Bass Ba AWM 014:Distortion 062:V-Distortion 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off InsL Over Drive off off AWM DCF Freq
14 A14 Swell String St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
15 A15 Aah Choir En AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off InsL Vowel
16 A16 Section Br AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Rev Send off off AWM Pitch
17 B1 Earth Lead Ld AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
18 B2 Mean Lead Ld AWM 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL D/W Bal off off AWM Pitch
19 B3 New Drone Ld AWM 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
20 B4 P5 Sync Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off FDSP Pitch
21 B5 Rap Whistle Ld AN+AWM 000:THRU 000:THRU 010:Rev Tunnel 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCO1 Edge off off AN Pitch
22 B6 Abendstern Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
23 B7 Silverlake Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
24 B8 VFEX Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Feedback off off AWM DCF Freq
25 B9 Morphyum Fx AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AN VCO1 PMD off off AN Pitch
26 B10 Rising High Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
27 B11 Shakuhachi Et AWM 000:THRU 043:Exciter 001:Rev Hall 1 001:Chorus 1 AWM Volume AWM LFO1 PMD,AWM LFO1 AMD,
AWM DCF Freq off AWM Volume off off AWM Pitch
28 B12 Natives Se AWM 000:THRU 006:Celeste 1 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
29 B13 Futopia Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
30 B14 Spitter Sc FDSP 000:THRU 000:THRU 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 PMD AWM LFO1 PMD FDSP Pitch off off AWM Pitch
31 B15 Equi 1998 Sq AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN FEG DcyTim off AN VCF HPF off off AN Pitch
32 B16 Juju Temple Se AWM 022:Phaser 012:Flanger 3 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Depth off AWM LFO2Speed off off AWM Pitch
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 000:THRU 000:THRU 008:Rev Plate 005:Chorus 5 off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off AN FEG Depth,AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off AN VCF Freq,AN VCF Reso
51 D3 Blue Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD,AN VCO1 PMD off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc AWM 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off AWM DCF Freq off off AWM Pitch
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off InsS LFO Freq,InsS D/W Bal
56 D8 Merapi Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off FDSP Sub Mod.,FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AWM 000:THRU 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
15
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq,AWM Volume InsL EQ L-Gain,InsS EQ L-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG AtTim InsS D/W Bal COM Rev Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send InsS D/W Bal,InsL L/R Depth off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM LFO1 FMD,AWM AEG D3Tim FDSP Pitch COM Cho Send off
AWM Volume AWM DCF Freq InsS EQ L-Gain InsS EQ H-Gain InsL LFO Depth,AWM Volume,
InsL EQ H-Gain COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume InsL LFO Depth,InsL EQ H-Gain,
AWM Volume COM Rev Send off
AWM DCF Freq AWM Volume AWM Volume AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Pickup Pos. FDSP Flet Pos. AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl AN VCO2 Edge,AN VCO1 Edge COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain AWM Volume COM Cho Send,InsL D/W Bal,
COM Rev Send off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain InsS Threshold InsS Out Level COM Cho Send off
AWM DCF Freq InsS EQ L-Gain InsS LPF Cutoff,InsS EQ M-Gain InsL Presence COM Cho Send,COM Volume COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL Vowel AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume,
AWM DCF Reso InsS EQ L-Freq InsL EQ M-Gain InsL EQ H-Gain,InsS EQ H-Gain AWM AEG AtTim COM Cho Send off
AN VCF HPF AN VCF Reso AN AEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D3Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Pitch FDSP Feedback FDSP LFO Depth FDSP LFO Speed COM Rev Send COM Cho Send off
AN VCO1 Edge AN VCF Reso AN AEG At Tim AN Port Time COM Rev Send COM Cho Send off
FDSP Wet AWM Volume AWM Volume FDSP Pitch COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN VCO2 PMD AWM LFO1 FMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim,AWM KeyOnDly AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL FB Level AWM AEG AtTim AWM AEG D1Tim COM Rev Send InsL LFO Depth off
AWM Volume AWM Volume AWM Volume AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D2Tim FDSP Pitch COM Cho Send,FDSP LFO Depth off
AN VCF Freq AN VCF Reso AN AEG At Tim,AWM AEG AtTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume InsL FB Level InsL LFO Freq COM Rev Send Arp tempo off
AWM Volume AWM KeyOnDly AWM KeyOnDly InsL D/W Bal InsS D/W Bal InsS LPF Cutoff off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso FDSP Flet Pos. AWM FEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN Sync Depth AN VCO1 PMD,AN VCO2 PMD AN AEG At Tim AN FEG At Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send off off
AN VCF Freq AN VCF Reso,AWM DCF Reso AN AEG At Tim AN AEG Rl Tim AN FEG At Tim AN VCF HPF off
FDSP EG Depth AWM Pitch AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim,InsL D/W Bal COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsL D/W Bal InsS D/W Bal InsS LFO Freq COM Rev Send off
InsL LPF Cutoff AWM AEG AtTim InsL D/W Bal InsS LFO Freq InsS FB Level COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq InsS EQ L-Gain InsS LFO Freq InsS LFO Depth AWM Pitch COM Rev Send off
AWM DCF Freq AWM AEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG AtTim InsL LFO Depth InsL LFO Freq,InsL EQ M-Gain AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG Rl Tim AN Sync Pitch AN VCO2 Edge COM Cho Send off
InsS Drive InsS Out Level InsS LPF Cutoff InsS D/W Bal COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Cho Send InsL D/W Bal off
AN VCF Freq AWM DCF Reso AWM LFO1 FMD AN LFO1 Speed COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsS LFO Freq,AWM LFO1Speed COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG R2Tim AWM KeyOnDly COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM FEG D1Tim InsL D/W Bal,InsL FB Level L off
AWM AEG AtTim FDSP PW FDSP LFO Speed FDSP LFO Depth COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL FB Level COM Rev Send COM Cho Send off
AN VCF FMD AN PEG Depth AN FM Depth AN Sync Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
16
Internal 1-4 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Natural Grnd Pf AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off COM Cho Send off AWM FEG Depth off off AWM Pitch
2 A2 Chorus Bell Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off InsL D/W Bal off AWM DCF Freq off off AWM Pitch
3 A3 Soulful Pf AWM 024:3Band EQ 021:Auto Pan 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsL L/R Depth off off AWM Pitch
4 A4 Ring Road Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 AMD off AWM DCF Freq off off AWM DCF Freq
5 A5 JazzyBallad Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off InsL Rotor,AWM Volume,
InsS LPF Cutoff off InsL L/H Bal off off InsL Rotor,AWM Volume,
InsS LPF Cutoff
6 A6 Fullx4 Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM DCF Freq off off InsL LFO Freq
7 A7 Hard Rock Or AWM 015:Overdrive 018:Rotary Speaker 1 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsS D/W Bal off off AWM DCF Freq
8 A8 VintStrat Gt FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
9 A9 Strat 4-Way Gt AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
10 A10 Dist Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
11 A11 Flamenco Gt AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
12 A12 18 String Gt AWM 023:EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
13 A13 Boogie Ba AN+AWM 000:THRU 000:THRU 009:Rev White Room 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD,
AWM LFO1 PMD off AWM Volume off off AN Pitch
14 A14 Hardsequence Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off FDSP Drive off FDSP Ceiling off off FDSP Egde Bias
15 A15 StereoString St AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
16 A16 Veloci Ens St AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
17 B1 FunkySect Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
18 B2 Smooth Brass Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
19 B3 Obersync Br FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
20 B4 Oberhorns Br AWM 000:THRU 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
21 B5 Singleline Ld AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM FEG Depth off off AWM Pitch
22 B6 New Drone Ld AWM 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
23 B7 Earth Lead Ld AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
24 B8 Fusion Tekk Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off FDSP LFO Depth off FDSP PW off off AWM DCF Freq
25 B9 Nightchoir En AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
26 B10 Abendstern Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
27 B11 Rising High Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
28 B12 VFEX Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Feedback off off AWM DCF Freq
29 B13 Silverlake Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
30 B14 Futopia Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
31 B15 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
32 B16 Equi 1998 Sq AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN FEG DcyTim off AN VCF HPF off off AN Pitch
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 000:THRU 000:THRU 008:Rev Plate 005:Chorus 5 off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off AN FEG Depth,AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off AN VCF Freq,AN VCF Reso
51 D3 Blue Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD,AN VCO1 PMD off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc AWM 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off AWM DCF Freq off off AWM Pitch
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off InsS LFO Freq,InsS D/W Bal
56 D8 Merapi Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off FDSP Sub Mod.,FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AWM 000:THRU 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
17
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
InsS EQ L-Gain,InsL EQ L-Gain InsS EQ H-Gain,InsL EQ H-Gain InsS EQ M-Gain,InsL EQ M-Gain AWM AEG AtTim AWM AEG R2Tim AWM FEG Depth off
AWM DCF Freq AWM DCF Reso AWM Volume AWM Volume COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ H-Gain InsL L/R Depth InsL LFO Freq COM Rev Send AWM Volume off
FDSP Pitch FDSP Sub Freq. AWM AEG D3Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume InsL L/H Bal COM Rev Send InsL Rotor,AWM Volume,
InsS LPF Cutoff off
AWM Volume AWM Volume AWM Volume AWM Volume InsL LFO Depth,InsL EQ H-Gain,
AWM Volume COM Rev Send off
AWM Volume AWM Volume AWM Volume AWM Volume COM Rev Send InsL D/W Bal off
FDSP Cutoff AWM Volume FDSP Flet Pos. off COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain InsS EQ M-Freq COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
InsS EQ L-Gain InsS EQ L-Freq InsS EQ H-Gain AWM DCF Reso COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl AN VCO2 Edge,AN VCO1 Edge COM Cho Send off
FDSP Drive FDSP Egde Bias FDSP Ceiling FDSP Overtone COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM AEG D2Tim AWM AEG D3Tim InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim,AWM FEG D1Tim AWM Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D3Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF HPF AN VCF Reso AN AEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Wet AWM Volume AWM Volume FDSP Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim,AWM KeyOnDly AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM Pitch COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM Volume AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG At Tim,AWM AEG AtTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM Volume AWM KeyOnDly AWM KeyOnDly InsL D/W Bal InsS D/W Bal InsS LPF Cutoff off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso FDSP Flet Pos. AWM FEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN Sync Depth AN VCO1 PMD,AN VCO2 PMD AN AEG At Tim AN FEG At Tim COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send off off
AN VCF Freq AN VCF Reso,AWM DCF Reso AN AEG At Tim AN AEG Rl Tim AN FEG At Tim AN VCF HPF off
FDSP EG Depth AWM Pitch AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim,InsL D/W Bal COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume InsL D/W Bal InsS D/W Bal InsS LFO Freq COM Rev Send off
InsL LPF Cutoff AWM AEG AtTim InsL D/W Bal InsS LFO Freq InsS FB Level COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq InsS EQ L-Gain InsS LFO Freq InsS LFO Depth AWM Pitch COM Rev Send off
AWM DCF Freq AWM AEG D1Tim AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG AtTim InsL LFO Depth InsL LFO Freq,InsL EQ M-Gain AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG Rl Tim AN Sync Pitch AN VCO2 Edge COM Cho Send off
InsS Drive InsS Out Level InsS LPF Cutoff InsS D/W Bal COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Cho Send InsL D/W Bal off
AN VCF Freq AWM DCF Reso AWM LFO1 FMD AN LFO1 Speed COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsS LFO Freq,AWM LFO1Speed COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM AEG R2Tim AWM KeyOnDly COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim AWM FEG D1Tim InsL D/W Bal,InsL FB Level L off
AWM AEG AtTim FDSP PW FDSP LFO Speed FDSP LFO Depth COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL FB Level COM Rev Send COM Cho Send off
AN VCF FMD AN PEG Depth AN FM Depth AN Sync Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
18
Internal 1 (65-128)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
65 E1 House Piano Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off FDSP Cutoff off off AWM Pitch
66 E2 Stage Stack Co AWM 017:Exciter 004:Chorus 4 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
67 E3 Funky Syn Sc AWM 000:THRU 015:Delay LR 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
68 E4 Genaside Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN FEG Depth off off AN Pitch
69 E5 Silent Lead Gt FDSP 000:THRU 000:THRU 002:Rev Hall 2 017:Ctrl. Delay off AWM LFO1 PMD off AWM DCF Freq off off AWM LFO1 PMD
70 E6 Hard Groove Sq FDSP 000:THRU 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off FDSP Overtone off FDSP Drive off off FDSP Egde Bias
71 E7 Harmonics Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off COM Rev Send off InsS EQ L-Gain,InsS EQ H-Gain off off COM Cho Send
72 E8 Harptar Et AWM 024:3Band EQ 043:Exciter 001:Rev Hall 1 011:Flanger 2 off AWM LFO1 PMD AWM LFO1 PMD InsL Drive off off AWM Pitch
73 E9 HealthSector Pd AWM 024:3Band EQ 015:Delay LR 007:Rev Stage 2 001:Chorus 1 off AWM LFO2Depth off InsS EQ M-Gain off off AWM LFO1 FMD
74 E10 House Org Ba AWM 023:EQ 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
75 E11 Impact Fx AWM 024:3Band EQ 052:Plate 009:Rev White Room 003:Chorus 3 off AWM LFO1Speed,AWM LFO1 AMD off AWM DCF Freq off off AWM LFO2Depth
76 E12 So Deep Fx AWM 000:THRU 000:THRU 002:Rev Hall 2 013:Symphonic off AWM FEG D2Tim,AWM FEG Depth off AWM Volume off off AWM LFO2Depth
77 E13 Jungle Call Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
78 E14 Glass Strat Gt FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off FDSP Cutoff off off AWM Pitch
79 E15 Lazy Sweep Pd AWM 022:Phaser 057:2Band EQ 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
80 E16 LoFi Ld AWM 015:Overdrive 062:V-Distortion 001:Rev Hall 1 010:Flanger 1 off AWM LFO1 PMD off InsL Over Drive off off AWM Pitch
81 F1 LoFiJazzComb Co AWM 015:Overdrive 072:Digital Turntable 001:Rev Hall 1 001:Chorus 1 off InsL Noise Lev,InsL Clk Level off InsS EQ M-Freq off off AWM Pitch
82 F2 Loved Up Sc AWM 004:Chorus 4 055:Ensemble Detune 006:Rev Stage 1 016:Delay L,R off AWM LFO1 PMD off InsS EQ H-Gain off off InsL EQ H-Gain
83 F3 LoDistortion Gt AWM 016:AMP Simulator 042:Comp Distortion 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
84 F4 Jaw Harp Se AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD AWM Pitch InsL Vowel,AWM DCF Freq off off AWM Pitch
85 F5 Mars Pd AWM 000:THRU 011:Flanger 2 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL LFO Freq off off AWM Pitch
86 F6 Minor Vocals Ld AWM 017:Exciter 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off off off AWM DCF Freq off off AWM DCF Freq
87 F7 Mr.Evolvo Pd AWM 010:Flanger 2 055:Ensemble Detune 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD,AWM LFO2Depth AWM LFO1Speed AWM LFO1 FMD off off AWM Pitch
88 F8 Multiplies Se AWM 000:THRU 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Depth off AWM LFO1Speed off off AWM Pitch
89 F9 Dist Lead Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
90 F10 Nee-owng Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Feedback
91 F11 Sucker Ld AWM 003:Chorus 3 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
92 F12 Phone Wires Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
93 F13 Pop Sq AWM 000:THRU 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Rev Send off off AWM DCF Freq
94 F14 Pro Lead Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF Freq
95 F15 Warp Fx FDSP 000:THRU 000:THRU 005:Rev Room 3 013:Symphonic off AWM PEG Depth off COM Rev Send off off AWM DCF Freq
96 F16 PulseBack Br FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
97 G1 Six String Gt AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
98 G2 Reso Choir En AWM 024:3Band EQ 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM PEG Depth off InsS EQ L-Gain off off InsS EQ M-Gain
99 G3 Ricochet Sq AWM 015:Overdrive 000:THRU 001:Rev Hall 1 016:Delay L,R off COM Rev Send off AWM FEG Depth off off InsS D/W Bal
100 G4 Ring Mod EP2 Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off FDSP Main Mod. off off AWM Pitch
101 G5 Suitcase3 Pf AWM 016:AMP Simulator 021:Auto Pan 001:Rev Hall 1 014:Phaser off InsL LFO Freq off InsL L/R Depth off off AWM Pitch
102 G6 Ring Leader Cp AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF Freq
103 G7 WarmDrive Gt AWM 000:THRU 077:Comp+Odrv+Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
104 G8 Silver Gt AWM 016:AMP Simulator 020:Tremolo 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD off InsS Drive,InsS Out Level off off AWM Pitch
105 G9 Reece EP Cp AWM 013:Auto Pan 017:Cross Delay 006:Rev Stage 1 014:Phaser off InsS L/R Depth off AWM LFO1 AMD off off AWM LFO1 PMD
106 G10 Trolddom Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off off FDSP Dry FDSP Pitch off off AWM Pitch
107 G11 G-Bass Ba AWM 024:3Band EQ 071:Attack Lofi 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
108 G12 Soda Straw Fx AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD off COM Rev Send off off AN Sync Pitch
109 G13 Squash Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 011:Flanger 2 off AN VCO1 PMD,AN VCO1 PMD off AN LFO1 Speed off off AN Sync Pitch
110 G14 ActiveBass Ba FDSP 000:THRU 000:THRU 009:Rev White Room 014:Phaser off AWM LFO1 PMD off FDSP Cutoff off off AWM Pitch
111 G15 Stonk Sc AWM 018:Compressor 058:3Band EQ 007:Rev Stage 2 003:Chorus 3 off AWM LFO1 FMD off AWM Volume off off AWM Pitch
112 G16 Strangg'e Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD off FDSP Wet off off FDSP Pitch
113 H1 NewAge Fx AWM 004:Chorus 4 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
114 H2 Sweet Chords Sq AWM 017:Exciter 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
115 H3 Sweet Pulse Ld AN+AWM 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN Port Time off off AN VCF Freq
116 H4 Swirl Pd AWM 024:3Band EQ 003:Chorus 3 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
117 H5 Sync Pad Pd AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN Sync Pitch off off AN Pitch
118 H6 Synthboy Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF Freq
119 H7 Talk Ld AWM 016:AMP Simulator 064:Talking Modulator 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off InsL Vowel off off InsL Vowel
120 H8 Holy Light Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 PMD off FDSP Pitch off off AWM Pitch
121 H9 TengJing Fx AWM 000:THRU 073:Jump 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off InsL Speed off off AWM Pitch
122 H10 TimeWalk Se AWM 000:THRU 024:Phaser 2 001:Rev Hall 1 016:Delay L,R off AWM LFO1 AMD off AWM LFO1Speed off off AWM Pitch
123 H11 Tine Bell Cp AWM 013:Auto Pan 055:Ensemble Detune 003:Rev Room 1 002:Chorus 2 off AWM LFO2Depth off InsS L/R Depth off off AWM DCF Freq
124 H12 Tringle Ld AWM 024:3Band EQ 014:Delay LCR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
125 H13 Utopia Pd AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
126 H14 Vega Bass Ba AWM 016:AMP Simulator 026:Early Ref 2 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 FMD off InsS D/W Bal off off AWM Volume
127 H15 Velo City Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
128 H16 Reed Amp Pf AWM 024:3Band EQ 040:AMP Simulator 007:Rev Stage 2 016:Delay L,R off AWM LFO1 AMD off InsL Drive,InsL LPF Cutoff off off AWM DCF Freq
19
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM Volume AWM Volume COM Rev Send,COM Cho Send InsL D/W Bal off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN VCF Reso AN FEG At Tim AN Sync Depth AN FM Depth AN VCF HPF off
AWM DCF Freq AWM DCF Reso AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume FDSP Drive FDSP Overtone FDSP Egde Bias COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM FEG R2Tim,AWM FEG R1Tim AWM AEG R2Tim InsL D/W Bal off
AWM DCF Freq AWM DCF Reso,AWM Volume AWM AEG D1Tim,AWM AEG D2Tim AWM FEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Reso InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain COM Rev Send,InsL D/W Bal,COM Cho Send AWM Volume off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM KeyOnDly AWM AEG R2Tim AWM PEG Depth COM Cho Send,COM Rev Send off
AWM Volume AWM Volume InsS D/W Bal InsS LPF Cutoff COM Cho Send AWM Pitch off
FDSP Cutoff FDSP Picking Pos. FDSP Flet Pos. AWM Volume COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG D1Tim AWM AEG R2Tim InsS Drive,InsS LPF Cutoff COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ M-Freq InsL Noise Lev,InsL Clk Level COM Rev Send COM Cho Send off
InsL EQ H-Gain AWM PEG Depth AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL LPF Cutoff,InsS LPF Cutoff InsL Drive InsS Drive InsL Threshold COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send InsL Vowel off
AWM DCF Freq InsL FB Level InsL LFO Depth AWM LFO1 FMD AWM AEG R2Tim COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG D2Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim,AWM KeyOnDly,AWM FEG D1Tim,
AWM KeyOnDly,AWM AEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO2Speed AWM LFO1 FMD AWM LFO1 AMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL EQ L-Gain InsL EQ H-Gain COM Rev Send COM Cho Send off
FDSP Pitch FDSP Wet COM Rev Send FDSP EG Depth FDSP LFO Depth FDSP LFO Speed off
AWM DCF Freq,AWM FEG Depth AWM DCF Reso AWM Volume AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Cho Send,InsS LFO Depth,
COM Volume off
FDSP Pitch FDSP Sub Freq. FDSP Main Mod. AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM Volume AWM Pitch AWM Pitch Arp tempo off
AN VCF Freq AN AEG At Tim AN AEG Rl Tim AN FEG Rl Tim AN Sync Pitch COM Rev Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim FDSP LFO Speed COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM FEG D1Tim AWM FEG D3Tim,AWM FEG D2Tim COM Rev Send COM Cho Send off
InsL EQ L-Gain InsL EQ H-Gain InsS Mix Level InsS HPF Cutoff COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso,AWM Volume AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal COM Cho Send,COM Rev Send off
AWM DCF Freq AWM DCF Reso COM Cho Send AWM Volume AWM Volume AWM Volume off
FDSP Main Freq. AWM DCF Reso FDSP Pitch FDSP Sub Freq. COM Rev Send COM Cho Send off
InsL EQ L-Freq InsL EQ H-Gain InsL L/R Depth InsL LFO Freq COM Rev Send COM Cho Send off
AN VCF Freq AN AEG At Tim,AN FEG At Tim AN AEG Rl Tim,AN FEG Rl Tim AN Sync Pitch AN FM Depth COM Cho Send off
AWM FEG Depth InsL Dst Mid G AWM AEG AtTim AWM AEG D1Tim COM Rev Send COM Cho Send off
InsL LFO Freq InsL AM Depth InsL EQ L-Gain InsL EQ M-Gain InsL EQ H-Gain COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM LFO1 AMD AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal InsS LFO Freq off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim COM Cho Send COM Rev Send FDSP Dry off
InsS EQ L-Gain AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN Sync Pitch AN LFO1 Speed AN AEG Rl Tim AN PEG DcyTim COM Rev Send COM Cho Send off
AN VCF Freq AN FEG At Tim AN AEG Rl Tim,AN FEG Rl Tim AN Sync Pitch COM Rev Send COM Cho Send off
FDSP Cutoff AWM DCF Reso FDSP Flet Pos. AWM Volume COM Cho Send COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D2Tim,AWM FEG D3Tim,AWM AEG D1Tim,
AWM AEG D2Tim,AWM FEG Depth AWM AEG R1Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim InsL EQ H-Gain COM Cho Send,COM Volume off
AN VCF Freq,AWM DCF Freq AN VCF Reso AN VCA AMD AWM Volume,AN Volume COM Rev Send COM Cho Send off
AN VCF Freq AN AEG At Tim,AN FEG At Tim AN FEG DcyTim AN VCF Reso COM Cho Send AN VCO1 Edge off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL Vowel COM Rev Send AWM Volume off
FDSP Pitch AWM PAN AWM AEG AtTim AWM AEG R2Tim FDSP Feedback COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim InsL Speed COM Rev Send COM Cho Send off
AWM LFO1 AMD AWM LFO1 PMD AWM AEG AtTim InsL LFO Freq COM Rev Send COM Cho Send off
AWM DCF Freq InsS EQ H-Gain AWM Volume AWM AEG D1Tim,AWM AEG D2Tim InsL D/W Bal,COM Cho Send COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D1Tim COM Rev Send InsL D/W Bal off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG D1Tim AWM Pitch AWM Pitch off
AWM DCF Freq AWM DCF Reso AWM PEG D1Tim AWM AEG R2Tim InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain AWM LFO1Speed AWM LFO1 AMD off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
20
Internal 2 (1-64)
MSB=63
LSB=3
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Equi 1998 Sq AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN FEG DcyTim off AN VCF HPF off off AN Pitch
2 A2 RoboTribeAT Sq AWM 016:AMP Simulator 064:Talking Modulator 011:Rev Basement 016:Delay L,R off AWM LFO1 PMD InsL Vowel InsS Out Level off off InsL Vowel
3 A3 Sync Echo Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 014:Phaser off AWM FEG D1Tim off InsL D/W Bal off off AWM DCF Freq
4 A4 Zambeezi Sq AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 009:Celeste 4 off AN VCO1 PMD,AN VCO2 PMD off COM Rev Send off off AN VCF Freq
5 A5 BasslineA Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PW off AN Sync Pitch off off AN VCO1 Edge
6 A6 BasslineB Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN Sync Pitch off AN Sync Pitch off off AN VCO1 Edge
7 A7 Dry Syn Ba AWM 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
8 A8 Hardsequence Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off FDSP Drive off FDSP Ceiling off off FDSP Egde Bias
9 A9 StrobeBass A Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
10 A10 AnaSweep Ba AWM 000:THRU 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
11 A11 Bwacka Bass Ba FDSP 000:THRU 000:THRU 011:Rev Basement 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM Pitch
12 A12 Talkin' Bass Ba FDSP 000:THRU 000:THRU 011:Rev Basement 010:Flanger 1 off AWM LFO1 PMD off FDSP Egde Bias off off AWM Pitch
13 A13 Hardstep Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN Sync Pitch off AN VCO2 Edge off off AN Feedback
14 A14 SH Acid Ba AWM 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM FEG Depth
15 A15 Sub Bass Ba AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM FEG Depth off off AWM Pitch
16 A16 Massive FM Ba FDSP 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AWM LFO1 PMD off FDSP EG Depth off off off
17 B1 Mean Bass Ba AWM 014:Distortion 062:V-Distortion 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off InsL Over Drive off off AWM DCF Freq
18 B2 Lately Bass Ba AWM 024:3Band EQ 016:Echo 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM PEG Depth off off AWM Pitch
19 B3 Speed Ba AWM 024:3Band EQ 022:Ambience 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD off AWM Volume off off AWM Pitch
20 B4 Kangaroo Ba AWM 016:AMP Simulator 011:Flanger 2 001:Rev Hall 1 016:Delay L,R off AWM AEG R2Tim,AWM FEG R1Tim off AWM DCF Freq off off AWM Pitch
21 B5 Plastic Box Ba AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AN VCO1 PMD off AN VCF Freq off off AN FEG Rl Tim,AN AEG Rl Tim
22 B6 Tosser Ba AN+AWM 000:THRU 000:THRU 003:Rev Room 1 013:Symphonic off AN VCF Freq off AN VCO2 Edge,AN VCO1 Edge off off AN VCF HPF
23 B7 Wave Bass Ba AN+AWM 000:THRU 000:THRU 007:Rev Stage 2 013:Symphonic off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCO2 Edge,AN VCO1 Edge
24 B8 Velo Sub Ba AWM 024:3Band EQ 015:Delay LR 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
25 B9 Mondoloid Ba AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AWM LFO1 PMD,
AN VCO2 PMD off AN Feedback,AN VCF Reso off off AN Pitch
26 B10 Hollow Bass Ba AWM 023:EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
27 B11 Techline AN Ba AWM 016:AMP Simulator 032:Auto WAH 001:Rev Hall 1 016:Delay L,R off InsL LFO Freq off InsS Drive off off AWM Pitch
28 B12 3 Pole Reso Ba AWM 000:THRU 000:THRU 001:Rev Hall 1 009:Celeste 4 off AWM LFO1 PMD off COM Cho Send off off AWM LFO1Speed
29 B13 Slipmat Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
30 B14 Fusion Tekk Ld FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off FDSP LFO Depth off FDSP PW off off AWM DCF Freq
31 B15 Minor Syn Ld AWM 023:EQ 015:Delay LR 001:Rev Hall 1 004:Chorus 4 off AWM DCF Freq off InsL D/W Bal off off AWM DCF Freq
32 B16 Fat Hook Ld AWM 016:AMP Simulator 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
33 C1 Chemistry Ld AWM 000:THRU 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1Speed off AWM Volume off off AWM DCF Freq
34 C2 Rap Whistle Ld AN+AWM 000:THRU 000:THRU 010:Rev Tunnel 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCO1 Edge off off AN Pitch
35 C3 MonoLead AN Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
36 C4 Sync Lead 2 Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 005:Chorus 5 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Sync Pitch
37 C5 Talk Mod Ld AWM 022:Phaser 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq,AWM DCF Freq off off AWM DCF Freq
38 C6 Mean Lead Ld AWM 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL D/W Bal off off AWM Pitch
39 C7 Trippy Ld AWM 024:3Band EQ 040:AMP Simulator 005:Rev Room 3 004:Chorus 4 off InsL Drive off AWM AEG R2Tim,AWM FEG R1Tim off off AWM FEG Depth
40 C8 Acid Saw Ld AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off InsL Drive off off InsL LPF Cutoff
41 C9 CompuTech Ld AWM 014:Distortion 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
42 C10 Organic Ld AWM 007:Celeste 3 024:Phaser 2 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM LFO2Depth off off AWM LFO2Speed
43 C11 HPF Attack Ld AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 017:Ctrl. Delay off AWM FEG D2Tim,AWM FEG D1Tim off AWM PEG Depth,AWM PEG D1Tim off off COM Cho Send
44 C12 Sync Lead 3 Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN Sync Pitch off off AN VCO1 Edge,AN VCO2 Edge
45 C13 Thor Ld FDSP 000:THRU 000:THRU 007:Rev Stage 2 001:Chorus 1 off AWM LFO1 PMD off FDSP Drive off off FDSP Cutoff
46 C14 PointySquare Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off COM Cho Send,COM Volume off off AN Pitch
47 C15 VocoLoco Ld AWM 000:THRU 061:DPCM 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM DCF Freq off off AWM Pitch
48 C16 StrayCat Ld AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AN VCO1 PMD off AN VCF Freq off off AN Pitch
49 D1 Vortex Pd FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD,AWM LFO1 AMD off AWM LFO1Speed off off FDSP Pitch
50 D2 Ghosts Pd AWM 000:THRU 055:Ensemble Detune 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
51 D3 Oasis Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Ceiling off off FDSP Drive
52 D4 Paris Pd AWM 000:THRU 024:Phaser 2 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
53 D5 Big Wave Pd AWM 013:Auto Pan 001:Chorus 1 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL LFO Freq off off AWM Pitch
54 D6 LunaPad MW Pd AWM 000:THRU 000:THRU 009:Rev White Room 014:Phaser off AWM LFO1 PMD off AWM LFO2Depth off off AWM DCF Freq
55 D7 Vapor Pd AWM 000:THRU 015:Delay LR 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
56 D8 Paddalicious Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Depth FDSP LFO Speed AWM LFO1 FMD off off AWM LFO1Speed
57 D9 Smoke Pad Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic off AWM LFO1 PMD off FDSP Pitch,FDSP Pitch EG Dpt off off AWM Pitch
58 D10 Stalactite Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 011:Flanger 2 off AWM LFO1 PMD off FDSP Pitch off off FDSP Main Mod.
59 D11 VariPad Pd FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off FDSP Pitch off FDSP Sub Freq. off off AWM Pitch
60 D12 FlangOrg Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off FDSP LFO Speed off off FDSP Pitch
61 D13 Deep Blue Pd AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 002:Chorus 2 off AN FM Depth,AN VCF FMD,
AN Sync Pitch off AN VCO1 PMD,AN VCO2 PMD off off AN Pitch
62 D14 Sky Organ Pd FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off FDSP LFO Speed off off AWM Pitch
63 D15 ComeOnHigh Pd FDSP 000:THRU 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 FMD,AWM LFO1 AMD off FDSP Pitch off off FDSP LFO Speed
64 D16 BitterSweet Pd AWM 024:3Band EQ 023:Phaser 1 003:Rev Room 1 001:Chorus 1 off AWM LFO1 PMD off AWM Volume off off AWM LFO1 FMD
21
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AN VCF Freq AN VCF Reso AN AEG At Tim,AWM AEG AtTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS LPF Cutoff AWM FEG Depth AWM Pitch Arp tempo off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM Volume COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN Sync Pitch AN VCO2 Edge AN VCF HPF Arp tempo off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Drive FDSP Egde Bias FDSP Ceiling FDSP Overtone COM Rev Send COM Cho Send off
AN VCO2 Edge,AN VCO1 Edge AN VCF Freq AN VCF FMD AN FEG DcyTim AN VCO1 PW,AN VCO2 PW COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso FDSP Egde Bias FDSP Drive AWM AEG AtTim AWM AEG R2Tim off
AWM FEG Depth,FDSP Drive AWM DCF Reso AWM AEG AtTim AWM AEG R1Tim COM Rev Send COM Volume,COM Cho Send off
AN VCF Freq AN VCF HPF AN VCF Reso AN AEG At Tim AN FEG Rl Tim COM Rev Send off
AWM FEG Depth AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM FEG R1Tim,AWM AEG R2Tim InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsS EQ L-Gain InsS EQ M-Gain off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM AEG R2Tim COM Rev Send off off
AWM DCF Freq InsS EQ L-Gain InsS LPF Cutoff,InsS EQ M-Gain InsL Presence COM Cho Send,COM Volume COM Rev Send off
AWM DCF Freq AWM DCF Reso InsL D/W Bal InsS EQ M-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG Depth AWM DCF Reso AWM FEG D1Tim AWM PEG D3Tim,AWM PEG D2Tim AWM AEG R1Tim,AWM AEG R2Tim off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D2Tim COM Rev Send COM Cho Send off
AN FEG Depth AN VCF Freq AN VCF Reso AN FEG DcyTim AN Port Time COM Rev Send off
AN VCF Reso AN FM Depth AN AEG Rl Tim AN VCF FMD COM Rev Send COM Cho Send off
AN FEG Depth AN VCF Reso AN FEG At Tim,AN FEG DcyTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM AEG AtTim,AWM FEG D2Tim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal COM Cho Send COM Rev Send off
AN VCF Freq AN VCF Reso AN AEG At Tim,AWM AEG AtTim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM FEG D1Tim InsS EQ L-Gain COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth,AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG D1Tim AWM FEG R1Tim,AWM AEG R2Tim COM Port SW off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R1Tim,AWM FEG R2Tim FDSP Drive FDSP Over Drive off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCO1 Edge AN VCF Reso AN AEG At Tim AN Port Time COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN FEG DcyTim AN FEG SusLvl,AN VCO1 Edge COM Rev Send COM Cho Send off
AN VCF Freq AN Sync Pitch AN FEG DcyTim AN FEG SusLvl COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM Volume AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM FEG D1Tim AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG Depth AWM AEG R2Tim InsL D/W Bal COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal InsS EQ M-Gain off
AN VCF Freq AN VCF Reso AN LFO1 Speed AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM AEG R1Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF Reso AN AEG At Tim AN AEG Rl Tim AN FEG DcyTim COM Rev Send off
AWM DCF Freq AWM FEG D1Tim InsL Samp.Freq InsL LPF Cutoff AWM LFO1 AMD COM Rev Send off
AN VCF Freq AN VCF Reso AN AEG At Tim AN AEG Rl Tim,AN FEG Rl Tim AN VCO1 Edge AN VCF HPF off
FDSP Pitch AWM AEG AtTim FDSP LFO Speed FDSP LFO Depth FDSP PAN COM Cho Send off
AWM DCF Freq AWM DCF Reso,AWM Volume AWM Volume AWM AEG AtTim AWM AEG R2Tim COM Cho Send,InsL D/W Bal off
FDSP Drive FDSP Ceiling AWM AEG AtTim AWM LFO1 FMD COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM PAN AWM AEG AtTim AWM AEG R2Tim COM Rev Send InsL LFO Freq off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM LFO1Speed AWM LFO1 AMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM Volume AWM AEG AtTim AWM AEG R2Tim FDSP Pitch,FDSP Pitch EG Dpt COM Cho Send off
AWM DCF Freq FDSP Pitch EG Dpt AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
FDSP Main Mod. AWM AEG AtTim AWM LFO1 PMD FDSP Main Mod.,AWM Pitch COM Cho Send AWM LFO2Depth,AWM LFO2Speed off
AWM DCF Freq FDSP LFO Speed AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCF HPF AN FEG At Tim AN AEG Rl Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim FDSP Pitch,AWM Volume COM Rev Send FDSP Feedback off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R1Tim,AWM AEG R2Tim COM Rev Send COM Cho Send off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
22
Internal 2 (65-128)
MSB=63
LSB=3
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
65 E1 RhythmWheels Fx AWM 024:3Band EQ 067:Auto Synth 001:Rev Hall 1 010:Flanger 1 off AWM LFO2Speed,AWM LFO2Depth AWM LFO1 PMD InsL AM Speed off off AWM Pitch
66 E2 Ribbon Slide Fx AWM 005:Celeste 1 059:Control Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off InsL Dly Trans. off off InsL Dly Time
67 E3 Quickening Fx FDSP 000:THRU 000:THRU 009:Rev White Room 014:Phaser off AWM LFO1Speed FDSP Pitch FDSP Dry off off AWM Pitch
68 E4 Hollow Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off AWM DCF Freq off off FDSP Pitch
69 E5 StarDust Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
70 E6 Nirvana Fx FDSP 000:THRU 000:THRU 002:Rev Hall 2 004:Chorus 4 off FDSP Pitch off AWM LFO1Speed off off AWM DCF Freq
71 E7 Moebius Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off FDSP LFO Speed off off AWM Pitch
72 E8 StarDrive Fx FDSP 000:THRU 000:THRU 001:Rev Hall 1 012:Flanger 3 off AWM LFO2Depth off COM Cho Send,AWM Volume off off AWM Pitch
73 E9 AstralMonkey Fx AWM 001:Chorus 1 066:Digital Scratch 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD InsL Scratch Spd InsL Scratch Spd off off AWM Pitch
74 E10 Broken Arp Se AWM 000:THRU 073:Jump 011:Rev Basement 012:Flanger 3 off AWM LFO1 AMD off InsL Speed off off AWM Pitch
75 E11 Geiger Count Se AWM 000:THRU 000:THRU 011:Rev Basement 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM PEG Depth
76 E12 Roswell Se AWM 013:Auto Pan 073:Jump 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
77 E13 Huge Machine Se AWM 000:THRU 073:Jump 010:Rev Tunnel 001:Chorus 1 off AWM LFO1Speed off AWM Volume off off AWM Pitch
78 E14 Circular Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off AN Pitch
79 E15 Millenium Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 010:Flanger 1 off FDSP Pitch off AWM Volume off off AWM LFO2Depth
80 E16 Seven Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM DCF Freq off AWM Volume off off AWM Pitch
81 F1 Down Spiral Se AWM 000:THRU 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off off off off COM Cho Send
82 F2 Ectoplasm Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 013:Symphonic FDSP Pitch AWM LFO2Depth,AWM LFO2Speed off AWM DCF Freq,AWM Volume off off AWM LFO1 AMD
83 F3 Whistlewind Se AWM 024:3Band EQ 055:Ensemble Detune 007:Rev Stage 2 016:Delay L,R off AWM DCF Freq off AWM LFO2Depth off off AWM LFO1 FMD
84 F4 Alien Rain Se AWM 024:3Band EQ 063:V-Flanger 001:Rev Hall 1 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM Pitch
85 F5 Bent Metal Se FDSP 000:THRU 000:THRU 006:Rev Stage 1 001:Chorus 1 off FDSP LFO Depth off FDSP Pitch off off AWM Pitch
86 F6 FM Waves Se AN+AWM 000:THRU 000:THRU 003:Rev Room 1 001:Chorus 1 off AN VCO1 PMD off AN VCF Freq off off AN Pitch
87 F7 Nusic Se AWM 000:THRU 021:Auto Pan 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO2Speed off off AWM Pitch
88 F8 Creature Se AWM 000:THRU 054:Pitch Change 2 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
89 F9 Talk2much Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN LFO1 Speed off AN Sync Pitch off off AN Pitch Down
90 F10 Radiophonik Se FDSP 000:THRU 000:THRU 004:Rev Room 2 005:Chorus 5 off FDSP Main Mod. off FDSP Main Freq. off off FDSP Main Freq.
91 F11 BodyElectric Se AWM 000:THRU 073:Jump 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsL Speed off off InsL Depth
92 F12 Trancer Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN LFO1 Speed off COM Rev Send off off AN VCF Freq,AWM DCF Freq
93 F13 Drumnotized Se AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off AWM Pitch
94 F14 Eraser Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 012:Flanger 3 off AWM LFO1 PMD off FDSP Pitch off off AWM Pitch
95 F15 Juju Temple Se AWM 022:Phaser 012:Flanger 3 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Depth off AWM LFO2Speed off off AWM Pitch
96 F16 DarkSide Se FDSP 000:THRU 000:THRU 001:Rev Hall 1 012:Flanger 3 off AWM LFO1 AMD off FDSP Pitch off off FDSP Pitch
97 G1 What's funy? Se AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 AMD off AWM DCF Freq off off AWM Pitch
98 G2 Generator Se AWM 022:Phaser 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off off off AWM Volume off off AWM Volume
99 G3 Natives Se AWM 000:THRU 006:Celeste 1 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
100 G4 Texture#6 VS Se AWM 000:THRU 027:Gate Reverb 010:Rev Tunnel 016:Delay L,R off off off InsL LPF Cutoff off off AWM LFO2Speed
101 G5 FullChargeAT Se AWM 000:THRU 040:AMP Simulator 008:Rev Plate 014:Phaser off InsL LPF Cutoff AWM Volume AWM LFO2Speed off off InsL LPF Cutoff
102 G6 Ai-ee-yi Se AN+AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD,
AN LFO1 Speed off AN VCO2 Edge off off AN VCF Freq
103 G7 Moving Sc FDSP 000:THRU 000:THRU 005:Rev Room 3 001:Chorus 1 off FDSP LFO Speed,FDSP LFO Depth off FDSP Pitch off off AWM PEG Depth
104 G8 Road Rage Sc AWM 024:3Band EQ 061:DPCM 001:Rev Hall 1 012:Flanger 3 off AWM LFO1 PMD,AWM LFO1 FMD InsL LPF Cutoff COM Cho Send off off AWM Pitch
105 G9 FutaFunk Sc FDSP 000:THRU 000:THRU 005:Rev Room 3 011:Flanger 2 off FDSP Phase,FDSP EG Depth off FDSP Drive off off AWM LFO1 PMD
106 G10 No Sleep Sc AWM 018:Compressor 016:Echo 001:Rev Hall 1 002:Chorus 2 off AWM LFO1 PMD off off off off AWM LFO1 FMD
107 G11 Flang Saw Sc FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
108 G12 Flux Sc AWM 000:THRU 011:Flanger 2 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM LFO1 FMD
109 G13 SynchroChoir Sc AWM 022:Phaser 027:Gate Reverb 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM DCF Freq off off AWM LFO1 AMD
110 G14 Echo Roads Pf FDSP 000:THRU 000:THRU 011:Rev Basement 014:Phaser off AWM LFO1 AMD,AWM LFO1 PMD,
COM Cho Send off AWM FEG Depth off off AWM LFO1Speed
111 G15 Undercover Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 014:Phaser off AWM LFO1 AMD off FDSP Cutoff off off AWM Pitch
112 G16 Touch Drive Pf AWM 011:Flanger 3 042:Comp Distortion 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off InsL Attack,COM Volume off off AWM Pitch
113 H1 Neptune St AWM 022:Phaser 010:Flanger 1 007:Rev Stage 2 004:Chorus 4 off AWM AEG AtTim off InsL LFO Depth,InsS LFO Depth off off AWM Pitch
114 H2 Ministry St AWM 018:Compressor 016:Echo 006:Rev Stage 1 013:Symphonic off AWM PEG Depth off AWM PEG D1Tim off off AWM DCF Freq
115 H3 Phasensembl St AWM 024:3Band EQ 058:3Band EQ 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
116 H4 No.9 Strings St AWM 000:THRU 061:DPCM 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM Volume off off InsL LPF Cutoff
117 H5 Organ XYZ Or AWM 018:Compressor 019:Rotary Speaker 2 007:Rev Stage 2 001:Chorus 1 off InsL EQ L-Gain off InsL Rotor off off AWM DCF Freq
118 H6 Union Jack Or AWM 000:THRU 023:Phaser 1 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
119 H7 House Br AWM 000:THRU 000:THRU 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
120 H8 CS80 Brass Br AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
121 H9 Raspberry Pi AWM 024:3Band EQ 071:Attack Lofi 001:Rev Hall 1 014:Phaser off AWM LFO1 PMD off AWM AEG D3Tim off off AWM Pitch
122 H10 Tai-koh Sq AWM 022:Phaser 013:Symphonic 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq,InsL D/W Bal
123 H11 RM Bellz Pc FDSP 000:THRU 000:THRU 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off FDSP Main Mod. off off AWM Pitch
124 H12 Tornado BD Pc FDSP 000:THRU 000:THRU 001:Rev Hall 1 003:Chorus 3 off FDSP Egde Bias off FDSP Ceiling off off COM Cho Send
125 H13 ViaArpeggia Co AWM 022:Phaser 014:Delay LCR 001:Rev Hall 1 001:Chorus 1 off AWM Volume off AWM Volume off off InsS EQ L-Gain
126 H14 Alien Kit Dr Drum 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off off off off off off off
127 H15 FX Kit Dr Drum 000:THRU 000:THRU 008:Rev Plate 001:Chorus 1 off COM Cho Send off COM Rev Send off off off
128 H16 Street Kit Dr Drum 000:THRU 000:THRU 008:Rev Plate 001:Chorus 1 off COM Cho Send off COM Rev Send off off off
23
Kn1 Kn2 Kn3 Kn4 Kn5 Kn6 Vel
AWM DCF Freq AWM DCF Reso AWM Volume AWM AEG AtTim AWM AEG R2Tim InsL AM Depth off
AWM DCF Freq AWM DCF Reso AWM FEG D3Tim AWM AEG R2Tim InsS D/W Bal,InsS LFO Depth,
COM Volume InsL D/W Bal off
AWM DCF Freq FDSP Pitch AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq FDSP Pitch EG Dpt FDSP Main Freq. FDSP Sub Freq. COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 PMD AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq FDSP PW AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,FDSP Wet AWM Volume AWM AEG AtTim,AWM AEG D1Tim AWM AEG R2Tim AWM PEG D2Tim COM Rev Send off
AWM DCF Freq InsL Auto P Spd AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM LFO1 FMD AWM AEG AtTim AWM AEG D1Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq InsL Speed InsL Depth InsL D/W Bal InsS LFO Freq COM Rev Send off
AWM DCF Freq AWM LFO1 PMD AWM DCF Freq,AWM AEG AtTim AWM DCF Reso,AWM AEG R2Tim COM Rev Send COM Cho Send off
AN VCF Freq AN FEG At Tim AN AEG Rl Tim AN Sync Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM PEG Depth AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,InsL Presence InsL D/W Bal AWM Volume AWM Volume COM Rev Send Arp tempo off
FDSP Pitch FDSP Main Freq. AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Rev Send off
AWM DCF Reso InsS EQ L-Gain InsS EQ M-Gain InsS EQ H-Gain COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL LFO Freq InsL FB Gain AWM Volume COM Cho Send off
AWM DCF Freq AWM DCF Reso FDSP Pitch FDSP EG Depth FDSP LFO Depth,FDSP LFO Speed COM Rev Send off
AN VCF Freq AN VCF Reso AN AEG At Tim AN AEG Rl Tim,AN FEG Rl Tim AN FEG At Tim AN VCF HPF off
AWM DCF Freq AWM LFO2Depth AWM LFO1Speed AWM Pitch COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL FB Level AWM AEG D1Tim COM Rev Send COM Cho Send off
AN VCF Freq AN VCO1 PMD AN LFO1 Speed AN VCF FMD COM Rev Send COM Cho Send off
AWM AEG AtTim AWM PEG D1Tim,AWM PEG R2Tim AWM AEG R2Tim FDSP Pitch FDSP Main Freq. COM Rev Send,COM Cho Send off
InsL D/W Bal AWM AEG D1Tim AWM AEG AtTim AWM LFO1 AMD COM Rev Send COM Cho Send off
AN VCF Freq,AWM DCF Freq AN VCF Reso,AWM DCF Reso AN VCO2 PMD,AN VCO1 PMD AN VCO2 PMD off AN AEG Rl Tim off
AWM Volume,AWM DCF Reso AWM Volume AWM Volume InsS D/W Bal COM Rev Send off off
FDSP Main Freq. FDSP Main Mod. AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Volume AWM Volume InsL FB Level InsL LFO Freq COM Rev Send Arp tempo off
AWM DCF Freq AWM LFO1 FMD AWM LFO1 PMD AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq off AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsS EQ H-Gain InsL Over Drive InsS D/W Bal InsS LFO Freq COM Rev Send Arp tempo off
AWM DCF Freq InsL FB Level AWM AEG AtTim AWM AEG D1Tim COM Rev Send InsL LFO Depth off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Cho Send InsL D/W Bal off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Cho Send COM Rev Send off
AN VCF Freq AN Sync Pitch AN AEG At Tim AN AEG Rl Tim AN VCO1 Level COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim,AWM AEG AtTim FDSP LFO Depth COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM LFO1 FMD AWM LFO1 AMD COM Cho Send COM Rev Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim,AWM FEG D3Tim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Reso InsL LFO Depth AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM Pitch AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal InsS D/W Bal off
FDSP Cutoff FDSP Drive AWM AEG AtTim,AWM FEG D1Tim AWM AEG R2Tim,AWM FEG R1Tim COM Rev Send COM Cho Send off
FDSP Drive FDSP Position AWM DCF Reso AWM DCF Freq COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS EQ L-Gain InsS EQ H-Gain InsL Attack,COM Volume InsS D/W Bal off
AWM DCF Freq AWM DCF Reso InsL EQ M-Gain AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM FEG Depth AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim InsL D/W Bal COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
InsL LPF Cutoff InsL LPF Reso. AWM AEG AtTim AWM AEG R2Tim,AWM FEG R1Tim COM Cho Send,COM Rev Send InsL Samp.Freq off
AWM Volume AWM Volume AWM Volume InsL L/H Bal COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsL LFO Depth,InsL LFO Freq COM Rev Send AWM AEG AtTim InsL D/W Bal off
AWM DCF Freq AWM DCF Reso AWM FEG D2Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso AWM FEG D1Tim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq,AWM FEG Depth,
InsL LPF Freq,InsS EQ H-Gain AWM DCF Reso AWM AEG AtTim AWM AEG R2Tim COM Rev Send COM Cho Send off
AWM DCF Freq AWM DCF Reso InsS D/W Bal InsS LFO Freq COM Cho Send Arp tempo off
FDSP Main Freq. FDSP Sub Freq. FDSP Main Mod. FDSP Sub Mod. COM Rev Send COM Cho Send off
FDSP Drive AWM AEG AtTim FDSP Ceiling FDSP Egde Bias FDSP PAN COM Rev Send off
AWM DCF Freq AWM DCF Reso AWM AEG AtTim AWM FEG D2Tim COM Rev Send InsL D/W Bal off
off off off off off off off
off off off off off off off
DR DCF Freq DR PAN off off off Arp tempo off
• The abbreviations “Ins S” and “Ins L” in the “Effect” and “Controller” sections of the Voice Lists refer to “Insertion Effect 1” and “Insertion Effect 2”, respectively.
• Nehmen Sie für die Abkürzungen “Ins S” und “Ins L” in den Abschnitten “Effect” und “Controller” der Voice-Liste jeweils auf die Abschnitte “Insertion Effect 1” und
“Insertion Effect 2” Bezug.
• A la section “Effect” et “Controller” de la liste des voix les abréviations “Ins S” et “Ins L” signifient respectivement “Insertion Effect 1” et “Insertion Effect 2”.
24
■Drum Voice List ■Liste mit Schlazeug-Voices
■Liste des voix de batterie
Preset 2:123-128
(MSB=63, LSB=1)
Note No.
Note
C 0
25
24
C#0
26 D 0
27 D#0
28 E 0
29 F 0
30 F#0
31 G 0
32 G#0
33 A 0
A#0
35
34
B 0
36 C 1
37 C#1
38 D 1
39 D#1
E 1
41
42
43
44
45
46
47
48
49
40
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
50 D 2
51 D#2
52 E 2
53 F 2
F#2
55
54
G 2
56 G#2
57 A 2
58 A#2
59 B 2
60 C 3
61 C#3
62 D 3
63 D#3
E 3
65
64
F 3
66 F#3
67 G 3
68 G#3
69 A 3
70 A#3
71 B 3
72 C 4
73 C#4
D 4
75
74
D#4
76 E 4
77 F 4
78 F#4
79 G 4
80 G#4
81 A 4
82 A#4
83
84
B 4
C 5
85 C#5
86 D 5
87 D#5
88 E 5
89 F 5
90 F#5
91 G 5
P2-123 Pop Kit
Sample 1 Sample 2 Sample 3 Sample 4
1424:Claves.1
1387:SdBrsS.1
1352:Noise.1
1387:SdBrsS.1
1352:Noise.1
1387:SdBrsS.1
1352:Noise.1
1387:SdBrsS.1
1352:Noise.1
0911:SxBrth.1
1368:SdBldM.1
1366:SdGM.1 1366:SdGM.1
1366:SdGM.1
1425:Castnt.1
1367:SdBldS.1 1383:SdPrmS.1
1391:Stick.1
1361:BdHby.1
1382:SdPcBH.1 1381:SdPcBS.1 1380:SdPclH.1
1361:BdHby.1 1361:BdHby.1
1360:BdPop.1 1360:BdPop.1
1389:C.Rim1.1
1366:SdGM.1 1375:SdSonB.1
1443:T8Clap.1
1382:SdPcBH.1 1381:SdPcBS.1
1392:TomF.1 1397:TmJzL.1
1400:HHCl1.1 1400:HHCl1.1
1392:TomF.1 1397:TmJzL.1
1403:HHPdl.1
1393:TomL.1 1397:TmJzL.1
1404:HHOpn.1
1394:TomM.1 1399:TmJzH.1
1395:TomHL.1 1399:TmJzH.1
1407:Crash.1
1395:TomHL.1 1399:TmJzH.1
1405:Ride.1
1408:China.1
1406:Cup.1 1405:Ride.1
1428:Tmborn.1
1407:Crash.1
1414:Cowbel.1
1407:Crash.1
1430:VbSlp.1
1405:Ride.1
1410:BongoH.1
1409:BongoL.1
1413:CngSlp.1
1412:CongaH.1
1411:CongaL.1
1419:TmblsH.1 1418:TmblsL.1
1418:TmblsL.1
1415:AgogoL.1
1415:AgogoL.1
1423:Cabasa.1
1426:Maracs.1 1426:Maracs.1
1431:Whistl.1
1431:Whistl.1
1417:GiroCl.1
1416:GuiroL.1
1424:Claves.1
1422:Wdblck.1
1422:Wdblck.1
1420:CuicaL.1
1421:CuicaH.1
1429:TrangL.1
1429:TrangL.1
1427:Shaker.1
1433:JnglBl.1
1434:Bltree.1
P2-124 Velocity Kit
Sample 1 Sample 2 Sample 3 Sample 4
1155:P50-1.8
1387:SdBrsS.1
1373:SdLdwH.1 1372:SdLdwS.1
1388:SdBrsH.1
1385:SdWdS.1
1386:SdWdH.1
1377:SdSonD.1
1378:SdHvy.1 1370:SdFsnL.1 1378:SdHvy.1
1425:Castnt.1
1367:SdBldS.1
1368:SdBldM.1 1366:SdGM.1
1369:SdBldH.1
1391:Stick.1
1362:Bd2.1 1351:Sin.1
1371:SdFsnH.1
1370:SdFsnL.1
1361:BdHby.1 1351:Sin.1
1360:BdPop.1 1351:Sin.1
1389:C.Rim1.1
1374:SdSonA.1 1375:SdSonB.1 1376:SdSonC.1 1377:SdSonD.1
1443:T8Clap.1
1380:SdPclH.1 1379:SdPclS.1 1382:SdPcBH.1
1392:TomF.1
1401:HHCL2.1
1400:HHCl1.1
1393:TomL.1
1401:HHCL2.1
1402:HHCl3.1
1393:TomL.1
1404:HHOpn.1
1402:HHCl3.1
1394:TomM.1
1395:TomHL.1
1407:Crash.1
1396:TomHH.1
1405:Ride.1
1408:China.1
1406:Cup.1
1428:Tmborn.1
1408:China.1 1407:Crash.1
1414:Cowbel.1 1351:Sin.1
1407:Crash.1 1405:Ride.1
1430:VbSlp.1
1405:Ride.1 1406:Cup.1
1410:BongoH.1
1409:BongoL.1
1413:CngSlp.1
1412:CongaH.1
1411:CongaL.1
1419:TmblsH.1 1418:TmblsL.1
1418:TmblsL.1
1415:AgogoL.1
1351:Sin.1
1415:AgogoL.1
1351:Sin.1
1423:Cabasa.1
1426:Maracs.1
1431:Whistl.1
1431:Whistl.1
1417:GiroCl.1
1416:GuiroL.1
1424:Claves.1
1422:Wdblck.1
1422:Wdblck.1
1420:CuicaL.1
1421:CuicaH.1
1429:TrangL.1
1429:TrangL.1
1427:Shaker.1
1433:JnglBl.1
1434:Bltree.1 1434:Bltree.1
P2-125 Rock Kit
Sample 1 Sample 2 Sample 3 Sample 4
1424:Claves.1
1387:SdBrsS.1 1352:Noise.1
1387:SdBrsS.1 1352:Noise.1
1387:SdBrsS.1 1352:Noise.1
1387:SdBrsS.1 1352:Noise.1
0911:SxBrth.1
1383:SdPrmS.1 1368:SdBldM.1 1368:SdBldM.1 1368:SdBldM.1
1425:Castnt.1
1367:SdBldS.1
1384:SdPrmH.1
1391:Stick.1
1361:BdHby.1
1382:SdPcBH.1 1381:SdPcBS.1 1380:SdPclH.1
1360:BdPop.1 1361:BdHby.1
1435:T8BdBm.1
1397:TmJzL.1
1389:C.Rim1.1
1366:SdGM.1
1380:SdPclH.1 1381:SdPcBS.1
1443:T8Clap.1
1382:SdPcBH.1 1379:SdPclS.1
1392:TomF.1 1397:TmJzL.1
1402:HHCl3.1
1468:T9HHC1.1
1392:TomF.1 1397:TmJzL.1
1403:HHPdl.1
1393:TomL.1 1397:TmJzL.1
1404:HHOpn.1
1394:TomM.1 1399:TmJzH.1
1395:TomHL.1 1399:TmJzH.1
1407:Crash.1
1395:TomHL.1 1399:TmJzH.1
1405:Ride.1
1408:China.1
1406:Cup.1 1405:Ride.1
1428:Tmborn.1
1407:Crash.1
1414:Cowbel.1
1407:Crash.1
1430:VbSlp.1
1405:Ride.1
1409:BongoL.1
1409:BongoL.1
1413:CngSlp.1
1412:CongaH.1
1411:CongaL.1
1419:TmblsH.1 1418:TmblsL.1
1418:TmblsL.1
1415:AgogoL.1
1415:AgogoL.1
1423:Cabasa.1
1426:Maracs.1 1426:Maracs.1
1431:Whistl.1
1431:Whistl.1
1417:GiroCl.1
1416:GuiroL.1
1424:Claves.1
1422:Wdblck.1
1422:Wdblck.1
1420:CuicaL.1
1421:CuicaH.1
1429:TrangL.1
1429:TrangL.1
1427:Shaker.1
1433:JnglBl.1
1434:Bltree.1
P2-126 Jazzy Kit
Sample 1 Sample 2 Sample 3
Sample 4
1155:P50-1.8
1387:SdBrsS.1
1373:SdLdwH.1 1372:SdLdwS.1
1388:SdBrsH.1
1387:SdBrsS.1
1352:Noise.1
0911:SxBrth.1
1385:SdWdS.1
1386:SdWdH.1
1425:Castnt.1
1367:SdBldS.1 1368:SdBldM.1
1391:Stick.1
1362:Bd2.1 1351:Sin.1
1371:SdFsnH.1 1370:SdFsnL.1
1365:BdLoJz.1
1351:Sin.1
1364:BdHiJz.1
1351:Sin.1
1390:C.Rim2.1
1374:SdSonA.1 1375:SdSonB.1 1376:SdSonC.1
1443:T8Clap.1
1387:SdBrsS.1 1388:SdBrsH.1
1397:TmJzL.1
1402:HHCl3.1 1401:HHCL2.1
1400:HHCl1.1
1397:TmJzL.1
1403:HHPdl.1 1403:HHPdl.1
1398:TmJzM.1
1404:HHOpn.1 1402:HHCl3.1
1398:TmJzM.1
1399:TmJzH.1 1351:Sin.1
1407:Crash.1
1399:TmJzH.1 1351:Sin.1
1405:Ride.1
1408:China.1
1406:Cup.1
1428:Tmborn.1
1408:China.1 1407:Crash.1
1414:Cowbel.1 1351:Sin.1
1407:Crash.1 1405:Ride.1
1430:VbSlp.1
1405:Ride.1 1406:Cup.1
1410:BongoH.1
1409:BongoL.1
1413:CngSlp.1
1412:CongaH.1
1411:CongaL.1
1419:TmblsH.1 1418:TmblsL.1
1418:TmblsL.1
1415:AgogoL.1 1351:Sin.1
1415:AgogoL.1 1351:Sin.1
1423:Cabasa.1
1426:Maracs.1
1431:Whistl.1
1431:Whistl.1
1417:GiroCl.1
1416:GuiroL.1
1424:Claves.1
1422:Wdblck.1
1422:Wdblck.1
1420:CuicaL.1
1421:CuicaH.1
1429:TrangL.1
1429:TrangL.1
1427:Shaker.1
1433:JnglBl.1
1434:Bltree.1 1434:Bltree.1
P2-127 House Kit
Sample 1 Sample 2
Sample 3 Sample 4
1407:Crash.1
1364:BdHiJz.1
1482:CONG.1
1369:SdBldH.1
1482:CONG.1
1474:EuroBD.1
1435:T8BdBm.1
1455:T9BD2.1
1456:T9BD3.1
1464:T9Rim.1 1484:WdBlk.1
1458:T9SD2.1
1442:T8Rmst.1
1461:T9SD5.1
1457:T9SD1.1
1435:T8BdBm.1
1468:T9HHC1.1
1435:T8BdBm.1
1469:T9HHC2.1
1435:T8BdBm.1
1470:T9HHO1.1
1435:T8BdBm.1
1471:T9HHO2.1
1472:T9Crsh.1
1473:T9Ride.1
1463:T9Clap.1
1477:AnvlPp.1
1454:T9BD1.1
1382:SdPcBH.1
1484:WdBlk.1
1477:AnvlPp.1
1482:CONG.1
1476:AnvlHt.1
1483:StlClp.1
1481:Ripper.1
1482:CONG.1
1450:T8CngH.1
1482:CONG.1
1450:T8CngH.1
1482:CONG.1
1450:T8CngH.1
1450:T8CngH.1
1447:T8Crsh.1
1445:T8HHCl.1
1446:T8HHOp.1
1429:TrangL.1
1453:T8Mrcs.1
1429:TrangL.1
1427:Shaker.1
1476:AnvlHt.1
1476:AnvlHt.1
1452:T8Clve.1
1480:VoxDrm.1
1475:DstKik.1
1447:T8Crsh.1
1433:JnglBl.1
1428:Tmborn.1
1428:Tmborn.1
1357:BigSyn.1
1357:BigSyn.1
1354:Melow.1
1358:VxDcnd.1
1358:VxDcnd.1
1358:VxDcnd.1
1437:T8SD1.1
1431:Whistl.1
1379:SdPclS.1
1472:T9Crsh.1
1363:BdDeep.1
P2-128 Tech Kit
Sample 1 Sample 2
Sample 3 Sample 4
1407:Crash.1
1366:SdGM.1
1475:DstKik.1
1370:SdFsnL.1
1475:DstKik.1
1474:EuroBD.1
1435:T8BdBm.1
1454:T9BD1.1
1456:T9BD3.1
1464:T9Rim.1
1457:T9SD1.1
1475:DstKik.1
1460:T9SD4.1
1465:T9TomL.1
1468:T9HHC1.1
1465:T9TomL.1
1469:T9HHC2.1
1466:T9TomM.1
1470:T9HHO1.1
1467:T9TomH.1
1471:T9HHO2.1
1472:T9Crsh.1
1473:T9Ride.1
1463:T9Clap.1
1454:T9BD1.1
1455:T9BD2.1
1458:T9SD2.1
1484:WdBlk.1
1477:AnvlPp.1
1461:T9SD5.1
1476:AnvlHt.1
1483:StlClp.1
1481:Ripper.1
1482:CONG.1
1450:T8CngH.1
1482:CONG.1
1450:T8CngH.1
1482:CONG.1
1450:T8CngH.1
1450:T8CngH.1
1447:T8Crsh.1
1445:T8HHCl.1
1446:T8HHOp.1
1429:TrangL.1
1453:T8Mrcs.1
1429:TrangL.1
1427:Shaker.1
1477:AnvlPp.1
1476:AnvlHt.1
1452:T8Clve.1
1480:VoxDrm.1
1475:DstKik.1
1447:T8Crsh.1
1458:T9SD2.1
1428:Tmborn.1
1428:Tmborn.1
0396:Perc.A
0401:SftTmp.1
1355:WndChm.1
1358:VxDcnd.1
1358:VxDcnd.1
1359:BdStd.1
1360:BdPop.1
1385:SdWdS.1
1379:SdPclS.1
1363:BdDeep.1
25
Internal 2:126-128
(MSB=63, LSB=3)
I2-126 Alien Kit I2-127 FX Kit I2-128 Street Kit
Note No.
Note
Sample 1 Sample 2 Sample 3 Sample 4 Sample 1 Sample 2 Sample 3 Sample 4 Sample 1 Sample 2 Sample 3 Sample 4
C 0 1397:TmJzL.1 1435:T8BdBm.1 1436:T8Bd.1
25
24
C#0 1435:T8BdBm.1 1437:T8SD1.1
26 D 0 1475:DstKik.1 1384:SdPrmH.1
27 D#0 1393:TomL.1 1378:SdHvy.1
28 E 0 1407:Crash.1 1454:T9BD1.1 1454:T9BD1.1 1436:T8Bd.1 1456:T9BD3.1
29 F 0 1366:SdGM.1 1455:T9BD2.1 1379:SdPclS.1 1380:SdPclH.1 1379:SdPclS.1 1454:T9BD1.1
30 F#0 1475:DstKik.1 1384:SdPrmH.1 1400:HHCl1.1 1455:T9BD2.1
31 G 0 1370:SdFsnL.1 1400:HHCl1.1 1400:HHCl1.1 1402:HHCl3.1 1361:BdHby.1
32 G#0 1475:DstKik.1 1378:SdHvy.1 1377:SdSonD.1 1376:SdSonC.1 1365:BdLoJz.1
33 A 0 1362:Bd2.1 1444:T8Tom.1 1361:BdHby.1 1361:BdHby.1
A#0 1435:T8BdBm.1 1405:Ride.1 1379:SdPclS.1
35
34
B 0 1454:T9BD1.1 1405:Ride.1 1435:T8BdBm.1
36 C 1 1362:Bd2.1 1435:T8BdBm.1 1435:T8BdBm.1 1454:T9BD1.1
37 C#1 1366:SdGM.1 1391:Stick.1 1476:AnvlHt.1 1390:C.Rim2.1
38 D 1 1457:T9SD1.1 1459:T9SD3.1 1447:T8Crsh.1 1458:T9SD2.1 1001:MogBs2.1
39 D#1 1435:T8BdBm.1 1443:T8Clap.1 1432:Clap.1
E 1 1460:T9SD4.1 1475:DstKik.1 1386:SdWdH.1
41
42
43
44
45
46
47
48
49
40
F 1 1465:T9TomL.1 1392:TomF.1 1380:SdPclH.1 1444:T8Tom.1
F#1 1400:HHCl1.1 1468:T9HHC1.1 1400:HHCl1.1
G 1 1465:T9TomL.1 1399:TmJzH.1 1476:AnvlHt.1 1471:T9HHO2.1 1444:T8Tom.1
G#1 1401:HHCL2.1 1426:Maracs.1 1403:HHPdl.1
A 1 1466:T9TomM.1 1393:TomL.1 1406:Cup.1 1444:T8Tom.1
A#1 1470:T9HHO1.1 1446:T8HHOp.1 1408:China.1 1446:T8HHOp.1
B 1 1467:T9TomH.1 1397:TmJzL.1 1415:AgogoL.1 1444:T8Tom.1
C 2 1403:HHPdl.1 1409:BongoL.1 1477:AnvlPp.1 1444:T8Tom.1
C#2 1407:Crash.1 1355:WndChm.1 1358:VxDcnd.1 1405:Ride.1 1472:T9Crsh.1
50 D 2 1472:T9Crsh.1 1409:BongoL.1 1418:TmblsL.1 1444:T8Tom.1
51 D#2 1360:BdPop.1 1362:Bd2.1 1436:T8Bd.1 1405:Ride.1 1447:T8Crsh.1 1447:T8Crsh.1
52 E 2 1456:T9BD3.1 1407:Crash.1 1407:Crash.1
53 F 2 1455:T9BD2.1 1406:Cup.1 1434:Bltree.1 1406:Cup.1
F#2 1388:SdBrsH.1 1378:SdHvy.1 1457:T9SD1.1 1428:Tmborn.1 1481:Ripper.1 1428:Tmborn.1
55
54
G 2 1484:WdBlk.1 1407:Crash.1 1472:T9Crsh.1 1407:Crash.1
56 G#2 0398:Clack.1 1451:T8Cwbl.1 1406:Cup.1 1477:AnvlPp.1 1451:T8Cwbl.1
57 A 2 0420:FngCym.1 1407:Crash.1 1407:Crash.1
58 A#2 1476:AnvlHt.1 1477:AnvlPp.1 1452:T8Clve.1 1412:CongaH.1
59 B 2 1483:StlClp.1 1405:Ride.1 1405:Ride.1 1405:Ride.1
60 C 3 1481:Ripper.1 1000:MogBs1.1 1001:MogBs2.1
61 C#3 1482:CONG.1 1000:MogBs1.1 1047:P5Saw.1
62 D 3 1395:TomHL.1 1410:BongoH.1 1410:BongoH.1 1030:FMGtr.1
63 D#3 1484:WdBlk.1 1449:T8CngM.1 1412:CongaH.1 1412:CongaH.1 1474:EuroBD.1
E 3 1460:T9SD4.1 1482:CONG.1 1001:MogBs2.1
65
64
F 3 1443:T8Clap.1 1443:T8Clap.1 1419:TmblsH.1 1419:TmblsH.1 1419:TmblsH.1 1087:1o1Sub.B
66 F#3 1402:HHCl3.1 1418:TmblsL.1 1106:MgRamp.2
67 G 3 1400:HHCl1.1 0439:HndBel.1 1477:AnvlPp.1
68 G#3 1404:HHOpn.1 0430:Gamln2.2 1477:AnvlPp.1
69 A 3 1429:TrangL.1 1357:BigSyn.1 1473:T9Ride.1
70 A#3 1453:T8Mrcs.1 1402:HHCl3.1 1476:AnvlHt.1
71 B 3 1429:TrangL.1 1354:Melow.1 1105:MgRamp.1
72 C 4 1427:Shaker.1 1354:Melow.1 1481:Ripper.1
73 C#4 1477:AnvlPp.1 1477:AnvlPp.1 1417:GiroCl.1 1451:T8Cwbl.1
D 4 1476:AnvlHt.1 1476:AnvlHt.1 1430:VbSlp.1 1002:MogBs3.1
75
74
D#4 1409:BongoL.1 0398:Clack.1 0230:D16.E
76 E 4 1480:VoxDrm.1 0435:Marimb.2 1464:T9Rim.1
77 F 4 1475:DstKik.1 0398:Clack.1 1064:Saw2.4
78 F#4 1447:T8Crsh.1 1353:VoxBel.1 0869:Oooo.2
79 G 4 1458:T9SD2.1 1353:VoxBel.1 1478:Scrch1.1
80 G#4 1428:Tmborn.1 1429:TrangL.1 1429:TrangL.1
81 A 4 1428:Tmborn.1 0433:Glock.3 1429:TrangL.1
82 A#4 0398:Clack.1 1000:MogBs1.1 1000:MogBs1.1
83 B 4 0401:SftTmp.1 1434:Bltree.1 1000:MogBs1.1
C 5 1352:Noise.1 1358:VxDcnd.1 1432:Clap.1 1432:Clap.1
85
84
C#5 1358:VxDcnd.1 1358:VxDcnd.1 1479:Scrch2.1
86 D 5 1358:VxDcnd.1 1358:VxDcnd.1 1463:T9Clap.1
87 D#5 1359:BdStd.1 1357:BigSyn.1 1479:Scrch2.1
88 E 5 1360:BdPop.1 1357:BigSyn.1 1358:VxDcnd.1
89 F 5 1385:SdWdS.1 1089:SawSqu.1 1358:VxDcnd.1
90 F#5 1379:SdPclS.1 1355:WndChm.1 1378:SdHvy.1
91 G 5 1363:BdDeep.1 1356:BelAir.1 1380:SdPclH.1
26
■Sample List ■Liste mit Samples
■Liste des échantillons
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
1 Grnd1.1 81 Rho3.1 161 JmPrc.1 241 D5 1/3.A 321 D1 1/3.1 401 SftTmp.1 481 SftFlg.3
2 Grnd1.2 82 Rho3.2 162 JmPrc.2 242 D5 1/3.B 322 D1 1/3.2 402 Farfis.1 482 SftFlg.4
3 Grnd1.3 83 Rho3.3 163 JmPrc.3 243 D5 1/3.C 323 D1 1/3.3 403 Farfis.2 483 SftFlg.5
4 Grnd1.4 84 Rho3.4 164 JmPrc.4 244 D5 1/3.D 324 D1 1/3.4 404 Farfis.3 484 SftFlg.6
5 Grnd1.5 85 Rho3.5 165 JmPrc.5 245 D5 1/3.E 325 D1 1/3.5 405 Farfis.4 485 SftFlg.7
6 Grnd1.6 86 Rho3.6 166 JmPrc.6 246 D5 1/3.F 326 D1 1/3.6 406 Farfis.5 486 SftFlg.8
7 Grnd1.7 87 Rho3.7 167 JmPrc.7 247 D5 1/3.G 327 D1 1/3.7 407 Farfis.6 487 Hermn.1
8 Grnd1.8 88 Rho3.8 168 JmPrc.8 248 D5 1/3.H 328 D1 1/3.8 408 Farfis.7 488 Hermn.2
9 Grnd1.9 89 Rho4.1 169 JmPrc.9 249 D5 1/3.I 329 D1 1/3.9 409 Farfis.8 489 Hermn.3
10 Grnd1.A 90 Rho4.2 170 JmPrc.A 250 D5 1/3.J 330 D1 1/3.A 410 Farfis.9 490 Hermn.4
11 Grnd1.B 91 Rho4.3 171 JmPrc.B 251 D8.1 331 D1 1/3.B 411 Farfis.A 491 Hermn.5
12 Grnd1.C 92 Rho4.4 172 JmPrc-.1 252 D8.2 332 D1 1/3.C 412 Farfis.B 492 Hermn.6
13 Grnd1.D 93 Rho4.5 173 Jazz.1 253 D8.3 333 D1 1/3.D 413 VoxOrg.1 493 Strgt.1
14 Grnd1.E 94 Rho4.6 174 Jazz.2 254 D8.4 334 D1.1 414 VoxOrg.2 494 Strgt.2
15 Grnd1.F 95 Rho4.7 175 Jazz.3 255 D8.5 335 D1.2 415 VoxOrg.3 495 Strgt.3
16 Grnd1.G 96 Rho4.8 176 Jazz.4 256 D8.6 336 D1.3 416 VoxOrg.4 496 Strgt.4
17 Grnd1.H 97 Rho4.9 177 Jazz.5 257 D8.7 337 D1.4 417 VoxOrg.5 497 Strgt.5
18 Grnd2.1 98 Rho4.A 178 Jazz.6 258 D8.8 338 D1.5 418 VoxOrg.6 498 Strgt.6
19 Grnd2.2 99 Rho4.B 179 Jazz.7 259 D8.9 339 D1.6 419 VxOrg-.1 499 Strgt.7
20 Grnd2.3 100 Wurli.1 180 Jazz.8 260 D8.A 340 D1.7 420 FngCym.1 500 TrpMed.1
21 Grnd2.4 101 Wurli.2 181 Jazz.9 261 D8.B 341 D1.8 421 Hibasi.1 501 TrpMed.2
22 Grnd2.5 102 Wurli.3 182 Jazz.A 262 D8.C 342 D1.9 422 StoneH.1 502 TrpMed.3
23 Grnd2.6 103 Wurli.4 183 Jazz.B 263 D8.D 343 D1.A 423 StoneH.2 503 TrpMed.4
24 Grnd2.7 104 Wurli.5 184 Rock.1 264 D4.1 344 D1.B 424 StoneS.1 504 TrpMed.5
25 Grnd2.8 105 Wurli.6 185 Rock.2 265 D4.2 345 Dw1+3.1 425 StoneS.2 505 TrpMed.6
26 Grnd2.9 106 Wurli.7 186 Rock.3 266 D4.3 346 Dw1+3.2 426 Gamln1.1 506 TrpSft.1
27 Grnd2.A 107 Wurli.8 187 Rock.4 267 D4.4 347 Dw1+3.3 427 Gamln1.2 507 TrpSft.2
28 Grnd2.B 108 Wurli.9 188 Rock.5 268 D4.5 348 Dw1+3.4 428 Gamln1.3 508 TrpSft.3
29 CP80.1 109 Wurli.A 189 Rock.6 269 D4.6 349 Dw1+3.5 429 Gamln2.1 509 TrpSft.4
30 CP80.2 110 Wurli.B 190 Rock.7 270 D4.7 350 Dw1+3.6 430 Gamln2.2 510 TrpSft.5
31 CP80.3 111 Wurli.C 191 Rock.8 271 D4.8 351 Dw1+3.7 431 Glock.1 511 TrpSft.6
32 CP80.4 112 Wurli.D 192 Rock.9 272 D4.9 352 Dw1+3.8 432 Glock.2 512 Trmpt.1
33 CP80.5 113 Wurli.E 193 Rock.A 273 D4.A 353 Dw1+3.9 433 Glock.3 513 Trmpt.2
34 CP80.6 114 Wurli+.1 194 Rock.B 274 D4.B 354 Dw1+3.A 434 Marimb.1 514 Trmpt.3
35 CP80.7 115 Wurli+.2 195 Rock.C 275 D4.C 355 Dw1+3.B 435 Marimb.2 515 Trmpt.4
36 CP80.8 116 DX7S.1 196 Rock.D 276 D4.D 356 Dw2+4.1 436 Vibra.1 516 Trmpt.5
37 CP80.9 117 DX7S.2 197 Rock.E 277 D2 2/3.1 357 Dw2+4.2 437 Vibra.2 517 Trmpt.6
38 CP80.A 118 DX7S.3 198 Rock.F 278 D2 2/3.2 358 Dw2+4.3 438 Xylo.1 518 Combi3.1
39 CP80.B 119 DX7S.4 199 Rock.G 279 D2 2/3.3 359 Dw2+4.4 439 HndBel.1 519 Horn.1
40 CP80.C 120 DX7H.1 200 Rock.H 280 D2 2/3.4 360 Dw2+4.5 440 HndBel.2 520 Horn.2
41 CP80.D 121 DX7H.2 201 Rock.I 281 D2 2/3.5 361 Dw2+4.6 441 HndBel.3 521 Horn.3
42 CP80+.1 122 DX7H.3 202 Rock.J 282 D2 2/3.6 362 Dw2+4.7 442 HndBel.4 522 StrL.1
43 CP80-.1 123 DX7H.4 203 Swish.1 283 D2 2/3.7 363 Dw2+4.8 443 HndBel.5 523 StrL.2
44 Rho1P.1 124 DX7H.5 204 Swish.2 284 D2 2/3.8 364 Dw2+4.9 444 HndBel.6 524 StrL.3
45 Rho1P.2 125 Clav1.1 205 Swish.3 285 D2 2/3.9 365 Dw2+4.A 445 SectnL.1 525 StrL.4
46 Rho1P.3 126 Clav1.2 206 Swish.4 286 D2 2/3.A 366 DrwEv.1 446 SectnL.2 526 StrL.5
47 Rho1P.4 127 Clav1.3 207 Swish.5 287 D2 2/3.B 367 DrwEv.2 447 SectnL.3 527 StrL.6
48 Rho1P.5 128 Clav1.4 208 Swish.6 288 D2 2/3.C 368 DrwEv.3 448 SectnL.4 528 StrL.7
49 Rho1P.6 129 Clav1.5 209 Swish.7 289 D2 2/3.D 369 DrwEv.4 449 SectnL.5 529 StrL.8
50 Rho1P.7 130 Clav1.6 210 Swish.8 290 D2.1 370 DrwEv.5 450 SectnL.6 530 StrL.9
51 Rho1P.8 131 Clav1.7 211 Swish.9 291 D2.2 371 DrwEv.6 451 SectnR.1 531 StrR.1
52 Rho1P.9 132 Clav1+.1 212 Swish.A 292 D2.3 372 DrwEv.7 452 SectnR.2 532 StrR.2
53 Rho1L.1 133 Clav2.1 213 Swish.B 293 D2.4 373 DrwEv.8 453 SectnR.3 533 StrR.3
54 Rho1L.2 134 Clav2.2 214 Swish.C 294 D2.5 374 DrwEv.9 454 PopBrs.1 534 StrR.4
55 Rho1L.3 135 Clav2.3 215 Swish.D 295 D2.6 375 DrwEv.A 455 PopBrs.2 535 StrR.5
56 Rho1L.4 136 Clav2.4 216 Swish-.1 296 D2.7 376 DrwEv.B 456 PopBrs.3 536 StrR.6
57 Rho1L.5 137 Clav2.5 217 D16.1 297 D2.8 377 DrwOd.1 457 PopBrs.4 537 StrR.7
58 Rho1L.6 138 Clav2.6 218 D16.2 298 D2.9 378 DrwOd.2 458 PopBrs.5 538 StrR.8
59 Rho1L.7 139 Clav2.7 219 D16.3 299 D2.A 379 DrwOd.3 459 PopBrs.6 539 StrR.9
60 Rho1L.8 140 Clav2.8 220 D16.4 300 D2.B 380 DrwOd.4 460 PopBrs.7 540 EnsMx.1
61 Rho1L.9 141 Clav2.9 221 D16.5 301 D2.C 381 DrwOd.5 461 Trmbn.1 541 EnsMx.2
62 Rho2S.1 142 Clav2.A 222 D16.6 302 D2.D 382 DrwOd.6 462 Trmbn.2 542 EnsMx.3
63 Rho2S.2 143 Clav2.B 223 D16.7 303 D1 3/5.1 383 DrwOd.7 463 Trmbn.3 543 EnsMx.4
64 Rho2S.3 144 Clav2.C 224 D16.8 304 D1 3/5.2 384 DrwOd.8 464 Trmbn.4 544 EnsMx.5
65 Rho2S.4 145 Clav2.D 225 D16.9 305 D1 3/5.3 385 DrwOd.9 465 Trmbn.5 545 EnsMx.6
66 Rho2S.5 146 Clav2.E 226 D16.A 306 D1 3/5.4 386 DrwOd.A 466 Trmbn.6 546 EnsMx.7
67 Rho2S.6 147 Clav3A.1 227 D16.B 307 D1 3/5.5 387 Perc.1 467 Trmbn.7 547 EnsMx.8
68 Rho2M.1 148 Clav3A.2 228 D16.C 308 D1 3/5.6 388 Perc.2 468 Trmbn.8 548 EnsMx.9
69 Rho2M.2 149 Clav3A.3 229 D16.D 309 D1 3/5.7 389 Perc.3 469 Trmbn.9 549 EnsMx.A
70 Rho2M.3 150 Clav3A.4 230 D16.E 310 D1 3/5.8 390 Perc.4 470 Trmbn.A 550 Nylon.1
71 Rho2M.4 151 Clav3A.5 231 D16.F 311 D1 3/5.9 391 Perc.5 471 SftTrb.1 551 Nylon.2
72 Rho2M.5 152 Clav3A.6 232 D5 1/3.1 312 D1 3/5.A 392 Perc.6 472 SftTrb.2 552 Nylon.3
73 Rho2M.6 153 Clav3A.7 233 D5 1/3.2 313 D1 3/5.B 393 Perc.7 473 SftTrb.3 553 Nylon.4
74 Rho2M.7 154 Clav3L.1 234 D5 1/3.3 314 D1 3/5.C 394 Perc.8 474 SftTrb.4 554 Nylon.5
75 Rho2H.1 155 Clav3L.2 235 D5 1/3.4 315 D1 3/5.D 395 Perc.9 475 SftTrb.5 555 Nylon.6
76 Rho2H.2 156 Clav3L.3 236 D5 1/3.5 316 D1 3/5.E 396 Perc.A 476 SftTrb.6 556 Nylon.7
77 Rho2H.3 157 Clav3L.4 237 D5 1/3.6 317 D1 3/5.F 397 Rotar.1 477 SftTrb.7 557 Nylon.8
78 Rho2H.4 158 Clav3L.5 238 D5 1/3.7 318 D1 3/5.G 398 Clack.1 478 SftTrb.8 558 Nylon.9
79 Rho2H.5 159 Clav3L.6 239 D5 1/3.8 319 D1 3/5.H 399 LesWho.1 479 SftFlg.1 559 Nylon.A
80 Rho2H.6 160 Clav3L.7 240 D5 1/3.9 320 D1 3/5.I 400 LesGrt.1 480 SftFlg.2 560 Nylon.B
27
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
561 NylnHi.1 641 StrtF.8 721 Dist2.7 801 Precsn.3 881 Alto.2 961 Padd.1 1041 Late-L.3
562 NylnHi.2 642 StrtF.9 722 Dist2.8 802 Precsn.4 882 Alto.3 962 ObBrs.1 1042 Late-L.4
563 NylnHi.3 643 StrtSl.1 723 Dist2.9 803 Precsn.5 883 Alto.4 963 ObBrs.2 1043 Late-L.5
564 NylnHi.4 644 StrtSl.2 724 Dist2.A 804 Precsn.6 884 Alto.5 964 ObBrs.3 1044 Late-L.6
565 Nylhrm.1 645 StrtSl.3 725 Dist2.B 805 Precsn.7 885 Alto.6 965 ObBrs.4 1045 Late-L.7
566 Nylhrm.2 646 StrtSl.4 726 Dist2.C 806 Precsn.8 886 Alto.7 966 ObBrs.5 1046 Late-L.8
567 Nylhrm.3 647 StrtSl.5 727 DistMt.1 807 Prcsn+.1 887 Alto.8 967 ObBrs.6 1047 P5Saw.1
568 Nylhrm.4 648 StrtSl.6 728 DistMt.2 808 Prcsn+.2 888 Alto.9 968 SyncLd.1 1048 P5Saw.2
569 Steel.1 649 StrtSl.7 729 DistMt.3 809 Prcsn+.3 889 Alto.A 969 SyncLd.2 1049 P5Saw.3
570 Steel.2 650 StrtSp.1 730 DistMt.4 810 Pecsn-.1 890 Tenor.1 970 SyncLd.3 1050 P5Saw.4
571 Steel.3 651 StrtSp.2 731 DistMt.5 811 Pecsn-.2 891 Tenor.2 971 SyncLd.4 1051 P5Saw.5
572 Steel.4 652 StrtSp.3 732 DistMt.6 812 Pecsn-.3 892 Tenor.3 972 SyncLd.5 1052 P5Saw.6
573 Steel.5 653 StrtSp.4 733 DistMt.7 813 Pecsn-.4 893 Tenor.4 973 SyncLd.6 1053 P5Saw.7
574 Steel.6 654 StrtSp.5 734 DistMt.8 814 PrsRw.1 894 Tenor.5 974 SyncLd.7 1054 P5Saw.8
575 Steel.7 655 StrtSp.6 735 DistMt.9 815 PrsRw.2 895 Tenor.6 975 SyncLd.8 1055 P5Saw.9
576 Steel.8 656 StrtSp.7 736 DistMt.A 816 PrsRw.3 896 Tenor.7 976 CS80Br.1 1056 P5Saw.A
577 Steel.9 657 StrtSp.8 737 DistMt.B 817 PrsRw.4 897 Tenor.8 977 CS80Br.2 1057 P5Saw.B
578 StelHi.1 658 StrtSp.9 738 FeedBk.1 818 PrsRw.5 898 Tenor.9 978 CS80Br.3 1058 P5Saw.C
579 StelHi.2 659 StrtMt.1 739 FeedBk.2 819 PrsRw.6 899 Tenor.A 979 CS80Br.4 1059 P5Saw.D
580 StelHi.3 660 StrtMt.2 740 FeedBk.3 820 PrsRw.7 900 Tenor.B 980 CS80Br.5 1060 P5Saw.E
581 StelLo.1 661 StrtMt.3 741 FeedBk.4 821 PrsRw.8 901 Tenor+.1 981 CS80Br.6 1061 Saw2.1
582 StelLo.2 662 StrtMt.4 742 FeedBk.5 822 PrsRw-.1 902 Bari.1 982 CS80Br.7 1062 Saw2.2
583 StlHrm.1 663 StrtMt.5 743 FeedBk.6 823 Pick.1 903 Bari.2 983 CS80Br.8 1063 Saw2.3
584 StlHrm.2 664 StrtMt.6 744 FeedBk.7 824 Pick.2 904 Bari.3 984 CS80Br.9 1064 Saw2.4
585 StlHrm.3 665 StrtMt.7 745 FeedBk.8 825 Pick.3 905 Bari.4 985 3o3Saw.1 1065 Saw2.5
586 StlHrm.4 666 StrtMt.8 746 FeedBk.9 826 Slap.1 906 Bari.5 986 3o3Saw.2 1066 Saw2.6
587 StlHrm.5 667 StrHrm.1 747 FeedBk.A 827 Slap.2 907 Bari.6 987 3o3Saw.3 1067 1o1Saw.1
588 StlHrm.6 668 StrHrm.2 748 FeedBk.B 828 Slap.3 908 Bari.7 988 3o3Saw.4 1068 1o1Saw.2
589 Single.1 669 StrHrm.3 749 FeedBk.C 829 Slap.4 909 Bari.8 989 3o3Saw.5 1069 1o1Saw.3
590 Single.2 670 StrHrm.4 750 FeedBk.D 830 Slap.5 910 Bari.9 990 3o3Saw.6 1070 1o1Saw.4
591 Single.3 671 StrHrm.5 751 FeedBk.E 831 Slap.6 911 SxBrth.1 991 3o3Saw.7 1071 1o1Saw.5
592 Single.4 672 Telcs.1 752 FeedBk.F 832 Slap2.1 912 Soprn.1 992 3o3Squ.1 1072 1o1Saw.6
593 Single.5 673 Telcs.2 753 FeedBk.G 833 Slap2.2 913 Soprn.2 993 3o3Squ.2 1073 1o1Saw.7
594 Single.6 674 Telcs.3 754 FeedBk.H 834 Slap2.3 914 Soprn.3 994 3o3Squ.3 1074 1o1Saw.8
595 Single.7 675 Telcs.4 755 FeedBk.I 835 Slap2.4 915 Soprn.4 995 3o3Squ.4 1075 1o1Saw.9
596 Single.8 676 Telcs.5 756 FeedBk.J 836 Frtl1.1 916 Soprn.5 996 3o3Squ.5 1076 1o1Saw.A
597 Single.9 677 Telcs.6 757 FeedBk.K 837 Frtl1.2 917 Soprn.6 997 3o3Squ.6 1077 1o1Sub.1
598 Single.A 678 Telcs.7 758 FeedBk.L 838 Frtl1.3 918 Soprn.7 998 3o3Squ.7 1078 1o1Sub.2
599 SnglHi.1 679 Telcs.8 759 FeedBk.M 839 Frtl1.4 919 Soprn.8 999 3o3Squ.8 1079 1o1Sub.3
600 SnglHi.2 680 Telcs.9 760 FeedBk.N 840 Frtl1.5 920 Soprn.9 1000 MogBs1.1 1080 1o1Sub.4
601 SnglHi.3 681 ES335.1 761 FeedBk.O 841 Frtl1.6 921 Soprn.A 1001 MogBs2.1 1081 1o1Sub.5
602 SnglHi.4 682 ES335.2 762 FeedBk.P 842 Frtl1+.1 922 Clari.1 1002 MogBs3.1 1082 1o1Sub.6
603 SnglHi.5 683 ES335.3 763 AcStic.1 843 Frtl1-.1 923 Clari.2 1003 FMBs1.1 1083 1o1Sub.7
604 SnglHi.6 684 ES335.4 764 AcStic.2 844 Frtl1-.2 924 Clari.3 1004 FMBs1.2 1084 1o1Sub.8
605 JzGtr.1 685 ES335.5 765 AcStic.3 845 Frtl2.1 925 Clari.4 1005 FMBs1.3 1085 1o1Sub.9
606 JzGtr.2 686 ES335.6 766 AcStic.4 846 Frtl2.2 926 Clari.5 1006 FMBs1.4 1086 1o1Sub.A
607 JzGtr.3 687 ES335.7 767 AcStic.5 847 Frtl2.3 927 Oboe.1 1007 FMBs1.5 1087 1o1Sub.B
608 JzGtr.4 688 ES335.8 768 AcStic.6 848 Frtl2.4 928 Oboe.2 1008 FMBs2.1 1088 1o1Sub.C
609 JzGtr.5 689 ES335.9 769 AcStic.7 849 Frtl2.5 929 Oboe.3 1009 FMBs2.2 1089 SawSqu.1
610 JzGtr.6 690 ES335.A 770 AcStic.8 850 Frtl2.6 930 Oboe.4 1010 FMBs2.3 1090 SawSqu.2
611 JzGtr.7 691 Front.1 771 AcStc-.1 851 SynVx1.1 931 Oboe.5 1011 FMBs3.1 1091 SawSqu.3
612 JzGtr.8 692 Front.2 772 6StrFn.1 852 SynVx1.2 932 Oboe.6 1012 FMBs3.2 1092 SawSqu.4
613 Strt.1 693 Front.3 773 6StrFn.2 853 SynVx1.3 933 Oboe.7 1013 FMBs3.3 1093 SawSqu.5
614 Strt.2 694 Front.4 774 6StrFn.3 854 SynVx1.4 934 Flute.1 1014 FMBs3.4 1094 SawSqu.6
615 Strt.3 695 Front.5 775 6StrFn.4 855 SynVx1.5 935 Flute.2 1015 FMBs4.1 1095 SawSqu.7
616 Strt.4 696 Front.6 776 6StrFn.5 856 SynVx2.1 936 Flute.3 1016 FMBs4.2 1096 SawSqu.8
617 Strt.5 697 Front.7 777 6StrFn.6 857 SynVx2.2 937 Flute.4 1017 FMBs4.3 1097 SquSaw.1
618 Strt.6 698 Front.8 778 6StrF-.1 858 SynVx2.3 938 Flute.5 1018 FMBs5.1 1098 SquSaw.2
619 Strt.7 699 Front.9 779 Fing1.1 859 SynVx2.4 939 Flute.6 1019 FMBs5.2 1099 SquSaw.3
620 Strt.8 700 DistCl.1 780 Fing1.2 860 SynVx2.5 940 Flute.7 1020 FMBs5.3 1100 SquSaw.4
621 Strt.9 701 DistCl.2 781 Fing1.3 861 SynVx2.6 941 Flute.8 1021 FMBs5.4 1101 SquSaw.5
622 Strt.A 702 DistCl.3 782 Fing1.4 862 VxNoiz.1 942 Flute.9 1022 FMBs5.5 1102 SquSaw.6
623 Strt.B 703 DistCl.4 783 Fing1.5 863 VxNoiz.2 943 PnFlt.1 1023 FMBs6.1 1103 SquSaw.7
624 StrtN.1 704 DistCl.5 784 Fing1.6 864 VxNoiz.3 944 PnFlt.2 1024 FMBs6.2 1104 SquSaw.8
625 StrtN.2 705 DistCl.6 785 Fing1.7 865 VxNoiz.4 945 PnFlt.3 1025 FMBs6.3 1105 MgRamp.1
626 StrtN.3 706 DistCl.7 786 Fing1.8 866 VxNoiz.5 946 PnFlt.4 1026 FMBs6.4 1106 MgRamp.2
627 StrtN.4 707 DistCl.8 787 Fing1+.1 867 VxNoiz.6 947 PnFlt.5 1027 FMBs6.5 1107 MgRamp.3
628 StrtN.5 708 DistCl.9 788 Fing1+.2 868 Oooo.1 948 ModSaw.1 1028 FMBs6.6 1108 MgRamp.4
629 StrtN.6 709 DistCl.A 789 Fing1-.1 869 Oooo.2 949 ModSaw.2 1029 FMFnk.1 1109 MgRamp.5
630 StrtN.7 710 DistCl.B 790 Fing1-.2 870 Oooo.3 950 ModSaw.3 1030 FMGtr.1 1110 MgRamp.6
631 StrtN.8 711 DistCl.C 791 Fing2.1 871 Oooo.4 951 ObStr.1 1031 Late-S.1 1111 MgRamp.7
632 StrtN.9 712 DistCl.D 792 Fing2.2 872 Oooo.5 952 ObStr.2 1032 Late-S.2 1112 MgRamp.8
633 StrtN.A 713 DistCl.E 793 Fing2.3 873 Oooo-.1 953 ObStr.3 1033 Late-S.3 1113 P10-1.1
634 StrtF.1 714 DistCl.F 794 Fing2.4 874 Oooo-.2 954 JpStr.1 1034 Late-S.4 1114 P10-1.2
635 StrtF.2 715 Dist2.1 795 Fing2.5 875 Itopia.1 955 JpStr.2 1035 Late-S.5 1115 P10-1.3
636 StrtF.3 716 Dist2.2 796 Fing2.6 876 Itopia.2 956 JpStr.3 1036 Late-S.6 1116 P10-1.4
637 StrtF.4 717 Dist2.3 797 Harmnc.1 877 Itopia.3 957 JpStr.4 1037 Late-S.7 1117 P10-1.5
638 StrtF.5 718 Dist2.4 798 Harmnc.2 878 Itopia.4 958 JpStr.5 1038 Late-S.8 1118 P10-1.6
639 StrtF.6 719 Dist2.5 799 Precsn.1 879 Itopia.5 959 JpStr.6 1039 Late-L.1 1119 P10-1.7
640 StrtF.7 720 Dist2.6 800 Precsn.2 880 Alto.1 960 SyzStr.1 1040 Late-L.2 1120 P10-1.8
28
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
Smpl No.
Smpl Name
1121 P10-2.1 1201 Digi05.3 1281 DgVox3.B 1361 BdHby.1 1441 T8Side.1
1122 P10-2.2 1202 Digi05.4 1282 DgVox4.1 1362 Bd2.1 1442 T8Rmst.1
1123 P10-2.3 1203 Digi05.5 1283 DgVox4.2 1363 BdDeep.1 1443 T8Clap.1
1124 P10-2.4 1204 Digi05.6 1284 DgVox4.3 1364 BdHiJz.1 1444 T8Tom.1
1125 P10-2.5 1205 Digi06.1 1285 DgVox4.4 1365 BdLoJz.1 1445 T8HHCl.1
1126 P10-2.6 1206 Digi06.2 1286 DgVox4.5 1366 SdGM.1 1446 T8HHOp.1
1127 P10-3.1 1207 Digi06.3 1287 DgVox4.6 1367 SdBldS.1 1447 T8Crsh.1
1128 P10-3.2 1208 Digi06.4 1288 DgVox4.7 1368 SdBldM.1 1448 T8CngL.1
1129 P10-3.3 1209 Digi07.1 1289 DgVox5.1 1369 SdBldH.1 1449 T8CngM.1
1130 P10-3.4 1210 Digi07.2 1290 DgVox5.2 1370 SdFsnL.1 1450 T8CngH.1
1131 P10-3.5 1211 Digi07.3 1291 DgVox5.3 1371 SdFsnH.1 1451 T8Cwbl.1
1132 P10-3.6 1212 Digi07.4 1292 DgVox5.4 1372 SdLdwS.1 1452 T8Clve.1
1133 P25-1.1 1213 Digi07.5 1293 DgVox5.5 1373 SdLdwH.1 1453 T8Mrcs.1
1134 P25-1.2 1214 Digi07.6 1294 DgVox5.6 1374 SdSonA.1 1454 T9BD1.1
1135 P25-1.3 1215 Digi07.7 1295 DgVox5.7 1375 SdSonB.1 1455 T9BD2.1
1136 P25-1.4 1216 Digi08.1 1296 DgVox5.8 1376 SdSonC.1 1456 T9BD3.1
1137 P25-1.5 1217 Digi08.2 1297 DgVox5.9 1377 SdSonD.1 1457 T9SD1.1
1138 P25-1.6 1218 Digi08.3 1298 DgVox5.A 1378 SdHvy.1 1458 T9SD2.1
1139 P25-1.7 1219 Digi08.4 1299 VoxG2.1 1379 SdPclS.1 1459 T9SD3.1
1140 P25-1.8 1220 Digi08.5 1300 VoxG2.2 1380 SdPclH.1 1460 T9SD4.1
1141 P25-2.1 1221 Digi08.6 1301 VoxG2.3 1381 SdPcBS.1 1461 T9SD5.1
1142 P25-2.2 1222 Digi08.7 1302 VoxG2.4 1382 SdPcBH.1 1462 T9SD6.1
1143 P25-2.3 1223 Digi09.1 1303 VoxG2.5 1383 SdPrmS.1 1463 T9Clap.1
1144 P25-2.4 1224 Digi09.2 1304 VoxG2.6 1384 SdPrmH.1 1464 T9Rim.1
1145 P25-2.5 1225 Digi09.3 1305 VoxG2.7 1385 SdWdS.1 1465 T9TomL.1
1146 P25-2.6 1226 Digi09.4 1306 VoxE3.1 1386 SdWdH.1 1466 T9TomM.1
1147 P25-2.7 1227 Digi09.5 1307 VoxE3.2 1387 SdBrsS.1 1467 T9TomH.1
1148 P50-1.1 1228 Digi10.1 1308 VoxE3.3 1388 SdBrsH.1 1468 T9HHC1.1
1149 P50-1.2 1229 Digi10.2 1309 VoxE3.4 1389 C.Rim1.1 1469 T9HHC2.1
1150 P50-1.3 1230 Digi10.3 1310 VoxE3.5 1390 C.Rim2.1 1470 T9HHO1.1
1151 P50-1.4 1231 Digi10.4 1311 VoxE3.6 1391 Stick.1 1471 T9HHO2.1
1152 P50-1.5 1232 Digi11.1 1312 VoxE3.7 1392 TomF.1 1472 T9Crsh.1
1153 P50-1.6 1233 Digi11.2 1313 Ep1.1 1393 TomL.1 1473 T9Ride.1
1154 P50-1.7 1234 Digi11.3 1314 Ep1.2 1394 TomM.1 1474 EuroBD.1
1155 P50-1.8 1235 Digi11.4 1315 Ep1.3 1395 TomHL.1 1475 DstKik.1
1156 P50-2.1 1236 Digi11.5 1316 Ep1.4 1396 TomHH.1 1476 AnvlHt.1
1157 P50-2.2 1237 Digi12.1 1317 Ep1.5 1397 TmJzL.1 1477 AnvlPp.1
1158 P50-2.3 1238 Digi12.2 1318 Ep2.1 1398 TmJzM.1 1478 Scrch1.1
1159 P50-2.4 1239 Digi12.3 1319 Ep2.2 1399 TmJzH.1 1479 Scrch2.1
1160 P50-2.5 1240 Digi12.4 1320 Ep2.3 1400 HHCl1.1 1480 VoxDrm.1
1161 P50-2.6 1241 Digi12.5 1321 Ep2.4 1401 HHCL2.1 1481 Ripper.1
1162 P50-2.7 1242 Bel1Wv.1 1322 Ep2.5 1402 HHCl3.1 1482 CONG.1
1163 Tri.1 1243 Bel1Wv.2 1323 Ep3.1 1403 HHPdl.1 1483 StlClp.1
1164 Tri.2 1244 Bel1Wv.3 1324 Ep3.2 1404 HHOpn.1 1484 WdBlk.1
1165 Tri.3 1245 Bel1Wv.4 1325 Ep3.3 1405 Ride.1
1166 Tri.4 1246 Bel1Wv.5 1326 Ep3.4 1406 Cup.1
1167 Tri.5 1247 Bel1Wv.6 1327 Ep3.5 1407 Crash.1
1168 Tri.6 1248 Bel1Wv.7 1328 Ep4.1 1408 China.1
1169 Tri.7 1249 Bel2Wv.1 1329 Ep4.2 1409 BongoL.1
1170 Digi01.1 1250 Bel2Wv.2 1330 Ep4.3 1410 BongoH.1
1171 Digi01.2 1251 Bel2Wv.3 1331 Ep4.4 1411 CongaL.1
1172 Digi01.3 1252 Bel2Wv.4 1332 Ep4.5 1412 CongaH.1
1173 Digi01.4 1253 Bel2Wv.5 1333 Ep5.1 1413 CngSlp.1
1174 Digi01.5 1254 Bel2Wv.6 1334 Ep5.2 1414 Cowbel.1
1175 Digi01.6 1255 Bel2Wv.7 1335 Ep5.3 1415 AgogoL.1
1176 Digi01.7 1256 DgVox1.1 1336 Ep5.4 1416 GuiroL.1
1177 Digi02.1 1257 DgVox1.2 1337 Ep5.5 1417 GiroCl.1
1178 Digi02.2 1258 DgVox1.3 1338 EP6.1 1418 TmblsL.1
1179 Digi02.3 1259 DgVox1.4 1339 EP6.2 1419 TmblsH.1
1180 Digi02.4 1260 DgVox1.5 1340 EP6.3 1420 CuicaL.1
1181 Digi02.5 1261 DgVox1.6 1341 EP6.4 1421 CuicaH.1
1182 Digi02.6 1262 DgVox2.1 1342 EP6.5 1422 Wdblck.1
1183 Digi02.7 1263 DgVox2.2 1343 Org1Wv.1 1423 Cabasa.1
1184 Digi03.1 1264 DgVox2.3 1344 Org1Wv.2 1424 Claves.1
1185 Digi03.2 1265 DgVox2.4 1345 Org1Wv.3 1425 Castnt.1
1186 Digi03.3 1266 DgVox2.5 1346 Org2Wv.1 1426 Maracs.1
1187 Digi03.4 1267 DgVox2.6 1347 Org2Wv.2 1427 Shaker.1
1188 Digi03.5 1268 DgVox2.7 1348 Org3Wv.1 1428 Tmborn.1
1189 Digi03.6 1269 DgVox2.8 1349 Org3Wv.2 1429 TrangL.1
1190 Digi03.7 1270 DgVox2.9 1350 Org3Wv.3 1430 VbSlp.1
1191 Digi03.8 1271 DgVox3.1 1351 Sin.1 1431 Whistl.1
1192 Digi04.1 1272 DgVox3.2 1352 Noise.1 1432 Clap.1
1193 Digi04.2 1273 DgVox3.3 1353 VoxBel.1 1433 JnglBl.1
1194 Digi04.3 1274 DgVox3.4 1354 Melow.1 1434 Bltree.1
1195 Digi04.4 1275 DgVox3.5 1355 WndChm.1 1435 T8BdBm.1
1196 Digi04.5 1276 DgVox3.6 1356 BelAir.1 1436 T8Bd.1
1197 Digi04.6 1277 DgVox3.7 1357 BigSyn.1 1437 T8SD1.1
1198 Digi04.7 1278 DgVox3.8 1358 VxDcnd.1 1438 T8SD2.1
1199 Digi05.1 1279 DgVox3.9 1359 BdStd.1 1439 T8SD3.1
1200 Digi05.2 1280 DgVox3.A 1360 BdPop.1 1440 T8SD4.1
29
■Wave List ■Liste der Wellenformen
■Liste des ondes
Wave No.
Cat. WaveName
Wave No.
Cat. WaveName
Wave No.
Cat. WaveName
Wave No.
Cat. WaveName
Wave No.
Cat. WaveName
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
Pc
BongoH
CongaL
CongaH
CngSlp
Cowbel
AgogoL
GuiroL
GiroCl
TmblsL
TmblsH
CuicaL
CuicaH
Wdblck
Cabasa
Claves
Castnt
Maracs
Shaker
Tmborn
TrangL
VbSlp
Whistl
Clap
JnglBl
Bltree
T8BdBm
T8Bd
T8SD1
T8SD2
T8SD3
T8SD4
T8Side
T8Rmst
T8Clap
T8Tom
T8HHCl
T8HHOp
T8Crsh
T8CngL
T8CngM
T8CngH
T8Cwbl
T8Clve
T8Mrcs
T9BD1
T9BD2
T9BD3
T9SD1
T9SD2
T9SD3
T9SD4
T9SD5
T9SD6
T9Clap
T9Rim
T9TomL
T9TomM
T9TomH
T9HHC1
T9HHC2
T9HHO1
T9HHO2
T9Crsh
T9Ride
EuroBD
DstKik
AnvlHt
AnvlPp
Scrch1
Scrch2
VoxDrm
Ripper
CONG
StlClp
WdBlk
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Pf
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Or
Grnd1
Grnd1+
Grnd1-
Grnd2
Grnd2+
Grnd2-
CP80
CP80+
CP80-
Rho1P
Rho1P+
Rho1P-
Rho1L
Rho1L+
Rho1L-
Rho2S
Rho2S+
Rho2S-
Rho2M
Rho2M+
Rho2M-
Rho2H
Rho2H+
Rho2H-
Rho3
Rho3+
Rho3-
Rho4
Rho4+
Rho4-
Wurli
Wurli+
Wurli-
DX7S
DX7H
Clav1
Clav1+
Clav1-
Clav2
Clav2+
Clav2-
Clav3A
Clav3L
Clv3L+
Clv3L-
JmPrc
JmPrc-
Jazz
Jazz+
Jazz-
Rock
Rock+
Rock-
Swish
Swish-
D16
D5 1/3
D8
D4
D2 2/3
D2
D1 3/5
D1 1/3
D1
Dw1+3
Dw1+3+
Dw1+3-
Dw2+4
Dw2+4+
Dw2+4-
DrwEv
DrwEv+
DrwEv-
DrwOd
DrwOd+
DrwOd-
Perc
Perc+
Perc-
Rotar
Clack
LesWho
LesGrt
SftTmp
Farfis
Farfi-
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
Or
Or
Cp
Cp
Cp
Cp
Cp
Cp
Cp
Cp
Cp
Cp
Cp
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
Br
St
St
St
St
St
St
St
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Gt
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
VoxOrg
VxOrg-
FngCym
Hibasi
StoneH
StoneS
Gamln1
Gamln2
Glock
Marimb
Vibra
Xylo
HndBel
SectnL
SectnR
SectSt
SctnL-
SctnR-
SctSt-
PopBrs
PopBr+
Trmbn
Trmbn-
SftTrb
SftFlg
SftFl-
Hermn
Strgt
TrpMed
TrpSft
Trmpt
Trmpt+
Trmpt-
PiclTp
Combi1
Combi2
Combi3
Combi4
Horn
StrL
StrLA
StrR
StrRA
StrST
EnsMx
EnsMx-
Nylon
NylnHi
Nylhrm
Steel
StelHi
StelLo
StlHrm
Single
SnglHi
JzGtr
Strt
StrtN
StrtF
StrtSl
StrtSp
StrtMt
StrHrm
Telcs
ES335
Front
DistCl
Dist2
DistMt
FeedBk
AcStic
AcStc+
AcStc-
6StrFn
6StrF+
6StrF-
Fing1
Fing1+
Fing1-
Fing2
Fing2+
Harmnc
Precsn
Prcsn+
Pecsn-
PrsRw
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
Ba
En
En
En
En
En
En
En
En
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Pi
Pi
Pi
Pi
Pi
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
PrsRw+
PrsRw-
Pick
Slap
Slap+
Slap-
Slap2
Frtl1
Frtl1+
Frtl1-
Frtl2
Frtl2+
Frtl2-
SynVx1
SyVx1+
SynVx2
VxNoiz
Oooo
Oooo+
Oooo-
Itopia
Alto
Alto+
Alto-
Tenor
Tenor+
Tenor-
Bari
BigSx1
BigSx2
SxBrth
Soprn
Soprn+
Soprn-
Clari
Clari+
Clari-
Oboe
Oboe+
Oboe-
Flute
Flute+
Flute-
PnFlt
PnFlt-
ModSaw
ObStr
JpStr
SyzStr
Padd
ObBrs
SyncLd
CS80Br
3o3Saw
3o3Squ
MogBs1
MogBs2
MogBs3
FMBs1
FMBs2
FMBs3
FMBs4
FMBs5
FMBs6
FMFnk
FMGtr
Late-S
Late-L
P5Saw
Saw2
1o1Saw
1o1Sub
SawSqu
SquSaw
MgRamp
P10-1
P10-2
P10-3
P25-1
P25-2
P50-1
P50-2
Tri
Digi01
Digi02
Digi03
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Wv
Fx
Fx
Fx
Fx
Fx
Fx
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Dr
Pc
Digi04
Digi05
Digi06
Digi07
Digi08
Digi09
Digi10
Digi11
Digi12
Bel1Wv
Bel2Wv
DgVox1
DgVox2
DgVox3
DgVox4
DgVox5
VoxG2
VoxE3
Ep1
Ep2
Ep3
Ep4
Ep5
EP6
Org1Wv
Org2Wv
Org3Wv
Sin
Noise
VoxBel
Melow
WndChm
BelAir
BigSyn
VxDcnd
BdStd
BdPop
BdHby
Bd2
BdDeep
BdHiJz
BdLoJz
SdGM
SdBldS
SdBldM
SdBldH
SdFsnL
SdFsnH
SdLdwS
SdLdwH
SdSonA
SdSonB
SdSonC
SdSonD
SdHvy
SdPclS
SdPclH
SdPcBS
SdPcBH
SdPrmS
SdPrmH
SdWdS
SdWdH
SdBrsS
SdBrsH
C.Rim1
C.Rim2
Stick
TomF
TomL
TomM
TomHL
TomHH
TmJzL
TmJzM
TmJzH
HHCl1
HHCL2
HHCl3
HHPdl
HHOpn
Ride
Cup
Crash
China
BongoL
30
■EX7 Performance List
■Liste der EX7 Performances
■Liste des performances EX7
Sq
Fx
Co
Co
Co
Sq
Fx
Co
Fx
Fx
Co
Se
Fx
Ba
Pd
Fx
Co
Co
Ld
Br
Pd
Co
Gt
Pd
Pd
Sq
Fx
Co
Co
Fx
Sq
Pd
Co
Co
St
Fx
Pf
En
Br
Pd
Se
Se
Pd
Or
Ba
Co
Co
Pd
Co
Fx
St
Sq
Fx
Rd
Fx
Se
Co
Fx
Fx
Sq
Co
St
Pd
Co
Int1-108
Int2-92
Pre1-2
Pre2-97
Int2-23
Int2-127
Pre2-118
Pre1-106
Int2-100
Pre1-61
Int2-1
Int2-78
Pre1-64
Int2-22
Pre2-8
Int1-98
Pre2-27
Pre1-2
Int2-38
Pre1-95
Pre2-4
Pre1-93
Pre2-58
Pre1-117
Pre1-126
Int1-41
Int2-51
Pre2-73
Pre1-1
Int1-71
Int2-18
Int2-55
Pre2-125
Pre1-10
Pre1-102
Pre2-121
Pre1-10
Pre1-122
Pre1-69
Pre2-117
Int1-62
Int2-91
Pre2-3
Pre1-49
Int2-23
Int1-58
Pre1-99
Pre1-122
Int2-98
Pre2-118
Pre1-107
Int2-99
Int2-74
Pre2-97
Int2-65
Int2-90
Pre1-117
Int2-94
Int1-85
Int2-81
Pre1-126
Pre1-99
Int2-67
Int1-53
Soda Straw
Trancer
Stereo Piano
Tennor Sax
Wave Bass
FX Kit
Morphyum
Tremolo
Texture#6 VS
Vibe
Equi 1998
Circular
WoodSequence
Tosser
Futopia
Reso Choir
Combi Comp
Stereo Piano
Mean Lead
Jupiter
Soft Obi
OberBrass
Lead Switch
Dreamsphere
Oberweich
BigArpeggio
Oasis
Fretless 2
Natural Grnd
Harmonics
Lately Bass
Vapor
Rock Kit
Georgia
StereoString
Foam
Georgia
Glass Choir
Pop Brass
Kosmik Fluid
Flivver
BodyElectric
Silverlake
Jazz Perc
Wave Bass
FM Line
EnsembleMix
Glass Choir
Generator
Morphyum
AnaOrch
Natives
Broken Arp
Tennor Sax
RhythmWheels
Radiophonik
Dreamsphere
Eraser
Mars
Down Spiral
Oberweich
EnsembleMix
Quickening
EX god
MSB=63
LSB=64
* The performances numbered 65 through 128 contain the same data as those of the performances numbered 1 through 64.
Part 1 Part 2
No.No. Perf Name Cat. Voice No. VoiceName Voice No. VoiceName
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
Radioactive
Eternal
Dream Grand
Lover's Sax
Analog Bros
FX loop
Lightyears
Epic
DolphinDance
CirqueDeLuna
Sync Chords
Warpout
HotSpring
Darkcore
Wave Pad
Snow Dwarf
80's Seq
Piano String
HeadDriver
Alaskan
BreathyChoir
Obi & Paddy
Two GuitarS
Sunbeam
Relax
FrenchSchool
Celebration
Fretles Pad
Ballad Stack
Saphire
BeatExplorer
Quarks
Drums & Bass
Roads&Brass
WideStrings
FlowerDrops
HybridRoads
WallChoir
Tower Brass
Amethyst
Microbe X
Clockshop
CrystalLake
Jazz Upr&Lwr
Moonbase
Silver Bird
The Dreamer
Stratosphere
Digi Rock
NeoCity
AnalogStrngs
The Journey
S P A W N E
TwinTenor
Emotion
Experiment
Midnite Blue
Nuclear
Mars > Orion
EX-Teknofarm
SteviesSplit
SmoothEnsmbl
Water Dance
Hokkaido
Int2-40
Int1-55
Pre2-2
Pre1-97
Pre1-91
Pre2-2
Pre1-97
Int1-49
Pre2-114
Pre2-4
Int1-113
Int2-81
Pre1-117
Pre2-114
Int1-34
Pre1-102
Int2-39
Pre1-93
Pre2-10
Pre2-2
Pre2-52
Pre1-119
Pre1-116
Int2-52
Pre2-12
Pre1-107
Pre1-10
Int1-71
Int2-127
Int1-64
Pre2-68
Pre1-65
Pre1-107
Int2-67
Pre1-18
Pre1-69
Pre2-121
Int2-75
Int2-74
Pre1-122
Pre1-44
Pre2-66
Pre1-99
Pre2-94
Int1-60
Int2-33
Pre2-115
Pre1-102
Int1-93
Int2-93
Pre2-98
Pre2-12
Int2-75
Pre1-83
Int2-52
Pre1-127
Int2-1
Pre2-85
Pre1-97
Pre2-14
Int1-55
Acid Saw
Witches
Warmer
Swell String
SynthClassic
Warmer
Swell String
Adventure
Fractal
Soft Obi
NewAge
Down Spiral
Dreamsphere
Fractal
4 Osc Sweep
StereoString
Trippy
OberBrass
BreathChoir
Warmer
Edgy Strat
Fifth Rise
Clear Bell
Paris
V-Choir
AnaOrch
Georgia
Harmonics
FX Kit
Flow
Slapit
Sect
AnaOrch
Quickening
Made in USA
Pop Brass
Foam
Geiger Count
Broken Arp
Glass Choir
Jazz Organ
Flatwound
EnsembleMix
Earth Lead
Faraway
Chemistry
Busy Brass
StereoString
Pop
Drumnotized
Tenor Soft
V-Choir
Geiger Count
Mute Trumpet
Paris
Orion
Equi 1998
Pulsaw
Swell String
Nightchoir
Witches
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
31
■Controller List (Dest. Param: Destination Parameters)
■Liste mit Controllern (Dest Param: Zielparameter)
■Liste des contrôleurs (Paramètres de destination)
0 off Assign Off ALL
1 COM Volume Common Volume Voice Common
2 COM Rev Send Reverb Send Level Voice Common
3 COM Cho Send Chorus Send Level Voice Common
4 COM Port SW Portamwnt SW Voice Common
5 EF1 Prm 1 Insertion-S Dist1 Voice Common
6 EF1 Prm 2 Insertion-S Dist2 Voice Common
7 EF1 Prm 3 Insertion-S Dist3 Voice Common
8 EF1 Prm 4 Insertion-S Dist4 Voice Common
9 EF1 Prm 5 Insertion-S Dist5 Voice Common
10 EF1 Prm 6 Insertion-S Dist6 Voice Common
11 EF1 Prm 7 Insertion-S Dist7 Voice Common
12 EF1 Prm 8 Insertion-S Dist8 Voice Common
13 EF1 Prm 9 Insertion-S Dist9 Voice Common
14 EF1 Prm 10 Insertion-S Dist10 Voice Common
15 EF1 Prm 11 Insertion-S Dist11 Voice Common
16 EF1 Prm 12 Insertion-S Dist12 Voice Common
17 EF1 Prm 13 Insertion-S Dist13 Voice Common
18 EF1 Prm 14 Insertion-S Dist14 Voice Common
19 EF1 Prm 15 Insertion-S Dist15 Voice Common
20 EF1 Prm 1 Insertion-L Dist1 Voice Common
21 EF2 Prm 2 Insertion-L Dist2 Voice Common
22 EF2 Prm 3 Insertion-L Dist3 Voice Common
23 EF2 Prm 4 Insertion-L Dist4 Voice Common
24 EF2 Prm 5 Insertion-L Dist5 Voice Common
25 EF2 Prm 6 Insertion-L Dist6 Voice Common
26 EF2 Prm 7 Insertion-L Dist7 Voice Common
27 EF2 Prm 8 Insertion-L Dist8 Voice Common
28 EF2 Prm 9 Insertion-L Dist9 Voice Common
29 EF2 Prm 10 Insertion-L Dist10 Voice Common
30 EF2 Prm 11 Insertion-L Dist11 Voice Common
31 EF2 Prm 12 Insertion-L Dist12 Voice Common
32 EF2 Prm 13 Insertion-L Dist13 Voice Common
33 EF2 Prm 14 Insertion-L Dist14 Voice Common
34 EF2 Prm 15 Insertion-L Dist15 Voice Common
35 EF2 Prm 16 Insertion-L Dist16 Voice Common
36 FDSP ------- FDSP Pan Voice Common
37 FDSP ------- FDSP Dist1 Voice Common
38 FDSP ------- FDSP Dist2 Voice Common
39 FDSP ------- FDSP Dist3 Voice Common
40 FDSP ------- FDSP Dist4 Voice Common
41 FDSP ------- FDSP Dist5 Voice Common
42 FDSP ------- FDSP Dist6 Voice Common
43 FDSP ------- FDSP Dist7 Voice Common
44 FDSP ------- FDSP Dist8 Voice Common
45 AWM Volume Volume AWM Element
46 AWM PAN PAN AWM Element
47 AWM Tune Fine Tune Fine AWM Element
48 AWM Pitch Pitch AWM Element
49 AWM KeyOnDly Key On Delay AWM Element
50 AWM LFO1Speed LFO1 Frequency AWM Element
51 AWM LFO1 PMD LFO1 PMD AWM Element
52 AWM LFO1 AMD LFO1 AMD AWM Element
53 AWM LFO1 FMD LFO1 CMD AWM Element
54 AWM LFO2Speed LFO2 Frequency AWM Element
55 AWM LFO2Phase LFO2 Wave Phase AWM Element
56 AWM LFO2Depth LFO2 Depth AWM Element
57 AWM PEG Depth PEG Depth AWM Element
58 AWM PEG Hold PEG Hold Time AWM Element
59 AWM PEG D1Tim PEG 1st Rate AWM Element
60 AWM PEG D2Tim PEG 2nd Rate AWM Element
61 AWM PEG D3Tim PEG 3rd Rate AWM Element
62 AWM PEG R1Tim PEG Release1 Rate AWM Element
63 AWM PEG R2Tim PEG Release2 Rate AWM Element
64 AWM AEG AtTim AEG AR AWM Element
65 AWM AEG D1Tim AEG D1R AWM Element
66 AWM AEG D2Tim AEG D2R AWM Element
67 AWM AEG D3Tim AEG D3R AWM Element
68 AWM AEG R1Tim AEG RR1 AWM Element
69 AWM AEG R2Tim AEG RR2 AWM Element
70 AWM FEG Hold FEG Initial Hold Rate AWM Element
71 AWM FEG D1Tim FEG 1st Rate AWM Element
72 AWM FEG D2Tim FEG 2nd Rate AWM Element
73 AWM FEG D3Tim FEG 3rd Rate AWM Element
74 AWM FEG R1Tim FEG Release1 Rate AWM Element
75 AWM FEG R2Tim FEG Release2 Rate AWM Element
76 AWM FEG Depth DCF1 FEG Depth AWM Element
77 AWM DCF Reso DCF Q AWM Element
78 AWM DCF Freq DCF1 Fc AWM Element
79 AN Volume Volume AN Element
80 AN PAN PAN AN Element
81 AN Detune Detune AN Element
82 AN Pitch Pitch AN Element
83 AN Pitch Down Pitch AN Element
84 AN PEG DcyTim PEG_DecayRate AN Element
85 AN PEG Depth PEG_Amount AN Element
86 AN Port Time PortamentoTime AN Element
87 AN LFO1 Speed LFO1_Speed AN Element
88 AN LFO1 Delay LFO1_Delay AN Element
89 AN LFO2 Speed LFO2_Speed AN Element
90 AN Sync Pitch VCO_Formant AN Element
91 AN Sync Depth VCO_SyncAmount AN Element
92 AN FM Depth VCO_FM_Amount AN Element
93 AN VCO1 Edge VCO1_Edge AN Element
94 AN VCO1 PW VCO1_PulseWidth AN Element
95 AN VCO1 PWM VCO1_PWM_Depth AN Element
96 AN VCO1 PMD VCO1_VibDepth AN Element
97 AN VCO2 Edge VCO2_Edge AN Element
98 AN VCO2 PW VCO2_PulseWidth AN Element
99 AN VCO2 PWM VCO2_PWM_Depth AN Element
100 AN VCO2 PMD VCO2_VibDepth AN Element
101 AN VCO1 Level MixVCO1Level AN Element
102 AN VCO2 Level MixVCO2Level AN Element
103 AN Ring Mod MixRmLevel AN Element
104 AN NoiseLevel MixNoiseLevel AN Element
105 AN FEG At Tim FEG_AttackRate AN Element
106 AN FEG DcyTim FEG_DecayRate AN Element
107 AN FEG SusLvl FEG_SustainLevel AN Element
108 AN FEG Rl Tim FEG_ReleaseRate AN Element
109 AN VCF HPF VCF_HPf_Cutoff AN Element
110 AN VCF Freq VCF_Cutoff AN Element
111 AN VCF Reso VCF_Emphasis AN Element
112 AN FEG Depth VCF_EnvelopeAmount AN Element
113 AN VCF FMD VCF_ModDepth AN Element
114 AN AEG At Tim AEG_AttackRate AN Element
115 AN AEG DcyTim AEG_DecayRate AN Element
116 AN AEG SusLvl AEG_SustainLevel AN Element
117 AN AEG Rl Tim AEG_ReleaseRate AN Element
118 AN Feedback VCA_FeedbackLevel AN Element
119 AN VCA Volume VCA_Volume AN Element
120 AN VCA AMD VCA_ModDepth AN Element
121 DR PAN PAN DRUM Element
122 DR PEG Depth PEG Depth DRUM Element
123 DR DCF Reso DCF Q DRUM Element
124 DR DCF Freq DCF1 Fc DRUM Element
125 DR FEG Depth DCF1 FEG Depth DRUM Element
126 VL Volume Volume VL Element
127 L PAN PAN VL Element
128 VL Detune Detune VL Element
129 VL Pressure Pressure VL Element
130 VL Embouchure Embouchure VL Element
131 VL Tonguing Tonguing VL Element
132 L Scream Scream VL Element
133 VL Brth Noise Breath Noise VL Element
134 VL Growl Growl VL Element
135 VL Throat Throat Formant VL Element
136 VL Enhancer Harmonic enhancer VL Element
137 VL Damping Damping VL Element
138 VL Absorption Absorption VL Element
139 VL Amplitude Amplitude VL Element
140 VL Flt Freq Filter VL Element
141 VL FMD Fmod VL Element
142 VL PMD Pmod VL Element
143 VL Pitch Pitch VL Element
144 VL Flt Reso Resonance VL Element
145 VL EG At Tim Aeg AR VL Element
146 VL EG Rl Tim Aeg RR VL Element
No. LCD Parameter
Voice/Element Type
No. LCD Parameter
Voice/Element Type
No. LCD Parameter
Voice/Element Type
NOTE: The parameters for EF1, EF2 and FDSP appearing on the screen depend on the currently selected type.
VL and AN parameters will be shown only when one of the VL/AN voices is selected.
32
■FDSP Parameter List ■FDSP Parameter-Liste
■Liste des Paramètres FDSP
1 1 1
2 2 2
3 3 3
4 4 4
5 5 5
6 6 6
7 7 7
8 8 8
99 drive 9
10 10 10
11 11 11
12 12 12
13 13 13
14 14 14
15 15 cutoff 15
16 16 16
17 17
single coil,hum backing
-24~+24
0~127
-64~+63
-32~+32
0~127
-64~+63
-32~+32
-48~+48
0~127
-48~+48
-32~+32
0~127
-32~+64
0~127
0~31
0~127 17
-64~+63
-50~+50
-32~+64
0~127
-15~+15
0~63
0~63
2~200
0~63
0~63
-15~+15
0~15
-15~+15
0~48
0~127
-64~+63
-64~+63
18 18 18
19 19 19
20
normal,integrate-defferentiate,differentiate
-64~+63
-64~+63
-48~+0
0~+48
0~127
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
0~127
-32~+64
0~127
-32~+64
0~31 20 20
1 1 1
2 2 2
3
drive
drive kf
position
output
cutoff
cutoff kf
Type1: EP Pickup
Parameter
pickup type
low break point
high break point
position high kf
position high mid kf
position low mid kf
position low kf
output high kf
output high mid kf
output low mid kf
output low kf
high pass
high pass kf
resonance
Controller
drive control
position control
cutoff control 3 3
Type3: Water
Parameter
pitch coarse
pitch fine
key follow
CutOff Frequency
Fc key follow
Resonance
Freq.Mod.Depth
Mod.Speed
Mod.Smoothness
Feedback level
FB key follow
High dump
High dump key follow
release time
highpass
wet level
dry level
Controller
pitch control
wet control
dry control
4 4
Type2: EG Pickup
Parameter
pickup type
coarse
picking position
picking position kf
picking notch
pickup position
pickup position kf
pickup notch
distance
output
output kf
highpass
highpass kf
resonance
filter bypass
Controller
picking position control
pickup position control
fret position control
cutoff control 4
5 5 5
6 6 6
7 7 7
8 8 8
9 9 9
10 10 10
1 1 1
2 2 pitch fine 2
3 3 key follow 3
4 4 eg depth 4
5 5 5
6 6 6
7 7 7
8 8 8
9 9 9
10 10 10
11 11 11
12 12 12
13 13 13
14 14 14
-64~+63
-32~+64
-64~+63
-64~+63
decay,attack
0~127
-64~+63
0~48
0~127
1~255
-64~+63
-64~+63
-64~+63
-64~+63
15
-64~+63
-32~+64
0~127
-64~+63
-64~+63
common,key on reset,random phase
0~64
1~255
tri,sin
0,90,180,270
decay,attack,fade in
0~64
0~127
-64~+63
-32~+32 15 15
16 16 wet level 16
17 17 dry level
-64~+63
-50~+50
-32~+64
-64~+63
-64~+63
0~127
-64~+63
0~127
-64~+63
0~127
0~48
0~127
1~255
-64~+63
-64~+63
-64~+63
-64~+63 17
18 18 18
19 19 19
20 20 20
Controller
1 1 1
2 2 2
3 3 3
4 4 4
5
Type4: PWM
Parameter
pitch coarse
key follow
pulse width
PWM depth
PWM depth vs
LFO mode
LFO depth
LFO speed
LFO wave
LFO phase
EG mode
EG shape
EG time
EG time kf
balance
Controller
PW control
PWM control
LFO depth control
LFO speed control
balance control 5 5
6 6 6
7 7
Type5: Flange
Parameter
pitch coarse
eg depth vs
attack time
attack time kf
decay time
decay time kf
sustain level
release time
LFO depth
LFO speed
feedback level
feedback level vs
pitch control
eg depth control
LFO depth control
LFO speed control
feedback control
wet control
dry control 7
Type6: Phaser
Parameter
pitch coarse
key follow
eg depth
eg depth vs
EG mode
EG time
EG time kf
release time
LFO depth
LFO speed
feedback level
feedback level vs
wet level
dry level
Controller
pitch control
eg depth control
LFO depth control
LFO speed control
feedback control
wet control
dry control
8 8 8
9 9 9
10 10 10
* Items listed under “Controller” can be selectable as the destination parameters for a Controller Set.
33
Type7: SelfFM Type8: Tornado Type9: RingMod
-64~+63
-32~+64
0~1
0~127
0~127
-64~+63
-64~+63
-64~+63
0~127
-32~+64
decay,attack
0~127
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
0~120
0~127
0~127
-64~+63
-64~+63
-64~+63
0~127
0~48
0~64
0~127
-64~+63
-64~+63
0~127
-32~+64
0~127
-32~+64
0~127
-64~+63
0~127
0~127
-64~+63
-50~+50
0~127
-32~+64
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
0~127
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
-64~+63
Parameter
pitch coarse
key follow
polarity
phase
drive
drive kf
drive eg depth
drive eg depth vs
drive lowpass
drive lowpass kf
EG mode
EG time
EG time kf
wet
wet vs
dry
dry vs
Controller
drive control
eg depth control
phase control
Parameter
pre gain
pre lowpass
drive
drive kf
eg depth
eg depth vs
decay time
release time
overtone
ceiling
edge bias
edge eg depth
highpass
highpass kf
lowpass
lowpass kf
wet gain
wet vs
wet
dry
Controller
drive control
overtone control
ceiling control
egde bias control
wet control
dry control
Parameter
pitch coarse
pitch fine
sub pitch
key follow coarse
key follow fine
pitch eg depth
pitch eg depth vs
main frequency coarse
main frequency fine
sub frequency coarse
sub frequency fine
EG mode
EG time
EG time kf
main modulation depth
main modulation eg depth
main modulation eg depth vs
sub modulation depth
sub modulation eg depth
sub modulation eg depth vs
Controller
pitch control
pitch eg depth control
main frequency control
sub frequency control
main modulation control
sub modulation control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
-64~+16
0~127
-64~+63
-64~+63
-64~+63
-64~+63
0~127
-64~+63
0~127
-64~+63
0~127
0~127
0~127
-32~64
-60~+60
Parameter
input
drive
drive vs
drive kf
drive eg depth
drive eg depth vs
attack time
attack time kf
decay time
decay time kf
sustain level
over drive
highpass
highpass kf
output
Controller
drive control
eg depth control
over drive control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
Type10: Seismic
34
■Effect Type List ■Liste mit Effekt-Typen
■Liste des type d’effets
No.
0
1
2
3
4
5
6
7
8
9
10
11
12
Effect Type
off
Rev Hall 1
Rev Hall 2
Rev Room 1
Rev Room 2
Rev Room 3
Rev Stage 1
Rev Stage 2
Rev Plate
RevWhiteRoom
Rev Tunnel
Rev Basement
Rev Canyon
Remarks
Turn off the effect.
Reverb simulating the acoustics of a hall.
Reverb simulating the acoustics of a room.
Reverb appropriate for a solo instrument.
Reverb simulating a metal plate reverb device.
Unique short reverb with a slight initial delay.
Simulation of a cylindrical space extending to left and right.
Reverb with distinctive resonance following a slight initial delay.
A hypothetical acoustic space which extends without limit.
No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Effect Type
off
Chorus 1
Chorus 2
Chorus 3
Chorus 4
Chorus 5
Celeste 1
Celeste 2
Celeste 3
Celeste 4
Flanger 1
Flanger 2
Flanger 3
Symphonic
Phaser
Ensemble
Delay L,R
ControlDelay
Remarks
Turn off the effect.
A standard chorus effect, adding natural spaciousness to the sound.
An effect which uses a 3-phase LFO to add modulation and spaciousness to the sound.
An effect reminiscent of a jet airplane taking off and landing.
A multi-stage version of CELESTE modulation.
Cyclically changes the phase to modulate the sound.
Chorus effect without modulation, created by adding a slightly pitch-shifted sound.
Two delay sounds L and R, with two feedback delays.
A delay with controllable delay time.
No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Effect Type
thru
Chorus 1
Chorus 2
Chorus 3
Chorus 4
Celeste 1
Celeste 2
Celeste 3
Celeste 4
Flanger 1
Flanger 2
Flanger 3
Tremolo
Auto Pan
Distortion
Overdrive
AmpSimulator
Exciter
Compressor
Noise Gate
Auto Wah
Touch Wah
Phaser
Equalizer
3 Band EQ
Remarks
Turn off the effect.
Conventional chorus effect which gives natural spaciousness to the sound.
A three-phase LFO is used to give modulation and spaciousness to the sound.
An effect reminiscent of a jet airplane taking off and landing.
An effect which cyclically modulates the volume.
An effect which cyclically moves the sound between left/right and front/back.
Adds distortion with an edge to the sound.
Adds mild distortion to the sound.
Simulation of a guitar amp.
This effect adds new overtones to the input signal to make the sound stand out.
Holds down the output when the input exceeds a specified level. Can be used to add a sense of attack to the sound.
Gates the input when the input signal falls below a specified level. Useful for cutting noise from the A/D input, etc.
Cyclically changes the center frequency of a wah filter. Can be used as a pedal wah by assigning it to a controller.
Changes the center frequency of a wah filter according to the input level. Can be used as a pedal wah by assigning it to a controller.
Cyclically changes the phase to modulate the sound.
Stereo EQ with equalization of LOW and HIGH. Ideal for Drum Parts.
Stereo EQ with equalization of LOW, MID and HIGH.
Reverb
Chorus
Insertion Effect 1
35
Insertion Effect 2
No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
Effect Type
thru
Chorus 1
Chorus 2
Chorus 3
Chorus 4
Chorus 5
Celeste 1
Celeste 2
Celeste 3
Celeste 4
Flanger 1
Flanger 2
Flanger 3
Symphonic
Delay L,C,R
Delay L,R
Echo
Cross Delay
Rotary Sp 1
Rotary Sp 2
Tremolo
Auto Pan
Ambience
Phaser 1
Phaser 2
Early Ref 1
Early Ref 2
Gate Reverb
Reverse Gate
Karaoke 1
Karaoke 2
Karaoke 3
Auto Wah
Touch Wah
A.Wah+Dist
A.Wah+Overdr
T.Wah+Dist
T.Wah+Overdr
Distortion
Overdrive
AmpSimulator
Compressor
Comp Dist
Exciter
Noise Gate
Rev Hall 1
Rev Hall 2
Rev Room 1
Rev Room 2
Rev Room 3
Rev Stage 1
Rev Stage 2
Rev Plate
PitchChange1
PitchChange2
Ensemble
Voice Cancel
2 Band EQ
3 Band EQ
Ctrl Delay 1
Ctrl Delay 2
DPCM
V-Distortion
V-Flanger
Talking Mod
Beat Change
D.Scratch
Auto Synth
Tech Mod
LoResolution
Noisy
Attack LoFi
D.Turntable
Jump
Wah+Dist+Dly
Wah+Odrv+Dly
Cmp+Dist+Dly
Cmp+Odrv+Dly
Dist + Delay
Odrv + Delay
Remarks
Turns off the effect.
Conventional chorus effect which gives natural spaciousness to the sound.
A three-phase LFO is used to give modulation and spaciousness to the sound.
An effect reminiscent of a jet airplane taking off and landing.
A multi-stage version of CELESTE modulation.
Three delay sounds L, R and C (center).
Two delay sounds L and R, with two feedback delays.
Two delays L and R, with independent feedback delay for L and R.
This effect crosses the feedback of two delays.
Simulation of a rotary speaker. Can be used to control the rotation speed by assigning it to a controller.
An effect which cyclically modulates the volume.
An effect which cyclically moves the sound between left/right and front/back.
An effect which adds spatial breadth by blurring the location of the sound.
Cyclically changes the phase to modulate the sound.
This effect isolates only the early reflection components of the reverb.
Simulation of gated reverb.
Simulation of gated reverb played back in reverse.
Echo for karaoke.
Cyclically changes the center frequency of a wah filter. Can be used as a pedal wah by assigning it to a controller.
Changes the center frequency of a wah filter according to the input level. Can be used as a pedal wah by assigning it to a controller.
Applies DISTORTION to the output of AUTO WAH to distort the sound. Can be used
as a pedal wah by assigning it to a controller.
Applies OVERDRIVE to the output of AUTO WAH to distort the sound. Can be used
as a pedal wah by assigning it to a controller.
Applies OVERDRIVE to the output of TOUCH WAH to distort the sound. Can be used as a pedal wah by assigning it to a controller.
Changes the center frequency of a wah filter according to the input level. Can be used as a pedal wah by assigning it to a controller.
Adds distortion with an edge to the sound.
Adds mild distortion to the sound.
Simulation of a guitar amp.
Holds down the output when the input exceeds a specified level. Can also be used to add a sense of attack to the sound.
Since a compressor is included in the first stage, distortion can be applied evenly, regardless of the input level.
This effect adds new overtones to the input signal to make the sound stand out.
Gates the input when the input signal falls below a specified level. Useful for cutting noise from the A/D input, etc.
Reverb simulating the acoustics of a hall.
Reverb simulating the acoustics of a room.
Reverb appropriate for a solo instrument.
Reverb simulating a metal plate reverb device.
This effect changes the pitch of the input signal.
Chorus effect without modulation, created by adding a slightly pitch-shifted sound.
Attenuates the vocal part from sources such as CDs.
Stereo EQ with equalization of LOW and HIGH. Ideal for Drum Parts.
Stereo EQ with equalization of LOW, MID and HIGH.
A delay with controllable delay time.
Distortion simulated the vintage tube and fuzz.
Degrades the audio quality of the input signal.
Simulated analog flanger. Random can be selected for the LFO wave.
Adds a vowel sound to the input signal.
Modifies the waveform length of the sound in realtime. Use in conjunction with a controller.
Adds a scratch sound to the input signal.
Processes the input signal into a synthesizer-type sound.
Adds a unique feeling of modulation similar to ring modulation.
Simulates a lowered resolution for the input signal. The phase of the Rch can be inverted.
Adds a feeling of noise to the input signal.
Creates a somewhat LoFi feeling, and emphasizes the attack of the sound. Also has the feel of a flanger.
Simulates the noise of an analog record.
Cuts apart the input signal and applies extreme modulation to the playback order or speed.
TOUCH WAH, DISTORTION and DELAY are connected in series.
TOUCH WAH, OVERDRIVE and DELAY are connected in series.
COMPRESSOR, DISTORTION and DELAY are connected in series.
COMPRESSOR, OVERDRIVE and DELAY are connected in series.
DISTORTION and DELAY are connected in series.
OVERDRIVE and DELAY are connected in series.
36
■Effect Parameter List ■Liste mit Effekt-Parametern
■Liste des Paramétres d’effets
✽
1. Reverb Block
[0] off
[1] HALL1 ~ [8] PLATE Controller
01. reverb time 0.3s~30.0sec
02. diffusion 0~10
03. initial delay 0.1ms~200.0ms
04. HPF cutoff frequency 20Hz~8.0kHz
❍
05. LPF cutoff frequency 1.0kHz~20.0kHz
❍
06. reverb delay 0.1ms~200.0ms
07. density 0~4
08. ER / rev balance E63>R ~ E=R ~ E<R63
❍
09. feedback high damp 0.1~1.0
10. feedback gain –63~+63
❍
[9] WHITE ROOM ~ [12] CANYON Controller
01. reverb time 0.3s~30.0sec
02. diffusion 0~10
03. initial delay 0.1ms~200.0ms
04. HPF cutoff frequency 20Hz~8.0kHz
❍
05. LPF cutoff frequency 1.0kHz~20.0kHz
❍
06. width 0.5m~30.2m
07. height 0.5m~30.2m
08. depth 0.5m~30.2m
09. wall vary 0~30
10. reverb delay 0.1ms~200.0ms
11. density 0~4
12. ER / rev balance E63>R ~ E=R ~ E<R63
❍
13. feedback high damp 0.1~1.0
14. feedback gain –63~+63
❍
2. Chorus Block
[0] off
[1] CHORUS1 ~ [5] CHORUS5
[6] CELESTE1 ~ [9] CELESTE4 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05. EQ low frequency 32Hz~2.0kHz
❍
06. EQ low gain –12dB~+12dB
❍
07. EQ high frequency 500Hz~16.0kHz
❍
08. EQ high gain –12dB~+12dB
❍
[10] FLANGER1 ~ [12] FLANGER3 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05. LFO phase difference –180deg~+180deg
06 ~ 09. are the same as parameter
✽
.
❍
[13] SYMPHONIC Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. delay offset 0.0ms~50.0ms
04 ~ 07. are the same as parameter
✽
.
❍
[14] PHASER Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. phase shift offset 0~127
04. feedback gain –63~+63
❍
05. stage 4, 5, 6
❍
06. diffusion mono/stereo
❍
07 ~ 10. are the same as parameter
✽
.
❍
[15] ENSEMBLE DETUNE Controller
01. detune –50cent~+50cent
02. initial delay Lch 0.0ms~50.0ms
03. initial delay Rch 0.0ms~50.0ms
[16] DELAY L,R(stereo) Controller
01. delay time L 0.1ms~743.0ms
02. delay time R 0.1ms~743.0ms
03. feedback time L 0.1ms~743.0ms
04. feedback time R 0.1ms~743.0ms
05. feedback gain –63~+63
❍
06. feedback high damp 0.1~1.0
❍
07 ~ 10. are the same as parameter
✽
.
❍
[17] Control Delay(mono) Controller
01. delay time 0.1ms~1486.0ms
❍
02. delay transition rate 1~48
❍
03. feedback gain –63~+63
❍
04. feedback high damp 0.1~1.0
❍
05 ~ 08. are the same as parameter
✽
.
❍
3. Insertion Effect 1
[0] thru
[1]~[4]CHORUS1~4
[5]~[8]CELESTE1~ 4 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05 ~ 08. are the same as parameter
✽
.
❍
09. input mode mono/stereo
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[9]~[11] FLANGER1~3 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05 ~ 08. are the same as parameter
✽
.
❍
09. LFO phase difference –180deg~+180deg
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[12]TREMOLO Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. AM depth 0~127
❍
03. PM depth 0~127
❍
04. LFO phase difference –180deg~+180deg
05 ~ 08. are the same as parameter
✽
.
❍
09. input mode mono/stereo
[13]AUTO PAN Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. L/R depth 0~127
❍
03. F/R depth 0~127
❍
04. PAN direction L<>R, L>>R, L<<R, Lturn, Rturn, L/R
05 ~ 08. are the same as parameter
✽
.
❍
[14] DISTORTION
[15] OVERDRIVE Controller
01. drive 0~127
❍
02. EQ low frequency 32Hz~2.0kHz
❍
03. EQ low gain –12dB~+12dB
❍
04. EQ mid frequency 100Hz~10.0kHz
❍
05. EQ mid gain –12dB~+12dB
❍
06. EQ mid width 1~12.0
❍
07. LPF cutoff frequency 1.0kHz~20.0kHz
❍
08. edge 0~127
❍
09. output level 0~127
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[16] AMP SIMULATOR Controller
01. drive 0~127
❍
02. AMP type Off,Stack,Combo,Tube
03. LPF cutoff frequency 1.0kHz~20.0kHz
❍
04. edge 0~127
❍
05. output level 0~127
❍
06. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[17] EXCITER Controller
01. HPF cutoff frequency 500Hz ~ 16.0kHz
❍
02. drive 0~127
❍
03. mix level 0~127
❍
[18] COMPRESSOR Controller
01. attack 1ms~40ms
❍
02. release 10ms~680ms
❍
03. threshold –48dB~+6dB
❍
04. ratio 1~20.0
❍
05. output level 0~127
❍
[19] NOISE GATE Controller
01. attack 1ms~40ms
❍
02. release 10ms~680ms
❍
03. threshold –72dB~+30dB
❍
04. output level 0~127
❍
37
[20] AUTO WAH Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. cutoff frequency offset 0~127
❍
04. resonanse 1~12.0
❍
05 ~ 08. are the same as parameter
✽
.
❍
09. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[21] TOUCH WAH Controller
01. sensitive 0~127
❍
02. cutoff frequency offset 0~127
❍
03. resonanse 1~12.0
❍
04 ~ 07.are the same as parameter
✽
.
❍
08. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[22] PHASER Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. phase shift offset 0~127
04. feedback gain –63~+63
❍
05. stage 4,5,6
❍
06. diffusion mono/stereo
07 ~ 10. are the same as parameter
✽
.
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[23] EQ Controller
01 ~ 04. are the same as parameter
✽
.
❍
[24] 3BAND EQ Controller
01. EQ low frequency 50Hz~2.0kHz
❍
02. EQ low gain –12dB~+12dB
❍
03. EQ mid frequency 100Hz~10.0kHz
❍
04. EQ mid gain –12dB~+12dB
❍
05. EQ mid Q 1~12.0
❍
06. EQ high frequency 500Hz~16.0kHz
❍
07. EQ high gain –12dB~+12dB
❍
08. input mode mono/stereo
4. Insertion Effect 2
[0] thru
[1]~[5]CHORUS1~5
[6]~[9] CELESTE1~4 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05 ~ 08. are the same as parameter
✽
.
❍
09. EQ mid frequency 100Hz~10.0kHz
❍
10. EQ mid gain –12dB~+12dB
❍
11. EQ mid Q 1~12.0
❍
12. input mode mono/stereo
13. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[10]~[12] FLANGER1~3 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. feedback gain –63~+63
❍
04. delay offset 0.0ms~50.0ms
05 ~ 08. are the same as parameter
✽
.
❍
09. EQ mid frequency 100Hz~10.0kHz
❍
10. EQ mid gain –12dB~+12dB
❍
11. EQ mid Q 1~12.0
❍
12. LFO phase difference –180deg~+180deg
13. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[13] SYMPHONIC Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. delay offset 0.0ms~50.0ms
04 ~ 07. are the same as parameter
✽
.
❍
08. EQ mid frequency 100Hz~10.0kHz
❍
09. EQ mid gain –12dB~+12dB
❍
10. EQ mid Q 1~12.0
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[14] DELAY L,C,R Controller
01. delay time L 0.1ms~1486.0ms
02. delay time R 0.1ms~1486.0ms
03. delay time C 0.1ms~1486.0ms
04. feedback time 0.1ms~1486.0ms
05. feedback gain –63~+63
❍
06. delay level C 0~127
❍
07. feedback high damp 0.1~1.0
08 ~ 11. are the same as parameter
✽
.
❍
12. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[15] DELAY L,R Controller
01. delay time L 0.1ms~1486.0ms
02. delay time R 0.1ms~1486.0ms
03. feedback time 1 0.1ms~1486.0ms
04. feedback time 2 0.1ms~1486.0ms
05. feedback gain –63~+63
❍
06. feedback high damp 0.1~1.0
07 ~ 10. are the same as parameter
✽
.
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[16] ECHO Controller
01. delay time L1 0.1ms~743.0ms
02. feedback gain L –63~+63
❍
03. delay time R1 0.1ms~743.0ms
04. feedback gain R –63~+63
❍
05. feedback high damp 0.1~1.0
06. delay time L2 0.1ms~743.0ms
07. delay time R2 0.1ms~743.0ms
08. delay level 2 0~127
❍
09 ~ 12. are the same as parameter
✽
.
❍
13. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[17] CROSS DELAY Controller
01. delay time L>R 0.1ms~743.0ms
02. delay time R>L 0.1ms~743.0ms
03. feedback gain –63~+63
❍
04. input select ( type ) L, R, L&R
05. feedback high damp 0.1~1.0
06 ~ 09. are the same as parameter
✽
.
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[18] ROTARY SPEAKER1 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03 ~ 06. are the same as parameter
✽
.
❍
07. EQ mid frequency 100Hz~10.0kHz
❍
08. EQ mid gain –12dB~+12dB
❍
09. EQ mid Q 1~12.0
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[19] ROTARY SPEAKER2 Controller
01. rotor speed 0.0Hz~39.70Hz
❍
02. drive low 0~127
❍
03. drive high 0~127
❍
04. low / high balance L63>H ~ L=H ~ L<H63
❍
05. mic L-R angle 0deg~180deg
06. divide frequency 100Hz~10.0kHz
07 ~ 10. are the same as parameter
✽
.
❍
[20]TREMOLO Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. AM depth 0~127
❍
03. PM depth 0~127
❍
04. LFO phase difference –180deg~+180deg
05 ~ 08. are the same as parameter
✽
.
❍
09. EQ mid frequency 100Hz~10.0kHz
❍
10. EQ mid gain –12dB~+12dB
❍
11. EQ mid Q 1~12.0
❍
12. input mode mono/stereo
[21]AUTO PAN Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. L/R depth 0~127
❍
03. F/R depth 0~127
❍
04. PAN direction L<>R, L>>R, L<<R, Lturn, Rturn, L/R
05 ~ 08. are the same as parameter
✽
.
❍
09. EQ mid frequency 100Hz~10.0kHz
❍
10. EQ mid gain –12dB~+12dB
❍
11. EQ mid Q 1~12.0
❍
[22] Ambience Controller
01. delay time 0.0ms~50.0ms
02. wet output phase normal/inverse
❍
03 ~ 06. are the same as parameter
✽
.
❍
07. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[23] PHASER1 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. phase shift offset 0~127
04. feedback gain –63~+63
❍
05. stage 4, 5, 6, 7, 8, 9, 10, 11, 12
❍
06. diffusion mono/stereo
07 ~ 10. are the same as parameter
✽
.
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
38
[24] PHASER2 Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. phase shift offset 0~127
04. feedback gain –63~+63
❍
05. stage 3, 4, 5, 6
❍
06. LFO phase difference –180deg~+180deg
07 ~ 10. are the same as parameter
✽
.
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[25]~[26]EARLY REF1~2 Controller
01. type S-hall, L-hall, random, reverse, plate, spring
02. room size 0.1~20.0
03. diffusion 0 ~ 10
04. initial delay 0.1ms~200.0ms
05. feedback gain –63~+63
❍
06. HPF cutoff frequency 20Hz ~ 8.0kHz
❍
07. LPF cutoff frequency 1.0kHz~20.0kHz
❍
08. liveness 0 ~ 10
09. density 0 ~ 3
10. feedback high damp 0.1~1.0
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[27] GATE REVERB
[28] REVERSE GATE Controller
01. type type-A, type-B
02 ~ 11. are the same as parameter EARLY REF1
[29]~[31]KARAOKE1~3 Controller
01. delay time 0.1ms~ 400.0ms
02. feedback gain –63~+63
❍
03. HPF cutoff frequency 20Hz ~ 8.0kHz
❍
04. LPF cutoff frequency 1.0kHz~20.0kHz
❍
05. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[32] AUTO WAH Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. cutoff frequency offset 0~127
❍
04. resonanse 1~12.0
❍
05 ~ 08. are the same as parameter
✽
.
❍
09. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[33] TOUCH WAH Controller
01. sensitive 0~127
❍
02. cutoff frequency offset 0~127
❍
03. resonanse 1~12.0
❍
04 ~ 07. are the same as parameter
✽
.
❍
08. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[34] AUTO WAH DISTORTION
[35] AUTO WAH OVERDRIVE Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. cutoff frequency offset 0~127
❍
04. resonanse 1~12.0
❍
05 ~ 08. are the same as parameter
✽
.
❍
09. drive 0~127
❍
10. Dist low gain –12dB~+12dB
❍
11. Dist mid gain –12dB~+12dB
❍
12. LPF cutoff frequency 1.0kHz~20.0kHz
❍
13. output level 0~127
❍
14. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[36] TOUCH WAH DISTORTION
[37] TOUCH WAH OVERDRIVE Controller
01. sensitive 0~127
❍
02. cutoff frequency offset 0~127
❍
03. resonanse 1~12.0
❍
04 ~ 07. are the same as parameter
✽
.
❍
08. drive 0~127
❍
09. Dist low gain –12dB~+12dB
❍
10. Dist mid gain –12dB~+12dB
❍
11. LPF cutoff frequency 1.0kHz~20.0kHz
❍
12. output level 0~127
❍
13. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[38] DISTORTION
[39] OVERDRIVE Controller
01. drive 0~127
❍
02. EQ low frequency 32Hz~2.0kHz
❍
03. EQ low gain –12dB~+12dB
❍
04. EQ mid frequency 100Hz~10.0kHz
❍
05. EQ mid gain –12dB~+12dB
❍
06. EQ mid Q 1~12.0
❍
07. LPF cutoff frequency 1.0kHz~20.0kHz
❍
08. edge 0~127
❍
09. output level 0~127
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[40] AMP SIMULATOR Controller
01. drive 0~127
❍
02. Amp type Off, Stack, Combo,Tube
03. LPF cutoff frequency 1.0kHz~20.0kHz
❍
04. edge 0~127
❍
05. output level 0~127
❍
06. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[41] COMPRESSOR Controller
01. attack 1ms~40ms
❍
02. release 10ms~680ms
❍
03. threshold –48dB~–6dB
❍
04. ratio 1~20.0
❍
05. output level 0~127
❍
[42] COMP DISTORTION Controller
01. attack 1ms~40ms
❍
02. release 10ms~680ms
❍
03. threshold –48dB~–6dB
❍
04. ratio 1~20.0
❍
05. drive 0~127
❍
06. EQ low frequency 32Hz~2.0kHz
❍
07. EQ low gain –12dB~+12dB
❍
08. EQ mid frequency 100Hz~10.0kHz
❍
09. EQ mid gain –12dB~+12dB
❍
10. EQ mid Q 1~12.0
❍
11. LPF cutoff frequency 1.0kHz~20.0kHz
❍
12. edge 0~127
❍
13. output level 0~127
❍
14. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[43] EXCITER Controller
01. HPF cutoff frequency 500Hz ~ 16.0kHz
❍
02. drive 0~127
❍
03. mix level 0~127
❍
[44] NOISE GATE Controller
01. attack 1ms~40ms
❍
02. release 10ms~680ms
❍
03. threshold –72dB~–30dB
❍
04. output level 0~127
❍
[45] HALL1 ~ [52] PLATE Controller
01. reverb time 0.3s~30.0s
02. diffusion 0~10
03. initial delay 0.1ms~99.3ms
04. HPF cutoff frequency 20Hz~8.0kHz
❍
05. LPF cutoff frequency 1.0kHz~20.0kHz
❍
06. reverb delay 0.1ms~99.3ms
07. density 0~4
08. ER / rev balance E63>R ~ E=R ~ E<R63
❍
09. feedback high damp 0.1~1.0
10. feedback gain –63~+63
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[53] PITCH CHANGE1
[54] PITCH CHANGE2 Controller
01. pitch –24~+24
02. initial delay 0.1ms~248.9ms
03. fine1 –50~+50
04. fine2 –50~+50
05. feedback gain –63~+63
❍
06. Pan1 L63~C~R63
❍
07. output level1 0~127
❍
08. Pan2 L63~C~R63
❍
09. output level2 0~127
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[55] ENSEMBLE DETUNE Controller
01. detune –50cent~+50cent
02. initial delay Lch 0.0ms~50.0ms
03. initial delay Rch 0.0ms~50.0ms
04 ~ 07. are the same as parameter
✽
.
❍
08. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[56] VOICE CANCELAR Controller
01. low adjust 0~26
02. high adjust 0~26
[57] 2BAND EQ Controller
01 ~ 04. are the same as parameter
✽
.
❍
[58] 3BAND EQ Controller
01. EQ low frequency 50Hz~2.0kHz
❍
02. EQ low gain –12dB~+12dB
❍
03. EQ mid frequency 100Hz~10.0kHz
❍
04. EQ mid gain –12dB~+12dB
❍
05. EQ mid Q 1~12.0
❍
06. EQ high frequency 500Hz~16.0kHz
❍
07. EQ high gain –12dB~+12dB
❍
08. input mode mono/stereo
39
[59] Control Delay(mono)
01. delay time 0.1ms~1486.0ms
❍
02. delay transition rate 1~48
❍
03. feedback level –63~+63
❍
04. feedback high damp 0.1~1.0
❍
06~ 09. are the same as parameter
✽
.
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[60] Control Delay(stereo) Controller
01. delay time 0.1ms~743.0ms
❍
02. delay transition rate 1~48
❍
03. feedback level –63~+63
❍
04. feedback high damp 0.1~1.0
❍
06~ 09. are the same as parameter
✽
.
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[61] DPCM Controller
01. sampling freq. control 44.1KHz~344Hz
❍
02. word length 1~127
❍
03. output gain –6dB~+36dB
❍
04. Pre-LPF cutoff frequency 63Hz~20.0kHz
❍
05. Pre-LPF resonance 1~12.0
❍
06. filter type thru, PowerBass, Radio, Telephone, Clean, Low
07. bit assign 0~6
08. emphasis off/on
09. input mode mono/stereo
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[62] V-Distortion Controller
01. Over Drive 0~100%
❍
02. Device Transister,Vintage Tube,Dsitortion1,2, Fuzz
❍
03. Speaker Type Flat, Stack, Combo,Twin,Radio,Megaphone
❍
04. Presence –10~10
❍
05. output level 0~100%
❍
06. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[63] V-Flanger Controller
01. LFO frequency 0.0Hz~39.70Hz
❍
02. LFO depth 0~127
❍
03. LFO Wave Triangle,Sine,Random
❍
04. delay offset 0.09~36.21ms
❍
05. Modulation Phase –180~+180
❍
06 ~ 09. are the same as parameter
✽
.
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
11. EQ mid frequency 100Hz~10.0kHz
❍
12. EQ mid gain –12dB~+12dB
❍
13. EQ mid width 1~12.0
❍
14. Feedback Gain –100~+100%
❍
15. feedback high damp 0.1~1.0
❍
16. Analog Feel 0~10
❍
[64] Talking Modulator Controller
01. vowel a/i/u/e/o
❍
02. move speed 1~62
❍
03. drive 0~127
❍
04. output Level 0~127
❍
[65] Beat Change Controller
01. beat change –63~+63
❍
02. beat range 0~12
❍
03. pitch change –63~+63
❍
04. pitch range 0~12
❍
05. accuracy type sound4~normal~rythm4
06. EQ frequency 32Hz~2.0kHz
❍
07. EQ gain –12dB~+12dB
❍
08. EQ Q 1.0~12.0
❍
09. dry / wet balance D63>W~D=W~D<W63
❍
[66]DIGITAL SCRATCH Controller
01. input level 0~127
❍
02. initial delay 0.1~460.0ms
03. scratch speed 1~127
❍
04. scratch depth 0~127
❍
05. auto pan speed 0.00Hz~39.7Hz
❍
06. auto pan depth 0~127
❍
07. EQ frequency 100Hz~10.0kHz
❍
08. EQ gain –12~+12dB
❍
09. EQ Q 1.0~12.0
❍
10. HPF frequency 20Hz~8.0kHz
❍
11. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[67]AUTO SYNTH Controller
01. Mod speed 0~127
❍
02. Mod wave type typeA, typeB, typeC, typeD
03. Mod depth 0~127
❍
04. Mod depth ofst R –63~+63
❍
05. LPF frequency 1.0kHz~20.0kHz
❍
06. HPF frequency 20Hz~8.0kHz
❍
07. dry mix level 0~127
❍
08. delay time 0.1~370.0ms
09. delay time ofst R 0~884
10. feedback gain –63~+63
❍
11. feedback gain ofst R –63~+63
❍
12. delay level 0~127
❍
13. AM speed 0.00Hz~39.7Hz
❍
14. AM wave tri,sine,saw up,saw down
15. AM depth 0~127
❍
16. AM inverse R normal, inverse
[68]TECH MODULATION Controller
01. Mod speed 0~127
❍
02. Mod depth 0~127
❍
03. Pre Mod HPF Freq 20Hz~8.0kHz
❍
04. Mod gain –12~+12dB
❍
05. Mod LPF frequency 1.0kHz~20.0kHz
❍
06. Mod LPF resonance 1.0~12.0
❍
07. Mod mix balance D63>W ~ D=W ~ D<W63
❍
08. delay time 0.1~740.0ms
09. delay time ofst R 0~884
10. feedback gain –63~+63
❍
11. feedback gain ofst R –63~+63
❍
12. feedback high damp 0.1~1.0
❍
13. feedback high damp ofst R –0.9~+0.9
❍
14. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[69]LOW RESOLUTION Controller
01. Mod depth 0~127
❍
02. Mod delay ofst 1~127
03. Mod feedback –63~+63
❍
04. resolution 1,1/2~1/128
05. Mod mix balance 0~127
❍
06. phase inverse R off,wet,wet+dry
07. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[70]NOISY Controller
01. drive 0~127
❍
02. Mod depth 0~10
❍
03. Mod speed 0~127
❍
04. Mod feedback –63~+63
❍
05. AM speed 0.00Hz~39.7Hz
❍
06. AM depth 0~127
❍
07. Mod mix balance 1~127
❍
08. LPF frequency 1.0kHz~20.0kHz
❍
09. LPF resonance 1.0~12.0
❍
10. EQ frequency 100Hz~10.0kHz
❍
11. EQ gain –12~+12dB
❍
12. EQ Q 1.0~12.0
❍
13. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[71]ATTACK LOFI Controller
01. sensitive 0~127
❍
02. resolution 1,1/2~1/32
03. peak frequency 100Hz~10.0kHz
❍
04. LPF frequency 1.0kHz~20.0kHz
❍
05. flanger speed 0.00Hz~39.7Hz
❍
06. flanger LFO wave tri,sine,saw up,saw down
07. flanger depth 0~127
❍
08. flanger depth ofst R –63~+63
❍
09. flanger delay 0.1~650.0ms
10. flanger delay ofst R 0~884
11. flanger feedback gain –63~+63
❍
12. flanger feedback gain ofst R –63~+63
❍
13. flanger feedback high damp 0.1~1.0
❍
14. flanger FB high damp ofst R –0.9~+0.9
❍
15. flanger mix balance 1~127
❍
16. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[72]DIGITAL TURNTABLE Controller
01. click density 0~5
02. click level 0~127
❍
03. noise tone 0~6
04. noise Mod speed 0.00Hz~39.7Hz
❍
05. noise Mod depth 0~127
❍
06. dry send to noise 0~127
❍
07. noise LPF frequency 1.0kHz~20.0kHz
❍
08. noise LPF resonace 1.0~12.0
❍
09. noise level 0~127
❍
10. dry LPF frequency 1.0kHz~20.0kHz
❍
11. dry level 0~127
❍
40
[73]JUMP Controller
01. depth 0~127
❍
02. speed 0~127
❍
03. direction L<>R,L>>R
04. type typeA,typeB,typeC
05. jump wave type typeA,typeB,typeC,typeD
06. resolution 1,1/2~1/256
07. LPF frequency 1.0kHz~20.0kHz
❍
08. HPF frequency 20Hz~8.0kHz
❍
09. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[74] WAH+DIST+DELAY
[75] WAH+ODRV+DELAY Controller
01. wah sensitive 0 ~ 127
❍
02. wah cutoff frequency 0 ~ 127
❍
03. wah resonance 1~12.0
❍
04. wah release 10ms~680ms
❍
05. dist. drive 0 ~ 127
❍
06. dist output level 0 ~ 127
❍
07. dist. EQ low gain –12dB~+12dB
❍
08. dist. EQ mid gain –12dB~+12dB
❍
09. delay time 0.1ms~1486.0ms
10. delay feedback gain –63~+63
❍
11. delay mix 0 ~ 127
❍
12. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[76] COMP+DIST+DELAY
[77] COMP+ODRV+DELAY Controller
01. comp attack 1ms~40ms
❍
02. comp release 10ms~680ms
❍
03. comp threshold –48dB~ -6dB
❍
04. comp ratio 1 ~ 20.0
❍
05. dist drive 0 ~ 127
❍
06. dist output level 0 ~ 127
❍
07. dist EQ low gain –12dB~+12dB
❍
08. dist EQ mid gain –12dB~+12dB
❍
09. delay time 0.1ms~1486.0ms
10. delay feedback gain –63~+63
❍
11. delay mix 0 ~ 127
❍
12. dry / wet balance D63>W ~ D=W ~ D<W63
❍
[78] DIST+DELAY
[79] OVERDRIVE+DELAY Controller
01. dist drive 0 ~ 127
❍
02. dist output level 0 ~ 127
❍
03. dist EQ low gain –12dB~+12dB
❍
04. dist EQ mid gain –12dB~+12dB
❍
05. delay time L 0.1ms~1486.0ms
06. delay time R 0.1ms~1486.0ms
07. delay feedback time 0.1ms~1486.0ms
08. delay feedback gain –63~+63
❍
09. delay mix 0 ~ 127
❍
10. dry / wet balance D63>W ~ D=W ~ D<W63
❍
41
■Groove Template List
■Groove Template-Liste
■Liste des modèles
d’expressions
rythmiques
No. Template Name No. Template Name
01 32Quantize 51 16SlipBeat
02 24Quantize 52 16 Swing
03 16Quantize 53 16Swing+24
04 16+24Quant 54 16LiteSwn1
05 12Quantize 55 16LiteSwn2
06 08Quantize 56 16MidSwing
07 08+12Quant 57 16HevySwng
08 06Quantize 58 16FullSwng
09 04Quantize 59 16 Tardy
10 32 Swing 60 16 WayBack
11 24>16+12 61 16 Zydeco
12 24>16+12of 62 12>8+6
13 24 Drunk 63 12>8+6 ofs
14 24 Sambody 64 12 Ashanti
15 24Shfflin1 65 12AshntRev
16 24Shfflin2 66 12 Drunk
17 16AccntDwn 67 12 Ju-Ju
18 16AccentUp 68 12Ju-JuRev
19 16AcidJazz 69 12Shfflin1
20 16 Baion 70 12Shfflin2
21 16BaionBmb 71 12Shfflin3
22 16Batucada 72 08'70Disco
23 16beatRock 73 08AccntDwn
24 16 Bomba 74 08AccentUp
25 16 Caixa 75 08 Charlie
26 16 Cuban 76 08 Drunk
27 16 Drunk 77 08 Late1&3
28 16 Dun-Dun 78 08 Late2
29 16GetFunky 79 08 Late2&3
30 16Guaguanc 80 08 Late2&4
31 16 HipHop 81 08 Late234
32 16 House 82 08 Push 1
33 16 Jungle 83 08 Push 3
34 16 Late 2 84 08 Push1&3
35 16 Late2&4 85 08 Push2&4
36 16 Late234 86 08 Push234
37 16 Later 87 08 PushAll
38 16LatinRck 88 08PushStrg
39 16Overeasy 89 08 Swing
40 16 Push1&3 90 08Swing+12
41 16 Push2&4 91 08 HardBop
42 16 Push234 92 08 Bebop
43 16 PushAll 93 08 UpSwing
44 16 Rap 94 08MidSwing
45 16Repiniqu 95 08SlowSwng
46 16Roadhous 96 08JzBallad
47 16 Robot 97 08 WayBack
48 16Rustaman 98 06>4+3
49 16 Samba 99 06>4+3 ofs
50 16 UpSamba 100 04 Swing
■Controll Change List
■Liste mit Controll
Change-Daten
■Liste des changements
de commande
No. Control Change
000 Bank MSB (off)
001 Modulation Wheel
002 Breath Controller
004 Foot Controller
005 Portamento Time
006 Data Entry MSB
007 Main Volume
010 Pan Pot
011 Expression
016 General Purpose 1 (Knob 1)
017 General Purpose 2 (Knob 2)
018 General Purpose 3 (Knob 3)
019 General Purpose 4 (Knob 4)
020 General Purpose 5 (Knob 5)
021 General Purpose 6 (Knob 6)
032 Bank LSB (off)
038 Data Entry LSB (off)
064 Sustain
065 Portamento Switch
066 Sostenuto
071 Harmonic Contents
072 Release Time
073 Attack Time
074 Brightness
084 Portamento Control
091 Effect 1
092 Effect 2
093 Effect 3
094 Effect 4
095 Effect 5
096 Data Increment
097 Data Decrement
098 NRPN LSB
099 NRPN MSB
100 RPN LSB
101 RPN MSB
■Arpeggio List
■Liste mit den
Arpeggio-Typen
■Liste des
Types arpèges
No. Name
1UpOct1
2 UpOct2
3 UpOct4
4 DnOct1
5 DnOct2
6 DnOct4
7 UpDnAOct1
8 UpDnAOct2
9 UpDnAOct4
10 UpDnBOct1
11 UpDnBOct2
12 UpDnBOct4
13 RndmOct1
14 RndmOct2
15 RndmOct4
16 Oct2Up
17 Oct4Up
18 UnisonUp
19 Up&Down1
20 Up&Down2
21 Up&Down4
22 Up&Alt1
23 Up&Rndm1
24 Up&Rndm2
25 Up&Rndm4
26 ChdAlsB1
27 ChdAlsB2
28 ChdAlsB4
29 ChdRndm1
30 ChdRndm2
31 ChdRndm4
32 TechnoA
33 TechnoB
34 TechnoC
35 DAHouse
36 SyncopaA
37 SyncopaB
38 SyncoEcho
39 TekkEchoA
40 TekkEchoB
41 PulseLine
42 SeqS&H1
43 SeqS&H2
44 CleanGt1
45 CleanGt2
46 CleanGt3
47 CleanGt4
48 Pno16Bt
49 PnoLatin
50 GrvBass
42
About MIDI
MIDI is an acronym that stands for Musical Instrument Digital Interface,
which allows electronic musical instruments to “communicate” with each
other, by sending and receiving compatible Note, Control Change, Program
Change and various other types of MIDI data, or messages.
The EX can control a MIDI device by transmitting note related data and
various types of controller data. The EX can be controlled by the incoming
MIDI messages which automatically select MIDI channels, voices and
effects, change parameter values, and of course play the voices specified
for the various Parts in a Performance.
MIDI Messages Transmitted/Received by the EX
The MIDI messages can be divided into two groups: the Channel Messages and System Messages. Below is a
brief explanation of the various types of MIDI messages which the EX can receive/transmit.
CHANNEL MESSAGES
The Channel Messages are the data related to the performance on the keyboard for the specific channel.
•Note On/Note Off (Key On/Key Off)
Messages which are generated when the keyboard is played. Each message includes a specific note
number which corresponds to the key which is pressed, plus a velocity value based on how hard the key is
struck.
•Control Change
Control Change messages let you select a voice bank (Bank Select), control volume, panning, modulation,
portamento time, brightness and various other controller parameters, through specific Control Change
numbers which correspond to each of the various parameters.
•Program Change
Messages which voice to select for each Part.
With a combination of Bank Select, you can select not only basic voice numbers, but also variation voice
bank numbers.
•Channel Aftertouch
Messages which let you control the sounds by the pressure you apply to the keys after the initial striking of
the keys, over the entire channel.
•Polyphonic Key Pressure
Messages which let you control the sounds by the pressure you apply to the keys after the initial striking of
the keys, for each individual key.
•Pitch Bend
Pitch Bend messages are continuous controller messages that allow the pitch of designated notes to be
raised or lowered by a specified amount over a specified duration.
SYSTEM MESSAGES
The System Messages are the data related to the overall system of the device.
•Exclusive Messages
Exclusive messages control various functions of the EX, including bulk dump, master volume and master
tuning, effect type and various other parameters.
•Realtime Messages
Messages which control the sequencer including Start, Stop, Continue, MIDI clock and Active Sensing
messages.
•Common Messages
Messages which also control the sequencer including Song Select and Song Position Pointer messages.
MIDI Data Format
Many MIDI messages listed in the MIDI Data Format section are expressed in hexadecimal or binary numbers.
Hexadecimal numbers may include the letter “H” as a suffix. The letter “n” indicates a certain whole number.
The chart below lists the corresponding decimal number for each hexadecimal/binary number.
Additional Notes
• For example, 144 - 159(Decimal)/9nH/1001 0000 - 1001 1111(Binary) indicate the note-on messages for the
channels 1 through 16 respectively. 176 - 191/BnH/1011 0000 - 1011 1111 indicate the control change messages
for the channels 1 through 16 respectively. 192 - 207/CnH/1100 0000 - 1100 1111 indicate the program change
messages for the channels 1 through 16 respectively. 240/F0H/1111 0000 is positioned at the beginning of data
to indicate a system exclusive message. 247/F7H/1111 0111 is positioned at the end of the system exclusive
message.
• aaH(Hexadecimal)/0aaaaaaa(Binary) indicates the data addresses. The data address consists of High, Mid and
Low.
• bbH/0bbbbbbb indicates byte counts.
• ccH/0ccccccc indicates tcheck sums.
• ddH/0ddddddd indicates data/value.
Decimal Hexadecimal Binary Decimal Hexadecimal Binary
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
0000 0000
0000 0001
0000 0010
0000 0011
0000 0100
0000 0101
0000 0110
0000 0111
0000 1000
0000 1001
0000 1010
0000 1011
0000 1100
0000 1101
0000 1110
0000 1111
0001 0000
0001 0001
0001 0010
0001 0011
0001 0100
0001 0101
0001 0110
0001 0111
0001 1000
0001 1001
0001 1010
0001 1011
0001 1100
0001 1101
0001 1110
0001 1111
0010 0000
0010 0001
0010 0010
0010 0011
0010 0100
0010 0101
0010 0110
0010 0111
0010 1000
0010 1001
0010 1010
0010 1011
0010 1100
0010 1101
0010 1110
0010 1111
0011 0000
0011 0001
0011 0010
0011 0011
0011 0100
0011 0101
0011 0110
0011 0111
0011 1000
0011 1001
0011 1010
0011 1011
0011 1100
0011 1101
0011 1110
0011 1111
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
0100 0000
0100 0001
0100 0010
0100 0011
0100 0100
0100 0101
0100 0110
0100 0111
0100 1000
0100 1001
0100 1010
0100 1011
0100 1100
0100 1101
0100 1110
0100 1111
0101 0000
0101 0001
0101 0010
0101 0011
0101 0100
0101 0101
0101 0110
0101 0111
0101 1000
0101 1001
0101 1010
0101 1011
0101 1100
0101 1101
0101 1110
0101 1111
0110 0000
0110 0001
0110 0010
0110 0011
0110 0100
0110 0101
0110 0110
0110 0111
0110 1000
0110 1001
0110 1010
0110 1011
0110 1100
0110 1101
0110 1110
0110 1111
0111 0000
0111 0001
0111 0010
0111 0011
0111 0100
0111 0101
0111 0110
0111 0111
0111 1000
0111 1001
0111 1010
0111 1011
0111 1100
0111 1101
0111 1110
0111 1111
43
1. NOTE ON/OFF
STATUS: 9nH/8nH
2. PROGRAM CHANGE
STATUS: CnH
3. PITCH BEND CHANGE
STATUS: EnH
4. CONTROL CHANGE
STATUS: BnH
<BANK SELECT MSB/LSB> 00H/20H
Cntrl# parameter Data Range
0 Bank Select MSB 63 (0x3F):Exclusive to EX
32 Bank Select LSB 0 (0x00):Preset1 Voice
1 (0x01):Preset2 Voice
2 (0x02):Internal1 Voice
3 (0x03):Internal2 Voice
64 (0x40):Performance
0 Bank Select MSB 0 (0x00): GM
32 Bank Select LSB 0 (0x00):Internal1 Voice
0 Bank Select MSB 127(0x7F): GM
32 Bank Select LSB 0 (0x00):Internal2 Voice
New bank selection will not become effective until the Program Change message is received.
<MODULATION> 01H
Cntrl# parameter Data Range
1 Modulation 0...127
<BREATH CONTROLLER> 02H
Cntrl# parameter Data Range
2 Breath Controller 0...127
<FOOT CONTROLLER> 04H
Cntrl# parameter Data Range
4 Foot Controller 0...127
<PORTAMENTO TIME> 05H
Cntrl# parameter Data Range
5 Portamento Time 0...127
Setting the value to 127 produces maximum portamento time and 0 results in minimum portamento
time.
<DATA ENTRY MSB/LSB> 06H/26H
Cntrl# parameter Data Range
6 Data Entry MSB 0...127
38 Data Entry LSB 0...127
Messages which set the value for the parameter specified by RPN.
<MAIN VOLUME> 07H
Cntrl# parameter Data Range
7 Main Volume 0...127
<PAN POT> 0AH
Cntrl# parameter Data Range
10 Panpot 0...127
Setting the value to 127 positions to the right most and 0 positions to the left most.
<EXPRESSION> 0BH
Cntrl# parameter Data Range
11 Expression 0...127
<CONTROL CHANGE 13> 0DH
Cntrl# parameter Data Range
13 Control Change 13 0...127
<SUSTAIN> 40H
Cntrl# parameter Data Range
64 Sustain 0...127 (0-63:Off, 64-127:On)
<PORTAMENTO> 41H
Cntrl# parameter Data Range
65 Portamento 0...127 (0-63:Off, 64-127:On)
Portamento is applied according to the amount set in the Portamento Time when the Prtament is
set to ON. MONO is selected when the Prtament is set to ON: Single Trigger mode is selected. In
the other cases: Multi Trigger mode.
<SOSTENUTO> 42H
Cntrl# parameter Data Range
66 Sostenuto 0...127 (0-63:Off, 64-127:On)
<HARMONIC CONTENT> 47H
Cntrl# parameter Data Range
71 Harmonic Content 0...127 (0:-64, 64:+0, 127:+63)
Adjusts the resonance. Effective range may be narrower than the available range.
<RELEASE TIME> 48H
Cntrl# parameter Data Range
72 Release Time 0...127 (0:-64, 64:+0, 127:+63)
Adjusts the envelope release time. Effective range may be narrower than the available range.
<ATTACK TIME> 49H
Cntrl# parameter Data Range
73 Attack Time 0...127 (0:-64, 64:+0, 127:+63)
Adjusts the envelope attack time. Effective range may be narrower than the available range.
<BRIGHTNESS> 4AH
Cntrl# parameter Data Range
74 Brightness 0...127 (0:-64, 64:+0, 127:+63)
Default:40H
Adjusts the filter cut-off frequency. Effective range may be narrower than the available range.
<PORTAMENT CONTROL> 54H
Cntrl# parameter Data Range
84 Portamento control 0...127
<EFFECT SEND LEVEL 1 (REVERB)> 5BH
Cntrl# parameter Data Range
91 Effect 1 Depth 0...127
Adjusts the reverb send level.
<EFFECT SEND LEVEL 3 (CHORUS)> 5DH
Cntrl# parameter Data Range
93 Effect3 Depth 0...127
Adjusts the chorus send level.
<DATA INCREMENT/DECREMENT> 60H/61H
Cntrl# parameter Data Range
96 Increment 0...127
97 Decrement 0...127
The data byte is ignored.
Messages which increase or decrease the MSB value designated by RPN.
<REGISTERED PARAMETER NUMBER (RPN) LSB/MSB> 64H/65H
Cntrl# parameter Data Range
100 RPN LSB 0...127
101 RPN MSB 0...127
The following parameters can be designated.
RPN
LSB MSB MSB parameter Data Range
00H 00H mmH Pitch Bend Sensitivity mm:00H-18H(0-+24)
Default:02H
01H 00H mmH Fine Tune mm:00H-40H-7FH(-64-0-+63)
Default : 40H 00H
02H 00H mmH Coarse Tune mm:28H-40H-58H(-24-0-+24)
Default : 40H 00H
7FH 7FH --- Null ---
5. CHANNEL MODE MESSAGES
<ALL SOUNDS OFF > 78H
Cntrl# parameter Data Range
120 ----- 0
All the sounds currently played except for the channel messages are muted when receiving this
message.
<RESET ALL CONTROLLERS> 79H
Cntrl# parameter Data Range
121 ----- 0
Resets the values set for the following controllers.
PITCH BEND CHANGE Center
CHANNEL AFTER TOUCH 0
MODULATION 0
BREATH CONTROLLER Maximum
FOOT CONTROLLER Maximum
EXPRESSION Maximum
CONTROL CHANGE 13 Center
SUSTAIN SWITCH Off
PORTAMENTO SWITCH Off
SOSTENUTO SWITCH Off
RPN Null
Resets the Portamento Control setting.
<ALL NOTES OFF> 7BH
Cntrl# parameter Data Range
123 --------- 0
All the notes currently set to on in a certain channel are muted when receiving this message.
However, if Hold 1 or Sostenute is on, notes will continue sounding until these are turned off.
<OMNI MODE OFF> 7CH
Cntrl# parameter Data Range
124 --------- 0
Performs the same function as when receiving ALL NOTES OFF.
<OMNI MODE ON> 7DH
Cntrl# parameter Data Range
125 ----- 0
Performs the same function as when receiving ALL NOTES OFF.
44
<MONO> 7EH
Cntrl# parameter Data Range
126 Mono 0...16
Performs the same function as when receiving ALL SOUNDS OFF. If the 3rd byte (mono) is
within 0 through 16, the channel will be Mode4(m = 1).
<POLY> 7FH
Cntrl# parameter Data Range
127 ----- 0
Performs the same function as when receiving ALL SOUNDS OFF. The channel will be Mode3.
6. CHANNEL AFTER TOUCH
STATUS: DnH
7. SYSTEM EXCLUSIVE MESSAGES
<UNIVERSAL REALTIME MESSAGES>
1) MIDI Master Volume (Receive only)
F0H,7FH,xnH,04H,01H,llH,mmH,F7H
xn:n=Device Number, xn=7F:Broadcast
ll:Don’t care
mm:Master Volume
When received, Master Volume in the System Parameter will be changed.
2) MIDI Machine Control (Transmit only)
Transmits when MTC is selected for the timing clock.
2-1) STOP
F0H,7FH,7FH,06H,01H,F7H
Transmits when STOP is pressed.
2-2) DEFERRED PLAY
F0H,7FH,7FH,06H,03H,F7H
Transmits when RUN is pressed.
2-3) LOCATE
F0H,7FH,7FH,06H,44H,06H,01H,hrH,mnH,scH,frH,ffH,F7H
Transmits when moving in measures in the Song Play mode.
<UNIVERSAL NON-REALTIME MESSAGES>
1) GM System On (Receive only)
F0H,7EH,xnH,09H,01H,F7H
xn:n=Device Number, xn=7F:Broadcast
Resets all the data to their respective default values except for MIDI Master Tune.
2) ID Request(Receive only)
F0H,7EH,xnH,06H,01H,F7H
xn:n=Device Number, xn=7F:Broadcast
3) ID Reply(Transmit only)
F0H,7EH,0nH,06H,02H,43H,00H,41H,02H,xxH,00H,00H,00H,7EH,F7H
0n:n=Device Number
xx:33(EX5),34(EX7),40(EX5R)
Transmits ID Reply when ID Request is received.
<PARAMETER CHANGES>
F0H,43H,1nH,idH,ahH,amH,alH,ddH,~,ddH,F7H
1n:n=Device Number
id:ID=5B,57
ah:Address High
am:Address Mid
al:Address Low
dd:Data
ID = 5BH AH AM AL
1) Current Performance / Common Parameters See < Table 1> 10 ** **
2) Current Performance / Part Parameters See < Table 2> 3p ** **
3) Current Voice / Common TG Parameters See < Table 3> 40 ** **
4) Current Voice / Common Control Parameters See < Table 4> 50 ** **
5) Current Voice / Element Parameters 1 See < Table 5> 60 ee **
6) Current Voice / Element Parameters 2 See < Table 6> 70 ee **
7) Remote SW See < Table 13> 0A 00 **
1) an 2) are effective only in the Performance mode.
3)~6) are effective only in the Voice mode.
7): receive only.
p = Part No.(0~F:Part1~Part16)
ee = Element No.(00~7F:EL1~EL128)
** = Address (Refer to the tables)
[Other]
MIDI Master Tune (Receive only)
F0H,43H,1nH,27H,30H,00H,00H,mmH,llH,ccH,F7H
1n:n=Device Number
mm:Master Tune MSB
ll:Master Tune LSB
cc:Don’t care
When received, Master Tune in the System Parameter will be changed.
<BULK DUMP>
F0H,43H,0nH,idH,bhH,blH,ahH,amH,alH,ddH,~,ddH,ccH,F7H
0n:n=Device Number
id:ID=5B,57
bh:Byte Count High
bl:Byte Count Low
ah:Address High
am:Address Mid
al:Address Low
dd:Data
cc:Check Sum
ID = 5BH AH AM AL
1) Current Performance / Common Bulk See < Table 7> 10 00 00
2) Current Performance / Part Bulk See < Table 8> 3p 00 00
3) 1 Performance Bulk See < Table 9> 11 00 nn
4) Current Voice / All Bulk See < Table 10> 40 00 00
5) Current Voice / Element Bulk See < Table 11> 60 ee 00
1) and 2) are effective only in the Performance mode.
4) and 5) are effective only in the Voice mode.
p = Part No.(0~F:Part1~Part16)
b = Memory Bank(1~4:P1,P2,I1,I2)
ee = Element No.(00~7F:EL1~EL128)
nn = Memory No.(Refer to the tables)
<BULK DUMP REQUEST>
F0H,43H,2nH,idH,ahH,amH,alH,F7H
2n:n=Device Number
id:ID=5B,57
ah:Address High
am:Address Mid
al:Address Low
Receive only.
Responds to all the Bulk Dumps.
See MIDI Data Table for Address and Byte Count.
The Check sum is the value that results in a value of 0 for the lower 7 bits when the Byte
Count, Start Address, Data and Check sum itself are added. When receiving the Bulk Dump with
the wrong check sum, a check sum error will be displayed.
8. SYSTEM COMMON MESSAGES
<MIDI TIME CODE (Quarter Frame Message)>
F1H,nxH
nx:data
Receives when MTC is selected for the timing clock.
<SONG POSITION POINTER>
F2H,llH,mmH
ll:Song Position LSB
mm:Song Position MSB
Transmits when moving in measures in the Song Play mode.
Receives when in the standby status in the Song Play mode.
9. SYSTEM REALTIME MESSAGES
Can transmit and receive.
<TIMING CLOCK>
STATUS: F8H
<START>
STATUS: FAH
<CONTINUE>
STATUS: FBH
<STOP>
STATUS: FCH
<ACTIVE SENSING>
STATUS: FEH
Once FE (Active Sensing) has been received, if no MIDI data is subsequently received for
longer than an interval of approximately 300msec, the EX will perform the same function as
when All Sounds Off, All Notes Off, and Reset All Controllers messages are received, and
will then return to a status in which FE is not monitored.
45
MIDI Data Table
< Table 1 >
Current Performance / Common Parameter
Address Size Data Parameter Description
(H) (H) (H)
10 00 00 2 00 20 - 00 7F Performance Name 1
00 01 2 00 20 - 00 7F Performance Name 2
00 02 2 00 20 - 00 7F Performance Name 3
00 03 2 00 20 - 00 7F Performance Name 4
00 04 2 00 20 - 00 7F Performance Name 5
00 05 2 00 20 - 00 7F Performance Name 6
00 06 2 00 20 - 00 7F Performance Name 7
00 07 2 00 20 - 00 7F Performance Name 8
00 08 2 00 20 - 00 7F Performance Name 9
00 09 2 00 20 - 00 7F Performance Name 10
00 0A 2 00 20 - 00 7F Performance Name 11
00 0B 2 00 20 - 00 7F Performance Name 12
00 0C 2 00 00 - 00 7F Category
00 0D 2 00 00 - 00 7F Total Volume
00 0E 2 00 00 - 00 01 TG/Master KBD Mode Master KBD,TG
00 0F 2 00 00 - 00 7F Reverb Type
00 10 2 00 00 - 00 7F Reverb Parameter1
00 11 2 00 00 - 00 7F Reverb Parameter2
00 12 2 00 00 - 00 7F Reverb Parameter3
00 13 2 00 00 - 00 7F Reverb Parameter4
00 14 2 00 00 - 00 7F Reverb Parameter5
00 15 2 00 00 - 00 7F Reverb Parameter6
00 16 2 00 00 - 00 7F Reverb Parameter7
00 17 2 00 00 - 00 7F Reverb Parameter8
00 18 2 00 00 - 00 7F Reverb Parameter9
00 19 2 00 00 - 00 7F Reverb Parameter10
00 1A 2 00 00 - 00 7F Reverb Parameter11
00 1B 2 00 00 - 00 7F Reverb Parameter12
00 1C 2 00 00 - 01 7F Reverb Parameter13H
00 1D 2 00 00 - 01 7F Reverb Parameter13L
00 1E 2 00 00 - 01 7F Reverb Parameter14H
00 1F 2 00 00 - 01 7F Reverb Parameter14L
00 20 2 00 00 - 00 7F Reverb Return
00 21 2 00 00 - 00 7F Reverb PAN
00 22 2 reserve
00 23 2 00 00 - 00 7F Chorus Type
00 24 2 00 00 - 01 7F Chorus Parameter1H
00 25 2 00 00 - 01 7F Chorus Parameter1L
00 26 2 00 00 - 01 7F Chorus Parameter2H
00 27 2 00 00 - 01 7F Chorus Parameter2L
00 28 2 00 00 - 01 7F Chorus Parameter3H
00 29 2 00 00 - 01 7F Chorus Parameter3L
00 2A 2 00 00 - 00 7F Chorus Parameter4H
00 2B 2 00 00 - 00 7F Chorus Parameter4L
00 2C 2 00 00 - 00 7F Chorus Parameter5
00 2D 2 00 00 - 00 7F Chorus Parameter6
00 2E 2 00 00 - 00 7F Chorus Parameter7
00 2F 2 00 00 - 00 7F Chorus Parameter8
00 30 2 00 00 - 00 7F Chorus Parameter9
00 31 2 00 00 - 00 7F Chorus Parameter10
00 32 2 00 00 - 00 7F Chorus Parameter11
00 33 2 00 00 - 00 7F Chorus Parameter12
00 34 2 00 00 - 00 7F Chorus Return
00 35 2 00 00 - 00 7F Chorus PAN
00 36 2 00 00 - 00 7F Send Chorus to Reverb
00 37 2 00 00 - 00 06 Arpeggiater Tempo Control off,Knob1...Knob6
00 38 2 reserve
00 39 2 reserve
00 3A 2 reserve
00 3B 2 00 00 - 00 0F Bend Wheel Depth
00 3C 2 00 00 - 00 0F Bend Wheel Curve
00 3D 2 00 00 - 00 7F Bend Wheel Offset
00 3E 2 00 00 - 00 0F Modulation Wheel1 Depth
00 3F 2 00 00 - 00 0F Modulation Wheel1 Curve
00 40 2 00 00 - 00 7F Modulation Wheel1 Offset
00 41 2 00 00 - 00 0F CH After Depth
00 42 2 00 00 - 00 0F CH After Curve
00 43 2 00 00 - 00 7F CH After Offset
00 44 2 00 00 - 00 7F Modulation Wheel2 CC Number
00 45 2 00 00 - 00 0F Modulation Wheel2 Depth
00 46 2 00 00 - 00 0F Modulation Wheel2 Curve
00 47 2 00 00 - 00 7F Modulation Wheel2 Offset
00 48 2 00 00 - 00 7F Foot Controller CC Number
00 49 2 00 00 - 00 0F Foot Controller Depth
00 4A 2 00 00 - 00 0F Foot Controller Curve
00 4B 2 00 00 - 00 7F Foot Controller Offset
00 4C 2 00 00 - 00 7F Breath Controller CC Number
00 4D 2 00 00 - 00 0F Breath Controller Depth
00 4E 2 00 00 - 00 0F Breath Controller Curve
00 4F 2 00 00 - 00 7F Breath Controller Offset
00 50 2 00 00 - 00 7F Ribbon Controller CC Number
00 51 2 00 00 - 00 0F Ribbon Controller Depth
00 52 2 00 00 - 00 0F Ribbon Controller Curve
00 53 2 00 00 - 00 0F Ribbon Controller Hold RESET,HOLD
00 54 2 00 00 - 00 7F Ribbon Controller Offset
00 55 2 00 00 - 00 7F Knob1 CC Number
00 56 2 00 00 - 00 0F Knob1 Depth
00 57 2 00 00 - 00 0F Knob1 Curve
00 58 2 00 00 - 00 7F Knob1 Offset
00 59 2 00 00 - 00 7F Knob2 CC Number
00 5A 2 00 00 - 00 0F Knob2 Depth
00 5B 2 00 00 - 00 0F Knob2 Curve
00 5C 2 00 00 - 00 7F Knob2 Offset
00 5D 2 00 00 - 00 7F Knob3 CC Number
00 5E 2 00 00 - 00 0F Knob3 Depth
00 5F 2 00 00 - 00 0F Knob3 Curve
00 60 2 00 00 - 00 7F Knob3 Offset
00 61 2 00 00 - 00 7F Knob4 CC Number
00 62 2 00 00 - 00 0F Knob4 Depth
00 63 2 00 00 - 00 0F Knob4 Curve
00 64 2 00 00 - 00 7F Knob4 Offset
00 65 2 00 00 - 00 7F Knob5 CC Number
00 66 2 00 00 - 00 0F Knob5 Depth
00 67 2 00 00 - 00 0F Knob5 Curve
00 68 2 00 00 - 00 7F Knob5 Offset
00 69 2 00 00 - 00 7F Knob6 CC Number
00 6A 2 00 00 - 00 0F Knob6 Depth
00 6B 2 00 00 - 00 0F Knob6 Curve
00 6C 2 00 00 - 00 7F Knob6 Offset
00 6D 2 00 00 - 00 01 Arpeggiater On OFF/ON
00 6E 2 00 00 - 00 7F Arpeggiater Type
00 6F 2 00 00 - 00 01 Arpeggiater Hold OFF/ON
00 70 2 00 00 - 00 01 Arpeggiater Tx A On OFF/ON
00 71 2 00 00 - 00 01 Arpeggiater Tx B On OFF/ON
00 72 2 00 00 - 00 0F Arpeggiater MIDI Channel
00 73 2 00 00 - 00 7F Note Limit Low
00 74 2 00 00 - 00 7F Note Limit High
00 75 2 00 00 - 01 7F Arpeggiater Tempo
00 76 2 00 00 - 00 7F Knob1 Scene1
00 77 2 00 00 - 00 7F Knob1 Scene2
00 78 2 00 00 - 00 7F Knob2 Scene1
00 79 2 00 00 - 00 7F Knob2 Scene2
00 7A 2 00 00 - 00 7F Knob3 Scene1
00 7B 2 00 00 - 00 7F Knob3 Scene2
00 7C 2 00 00 - 00 7F Knob4 Scene1
00 7D 2 00 00 - 00 7F Knob4 Scene2
00 7E 2 00 00 - 00 7F Knob5 Scene1
00 7F 2 00 00 - 00 7F Knob5 Scene2
01 00 2 00 00 - 00 7F Knob6 Scene1
01 01 2 00 00 - 00 7F Knob6 Scene2
01 02 2 00 00 - 00 01 Mono Mode MONO,POLY
01 03 2 00 00 - 01 7F Detune
01 04 2 00 00 - 00 7F Volume
01 05 2 00 00 - 00 7F PAN
01 06 2 00 00 - 00 7F Chorus Send
01 07 2 00 00 - 00 7F Reverb Send
01 08 2 00 00 - 00 7F Vibrato Rate
01 09 2 00 00 - 00 7F Vibrato Depth
01 0A 2 00 00 - 00 7F Vibrato Delay
01 0B 2 00 00 - 00 7F Filter Cut Off Frequency
01 0C 2 00 00 - 00 7F Filter Resonance
01 0D 2 00 00 - 00 7F EG Attack Time
01 0E 2 00 00 - 00 7F EG Decay Time
01 0F 2 00 00 - 00 7F EG Release Time
01 10 2 00 00 - 00 01 Portament Switch
01 11 2 00 00 - 00 7F Portament Time
01 12 2 00 00 - 00 7F Pitch EG Initial Level
01 13 2 00 00 - 00 7F Pitch EG Attack Time
01 14 2 00 00 - 00 7F Pitch EG Release Level
01 15 2 00 00 - 00 7F Pitch EG Release Time
< Table 2 >
Current Performance / Part Parameter
Address Size Data Parameter Description
(H) (H) (H)
30 00 00 2 00 00 - 00 7F Bank Select MSB
00 01 2 00 00 - 00 02 Bank Select LSB
00 02 2 00 00 - 00 7F Program Number
00 03 2 00 00 - 00 01 Same Note Number Key ON Assign
00 04 2 00 00 - 00 03 TG Bank
00 05 2 00 00 - 00 01 MONO/POLY Mode
00 06 2 00 00 - 01 7F Detune
00 07 2 00 00 - 00 7F Volume
00 08 2 00 00 - 00 7F PAN
00 09 2 00 00 - 00 7F Chorus Send
00 0A 2 00 00 - 00 7F Reverb Send
00 0B 2 00 00 - 00 7F Vibrato Rate
00 0C 2 00 00 - 00 7F Vibrato Depth
00 0D 2 00 00 - 00 7F Vibrato Delay
00 0E 2 00 00 - 00 7F Filter Cut Off Frequency
00 0F 2 00 00 - 00 7F Filter Resonance
00 10 2 00 00 - 00 7F EG Attack Time
00 11 2 00 00 - 00 7F EG Decay Time
00 12 2 00 00 - 00 7F EG Release Time
00 13 2 00 00 - 00 01 Insertion SW
00 14 2 00 00 - 00 01 Arpeggiater SW
00 15 2 00 00 - 00 01 Portament Mode
00 16 2 00 00 - 00 01 Portament SW
00 17 2 00 00 - 00 7F Portament Time
00 18 2 00 00 - 00 7F Pitch EG Initial Level
00 19 2 00 00 - 00 7F Pitch EG Attack Time
00 1A 2 00 00 - 00 7F Pitch EG Release Level
00 1B 2 00 00 - 00 7F Pitch EG Release Time
00 1C 2 00 00 - 00 7F TG Program Number
00 1D 2 reserve
||
00 66 2 reserve
00 67 2 00 10 - 00 58 Pitch Bend Upper Depth
00 68 2 00 10 - 00 58 Pitch Bend Lower Depth
00 69 2 00 00 - 00 09 Output Select
00 6A 2 00 00 - 00 01 Layer SW
00 6B 2 00 00 - 00 01 MIDI Receive SW
00 6C 2 reserve
00 6D 2 00 00 - 00 0F MIDI Channel
00 6E 2 00 20 - 00 58 Transpose
00 6F 2 00 00 - 00 7F Note Limit Low
00 70 2 00 00 - 00 7F Note Limit High
00 71 2 00 01 - 00 7F Velocity Limit LOW
00 72 2 00 01 - 00 7F Velocity Limit HIGH
00 73 2 00 00 - 00 01 TX MIDI A OFF/ON
46
00 74 2 00 00 - 00 01 TX MIDI B OFF/ON
00 75 2 00 00 - 00 1F Master Keyboard Velocity Curve
00 76 2 00 00 - 00 7F Master Keyboard Velocity Sense Depth
00 77 2 00 00 - 00 7F Master Keyboard Velocity Sence OFFset
00 78 2 00 00 - 00 7F Bend Wheel Initial Value
00 79 2 00 00 - 00 7F Modulation Wheel1 Initial Value
00 7A 2 00 00 - 00 7F CH After Initial Value
00 7B 2 00 00 - 00 7F Modulation Wheel2 Initial Value
00 7C 2 00 00 - 00 7F Foot Controller Initial Value
00 7D 2 00 00 - 00 7F Breath Controller Initial Value
00 7E 2 00 00 - 00 7F Ribbon Controller Initial Value
00 7F 2 00 00 - 00 7F Knob1 Initial Value
01 00 2 00 00 - 00 7F Knob2 Initial Value
01 01 2 00 00 - 00 7F Knob3 Initial Value
01 02 2 00 00 - 00 7F Knob4 Initial Value
01 03 2 00 00 - 00 7F Knob5 Initial Value
01 04 2 00 00 - 00 7F Knob6 Initial Value
01 05 2 00 00 - 00 01 Tx Foot Volume OFF/ON
01 06 2 00 00 - 00 01 Tx Bend Wheel OFF/ON
01 07 2 00 00 - 00 01 Tx Modulation Wheel1 OFF/ON
01 08 2 00 00 - 00 01 Tx CH After OFF/ON
01 09 2 00 00 - 00 01 Tx Modulation Wheel2 OFF/ON
01 0A 2 00 00 - 00 01 Tx Foot Controller OFF/ON
01 0B 2 00 00 - 00 01 Tx Breath Controller OFF/ON
01 0C 2 00 00 - 00 01 Tx Ribbon Controller OFF/ON
01 0D 2 00 00 - 00 01 Tx Sustain OFF/ON
01 0E 2 00 00 - 00 01 Tx Foot Sw OFF/ON
01 0F 2 00 00 - 00 01 Tx Knob1 OFF/ON
01 10 2 00 00 - 00 01 Tx Knob2 OFF/ON
01 11 2 00 00 - 00 01 Tx Knob3 OFF/ON
01 12 2 00 00 - 00 01 Tx Knob4 OFF/ON
01 13 2 00 00 - 00 01 Tx Knob5 OFF/ON
01 14 2 00 00 - 00 01 Tx Knob6 OFF/ON
01 15 2 00 00 - 00 01 Init Tx CC OFF/ON
01 16 2 00 00 - 00 01 Init Tx Knob OFF/ON
01 17 2 00 00 - 00 01 Init Tx Pc OFF/ON
01 18 2 00 00 - 00 01 Init Tx Vol & PAN OFF/ON
01 19 2 00 00 - 00 01 Init Tg CC OFF/ON
01 1A 2 00 00 - 00 01 Init Tg Knob OFF/ON
p = Part No.(0 - F : Part1 - Part16)
< Table 3 >
Current Voice / Common TG Parameter
Address Size Data Parameter Description
(H) (H) (H)
40 00 00 2 00 20 - 00 7F Voice Name1 32-127(ASCII)
00 01 2 00 20 - 00 7F Voice Name2
00 02 2 00 20 - 00 7F Voice Name3
00 03 2 00 20 - 00 7F Voice Name4
00 04 2 00 20 - 00 7F Voice Name5
00 05 2 00 20 - 00 7F Voice Name6
00 06 2 00 20 - 00 7F Voice Name7
00 07 2 00 20 - 00 7F Voice Name8
00 08 2 00 20 - 00 7F Voice Name9
00 09 2 00 20 - 00 7F Voice Name10
00 0A 2 00 20 - 00 7F Voice Name11
00 0B 2 00 20 - 00 7F Voice Name12
00 0C 2 00 00 - 00 7F Category
00 0D 2 00 00 - 00 7F Voice Volume
00 0E 2 00 00 - 00 7F Drum Layer Count/Layer Flag
00 0F 2 00 00 - 00 7F Velocity Sense Depth
00 10 2 00 00 - 00 7F Velocity Sense Offset
00 11 2 00 00 - 00 7F Reverb Send Level
00 12 2 00 00 - 00 7F Chorus Send Level
00 13 2 00 00 - 00 7F Reverb Type
00 14 2 00 00 - 00 7F Reverb Parameter1
00 15 2 00 00 - 00 7F Reverb Parameter2
00 16 2 00 00 - 00 7F Reverb Parameter3
00 17 2 00 00 - 00 7F Reverb Parameter4
00 18 2 00 00 - 00 7F Reverb Parameter5
00 19 2 00 00 - 00 7F Reverb Parameter6
00 1A 2 00 00 - 00 7F Reverb Parameter7
00 1B 2 00 00 - 00 7F Reverb Parameter8
00 1C 2 00 00 - 00 7F Reverb Parameter9
00 1D 2 00 00 - 00 7F Reverb Parameter10
00 1E 2 00 00 - 00 7F Reverb Parameter11
00 1F 2 00 00 - 00 7F Reverb Parameter12
00 20 2 00 00 - 01 7F Reverb Parameter13 H
00 21 2 00 00 - 01 7F Reverb Parameter13 L
00 22 2 00 00 - 01 7F Reverb Parameter14 H
00 23 2 00 00 - 01 7F Reverb Parameter14 L
00 24 2 00 00 - 00 7F Reverb Return
00 25 2 00 00 - 00 7F Reverb PAN
00 26 2 reserve
00 27 2 00 00 - 00 7F Chorus Type
00 28 2 00 00 - 01 7F Chorus Parameter1H
00 29 2 00 00 - 01 7F Chorus Parameter1L
00 2A 2 00 00 - 01 7F Chorus Parameter2H
00 2B 2 00 00 - 01 7F Chorus Parameter2L
00 2C 2 00 00 - 01 7F Chorus Parameter3H
00 2D 2 00 00 - 01 7F Chorus Parameter3L
00 2E 2 00 00 - 00 7F Chorus Parameter4H
00 2F 2 00 00 - 00 7F Chorus Parameter4L
00 30 2 00 00 - 00 7F Chorus Parameter5
00 31 2 00 00 - 00 7F Chorus Parameter6
00 32 2 00 00 - 00 7F Chorus Parameter7
00 33 2 00 00 - 00 7F Chorus Parameter8
00 34 2 00 00 - 00 7F Chorus Parameter9
00 35 2 00 00 - 00 7F Chorus Parameter10
00 36 2 00 00 - 00 7F Chorus Parameter11
00 37 2 00 00 - 00 7F Chorus Parameter12
00 38 2 00 00 - 00 7F Chorus Return
00 39 2 00 00 - 00 7F Chorus PAN
00 3A 2 00 00 - 00 7F Send Chorus to Reverb
00 3B 2 00 00 - 00 03 Ins Type Type1,Type2,Type3
00 3C 2 00 00 - 00 06 Voice Type AWM,VL,FDSP,AN-poly,
AN-layer,AN+FDSP,Drum
00 3D 2 00 00 - 00 7F Insertion-S Type
00 3E 2 00 00 - 00 7F Insertion-S Parameter1
00 3F 2 00 00 - 00 7F Insertion-S Parameter2
00 40 2 00 00 - 00 7F Insertion-S Parameter3
00 41 2 00 00 - 00 7F Insertion-S Parameter4
00 42 2 00 00 - 00 7F Insertion-S Parameter5
00 43 2 00 00 - 00 7F Insertion-S Parameter6
00 44 2 00 00 - 00 7F Insertion-S Parameter7
00 45 2 00 00 - 00 7F Insertion-S Parameter8
00 46 2 00 00 - 00 7F Insertion-S Parameter9
00 47 2 00 00 - 00 7F Insertion-S Parameter10
00 48 2 00 00 - 00 7F Insertion-S Parameter11
00 49 2 00 00 - 00 7F Insertion-S Parameter12
00 4A 2 00 00 - 00 7F Insertion-S Parameter13
00 4B 2 00 00 - 00 7F Insertion-S Parameter14
00 4C 2 00 00 - 00 7F Insertion-S Parameter15
00 4D 2 00 00 - 00 7F FDSP PAN
00 4E 2 reserve
00 4F 2 00 00 - 00 7F Insertion-L Type
00 50 2 00 00 - 01 7F Insertion-L Parameter1H
00 51 2 00 00 - 01 7F Insertion-L Parameter1L
00 52 2 00 00 - 01 7F Insertion-L Parameter2H
00 53 2 00 00 - 01 7F Insertion-L Parameter2L
00 54 2 00 00 - 01 7F Insertion-L Parameter3H
00 55 2 00 00 - 01 7F Insertion-L Parameter3L
00 56 2 00 00 - 01 7F Insertion-L Parameter4H
00 57 2 00 00 - 01 7F Insertion-L Parameter4L
00 58 2 00 00 - 01 7F Insertion-L Parameter5H
00 59 2 00 00 - 01 7F Insertion-L Parameter5L
00 5A 2 00 00 - 01 7F Insertion-L Parameter6H
00 5B 2 00 00 - 01 7F Insertion-L Parameter6L
00 5C 2 00 00 - 01 7F Insertion-L Parameter7H
00 5D 2 00 00 - 01 7F Insertion-L Parameter7L
00 5E 2 00 00 - 01 7F Insertion-L Parameter8H
00 5F 2 00 00 - 01 7F Insertion-L Parameter8L
00 60 2 00 00 - 01 7F Insertion-L Parameter9H
00 61 2 00 00 - 01 7F Insertion-L Parameter9L
00 62 2 00 00 - 01 7F Insertion-L Parameter10H
00 63 2 00 00 - 01 7F Insertion-L Parameter10
00 64 2 00 00 - 01 7F Insertion-L Parameter11H
00 65 2 00 00 - 01 7F Insertion-L Parameter11L
00 66 2 00 00 - 01 7F Insertion-L Parameter12H
00 67 2 00 00 - 01 7F Insertion-L Parameter12L
00 68 2 00 00 - 01 7F Insertion-L Parameter13H
00 69 2 00 00 - 01 7F Insertion-L Parameter13L
00 6A 2 00 00 - 01 7F Insertion-L Parameter14H
00 6B 2 00 00 - 01 7F Insertion-L Parameter14L
00 6C 2 00 00 - 01 7F Insertion-L Parameter15H
00 6D 2 00 00 - 01 7F Insertion-L Parameter15L
00 6E 2 00 00 - 01 7F Insertion-L Parameter16H
00 6F 2 00 00 - 01 7F Insertion-L Parameter16L
00 70 2 00 00 - 00 06 Arpeggiater Tempo Control
00 71 2 reserve
00 72 2 reserve
00 73 2 00 00 - 00 7F Insertion To Reverb Send Level
00 74 2 00 00 - 00 7F Insertion To Chorus Send Level
00 75 2 00 00 - 01 7F Insertion Large/Insertion Small/FDSP Type
00 76 2 00 00 - 00 7F FDSP Parameter1
00 77 2 00 00 - 00 7F FDSP Parameter2
00 78 2 00 00 - 00 7F FDSP Parameter3
00 79 2 00 00 - 00 7F FDSP Parameter4
00 7A 2 00 00 - 00 7F FDSP Parameter5
00 7B 2 00 00 - 00 7F FDSP Parameter6
00 7C 2 00 00 - 00 7F FDSP Parameter7
00 7D 2 00 00 - 00 7F FDSP Parameter8
00 7E 2 00 00 - 00 7F FDSP Parameter9
00 7F 2 00 00 - 00 7F FDSP Parameter10
01 00 2 00 00 - 00 7F FDSP Parameter11
01 01 2 00 00 - 00 7F FDSP Parameter12
01 02 2 00 00 - 00 7F FDSP Parameter13
01 03 2 00 00 - 00 7F FDSP Parameter14
01 04 2 00 00 - 00 7F FDSP Parameter15
01 05 2 00 00 - 00 7F FDSP Parameter16
01 06 2 00 00 - 00 7F FDSP Parameter17
01 07 2 00 00 - 00 7F FDSP Parameter18
01 08 2 00 00 - 00 7F FDSP Parameter19
01 09 2 00 00 - 00 7F FDSP Parameter20
01 0A 2 00 00 - 00 01 Assign Mode Single,Multi
01 0B 2 00 00 - 00 02 AN/VL Assign Mode Last,Top,Bottom
01 0C 2 00 00 - 00 01 AWM Mono/Poly Mono,Poly
01 0D 2 00 00 - 00 01 AN/VL Mono/Poly Mono,Poly
01 0E 2 reserve
01 0F 2 00 00 - 00 01 Portament Mode Fingered,Fulltime
01 10 2 00 00 - 00 01 Portament Sw OFF/ON
01 11 2 00 00 - 00 7F Portament Time
< Table 4>
Current Voice / Common Control Parameter
Address Size Data Parameter Description
(H) (H) (H)
50 00 00 2 00 00 - 01 7F Bend Wheel Assign Switch H
01 2 00 00 - 01 7F Bend Wheel Assign Switch L
02 2 00 00 - 01 7F Modulation Wheel Assign Switch H
03 2 00 00 - 01 7F Modulation Wheel Assign Switch L
04 2 00 00 - 01 7F CH After Assign Switch H
05 2 00 00 - 01 7F CH After Assign Switch L
06 2 00 00 - 01 7F Modulation Wheel 2 Assign Switch H
07 2 00 00 - 01 7F Modulation Wheel 2 Assign Switch L
47
08 2 00 00 - 01 7F Foot Controller Assign Switch H
09 2 00 00 - 01 7F Foot Controller Assign Switch L
0A 2 00 00 - 01 7F Breath Controller Assign Switch H
0B 2 00 00 - 01 7F Breath Controller Assign Switch L
0C 2 00 00 - 01 7F Ribbon Controller Assign Switch H
0D 2 00 00 - 01 7F Ribbon Controller Assign Switch L
0E 2 00 00 - 01 7F Knob1 Assign Switch H
0F 2 00 00 - 01 7F Knob1 Assign Switch L
10 2 00 00 - 01 7F Knob2 Assign Switch H
11 2 00 00 - 01 7F Knob2 Assign Switch L
12 2 00 00 - 01 7F Knob3 Assign Switch H
13 2 00 00 - 01 7F Knob3 Assign Switch L
14 2 00 00 - 01 7F Knob4 Assign Switch H
15 2 00 00 - 01 7F Knob4 Assign Switch L
16 2 00 00 - 01 7F Knob5 Assign Switch H
17 2 00 00 - 01 7F Knob5 Assign Switch L
18 2 00 00 - 01 7F Knob6 Assign Switch H
19 2 00 00 - 01 7F Knob6 Assign Switch L
1A 2 00 00 - 00 7F VC1 Control Depth
1B 2 00 00 - 00 7F VC2 Control Depth
1C 2 00 00 - 00 7F VC3 Control Depth
1D 2 00 00 - 00 7F VC4 Control Depth
1E 2 00 00 - 00 7F VC5 Control Depth
1F 2 00 00 - 00 7F VC6 Control Depth
20 2 00 00 - 00 7F VC7 Control Depth
21 2 00 00 - 00 7F VC8 Control Depth
22 2 00 00 - 00 7F VC9 Control Depth
23 2 00 00 - 00 7F VC10 Control Depth
24 2 00 00 - 00 7F VC11 Control Depth
25 2 00 00 - 00 7F VC12 Control Depth
26 2 00 00 - 00 7F VC13 Control Depth
27 2 00 00 - 00 7F VC14 Control Depth
28 2 00 00 - 00 7F VC15 Control Depth
29 2 00 00 - 00 7F VC16 Control Depth
2A 2 00 00 - 01 7F VC1 Destination Assign Number
2B 2 00 00 - 01 7F VC2 Destination Assign Number
2C 2 00 00 - 01 7F VC3 Destination Assign Number
2D 2 00 00 - 01 7F VC4 Destination Assign Number
2E 2 00 00 - 01 7F VC5 Destination Assign Number
2F 2 00 00 - 01 7F VC6 Destination Assign Number
30 2 00 00 - 01 7F VC7 Destination Assign Number
31 2 00 00 - 01 7F VC8 Destination Assign Number
32 2 00 00 - 01 7F VC9 Destination Assign Number
33 2 00 00 - 01 7F VC10 Destination Assign Number
34 2 00 00 - 01 7F VC11 Destination Assign Number
35 2 00 00 - 01 7F VC12 Destination Assign Number
36 2 00 00 - 01 7F VC13 Destination Assign Number
37 2 00 00 - 01 7F VC14 Destination Assign Number
38 2 00 00 - 01 7F VC15 Destination Assign Number
39 2 00 00 - 01 7F VC16 Destination Assign Number
3A 2 00 00 - 00 0F VC1 Destination Assign Element SW
3B 2 00 00 - 00 0F VC2 Destination Assign Element SW
3C 2 00 00 - 00 0F VC3 Destination Assign Element SW
3D 2 00 00 - 00 0F VC4 Destination Assign Element SW
3E 2 00 00 - 00 0F VC5 Destination Assign Element SW
3F 2 00 00 - 00 0F VC6 Destination Assign Element SW
40 2 00 00 - 00 0F VC7 Destination Assign Element SW
41 2 00 00 - 00 0F VC8 Destination Assign Element SW
42 2 00 00 - 00 0F VC9 Destination Assign Element SW
43 2 00 00 - 00 0F VC10 Destination Assign Element SW
44 2 00 00 - 00 0F VC11 Destination Assign Element SW
45 2 00 00 - 00 0F VC12 Destination Assign Element SW
46 2 00 00 - 00 0F VC13 Destination Assign Element SW
47 2 00 00 - 00 0F VC14 Destination Assign Element SW
48 2 00 00 - 00 0F VC15 Destination Assign Element SW
49 2 00 00 - 00 0F VC16 Destination Assign Element SW
4A 2 00 10 - 00 58 Pitch Bend Upper Depth
4B 2 00 10 - 00 58 Pitch Bend Lower Depth
4C 2 00 00 - 00 7F Knob1 Scene1
4D 2 00 00 - 00 7F Knob1 Scene2
4E 2 00 00 - 00 7F Knob1 Initial
4F 2 00 00 - 00 7F Knob2 Scene1
50 2 00 00 - 00 7F Knob2 Scene2
51 2 00 00 - 00 7F Knob2 Initial
52 2 00 00 - 00 7F Knob3 Scene1
53 2 00 00 - 00 7F Knob3 Scene2
54 2 00 00 - 00 7F Knob3 Initial
55 2 00 00 - 00 7F Knob4 Scene1
56 2 00 00 - 00 7F Knob4 Scene2
57 2 00 00 - 00 7F Knob4 Initial
58 2 00 00 - 00 7F Knob5 Scene1
59 2 00 00 - 00 7F Knob5 Scene2
5A 2 00 00 - 00 7F Knob5 Initial
5B 2 00 00 - 00 7F Knob6 Scene1
5C 2 00 00 - 00 7F Knob6 Scene2
5D 2 00 00 - 00 7F Knob6 Initial
5E 2 00 00 - 00 01 Arpeggiater On
5F 2 00 00 - 00 7F Arpeggiater Type
60 2 00 00 - 00 7F Arpeggiater Note Limit Low
61 2 00 00 - 00 7F Arpeggiater Note Limit High
62 2 00 00 - 01 7F Arpeggiater Tempo
< Table 5 >
Current Voice / Element Parameter 1
Address Size Data Parameter Description
(H) (H) (H)
60 ee 00 3 00 00 00 - 00 00 03 Wave Bank
01 3 00 00 00 - 00 00 03 Element Type AWM,VL,AN,DRUM
02 3 00 00 00 - 00 00 7F Element Volume
03 3 00 00 00 - 00 1F 7F Wave Number
04 3 00 00 00 - 00 00 01 Random PAN
05 3 00 00 00 - 00 00 7F PAN(Random Depth)
06 3 00 00 00 - 00 00 01 Release Loop
07 3 00 00 00 - 00 00 01 One Shot Flag
08 3 00 00 00 - 00 00 01 REVS
09 3 00 00 00 - 00 00 01 Vce Flag
0A 3 00 00 00 - 00 00 0F Scaling PAN Depth
0B 3 00 00 00 - 00 00 7F Tune Fine
0C 3 00 00 00 - 00 00 7F Tune Coarse
0D 3 00 00 35 - 00 01 4B Detune
0E 3 00 00 00 - 00 00 7F Note Limit (Low)
0F 3 00 00 00 - 00 00 7F Note Limit(High)
10 3 00 00 00 - 00 00 7F Note Cross Fade
11 3 00 00 00 - 00 00 7F Velocity Limit(Low)
12 3 00 00 00 - 00 00 7F Velocity Limit(High)
13 3 00 00 00 - 00 00 7F Velocity Cross Fade
14 3 00 00 00 - 00 00 7F ExpressionLimit Low
15 3 00 00 00 - 00 00 7F Key On Delay
16 3 00 00 00 - 00 00 03 LFO Wave
17 3 reserve
18 3 00 00 00 - 00 00 3F LFO Freqency
19 3 00 00 00 - 00 01 7F PMD
1A 3 00 00 00 - 00 00 01 PINV
1B 3 00 00 00 - 00 00 7F AMD
1C 3 00 00 00 - 00 00 01 CINV
1D 3 00 00 00 - 00 00 7F CMD
1E 3 00 00 00 - 00 00 01 Sync
1F 3 00 00 00 - 00 00 7F Delay Vib. Start Time
20 3 00 00 00 - 00 01 7F LFO Fade Time
21 3 00 00 00 - 00 00 0F Freq Random Sense 0 - 15
22 3 00 00 00 - 00 00 0E Freq Vel Sense -7 - +7
23 3 00 00 00 - 00 00 3F LFO Freqency
24 3 00 00 00 - 00 00 03 LFO Wave Phase
25 3 00 00 00 - 00 00 07 LFO Wave Type
26 3 00 00 00 - 00 00 7F LFO Destination No.
27 3 00 00 00 - 00 00 7F LFO Depth
28 3 00 00 00 - 00 00 01 Sync
29 3 00 00 00 - 00 00 7F Delay Vib. Start Time
2A 3 00 00 00 - 00 01 7F LFO Fade Time
2B 3 00 00 00 - 00 00 1F Micro Tuning Table No.
2C 3 00 00 00 - 00 00 07 Pitch Scaling
2D 3 00 00 00 - 00 00 7F Pitch Scaling Center Note
2E 3 00 00 00 - 00 01 7F Initial Level(cent)
2F 3 00 00 00 - 00 01 7F 1st Level(cent)
30 3 00 00 00 - 00 01 7F 2nd Level(cent)
31 3 00 00 00 - 00 01 7F 3rd Level(cent)
32 3 00 00 00 - 00 01 7F Release1 Level(cent)
33 3 00 00 00 - 00 01 7F Release2 Level(cent)
34 3 00 00 28 - 00 00 58 Pitch EG Depth
35 3 00 00 00 - 00 00 7F Hold Time
36 3 00 00 00 - 00 00 7F 1st Rate
37 3 00 00 00 - 00 00 7F 2nd Rate
38 3 00 00 00 - 00 00 7F 3rd Rate
39 3 00 00 00 - 00 00 7F Release1 Rate
3A 3 00 00 00 - 00 00 7F Release2 Rate
3B 3 00 00 00 - 00 00 03 Loop Segment
3C 3 00 00 00 - 00 00 0E PEG Rate Scaling Sense -7 - +7
3D 3 00 00 00 - 00 00 0F Pitch Random Sense 0 - 15
3E 3 00 00 00 - 00 00 0E I.Touch->IHR Sense -7 - +7
3F 3 00 00 00 - 00 00 0E I.Touch->1st Rate Sense -7 - +7
40 3 00 00 00 - 00 00 0E I.Touch->Other Rates Sense -7 - +7
41 3 00 00 00 - 00 00 0E ITouch->PEG Level Sense -7 - +7
42 3 00 00 00 - 00 01 7F Initial Level
43 3 00 00 00 - 00 00 01 EGmode
44 3 00 00 00 - 00 00 7F AR/IHR
45 3 00 00 00 - 00 00 7F D1R
46 3 00 00 00 - 00 01 7F D1L
47 3 00 00 00 - 00 00 7F D2R
48 3 00 00 00 - 00 01 7F D2L
49 3 00 00 00 - 00 00 7F D3R
4A 3 00 00 00 - 00 01 7F D3L
4B 3 00 00 00 - 00 00 01 RR1mode
4C 3 00 00 00 - 00 00 7F Release1 Rate
4D 3 00 00 00 - 00 01 7F R1L
4E 3 00 00 00 - 00 00 7F Release2 Rate
4F 3 00 00 00 - 00 00 7F Level Scaling Break Point 1
50 3 00 00 00 - 00 00 7F Level Scaling Break Point 2
51 3 00 00 00 - 00 00 7F Level Scaling Break Point 3
52 3 00 00 00 - 00 00 7F Level Scaling Break Point 4
53 3 00 00 00 - 00 01 7F Level Scaling Offset 1
54 3 00 00 00 - 00 01 7F Level Scaling Offset 2
55 3 00 00 00 - 00 01 7F Level Scaling Offset 3
56 3 00 00 00 - 00 01 7F Level Scaling Offset 4
57 3 00 00 00 - 00 00 7F Level Scaling Sense
58 3 00 00 00 - 00 00 7F I.Touch Level Sense
59 3 00 00 00 - 00 00 0E I.Touch->DL Sense -7 - +7
5A 3 00 00 00 - 00 00 0E I.Touch->IHR Sense -7 - +7
5B 3 00 00 00 - 00 00 0E Rate Scaling Sense -7 - +7
5C 3 00 00 00 - 00 00 0E I.Touch->AR Sense -7 - +7
5D 3 00 00 00 - 00 00 0E I.Touch->D1R Sense -7 - +7
5E 3 00 00 00 - 00 00 0E I.Touch->Other Rates Sense -7 - +7
ee = Element No.(00 - 7F: Element1 - Element128)
< Table 6 >
Current Voice / Element Parameter 2
Address Size Data Parameter Description
(H) (H) (H)
70 ee 00 3 00 00 00 - 00 00 01 Cnct
01 3 00 00 00 - 00 00 1F Q
02 3 00 00 00 - 00 01 7F FEG Level init
03 3 00 00 00 - 00 01 7F 1st Fc offset
04 3 00 00 00 - 00 01 7F 2nd Fc offs
05 3 00 00 00 - 00 01 7F 3rd Fc offs
06 3 00 00 00 - 00 01 7F Release1 Fc offs
07 3 00 00 00 - 00 01 7F Release2 Fc offs
08 3 00 00 00 - 00 00 7F FEG Initail Hold Rate
09 3 00 00 00 - 00 00 7F FEG 1st Rate
0A 3 00 00 00 - 00 00 7F FEG 2nd Rate
48
0B 3 00 00 00 - 00 00 7F FEG 3rd Rate
0C 3 00 00 00 - 00 00 7F FEG Release1 Rate
0D 3 00 00 00 - 00 00 7F FEG Release2 Rate
0E 3 00 00 00 - 00 00 03 Loop Segment
0F 3 00 00 00 - 00 00 0E FEG Rate Scaling Sense -7 - +7
10 3 00 00 00 - 00 00 0E I.Touch->Q Level Sense -7 - +7
11 3 00 00 00 - 00 00 0E I.Touch->IHR Sense -7 - +7
12 3 00 00 00 - 00 00 0E I.Touch->1st Rate Sense -7 - +7
13 3 00 00 00 - 00 00 0E I.Touch->Other Rates Sense -7 - +7
14 3 00 00 00 - 00 00 01 Q enable
15 3 00 00 00 - 00 00 01 LFO enable
16 3 00 00 00 - 00 00 01 FEG enable
17 3 00 00 00 - 00 00 0F Filter Type
18 3 00 00 00 - 00 01 7F Fc
19 3 00 00 00 - 00 01 7F Gain
1A 3 00 00 00 - 00 00 7F Filter Scaling Break Point 1
1B 3 00 00 00 - 00 00 7F Filter Scaling Break Point 2
1C 3 00 00 00 - 00 00 7F Filter Scaling Break Point 3
1D 3 00 00 00 - 00 00 7F Filter Scaling Break Point 4
1E 3 00 00 00 - 00 01 7F Filter Scaling Offset 1
1F 3 00 00 00 - 00 01 7F Filter Scaling Offset 2
20 3 00 00 00 - 00 01 7F Filter Scaling Offset 3
21 3 00 00 00 - 00 01 7F Filter Scaling Offset 4
22 3 00 00 00 - 00 00 7F Fc scaling Sense
23 3 00 00 00 - 00 00 0E I.Touch->Gain Sense -7 - +7
24 3 00 00 00 - 00 00 0E I.Touch->Fc Sense -7 - +7
25 3 00 00 00 - 00 00 0F Fc Random Sense 0 - 15
26 3 00 00 00 - 00 00 0E I.Touch->FEG Level Sense -7 - +7
27 3 00 00 00 - 00 00 7F FEG Depth
28 3 00 00 00 - 00 00 01 Q enable
29 3 00 00 00 - 00 00 01 LFO enable
2A 3 00 00 00 - 00 00 01 FEG enable
2B 3 00 00 00 - 00 00 0F Filter Type
2C 3 00 00 00 - 00 01 7F Fc
2D 3 00 00 00 - 00 01 7F Gain
2E 3 00 00 00 - 00 00 7F Filter Scaling Break Point 1
2F 3 00 00 00 - 00 00 7F Filter Scaling Break Point 2
30 3 00 00 00 - 00 00 7F Filter Scaling Break Point 3
31 3 00 00 00 - 00 00 7F Filter Scaling Break Point 4
32 3 00 00 00 - 00 01 7F Filter Scaling Offset 1
33 3 00 00 00 - 00 01 7F Filter Scaling Offset 2
34 3 00 00 00 - 00 01 7F Filter Scaling Offset 3
35 3 00 00 00 - 00 01 7F Filter Scaling Offset 4
36 3 00 00 00 - 00 00 7F Fc scaling Sense
37 3 00 00 00 - 00 00 0E I.Touch->Gain Sense -7 - +7
38 3 00 00 00 - 00 00 0E I.Touch->Fc Sense -7 - +7
39 3 00 00 00 - 00 00 0F Fc Random Sense 0 - 15
3A 3 00 00 00 - 00 00 0E I.Touch->FEG Level Sense -7 - +7
3B 3 00 00 00 - 00 00 7F FEG Depth
3C 3 00 00 00 - 00 00 08 Static Filter Type
3D 3 00 00 00 - 00 01 7F Freq1
3E 3 00 00 00 - 00 00 7F Boost/Cut1
3F 3 00 00 00 - 00 00 1F Q or Bandwidth
40 3 00 00 00 - 00 00 0E I.Touch->B/C1 Sens
41 3 00 00 00 - 00 00 0E I.Touch->Fr1 Sens.
42 3 00 00 00 - 00 00 07 B/C Random Sens.
43 3 00 00 00 - 00 00 07 Fc Random Sens.
44 3 00 00 00 - 00 01 7F Freq2
45 3 00 00 00 - 00 00 7F Boost/Cut2
46 3 00 00 00 - 00 01 7F reserve
47 3 00 00 00 - 00 00 0E I.Touch->B/C2 Sens
48 3 00 00 00 - 00 00 0E I.Touch->Fr2 Sens.
49 3 00 00 00 - 00 00 7F Fc scaling sens.
4A 3 00 00 00 - 00 00 7F Gain
4B 3 00 00 00 - 00 00 01 FDSP SW
4C 3 00 00 00 - 00 00 02 Insertion Select SW
Bypass,Ins-S On,Ins-L On
ee = Element No.(00 - 7F : Element1 - Element128)
< Table 7 >
Current Performance / Common Bulk
Address Size Data Parameter Description
(H) (H) (H)
10 00 00 12 Performance Name ASCII
1 00 - 7F Category
1 00 - 7F Total Volume
1 00 - 01 TG/Master KBD
1 00 - 7F Reverb Type
1 00 - 7F Reverb Parameter1
1 00 - 7F Reverb Parameter2
1 00 - 7F Reverb Parameter3
1 00 - 7F Reverb Parameter4
1 00 - 7F Reverb Parameter5
1 00 - 7F Reverb Parameter6
1 00 - 7F Reverb Parameter7
1 00 - 7F Reverb Parameter8
1 00 - 7F Reverb Parameter9
1 00 - 7F Reverb Parameter10
1 00 - 7F Reverb Parameter11
1 00 - 7F Reverb Parameter12
2 00 00 - FF FF Reverb Parameter13
2 00 00 - FF FF Reverb Parameter14
1 00 - 7F Reverb Return
1 00 - 7F Reverb PAN
1 reserve
1 00 - 7F Chorus Type
2 00 00 - FF FF Chorus Parameter1
2 00 00 - FF FF Chorus Parameter2
2 00 00 - FF FF Chorus Parameter3
2 00 00 - FF FF Chorus Parameter4
1 00 - 7F Chorus Parameter5
1 00 - 7F Chorus Parameter6
1 00 - 7F Chorus Parameter7
1 00 - 7F Chorus Parameter8
1 00 - 7F Chorus Parameter9
1 00 - 7F Chorus Parameter10
1 00 - 7F Chorus Parameter11
1 00 - 7F Chorus Parameter12
1 00 - 7F Chorus Return
1 00 - 7F Chorus PAN
1 00 - 7F Send Chorus to Reverb
1 00 - 06 Arpeggiater Tempo Control
3 reserve
1 00 - FF Bend Wheel Depth/Curve
1 00 - 7F Bend Wheel Offset
1 00 - FF Modulation Wheel1 Depth/Curve
1 00 - 7F Modulation Wheel1 Offset
1 00 - FF CH After Depth/Curve
1 00 - 7F CH After Offset
1 00 - 7F Modulation Wheel2 CC Number
1 00 - FF Modulation Wheel2 Depth/Curve
1 00 - 7F Modulation Wheel2 Offset
1 00 - 7F Foot Controller CC Number
1 00 - FF Foot Controller Depth/Curve
1 00 - 7F Foot Controller Offset
1 00 - 7F Breath Controller CC Number
1 00 - FF Breath Controller Depth/Curve
1 00 - 7F Breath Controller Offset
1 00 - 7F Ribbon Controller CC Number
1 00 - FF Ribbon Controller Depth/Curve
1 00 - FF Ribbon Hold/Ribbon Controller Offset
1 00 - 7F Knob1 CC Number
1 00 - FF Knob1 Depth/Curve
1 00 - 7F Knob1 Offset
1 00 - 7F Knob2 CC Number
1 00 - FF Knob2 Depth/Curve
1 00 - 7F Knob2 Offset
1 00 - 7F Knob3 CC Number
1 00 - FF Knob3 Depth/Curve
1 00 - 7F Knob3 Offset
1 00 - 7F Knob4 CC Number
1 00 - FF Knob4 Depth/Curve
1 00 - 7F Knob4 Offset
1 00 - 7F Knob5 CC Number
1 00 - FF Knob5 Depth/Curve
1 00 - 7F Knob5 Offset
1 00 - 7F Knob6 CC Number
1 00 - FF Knob6 Depth/Curve
1 00 - 7F Knob6 Offset
1 00 - FF Arpeggiater On/Type
1 00 - 7F Arpeggiater Hold/Tx A On/Tx B On/MIDI Channel
1 00 - 7F Note Limit Low
1 00 - 7F Note Limit High
1 00 - FF Arpeggiater Tempo
1 00 - 7F Knob1Scene1
1 00 - 7F Knob1 Scene2
1 00 - 7F Knob2 Scene1
1 00 - 7F Knob2 Scene2
1 00 - 7F Knob3 Scene1
1 00 - 7F Knob3 Scene2
1 00 - 7F Knob4 Scene1
1 00 - 7F Knob4 Scene2
1 00 - 7F Knob5 Scene1
1 00 - 7F Knob5 Scene2
1 00 - 7F Knob6 Scene1
1 00 - 7F Knob6 Scene2
1 00 - 01 Mono Mode
1 00 - FF Detune
1 00 - 7F Volume
1 00 - 7F PAN
1 00 - 7F Chorus Send
1 00 - 7F Reverb Send
1 00 - 7F Vibrato Rate
1 00 - 7F Vibrato Depth
1 00 - 7F Vibrato Delay
1 00 - 7F Filter Cut Off Frequency
1 00 - 7F Filter Resonance
1 00 - 7F EG Attack Time
1 00 - 7F EG Decay Time
1 00 - 7F EG Release Time
1 00 - 01 Portament Switch
1 00 - 7F Portament Time
1 00 - 7F Pitch EG Initial Level
1 00 - 7F Pitch EG Attack Time
1 00 - 7F Pitch EG Release Level
1 00 - 7F Pitch EG Release Time
NET SIZE 132
GROSS SIZE 152
< Table 8 >
Current Performance / Part Bulk
Address Size Data Parameter Description
(H) (H) (H)
3p 00 00 1 00 - 7F Bank Select MSB
1 00 - 02 Bank Select LSB
1 00 - 7F Program Number
1 00 - 0F ASGN/TG Bank/MonoPoly
1 00 - FF Detune
1 00 - 7F Volume
1 00 - 7F PAN
1 00 - 7F Chorus Send
1 00 - 7F Reverb Send
1 00 - 7F Vibrato Rate
1 00 - 7F Vibrato Depth
1 00 - 7F Vibrato Delay
49
1 00 - 7F Filter Cut Off Frequency
1 00 - 7F Filter Resonance
1 00 - 7F EG Attack Time
1 00 - 7F EG Decay Time
1 00 - 7F EG Release Time
1 00 - 33 INS SW/ARP SW/Portamento Mode/Portamento SW
1 00 - 7F Portament Time
1 00 - 7F Pitch EG Initial Level
1 00 - 7F Pitch EG Attack Time
1 00 - 7F Pitch EG Release Level
1 00 - 7F Pitch EG Release Time
1 00 - 7F TG Program Number
74 reserve
1 10 - 58 Pitch Bend Upper Depth
1 10 - 58 Pitch Bend Lower Depth
1 00 - 09 Output Select
1 00 - 7F Layer SW/Rx ON/MIDI Channel
1 28 - 58 Transpose
1 00 - 7F Note Limit Low
1 00 - 7F Note Limit High
1 01 - 7F Velocity Limit LOW
1 01 - 7F Velocity Limit HIGH
1 00 - 7F Tx MIDI A ON/Tx MIDI B ON/Master Keyboard Velocity Curve
1 00 - 7F Master Keyboard Velocity Sense Depth
1 00 - 7F Master Keyboard Velocity Sence OFFset
1 00 - 7F Bend Wheel Initial Value
1 00 - 7F Modulation Wheel1 Initial Value
1 00 - 7F CH After Initial Value
1 00 - 7F Modulation Wheel2 Initial Value
1 00 - 7F Foot Controller Initial Value
1 00 - 7F Breath Controller Initial Value
1 00 - 7F Ribbon Controller Initial Value
1 00 - 7F Knob1 Initial Value
1 00 - 7F Init On/Knob2 Initial Value
1 00 - 7F Knob3 Initial Value
1 00 - 7F Knob4 Initial Value
1 00 - 7F Knob5 Initial Value
1 00 - 7F Knob6 Initial Value
1 00 - FF Tx FV/PB/MOD1/CAT/MOD2/FC/BC/RB
1 00 - FF Tx SUS/FS/KN1/KN2/KN3/KN4/KN5/KN6
1 00 - 3F Init Tx CC/Tx Knob/Tx PC/Tx Vol&PAN/Tg CC/Tg Knob
p = Part No.(0 - F : Part1 - Part16)
NET SIZE 126
GROSS SIZE 144
< Table 9 >
Performance Bulk
Address Size Data Parameter Description
(H) (H) (H)
11 00 nn Conforms to <Table7> and <Table8>.
nn = Memory No.(00 - 7F : Performance1 - Performance128)
NET SIZE 2148
GROSS SIZE 2456
< Table 10 >
Current Voice / All Bulk
Address Size Data Parameter Description
(H) (H) (H)
40 00 00 12 Voice Name ASCII
1 00 - 7F Category
1 00 - 7F Voice Volume
1 00 - 80 Drum Layer Count/Layer Flag
1 00 - 7F Velocity Sense Depth
1 00 - 7F Velocity Sense Offset
1 00 - 7F Reverb Send Level
1 00 - 7F Chorus Send Level
1 00 - 7F Reverb Type
1 00 - 7F Reverb Parameter1
1 00 - 7F Reverb Parameter2
1 00 - 7F Reverb Parameter3
1 00 - 7F Reverb Parameter4
1 00 - 7F Reverb Parameter5
1 00 - 7F Reverb Parameter6
1 00 - 7F Reverb Parameter7
1 00 - 7F Reverb Parameter8
1 00 - 7F Reverb Parameter9
1 00 - 7F Reverb Parameter10
1 00 - 7F Reverb Parameter11
1 00 - 7F Reverb Parameter12
2 00 00 - FF FF Reverb Parameter13
2 00 00 - FF FF Reverb Parameter14
1 00 - 7F Reverb Return
1 00 - 7F Reverb PAN
1 reserve
1 00 - 7F Chorus Type
2 00 00 - FF FF Chorus Parameter1
2 00 00 - FF FF Chorus Parameter2
2 00 00 - FF FF Chorus Parameter3
2 00 00 - FF FF Chorus Parameter4
1 00 - 7F Chorus Parameter5
1 00 - 7F Chorus Parameter6
1 00 - 7F Chorus Parameter7
1 00 - 7F Chorus Parameter8
1 00 - 7F Chorus Parameter9
1 00 - 7F Chorus Parameter10
1 00 - 7F Chorus Parameter11
1 00 - 7F Chorus Parameter12
1 00 - 7F Chorus Return
1 00 - 7F Chorus PAN
1 00 - 7F Send Chorus to Reverb
1 00 - 06 Ins Type/Voice Type
1 00 - 7F Insertion-S Type
1 00 - 7F Insertion-S Parameter1
1 00 - 7F Insertion-S Parameter2
1 00 - 7F Insertion-S Parameter3
1 00 - 7F Insertion-S Parameter4
1 00 - 7F Insertion-S Parameter5
1 00 - 7F Insertion-S Parameter6
1 00 - 7F Insertion-S Parameter7
1 00 - 7F Insertion-S Parameter8
1 00 - 7F Insertion-S Parameter9
1 00 - 7F Insertion-S Parameter10
1 00 - 7F Insertion-S Parameter11
1 00 - 7F Insertion-S Parameter12
1 00 - 7F Insertion-S Parameter13
1 00 - 7F Insertion-S Parameter14
1 00 - 7F Insertion-S Parameter15
1 00 - 7F FDSP PAN
1 00 - 7F Insertion-L Type
2 00 00 - FF FF Insertion-L Parameter1
2 00 00 - FF FF Insertion-L Parameter2
2 00 00 - FF FF Insertion-L Parameter3
2 00 00 - FF FF Insertion-L Parameter4
2 00 00 - FF FF Insertion-L Parameter5
2 00 00 - FF FF Insertion-L Parameter6
2 00 00 - FF FF Insertion-L Parameter7
2 00 00 - FF FF Insertion-L Parameter8
2 00 00 - FF FF Insertion-L Parameter9
2 00 00 - FF FF Insertion-L Parameter10
2 00 00 - FF FF Insertion-L Parameter11
2 00 00 - FF FF Insertion-L Parameter12
2 00 00 - FF FF Insertion-L Parameter13
2 00 00 - FF FF Insertion-L Parameter14
2 00 00 - FF FF Insertion-L Parameter15
2 00 00 - FF FF Insertion-L Parameter16
1 00 - 06 Arpeggiater Tempo Control
2 reserve
1 00 - 7F Insertion To Reverb Send Level
1 00 - 7F Insertion To Chorus Send Level
1 00 - FF Insertion Large/Insertion Small/FDSP Type
20 FDSP Parameter 00 - 7F
1 00 - FF Asgn/AN,VL Asgn/AWM Mono/AN,VL Mono/Port Mode/Port SW
1 00 - 7F Portament Time
2 00 00 - FF FF Bend Wheel Assign Switch
2 00 00 - FF FF Modulation Wheel Assign Switch
2 00 00 - FF FF CH After Assign Switch
2 00 00 - FF FF Modulation Wheel 2 Assign Switch
2 00 00 - FF FF Foot Controller Assign Switch
2 00 00 - FF FF Breath Controller Assign Switch
2 00 00 - FF FF Ribbon Controller Assign Switch
2 00 00 - FF FF Knob1 Assign Switch
2 00 00 - FF FF Knob2 Assign Switch
2 00 00 - FF FF Knob3 Assign Switch
2 00 00 - FF FF Knob4 Assign Switch
2 00 00 - FF FF Knob5 Assign Switch
2 00 00 - FF FF Knob6 Assign Switch
16 VC1~16 Control Depth 00 - 7F
16 VC1~16 Destination Assign Number 00 - FF
16 VC1~16 Dest Assign Elem 00 - 0F
1 10 - 58 Pitch Bend Upper Depth
1 10 - 58 Pitch Bend Lower Depth
1 00 - 7F Knob1Scene1
1 00 - 7F Knob1 Scene2
1 00 - 7F Knob1 Initial
1 00 - 7F Knob2 Scene1
1 00 - 7F Knob2 Scene2
1 00 - 7F Knob2 Initial
1 00 - 7F Knob3 Scene1
1 00 - 7F Knob3 Scene2
1 00 - 7F Knob3 Initial
1 00 - 7F Knob4 Scene1
1 00 - 7F Knob4 Scene2
1 00 - 7F Knob4 Initial
1 00 - 7F Knob5 Scene1
1 00 - 7F Knob5 Scene2
1 00 - 7F Knob5 Initial
1 00 - 7F Knob6 Scene1
1 00 - 7F Knob6 Scene2
1 00 - 7F Knob6 Initial
1 00 - FF Arpeggiater On/Type
1 00 - 7F Arpeggiater Note Limit Low
1 00 - 7F Arpeggiater Note Limit High
1 00 - FF Arpeggiater Tempo
132 Element data Conforms to <Table11>.
Common data size
NET SIZE 236
Element data size (per 1 Element)
NET SIZE 132
Element : Normal voice = 0 - 4, Drum voice = 0 - 128
voice data size
NET SIZE MAX 764(Normal Voice) , 17132(Drum Voice)
GROSS SIZE MAX 880(Normal Voice) , 19584(Drum Voice)
50
< Table 11 >
Current Voice / Element Bulk
Address Size Data Parameter Description
(H) (H) (H)
60 ee 00 1 00 - C4 Wave Bank/Element Type
1 00 - 7F Element Volume
2 00 00 - 0F FF Wave Number
1 00 - FF Random PAN/PAN(Random Depth)
1 00 - FF Release Loop/O.S./Revs/Vce/Scaling PAN Depth
1 00 - 7F Tune Fine
1 00 - 7F Tune Coarse
1 35 - CB Detune
1 00 - 7F Note Limit (Low)
1 00 - 7F Note Limit(High)
1 00 - 7F Note Cross Fade
1 00 - 7F Velocity Limit(Low)
1 00 - 7F Velocity Limit(High)
1 00 - 7F Velocity Cross Fade
1 00 - 7F ExpressionLimit Low
1 00 - 7F Key On Delay
1 00 - FF LFO Wave/Frequency
1 00 - FF PMD
1 00 - FF PINV/AMD
1 00 - FF CINV/CMD
1 00 - FF Sync/Delay Vibrato Start Time
1 00 - FF LFO Fade Time
1 00 - FE Freq Random Sense/Freq Vel Sense
1 00 - 3F LFO Freqency
1 00 - 1F Wave Phase/LFO Wave
1 00 - 7F LFO Destination No.
1 00 - 7F LFO Depth
1 00 - FF Sync/Delay Vibrato Start Time
1 00 - FF LFO Fade Time
1 00 - FF Micro Tuning Table No./Pitch Scaling
1 00 - 7F Pitch Scaling Center Note
1 00 - FF Initial Level(cent)
1 00 - FF 1st Level(cent)
1 00 - FF 2nd Level(cent)
1 00 - FF 3rd Level(cent)
1 00 - FF Release1 Level(cent)
1 00 - FF Release2 Level(cent)
1 00 - 7F Pitch EG Depth
1 00 - 7F Hold Time
1 00 - 7F 1st Rate
1 00 - 7F 2nd Rate
1 00 - 7F 3rd Rate
1 00 - 7F Release1 Rate
1 00 - 7F Release2 Rate
1 00 - 3E Loop Segment/PEG Rate Scaling Sense
1 00 - FE Pitch Random Sense/I.Touch->IHR Sense
1 00 - EE I.Touch->1st Rate sense/I.Touch->Other Rates Sense
1 00 - 0E I.Touch->PEG Level Sense
1 00 - FF Initial Level
1 00 - FF EGmode/AR,IHR
1 00 - 7F D1R
1 00 - FF D1L
1 00 - 7F D2R
1 00 - FF D2L
1 00 - 7F D3R
1 00 - FF D3L
1 00 - FF RR1mode/Release Rate
1 00 - FF R1L
1 00 - 7F Release2 Rate
1 00 - 7F Level Scaling Break Point 1
1 00 - 7F Level Scaling Break Point 2
1 00 - 7F Level Scaling Break Point 3
1 00 - 7F Level Scaling Break Point 4
1 00 - FF Level Scaling Offset 1
1 00 - FF Level Scaling Offset 2
1 00 - FF Level Scaling Offset 3
1 00 - FF Level Scaling Offset 4
1 00 - 7F Level Scaling Sense
1 00 - 7F I.Touch Level Sense
1 00 - EE I.Touch->DL Sense/I.Touch->IHR Sense
1 00 - EE Rate Scaling Sense/I.Touch->AR Sense
1 00 - EE I.Touch->D1R Sense/I.Touch->Other Rate Sense
1 00 - 5F Cnct/Q
1 00 - FF FEG Level init
1 00 - FF 1st Fc offset
1 00 - FF 2nd Fc offs
1 00 - FF 3rd Fc offs
1 00 - FF Release1 Fc offs
1 00 - FF Release2 Fc offs
1 00 - 7F FEG Initail Hold Rate
1 00 - 7F FEG 1st Rate
1 00 - 7F FEG 2nd Rate
1 00 - 7F FEG 3rd Rate
1 00 - 7F FEG Release1 Rate
1 00 - 7F FEG Release2 Rate
1 00 - 3E Loop Segment/PEG Rate Scaling Sense
1 00 - EE I.Touch->Q Level Sense/I.Touch->IHR Sense
1 00 - EE I.Touch->1st Rate Sense/I.Touch->Other Rate Sense
1 00 - 7F Q enable/LFO/FEG enable/Filter Type
1 00 - FF Fc
1 00 - FF Gain
1 00 - 7F Filter Scaling Break Point 1
1 00 - 7F Filter Scaling Break Point 2
1 00 - 7F Filter Scaling Break Point 3
1 00 - 7F Filter Scaling Break Point 4
1 00 - FF Filter Scaling Offset 1
1 00 - FF Filter Scaling Offset 2
1 00 - FF Filter Scaling Offset 3
1 00 - FF Filter Scaling Offset 4
1 00 - 7F Fc scaling sense
1 00 - EE I.Touch->Gain Sense/I.Touch->Fc Sense
1 00 - FE Fc Random Sense/I.Touch->FEG Level Sense
1 00 - 7F FEG Depth
1 00 - 7F Q enable/LFO/FEG enable/Filter Type
1 00 - FF Fc
1 00 - FF Gain
1 00 - 7F Filter Scaling Break Point 1
1 00 - 7F Filter Scaling Break Point 2
1 00 - 7F Filter Scaling Break Point 3
1 00 - 7F Filter Scaling Break Point 4
1 00 - FF Filter Scaling Offset 1
1 00 - FF Filter Scaling Offset 2
1 00 - FF Filter Scaling Offset 3
1 00 - FF Filter Scaling Offset 4
1 00 - 7F Fc scaling sense
1 00 - EE I.Touch->Gain Sense/I.Touch->Fc Sense
1 00 - FE Fc Random Sense/I.Touch->FEG Level Sense
1 00 - 7F FEG Depth
1 00 - 08 Static Filter Type
1 00 - FF Freq 1
1 00 - 7F Boost/Cut 1
1 00 - 1F Q or Band Width
1 00 - EE I.Touch->Boost or Cut1 Sense/I.Touch->Fc1 Sense
1 00 - 77 Boost or Cut Random Sense/Fc Random Sense
1 00 - FF Freq 2
1 00 - 7F Boost/Cut 2
1 reserve
1 00 - EE I.Touch->Boost or Cut2 Sense/I.Touch->Fc2 Sense
1 00 - 7F Fc Scaling Sense
1 00 - 7F Gain
1 00 - 42 FDSP Sw/Ins Sw
ee = Element No.(00 - 7F : Element1 - Element128)
NET SIZE 132
GROSS SIZE 152
< Table 12 >
Voice Bulk
Address Size Data Parameter Description
(H) (H) (H)
5b 00 nn Conforms to <Table10>.
b = Bank No.(1 - 4 : Preset1,Preset2,Intternal1,Internal2)
nn = Memory No.(00 - 7F : Voice1 - Voice128)
NET SIZE MAX 764(Normal Voice) , 17132(Drum Voice)
GROSS SIZE MAX 880(Normal Voice) , 19584(Drum Voice)
Ignores Preset1/Preset2 reception.
< Table 13 >
Remote SW
Address Size Data Parameter Description
(H) (H) (H)
0A 00 00 1 00 - 01 F1 OFF/ON
01 1 00 - 01 F2 OFF/ON
02 1 00 - 01 F3 OFF/ON
03 1 00 - 01 F4 OFF/ON
04 1 00 - 01 F5 OFF/ON
05 1 00 - 01 F6 OFF/ON
06 1 00 - 01 F7 OFF/ON
07 1 00 - 01 F8 OFF/ON
08 1 00 - 01 TEN KEY 0 OFF/ON
09 1 00 - 01 TEN KEY 1 OFF/ON
0A 1 00 - 01 TEN KEY 2 OFF/ON
0B 1 00 - 01 TEN KEY 3 OFF/ON
0C 1 00 - 01 TEN KEY 4 OFF/ON
0D 1 00 - 01 TEN KEY 5 OFF/ON
0E 1 00 - 01 TEN KEY 6 OFF/ON
0F 1 00 - 01 TEN KEY 7 OFF/ON
10 1 00 - 01 TEN KEY 8 OFF/ON
11 1 00 - 01 TEN KEY 9 OFF/ON
12 1 00 - 01 TEN KEY - OFF/ON
13 1 00 - 01 ENTER OFF/ON
14 1 00 - 01 EXIT OFF/ON
15 1 00 - 01 SHIFT OFF/ON
16 1 00 - 01 DEC OFF/ON
17 1 00 - 01 INC OFF/ON
18 1 00 - 01 RIGHT OFF/ON
19 1 00 - 01 LEFT OFF/ON
1A 1 00 - 01 DOWN OFF/ON
1B 1 00 - 01 UP OFF/ON
1C 1 00 - 01 DATA/CURSOR OFF/ON
1D 1 00 - 01 CANCEL OFF/ON
1E 1 00 - 01 SCENE 1 OFF/ON
1F 1 00 - 01 SCENE 2 OFF/ON
20 1 00 - 01 VOICE OFF/ON
21 1 00 - 01 PERFORMANCE OFF/ON
22 1 00 - 01 SONG OFF/ON
23 1 00 - 01 PATTERN OFF/ON
24 1 00 - 01 SAMPLE OFF/ON
25 1 00 - 01 EDIT OFF/ON
26 1 00 - 01 JOB OFF/ON
27 1 00 - 01 STORE OFF/ON
28 1 00 - 01 UTILITY OFF/ON
29 1 00 - 01 DISK OFF/ON
2A 1 00 - 01 ARPEGGIO OFF/ON
2B 1 00 - 01 KNOB MODE OFF/ON
2C 1 00 - 01 KEY MAP OFF/ON
2D 1 00 - 01 EF BYPASS OFF/ON
2E 1 00 - 01 TOP OFF/ON
2F 1 00 - 01 REW OFF/ON
51
30 1 00 - 01 FWD OFF/ON
31 1 00 - 01 REC OFF/ON
32 1 00 - 01 STOP OFF/ON
33 1 00 - 01 PLAY OFF/ON
34 1 00 - 01 OCTAVE - OFF/ON
35 1 00 - 01 OCTAVE + OFF/ON
36 1 00 - 01 BANK A OFF/ON
37 1 00 - 01 BANK B OFF/ON
38 1 00 - 01 BANK C OFF/ON
39 1 00 - 01 BANK D OFF/ON
3A 1 00 - 01 BANK E OFF/ON
3B 1 00 - 01 BANK F OFF/ON
3C 1 00 - 01 BANK G OFF/ON
3D 1 00 - 01 BANK H OFF/ON
3E 1 00 - 01 PROG 1 OFF/ON
3F 1 00 - 01 PROG 2 OFF/ON
40 1 00 - 01 PROG 3 OFF/ON
41 1 00 - 01 PROG 4 OFF/ON
42 1 00 - 01 PROG 5 OFF/ON
43 1 00 - 01 PROG 6 OFF/ON
44 1 00 - 01 PROG 7 OFF/ON
45 1 00 - 01 PROG 8 OFF/ON
46 1 00 - 01 PROG 9 OFF/ON
47 1 00 - 01 PROG 10 OFF/ON
48 1 00 - 01 PROG 11 OFF/ON
49 1 00 - 01 PROG 12 OFF/ON
4A 1 00 - 01 PROG 13 OFF/ON
4B 1 00 - 01 PROG 14 OFF/ON
4C 1 00 - 01 PROG 15 OFF/ON
4D 1 00 - 01 PROG 16 OFF/ON
52
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number :
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System :
Real Time :
Aux : Local ON/OFF
: All Notes OFF
Mes- : Active Sense
sages: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0,32
1,7,11,64,65
5,10,66,67
6,38
0-95
71-74
84
91,93,94
96,97
98,99
100,101
120
121
Clock
Commands
1 - 16
1 - 16
Ø 9nH,v=1-127
˛ 9nH,v=0
˛
Ø
Ø
Ø
˛
˛
Ø
˛
˛
˛
˛
˛
˛
˛
˛
Ø 0 - 127
**************
˛
˛
˛
˛
˛
˛
˛
Ø
˛
*1 receive if switch is on.
*2 m is always treated as "1" regardless of its value.
3
˛
**************
0 - 127
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø
1 - 16
1 - 16
Ø v=1-127
˛
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
˛
Ø *1
Ø *1
Ø *1
Ø 0 - 127 *1
0 - 127
˛
˛
˛
˛
˛
˛
Ø(123-127) *1
Ø
˛
1
1 - 4(m=1) *2
˛
0 - 127
0 - 127
Ø
Ø 0-24 semi *1
Bank Select
Data Entry
Assignable Cntrl
Sound Controller
Portamento Cntrl
Effect SendLevel
Data Inc,Dec
NRPN LSB,MSB
RPN LSB,MSB
All Sound Off
Reset All Cntrls
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Music Synthesizer - synth. part ] Date :13-JAN-1998
Model EX5/7/5R MIDI Implementation Chart Version : 1.0
Memorised
Memorised
Transpose
53
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
Aux : Local ON/OFF
: All Notes OFF
Mes- : Active Sense
sages: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0-121
1 - 16
˛
Ø 9nH,v=1-127
˛ 9nH,v=0
Ø *1
Ø *1
Ø *1
Ø 0 - 127 *1
**************
Ø *4
˛
˛
Ø *4
Ø *4
Ø
˛
Ø
˛
*1 receive if filter out is pass.
*2 receive if filter in is pass.
*3 if MIDI sync is midi
*4 if MIDI control out is on
*5 if MIDI control in is on
˛
˛
**************
0 - 127 *1
**************
Ø *1
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø *1
1 - 16
˛
Ø v=1-127
˛
Ø *2
Ø *2
Ø *2
Ø 0 - 127 *2
Ø *5
˛
˛
Ø *3
Ø *5
Ø
˛
˛
˛
˛
˛
˛
0 - 127 *2
Ø *2
Ø *2
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Music Synthesizer --- seq. part ] Date :13-JAN-1998
Model EX5/7/5R MIDI Implementation Chart Version : 1.0
Memorised
54
■MEMO
M.D.G., EMI Division Yamaha Corporation
©1998 Yamaha Corporation
V245260 001MWIT2.2-03B0 Printed in Japan
This document is printed on chlorine free (ECF) paper with soy ink.
EX7 DL Cover/E 00.2.8 1:47 PM ページ 2
