MUSIC PRODUCTION SYNTHESIZER
Integrated Sampling Sequencer / Real-Time External Control Surface / Modular Synthesis Plug-in System
DATA L IST
DATEN-LISTE
LISTE DE DONNÉES
Table of Contents
Voice List .......................................... 2
Drum Voice List................................ 7
Drum Voice Name List ................ 7
Drum Kit Assign List ................... 8
Wave List......................................... 20
Performance List ........................... 22
Effect Type List.............................. 23
Effect Parameter List.................... 25
Effect Data Assign Table .............. 35
Control List..................................... 39
Arpeggio Type List......................... 40
Preset Phrase List..........................
4
1
About MIDI ...................................... 42
MIDI Data Format........................... 42
MIDI Data Table.............................. 46
MIDI Implementation Chart ..........
6
1
2
Voice List
PRE1 (MSB 63, LSB 0)
Number Voice Name Category Sub Category
1 A01 PowerGrand Ap A PIANO
2 A02 Jazz Grand Ap A PIANO
3 A03 Dark Grand Ap A PIANO
4 A04 CP 80 Ap E GRAND
5 A05 CP80&EP Kb E.PIANO
6 A06 Yama EP's Kb OTHER
7 A07 BalladKeys Ap OTHER
8 A08 80s Layer Ap OTHER
9 A09 Piano&Strg Ap OTHER
10 A10 Piano Ooh Ap OTHER
11 A11 PianoBakup Ap OTHER
12 A12 Max Tine Kb E.PIANO
13 A13 Early Fusn Kb E.PIANO
14 A14 Vintage'74 Kb E.PIANO
15 A15 Sweetness Kb E.PIANO
16 A16 DynoStrait Kb E.PIANO
17 B01 ChorusHard Kb E.PIANO
18 B02 VintagCase Kb E.PIANO
19 B03 ChorusDyno Kb E.PIANO
20 B04 80th Boost Kb E.PIANO
21 B05 Contempo Kb E.PIANO
22 B06 Early 70's Kb E.PIANO
23 B07 Tonight Kb E.PIANO
24 B08 E.PianoPad Kb OTHER
25 B09 TX802 Kb E.PIANO
26 B10 ChorusBel Kb E.PIANO
27 B11 BellDX Kb E.PIANO
28 B12 Dark DX Kb E.PIANO
29 B13 GS Tines Kb E.PIANO
30 B14 Rich FM Kb E.PIANO
31 B15 FilteredDX Kb E.PIANO
32 B16 Ice Piano Kb OTHER
33 C01 WurliTrem Kb E.PIANO
34 C02 WurliAmped Kb E.PIANO
35 C03 TouchClavi Kb CLAVI
36 C04 SuperClavi Kb CLAVI
37 C05 StereoClav Kb CLAVI
38 C06 HollowClav Kb CLAVI
39 C07 Nu Phasing Kb CLAVI
40 C08 Digi Clavi Kb CLAVI
41 C09 PulseClavi Kb CLAVI
42 C10 Twinkle Cp BELL
43 C11 Stick Bell Cp BELL
44 C12 Bell Chiff Cp BELL
45 C13 FngrCymbl Cp BELL
46 C14 ChorusBell Cp BELL
47 C15 Tibetan Cp BELL
48 C16 EastBell Cp BELL
49 D01 Gamelan Cp BELL
50 D02 IceBells Cp BELL
51 D03 Digi Bell Cp BELL
52 D04 Marimbell Cp MALLET
53 D05 16+8+5&1/3 Or ELECTRIC
54 D06 Petit Or ELECTRIC
55 D07 Glassy Or ELECTRIC
56 D08 Jazzy Or ELECTRIC
57 D09 Slow Jam Or ELECTRIC
58 D10 Greasy Or ELECTRIC
59 D11 Swishie Or ELECTRIC
60 D12 Clean Or ELECTRIC
61 D13 Full/CVib Or ELECTRIC
62 D14 Mellow Or ELECTRIC
63 D15 Nu Shade Or ELECTRIC
64 D16 Cool Cat Or ELECTRIC
65 E01 Flutey Or ELECTRIC
66 E02 LeftManual Or ELECTRIC
67 E03 DrawContrl Or ELECTRIC
68 E04 Rocky Or ELECTRIC
69 E05 Expensive Or ELECTRIC
70 E06 Progressy Or ELECTRIC
71 E07 Crunchy Or ELECTRIC
72 E08 Early Bird Or ELECTRIC
73 E09 Jazz Split Or ELECTRIC
74 E10 GosplSplit Or ELECTRIC
75 E11 Tradi Or ELECTRIC
76 E12 Sunday Or PIPE
77 E13 BreathPipe Or PIPE
78 E14 Fluty Pipe Or PIPE
79 E15 Reedy Pipe Or PIPE
80 E16 OohPipes Pd CHOIR
81 F01 Flamenco Gt A.GUITAR
82 F02 Nylon Jam Gt A.GUITAR
83 F03 BriteSteel Gt A.GUITAR
84 F04 Strums Gt A.GUITAR
85 F05 Big Steel Gt A.GUITAR
86 F06 Folk Steel Gt A.GUITAR
87 F07 18 String Gt A.GUITAR
88 F18 HarpsiGtr Gt A.GUITAR
89 F09 HybridGtr Gt A.GUITAR
90 F10 JazzGTmelo Gt E.GUITAR
91 F11 Velo Jazz Gt E.GUITAR
92 F12 FM Jazz Gt E.GUITAR
93 F13 For Funk Gt E.GUITAR
94 F14 Spanky Gt E.GUITAR
95 F15 Funkiest Gt E.GUITAR
96 F16 Vin Strum Gt E.GUITAR
97 G01 1CoilChors Gt E.GUITAR
98 G02 CleanChors Gt E.GUITAR
99 G03 ChorusPlus Gt E.GUITAR
100 G04 SmoothChor Gt E.GUITAR
101 G05 TexBoogie Gt E.GUITAR
102 G06 Rockabilly Gt E.GUITAR
103 G07 65 Combo Gt E.GUITAR
104 G08 VinTremolo Gt E.GUITAR
105 G09 Crunchoid Gt E.GUITAR
106 G10 DynamicAmp Gt E.GUITAR
107 G11 Feedback Gt E.GUITAR
108 G12 VOODOOMAN Gt E.GUITAR
109 G13 BlueLead Gt E.GUITAR
110 G14 MeloRckLd Gt E.GUITAR
111 G15 MetalMute Gt E.GUITAR
112 G16 OverTheTop Gt E.GUITAR
113 H01 RoundWound Ba E.BASS
114 H02 FingerMan Ba E.BASS
115 H03 PrecRW Ba E.BASS
116 H04 PrecFW Ba E.BASS
117 H05 HybridBass Ba E.BASS
118 H06 Stand Up Ba A.BASS
119 H07 Fretless Ba E.BASS
120 H08 Slap&Fx Ba E.BASS
121 H09 BriteSlap Ba E.BASS
122 H10 Velo Bass Ba E.BASS
123 H11 Bs+Cym+Vb Co SPLIT
124 H12 Boogie on Ba SYNTH
125 H13 MiniDetune Ba SYNTH
126 H14 Long Spit Ba SYNTH
127 H15 Tack Bass Ba SYNTH
128 H16 Fat Octave Ba SYNTH
Number Voice Name Category Sub Category
3
PRE2 (MSB 63, LSB 1)
Number Voice Name Category Sub Category
1 A01 Violin St SOLO
2 A02 Viola St SOLO
3 A03 Cello St SOLO
4 A04 SoloSpicat St SOLO
5 A05 2 Solos St ENSEMBLE
6 A06 Cello Duet St ENSEMBLE
7 A07 Trio St ENSEMBLE
8 A08 Chamber St ENSEMBLE
9 A09 Small Ens St ENSEMBLE
10 A10 Medium Ens St ENSEMBLE
11 A11 Ens Mix St ENSEMBLE
12 A12 Ensemble St ENSEMBLE
13 A13 Hard Ens St ENSEMBLE
14 A14 Background St ENSEMBLE
15 A15 BigSymphny St ENSEMBLE
16 A16 Str/Horns Br SECTION
17 B01 Stringy St SYNTH
18 B02 Polystring St SYNTH
19 B03 JP Strings St SYNTH
20 B04 MournStrgs St SYNTH
21 B05 The Pizz St ENSEMBLE
22 B06 Fanfare Br SECTION
23 B07 Hi Brass Br SECTION
24 B08 Fat Sect Br SECTION
25 B09 Sforzando Br SECTION
26 B10 Symphony Br SECTION
27 B11 Big Band Br SECTION
28 B12 Big Band 2 Br SECTION
29 B13 SaxBigBand Br SECTION
30 B14 MedmBrass Br SECTION
31 B15 Soft Brass Br SECTION
32 B16 SoftVeloBr Br SECTION
33 C01 TrpRomantc Br SOLO
34 C02 Phase Mute Br SOLO
35 C03 Legend Br SOLO
36 C04 Trombone Br SOLO
37 C05 Flugelleaz Br SOLO
38 C06 F.Horn Ens Br SECTION
39 C07 SlowAttack Br SECTION
40 C08 Strng/Bras Br SECTION
41 C09 Movie Ens Br SECTION
42 C10 Powered Br SYNTH
43 C11 ObStuff Br SYNTH
44 C12 Prophy Br SYNTH
45 C13 AnalogBras Br SYNTH
46 C14 After 1984 Br SYNTH
47 C15 Soprano Rp SAX/REED
48 C16 Alto Vib Rp SAX/REED
49 D01 SaxEnsembl Rp SAX/REED
50 D02 Tenor Sax Rp SAX/REED
51 D03 Tenor Soft Rp SAX/REED
52 D04 The Winds Rp OTHER
53 D05 WindOrch St ENSEMBLE
54 D06 SweetFlute Rp PIPE
55 D07 PanBottle Rp PIPE
56 D08 AmpHarpMW Rp OTHER
57 D09 SmoothSaw Ld SOFT
58 D10 Lucky Ld SOFT
59 D11 Tri Solo Ld SOFT
60 D12 Syntrump Ld SOFT
61 D13 PWM Lead Ld SOFT
62 D14 Clicky Saw Ld SOFT
63 D15 Mini Pulse Ld SOFT
64 D16 Sync Lead Ld HARD
65 E01 Altair Pd SOFT
66 E02 Analog Pd SOFT
67 E03 Sweetland Pd BRIGHT
68 E04 WarmSweepy Pd BRIGHT
69 E05 SinePad Pd SOFT
70 E06 Square Pd SOFT
71 E07 VoxPad Pd CHOIR
72 E08 Pure Syn Pd BRIGHT
73 E09 MovingPad Pd BRIGHT
74 E10 SimpleSaws Pd SOFT
75 E11 X-Shower Pd SOFT
76 E12 PWM Pad Pd SOFT
77 E13 Bell Choir Pd BRIGHT
78 E14 ObSoft Pd SOFT
79 E15 MellowAnlg Pd SOFT
80 E16 Glasschoir Pd BRIGHT
81 F01 PeaceVox Pd CHOIR
82 F02 StackChoir Pd CHOIR
83 F03 Bronx Pd CHOIR
84 F04 IceChoir Pd CHOIR
85 F05 Fast Oohs Pd CHOIR
86 F06 Ooze & OZ Pd CHOIR
87 F07 NeoCrystal Pd BRIGHT
88 F18 Pop Synth Pd BRIGHT
89 F09 Fantasy Pd SOFT
90 F10 Heavenly Pd BRIGHT
91 F11 Retro Pd BRIGHT
92 F12 Airy Nylon Pd SOFT
93 F13 Antares Pd BRIGHT
94 F14 Pan Sphere Pd SOFT
95 F15 Tamburax Pd BRIGHT
96 F16 IndianFlai Pd BRIGHT
97 G01 SAKURA Me MOTION
98 G02 RisingHigh Me MOTION
99 G03 Champ Me MOTION
100 G04 Gladiator Me MOTION
101 G05 Hades Me MOTION
102 G06 Glacy Me MOTION
103 G07 Forest Me MOTION
104 G08 MirrorRing Me MOTION
105 G09 Poly Sc HARD
106 G10 AnaTonk Sc SOFT
107 G11 Jaipur Gt PLUCK
108 G12 Dulcitar Gt PLUCK
109 G13 Cimbalon Cp PERCUSSION
110 G14 EthncFlute Rp PIPE
111 G15 Hichiriki Rp SAX/REED
112 G16 Ryuteki Rp PIPE
113 H01 Gagaku Rp PIPE
114 H02 Kokyu St SOLO
115 H03 Digidoo Rp PIPE
116 H04 Bali Dr PERCUSSION
117 H05 Indo Gt PLUCK
118 H06 Trip East Dr PERCUSSION
119 H07 Tabla Dr PERCUSSION
120 H08 Djembe Dr PERCUSSION
121 H09 Djerimbe Cp PERCUSSION
122 H10 Udu Dr PERCUSSION
123 H11 Tribal Dr PERCUSSION
124 H12 Log&Drum Cp PERCUSSION
125 H13 Afro Dr PERCUSSION
126 H14 Japanesque Co SEQ
127 H15 EthnoShock Me HIT
128 H16 Ethnology Dr PERCUSSION
Number Voice Name Category Sub Category
4
PRE3 (MSB 63, LSB 2)
Number Voice Name Category Sub Category
1 A01 Wide Comp Ap A PIANO
2 A02 78rpmPiano Ap A PIANO
3 A03 Bristol Ap A PIANO
4 A04 Mono Comp Ap A PIANO
5 A05 Dance Ap A PIANO
6 A06 Houze Ap A PIANO
7 A07 Glass EP Kb E.PIANO
8 A08 VintSwitch Kb E.PIANO
9 A09 Early Case Kb E.PIANO
10 A10 RdsScape Kb E.PIANO
11 A11 RichEcho Ap A PIANO
12 A12 StringyPno Kb OTHER
13 A13 Champagne Or OTHER
14 A14 Moet Or OTHER
15 A15 Compact Or ELECTRIC
16 A16 1967 Keys Or ELECTRIC
17 B01 YD-45C Or ELECTRIC
18 B02 Gnarly Ba E.BASS
19 B03 Modular Ba SYNTH
20 B04 Dark Jack Ba SYNTH
21 B05 OneVoice Ba SYNTH
22 B06 Dry Syn Ba SYNTH
23 B07 PlasticBas Ba SYNTH
24 B08 Bassline Ba SYNTH
25 B09 RubbaRap Ba SYNTH
26 B10 Juicy Ba SYNTH
27 B11 Dark Ba SYNTH
28 B12 UniBass Ba SYNTH
29 B13 Flyer Ba SYNTH
30 B14 QuackBass Ba SYNTH
31 B15 Moonbass Ba SYNTH
32 B16 ClassicSub Ba SYNTH
33 C01 DX100 Ba SYNTH
34 C02 Lately Ba SYNTH
35 C03 FMBass Ba SYNTH
36 C04 Oct String St SYNTH
37 C05 3 Octave St SYNTH
38 C06 TapeStrngs St SYNTH
39 C07 VP Strings St SYNTH
40 C08 BriteTeeth Br SYNTH
41 C09 XDance Br SYNTH
42 C10 Timeless Br SYNTH
43 C11 FatSynth Br SYNTH
44 C12 Big Syn Br SYNTH
45 C13 Bluesharp Rp OTHER
46 C14 Sync Ld HARD
47 C15 Atk Reso Ld SOFT
48 C16 Singleline Ld SOFT
49 D01 Free LFO Ld HARD
50 D02 Soft Lead Ld SOFT
51 D03 PulseWound Ld HARD
52 D04 Big Drone Ld HARD
53 D05 Big Tune Ld HARD
54 D06 PowerWheel Ld HARD
55 D07 Flangefilt Ld HARD
56 D08 G-Funk Ld SOFT
57 D09 Maria AT Ld SOFT
58 D10 InThePast Ld HARD
59 D11 FatSawPad Pd BRIGHT
60 D12 Wide Sweep Pd BRIGHT
61 D13 Sunbeams Pd SOFT
62 D14 BPFx Pd BRIGHT
63 D15 FrozenPad Pd BRIGHT
64 D16 MICHINOKU Pd SOFT
65 E01 Esmeralda Pd SOFT
66 E02 Romance Pd SOFT
67 E03 Circle Pd BRIGHT
68 E04 Dreamspher Pd BRIGHT
69 E05 Silverlake Pd SOFT
70 E06 Shadow Pd BRIGHT
71 E07 Platinum Pd BRIGHT
72 E08 Gently Pd SOFT
73 E09 Warming Pd SOFT
74 E10 PW-EMMY Pd SOFT
75 E11 X-fade Pad Pd SOFT
76 E12 Zosma Pd BRIGHT
77 E13 NoizRezz Pd BRIGHT
78 E14 Mira Pd BRIGHT
79 E15 MultiPulse Pd SOFT
80 E16 VoxWaves Pd CHOIR
81 F01 LazySweep Pd CHOIR
82 F02 Doomed Pd CHOIR
83 F03 PerkaVox Sc SOFT
84 F04 Punchy Sc HARD
85 F05 Eyeliner Sc HARD
86 F06 Quieck Me MOTION
87 F07 Aladdin Me MOTION
88 F18 QuadSwell Me MOTION
89 F09 Lilley Pad Me MOTION
90 F10 Didje Baz Me MOTION
91 F11 RING PAD Me MOTION
92 F12 Chaser 1 Me MOTION
93 F13 Chaser 2 Me MOTION
94 F14 Spacebreat Me MOTION
95 F15 Long HiPa Me MOTION
96 F16 Action Y Me MOTION
97 G01 Trancelan Me HIT
98 G02 Eternal Me MOTION
99 G03 VirtualSyn Me MOTION
100 G04 Interlude Me MOTION
101 G05 Flying Me MOTION
102 G06 TheSlayer Me MOTION
103 G07 White Rabb Me MOTION
104 G08 Siam Me MOTION
105 G09 Ududu Co SEQ
106 G10 Particle Co SEQ
107 G11 Shaper Co SEQ
108 G12 VintageArp Co SEQ
109 G13 Aah Dance Co SEQ
110 G14 Joker Co SEQ
111 G15 Holiday Co SEQ
112 G16 Android Co SEQ
113 H01 Spacious Co SEQ
114 H02 VoiceCuica Co SEQ
115 H03 Pop Arp Co SEQ
116 H04 Ping Pong Co SEQ
117 H05 Amoeba Se SYNTH
118 H06 Landing Se SYNTH
119 H07 I was born Se SYNTH
120 H08 PsychoGtr Se SYNTH
121 H09 NoGravity Se SYNTH
122 H10 Pulser Se SYNTH
123 H11 Racer Se SYNTH
124 H12 Storm Se NATURAL
125 H13 Oscillatin Se SYNTH
126 H14 FamlyFeud Se NATURAL
127 H15 WatrForest Se NATURAL
128 H16 Spacecraft Se SYNTH
Number Voice Name Category Sub Category
5
USER (MSB 63, LSB 8)
Number Voice Name Category Sub Category
1 A01 M25 M.W. Co SEQ
2 A02 Softstars Pd CHOIR
3 A03 Fast PWM Ba SYNTH
4 A04 Terminator Ba E.BASS
5 A05 Soft Tar Me MOTION
6 A06 Sorted Co SEQ
7 A07 Trendy Wah Ba SYNTH
8 A08 Feed S&H Se SYNTH
9 A09 Didge Me MOTION
10 A10 Old House Ba SYNTH
11 A11 HPF Dance Ld HARD
12 A12 Like Bees Me MOTION
13 A13 Exodus Ba SYNTH
14 A14 S/H Gruv Me MOTION
15 A15 Funk It!! Gt E.GUITAR
16 A16 Opening Co SEQ
17 B01 DigDag Co SEQ
18 B02 Dark Light Pd SOFT
19 B03 Boom Bass Ba SYNTH
20 B04 Dirtbox Se SYNTH
21 B05 Shandala Pd CHOIR
22 B06 Titan Co SEQ
23 B07 Puls Step Ba SYNTH
24 B08 Racket Co SEQ
25 B09 Big Lead Ld HARD
26 B10 Blush Ba SYNTH
27 B11 Squeaky Ld HARD
28 B12 Duck Worm Se SYNTH
29 B13 Jon Ba SYNTH
30 B14 Weird scar Co SEQ
31 B15 Auto Wah Gt E.GUITAR
32 B16 MINIMAL Co SEQ
33 C01 MGul Co SEQ
34 C02 BrokenStar Pd SOFT
35 C03 Smooth Ba SYNTH
36 C04 Sawmill Se SYNTH
37 C05 Cavern Me MOTION
38 C06 Supersnap Co SEQ
39 C07 Fuzzline Ba SYNTH
40 C08 Foreplay Ld SOFT
41 C09 Brooklyn Or ELECTRIC
42 C10 Brief Ba SYNTH
43 C11 Dist-MW Ld HARD
44 C12 Hit&Down Me HIT
45 C13 Froglegs Ba SYNTH
46 C14 Sand Me MOTION
47 C15 R&B Steel Gt A.GUITAR
48 C16 Rabbit Co SEQ
49 D01 ElecWorld Co SEQ
50 D02 Sickday Me MOTION
51 D03 LoSnake Ba SYNTH
52 D04 Boomeran Se SYNTH
53 D05 O+Ca+Si+Na Me MOTION
54 D06 Space Run Co SEQ
55 D07 Additive Ba SYNTH
56 D08 Rap Lead 1 Ld SOFT
57 D09 Nordic Me MOTION
58 D10 Hip Aco Ba A.BASS
59 D11 Mr. Cool Ld HARD
60 D12 Orch Hits Me HIT
61 D13 Damp Cat Ba SYNTH
62 D14 FISHINREEL Me MOTION
63 D15 Melo Trmlo Gt E.GUITAR
64 D16 Fois Gras Sc HARD
65 E01 CheapEP Kb E.PIANO
66 E02 AnaMarcato St SYNTH
67 E03 G Bass Ba SYNTH
68 E04 Dolphin Se SYNTH
69 E05 Evolve Me MOTION
70 E06 ARRIVAL Me MOTION
71 E07 Wazzo Ba SYNTH
72 E08 Rap Lead 2 Ld HARD
73 E09 Richard Me MOTION
74 E10 Hip Pick Ba E.BASS
75 E11 Early Lead Ld SOFT
76 E12 BDScrtch Se SYNTH
77 E13 Dukes Ba SYNTH
78 E14 Mayday MW Ld HARD
79 E15 CoolWAH Gt E.GUITAR
80 E16 Mascara Sc HARD
81 F01 HipWahEP Kb E.PIANO
82 F02 ChorusComp Br SYNTH
83 F03 Compton Ba SYNTH
84 F04 Red Dots Se SYNTH
85 F05 Fragile Pd SOFT
86 F06 SpookyVibe Me HIT
87 F07 Gangsta Ba SYNTH
88 F18 Rap Lead 3 Ld HARD
89 F09 81Z Comp Sc HARD
90 F10 DarkBass Ba SYNTH
91 F11 HiPaWheel Ld HARD
92 F12 Rap Scream Se SYNTH
93 F13 InyerBass Ba SYNTH
94 F14 Pierced Ld HARD
95 F15 Hip Mute Gt E.GUITAR
96 F16 Hip Pizz St ENSEMBLE
97 G01 R&B EP+DX Kb E.PIANO
98 G02 Kustom Br SYNTH
99 G03 PortaBass Ba SYNTH
100 G04 Sirens Se NATURAL
101 G05 Silver Me MOTION
102 G06 Zanaks Me MOTION
103 G07 2001 Sub Ba SYNTH
104 G08 Sine Lead Ld SOFT
105 G09 UK Oam Ba SYNTH
106 G10 Fooger Ba SYNTH
107 G11 D-tune Ld HARD
108 G12 Rap Toyz Se SYNTH
109 G13 Mucus M Ba SYNTH
110 G14 Future Z Ld HARD
111 G15 FM Guitar Gt PLUCK
112 G16 Trancedot Me MOTION
113 H01 Dead?Alive Me MOTION
114 H02 SlowSuckr St SYNTH
115 H03 Clickk Ba SYNTH
116 H04 KewBrick Se SYNTH
117 H05 Munchkins Pd CHOIR
118 H06 Ants Me MOTION
119 H07 Snoop Bass Ba SYNTH
120 H08 BabeMagnet Ld SOFT
121 H09 Jones Ba SYNTH
122 H10 100 dreams Se SYNTH
123 H11 FKitchen Ld HARD
124 H12 Rabino Co SEQ
125 H13 Teknophobe Ba SYNTH
126 H14 FizzWah Me MOTION
127 H15 Hip Voice Ld HARD
128 H16 Strobe Me MOTION
Number Voice Name Category Sub Category
6
GM (MSB 0, LSB 0)
Number Voice Name Category Sub Category
1 A01 NaturlGrnd Ap A PIANO
2 A02 Rock Brite Ap A PIANO
3 A03 CP 2001 Ap E GRAND
4 A04 Honkytonk Ap A PIANO
5 A05 E.Piano 1 Kb E.PIANO
6 A06 E.Piano 2 Kb E.PIANO
7 A07 Harpsicord Kb OTHER
8 A08 Brite Clav Kb CLAVI
9 A09 Celeste Cp MALLET
10 A10 Glocken Cp MALLET
11 A11 Music Box Cp PERCUSSION
12 A12 Vibes Cp MALLET
13 A13 Marimba Cp MALLET
14 A14 Xylophone Cp MALLET
15 A15 TublarBell Cp BELL
16 A16 Dulcimar Cp PERCUSSION
17 B01 Draw Organ Or ELECTRIC
18 B02 Perc Organ Or ELECTRIC
19 B03 Rock Organ Or ELECTRIC
20 B04 ChurchOrgn Or PIPE
21 B05 Reed Organ Or OTHER
22 B06 Accordion Kb OTHER
23 B07 Harmonica Rp OTHER
24 B08 TangoAccrd Kb OTHER
25 B09 Nylon Gt A.GUITAR
26 B10 Steel Gt A.GUITAR
27 B11 ModernJazz Gt E.GUITAR
28 B12 Clean Gt E.GUITAR
29 B13 Mute Gt E.GUITAR
30 B14 Overdrive Gt E.GUITAR
31 B15 Distortion Gt E.GUITAR
32 B16 Harmonics Gt E.GUITAR
33 C01 Accoustic Ba A.BASS
34 C02 FingerBass Ba E.BASS
35 C03 Pick Bass Ba E.BASS
36 C04 Fretless 2 Ba E.BASS
37 C05 SimpleSlap Ba E.BASS
38 C06 Velo Slap Ba E.BASS
39 C07 SynthBass1 Ba SYNTH
40 C08 SynthBass2 Ba SYNTH
41 C09 Violin 2 St SOLO
42 C10 Viola 2 St SOLO
43 C11 Cello 2 St SOLO
44 C12 Contrabass St SOLO
45 C13 TremoloStr St ENSEMBLE
46 C14 Pizz Gt PLUCK
47 C15 Harp Gt PLUCK
48 C16 Timpni+Cym Cp PERCUSSION
49 D01 StereoSt1 St ENSEMBLE
50 D02 StereoSt2 St ENSEMBLE
51 D03 Grand Saw St SYNTH
52 D04 SynStrings St SYNTH
53 D05 Aah Choir Pd CHOIR
54 D06 Ooh Choir Pd CHOIR
55 D07 Syn Voice Pd CHOIR
56 D08 Orch.Hit Me HIT
57 D09 Trumpet Br SOLO
58 D10 Trombone 2 Br SOLO
59 D11 Tuba Br SOLO
60 D12 MuteTrpt 2 Br SOLO
61 D13 F.Horns Br SECTION
62 D14 Brass Sect Br SECTION
63 D15 SynthBrass Br SYNTH
64 D16 Soft Brass Br SYNTH
65 E01 Soprano 2 Rp SAX/REED
66 E02 Alto Sax Rp SAX/REED
67 E03 TenorSax 2 Rp SAX/REED
68 E04 Bari Sax Rp SAX/REED
69 E05 Oboe Rp SAX/REED
70 E06 Eng.Horn Rp SAX/REED
71 E07 Bassoon Rp SAX/REED
72 E08 Clarinet Rp SAX/REED
73 E09 Piccolo Rp PIPE
74 E10 Flute Rp PIPE
75 E11 Recorder Rp PIPE
76 E12 Panflute Rp PIPE
77 E13 Bottle Rp PIPE
78 E14 Shakuhachi Rp PIPE
79 E15 Whistle Rp PIPE
80 E16 Ocarina Rp PIPE
81 F01 Square Ld Ld HARD
82 F02 Saw Ld Ld HARD
83 F03 Caliop Ld Ld SOFT
84 F04 Chiff Ld Ld HARD
85 F05 Charan Ld Ld HARD
86 F06 Voice Ld Ld SOFT
87 F07 Fifth Ld Ld HARD
88 F18 Bass&Ld Ld HARD
89 F09 New Age Pd BRIGHT
90 F10 Warm Pad Pd SOFT
91 F11 Poly Synth Pd BRIGHT
92 F12 Choir Pad Pd CHOIR
93 F13 BowedPad Pd SOFT
94 F14 Metal Pad Pd BRIGHT
95 F15 Halo Pad Pd BRIGHT
96 F16 Sweep Pad Pd BRIGHT
97 G01 Rain Pad Me MOTION
98 G02 SoundTrack Pd BRIGHT
99 G03 Crystal Cp BELL
100 G04 Atmosphere Pd SOFT
101 G05 Brightness Sc HARD
102 G06 Goblin Me MOTION
103 G07 Echoes Me MOTION
104 G08 Sci-Fi Pd BRIGHT
105 G09 Sitar Gt PLUCK
106 G10 Banjo Gt PLUCK
107 G11 Shamisen Gt PLUCK
108 G12 Koto Gt PLUCK
109 G13 Kalimba Cp PERCUSSION
110 G14 Bagpipe Rp SAX/REED
111 G15 Fiddle St SOLO
112 G16 Shanai Rp SAX/REED
113 H01 Tinkerbel Cp BELL
114 H02 Agogo Dr PERCUSSION
115 H03 Steeldrum Cp PERCUSSION
116 H04 Woodblock Dr PERCUSSION
117 H05 Taikodrum Dr PERCUSSION
118 H06 MelodicTom Dr DRUMS
119 H07 Synth Drum Dr DRUMS
120 H08 Rev Cymbal Se SYNTH
121 H09 Fret Noise Se NATURAL
122 H10 BreathNoiz Se NATURAL
123 H11 Seashore Se NATURAL
124 H12 Tweet Se NATURAL
125 H13 Telephone Se NATURAL
126 H14 Helicopter Se NATURAL
127 H15 Applause Se NATURAL
128 H16 Gunshot Se NATURAL
Number Voice Name Category Sub Category
7
Drum Voice List
Drum Voice Name List
Bank Select MSB 63, LSB 32
PRE No. Voice Name
1 PoweredStd
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 DryStandrd
3 RockSt1
4 RockSt2
5 RockMono1
6 Hip Hop1
7 Hip Hop2
8 HipStick1
9 T9HipKit1
10 R&B Kit1
11 R&B Kit2
12 AnalogT9
13 AnalogT8
14 Tekno Kit
15 House Kit1
16 House Kit2
17 Big Kit
18 Break Kit
19 Drum'nBass
20 Acid Kit
21 Jungle Kit
22 Electric
23 Human Kit
24 Hard Kit
25 DistrtdKit
26 AmbientKit
27 Jazz Kit
28 Hip Hop3
29 Hip Hop4
30 HipStick2
31 Garage
These original drum kits, programmed for the
MOTIF, feature a special non-standard order for
ease in playing.
32 ALL-ROUND
33 Rock Multi
34 Hip Multi
35 Percussion
These original kits feature a variety of
instruments and special sound effects, and are
grouped according to their type.
36 Latin Perc
37 Gtr/Bs Fx
38 Wacko Kit
39 Wood Bits
40 Metal Bits
41 Hands Kit
42 Scratches
43 AcstSnares
44 StSnares
45 AllKicks
46 DanceKicks
47 Snare & Fx
48 EasySnares
Bank Select MSB 63, LSB 40
USER No.
Voice Name
1 RockMono2
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 RockMono3
3 Hip Hop5
4 Hip Hop6
5 T9HipKit2
6 HipStick3
7 HipStick4
8 R&B Kit3
Bank Select MSB 127, LSB 0
GM Drum No. Voice Name
1 Stereo GM
8
Drum Kit Assign List
PRE 1 PoweredStd PRE 2 DryStandrd PRE 3 RockSt1 PRE 4 RockSt2 PRE 5 RockMono1
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 735 Clave C 0 735 Clave C 0 763 AnaClick C 0 763 AnaClick C 0 763 AnaClick
C#0 1057 SdBrMtSt C#0 1057 SdBrMtSt C#0 1057 SdBrMtSt C#0 1057 SdBrMtSt C#0 1058 SdBrMtL
D 0 1063 SdBrSwrSt D 0 1063 SdBrSwrSt D 0 1063 SdBrSwrSt D 0 1063 SdBrSwrSt D 0 1064 SdBrSwrL
D#0 1060 SdBrMt2St D#0 1060 SdBrMt2St D#0 1060 SdBrMt2St D#0 1060 SdBrMt2St D#0 1061 SdBrMt2L
E 0 1066 SdBSwrAtSt E 0 1066 SdBSwrAtSt E 0 1066 SdBSwrAtSt E 0 1066 SdBSwrAtSt E 0 1067 SdBrSwrAtL
F 0 1053 SnLvRolSt F 0 1053 SnLvRolSt F 0 1047 SdRkRolSt F 0 1047 SdRkRolSt F 0 1054 SnLvRolL
F#0 734 Castanet F#0 734 Castanet F#0 734 Castanet F#0 734 Castanet F#0 734 Castanet
G 0 866 SdNm1St G 0 866 SdNm1St G 0 992 SdRkOp1St G 0 1001 SdRkOp2St G 0 973 SdLdwL1-4
G#0 732 Stick G#0 732 Stick G#0 732 Stick G#0 732 Stick G#0 732 Stick
A 0 794 BdFkSonSt A 0 773 BdFkSt1-2 A 0 764 BdNmSt1-2 A 0 785 BdLoSt A 0 803 BdDry1
A#0 898 SdBsSt1-3 A#0 900 SdBsSt2-3 A#0 998 SdRkRim1St A#0 1007 SdRkRim2St A#0 962 SdBh3R
B 0 785 BdLoSt B 0 782 BdHiSt B 0 782 BdHiSt B 0 766 BdNm2St B 0 772 BdNm2R
C 1 788 BdHSonSt C 1 764 BdNmSt1-2 C 1 797 BdRk1St C 1 800 BdRk2St C 1 810 BdRoom3
C#1 1042 SdClRmSt C#1 1042 SdClRmSt C#1 1026 SdRkStk1St C#1 1029 SdRkStk2St C#1 1045 SdClRim2
D 1 913 SdSonSt1-4 D 1 860 SdNmSt1-4 D 1 992 SdRkOp1St D 1 1001 SdRkOp2St D 1 929 SdSon3L
D#1 752 ClapT9 D#1 752 ClapT9 D#1 742 HandClapSt D#1 742 HandClapSt D#1 743 HandClapL
E 1 963 SdLdwSt1-4 E 1 899 SdBsSt1-2 E 1 995 SdRkMte1St E 1 1004 SdRkMte2St E 1 932 SdSon4R
F 1 1227 TomFlSt F 1 1227 TomFlSt F 1 1236 TomRkLoSt F 1 1236 TomRkLoSt F 1 1228 TomFlL
F#1 1152 HHClFtSt F#1 1131 HHClSt1-4 F#1 1161 HHClRkStSw F#1 1173 HHClRk2St F#1 1175 HHClRk2R
G 1 1224 TomLoSt G 1 1224 TomLoSt G 1 1236 TomRkLoSt G 1 1236 TomRkLoSt G 1 1225 TomLoL
G#1 1155 HHHlf2St G#1 1146 HHPdlSt G#1 1170 HHPdRkStSw G#1 1181 HHHfOpRkSt G#1 1178 HHPdlRkR
A 1 1224 TomLoSt A 1 1224 TomLoSt A 1 1233 TomRkMdSt A 1 1233 TomRkMdSt A 1 1222 TomMdL
A#1 1158 HHOp2St A#1 1149 HHOpSt A#1 1179 HHOpRkStSw A#1 1180 HHOpRkSt A#1 1185 HHOpRkR
B 1 1221 TomMdSt B 1 1221 TomMdSt B 1 1233 TomRkMdSt B 1 1233 TomRkMdSt B 1 1222 TomMdL
C 2 1221 TomMdSt C 2 1221 TomMdSt C 2 1230 TomRkHiSt C 2 1230 TomRkHiSt C 2 1220 TomHiR
C#2 1253 CrashSt C#2 1253 CrashSt C#2 1253 CrashSt C#2 1253 CrashSt C#2 1254 CrashL
D 2 1218 TomHiSt D 2 1218 TomHiSt D 2 1230 TomRkHiSt D 2 1230 TomRkHiSt D 2 1220 TomHiR
D#2 1258 RideSt D#2 1258 RideSt D#2 1258 RideSt D#2 1258 RideSt D#2 1264 RideMono
E 2 1267 ChinaSt E 2 1267 ChinaSt E 2 1267 ChinaSt E 2 1267 ChinaSt E 2 1267 ChinaSt
F 2 1261 CupSt F 2 1261 CupSt F 2 1261 CupSt F 2 1261 CupSt F 2 1266 CupMono2
F#2 714 TambrnSw F#2 714 TambrnSw F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 714 TambrnSw
G 2 1271 SplashSt G 2 1271 SplashSt G 2 1271 SplashSt G 2 1271 SplashSt G 2 1273 SplashR
G#2 746 Cowbell2 G#2 746 Cowbell2 G#2 745 Cowbel1 G#2 745 Cowbel1 G#2 745 Cowbel1
A 2 1305 CrashRL A 2 1305 CrashRL A 2 1253 CrashSt A 2 1253 CrashSt A 2 1254 CrashL
A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap
B 2 1306 RideRL B 2 1306 RideRL B 2 1258 RideSt B 2 1258 RideSt B 2 1264 RideMono
C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2
C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 661 CongaOp D#3 661 CongaOp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 669 TumbaOp E 3 669 TumbaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3
F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3
G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi
G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo
A 3 698 Cabasa1-2 A 3 698 Cabasa1-2 A 3 698 Cabasa1-2 A 3 698 Cabasa1-2 A 3 698 Cabasa1-2
A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle
C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle
C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort
D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong
D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 735 Clave
E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock
F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock
F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi
G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2
B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree
C#5 940 SdBlL1-3 C#5 940 SdBlL1-3 C#5 1010 SdRkFlmSt C#5 1010 SdRkFlmSt C#5 1044 SdClRmR
D 5 963 SdLdwSt1-4 D 5 963 SdLdwSt1-4 D 5 1001 SdRkOp2St D 5 992 SdRkOp1St D 5 1024 SdHeavy
D#5 956 SdBhR1-3 D#5 956 SdBhR1-3 D#5 1007 SdRkRim2St D#5 998 SdRkRim1St D#5 1000 SdRkRim1R
E 5 983 SdHipSt1-2 E 5 983 SdHipSt1-2 E 5 1004 SdRkMte2St E 5 995 SdRkMte1St E 5 1021 SdLdwHMono
F 5 785 BdLoSt F 5 785 BdLoSt F 5 774 BdFk1St F 5 797 BdRk1St F 5 801 BdRk2L
F#5 1021 SdLdwHMono F#5 1021 SdLdwHMono F#5 1050 SdRkRolDSt F#5 1050 SdRkRolDSt F#5 987 SdHipR1-2
G 5 834 BdR&B1 G 5 834 BdR&B1 G 5 788 BdHSonSt G 5 775 BdFk2St G 5 841 BdBreakHrd
G#5 1024 SdHeavy G#5 1024 SdHeavy G#5 963 SdLdwSt1-4 G#5 963 SdLdwSt1-4 G#5 982 SdLdw4R
A 5 808 BdRoom1 A 5 808 BdRoom1 A 5 794 BdFkSonSt A 5 782 BdHiSt A 5 783 BdHiL
A#5 1018 SdAmb A#5 1018 SdAmb A#5 921 SdSon3St A#5 922 SdSon4St A#5 956 SdBhR1-3
B 5 794 BdFkSonSt B 5 794 BdFkSonSt B 5 777 BdFkR1-2 B 5 791 BdLSonSt B 5 780 BdFkHL
C 6 809 BdRoom2 C 6 809 BdRoom2 C 6 788 BdHSonSt C 6 797 BdRk1St C 6 795 BdFkSonL
9
PRE 6 Hip Hop1 PRE 7 Hip Hop2 PRE 8 HipStick1 PRE 9 T9HipKit1 PRE 10 R&B Kit1
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 1033 SdHpStk2 C 0 822 BdT8-3 C 0 1106 SdHipRm4 C 0 762 ClaveT8 C 0 819 BdT9Hd3
C#0 554 VoxHitRev C#0 1081 SdT8Rim C#0 552 HiQ1 C#0 1073 SdT9-5 C#0 1084 SdAnCR
D 0 560 TurnTable D 0 1099 SdHip1 D 0 560 TurnTable D 0 560 TurnTable D 0 1083 SdAnSmRim
D#0 537 HitBrass D#0 752 ClapT9 D#0 536 HitOrch1 D#0 532 Quiek D#0 1117 SdClpAna
E 0 583 ScratchSdR E 0 1124 SdSyn E 0 581 ScratchBdR E 0 592 ScratchCb3 E 0 1074 SdT9Gate
F 0 1055 SnLvRolR F 0 1055 SnLvRolR F 0 1055 SnLvRolR F 0 1054 SnLvRolL F 0 1056 SdRollMono
F#0 762 ClaveT8 F#0 1035 SdHpStk4 F#0 763 AnaClick F#0 763 AnaClick F#0 1126 SdTimber
G 0 991 SdHip2R G 0 368 DjembeEd G 0 1105 SdHipRm3 G 0 1074 SdT9Gate G 0 1123 SdFMRim
G#0 1039 SdHpStk6R G#0 1037 SdHpStk6St G#0 1085 SdAnCRRim G#0 1130 SdRimSE G#0 1091 SdJnglFx
A 0 836 BdHipDp A 0 820 BdT8-1 A 0 836 BdHipDp A 0 815 BdT9-3 A 0 806 BdVar1
A#0 1121 SdDodgL A#0 1097 SdR&B1Rm A#0 1083 SdAnSmRim A#0 1071 SdT9-3 A#0 1103 SdHipRm1
B 0 822 BdT8-3 B 0 840 BdBreakHvy B 0 822 BdT8-3 B 0 814 BdT9-2 B 0 821 BdT8-2
C 1 821 BdT8-2 C 1 836 BdHipDp C 1 821 BdT8-2 C 1 813 BdT9-1 C 1 851 BdZapMid
C#1 1033 SdHpStk2 C#1 1079 SdT8-4 C#1 1081 SdT8Rim C#1 1075 SdT9Rim C#1 1081 SdT8Rim
D 1 1117 SdClpAna D 1 1101 SdHip3 D 1 1032 SdHpStk1 D 1 1073 SdT9-5 D 1 1104 SdHipRm2
D#1 744 HandClapR D#1 742 HandClapSt D#1 744 HandClapR D#1 752 ClapT9 D#1 742 HandClapSt
E 1 1098 SdR&B2 E 1 1129 SdLofi E 1 1033 SdHpStk2 E 1 1072 SdT9-4 E 1 1084 SdAnCR
F 1 1247 TomT8 F 1 1229 TomFlR F 1 1247 TomT8 F 1 1246 TomT9Lo F 1 822 BdT8-3
F#1 1193 HHClT8-1 F#1 1211 HHClLoFi F#1 1193 HHClT8-1 F#1 1191 HHClT9 F#1 1195 HHClT8-2
G 1 1247 TomT8 G 1 1225 TomLoL G 1 1247 TomT8 G 1 1246 TomT9Lo G 1 822 BdT8-3
G#1 1194 HHOpT8-1 G#1 1200 HHClBreak G#1 1194 HHOpT8-1 G#1 1192 HHOpT9 G#1 1198 HHClAnCR
A 1 1247 TomT8 A 1 1225 TomLoL A 1 1247 TomT8 A 1 1246 TomT9Lo A 1 822 BdT8-3
A#1 1194 HHOpT8-1 A#1 1212 HHOpLoFi A#1 1194 HHOpT8-1 A#1 1192 HHOpT9 A#1 1196 HHOpT8-2
B 1 1247 TomT8 B 1 1225 TomLoL B 1 1247 TomT8 B 1 1246 TomT9Lo B 1 822 BdT8-3
C 2 1247 TomT8 C 2 1219 TomHiL C 2 1247 TomT8 C 2 1245 TomT9Hi C 2 822 BdT8-3
C#2 1257 Crash2 C#2 1256 Crash C#2 1257 Crash2 C#2 1274 CrashT9 C#2 1256 Crash
D 2 1247 TomT8 D 2 1219 TomHiL D 2 1247 TomT8 D 2 1245 TomT9Hi D 2 822 BdT8-3
D#2 1260 RideR D#2 1277 RideT9 D#2 1260 RideR D#2 1277 RideT9 D#2 1277 RideT9
E 2 1275 CrashT8 E 2 1270 China E 2 1275 CrashT8 E 2 1274 CrashT9 E 2 1270 China
F 2 1277 RideT9 F 2 1265 CupMono F 2 1277 RideT9 F 2 1277 RideT9 F 2 1265 CupMono
F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 715 TambrnHit
G 2 1273 SplashR G 2 1256 Crash G 2 1273 SplashR G 2 1274 CrashT9 G 2 1256 Crash
G#2 748 MamboBdy G#2 756 CowBelRX11 G#2 748 MamboBdy G#2 757 CowBelAnCR G#2 745 Cowbel1
A 2 1274 CrashT9 A 2 1255 CrashR A 2 1274 CrashT9 A 2 1274 CrashT9 A 2 1274 CrashT9
A#2 737 Vibraslap A#2 755 CowBelT8 A#2 737 Vibraslap A#2 737 Vibraslap A#2 755 CowBelT8
B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9 B 2 1258 RideSt
C 3 675 BongoHi1-2 C 3 676 BongoHi1 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 676 BongoHi1
C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 683 TmbaleH1-3 F 3 524 RadioNz F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 552 HiQ1
F#3 687 TmbaleL1-3 F#3 524 RadioNz F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 552 HiQ1
G 3 725 AgogoLo G 3 725 AgogoLo G 3 724 AgogoHi G 3 724 AgogoHi G 3 725 AgogoLo
G#3 724 AgogoHi G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo
A 3 707 ShakerHip1 A 3 699 Cabasa1 A 3 707 ShakerHip1 A 3 698 Cabasa1-2 A 3 758 AnaShaker
A#3 761 MarcsT8 A#3 761 MarcsT8 A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 738 Whistle B 3 557 FxGun2 B 3 738 Whistle B 3 738 Whistle B 3 545 VoxDrum
C 4 738 Whistle C 4 558 FxGun1 C 4 738 Whistle C 4 738 Whistle C 4 545 VoxDrum
C#4 728 GuiroShort C#4 587 ScratchSpn C#4 728 GuiroShort C#4 728 GuiroShort C#4 552 HiQ1
D 4 727 GuiroLong D 4 586 ScratchStp D 4 727 GuiroLong D 4 727 GuiroLong D 4 553 HiQ2
D#4 762 ClaveT8 D#4 762 ClaveT8 D#4 735 Clave D#4 735 Clave D#4 762 ClaveT8
E 4 736 WoodBlock E 4 562 DoorSqk E 4 736 WoodBlock E 4 736 WoodBlock E 4 552 HiQ1
F 4 736 WoodBlock F 4 553 HiQ2 F 4 736 WoodBlock F 4 736 WoodBlock F 4 587 ScratchSpn
F#4 674 CuicaHi F#4 580 ScratchBdF F#4 674 CuicaHi F#4 674 CuicaHi F#4 577 ScratchHiR
G 4 673 CuicaLo G 4 581 ScratchBdR G 4 673 CuicaLo G 4 673 CuicaLo G 4 576 ScratchHiF
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 758 AnaShaker A#4 758 AnaShaker A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 706 Shaker2
B 4 750 SleighBel B 4 715 TambrnHit B 4 750 SleighBel B 4 750 SleighBel B 4 715 TambrnHit
C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree
C#5 1041 SdHipStk8 C#5 1087 SdHuman2 C#5 1082 SdAnSm C#5 1075 SdT9Rim C#5 1112 SdBreakRol
D 5 1090 SdJngl3 D 5 1112 SdBreakRol D 5 1046 SdClRim3 D 5 1074 SdT9Gate D 5 520 Mother
D#5 744 HandClapR D#5 540 StabHard D#5 763 AnaClick D#5 742 HandClapSt D#5 502 VoxBell
E 5 1107 SdHipRm5 E 5 1088 SdJngl1 E 5 1045 SdClRim2 E 5 1073 SdT9-5 E 5 1096 SdR&B1
F 5 573 Scratch H F 5 797 BdRk1St F 5 573 Scratch H F 5 573 Scratch H F 5 512 VoxAlk
F#5 574 Scratch L F#5 575 ScratchDwn F#5 574 Scratch L F#5 574 Scratch L F#5 377 Udo Hi
G 5 575 ScratchDwn G 5 367 Wataiko G 5 575 ScratchDwn G 5 575 ScratchDwn G 5 507 TranCho
G#5 577 ScratchHiR G#5 511 HH Hit G#5 577 ScratchHiR G#5 576 ScratchHiF G#5 519 Swarm
A 5 580 ScratchBdF A 5 541 StabOrgan2 A 5 580 ScratchBdF A 5 577 ScratchHiR A 5 805 BdPop
A#5 590 ScratchCmb A#5 534 Sonar1 A#5 590 ScratchCmb A#5 578 ScratchLoF A#5 1097 SdR&B1Rm
B 5 585 ScratchVoR B 5 560 TurnTable B 5 585 ScratchVoR B 5 579 ScratchLoR B 5 835 BdR&B2
C 6 839 BdBreak2 C 6 561 Police C 6 830 BdJngl2 C 6 817 BdT9Hd1 C 6 1256 Crash
10
PRE 11 R&B Kit2 PRE 12 AnalogT9 PRE 13 AnalogT8 PRE 14 Tekno Kit PRE 15 House Kit1
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 808 BdRoom1 C 0 814 BdT9-2 C 0 820 BdT8-1 C 0 859 BdSlimy C 0 816 BdT9-4
C#0 763 AnaClick C#0 1084 SdAnCR C#0 1084 SdAnCR C#0 1075 SdT9Rim C#0 1081 SdT8Rim
D 0 614 PlayFxABa4 D 0 1073 SdT9-5 D 0 1079 SdT8-4 D 0 1080 SdT8-5 D 0 1080 SdT8-5
D#0 1035 SdHpStk4 D#0 753 ClapAnSm D#0 1117 SdClpAna D#0 752 ClapT9 D#0 742 HandClapSt
E 0 667 QuintTip E 0 1074 SdT9Gate E 0 1078 SdT8-3 E 0 1071 SdT9-3 E 0 1121 SdDodgL
F 0 594 PickNoise1 F 0 1047 SdRkRolSt F 0 1247 TomT8 F 0 1086 SdHuman1 F 0 1053 SnLvRolSt
F#0 1075 SdT9Rim F#0 1071 SdT9-3 F#0 1080 SdT8-5 F#0 1101 SdHip3 F#0 1071 SdT9-3
G 0 860 SdNmSt1-4 G 0 1072 SdT9-4 G 0 822 BdT8-3 G 0 1072 SdT9-4 G 0 1076 SdT8-1
G#0 1097 SdR&B1Rm G#0 1074 SdT9Gate G#0 1079 SdT8-4 G#0 1100 SdHip2 G#0 1073 SdT9-5
A 0 764 BdNmSt1-2 A 0 816 BdT9-4 A 0 821 BdT8-2 A 0 858 BdThkSkn A 0 813 BdT9-1
A#0 894 SdFk3R A#0 1073 SdT9-5 A#0 1078 SdT8-3 A#0 1070 SdT9-2 A#0 1074 SdT9Gate
B 0 822 BdT8-3 B 0 813 BdT9-1 B 0 436 T8KickBass B 0 845 BdDist4 B 0 814 BdT9-2
C 1 834 BdR&B1 C 1 815 BdT9-3 C 1 820 BdT8-1 C 1 851 BdZapMid C 1 815 BdT9-3
C#1 1046 SdClRim3 C#1 1075 SdT9Rim C#1 1081 SdT8Rim C#1 1081 SdT8Rim C#1 1075 SdT9Rim
D 1 1014 SdPcRim D 1 1069 SdT9-1 D 1 1077 SdT8-2 D 1 1080 SdT8-5 D 1 1069 SdT9-1
D#1 742 HandClapSt D#1 752 ClapT9 D#1 752 ClapT9 D#1 752 ClapT9 D#1 752 ClapT9
E 1 1097 SdR&B1Rm E 1 1070 SdT9-2 E 1 1076 SdT8-1 E 1 1124 SdSyn E 1 1070 SdT9-2
F 1 822 BdT8-3 F 1 1246 TomT9Lo F 1 1247 TomT8 F 1 1247 TomT8 F 1 1246 TomT9Lo
F#1 1195 HHClT8-2 F#1 1191 HHClT9 F#1 1195 HHClT8-2 F#1 1211 HHClLoFi F#1 1193 HHClT8-1
G 1 822 BdT8-3 G 1 1246 TomT9Lo G 1 1247 TomT8 G 1 1247 TomT8 G 1 1246 TomT9Lo
G#1 1193 HHClT8-1 G#1 1192 HHOpT9 G#1 1194 HHOpT8-1 G#1 1212 HHOpLoFi G#1 1192 HHOpT9
A 1 822 BdT8-3 A 1 1246 TomT9Lo A 1 1247 TomT8 A 1 1247 TomT8 A 1 1246 TomT9Lo
A#1 1196 HHOpT8-2 A#1 1192 HHOpT9 A#1 1194 HHOpT8-1 A#1 1212 HHOpLoFi A#1 1192 HHOpT9
B 1 822 BdT8-3 B 1 1245 TomT9Hi B 1 1247 TomT8 B 1 1247 TomT8 B 1 1245 TomT9Hi
C 2 1247 TomT8 C 2 1245 TomT9Hi C 2 1247 TomT8 C 2 1247 TomT8 C 2 1245 TomT9Hi
C#2 1253 CrashSt C#2 1274 CrashT9 C#2 1275 CrashT8 C#2 1275 CrashT8 C#2 1274 CrashT9
D 2 1247 TomT8 D 2 1245 TomT9Hi D 2 1247 TomT8 D 2 1247 TomT8 D 2 1245 TomT9Hi
D#2 1258 RideSt D#2 1277 RideT9 D#2 1277 RideT9 D#2 1277 RideT9 D#2 1277 RideT9
E 2 1267 ChinaSt E 2 1270 China E 2 1270 China E 2 1256 Crash E 2 1256 Crash
F 2 1261 CupSt F 2 1265 CupMono F 2 1265 CupMono F 2 1265 CupMono F 2 1265 CupMono
F#2 714 TambrnSw F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 760 TambrnAnCR F#2 715 TambrnHit
G 2 1256 Crash G 2 1256 Crash G 2 1273 SplashR G 2 1254 CrashL G 2 1256 Crash
G#2 745 Cowbel1 G#2 745 Cowbel1 G#2 755 CowBelT8 G#2 755 CowBelT8 G#2 745 Cowbel1
A 2 1274 CrashT9 A 2 1257 Crash2 A 2 1257 Crash2 A 2 1274 CrashT9 A 2 1253 CrashSt
A#2 755 CowBelT8 A#2 755 CowBelT8 A#2 737 Vibraslap A#2 755 CowBelT8 A#2 755 CowBelT8
B 2 1258 RideSt B 2 1260 RideR B 2 1260 RideR B 2 1276 CrashSyn B 2 1258 RideSt
C 3 676 BongoHi1 C 3 754 CongaT8 C 3 754 CongaT8 C 3 754 CongaT8 C 3 676 BongoHi1
C#3 679 BongoLo1-3 C#3 754 CongaT8 C#3 754 CongaT8 C#3 754 CongaT8 C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 663 CongaTip D 3 754 CongaT8 D 3 754 CongaT8 D 3 663 CongaTip
D#3 662 CongaSlp D#3 662 CongaSlp D#3 754 CongaT8 D#3 754 CongaT8 D#3 662 CongaSlp
E 3 661 CongaOp E 3 661 CongaOp E 3 754 CongaT8 E 3 754 CongaT8 E 3 661 CongaOp
F 3 552 HiQ1 F 3 683 TmbaleH1-3 F 3 684 TimbaleHi1 F 3 683 TmbaleH1-3 F 3 684 TimbaleHi1
F#3 552 HiQ1 F#3 687 TmbaleL1-3 F#3 688 TimbaleLo1 F#3 687 TmbaleL1-3 F#3 684 TimbaleHi1
G 3 725 AgogoLo G 3 763 AnaClick G 3 547 Glass G 3 547 Glass G 3 725 AgogoLo
G#3 758 AnaShaker G#3 754 CongaT8 G#3 547 Glass G#3 547 Glass G#3 725 AgogoLo
A 3 758 AnaShaker A 3 698 Cabasa1-2 A 3 698 Cabasa1-2 A 3 699 Cabasa1 A 3 699 Cabasa1
A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 761 MarcsT8 A#3 761 MarcsT8 A#3 696 MaracasSlr
B 3 545 VoxDrum B 3 557 FxGun2 B 3 557 FxGun2 B 3 557 FxGun2 B 3 545 VoxDrum
C 4 545 VoxDrum C 4 558 FxGun1 C 4 558 FxGun1 C 4 558 FxGun1 C 4 545 VoxDrum
C#4 552 HiQ1 C#4 573 Scratch H C#4 758 AnaShaker C#4 573 Scratch H C#4 728 GuiroShort
D 4 553 HiQ2 D 4 575 ScratchDwn D 4 758 AnaShaker D 4 575 ScratchDwn D 4 727 GuiroLong
D#4 762 ClaveT8 D#4 552 HiQ1 D#4 762 ClaveT8 D#4 552 HiQ1 D#4 735 Clave
E 4 552 HiQ1 E 4 552 HiQ1 E 4 552 HiQ1 E 4 552 HiQ1 E 4 736 WoodBlock
F 4 587 ScratchSpn F 4 553 HiQ2 F 4 553 HiQ2 F 4 553 HiQ2 F 4 736 WoodBlock
F#4 577 ScratchHiR F#4 574 Scratch L F#4 574 Scratch L F#4 574 Scratch L F#4 674 CuicaHi
G 4 576 ScratchHiF G 4 574 Scratch L G 4 574 Scratch L G 4 574 Scratch L G 4 673 CuicaLo
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 706 Shaker2 A#4 758 AnaShaker A#4 758 AnaShaker A#4 758 AnaShaker A#4 758 AnaShaker
B 4 715 TambrnHit B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree
C#5 1129 SdLofi C#5 1013 SdPicol C#5 1099 SdHip1 C#5 368 DjembeEd C#5 1112 SdBreakRol
D 5 1029 SdRkStk2St D 5 1080 SdT8-5 D 5 1100 SdHip2 D 5 367 Wataiko D 5 520 Mother
D#5 1013 SdPicol D#5 1050 SdRkRolDSt D#5 1102 SdHipGate D#5 540 StabHard D#5 502 VoxBell
E 5 1098 SdR&B2 E 5 1060 SdBrMt2St E 5 1108 SdBreak1 E 5 536 HitOrch1 E 5 1096 SdR&B1
F 5 835 BdR&B2 F 5 828 BdBlpHd F 5 827 BdBlip F 5 541 StabOrgan2 F 5 512 VoxAlk
F#5 1122 SdFM F#5 1088 SdJngl1 F#5 1113 SdFx1 F#5 575 ScratchDwn F#5 377 Udo Hi
G 5 836 BdHipDp G 5 852 BdSus G 5 849 BdFxHmr G 5 797 BdRk1St G 5 507 TranCho
G#5 1128 SdHammer G#5 1092 SdD&B1 G#5 1128 SdHammer G#5 511 HH Hit G#5 519 Swarm
A 5 859 BdSlimy A 5 839 BdBreak2 A 5 850 BdZapHrd A 5 367 Wataiko A 5 805 BdPop
A#5 511 HH Hit A#5 1118 SdDist A#5 1121 SdDodgL A#5 534 Sonar1 A#5 1097 SdR&B1Rm
B 5 822 BdT8-3 B 5 853 BdTekPower B 5 853 BdTekPower B 5 560 TurnTable B 5 835 BdR&B2
C 6 560 TurnTable C 6 847 BdDistRM C 6 859 BdSlimy C 6 561 Police C 6 1256 Crash
11
PRE 16 House Kit2 PRE 17 Big Kit PRE 18 Break Kit PRE 19 Drum’nBass PRE 20 Acid Kit
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 814 BdT9-2 C 0 812 BdFXGate C 0 837 BdBrkDp C 0 836 BdHipDp C 0 855 BdATite
C#0 1081 SdT8Rim C#0 681 BongoLo2 C#0 984 SdHip1St C#0 681 BongoLo2 C#0 1081 SdT8Rim
D 0 618 PlayFxABa8 D 0 1025 SdGM D 0 1129 SdLofi D 0 1098 SdR&B2 D 0 1090 SdJngl3
D#0 752 ClapT9 D#0 742 HandClapSt D#0 1125 SdClappy D#0 1126 SdTimber D#0 742 HandClapSt
E 0 1070 SdT9-2 E 0 1020 SdGate2 E 0 1021 SdLdwHMono E 0 1094 SdD&B3 E 0 1076 SdT8-1
F 0 1074 SdT9Gate F 0 1047 SdRkRolSt F 0 1050 SdRkRolDSt F 0 1128 SdHammer F 0 1053 SnLvRolSt
F#0 1087 SdHuman2 F#0 998 SdRkRim1St F#0 1019 SdGate1 F#0 547 Glass F#0 955 SdBhL1-3
G 0 1113 SdFx1 G 0 1013 SdPicol G 0 1016 SdMid G 0 833 BdD&B2 G 0 962 SdBh3R
G#0 1129 SdLofi G#0 1010 SdRkFlmSt G#0 1022 SdBrRim G#0 1146 HHPdlSt G#0 914 SdSonSt1-3
A 0 818 BdT9Hd2 A 0 809 BdRoom2 A 0 840 BdBreakHvy A 0 836 BdHipDp A 0 773 BdFkSt1-2
A#0 1075 SdT9Rim A#0 1026 SdRkStk1St A#0 1106 SdHipRm4 A#0 1158 HHOp2St A#0 898 SdBsSt1-3
B 0 815 BdT9-3 B 0 810 BdRoom3 B 0 839 BdBreak2 B 0 832 BdD&B1 B 0 770 BdNm1R
C 1 817 BdT9Hd1 C 1 811 BdGate C 1 838 BdBreak1 C 1 833 BdD&B2 C 1 780 BdFkHL
C#1 1075 SdT9Rim C#1 1017 SdMdRim C#1 1103 SdHipRm1 C#1 1017 SdMdRim C#1 1031 SdRkStk2R
D 1 1127 SdWood D 1 1019 SdGate1 D 1 1110 SdBreak3 D 1 1092 SdD&B1 D 1 974 SdLdwR1-4
D#1 549 NzBurst D#1 753 ClapAnSm D#1 1108 SdBreak1 D#1 549 NzBurst D#1 752 ClapT9
E 1 551 Zap2 E 1 1018 SdAmb E 1 1109 SdBreak2 E 1 1093 SdD&B2 E 1 973 SdLdwL1-4
F 1 1124 SdSyn F 1 1244 TomAmbLo F 1 1224 TomLoSt F 1 1244 TomAmbLo F 1 1246 TomT9Lo
F#1 1191 HHClT9 F#1 1202 HHClD&B F#1 1167 HHClRkSR F#1 1202 HHClD&B F#1 1167 HHClRkSR
G 1 1124 SdSyn G 1 1244 TomAmbLo G 1 1224 TomLoSt G 1 1244 TomAmbLo G 1 1246 TomT9Lo
G#1 1192 HHOpT9 G#1 1203 HHPdlD&B G#1 1178 HHPdlRkR G#1 1203 HHPdlD&B G#1 1175 HHClRk2R
A 1 1124 SdSyn A 1 1244 TomAmbLo A 1 1224 TomLoSt A 1 1244 TomAmbLo A 1 1246 TomT9Lo
A#1 1192 HHOpT9 A#1 1204 HHOpD&B A#1 1187 HHHlfOpRkR A#1 1204 HHOpD&B A#1 1187 HHHlfOpRkR
B 1 1124 SdSyn B 1 1243 TomAmbHi B 1 1218 TomHiSt B 1 1243 TomAmbHi B 1 1245 TomT9Hi
C 2 1124 SdSyn C 2 1243 TomAmbHi C 2 1218 TomHiSt C 2 1243 TomAmbHi C 2 1245 TomT9Hi
C#2 1274 CrashT9 C#2 1253 CrashSt C#2 1254 CrashL C#2 1254 CrashL C#2 1254 CrashL
D 2 1124 SdSyn D 2 1243 TomAmbHi D 2 1218 TomHiSt D 2 1243 TomAmbHi D 2 1245 TomT9Hi
D#2 1277 RideT9 D#2 1258 RideSt D#2 1259 RideL D#2 1258 RideSt D#2 1260 RideR
E 2 1276 CrashSyn E 2 1267 ChinaSt E 2 1268 ChinaL E 2 1270 China E 2 1256 Crash
F 2 1265 CupMono F 2 1265 CupMono F 2 1265 CupMono F 2 1265 CupMono F 2 1262 CupL
F#2 715 TambrnHit F#2 715 TambrnHit F#2 715 TambrnHit F#2 715 TambrnHit F#2 715 TambrnHit
G 2 1275 CrashT8 G 2 1256 Crash G 2 1256 Crash G 2 1256 Crash G 2 1256 Crash
G#2 745 Cowbel1 G#2 745 Cowbel1 G#2 745 Cowbel1 G#2 745 Cowbel1 G#2 745 Cowbel1
A 2 1256 Crash A 2 1253 CrashSt A 2 1255 CrashR A 2 1253 CrashSt A 2 1254 CrashL
A#2 755 CowBelT8 A#2 737 Vibraslap A#2 756 CowBelRX11 A#2 737 Vibraslap A#2 755 CowBelT8
B 2 1258 RideSt B 2 1258 RideSt B 2 1264 RideMono B 2 1258 RideSt B 2 1264 RideMono
C 3 676 BongoHi1 C 3 676 BongoHi1 C 3 676 BongoHi1 C 3 676 BongoHi1 C 3 675 BongoHi1-2
C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 664 CongaHeel D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 1248 TomSyn1 F 3 848 Bd+HH F 3 675 BongoHi1-2 F 3 1095 SdD&B4 F 3 684 TimbaleHi1
F#3 1248 TomSyn1 F#3 848 Bd+HH F#3 679 BongoLo1-3 F#3 1205 HHRvD&B F#3 684 TimbaleHi1
G 3 763 AnaClick G 3 725 AgogoLo G 3 661 CongaOp G 3 725 AgogoLo G 3 724 AgogoHi
G#3 1130 SdRimSE G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo
A 3 699 Cabasa1 A 3 699 Cabasa1 A 3 699 Cabasa1 A 3 699 Cabasa1 A 3 699 Cabasa1
A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 545 VoxDrum B 3 557 FxGun2 B 3 684 TimbaleHi1 B 3 557 FxGun2 B 3 557 FxGun2
C 4 545 VoxDrum C 4 558 FxGun1 C 4 688 TimbaleLo1 C 4 558 FxGun1 C 4 558 FxGun1
C#4 760 TambrnAnCR C#4 573 Scratch H C#4 573 Scratch H C#4 728 GuiroShort C#4 573 Scratch H
D 4 758 AnaShaker D 4 575 ScratchDwn D 4 575 ScratchDwn D 4 727 GuiroLong D 4 575 ScratchDwn
D#4 762 ClaveT8 D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 552 HiQ1
E 4 759 TambrnRX5 E 4 736 WoodBlock E 4 736 WoodBlock E 4 495 Sine E 4 552 HiQ1
F 4 756 CowBelRX11 F 4 736 WoodBlock F 4 736 WoodBlock F 4 495 Sine F 4 553 HiQ2
F#4 758 AnaShaker F#4 574 Scratch L F#4 574 Scratch L F#4 462 P50-1 F#4 574 Scratch L
G 4 576 ScratchHiF G 4 574 Scratch L G 4 574 Scratch L G 4 653 PlyFxSl17S G 4 574 Scratch L
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 560 TurnTable G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 758 AnaShaker A#4 706 Shaker2 A#4 706 Shaker2 A#4 706 Shaker2 A#4 758 AnaShaker
B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 751 BellTree C 5 560 TurnTable C 5 751 BellTree C 5 751 BellTree
C#5 372 TabraBya C#5 1118 SdDist C#5 1112 SdBreakRol C#5 1118 SdDist C#5 1073 SdT9-5
D 5 373 TabraNah D 5 1122 SdFM D 5 520 Mother D 5 1122 SdFM D 5 1073 SdT9-5
D#5 374 TablaMut D#5 1123 SdFMRim D#5 528 Mind Bell D#5 1123 SdFMRim D#5 1073 SdT9-5
E 5 502 VoxBell E 5 1125 SdClappy E 5 1113 SdFx1 E 5 1125 SdClappy E 5 1073 SdT9-5
F 5 805 BdPop F 5 810 BdRoom3 F 5 800 BdRk2St F 5 832 BdD&B1 F 5 773 BdFkSt1-2
F#5 377 Udo Hi F#5 1126 SdTimber F#5 533 LfoSeq F#5 1126 SdTimber F#5 1092 SdD&B1
G 5 812 BdFXGate G 5 797 BdRk1St G 5 546 Ripper G 5 846 BdDist5 G 5 788 BdHSonSt
G#5 520 Mother G#5 1130 SdRimSE G#5 549 NzBurst G#5 1130 SdRimSE G#5 1102 SdHipGate
A 5 813 BdT9-1 A 5 800 BdRk2St A 5 561 Police A 5 845 BdDist4 A 5 812 BdFXGate
A#5 1112 SdBreakRol A#5 1112 SdBreakRol A#5 526 Fairwave A#5 1101 SdHip3 A#5 1108 SdBreak1
B 5 1256 Crash B 5 832 BdD&B1 B 5 519 Swarm B 5 859 BdSlimy B 5 829 BdJngl1
C 6 560 TurnTable C 6 809 BdRoom2 C 6 524 RadioNz C 6 848 Bd+HH C 6 840 BdBreakHvy
12
PRE 21 Jungle Kit PRE 22 Electric PRE 23 Human Kit PRE 24 Hard Kit PRE 25 DistrtdKit
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 830 BdJngl2 C 0 824 BdAnCR C 0 825 BdHuman1 C 0 844 BdDist3 C 0 763 AnaClick
C#0 1017 SdMdRim C#0 827 BdBlip C#0 584 ScratchVoF C#0 1127 SdWood C#0 1057 SdBrMtSt
D 0 1090 SdJngl3 D 0 1080 SdT8-5 D 0 543 Hit Uhh D 0 1019 SdGate1 D 0 1063 SdBrSwrSt
D#0 1090 SdJngl3 D#0 753 ClapAnSm D#0 585 ScratchVoR D#0 742 HandClapSt D#0 1060 SdBrMt2St
E 0 1014 SdPcRim E 0 1104 SdHipRm2 E 0 1091 SdJnglFx E 0 1020 SdGate2 E 0 1066 SdBSwrAtSt
F 0 1056 SdRollMono F 0 1056 SdRollMono F 0 1047 SdRkRolSt F 0 1056 SdRollMono F 0 1053 SnLvRolSt
F#0 1127 SdWood F#0 1076 SdT8-1 F#0 1108 SdBreak1 F#0 1117 SdClpAna F#0 734 Castanet
G 0 1098 SdR&B2 G 0 1084 SdAnCR G 0 1084 SdAnCR G 0 1101 SdHip3 G 0 866 SdNm1St
G#0 1093 SdD&B2 G#0 1077 SdT8-2 G#0 1069 SdT9-1 G#0 546 Ripper G#0 732 Stick
A 0 830 BdJngl2 A 0 820 BdT8-1 A 0 852 BdSus A 0 847 BdDistRM A 0 802 BdRk2R
A#0 1091 SdJnglFx A#0 1079 SdT8-4 A#0 1032 SdHpStk1 A#0 1081 SdT8Rim A#0 969 SdLdw1St
B 0 831 BdJngl3 B 0 827 BdBlip B 0 825 BdHuman1 B 0 843 BdDist2 B 0 838 BdBreak1
C 1 829 BdJngl1 C 1 821 BdT8-2 C 1 826 BdHuman2 C 1 842 BdDist1 C 1 802 BdRk2R
C#1 1106 SdHipRm4 C#1 1081 SdT8Rim C#1 1127 SdWood C#1 1017 SdMdRim C#1 1031 SdRkStk2R
D 1 1089 SdJngl2 D 1 1078 SdT8-3 D 1 1086 SdHuman1 D 1 1118 SdDist D 1 925 SdSon1L
D#1 1091 SdJnglFx D#1 752 ClapT9 D#1 1120 SdDodgH D#1 549 NzBurst D#1 743 HandClapL
E 1 1088 SdJngl1 E 1 753 ClapAnSm E 1 1087 SdHuman2 E 1 1114 SdFx2 E 1 1014 SdPcRim
F 1 1228 TomFlL F 1 1249 TomSyn2 F 1 825 BdHuman1 F 1 1252 TomDistLo F 1 1244 TomAmbLo
F#1 1165 HHClRkRSw F#1 1195 HHClT8-2 F#1 1217 HHOpHuman F#1 1191 HHClT9 F#1 1175 HHClRk2R
G 1 1225 TomLoL G 1 1249 TomSyn2 G 1 825 BdHuman1 G 1 1252 TomDistLo G 1 1244 TomAmbLo
G#1 1172 HHPdlRkRSw G#1 1194 HHOpT8-1 G#1 1217 HHOpHuman G#1 1192 HHOpT9 G#1 1178 HHPdlRkR
A 1 1223 TomMdR A 1 1249 TomSyn2 A 1 825 BdHuman1 A 1 1252 TomDistLo A 1 1244 TomAmbLo
A#1 1183 HHOpRkRSw A#1 1196 HHOpT8-2 A#1 1217 HHOpHuman A#1 1192 HHOpT9 A#1 1185 HHOpRkR
B 1 1223 TomMdR B 1 1249 TomSyn2 B 1 825 BdHuman1 B 1 1251 TomDistHi B 1 1243 TomAmbHi
C 2 1220 TomHiR C 2 1249 TomSyn2 C 2 825 BdHuman1 C 2 1251 TomDistHi C 2 1243 TomAmbHi
C#2 1254 CrashL C#2 1274 CrashT9 C#2 549 NzBurst C#2 1274 CrashT9 C#2 1254 CrashL
D 2 1220 TomHiR D 2 1249 TomSyn2 D 2 825 BdHuman1 D 2 1251 TomDistHi D 2 1243 TomAmbHi
D#2 1260 RideR D#2 1277 RideT9 D#2 1275 CrashT8 D#2 1277 RideT9 D#2 1260 RideR
E 2 1270 China E 2 1256 Crash E 2 1270 China E 2 1270 China E 2 1268 ChinaL
F 2 1265 CupMono F 2 1276 CrashSyn F 2 1265 CupMono F 2 1265 CupMono F 2 1263 CupR
F#2 715 TambrnHit F#2 1275 CrashT8 F#2 583 ScratchSdR F#2 760 TambrnAnCR F#2 714 TambrnSw
G 2 1256 Crash G 2 1256 Crash G 2 1271 SplashSt G 2 1256 Crash G 2 1273 SplashR
G#2 745 Cowbel1 G#2 1130 SdRimSE G#2 545 VoxDrum G#2 755 CowBelT8 G#2 747 MamboBel
A 2 1253 CrashSt A 2 1253 CrashSt A 2 1257 Crash2 A 2 1253 CrashSt A 2 1254 CrashL
A#2 737 Vibraslap A#2 755 CowBelT8 A#2 755 CowBelT8 A#2 737 Vibraslap A#2 737 Vibraslap
B 2 1258 RideSt B 2 1276 CrashSyn B 2 542 StabAah B 2 1258 RideSt B 2 1258 RideSt
C 3 676 BongoHi1 C 3 1247 TomT8 C 3 676 BongoHi1 C 3 1126 SdTimber C 3 675 BongoHi1-2
C#3 679 BongoLo1-3 C#3 1247 TomT8 C#3 679 BongoLo1-3 C#3 1126 SdTimber C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 1247 TomT8 D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 662 CongaSlp D#3 1247 TomT8 D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 661 CongaOp E 3 1247 TomT8 E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 373 TabraNah F 3 571 Applause F 3 683 TmbaleH1-3 F 3 848 Bd+HH F 3 683 TmbaleH1-3
F#3 372 TabraBya F#3 566 Telephone F#3 687 TmbaleL1-3 F#3 848 Bd+HH F#3 687 TmbaleL1-3
G 3 725 AgogoLo G 3 563 Heartbeat G 3 725 AgogoLo G 3 547 Glass G 3 724 AgogoHi
G#3 725 AgogoLo G#3 555 Bomb G#3 725 AgogoLo G#3 547 Glass G#3 725 AgogoLo
A 3 699 Cabasa1 A 3 1212 HHOpLoFi A 3 699 Cabasa1 A 3 699 Cabasa1 A 3 698 Cabasa1-2
A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 684 TimbaleHi1 B 3 551 Zap2 B 3 557 FxGun2 B 3 557 FxGun2 B 3 738 Whistle
C 4 688 TimbaleLo1 C 4 550 Zap1 C 4 558 FxGun1 C 4 558 FxGun1 C 4 738 Whistle
C#4 728 GuiroShort C#4 573 Scratch H C#4 573 Scratch H C#4 573 Scratch H C#4 728 GuiroShort
D 4 727 GuiroLong D 4 575 ScratchDwn D 4 575 ScratchDwn D 4 575 ScratchDwn D 4 727 GuiroLong
D#4 735 Clave D#4 552 HiQ1 D#4 578 ScratchLoF D#4 552 HiQ1 D#4 735 Clave
E 4 736 WoodBlock E 4 552 HiQ1 E 4 579 ScratchLoR E 4 552 HiQ1 E 4 736 WoodBlock
F 4 736 WoodBlock F 4 553 HiQ2 F 4 553 HiQ2 F 4 553 HiQ2 F 4 736 WoodBlock
F#4 674 CuicaHi F#4 574 Scratch L F#4 574 Scratch L F#4 574 Scratch L F#4 591 ScratchCb2
G 4 673 CuicaLo G 4 544 HitOrch2 G 4 574 Scratch L G 4 574 Scratch L G 4 577 ScratchHiR
G#4 741 TriangleMt G#4 1215 HHClFx G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 1216 HHOpFx A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 706 Shaker2 A#4 758 AnaShaker A#4 706 Shaker2 A#4 758 AnaShaker A#4 704 Shaker1-2
B 4 750 SleighBel B 4 758 AnaShaker B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 560 TurnTable C 5 560 TurnTable C 5 751 BellTree C 5 751 BellTree
C#5 1205 HHRvD&B C#5 1112 SdBreakRol C#5 1000 SdRkRim1R C#5 1118 SdDist C#5 1013 SdPicol
D 5 572 RainLoop D 5 520 Mother D 5 564 Helicopter D 5 1122 SdFM D 5 1024 SdHeavy
D#5 573 Scratch H D#5 528 Mind Bell D#5 540 StabHard D#5 1123 SdFMRim D#5 1117 SdClpAna
E 5 574 Scratch L E 5 1113 SdFx1 E 5 1019 SdGate1 E 5 1125 SdClappy E 5 1014 SdPcRim
F 5 828 BdBlpHd F 5 800 BdRk2St F 5 797 BdRk1St F 5 849 BdFxHmr F 5 809 BdRoom2
F#5 1124 SdSyn F#5 533 LfoSeq F#5 575 ScratchDwn F#5 548 IndusTom F#5 1016 SdMid
G 5 548 IndusTom G 5 546 Ripper G 5 823 BdAnSm G 5 832 BdD&B1 G 5 810 BdRoom3
G#5 717 PandieroOp G#5 549 NzBurst G#5 534 Sonar1 G#5 548 IndusTom G#5 1017 SdMdRim
A 5 546 Ripper A 5 561 Police A 5 367 Wataiko A 5 810 BdRoom3 A 5 811 BdGate
A#5 567 TelRing A#5 526 Fairwave A#5 367 Wataiko A#5 548 IndusTom A#5 1019 SdGate1
B 5 579 ScratchLoR B 5 519 Swarm B 5 511 HH Hit B 5 816 BdT9-4 B 5 812 BdFXGate
C 6 556 TapeRewnd C 6 524 RadioNz C 6 541 StabOrgan2 C 6 1128 SdHammer C 6 832 BdD&B1
13
PRE 26 AmbientKit PRE 27 Jazz Kit PRE 28 Hip Hop3 PRE 29 Hip Hop4 PRE 30 HipStick2
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 827 BdBlip C 0 809 BdRoom2 C 0 1081 SdT8Rim C 0 1033 SdHpStk2 C 0 1106 SdHipRm4
C#0 553 HiQ2 C#0 1059 SdBrMtR C#0 554 VoxHitRev C#0 553 HiQ2 C#0 549 NzBurst
D 0 1015 SdPcRim2 D 0 1066 SdBSwrAtSt D 0 560 TurnTable D 0 560 TurnTable D 0 560 TurnTable
D#0 552 HiQ1 D#0 1060 SdBrMt2St D#0 540 StabHard D#0 536 HitOrch1 D#0 543 Hit Uhh
E 0 1084 SdAnCR E 0 1066 SdBSwrAtSt E 0 585 ScratchVoR E 0 587 ScratchSpn E 0 581 ScratchBdR
F 0 1248 TomSyn1 F 0 1053 SnLvRolSt F 0 1056 SdRollMono F 0 1049 SdRkRolR F 0 1055 SnLvRolR
F#0 1213 HHClSyn F#0 734 Castanet F#0 762 ClaveT8 F#0 762 ClaveT8 F#0 762 ClaveT8
G 0 1248 TomSyn1 G 0 984 SdHip1St G 0 989 SdHip1R G 0 1110 SdBreak3 G 0 1083 SdAnSmRim
G#0 1215 HHClFx G#0 732 Stick G#0 1035 SdHpStk4 G#0 1040 SdHpStk7 G#0 1102 SdHipGate
A 0 1249 TomSyn2 A 0 778 BdFkML A 0 824 BdAnCR A 0 835 BdR&B2 A 0 815 BdT9-3
A#0 1214 HHOpSyn A#0 1029 SdRkStk2St A#0 1105 SdHipRm3 A#0 1097 SdR&B1Rm A#0 1081 SdT8Rim
B 0 824 BdAnCR B 0 794 BdFkSonSt B 0 815 BdT9-3 B 0 816 BdT9-4 B 0 821 BdT8-2
C 1 813 BdT9-1 C 1 773 BdFkSt1-2 C 1 836 BdHipDp C 1 814 BdT9-2 C 1 813 BdT9-1
C#1 1034 SdHpStk3 C#1 1042 SdClRmSt C#1 1036 SdHpStk5 C#1 1034 SdHpStk3 C#1 1105 SdHipRm3
D 1 1088 SdJngl1 D 1 969 SdLdw1St D 1 1102 SdHipGate D 1 1105 SdHipRm3 D 1 1034 SdHpStk3
D#1 752 ClapT9 D#1 742 HandClapSt D#1 744 HandClapR D#1 744 HandClapR D#1 744 HandClapR
E 1 1088 SdJngl1 E 1 948 SdBhSt1-3 E 1 1129 SdLofi E 1 1106 SdHipRm4 E 1 1035 SdHpStk4
F 1 1247 TomT8 F 1 1227 TomFlSt F 1 1247 TomT8 F 1 822 BdT8-3 F 1 1246 TomT9Lo
F#1 1195 HHClT8-2 F#1 1152 HHClFtSt F#1 1208 HHClHip F#1 1191 HHClT9 F#1 1191 HHClT9
G 1 1247 TomT8 G 1 1227 TomFlSt G 1 1247 TomT8 G 1 822 BdT8-3 G 1 1246 TomT9Lo
G#1 1194 HHOpT8-1 G#1 1146 HHPdlSt G#1 1209 HHPdlHip G#1 1192 HHOpT9 G#1 1192 HHOpT9
A 1 1247 TomT8 A 1 1224 TomLoSt A 1 1247 TomT8 A 1 822 BdT8-3 A 1 1246 TomT9Lo
A#1 1196 HHOpT8-2 A#1 1158 HHOp2St A#1 1210 HHOpHip A#1 1192 HHOpT9 A#1 1192 HHOpT9
B 1 1247 TomT8 B 1 1221 TomMdSt B 1 1247 TomT8 B 1 822 BdT8-3 B 1 1245 TomT9Hi
C 2 1247 TomT8 C 2 1221 TomMdSt C 2 1247 TomT8 C 2 822 BdT8-3 C 2 1245 TomT9Hi
C#2 1276 CrashSyn C#2 1253 CrashSt C#2 1257 Crash2 C#2 1257 Crash2 C#2 1257 Crash2
D 2 1247 TomT8 D 2 1218 TomHiSt D 2 1247 TomT8 D 2 822 BdT8-3 D 2 1245 TomT9Hi
D#2 1277 RideT9 D#2 1258 RideSt D#2 1260 RideR D#2 1260 RideR D#2 1260 RideR
E 2 1256 Crash E 2 1267 ChinaSt E 2 1275 CrashT8 E 2 1275 CrashT8 E 2 1275 CrashT8
F 2 1265 CupMono F 2 1261 CupSt F 2 1277 RideT9 F 2 1277 RideT9 F 2 1277 RideT9
F#2 715 TambrnHit F#2 715 TambrnHit F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5
G 2 1256 Crash G 2 1271 SplashSt G 2 1273 SplashR G 2 1273 SplashR G 2 1273 SplashR
G#2 755 CowBelT8 G#2 745 Cowbel1 G#2 748 MamboBdy G#2 748 MamboBdy G#2 748 MamboBdy
A 2 1253 CrashSt A 2 1253 CrashSt A 2 1274 CrashT9 A 2 1274 CrashT9 A 2 1274 CrashT9
A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap
B 2 1258 RideSt B 2 1258 RideSt B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9
C 3 676 BongoHi1 C 3 676 BongoHi1 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2
C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 683 TmbaleH1-3 F 3 684 TimbaleHi1 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3
F#3 687 TmbaleL1-3 F#3 684 TimbaleHi1 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3
G 3 547 Glass G 3 725 AgogoLo G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi
G#3 547 Glass G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo
A 3 699 Cabasa1 A 3 699 Cabasa1 A 3 707 ShakerHip1 A 3 707 ShakerHip1 A 3 707 ShakerHip1
A#3 761 MarcsT8 A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 568 Bird B 3 1063 SdBrSwrSt B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle
C 4 569 Stream C 4 1063 SdBrSwrSt C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle
C#4 559 Thunder C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort
D 4 570 Gunshot D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong
D#4 762 ClaveT8 D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 735 Clave
E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock
F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock
F#4 760 TambrnAnCR F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi
G 4 757 CowBelAnCR G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 758 AnaShaker A#4 706 Shaker2 A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2
B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree
C#5 1080 SdT8-5 C#5 940 SdBlL1-3 C#5 1032 SdHpStk1 C#5 1042 SdClRmSt C#5 1083 SdAnSmRim
D 5 534 Sonar1 D 5 895 SdFkAySt D 5 1088 SdJngl1 D 5 1091 SdJnglFx D 5 1044 SdClRmR
D#5 1080 SdT8-5 D#5 956 SdBhR1-3 D#5 744 HandClapR D#5 744 HandClapR D#5 1106 SdHipRm4
E 5 523 Resonator E 5 934 SdBlSt1-2 E 5 1111 SdBreakHvy E 5 1112 SdBreakRol E 5 1046 SdClRim3
F 5 518 Bubble F 5 786 BdLoL F 5 574 Scratch L F 5 577 ScratchHiR F 5 574 Scratch L
F#5 1080 SdT8-5 F#5 1021 SdLdwHMono F#5 575 ScratchDwn F#5 578 ScratchLoF F#5 575 ScratchDwn
G 5 518 Bubble G 5 804 BdDry2 G 5 576 ScratchHiF G 5 579 ScratchLoR G 5 576 ScratchHiF
G#5 1080 SdT8-5 G#5 1066 SdBSwrAtSt G#5 578 ScratchLoF G#5 580 ScratchBdF G#5 578 ScratchLoF
A 5 509 Eery A 5 859 BdSlimy A 5 579 ScratchLoR A 5 581 ScratchBdR A 5 581 ScratchBdR
A#5 1080 SdT8-5 A#5 1056 SdRollMono A#5 580 ScratchBdF A#5 582 ScratchSdF A#5 591 ScratchCb2
B 5 504 WindChime B 5 772 BdNm2R B 5 581 ScratchBdR B 5 583 ScratchSdR B 5 586 ScratchStp
C 6 504 WindChime C 6 1256 Crash C 6 840 BdBreakHvy C 6 841 BdBreakHrd C 6 828 BdBlpHd
14
PRE 31 Garage PRE 32 ALL-ROUND PRE 33 Rock Multi PRE 34 Hip Multi PRE 35 Percussion
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 854 BdHardLong C 0 854 BdHardLong C 0 764 BdNmSt1-2 C 0 822 BdT8-3 C 0 367 Wataiko
C#0 813 BdT9-1 C#0 853 BdTekPower C#0 1026 SdRkStk1St C#0 1081 SdT8Rim C#0 377 Udo Hi
D 0 859 BdSlimy D 0 846 BdDist5 D 0 1001 SdRkOp2St D 0 1121 SdDodgL D 0 370 DjembeOp
D#0 856 BdAnHard D#0 844 BdDist3 D#0 1047 SdRkRolSt D#0 752 ClapT9 D#0 667 QuintTip
E 0 845 BdDist4 E 0 842 BdDist1 E 0 992 SdRkOp1St E 0 1101 SdHip3 E 0 378 Udo Low
F 0 835 BdR&B2 F 0 832 BdD&B1 F 0 1224 TomLoSt F 0 822 BdT8-3 F 0 376 UdoFinger
F#0 836 BdHipDp F#0 827 BdBlip F#0 1152 HHClFtSt F#0 1206 HHClTek F#0 377 Udo Hi
G 0 849 BdFxHmr G 0 823 BdAnSm G 0 1224 TomLoSt G 0 822 BdT8-3 G 0 372 TabraBya
G#0 817 BdT9Hd1 G#0 821 BdT8-2 G#0 1146 HHPdlSt G#0 1207 HHOpTek G#0 721 TmbourimOp
A 0 822 BdT8-3 A 0 820 BdT8-1 A 0 1221 TomMdSt A 0 822 BdT8-3 A 0 374 TablaMut
A#0 852 BdSus A#0 819 BdT9Hd3 A#0 1149 HHOpSt A#0 1207 HHOpTek A#0 373 TabraNah
B 0 851 BdZapMid B 0 814 BdT9-2 B 0 1218 TomHiSt B 0 822 BdT8-3 B 0 374 TablaMut
C 1 821 BdT8-2 C 1 815 BdT9-3 C 1 800 BdRk2St C 1 836 BdHipDp C 1 92 Timpani
C#1 859 BdSlimy C#1 852 BdSus C#1 1026 SdRkStk1St C#1 1035 SdHpStk4 C#1 543 Hit Uhh
D 1 1076 SdT8-1 D 1 1069 SdT9-1 D 1 1001 SdRkOp2St D 1 1103 SdHipRm1 D 1 594 PickNoise1
D#1 1081 SdT8Rim D#1 1075 SdT9Rim D#1 742 HandClapSt D#1 744 HandClapR D#1 752 ClapT9
E 1 1125 SdClappy E 1 1072 SdT9-4 E 1 1004 SdRkMte2St E 1 1100 SdHip2 E 1 741 TriangleMt
F 1 939 SdBl3St F 1 1246 TomT9Lo F 1 1236 TomRkLoSt F 1 1247 TomT8 F 1 740 TriangleOp
F#1 1149 HHOpSt F#1 1191 HHClT9 F#1 1161 HHClRkStSw F#1 1195 HHClT8-2 F#1 734 Castanet
G 1 1195 HHClT8-2 G 1 1246 TomT9Lo G 1 1236 TomRkLoSt G 1 1247 TomT8 G 1 734 Castanet
G#1 1149 HHOpSt G#1 1192 HHOpT9 G#1 1170 HHPdRkStSw G#1 1199 HHOpAnCR G#1 734 Castanet
A 1 1196 HHOpT8-2 A 1 1246 TomT9Lo A 1 1233 TomRkMdSt A 1 1247 TomT8 A 1 727 GuiroLong
A#1 1149 HHOpSt A#1 1192 HHOpT9 A#1 1179 HHOpRkStSw A#1 1194 HHOpT8-1 A#1 728 GuiroShort
B 1 1196 HHOpT8-2 B 1 752 ClapT9 B 1 1233 TomRkMdSt B 1 1247 TomT8 B 1 729 GuiroSwp
C 2 753 ClapAnSm C 2 753 ClapAnSm C 2 1230 TomRkHiSt C 2 1247 TomT8 C 2 737 Vibraslap
C#2 1253 CrashSt C#2 1274 CrashT9 C#2 1253 CrashSt C#2 1274 CrashT9 C#2 735 Clave
D 2 1274 CrashT9 D 2 754 CongaT8 D 2 1230 TomRkHiSt D 2 1247 TomT8 D 2 762 ClaveT8
D#2 1258 RideSt D#2 1277 RideT9 D#2 1258 RideSt D#2 1276 CrashSyn D#2 673 CuicaLo
E 2 1277 RideT9 E 2 754 CongaT8 E 2 1267 ChinaSt E 2 1276 CrashSyn E 2 674 CuicaHi
F 2 763 AnaClick F 2 763 AnaClick F 2 1261 CupSt F 2 1275 CrashT8 F 2 687 TmbaleL1-3
F#2 762 ClaveT8 F#2 762 ClaveT8 F#2 714 TambrnSw F#2 759 TambrnRX5 F#2 736 WoodBlock
G 2 753 ClapAnSm G 2 761 MarcsT8 G 2 1271 SplashSt G 2 1273 SplashR G 2 689 TimbaleLo2
G#2 752 ClapT9 G#2 760 TambrnAnCR G#2 745 Cowbel1 G#2 755 CowBelT8 G#2 736 WoodBlock
A 2 758 AnaShaker A 2 758 AnaShaker A 2 1253 CrashSt A 2 1274 CrashT9 A 2 683 TmbaleH1-3
A#2 754 CongaT8 A#2 755 CowBelT8 A#2 704 Shaker1-2 A#2 757 CowBelAnCR A#2 749 ChaCha
B 2 754 CongaT8 B 2 757 CowBelAnCR B 2 1258 RideSt B 2 1277 RideT9 B 2 685 TimbaleHi2
C 3 1084 SdAnCR C 3 1076 SdT8-1 C 3 797 BdRk1St C 3 836 BdHipDp C 3 691 TmblPailaL
C#3 1047 SdRkRolSt C#3 1077 SdT8-2 C#3 1029 SdRkStk2St C#3 1036 SdHpStk5 C#3 691 TmblPailaL
D 3 724 AgogoHi D 3 1078 SdT8-3 D 3 992 SdRkOp1St D 3 1104 SdHipRm2 D 3 690 TmblPailaH
D#3 1308 ChinaRL D#3 1084 SdAnCR D#3 752 ClapT9 D#3 743 HandClapL D#3 747 MamboBel
E 3 553 HiQ2 E 3 1088 SdJngl1 E 3 995 SdRkMte1St E 3 1099 SdHip1 E 3 679 BongoLo1-3
F 3 552 HiQ1 F 3 1092 SdD&B1 F 3 1236 TomRkLoSt F 3 1246 TomT9Lo F 3 682 BongoLo3
F#3 551 Zap2 F#3 1095 SdD&B4 F#3 1161 HHClRkStSw F#3 1197 HHClRX5 F#3 745 Cowbel1
G 3 550 Zap1 G 3 1096 SdR&B1 G 3 1236 TomRkLoSt G 3 1246 TomT9Lo G 3 675 BongoHi1-2
G#3 551 Zap2 G#3 1098 SdR&B2 G#3 1176 HHPdlRkSt G#3 1198 HHClAnCR G#3 746 Cowbell2
A 3 562 DoorSqk A 3 1099 SdHip1 A 3 1233 TomRkMdSt A 3 1246 TomT9Lo A 3 678 BongoHHeel
A#3 592 ScratchCb3 A#3 1127 SdWood A#3 1181 HHHfOpRkSt A#3 1196 HHOpT8-2 A#3 725 AgogoLo
B 3 597 FretNoise B 3 1126 SdTimber B 3 1233 TomRkMdSt B 3 1246 TomT9Lo B 3 724 AgogoHi
C 4 602 PlayFxGt5 C 4 1193 HHClT8-1 C 4 1230 TomRkHiSt C 4 1245 TomT9Hi C 4 672 TumbaHeel
C#4 576 ScratchHiF C#4 1194 HHOpT8-1 C#4 1253 CrashSt C#4 1255 CrashR C#4 671 TumbaTip
D 4 60 Wurli+ D 4 1195 HHClT8-2 D 4 1230 TomRkHiSt D 4 1245 TomT9Hi D 4 670 TumbaSlp
D#4 60 Wurli+ D#4 1196 HHOpT8-2 D#4 1259 RideL D#4 1275 CrashT8 D#4 696 MaracasSlr
E 4 60 Wurli+ E 4 1146 HHPdlSt E 4 1267 ChinaSt E 4 1276 CrashSyn E 4 669 TumbaOp
F 4 531 ResoXFade F 4 1149 HHOpSt F 4 1261 CupSt F 4 1275 CrashT8 F 4 664 CongaHeel
F#4 534 Sonar1 F#4 1149 HHOpSt F#4 715 TambrnHit F#4 715 TambrnHit F#4 663 CongaTip
G 4 545 VoxDrum G 4 1211 HHClLoFi G 4 1271 SplashSt G 4 1269 ChinaR G 4 662 CongaSlp
G#4 545 VoxDrum G#4 1212 HHOpLoFi G#4 747 MamboBel G#4 756 CowBelRX11 G#4 705 Shaker1
A 4 545 VoxDrum A 4 1213 HHClSyn A 4 1253 CrashSt A 4 1254 CrashL A 4 661 CongaOp
A#4 1214 HHOpSyn A#4 1214 HHOpSyn A#4 711 ShekereDw A#4 745 Cowbel1 A#4 699 Cabasa1
B 4 1213 HHClSyn B 4 758 AnaShaker B 4 1260 RideR B 4 1260 RideR B 4 698 Cabasa1-2
C 5 464 TriWv C 5 759 TambrnRX5 C 5 773 BdFkSt1-2 C 5 836 BdHipDp C 5 668 QuintHeel
C#5 464 TriWv C#5 714 TambrnSw C#5 1026 SdRkStk1St C#5 1041 SdHipStk8 C#5 667 QuintTip
D 5 464 TriWv D 5 746 Cowbell2 D 5 998 SdRkRim1St D 5 1102 SdHipGate D 5 666 QuintSlp
D#5 464 TriWv D#5 676 BongoHi1 D#5 1010 SdRkFlmSt D#5 1100 SdHip2 D#5 706 Shaker2
E 5 464 TriWv E 5 684 TimbaleHi1 E 5 1007 SdRkRim2St E 5 1107 SdHipRm5 E 5 665 QuintOp
F 5 464 TriWv F 5 736 WoodBlock F 5 1227 TomFlSt F 5 1252 TomDistLo F 5 702 Caxixi1
F#5 464 TriWv F#5 854 BdHardLong F#5 1135 HHCl4St F#5 1208 HHClHip F#5 716 TambrnShk
G 5 464 TriWv G 5 669 TumbaOp G 5 1224 TomLoSt G 5 1252 TomDistLo G 5 715 TambrnHit
G#5 464 TriWv G#5 665 QuintOp G#5 1146 HHPdlSt G#5 1209 HHPdlHip G#5 714 TambrnSw
A 5 464 TriWv A 5 557 FxGun2 A 5 1221 TomMdSt A 5 1251 TomDistHi A 5 715 TambrnHit
A#5 464 TriWv A#5 555 Bomb A#5 1158 HHOp2St A#5 1210 HHOpHip A#5 750 SleighBel
B 5 464 TriWv B 5 850 BdZapHrd B 5 1221 TomMdSt B 5 1251 TomDistHi B 5 738 Whistle
C 6 464 TriWv C 6 589 ScratchHp2 C 6 1218 TomHiSt C 6 1250 TomAnSm C 6 738 Whistle
15
PRE 36 Latin Perc PRE 37 Gtr/Bs Fx PRE 38 Wacko Kit PRE 39
Wood Bits
PRE 40 Metal Bits
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 791 BdLSonSt C 0 618 PlayFxABa8 C 0 630 PlyFxSlp5H C 0 762 ClaveT8 C 0 755 CowBelT8
C#0 1029 SdRkStk2St C#0 618 PlayFxABa8 C#0 594 PickNoise1 C#0 1038 SdHpStk6L C#0 1145 HHCl4R
D 0 883 SdFkSt1/3 D 0 601 PlayFxGt4 D 0 1203 HHPdlD&B D 0 727 GuiroLong D 0 1263 CupR
D#0 1253 CrashSt D#0 188 PwrChdMono D#0 743 HandClapL D#0 1039 SdHpStk6R D#0 1214 HHOpSyn
E 0 1271 SplashSt E 0 188 PwrChdMono E 0 584 ScratchVoF E 0 727 GuiroLong E 0 1262 CupL
F 0 1224 TomLoSt F 0 619 PlayFxABa9 F 0 548 IndusTom F 0 619 PlayFxABa9 F 0 1261 CupSt
F#0 1131 HHClSt1-4 F#0 595 PickNoise2 F#0 1127 SdWood F#0 734 Castanet F#0 446 FMMetal2
G 0 1224 TomLoSt G 0 616 PlayFxABa6 G 0 548 IndusTom G 0 618 PlayFxABa8 G 0 1258 RideSt
G#0 1146 HHPdlSt G#0 595 PickNoise2 G#0 1117 SdClpAna G#0 732 Stick G#0 1258 RideSt
A 0 1221 TomMdSt A 0 616 PlayFxABa6 A 0 548 IndusTom A 0 617 PlayFxABa7 A 0 746 Cowbell2
A#0 1149 HHOpSt A#0 604 PlayFxGt7 A#0 1123 SdFMRim A#0 614 PlayFxABa4 A#0 1132 HHCl1St
B 0 1218 TomHiSt B 0 622 PlyFxSlp1H B 0 812 BdFXGate B 0 1245 TomT9Hi B 0 749 ChaCha
C 1 671 TumbaTip C 1 643 PlyFxSl12S C 1 849 BdFxHmr C 1 596 PickNoise3 C 1 746 Cowbell2
C#1 672 TumbaHeel C#1 614 PlayFxABa4 C#1 614 PlayFxABa4 C#1 1046 SdClRim3 C#1 1213 HHClSyn
D 1 670 TumbaSlp D 1 600 PlayFxGt3 D 1 1122 SdFM D 1 733 Stick2 D 1 1207 HHOpTek
D#1 735 Clave D#1 619 PlayFxABa9 D#1 743 HandClapL D#1 727 GuiroLong D#1 1195 HHClT8-2
E 1 669 TumbaOp E 1 602 PlayFxGt5 E 1 1126 SdTimber E 1 733 Stick2 E 1 1197 HHClRX5
F 1 663 CongaTip F 1 623 PlyFxSlp2S F 1 1249 TomSyn2 F 1 614 PlayFxABa4 F 1 746 Cowbell2
F#1 664 CongaHeel F#1 595 PickNoise2 F#1 1213 HHClSyn F#1 1083 SdAnSmRim F#1 1194 HHOpT8-1
G 1 662 CongaSlp G 1 623 PlyFxSlp2S G 1 1249 TomSyn2 G 1 614 PlayFxABa4 G 1 746 Cowbell2
G#1 749 ChaCha G#1 595 PickNoise2 G#1 1214 HHOpSyn G#1 753 ClapAnSm G#1 1213 HHClSyn
A 1 661 CongaOp A 1 623 PlyFxSlp2S A 1 1249 TomSyn2 A 1 614 PlayFxABa4 A 1 746 Cowbell2
A#1 748 MamboBdy A#1 597 FretNoise A#1 1214 HHOpSyn A#1 737 Vibraslap A#1 1214 HHOpSyn
B 1 747 MamboBel B 1 623 PlyFxSlp2S B 1 1249 TomSyn2 B 1 614 PlayFxABa4 B 1 746 Cowbell2
C 2 667 QuintTip C 2 623 PlyFxSlp2S C 2 1249 TomSyn2 C 2 614 PlayFxABa4 C 2 746 Cowbell2
C#2 668 QuintHeel C#2 657 PlyFxSl19S C#2 1189 HHOpMono C#2 565 Seashore C#2 1216 HHOpFx
D 2 666 QuintSlp D 2 623 PlyFxSlp2S D 2 534 Sonar1 D 2 614 PlayFxABa4 D 2 746 Cowbell2
D#2 749 ChaCha D#2 595 PickNoise2 D#2 1194 HHOpT8-1 D#2 1029 SdRkStk2St D#2 1261 CupSt
E 2 665 QuintOp E 2 657 PlyFxSl19S E 2 1189 HHOpMono E 2 571 Applause E 2 1199 HHOpAnCR
F 2 680 BongoLo1 F 2 595 PickNoise2 F 2 1262 CupL F 2 1027 SdRkStk1L F 2 1261 CupSt
F#2 678 BongoHHeel F#2 624 PlyFxSlp2H F#2 750 SleighBel F#2 716 TambrnShk F#2 714 TambrnSw
G 2 676 BongoHi1 G 2 657 PlyFxSl19S G 2 1196 HHOpT8-2 G 2 565 Seashore G 2 1216 HHOpFx
G#2 688 TimbaleLo1 G#2 609 PlayFxGt12 G#2 531 ResoXFade G#2 736 WoodBlock G#2 747 MamboBel
A 2 691 TmblPailaL A 2 657 PlyFxSl19S A 2 1254 CrashL A 2 571 Applause A 2 1216 HHOpFx
A#2 684 TimbaleHi1 A#2 655 PlyFxSl18S A#2 572 RainLoop A#2 564 Helicopter A#2 750 SleighBel
B 2 690 TmblPailaH B 2 595 PickNoise2 B 2 1263 CupR B 2 1031 SdRkStk2R B 2 1264 RideMono
C 3 736 WoodBlock C 3 614 PlayFxABa4 C 3 516 AirHoseL C 3 613 PlayFxABa3 C 3 78 Vibraphone
C#3 736 WoodBlock C#3 614 PlayFxABa4 C#3 516 AirHoseL C#3 613 PlayFxABa3 C#3 78 Vibraphone
D 3 711 ShekereDw D 3 612 PlayFxABa2 D 3 377 Udo Hi D 3 734 Castanet D 3 82 Tubular
D#3 712 ShekereUp D#3 613 PlayFxABa3 D#3 426 MgBass2 D#3 734 Castanet D#3 83 Bell
E 3 713 ShekereSap E 3 611 PlayFxABa1 E 3 427 MgBass3 E 3 736 WoodBlock E 3 86 BrBell
F 3 696 MaracasSlr F 3 618 PlayFxABa8 F 3 618 PlayFxABa8 F 3 691 TmblPailaL F 3 690 TmblPailaH
F#3 697 MaracasStc F#3 618 PlayFxABa8 F#3 618 PlayFxABa8 F#3 691 TmblPailaL F#3 691 TmblPailaL
G 3 727 GuiroLong G 3 618 PlayFxABa8 G 3 725 AgogoLo G 3 732 Stick G 3 83 Bell
G#3 728 GuiroShort G#3 618 PlayFxABa8 G#3 725 AgogoLo G#3 733 Stick2 G#3 83 Bell
A 3 729 GuiroSwp A 3 603 PlayFxGt6 A 3 1217 HHOpHuman A 3 701 Caxixi1-2 A 3 1132 HHCl1St
A#3 731 SurdoMt A#3 601 PlayFxGt4 A#3 554 VoxHitRev A#3 703 Caxixi2 A#3 1199 HHOpAnCR
B 3 730 SurdoOp B 3 610 PlayFxGt13 B 3 552 HiQ1 B 3 562 DoorSqk B 3 505 BellAir
C 4 719 PandierTip C 4 609 PlayFxGt12 C 4 552 HiQ1 C 4 562 DoorSqk C 4 504 WindChime
C#4 720 PandroHeel C#4 615 PlayFxABa5 C#4 533 LfoSeq C#4 728 GuiroShort C#4 1184 HHOpRkL
D 4 718 PandierThm D 4 616 PlayFxABa6 D 4 533 LfoSeq D 4 727 GuiroLong D 4 521 Lektronica
D#4 717 PandieroOp D#4 594 PickNoise1 D#4 505 BellAir D#4 735 Clave D#4 725 AgogoLo
E 4 722 TmbourmFng E 4 594 PickNoise1 E 4 511 HH Hit E 4 736 WoodBlock E 4 745 Cowbel1
F 4 723 TmbourimMt F 4 596 PickNoise3 F 4 511 HH Hit F 4 736 WoodBlock F 4 746 Cowbell2
F#4 721 TmbourimOp F#4 604 PlayFxGt7 F#4 525 OohFB F#4 562 DoorSqk F#4 513 HiLo
G 4 726 AgogoLoTap G 4 605 PlayFxGt8 G 4 525 OohFB G 4 562 DoorSqk G 4 513 HiLo
G#4 725 AgogoLo G#4 595 PickNoise2 G#4 528 Mind Bell G#4 736 WoodBlock G#4 741 TriangleMt
A 4 724 AgogoHi A 4 595 PickNoise2 A 4 547 Glass A 4 735 Clave A 4 740 TriangleOp
A#4 740 TriangleOp A#4 600 PlayFxGt3 A#4 519 Swarm A#4 562 DoorSqk A#4 504 WindChime
B 4 741 TriangleMt B 4 655 PlyFxSl18S B 4 557 FxGun2 B 4 743 HandClapL B 4 750 SleighBel
C 5 692 GanzaAc C 5 606 PlayFxGt9 C 5 521 Lektronica C 5 749 ChaCha C 5 751 BellTree
C#5 693 GanzaBk C#5 607 PlayFxGt10 C#5 609 PlayFxGt12 C#5 1001 SdRkOp2St C#5 87 SmBell
D 5 694 GanzaFw D 5 608 PlayFxGt11 D 5 570 Gunshot D 5 831 BdJngl3 D 5 87 SmBell
D#5 699 Cabasa1 D#5 598 PlayFxGt1 D#5 561 Police D#5 666 QuintSlp D#5 86 BrBell
E 5 700 Cabasa2 E 5 599 PlayFxGt2 E 5 546 Ripper E 5 809 BdRoom2 E 5 88 Hibasi
F 5 702 Caxixi1 F 5 600 PlayFxGt3 F 5 604 PlayFxGt7 F 5 788 BdHSonSt F 5 76 Harpsicord
F#5 703 Caxixi2 F#5 601 PlayFxGt4 F#5 556 TapeRewnd F#5 1024 SdHeavy F#5 1021 SdLdwHMono
G 5 673 CuicaLo G 5 653 PlyFxSl17S G 5 558 FxGun1 G 5 614 PlayFxABa4 G 5 78 Vibraphone
G#5 674 CuicaHi G#5 634 PlyFxSlp7H G#5 555 Bomb G#5 1026 SdRkStk1St G#5 1022 SdBrRim
A 5 738 Whistle A 5 633 PlyFxSlp7S A 5 551 Zap2 A 5 859 BdSlimy A 5 358 Gamelan2
A#5 738 Whistle A#5 656 PlyFxSl18H A#5 549 NzBurst A#5 1019 SdGate1 A#5 376 UdoFinger
B 5 737 Vibraslap B 5 657 PlyFxSl19S B 5 539 StabGiant B 5 794 BdFkSonSt B 5 89 FingerCym
C 6 751 BellTree C 6 659 PlyFxSl20S C 6 538 StabOrch C 6 811 BdGate C 6 83 Bell
16
PRE 41 Hands Kit PRE 42 Scratches PRE 43 AcstSnares PRE 44 StSnares PRE 45 AllKicks
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 374 TablaMut C 0 573 Scratch H C 0 866 SdNm1St C 0 860 SdNmSt1-4 C 0 764 BdNmSt1-2
C#0 1057 SdBrMtSt C#0 574 Scratch L C#0 867 SdNm2St C#0 861 SdNmSt1-3 C#0 765 BdNm1St
D 0 1063 SdBrSwrSt D 0 575 ScratchDwn D 0 868 SdNm3St D 0 862 SdNmSt2-4 D 0 766 BdNm2St
D#0 1060 SdBrMt2St D#0 576 ScratchHiF D#0 869 SdNm4St D#0 863 SdNmSt1-2 D#0 767 BdNmL1-2
E 0 1066 SdBSwrAtSt E 0 577 ScratchHiR E 0 884 SdFk1St E 0 864 SdNmSt2-3 E 0 773 BdFkSt1-2
F 0 657 PlyFxSl19S F 0 578 ScratchLoF F 0 885 SdFk2St F 0 865 SdNmSt3-4 F 0 774 BdFk1St
F#0 614 PlayFxABa4 F#0 579 ScratchLoR F#0 886 SdFk3St F#0 866 SdNm1St F#0 775 BdFk2St
G 0 718 PandierThm G 0 580 ScratchBdF G 0 895 SdFkAySt G 0 867 SdNm2St G 0 782 BdHiSt
G#0 374 TablaMut G#0 581 ScratchBdR G#0 902 SdBs1St G#0 868 SdNm3St G#0 785 BdLoSt
A 0 648 PlyFxSl14H A 0 582 ScratchSdF A 0 903 SdBs2St A 0 869 SdNm4St A 0 788 BdHSonSt
A#0 614 PlayFxABa4 A#0 583 ScratchSdR A#0 904 SdBs3St A#0 880 SdFkSt1-3 A#0 791 BdLSonSt
B 0 375 TabraCmb B 0 584 ScratchVoF B 0 919 SdSon1St B 0 881 SdFkSt1-2 B 0 794 BdFkSonSt
C 1 367 Wataiko C 1 573 Scratch H C 1 920 SdSon2St C 1 882 SdFkSt2-3 C 1 797 BdRk1St
C#1 667 QuintTip C#1 574 Scratch L C#1 921 SdSon3St C#1 883 SdFkSt1/3 C#1 800 BdRk2St
D 1 1060 SdBrMt2St D 1 575 ScratchDwn D 1 922 SdSon4St D 1 884 SdFk1St D 1 803 BdDry1
D#1 742 HandClapSt D#1 576 ScratchHiF D#1 937 SdBl1St D#1 885 SdFk2St D#1 804 BdDry2
E 1 895 SdFkAySt E 1 577 ScratchHiR E 1 938 SdBl2St E 1 886 SdFk3St E 1 805 BdPop
F 1 378 Udo Low F 1 578 ScratchLoF F 1 939 SdBl3St F 1 895 SdFkAySt F 1 806 BdVar1
F#1 374 TablaMut F#1 579 ScratchLoR F#1 952 SdBh1St F#1 898 SdBsSt1-3 F#1 807 BdVar2
G 1 378 Udo Low G 1 580 ScratchBdF G 1 953 SdBh2St G 1 899 SdBsSt1-2 G 1 808 BdRoom1
G#1 372 TabraBya G#1 581 ScratchBdR G#1 954 SdBh3St G#1 900 SdBsSt2-3 G#1 809 BdRoom2
A 1 377 Udo Hi A 1 582 ScratchSdF A 1 969 SdLdw1St A 1 901 SdBsSt1/3 A 1 810 BdRoom3
A#1 373 TabraNah A#1 583 ScratchSdR A#1 970 SdLdw2St A#1 902 SdBs1St A#1 811 BdGate
B 1 377 Udo Hi B 1 584 ScratchVoF B 1 971 SdLdw3St B 1 903 SdBs2St B 1 812 BdFXGate
C 2 376 UdoFinger C 2 585 ScratchVoR C 2 972 SdLdw4St C 2 904 SdBs3St C 2 813 BdT9-1
C#2 1260 RideR C#2 586 ScratchStp C#2 984 SdHip1St C#2 913 SdSonSt1-4 C#2 814 BdT9-2
D 2 376 UdoFinger D 2 587 ScratchSpn D 2 985 SdHip2St D 2 914 SdSonSt1-3 D 2 815 BdT9-3
D#2 1261 CupSt D#2 588 ScrathcHip D#2 992 SdRkOp1St D#2 915 SdSonSt2-4 D#2 816 BdT9-4
E 2 1266 CupMono2 E 2 589 ScratchHp2 E 2 995 SdRkMte1St E 2 916 SdSonSt1-2 E 2 817 BdT9Hd1
F 2 1261 CupSt F 2 590 ScratchCmb F 2 998 SdRkRim1St F 2 917 SdSonSt2-3 F 2 818 BdT9Hd2
F#2 715 TambrnHit F#2 591 ScratchCb2 F#2 1001 SdRkOp2St F#2 918 SdSonSt3-4 F#2 819 BdT9Hd3
G 2 1261 CupSt G 2 592 ScratchCb3 G 2 1004 SdRkMte2St G 2 919 SdSon1St G 2 820 BdT8-1
G#2 745 Cowbel1 G#2 593 ScratchCb4 G#2 1007 SdRkRim2St G#2 920 SdSon2St G#2 821 BdT8-2
A 2 1264 RideMono A 2 573 Scratch H A 2 1010 SdRkFlmSt A 2 921 SdSon3St A 2 822 BdT8-3
A#2 737 Vibraslap A#2 574 Scratch L A#2 992 SdRkOp1St A#2 922 SdSon4St A#2 823 BdAnSm
B 2 1259 RideL B 2 575 ScratchDwn B 2 995 SdRkMte1St B 2 933 SdBlSt1-3 B 2 824 BdAnCR
C 3 675 BongoHi1-2 C 3 576 ScratchHiF C 3 998 SdRkRim1St C 3 934 SdBlSt1-2 C 3 825 BdHuman1
C#3 679 BongoLo1-3 C#3 577 ScratchHiR C#3 1001 SdRkOp2St C#3 935 SdBlSt2-3 C#3 826 BdHuman2
D 3 663 CongaTip D 3 578 ScratchLoF D 3 1004 SdRkMte2St D 3 936 SdBlSt1/3 D 3 827 BdBlip
D#3 662 CongaSlp D#3 579 ScratchLoR D#3 1007 SdRkRim2St D#3 937 SdBl1St D#3 828 BdBlpHd
E 3 661 CongaOp E 3 580 ScratchBdF E 3 1010 SdRkFlmSt E 3 938 SdBl2St E 3 829 BdJngl1
F 3 683 TmbaleH1-3 F 3 581 ScratchBdR F 3 868 SdNm3St F 3 939 SdBl3St F 3 830 BdJngl2
F#3 687 TmbaleL1-3 F#3 582 ScratchSdF F#3 895 SdFkAySt F#3 948 SdBhSt1-3 F#3 831 BdJngl3
G 3 724 AgogoHi G 3 583 ScratchSdR G 3 904 SdBs3St G 3 949 SdBhSt1-2 G 3 832 BdD&B1
G#3 725 AgogoLo G#3 584 ScratchVoF G#3 921 SdSon3St G#3 950 SdBhSt2-3 G#3 833 BdD&B2
A 3 722 TmbourmFng A 3 585 ScratchVoR A 3 954 SdBh3St A 3 951 SdBhSt1/3 A 3 834 BdR&B1
A#3 722 TmbourmFng A#3 586 ScratchStp A#3 971 SdLdw3St A#3 952 SdBh1St A#3 835 BdR&B2
B 3 743 HandClapL B 3 587 ScratchSpn B 3 980 SdLdw3R B 3 953 SdBh2St B 3 836 BdHipDp
C 4 743 HandClapL C 4 588 ScrathcHip C 4 1013 SdPicol C 4 954 SdBh3St C 4 837 BdBrkDp
C#4 727 GuiroLong C#4 589 ScratchHp2 C#4 1014 SdPcRim C#4 963 SdLdwSt1-4 C#4 838 BdBreak1
D 4 727 GuiroLong D 4 590 ScratchCmb D 4 1015 SdPcRim2 D 4 964 SdLdwSt1-3 D 4 839 BdBreak2
D#4 376 UdoFinger D#4 591 ScratchCb2 D#4 1016 SdMid D#4 965 SdLdwSt2-4 D#4 840 BdBreakHvy
E 4 372 TabraBya E 4 592 ScratchCb3 E 4 1017 SdMdRim E 4 966 SdLdwSt1-2 E 4 841 BdBreakHrd
F 4 663 CongaTip F 4 593 ScratchCb4 F 4 1018 SdAmb F 4 967 SdLdwSt2-3 F 4 842 BdDist1
F#4 377 Udo Hi F#4 573 Scratch H F#4 1019 SdGate1 F#4 968 SdLdwSt3-4 F#4 843 BdDist2
G 4 377 Udo Hi G 4 574 Scratch L G 4 1021 SdLdwHMono G 4 969 SdLdw1St G 4 844 BdDist3
G#4 376 UdoFinger G#4 575 ScratchDwn G#4 1022 SdBrRim G#4 970 SdLdw2St G#4 845 BdDist4
A 4 89 FingerCym A 4 576 ScratchHiF A 4 1023 SdDry A 4 971 SdLdw3St A 4 846 BdDist5
A#4 374 TablaMut A#4 577 ScratchHiR A#4 1024 SdHeavy A#4 972 SdLdw4St A#4 847 BdDistRM
B 4 750 SleighBel B 4 578 ScratchLoF B 4 1025 SdGM B 4 984 SdHip1St B 4 848 Bd+HH
C 5 751 BellTree C 5 579 ScratchLoR C 5 1026 SdRkStk1St C 5 992 SdRkOp1St C 5 849 BdFxHmr
C#5 614 PlayFxABa4 C#5 580 ScratchBdF C#5 1029 SdRkStk2St C#5 995 SdRkMte1St C#5 850 BdZapHrd
D 5 613 PlayFxABa3 D 5 581 ScratchBdR D 5 1042 SdClRmSt D 5 998 SdRkRim1St D 5 851 BdZapMid
D#5 613 PlayFxABa3 D#5 582 ScratchSdF D#5 1045 SdClRim2 D#5 1001 SdRkOp2St D#5 852 BdSus
E 5 612 PlayFxABa2 E 5 583 ScratchSdR E 5 1046 SdClRim3 E 5 1004 SdRkMte2St E 5 853 BdTekPower
F 5 613 PlayFxABa3 F 5 584 ScratchVoF F 5 1047 SdRkRolSt F 5 1007 SdRkRim2St F 5 854 BdHardLong
F#5 618 PlayFxABa8 F#5 585 ScratchVoR F#5 1001 SdRkOp2St F#5 1010 SdRkFlmSt F#5 855 BdATite
G 5 669 TumbaOp G 5 586 ScratchStp G 5 1053 SnLvRolSt G 5 1047 SdRkRolSt G 5 856 BdAnHard
G#5 611 PlayFxABa1 G#5 587 ScratchSpn G#5 920 SdSon2St G#5 992 SdRkOp1St G#5 857 BdLofi
A 5 617 PlayFxABa7 A 5 588 ScrathcHip A 5 1056 SdRollMono A 5 1050 SdRkRolDSt A 5 858 BdThkSkn
A#5 378 Udo Low A#5 589 ScratchHp2 A#5 971 SdLdw3St A#5 1001 SdRkOp2St A#5 859 BdSlimy
B 5 371 DjembeCmb B 5 590 ScratchCmb B 5 1057 SdBrMtSt B 5 1053 SnLvRolSt B 5 859 BdSlimy
C 6 670 TumbaSlp C 6 591 ScratchCb2 C 6 1066 SdBSwrAtSt C 6 868 SdNm3St C 6 859 BdSlimy
17
PRE 46 DanceKicks PRE 47 Snare & Fx PRE 48 EasySnares USER 1 RockMono2 USER 2 RockMono3
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 813 BdT9-1 C 0 1113 SdFx1 C 0 C 0 763 AnaClick C 0 763 AnaClick
C#0 813 BdT9-1 C#0 1114 SdFx2 C#0 C#0 1058 SdBrMtL C#0 1058 SdBrMtL
D 0 814 BdT9-2 D 0 1115 SdFx3 D 0 D 0 1064 SdBrSwrL D 0 1064 SdBrSwrL
D#0 815 BdT9-3 D#0 1116 SdFx4 D#0 D#0 1061 SdBrMt2L D#0 1061 SdBrMt2L
E 0 815 BdT9-3 E 0 1118 SdDist E 0 E 0 1067 SdBrSwrAtL E 0 1067 SdBrSwrAtL
F 0 816 BdT9-4 F 0 1119 SdCut F 0 F 0 1054 SnLvRolL F 0 1054 SnLvRolL
F#0 817 BdT9Hd1 F#0 1120 SdDodgH F#0 F#0 734 Castanet F#0 734 Castanet
G 0 818 BdT9Hd2 G 0 1121 SdDodgL G 0 G 0 978 SdLdw2R G 0 973 SdLdwL1-4
G#0 819 BdT9Hd3 G#0 1122 SdFM G#0 G#0 732 Stick G#0 732 Stick
A 0 819 BdT9Hd3 A 0 1124 SdSyn A 0 A 0 805 BdPop A 0 803 BdDry1
A#0 854 BdHardLong A#0 1128 SdHammer A#0 A#0 981 SdLdw4L A#0 1017 SdMdRim
B 0 824 BdAnCR B 0 1129 SdLofi B 0 B 0 772 BdNm2R B 0 807 BdVar2
C 1 813 BdT9-1 C 1 1069 SdT9-1 C 1 1053 SnLvRolSt C 1 803 BdDry1 C 1 810 BdRoom3
C#1 814 BdT9-2 C#1 1070 SdT9-2 C#1 1066 SdBSwrAtSt C#1 1044 SdClRmR C#1 1044 SdClRmR
D 1 815 BdT9-3 D 1 1071 SdT9-3 D 1 1063 SdBrSwrSt D 1 941 SdBlR1-3 D 1 1016 SdMid
D#1 816 BdT9-4 D#1 1072 SdT9-4 D#1 1060 SdBrMt2St D#1 743 HandClapL D#1 743 HandClapL
E 1 817 BdT9Hd1 E 1 1073 SdT9-5 E 1 1057 SdBrMtSt E 1 974 SdLdwR1-4 E 1 1024 SdHeavy
F 1 818 BdT9Hd2 F 1 1074 SdT9Gate F 1 1042 SdClRmSt F 1 1237 TomRkLoL F 1 1242 TmDryLo
F#1 819 BdT9Hd3 F#1 1076 SdT8-1 F#1 1042 SdClRmSt F#1 1175 HHClRk2R F#1 1188 HHClMono
G 1 820 BdT8-1 G 1 1077 SdT8-2 G 1 884 SdFk1St G 1 1237 TomRkLoL G 1 1242 TmDryLo
G#1 821 BdT8-2 G#1 1078 SdT8-3 G#1 884 SdFk1St G#1 1178 HHPdlRkR G#1 1190 HHPdlMono
A 1 822 BdT8-3 A 1 1079 SdT8-4 A 1 884 SdFk1St A 1 1234 TomRkMdL A 1 1241 TomDryHi
A#1 823 BdAnSm A#1 1080 SdT8-5 A#1 885 SdFk2St A#1 1185 HHOpRkR A#1 1189 HHOpMono
B 1 824 BdAnCR B 1 1082 SdAnSm B 1 885 SdFk2St B 1 1234 TomRkMdL B 1 1241 TomDryHi
C 2 825 BdHuman1 C 2 1084 SdAnCR C 2 886 SdFk3St C 2 1232 TomRkHiR C 2 1241 TomDryHi
C#2 826 BdHuman2 C#2 1086 SdHuman1 C#2 886 SdFk3St C#2 1254 CrashL C#2 1254 CrashL
D 2 827 BdBlip D 2 1088 SdJngl1 D 2 937 SdBl1St D 2 1232 TomRkHiR D 2 1241 TomDryHi
D#2 828 BdBlpHd D#2 1089 SdJngl2 D#2 938 SdBl2St D#2 1260 RideR D#2 1260 RideR
E 2 829 BdJngl1 E 2 1090 SdJngl3 E 2 938 SdBl2St E 2 1269 ChinaR E 2 1267 ChinaSt
F 2 830 BdJngl2 F 2 1091 SdJnglFx F 2 939 SdBl3St F 2 1263 CupR F 2 1263 CupR
F#2 831 BdJngl3 F#2 1092 SdD&B1 F#2 939 SdBl3St F#2 759 TambrnRX5 F#2 759 TambrnRX5
G 2 832 BdD&B1 G 2 1093 SdD&B2 G 2 866 SdNm1St G 2 1273 SplashR G 2 1273 SplashR
G#2 833 BdD&B2 G#2 1094 SdD&B3 G#2 867 SdNm2St G#2 745 Cowbel1 G#2 745 Cowbel1
A 2 834 BdR&B1 A 2 1095 SdD&B4 A 2 867 SdNm2St A 2 1254 CrashL A 2 1254 CrashL
A#2 835 BdR&B2 A#2 1096 SdR&B1 A#2 868 SdNm3St A#2 737 Vibraslap A#2 737 Vibraslap
B 2 836 BdHipDp B 2 1097 SdR&B1Rm B 2 868 SdNm3St B 2 1264 RideMono B 2 1264 RideMono
C 3 837 BdBrkDp C 3 1098 SdR&B2 C 3 869 SdNm4St C 3 675 BongoHi1-2 C 3 675 BongoHi1-2
C#3 838 BdBreak1 C#3 1099 SdHip1 C#3 869 SdNm4St C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 839 BdBreak2 D 3 1100 SdHip2 D 3 984 SdHip1St D 3 663 CongaTip D 3 663 CongaTip
D#3 840 BdBreakHvy D#3 1101 SdHip3 D#3 984 SdHip1St D#3 662 CongaSlp D#3 662 CongaSlp
E 3 841 BdBreakHrd E 3 1102 SdHipGate E 3 984 SdHip1St E 3 661 CongaOp E 3 661 CongaOp
F 3 842 BdDist1 F 3 1103 SdHipRm1 F 3 985 SdHip2St F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3
F#3 843 BdDist2 F#3 1104 SdHipRm2 F#3 985 SdHip2St F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3
G 3 844 BdDist3 G 3 1105 SdHipRm3 G 3 919 SdSon1St G 3 724 AgogoHi G 3 724 AgogoHi
G#3 845 BdDist4 G#3 1106 SdHipRm4 G#3 920 SdSon2St G#3 725 AgogoLo G#3 725 AgogoLo
A 3 846 BdDist5 A 3 1107 SdHipRm5 A 3 920 SdSon2St A 3 698 Cabasa1-2 A 3 698 Cabasa1-2
A#3 847 BdDistRM A#3 1109 SdBreak2 A#3 921 SdSon3St A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 848 Bd+HH B 3 1111 SdBreakHvy B 3 921 SdSon3St B 3 738 Whistle B 3 738 Whistle
C 4 849 BdFxHmr C 4 598 PlayFxGt1 C 4 922 SdSon4St C 4 738 Whistle C 4 738 Whistle
C#4 850 BdZapHrd C#4 602 PlayFxGt5 C#4 922 SdSon4St C#4 728 GuiroShort C#4 728 GuiroShort
D 4 851 BdZapMid D 4 609 PlayFxGt12 D 4 902 SdBs1St D 4 727 GuiroLong D 4 727 GuiroLong
D#4 852 BdSus D#4 611 PlayFxABa1 D#4 903 SdBs2St D#4 735 Clave D#4 735 Clave
E 4 853 BdTekPower E 4 618 PlayFxABa8 E 4 903 SdBs2St E 4 736 WoodBlock E 4 736 WoodBlock
F 4 854 BdHardLong F 4 596 PickNoise3 F 4 904 SdBs3St F 4 736 WoodBlock F 4 736 WoodBlock
F#4 855 BdATite F#4 573 Scratch H F#4 904 SdBs3St F#4 674 CuicaHi F#4 674 CuicaHi
G 4 856 BdAnHard G 4 574 Scratch L G 4 969 SdLdw1St G 4 673 CuicaLo G 4 673 CuicaLo
G#4 857 BdLofi G#4 575 ScratchDwn G#4 970 SdLdw2St G#4 741 TriangleMt G#4 741 TriangleMt
A 4 858 BdThkSkn A 4 576 ScratchHiF A 4 970 SdLdw2St A 4 740 TriangleOp A 4 740 TriangleOp
A#4 859 BdSlimy A#4 586 ScratchStp A#4 971 SdLdw3St A#4 704 Shaker1-2 A#4 704 Shaker1-2
B 4 811 BdGate B 4 587 ScratchSpn B 4 971 SdLdw3St B 4 750 SleighBel B 4 750 SleighBel
C 5 812 BdFXGate C 5 546 Ripper C 5 972 SdLdw4St C 5 751 BellTree C 5 751 BellTree
C#5 813 BdT9-1 C#5 549 NzBurst C#5 972 SdLdw4St C#5 1030 SdRkStk2L C#5 1032 SdHpStk1
D 5 814 BdT9-2 D 5 550 Zap1 D 5 952 SdBh1St D 5 1017 SdMdRim D 5 1024 SdHeavy
D#5 815 BdT9-3 D#5 551 Zap2 D#5 953 SdBh2St D#5 991 SdHip2R D#5 1013 SdPicol
E 5 816 BdT9-4 E 5 552 HiQ1 E 5 953 SdBh2St E 5 1016 SdMid E 5 1021 SdLdwHMono
F 5 817 BdT9Hd1 F 5 553 HiQ2 F 5 954 SdBh3St F 5 808 BdRoom1 F 5 802 BdRk2R
F#5 818 BdT9Hd2 F#5 555 Bomb F#5 954 SdBh3St F#5 979 SdLdw3L F#5 1017 SdMdRim
G 5 819 BdT9Hd3 G 5 558 FxGun1 G 5 742 HandClapSt G 5 836 BdHipDp G 5 835 BdR&B2
G#5 828 BdBlpHd G#5 510 Electer G#5 752 ClapT9 G#5 982 SdLdw4R G#5 1019 SdGate1
A 5 835 BdR&B2 A 5 511 HH Hit A 5 753 ClapAnSm A 5 790 BdHSonR A 5 773 BdFkSt1-2
A#5 851 BdZapMid A#5 520 Mother A#5 732 Stick A#5 993 SdRkOp1L A#5 1014 SdPcRim
B 5 854 BdHardLong B 5 544 HitOrch2 B 5 733 Stick2 B 5 805 BdPop B 5 778 BdFkML
C 6 855 BdATite C 6 539 StabGiant C 6 895 SdFkAySt C 6 809 BdRoom2 C 6 809 BdRoom2
18
USER 3 Hip Hop5 USER 4 Hip Hop6 USER 5 T9HipKit2 USER 6 HipStick3 USER 7 HipStick4
Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name Note Wave No. Wave Name
C 0 1032 SdHpStk1 C 0 1032 SdHpStk1 C 0 762 ClaveT8 C 0 1123 SdFMRim C 0 1130 SdRimSE
C#0 552 HiQ1 C#0 551 Zap2 C#0 1073 SdT9-5 C#0 555 Bomb C#0 752 ClapT9
D 0 560 TurnTable D 0 560 TurnTable D 0 560 TurnTable D 0 560 TurnTable D 0 560 TurnTable
D#0 543 Hit Uhh D#0 546 Ripper D#0 532 Quiek D#0 545 VoxDrum D#0 555 Bomb
E 0 586 ScratchStp E 0 589 ScratchHp2 E 0 592 ScratchCb3 E 0 580 ScratchBdF E 0 590 ScratchCmb
F 0 1054 SnLvRolL F 0 1054 SnLvRolL F 0 1054 SnLvRolL F 0 1055 SnLvRolR F 0 1056 SdRollMono
F#0 762 ClaveT8 F#0 762 ClaveT8 F#0 763 AnaClick F#0 736 WoodBlock F#0 1075 SdT9Rim
G 0 1119 SdCut G 0 1109 SdBreak2 G 0 1074 SdT9Gate G 0 1085 SdAnCRRim G 0 1105 SdHipRm3
G#0 1028 SnRkStk1R G#0 1030 SdRkStk2L G#0 1085 SdAnCRRim G#0 1101 SdHip3 G#0 1088 SdJngl1
A 0 814 BdT9-2 A 0 808 BdRoom1 A 0 819 BdT9Hd3 A 0 822 BdT8-3 A 0 810 BdRoom3
A#0 1103 SdHipRm1 A#0 1101 SdHip3 A#0 1070 SdT9-2 A#0 1075 SdT9Rim A#0 1038 SdHpStk6L
B 0 820 BdT8-1 B 0 815 BdT9-3 B 0 818 BdT9Hd2 B 0 820 BdT8-1 B 0 815 BdT9-3
C 1 837 BdBrkDp C 1 834 BdR&B1 C 1 817 BdT9Hd1 C 1 814 BdT9-2 C 1 816 BdT9-4
C#1 1046 SdClRim3 C#1 1030 SdRkStk2L C#1 1075 SdT9Rim C#1 1106 SdHipRm4 C#1 1106 SdHipRm4
D 1 1104 SdHipRm2 D 1 1099 SdHip1 D 1 1069 SdT9-1 D 1 1036 SdHpStk5 D 1 1040 SdHpStk7
D#1 744 HandClapR D#1 744 HandClapR D#1 752 ClapT9 D#1 744 HandClapR D#1 744 HandClapR
E 1 1096 SdR&B1 E 1 1100 SdHip2 E 1 1073 SdT9-5 E 1 1037 SdHpStk6St E 1 1041 SdHipStk8
F 1 754 CongaT8 F 1 754 CongaT8 F 1 1246 TomT9Lo F 1 822 BdT8-3 F 1 754 CongaT8
F#1 1202 HHClT8-1 F#1 1208 HHClHip F#1 1191 HHClT9 F#1 1208 HHClHip F#1 1206 HHClTek
G 1 754 CongaT8 G 1 754 CongaT8 G 1 1246 TomT9Lo G 1 822 BdT8-3 G 1 754 CongaT8
G#1 1203 HHOpT8-1 G#1 1209 HHPdlHip G#1 1192 HHOpT9 G#1 1209 HHPdlHip G#1 1198 HHClAnCR
A 1 754 CongaT8 A 1 754 CongaT8 A 1 1246 TomT9Lo A 1 822 BdT8-3 A 1 754 CongaT8
A#1 1204 HHOpT8-1 A#1 1210 HHOpHip A#1 1192 HHOpT9 A#1 1210 HHOpHip A#1 1207 HHOpTek
B 1 754 CongaT8 B 1 754 CongaT8 B 1 1246 TomT9Lo B 1 822 BdT8-3 B 1 754 CongaT8
C 2 754 CongaT8 C 2 754 CongaT8 C 2 1245 TomT9Hi C 2 822 BdT8-3 C 2 754 CongaT8
C#2 1257 Crash2 C#2 1257 Crash2 C#2 1274 CrashT9 C#2 1257 Crash2 C#2 1257 Crash2
D 2 754 CongaT8 D 2 754 CongaT8 D 2 1245 TomT9Hi D 2 822 BdT8-3 D 2 754 CongaT8
D#2 1260 RideR D#2 1260 RideR D#2 1277 RideT9 D#2 1260 RideR D#2 1260 RideR
E 2 1275 CrashT8 E 2 1275 CrashT8 E 2 1274 CrashT9 E 2 1275 CrashT8 E 2 1275 CrashT8
F 2 1277 RideT9 F 2 1277 RideT9 F 2 1277 RideT9 F 2 1277 RideT9 F 2 1277 RideT9
F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5 F#2 759 TambrnRX5
G 2 1273 SplashR G 2 1273 SplashR G 2 1274 CrashT9 G 2 1273 SplashR G 2 1273 SplashR
G#2 748 MamboBdy G#2 748 MamboBdy G#2 757 CowBelAnCR G#2 748 MamboBdy G#2 748 MamboBdy
A 2 1274 CrashT9 A 2 1274 CrashT9 A 2 1274 CrashT9 A 2 1274 CrashT9 A 2 1274 CrashT9
A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap A#2 737 Vibraslap
B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9 B 2 1277 RideT9
C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2 C 3 675 BongoHi1-2
C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3 C#3 679 BongoLo1-3
D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip D 3 663 CongaTip
D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp D#3 662 CongaSlp
E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp E 3 661 CongaOp
F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3 F 3 683 TmbaleH1-3
F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3 F#3 687 TmbaleL1-3
G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi G 3 724 AgogoHi
G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo G#3 725 AgogoLo
A 3 707 ShakerHip1 A 3 707 ShakerHip1 A 3 698 Cabasa1-2 A 3 707 ShakerHip1 A 3 707 ShakerHip1
A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr A#3 696 MaracasSlr
B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle B 3 738 Whistle
C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle C 4 738 Whistle
C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort C#4 728 GuiroShort
D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong D 4 727 GuiroLong
D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 735 Clave D#4 735 Clave
E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock E 4 736 WoodBlock
F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock F 4 736 WoodBlock
F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi F#4 674 CuicaHi
G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo G 4 673 CuicaLo
G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp A 4 740 TriangleOp
A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2 A#4 704 Shaker1-2
B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel B 4 750 SleighBel
C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree C 5 751 BellTree
C#5 1044 SdClRmR C#5 1046 SdClRim3 C#5 1075 SdT9Rim C#5 1083 SdAnSmRim C#5 1083 SdAnSmRim
D 5 1083 SdAnSmRim D 5 1082 SdAnSm D 5 1073 SdT9-5 D 5 1044 SdClRmR D 5 1073 SdT9-5
D#5 742 HandClapSt D#5 742 HandClapSt D#5 752 ClapT9 D#5 1106 SdHipRm4 D#5 1105 SdHipRm3
E 5 1101 SdHip3 E 5 1098 SdR&B2 E 5 1072 SdT9-4 E 5 1045 SdClRim2 E 5 1043 SdClRmL
F 5 583 ScratchSdR F 5 573 Scratch H F 5 573 Scratch H F 5 574 Scratch L F 5 578 ScratchLoF
F#5 588 ScrathcHip F#5 574 Scratch L F#5 574 Scratch L F#5 575 ScratchDwn F#5 579 ScratchLoR
G 5 581 ScratchBdR G 5 575 ScratchDwn G 5 575 ScratchDwn G 5 576 ScratchHiF G 5 580 ScratchBdF
G#5 585 ScratchVoR G#5 576 ScratchHiF G#5 576 ScratchHiF G#5 578 ScratchLoF G#5 581 ScratchBdR
A 5 589 ScratchHp2 A 5 577 ScratchHiR A 5 577 ScratchHiR A 5 581 ScratchBdR A 5 582 ScratchSdF
A#5 591 ScratchCb2 A#5 578 ScratchLoF A#5 578 ScratchLoF A#5 591 ScratchCb2 A#5 583 ScratchSdR
B 5 593 ScratchCb4 B 5 579 ScratchLoR B 5 579 ScratchLoR B 5 586 ScratchStp B 5 584 ScratchVoF
C 6 836 BdHipDp C 6 830 BdJngl2 C 6 813 BdT9-1 C 6 827 BdBlip C 6 821 BdT8-2
19
USER 8 R&B Kit3 GM Drum 1 Stereo GM
Note Wave No. Wave Name Note Wave No. Wave Name
C 0 610 PlayFxGt13 C 0 735 Clave
C#0 613 PlayFxABa3 C#0 1057 SdBrMtSt
D 0 614 PlayFxABa4 D 0 1063 SdBrSwrSt
D#0 615 PlayFxABa5 D#0 1060 SdBrMt2St
E 0 651 PlyFxSl16S E 0 1066 SdBSwrAtSt
F 0 621 PlyFxSlp1S F 0 1053 SnLvRolSt
F#0 1279 HHClRL1-4 F#0 734 Castanet
G 0 764 BdNmSt1-2 G 0 866 SdNm1St
G#0 1146 HHPdlSt G#0 732 Stick
A 0 860 SdNmSt1-4 A 0 773 BdFkSt1-2
A#0 1149 HHOpSt A#0 900 SdBsSt2-3
B 0 822 BdT8-3 B 0 782 BdHiSt
C 1 834 BdR&B1 C 1 764 BdNmSt1-2
C#1 1046 SdClRim3 C#1 1042 SdClRmSt
D 1 1014 SdPcRim D 1 860 SdNmSt1-4
D#1 742 HandClapSt D#1 752 ClapT9
E 1 1097 SdR&B1Rm E 1 899 SdBsSt1-2
F 1 822 BdT8-3 F 1 1227 TomFlSt
F#1 1195 HHClT8-2 F#1 1131 HHClSt1-4
G 1 822 BdT8-3 G 1 1224 TomLoSt
G#1 1193 HHClT8-1 G#1 1146 HHPdlSt
A 1 822 BdT8-3 A 1 1224 TomLoSt
A#1 1196 HHOpT8-2 A#1 1149 HHOpSt
B 1 822 BdT8-3 B 1 1221 TomMdSt
C 2 1247 TomT8 C 2 1221 TomMdSt
C#2 1253 CrashSt C#2 1253 CrashSt
D 2 1247 TomT8 D 2 1218 TomHiSt
D#2 1258 RideSt D#2 1258 RideSt
E 2 1267 ChinaSt E 2 1267 ChinaSt
F 2 1261 CupSt F 2 1261 CupSt
F#2 714 TambrnSw F#2 714 TambrnSw
G 2 1256 Crash G 2 1271 SplashSt
G#2 758 AnaShaker G#2 746 Cowbell2
A 2 758 AnaShaker A 2 1305 CrashRL
A#2 761 MarcsT8 A#2 737 Vibraslap
B 2 761 MarcsT8 B 2 1306 RideRL
C 3 692 GanzaAc C 3 675 BongoHi1-2
C#3 693 GanzaBk C#3 679 BongoLo1-3
D 3 694 GanzaFw D 3 663 CongaTip
D#3 695 Maracas1-2 D#3 661 CongaOp
E 3 696 MaracasSlr E 3 669 TumbaOp
F 3 698 Cabasa1-2 F 3 683 TmbaleH1-3
F#3 699 Cabasa1 F#3 687 TmbaleL1-3
G 3 700 Cabasa2 G 3 724 AgogoHi
G#3 701 Caxixi1-2 G#3 725 AgogoLo
A 3 758 AnaShaker A 3 698 Cabasa1-2
A#3 703 Caxixi2 A#3 696 MaracasSlr
B 3 704 Shaker1-2 B 3 738 Whistle
C 4 705 Shaker1 C 4 738 Whistle
C#4 707 ShakerHip1 C#4 728 GuiroShort
D 4 710 ShakerHip4 D 4 727 GuiroLong
D#4 762 ClaveT8 D#4 735 Clave
E 4 666 QuintSlp E 4 736 WoodBlock
F 4 587 ScratchSpn F 4 736 WoodBlock
F#4 577 ScratchHiR F#4 674 CuicaHi
G 4 576 ScratchHiF G 4 673 CuicaLo
G#4 741 TriangleMt G#4 741 TriangleMt
A 4 740 TriangleOp A 4 740 TriangleOp
A#4 719 PandierTip A#4 704 Shaker1-2
B 4 715 TambrnHit B 4 750 SleighBel
C 5 854 BdHardLong C 5 751 BellTree
C#5 1129 SdLofi C#5 940 SdBlL1-3
D 5 1029 SdRkStk2St D 5 963 SdLdwSt1-4
D#5 1013 SdPicol D#5 956 SdBhR1-3
E 5 560 TurnTable E 5 983 SdHipSt1-2
F 5 1098 SdR&B2 F 5 785 BdLoSt
F#5 1152 HHClFtSt F#5 1021 SdLdwHMono
G 5 836 BdHipDp G 5 834 BdR&B1
G#5 1155 HHHlf2St G#5 1024 SdHeavy
A 5 859 BdSlimy A 5 808 BdRoom1
A#5 1158 HHOp2St A#5 1018 SdAmb
B 5 507 TranCho B 5 794 BdFkSonSt
C 6 822 BdT8-3 C 6 809 BdRoom2
20
Wave List
No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name
1 Ap Piano1 St 101 Or Jazz 201 Ba PrecRW 301 Br F.Horn 401 Wv VPStrngSt 501 Me OrchHit 601 Se PlayFxGt4
2 Ap Piano1 L 102 Or Jazz+ 202 Ba PrecRW+ 302 Br F.Horn+ 402 Wv VPStrngL 502 Me VoxBell 602 Se PlayFxGt5
3 Ap Piano1 R 103 Or Jazz- 203 Ba PrecRW- 303 Br F.Horn- 403 Wv VPStrngR 503 Me Melow 603 Se PlayFxGt6
4 Ap Piano1Mono 104 Or Full 204 Ba PrecFW 304 Br Tuba 404 Wv OBStrings 504 Me WindChime 604 Se PlayFxGt7
5 Ap Piano1 St+ 105 Or Full+ 205 Ba PrecFW+ 305 Br Combi1 405 Wv SyzleStrng 505 Me BellAir 605 Se PlayFxGt8
6 Ap Piano1 L+ 106 Or Full- 206 Ba PrecFW- 306 Br Combi2 406 Wv Padd 506 Me BigSyn 606 Se PlayFxGt9
7 Ap Piano1 R+ 107 Or Swish 207 Ba FingerWW 307 Br Combi3 407 Wv Darklight 507 Me TranCho 607 Se PlayFxGt10
8 Ap Piano1 St- 108 Or Swish- 208 Ba FingerWW+ 308 Br Combi4 408 Wv OBBrass 508 Me StabOrgLP 608 Se PlayFxGt11
9 Ap Piano1 L- 109 Or Compact 209 Ba FingerWW- 309 Rd SopranoSax 409 Wv Sync 509 Me Eery 609 Se PlayFxGt12
10 Ap Piano1 R- 110 Or Compact- 210 Ba SlapThmbmf 310 Rd SopranSax+ 410 Wv SyncLd 510 Me Electer 610 Se PlayFxGt13
11 Ap Piano2 St 111 Or Portable 211 Ba SlapThmbff 311 Rd SopranSax- 411 Wv PWMfast 511 Me HH Hit 611 Se PlayFxABa1
12 Ap Piano2 L 112 Or Portable- 212 Ba SlapPull 312 Rd AltoSaxVb 412 Wv PWMslow 512 Me VoxAlk 612 Se PlayFxABa2
13 Ap Piano2 R 113 Or BowNv 213 Ba SlapHarm 313 Rd AltoSaxNv 413 Wv CS80Brass 513 Me HiLo 613 Se PlayFxABa3
14 Ap Piano2Mono 114 Or BowVb 214 Ba SlapFxSoft 314 Rd AltoSaxNv+ 414 Wv P5Saw 514 Me MultiPiano 614 Se PlayFxABa4
15 Ap Piano2 St+ 115 Or Gospel 215 Ba SlapFxHard 315 Rd AltoSaxNv- 415 Wv OBSaw 515 Me AirHoseSt 615 Se PlayFxABa5
16 Ap Piano2 L+ 116 Or Soul 216 Ba Thmb&Fx-mf 316 Rd TenorSax 416 Wv Saw2 516 Me AirHoseL 616 Se PlayFxABa6
17 Ap Piano2 R+ 117 Or 1stFour 217 Ba Thmb&Fx-ff 317 Rd TenorSax+ 417 Wv 3o3Saw 517 Me AirHoseR 617 Se PlayFxABa7
18 Ap Piano2 St- 118 Or Draw 16' 218 Ba Pull&Fx 318 Rd TenorSax- 418 Wv 3o3Saw2 518 Me Bubble 618 Se PlayFxABa8
19 Ap Piano2 L- 119 Or Draw 5 1/3 219 Ba Fretless 319 Rd BaritonSax 419 Wv 3o3Squ 519 Me Swarm 619 Se PlayFxABa9
20 Ap Piano2 R- 120 Or Draw 8' 220 Ba Fretless+ 320 Rd Clarinet 420 Wv 1o1Saw 520 Me Mother 620 Se PlyFxABa10
21 Ap Brite Pno 121 Or Draw 4' 221 Ba Fretless- 321 Rd Oboe 421 Wv 1o1Sub 521 Me Lektronica 621 Se PlyFxSlp1S
22 Ap Brite Pno- 122 Or Draw 2 2/3 222 St ViolinVb 322 Rd EnglishHrn 422 Wv SawSqu 522 Me SpaceScrem 622 Se PlyFxSlp1H
23 Ap CP80 123 Or Draw 2' 223 St ViolinVb+ 323 Rd Basoon 423 Wv SquSaw 523 Me Resonator 623 Se PlyFxSlp2S
24 Ap CP80+ 124 Or Draw 1 3/5 224 St ViolinVb- 324 Rd Bagpipe1 424 Wv MgRamp 524 Me RadioNz 624 Se PlyFxSlp2H
25 Ap CP80- 125 Or Draw 1 1/3 225 St ViolinSpc 325 Rd Bagpipe2 425 Wv MgBass1 525 Me OohFB 625 Se PlyFxSlp3S
26 Ep EP1 Soft 126 Or Draw 1' 226 St ViolinSpc+ 326 Rd SaxBreath 426 Wv MgBass2 526 Me Fairwave 626 Se PlyFxSlp3H
27 Ep EP1 Soft+ 127 Or Draw 1+3 227 St ViolinSpc- 327 Rd Harmonica 427 Wv MgBass3 527 Me Hoo 627 Se PlyFxSlp4S
28 Ep EP1 Soft- 128 Or Draw 1+3+ 228 St ViolaVb 328 Pi FluteVb 428 Wv ModBass 528 Me Mind Bell 628 Se PlyFxSlp4H
29 Ep EP1 Med 129 Or Draw 1+3- 229 St ViolaVb+ 329 Pi FluteVbAtk 429 Wv AnaBass1 529 Me Loop145 629 Se PlyFxSlp5S
30 Ep EP1 Med+ 130 Or Draw 2+4 230 St ViolaVb- 330 Pi Flute 430 Wv AnaBass2 530 Me X-Fade 630 Se PlyFxSlp5H
31 Ep EP1 Med- 131 Or Draw 2+4+ 231 St ViolaSpc 331 Pi Flute+ 431 Wv UniBass 531 Me ResoXFade 631 Se PlyFxSlp6S
32 Ep EP1 Hard 132 Or Draw 2+4- 232 St ViolaSpc+ 332 Pi Flute- 432 Wv AnaBass3 532 Me Quiek 632 Se PlyFxSlp6H
33 Ep EP1 Hard+ 133 Or Draw Even 233 St ViolaSpc- 333 Pi PanFlute 433 Wv AnaBass4 533 Me LfoSeq 633 Se PlyFxSlp7S
34 Ep EP1 Hard- 134 Or Draw Even+ 234 St CelloVb 334 Pi PanFlute- 434 Wv AnaBass5 534 Me Sonar1 634 Se PlyFxSlp7H
35 Ep EP2 Soft1 135 Or Draw Even- 235 St CelloVb+ 335 Pi Shakuhachi 435 Wv AnaBass6 535 Me Sonar2 635 Se PlyFxSlp8S
36 Ep EP2 Soft1+ 136 Or Draw Odd 236 St CelloVb- 336 Pi Recorder 436 Wv T8KickBass 536 Me HitOrch1 636 Se PlyFxSlp8H
37 Ep EP2 Soft1- 137 Or Draw Odd+ 237 St CelloSpc 337 Pi Bottle 437 Wv FMBass1 537 Me HitBrass 637 Se PlyFxSlp9S
38 Ep EP2 Soft2 138 Or Draw Odd- 238 St CelloSpc+ 338 Pi Ocarina 438 Wv FMBass2 538 Me StabOrch 638 Se PlyFxSlp9H
39 Ep EP2 Soft2+ 139 Or Perc 239 St CelloSpc- 339 Pi Whistle 439 Wv FMBass3 539 Me StabGiant 639 Se PlyFxSl10S
40 Ep EP2 Soft2- 140 Or Perc+ 240 St SoloVbCmb 340 Pi BreathO.S. 440 Wv FMBass4 540 Me StabHard 640 Se PlyFxSl10H
41 Ep EP2 Hard1 141 Or Perc- 241 St SoloVbCmb+ 341 Cp SteelDrum 441 Wv FMBass5 541 Me StabOrgan2 641 Se PlyFxSl11S
42 Ep EP2 Hard1+ 142 Or Rotar 242 St SoloVbCmb- 342 Gt Sitar 442 Wv FMBass6 542 Me StabAah 642 Se PlyFxSl11H
43 Ep EP2 Hard1- 143 Or Clack 243 St SoloSpcCmb 343 Gt SitarWv1 443 Wv FMSquare 543 Me Hit Uhh 643 Se PlyFxSl12S
44 Ep EP2 Hard2 144 Or RotarWhstl 244 St SoloSpCmb+ 344 Gt SitarWv2 444 Wv FMShaper 544 Me HitOrch2 644 Se PlyFxSl12H
45 Ep EP2 Hard2+ 145 Or RotarGrit 245 St SoloSpCmb- 345 Gt SitarWv3 445 Wv FMMetal1 545 Me VoxDrum 645 Se PlyFxSl13S
46 Ep EP2 Hard2- 146 Or RotarGrit2 246 St ContraBass 346 Gt SitarWv4 446 Wv FMMetal2 546 Se Ripper 646 Se PlyFxSl13H
47 Ep EP3 Soft1 147 Or SftTmp 247 St EnsMix 347 Gt SitarWv5 447 Wv FMOrgan1 547 Se Glass 647 Se PlyFxSl14S
48 Ep EP3 Soft1+ 148 Or Pipe1St 248 St EnsMixSt 348 Gt SitarWv6 448 Wv FMOrgan2 548 Se IndusTom 648 Se PlyFxSl14H
49 Ep EP3 Soft1- 149 Or Pipe1L 249 St EnsMixL 349 Gt Tambura 449 Wv FMOrgan3 549 Se NzBurst 649 Se PlyFxSl15S
50 Ep EP3 Soft2 150 Or Pipe1R 250 St EnsMixR 350 Gt TamburaWv1 450 Wv FMOrgan4 550 Se Zap1 650 Se PlyFxSl15H
51 Ep EP3 Soft2+ 151 Or Pipe2 251 St EnsMute 351 Gt TamburaWv2 451 Wv FMFunk 551 Se Zap2 651 Se PlyFxSl16S
52 Ep EP3 Soft2- 152 Or Pipe3St 252 St EnsMute- 352 Gt TamburaWv3 452 Wv FMGuitar 552 Se HiQ1 652 Se PlyFxSl16H
53 Ep EP3 Hard1 153 Or Pipe3L 253 St EnsMuteSt 353 Cp HmDulcimar 453 Wv FSBuzz 553 Se HiQ2 653 Se PlyFxSl17S
54 Ep EP3 Hard1+ 154 Or Pipe3R 254 St HardEnsSt 354 Gt Shamisen 454 Wv WetPluck 554 Se VoxHitRev 654 Se PlyFxSl17H
55 Ep EP3 Hard1- 155 Or Pipe4 255 St HardEnsSt+ 355 Gt Koto 455 Wv Lately-S 555 Se Bomb 655 Se PlyFxSl18S
56 Ep EP3 Hard2 156 Or Pipe5 256 St HardEnsSt- 356 Cp Kalimba 456 Wv Lately-L 556 Se TapeRewnd 656 Se PlyFxSl18H
57 Ep EP3 Hard2+ 157 Or Pipe6 257 St HardEnsL 357 Cp Gamelan1 457 Wv P10-1 557 Se FxGun2 657 Se PlyFxSl19S
58 Ep EP3 Hard2- 158 Or Pipe7 258 St HardEnsL+ 358 Cp Gamelan2 458 Wv P10-2 558 Se FxGun1 658 Se PlyFxSl19H
59 Ep Wurli 159 Or Accordion 259 St HardEnsL- 359 Pi Didgerido1 459 Wv P10-3 559 Se Thunder 659 Se PlyFxSl20S
60 Ep Wurli+ 160 Or TangoAcd 260 St HardEnsR 360 Pi Didgerido2 460 Wv P25-1 560 Se TurnTable 660 Se PlyFxSl20H
61 Ep Wurli- 161 Gt Nylon 261 St HardEnsR+ 361 Pi Didgerido3 461 Wv P25-2 561 Se Police 661 Pc CongaOp
62 Ep DX1 162 Gt Nylon Hi 262 St HardEnsR- 362 Pi DidgCmb1 462 Wv P50-1 562 Se DoorSqk 662 Pc CongaSlp
63 Ep DX2 163 Gt NylonHarm 263 St EnsMxLPSt 363 Pi DidgCmb2 463 Wv P50-2 563 Se Heartbeat 663 Pc CongaTip
64 Ep DX3 164 Gt Steel Gtr1 264 St EnsMxLP L 364 Pi Sho 464 Wv TriWv 564 Se Helicopter 664 Pc CongaHeel
65 Ep DX4 165 Gt SteelGtrHi 265 St EnsMxLP R 365 Pc Log1 465 Wv Digi01 565 Se Seashore 665 Pc QuintOp
66 Ep DX5 166 Gt SteelGtrLo 266 St EnsMuteLP 366 Pc Log2 466 Wv Digi02 566 Se Telephone 666 Pc QuintSlp
67 Kb Clav1 167 Gt SteelHarm 267 St EnsMuteLP- 367 Pc Wataiko 467 Wv Digi03 567 Se TelRing 667 Pc QuintTip
68 Kb Clav1+ 168 Gt Steel Gtr2 268 St EnsMutLPSt 368 Pc DjembeEd 468 Wv Digi04 568 Se Bird 668 Pc QuintHeel
69 Kb Clav1- 169 Gt SteelGt2St 269 St HrdEnsLPSt 369 Pc DjembeMt 469 Wv Digi05 569 Se Stream 669 Pc TumbaOp
70 Kb Clav2 170 Gt SteelGt2Hi 270 St HrdEnsLP L 370 Pc DjembeOp 470 Wv Digi06 570 Se Gunshot 670 Pc TumbaSlp
71 Kb Clav2+ 171 Gt SteelGtr2- 271 St HrdEnsLP R 371 Pc DjembeCmb 471 Wv Digi07 571 Se Applause 671 Pc TumbaTip
72 Kb Clav2- 172 Gt Jazz Gtr 272 St Pizzicato 372 Pc TabraBya 472 Wv Digi08 572 Se RainLoop 672 Pc TumbaHeel
73 Kb Clav3 173 Gt VintAmpA 273 St PopPizz 373 Pc TabraNah 473 Wv Digi09 573 Se Scratch H 673 Pc CuicaLo
74 Kb Clav3+ 174 Gt VintAmpB 274 St Harp 374 Pc TablaMut 474 Wv Digi10 574 Se Scratch L 674 Pc CuicaHi
75 Kb Clav3- 175 Gt Strat 275 Br BrsSctSt 375 Pc TabraCmb 475 Wv Digi11 575 Se ScratchDwn 675 Pc BongoHi1-2
76 Kb Harpsicord 176 Gt StratN 276 Br BrsSctSt+ 376 Pc UdoFinger 476 Wv Digi12 576 Se ScratchHiF 676 Pc BongoHi1
77 Cp Celeste 177 Gt StratF 277 Br BrsSctSt- 377 Pc Udo Hi 477 Wv Bel1Wv 577 Se ScratchHiR 677 Pc BongoHi2
78 Cp Vibraphone 178 Gt StratSl 278 Br BrsSctL 378 Pc Udo Low 478 Wv Bel2Wv 578 Se ScratchLoF 678 Pc BongoHHeel
79 Cp Mairmba 179 Gt StratSp 279 Br BrsSctL+ 379 Pc UduCombi 479 Wv DigiVox1 579 Se ScratchLoR 679 Pc BongoLo1-3
80 Cp Glocken 180 Gt StratMute 280 Br BrsSctL- 380 Vo Aahs St 480 Wv DigiVox2 580 Se ScratchBdF 680 Pc BongoLo1
81 Cp Xylophone 181 Gt StratHarm 281 Br BrsSctR 381 Vo Aahs L 481 Wv DigiVox3 581 Se ScratchBdR 681 Pc BongoLo2
82 Cp Tubular 182 Gt Front 282 Br BrsSctR+ 382 Vo Aahs R 482 Wv DigiVox4 582 Se ScratchSdF 682 Pc BongoLo3
83 Cp Bell 183 Gt Dist Gtr 1 283 Br BrsSctR- 383 Vo Ooh St 483 Wv DigiVox5 583 Se ScratchSdR 683 Pc TmbaleH1-3
84 Cp BellSt1 184 Gt Dist2 284 Br Trumpet 384 Vo Ooh L 484 Wv VoxG2 584 Se ScratchVoF 684 Pc TimbaleHi1
85 Cp BellSt2 185 Gt DistMt 285 Br Trumpet+ 385 Vo Ooh R 485 Wv VoxE3 585 Se ScratchVoR 685 Pc TimbaleHi2
86 Cp BrBell 186 Gt Feedback 286 Br Trumpet- 386 Vo ChoBreathL 486 Wv EP Wave 1 586 Se ScratchStp 686 Pc TimbaleHi3
87 Cp SmBell 187 Gt PwrChrdSt 287 Br Trumpet2 387 Vo ChoBreathR 487 Wv EP Wave 2 587 Se ScratchSpn 687 Pc TmbaleL1-3
88 Cp Hibasi 188 Gt PwrChdMono 288 Br Trumpet2+ 388 Vo ChoAahLPSt 488 Wv EP Wave 3 588 Se ScrathcHip 688 Pc TimbaleLo1
89 Cp FingerCym 189 Gt PlayFx 289 Br Trumpet2- 389 Vo ChoAahLPL 489 Wv EP Wave 4 589 Se ScratchHp2 689 Pc TimbaleLo2
90 Cp StoneH 190 Gt PChdSt&Fx 290 Br Trombone 390 Vo ChoAahLPR 490 Wv EP Wave 5 590 Se ScratchCmb 690 Pc TmblPailaH
91 Cp StoneS 191 Gt PChd&Fx 291 Br Trombone- 391 Vo ChoOohLPSt 491 Wv EP Wave 6 591 Se ScratchCb2 691 Pc TmblPailaL
92 Cp Timpani 192 Gt Banjo 292 Br Trombone2 392 Vo ChoOohLPL 492 Wv Org Wave1 592 Se ScratchCb3 692 Pc GanzaAc
93 Or RockVb 193 Ba A Bass 293 Br SiftTrb 393 Vo ChoOohLPR 493 Wv Org Wave2 593 Se ScratchCb4 693 Pc GanzaBk
94 Or RockPc 194 Ba A Bass+ 294 Br SoftFlugel 394 Vo SynVox 494 Wv Org Wave3 594 Se PickNoise1 694 Pc GanzaFw
95 Or Click 195 Ba A Bass- 295 Br SoftFlugl- 395 Vo VoxNoiz 495 Wv Sine 595 Se PickNoise2 695 Pc Maracas1-2
96 Or Rock2 196 Ba A Bass FX 296 Br TrmptMute 396 Vo Itopia 496 Wv Noise 596 Se PickNoise3 696 Pc MaracasSlr
97 Or Rock2+ 197 Ba PickBass 297 Br TrmptMute2 397 Wv ModSaw 497 Wv Mallet 597 Se FretNoise 697 Pc MaracasStc
98 Or Rock2- 198 Ba FingerMM 298 Br TrumptMed 398 Wv FatSaw 498 Wv PnoNP 598 Se PlayFxGt1 698 Pc Cabasa1-2
99 Or JazzPrc 199 Ba FingerMM+ 299 Br TrumptSoft 399 Wv FatSaw- 499 Wv EPNP 599 Se PlayFxGt2 699 Pc Cabasa1
100 Or JazzPrc- 200 Ba FingerMM- 300 Br PicolTrmpt 400 Wv OBModSaw 500 Wv VibeNP 600 Se PlayFxGt3 700 Pc Cabasa2
21
No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name
701 Pc Caxixi1-2 801 Dr BdRk2L 901 Dr SdBsSt1/3 1001 Dr SdRkOp2St 1101 Dr SdHip3 1201 Dr HHPdlBreak 1301 Dr TomFlRL
702 Pc Caxixi1 802 Dr BdRk2R 902 Dr SdBs1St 1002 Dr SdRkOp2L 1102 Dr SdHipGate 1202 Dr HHClD&B 1302 Dr TomRkHiRL
703 Pc Caxixi2 803 Dr BdDry1 903 Dr SdBs2St 1003 Dr SdRkOp2R 1103 Dr SdHipRm1 1203 Dr HHPdlD&B 1303 Dr TomRkMdRL
704 Pc Shaker1-2 804 Dr BdDry2 904 Dr SdBs3St 1004 Dr SdRkMte2St 1104 Dr SdHipRm2 1204 Dr HHOpD&B 1304 Dr TomRkLoRL
705 Pc Shaker1 805 Dr BdPop 905 Dr SdBsL1-3 1005 Dr SdRkMte2L 1105 Dr SdHipRm3 1205 Dr HHRvD&B 1305 Dr CrashRL
706 Pc Shaker2 806 Dr BdVar1 906 Dr SdBsR1-3 1006 Dr SdRkMte2R 1106 Dr SdHipRm4 1206 Dr HHClTek 1306 Dr RideRL
707 Pc ShakerHip1 807 Dr BdVar2 907 Dr SdBs1L 1007 Dr SdRkRim2St 1107 Dr SdHipRm5 1207 Dr HHOpTek 1307 Dr CupRL
708 Pc ShakerHip2 808 Dr BdRoom1 908 Dr SdBs1R 1008 Dr SdRkRim2L 1108 Dr SdBreak1 1208 Dr HHClHip 1308 Dr ChinaRL
709 Pc ShakerHip3 809 Dr BdRoom2 909 Dr SdBs2L 1009 Dr SdRkRim2R 1109 Dr SdBreak2 1209 Dr HHPdlHip 1309 Dr SplashRL
710 Pc ShakerHip4 810 Dr BdRoom3 910 Dr SdBs2R 1010 Dr SdRkFlmSt 1110 Dr SdBreak3 1210 Dr HHOpHip
711 Pc ShekereDw 811 Dr BdGate 911 Dr SdBs3L 1011 Dr SdRkFlmL 1111 Dr SdBreakHvy 1211 Dr HHClLoFi
712 Pc ShekereUp 812 Dr BdFXGate 912 Dr SdBs3R 1012 Dr SdRkFlmR 1112 Dr SdBreakRol 1212 Dr HHOpLoFi
713 Pc ShekereSap 813 Dr BdT9-1 913 Dr SdSonSt1-4 1013 Dr SdPicol 1113 Dr SdFx1 1213 Dr HHClSyn
714 Pc TambrnSw 814 Dr BdT9-2 914 Dr SdSonSt1-3 1014 Dr SdPcRim 1114 Dr SdFx2 1214 Dr HHOpSyn
715 Pc TambrnHit 815 Dr BdT9-3 915 Dr SdSonSt2-4 1015 Dr SdPcRim2 1115 Dr SdFx3 1215 Dr HHClFx
716 Pc TambrnShk 816 Dr BdT9-4 916 Dr SdSonSt1-2 1016 Dr SdMid 1116 Dr SdFx4 1216 Dr HHOpFx
717 Pc PandieroOp 817 Dr BdT9Hd1 917 Dr SdSonSt2-3 1017 Dr SdMdRim 1117 Dr SdClpAna 1217 Dr HHOpHuman
718 Pc PandierThm 818 Dr BdT9Hd2 918 Dr SdSonSt3-4 1018 Dr SdAmb 1118 Dr SdDist 1218 Dr TomHiSt
719 Pc PandierTip 819 Dr BdT9Hd3 919 Dr SdSon1St 1019 Dr SdGate1 1119 Dr SdCut 1219 Dr TomHiL
720 Pc PandroHeel 820 Dr BdT8-1 920 Dr SdSon2St 1020 Dr SdGate2 1120 Dr SdDodgH 1220 Dr TomHiR
721 Pc TmbourimOp 821 Dr BdT8-2 921 Dr SdSon3St 1021 Dr SdLdwHMono 1121 Dr SdDodgL 1221 Dr TomMdSt
722 Pc TmbourmFng 822 Dr BdT8-3 922 Dr SdSon4St 1022 Dr SdBrRim 1122 Dr SdFM 1222 Dr TomMdL
723 Pc TmbourimMt 823 Dr BdAnSm 923 Dr SdSonL1-4 1023 Dr SdDry 1123 Dr SdFMRim 1223 Dr TomMdR
724 Pc AgogoHi 824 Dr BdAnCR 924 Dr SdSonR1-4 1024 Dr SdHeavy 1124 Dr SdSyn 1224 Dr TomLoSt
725 Pc AgogoLo 825 Dr BdHuman1 925 Dr SdSon1L 1025 Dr SdGM 1125 Dr SdClappy 1225 Dr TomLoL
726 Pc AgogoLoTap 826 Dr BdHuman2 926 Dr SdSon1R 1026 Dr SdRkStk1St 1126 Dr SdTimber 1226 Dr TomLoR
727 Pc GuiroLong 827 Dr BdBlip 927 Dr SdSon2L 1027 Dr SdRkStk1L 1127 Dr SdWood 1227 Dr TomFlSt
728 Pc GuiroShort 828 Dr BdBlpHd 928 Dr SdSon2R 1028 Dr SnRkStk1R 1128 Dr SdHammer 1228 Dr TomFlL
729 Pc GuiroSwp 829 Dr BdJngl1 929 Dr SdSon3L 1029 Dr SdRkStk2St 1129 Dr SdLofi 1229 Dr TomFlR
730 Pc SurdoOp 830 Dr BdJngl2 930 Dr SdSon3R 1030 Dr SdRkStk2L 1130 Dr SdRimSE 1230 Dr TomRkHiSt
731 Pc SurdoMt 831 Dr BdJngl3 931 Dr SdSon4L 1031 Dr SdRkStk2R 1131 Dr HHClSt1-4 1231 Dr TomRkHiL
732 Pc Stick 832 Dr BdD&B1 932 Dr SdSon4R 1032 Dr SdHpStk1 1132 Dr HHCl1St 1232 Dr TomRkHiR
733 Dr Stick2 833 Dr BdD&B2 933 Dr SdBlSt1-3 1033 Dr SdHpStk2 1133 Dr HHCl2St 1233 Dr TomRkMdSt
734 Pc Castanet 834 Dr BdR&B1 934 Dr SdBlSt1-2 1034 Dr SdHpStk3 1134 Dr HHCl3St 1234 Dr TomRkMdL
735 Pc Clave 835 Dr BdR&B2 935 Dr SdBlSt2-3 1035 Dr SdHpStk4 1135 Dr HHCl4St 1235 Dr TomRkMdR
736 Pc WoodBlock 836 Dr BdHipDp 936 Dr SdBlSt1/3 1036 Dr SdHpStk5 1136 Dr HHClL1-4 1236 Dr TomRkLoSt
737 Pc Vibraslap 837 Dr BdBrkDp 937 Dr SdBl1St 1037 Dr SdHpStk6St 1137 Dr HHClR1-4 1237 Dr TomRkLoL
738 Pc Whistle 838 Dr BdBreak1 938 Dr SdBl2St 1038 Dr SdHpStk6L 1138 Dr HHCl1L 1238 Dr TomRkLoR
739 Pc TriangleSw 839 Dr BdBreak2 939 Dr SdBl3St 1039 Dr SdHpStk6R 1139 Dr HHCl1R 1239 Dr TomMonoHi
740 Pc TriangleOp 840 Dr BdBreakHvy 940 Dr SdBlL1-3 1040 Dr SdHpStk7 1140 Dr HHCl2L 1240 Dr TomMonoLo
741 Pc TriangleMt 841 Dr BdBreakHrd 941 Dr SdBlR1-3 1041 Dr SdHipStk8 1141 Dr HHCl2R 1241 Dr TomDryHi
742 Pc HandClapSt 842 Dr BdDist1 942 Dr SdBl1L 1042 Dr SdClRmSt 1142 Dr HHCl3L 1242 Dr TmDryLo
743 Pc HandClapL 843 Dr BdDist2 943 Dr SdBl1R 1043 Dr SdClRmL 1143 Dr HHCl3R 1243 Dr TomAmbHi
744 Pc HandClapR 844 Dr BdDist3 944 Dr SdBl2L 1044 Dr SdClRmR 1144 Dr HHCl4L 1244 Dr TomAmbLo
745 Pc Cowbel1 845 Dr BdDist4 945 Dr SdBl2R 1045 Dr SdClRim2 1145 Dr HHCl4R 1245 Dr TomT9Hi
746 Pc Cowbell2 846 Dr BdDist5 946 Dr SdBl3L 1046 Dr SdClRim3 1146 Dr HHPdlSt 1246 Dr TomT9Lo
747 Pc MamboBel 847 Dr BdDistRM 947 Dr SdBl3R 1047 Dr SdRkRolSt 1147 Dr HHPdlL 1247 Dr TomT8
748 Pc MamboBdy 848 Dr Bd+HH 948 Dr SdBhSt1-3 1048 Dr SdRkRolL 1148 Dr HHPdlR 1248 Dr TomSyn1
749 Pc ChaCha 849 Dr BdFxHmr 949 Dr SdBhSt1-2 1049 Dr SdRkRolR 1149 Dr HHOpSt 1249 Dr TomSyn2
750 Pc SleighBel 850 Dr BdZapHrd 950 Dr SdBhSt2-3 1050 Dr SdRkRolDSt 1150 Dr HHOpL 1250 Dr TomAnSm
751 Pc BellTree 851 Dr BdZapMid 951 Dr SdBhSt1/3 1051 Dr SdRkRolDL 1151 Dr HHOpR 1251 Dr TomDistHi
752 Pc ClapT9 852 Dr BdSus 952 Dr SdBh1St 1052 Dr SdRkRolDR 1152 Dr HHClFtSt 1252 Dr TomDistLo
753 Pc ClapAnSm 853 Dr BdTekPower 953 Dr SdBh2St 1053 Dr SnLvRolSt 1153 Dr HHClFtL 1253 Dr CrashSt
754 Pc CongaT8 854 Dr BdHardLong 954 Dr SdBh3St 1054 Dr SnLvRolL 1154 Dr HHClFtR 1254 Dr CrashL
755 Pc CowBelT8 855 Dr BdATite 955 Dr SdBhL1-3 1055 Dr SnLvRolR 1155 Dr HHHlf2St 1255 Dr CrashR
756 Pc CowBelRX11 856 Dr BdAnHard 956 Dr SdBhR1-3 1056 Dr SdRollMono 1156 Dr HHHlf2L 1256 Dr Crash
757 Pc CowBelAnCR 857 Dr BdLofi 957 Dr SdBh1L 1057 Dr SdBrMtSt 1157 Dr HHHlf2R 1257 Dr Crash2
758 Pc AnaShaker 858 Dr BdThkSkn 958 Dr SdBh1R 1058 Dr SdBrMtL 1158 Dr HHOp2St 1258 Dr RideSt
759 Pc TambrnRX5 859 Dr BdSlimy 959 Dr SdBh2L 1059 Dr SdBrMtR 1159 Dr HHOp2L 1259 Dr RideL
760 Pc TambrnAnCR 860 Dr SdNmSt1-4 960 Dr SdBh2R 1060 Dr SdBrMt2St 1160 Dr HHOp2R 1260 Dr RideR
761 Pc MarcsT8 861 Dr SdNmSt1-3 961 Dr SdBh3L 1061 Dr SdBrMt2L 1161 Dr HHClRkStSw 1261 Dr CupSt
762 Pc ClaveT8 862 Dr SdNmSt2-4 962 Dr SdBh3R 1062 Dr SdBrMt2R 1162 Dr HHClRkSSt 1262 Dr CupL
763 Pc AnaClick 863 Dr SdNmSt1-2 963 Dr SdLdwSt1-4 1063 Dr SdBrSwrSt 1163 Dr HHClRkHSt 1263 Dr CupR
764 Dr BdNmSt1-2 864 Dr SdNmSt2-3 964 Dr SdLdwSt1-3 1064 Dr SdBrSwrL 1164 Dr HHClRkLSw 1264 Dr RideMono
765 Dr BdNm1St 865 Dr SdNmSt3-4 965 Dr SdLdwSt2-4 1065 Dr SdBrSwrR 1165 Dr HHClRkRSw 1265 Dr CupMono
766 Dr BdNm2St 866 Dr SdNm1St 966 Dr SdLdwSt1-2 1066 Dr SdBSwrAtSt 1166 Dr HHClRkSL 1266 Dr CupMono2
767 Dr BdNmL1-2 867 Dr SdNm2St 967 Dr SdLdwSt2-3 1067 Dr SdBrSwrAtL 1167 Dr HHClRkSR 1267 Dr ChinaSt
768 Dr BdNmR1-2 868 Dr SdNm3St 968 Dr SdLdwSt3-4 1068 Dr SdBrSwrAtR 1168 Dr HHClRkHL 1268 Dr ChinaL
769 Dr BdNm1L 869 Dr SdNm4St 969 Dr SdLdw1St 1069 Dr SdT9-1 1169 Dr HHClRkHR 1269 Dr ChinaR
770 Dr BdNm1R 870 Dr SdNmL1-4 970 Dr SdLdw2St 1070 Dr SdT9-2 1170 Dr HHPdRkStSw 1270 Dr China
771 Dr BdNm2L 871 Dr SdNmR1-4 971 Dr SdLdw3St 1071 Dr SdT9-3 1171 Dr HHPdlRkLSw 1271 Dr SplashSt
772 Dr BdNm2R 872 Dr SdNm1L 972 Dr SdLdw4St 1072 Dr SdT9-4 1172 Dr HHPdlRkRSw 1272 Dr SplashL
773 Dr BdFkSt1-2 873 Dr SdNm1R 973 Dr SdLdwL1-4 1073 Dr SdT9-5 1173 Dr HHClRk2St 1273 Dr SplashR
774 Dr BdFk1St 874 Dr SdNm2L 974 Dr SdLdwR1-4 1074 Dr SdT9Gate 1174 Dr HHClRk2L 1274 Dr CrashT9
775 Dr BdFk2St 875 Dr SdNm2R 975 Dr SdLdw1L 1075 Dr SdT9Rim 1175 Dr HHClRk2R 1275 Dr CrashT8
776 Dr BdFkL1-2 876 Dr SdNm3L 976 Dr SdLdw1R 1076 Dr SdT8-1 1176 Dr HHPdlRkSt 1276 Dr CrashSyn
777 Dr BdFkR1-2 877 Dr SdNm3R 977 Dr SdLdw2L 1077 Dr SdT8-2 1177 Dr HHPdlRkL 1277 Dr RideT9
778 Dr BdFkML 878 Dr SdNm4L 978 Dr SdLdw2R 1078 Dr SdT8-3 1178 Dr HHPdlRkR 1278 Dr RevCymbal
779 Dr BdFkMR 879 Dr SdNm4R 979 Dr SdLdw3L 1079 Dr SdT8-4 1179 Dr HHOpRkStSw 1279 Dr HHClRL1-4
780 Dr BdFkHL 880 Dr SdFkSt1-3 980 Dr SdLdw3R 1080 Dr SdT8-5 1180 Dr HHOpRkSt 1280 Dr HHCl1RL
781 Dr BdFkHR 881 Dr SdFkSt1-2 981 Dr SdLdw4L 1081 Dr SdT8Rim 1181 Dr HHHfOpRkSt 1281 Dr HHCl2RL
782 Dr BdHiSt 882 Dr SdFkSt2-3 982 Dr SdLdw4R 1082 Dr SdAnSm 1182 Dr HHOpRkLSw 1282 Dr HHCl3RL
783 Dr BdHiL 883 Dr SdFkSt1/3 983 Dr SdHipSt1-2 1083 Dr SdAnSmRim 1183 Dr HHOpRkRSw 1283 Dr HHCl4RL
784 Dr BdHiR 884 Dr SdFk1St 984 Dr SdHip1St 1084 Dr SdAnCR 1184 Dr HHOpRkL 1284 Dr HHPdlRL
785 Dr BdLoSt 885 Dr SdFk2St 985 Dr SdHip2St 1085 Dr SdAnCRRim 1185 Dr HHOpRkR 1285 Dr HHOpRL
786 Dr BdLoL 886 Dr SdFk3St 986 Dr SdHipL1-2 1086 Dr SdHuman1 1186 Dr HHHlfOpRkL 1286 Dr HHClFtRL
787 Dr BdLoR 887 Dr SdFkL1-3 987 Dr SdHipR1-2 1087 Dr SdHuman2 1187 Dr HHHlfOpRkR 1287 Dr HHHlf2RL
788 Dr BdHSonSt 888 Dr SdFkR1-3 988 Dr SdHip1L 1088 Dr SdJngl1 1188 Dr HHClMono 1288 Dr HHOp2RL
789 Dr BdHSonL 889 Dr SdFk1L 989 Dr SdHip1R 1089 Dr SdJngl2 1189 Dr HHOpMono 1289 Dr HHClRkRLSw
790 Dr BdHSonR 890 Dr SdFk1R 990 Dr SdHip2L 1090 Dr SdJngl3 1190 Dr HHPdlMono 1290 Dr HHClRkSRL
791 Dr BdLSonSt 891 Dr SdFk2L 991 Dr SdHip2R 1091 Dr SdJnglFx 1191 Dr HHClT9 1291 Dr HHClRkHRL
792 Dr BdLSonL 892 Dr SdFk2R 992 Dr SdRkOp1St 1092 Dr SdD&B1 1192 Dr HHOpT9 1292 Dr HHPdRkRLSw
793 Dr BdLSonR 893 Dr SdFk3L 993 Dr SdRkOp1L 1093 Dr SdD&B2 1193 Dr HHClT8-1 1293 Dr HHClRk2RL
794 Dr BdFkSonSt 894 Dr SdFk3R 994 Dr SdRkOp1R 1094 Dr SdD&B3 1194 Dr HHOpT8-1 1294 Dr HHPdlRkRL
795 Dr BdFkSonL 895 Dr SdFkAySt 995 Dr SdRkMte1St 1095 Dr SdD&B4 1195 Dr HHClT8-2 1295 Dr HHOpRkRLSw
796 Dr BdFkSonR 896 Dr SdFkAyL 996 Dr SdRkMte1L 1096 Dr SdR&B1 1196 Dr HHOpT8-2 1296 Dr HHOpRkRL
797 Dr BdRk1St 897 Dr SdFkAyR 997 Dr SdRkMte2R 1097 Dr SdR&B1Rm 1197 Dr HHClRX5 1297 Dr HHHfOpRkRL
798 Dr BdRk1L 898 Dr SdBsSt1-3 998 Dr SdRkRim1St 1098 Dr SdR&B2 1198 Dr HHClAnCR 1298 Dr TomHiRL
799 Dr BdRk1R 899 Dr SdBsSt1-2 999 Dr SnRkRim1L 1099 Dr SdHip1 1199 Dr HHOpAnCR 1299 Dr TomMdRL
800 Dr BdRk2St 900 Dr SdBsSt2-3 1000 Dr SdRkRim1R 1100 Dr SdHip2 1200 Dr HHClBreak 1300 Dr TomLoRL
22
Performance List
Bank MSB:63, LSB:64
Number Performance Name Category SubCategory Number Performance Name Category SubCategory
1 Procession Co SEQ 65 Incomplete Co SEQ
2 2001BrsOrc Br SECTION 66 ActionFlik St SECTION
3 RStreet Co SEQ 67 4x4 Co SPLIT
4 Nouveau Me MOTION 68 Swirling Me MOTION
5 GuitarRox Co SPLIT 69 Hot Chili Co SEQ
6 Sprinkler Pd SOFT 70 Awake Me MOTION
7 SoulSpirit Co SPLIT 71 Latin Jam Co SEQ
8 Film Noir Co SPLIT 72 Grand+FM Ap A.PIANO
9 LittleBear Co SEQ 73 My House Co SEQ
10 SynHeaven Me MOTION 74 Paranoid Me MOTION
11 BluesCruis Co SPLIT 75 80CompSplt Co SPLIT
12 SmoothMood Co SPLIT 76 Warm Bell Pd SOFT
13 PopR&B Co SPLIT 77 Nobody Co SPLIT
14 Iron Dance Co SEQ 78 Mantra Co SEQ
15 LittleFox Gt A.GUITAR 79 LoneGitars Gt A.GUITAR
16 Glass+san Me MOTION 80 Tranzlot Me MOTION
17 Big Jon Co SEQ 81 Transfer Co SEQ
18 Wnds&Strgs St SECTION 82 StringSect St SECTION
19 Hip Balad Co SPLIT 83 Hop It Co SEQ
20 Emortion Co SEQ 84 Jambala Co SEQ
21 Rockabilly Gt E.GUITAR 85 Rockn’Rave Co SEQ
22 Waterfowl Me MOTION 86 OnTheEarth Co SPLIT
23 JourneyMan Co SEQ 87 UTAGE Co SPLIT
24 Ba-PnoCmp Co SPLIT 88 Romantic 2 Ap A.PIANO
25 Bass’ndrum Co SEQ 89 Darkside Co SPLIT
26 Fat Stack Pd BRIGHT 90 Talitha Me MOTION
27 Funk Jam Co SPLIT 91 Bebop Trio Co SPLIT
28 ChinaEns Co SPLIT 92 Hwang Ho Co SPLIT
29 A Visit Co SEQ 93 Smoove Co SEQ
30 Race Co SEQ 94 Freedom Co SEQ
31 SongWriter Co SPLIT 95 Overture St SECTION
32 Multiplex Co SEQ 96 Transform Co SEQ
33 Generation Co SEQ 97 PressedBas Co SEQ
34 Orch Theme St SECTION 98 Philharmnc St SECTION
35 HopStringy Co SPLIT 99 GuitarMood Co SPLIT
36 Birth Me MOTION 100 Insanity Se SYNTH
37 Heavy Jam Co SEQ 101 Sub-Urban Co SEQ
38 Utopia Me MOTION 102 Color Gruv Co SEQ
39 Islands Co SPLIT 103 LatinFlavr Dr PERCUSSION
40 Romantic Kb E.PIANO 104 Peace Co SPLIT
41 Afro/House Co SEQ 105 Edgey Co SPLIT
42 Wavepad Pd SOFT 106 Lugosi Me MOTION
43 80AnaSplit Co SPLIT 107 Groovin’EP Co SPLIT
44 Ana Love Pd SOFT 108 Arabian Pd SOFT
45 The Quest Me MOTION 109 Techstep Co SEQ
46 BigBouncer Me MOTION 110 N-yaSpace Me MOTION
47 TradeWinds Me MOTION 111 70th Heroe Or ELECTRIC
48 Wormholez Co SEQ 112 Mo’s SciFi Se SYNTH
49 Lipolectro Co SPLIT 113 Lover Co SEQ
50 Superstrgs St SECTION 114 BrassChord Br SECTION
51 Flip Hop Co SPLIT 115 Hip Space Co SEQ
52 A dream Co SEQ 116 Sweet Ens Rp PIPE
53 VintString Gt E.GUITAR 117 AltrnaRock Co SPLIT
54 Motivation Me MOTION 118 LatinBrass Br SECTION
55 AsianPad Me MOTION 119 Ethno Jam Co SEQ
56 Grand+Dyno Ap A.PIANO 120 Stormy Kb E.PIANO
57 Big D&B Co SEQ 121 Book Him Co SEQ
58 Nast&Clean Co SPLIT 122 MonstrLead Ld HARD
59 RareGroove Co SPLIT 123 Raga #5 Co SEQ
60 Another Pd SOFT 124 Ethnoluv Co SPLIT
61 Pager Co SEQ 125 Coal Co SPLIT
62 Galaxy Co SEQ 126 SonOfMars Me MOTION
63 Pickin8ths Gt E.GUITAR 127 Trance cho Sc HARD
64 HiPa Gruv Me MOTION 128 Velomuv Me MOTION
23
Effect Type List
Effect Category Effect Name LCD MIDI (HEX) No.
MSB LSB REV CHO InsEf1 InsEf2 Var(*)
--- NO EFFECT off 00 00 0 0 0
--- THRU Thru 00 00 0 0
REV
HALL 1 Rev Hall 1 01 00 1 1
HALL 2 Rev Hall 2 01 01 2 2
ROOM 1 Rev Room 1 01 10 3 3
ROOM 2 Rev Room 2 01 11 4 4
ROOM 3 Rev Room 3 01 12 5 5
STAGE 1 Rev Stage 1 01 20 6 6
STAGE 2 Rev Stage 2 01 21 7 7
PLATE Rev Plate 01 30 8 8
WHITE ROOM RevWhiteRoom 01 40 9
TUNNEL Rev Tunnel 01 41 10
BASEMENT Rev Basement 01 42 11
CANYON Rev Canyon 01 43 12
DLY
DELAY L,C,R Delay L,C,R 02 00 9
DELAY L,R Delay L,R 02 10 18 10
ECHO Echo 02 20 19 11
CROSS DELAY Cross Delay 02 30 20 12
CONTROL DELAY (MONO) Ctrl Delay 1 02 40 21 13
CONTROL DELAY (STEREO) Ctrl Delay 2 02 48 22 14
TEMPO DELAY (MONO) TempoDelay 1 02 50 23 15
TEMPO DELAY (STEREO) TempoDelay 2 02 58 24 16
TEMPO CROSS DELAY TempoCrosDly 02 60 25 17
ER
EARLY REFLECTION 1 Early Ref 1 03 00 18
EARLY REFLECTION 2 Early Ref 2 03 01 19
GATE REVERB Gate Reverb 03 10 20
REVERSE GATE Reverse Gate 03 20 21
KAR
KARAOKE 1 Karaoke 1 04 00 22
KARAOKE 2 Karaoke 2 04 01 23
KARAOKE 3 Karaoke 3 04 02 24
CHO
CHORUS 1 Chorus 1 05 00 1 1 25 1
CHORUS 2 Chorus 2 05 01 2 2 26 2
CHORUS 3 Chorus 3 05 02 3 3 27 3
CHORUS 4 Chorus 4 05 08 4 4 28 4
CHORUS 5 Chorus 5 05 09 5 29
CELESTE 1 Celeste 1 05 10 6 5 30 5
CELESTE 2 Celeste 2 05 11 7 6 31 6
CELESTE 3 Celeste 3 05 12 8 7 32 7
CELESTE 4 Celeste 4 05 18 9 8 33 8
SYMPHONIC Symphonic 05 20 10 34
ENSEMBLE DETUNE Ensemble 05 30 11 35
FLG
FLANGER 1 Flanger 1 06 00 12 9 36 9
FLANGER 2 Flanger 2 06 01 13 10 37 10
FLANGER 3 Flanger 3 06 08 14 11 38 11
V-FLANGER V-Flanger 06 10 39
TEMPO FLANGER TempoFlanger 06 50 15 40
DYNAMIC FLANGER DynamFlanger 06 60 41
PHA
PHASER 1 Phaser 1 07 00 16 12 42 12
PHASER 2 Phaser 2 07 08 43
TEMPO PHASER TempoPhaser 07 50 17 44
DYNAMIC PHASER DynamPhaser 07 60 45
MOD
TREMOLO Tremolo 08 00 13 46 13
AUTO PAN Auto Pan 08 10 14 47 14
AUTO PAN 2 Auto Pan 2 08 11 48
ROTARY SPEAKER Rotary SP 1 08 50 49
DISTORTION+ROTARY SPEAKER Dist+RotSp1 08 51 50
OVERDRIVE+ROTARY SPEAKER Odrv+RotSp1 08 52 51
AMP SIM.+ROTARY SPEAKER Amp +RotSp1 08 53 52
2WAY ROTARY SPEAKER Rotary Sp2 08 60 53
DISTORTION+2WAY ROTARY SPEAKER Dist+RotSp2 08 61 54
OVERDRIVE+2WAY ROTARY SPEAKER Odrv+RotSp2 08 62 55
AMP SIM.+2WAY ROTARY SPEAKER Amp +RotSp2 08 63 56
DUAL ROTOR SPEAKER1 Dual RotSp 1 08 70 57
DUAL ROTOR SPEAKER2 Dual RotSp 2 08 71 58
DUAL ROTOR SPEAKER3 Dual RotSp 3 08 72 59
(*) Performance Mode Only.
24
(*) Performance Mode Only.
DST
DISTORTION Distortion 09 00 15 60 15
COMP DISTORTION Comp + Dist 09 01 61
V-DISTORTION V-Distortion 09 10 62
OVER DRIVE Overdrive 09 20 16 63 16
AMP SIMULATOR AmpSimulator 09 30 17 64 17
AMP SIMULATOR 2 AmpSim 2 09 31 18 65 18
DIST+DELAY Dist + Delay 09 40 66
OVERDRIVE+DELAY Odrv + Delay 09 41 67
DYN
COMPRESSOR Compressor 0A 00 19 68 19
NOISE GATE Noise Gate 0A 20 20 69 20
COMP+DIST+DELAY Cmp+Dist+Dly 0A 40 70
COMP+OVERDRIVE+DELAY Cmp+Odrv+Dly 0A 41 71
MULTI BAND COMPRESSOR 1 MltBndComp 1 0A 50 72
MULTI BAND COMPRESSOR 2 MltBndComp 2 0A 51 73
PCH
PITCH CHANGE 1 PitchChange1 0B 00 74
PITCH CHANGE 2 PitchChange2 0B 01 75
WAH
AUTO WAH Auto Wah 0C 00 21 76 21
AUTO WAH + DIST A.Wah+Dist 0C 01 77
AUTO WAH + OVERDRIVE A.Wah+Odrv 0C 02 78
TOUCH WAH Touch Wah 0C 10 22 79 22
TOUCH WAH + DIST T.Wah+Dist 0C 11 80
TOUCH WAH + OVERDRIVE T.Wah+Odrv 0C 12 81
WAH+DIST+DELAY Wah+Dist+Dly 0C 40 82
WAH+OVERDRIVE+DELAY Wah+Odrv+Dly 0C 41 83
L-F
LO-FI Lo-Fi 0D 00 84
LOW RESOLUTION LoResolution 0D 10 85
NOISY Noisy 0D 20 86
ATTACK LO-FI Attack LoFi 0D 30 87
DIGITAL TURNTABLE D.Turntable 0D 50 88
TEC
DIGITAL SCRATCH D.Scratch 0E 00 89
AUTO SYNTH Auto Synth 0E 10 90
TECH MODULATION Tech Mod 0E 20 91
JUMP Jump 0E 30 92
ISOLATION Isolator 0E 40 93
SLICE Slice 0E 50 94
MSC
3-BAND EQ 3 Band EQ 0F 00 23 95 23
2-BAND EQ 2 Band EQ 0F 01 24 96 24
HARMONIC ENHANCER Enhancer 0F 10 25 97 25
VOICE CANCEL Voice Cancel 0F 20 98
AMBIENCE Ambience 0F 30 99
TALKING MODULATOR Talking Mod 0F 40 100
BEAT CHANGE Beat Change 0F 50 101
RING MODULATOR Ring Mod 0F 70 102
DYNAMIC RING MODULATOR DynamRingMod 0F 71 103
DYNAMIC FILTER DynamFilter 0F 78 104
Effect Category Effect Name LCD MIDI (HEX) No.
MSB LSB REV CHO InsEf1 InsEf2 Var(*)
25
Effect Parameter List
1. Reverb
01 HALL 1~08 PLATE
09 WHITE ROOM~12 CANYON
2. Chorus
01 CHORUS 1~09 CELESTE 4
10 SYMPHONIC
11 ENSEMBLE DETUNE
12 FLANGER 1~14 FLANGER 3
15 TEMPO FLANGER
16 PHASER 1
17 TEMPO PHASER
18 DELAY L, R
19 ECHO
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Reverb Time 0.3s~30.0s (0~69) 1 4
2 Initial Delay 0.1ms~200.0ms (0~127) 3 5
3 Reverb Delay 0.1ms~200.0ms (0~127) 6 5
4 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 4 3
5 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 5 3
6 Diffusion 0~10 (0~10) 2
7 Density 0~4 (0~4) 7
8 ER/Rev Balance E63>R~E=R~E<R63 (1~127) 8
9 Feedback Level -63~+63 (1~127) 10
10 Feedback High Damp 0.1~1.0 (1~10) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Reverb Time 0.3s~30.0s (0~69) 1 4
2 Initial Delay 0.1ms~200.0ms (0~127) 3 5
3 Reverb Delay 0.1ms~200.0ms (0~127) 10 5
4 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 4 3
5 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 5 3
6 Diffusion 0~10 (0~10) 2
7 Width 0.5m~30.2m (0~104) 6 11
8 Height 0.5m~30.2m (0~104) 7 11
9 Depth 0.5m~30.2m (0~104) 8 11
10 Wall Vary 0~30 (0~30) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 EQ Low Frequency 32Hz~2.0kHz (4~40) 5 3
4 EQ Low Gain -12dB~+12dB (52~76) 6
5 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
6 EQ High Gain -12dB~+12dB (52~76) 8
7 Delay Offset 0.0ms~50.0ms (0~127) 4 2
8 Feedback Level -63~+63 (1~127) 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Delay Offset 0.0ms~50.0ms (0~127) 3 2
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 4 3
5 EQ Low Gain -12dB~+12dB (52~76) 5
6 EQ High Frequency 500Hz~16.0kHz (28~58) 6 3
7 EQ High Gain -12dB~+12dB (52~76) 7
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Detune -50cent~+50cent (14~114) 1
2 Initial Delay Lch 0.0ms~50.0ms (0~127) 2 2
3 Initial Delay Rch 0.0ms~50.0ms (0~127) 3 2
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (4~124) 5
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 Delay Offset 0.0ms~50.0ms (0~127) 4 2
9 Feedback Level -63~+63 (1~127) 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 16th, 8th/3, 16th., 8th, 4th/3,
8th., 4th, 2nd/3, 4th., 2nd,
Whole/3, 2nd., 4thx4, 4thx5,
4thx6, 4thx7, 4thx8
(5~21) 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (0~2) 5
4 LFO Phase Reset off(free run), Key On Reset,
SEQ Start Reset
(4~124) 6
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
6 EQ Low Gain -12dB~+12dB (52~76) 8
7 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
8 EQ High Gain -12dB~+12dB (52~76) 10
9 Delay Offset 0.0ms~50.0ms (0~127) 4 2
10 Feedback Level -63~+63 (1~127) 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Diffusion mono/stereo (0~1) 6
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
5 EQ Low Gain -12dB~+12dB (52~76) 8
6 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
7 EQ High Gain -12dB~+12dB (52~76) 10
8 Stage 4, 5, 6 (4~6) 5
9 Phase Shift Offset 0~127 (0~127) 3
10 Feedback Level -63~+63 (1~127) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 16th, 8th/3, 16th., 8th, 4th/3,
8th., 4th, 2nd/3, 4th., 2nd,
Whole/3, 2nd., 4thx4, 4thx5,
4thx6, 4thx7, 4thx8
(5~21) 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Reset off(free run), Key On Reset,
SEQ Start Reset
(0~2) 6
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
5 EQ Low Gain -12dB~+12dB (52~76) 8
6 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
7 EQ High Gain -12dB~+12dB (52~76) 10
8 Stage 4, 5, 6 (4~6) 5
9 Phase Shift Offset 0~127 (0~127) 3
10 Feedback Level -63~+63 (1~127) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Lch Delay Time 0.1ms~740.0ms (0~127) 1 19
2 Rch Delay Time 0.1ms~740.0ms (0~127) 2 19
3 Lch Feedback Time 0.1ms~740.0ms (0~127) 3 19
4 Rch Feedback Time 0.1ms~740.0ms (0~127) 4 19
5 Feedback Level -63~+63 (1~127) 5
6 Feedback High Damp 0.1~1.0 (1~10) 6
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
8 EQ Low Gain -12dB~+12dB (52~76) 8
9 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
10 EQ High Gain -12dB~+12dB (52~76) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Lch Delay1 Time 0.1ms~740.0ms (0~127) 1 19
2 Rch Delay1 Time 0.1ms~740.0ms (0~127) 3 19
3 Lch Feedback Level -63~+63 (1~127) 2
4 Rch Feedback Level -63~+63 (1~127) 4
5 Feedback High Damp 0.1~1.0 (1~10) 5
6 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
7 EQ Low Gain -12dB~+12dB (52~76) 7
8 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
9 EQ High Gain -12dB~+12dB (52~76) 9
26
20 CROSS DELAY
21 CONTROL DELAY(MONO)
22 CONTROL DELAY(STEREO)
23 TEMPO DELAY (MONO)~24 TEMPO DELAY (STEREO)
25 TEMPO CROSS DELAY
3. Insertion Effect 2
001 HALL1~008 PLATE
009 DELAY L, C, R
010 DELAY L, R
011 ECHO
012 CROSS DELAY
No. Parameter Range Value
MIDI Parameter
Number
Table
1 L->R Delay Time 0.1ms~740.0ms (0~127) 1 19
2 R->L Delay Time 0.1ms~740.0ms (0~127) 2 19
3 Input Select L, R, L&R (0~2) 4
4 Feedback Level -63~+63 (1~127) 3
5 Feedback High Damp 0.1~1.0 (1~10) 5
6 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
7 EQ Low Gain -12dB~+12dB (52~76) 7
8 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
9 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.1ms~1480.0ms (0~127) 1 20
2 Delay Transition Rate 1~48 (1~48) 2
3 Feedback Level -63~+63 (1~127) 3
4 Feedback High Damp 0.1~1.0 (1~10) 4
5 Delay Time Offset 0~127 (0~127) 5
6 Control Type normal, scratch (0~1) 6
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
8 EQ Low Gain -12dB~+12dB (52~76) 8
9 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
10 EQ High Gain -12dB~+12dB (52~76) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.1ms~740.0ms (0~127) 1 19
2 Delay Transition Rate 1~48 (1~48) 2
3 Feedback Level -63~+63 (1~127) 3
4 Feedback High Damp 0.1~1.0 (1~10) 4
5 Delay Time Offset 0~127 (0~127) 5
6 Control Type normal, scratch (0~1) 6
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
8 EQ Low Gain -12dB~+12dB (52~76) 8
9 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
10 EQ High Gain -12dB~+12dB (52~76) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 1
2 Lag -63ms~+63ms (1~127) 5
3 L/R Diffusion -63ms~+63ms (1~127) 4
4 Feedback Level -63~+63 (1~127) 2
5 Feedback High Dump 0.1~1.0 (1~10) 3
6 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
7 EQ Low Gain -12dB~+12dB (52~76) 7
8 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
9 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 L->R Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 1
2 R->L Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 2
3 Input Select L, R, L&R (0~2) 5
4 Lag -63ms~+63ms (1~127) 6
5 Feedback Level -63~+63 (1~127) 3
6 Feedback High Dump 0.1~1.0 (1~10) 4
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 7 3
8 EQ Low Gain -12dB~+12dB (52~76) 8
9 EQ High Frequency 500Hz~16.0kHz (28~58) 9 3
10 EQ High Gain -12dB~+12dB (52~76) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Reverb Time 0.3s~30.0s (0~69) 1 4
2 Initial Delay 0.1ms~99.3ms (0~63) 3 5
3 Reverb Delay 0.1ms~99.3ms (0~63) 11 5
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 4 3
6 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 5 3
7 Diffusion 0~10 (0~10) 2
8 Density 0~4 (0~4) 12
9 ER/Rev Balance E63>R~E=R~E<R63 (1~127) 13
10 Feedback Level -63~+63 (1~127) 15
11 Feedback High Damp 0.1~1.0 (1~10) 14
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Lch Delay Time 0.1ms~1486.0ms (1~14860 ) 1
2 Rch Delay Time 0.1ms~1486.0ms (1~14860 ) 2
3 Cch Delay Time 0.1ms~1486.0ms (1~14860 ) 3
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 Cch Level 0~127 (0~127) 6
6 Feedback Time 0.1ms~1486.0ms (1~14860 ) 4
7 Feedback Level -63~+63 (1~127) 5
8 Feedback High Damp 0.1~1.0 (1~10) 7
9 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
10 EQ Low Gain -12dB~+12dB (52~76) 14
11 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
12 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Lch Delay Time 0.1ms~1486.0ms (1~14860 ) 1
2 Rch Delay Time 0.1ms~1486.0ms (1~14860 ) 2
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Lch Feedback Time 0.1ms~1486.0ms (1~14860 ) 3
5 Rch Feedback Time 0.1ms~1486.0ms (1~14860 ) 4
6 Feedback Level -63~+63 (1~127) 5
7 Feedback High Damp 0.1~1.0 (1~10) 6
8 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
9 EQ Low Gain -12dB~+12dB (52~76) 14
10 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
11 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Lch Delay1 Time 0.1ms~743.0ms (1~7430 ) 1
2 Rch Delay1 Time 0.1ms~743.0ms (1~7430 ) 3
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Lch Feedback Level -63~+63 (1~127) 2
5 Rch Feedback Level -63~+63 (1~127) 4
6 Feedback High Damp 0.1~1.0 (1~10) 5
7 Lch Delay2 Time 0.1ms~743.0ms (1~7430 ) 6
8 Rch Delay2 Time 0.1ms~743.0ms (1~7430 ) 7
9 Delay2 Level 0~127 (0~127) 8
10 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
11 EQ Low Gain -12dB~+12dB (52~76) 14
12 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
13 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 L->R Delay Time 0.1ms~743.0ms (1~7430 ) 1
2 R->L Delay Time 0.1ms~743.0ms (1~7430 ) 2
3 Input Select L, R, L&R (0~2) 4
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 Feedback Level -63~+63 (1~127) 3
6 Feedback High Damp 0.1~1.0 (1~10) 5
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
8 EQ Low Gain -12dB~+12dB (52~76) 14
9 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
10 EQ High Gain -12dB~+12dB (52~76) 16
27
013 CONTROL DELAY(MONO)
014 CONTROL DELAY (STEREO)
015 TEMPO DELAY (MONO)~016 TEMPO DELAY (STEREO)
017 TEMPO CROSS DELAY
018 EARLY REFLECTION 1~019 EARLY REFLECTION 2
020 GATE REVERB~021 REVERSE GATE
022 KARAOKE 1~024 KARAOKE 3
025 CHORUS 1~033 CELESTE 4
034 SYMPHONIC
035 ENSEMBLE DETUNE
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.1ms~1486.0ms (1~14860 ) 1
2 Delay Transition Rate 1~48 (1~48) 2
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Control Type normal, scratch (0~1) 11
5 Feedback Level -63~+63 (1~127) 3
6 Feedback High Damp 0.1~1.0 (1~10) 4
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
8 EQ Low Gain -12dB~+12dB (52~76) 7
9 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
10 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.1ms~743.0ms (1~7430 ) 1
2 Delay Transition Rate 1~48 (1~48) 2
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Control Type normal, scratch (0~1) 11
5 Feedback Level -63~+63 (1~127) 3
6 Feedback High Damp 0.1~1.0 (1~10) 4
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
8 EQ Low Gain -12dB~+12dB (52~76) 7
9 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
10 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 1
2 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
3 Lag -63ms~+63ms (1~127) 6
4 L/R Diffusion -63ms~+63ms (1~127) 5
5 Feedback Level -63~+63 (1~127) 3
6 Feedback High Dump 0.1~1.0 (1~10) 4
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
8 EQ Low Gain -12dB~+12dB (52~76) 14
9 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
10 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 L->R Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 1
2 R->L Delay Time 32nd, 16th/3, 32nd., 16th,
8th/3, 16th., 8th, 4th/3, 8th.,
4th, 2nd/3, 4th., 2nd
(2~14) 2
3 Input Select L, R, L&R (0~2) 6
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 Lag -63ms~+63ms (1~127) 8
6 Feedback Level -63~+63 (1~127) 4
7 Feedback High Dump 0.1~1.0 (1~10) 5
8 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
9 EQ Low Gain -12dB~+12dB (52~76) 14
10 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
11 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Type S-hall, L-hall, random,
reverse, plate, spring
(0~5) 1
2 Room Size 0.1~20.0 (0~127) 2 6
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Diffusion 0~10 (0~10) 3
5 Initial Delay 0.1ms~200.0ms (0~127) 4 5
6 Liveness 0~10 (0~10) 11
7 Density 0~3 (0~3) 12
8 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 6 3
9 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 7 3
10 Feedback Level -63~+63 (1~127) 5
11 Feedback High Damp 0.1~1.0 (1~10) 13
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Type type-A, type-B (0~1) 1
2 Room Size 0.1~20.0 (0~127) 2 6
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 Diffusion 0~10 (0~10) 3
5 Initial Delay 0.1ms~200.0ms (0~127) 4 5
6 Liveness 0~10 (0~10) 11
7 Density 0~3 (0~3) 12
8 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 6 3
9 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 7 3
10 Feedback Level -63~+63 (1~127) 5
11 Feedback High Damp 0.1~1.0 (1~10) 13
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.1ms~400.0ms (0~127 ) 1 7
2 Feedback Level -63~+63 (1~127) 2
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 3 3
5 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 4 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Input Mode mono/stereo (0~1) 15
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
9 EQ Mid Gain -12dB~+12dB (52~76) 12
10 EQ Mid Width 0.1~12.0 (1~120) 13
11 Delay Offset 0.0ms~50.0ms (0~127) 4 2
12 Feedback Level -63~+63 (1~127) 3
13 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Delay Offset 0.0ms~50.0ms (0~127) 4 2
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
9 EQ Mid Gain -12dB~+12dB (52~76) 12
10 EQ Mid Width 0.1~12.0 (1~120) 13
11 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Detune -50cent~+50cent (14~114) 1
2 Lch Initial Delay 0.0ms~50.0ms (0~127) 2 2
3 Rch Initial Delay 0.0ms~50.0ms (0~127) 3 2
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 11 3
6 EQ Low Gain -12dB~+12dB (52~76) 12
7 EQ High Frequency 500Hz~16.0kHz (28~58) 13 3
8 EQ High Gain -12dB~+12dB (52~76) 14
28
036 FLANGER 1~038 FLANGER 3
039 V-FLANGER
040 TEMPO FLANGER
41 DYNAMIC FLANGER
42 PHASER 1
043 PHASER 2
44 TEMPO PHASER
045 DYNAMIC PHASER
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (4~124) 14
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
9 EQ Mid Gain -12dB~+12dB (52~76) 12
10 EQ Mid Width 0.1~12.0 (1~120) 13
11 Delay Offset 0.0ms~50.0ms (0~127) 4 2
12 Feedback Level -63~+63 (1~127) 3
13 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Wave Triangle, Sine, Random (0~2) 3
4 Modulation Phase -180~+180 (0~16) 5
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
10 EQ Mid Gain -12dB~+12dB (52~76) 12
11 EQ Mid Width 0.1~12.0 (1~120) 13
12 Analog Feel 0~10 (0~10) 16
13 Feedback Level -100~+100% (0~200) 14
14 Feedback High Damp 0.1~1.0 (1~10) 15
15 Delay offset 0.09~36.21ms (0~139) 4
16 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 16th, 8th/3, 16th., 8th, 4th/3,
8th., 4th, 2nd/3, 4th., 2nd,
Whole/3, 2nd., 4thx4, 4thx5,
4thx6, 4thx7, 4thx8
(5~21) 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (4~124) 14
4 LFO Phase Reset off(free run), Key On Reset,
SEQ Start Reset
(0~2) 5
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
10 EQ Mid Gain -12dB~+12dB (52~76) 12
11 EQ Mid Width 0.1~12.0 (1~120) 13
12 Delay offset 0.0ms~50.0ms (0~127) 4 2
13 Feedback Level -63~+63 (1~127) 3
14 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitivity 0~127 (0~127) 1
2 Delay Time Offset 0~127 (0~127) 2
3 Feedback Level -63~+63 (1~127) 3
4 Attack Time 0.3ms~227ms (0~127) 4 17
5 Release Time 2.6ms~2171ms (0~127) 5 18
6 Release Curve 0~127 (0~127) 6
7 Direction up, down (0~1) 7
8 Dyna Threshold Level 0~127 (0~127) 8
9 Dyna Level Offset 0~127 (0~127) 9
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
11 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
12 EQ Low Gain -12dB~+12dB (52~76) 14
13 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
14 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Diffusion mono/stereo (0~1) 12
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 Stage 4, 5, 6, 7, 8, 9, 10, 11, 12 (4~12) 11
9 Phase Shift Offset 0~127 (0~127) 3
10 Feedback Level -63~+63 (1~127) 4
11 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (4~124) 13
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 Stage 3, 4, 5, 6 (3~6) 11
9 Phase Shift Offset 0~127 (0~127) 3
10 Feedback Level -63~+63 (1~127) 4
11 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 16th, 8th/3, 16th., 8th, 4th/3,
8th., 4th, 2nd/3, 4th., 2nd,
Whole/3, 2nd., 4thx4, 4thx5,
4thx6, 4thx7, 4thx8
(5~21) 1
2 LFO Depth 0~127 (0~127) 2
4 LFO Phase Reset off(free run), Key On Reset,
SEQ Start Reset
(0~2) 5
3
LFO Phase Difference (deg)
-180deg~+180deg (4~124) 13
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 Stage 3, 4, 5, 6 (3~6) 11
10 Phase Shift Offset 0~127 (0~127) 3
11 Feedback Level -63~+63 (1~127) 4
12 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitivity 0~127 (0~127) 1
2 Dyna Level Offset 0~127 (0~127) 2
3 Feedback Level -63~+63 (1~127) 3
4 Attack Time 0.3ms~227ms (0~127) 4 17
5 Release Time 2.6ms~2171ms (0~127) 5 18
6 Release Curve 0~127 (0~127) 6
7 Direction up, down (0~1) 7
8 Dyna Threshold Level 0~127 (0~127) 8
9 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
10 Stage 4, 5, 6 (4~6) 11
11 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
12 EQ Low Gain -12dB~+12dB (52~76) 14
13 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
14 EQ High Gain -12dB~+12dB (52~76) 16
29
046 TREMOLO
047 AUTO PAN
048 AUTO PAN 2
049 ROTARY SPEAKER
050 DISTORTION + ROTARY SPEAKER~051 OVERDRIVE + ROTARY SPEAKER
052 AMP SIM. + ROTARY SPEAKER
053 2-WAY ROTARY SPEAKER
054 DISTORTION + 2-WAY ROTARY SPEAKER~055 OVERDRIVE + 2-WAY ROTARY
SPEAKER
056 AMP SIM. + 2-WAY ROTARY SPEAKER
057 DUAL ROTOR SPEAKER 1~059 DUAL ROTOR SPEAKER 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 AM Depth 0~127 (0~127) 2
3 PM Depth 0~127 (0~127) 3
4 LFO Phase Difference -180deg~+180deg (4~124) 14
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
10 EQ Mid Gain -12dB~+12dB (52~76) 12
11 EQ Mid Width 0.1~12.0 (1~120) 13
12 Input Mode mono/stereo (0~1) 15
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 L/R Depth 0~127 (0~127) 2
3 F/R Depth 0~127 (0~127) 3
4 PAN Direction L<>R, L>>R, L<<R, Lturn,
Rturn, L/R
(0~5) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
10 EQ Mid Gain -12dB~+12dB (52~76) 12
11 EQ Mid Width 0.1~12.0 (1~120) 13
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Wave 0~28 (0~28) 2
3 L/R Depth 0~127 (0~127) 3
4 F/R Depth 0~127 (0~127) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 PAN Direction L<>R, L>>R, L<<R, Lturn,
Rturn, L/R
(0~5) 5
10 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
11 EQ Mid Gain -12dB~+12dB (52~76) 12
12 EQ Mid Width 0.1~12.0 (1~120) 13
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
4 EQ Low Gain -12dB~+12dB (52~76) 7
5 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
6 EQ High Gain -12dB~+12dB (52~76) 9
7 EQ Mid Frequency 100Hz~10.0kHz (14~54) 11 3
8 EQ Mid Gain -12dB~+12dB (52~76) 12
9 EQ Mid Width 0.1~12.0 (1~120) 13
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Drive 0~127 (0~127) 14
4 Drive LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 15 3
5 Drive Output Level 0~127 (0~127) 16
6 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
7 EQ Low Gain -12dB~+12dB (52~76) 7
8 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
9 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Amp Type off, stack, combo, tube (0~3) 3
4 Amp Drive 0~127 (0~127) 14
5 Amp LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 15 3
6 Amp Output Level 0~127 (0~127) 16
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
8 EQ Low Gain -12dB~+12dB (52~76) 7
9 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
10 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Rotor Speed 0.0Hz~39.70Hz (0~127) 1 1
2 Drive Low 0~127 (0~127) 2
3 Drive High 0~127 (0~127) 3
4 Low/High Balance L63>H~L=H~L<H63 (1~127) 4
5 Mic L-R Angle 0deg~180deg (0~60) 5
6 Divide Frequency 100Hz~10.0kHz (14~54) 11 3
7 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
8 EQ Low Gain -12dB~+12dB (52~76) 7
9 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
10 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Rotor Speed 0.0Hz~39.70Hz (0~127) 1 1
2 Drive Low 0~127 (0~127) 2
3 Drive High 0~127 (0~127) 3
4 Low/High Balance L63>H~L=H~L<H63 (1~127) 4
5 Mic L-R Angle 0deg~180deg (0~60) 12
6 Divide Frequency 100Hz~10.0kHz (14~54) 11 3
7 Drive 0~127 (0~127) 14
8 Drive LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 15 3
9 Drive Output Level 0~127 (0~127) 16
10 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
11 EQ Low Gain -12dB~+12dB (52~76) 7
12 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
13 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Rotor Speed 0.0Hz~39.70Hz (0~127) 1 1
2 Drive Low 0~127 (0~127) 2
3 Drive High 0~127 (0~127) 3
4 Low/High Balance L63>H~L=H~L<H63 (1~127) 4
5 Mic L-R Angle 0deg~180deg (0~60) 12
6 Divide Frequency 100Hz~10.0kHz (14~54) 11 3
7 Amp Type off, stack, combo, tube (0~3) 13
8 Amp Drive 0~127 (0~127) 14
9 Amp LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 15 3
10 Amp Output Level 0~127 (0~127) 16
11 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
12 EQ Low Gain -12dB~+12dB (52~76) 7
13 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
14 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Speed Control slow, fast (0~1) 16
2 Slow-Fast Time of Rotor 0~127 (0~127) 5
3 Slow-Fast Time of Horn 0~127 (0~127) 6
4 Rotor Speed Slow 0.0Hz~2.65Hz (0~63) 1 1
5 Horn Speed Slow 0.0Hz~2.65Hz (0~63) 2 1
6 Rotor Speed Fast 2.692Hz~39.70Hz (64~127) 3 1
7 Horn Speed Fast 2.692Hz~39.70Hz (64~127) 4 1
8 Mic L-R Angle 0deg~180deg (0~60) 15
9 Drive Low 0~127 (0~127) 7
10 Drive High 0~127 (0~127) 8
11 Low/High Balance L63>H~L=H~L<H63 (1~127) 9
12 EQ Low Frequency 32Hz~2.0kHz (4~40) 11 3
13 EQ Low Gain -12dB~+12dB (52~76) 12
14 EQ High Frequency 500Hz~16.0kHz (28~58) 13 3
15 EQ High Gain -12dB~+12dB (52~76) 14
30
060 DISTORTION, 063 OVERDRIVE
061 COMP DISTORTION
062 V-DISTORTION
064 AMP SIMULATOR
065 AMP SIMULATOR 2
066 DIST + DELAY, 067 OVERDRIVE + DELAY
068 COMPRESSOR
069 NOISE GATE
070 COMP + DIST + DELAY~071 COMP + OVERDRIVE + DELAY
072 MULTI BAND COMPRESSOR 1
073 MULTI BAND COMPRESSOR 2
074 PITCH CHANGE 1~075 PITCH CHANGE 2
In 075 PITCH CHANGE 2, the unit of Fine 1 and Fine 2 (numbers 5 and 6) is cent.
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Drive 0~127 (0~127) 1
2 Edge 0~127 (0~127) 11
3 Output Level 0~127 (0~127) 5
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 2 3
5 EQ Low Gain -12dB~+12dB (52~76) 3
6 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 4 3
7 EQ Mid Frequency 100Hz~10.0kHz (14~54) 7 3
8 EQ Mid Gain -12dB~+12dB (52~76) 8
9 EQ Mid Width 0.1~12.0 (1~120) 9
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Attack 1ms~40ms (0~19) 12 8
2 Release 10ms~680ms (0~15) 13 9
3 Threshold -48dB~-6dB (79~121) 14
4 Ratio 1~20.0 (0~7) 15 10
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 2 3
6 EQ Low Gain -12dB~+12dB (52~76) 3
7 Drive 0~127 (0~127) 1
8 Output Level 0~127 (0~127) 5
9 EQ Mid Frequency 100Hz~10.0kHz (14~54) 7 3
10 EQ Mid Gain -12dB~+12dB (52~76) 8
11 EQ Mid Width 0.1~12.0 (1~120) 9
12 Edge 0~127 (0~127) 11
13 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 4 3
14 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Over Drive 0~100% (0~100) 1
2 Device
Transistor, Vintage Tube,
Dsitortion1, Dsitortion2, Fuzz
(0~4) 2
3 Speaker Type Flat, Stack, Combo, Twin,
Radio, Megaphone
(0~5) 3
4 Presence -10~10 (0~20) 4
5 Lch Delay Time 0.1ms~1486.0ms (1~14860 ) 6
6 Rch Delay Time 0.1ms~1486.0ms (1~14860 ) 7
7 Feedback Time 0.1ms~1486.0ms (1~14860 ) 8
8 Feedback Level -63~+63 (1~127) 9
9 Feedback High Damp 0.1~1.0 (1~10) 12
10 Dist Output Level 0~100% (0~100) 5
11 Delay Mix 0~127 (0~127) 11
12 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 AMP type off, stack, combo, tube (0~3) 2
2 drive 0~127 (0~127) 1
3 edge 0~127 (0~127) 11
4 LPF cutoff frequency 1.0kHz~20.0kHz (34~60) 3 3
5 output level 0~127 (0~127) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 AMP type off, stack, combo, tube,
crunch, hi gain, british
(0~3) 2
2 drive 0~127 (0~127) 1
3 output level 0~127 (0~127) 4
4 LPF cutoff frequency 1.0kHz~20.0kHz (34~60) 3 3
5 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Dist Drive 0~127 (0~127) 6
2 Dist EQ Low Gain -12dB~+12dB (52~76) 8
3 Dist EQ Mid Gain -12dB~+12dB (52~76) 9
4 Dist Output Level 0~127 (0~127) 7
5 Delay Time L 0.1ms~1486.0ms (1~14860) 1
6 Delay Time R 0.1ms~1486.0ms (1~14860) 2
7 Delay Feedback Time 0.1ms~1486.0ms (1~14860) 3
8 Delay Feedback Level -63~+63 (1~127) 4
9 Delay Mix 0~127 (0~127) 5
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Attack 1ms~40ms (0~19) 1 8
2 Release 10ms~680ms (0~15) 2 9
3 Threshold -48dB~-6dB (79~121) 3
4 Ratio 1~20.0 (0~7) 4 10
5 Output Level 0~127 (0~127) 5
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Attack 1ms~40ms (0~19) 1 8
2 Release 10ms~680ms (0~15) 2 9
3 Threshold -72dB~-30dB (55~97) 3
4 Output Level 0~127 (0~127) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Comp Attack 1ms~40ms (0~19) 11 8
2 Comp Release 10ms~680ms (0~15) 12 9
3 Comp Threshold -48dB~-6dB (79~121) 13
4 Comp Ratio 1~20.0 (0~7) 14 10
5 Drive 0~127 (0~127) 4
6 Drive EQ Low Gain -12dB~+12dB (52~76) 6
7 Drive EQ Mid Gain -12dB~+12dB (52~76) 7
8 Drive Output Level 0~127 (0~127) 5
9 Delay Time 0.1ms~1486.0ms (1~14860) 1
10 Delay Feedback Level -63~+63 (1~127) 2
11 Delay Mix 0~127 (0~127) 3
12 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Type Normal, Low, Mid, High,
Low/High, Low/Mid, Mid/
High, Full Bit, Wild, Attacky,
Low End, Hard
(0~11) 1
2 Threshold Offset -32~+32 (32~96) 2
3 Low Gain Offset -63~+63 (1~127) 3
4 Mid Gain Offset -63~+63 (1~127) 4
5 High Gain Offset -63~+63 (1~127) 5
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Low Attack 1ms~200ms (0~29) 1 8
2 Low Release 10ms~3000ms (0~15) 2 9
3 Low Threshold -54dB~-6dB (73~121) 3
4 Low Ratio 1~20.0 (0~7) 4 10
5 Low Gain -
∞
~+18dB (0~55) 5 14
6 Mid Attack 1ms~200ms (0~29) 6 8
7 Mid Release 10ms~3000ms (0~15) 7 9
8 Mid Threshold -54dB~-6dB (73~121) 8
9 Mid Ratio 1~20.0 (0~7) 9 10
10 Mid Gain -
∞
~+18dB (0~55) 10 14
11 High Attack 1ms~200ms (0~29) 11 8
12 High Release 10ms~3000ms (0~15) 12 9
13 High Threshold -54dB~-6dB (73~121) 13
14 High Ratio 1~20.0 (0~7) 14 10
15 High Gain -
∞
~+18dB (0~55) 15 14
16 Divide Freq 32Hz, 1.2kHz~630Hz,
10.0kHz
(0~89) 16 15
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Pitch -24~+24 (40~88) 1
2 Initial Delay 0.1ms~248.9ms (0~79) 2 7
3 Feedback Level -63~+63 (1~127) 5
4 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
5 Fine1 -50~+50 (14~114) 3
6 Fine2 -50~+50 (14~114) 4
7 Pan1 L63~C~R63 (1~127) 11
8 Output Level1 0~127 (0~127) 12
9 Pan2 L63~C~R63 (1~127) 13
10 Output Level2 0~127 (0~127) 14
31
076 AUTO WAH
077 AUTO WAH + DIST~078 AUTO WAH + OVERDRIVE
079 TOUCH WAH
080 TOUCH WAH + DIST~081 TOUCH WAH + OVERDRIVE
082 WAH + DIST + DELAY~083 WAH + OVERDRIVE + DELAY
084 LO-FI
085 LOW RESOLUTION
086 NOISY
087 ATTACK LO-FI
088 DIGITAL TURNTABLE
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Cutoff Frequency Offset 0~127 (0~127) 3
4 Resonance 1~12.0 (10~120) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Cutoff Frequency Offset 0~127 (0~127) 3
4 Resonance 1~12.0 (10~120) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
6 EQ Low Gain -12dB~+12dB (52~76) 7
7 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
8 EQ High Gain -12dB~+12dB (52~76) 9
9 Drive 0~127 (0~127) 11
10 Drive Low Gain -12dB~+12dB (52~76) 12
11 Drive Mid Gain -12dB~+12dB (52~76) 13
12 Drive LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 14 3
13 Drive Output Level 0~127 (0~127) 15
14 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitive 0~127 (0~127) 1
2 Cutoff Frequency Offset 0~127 (0~127) 2
3 Resonance 1~12.0 (10~120) 3
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitive 0~127 (0~127) 1
2 Cutoff Frequency Offset 0~127 (0~127) 2
3 Resonance 1~12.0 (10~120) 3
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
8 Drive 0~127 (0~127) 11
9 Drive Low Gain -12dB~+12dB (52~76) 12
10 Drive Mid Gain -12dB~+12dB (52~76) 13
11 Drive LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 14 3
12 Drive Output Level 0~127 (0~127) 15
13 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Wah Sensitive 0~127 (0~127) 11
2 Wah Cutoff Frequency 0~127 (0~127) 12
3 Wah Resonance 1~12.0 (10~120) 13
4 Wah Release 10ms~680ms (52~67) 14 12
5 Dist Drive 0~127 (0~127) 4
6 Dist EQ Low Gain -12dB~+12dB (52~76) 6
7 Dist EQ Mid Gain -12dB~+12dB (52~76) 7
8 Dist Output Level 0~127 (0~127) 5
9 Delay Time 0.1ms~1486.0ms (1~14860) 1
10 Delay Feedback Level -63~+63 (1~127) 2
11 Delay Mix 0~127 (0~127) 3
12 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sampling Freq. Control 44.1KHz~344.5Hz (0~127) 1
2 Word Length 1~127 (1~127) 2
3 Output Gain -6dB~+36dB (0~42) 3
4 Filter Type thru, Power Bass, Radio,
Telephone, Clean, Low
(0~5) 5
5 Pre-LPF Cutoff Freq 63Hz~20.0kHz (10~60) 4 3
6 Pre-LPF Resonance 1~12.0 (10~120) 6
7 Bit Assign 0~6 (0~6) 7
8 Emphasis off/on (0~1) 8
9 Input Mode mono/stereo (0~1) 15
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Mod Depth 0~127 (0~127) 1
2 Mod Delay Offset 1~127 (1~127) 2
3 Mod Feedback -63~+63 (1~127) 3
4 Mod Mix Balance 0~127 (0~127) 5
5 Resolution 1, 1/2~1/128 (0~7) 4
6 Phase Inverse R off, wet (0~1) 6
7 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Mod Depth 0~10 (0~10) 2
2 Mod Speed 0~127 (0~127) 3
3 Mod Feedback -63~+63 (1~127) 4
4 Mod Mix Balance 1~127 (1~127) 7
5 Drive 0~127 (0~127) 1
6 AM Speed 0.00Hz~39.7Hz (0~127) 5 1
7 AM Depth 0~127 (0~127) 6
8 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 8 3
9 LPF Resonance 1.0~12.0 (10~120) 9
10 EQ Frequency 100Hz~10.0kHz (14~54) 10 3
11 EQ Gain -12~+12dB (52~76) 11
12 EQ Width 1.0~12.0 (10~120) 12
13 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitive 0~127 (0~127) 1
2 Resolution 1, 1/2~1/32 (0~5) 2
3 Peak Frequency 100Hz~10.0kHz (14~54) 3 3
4 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 4 3
5 Flanger Speed 0.00Hz~39.7Hz (0~127) 5 1
6 Flanger LFO Wave tri, sine, saw up, saw down (0~3) 6
7 Flanger Depth 0~127 (0~127) 7
8 Flanger Depth Ofst R -63~+63 (1~127) 8
9 Flanger Delay 0.1~650.0ms (1~6500) 9
10 Flanger Delay Ofst R 0~-884 (0~884) 10
11 Flanger Feedback -63~+63 (1~127) 11
12 Flanger Feedback Ofst R -63~+63 (1~127) 12
13
Flanger Feedback HiDamp
0.1~1.0 (1~10) 13
14 Feedback HiDamp Ofst R -0.9~+0.9 (1~19) 14
15 Flanger Mix Balance 1~127 (1~127) 15
16 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Click Density 0~5 (0~5) 1
2 Click Level 0~127 (0~127) 2
3 Noise Tone 0~6 (0~6) 3
4 Dry Send to Noise 0~127 (0~127) 6
5 Noise Mod Speed 0.00Hz~39.7Hz (0~127) 4 1
6 Noise Mod Depth 0~127 (0~127) 5
7 Noise LPF Freq 1.0kHz~20.0kHz (34~60) 7 3
8 Noise LPF Q 1.0~12.0 (10~120) 8
9 Noise Level 0~127 (0~127) 9
10 Dry LPF Frequency 1.0kHz~20.0kHz (34~60) 10 3
11 Dry Level 0~127 (0~127) 11
32
089 DIGITAL SCRATCH
090 AUTO SYNTH
091 TECH MODULATION
092 JUMP
093 ISOLATION
094 SLICE
095 3-BAND EQ
096 2-BAND EQ
097 HARMONIC ENHANCER
098 VOICE CANCEL
099 AMBIENCE
100 TALKING MODULATOR
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Input Level 0~127 (0~127) 1
2 Initial Delay 0.1~460.0ms (1~4600) 2
3 Scratch Speed 1~127 (1~127) 3
4 Scratch Depth 0~127 (0~127) 4
5 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 10 3
6 Auto Pan Speed 0.00Hz~39.7Hz (0~127) 5 1
7 Auto Pan Depth 0~127 (0~127) 6
8 EQ Frequency 100Hz~10.0kHz (14~54) 7 3
9 EQ Gain -12~+12dB (52~76) 8
10 EQ Width 1.0~12.0 (10~120) 9
11 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Mod Speed 0~127 (0~127) 1
2 Mod Wave Type typeA, typeB, typeC, typeD (0~3) 2
3 Mod Depth 0~127 (0~127) 3
4 Mod Depth Ofst R -63~+63 (1~127) 4
5 HPF Frequency 20Hz~8.0kHz (0~52) 6 3
6 LPF Frequency 1.0kHz~20.0kHz (34~60) 5 3
7 Dry Mix Level 0~127 (0~127) 7
8 Delay Level 0~127 (0~127) 12
9 Delay Time 0.1~370.0ms (1~3700) 8
10 Delay Time Ofst R 0~884 (0~884) 9
11 Feedback Level -63~+63 (1~127) 10
12 FB Level Ofst R -63~+63 (1~127) 11
13 AM Speed 0.00Hz~39.7Hz (0~127) 13 1
14 AM Wave tri, sine, saw up, saw down (0~3) 14
15 AM Depth 0~127 (0~127) 15
16 AM Inverse R normal, inverse (0~1) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Mod Speed 0~127 (0~127) 1
2 Mod Depth 0~127 (0~127) 2
3 Mod Gain -12~+12dB (52~76) 4
4 Mod Mix Balance D63>W~D=W~D<W63 (1~127) 7
5 Pre Mod HPF Cutoff Freq 20Hz~8.0kHz (0~52) 3 3
6 Mod LPF Cutoff Freq 1.0kHz~20.0kHz (34~60) 5 3
7 Mod LPF Resonance 1.0~12.0 (10~120) 6
8 Delay Time 0.1~740.0ms (1~7400) 8
9 Delay Time Ofst R 0~884 (0~884) 9
10 Feedback Level -63~+63 (1~127) 10
11 Feedback Level Ofst R -63~+63 (1~127) 11
12 Feedback Hi Damp 0.1~1.0 (1~10) 12
13 Feedback Hi Damp Ofst R -0.9~+0.9 (1~19) 13
14 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Depth 0~127 (0~127) 1
2 Speed 0~127 (0~127) 2
3 Direction L<>R, L>>R (0~1) 3
4 Type typeA, typeB, typeC (0~2) 4
5 Jump Wave Type typeA, typeB, typeC, typeD (0~3) 5
6 Resolution 1, 1/2~1/256 (0~8) 6
7 HPF Frequency 20Hz~8.0kHz (0~52) 8 3
8 LPF Frequency 1.0kHz~20.0kHz (34~60) 7 3
9 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 On/off SW off, on (0~1) 1
2 Low Level 0~127 (0~127) 2
3 Mid Level 0~127 (0~127) 3
4 High Level 0~127 (0~127) 4
5 Low Mute off/on (0~1) 5
6 Mid Mute off/on (0~1) 6
7 High Mute off/on (0~1) 7
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Divide Type 4th, 8th, 16th (0~2) 1
2 Gate Time 0~100% (0~100) 2
3 Pan AEG Type A~E (0~4) 3
4 Pan AEG Min Level 0~127 (0~127) 4
5 Pan Depth -63~+63 (1~127) 5
6 Divide Min Level 0~127 (0~127) 6
7 Pan Type A~J (0~9) 7
8 Drive 0~127 (0~127) 8
9 AEG Phase 0~15 (x16th note) (0~15) 9
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
11 EQ low frequency 32Hz~2.0kHz (4~40) 13 3
12 EQ low gain -12dB~+12dB (52~76) 14
13 EQ high frequency 500Hz~16.0kHz (28~58) 15 3
14 EQ high gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 EQ Low Frequency 50Hz~2.0kHz (8~40) 6 3
2 EQ Low Gain -12dB~+12dB (52~76) 1
3 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
4 EQ High Gain -12dB~+12dB (52~76) 5
5 EQ Mid Frequency 100H~10.0kHz (14~54) 2 3
6 EQ Mid Gain -12dB~+12dB (52~76) 3
7 EQ Mid Width 0.1~12.0 (1~120) 4
8 Input Mode mono/stereo (0~1) 15
No. Parameter Range Value
MIDI Parameter
Number
Table
1 EQ Low Frequency 32Hz~2.0kHz (4~40) 1 3
2 EQ Low Gain -12dB~+12dB (52~76) 2
3 EQ High Frequency 500Hz~16.0kHz (28~58) 3 3
4 EQ High Gain -12dB~+12dB (52~76) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 HPF Cutoff Frequency 500Hz~16.0kHz (28~58) 1 3
2 Drive 0~127 (0~127) 2
3 Mix Level 0~127 (0~127) 3
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Low Adjust 0~26 (0~26) 11
2 High Adjust 0~26 (0~26) 12
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Delay Time 0.0ms~50.0ms (0~127) 1 2
2 Wet Output Phase normal/inverse (0~1) 2
3 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 6 3
5 EQ Low Gain -12dB~+12dB (52~76) 7
6 EQ High Frequency 500Hz~16.0kHz (28~58) 8 3
7 EQ High Gain -12dB~+12dB (52~76) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Vowel a/i/u/e/o (0~4) 1
2 Move Speed 1~62 (1~62) 2
3 Drive 0~127 (0~127) 3
4 Output Level 0~127 (0~127) 4
33
101 BEAT CHANGE
102 RING MODULATOR
103 DYNAMIC RING MODULATOR
104 DYNAMIC FILTER
4. Insertin Effect 1/Variation Effect (Performance
Mode only)
01 CHORUS 1~08 CELESTE 4
09 FLANGER 1~11 FLANGER 3
12 PHASER 1
13 TREMOLO
14 AUTO PAN
No. Parameter Range Value
MIDI Parameter
Number
Table
1 BeatChange -63~+63 (1~127) 1
2 Beat Range 0~12 (0~12) 2
3 PitchChange -63~+63 (1~127) 3
4 Pitch Range 0~12 (0~12) 4
5 EQ Frequency 32Hz~2.0kHz (4~40) 6
6 EQ Gain -12dB~+12dB (52~76) 7
7 EQ Width 1.0~12.0 (10~120) 8
8 Accuracy Type sound4~normal~rythm4 (0~8) 5
9 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Carrier Freq Coarse 0.5 - 5kHz (0~127) 1 16
2 Carrier Freq Fine 0~127 (0~127) 2
3 LFO Wave tri, sine (0~1) 3
4 LFO Depth 0~127 (0~127) 4
5 LFO Speed 0.0Hz~39.70Hz (0~127) 5 1
6 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 6 3
7 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 7 3
8 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
9 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
10 EQ Low Gain -12dB~+12dB (52~76) 14
11 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
12 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitivity 0~127 (0~127) 1
2 HPF Cutoff Frequency 20Hz~8.0kHz (0~52) 2 3
3 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 3 3
4 Attack Time 0.3ms~227ms (0~127) 4 17
5 Release Time 2.6ms~2171ms (0~127) 5 18
6 Release Curve 0~127 (0~127) 6
7 Direction up, down (0~1) 7
8 Dyna Threshold Level 0~127 (0~127) 8
9 Dyna Level Offset 0~127 (0~127) 9
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
11 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
12 EQ Low Gain -12dB~+12dB (52~76) 14
13 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
14 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Filter Type LPF(12dB), LPF(18dB),
LPF(24dB), HPF, BPF, BEF
(0~5) 1
2 Sensitivity 0~127 (0~127) 2
3 Dyna Level Offset 0~127 (0~127) 3
4 Resonance -16~+111 (0~127) 4
5 Attack Time 0.3ms~227ms (0~127) 5 17
6 Release Time 2.6ms~2171ms (0~127) 6 18
7 Release Curve 0~127 (0~127) 7
8 Direction up, down (0~1) 8
9 Dyna Threshold Level 0~127 (0~127) 9
10 Dry/Wet Balance D63>W~D=W~D<W63 (1~127) 10
11 EQ Low Frequency 32Hz~2.0kHz (4~40) 13 3
12 EQ Low Gain -12dB~+12dB (52~76) 14
13 EQ High Frequency 500Hz~16.0kHz (28~58) 15 3
14 EQ High Gain -12dB~+12dB (52~76) 16
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Input Mode mono/stereo (0~1) 9
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 5 3
5 EQ Low Gain -12dB~+12dB (52~76) 6
6 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
7 EQ High Gain -12dB~+12dB (52~76) 8
8 Delay Offset 0.0ms~50.0ms (0~127) 4 2
9 Feedback Level -63~+63 (1~127) 3
10 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 LFO Phase Difference -180deg~+180deg (4~124) 9
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 5
5 EQ Low Gain -12dB~+12dB (52~76) 6
6 EQ High Frequency 500Hz~16.0kHz (28~58) 7
7 EQ High Gain -12dB~+12dB (52~76) 8
8 Delay Offset 0.0ms~50.0ms (0~127) 4 2
9 Feedback Level -63~+63 (1~127) 3
10 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 EQ Low Frequency 32Hz~2.0kHz (4~40) 6
4 EQ Low Gain -12dB~+12dB (52~76) 7 3
5 EQ High Frequency 500Hz~16.0kHz (28~58) 8
6 EQ High Gain -12dB~+12dB (52~76) 9 3
7 Stage 4, 5, 6 (4~6) 5
8 Phase Shift Offset 0~127 (0~127) 3
9 Feedback Level -63~+63 (1~127) 4
10 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 AM Depth 0~127 (0~127) 2
3 PM Depth 0~127 (0~127) 3
4 LFO Phase Difference -180deg~+180deg (4~124) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 5 3
6 EQ Low Gain -12dB~+12dB (52~76) 6
7 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
8 EQ High Gain -12dB~+12dB (52~76) 8
9 Input Mode mono/stereo (0~1) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 L/R Depth 0~127 (0~127) 2
3 F/R Depth 0~127 (0~127) 3
4 PAN Direction L<>R, L>>R, L<<R, Lturn,
Rturn, L/R
(0~5) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 5 3
6 EQ Low Gain -12dB~+12dB (52~76) 6
7 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
8 EQ High Gain -12dB~+12dB (52~76) 8
34
15 DISTORTION, 16 OVERDRIVE
17 AMP SIMULATOR
18 AMP SIMULATOR 2
19 COMPRESSOR
20 NOISE GATE
21 AUTO WAH
22 TOUCH WAH
23 3-BAND EQ
24 2-BAND EQ
25 HARMONIC ENHANCER
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Drive 0~127 (0~127) 1
2 Edge 0~127 (0~127) 8
3 Output Level 0~127 (0~127) 9
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 2 3
5 EQ Low Gain -12dB~+12dB (52~76) 3
6 LPF Cutoff Frequency 1.0kHz~20.0kHz (34~60) 7 3
7 EQ Mid Frequency 100Hz~10.0kHz (14~54) 4 3
8 EQ Mid Gain -12dB~+12dB (52~76) 5
9 EQ Mid Width 0.1~12.0 (1~120) 6
10 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 10
No. Parameter Range Value
MIDI Parameter
Number
Table
1 AMP type off, stack, combo, tube (0~3) 2
2 drive 0~127 (0~127) 1
3 edge 0~127 (0~127) 4
4 output level 0~127 (0~127) 5
5 LPF cutoff frequency 1.0kHz~20.0kHz (34~60) 3 3
6 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 6
No. Parameter Range Value
MIDI Parameter
Number
Table
1 AMP type off, stack, combo, tube,
crunch, hi gain, british
(0~3) 2
2 drive 0~127 (0~127) 1
3 output level 0~127 (0~127) 4
4 LPF cutoff frequency 1.0kHz~20.0kHz (34~60) 3 3
5 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 5
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Attack 1ms~40ms (0~19) 1 8
2 Release 10ms~680ms (0~15) 2 9
3 Threshold -48dB~-6dB (79~121) 3
4 Ratio 1~20.0 (0~7) 4 10
5 Output Level 0~127 (0~127) 5
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Attack 1ms~40ms (0~19) 1 8
2 Release 10ms~680ms (0~15) 2 9
3 Threshold -72dB~-30dB (55~97) 3
4 Output Level 0~127 (0~127) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 LFO Speed 0.0Hz~39.70Hz (0~127) 1 1
2 LFO Depth 0~127 (0~127) 2
3 Cutoff Frequency Offset 0~127 (0~127) 3
4 Resonance 1~12.0 (10~120) 4
5 EQ Low Frequency 32Hz~2.0kHz (4~40) 5 3
6 EQ Low Gain -12dB~+12dB (52~76) 6
7 EQ High Frequency 500Hz~16.0kHz (28~58) 7 3
8 EQ High Gain -12dB~+12dB (52~76) 8
9 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 9
No. Parameter Range Value
MIDI Parameter
Number
Table
1 Sensitive 0~127 (0~127) 1
2 Cutoff Frequency Offset 0~127 (0~127) 2
3 Resonance 1~12.0 (10~120) 3
4 EQ Low Frequency 32Hz~2.0kHz (4~40) 4 3
5 EQ Low Gain -12dB~+12dB (52~76) 5
6 EQ High Frequency 500Hz~16.0kHz (28~58) 6 3
7 EQ High Gain -12dB~+12dB (52~76) 7
9 Dry / Wet Balance D63>W~D=W~D<W63 (1~127) 8
No. Parameter Range Value
MIDI Parameter
Number
Table
1 EQ Low Frequency 50Hz~2.0kHz (8~40) 1 3
2 EQ Low Gain -12dB~+12dB (52~76) 2
3 EQ High Frequency 500Hz~16.0kHz (28~58) 6 3
4 EQ High Gain -12dB~+12dB (52~76) 7
5 EQ Mid Frequency 100Hz~10.0kHz (14~54) 3 3
6 EQ Mid Gain -12dB~+12dB (52~76) 4
7 EQ Mid Width 0.1~12.0 (1~120) 5
8 Input Mode mono/stereo (0~1) 8
No. Parameter Range Value
MIDI Parameter
Number
Table
1 EQ Low Frequency 32Hz~2.0kHz (4~40) 1 3
2 EQ Low Gain -12dB~+12dB (52~76) 2
3 EQ High Frequency 500H~16.0kHz (28~58) 3 3
4 EQ High Gain -12dB~+12dB (52~76) 4
No. Parameter Range Value
MIDI Parameter
Number
Table
1 HPF Cutoff Frequency 500Hz~16.0kHz (28~58) 1 3
2 Drive 0~127 (0~127) 2
3 Mix Level 0~127 (0~127) 3
35
Effect Data Assign Table
Table#1
LFO Frequency
Data Value Data Value
00.00 642.69
10.04 652.78
20.08 662.86
30.13 672.94
40.17 683.03
50.21 693.11
60.25 703.20
70.29 713.28
80.34 723.37
90.38 733.45
10 0.42 74 3.53
11 0.46 75 3.62
12 0.51 76 3.70
13 0.55 77 3.87
14 0.59 78 4.04
15 0.63 79 4.21
16 0.67 80 4.37
17 0.72 81 4.54
18 0.76 82 4.71
19 0.80 83 4.88
20 0.84 84 5.05
21 0.88 85 5.22
22 0.93 86 5.38
23 0.97 87 5.55
24 1.01 88 5.72
25 1.05 89 6.06
26 1.09 90 6.39
27 1.14 91 6.73
28 1.18 92 7.07
29 1.22 93 7.40
30 1.26 94 7.74
31 1.30 95 8.08
32 1.35 96 8.41
33 1.39 97 8.75
34 1.43 98 9.08
35 1.47 99 9.42
36 1.51 100 9.76
37 1.56 101 10.1
38 1.60 102 10.8
39 1.64 103 11.4
40 1.68 104 12.1
41 1.72 105 12.8
42 1.77 106 13.5
43 1.81 107 14.1
44 1.85 108 14.8
45 1.89 109 15.5
46 1.94 110 16.2
47 1.98 111 16.8
48 2.02 112 17.5
49 2.06 113 18.2
50 2.10 114 19.5
51 2.15 115 20.9
52 2.19 116 22.2
53 2.23 117 23.6
54 2.27 118 24.9
55 2.31 119 26.2
56 2.36 120 27.6
57 2.40 121 28.9
58 2.44 122 30.3
59 2.48 123 31.6
60 2.52 124 33.0
61 2.57 125 34.3
62 2.61 126 37.0
63 2.65 127 39.7
Table#2
Modulation Delay Offset
Data Value Data Value
0 0.0 64 6.4
1 0.1 65 6.5
2 0.2 66 6.6
3 0.3 67 6.7
4 0.4 68 6.8
5 0.5 69 6.9
6 0.6 70 7.0
7 0.7 71 7.1
8 0.8 72 7.2
9 0.9 73 7.3
10 1.0 74 7.4
11 1.1 75 7.5
12 1.2 76 7.6
13 1.3 77 7.7
14 1.4 78 7.8
15 1.5 79 7.9
16 1.6 80 8.0
17 1.7 81 8.1
18 1.8 82 8.2
19 1.9 83 8.3
20 2.0 84 8.4
21 2.1 85 8.5
22 2.2 86 8.6
23 2.3 87 8.7
24 2.4 88 8.8
25 2.5 89 8.9
26 2.6 90 9.0
27 2.7 91 9.1
28 2.8 92 9.2
29 2.9 93 9.3
30 3.0 94 9.4
31 3.1 95 9.5
32 3.2 96 9.6
33 3.3 97 9.7
34 3.4 98 9.8
35 3.5 99 9.9
36 3.6 100 10.0
37 3.7 101 11.1
38 3.8 102 12.2
39 3.9 103 13.3
40 4.0 104 14.4
41 4.1 105 15.5
42 4.2 106 17.1
43 4.3 107 18.6
44 4.4 108 20.2
45 4.5 109 21.8
46 4.6 110 23.3
47 4.7 111 24.9
48 4.8 112 26.5
49 4.9 113 28.0
50 5.0 114 29.6
51 5.1 115 31.2
52 5.2 116 32.8
53 5.3 117 34.3
54 5.4 118 35.9
55 5.5 119 37.5
56 5.6 120 39.0
57 5.7 121 40.6
58 5.8 122 42.2
59 5.9 123 43.7
60 6.0 124 45.3
61 6.1 125 46.9
62 6.2 126 48.4
63 6.3 127 50.0
Table#3
EQ Frequency
Data Value
0 THRU(20)
122
225
328
432
536
640
745
850
956
10 63
11 70
12 80
13 90
14 100
15 110
16 125
17 140
18 160
19 180
20 200
21 225
22 250
23 280
24 315
25 355
26 400
27 450
28 500
29 560
30 630
31 700
32 800
33 900
34 1.0k
35 1.1k
36 1.2k
37 1.4k
38 1.6k
39 1.8k
40 2.0k
41 2.2k
42 2.5k
43 2.8k
44 3.2k
45 3.6k
46 4.0k
47 4.5k
48 5.0k
49 5.6k
50 6.3k
51 7.0k
52 8.0k
53 9.0k
54 10.0k
55 11.0k
56 12.0k
57 14.0k
58 16.0k
59 18.0k
60 THRU(20.0k)
Table#4
Reverb time
Data Value Data Value
0 0.3 64 17.0
1 0.4 65 18.0
2 0.5 66 19.0
3 0.6 67 20.0
4 0.7 68 25.0
5 0.8 69 30.0
60.9
71.0
81.1
91.2
10 1.3
11 1.4
12 1.5
13 1.6
14 1.7
15 1.8
16 1.9
17 2.0
18 2.1
19 2.2
20 2.3
21 2.4
22 2.5
23 2.6
24 2.7
25 2.8
26 2.9
27 3.0
28 3.1
29 3.2
30 3.3
31 3.4
32 3.5
33 3.6
34 3.7
35 3.8
36 3.9
37 4.0
38 4.1
39 4.2
40 4.3
41 4.4
42 4.5
43 4.6
44 4.7
45 4.8
46 4.9
47 5.0
48 5.5
49 6.0
50 6.5
51 7.0
52 7.5
53 8.0
54 8.5
55 9.0
56 9.5
57 10.0
58 11.0
59 12.0
60 13.0
61 14.0
62 15.0
63 16.0
Table#5
Delay Time(200.0ms)
Data Value Data Value
0 0.1 64 100.8
1 1.7 65 102.4
2 3.2 66 104.0
3 4.8 67 105.6
4 6.4 68 107.1
5 8.0 69 108.7
6 9.5 70 110.3
7 11.1 71 111.9
8 12.7 72 113.4
9 14.3 73 115.0
10 15.8 74 116.6
11 17.4 75 118.2
12 19.0 76 119.7
13 20.6 77 121.3
14 22.1 78 122.9
15 23.7 79 124.4
16 25.3 80 126.0
17 26.9 81 127.6
18 28.4 82 129.2
19 30.0 83 130.7
20 31.6 84 132.3
21 33.2 85 133.9
22 34.7 86 135.5
23 36.3 87 137.0
24 37.9 88 138.6
25 39.5 89 140.2
26 41.0 90 141.8
27 42.6 91 143.3
28 44.2 92 144.9
29 45.7 93 146.5
30 47.3 94 148.1
31 48.9 95 149.6
32 50.5 96 151.2
33 52.0 97 152.8
34 53.6 98 154.4
35 55.2 99 155.9
36 56.8 100 157.5
37 58.3 101 159.1
38 59.9 102 160.6
39 61.5 103 162.2
40 63.1 104 163.8
41 64.6 105 165.4
42 66.2 106 166.9
43 67.8 107 168.5
44 69.4 108 170.1
45 70.9 109 171.7
46 72.5 110 173.2
47 74.1 111 174.8
48 75.7 112 176.4
49 77.2 113 178.0
50 78.8 114 179.5
51 80.4 115 181.1
52 81.9 116 182.7
53 83.5 117 184.3
54 85.1 118 185.8
55 86.7 119 187.4
56 88.2 120 189.0
57 89.8 121 190.6
58 91.4 122 192.1
59 93.0 123 193.7
60 94.5 124 195.3
61 96.1 125 196.9
62 97.7 126 198.4
63 99.3 127 200.0
36
Table#6
Room Size
Data Value
00.1
10.3
20.4
30.6
40.7
50.9
61.0
71.2
81.4
91.5
10 1.7
11 1.8
12 2.0
13 2.1
14 2.3
15 2.5
16 2.6
17 2.8
18 2.9
19 3.1
20 3.2
21 3.4
22 3.5
23 3.7
24 3.9
25 4.0
26 4.2
27 4.3
28 4.5
29 4.6
30 4.8
31 5.0
32 5.1
33 5.3
34 5.4
35 5.6
36 5.7
37 5.9
38 6.1
39 6.2
40 6.4
41 6.5
42 6.7
43 6.8
44 7.0
Table#7
Delay Time(400.0ms)
Data Value Data Value
0 0.1 64 201.6
1 3.2 65 204.8
2 6.4 66 207.9
3 9.5 67 211.1
4 12.7 68 214.2
5 15.8 69 217.4
6 19.0 70 220.5
7 22.1 71 223.7
8 25.3 72 226.8
9 28.4 73 230.0
10 31.6 74 233.1
11 34.7 75 236.3
12 37.9 76 239.4
13 41.0 77 242.6
14 44.2 78 245.7
15 47.3 79 248.9
16 50.5 80 252.0
17 53.6 81 255.2
18 56.8 82 258.3
19 59.9 83 261.5
20 63.1 84 264.6
21 66.2 85 267.7
22 69.4 86 270.9
23 72.5 87 274.0
24 75.7 88 277.2
25 78.8 89 280.3
26 82.0 90 283.5
27 85.1 91 286.6
28 88.3 92 289.8
29 91.4 93 292.9
30 94.6 94 296.1
31 97.7 95 299.2
32 100.9 96 302.4
33 104.0 97 305.5
34 107.2 98 308.7
35 110.3 99 311.8
36 113.5 100 315.0
37 116.6 101 318.1
38 119.8 102 321.3
39 122.9 103 324.4
40 126.1 104 327.6
41 129.2 105 330.7
42 132.4 106 333.9
43 135.5 107 337.0
44 138.6 108 340.2
45 141.8 109 343.3
46 144.9 110 346.5
47 148.1 111 349.6
48 151.2 112 352.8
49 154.4 113 355.9
50 157.5 114 359.1
51 160.7 115 362.2
52 163.8 116 365.4
53 167.0 117 368.5
54 170.1 118 371.7
55 173.3 119 374.8
56 176.4 120 378.0
57 179.6 121 381.1
58 182.7 122 384.3
59 185.9 123 387.4
60 189.0 124 390.6
61 192.2 125 393.7
62 195.3 126 396.9
63 198.5 127 400.0
Table#8
Compressor Attack Time
Table#9
Compressor Release Time
Table#10
Compressor Ratio
Data Value
01
12
23
34
45
56
67
78
89
910
10 12
11 14
12 16
13 18
14 20
15 23
16 26
17 30
18 35
19 40
20 50
21 60
22 70
23 80
24 100
25 120
26 140
27 160
28 180
29 200
Data Value
010
115
225
335
445
555
665
775
885
9 100
10 115
11 140
12 170
13 230
14 340
15 680
16 850
17 1000
18 1200
19 1500
20 1700
21 2000
22 2400
23 3000
Data Value
01
11.5
22
33
45
57
610
720
Table#11
Reverb Width;Depth;Height
Data Value Data Value
0 0.5 64 17.6
1 0.8 65 17.9
2 1.0 66 18.2
3 1.3 67 18.5
4 1.5 68 18.8
5 1.8 69 19.1
6 2.0 70 19.4
7 2.3 71 19.7
8 2.6 72 20.0
9 2.8 73 20.2
10 3.1 74 20.5
11 3.3 75 20.8
12 3.6 76 21.1
13 3.9 77 21.4
14 4.1 78 21.7
15 4.4 79 22.0
16 4.6 80 22.4
17 4.9 81 22.7
18 5.2 82 23.0
19 5.4 83 23.3
20 5.7 84 23.6
21 5.9 85 23.9
22 6.2 86 24.2
23 6.5 87 24.5
24 6.7 88 24.9
25 7.0 89 25.2
26 7.2 90 25.5
27 7.5 91 25.8
28 7.8 92 26.1
29 8.0 93 26.5
30 8.3 94 26.8
31 8.6 95 27.1
32 8.8 96 27.5
33 9.1 97 27.8
34 9.4 98 28.1
35 9.6 99 28.5
36 9.9 100 28.8
37 10.2 101 29.2
38 10.4 102 29.5
39 10.7 103 29.9
40 11.0 104 30.2
41 11.2
42 11.5
43 11.8
44 12.1
45 12.3
46 12.6
47 12.9
48 13.1
49 13.4
50 13.7
51 14.0
52 14.2
53 14.5
54 14.8
55 15.1
56 15.4
57 15.6
58 15.9
59 16.2
60 16.5
61 16.8
62 17.1
63 17.3
Table#12
Wah Release Time
Data Value
52 10
53 15
54 25
55 35
56 45
57 55
58 65
59 75
60 85
61 100
62 115
63 140
64 170
65 230
66 340
67 680
37
Table#13
LO-FI Sampling Frequency Control
Data Value Data Value
0 44.1k 64 678.5
1 22.1k 65 668.2
2 14.7k 66 658.2
3 11.0k 67 648.5
4 8.82k 68 639.1
5 7.35k 69 630.0
6 6.30k 70 621.1
7 5.51k 71 612.5
8 4.90k 72 604.1
9 4.41k 73 595.9
10 4.01k 74 588.0
11 3.68k 75 580.3
12 3.39k 76 572.7
13 3.15k 77 565.4
14 2.94k 78 558.2
15 2.76k 79 551.3
16 2.59k 80 544.4
17 2.45k 81 537.8
18 2.32k 82 531.3
19 2.21k 83 525.0
20 2.10k 84 518.8
21 2.00k 85 512.8
22 1.92k 86 506.9
23 1.84k 87 501.1
24 1.76k 88 495.5
25 1.70k 89 490.0
26 1.63k 90 484.6
27 1.58k 91 479.3
28 1.52k 92 474.2
29 1.47k 93 469.1
30 1.42k 94 464.2
31 1.38k 95 459.4
32 1.34k 96 454.6
33 1.30k 97 450.0
34 1.26k 98 445.5
35 1.23k 99 441.0
36 1.19k 100 436.6
37 1.16k 101 432.4
38 1.13k 102 428.2
39 1.10k 103 424.0
40 1.08k 104 420.0
41 1.05k 105 416.0
42 1.03k 106 412.1
43 1.00k 107 408.3
44 980.0 108 404.6
45 958.7 109 400.9
46 938.3 110 397.3
47 918.8 111 393.8
48 900.0 112 390.3
49 882.0 113 386.8
50 864.7 114 383.5
51 848.1 115 380.2
52 832.1 116 376.9
53 816.7 117 373.7
54 801.8 118 370.6
55 787.5 119 367.5
56 773.7 120 364.5
57 760.3 121 361.5
58 747.5 122 358.5
59 735.0 123 355.6
60 723.0 124 352.8
61 711.3 125 350.0
62 700.0 126 347.2
63 689.1 127 344.5
Table#14
Multi Compressor Gain
Data Value
0-∞
1-60
2-57
3-54
4-51
5-48
6-45
7-42
8-39
9-36
10 -33
11 -30
12 -27
13 -24
14 -23
15 -22
16 -21
17 -20
18 -19
19 -18
20 -17
21 -16
22 -15
23 -14
24 -13
25 -12
26 -11
27 -10
28 -9
29 -8
30 -7
31 -6
32 -5
33 -4
34 -3
35 -2
36 -1
37 0
38 1
39 2
40 3
41 4
42 5
43 6
44 7
45 8
46 9
47 10
48 11
49 12
50 13
51 14
52 15
53 16
54 17
55 18
Table#15
Divide Frequency
Data Value1 value2 Data Value1 value2
0 32 1.2k 64 315 3.2k
1 32 1.6k 65 315 4.0k
2 32 2.0k 66 315 5.0k
3 32 2.5k 67 315 6.3k
4 32 3.2k 68 315 8.0k
5 32 4.0k 69 315 10.0k
6 32 5.0k 70 500 1.2k
7 32 6.3k 71 500 1.6k
8 32 8.0k 72 500 2.0k
9 32 10.0k 73 500 2.5k
10 63 1.2k 74 500 3.2k
11 63 1.6k 75 500 4.0k
12 63 2.0k 76 500 5.0k
13 63 2.5k 77 500 6.3k
14 63 3.2k 78 500 8.0k
15 63 4.0k 79 500 10.0k
16 63 5.0k 80 630 1.2k
17 63 6.3k 81 630 1.6k
18 63 8.0k 82 630 2.0k
19 63 10.0k 83 630 2.5k
20 80 1.2k 84 630 3.2k
21 80 1.6k 85 630 4.0k
22 80 2.0k 86 630 5.0k
23 80 2.5k 87 630 6.3k
24 80 3.2k 88 630 8.0k
25 80 4.0k 89 630 10.0k
26 80 5.0k
27 80 6.3k
28 80 8.0k
29 80 10.0k
30 125 1.2k
31 125 1.6k
32 125 2.0k
33 125 2.5k
34 125 3.2k
35 125 4.0k
36 125 5.0k
37 125 6.3k
38 125 8.0k
39 125 10.0k
40 160 1.2k
41 160 1.6k
42 160 2.0k
43 160 2.5k
44 160 3.2k
45 160 4.0k
46 160 5.0k
47 160 6.3k
48 160 8.0k
49 160 10.0k
50 250 1.2k
51 250 1.6k
52 250 2.0k
53 250 2.5k
54 250 3.2k
55 250 4.0k
56 250 5.0k
57 250 6.3k
58 250 8.0k
59 250 10.0k
60 315 1.2k
61 315 1.6k
62 315 2.0k
63 315 2.5k
Table#16
Carrier Frequency Coarse
Data Value Data Value
0 0.5 64 152
1 1.5 65 160
2 2.0 66 169
3 2.5 67 179
4 3.5 68 189
5 4.0 69 200
6 4.5 70 211
7 5.5 71 224
8 6.0 72 236
9 6.5 73 250
10 7.5 74 264
11 8.0 75 279
12 8.5 76 295
13 8.9 77 312
14 9.4 78 330
15 10.0 79 348
16 10.6 80 368
17 11.2 81 389
18 11.8 82 412
19 12.5 83 435
20 13.2 84 460
21 13.9 85 486
22 14.7 86 514
23 15.6 87 543
24 16.5 88 574
25 17.4 89 607
26 18.4 90 642
27 19.4 91 678
28 20.6 92 717
29 21.7 93 758
30 23.0 94 801
31 24.3 95 847
32 25.7 96 895
33 27.1 97 946
34 28.7 98 1.00k
35 30.3 99 1.05k
36 32.0 100 1.11k
37 33.9 101 1.18k
38 35.8 102 1.24k
39 37.8 103 1.32k
40 40.0 104 1.39k
41 42.3 105 1.47k
42 44.7 106 1.55k
43 47.3 107 1.64k
44 49.9 108 1.74k
45 52.8 109 1.84k
46 55.8 110 1.94k
47 59.0 111 2.05k
48 62.4 112 2.17k
49 65.9 113 2.29k
50 69.7 114 2.43k
51 73.7 115 2.56k
52 77.9 116 2.71k
53 82.3 117 2.87k
54 87.0 118 3.03k
55 92.0 119 3.20k
56 97.2 120 3.39k
57 103 121 3.58k
58 109 122 3.79k
59 115 123 4.00k
60 121 124 4.23k
61 128 125 4.47k
62 136 126 4.73k
63 143 127 5.00k
38
Table#17
Dynamic Attack Time
Data Value Data Value
0 0.3 64 112
1 0.9 65 114
2 1.8 66 116
3 2.7 67 118
4 3.6 68 120
5 5.4 69 121
6 7.2 70 123
7 9.0 71 125
8 10 72 127
9 12 73 129
10 14 74 130
11 16 75 132
12 18 76 134
13 20 77 136
14 21 78 138
15 23 79 140
16 25 80 141
17 27 81 143
18 29 82 145
19 30 83 147
20 32 84 149
21 34 85 150
22 36 86 152
23 38 87 154
24 40 88 156
25 41 89 158
26 43 90 160
27 45 91 161
28 47 92 163
29 49 93 165
30 50 94 167
31 52 95 169
32 54 96 170
33 56 97 172
34 58 98 174
35 60 99 176
36 61 100 178
37 63 101 180
38 65 102 181
39 67 103 183
40 69 104 185
41 70 105 187
42 72 106 189
43 74 107 190
44 76 108 192
45 78 109 194
46 80 110 196
47 81 111 198
48 83 112 200
49 85 113 201
50 87 114 203
51 89 115 205
52 90 116 207
53 92 117 209
54 94 118 210
55 96 119 212
56 98 120 214
57 100 121 216
58 101 122 218
59 103 123 220
60 105 124 221
61 107 125 223
62 109 126 225
63 110 127 227
Table#18
Dynamic Release Time
Data Value Data Value
0 2.6 64 369
1 3.0 65 391
2 3.4 66 413
3 3.9 67 434
4 4.3 68 456
5 4.7 69 478
6 5.2 70 499
7 5.6 71 521
8 6.0 72 543
9 6.5 73 565
10 6.9 74 586
11 7.3 75 608
12 7.8 76 630
13 8.2 77 651
14 8.6 78 673
15 13 79 695
16 17 80 717
17 22 81 738
18 26 82 760
19 30 83 782
20 35 84 803
21 39 85 825
22 43 86 847
23 48 87 869
24 52 88 890
25 56 89 912
26 61 90 934
27 65 91 955
28 69 92 977
29 74 93 999
30 78 94 1021
31 83 95 1042
32 87 96 1064
33 91 97 1086
34 96 98 1107
35 100 99 1129
36 104 100 1151
37 109 101 1173
38 113 102 1194
39 117 103 1216
40 122 104 1238
41 126 105 1259
42 130 106 1281
43 135 107 1303
44 139 108 1346
45 143 109 1390
46 148 110 1433
47 152 111 1477
48 156 112 1520
49 161 113 1563
50 165 114 1607
51 169 115 1650
52 174 116 1694
53 178 117 1737
54 182 118 1781
55 187 119 1824
56 195 120 1867
57 217 121 1911
58 239 122 1954
59 261 123 1998
60 282 124 2041
61 304 125 2085
62 326 126 2128
63 347 127 2171
Table#19
Delay Time (740.0ms)
Data Value Data Value
0 1 64 1950
1 2 65 2000
2 5 66 2050
3 10 67 2100
4 15 68 2150
5 20 69 2200
6 30 70 2250
7 40 71 2300
8 50 72 2350
9 60 73 2400
10 70 74 2450
11 80 75 2500
12 90 76 2550
13 100 77 2600
14 110 78 2650
15 120 79 2700
16 130 80 2750
17 140 81 2800
18 150 82 2850
19 160 83 2900
20 170 84 2950
21 180 85 3000
22 190 86 3100
23 200 87 3200
24 220 88 3300
25 240 89 3400
26 260 90 3500
27 280 91 3600
28 300 92 3700
29 320 93 3800
30 340 94 3900
31 360 95 4000
32 380 96 4100
33 400 97 4200
34 450 98 4300
35 500 99 4400
36 550 100 4500
37 600 101 4600
38 650 102 4700
39 700 103 4800
40 750 104 4900
41 800 105 5000
42 850 106 5100
43 900 107 5200
44 950 108 5300
45 1000 109 5400
46 1050 110 5500
47 1100 111 5600
48 1150 112 5700
49 1200 113 5800
50 1250 114 5900
51 1300 115 6000
52 1350 116 6100
53 1400 117 6200
54 1450 118 6300
55 1500 119 6400
56 1550 120 6500
57 1600 121 6600
58 1650 122 6700
59 1700 123 6800
60 1750 124 6900
61 1800 125 7000
62 1850 126 7200
63 1900 127 7400
Table#20
Delay Time (1480.0ms)
Data Value Data Value
0 1 64 4100
1 2 65 4200
2 5 66 4300
3 10 67 4400
4 15 68 4500
5 20 69 4600
6 30 70 4700
7 40 71 4800
8 50 72 4900
9 60 73 5000
10 70 74 5100
11 80 75 5200
12 90 76 5300
13 100 77 5400
14 120 78 5500
15 140 79 5600
16 160 80 5700
17 180 81 5800
18 200 82 5900
19 220 83 6000
20 240 84 6200
21 260 85 6400
22 280 86 6600
23 300 87 6800
24 350 88 7000
25 400 89 7200
26 450 90 7400
27 500 91 7600
28 550 92 7800
29 600 93 8000
30 700 94 8200
31 800 95 8400
32 900 96 8600
33 1000 97 8800
34 1100 98 9000
35 1200 99 9200
36 1300 100 9400
37 1400 101 9600
38 1500 102 9800
39 1600 103 10000
40 1700 104 10200
41 1800 105 10400
42 1900 106 10600
43 2000 107 10800
44 2100 108 11000
45 2200 109 11200
46 2300 110 11400
47 2400 111 11600
48 2500 112 11800
49 2600 113 12000
50 2700 114 12200
51 2800 115 12400
52 2900 116 12600
53 3000 117 12800
54 3100 118 13000
55 3200 119 13200
56 3300 120 13400
57 3400 121 13600
58 3500 122 13800
59 3600 123 14000
60 3700 124 14200
61 3800 125 14400
62 3900 126 14600
63 4000 127 14800
39
Control List
Assign A/B DESTINATION VOICE CONTROL SET DESTINATION
No. Display Description
0 "off" off
1 "EQLow-G" MEQ Low Gain
2 "EQLow-F" MEQ Low Frequency
3 "EQLow-Q" MEQ Low Q
4 "EQLoM-G" MEQ Low Mid Gain
5 "EQLoM-F" MEQ Low Mid Frequency
6 "EQLoM-Q" MEQ Low Mid Q
7 "EQMid-G" MEQ Mid Gain
8 "EQMid-F" MEQ Mid Frequency
9 "EQMid-Q" MEQ Mid Q
10 "EQHiM-G" MEQ High Mid Gain
11 "EQHiM-F" MEQ High Mid Frequency
12 "EQHiM-Q" MEQ High Mid Q
13 "EQHighG" MEQ High Gain
14 "EQHighF" MEQ High Frequency
15 "EQHighQ" MEQ High Q
16 "REV-P1" Reverb Parameter 1
: : :
25 "REV-P10" Reverb Parameter 10
26 "REV-Rtn" Reverb Return
27 "REV-Pan" Reverb Pan
28 "CHO-P1" Chorus Parameter 1
: : :
37 "CHO-P10" Chorus Parameter 10
38 "CHO-Rtn" Chorus Return
39 "CHO-Pan" Chorus Pan
40 "Cho>Rev" Send Chorus To Reverb
41 "Cho-Ctl" Chorus Control
42 "ARP-Typ" Arpeggio Type
43 "ARP-Unt" Arpeggio Unit Multiply
44 "ARP-Vel" Arpeggio Velocity Rate
45 "ARP-Gat" Arpeggio Gate Time Rate
46 "Tempo" Arpeggio/Sequencer Tempo
47 "AEG-Atk" AEG Attack Time
48 "AEG-Dcy" AEG Decay Time
49 "AEG-Sus" AEG Sustain Level
50 "AEG-Rel" AEG Release Time
47 "FEG-Atk" FEG Attack Time
48 "FEG-Dcy" FEG Decay Time
49 "FEG-Rel" FEG Release Time
50 "FEG-Dpt" FEG Depth
51 "Cutoff" Cutoff Frequency
52 "Reso" Resonance
No. Display Description Normal Other
0 "off" off ØØ
1 "Volume" Voice Volume ØØ
2 "RevSend" Reverb Send ØØ
3 "ChoSend" Chorus Send ØØ
4 "INS1-P1" Insertion Effect 1 Parameter 1 ØØ
: : : ::
13 "INS1P10" Insertion Effect 1 Parameter 10 ØØ
14 "INS2-P1" Insertion Effect 2 Parameter 1 ØØ
: : : ::
29 "INS2P16" Insertion Effect 2 Parameter 16 ØØ
30 "CLFOSpd" Common LFO Speed Ø˛
31 "CLFO-D1" Common LFO Depth1 Ø˛
32 "CLFO-D2" Common LFO Depth2 Ø˛
33 "PorTime" Portamento Time Ø˛
34 "ELM-Lvl" Element Level Ø˛
35 "ELM-Pan" Element Pan Ø˛
36 "ELM-Dly" Element Key On Delay Ø˛
37 "ELFOSpd" Element LFO Speed Ø˛
38 "ELFO-PM" Element LFO Pitch Modulation Depth Ø˛
39 "ELFO-AM" Element LFO Amplitude Modulation Depth Ø˛
40 "ELFO-FM" Element LFO Filter Modulation Depth Ø˛
41 "PCH-Crs" Element Pitch Coarse Ø˛
42 "PCH-Fin" Element Pitch Fine Ø˛
43 "PEG-Dpt" Element Pitch EG Depth Ø˛
44 "PEG-Hld" Element Pitch EG Hold Time Ø˛
45 "PEG-Atk" Element Pitch EG Attack Time Ø˛
46 "PEG-D1" Element Pitch EG Decay1 Time Ø˛
47 "PEG-D2" Element Pitch EG Decay2 Time Ø˛
48 "PEG-Rel" Element Pitch EG Release Time Ø˛
49 "AEG-Atk" Element Amplitude EG Attack Time Ø˛
50 "AEG-D1" Element Amplitude EG Decay1 Time Ø˛
51 "AEG-D2" Element Amplitude EG Decay2 Time Ø˛
52 "AEG-Rel" Element Amplitude EG Release Time Ø˛
53 "FEG-Dpt" Element Filter EG Depth Ø˛
54 "FEG-Hld" Element Filter EG Hold Time Ø˛
55 "FEG-Atk" Element Filter EG Attack Time Ø˛
56 "FEG-D1" Element Filter EG Decay1 Time Ø˛
57 "FEG-D2" Element Filter EG Decay2 Time Ø˛
58 "FEG-Rel" Element Filter EG Release Time Ø˛
59 "FLT-Frq" Element Filter Cutoff Frequency Ø˛
60 "FLT-Rez" Element Filter Resonance Ø˛
61 "HPF-Frq" Element HPF Cutoff Frequency Ø˛
62 "CLFO-D3" Common LFO Depth3 Ø˛
40
Arpeggio Type List
Preset1
No. Name Type
1 UpOct1 Sq
2 UpOct2 Sq
3 UpOct4 Sq
4 DownOct1 Sq
5 DownOct2 Sq
6 DownOct4 Sq
7U/DAOct1 Sq
8U/DAOct2 Sq
9U/DAOct4 Sq
10 U/DBOct1 Sq
11 U/DBOct2 Sq
12 U/DBOct4 Sq
13 RndmOct1 Sq
14 RndmOct2 Sq
15 RndmOct4 Sq
16 Oct2Up Sq
17 Oct4Up Sq
18 UnisonUp Sq
19 Up&Down1 Sq
20 Up&Down2 Sq
21 Up&Down4 Sq
22 Up&Alt1 Sq
23 Up&Rndm1 Sq
24 Up&Rndm2 Sq
25 Up&Rndm4 Sq
26 ChdAltB1 Sq
27 ChdAltB2 Sq
28 ChdAltB4 Sq
29 ChdRndm1 Sq
30 ChdRndm2 Sq
31 ChdRndm4 Sq
32 Techno A Ph
33 Techno B Ph
34 Techno C Ph
35 DAHouse Ph
36 SyncopaA Ph
37 SyncopaB Ph
38 SyncpEco Ph
39 TekEchoA Ph
40 TekEchoB Ph
41 PulsLine Ph
42 SeqS&H A Ph
43 SeqS&H B Ph
44 CleanGtA Ph
45 CleanGtB Ph
46 CleanGtC Ph
47 CleanGtD Ph
48 Pno16Bt Ph
49 PnoLatin Ph
50 GruvBass Ph
51 Ocean Ph
52 Orbit Ph
53 X-SweepA Ph
54 X-SweepB Ph
55 X-SweepC Ph
56 Lamb Ph
57 Thips Ph
58 Hardcore Ph
59 Harmo Ph
60 Ascorbic Ph
61 Doves Ph
62 Chodal Ph
63 Simple Ph
64 Waggle Ph
No. Name Type
65 SuperArp Ph
66 MuteArpA Ph
67 MuteArpB Ph
68 VelGruvA Ph
69 VelGruvB Ph
70 SpaceArp Ph
71 MuteLine Ph
72 StepLine Ph
73 AcidLine Ph
74 SplitArp Ph
75 Step Seq Ph
76 PolyArpA Ph
77 PolyArpB Ph
78 Ana Seq Ph
79 Planet Ph
80 Rosync Ph
81 StrumArp Ph
82 Guit1Arp Ph
83 RolliArp Ph
84 Guit2Arp Ph
85 Guit3Arp Ph
86 Guit4Arp Ph
87 Harp Arp Ph
88 BigBeatA Dr
89 BigBeatB Dr
90 BigBeatC Dr
91 BigBeatD Dr
92 Rock A Dr
93 Rock B Dr
94 Rock C Dr
95 BigBeatE Dr
96 BigBeatF Dr
97 BigBeatG Dr
98 BigBeatH Dr
99 BigBeatI Dr
100 BrkTrnce Dr
101 House A Dr
102 House B Dr
103 House C Dr
104 Garage Dr
105 House D Dr
106 House E Dr
107 HipHop A Dr
108 JazzHop Dr
109 Abstract Dr
110 LoBeat A Dr
111 LoBeat B Dr
112 LoBeat C Dr
113 LoBeat D Dr
114 LoBeat E Dr
115 LoBeat F Dr
116 DrumnBsA Dr
117 DrumnBsB Dr
118 Linear Dr
119 08beat A Sp
120 08beat B Sp
121 08beat C Sp
122 16beat A Sp
123 16beat B Sp
124 1Bar Sp
125 1BarRndm Sp
126 GateCutA Ct
127 GateCutB Ct
128 GateCutC Ct
Preset2
No. Name Type
1 Strum A Ph
2 Strum B Ph
3 Strum C Ph
4 Strum D Ph
5 Strum E Ph
6 Strum F Ph
7 Strum G Ph
8 Strum H Ph
9 Strum I Ph
10 Strum J Ph
11 LatinPHA Ph
12 LatinPHB Ph
13 LatinPHC Ph
14 Funky A Ph
15 Funky B Ph
16 Funky C Ph
17 Funky D Ph
18 RockGtrA Ph
19 RockGtrB Ph
20 RockGtrC Ph
21 Lick A Ph
22 Lick B Ph
23 Lick C Ph
24 Lick D Ph
25 Lick E Ph
26 Lick F Ph
27 News A Ph
28 News B Ph
29 Fugue Ph
30 AcidBs A Ph
31 AcidBs B Ph
32 SlapBs A Ph
33 SlapBs B Ph
34 Walkin Ph
35 Trill A Ph
36 Trill B Ph
37 Trill C Ph
38 FlutterA Ph
39 FlutterB Ph
40 FlutterC Ph
41 Flute A Ph
42 Flute B Ph
43 Flute C Ph
44 Cresendo Ph
45 MOD A Ph
46 MOD B Ph
47 MOD C Ph
48 Pickin A Ph
49 Pickin B Ph
50 Pickin C Ph
51 ArmDown Ct
52 BendVib Ct
53 BotDwVib Ct
54 BotUpVib Ct
55 CHVib Ct
56 HamVib Ct
57 PullVibA Ct
58 PullVibB Ct
59 SlideVib Ct
60 Trill D Ct
61 Trill E Ct
62 UDCHVib Ct
63 Vibra A Ct
64 Vibra B Ct
No. Name Type
65 FlipHopA Dr
66 FlipHopB Dr
67 FlipHopC Dr
68 FlipHopD Dr
69 GangstaA Dr
70 GangstaB Dr
71 GangstaC Dr
72 GangstaD Dr
73 i-Hop A Dr
74 i-Hop B Dr
75 i-Hop C Dr
76 i-Hop D Dr
77 R&BSmthA Dr
78 R&BSmthB Dr
79 R&BSmthC Dr
80 R&BSmthD Dr
81 House F Dr
82 House G Dr
83 House H Dr
84 Funk A Dr
85 Funk B Dr
86 Funk C Dr
87 Funk D Dr
88 Gospel A Dr
89 Gospel B Dr
90 Bebop A Dr
91 Bebop B Dr
92 PopRckAA Dr
93 PopRckAB Dr
94 PopRckAC Dr
95 PopRckAD Dr
96 PopRckBA Dr
97 PopRckBB Dr
98 PopRckBC Dr
99 PopRckBD Dr
100 MondoRkA Dr
101 MondoRkB Dr
102 MondoRkC Dr
103 MondoRkD Dr
104 BalladAA Dr
105 BalladAB Dr
106 BalladAC Dr
107 BalladAD Dr
108 BalladBA Dr
109 BalladBB Dr
110 Roll A Dr
111 Roll B Dr
112 Roll C Dr
113 Roll D Dr
114 Latin A Dr
115 Latin B Dr
116 Latin C Dr
117 Latin D Dr
118 Latin E Dr
119 DrumnBsC Dr
120 DrumnBsD Dr
121 DrumnBsE Dr
122 DrumnBsF Dr
123 DrumnBsG Dr
124 EuroTekA Dr
125 EuroTekB Dr
126 EuroTekC Dr
127 EuroTekD Dr
128 EuroTekE Dr
41
Preset Phrase List
No. Name No. Name
1 FlipHop1 65 PopRckA1
2 FlipHop2 66 PopRckA2
3 FlipHop3 67 PopRckA3
4 FlipHop4 68 PopRckA4
5 FlipHop5 69 PopRckA5
6 FlipHop6 70 PopRckA6
7 FlipHop7 71 PopRckA7
8 FlipHop8 72 PopRckA8
9 Gangsta1 73 PopRckB1
10 Gangsta2 74 PopRckB2
11 Gangsta3 75 PopRckB3
12 Gangsta4 76 PopRckB4
13 Gangsta5 77 PopRckB5
14 Gangsta6 78 PopRckB6
15 Gangsta7 79 PopRckB7
16 Gangsta8 80 PopRckB8
17 i-Hop__1 81 MondoRk1
18 i-Hop__2 82 MondoRk2
19 i-Hop__3 83 MondoRk3
20 i-Hop__4 84 MondoRk4
21 i-Hop__5 85 MondoRk5
22 i-Hop__6 86 MondoRk6
23 i-Hop__7 87 MondoRk7
24 i-Hop__8 88 MondoRk8
25 R&BSmth1 89 BalladA1
26 R&BSmth2 90 BalladA2
27 R&BSmth3 91 BalladA3
28 R&BSmth4 92 BalladA4
29 R&BSmth5 93 BalladA5
30 R&BSmth6 94 BalladA6
31 R&BSmth7 95 BalladA7
32 R&BSmth8 96 BalladA8
33 House__1 97 BalladB1
34 House__2 98 BalladB2
35 House__3 99 BalladB3
36 House__4 100 BalladB4
37 House__5 101 BalladB5
38 House__6 102 BalladB6
39 House__7 103 BalladB7
40 House__8 104 BalladB8
41 Funk___1 105 Latin__1
42 Funk___2 106 Latin__2
43 Funk___3 107 Latin__3
44 Funk___4 108 Latin__4
45 Funk___5 109 Latin__5
46 Funk___6 110 Latin__6
47 Funk___7 111 Latin__7
48 Funk___8 112 Latin__8
49 Gospel_1 113 DrumnBs1
50 Gospel_2 114 DrumnBs2
51 Gospel_3 115 DrumnBs3
52 Gospel_4 116 DrumnBs4
53 Gospel_5 117 DrumnBs5
54 Gospel_6 118 DrumnBs6
55 Gospel_7 119 DrumnBs7
56 Gospel_8 120 DrumnBs8
57 Bebop__1 121 EuroTek1
58 Bebop__2 122 EuroTek2
59 Bebop__3 123 EuroTek3
60 Bebop__4 124 EuroTek4
61 Bebop__5 125 EuroTek5
62 Bebop__6 126 EuroTek6
63 Bebop__7 127 EuroTek7
64 Bebop__8 128 EuroTek8
42
About MIDI
MIDI is an acronym that stands for Musical Instrument Digital Interface, which allows
electronic musical instruments to “communicate” with each other, by sending and
receiving compatible Note, Control Change, Program Change and various other types of
MIDI data, or messages.
The MOTIF6/7/8 can control a MIDI device by transmitting note related data and various
types of controller data. The MOTIF6/7/8 can be controlled by the incoming MIDI messages
which automatically select MIDI channels, voices and effects, change parameter values,
and of course play the voices specified for the various Parts in a Performance.
MIDI Messages Transmitted/Received by the
MOTIF6/7/8
The MIDI messages can be divided into two groups: the Channel Messages and System
Messages. Below is a brief explanation of the various types of MIDI messages which the
MOTIF6/7/8 can receive/transmit.
CHANNEL MESSAGES
The Channel Messages are the data related to the performance on the keyboard for the specific
channel.
• Note On/Note Off (Key On/Key Off)
Messages which are generated when the keyboard is played. Each message includes a
specific note number which corresponds to the key which is pressed, plus a velocity value
based on how hard the key is struck.
• Control Change
Control Change messages let you select a voice bank (Bank Select), control volume,
panning, modulation, portamento time, brightness and various other controller parameters,
through specific Control Change numbers which correspond to each of the various
parameters.
• Program Change
Messages which voice to select for each Part. With a combination of Bank Select, you can
select not only basic voice numbers, but also variation voice bank numbers.
• Channel Aftertouch
Messages which let you control the sounds by the pressure you apply to the keys after the
initial striking of the keys, over the entire channel.
• Polyphonic Key Pressure
Messages which let you control the sounds by the pressure you apply to the keys after the
initial striking of the keys, for each individual key. The internal sequencer (MOTIF6/7/8) can
send this message.
• Pitch Bend
Pitch Bend messages are continuous controller messages that allow the pitch of
designated notes to be raised or lowered by a specified amount over a specified duration.
SYSTEM MESSAGES
The System Messages are the data related to the overall system of the device.
• Exclusive Messages
Exclusive messages control various functions of the MOTIF6/7/8, including bulk dump,
master volume and master tuning, effect type and various other parameters.
• Realtime Messages
Messages which control the sequencer including Start, Stop, Continue, MIDI clock and
Active Sensing messages.
• Common Messages
Messages which also control the sequencer including Song Select and Song Position
Pointer messages.
MIDI Data Format
Many MIDI messages listed in the MIDI Data Format section are expressed in hexadecimal or
binary numbers. Hexadecimal numbers may include the letter “H” as a suffix. The letter “n”
indicates a certain whole number.
The chart below lists the corresponding decimal number for each hexadecimal/binary number.
Additional Notes
• For example, 144 - 159(Decimal)/9nH/1001 0000 - 1001 1111(Binary) indicate the note-on
messages for the channels 1 through 16 respectively. 176 - 191/BnH/1011 0000 - 1011 1111
indicate the control change messages for the channels 1 through 16 respectively. 192 -207/
CnH/1100 0000 - 1100 1111 indicate the program change messages for the channels 1
through 16 respectively. 240/F0H/1111 0000 is positioned at the beginning of data to
indicate a system exclusive message. 247/F7H/1111 0111 is positioned at the end of the
system exclusive message.
• aaH(Hexadecimal)/0aaaaaaa(Binary) indicates the data addresses. The data address
consists of High, Mid and Low.
• bbH/0bbbbbbb indicates byte counts.
• ccH/0ccccccc indicates tcheck sums.
• ddH/0ddddddd indicates data/value.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
0000 0000
0000 0001
0000 0010
0000 0011
0000 0100
0000 0101
0000 0110
0000 0111
0000 1000
0000 1001
0000 1010
0000 1011
0000 1100
0000 1101
0000 1110
0000 1111
0001 0000
0001 0001
0001 0010
0001 0011
0001 0100
0001 0101
0001 0110
0001 0111
0001 1000
0001 1001
0001 1010
0001 1011
0001 1100
0001 1101
0001 1110
0001 1111
0010 0000
0010 0001
0010 0010
0010 0011
0010 0100
0010 0101
0010 0110
0010 0111
0010 1000
0010 1001
0010 1010
0010 1011
0010 1100
0010 1101
0010 1110
0010 1111
0011 0000
0011 0001
0011 0010
0011 0011
0011 0100
0011 0101
0011 0110
0011 0111
0011 1000
0011 1001
0011 1010
0011 1011
0011 1100
0011 1101
0011 1110
0011 1111
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
0100 0000
0100 0001
0100 0010
0100 0011
0100 0100
0100 0101
0100 0110
0100 0111
0100 1000
0100 1001
0100 1010
0100 1011
0100 1100
0100 1101
0100 1110
0100 1111
0101 0000
0101 0001
0101 0010
0101 0011
0101 0100
0101 0101
0101 0110
0101 0111
0101 1000
0101 1001
0101 1010
0101 1011
0101 1100
0101 1101
0101 1110
0101 1111
0110 0000
0110 0001
0110 0010
0110 0011
0110 0100
0110 0101
0110 0110
0110 0111
0110 1000
0110 1001
0110 1010
0110 1011
0110 1100
0110 1101
0110 1110
0110 1111
0111 0000
0111 0001
0111 0010
0111 0011
0111 0100
0111 0101
0111 0110
0111 0111
0111 1000
0111 1001
0111 1010
0111 1011
0111 1100
0111 1101
0111 1110
0111 1111
Decimal Hexadecimal Binary Decimal Hexadecimal Binary
43
SYNTHESIZER/SEQUENCER PART
(1) TRANSMIT FLOW
MIDI<- +-[SW1]-+-------- NOTE ON/OFF 9nH
OUT | |
| |
| +-------- KEY'S AFTER TOUCH AnH (Seq only)
| |
| +-------- CONTROL CHANGE
| | MODULATION BnH,01H
| | VOLUME BnH,07H
| | PAN BnH,0AH
| | SUSTAIN SWITCH BnH,40H
| | FILTER RESONANCE BnH,47H
| | EG RELEASE TIME BnH,48H
| | EG ATTACK TIME BnH,49H
| | FILTER CUTOFF FREQ BnH,4AH
| | EG DECAY TIME BnH,4BH
| | REVERB SEND BnH,5BH
| | CHORUS SEND BnH,5DH
| | ASSIGNABLE CONTROLLERS BnH,(00H .. 5FH)
| | SEQ REMORT CONTROL BnH,(00H .. 7FH)
| |
| +-[SW7]-- BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
| |
| +-------- CHANNEL MODE MESSAGE (Seq only)
| | RESET ALL CONTROLLERS BnH,79H
| | LOCAL CONTROL BnH,7AH
| | OMNI MODE OFF BnH,7CH
| | OMNI MODE ON BnH,7DH
| | MONO MODE ON BnH,7EH
| | POLY MODE ON BnH,7FH
| |
| +-[SW8]-- PROGRAM CHANGE CnH
| |
| +-------- CHANNEL AFTER TOUCH DnH
| |
| +-------- PITCH BEND CHANGE EnH
|
+-[SW4]---------- SYSTEM COMMON MESSAGE
| SONG POSITION POINTERF2H
| SONG SELECTF 3H
|
+-[SW4]---------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
| START FAH
| CONTINUE FBH
| STOP FCH
|
+---------------- ACTIVE SENSING FEH
|
+-[SW5]-+-------- SYSTEM EXCLUSIVE MESSAGE
| +-[SW6]-- <BULK DUMP>
F0H 43H 0nH 6BH bhH blH ahH amH alH ddH... ddH ccH F7H
| |
| +-[SW6]-- <PARAMETER CHANGE> F0H 43H 1nH 6BH ahH amH alH ddH.....ddH F7H
|
+---------------- SYSTEM EXCLUSIVE MESSAGE
| IDENTITY REPLY F0H 7EH 7FH 06H 02H 43H 00H 41H 7CH (or 7DH
| or 7EH) 04H 00H 00H 00H 7FH F7H
+-[SW3,4]-------- MIDI MACHINE CONTROL
| STOP F0H 7FH 7FH 06H 01H F7H
| DEFERRED PLAY F0H 7FH 7FH 06H 03H F7H
| LOCATE F0H 7FH 7FH 06H 44H 06H 01H
| hrH mnH scH frH ffH F7H
|
|
+---------------- SYSTEM EXCLUSIVE MESSAGE
LCD DATA REQUEST
[SW1] MIDI Transmit Channel
In the Master mode: complies with Zone Transmit Channel.
In the mode other than the Master: complies with Keyboard Transmit Channel.
The sequence data played back in the Song/Pattern mode is transmitted according to the MIDI Filter settings.
[SW2] MIDI Control Mode
[SW3] MIDI Sync (transmitted when the MIDI Sync is set to MTC.)
[SW4] Seq MIDI Control
[SW5] MIDI Device Number
When set to all, transmitted via 1.
The sequence data played back in the Song/Pattern mode is transmitted according to the MIDI Filter settings.
[SW6] In the Voice mode, only the Voice related data can be transmitted.
In the Performance mode, only the Performance related data can be transmitted.
The System data can be transmitted/recognized in any mode.
[SW7] SYSTEM Bank Select Switch
[SW8] SYSTEM Program Change Switch
(2) RECEIVE FLOW
MIDI>- +[SW10]-+-------- NOTE OFF 8nH
| |
| +-------- NOTE ON/OFF 9nH
| |
| +-------- KEY'S AFTER TOUCH AnH (Seq only)
| |
| +-------- CONTROL CHANGE
| | MODULATION BnH,01H
| | PORTAMENTO TIME BnH,05H
| | DATA ENTRY MSB BnH,06H
| | DATA ENTRY LSB BnH,26H
| | MAIN VOLUME BnH,07H
| | PAN BnH,0AH
| | EXPRESSION BnH,0BH
| | SUSTAIN SWITCH BnH,40H
| | PORTAMENTO SWITCH BnH,41H
| | SOSTENUTO BnH,42H
| | HARMONIC CONTENT BnH,47H
| | EG RELEASE TIME BnH,48H
| | EG ATTACK TIME BnH,49H
| | BRIGHTNESS BnH,4AH
| | EG DECAY TIME BnH,4BH
| | EFFECT1 DEPTH BnH,5BH
| | EFFECT3 DEPTH BnH,5DH
| | DATA ENTRY INC BnH,60H
| | DATA ENTRY DEC BnH,61H
| | ALL SOUND OFF BnH,78H
| | ASSIGNABLE CONTROLLER BnH,(00H .. 5FH)
| | NRPN BnH,62H,63H *2
| | RPN
| | PITCH BEND SENS. BnH,64H,00H,65H,00H,06H,mmH
| | FINE TUNING BnH,64H,01H,65H,00H,06H,mmH,26H,llH *1
| | COARSE TUNING BnH,64H,02H,65H,00H,06H,mmH *1
| | RPN RESET BnH,64H,7FH,65H,7FH
| |
| +-[SW2]-- EG SUSTAIN LEVEL BnH,1FH
| |
| +-[SW7]-- BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
| |
| +-------- CHANNEL MODE MESSAGE
| | RESET ALL CONTROLLERS BnH,79H
| | LOCAL CONTROL BnH,7AH
| | OMNI MODE OFF BnH,7CH
| | OMNI MODE ON BnH,7DH
| | MONO MODE ON BnH,7EH
| | POLY MODE ON BnH,7FH
| |
| +-[SW8]-- PROGRAM CHANGE CnH
| |
| +-------- CHANNEL AFTER TOUCH DnH
| |
| +-------- PITCH BEND CHANGE EnH
|
+-[SW3]-+-------- SYSTEM COMMON MESSAGE
| MTC QUARTER FRAME MESSAGEF1H
|
+-[SW4]-+-------- SYSTEM COMMON MESSAGE
| SONG POSITION POINTER F2H
| SONG SELECT F3H
|
+-[SW3]-+-------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
+-[SW4]-+-------- SYSTEM REALTIME MESSAGE
| START FAH
| CONTINUE FBH
| STOP FCH
|
+---------------- ACTIVE SENSINGFEH
|
+-[SW5]-+-------- SYSTEM EXCLUSIVE MESSAGE
| | MIDI MASTER VOLUME
F0H 7FH 7FH 04H 01H llH mmH F7H
| |
| +-[SW9]-- <BULK DUMP>
F0H 43H 0nH 6BH bhH blH ahH amH alH ddH....ddH ccH F7H *3
| |
| +-[SW6]-- <PARAMETER CHANGE>
F0H 43H 1nH 6BH ahH amH alH ddH.....ddH F7H *3
| |
| +-[SW6]-- <BULK DUMP REQUEST>
F0H 43H 2nH 6BH ahH amH alH ddH.....ddH F7H *3
| |
| +-[SW6]-- <PARAMETER REQUEST> F0H 43H 3nH 6BH ahH amH alH F7H *3
| |
| +-[SW11]- XG SYSTEM ON F0H 43H 1nH 4CH 00H 00H 7EH 00H F7H
| |
| +-[SW11]- GM MODE ON F0H 7EH 7FH 09H 01H F7H
|
+---------------- SYSTEM EXCLUSIVE MESSAGE
| IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H
| SECTION CONTROL F0H 43H 7EH 00H ssH ddH F7H
| (Pattern Mode only)
+---------------- SYSTEM EXCLUSIVE MESSAGE
TEST ENTRY F0H 43H 10H 18H 5AH 00H F7H
LCD HARD COPY F0H 43H 10H 18H 5AH 01H F7H
[SW2] MIDI Control Mode
[SW3] MIDI Sync (can be set to "internal", "MIDI", or ""MTC.")
[SW4] Seq MIDI Control
[SW5] MIDI Device Number
When this is not set to off, the MIDI Master Volume can be recognized in any mode.
The sequence data played back in the Song/Pattern mode is transmitted according to the MIDI Filter settings.
[SW6] In the Voice mode, only the Voice related data can be transmitted.
In the Performance mode, only the Performance related data can be transmitted.
The System data can be transmitted/recognized in any mode.
[SW7] SYSTEM Bank Select Switch
[SW8] SYSTEM Program Change Switch (In the Voice mode, recognized only in the play mode.)
[SW9] SYSTEM Bulk Protect and same as SW6.
[SW10] MIDI Receive Channel and Receive Filter
In the Performance mode: complies with Part Receive Channel and Part Receive Switch.
In the other mode: complies with Basic Receive Channel.
The sequence data recorded to the Song/Pattern is recognized according to the MIDI Filter settings.
[SW11] SYSTEM Receive GM/XG On
*1: Performance Mode Only
*2: Available only for the Plug-in voices
*3: Recognized/transmitted only when the Plug-in voice (MODEL ID = 0x64) is selected.
44
(3) TRANSMIT/RECEIVE DATA
(3-1) CHANNEL VOICE MESSAGES
(3-1-1) NOTE OFF
STATUS 1000nnnn(8nH) n = 0~15 CHANNEL NUMBER
NOTE No. 0kkkkkkk k = 0 (C-2)~127 (G8)
VELOCITY 0vvvvvvv V: ignored
(3-1-2) NOTE ON/OFF
STATUS 1001nnnn(9nH) n = 0~15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0 (C-2)~127 (G8)
VELOCITY NOTE ON 0vvvvvvv(v≠0)
NOTE OFF 0vvvvvvv(v=0)
(3-1-3) CONTROL CHANGE
STATUS 1011nnnn(BnH) n = 0~15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc
CONTROL VALUE 0vvvvvvv
* TRANSMITTED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0 - 127 *3
c = 32 BANK SEL LSB ; v = 0 - 127 *3
c = 1 MODULATION ; v = 0 - 127
c = 7 MAIN VOLUME ; v = 0 - 127
c = 10 PAN ; v = 0 - 127
c = 11 EXPRESSION ; v = 0 - 127
c = 64 SUSTAIN SWITCH ; v = 0, 127
c = 71 FILTER RESONANCE ; v = 0:-64 - 64:0 - 127:+63
c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63
c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63
c = 74 FILTER CUTOFF FREQ ; v = 0:-64 - 64:0 - 127:+63
c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63
c = 91 REVERB SEND ; v = 0, 127
c = 93 CHORUS SEND ; v = 0, 127
c = 0..95
ASSIGNABLE CONTROLLERS
; v = 0 - 127 *6
The Sequencer Part will play back all recorded ontrol change messages.
* RECEIVED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0 - 127 *3
c = 32 BANK SEL LSB ; v = 0 - 127 *3
c = 1 MODULATION ; v = 0 - 127
c = 5 PORTAMENTO TIME ; v = 0 - 127 *2
c = 6 DATA ENTRY MSB ; v = 0 - 127 *1
c = 38 DATA ENTRY LSB ; v = 0 - 127 *1
c = 7 MAIN VOLUME ; v = 0 - 127
c = 10 PAN ; v = 0 - 127
c = 11 EXPRESSION ; v = 0 - 127
c = 31 EG SUSTAIN LEVEL ; v = 0:-64 - 64:0 - 127:+63 *2,*5
c = 64 SUSTAIN SWITCH ; v = 0-63:OFF, 64-127:ON *2
c = 65 PORTAMENTO SWITCH ; v = 0-63:OFF, 64-127:ON *2
c = 66 SOSTENUTO ; v = 0-63:OFF, 64-127:ON *2
c = 71 HARMONIC CONTENT ; v = 0:-64 - 64:0 - 127:+63
c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63 *2
c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63
c = 74 BRIGHTNESS ; v = 0:-64 - 64:0 - 127:+63
c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63
c = 91 EFFECT1 DEPTH ; v = 0 - 127
c = 93 EFFECT3 DEPTH ; v = 0 - 127
c = 96 DATA ENTRY INC ; v = 127 *1
c = 97 DATA ENTRY DEC ; v = 127 *1
c = 0..95
ASSIGNABLE CONTROLLER
; v = 0 - 127 *6
c = 0..95 ARPEGGIO SW ; v = 0-63:OFF, 64-127:ON *6
c = 0..95 ARPEGGIO HOLD ; v = 0-63:OFF, 64-127:ON *6
All Control Change events can be recorded to the song/pattern.
*1 Used only when a value is set using RPN.
*2 Invalid with Drum Voices.
*3 Relation between BANK CHANGE and PROGRAM is as follows:
*4 Can be selected only when the corresponding Plug-in board has been installed.
*5 Transmitted/received only when MODE2 is selected in CONTROL CHANGE MODE.
*6 The default CONTROL NUMBERs of ASSIGNABLE CONTROLLER are as follows:
BREATH CONTROLLER 2
FOOT CONTROLLER 4
Assign1 16
Assign2 17
Assign A 18
Assign B 19
FOOT SWITCH 88
ARPEGGIO HOLD 89
ARPEGGIO SWITCH 90
*7 Up to 128 voices can be selected in the Song/Pattern mode.
PORTAMENTO TIME sets the time it takes for the pitch to reach the next note played when PORTAMENTO SWITCH is
set to on.
PAN position relatively changes according to the preset value for each voice.
EFFECT1 DEPTH controls reverb send level.
EFFECT3 DEPTH controls chorus send level.
HARMONIC CONTENT adjusts the resonance preset for each voice.
Setting a value adds to or subtracts from the center value, 64, since it is an offset parameter.
The larger the value more resonant sound will be produced. The effective range may be narrower than the range you
can designate depending on the selected voice.
The parameters, EG ATTACK TIME, EG DECAY TIME, EG SUSTAIN LEVEL, EG RELEASE TIME adjust the envelopes
preset for each voice.
Setting these values add to or subtract from the center value, 64, since these are offset parameters.
BRIGHTNESS adjusts the cutoff frequency preset for each voice.
Setting a value adds to or subtracts from the center value, 64, since it is an offset parameter.
The smaller the value the cutoff frequency will be lowered. The effective range may be narrower than the range you
can designate depending on the selected voice.
Bank Select will be actually executed when the Program Change message is received.
Bank Select and Program Change numbers that are not supported by Yamaha will be ignored, but transmitted to the
Plug-in board.
(3-1-4) PROGRAM CHANGE
STATUS 1100nnnn(CnH) n = 0~15 CHANNEL NUMBER
PROGRAM NUMBER 0pppppppp = 0~127
(3-1-5) CHANNEL AFTER TOUCH
STATUS 1101nnnn(DnH) n = 0~15 CHANNEL NUMBER
VALUE 0vvvvvvv v = 0~127 AFTER TOUCH VALUE
(3-1-6) PITCH BEND CHANGE
STATUS 1110nnnn(EnH) n = 0~15 CHANNEL NUMBER
LSB 0vvvvvvv PITCH BEND CHANGE LSB
MSB 0vvvvvvv PITCH BEND CHANGE MSB
Transmitted with a resolution of 7 bits.
(3-2) CHANNEL MODE MESSAGES
STATUS 1011nnnn(BnH) n = 0~15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc c = CONTROL NUMBER
CONTROL VALUE 0vvvvvvv v = DATA VALUE
(3-2-1) ALL SOUND OFF (CONTROL NUMBER = 78H, DATA VALUE = 0)
All the sounds currently played including the channel messages such as note-on and hold-on in a certain channel are
muted when receiving this message.
(3-2-2) RESET ALL CONTROLLERS (CONTROL NUMBER = 79H, DATA VALUE = 0)
Resets the values set for the following controllers.
PITCH BEND CHANGE 0 (center)
CHANNEL AFTER TOUCH 0 (minimum)
MODULATION 0 (minimum)
EXPRESSION 127 (maximum)
BREATH CONTROLLER 127 (maximum)
FOOT CONTROLLER 127 (maximum)
Assign A 0 (center)
Assign B 0 (center)
Assign 1 0 (center)
Assign 2 0 (center)
SUSTAIN SWITCH 0 (off)
SOSTENUTO SWITCH 0 (off)
RPN Not assigned; No change
Doesn’t reset the following data:
PROGRAM CHANGE, BANK SELECT MSB/LSB, VOLUME, PAN, HARMONIC CONTENT, SUSTAIN LEVEL, RELEASE
TIME, ATTACK TIME, DECAY TIME, BRIGHTNESS, EFFECT SEND LEVEL 1, EFFECT SEND LEVEL 3, PORTAMENTO
SWITCH, PITCH BEND SENSITIVITY, FINE TUNING, COARSE TUNING
(3-2-3) ALL NOTE OFF (CONTROL NUMBER = 7BH, DATA VALUE = 0)
All the notes currently set to on in certain channel(s) are muted when receiving this message. However, if Sustain or
Sostenuto is on, notes will continue sounding until these are turned off.
(3-2-4) OMNI MODE OFF (CONTROL NUMBER = 7CH, DATA VALUE = 0)
Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to "OMNI OFF," channel 1.
(3-2-5) OMNI MODE ON(CONTROL NUMBER = 7DH, DATA VALUE = 0)
Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to "OMNI ON."
(3-2-6) MONO (CONTROL NUMBER = 7EH, DATA VALUE = 0..16)
Performs the same function as when receiving ALL SOUNDS OFF. If the 3rd byte (mono) is within 0 through 16, the
channel will be Mode4(m = 1).
In the Voice mode, the mode can be Mode2(m=1) according to VOICE RECEIVE CHANNEL.
(3-2-7) POLY (CONTROL NUMBER = 7FH, DATA VALUE = 0)
Performs the same function as when receiving ALL SOUNDS OFF. The channel will be Mode3.
In the Voice mode, the mode can be Mode1 according to VOICE RECEIVE CHANNEL.
CATEGORY MSB LSB PROGRAM No.
GM Voice 0 0 0..127 (1..128)
GM Drum Voice 127 0 0..1 (1..2)
Normal Voice Preset 1 63 0 0..127 (1..128)
Preset 2 63 1 0..127 (1..128)
Preset 3 63 2 0..127 (1..128)
User 63 8 0..127 (1..128)
Drum Voice Preset 63 32 0..47 (1..48)
User 63 40 0..15 (1..16)
Plug-in Voice User 1 63 24 0..63 (1..64)
User 2 63 25 0..63 (1..64)
User 3 63 26 0..63 (1..64)
Performance User 63 64 0..127 (1..128)
Sample Voice 63 50 0..127 (1..128) *7
Plug-in Voice Preset 1 (Slot1) 63 70 0..63 (1..64) *4
Preset 2 (Slot1) 63 71 0..63 (1..64) *4
Preset 3 (Slot1) 63 72 0..63 (1..64) *4
Preset 1 (Slot2) 63 73 0..63 (1..64) *4
Preset 2 (Slot2) 63 74 0..63 (1..64) *4
Preset 3 (Slot2) 63 75 0..63 (1..64) *4
Preset 1 (Slot3) 63 76 0..63 (1..64) *4
Preset 2 (Slot3) 63 77 0..63 (1..64) *4
Preset 3 (Slot3) 63 78 0..63 (1..64) *4
45
(3-3) REGISTERED PARAMETER NUMBER
STATUS 1011nnnn(BnH) n = 0~15 CHANNEL NUMBER
LSB 01100100(64H)
RPN LSB 0ppppppp
p = RPN LSB (Refer to the table as shown below)
MSB 01100101(65H)
RPN MSB 0qqqqqqq
q = RPN MSB (Refer to the table as shown below)
DATA ENTRY MSB 00000110(06H)
DATA VALUE 0mmmmmmm m = Data Value
DATA ENTRY LSB 00100110(26H)
DATA VALUE 0lllllll l = Data Value
First, designate the parameter using RPN MSB/LSB numbers. Then, set its value with data entry MSB/LSB.
RPN D.ENTRY
LSB MSB MSB LSB PARAMETER NAME DATA RANGE
00H 00H mmH --- PITCH BEND SENSITIVITY 00H - 18H (0 - 24 semitones)
01H 00H mmH llH MASTER FINE TUNE {mmH,llH}={00H,00H}-{40H,00H}-{7FH,7FH}
(-8192*100/8192) - 0 - (+8192*100/8192)
02H 00H mmH --- MASTER COARSE TUNE 28H - 40H - 58H (-24 - 0 - +24 semitones)
7FH 7FH --- --- RPN RESET
RPN numbers will be left not designated.
The internal values are not affected.
(3-4) NON-REGISTERED PARAMETER NUMBER
There are no applicable parameters.
These are transmitted to the Plug-in board.
(3-5) SYSTEM REAL TIME MESSAGES
(3-5-1) ACTIVE SENSING
STATUS 11111110(FEH)
Transmitted at every 200 msec.
Once this code is received, the instrument starts sensing. When no status nor data is received for over approximately
350 ms, MIDI receiving buffer will be cleared, and the sounds currently played and the sustain switch are forcibly
turned off. In this case, each control data will be reset to a certain value.
(3-6) SYSTEM EXCLUSIVE MESSAGE
(3-6-1) UNIVERSAL NON REALTIME MESSAGE
(3-6-1-1) GENERAL MIDI MODE ON
F0H 7EH 7FH 09H 01H F7H
Received only when SYSTEM Receive GM/XG on is set to on in PERFORMANCE MODE. The Part values will be reset
according to the SYSTEM Internal Part settings.
(3-6-1-2) IDENTITY REQUEST (Receive only)
F0H 7EH 0nH 06H 01H F7H ("n" = Device No.However, this instrument receives under "omni.")
(3-6-1-3) IDENTITY REPLY (Transmit only)
F0H 7EH 7FH 06H 02H 43H 00H 41H ddH ddH 00H 00H 00H 7FH F7H
dd;Device Number Code
MOTIF6: 7C 04
MOTIF7: 7D 04
MOTIF8: 7E 04
(3-6-2) UNIVERSAL REALTIME MESSAGE
(3-6-2-1) MIDI MASTER VOLUME
F0H 7FH 7FH 04H 01H llH mmH F7H
Sets the MASTER VOLUME value.
The value "mm" is used to set the master volume (the value "ll" should be ignored).
(3-6-3) PARAMETER CHANGE
(3-6-3-1) XG SYSTEM ON
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n device Number
01001100 4C Model ID
0aaaaaaa 0A ddress High
0aaaaaaa 0A ddress Mid
0aaaaaaa 7E Address Low
0 0 Data
11110111 F7 End of Exclusive
Received only when SYSTEM Receive GM/XG on is set to on in PERFORMANCE MODE. The Part values will be reset
according to the SYSTEM Internal Part settings.
Be aware that executing this message takes ca. 170ms and that, therefore, a certain interval before executing the
following message is needed.
(3-6-3-2) NATIVE PARAMETER CHANGE, MODE CHANGE
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n device Number
01101011 6B Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0ddddddd ddddddd Data
||
11110111 F7 End of Exclusive
For parameters with data size of 2 or more, the appropriate number of data bytes will be transmitted.
See the following MIDI Data Table for Address and Byte Count.
Always received no matter which device number is selected, in the case of REMOTE SWITCH.
(3-6-4) BULK DUMP
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0000nnnn 0n device Number
01101011 6B Model ID
0bbbbbbb bbbbbbb Byte Count
0bbbbbbb bbbbbbb Byte Count
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0 0 Data
||
0ccccccc ccccccc Check-sum
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address and Byte Count.
The Check sum is the value that results in a value of 0 for the lower 7 bits when the Byte Count, Start Address, Data
and Check sum itself are added.
(3-6-5) DUMP REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0010nnnn 2n device Number
01101011 6B Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address and Byte Count.
(3-6-6) PARAMETER REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0011nnnn 3n device Number
01101011 6B Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address and Byte Count.
(4) SYSTEM OVERVIEW (Keyboard, Sequencer and Tone
Generator)
The optional mLAN board can be installed to the MOTIF.
Although three types of note on/note off data, received via MIDI, played by the internal sequencer and played on the
keyboard will be distinguished, the other controllers (channel messages) equally affect the entire notes.
ALL SOUND OFF clears all the sounds in the specific channel(s) played by both the keyboard and the data via MIDI.
ALL NOTES OFF received via MIDI clears the sounds in the specific channel(s) played via MIDI.
46
MIDI Data Table
Bank Select
Available Bank Select/Program Change
When only the Program Change is received after entering any of the mode, the corresponding
voice in the currently selected Type/Memory is called up.
The Master number and the Performance/Song/Pattern/Voice mode can be changed only via
the Parameter Change.
The Song/Pattern can be changed only via the Song Select (Song: F3, 00-F3, 3F/Pattern: F3,
00-F3, 3F).
In the Performance mode, the Part Voice cannot be changed via the Program Change.
Parameter Base Address
MSB (HEX) LSB (HEX) Program No. Type Memory Description
0 00 0 00 0 - 127 Normal Voice GM Voice
127 7F 0 00 0 Drum Voice GM Drum
63 3F 0 00 0 - 127 Normal Voice Preset 1
1 01 0 - 127 Preset 2
2 02 0 - 127 Preset 3
8 08 0 - 127 User
32 20 0 - 47 Drum Voice Preset
40 28 0 - 15 User
50 32 0 - 127 Sample Voice User Can be selected in the Song/Pattern mode.
24 18 0 - 63 Plug-in Voice User 1(Slot1)
25 19 0 - 63 User 2(Slot2)
26 1A 0 - 63 User 3(Slot3)
70 46 0 - 63 Preset 1(Slot1) Can be selected when the Plug-in board has
been installed to slot 1.
71 47 0 - 63 Preset 2(Slot1)
72 48 0 - 63 Preset 3(Slot1)
73 49 0 - 63 Preset 1(Slot2) Can be selected when the Plug-in board has
been installed to slot 2.
74 4A 0 - 63 Preset 2(Slot2)
75 4B 0 - 63 Preset 3(Slot2)
76 4C 0 - 63 Preset 1(Slot3) Can be selected when the Plug-in board has
been installed to slot 3.
77 4D 0 - 63 Preset 2(Slot3)
78 4E 0 - 63 Preset 3(Slot3)
Depending on the installed Plug-in Board. Plug-in Direct -
63 3F 64 40 0 - 127 Performance User(Internal)
Parameter Block Description
Top Address
H M L
SYSTEM 00 00 00 System
00 10 00 Plug-in Board Native System
00 20 00 Master EQ for Voice
01 00 00 Seq Remote Mode Common
02 00 00 Seq Remote Mode Track1 Message
:
02 0F 00 Seq Remote Mode Track16 Message
MODE CHANGE 0A 00 00 Mode Change
BULK CONTROL 0E 00 00 Header
0F 00 00 Footer
MASTER KEYBOARD 33 00 00 Common
32 00 00 Zone1
:
32 03 00 Zone4
PERFORMANCE COMMON 30 00 00 Performace Common
PERFORMANCE PART 31 00 00 Part1
:
31 03 00 Part4
31 60 00 Plug-in 1 Part
31 61 00 Plug-in 2 Part
31 62 00 Plug-in 3 Part
NORMAL VOICE COMMON 40 00 00 Common1
40 00 40 Common2
40 01 00 Reverb
40 02 00 Chorus
40 03 00 Insertion 1
40 04 00 Insertion 2
40 05 00 Controller
40 06 00 LFO
40 70 00 Extra
NORMAL VOICE ELEMENT GROUP1 41 ee 00 ee : Element No.
NORMAL VOICE ELEMENT GROUP2 42 ee 00 ee : Element No.
NORMAL VOICE ELEMENT GROUP3 43 ee 00 ee : Element No.
NORMAL VOICE ELEMENT GROUP4 44 ee 00 ee : Element No.
DRUM COMMON 46 00 00 Common1
46 00 40 Common2
46 01 00 Reverb
46 02 00 Chorus
46 03 00 Insertion 1
46 04 00 Insertion 2
46 05 00 Controller
46 70 00 Extra
DRUM ELEMENT GROUP1 47 ee 00 ee : Element No.
DRUM ELEMENT GROUP2 48 ee 00 ee : Element No.
DRUM ELEMENT GROUP3 49 ee 00 ee : Element No.
DRUM ELEMENT GROUP4 4A ee 00 ee : Element No.
VOICE PLUG-IN 4C 00 00 Common
4C 01 00 Reverb
4C 02 00 Chorus
4C 03 00 Insertion 1
4C 04 00 Insertion 2
4C 05 00 Controller
4C 10 00 Plug-in XG Part
4C 20 00 Native
4C 70 00 Extra
Mix for Song/Pattern 36 00 00 Mix Common
37 00 00 Part1
:
37 0F 00 Part16
37 60 00 Plug-in 1 Part
37 61 00 Plug-in 2 Part
37 62 00 Plug-in 3 Part
47
Bulk Dump Block
“Top Address” indicates the top address of each block designated by bulk dump operation.
“Byte Count” indicates the data size contained in each block designated by bulk dump operation.
To execute 1 Performance/1 Voice bulk dump request, designate its corresponding Bulk Header address.
For the information about “mm” and “nn” shown in the following list, refer to MIDI PARAMETER CHANGE TABLE
(BULK CONTROL) below.
MIDI PARAMETER CHANGE TABLE (Mode Change)
MIDI PARAMETER CHANGE TABLE (BULK CONTROL)
Parameter Block Description Byte Count Top Address
Dec Hex H M L
SYSTEM System 60 003C 00 00 00
Plug-in Board Native System 48 0030 00 10 00
Master EQ (for Voice Mode) 20 0014 00 20 00
Seq Remote Mode Common 19 0013 01 00 00
Seq Remote Tr1 Message 57 0039 02 00 00
: 16 Blocks : : :
Seq Remote Tr16 Message 57 0039 02 0F 00
MASTER KEYBOARD Bulk Header 0 00 0E mm nn
Common 19 0013 33 00 00
Zone1 16 0010 32 00 00
: 4 Blocks : : :
Zone4 16 0010 32 03 00
Bulk Footer 0 00 0F mm nn
PERFORMANCE Bulk Header 0 00 0E mm nn
COMMON Common 88 0058 30 00 00
Reverb 24 0018 30 01 00
Chorus 25 0019 30 02 00
Variation 38 0026 30 03 00
Master EQ 20 0014 30 10 00
Native (for InsEF Plug-in) 68 0044 30 20 00
PART Part1 45 002D 31 00 00
: 4 Blocks : : :
Part4 45 002D 31 03 00
PLUG-IN PART Plug-in 1 Part 45 002D 31 60 00
: 3 Blocks : : :
Plug-in 3 Part 45 002D 31 62 00
Bulk Footer 0 00 0F mm nn
VOICE (NORMAL) Bulk Header 0 00 0E mm nn
COMMON Extra 66 0042 40 70 00
Common1 15 000F 40 00 00
Common2 4 0004 40 00 40
Reverb 24 0018 40 01 00
Chorus 25 0019 40 02 00
Insertion 1(S) 22 0016 40 03 00
Insertion 2(L) 34 0022 40 04 00
Controller 30 001E 40 05 00
LFO 37 0025 40 06 00
ELEMENT 1 Oscillator 28 001C 41 00 00
Amplitude 30 001E 41 00 20
Pitch 29 001D 42 00 00
Filter 50 0032 43 00 00
EQ 8 0008 44 00 00
LFO 7 0007 44 00 40
ELEMENT 2 Oscillator 28 001C 41 01 00
Amplitude 30 001E 41 01 20
Pitch 29 001D 42 01 00
Filter 50 0032 43 01 00
EQ 8 0008 44 01 00
LFO 7 0007 44 01 40
ELEMENT 3 Oscillator 28 001C 41 02 00
Amplitude 30 001E 41 02 20
Pitch 29 001D 42 02 00
Filter 50 0032 43 02 00
EQ 8 0008 44 02 00
LFO 7 0007 44 02 40
ELEMENT 4 Oscillator 28 001C 41 03 00
Amplitude 30 001E 41 03 20
Pitch 29 001D 42 03 00
Filter 50 0032 43 03 00
EQ 8 0008 44 03 00
LFO 7 0007 44 03 40
Bulk Footer 0 00 0F mm nn
VOICE (DRUM) Bulk Header 0 00 0E mm nn
COMMON Extra 66 0042 46 70 00
Common1 8 0008 46 00 00
Common2 4 0004 46 00 40
Reverb 24 0018 46 01 00
Chorus 25 0019 46 02 00
Insertion 1(S) 22 0016 46 03 00
Insertion 2(L) 34 0022 46 04 00
Controller 30 001E 46 05 00
KEY C 0 Oscillator 19 0013 47 00 00
Amplitude 12 000C 47 00 20
Pitch 3 0003 48 00 00
Filter 8 0008 49 00 00
EQ 8 0008 4A 00 00
: 73 Blocks : : :
KEY C 6 Oscillator 19 0013 47 48 00
Amplitude 12 000C 47 48 20
Pitch 3 0003 48 48 00
Filter 8 0008 49 48 00
EQ 8 0008 4A 48 00
Bulk Footer 0 00 0F mm nn
VOICE (PLUG-IN) Bulk Header 0 00 0E mm nn
COMMON Extra 66 0042 4C 70 00
* Receives the Plug-in Bulk Dump
of the MOTIF and complies with
the Dump Request.
Common 13 000D 4C 00 00
Reverb 24 0018 4C 01 00
Chorus 25 0019 4C 02 00
Insertion 1(S) 22 0016 4C 03 00
Insertion 2(L) 34 0022 4C 04 00
Controller 10 000A 4C 05 00
Plug-in XG Part 35 0023 4C 10 00
Native 68 0044 4C 20 00
Bulk Footer 0 00 0F mm nn
MIX Bulk Header 0 00 0E mm nn
COMMON Common 88 0058 36 00 00
Reverb 24 0018 36 01 00
Chorus 25 0019 36 02 00
Variation 38 0026 36 03 00
Master EQ 20 0014 36 10 00
Native (for InsEF Plug-in) 68 0044 36 20 00
PART Part1 45 002D 37 00 00
: 16 Blocks : : :
Part16 45 002D 37 0F 00
PLUG-IN PART Plug-in 1 Part 45 002D 37 60 00
: 3 Blocks : : :
Plug-in 3 Part 45 002D 37 62 00
Bulk Footer 0 00 0F mm nn
Address Size Data
Range
(HEX)
Prameter Name Description Notes
0A 00 00 1 00 - 7F MASTER NUMBER SELECT 0-127
01 1 00 - 04 MODE CHANGE 0:Voice, 1:Performance,
2:Pattern(Mix), 3:Song(Mix),
4:Master
Address Size Data
Range
(HEX)
Prameter Name Description Notes
0E 08 nn 1 - Bulk Header Normal Voice INT (nn = 0 - 127)
09 nn 1 - reserved
0F nn 1 - Normal Voice Edit Buffer (nn = 0)
18 nn 1 - Plug-in Voice PLG1 (nn = 0 - 63)
19 nn 1 - Plug-in Voice PLG2 (nn = 0 - 63)
1A nn 1 - Plug-in Voice PLG3 (nn = 0 - 63)
1F nn 1 - Plug-in Voice Edit Buffer (nn = 0)
28 nn 1 - Drum Voice INT (nn = 0 - 15)
29 nn 1 - reserved
2F nn 1 - Drum Voice Edit Buffer (nn = 0)
40 nn 1 - Performance INT (nn = 0 - 127)
41 nn 1 - reserved
4F nn 1 - Performance Edit Buffer (nn = 0)
5F nn 1 - Mix Edit Buffer (nn = 0)
68 nn 1 - reserved
6F nn 1 - reserved
70 nn 1 - Master INT (nn = 0 - 127)
7F nn 1 - Master Edit Buffer (nn = 0)
0F 08 nn 1 - Bulk Footer Normal Voice INT (nn = 0 - 127)
09 nn 1 - reserved
0F nn 1 - Normal Voice Edit Buffer (nn = 0)
18 nn 1 - Plug-in Voice PLG1 (nn = 0 - 63)
19 nn 1 - Plug-in Voice PLG2 (nn = 0 - 63)
1A nn 1 - Plug-in Voice PLG3 (nn = 0 - 63)
1F nn 1 - Plug-in Voice Edit Buffer (nn = 0)
28 nn 1 - Drum Voice INT (nn = 0 - 15)
29 nn 1 - reserved
2F nn 1 - Drum Voice Edit Buffer (nn = 0)
40 nn 1 - Performance INT (nn = 0 - 127)
41 nn 1 - reserved
4F nn 1 - Performance Edit Buffer (nn = 0)
5F nn 1 - Mix Edit Buffer (nn = 0)
68 nn 1 - reserved
6F nn 1 - reserved
70 nn 1 - Master INT (nn = 0 - 127)
7F nn 1 - Master Edit Buffer (nn = 0)
Parameter Block Description Byte Count Top Address
Dec Hex H M L
48
MIDI PARAMETER CHANGE TABLE (SYSTEM)
TOTAL SIZE = 60 3C (HEX)
TOTAL SIZE = 48 30 (HEX)
TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 19 13 (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
00 00 00 1 00 - 7F Master Volume 0 - 127
MIDI Master Volume
01 1 28 - 58 Master Note Shift -24 - +24[semitones]
02 4 00 - 0F Master Tune -102.4 - +102.3[cent] MIDI Master Tuning
00 - 0F 1st bit 3-0 → bit 15-12
00 - 0F 2nd bit 3-0 → bit 11-8
00 - 0F 3rd bit 3-0 → bit 7-4
4th bit 3-0 → bit 3-0
06 1 00 - 01 Controller Reset hold, reset
07 1 35 - 4B Master Transpose -11 - +11(semitones)
08 1 3D - 43 Master Octave Shift -3 - +3
09 1 00 - 01 Local Switch off, on
0A 1 00 - 10,
7F
Basic Receive Channel 1 - 16, omni, off
0B 1 00 - 0F,
7F
Keyboard Transmit Channel 1 - 16, off
0C 1 00 reserved
0D 1 00 - 01 REC ARP Switch off, on
0E 1 00 - 03 STEREO L&R OUTPUT GAIN 00:0dB, 01:+6dB, 02:+12dB,
03:+18dB
0F 1 00 - 03 INDIVIDUAL OUT 1 OUTPUT
GAIN
00:0dB, 01:+6dB, 02:+12dB,
03:+18dB
10 1 00 - 03 INDIVIDUAL OUT 2 OUTPUT
GAIN
00:0dB, 01:+6dB, 02:+12dB,
03:+18dB
11 1 00 - 03 BC Curve (for TG) thru, soft, hard, wide
12 1 00 - 04 Keyboard Velocity Curve norm, soft, hard, wide, fixed
13 1 01 - 7F Keyboard Fixed Velocity 1 - 127
14 1 00 - 01 Receive GM/XG On for Multi Part
PB
off, on
15 1 00 - 01 Receive/Transmit Bank Select off, on
16 1 00 - 01 Receive/Transmit Program Change off, on
17 1 00 - 01 MIDI Control Mode mode 1, mode 2
18 1 00 - 07 Thru Port for USB 1 - 8
19 1 00 - 02 MIDI IN/OUT MIDI, USB, mLAN
1A 1 00 - 07 Effect Bypass for System Effect bit0: Reverb, bit1: Chorus, bit2:
Variation
1B 1 01 reserved
1C 1 00 - 03 Effect Bypass for Insertion Effect bit0: Internal, bit1: Plug-in Board
1D 1 00 - 01 Auto ROM Demo Song&Chain
Load Switch
off, on
1E 1 00 - 01 AutoLoad Switch off, on
1F 1 00 - 05 Power on Mode Performance, Voice (INT), Voice
(PRE1), GM, last, Master
20 1 00 reserved
21 1 00 - 02 Single Part Plug-in Board Port
Assign
1, 2, 3 Port 1 in any other
mode
22 1 00 - 02 Multi Part Plug-in Board Port
Assign
1, 2, 3 Port 1 in any other
mode
23 1 00 - 01 Send XGon to for Song/Pattern
Change
off, on
24 1 00 - 01 A/D Source analog, mLAN
25 1 00 - 01 Analog Input Gain mic, line
26 1 00 reserved
27 1 00 - 01 Digital Input for AIEB1 coaxial, optical
28 1 00 - 01 Digital Output Word Length for
AIEB1
20 bit, 24 bit
29 1 reserved
2A 1 00 - 34 Assign A Destination off, 1 - 52
2B 1 00 - 34 Assign B Destination off, 1 - 52
2C 1 reserved
2D 1 00 - 5F Assign A Control Number off, 1 - 95
2E 1 00 - 5F Assign B Control Number off, 1 - 95
2F 1 14 reserved
30 1 01 reserved
31 1 00 - 65 FS Assign off, 1 - 95, ArpSw, ArpHold, Play/
Stop, PCInc, PCDec, OctaveReset
32 1 00 - 5F ARP Switch Control Number off, 1 - 95
33 1 00 - 5F ARP Hold Control Number off, 1 - 95
34 1 00 - 01 ARP MIDI Out Switch off, on for Voice Mode
35 1 00 - 0F ARP MIDI Out Channel 1 - 16 :
36 1 00 - 5F Assign1 Control Number off, 1 - 95 :
37 1 00 - 5F Assign2 Control Number off, 1 - 95 :
38 1 00 - 5F BC Control Number off, 1 - 95 :
39 1 00 - 5F FC2 Control Number off, 1 - 95 :
3A 1 00 - 5F FC1 Control Number off, 1 - 95
3B 1 reserved
00 10 00 16 00 - 7F Plug-in 1 Native System Parameter depends on Plug-in Board
10 16 00 - 7F Plug-in 2 Native System Parameter depends on Plug-in Board
20 16 00 - 7F Plug-in 3 Native System Parameter depends on Plug-in Board
Address Size Data
Range
(HEX)
Prameter Name Description Notes
00 20 00 1 34 -4C EQ Gain1 -12 - +12[dB] for Voice Mode
01 1 04 - 28 EQ Frequency1 32 - 2000[Hz] :
02 1 01 - 78 EQ Q1 0. 1 - 12.0 :
03 1 00 - 01 EQ Shape1 shelv, peak :
04 1 34 - 4C EQ Gain2 -12 - +12[dB] :
05 1 0E - 36 EQ Frequency2 100 - 10.0[kHz] :
06 1 01 - 78 EQ Q2 0.1 - 12.0 :
1 01 reserved
08 1 34 -4C EQ Gain3 -12 - +12[dB] :
09 1 0E - 36 EQ Frequency3 100 - 10.0[kHz] :
0A 1 01 - 78 EQ Q3 0. 1- 12.0 :
1 NOT USED :
0C 1 34 - 4C EQ Gain4 -12 - +12[dB] :
0D 1 0E - 36 EQ Frequency4 100 - 10.0[kHz] :
0E 1 01 - 78 EQ Q4 0.1 - 12.0 :
1 NOT USED :
10 1 34 - 4C EQ Gain5 -12 - +12[dB] :
11 1 1C - 3A EQ Frequency5 0.5 - 16.0[kHz] :
12 1 01 - 78 EQ Q5 0.1 - 12.0 :
13 1 00 - 01 EQ Shape5 shelv, peak :
01 00 00 1 00 - 03 Seq Remote Mode Template 0:Logic, 1:Cubase, 2:Cakewalk,
3:ProTools
01 00 01 1 00 - 03 Seq Remote Mode Port Number off, 1, 2, 3
01 00 02 1 00 - 03 Seq Remote Knob Function Select Group1, 2, 3, 4
01 00 03 1 00 - 7F Seq Remote Mode Top Switch
Message
0 - 127
01 00 04 1 00 - 0F,
7F
Seq Remote Mode Top Switch
Channel
1 - 16,off
01 00 05 1 00 - 7F Seq Remote Mode << Switch
Message
0 - 127
01 00 06 1 00 - 7F Seq Remote Mode << Switch on
Value
0 - 127
01 00 07 1 00 - 7F Seq Remote Mode << Switch off
Value
0 - 127
01 00 08 1 00 - 0F,
7F
Seq Remote Mode << Switch
Channel
1 - 16, off
01 00 09 1 00 - 7F Seq Remote Mode >> Switch
Message
0 - 127
01 00 0A 1 00 - 7F Seq Remote Mode >> Switch on
Value
0 - 127
01 00 0B 1 00 - 7F Seq Remote Mode >> Switch off
Value
0 - 127
01 00 0C 1 00 - 0F,
7F
Seq Remote Mode >> Switch
Channel
1 - 16, off
01 00 0D 1 00 - 7F Seq Remote Mode Rec Switch
Message
0 - 127
01 00 0E 1 00 - 0F,
7F
Seq Remote Mode Rec Switch
Channel
1 - 16, off
01 00 0F 1 00 - 7F Seq Remote Mode Stop Switch
Message
0 - 127
01 00 10 1 00 - 0F,
7F
Seq Remote Mode Stop Switch
Channel
1 - 16, off
01 00 11 1 00 - 7F Seq Remote Mode Play Switch
Message
0 - 127
01 00 12 1 00 - 0F,
7F
Seq Remote Mode Play Switch
Channel
1 - 16, off
02 tt 00 1 00 - 7F Seq Remote Mode Track Select
Switch Message
0 - 127
02 tt 01 1 00 - 0F,
7F
Seq Remote Mode Track Select
Switch Channel
1 - 16, off
02 tt 02 1 00 - 7F Seq Remote Mode Track Mute
Switch Message
0 - 127
02 tt 03 1 00 - 7F Seq Remote Mode Track Mute on
Value
0 - 127
02 tt 04 1 00 - 7F Seq Remote Mode Track Mute off
Value
0 - 127
02 tt 05 1 00 - 0F,
7F
Seq Remote Mode Track Mute
Switch Channel
1 - 16, off
02 tt 06 1 00 - 7F Seq Remote Mode Slider Message 0 - 127
02 tt 07 1 00 - 0F,
7F
Seq Remote Mode Slider Channel 1 - 16, off
02 tt 08 1 00 - 32 Seq Remote Mode Slider Name 0 - 50
02 tt 09 1 00 - 7F Seq Remote Mode Group1 Knob1
Message
0 - 127
02 tt 0A 1 00 - 0F,
7F
Seq Remote Mode Group1 Knob1
Channel
1 - 16, off
02 tt 0B 1 00 - 32 Seq Remote Mode Group1 Knob1
Name
---, Vol, Pan, Fx1, …
02 tt 0C 1 00 - 7F Seq Remote Mode Group1 Knob2
Message
0 - 127
02 tt 0D 1 00 - 0F,
7F
Seq Remote Mode Group1 Knob2
Channel
1 - 16, off
02 tt 0E 1 00 - 32 Seq Remote Mode Group1 Knob2
Name
---, Vol, Pan, Fx1, …
02 tt 0F 1 00 - 7F Seq Remote Mode Group1 Knob3
Message
0 - 127
02 tt 10 1 00 - 0F,
7F
Seq Remote Mode Group1 Knob3
Channel
1 - 16, off
02 tt 11 1 00 - 32 Seq Remote Mode Group1 Knob3
Name
---, Vol, Pan, Fx1, …
49
TOTAL SIZE = 57 39 (HEX)
tt = Track number
00 - 0F Track 1 - 16
MIDI PARAMETER CHANGE TABLE (MASTER)
TOTAL SIZE = 19 13 (HEX)
TOTAL SIZE = 16 10 (HEX)
nn = zone number 00 - 03
MIDI PARAMETER CHANGE TABLE
(PERFORMANCE COMMON)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
02 tt 12 1 00 - 7F Seq Remote Mode Group1 Knob4
Message
0 - 127
02 tt 13 1 00 - 0F,
7F
Seq Remote Mode Group1 Knob4
Channel
1 - 16, off
02 tt 14 1 00 - 32 Seq Remote Mode Group1 Knob4
Name
---, Vol, Pan, Fx1, …
02 tt 15 1 00 - 7F Seq Remote Mode Group2 Knob1
Message
0 - 127
02 tt 16 1 00 - 0F,
7F
Seq Remote Mode Group2 Knob1
Channel
1 - 16, off
02 tt 17 1 00 - 32 Seq Remote Mode Group2 Knob1
Name
---, Vol, Pan, Fx1, …
02 tt 18 1 00 - 7F Seq Remote Mode Group2 Knob2
Message
0 - 127
02 tt 19 1 00 - 0F,
7F
Seq Remote Mode Group2 Knob2
Channel
1 - 16, off
02 tt 1A 1 00 - 32 Seq Remote Mode Group2 Knob2
Name
---, Vol, Pan, Fx1, …
02 tt 1B 1 00 - 7F Seq Remote Mode Group2 Knob3
Message
0 - 127
02 tt 1C 1 00 - 0F,
7F
Seq Remote Mode Group2 Knob3
Channel
1 - 16, off
02 tt 1D 1 00 - 32 Seq Remote Mode Group2 Knob3
Name
---, Vol, Pan, Fx1, …
02 tt 1E 1 00 - 7F Seq Remote Mode Group2 Knob4
Message
0 - 127
02 tt 1F 1 00 - 0F,
7F
Seq Remote Mode Group2 Knob4
Channel
1 - 16,off
02 tt 20 1 00 - 32 Seq Remote Mode Group2 Knob4
Name
---, Vol, Pan, Fx1, …
02 tt 21 1 00 - 7F Seq Remote Mode Group3 Knob1
Message
0 - 127
02 tt 22 1 00 - 0F,
7F
Seq Remote Mode Group3 Knob1
Channel
1 - 16, off
02 tt 23 1 00 - 32 Seq Remote Mode Group3 Knob1
Name
---, Vol, Pan, Fx1, …
02 tt 24 1 00 - 7F Seq Remote Mode Group3 Knob2
Message
0 - 127
02 tt 25 1 00 - 0F,
7F
Seq Remote Mode Group3 Knob2
Channel
1 - 16, off
02 tt 26 1 00 - 32 Seq Remote Mode Group3 Knob2
Name
---, Vol, Pan, Fx1, …
02 tt 27 1 00 - 7F Seq Remote Mode Group3 Knob3
Message
0 - 127
02 tt 28 1 00 - 0F,
7F
Seq Remote Mode Group3 Knob3
Channel
1 - 16, off
02 tt 29 1 00 - 32 Seq Remote Mode Group3 Knob3
Name
---, Vol, Pan, Fx1, …
02 tt 2A 1 00 - 7F Seq Remote Mode Group3 Knob4
Message
0 - 127
02 tt 2B 1 00 - 0F,
7F
Seq Remote Mode Group3 Knob4
Channel
1 - 16, off
02 tt 2C 1 00 - 32 Seq Remote Mode Group3 Knob4
Name
---, Vol, Pan, Fx1, …
02 tt 2D 1 00 - 7F Seq Remote Mode Group4 Knob1
Message
0 - 127
02 tt 2E 1 00 - 0F,
7F
Seq Remote Mode Group4 Knob1
Channel
1 - 16, off
02 tt 2F 1 00 - 32 Seq Remote Mode Group4 Knob1
Name
---, Vol, Pan, Fx1, …
02 tt 30 1 00 - 7F Seq Remote Mode Group4 Knob2
Message
0 - 127
02 tt 31 1 00 - 0F,
7F
Seq Remote Mode Group4 Knob2
Channel
1 - 16, off
02 tt 32 1 00 - 32 Seq Remote Mode Group4 Knob2
Name
---, Vol, Pan, Fx1, …
02 tt 33 1 00 - 7F Seq Remote Mode Group4 Knob3
Message
0 - 127
02 tt 34 1 00 - 0F,
7F
Seq Remote Mode Group4 Knob3
Channel
1 - 16, off
02 tt 35 1 00 - 32 Seq Remote Mode Group4 Knob3
Name
---, Vol, Pan, Fx1, …
02 tt 36 1 00 - 7F Seq Remote Mode Group4 Knob4
Message
0 - 127
02 tt 37 1 00 - 0F,
7F
Seq Remote Mode Group4 Knob4
Channel
1 - 16, off
02 tt 38 1 00 - 32 Seq Remote Mode Group4 Knob4
Name
---, Vol, Pan, Fx1, …
Address Size Data
Range
(HEX)
Prameter Name Description Notes
33 00 00 1 20 - 7E Master Name1 32..126(ASCII)
33 00 01 1 20 - 7E Master Name2 32..126(ASCII)
33 00 02 1 20 - 7E Master Name3 32..126(ASCII)
33 00 03 1 20 - 7E Master Name4 32..126(ASCII)
33 00 04 1 20 - 7E Master Name5 32..126(ASCII)
33 00 05 1 20 - 7E Master Name6 32..126(ASCII)
33 00 06 1 20 - 7E Master Name7 32..126(ASCII)
33 00 07 1 20 - 7E Master Name8 32..126(ASCII)
33 00 08 1 20 - 7E Master Name9 32..126(ASCII)
33 00 09 1 20 - 7E Master Name10 32..126(ASCII)
33 00 0A 1 00 reserved
33 00 0B 1 00 reserved
33 00 0C 1 00 reserved
33 00 0D 1 00 - 03 Mode Change 0=Voice, 1=Performance,
2=Pattern, 3=Song
33 00 0E 1 00 - 7F Bank MSB for Voice/Perf Mode 0..127
33 00 0F 1 00 - 7F Bank LSB for Voice/Perf Mode 0..127
33 00 10 1 00 - 7F Program Number 1..128
33 00 11 1 00 - 01 Zone on/off for Performance Mode off, on
33 00 12 1 00 - 04 Knob/Slider Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset, 4=Zone
Address Size Data
Range
(HEX)
Prameter Name Description Notes
32 nn 00 1 00 - 3F Transmit Channel, MIDI/TG Switch bit0-3: Ch1..16
bit4: MIDI off,on
bit5: TG off,on
32 nn 01 1 3D - 43 Transpose (Octave) -3..+3
32 nn 02 1 35 - 4B Transpose (Semitone) -11..+11(semitones)
32 nn 03 1 00 - 7F Note Limit Low C-2..G8
32 nn 04 1 00 - 7F Note Limit High C-2..G8
32 nn 05 1 00 - 03 Transmit Bank Select for TG bit0: off, on Bank Select
Transmit Program Change for TG bit1: off, on Program Change
32 nn 06 1 7F reserved
32 nn 07 1 00 - 7F MIDI Volume 0..127
32 nn 08 1 00 - 7F MIDI Pan 0..127
32 nn 09 1 00 - 7F MIDI Bank MSB 0..127
32 nn 0A 1 00 - 7F MIDI Bank LSB 0..127
32 nn 0B 1 00 - 7F MIDI Program Number 1..128
32 nn 0C 1 00 - 7F Transmit Volume/Expression bit0: off, on Volume/Expression
Ctrl#7,11
Transmit Pan bit1: off, on Pan
Transmit Sustain bit2: off, on Sustain
Transmit Bank Select for MIDI bit3: off, on Bank Select
Transmit Program Change for MIDI bit4: off, on Program Change
Transmit AT bit5: off, on AT
Transmit PB bit6: off, on PB
32 nn 0D 1 00 - 7F Transmit FC2 bit0: off, on FC2
Transmit FS bit1: off, on FS
Transmit FC1 bit2: off, on FC1
Transmit BC bit3: off, on BC
Transmit MW bit4: off, on MW
Transmit Assignable Slider bit5: off, on Assignable Slider
Transmit Assignable Knob bit6: off, on Assignable Knob
32 nn 0E 1 00 - 5F Control Slider Control Number off, 1 - 95
32 nn 0F 1 00 - 5F Control knob Control Number off, 1 - 95
Address Size Data
Range
(HEX)
Prameter Name Description Notes
30 00 00 1 20 - 7E Performance Name1 32..126(ASCII)
30 00 01 1 20 - 7E Performance Name2 32..126(ASCII)
30 00 02 1 20 - 7E Performance Name3 32..126(ASCII)
30 00 03 1 20 - 7E Performance Name4 32..126(ASCII)
30 00 04 1 20 - 7E Performance Name5 32..126(ASCII)
30 00 05 1 20 - 7E Performance Name6 32..126(ASCII)
30 00 06 1 20 - 7E Performance Name7 32..126(ASCII)
30 00 07 1 20 - 7E Performance Name8 32..126(ASCII)
30 00 08 1 20 - 7E Performance Name9 32..126(ASCII)
30 00 09 1 20 - 7E Performance Name10 32..126(ASCII)
30 00 0A 1 00 reserved
30 00 0B 1 00 reserved
30 00 0C 1 00 - 10 Performance Category(Main) 0..16(--..Co)
Ap, Kb, Or, Gt, Ba,
St, Br, Rp, Ld, Pd,
Sc,Cp,Dr,Se,Me,Co
30 00 0D 1 00 - 03 Performance Category(Sub) 0..3(--.Sub1..Sub3)
depens on Main
Category
30 00 0E 1 00 reserved
30 00 0F 1 00 reserved
30 00 10 1 10 reserved
30 00 11 1 00 - 01 ARP MIDI Out Switch off, on
30 00 12 1 00 - 10 ARP MIDI Out Channel 1..16, kbd-ch
30 00 13 1 00 - 02 QED ARP Type Bank pre1, pre2, user
30 00 14 1 00 - 7F QED ARP Type UpOct1 - GateCut3
50
TOTAL SIZE = 88 58 (HEX)
TOTAL SIZE = 24 18 (HEX)
TOTAL SIZE = 25 19 (HEX)
TOTAL SIZE = 38 26 (HEX)
30 00 15 1 00 - 01 ARP Switch off, on
30 00 16 1 00 - 02 ARP Hold sync-off, off, on
30 00 17 1 00 - 06 ARP Unit Multiply 50%, 66%, 75%, 100%, 133%,
150%, 200%
30 00 18 1 00 - 7F ARP Note Limit Low C-2..G8
30 00 19 1 00 - 7F ARP Note Limit High C-2..G8
30 00 1A 1 01 - 7F ARP Velocity Limit Low 1 - 127
30 00 1B 1 01 - 7F ARP Velocity Limit High 1 - 127
30 00 1C 1 00 - 02 ARP Key Mode sort, thru, direct
30 00 1D 1 00 - 01 ARP Vel Mode original,thru
30 00 1E 2 0000 -
00C8
ARP Velocity Rate MSB 0...200%
ARP Velocity Rate LSB
30 00 20 2 0000 -
00C8
ARP Gate Time Rate MSB 0...200%
ARP Gate TIme Rate LSB
30 00 22 2 0001 -
012C
QED ARP Tempo MSB 1..300
QED ARP Tempo LSB
30 00 24 1 00 - 03 Knob Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset
30 00 25 1 01 - 7F Pan L63..C..R63
30 00 26 1 00 - 7F Chorus Control -64..+63
30 00 27 1 00 - 7F QED Decay Time -64..+63
30 00 28 1 00 - 7F QED Sustain Level -64..+63
30 00 29 1 00 - 7F QED FEG Attack Time -64..+63
30 00 2A 1 00 - 7F QED FEG Decay Time -64..+63
30 00 2B 1 00 - 7F QED FEG Release Time -64..+63
30 00 2C 1 40 reserved
30 00 2D 1 00 - 7F QED FEG Depth -64..+63
30 00 2E 1 00 - 7F KnobA -64..+63
30 00 2F 1 00 - 7F KnobB -64..+63
30 00 30 1 40 reserved
30 00 31 1 00 - 7F EQ Low Gain -64..+63
30 00 32 1 00 - 7F EQ Low Mid Gain -64..+63
30 00 33 1 00 - 7F EQ High Mid Gain -64..+63
30 00 34 1 00 - 7F EQ High Gain -64..+63
30 00 35 1 00 - 7F Scene 1 Assign1 -64..+63
30 00 36 1 00 - 7F Scene 1 Assign2 -64..+63
30 00 37 1 00 - 7F Scene 1 Cutoff Frequency -64..+63
30 00 38 1 00 - 7F Scene 1 Resonance -64..+63
30 00 39 1 00 - 7F Scene 1 Attack Time -64..+63
30 00 3A 1 00 - 7F Scene 1 Release Time -64..+63
30 00 3B 1 40 reserved
30 00 3C 1 40 reserved
30 00 3D 1 40 reserved
30 00 3E 1 40 reserved
30 00 3F 1 40 reserved
30 00 40 1 40 reserved
30 00 41 1 40 reserved
30 00 42 1 00 - 7F Volume 0..127
30 00 43 1 00 - 7F QED Portamento Time -64..+63
30 00 44 1 00 - 01 QED Portamento Switch off, on
30 00 45 1 00 - 7F Reverb Send 0..127
30 00 46 1 00 - 7F Chorus Send 0..127
30 00 47 1 00 reserved
30 00 48 1 00 - 5F Assign1 Control Number off, 1 - 95
30 00 49 1 00 - 5F Assign2 Control Number off, 1 - 95
30 00 4A 1 00 - 5F BC Control Number off, 1 - 95
30 00 4B 1 00 - 5F FC2 Control Number off, 1 - 95
30 00 4C 1 00 - 5F FC1 Control Number off, 1 - 95
30 00 4D 1 00 - 7F Voice Insertion Effect Part 0 - 3: Part1…4
96 - 98: PB Part1, 2, 3
127: off
30 00 4E 1 reserved
30 00 4F 1 00 - 7F InsEF Plug-in Part 0 - 3: Part1…4
64: PartAD
97 - 98: PB Part2, 3
127: off
30 00 50 1 00 - 03 A/D Input Mode L mono, R mono, L+R mono,
stereo
30 00 51 1 00 - 7F A/D Part Volume 0 - 127
30 00 52 1 01 - 7F A/D Part Pan L63 - C - R63
30 00 53 1 00 - 7F A/D Part Reverb Send 0 - 127
30 00 54 1 00 - 7F A/D Part Chorus Send 0 - 127
30 00 55 1 00 - 7F A/D Part Variation Send 0 - 127
30 00 56 1 00 - 7F A/D Part Dry Level 0 - 127
30 00 57 1 00 - 71 A/D Part Output Select 0: L&R
8: asnL&R, 9: asn1&2, 10: asn3&4,
11: asn5&6
64 - 71: asnL, asnR - asn5, asn6
Address Size Data
Range
(HEX)
Prameter Name Description Notes Address Size Data
Range
(HEX)
Prameter Name Description Notes
30 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List
00 - 7F Reverb Type LSB
30 01 02 2 00 - 7F Reverb Parameter 1 MSB ˝
00 - 7F Reverb Parameter 1 LSB
30 01 04 2 00 - 7F Reverb Parameter 2 MSB ˝
00 - 7F Reverb Parameter 2 LSB
30 01 06 2 00 - 7F Reverb Parameter 3 MSB Refer to Effect Parameter List
00 - 7F Reverb Parameter 3 LSB
30 01 08 2 00 - 7F Reverb Parameter 4 MSB ˝
00 - 7F Reverb Parameter 4 LSB
30 01 0A 2 00 - 7F Reverb Parameter 5 MSB ˝
00 - 7F Reverb Parameter 5 LSB
30 01 0C 2 00 - 7F Reverb Parameter 6 MSB ˝
00 - 7F Reverb Parameter 6 LSB
30 01 0E 2 00 - 7F Reverb Parameter 7 MSB ˝
00 - 7F Reverb Parameter 7 LSB
30 01 10 2 00 - 7F Reverb Parameter 8 MSB ˝
00 - 7F Reverb Parameter 8 LSB
30 01 12 2 00 - 7F Reverb Parameter 9 MSB ˝
00 - 7F Reverb Parameter 9 LSB
30 01 14 2 00 - 7F Reverb Parameter 10 MSB ˝
00 - 7F Reverb Parameter 10 LSB
30 01 16 1 00 - 7F Reverb Return -∞dB…0dB…+6dB(0…96…127)
30 01 17 1 01 - 7F Reverb Pan L63…C…R63
30 02 00 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List
00 - 7F Chorus Type LSB
30 02 02 2 00 - 7F Chorus Parameter 1 MSB ˝
00 - 7F Chorus Parameter 1 LSB
30 02 04 2 00 - 7F Chorus Parameter 2 MSB ˝
00 - 7F Chorus Parameter 2 LSB
30 02 06 2 00 - 7F Chorus Parameter 3 MSB ˝
00 - 7F Chorus Parameter 3 LSB
30 02 08 2 00 - 7F Chorus Parameter 4 MSB ˝
00 - 7F Chorus Parameter 4 LSB
30 02 0A 2 00 - 7F Chorus Parameter 5 MSB ˝
00 - 7F Chorus Parameter 5 LSB
30 02 0C 2 00 - 7F Chorus Parameter 6 MSB ˝
00 - 7F Chorus Parameter 6 LSB
30 02 0E 2 00 - 7F Chorus Parameter 7 MSB ˝
00 - 7F Chorus Parameter 7 LSB
30 02 10 2 00 - 7F Chorus Parameter 8 MSB ˝
00 - 7F Chorus Parameter 8 LSB
30 02 12 2 00 - 7F Chorus Parameter 9 MSB ˝
00 - 7F Chorus Parameter 9 LSB
30 02 14 2 00 - 7F Chorus Parameter 10 MSB ˝
00 - 7F Chorus Parameter 10 LSB
30 02 16 1 00 - 7F Chorus Return -∞dB…0dB…+6dB(0…96…127)
30 02 17 1 01 - 7F Chorus Pan L63…C…R63
30 02 18 1 00 - 7F Send Chorus To Reverb -∞dB…0dB(0…127)
30 03 00 2 00 - 7F Variation Type MSB (for
Performance)
Refer to Effect Parameter List
00 - 7F Variation Type LSB
30 03 02 2 00 - 7F Variation Parameter1 MSB ˝
00 - 7F Variation Parameter1 LSB
30 03 04 2 00 - 7F Variation Parameter2 MSB ˝
00 - 7F Variation Parameter2 LSB
30 03 06 2 00 - 7F Variation Parameter3 MSB ˝
00 - 7F Variation Parameter3 LSB
30 03 08 2 00 - 7F Variation Parameter4 MSB ˝
00 - 7F Variation Parameter4 LSB
30 03 0A 2 00 - 7F Variation Parameter5 MSB ˝
00 - 7F Variation Parameter5 LSB
30 03 0C 2 00 - 7F Variation Parameter6 MSB ˝
00 - 7F Variation Parameter6 LSB
30 03 0E 2 00 - 7F Variation Parameter7 MSB ˝
00 - 7F Variation Parameter7 LSB
30 03 10 2 00 - 7F Variation Parameter8 MSB ˝
00 - 7F Variation Parameter8 LSB
30 03 12 2 00 - 7F Variation Parameter9 MSB ˝
00 - 7F Variation Parameter9 LSB
30 03 14 2 00 - 7F Variation Parameter10 MSB ˝
00 - 7F Variation Parameter10 LSB
30 03 16 2 00 - 7F Variation Parameter11 MSB ˝
00 - 7F Variation Parameter11 LSB
30 03 18 2 00 - 7F Variation Parameter12 MSB ˝
00 - 7F Variation Parameter12 LSB
30 03 1A 2 00 - 7F Variation Parameter13 MSB ˝
00 - 7F Variation Parameter13 LSB
30 03 1C 2 00 - 7F Variation Parameter14 MSB ˝
00 - 7F Variation Parameter14 LSB
30 03 1E 2 00 - 7F Variation Parameter15 MSB ˝
00 - 7F Variation Parameter15 LSB
30 03 20 2 00 - 7F Variation Parameter16 MSB ˝
00 - 7F Variation Parameter16 LSB
30 03 22 1 00 - 7F Variation Return -∞dB…0dB…+6dB(0…96…127)
30 03 23 1 01 - 7F Variation Pan L63…C…R63
30 03 24 1 00 - 7F Send Variation To Reverb -∞dB…0dB(0…127)
30 03 25 1 00 - 7F Send Variation To Chorus -∞dB…0dB(0…127)
51
TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 68 44 (HEX)
MIDI PARAMETER CHANGE TABLE
(PERFORMANCE PART)
TOTAL SIZE = 45 2D (HEX)
pp = part number
00 - 0F Part 1 - 4 (Normal, Drum)
60 Part Plug-in 1 (User, Preset, Direct)
61 Part Plug-in 2 (User, Preset, Direct)
62 Part Plug-in 3 (User, Preset, Direct)
MIDI PARAMETER CHANGE TABLE (NORMAL
VOICE COMMON)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
30 10 00 1 34 - 4C EQ Gain1 -12 - +12[dB]
30 10 01 1 04 - 28 EQ Frequency1 32 - 2000[Hz]
30 10 02 1 01 - 78 EQ Q1 0. 1 - 12.0
30 10 03 1 00 - 01 EQ Shape1 shelv,peak
30 10 04 1 34 - 4C EQ Gain2 -12 - +12[dB]
30 10 05 1 0E - 36 EQ Frequency2 100 - 10.0[kHz]
30 10 06 1 01 - 78 EQ Q2 0.1 - 12.0
30 10 07 1 01 reserved
30 10 08 1 34 - 4C EQ Gain3 -12 - +12[dB]
30 10 09 1 0E - 36 EQ Frequency3 100 - 10.0[kHz]
30 10 0A 1 01 - 78 EQ Q3 0. 1- 12.0
1 Not Used
30 10 0C 1 34 - 4C EQ Gain4 -12 - +12[dB]
30 10 0D 1 0E - 36 EQ Frequency4 100 - 10.0[kHz]
30 10 0E 1 01 - 78 EQ Q4 0.1 - 12.0
1 Not Used
30 10 10 1 34 - 4C EQ Gain5 -12 - +12[dB]
30 10 11 1 1C - 3A EQ Frequency5 0.5 - 16.0[kHz]
30 10 12 1 01 - 78 EQ Q5 0.1 - 12.0
30 10 13 1 00 - 01 EQ Shape5 shelv,peak
30 20 00 16 00 - 7F Plug-in Board Native System
Parameter
(for InsEF Plug-in)
30 20 10 48 00 - 7F Plug-in Board Native Parameter (for InsEF Plug-in)
30 20 40 3 00 - 7F Plug-in Board Type MSB (for InsEF Plug-in)
00 - 7F Plug-in Board Type LSB
00 - 7F Plug-in Board Version Number
43 1 00 - 7F reserved
Address Size Data
Range
(HEX)
Prameter Name Description Notes
31 pp 00 1 00 - 7F Bank Select MSB 0 - 127
31 pp 01 1 00 - 7F Bank Select LSB 0 - 127
31 pp 02 1 00 - 7F Program Number 1 - 128
31 pp 03 1 00 reserved
31 pp 04 1 00 - 01 Part Mode mono, poly
31 pp 05 1 01 - 7F Velocity Limit Low 1 - 127
31 pp 06 1 01 - 7F Velocity Limit High 1 - 127
31 pp 07 1 00 - 7F Note Limit Low C-2 - G8
31 pp 08 1 00 - 7F Note Limit High C-2 - G8
31 pp 09 1 10 - 58 Pitch Bend Range Upper -48 - +24 (PB Part: -24 - +24)
31 pp 0A 1 10 - 58 Pitch Bend Range Lower -48 - +24
31 pp 0B 1 00 - 7F Velocity Sense Depth 0 - 127
31 pp 0C 1 00 - 7F Velocity Send Offset 0 - 127
31 pp 0D 1 00 - 7F Volume 0 - 127
31 pp 0E 1 01 - 7F Pan L63 - C - R63
31 pp 0F 1 40 reserved
31 pp 10 2 00 - 0F Detune MSB -12.8 - +12.7[Hz]
00 - 0F Detune LSB 1st bit 3-0 → bit 7-4
2nd bit 3-0 → bit 3-0
31 pp 12 1 00 - 7F Reverb Send 0 - 127
31 pp 13 1 00 - 7F Chorus Send 0 - 127
31 pp 14 1 00 - 7F Variation Send 0 - 127
31 pp 15 1 00 - 7F Dry Level 0 - 127
31 pp 16 1 28 - 58 Note Shift -24 - +24[semitones]
31 pp 17 1 00 - 7F Filter Cutoff Frequency -64 - +63
31 pp 18 1 00 - 7F Filter Resonance/Width -64 - +63
31 pp 19 1 40 reserved
31 pp 1A 1 00 - 01 Portamento Switch off, on
31 pp 1B 1 00 - 7F Portamento Time 0 - 127
31 pp 1C 1 00 - 01 Portamento Mode fingered, fulltime
31 pp 1D 1 00 reserved
31 pp 1E 1 00 - 7F Output Select 0: L&R
8: asnL&R, 9: asn1&2, 10: asn3&4,
11: asn5&6
64 - 71: asnL, asnR - asn5, asn6
127: drum (or L&R)
31 pp 1F 1 00 - 7F Layer Sw bit0: Layer Sw off, on
Part1:on, Other:off
Arpeggio Sw bit1: Arpeggio Sw off, on
Part1:on, Other:off
Receive Control Change bit2: off,on Control Change
bit3: reserved
bit4: reserved
Receive AT bit5: off, on AT
Receive PB bit6: off, on PB
31 pp 20 1 00 - 7F Receive Expression bit0: off, on Expression
bit1: reserved
bit2: reserved
Receive Sustain/Sostenute bit3: off, on Sustain/Sostenute
bit4: reserved
Receive MW bit5: off, on MW
bit6: reserved
31 pp 21 1 00 - 7F Receive FC2 bit0: off, on FC2
Receive FS bit1: off, on FS
Receive FC1 bit2: off, on FC1
Receive BC bit3: off, on BC
Receive Knob1 bit4: off, on KN1
Receive Knob2 bit5: off, on KN2
bit6: reserved
31 pp 22 1 00 - 7F AEG Decay2 Level (EG Sustain
Level)
-64 - +63
31 pp 23 1 00 - 7F AEG Attack Time (EG Attack Time) -64 - +63
31 pp 24 1 00 - 01 Voice Pan on/off off, on
31 pp 25 1 00 - 7F AEG Decay2 Time (EG Decay
Time)
-64 - +63
31 pp 26 1 00 - 7F AEG Release Time (EG Release
Time)
-64 - +63
31 pp 27 1 00 - 7F FEG Decay2 Level (EG Sustain
Level)
-64 - +63
31 pp 28 1 00 - 7F FEG Attack Time (EG Attack Time) -64 - +63
31 pp 29 1 40 reserved
31 pp 2A 1 00 - 7F FEG Decay2 Time (EG Decay
Time)
-64 - +63
31 pp 2B 1 00 - 7F FEG Release Time (EG Release
Time)
-64 - +63
31 pp 2C 1 00 - 7F FEG DEPTH -64 - +63
Address Size Data
Range(H
EX)
Prameter Name Description Notes
40 70 00 1 20 - 7E Voice Name1 32..126(ASCII)
40 70 01 1 20 - 7E Voice Name2 32..126(ASCII)
40 70 02 1 20 - 7E Voice Name3 32..126(ASCII)
40 70 03 1 20 - 7E Voice Name4 32..126(ASCII)
40 70 04 1 20 - 7E Voice Name5 32..126(ASCII)
40 70 05 1 20 - 7E Voice Name6 32..126(ASCII)
40 70 06 1 20 - 7E Voice Name7 32..126(ASCII)
40 70 07 1 20 - 7E Voice Name8 32..126(ASCII)
40 70 08 1 20 - 7E Voice Name9 32..126(ASCII)
40 70 09 1 20 - 7E Voice Name10 32..126(ASCII)
40 70 0A 1 reserved
40 70 0B 1 reserved
40 70 0C 1 00 - 10 Voice Category (Main) 0..16(--..Co)
Ap, Kb, Or, Gt, Ba, St,
Br, Rp, Ld, Pd, Sc,
Cp, Dr, Se, Me, Co
40 70 0D 1 00 - 03 Voice Category (Sub) 0..3(--.Sub1..Sub3)
40 70 0E 1 reserved
40 70 0F 1 reserved
40 70 10 1 reserved
40 70 11 1 reserved
40 70 12 1 reserved
40 70 13 1 00 - 02 QED ARP Type Bank pre1, pre2, user
40 70 14 1 00 - 7F QED ARP Type UpOct1 - GateCut3
40 70 15 1 00 - 01 ARP Switch off, on
40 70 16 1 00 - 02 ARP Hold sync-off, off, on
40 70 17 1 00 - 06 ARP Unit Multiply 50%, 66%, 75%, 100%, 133%,
150%, 200%
40 70 18 1 00 - 7F ARP Note Limit Low C-2..G8
40 70 19 1 00 - 7F ARP Note Limit High C-2..G8
40 70 1A 1 01 - 7F ARP Velocity Limit Low 1 - 127
40 70 1B 1 01 - 7F ARP Velocity Limit High 1 - 127
40 70 1C 1 00 - 02 ARP Key Mode sort, thru, direct
40 70 1D 1 00 - 01 ARP Vel Mode original, thru
40 70 1E 2 0000 -
00C8
ARP Velocity Rate MSB 0...200%
ARP Velocity Rate LSB
40 70 20 2 0000 -
00C8
ARP Gate Time Rate MSB 0...200%
ARP Gate TIme Rate LSB
40 70 22 2 0001 -
012C
QED ARP Tempo MSB 1..300
QED ARP Tempo LSB
40 70 24 1 00 - 03 Knob Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset
40 70 25 1 01 - 7F Pan L63..C..R63
40 70 26 1 00 - 7F Chorus Control -64..+63
40 70 27 1 00 - 7F QED Decay Time -64..+63
40 70 28 1 00 - 7F QED Sustain Level -64..+63
40 70 29 1 00 - 7F QED FEG Attack Time -64..+63
40 70 2A 1 00 - 7F QED FEG Decay Time -64..+63
40 70 2B 1 00 - 7F QED FEG Release Time -64..+63
40 70 2C 1 40 reserved
40 70 2D 1 00 - 7F QED FEG Depth -64..+63
40 70 2E 1 00 - 7F KnobA -64..+63
40 70 2F 1 00 - 7F KnobB -64..+63
40 70 30 1 40 reserved
40 70 31 1 00 - 7F EQ Low Gain -64..+63
40 70 32 1 00 - 7F EQ Low Mid Gain -64..+63
40 70 33 1 00 - 7F EQ High Mid Gain -64..+63
40 70 34 1 00 - 7F EQ High Gain -64..+63
40 70 35 1 00 - 7F Scene 1 Assign1 -64..+63
Address Size Data
Range
(HEX)
Prameter Name Description Notes
52
TOTAL SIZE = 66 42 (HEX)
TOTAL SIZE = 15 0F (HEX)
TOTAL SIZE = 4 04 (HEX)
TOTAL SIZE = 24 18 (HEX)
TOTAL SIZE = 25 19 (HEX)
TOTAL SIZE = 22 16 (HEX)
TOTAL SIZE = 34 22 (HEX)
40 70 36 1 00 - 7F Scene 1 Assign2 -64..+63
40 70 37 1 00 - 7F Scene 1 Cutoff Frequency -64..+63
40 70 38 1 00 - 7F Scene 1 Resonance -64..+63
40 70 39 1 00 - 7F Scene 1 Attack Time -64..+63
40 70 3A 1 00 - 7F Scene 1 Release Time -64..+63
40 70 3B 1 40 reserved
40 70 3C 1 40 reserved
40 70 3D 1 40 reserved
40 70 3E 1 40 reserved
40 70 3F 1 40 reserved
40 70 40 1 40 reserved
40 70 41 1 00 reserved
40 00 00 1 03 reserved
40 00 01 1 00 - 7F Volume 0 - 127
40 00 02 1 00 - 01 Same Note Number Key On Assign single, multi
40 00 03 1 00 - 01 QED Mono/Poly Mode mono, poly
40 00 04 1 00 - 1F Micro Tuning Equal - Indian
40 00 05 1 10 - 58 QED Pitch Bend Range Upper -48 - +24[semitones]
40 00 06 1 10 - 58 QED Pitch Bend Range Lower -48 - +24[semitones]
40 00 07 1 00 - 01 QED Portamento Mode fingered, fulltime
40 00 08 1 00 - 01 QED Portamento Switch off, on
40 00 09 1 00 - 7F QED Portamento Time 0 - 127
40 00 0A 1 00 - 01 Portamento Time Mode rate, time
40 00 0B 1 00 - 7F Reverb Send -∞dB…0dB
40 00 0C 1 00 - 7F Chorus Send -∞dB…0dB
40 00 0D 1 00 reserved
40 00 0E 1 7F reserved
40 00 40 1 00 - 02 Insertion Connect Type Para, S->L, L->S
40 00 41 1 7F reserved
40 00 42 1 7F reserved
40 00 43 1 00 reserved
40 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List
00 - 7F Reverb Type LSB
40 01 02 2 00 - 7F Reverb Parameter 1 MSB ˝
00 - 7F Reverb Parameter 1 LSB
40 01 04 2 00 - 7F Reverb Parameter 2 MSB ˝
00 - 7F Reverb Parameter 2 LSB
40 01 06 2 00 - 7F Reverb Parameter 3 MSB ˝
00 - 7F Reverb Parameter 3 LSB
40 01 08 2 00 - 7F Reverb Parameter 4 MSB ˝
00 - 7F Reverb Parameter 4 LSB
40 01 0A 2 00 - 7F Reverb Parameter 5 MSB ˝
00 - 7F Reverb Parameter 5 LSB
40 01 0C 2 00 - 7F Reverb Parameter 6 MSB ˝
00 - 7F Reverb Parameter 6 LSB
40 01 0E 2 00 - 7F Reverb Parameter 7 MSB ˝
00 - 7F Reverb Parameter 7 LSB
40 01 10 2 00 - 7F Reverb Parameter 8 MSB ˝
00 - 7F Reverb Parameter 8 LSB
40 01 12 2 00 - 7F Reverb Parameter 9 MSB ˝
00 - 7F Reverb Parameter 9 LSB
40 01 14 2 00 - 7F Reverb Parameter 10 MSB ˝
00 - 7F Reverb Parameter 10 LSB
40 01 16 1 00 - 7F Reverb Return -∞dB…0dB…+6dB(0…96…127)
40 01 17 1 01 - 7F Reverb Pan L63…C…R63
40 02 00 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List
00 - 7F Chorus Type LSB
40 02 02 2 00 - 7F Chorus Parameter 1 MSB ˝
00 - 7F Chorus Parameter 1 LSB
40 02 04 2 00 - 7F Chorus Parameter 2 MSB ˝
00 - 7F Chorus Parameter 2 LSB
40 02 06 2 00 - 7F Chorus Parameter 3 MSB ˝
00 - 7F Chorus Parameter 3 LSB
40 02 08 2 00 - 7F Chorus Parameter 4 MSB ˝
00 - 7F Chorus Parameter 4 LSB
40 02 0A 2 00 - 7F Chorus Parameter 5 MSB ˝
00 - 7F Chorus Parameter 5 LSB
40 02 0C 2 00 - 7F Chorus Parameter 6 MSB ˝
00 - 7F Chorus Parameter 6 LSB
40 02 0E 2 00 - 7F Chorus Parameter 7 MSB ˝
00 - 7F Chorus Parameter 7 LSB
40 02 10 2 00 - 7F Chorus Parameter 8 MSB ˝
00 - 7F Chorus Parameter 8 LSB
40 02 12 2 00 - 7F Chorus Parameter 9 MSB ˝
00 - 7F Chorus Parameter 9 LSB
40 02 14 2 00 - 7F Chorus Parameter 10 MSB ˝
00 - 7F Chorus Parameter 10 LSB
40 02 16 1 00 - 7F Chorus Return -∞dB…0dB…+6dB(0…96…127)
40 02 17 1 01 - 7F Chorus Pan L63…C…R63
40 02 18 1 00 - 7F Send Chorus To Reverb -∞dB…0dB(0…127)
Address Size Data
Range(H
EX)
Prameter Name Description Notes Address Size Data
Range
(HEX)
Prameter Name Description Notes
40 03 00 2 00 - 7F Insertion-1 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-1 Type LSB
40 03 02 2 00 - 7F Insertion-1 Parameter1 MSB ˝
00 - 7F Insertion-1 Parameter1 LSB
40 03 04 2 00 - 7F Insertion-1 Parameter2 MSB ˝
00 - 7F Insertion-1 Parameter2 LSB
40 03 06 2 00 - 7F Insertion-1 Parameter3 MSB ˝
00 - 7F Insertion-1 Parameter3 LSB
40 03 08 2 00 - 7F Insertion-1 Parameter4 MSB ˝
00 - 7F Insertion-1 Parameter4 LSB
40 03 0A 2 00 - 7F Insertion-1 Parameter5 MSB ˝
00 - 7F Insertion-1 Parameter5 LSB
40 03 0C 2 00 - 7F Insertion-1 Parameter6 MSB ˝
00 - 7F Insertion-1 Parameter6 LSB
40 03 0E 2 00 - 7F Insertion-1 Parameter7 MSB ˝
00 - 7F Insertion-1 Parameter7 LSB
40 03 10 2 00 - 7F Insertion-1 Parameter8 MSB ˝
00 - 7F Insertion-1 Parameter8 LSB
40 03 12 2 00 - 7F Insertion-1 Parameter9 MSB ˝
00 - 7F Insertion-1 Parameter9 LSB
40 03 14 2 00 - 7F Insertion-1 Parameter10 MSB ˝
00 - 7F Insertion-1 Parameter10 LSB
40 04 00 2 00 - 7F Insertion-2 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-2 Type LSB
40 04 02 2 00 - 7F Insertion-2 Parameter 1 MSB ˝
00 - 7F Insertion-2 Parameter 1 LSB
40 04 04 2 00 - 7F Insertion-2 Parameter 2 MSB ˝
00 - 7F Insertion-2 Parameter 2 LSB
40 04 06 2 00 - 7F Insertion-2 Parameter 3 MSB ˝
00 - 7F Insertion-2 Parameter 3 LSB
40 04 08 2 00 - 7F Insertion-2 Parameter 4 MSB ˝
00 - 7F Insertion-2 Parameter 4 LSB
40 04 0A 2 00 - 7F Insertion-2 Parameter 5 MSB ˝
00 - 7F Insertion-2 Parameter 5 LSB
40 04 0C 2 00 - 7F Insertion-2 Parameter 6 MSB ˝
00 - 7F Insertion-2 Parameter 6 LSB
40 04 0E 2 00 - 7F Insertion-2 Parameter 7 MSB ˝
00 - 7F Insertion-2 Parameter 7 LSB
40 04 10 2 00 - 7F Insertion-2 Parameter 8 MSB ˝
00 - 7F Insertion-2 Parameter 8 LSB
40 04 12 2 00 - 7F Insertion-2 Parameter 9 MSB ˝
00 - 7F Insertion-2 Parameter 9 LSB
40 04 14 2 00 - 7F Insertion-2 Parameter 10 MSB ˝
00 - 7F Insertion-2 Parameter 10 LSB
40 04 16 2 00 - 7F Insertion-2 Parameter 11 MSB ˝
00 - 7F Insertion-2 Parameter 11 LSB
40 04 18 2 00 - 7F Insertion-2 Parameter 12 MSB ˝
00 - 7F Insertion-2 Parameter 12 LSB
40 04 1A 2 00 - 7F Insertion-2 Parameter 13 MSB ˝
00 - 7F Insertion-2 Parameter 13 LSB
40 04 1C 2 00 - 7F Insertion-2 Parameter 14 MSB ˝
00 - 7F Insertion-2 Parameter 14 LSB
40 04 1E 2 00 - 7F Insertion-2 Parameter 15 MSB ˝
00 - 7F Insertion-2 Parameter 15 LSB
40 04 20 2 00 - 7F Insertion-2 Parameter 16 MSB ˝
00 - 7F Insertion-2 Parameter 16 LSB
40 05 00 1 00 - 09 Controller Set1 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
40 05 01 2 00 Controller Set1 Destination MSB 0 - 62
00 - 3E Controller Set1 Destination LSB
40 05 03 1 00 - 7F Controller Set1 Depth -64 - +63
40 05 04 1 reserved
40 05 05 1 00 - 09 Controller Set2 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
40 05 06 2 00 Controller Set2 Destination MSB 0 - 62
00 - 3E Controller Set2 Destination LSB
40 05 08 1 00 - 7F Controller Set2 Depth -64 - +63
40 05 09 1 reserved
40 05 0A 1 00 - 09 Controller Set3 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
40 05 0B 2 00 Controller Set3 Destination MSB 0 - 62
00 - 3E Controller Set3 Destination LSB
40 05 0D 1 00 - 7F Controller Set3 Depth -64 - +63
40 05 0E 1 reserved
40 05 0F 1 00 - 09 Controller Set4 Source PB, MW, ---, AT,FC2, FS,FC1, BC,
KN1, KN2
40 05 10 2 00 Controller Set4 Destination MSB 0 - 62
00 - 3E Controller Set4 Destination LSB
40 05 12 1 00 - 7F Controller Set4 Depth -64 - +63
40 05 13 1 reserved
40 05 14 1 00 - 09 Controller Set5 Source PB, MW, ---, AT,FC2, FS,FC1, BC,
KN1, KN2
40 05 15 2 00 Controller Set5 Destination MSB 0 - 62
00 - 3E Controller Set5 Destination LSB
40 05 17 1 00 - 7F Controller Set5 Depth -64 - +63
40 05 18 1 reserved
40 05 19 1 00 - 09 Controller Set6 Source PB, MW, ---, AT,FC2, FS,FC1, BC,
KN1, KN2
53
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 37 25 (HEX)
MIDI PARAMETER CHANGE TABLE (NORMAL
VOICE ELEMENT)
TOTAL SIZE = 28 1C (HEX)
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 29 1D (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
40 05 1A 2 00 Controller Set6 Destination MSB 0 - 62
00 - 3E Controller Set6 Destination LSB
40 05 1C 1 00 - 7F Controller Set6 Depth -64 - +63
40 05 1D 1 00 - 0F reserved
40 06 00 1 00 - 05 LFO Phase 0, 90,120,180, 240, 270
40 06 01 1 00 - 0C LFO Wave tri, tri+, sawup, sawdwn, squ1/4,
squ1/3, squ, squ2/3, squ3/4, trpzd,
S/H1, S/H2, user
40 06 02 1 00 - 3F LFO Speed 0 - 63 (available only when the
Tempo Sync is set to off)
40 06 03 1 05 - 15 LFO TEMPO SPEED 5 - 21 (available only when the
Tempo Sync is set to off)
1
6th,8th/3, 16th., 8th,
4th/3, 8th., 4th, 2th/3,
4th., 2nd, Whole/3,
2nd., 4thX4, 4thX6,
4thX6, 4thX7, 4thX8
40 06 04 1 00 - 01 LFO TEMPO SYNC OFF, ON
40 06 05 1 00 - 7F LFO Delay Time 0 - 127
40 06 06 1 00 - 7F LFO Fade In Time 0 - 127
40 06 07 1 00 - 7F LFO Hold Time 0 - 127
40 06 08 1 00 - 7F LFO Fade Out Time 0 - 127
40 06 09 1 00 - 02 LFO Key On Reset off, each-on, 1st-on
40 06 0A 1 00 - 05 LFO Box1 Destination AMD, PMD, FMD, RESO, PAN,
ELEMENT LFO SPEED
40 06 0B 1 00 - 7F LFO Box1 Depth 0 - 127
40 06 0C 1 reserved
40 06 0D 1 00 - 05 LFO Box2 Destination AMD, PMD, FMD, RESO, PAN,
ELEMENT LFO SPEED
40 06 0E 1 00 - 7F LFO Box2 Depth 0 - 127
40 06 0F 1 reserved
40 06 10 1 00 - 05 LFO Box3 Destination AMD, PMD, FMD, RESO, PAN,
ELEMENT LFO SPEED
40 06 11 1 00 - 7F LFO Box3 Depth 0 - 127
40 06 12 1 reserved
40 06 13 1 00 - 06 USER WAVE TOTAL STEP 2, 3, 4, 6, 8, 12, 16
40 06 14 1 00 - 03 USER WAVE SLOPE OFF, UP, DOWN, UP&DOWN
40 06 15 1 00 - 7F USER WAVE STEP VALUE1 0 - 127
40 06 16 1 00 - 7F USER WAVE STEP VALUE2 0 - 127
40 06 17 1 00 - 7F USER WAVE STEP VALUE3 0 - 127
40 06 18 1 00 - 7F USER WAVE STEP VALUE4 0 - 127
40 06 19 1 00 - 7F USER WAVE STEP VALUE5 0 - 127
40 06 1A 1 00 - 7F USER WAVE STEP VALUE6 0 - 127
40 06 1B 1 00 - 7F USER WAVE STEP VALUE7 0 - 127
40 06 1C 1 00 - 7F USER WAVE STEP VALUE8 0 - 127
40 06 1D 1 00 - 7F USER WAVE STEP VALUE9 0 - 127
40 06 1E 1 00 - 7F USER WAVE STEP VALUE10 0 - 127
40 06 1F 1 00 - 7F USER WAVE STEP VALUE11 0 - 127
40 06 20 1 00 - 7F USER WAVE STEP VALUE12 0 - 127
40 06 21 1 00 - 7F USER WAVE STEP VALUE13 0 - 127
40 06 22 1 00 - 7F USER WAVE STEP VALUE14 0 - 127
40 06 23 1 00 - 7F USER WAVE STEP VALUE15 0 - 127
40 06 24 1 00 - 7F USER WAVE STEP VALUE16 0 - 127
Address Size Data
Range
(HEX)
Prameter Name Description Notes
41 ee 00 1 00 - 01 ELEMENT ASSIGN 0:OFF, 1:ON
41 ee 01 1 00 - 01 WAVE SELECT 0:PRESET, 1:USER WAVE
41 ee 02 1 00 reserved
41 ee 03 2 00 - 7F Wave Number MSB 0 - 16383 (User: 0-256)
00 - 7F Wave Number LSB 1st bit 6-0 → bit 13-7
41 ee 05 1 01 reserved
41 ee 06 1 01 reserved
41 ee 07 1 00 reserved
41 ee 08 1 01 - 7F Pan L63 - C - R63
41 ee 09 1 00 - 7F Random Pan Depth 0 - 127
41 ee 0A 1 00 - 7F Alternate Pan Depth L64 - 0 - R63
41 ee 0B 1 00 - 7F Scaling Pan Depth -64 - +63
41 ee 0C 1 00 - 7F Note Limit Low 0 - 127
41 ee 0D 1 00 - 7F Note Limit High 0 - 127
41 ee 0E 1 01 - 7F Velocity Limit Low 1 - 127
41 ee 0F 1 01 - 7F Velocity Limit High 1 - 127
41 ee 10 1 00 - 7F VELOCITY CROSS FADE 0 - 127
41 ee 11 1 00 - 7F Key On Delay 0 - 127
41 ee 12 1 00 reserved
41 ee 13 1 7F reserved
41 ee 14 1 7F reserved
41 ee 15 1 00 RESERVE RESERVE for ELEMENT VAR
SEND
41 ee 16 1 00 - 02 Insertion Effect Switch thru, ins1, ins2
41 ee 17 1 00 reserved
41 ee 18 2 00 - 00 CONTROL BOX SW BIT0~6:RESERVE
00 - 3F BIT0~5:BOX1~BOX6,
BIT6:RESERVE
41 ee 1A 2 00 - 00 LFO BOX SW BIT0~6:RESERVE
00 - 07 BIT0~2:BOX1~BOX3,
BIT3~6:RESERVE
Address Size Data
Range
(HEX)
Prameter Name Description Notes
41 ee 20 1 00 - 7F Element Level 0 - 127
41 ee 21 1 00 - 7F Level Velocity Snesitivity -64 - +63
41 ee 22 1 00 - 04 LEVEL SENS VELOCITY CURVE 00 - 04
41 ee 23 1 00 reserved
41 ee 24 1 00 - 7F AEG Attack Time 0 - 127
41 ee 25 1 00 - 7F AEG Decay1 Time 0 - 127
41 ee 26 1 00 - 7F AEG Decay2 Time 0 - 127
41 ee 27 1 00 - 7F AEG Release Time 0 - 127
41 ee 28 1 00 - 7F AEG Init Level 0 - 127
41 ee 29 1 00 reserved
41 ee 2A 1 00 - 7F AEG Decay1 Level 0 - 127
41 ee 2B 1 00 - 7F AEG Sustain Level 0 - 127
41 ee 2C 1 00 reserved
41 ee 2D 1 00 - 04 AEG Time Velocity Segment ATK, ATK+DCY, DCY, ATK+RLS,
ALL
41 ee 2E 1 00 - 7F AEG Time Velocity Sensitivity -64 - +63
41 ee 2F 1 00 - 7F Level Key Follow Sensitivity -200% - +200%
41 ee 30 1 00 - 7C Level Scaling Break Point 1 C -2 - E8
BP1<BP2<BP3<BP4
41 ee 31 1 01 - 7D Level Scaling Break Point 2 C#-2 - F8
BP1<BP2<BP3<BP4
41 ee 32 1 02 - 7E Level Scaling Break Point 3 D -2 - F#8
BP1<BP2<BP3<BP4
41 ee 33 1 03 - 7F Level Scaling Break Point 4 D#-2 - G8
BP1<BP2<BP3<BP4
41 ee 34 2 00 - 01 Level Scaling Offset 1 -128 - +127
00 - 7F
41 ee 36 2 00 - 01 Level Scaling Offset 2 -128 - +127
00 - 7F
41 ee 38 2 00 - 01 Level Scaling Offset 3 -128 - +127
00 - 7F
41 ee 3A 2 00 - 01 Level Scaling Offset 4 -128 - +127
00 - 7F
41 ee 3C 1 00 - 7F AEG Time Key Follow Sensitivity -64 - +63
41 ee 3D 1 00 - 7F AEG Time Key Follow Center Note C-2 - G8
42 ee 00 1 10 - 70 Coarse Tune -48 - +48
42 ee 01 1 00 - 7F Fine Tune -64 - +63
42 ee 02 1 00 - 7F VELOCITY->PITCH SENSITIVITY -64 - +63
42 ee 03 1 00 reserved
42 ee 04 1 00 - 7F Random Pitch Depth 0 - 127
42 ee 05 1 00 - 7F PEG Hold Time 0 - 127
42 ee 06 1 00 - 7F PEG Attack Time 0 - 127
42 ee 07 1 00 - 7F PEG Decay1 Time 0 - 127
42 ee 08 1 00 - 7F PEG Decay2 Time 0 - 127
42 ee 09 1 00 - 7F PEG Release Time 0 - 127
42 ee 0A 2 00 - 01 PEG Hold Level -128 - +127 (-4800 - +4800[cent])
00 - 7F
42 ee 0C 2 00 - 01 PEG Attack Level -128 - +127 (-4800 - +4800[cent])
00 - 7F
42 ee 0E 2 00 - 01 PEG Decay1 Level -128 - +127 (-4800 - +4800[cent])
00 - 7F
42 ee 10 2 00 - 01 PEG Sustain Level -128 - +127 (-4800 - +4800[cent])
00 - 7F
42 ee 12 2 00 - 01 PEG Release Level -128 - +127 (-4800 - +4800[cent])
00 - 7F
42 ee 14 1 00 - 7F PEG Depth -64 - +63
42 ee 15 1 00 - 04 PEG Time Velocity Segment ATK, ATK+DCY, DCY, ATK+RLS,
ALL
42 ee 16 1 00 - 7F PEG Time Velocity Sensitivity -64 - +63
42 ee 17 1 00 - 7F PEG Level Velocity Sensitivity -64 - +63
42 ee 18 1 00 - 04 PEG LEVEL SENS VELOCITY
CURVE
00 - 04
42 ee 19 1 00 - 7F Pitch Key Follow Sensitivity -200% - +200%
42 ee 1A 1 00 - 7F Pitch Key Follow Center Note C-2 - G8
42 ee 1B 1 00 - 7F PEG Time Key Follow Sensitivity -64 - +63
42 ee 1C 1 00 - 7F PEG Time Key Follow Center Note C-2 - G8
54
TOTAL SIZE = 50 32 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 7 07 (HEX)
ee = Element Number (00..03: Element1..4)
MIDI PARAMETER CHANGE TABLE (DRUM VOICE
COMMON)
TOTAL SIZE = 66 42 (HEX)
TOTAL SIZE = 8 08 (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
43 ee 00 1 00 - 15 Filter Type
LPF24D, LPF24A, LPF18, LPF18s,
LPF12, LPF6, HPF24D, HPF12,
BPF12D, BPF12s, BPF6, BPFw,
BEF12, BEF6, DualLPF, DualHPF,
DualBPF, DualBEF, LPF12+HPF12,
LPF12+BPF6, HPF12+BPF6, THRU
43 ee 01 2 00 - 01 Filter Cutoff Frequency 0 - 255
00 - 7F
43 ee 03 1 00 - 7F Filter Cutoff Velocity Sensitivity -64 - +63
43 ee 04 1 02 reserved
43 ee 05 1 00 - 1F Filter Resonance/Width/Band 0 - 31
43 ee 06 1 00 - 7F Filter Resonance Velocity
Sensitivity
-64 - +63
43 ee 07 2 00 - 01 HPF Cutoff Frequency 0 - 255
00 - 7F
43 ee 09 1 40 reserved
43 ee 0A 2 00 - 01 DISTANCE 0 - 255
00 - 7F
43 ee 0C 2 00 - 01 Filter Gain 0 - 255
00 - 7F
43 ee 0E 1 00 - 7F FEG Hold Time 0 - 127
43 ee 0F 1 00 - 7F FEG Attack Time 0 - 127
43 ee 10 1 00 - 7F FEG Decay1 Time 0 - 127
43 ee 11 1 00 - 7F FEG Decay2 Time 0 - 127
43 ee 12 1 00 - 7F FEG Release Time 0 - 127
43 ee 13 2 00 - 01 FEG Hold Level -128 - +127 (-9600 - +9600[cent])
00 - 7F
43 ee 15 2 00 - 01 FEG Attack Level -128 - +127 (-9600 - +9600[cent])
00 - 7F
43 ee 17 2 00 - 01 FEG Decay1 Level -128 - +127 (-9600 - +9600[cent])
00 - 7F
43 ee 19 2 00 - 01 FEG Sustain Level -128 - +127 (-9600 - +9600[cent])
00 - 7F
43 ee 1B 2 00 - 01 FEG Release Level -128 - +127 (-9600 - +9600[cent])
00 - 7F
43 ee 1D 1 00 - 7F FEG Depth -64 - +63
43 ee 1E 1 00 - 04 FEG Time Velocity Segment ATK, ATK+DCY, DCY, ATK+RLS,
ALL
43 ee 1F 1 00 - 7F FEG Time Velocity Sensitivity -64 - +63
43 ee 20 1 00 - 7F FEG Level Velocity Sensitivity -64 - +63
43 ee 21 1 00 - 04 FEG LEVEL VELOCITY CURVE 00 - 04
43 ee 22 1 00 - 7F Filter Cutoff Key Follow Sensitivity -200% - +200%
43 ee 23 1 00 - 7C Filter Cutoff Scaling Break Point 1 C -2 - E8
BP1<BP2<BP3<BP4
43 ee 24 1 01 - 7D Filter Cutoff Scaling Break Point 2 C#-2 - F8
BP1<BP2<BP3<BP4
43 ee 25 1 02 - 7E Filter Cutoff Scaling Break Point 3 D -2 - F#8
BP1<BP2<BP3<BP4
43 ee 26 1 03 - 7F Filter Cutoff Scaling Break Point 4 D#-2 - G8
BP1<BP2<BP3<BP4
43 ee 27 2 00 - 01 Filter Cutoff Scaling Offset 1 -128 - +127
00 - 7F
43 ee 29 2 00 - 01 Filter Cutoff Scaling Offset 2 -128 - +127
00 - 7F
43 ee 2B 2 00 - 01 Filter Cutoff Scaling Offset 3 -128 - +127
00 - 7F
43 ee 2D 2 00 - 01 Filter Cutoff Scaling Offset 4 -128 - +127
00 - 7F
43 ee 2F 1 00 - 7F HPF Cutoff Key Follow Sensitivity -200% - +200%
43 ee 30 1 00 - 7F FEG Time Key Follow Sensitivity -64 - +63
43 ee 31 1 00 - 7F FEG Time Key Follow Center Note C-2 - G8
44 ee 00 1 00 - 05 EQ Type EQ L/H, P.EQ, Boost6, Boost12,
Boost18, thru
44 ee 01 1 00 - 1F EQ Resonance 0 - 31
44 ee 02 2 00 - 01 EQ 1 Frequency EQ L/H: 46-182, P.EQ: 83-251
00 - 7F
44 ee 04 1 20 - 60 EQ 1 Gain -32 - +32
44 ee 05 2 00 - 01 EQ 2 Frequency EQ L/H:131-241
00 - 7F
44 ee 07 1 20 - 60 EQ 2 Gain -32 - +32
44 ee 40 1 00 - 02 LFO Wave saw,tri,squ
44 ee 41 1 00 - 01 LFO Key On Sync off,on
44 ee 42 1 00 - 7F LFO KEY ON DELAY TIME 0 - 127
44 ee 43 1 00 - 3F LFO Speed 0 - 63
44 ee 44 1 00 - 7F LFO AMod Depth 0 - 127
44 ee 45 1 00 - 7F LFO PMod Depth 0 - 127
44 ee 46 1 00 - 7F LFO FMod Depth 0 - 127
Address Size Data
Range
(HEX)
Prameter Name Description Notes
46 70 00 1 20 - 7E Voice Name1 32..126(ASCII)
46 70 01 1 20 - 7E Voice Name2 32..126(ASCII)
46 70 02 1 20 - 7E Voice Name3 32..126(ASCII)
46 70 03 1 20 - 7E Voice Name4 32..126(ASCII)
46 70 04 1 20 - 7E Voice Name5 32..126(ASCII)
46 70 05 1 20 - 7E Voice Name6 32..126(ASCII)
46 70 06 1 20 - 7E Voice Name7 32..126(ASCII)
46 70 07 1 20 - 7E Voice Name8 32..126(ASCII)
46 70 08 1 20 - 7E Voice Name9 32..126(ASCII)
46 70 09 1 20 - 7E Voice Name10 32..126(ASCII)
46 70 0A 1 reserved
46 70 0B 1 reserved
46 70 0C 1 00 - 10 Voice Category(Main) 0..16(--..Co)
Ap, Kb, Or, Gt, Ba,St,
Br, Rp, Ld, Pd, Sc,
Cp, Dr, Se, Me, Co
46 70 0D 1 00 - 03 Voice Category(Sub) 0..3(--.Sub1..Sub3)
depens on Main
Category
46 70 0E 1 reserved
46 70 0F 1 reserved
46 70 10 1 reserved
46 70 11 1 reserved
46 70 12 1 reserved
46 70 13 1 00 - 02 QED ARP Type Bank pre1, pre2, user
46 70 14 1 00 - 7F QED ARP Type BigBeat1 - Drm&Bs2 + α
46 70 15 1 00 - 01 ARP Switch off, on
46 70 16 1 00 - 02 ARP Hold sync-off, off, on
46 70 17 1 00 - 06 ARP Unit Multiply 50%, 66%, 75%, 100%, 133%,
150%, 200%
46 70 18 1 00 - 7F ARP Note Limit Low C-2..G8
46 70 19 1 00 - 7F ARP Note Limit High C-2..G8
46 70 1A 1 01 - 7F ARP Velocity Limit Low 1 - 127
46 70 1B 1 01 - 7F ARP Velocity Limit High 1 - 127
46 70 1C 1 00 - 02 ARP Key Mode sort, thru, direct
46 70 1D 1 00 - 01 ARP Vel Mode original, thru
46 70 1E 2 0000 -
00C8
ARP Velocity Rate MSB 0...200%
ARP Velocity Rate LSB
46 70 20 2 0000 -
00C8
ARP Gate Time Rate MSB 0...200%
ARP Gate TIme Rate LSB
46 70 22 2 0001 -
012C
QED ARP Tempo MSB 1..300
QED ARP Tempo LSB
46 70 24 1 00 - 03 Knob Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset
46 70 25 1 01 - 7F Pan L63..C..R63
46 70 26 1 00 - 7F Chorus Control -64..+63
46 70 27 1 00 - 7F QED Decay Time -64..+63
46 70 28 1 40 reserved
46 70 29 1 40 reserved
46 70 2A 1 40 reserved
46 70 2B 1 40 reserved
46 70 2C 1 40 reserved
46 70 2D 1 40 reserved
46 70 2E 1 00 - 7F KnobA -64..+63
46 70 2F 1 00 - 7F KnobB -64..+63
46 70 30 1 40 reserved
46 70 31 1 00 - 7F EQ Low Gain -64..+63
46 70 32 1 00 - 7F EQ Low Mid Gain -64..+63
46 70 33 1 00 - 7F EQ High Mid Gain -64..+63
46 70 34 1 00 - 7F EQ High Gain -64..+63
46 70 35 1 00 - 7F Scene 1 Assign1 -64..+63
46 70 36 1 00 - 7F Scene 1 Assign2 -64..+63
46 70 37 1 00 - 7F Scene 1 Cutoff Frequency -64..+63
46 70 38 1 00 - 7F Scene 1 Resonance -64..+63
46 70 39 1 00 - 7F Scene 1 Attack Time -64..+63
46 70 3A 1 40 reserved
46 70 3B 1 40 reserved
46 70 3C 1 40 reserved
46 70 3D 1 40 reserved
46 70 3E 1 40 reserved
46 70 3F 1 40 reserved
46 70 40 1 40 reserved
46 70 41 1 00 reserved
46 00 00 1 00 - 7F Volume 0 - 127
46 00 01 1 00 reserved
46 00 02 1 10 - 58 QED Pitch Bend Range Upper -48 - +24[semitones]
46 00 03 1 10 - 58 QED Pitch Bend Range Lower -48 - +24[semitones]
46 00 04 1 00 - 7F Reverb Send -∞dB…0dB
46 00 05 1 00 - 7F Chorus Send -∞dB…0dB
46 00 06 1 00 reserved
46 00 07 1 7F reserved
55
TOTAL SIZE = 4 04 (HEX)
TOTAL SIZE = 24 18 (HEX)
TOTAL SIZE = 25 19 (HEX)
TOTAL SIZE = 22 16 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 30 1E (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
46 00 40 1 00 - 02 Insertion Connect Type Para, S->L, L->S
46 00 41 1 00 - 7F Ins-EF Reverb Send Level 0 - 127
46 00 42 1 00 - 7F Ins-EF Chorus Send Level 0 - 127
46 00 43 1 00 reserved
46 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List
00 - 7F Reverb Type LSB
46 01 02 2 00 - 7F Reverb Parameter 1 MSB ˝
00 - 7F Reverb Parameter 1 LSB
46 01 04 2 00 - 7F Reverb Parameter 2 MSB ˝
00 - 7F Reverb Parameter 2 LSB
46 01 06 2 00 - 7F Reverb Parameter 3 MSB ˝
00 - 7F Reverb Parameter 3 LSB
46 01 08 2 00 - 7F Reverb Parameter 4 MSB ˝
00 - 7F Reverb Parameter 4 LSB
46 01 0A 2 00 - 7F Reverb Parameter 5 MSB ˝
00 - 7F Reverb Parameter 5 LSB
46 01 0C 2 00 - 7F Reverb Parameter 6 MSB ˝
00 - 7F Reverb Parameter 6 LSB
46 01 0E 2 00 - 7F Reverb Parameter 7 MSB ˝
00 - 7F Reverb Parameter 7 LSB
46 01 10 2 00 - 7F Reverb Parameter 8 MSB ˝
00 - 7F Reverb Parameter 8 LSB
46 01 12 2 00 - 7F Reverb Parameter 9 MSB ˝
00 - 7F Reverb Parameter 9 LSB
46 01 14 2 00 - 7F Reverb Parameter 10 MSB ˝
00 - 7F Reverb Parameter 10 LSB
46 01 16 1 00 - 7F Reverb Return -∞dB…0dB…+6dB(0…96…127)
46 01 17 1 01 - 7F Reverb Pan L63…C…R63
46 02 00 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List
00 - 7F Chorus Type LSB
46 02 02 2 00 - 7F Chorus Parameter 1 MSB ˝
00 - 7F Chorus Parameter 1 LSB
46 02 04 2 00 - 7F Chorus Parameter 2 MSB ˝
00 - 7F Chorus Parameter 2 LSB
46 02 06 2 00 - 7F Chorus Parameter 3 MSB ˝
00 - 7F Chorus Parameter 3 LSB
46 02 08 2 00 - 7F Chorus Parameter 4 MSB ˝
00 - 7F Chorus Parameter 4 LSB
46 02 0A 2 00 - 7F Chorus Parameter 5 MSB ˝
00 - 7F Chorus Parameter 5 LSB
46 02 0C 2 00 - 7F Chorus Parameter 6 MSB ˝
00 - 7F Chorus Parameter 6 LSB
46 02 0E 2 00 - 7F Chorus Parameter 7 MSB ˝
00 - 7F Chorus Parameter 7 LSB
46 02 10 2 00 - 7F Chorus Parameter 8 MSB ˝
00 - 7F Chorus Parameter 8 LSB
46 02 12 2 00 - 7F Chorus Parameter 9 MSB ˝
00 - 7F Chorus Parameter 9 LSB
46 02 14 2 00 - 7F Chorus Parameter 10 MSB ˝
00 - 7F Chorus Parameter 10 LSB
46 02 16 1 00 - 7F Chorus Return -∞dB…0dB…+6dB(0…96…127)
46 02 17 1 01 - 7F Chorus Pan L63…C…R63
46 02 18 1 00 - 7F Send Chorus To Reverb -∞dB…0dB(0…127)
46 03 00 2 00 - 7F Insertion-1 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-1 Type LSB
46 03 02 2 00 - 7F Insertion-1 Parameter1 MSB ˝
00 - 7F Insertion-1 Parameter1 LSB
46 03 04 2 00 - 7F Insertion-1 Parameter2 MSB ˝
00 - 7F Insertion-1 Parameter2 LSB
46 03 06 2 00 - 7F Insertion-1 Parameter3 MSB ˝
00 - 7F Insertion-1 Parameter3 LSB
46 03 08 2 00 - 7F Insertion-1 Parameter4 MSB ˝
00 - 7F Insertion-1 Parameter4 LSB
46 03 0A 2 00 - 7F Insertion-1 Parameter5 MSB ˝
00 - 7F Insertion-1 Parameter5 LSB
46 03 0C 2 00 - 7F Insertion-1 Parameter6 MSB ˝
00 - 7F Insertion-1 Parameter6 LSB
46 03 0E 2 00 - 7F Insertion-1 Parameter7 MSB ˝
00 - 7F Insertion-1 Parameter7 LSB
46 03 10 2 00 - 7F Insertion-1 Parameter8 MSB ˝
00 - 7F Insertion-1 Parameter8 LSB
46 03 12 2 00 - 7F Insertion-1 Parameter9 MSB ˝
00 - 7F Insertion-1 Parameter9 LSB
46 03 14 2 00 - 7F Insertion-1 Parameter10 MSB ˝
00 - 7F Insertion-1 Parameter10 LSB
Address Size Data
Range
(HEX)
Prameter Name Description Notes
46 04 00 2 00 - 7F Insertion-2 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-2 Type LSB
46 04 02 2 00 - 7F Insertion-2 Parameter 1 MSB ˝
00 - 7F Insertion-2 Parameter 1 LSB
46 04 04 2 00 - 7F Insertion-2 Parameter 2 MSB ˝
00 - 7F Insertion-2 Parameter 2 LSB
46 04 06 2 00 - 7F Insertion-2 Parameter 3 MSB ˝
00 - 7F Insertion-2 Parameter 3 LSB
46 04 08 2 00 - 7F Insertion-2 Parameter 4 MSB ˝
00 - 7F Insertion-2 Parameter 4 LSB
46 04 0A 2 00 - 7F Insertion-2 Parameter 5 MSB ˝
00 - 7F Insertion-2 Parameter 5 LSB
46 04 0C 2 00 - 7F Insertion-2 Parameter 6 MSB ˝
00 - 7F Insertion-2 Parameter 6 LSB
46 04 0E 2 00 - 7F Insertion-2 Parameter 7 MSB ˝
00 - 7F Insertion-2 Parameter 7 LSB
46 04 10 2 00 - 7F Insertion-2 Parameter 8 MSB ˝
00 - 7F Insertion-2 Parameter 8 LSB
46 04 12 2 00 - 7F Insertion-2 Parameter 9 MSB ˝
00 - 7F Insertion-2 Parameter 9 LSB
46 04 14 2 00 - 7F Insertion-2 Parameter 10 MSB ˝
00 - 7F Insertion-2 Parameter 10 LSB
46 04 16 2 00 - 7F Insertion-2 Parameter 11 MSB ˝
00 - 7F Insertion-2 Parameter 11 LSB
46 04 18 2 00 - 7F Insertion-2 Parameter 12 MSB ˝
00 - 7F Insertion-2 Parameter 12 LSB
46 04 1A 2 00 - 7F Insertion-2 Parameter 13 MSB ˝
00 - 7F Insertion-2 Parameter 13 LSB
46 04 1C 2 00 - 7F Insertion-2 Parameter 14 MSB ˝
00 - 7F Insertion-2 Parameter 14 LSB
46 04 1E 2 00 - 7F Insertion-2 Parameter 15 MSB ˝
00 - 7F Insertion-2 Parameter 15 LSB
46 04 20 2 00 - 7F Insertion-2 Parameter 16 MSB ˝
00 - 7F Insertion-2 Parameter 16 LSB
46 05 00 1 00 - 09 Controller Set1 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
46 05 01 2 00 Controller Set1 Destination MSB 0 - 29
00 - 1D Controller Set1 Destination LSB
46 05 03 1 00 - 7F Controller Set1 Depth -64 - +63
46 05 04 1 reserved
46 05 05 1 00 - 09 Controller Set2 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
46 05 06 2 00 Controller Set2 Destination MSB 0 - 29
00 - 1D Controller Set2 Destination LSB
46 05 08 1 00 - 7F Controller Set2 Depth -64 - +63
46 05 09 1 reserved
46 05 0A 1 00 - 09 Controller Set3 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
46 05 0B 2 00 Controller Set3 Destination MSB 0 - 29
00 - 1D Controller Set3 Destination LSB
46 05 0D 1 00 - 7F Controller Set3 Depth -64 - +63
46 05 0E 1 reserved
46 05 0F 1 00 - 09 Controller Set4 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
46 05 10 2 00 Controller Set4 Destination MSB 0 - 29
00 - 1D Controller Set4 Destination LSB
46 05 12 1 00 - 7F Controller Set4 Depth -64 - +63
46 05 13 1 reserved
46 05 14 1 00 - 09 Controller Set5 Source PB, MW, ---, AT,FC2, FS,FC1, BC,
KN1, KN2
46 05 15 2 00 Controller Set5 Destination MSB 0 - 29
00 - 1D Controller Set5 Destination LSB
46 05 17 1 00 - 7F Controller Set5 Depth -64 - +63
46 05 18 1 reserved
46 05 19 1 00 - 09 Controller Set6 Source PB, MW, ---, AT,FC2, FS,FC1, BC,
KN1, KN2
46 05 1A 2 00 Controller Set6 Destination MSB 0 - 29
00 - 1D Controller Set6 Destination LSB
46 05 1C 1 00 - 7F Controller Set6 Depth -64 - +63
46 05 1D 1 reserved
56
MIDI PARAMETER CHANGE TABLE (DRUM VOICE
KEY)
TOTAL SIZE = 19 13 (HEX)
TOTAL SIZE = 12 0C (HEX)
TOTAL SIZE = 3 03 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 8 08 (HEX)
ee = Element Number (00..48: C0 - C6)
*1 When the Wave/Voice type is set to "voice", only these parameters are available.
MIDI PARAMETER CHANGE TABLE (PLUG-IN VOICE)
TOTAL SIZE = 66 42 (HEX)
TOTAL SIZE = 13 0D (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
47 ee 00 1 00 - 01 Element Assign off, on
47 ee 01 1 00 - 02 Wave Type 0:PresetWave 1:Voice 2:UserWave
47 ee 02 1 00 reserved
47 ee 03 1 00 - 01 Receive Note Off off, on
47 ee 04 1 00 - 01 Assign Mode single, multi
*1
47 ee 05 1 00 - 7F Alternate Group 0:off, 1 - 127
47 ee 06 2 00 - 7F Wave Number MSB 1st bit6-0 → bit13-7 (User: 0-256)
00 - 7F Wave Number LSB 2nd bit6-0 → bit6-0
47 ee 08 3 00 - 7F Voice Bank Number MSB 0 - 127
*1
00 - 7F Voice Bank Number LSB 0 - 127
*1
00 - 7F Voice Number 0 - 127
*1
47 ee 0B 1 01 - 7F Pan L63 - C - R63
*1
47 ee 0C 1 00 - 7F Random Pan Depth 0 - 127
47 ee 0D 1 00 - 7F Alternate Pan Depth L64 - 0 - R63
47 ee 0E 1 00 - 7F Reverb Send Level 0 - 127
*1
47 ee 0F 1 00 - 7F Chorus Send Level 0 - 127
*1
47 ee 10 1 reserved
47 ee 11 1 00 - 02 Insertion Effect Switch thru, ins1, ins2
*1
47 ee 12 1 00 - 47 Output Select 0: L&R
*1
8: asnL&R, 9: asn1&2, 10: asn3&4,
11: asn5&6
64 - 71: asnL, asnR - asn5, asn6
47 ee 20 1 00 - 7F Element Level 0 - 127
*1
47 ee 21 1 00 - 7F Level Velocity Sensitivity -64 - +63
47 ee 22 1 00 reserved
47 ee 23 1 00 - 7F AEG Attack Time 0 - 127
47 ee 24 1 00 - 7F AEG Decay1 Time 0 - 127
47 ee 25 1 00 - 7F AEG Decay2 Time 0 - 126,hold
47 ee 26 1 00 reserved
47 ee 27 1 00 reserved
47 ee 28 1 00 reserved
47 ee 29 1 00 - 7F AEG Decay1 Level 0 - 127
47 ee 2A 1 00 reserved
47 ee 2B 1 00 reserved
48 ee 00 1 10 - 70 Coarse Tune -48 - +48
*1
48 ee 01 1 00 - 7F Fine Tune -64 - +63
*1
48 ee 02 1 00 - 7F Pitch Velocity Sensitivity -64 - +63
49 ee 00 1 00 reserved
49 ee 01 2 00 - 01 LPF Cutoff Frequency MSB 0 - 255
00 - 7F LPF Cutoff Frequency LSB
49 ee 03 1 00 - 7F LPF Cutoff Velocity Sensitivity -64 - +63
49 ee 04 1 00 - 1F LPF Resonance 0 - 31
49 ee 05 1 40 reserved
49 ee 06 2 00 - 01 HPF Cutoff Frequency MSB 0 - 255
00 - 7F HPF Cutoff Frequency LSB
4A ee 00 1 00 - 05 EQ Type EQ L/H, P.EQ, Boost6, Boost12,
Boost18, thru
4A ee 01 1 00 - 1F EQ Resonance 0 - 31
4A ee 02 2 00 - 01 EQ 1 Frequency MSB EQ L/H: 46-182, P.EQ: 83-251
00 - 7F EQ 1 Frequency LSB
4A ee 04 1 20 - 60 EQ 1 GAIN -32 - +32
4A ee 05 2 00 - 01 EQ 2 Frequency MSB EQ L/H:131-241
00 - 7F EQ 2 Frequency LSB
4A ee 07 1 20 - 60 EQ 2 GAIN -32 - +32
Address Size Data
Range
(HEX)
Prameter Name Description Notes
4C 70 00 1 20 - 7E Voice Name1 32..126(ASCII)
4C 70 01 1 20 - 7E Voice Name2 32..126(ASCII)
4C 70 02 1 20 - 7E Voice Name3 32..126(ASCII)
4C 70 03 1 20 - 7E Voice Name4 32..126(ASCII)
4C 70 04 1 20 - 7E Voice Name5 32..126(ASCII)
4C 70 05 1 20 - 7E Voice Name6 32..126(ASCII)
4C 70 06 1 20 - 7E Voice Name7 32..126(ASCII)
4C 70 07 1 20 - 7E Voice Name8 32..126(ASCII)
4C 70 08 1 20 - 7E Voice Name9 32..126(ASCII)
4C 70 09 1 20 - 7E Voice Name10 32..126(ASCII)
4C 70 0A 1 reserved
4C 70 0B 1 reserved
4C 70 0C 1 00 - 10 Voice Category(Main) 0..16(--..Co)
Ap, Kb, Or, Gt, Ba, St,
Br, Rp, Ld, Pd, Sc,
Cp, Dr, Se, Me, Co
4C 70 0D 1 00 - 03 Voice Category(Sub) 0..3(--.Sub1..Sub3)
depens on Main
Category
4C 70 0E 1 reserved
4C 70 0F 1 reserved
4C 70 10 1 reserved
4C 70 11 1 reserved
4C 70 12 1 reserved
4C 70 13 1 00 - 02 QED ARP Type Bank pre1, pre2, user
4C 70 14 1 00 - 7F QED ARP Type UpOct1 - GateCut3
4C 70 15 1 00 - 01 ARP Switch off, on
4C 70 16 1 00 - 02 ARP Hold sync-off, off, on
4C 70 17 1 00 - 06 ARP Unit Multiply 50%, 66%, 75%, 100%, 133%,
150%, 200%
4C 70 18 1 00 - 7F ARP Note Limit Low C-2..G8
4C 70 19 1 00 - 7F ARP Note Limit High C-2..G8
4C 70 1A 1 01 - 7F ARP Velocity Limit Low 1 - 127
4C 70 1B 1 01 - 7F ARP Velocity Limit High 1 - 127
4C 70 1C 1 00 - 02 ARP Key Mode sort, thru, direct
4C 70 1D 1 00 - 01 ARP Vel Mode original, thru
4C 70 1F 2 0000 -
00C8
ARP Velocity Rate MSB 0...200%
ARP Velocity Rate LSB
4C 70 20 2 0000 -
00C8
ARP Gate Time Rate MSB 0...200%
ARP Gate TIme Rate LSB
4C 70 22 2 0001 -
012C
QED ARP Tempo MSB 1..300
QED ARP Tempo LSB
4C 70 24 1 00 - 03 Knob Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset
4C 70 25 1 01 - 7F Pan L63..C..R63
4C 70 26 1 00 - 7F Chorus Control -64..+63
4C 70 27 1 00 - 7F QED Decay Time -64..+63
4C 70 28 1 40 reserved
4C 70 29 1 40 reserved
4C 70 2A 1 40 reserved
4C 70 2B 1 40 reserved
4C 70 2C 1 40 reserved
4C 70 2D 1 40 reserved
4C 70 2E 1 00 - 7F KnobA -64..+63
4C 70 2F 1 00 - 7F KnobB -64..+63
4C 70 30 1 40 reserved
4C 70 31 1 00 - 7F EQ Low Gain -64..+63
4C 70 32 1 00 - 7F EQ Low Mid Gain -64..+63
4C 70 33 1 00 - 7F EQ High Mid Gain -64..+63
4C 70 34 1 00 - 7F EQ High Gain -64..+63
4C 70 35 1 00 - 7F Scene 1 Assign1 -64..+63
4C 70 36 1 00 - 7F Scene 1 Assign2 -64..+63
4C 70 37 1 00 - 7F Scene 1 Cutoff Frequency -64..+63
4C 70 38 1 00 - 7F Scene 1 Resonance -64..+63
4C 70 39 1 00 - 7F Scene 1 Attack Time -64..+63
4C 70 3A 1 00 - 7F Scene 1 Release Time -64..+63
4C 70 3B 1 40 reserved
4C 70 3C 1 40 reserved
4C 70 3D 1 40 reserved
4C 70 3E 1 40 reserved
4C 70 3F 1 40 reserved
4C 70 40 1 40 reserved
4C 70 41 1 00 reserved
4C 00 00 1 00 - 7F Volume 0 - 127
4C 00 01 1 reserved
4C 00 02 1 00 - 01 Same Note Number Key On Assign single, multi
4C 00 03 1 00 - 01 QED Mono/Poly Mode mono, poly
4C 00 04 1 reserved
4C 00 05 1 28 - 58 QED Pitch Bend Range -24 - +24[semitones]
4C 00 06 1 reserved
4C 00 07 1 reserved
4C 00 08 1 00 - 01 QED Portamento Switch off, on
4C 00 09 1 00 - 7F QED Portamento Time 0 - 127
4C 00 0A 1 01-02 Insertion Connect Type S->L, L->S
4C 00 0B 1 00 - 7F Reverb Send -∞dB …0dB
4C 00 0C 1 00 - 7F Chorus Send -∞dB …0dB
57
TOTAL SIZE = 24 18 (HEX)
TOTAL SIZE = 25 19 (HEX)
TOTAL SIZE = 22 16 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 10 0A (HEX)
TOTAL SIZE = 35 23 (HEX)
TOTAL SIZE = 68 44 (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
4C 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List
00 - 7F Reverb Type LSB
4C 01 02 2 00 - 7F Reverb Parameter 1 MSB ˝
00 - 7F Reverb Parameter 1 LSB
4C 01 04 2 00 - 7F Reverb Parameter 2 MSB ˝
00 - 7F Reverb Parameter 2 LSB
4C 01 06 2 00 - 7F Reverb Parameter 3 MSB ˝
00 - 7F Reverb Parameter 3 LSB
4C 01 08 2 00 - 7F Reverb Parameter 4 MSB ˝
00 - 7F Reverb Parameter 4 LSB
4C 01 0A 2 00 - 7F Reverb Parameter 5 MSB ˝
00 - 7F Reverb Parameter 5 LSB
4C 01 0C 2 00 - 7F Reverb Parameter 6 MSB ˝
00 - 7F Reverb Parameter 6 LSB
4C 01 0E 2 00 - 7F Reverb Parameter 7 MSB ˝
00 - 7F Reverb Parameter 7 LSB
4C 01 10 2 00 - 7F Reverb Parameter 8 MSB ˝
00 - 7F Reverb Parameter 8 LSB
4C 01 12 2 00 - 7F Reverb Parameter 9 MSB ˝
00 - 7F Reverb Parameter 9 LSB
4C 01 14 2 00 - 7F Reverb Parameter 10 MSB ˝
00 - 7F Reverb Parameter 10 LSB
4C 01 16 1 00 - 7F Reverb Return -∞dB…0dB…+6dB(…c96…127)
4C 01 17 1 01 - 7F Reverb Pan L63…C…R63
4C 02 00 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List
00 - 7F Chorus Type LSB
4C 02 02 2 00 - 7F Chorus Parameter 1 MSB ˝
00 - 7F Chorus Parameter 1 LSB
4C 02 04 2 00 - 7F Chorus Parameter 2 MSB ˝
00 - 7F Chorus Parameter 2 LSB
4C 02 06 2 00 - 7F Chorus Parameter 3 MSB ˝
00 - 7F Chorus Parameter 3 LSB
4C 02 08 2 00 - 7F Chorus Parameter 4 MSB ˝
00 - 7F Chorus Parameter 4 LSB
4C 02 0A 2 00 - 7F Chorus Parameter 5 MSB ˝
00 - 7F Chorus Parameter 5 LSB
4C 02 0C 2 00 - 7F Chorus Parameter 6 MSB ˝
00 - 7F Chorus Parameter 6 LSB
4C 02 0E 2 00 - 7F Chorus Parameter 7 MSB ˝
00 - 7F Chorus Parameter 7 LSB
4C 02 10 2 00 - 7F Chorus Parameter 8 MSB ˝
00 - 7F Chorus Parameter 8 LSB
4C 02 12 2 00 - 7F Chorus Parameter 9 MSB ˝
00 - 7F Chorus Parameter 9 LSB
4C 02 14 2 00 - 7F Chorus Parameter 10 MSB ˝
00 - 7F Chorus Parameter 10 LSB
4C 02 16 1 00 - 7F Chorus Return -∞dB…0dB…+6dB(…c96…127)
4C 02 17 1 01 - 7F Chorus Pan L63…C…R63
4C 02 18 1 00 - 7F Send Chorus To Reverb -∞dB…0dB(0…127)
4C 03 00 2 00 - 7F Insertion-1 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-1 Type LSB
4C 03 02 2 00 - 7F Insertion-1 Parameter1 MSB ˝
00 - 7F Insertion-1 Parameter1 LSB
4C 03 04 2 00 - 7F Insertion-1 Parameter2 MSB ˝
00 - 7F Insertion-1 Parameter2 LSB
4C 03 06 2 00 - 7F Insertion-1 Parameter3 MSB ˝
00 - 7F Insertion-1 Parameter3 LSB
4C 03 08 2 00 - 7F Insertion-1 Parameter4 MSB ˝
00 - 7F Insertion-1 Parameter4 LSB
4C 03 0A 2 00 - 7F Insertion-1 Parameter5 MSB ˝
00 - 7F Insertion-1 Parameter5 LSB
4C 03 0C 2 00 - 7F Insertion-1 Parameter6 MSB ˝
00 - 7F Insertion-1 Parameter6 LSB
4C 03 0E 2 00 - 7F Insertion-1 Parameter7 MSB ˝
00 - 7F Insertion-1 Parameter7 LSB
4C 03 10 2 00 - 7F Insertion-1 Parameter8 MSB ˝
00 - 7F Insertion-1 Parameter8 LSB
4C 03 12 2 00 - 7F Insertion-1 Parameter9 MSB ˝
00 - 7F Insertion-1 Parameter9 LSB
4C 03 14 2 00 - 7F Insertion-1 Parameter10 MSB ˝
00 - 7F Insertion-1 Parameter10 LSB
4C 04 00 2 00 - 7F Insertion-2 Type MSB Refer to Effect Parameter List
00 - 7F Insertion-2 Type LSB
4C 04 02 2 00 - 7F Insertion-2 Parameter 1 MSB ˝
00 - 7F Insertion-2 Parameter 1 LSB
4C 04 04 2 00 - 7F Insertion-2 Parameter 2 MSB ˝
00 - 7F Insertion-2 Parameter 2 LSB
4C 04 06 2 00 - 7F Insertion-2 Parameter 3 MSB ˝
00 - 7F Insertion-2 Parameter 3 LSB
4C 04 08 2 00 - 7F Insertion-2 Parameter 4 MSB ˝
00 - 7F Insertion-2 Parameter 4 LSB
Address Size Data
Range
(HEX)
Prameter Name Description Notes
4C 04 0A 2 00 - 7F Insertion-2 Parameter 5 MSB Refer to Effect Parameter List
00 - 7F Insertion-2 Parameter 5 LSB
4C 04 0C 2 00 - 7F Insertion-2 Parameter 6 MSB ˝
00 - 7F Insertion-2 Parameter 6 LSB
4C 04 0E 2 00 - 7F Insertion-2 Parameter 7 MSB ˝
00 - 7F Insertion-2 Parameter 7 LSB
4C 04 10 2 00 - 7F Insertion-2 Parameter 8 MSB ˝
00 - 7F Insertion-2 Parameter 8 LSB
4C 04 12 2 00 - 7F Insertion-2 Parameter 9 MSB ˝
00 - 7F Insertion-2 Parameter 9 LSB
4C 04 14 2 00 - 7F Insertion-2 Parameter 10 MSB ˝
00 - 7F Insertion-2 Parameter 10 LSB
4C 04 16 2 00 - 7F Insertion-2 Parameter 11 MSB ˝t
00 - 7F Insertion-2 Parameter 11 LSB
4C 04 18 2 00 - 7F Insertion-2 Parameter 12 MSB ˝
00 - 7F Insertion-2 Parameter 12 LSB
4C 04 1A 2 00 - 7F Insertion-2 Parameter 13 MSB ˝
00 - 7F Insertion-2 Parameter 13 LSB
4C 04 1C 2 00 - 7F Insertion-2 Parameter 14 MSB ˝
00 - 7F Insertion-2 Parameter 14 LSB
4C 04 1E 2 00 - 7F Insertion-2 Parameter 15 MSB ˝
00 - 7F Insertion-2 Parameter 15 LSB
4C 04 20 2 00 - 7F Insertion-2 Parameter 16 MSB ˝
00 - 7F Insertion-2 Parameter 16 LSB
4C 05 00 1 00 - 09 Controller Set1 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
4C 05 01 2 00 Controller Set1 Destination MSB 0 - 29
00 - 1D Controller Set1 Destination LSB
4C 05 03 1 00 - 7F Controller Set1 Depth -64 - +63
4C 05 04 1 reserved
4C 05 05 1 00 - 09 Controller Set2 Source PB, MW, ---, AT, FC2, FS, FC1, BC,
KN1, KN2
4C 05 06 2 00 Controller Set2 Destination 0 - 29
00 - 1D Controller Set2 Destination MSB
4C 05 08 1 00 - 7F Controller Set2 Depth -64 - +63
4C 05 09 1 reserved
4C 10 00 1 00 - 7F Voice Bank MSB 0..127
4C 10 01 1 00 - 7F Voice Bank LSB 0..127
4C 10 02 1 00 - 7F Voice Number 0..127
4C 10 03 1 28 - 58 Note Shift -24...0...+24[semitones]
4C 10 04 1 00 - 7F Velocity Sense Depth 0..127
4C 10 05 1 00 - 7F Velocity Sense Offset 0..127
4C 10 06 1 00 - 7F (Vibrato Rate) LFO Speed -64..+63
4C 10 07 1 00 - 7F (Vibrato Depth) LFO Pitch Depth -64..+63
4C 10 08 1 00 - 7F (Vibrato Delay) LFO Delay -64..+63
4C 10 09 1 00 - 7F MW Filter Control -64..+63
4C 10 0A 1 40 reserved 0
4C 10 0B 1 00 - 7F MW LFO Pitch Modulation Depth 0..127
4C 10 0C 1 00 - 7F MW LFO Filter Modulation Depth 0..127
4C 10 0D 1 00 - 7F MW LFO Amplitude Modulation
Depth
0..127
4C 10 0E 1 28 - 58 CAT Pitch Control -24..+24[semitones]
4C 10 0F 1 00 - 7F CAT Filter Control -64..+63
4C 10 10 1 40 reserved -64..+63
4C 10 11 1 00 - 7F CAT LFO Pitch Modulation Depth 0..127
4C 10 12 1 00 - 7F CAT LFO Filter Modulation Depth 0..127
4C 10 13 1 00 - 7F CAT LFO Amplitude Modulation
Depth
0..127
4C 10 14 1 00 - 5F AC1 Controller Number 0..95
4C 10 15 1 00 - 7F AC1 Filter Control -64..+63
4C 10 16 1 40 reserved -64..+63
4C 10 17 1 00 - 7F AC1 LFO Pitch Modulation Depth 0..127
4C 10 18 1 00 - 7F AC1 LFO Filter Modulation Depth 0..127
4C 10 19 1 00 - 7F AC1 LFO Amplitude Modulation
Depth
0..127
4C 10 1A 1 00 - 7F Pitch EG Initial Level -64..+63
4C 10 1B 1 00 - 7F Pitch EG Attack Time -64..+63
4C 10 1C 1 00 - 7F Pitch EG Release Level -64..+63
4C 10 1D 1 00 - 7F Pitch EG Release Time -64..+63
4C 10 1E 1 00 - 7F EQ Low Gain -64..+63(-12 - +12[dB])
4C 10 1F 1 00 - 7F EQ High Gain -64..+63(-12 - +12[dB])
4C 10 20 1 04 - 28 EQ Low Frequency 32...2.0k[Hz]
4C 10 21 1 1C - 3A EQ High Frequency 500...16.0k[Hz]
4C 10 22 1 00 - 7F HPF Cutoff Frequency -64...0...+63
4C 20 00 64 00 - 7F Plug-in Board Native Parameter depends on Plug-in Board
4C 20 40 3 00 - 7F Plug-in Board Type MSB
00 - 7F Plug-in Board Type LSB
00 - 7F Plug-in Board Version Number
43 1 00 - 7F reserved
58
MIDI PARAMETER CHANGE TABLE (MIX COMMON
for Pattern, Song)
TOTAL SIZE = 88 58 (HEX)
TOTAL SIZE = 24 18 (HEX)
TOTAL SIZE = 25 19 (HEX)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
36 00 00 1 20 reserved
36 00 01 1 20 reserved
36 00 02 1 20 reserved
36 00 03 1 20 reserved
36 00 04 1 20 reserved
36 00 05 1 20 reserved
36 00 06 1 20 reserved
36 00 07 1 20 reserved
36 00 08 1 20 reserved
36 00 09 1 20 reserved
36 00 0A 1 reserved
36 00 0B 1 reserved
36 00 0C 1 reserved
36 00 0D 1 reserved
36 00 0E 1 reserved
36 00 0F 1 reserved
36 00 10 1 10 reserved
36 00 11 1 00 - 01 ARP MIDI Out Switch off, on
36 00 12 1 00 - 10 ARP MIDI Out Channel 1..16, kbd-ch
36 00 13 1 00 - 02 ARP Type Bank pre1, pre2, user
36 00 14 1 00 - 7F ARP Type UpOct1 - GateCut3
36 00 15 1 00 - 01 ARP Switch off, on
36 00 16 1 00 - 02 ARP Hold sync-off, off, on
36 00 17 1 00 - 06 ARP Unit Multiply 50%, 66%, 75%, 100%, 133%,
150%, 200%
36 00 18 1 00 - 7F ARP Note Limit Low C-2..G8
36 00 19 1 00 - 7F ARP Note Limit High C-2..G8
36 00 1A 1 01 - 7F ARP Velocity Limit Low 1 - 127
36 00 1B 1 01 - 7F ARP Velocity Limit High 1 - 127
36 00 1C 1 00 - 02 ARP Key Mode sort, thru, direct
36 00 1D 1 00 - 01 ARP Vel Mode original, thru
36 00 1E 2 0000 -
00C8
ARP Velocity Rate MSB 0...200%
ARP Velocity Rate LSB
36 00 20 2 0000 -
00C8
ARP Gate Time Rate MSB 0...200%
ARP Gate TIme Rate LSB
36 00 22 2 reserved
reserved
36 00 24 1 00 - 03 Knob Function Select 0=Pan&Send, 1=Tone, 2=Assign,
3=MeqOffset
36 00 25 1 40 reserved
36 00 26 1 00 - 7F Chorus Control -64..+63
36 00 27 1 40 reserved
36 00 28 1 40 reserved
36 00 29 1 40 reserved
36 00 2A 1 40 reserved
36 00 2B 1 40 reserved
36 00 2C 1 40 reserved
36 00 2D 1 40 reserved
36 00 2E 1 00 - 7F KnobA -64..+63
36 00 2F 1 00 - 7F KnobB -64..+63
36 00 30 1 40 reserved
36 00 31 1 00 - 7F EQ Low Gain -64..+63
36 00 32 1 00 - 7F EQ Low Mid Gain -64..+63
36 00 33 1 00 - 7F EQ High Mid Gain -64..+63
36 00 34 1 00 - 7F EQ High Gain -64..+63
36 00 35 1 00 - 7F Scene 1 Assign1 -64..+63
36 00 36 1 00 - 7F Scene 1 Assign2 -64..+63
36 00 37 1 40 reserved
36 00 38 1 40 reserved
36 00 39 1 40 reserved
36 00 3A 1 40 reserved
36 00 3B 1 40 reserved
36 00 3C 1 40 reserved
36 00 3D 1 40 reserved
36 00 3E 1 40 reserved
36 00 3F 1 40 reserved
36 00 40 1 40 reserved
36 00 41 1 00 reserved
36 00 42 1 7F reserved
36 00 43 1 40 reserved
36 00 44 1 00 reserved
36 00 45 1 20 reserved
36 00 46 1 00 reserved
36 00 47 1 00 reserved
36 00 48 1 00 - 5F Assign1 Control Number off, 1 - 95
36 00 49 1 00 - 5F Assign2 Control Number off, 1 - 95
36 00 4A 1 00 - 5F BC Control Number off, 1 - 95
36 00 4B 1 00 - 5F FC2 Control Number off, 1 - 95
36 00 4C 1 00 - 5F FC1 Control Number off, 1 - 95
36 00 4D 1 00 - 7F Voice Insertion Effect Part 0 - 15: Part1…16
96 - 98: PB Part1, 2, 3
127: off
36 00 4E 1 reserved
36 00 4F 1 00 - 7F InsEF Plug-in Part 0 - 15: Part1 …16
64: PartAD
97 - 98: PB Part2,3
127: off
36 00 50 1 00 - 01 A/D Input Mode L mono, R mono, L+R mono,
stereo
36 00 51 1 00 - 7F A/D Part Volume 0 - 127
36 00 52 1 01 - 7F A/D Part Pan L63 - C - R63
36 00 53 1 00 - 7F A/D Part Reverb Send 0 - 127
36 00 54 1 00 - 7F A/D Part Chorus Send 0 - 127
36 00 55 1 00 - 7F A/D Part Variation Send 0 - 127
36 00 56 1 00 - 7F A/D Part Dry Level 0 - 127
36 00 57 1 00 - 71 A/D Part Output Select 0: L&R
8: asnL&R, 9: asn1&2, 10: asn3&4,
11: asn5&6
64 - 71: asnL,asnR - asn5,asn6
36 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List
00 - 7F Reverb Type LSB
36 01 02 2 00 - 7F Reverb Parameter 1 MSB ˝
00 - 7F Reverb Parameter 1 LSB
36 01 04 2 00 - 7F Reverb Parameter 2 MSB ˝
00 - 7F Reverb Parameter 2 LSB
36 01 06 2 00 - 7F Reverb Parameter 3 MSB ˝
00 - 7F Reverb Parameter 3 LSB
36 01 08 2 00 - 7F Reverb Parameter 4 MSB ˝
00 - 7F Reverb Parameter 4 LSB
36 01 0A 2 00 - 7F Reverb Parameter 5 MSB ˝
00 - 7F Reverb Parameter 5 LSB
36 01 0C 2 00 - 7F Reverb Parameter 6 MSB ˝
00 - 7F Reverb Parameter 6 LSB
36 01 0E 2 00 - 7F Reverb Parameter 7 MSB ˝
00 - 7F Reverb Parameter 7 LSB
36 01 10 2 00 - 7F Reverb Parameter 8 MSB ˝
00 - 7F Reverb Parameter 8 LSB
36 01 12 2 00 - 7F Reverb Parameter 9 MSB ˝
00 - 7F Reverb Parameter 9 LSB
36 01 14 2 00 - 7F Reverb Parameter 10 MSB ˝
00 - 7F Reverb Parameter 10 LSB
36 01 16 1 00 - 7F Reverb Return -∞dB…0dB…+6dB(…c96…127)
36 01 17 1 01 - 7F Reverb Pan L63…C…R63
36 02 00 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List
00 - 7F Chorus Type LSB
36 02 02 2 00 - 7F Chorus Parameter 1 MSB ˝
00 - 7F Chorus Parameter 1 LSB
36 02 04 2 00 - 7F Chorus Parameter 2 MSB ˝
00 - 7F Chorus Parameter 2 LSB
36 02 06 2 00 - 7F Chorus Parameter 3 MSB ˝
00 - 7F Chorus Parameter 3 LSB
36 02 08 2 00 - 7F Chorus Parameter 4 MSB ˝
00 - 7F Chorus Parameter 4 LSB
36 02 0A 2 00 - 7F Chorus Parameter 5 MSB ˝
00 - 7F Chorus Parameter 5 LSB
36 02 0C 2 00 - 7F Chorus Parameter 6 MSB ˝
00 - 7F Chorus Parameter 6 LSB
36 02 0E 2 00 - 7F Chorus Parameter 7 MSB ˝
00 - 7F Chorus Parameter 7 LSB
36 02 10 2 00 - 7F Chorus Parameter 8 MSB ˝
00 - 7F Chorus Parameter 8 LSB
36 02 12 2 00 - 7F Chorus Parameter 9 MSB ˝
00 - 7F Chorus Parameter 9 LSB
36 02 14 2 00 - 7F Chorus Parameter 10 MSB ˝
00 - 7F Chorus Parameter 10 LSB
36 02 16 1 00 - 7F Chorus Return -∞dB…0dB…+6dB(…c96…127)
36 02 17 1 01 - 7F Chorus Pan L63…C…R63
36 02 18 1 00 - 7F Send Chorus To Reverb -∞dB…0dB(0…127)
36 03 00 2 00 - 7F Variation Type MSB (for
Performance)
Refer to Effect Parameter List
00 - 7F Variation Type LSB
36 03 02 2 00 - 7F Variation Parameter1 MSB ˝
00 - 7F Variation Parameter1 LSB
36 03 04 2 00 - 7F Variation Parameter2 MSB ˝
00 - 7F Variation Parameter2 LSB
36 03 06 2 00 - 7F Variation Parameter3 MSB ˝
00 - 7F Variation Parameter3 LSB
36 03 08 2 00 - 7F Variation Parameter4 MSB ˝
00 - 7F Variation Parameter4 LSB
36 03 0A 2 00 - 7F Variation Parameter5 MSB ˝
00 - 7F Variation Parameter5 LSB
36 03 0C 2 00 - 7F Variation Parameter6 MSB ˝
00 - 7F Variation Parameter6 LSB
36 03 0E 2 00 - 7F Variation Parameter7 MSB ˝
00 - 7F Variation Parameter7 LSB
36 03 10 2 00 - 7F Variation Parameter8 MSB ˝
00 - 7F Variation Parameter8 LSB
36 03 12 2 00 - 7F Variation Parameter9 MSB ˝
00 - 7F Variation Parameter9 LSB
36 03 14 2 00 - 7F Variation Parameter10 MSB ˝
00 - 7F Variation Parameter10 LSB
36 03 16 2 00 - 7F Variation Parameter11 MSB ˝
00 - 7F Variation Parameter11 LSB
36 03 18 2 00 - 7F Variation Parameter12 MSB ˝
00 - 7F Variation Parameter12 LSB
36 03 1A 2 00 - 7F Variation Parameter13 MSB ˝
00 - 7F Variation Parameter13 LSB
Address Size Data
Range
(HEX)
Prameter Name Description Notes
59
TOTAL SIZE = 38 26 (HEX)
TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 68 44 (HEX)
MIDI PARAMETER CHANGE TABLE (MIX PART for
Pattern, Song)
TOTAL SIZE = 45 2D (HEX)
pp = part number
00 - 0F Part 1 - 16 (Normal, Drum, Sample)
60 Part Plug-in 1 (User, Preset, Direct)
61 Part Plug-in 2 (User, Preset, Direct)
62 Part Plug-in 3 (User, Preset, Direct)
10 - 1F Multi Plug-in Board Part (Not included in the Mixing setup)
Address Size Data
Range
(HEX)
Prameter Name Description Notes
36 03 1C 2 00 - 7F Variation Parameter14 MSB Refer to Effect Parameter List
00 - 7F Variation Parameter14 LSB
36 03 1E 2 00 - 7F Variation Parameter15 MSB ˝
00 - 7F Variation Parameter15 LSB
36 03 20 2 00 - 7F Variation Parameter16 MSB ˝
00 - 7F Variation Parameter16 LSB
36 03 22 1 00 - 7F Variation Return -∞dB…0dB…+6dB(…c96…127)
36 03 23 1 01 - 7F Variation Pan L63…C…R63
36 03 24 1 00 - 7F Send Variation To Reverb -∞dB…0dB(0…127)
36 03 25 1 00 - 7F Send Variation To Chorus -∞dB…0dB(0…127)
36 10 00 1 34 - 4C EQ Gain1 -12 - +12[dB]
36 10 01 1 04 - 28 EQ Frequency1 32 - 2000[Hz]
36 10 02 1 01 - 78 EQ Q1 0.1 - 12.0
36 10 03 1 00 - 01 EQ Shape1 shelv, peak
36 10 04 1 34 - 4C EQ Gain2 -12 - +12[dB]
36 10 05 1 0E - 36 EQ Frequency2 100 - 10.0[kHz]
36 10 06 1 01 - 78 EQ Q2 0.1 - 12.0
36 10 07 1 01 reserved
36 10 08 1 34 - 4C EQ Gain3 -12 - +12[dB]
36 10 09 1 0E - 36 EQ Frequency3 100 - 10.0[kHz]
36 10 0A 1 01 - 78 EQ Q3 0.1- 12.0
1 Not Used
36 10 0C 1 34 - 4C EQ Gain4 -12 - +12[dB]
36 10 0D 1 0E - 36 EQ Frequency4 100 - 10.0[kHz]
36 10 0E 1 01 - 78 EQ Q4 0.1 - 12.0
1 Not Used
36 10 10 1 34 - 4C EQ Gain5 -12 - +12[dB]
36 10 11 1 1C - 3A EQ Frequency5 0.5 - 16.0[kHz]
36 10 12 1 01 - 78 EQ Q5 0.1 - 12.0
36 10 13 1 00 - 01 EQ Shape5 shelv, peak
36 20 00 16 00 - 7F Plug-in Board Native System
Parameter
(for InsEF Plug-in)
36 20 10 48 00 - 7F Plug-in Board Native Parameter (for InsEF Plug-in)
36 20 40 3 00 - 7F Plug-in Board Type MSB (for InsEF Plug-in)
00 - 7F Plug-in Board Type LSB
00 - 7F Plug-in Board Version Number
43 1 00 - 7F reserved
Address Size Data
Range
(HEX)
Prameter Name Description Notes
37 pp 00 1 00 - 7F Bank Select MSB 0 - 127
37 pp 01 1 00 - 7F Bank Select LSB 0 - 127
37 pp 02 1 00 - 7F Program Number 1 - 128
37 pp 03 1 00 - 0F,
7F
Receive Channel 1..16, off(7F)
37 pp 04 1 00 - 01 Part Mode mono, poly
37 pp 05 1 01 - 7F Velocity Limit Low 1 - 127
37 pp 06 1 01 - 7F Velocity Limit High 1 - 127
37 pp 07 1 00 - 7F Note Limit Low C-2 - G8
37 pp 08 1 00 - 7F Note Limit High C-2 - G8
37 pp 09 1 10 - 58 Pitch Bend Range Upper -48 - +24 (PB Part: -24 - +24)
37 pp 0A 1 10 - 58 Pitch Bend Range Lower -48 - +24
37 pp 0B 1 00 - 7F Velocity Sense Depth 0 - 127
37 pp 0C 1 00 - 7F Velocity Send Offset 0 - 127
37 pp 0D 1 00 - 7F Volume 0 - 127
37 pp 0E 1 01 - 7F Pan L63 - C - R63
37 pp 0F 1 reserved
37 pp 10 2 00 - 0F Detune MSB -12.8 - +12.7[Hz]
00 - 0F Detune LSB 1st bit3-0 → bit7-4
2nd bit3-0 → bit3-0
37 pp 12 1 00 - 7F Reverb Send 0 - 127
37 pp 13 1 00 - 7F Chorus Send 0 - 127
37 pp 14 1 00 - 7F Variation Send 0 - 127
37 pp 15 1 00 - 7F Dry Level 0 - 127
37 pp 16 1 28 - 58 Note Shift -24 - +24[semitones]
37 pp 17 1 00 - 7F Filter Cutoff Frequency -64 - +63
37 pp 18 1 00 - 7F Filter Resonance/Width -64 - +63
37 pp 19 1 reserved
37 pp 1A 1 00 - 01 Portamento Switch off, on
37 pp 1B 1 00 - 7F Portamento Time 0 - 127
37 pp 1C 1 00 - 01 Portamento Mode fingered, fulltime
37 pp 1D 1 reserved
37 pp 1E 1 00 - 7F Output Select 0: L&R
8: asnL&R, 9: asn1&2, 10: asn3&4,
11: asn5&6
L&R on parts 17-32
64 - 71: asnL,asnR - asn5,asn6
127: drum(or L&R)
37 pp 1F 1 00 - 7F reserved bit0: reserved
Arpeggio Sw bit1: Arpeggio Sw off, on
Receive Control Change bit2: off, on Control Change
Receive Bank Select bit3: off, on Bank Select
Receive Program Change bit4: off, on Program Change
Receive AT bit5: off, on AT
Receive PB bit6: off, on PB
37 pp 20 1 00 - 7F Receive Volume/Expression bit0: off, on Volume/Expression
Receive Pan bit1: off, on Pan
bit2: reserved
Receive Sustain/Sostenute bit3: off, on Sustain/Sostenute
bit4: reserved
Receive MW bit5: off, on MW
bit6: reserved
37 pp 21 1 00 - 7F Receive FC2 bit0: off, on FC2
Receive FS bit1: off, on FS
Receive FC1 bit2: off, on FC1
Receive BC bit3: off, on BC
Receive Knob1 bit4: off, on KN1
Receive Knob2 bit5: off, on KN2
bit6: reserved
37 pp 22 1 00 - 7F AEG Decay2 Level (EG Sustain
Level)
-64 - +63
37 pp 23 1 00 - 7F AEG Attack Time (EG Attack Time) -64 - +63
37 pp 24 1 00 - 01 Voice Pan on/off off, on
37 pp 25 1 00 - 7F AEG Decay2 Time (EG Decay
Time)
-64 - +63
37 pp 26 1 00 - 7F AEG Release Time (EG Release
Time)
-64 - +63
37 pp 27 1 00 - 7F FEG Decay2 Level (EG Sustain
Level)
-64 - +63
37 pp 28 1 00 - 7F FEG Attack Time (EG Attack Time) -64 - +63
37 pp 29 1 reserved
37 pp 2A 1 00 - 7F FEG Decay2 Time (EG Decay
Time)
-64 - +63
37 pp 2B 1 00 - 7F FEG Release Time (EG Release
Time)
-64 - +63
37 pp 2C 1 00 - 7F FEG DEPTH -64 - +63
60
Assign A/B DESTINATION VOICE CONTROL SET DESTINATION
No. Display Description
0 " off" off
1 "EQLow-G" MEQ Low Gain
2 "EQLow-F" MEQ Low Frequency
3 "EQLow-Q" MEQ Low Q
4 "EQLoM-G" MEQ Low Mid Gain
5 "EQLoM-F" MEQ Low Mid Frequency
6 "EQLoM-Q" MEQ Low Mid Q
7 "EQMid-G" MEQ Mid Gain
8 "EQMid-F" MEQ Mid Frequency
9 "EQMid-Q" MEQ Mid Q
10 "EQHiM-G" MEQ High Mid Gain
11 "EQHiM-F" MEQ High Mid Frequency
12 "EQHiM-Q" MEQ High Mid Q
13 "EQHighG" MEQ High Gain
14 "EQHighF" MEQ High Frequency
15 "EQHighQ" MEQ High Q
16 " REV-P1" Reverb Parameter 1
: : :
25 "REV-P10" Reverb Parameter 10
26 "REV-Rtn" Reverb Return
27 "REV-Pan" Reverb Pan
28 " CHO-P1" Chorus Parameter 1
: : :
37 "CHO-P10" Chorus Parameter 10
38 "CHO-Rtn" Chorus Return
39 "CHO-Pan" Chorus Pan
40 "Cho>Rev" Send Chorus To Reverb
41 "Cho-Ctl" Chorus Control
42 "ARP-Typ" Arpeggio Type
43 "ARP-Unt" Arpeggio Unit Multiply
44 "ARP-Vel" Arpeggio Velocity Rate
45 "ARP-Gat" Arpeggio Gate Time Rate
46 " Tempo" Arpeggio/Sequencer Tempo
47 "AEG-Atk" AEG Attack Time
48 "AEG-Dcy" AEG Decay Time
49 "AEG-Sus" AEG Sustain Level
50 "AEG-Rel" AEG Release Time
47 "FEG-Atk" FEG Attack Time
48 "FEG-Dcy" FEG Decay Time
49 "FEG-Rel" FEG Release Time
50 "FEG-Dpt" FEG Depth
51 " Cutoff" Cutoff Frequency
52 " Reso" Resonance
No. Display Description Normal Other
0 " off" off Ø˛
1 " Volume" Voice Volume ØØ
2 "RevSend" Reverb Send ØØ
3 "ChoSend" Chorus Send ØØ
4 "INS1-P1" Insertion Effect 1 Parameter 1 ØØ
: : : ::
13 "INS1P10" Insertion Effect 1 Parameter 10 ØØ
14 "INS2-P1" Insertion Effect 2 Parameter 1 ØØ
: : : ::
29 "INS2P16" Insertion Effect 2 Parameter 16 ØØ
30 "CLFOSpd" Common LFO Speed Ø˛
31 "CLFO-D1" Common LFO Depth1 Ø˛
32 "CLFO-D2" Common LFO Depth2 Ø˛
33 "PorTime" Portamento Time Ø˛
34 "ELM-Lvl" Element Level Ø˛
35 "ELM-Pan" Element Pan Ø˛
36 "ELM-Dly" Element Key On Delay Ø˛
37 "ELFOSpd" Element LFO Speed Ø˛
38 "ELFO-PM" Element LFO Pitch Modulation Depth Ø˛
39 "ELFO-AM" Element LFO Amplitude Modulation Depth Ø˛
40 "ELFO-FM" Element LFO Filter Modulation Depth Ø˛
41 "PCH-Crs" Element Pitch Coarse Ø˛
42 "PCH-Fin" Element Pitch Fine Ø˛
43 "PEG-Dpt" Element Pitch EG Depth Ø˛
44 "PEG-Hld" Element Pitch EG Hold Time Ø˛
45 "PEG-Atk" Element Pitch EG Attack Time Ø˛
46 " PEG-D1" Element Pitch EG Decay1 Time Ø˛
47 " PEG-D2" Element Pitch EG Decay2 Time Ø˛
48 "PEG-Rel" Element Pitch EG Release Time Ø˛
49 "AEG-Atk" Element Amplitude EG Attack Time Ø˛
50 " AEG-D1" Element Amplitude EG Decay1 Time Ø˛
51 " AEG-D2" Element Amplitude EG Decay2 Time Ø˛
52 "AEG-Rel" Element Amplitude EG Release Time Ø˛
53 "FEG-Dpt" Element Filter EG Depth Ø˛
54 "FEG-Hld" Element Filter EG Hold Time Ø˛
55 "FEG-Atk" Element Filter EG Attack Time Ø˛
56 " FEG-D1" Element Filter EG Decay1 Time Ø˛
57 " FEG-D2" Element Filter EG Decay2 Time Ø˛
58 "FEG-Rel" Element Filter EG Release Time Ø˛
59 "FLT-Frq" Element Filter Cutoff Frequency Ø˛
60 "FLT-Rez" Element Filter Resonance Ø˛
61 "HPF-Frq" Element HPF Cutoff Frequency Ø˛
62 "CLFO-D3" Common LFO Depth3 Ø˛
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
: All Sound Off
Aux :
Reset
All
Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0-121
1 - 16
˛
Ø 9nH,v=1-127
˛ 9nH,v=0
Ø
Ø
Ø
Ø 0 - 127
**************
Ø *2
Ø *2
˛
Ø *2
Ø *2
Ø
Ø
Ø
˛
˛
˛
*1 if MIDI Sync is midi
*2 if MIDI Control is on
send MMC(stop,deffered play,locate) if sync mode is MTC.
receive MTC quarter frame message if sync mode is MTC.
˛
˛
**************
0 - 127
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø
1 - 16
˛
Ø 9nH,v=1-127
˛ 9nH,v=0
Ø
Ø
Ø *1
Ø *1
Ø *1
˛
Ø *1,*2
Ø *1
Ø
Ø
Ø
˛
˛
˛
˛
˛
˛
0 - 127
Ø
Ø
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Music Synthesizer - seq.part] Date :06-SEP-2000
Model MOTIF6/7/8 MIDI Implementation Chart Version : 1.0
Memorized
Ø0 - 127
Transpose
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
: All Sound Off
Aux :
Reset
All
Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0,32
1,7,10,11
6,38
64
65
66
71-75
91,93
96-97
100-101
1-95
1 - 16
1 - 16
Ø 9nH,v=1-127
˛ 9nH,v=0
˛
Ø
Ø
Ø
˛
Ø
˛
˛
Ø
Ø
˛
˛
Ø
Ø 0 - 127
**************
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø
˛
*1 receive if switch is on.
*2 m is always treated as "1" regardless of its value.
3
˛
**************
0 - 127
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
Ø
1 - 16
1 - 16
Ø v=1-127
˛
˛
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
˛
˛
˛
Ø
˛
Ø (120,126,127)
Ø (121)
˛
Ø (123-125)
Ø
˛
1
1 - 4(m=1) *2
˛
0 - 127
0 - 127
Ø
Ø *1
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Music Synthesizer - synth.part] Date :06-SEP-2000
Model MOTIF6/7/8 MIDI Implementation Chart Version : 1.0
Memorized
Memorized
Bank Select
Data Entry
Sustain Sw
Portamento Sw
Sosutenuto
Sound Controller
Effect Depth
RPN Inc,Dec
RPN LSB,MSB
Assignable Cntrl
Ø0 - 127
0 - 127
Yamaha Web Site (English only)
www.yamahasynth.com
Yamaha Manual Library (English versions only)
http://www2.yamaha.co.jp/manual/english/
M.D.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation
© 2001 Yamaha Corporation
V768860 106MWAP15.2-02B0
Printed in Japan
This document is printed on recycled chlorine free (ECF) paper with soy ink.
スミ -> スミ
