0.78K-441 Printed in Japan ’00.09
RGX 121S
SERVICE MANUAL
EG 011535
ELECTRIC GUITAR
HAMAMATSU, JAPAN
CONTENTS
OVERALL ASSEMBLY ............................................... 2
CIRCUIT DIAGRAM .................................................... 4
WIRING ....................................................................... 4
SPECIFICATIONS .................................................... 5
This document is printed on chlorine free (ECF) paper with soy ink.
RGX 121S
2
E44
E43
E45
E01 E06
E10 E11
E07 E08
RGX 121S
A01a
A seal is attached
on the rear of the neck.
品番シール（ネック裏面に貼付）
E12
E20 E21
E47
F08 F09 F10
F08 F09 F10
F12
F14F11
F15 F16
F13
F04
E47
E39
A01
E55
G03
D02
G05
G09
G08
G07
E57
F03
F01
E28E27
E33
E54E53
F01a
F01d
E27a
E27b
F01b F01c
G11
G13
E28 MASTER VOLUME: 15A 500KΩ
MASTER TONE: 05A 250KΩ
OVERALL ASSEMBLY
Bridge Assembly: YS-11 (Black)
E27
B01
B02
B03
B05
B04
Jack Installation
F16 F15
F13
F13
F12
F11
F14
（総組立）
（JACK 部詳細）
RGX 121S
3
REF NO.
PART NO. DESCRIPTION REMARKS
QTY
: New Parts RANK: Japan only
*
OVERALL ASSEMBLY RGX 121S
A01 Neck Assembly SBL
A01a Seal (QC59460)
D02 Body
E01 Tuning Machine Assembly RM1273 (Black) 1set 12
E06 String Guide Black 01
E07 Spacer Black 02
E08 Round Head Wood Screw 2.1X10 (Black)
E10 Rod Cover Black 01
E11 Oval Head Wood Screw 2.1X10 (Black) 01
E12 Nut Black 04
E20 Neck Plate Black 06
E21 Oval Head Tapping Screw 4.0X45 (Black) 4
E27 Bridge Assembly YS-11 (Black) 2 13
E27a Arm Spring Plate
E27b Arm Spring 3
E28 Round Head Wood Screw 3.1X25 (Black) 6
E33 Oval Head Tapping Screw 4.0X45 (Nickel plate) 2 01
E39 Strings XL-120 1set (QC16510)
E43 End Pin Black 201
E44 Oval Head Tapping Screw 3.0X25 (Black) 2 01
E45 Spacer Black 201
E47 Knob Assembly H=16.5 (Black) 2 05
E53 Back Cover Bridge (Black) 1 04
E54 Oval Head Wood Screw 2.7X13 (Black) 6 03
E55 Back Cover 1 (Black) 05
E57 Oval Head Wood Screw 2.7X13 (Black) 3 03
F01 Electrical Unit 1set (QC16930)
F01a Variable Resistor 15A 500K ohm VOLUME 03
F01b Variable Resistor 05A 250K ohm TONE 03
F01c Mylar Cap. 0.022uF 01
F01d Pickup Switch 5-P 08
F03 Knob Black 02
F04 Oval Head Screw 3.0X8 (Black) 2 01
F08 Hexagonal Nut 2
F09 Flat Washer 2
F10 Toothed Lock Washer 2
F11 Electrical unit (Jack) 1set 06
F12 Jack Panel Black 05
F13 Oval Head Wood Screw 2.7X13 (Black) 2 03
F14 Hexagonal Nut Black 01
F15 Flat Washer Black 01
F16 Toothed Lock Washer 9S 201
G03 Pickup Assembly FRONT 10
G05 Oval Head Tapping Screw 2.4X16 (Black) 4 01
G07 Pickup Assembly CENTER 09
G08 Pickup Spring 201
G09 Round Head Wood Screw 2.4X25 (Black) 2 01
G11 Pickup Assembly REAR 10
G13 Oval Head Tapping Screw 2.4X16 (Black) 4 01
H01 Accessory Unit G-2 1set (QC35410)
Cord D 05
Wrench #5
Wrench #2
Wrench #1.5
Bridge Assembly YS-11 (Black) 13
B01 Arm 06
B02 Bridge Base 06
B03 Bridge Tail 06
B04 Bridge Piece Assembly 605
B05 Flat Head Screw 4.0X9 301
AAX19490
--
--
QC296300
QC201700
QC370200
EA620080
VD955900
03706220
VB344800
QC201900
EN240070
QC335200
--
--
QC202100
EN240060
--
VB563800
VD816500
VB793700
VK739800
CB822600
EB620020
QC019200
EB620020
--
HS120070
HS120100
UA114220
KA502000
CB821810
03755170
--
--
--
QC234800
VB518300
EB620020
AA820860
AA820850
ET800180
QC457300
20454100
QC163800
QA197100
QC007000
QC371100
20454100
--
QA262600
--
--
--
QC335200
AX817690
AX817910
AX814050
AX817920
EX803790
RANK
RGX 121S
4
CIRCUIT DIAGRAM
WIRING
FRONT PICKUP
CENTER PICKUP
REAR PICKUP PICKUP SWITCH
(2pole 5P Lever Switch)
MASTER
TONE
05A 250Kohm
MASTER
VOLUME
15A 500Kohm OUTPUT
FRONT PICKUP
FRONT & REAR PICKUPS
CENTER PICKUP REAR PICKUP
to spring plate
BL
BL
RE
RE
RE
MASTER VOLUME
15A 500Kohm
MASTER TONE
05A 250Kohm OUTPUT JACK
PICKUP SWITCH
(2pole 5position)
Start (E)
End
Start (S)
End
Signal(WH)
Ground
M2
M1
CENTER PICKUP
Signal(WH)
End
Start Ground
GP21-04
RGX 121S
5
WARNING : CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (Where
applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and possibly
other entities) to cause cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON
WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes
to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling
food.
SPECIFICATIONS
STANDARD SPECIFICATIONS
Scale Length..............................648mm
Body-Neck Construction .........Bolt On
Length........................................ 975.5mm
Width ......................................... 315.8mm
Net Weight ................................ 3.4kg
COLOR
Body
SBL........................................... Satin Black
SLB........................................... Sheiby Blue
MRB .........................................Mist Raspberry
MPP ......................................... Mist Purple
Neck
SBL........................................... Satin Black
BODY
Material...................................... Alder
Body Depth ...............................44mm
FINGERBOARD
Material...................................... Rose
Fingerboard Width................... 0-F 41 mm, 12-F 51.4 mm
No. of Frets................................ 22
NECK
Material...................................... Maple
Neck Thickness ........................ 1-F 19.0 mm, 12-F 21.7 mm
PARTS
Hardware ................................... Black
Nut.............................................. Urea
Bridge ........................................YS-11: Black
Strings........................................ Super Light: XL-120
CONTROLS
Volume .......................................15A 500KΩ x 1
Tone ........................................... 05A 250KΩ x 1
Pickup Switch............................ 2pole 5P Lever Switch
PICKUPS
Front/Rear ................................ Open Humbucking
Center ........................................ Single Coil
Magnet
Front/Center/Rear .................. Ferrite
