Table of Contents
Normal Voice List . . . . . . . . . . . . . . 2
Drum Voice List . . . . . . . . . . . . . . . 10
Drum Voice Name List . . . . . . . . 10
Drum Kit Assign List . . . . . . . . . .11
Wave List . . . . . . . . . . . . . . . . . . . .23
Multi List . . . . . . . . . . . . . . . . . . . . 25
Multi Library List . . . . . . . . . . . . . . .25
Effect Type List . . . . . . . . . . . . . . . . 26
Effect Parameter List . . . . . . . . . . . . 28
Effect Data Assign Table . . . . . . . . . 37
Control List . . . . . . . . . . . . . . . . . . .40
Arpeggio Type List . . . . . . . . . . . . . 41
Audition Phrase List . . . . . . . . . . . . 42
MIDI Data Format . . . . . . . . . . . . . .43
MIDI Data Table . . . . . . . . . . . . . . . 46
MIDI Implementation Chart. . . . . . . 60
2
Normal Voice List
Some stereo Voices include stereo Elements. Since a stereo Element is made up of stereo (two-channel) data, the maximum Elements used in a Voice containing such
Elements may be more than four, even though a Voice can have only up to four Elements.
Preset1 (MSB=63, LSB=0)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap PowerGrand 4 2
2 Ap Jazz Grand 4 2
3 Ap Dark Grand 4 2
4 Ap CP 80 4 1
5 Kb CP80&EP 4 4
6 Kb Yama EP's 4 4
7 Ap BalladKeys 4 3
8 Ap 80s Layer 3 4
9 Ap Piano&Strg 4 4
10 Ap Piano Ooh 3 4
11 Ap PianoBakup 3 4
12 Kb Max Tine 4 3
13 Kb Early Fusn 4 2
14 Kb Vintage'74 4 1
15 Kb Sweetness 3 1
16 Kb DynoStrait 4 1
17 Kb ChorusHard 4 1
18 Kb VintagCase 4 1
19 Kb ChorusDyno 4 1
20 Kb 80th Boost 4 1
21 Kb Contempo 4 1
22 Kb Early 70's 3 2
23 Kb Tonight 4 1
24 Kb E.PianoPad 3 3
25 Kb TX802 3 2
26 Kb ChorusBel 2 2
27 Kb BellDX 3 3
28 Kb Dark DX 3 3
29 Kb GS Tines 3 2
30 Kb Rich FM 4 4
31 Kb FilteredDX 2 2
32 Kb Ice Piano 3 3
33 Kb WurliTrem 4 1
34 Kb WurliAmped 3 1
35 Kb TouchClavi 1 1
36 Kb SuperClavi 2 2
37 Kb StereoClav 2 2
38 Kb HollowClav 3 2
39 Kb Nu Phasing 4 2
40 Kb Digi Clavi 1 1
41 Kb PulseClavi 3 1
42 Cp Twinkle 4 4
43 Cp Stick Bell 3 3
44 Cp Bell Chiff 4 2
45 Cp FngrCymbl 4 2
46 Cp ChorusBell 2 2
47 Cp Tibetan 3 3
48 Cp EastBell 4 5
49 Cp Gamelan 3 2
50 Cp IceBells 4 4
51 Cp Digi Bell 1 1
52 Cp Marimbell 3 4
53 Or 16+8+5&1/3 4 4
54 Or Petit 1 1
55 Or Glassy 4 4
56 Or Jazzy 4 4
57 Or Slow Jam 3 3
58 Or Greasy 4 4
59 Or Swishie 2 2
60 Or Clean 2 2
61 Or Full/CVib 2 2
62 Or Mellow 2 1
63 Or Nu Shade 3 3
64 Or Cool Cat 4 4
65 Or Flutey 1 1
66 Or LeftManual 4 4
67 Or DrawContrl 4 4
68 Or Rocky 4 4
69 Or Expensive 4 4
70 Or Progressy 3 3
71 Or Crunchy 4 4
72 Or Early Bird 4 4
73 Or Jazz Split 4 2
74 Or GosplSplit 4 3
75 Or Tradi 4 4
76 Or Sunday 3 4
77 Or BreathPipe 4 5
78 Or Fluty Pipe 3 3
79 Or Reedy Pipe 3 4
80 Pd OohPipes 4 6
81 Gt Flamenco 4 3
82 Gt Nylon Jam 4 3
83 Gt BriteSteel 2 2
84 Gt Strums 3 3
85 Gt Big Steel 4 4
86 Gt Folk Steel 4 4
87 Gt 18 String 4 4
88 Gt HarpsiGtr 3 3
89 Gt HybridGtr 3 3
90 Gt JazzGTmelo 2 2
91 Gt Velo Jazz 4 2
92 Gt FM Jazz 2 1
93 Gt For Funk 3 3
94 Gt Spanky 2 2
95 Gt Funkiest 4 4
96 Gt Vin Strum 3 3
97 Gt 1CoilChors 2 2
98 Gt CleanChors 4 2
99 Gt ChorusPlus 1 1
100 Gt SmoothChor 3 2
101 Gt TexBoogie 3 3
102 Gt Rockabilly 4 2
103 Gt 65 Combo 3 3
104 Gt VinTremolo 2 2
105 Gt Crunchoid 4 2
106 Gt DynamicAmp 3 3
107 Gt Feedback 3 3
108 Gt VOODOOMAN 2 2
109 Gt BlueLead 4 4
110 Gt MeloRckLd 4 4
111 Gt MetalMute 4 2
112 Gt OverTheTop 4 2
113 Ba RoundWound 3 2
114 Ba FingerMan 2 1
115 Ba PrecRW 3 2
116 Ba PrecFW 2 2
117 Ba HybridBass 4 4
118 Ba Stand Up 3 2
119 Ba Fretless 1 1
120 Ba Slap&Fx 3 2
121 Ba BriteSlap 4 2
122 Ba Velo Bass 4 2
123 Co Bs+Cym+Vb 4 3
124 Ba Boogie on 3 3
125 Ba MiniDetune 2 2
126 Ba Long Spit 3 2
127 Ba Tack Bass 3 3
128 Ba Fat Octave 2 2
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 2 Monday, January 6, 2003 11:10 AM
3
Preset2 (MSB=63, LSB=1)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 St Violin 4 2
2 St Viola 2 2
3 St Cello 3 2
4 St SoloSpicat 3 1
5 St 2 Solos 4 4
6 St Cello Duet 4 4
7 St Trio 3 3
8 St Chamber 4 4
9 St Small Ens 4 4
10 St Medium Ens 4 4
11 St Ens Mix 1 2
12 St Ensemble 1 2
13 St Hard Ens 2 2
14 St Background 3 5
15 St BigSymphny 3 4
16 Br Str/Horns 4 6
17 St Stringy 2 4
18 St Polystring 2 3
19 St JP Strings 2 2
20 St MournStrgs 2 3
21 St The Pizz 4 4
22 Br Fanfare 3 3
23 Br Hi Brass 3 3
24 Br Fat Sect 2 2
25 Br Sforzando 3 4
26 Br Symphony 4 5
27 Br Big Band 3 3
28 Br Big Band 2 4 5
29 Br SaxBigBand 3 4
30 Br MedmBrass 3 3
31 Br Soft Brass 3 3
32 Br SoftVeloBr 4 2
33 Br TrpRomantc 2 2
34 Br Phase Mute 3 1
35 Br Legend 2 2
36 Br Trombone 2 1
37 Br Flugelleaz 4 2
38 Br F.Horn Ens 4 4
39 Br SlowAttack 4 5
40 Br Strng/Bras 4 4
41 Br Movie Ens 4 6
42 Br Powered 3 3
43 Br ObStuff 3 3
44 Br Prophy 3 3
45 Br AnalogBras 3 3
46 Br After 1984 4 4
47 Rp Soprano 3 3
48 Rp Alto Vib 3 2
49 Rp SaxEnsembl 4 4
50 Rp Tenor Sax 4 2
51 Rp Tenor Soft 4 3
52 Rp The Winds 4 3
53 St WindOrch 4 5
54 Rp SweetFlute 3 1
55 Rp PanBottle 4 3
56 Rp AmpHarpMW 2 2
57 Ld SmoothSaw 2 2
58 Ld Lucky 2 2
59 Ld Tri Solo 1 1
60 Ld Syntrump 1 1
61 Ld PWM Lead 2 2
62 Ld Clicky Saw 4 4
63 Ld Mini Pulse 2 2
64 Ld Sync Lead 2 2
65 Pd Altair 3 6
66 Pd Analog 2 2
67 Pd Sweetland 4 5
68 Pd WarmSweepy 1 1
69 Pd SinePad 2 2
70 Pd Square 2 2
71 Pd VoxPad 4 4
72 Pd Pure Syn 2 2
73 Pd MovingPad 2 4
74 Pd SimpleSaws 3 3
75 Pd X-Shower 2 2
76 Pd PWM Pad 3 3
77 Pd Bell Choir 3 3
78 Pd ObSoft 3 3
79 Pd MellowAnlg 2 2
80 Pd Glasschoir 4 4
81 Pd PeaceVox 2 2
82 Pd StackChoir 4 3
83 Pd Bronx 4 4
84 Pd IceChoir 4 7
85 Pd Fast Oohs 2 4
86 Pd Ooze & OZ 4 5
87 Pd NeoCrystal 4 4
88 Pd Pop Synth 2 2
89 Pd Fantasy 4 6
90 Pd Heavenly 4 4
91 Pd Retro 2 3
92 Pd Airy Nylon 4 6
93 Pd Antares 3 3
94 Pd Pan Sphere 4 6
95 Pd Tamburax 2 2
96 Pd IndianFlai 4 5
97 Me SAKURA 4 4
98 Me RisingHigh 3 2
99 Me Champ 4 4
100 Me Gladiator 4 4
101 Me Hades 4 4
102 Me Glacy 4 4
103 Me Forest 4 5
104 Me MirrorRing 3 3
105 Sc Poly 1 1
106 Sc AnaTonk 2 2
107 Gt Jaipur 4 3
108 Gt Dulcitar 2 2
109 Cp Cimbalon 3 3
110 Rp EthncFlute 4 3
111 Rp Hichiriki 2 1
112 Rp Ryuteki 3 3
113 Rp Gagaku 4 2
114 St Kokyu 2 1
115 Rp Digidoo 3 2
116 Dr Bali 4 3
117 Gt Indo 4 1
118 Dr Trip East 3 3
119 Dr Tabla 4 2
120 Dr Djembe 3 1
121 Cp Djerimbe 2 1
122 Dr Udu 4 2
123 Dr Tribal 4 4
124 Cp Log&Drum 3 3
125 Dr Afro 3 2
126 Co Japanesque 2 2
127 Me EthnoShock 4 4
128 Dr Ethnology 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 3 Monday, January 6, 2003 11:10 AM
4
Preset3 (MSB=63, LSB=2)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap Wide Comp 3 3
2 Ap 78rpmPiano 4 2
3 Ap Bristol 2 2
4 Ap Mono Comp 4 1
5 Ap Dance 2 3
6 Ap Houze 4 4
7 Kb Glass EP 3 3
8 Kb VintSwitch 3 1
9 Kb Early Case 3 1
10 Kb RdsScape 3 3
11 Ap RichEcho 3 3
12 Kb StringyPno 2 2
13 Or Champagne 2 2
14 Or Moet 2 2
15 Or Compact 4 2
16 Or 1967 Keys 4 1
17 Or YD-45C 4 3
18 Ba Gnarly 2 2
19 Ba Modular 3 3
20 Ba Dark Jack 1 1
21 Ba OneVoice 1 1
22 Ba Dry Syn 1 1
23 Ba PlasticBas 4 4
24 Ba Bassline 1 1
25 Ba RubbaRap 2 2
26 Ba Juicy 1 1
27 Ba Dark 1 1
28 Ba UniBass 1 1
29 Ba Flyer 2 2
30 Ba QuackBass 4 4
31 Ba Moonbass 1 1
32 Ba ClassicSub 2 2
33 Ba DX100 4 2
34 Ba Lately 2 2
35 Ba FMBass 1 1
36 St Oct String 4 4
37 St 3 Octave 4 4
38 St TapeStrngs 3 3
39 St VP Strings 1 2
40 Br BriteTeeth 2 2
41 Br XDance 2 2
42 Br Timeless 2 2
43 Br FatSynth 2 2
44 Br Big Syn 2 2
45 Rp Bluesharp 1 1
46 Ld Sync 2 2
47 Ld Atk Reso 2 2
48 Ld Singleline 3 2
49 Ld Free LFO 1 1
50 Ld Soft Lead 3 3
51 Ld PulseWound 1 1
52 Ld Big Drone 4 4
53 Ld Big Tune 4 4
54 Ld PowerWheel 4 4
55 Ld Flangefilt 2 2
56 Ld G-Funk 1 1
57 Ld Maria AT 1 1
58 Ld InThePast 2 2
59 Pd FatSawPad 2 2
60 Pd Wide Sweep 2 2
61 Pd Sunbeams 4 4
62 Pd BPFx 3 3
63 Pd FrozenPad 4 4
64 Pd MICHINOKU 1 1
65 Pd Esmeralda 4 4
66 Pd Romance 4 4
67 Pd Circle 2 2
68 Pd Dreamspher 3 3
69 Pd Silverlake 4 4
70 Pd Shadow 3 3
71 Pd Platinum 3 2
72 Pd Gently 3 4
73 Pd Warming 3 3
74 Pd PW-EMMY 3 3
75 Pd X-fade Pad 4 4
76 Pd Zosma 4 4
77 Pd NoizRezz 2 2
78 Pd Mira 3 3
79 Pd MultiPulse 4 4
80 Pd VoxWaves 4 3
81 Pd LazySweep 3 4
82 Pd Doomed 4 3
83 Sc PerkaVox 2 2
84 Sc Punchy 1 1
85 Sc Eyeliner 2 2
86 Me Quieck 4 4
87 Me Aladdin 2 2
88 Me QuadSwell 4 4
89 Me Lilley Pad 4 6
90 Me Didje Baz 3 4
91 Me RING PAD 4 4
92 Me Chaser 1 3 3
93 Me Chaser 2 4 4
94 Me Spacebreat 4 4
95 Me Long HiPa 4 4
96 Me Action Y 4 4
97 Me Trancelan 2 2
98 Me Eternal 2 2
99 Me VirtualSyn 2 2
100 Me Interlude 3 2
101 Me Flying 3 3
102 Me TheSlayer 3 3
103 Me White Rabb 4 4
104 Me Siam 1 1
105 Co Ududu 2 2
106 Co Particle 2 2
107 Co Shaper 2 2
108 Co VintageArp 2 2
109 Co Aah Dance 4 6
110 Co Joker 1 1
111 Co Holiday 4 4
112 Co Android 3 3
113 Co Spacious 4 4
114 Co VoiceCuica 2 1
115 Co Pop Arp 2 2
116 Co Ping Pong 1 1
117 Se Amoeba 1 1
118 Se Landing 4 4
119 Se I was born 3 3
120 Se PsychoGtr 3 3
121 Se NoGravity 1 1
122 Se Pulser 1 1
123 Se Racer 2 2
124 Se Storm 4 4
125 Se Oscillatin 2 2
126 Se FamlyFeud 4 1
127 Se WatrForest 3 3
128 Se Spacecraft 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 4 Monday, January 6, 2003 11:10 AM
5
Preset 4 (MSB=63, LSB=3)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap MultcmpPno 4 2
2 Ap Light 4 2
3 Ap ConcrtGrnd 4 2
4 Ap Balld Stck 1 2
5 Ap Hard CP80 4 1
6 Ap StereoComp 4 2
7 Ap MetalPiano 3 3
8 Ap Old Piano 4 2
9 Ap Diablo 4 2
10 Kb Satellite 4 1
11 Kb SummerTime 4 2
12 Kb SparkleTin 3 2
13 Kb Tine E 2 2
14 Kb Mr. Klank 2 2
15 Kb DX7+Pad 4 3
16 Kb PluckBells 3 3
17 Kb RetroWurli 4 2
18 Kb DampedClav 2 2
19 Kb Dummy 4 1
20 Kb Neo Soul 2 1
21 Kb EpfCrusher 2 2
22 Kb PlukdThing 3 3
23 Kb Hiss Pad 2 2
24 Cp GlassBells 4 4
25 Cp YumiBell 1 1
26 Cp Pad Bells 4 5
27 Cp EthnoStone 2 2
28 Cp BellsAbuzz 2 2
29 Cp Icey Vibe 2 2
30 Cp Gongladeer 1 2
31 Cp ScaryNight 4 2
32 Or MoreDrwbrs 4 4
33 Or Soulemn 3 3
34 Or Green 1 1
35 Or JimyPercC3 2 2
36 Or Dirt Organ 2 2
37 Or Vint Drive 1 1
38 Or Yoshi Perc 3 3
39 Or Big Track 2 2
40 Or Circus 2 3
41 Or Mikuni’sFI 3 3
42 Or Elemental 2 2
43 Or Farfasso 4 2
44 Or Willis 2 2
45 Or Reed 2 2
46 Or Partita 1 2
47 Gt Policia 2 2
48 Gt Jazzmaster 2 2
49 Gt Trip Rotor 1 1
50 Gt Radio Cmp2 2 2
51 Gt Simple WAH 1 1
52 Gt Wah-Riff 3 3
53 Gt Guitar&Pad 4 4
54 Gt Coral 4 2
55 Gt Harp 2 2
56 Gt RnB Harp 1 1
57 Ba Precsn Cmp 1 1
58 Ba TubeFinger 1 1
59 Ba Finger Amp 1 1
60 Ba It'sRounda 2 2
61 Ba NoResBass 1 1
62 Ba Fat Sine 4 4
63 Ba Wobble 2 2
64 Ba Decor 1 1
65 Ba Thump 2 2
66 Ba EmFunk 1 1
67 Ba FatOctaRes 3 3
68 Ba Org Bass 1 1
69 Ba FM Klick 2 2
70 Ba Fat Low 2 2
71 Ba SimplePowr 1 1
72 St VeloString 3 5
73 St NoSofia St 1 2
74 St HoodStrngs 3 4
75 St FullStrngs 3 4
76 St Chamber AT 2 2
77 St Big Swell2 2 3
78 St BlueString 2 3
79 St Old String 2 3
80 St 78rpmStrgs 1 1
81 St Ens+Flute 3 3
82 St Bells&Bows 4 6
83 St The Pad 1 2
84 St Full PWM 4 4
85 Br HybridSect 2 3
86 Br TaniBrass 4 5
87 Br Hybrid 3 4
88 Br F HornSec2 3 3
89 Br Hi Brass 2 3 3
90 Br Brassy 2 2
91 Br Hybri Pad 3 3
92 Br Oberhorns 2 2
93 Br PiccoloTpt 3 2
94 Br Flugelist 2 2
95 Rp Soprano 3 2 2
96 Rp 4Brothers 4 3
97 Rp Antique 1 1
98 Rp Flutter Fl 4 3
99 Rp Real Flute 2 2
100 Rp Querfloete 1 1
101 Rp Oboe+EHorn 3 3
102 Rp FluteChord 4 4
103 Ld Mini Soft 2 2
104 Ld Portatone 3 3
105 Ld Sine Ld 2 1 1
106 Ld Bare Saw 1 1
107 Ld Green Eyes 1 1
108 Ld inda Night 1 1
109 Pd Shine on 2 2
110 Pd Simp. Pad 1 1
111 Pd Voxxaire 2 3
112 Pd Angelvoice 2 3
113 Pd Shangralo 2 2
114 Pd Warm PWM 2 2
115 Pd Balcony 4 4
116 Pd Alabaster 2 3
117 Pd BackPad MW 2 2
118 Pd Dark Tower 1 1
119 Sc Basic Poly 1 1
120 Sc Straight 3 3
121 Sc Soleil 3 5
122 Sc Ana Synth1 2 2
123 Sc PopularSyn 3 3
124 Co For Bertje 2 2
125 Co Udu Too 2 2
126 Co Funky Mood 3 3
127 Co Step Down 1 2
128 Co Shantasma 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 5 Monday, January 6, 2003 11:10 AM
6
Preset 5 (MSB=63, LSB=4)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co Gruvmaster 2 2
2 Co ANbasicARP 2 2
3 Co Europa 3 3
4 Co Q Machine 3 3
5 Co Happy Boy 4 6
6 Co X-Pulsar 2 2
7 Co Tekno Spy 4 4
8 Co Tuff Arp 2 2
9 Co Polygroove 4 4
10 Co OrangeMW 3 3
11 Co Hip Chordz 2 2
12 Co Em Arp 2 2
13 Co LostIsland 4 4
14 Ba Bobby Bass 2 2
15 Ba RnBass 2 2
16 Ba SimpleBss2 2 2
17 Ba SimpleReso 2 1
18 Ba BobbyJuice 1 1
19 Ba Bass&Comp! 4 4
20 Ba TranceBass 2 2
21 Ba Emlate 1 1
22 Ba Velomaster 1 1
23 Ba Kick Bass 3 3
24 Ba Hollow 2 2
25 Ba Em Bass 1 1
26 Ba Oxide 2 2
27 Ba Acidd 3 3
28 Ba Pirate 1 1
29 Ba AgressoFx 1 1
30 Ba LOFI-BASS 2 2
31 Ba Quack 1 1
32 Ba ConeFlappe 4 4
33 St Warmest 2 2
34 St FatStrings 3 3
35 St Superstrgs 3 4
36 St JupiterStr 1 1
37 St MIDIPAD 2 2
38 Br AKIRABRASS 2 2
39 Br TV Brass 4 2
40 Br Oberbrass 3 3
41 Br Thinth 2 2
42 Br Trendy 3 3
43 Ld Tech Lead 1 1
44 Ld PulseWidth 1 1
45 Ld Mr. Finger 2 2
46 Ld Punch Lead 2 2
47 Ld GOA LEAD 3 3
48 Ld I.C.U.2. 1 1
49 Ld Space Lead 2 2
50 Ld Lead Wait 4 4
51 Ld Pig Lead 3 3
52 Ld Chordz 4 4
53 Pd Twilight 3 2
54 Pd VDU Pad 3 3
55 Pd HPF+LPFpad 2 2
56 Pd Sonar Pad 4 5
57 Pd Whisperer 3 3
58 Pd Flangerous 2 2
59 Pd Sadness 2 3
60 Pd Super Back 2 2
61 Pd Bastille 3 4
62 Pd Fat Swell 2 2
63 Pd Pad&Syn 4 4
64 Pd Eurostar 3 3
65 Pd Pretty far 4 4
66 Pd Needles 3 3
67 Pd VectorPad1 3 3
68 Pd Wake Up 3 3
69 Pd Ether 4 4
70 Pd Spiralised 4 4
71 Pd RezSinePad 1 2
72 Pd Granular 3 3
73 Pd Ropey 4 4
74 Pd Smear 3 3
75 Pd Mizar 3 3
76 Pd Homesick 3 4
77 Pd Lost. 2 2
78 Pd Haunting 1 1
79 Pd Infant 3 2
80 Pd High Sine 2 2
81 Pd Sm.OrganPd 2 2
82 Pd Chianti 4 4
83 Pd Guitar Pad 4 4
84 Pd Tuscan 3 4
85 Pd Shuttle 4 4
86 Pd Ether 2 4 4
87 Sc Sine Comp 3 1
88 Sc Queens 3 3
89 Sc Kairo 4 5
90 Sc Synes XL 4 4
91 Sc FaaatDance 2 2
92 Sc Random LFO 1 1
93 Sc Vacuum 4 4
94 Sc RezzPunch 4 4
95 Sc Kordal MW 2 2
96 Sc M-Trance 2 2
97 Sc Euro 4 4
98 Sc DX Metal 2 2
99 Me Atlantis 4 4
100 Me Meteors 3 3
101 Me Girlfriend 2 4
102 Me Nebula AT 2 2
103 Me CosmicRain 4 4
104 Me Contact 3 3
105 Me Dalahi 3 4
106 Me CrushpadMW 4 4
107 Me Ar-tic 3 3
108 Me Alaska 4 6
109 Me Clusters 4 4
110 Me Glister 4 4
111 Me SliceIt Up 2 2
112 Me Chaser 3 4 4
113 Me Surface 4 6
114 Me Stalagtite 3 3
115 Me 4ling Star 4 4
116 Me Old Skool 3 3
117 Me Katsu 3 3
118 Me Genie 2 2
119 Se Dream Text 4 4
120 Se Ambi Rain 1 1
121 Se Bitzz MW 1 1
122 Se JumpQ MW 1 1
123 Se Molt 1 1
124 Se Samsara 1 1
125 Se FX-MWSweep 2 2
126 Se Static 2 2
127 Dr Wriggle 3 3
128 Dr Kraftbeat 4 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 6 Monday, January 6, 2003 11:10 AM
7
GM (MSB=0, LSB=0)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap NaturlGrnd 4 2
2 Ap Rock Brite 2 1
3 Ap CP 2001 4 1
4 Ap Honkytonk 4 2
5 Kb E.Piano 1 4 1
6 Kb E.Piano 2 2 2
7 Kb Harpsicord 1 1
8 Kb Brite Clav 4 2
9 Cp Celeste 3 3
10 Cp Glocken 4 2
11 Cp Music Box 3 3
12 Cp Vibes 4 2
13 Cp Marimba 3 1
14 Cp Xylophone 2 2
15 Cp TublarBell 4 3
16 Cp Dulcimar 2 2
17 Or Draw Organ 2 2
18 Or Perc Organ 3 2
19 Or Rock Organ 2 2
20 Or ChurchOrgn 2 3
21 Or Reed Organ 4 2
22 Kb Accordion 1 1
23 Rp Harmonica 1 1
24 Kb TangoAccrd 1 1
25 Gt Nylon 2 2
26 Gt Steel 1 1
27 Gt ModernJazz 3 2
28 Gt Clean 1 1
29 Gt Mute 2 2
30 Gt Overdrive 2 2
31 Gt Distortion 3 2
32 Gt Harmonics 2 2
33 Ba Accoustic 2 2
34 Ba FingerBass 2 2
35 Ba Pick Bass 1 1
36 Ba Fretless 2 1 1
37 Ba SimpleSlap 3 2
38 Ba Velo Slap 4 1
39 Ba SynthBass1 4 2
40 Ba SynthBass2 2 2
41 St Violin 2 4 2
42 St Viola 2 4 1
43 St Cello 2 2 2
44 St Contrabass 4 2
45 St TremoloStr 2 2
46 Gt Pizz 2 1
47 Gt Harp 3 2
48 Cp Timpni+Cym 3 2
49 St StereoSt1 1 2
50 St StereoSt2 2 2
51 St Grand Saw 3 3
52 St SynStrings 3 3
53 Pd Aah Choir 1 2
54 Pd Ooh Choir 1 2
55 Pd Syn Voice 2 3
56 Me Orch.Hit 2 2
57 Br Trumpet 3 1
58 Br Trombone 2 1 1
59 Br Tuba 2 1
60 Br MuteTrpt 2 1 1
61 Br F.Horns 2 2
62 Br Brass Sect 3 3
63 Br SynthBrass 3 3
64 Br Soft Brass 3 3
65 Rp Soprano 2 2 2
66 Rp Alto Sax 2 2
67 Rp TenorSax 2 3 2
68 Rp Bari Sax 3 2
69 Rp Oboe 1 1
70 Rp Eng.Horn 2 1
71 Rp Bassoon 2 2
72 Rp Clarinet 1 1
73 Rp Piccolo 2 1
74 Rp Flute 3 2
75 Rp Recorder 2 2
76 Rp Panflute 1 1
77 Rp Bottle 3 2
78 Rp Shakuhachi 2 2
79 Rp Whistle 2 2
80 Rp Ocarina 2 2
81 Ld Square Ld 2 2
82 Ld Saw Ld 4 2
83 Ld Caliop Ld 3 2
84 Ld Chiff Ld 1 1
85 Ld Charan Ld 2 2
86 Ld Voice Ld 2 4
87 Ld Fifth Ld 2 2
88 Ld Bass&Ld 1 1
89 Pd New Age 2 2
90 Pd Warm Pad 2 2
91 Pd Poly Synth 2 2
92 Pd Choir Pad 2 3
93 Pd BowedPad 2 2
94 Pd Metal Pad 2 2
95 Pd Halo Pad 2 3
96 Pd Sweep Pad 2 2
97 Me Rain Pad 2 2
98 Pd SoundTrack 2 3
99 Cp Crystal 2 3
100 Pd Atmosphere 2 3
101 Sc Brightness 3 2
102 Me Goblin 3 2
103 Me Echoes 2 4
104 Pd Sci-Fi 2 2
105 Gt Sitar 1 1
106 Gt Banjo 2 1
107 Gt Shamisen 2 1
108 Gt Koto 1 1
109 Cp Kalimba 2 2
110 Rp Bagpipe 2 2
111 St Fiddle 4 2
112 Rp Shanai 3 2
113 Cp Tinkerbel 4 2
114 Dr Agogo 1 1
115 Cp Steeldrum 3 2
116 Dr Woodblock 1 1
117 Dr Taikodrum 2 2
118 Dr MelodicTom 2 1
119 Dr Synth Drum 2 1
120 Se Rev Cymbal 1 1
121 Se Fret Noise 1 1
122 Se BreathNoiz 2 1
123 Se Seashore 2 2
124 Se Tweet 1 1
125 Se Telephone 1 1
126 Se Helicopter 2 2
127 Se Applause 2 2
128 Se Gunshot 1 1
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 7 Monday, January 6, 2003 11:10 AM
8
User1 (MSB=63, LSB=8)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co M25 M.W. 3 3
2 Pd Softstars 3 3
3 Ba Fast PWM 2 2
4 Ba Terminator 3 3
5 Me Soft Tar 4 4
6 Co Sorted 4 4
7 Ba Trendy Wah 3 3
8 Se Feed S&H 1 1
9 Me Didge 4 4
10 Ba Old House 4 4
11 Ld HPF Dance 1 1
12 Me Like Bees 4 4
13 Ba Exodus 3 3
14 Me S/H Gruv 4 5
15 Gt Funk It!! 2 1
16 Co Opening 4 4
17 Co DigDag 2 2
18 Pd Dark Light 2 2
19 Ba Boom Bass 2 2
20 Se Dirtbox 2 2
21 Pd Shandala 3 3
22 Co Titan 4 4
23 Ba Puls Step 2 2
24 Co Racket 2 2
25 Ld Big Lead 3 3
26 Ba Blush 2 2
27 Ld Squeaky 2 2
28 Se Duck Worm 1 1
29 Ba Jon 3 3
30 Co Weird scar 3 3
31 Gt Auto Wah 2 2
32 Co MINIMAL 3 3
33 Co MGul 4 4
34 Pd BrokenStar 3 5
35 Ba Smooth 2 2
36 Se Sawmill 4 4
37 Me Cavern 3 3
38 Co Supersnap 4 4
39 Ba Fuzzline 2 1
40 Ld Foreplay 1 1
41 Or Brooklyn 2 2
42 Ba Brief 2 2
43 Ld Dist-MW 3 3
44 Me Hit&Down 2 1
45 Ba Froglegs 4 4
46 Me Sand 2 2
47 Gt R&B Steel 2 2
48 Co Rabbit 1 1
49 Co ElecWorld 4 4
50 Me Sickday 4 4
51 Ba LoSnake 1 1
52 Se Boomeran 4 4
53 Me O+Ca+Si+Na 3 3
54 Co Space Run 2 2
55 Ba Additive 2 2
56 Ld Rap Lead 1 1 1
57 Me Nordic 3 3
58 Ba Hip Aco 4 3
59 Ld Mr. Cool 4 4
60 Me Orch Hits 4 1
61 Ba Damp Cat 2 2
62 Me FISHINREEL 4 4
63 Gt Melo Trmlo 1 1
64 Sc Fois Gras 2 2
65 Kb CheapEP 1 1
66 St AnaMarcato 4 4
67 Ba G Bass 2 2
68 Se Dolphin 4 3
69 Me Evolve 4 4
70 Me ARRIVAL 4 5
71 Ba Wazzo 2 2
72 Ld Rap Lead 2 1 1
73 Me Richard 4 4
74 Ba Hip Pick 2 2
75 Ld Early Lead 2 2
76 Se BDScrtch 4 1
77 Ba Dukes 4 4
78 Ld Mayday MW 1 1
79 Gt CoolWAH 2 2
80 Sc Mascara 3 2
81 Kb HipWahEP 1 1
82 Br ChorusComp 2 2
83 Ba Compton 2 2
84 Se Red Dots 1 1
85 Pd Fragile 3 3
86 Me SpookyVibe 2 2
87 Ba Gangsta 3 3
88 Ld Rap Lead 3 1 1
89 Sc 81Z Comp 2 2
90 Ba DarkBass 2 2
91 Ld HiPaWheel 1 1
92 Se Rap Scream 1 1
93 Ba InyerBass 3 3
94 Ld Pierced 2 2
95 Gt Hip Mute 2 2
96 St Hip Pizz 4 4
97 Kb R&B EP+DX 2 2
98 Br Kustom 3 3
99 Ba PortaBass 2 2
100 Se Sirens 4 1
101 Me Silver 3 3
102 Me Zanaks 3 2
103 Ba 2001 Sub 1 1
104 Ld Sine Lead 1 1
105 Ba UK Oam 3 3
106 Ba Fooger 2 2
107 Ld D-tune 4 4
108 Se Rap Toyz 4 1
109 Ba Mucus M 4 3
110 Ld Future Z 2 2
111 Gt FM Guitar 4 3
112 Me Trancedot 4 4
113 Me Dead?Alive 4 4
114 St SlowSuckr 4 4
115 Ba Clickk 2 2
116 Se KewBrick 3 4
117 Pd Munchkins 2 1
118 Me Ants 2 1
119 Ba Snoop Bass 2 2
120 Ld BabeMagnet 1 1
121 Ba Jones 3 3
122 Se 100 dreams 2 2
123 Ld FKitchen 2 2
124 Co Rabino 2 2
125 Ba Teknophobe 3 2
126 Me FizzWah 1 1
127 Ld Hip Voice 2 2
128 Me Strobe 3 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 8 Monday, January 6, 2003 11:10 AM
9
User2 (MSB=63, LSB=9)
The factory setting is the same as Preset 5.
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co Gruvmaster 2 2
2 Co ANbasicARP 2 2
3 Co Europa 3 3
4 Co Q Machine 3 3
5 Co Happy Boy 4 6
6 Co X-Pulsar 2 2
7 Co Tekno Spy 4 4
8 Co Tuff Arp 2 2
9 Co Polygroove 4 4
10 Co OrangeMW 3 3
11 Co Hip Chordz 2 2
12 Co Em Arp 2 2
13 Co LostIsland 4 4
14 Ba Bobby Bass 2 2
15 Ba RnBass 2 2
16 Ba SimpleBss2 2 2
17 Ba SimpleReso 2 1
18 Ba BobbyJuice 1 1
19 Ba Bass&Comp! 4 4
20 Ba TranceBass 2 2
21 Ba Emlate 1 1
22 Ba Velomaster 1 1
23 Ba Kick Bass 3 3
24 Ba Hollow 2 2
25 Ba Em Bass 1 1
26 Ba Oxide 2 2
27 Ba Acidd 3 3
28 Ba Pirate 1 1
29 Ba AgressoFx 1 1
30 Ba LOFI-BASS 2 2
31 Ba Quack 1 1
32 Ba ConeFlappe 4 4
33 St Warmest 2 2
34 St FatStrings 3 3
35 St Superstrgs 3 4
36 St JupiterStr 1 1
37 St MIDIPAD 2 2
38 Br AKIRABRASS 2 2
39 Br TV Brass 4 2
40 Br Oberbrass 3 3
41 Br Thinth 2 2
42 Br Trendy 3 3
43 Ld Tech Lead 1 1
44 Ld PulseWidth 1 1
45 Ld Mr. Finger 2 2
46 Ld Punch Lead 2 2
47 Ld GOA LEAD 3 3
48 Ld I.C.U.2. 1 1
49 Ld Space Lead 2 2
50 Ld Lead Wait 4 4
51 Ld Pig Lead 3 3
52 Ld Chordz 4 4
53 Pd Twilight 3 2
54 Pd VDU Pad 3 3
55 Pd HPF+LPFpad 2 2
56 Pd Sonar Pad 4 5
57 Pd Whisperer 3 3
58 Pd Flangerous 2 2
59 Pd Sadness 2 3
60 Pd Super Back 2 2
61 Pd Bastille 3 4
62 Pd Fat Swell 2 2
63 Pd Pad&Syn 4 4
64 Pd Eurostar 3 3
65 Pd Pretty far 4 4
66 Pd Needles 3 3
67 Pd VectorPad1 3 3
68 Pd Wake Up 3 3
69 Pd Ether 4 4
70 Pd Spiralised 4 4
71 Pd RezSinePad 1 2
72 Pd Granular 3 3
73 Pd Ropey 4 4
74 Pd Smear 3 3
75 Pd Mizar 3 3
76 Pd Homesick 3 4
77 Pd Lost. 2 2
78 Pd Haunting 1 1
79 Pd Infant 3 2
80 Pd High Sine 2 2
81 Pd Sm.OrganPd 2 2
82 Pd Chianti 4 4
83 Pd Guitar Pad 4 4
84 Pd Tuscan 3 4
85 Pd Shuttle 4 4
86 Pd Ether 2 4 4
87 Sc Sine Comp 3 1
88 Sc Queens 3 3
89 Sc Kairo 4 5
90 Sc Synes XL 4 4
91 Sc FaaatDance 2 2
92 Sc Random LFO 1 1
93 Sc Vacuum 4 4
94 Sc RezzPunch 4 4
95 Sc Kordal MW 2 2
96 Sc M-Trance 2 2
97 Sc Euro 4 4
98 Sc DX Metal 2 2
99 Me Atlantis 4 4
100 Me Meteors 3 3
101 Me Girlfriend 2 4
102 Me Nebula AT 2 2
103 Me CosmicRain 4 4
104 Me Contact 3 3
105 Me Dalahi 3 4
106 Me CrushpadMW 4 4
107 Me Ar-tic 3 3
108 Me Alaska 4 6
109 Me Clusters 4 4
110 Me Glister 4 4
111 Me SliceIt Up 2 2
112 Me Chaser 3 4 4
113 Me Surface 4 6
114 Me Stalagtite 3 3
115 Me 4ling Star 4 4
116 Me Old Skool 3 3
117 Me Katsu 3 3
118 Me Genie 2 2
119 Se Dream Text 4 4
120 Se Ambi Rain 1 1
121 Se Bitzz MW 1 1
122 Se JumpQ MW 1 1
123 Se Molt 1 1
124 Se Samsara 1 1
125 Se FX-MWSweep 2 2
126 Se Static 2 2
127 Dr Wriggle 3 3
128 Dr Kraftbeat 4 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 9 Monday, January 6, 2003 11:10 AM
10
Drum Voice List
Drum Voice Name List
Preset (MSB=63, LSB=32) User (MSB=63, LSB=40)
GM (MSB=127, LSB=0)
PRE No. Kit Name
1 PoweredStd
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 DryStandrd
3 RockSt1
4 RockSt2
5 RockMono1
6 Hip Hop1
7 Hip Hop2
8 HipStick1
9 T9HipKit1
10 R&B Kit1
11 R&B Kit2
12 AnalogT9
13 AnalogT8
14 Tekno Kit
15 House Kit1
16 House Kit2
17 Big Kit
18 Break Kit
19 Drum'nBass
20 Acid Kit
21 Jungle Kit
22 Electric
23 Human Kit
24 Hard Kit
25 DistrtdKit
26 AmbientKit
27 Jazz Kit
28 Hip Hop3
29 Hip Hop4
30 HipStick2
31 Garage
These original drum kits, programmed for the
MOTIF-RACK, feature a special non-standard
order for ease in playing.
32 ALL-ROUND
33 Rock Multi
34 Hip Multi
35 Percussion
These original kits feature a variety of
instruments and special sound effects, and are
grouped according to their type.
36 Latin Perc
37 Gtr/Bs Fx
38 Wacko Kit
39 Wood Bits
40 Metal Bits
41 Hands Kit
42 Scratches
43 AcstSnares
44 StSnares
45 AllKicks
46 DanceKicks
47 Snare & Fx
48 EasySnares
USER No. Kit Name
1 RockMono2
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 RockMono3
3 Hip Hop5
4 Hip Hop6
5 T9HipKit2
6 HipStick3
7 HipStick4
8 R&B Kit3
9 Motor City
10 MW AmpSim
GM Drum No. Kit Name
1 Stereo GM
MR_DL1.book Page 10 Monday, January 6, 2003 11:10 AM
11
PRE 1 PoweredStd PRE 2 DryStandrd PRE 3 RockSt1 PRE 4 RockSt2 PRE 5 RockMono1
Note Wave
No. Wave Name
C 0 735 Clave
C
0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D
0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F
0 734 Castanet
G 0 866 SdNm1St
G
0 732 Stick
A 0 794 BdFkSonSt
A
0 898 SdBsSt1-3
B 0 785 BdLoSt
C 1 788 BdHSonSt
C
1 1042 SdClRmSt
D 1 913 SdSonSt1-4
D
1 752 ClapT9
E 1 963 SdLdwSt1-4
F 1 1227 TomFlSt
F
1 1152 HHClFtSt
G 1 1224 TomLoSt
G
1 1155 HHHlf2St
A 1 1224 TomLoSt
A
1 1158 HHOp2St
B 1 1221 TomMdSt
C 2 1221 TomMdSt
C
2 1253 CrashSt
D 2 1218 TomHiSt
D
2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F
2 714 TambrnSw
G 2 1271 SplashSt
G
2 746 Cowbell2
A 2 1305 CrashRL
A
2 737 Vibraslap
B 2 1306 RideRL
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 661 CongaOp
E 3 669 TumbaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 724 AgogoHi
G
3 725 AgogoLo
A 3 698 Cabasa1-2
A
3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C
5 940 SdBlL1-3
D 5 963 SdLdwSt1-4
D
5 956 SdBhR1-3
E 5 983 SdHipSt1-2
F 5 785 BdLoSt
F
5 1021 SdLdwHMono
G 5 834 BdR&B1
G
5 1024 SdHeavy
A 5 808 BdRoom1
A
5 1018 SdAmb
B 5 794 BdFkSonSt
C 6 809 BdRoom2
Note Wave
No. Wave Name
C 0 735 Clave
C
0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D
0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F
0 734 Castanet
G 0 866 SdNm1St
G
0 732 Stick
A 0 773 BdFkSt1-2
A
0 900 SdBsSt2-3
B 0 782 BdHiSt
C 1 764 BdNmSt1-2
C
1 1042 SdClRmSt
D 1 860 SdNmSt1-4
D
1 752 ClapT9
E 1 899 SdBsSt1-2
F 1 1227 TomFlSt
F
1 1131 HHClSt1-4
G 1 1224 TomLoSt
G
1 1146 HHPdlSt
A 1 1224 TomLoSt
A
1 1149 HHOpSt
B 1 1221 TomMdSt
C 2 1221 TomMdSt
C
2 1253 CrashSt
D 2 1218 TomHiSt
D
2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F
2 714 TambrnSw
G 2 1271 SplashSt
G
2 746 Cowbell2
A 2 1305 CrashRL
A
2 737 Vibraslap
B 2 1306 RideRL
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 661 CongaOp
E 3 669 TumbaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 724 AgogoHi
G
3 725 AgogoLo
A 3 698 Cabasa1-2
A
3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C
5 940 SdBlL1-3
D 5 963 SdLdwSt1-4
D
5 956 SdBhR1-3
E 5 983 SdHipSt1-2
F 5 785 BdLoSt
F
5 1021 SdLdwHMono
G 5 834 BdR&B1
G
5 1024 SdHeavy
A 5 808 BdRoom1
A
5 1018 SdAmb
B 5 794 BdFkSonSt
C 6 809 BdRoom2
Note Wave
No. Wave Name
C 0 763 AnaClick
C
0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D
0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1047 SdRkRolSt
F
0 734 Castanet
G 0 992 SdRkOp1St
G
0 732 Stick
A 0 764 BdNmSt1-2
A
0 998 SdRkRim1St
B 0 782 BdHiSt
C 1 797 BdRk1St
C
1 1026 SdRkStk1St
D 1 992 SdRkOp1St
D
1 742 HandClapSt
E 1 995 SdRkMte1St
F 1 1236 TomRkLoSt
F
1 1161 HHClRkStSw
G 1 1236 TomRkLoSt
G
1 1170 HHPdRkStSw
A 1 1233 TomRkMdSt
A
1 1179 HHOpRkStSw
B 1 1233 TomRkMdSt
C 2 1230 TomRkHiSt
C
2 1253 CrashSt
D 2 1230 TomRkHiSt
D
2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F
2 759 TambrnRX5
G 2 1271 SplashSt
G
2 745 Cowbel1
A 2 1253 CrashSt
A
2 737 Vibraslap
B 2 1258 RideSt
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 724 AgogoHi
G
3 725 AgogoLo
A 3 698 Cabasa1-2
A
3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C
5 1010 SdRkFlmSt
D 5 1001 SdRkOp2St
D
5 1007 SdRkRim2St
E 5 1004 SdRkMte2St
F 5 774 BdFk1St
F
5 1050 SdRkRolDSt
G 5 788 BdHSonSt
G
5 963 SdLdwSt1-4
A 5 794 BdFkSonSt
A
5 921 SdSon3St
B 5 777 BdFkR1-2
C 6 788 BdHSonSt
Note Wave
No. Wave Name
C 0 763 AnaClick
C
0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D
0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1047 SdRkRolSt
F
0 734 Castanet
G 0 1001 SdRkOp2St
G
0 732 Stick
A 0 785 BdLoSt
A
0 1007 SdRkRim2St
B 0 766 BdNm2St
C 1 800 BdRk2St
C
1 1029 SdRkStk2St
D 1 1001 SdRkOp2St
D
1 742 HandClapSt
E 1 1004 SdRkMte2St
F 1 1236 TomRkLoSt
F
1 1173 HHClRk2St
G 1 1236 TomRkLoSt
G
1 1181 HHHfOpRkSt
A 1 1233 TomRkMdSt
A
1 1180 HHOpRkSt
B 1 1233 TomRkMdSt
C 2 1230 TomRkHiSt
C
2 1253 CrashSt
D 2 1230 TomRkHiSt
D
2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F
2 759 TambrnRX5
G 2 1271 SplashSt
G
2 745 Cowbel1
A 2 1253 CrashSt
A
2 737 Vibraslap
B 2 1258 RideSt
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 724 AgogoHi
G
3 725 AgogoLo
A 3 698 Cabasa1-2
A
3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C
5 1010 SdRkFlmSt
D 5 992 SdRkOp1St
D
5 998 SdRkRim1St
E 5 995 SdRkMte1St
F 5 797 BdRk1St
F
5 1050 SdRkRolDSt
G 5 775 BdFk2St
G
5 963 SdLdwSt1-4
A 5 782 BdHiSt
A
5 922 SdSon4St
B 5 791 BdLSonSt
C 6 797 BdRk1St
Note Wave
No. Wave Name
C 0 763 AnaClick
C
0 1058 SdBrMtL
D 0 1064 SdBrSwrL
D
0 1061 SdBrMt2L
E 0 1067 SdBrSwrAtL
F 0 1054 SnLvRolL
F
0 734 Castanet
G 0 973 SdLdwL1-4
G
0 732 Stick
A 0 803 BdDry1
A
0 962 SdBh3R
B 0 772 BdNm2R
C 1 810 BdRoom3
C
1 1045 SdClRim2
D 1 929 SdSon3L
D
1 743 HandClapL
E 1 932 SdSon4R
F 1 1228 TomFlL
F
1 1175 HHClRk2R
G 1 1225 TomLoL
G
1 1178 HHPdlRkR
A 1 1222 TomMdL
A
1 1185 HHOpRkR
B 1 1222 TomMdL
C 2 1220 TomHiR
C
2 1254 CrashL
D 2 1220 TomHiR
D
2 1264 RideMono
E 2 1267 ChinaSt
F 2 1266 CupMono2
F
2 714 TambrnSw
G 2 1273 SplashR
G
2 745 Cowbel1
A 2 1254 CrashL
A
2 737 Vibraslap
B 2 1264 RideMono
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 724 AgogoHi
G
3 725 AgogoLo
A 3 698 Cabasa1-2
A
3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C
5 1044 SdClRmR
D 5 1024 SdHeavy
D
5 1000 SdRkRim1R
E 5 1021 SdLdwHMono
F 5 801 BdRk2L
F
5 987 SdHipR1-2
G 5 841 BdBreakHrd
G
5 982 SdLdw4R
A 5 783 BdHiL
A
5 956 SdBhR1-3
B 5 780 BdFkHL
C 6 795 BdFkSonL
Drum Kit Assign List
MR_DL1.book Page 11 Monday, January 6, 2003 11:10 AM
12
PRE 6 Hip Hop1 PRE 7 Hip Hop2 PRE 8 HipStick1 PRE 9 T9HipKit1 PRE 10 R&B Kit1
Note Wave
No. Wave Name
C 0 1033 SdHpStk2
C
0 554 VoxHitRev
D 0 560 TurnTable
D
0 537 HitBrass
E 0 583 ScratchSdR
F 0 1055 SnLvRolR
F
0 762 ClaveT8
G 0 991 SdHip2R
G
0 1039 SdHpStk6R
A 0 836 BdHipDp
A
0 1121 SdDodgL
B 0 822 BdT8-3
C 1 821 BdT8-2
C
1 1033 SdHpStk2
D 1 1117 SdClpAna
D
1 744 HandClapR
E 1 1098 SdR&B2
F 1 1247 TomT8
F
1 1193 HHClT8-1
G 1 1247 TomT8
G
1 1194 HHOpT8-1
A 1 1247 TomT8
A
1 1194 HHOpT8-1
B 1 1247 TomT8
C 2 1247 TomT8
C
2 1257 Crash2
D 2 1247 TomT8
D
2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F
2 759 TambrnRX5
G 2 1273 SplashR
G
2 748 MamboBdy
A 2 1274 CrashT9
A
2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F
3 687 TmbaleL1-3
G 3 725 AgogoLo
G
3 724 AgogoHi
A 3 707 ShakerHip1
A
3 761 MarcsT8
B 3 738 Whistle
C 4 738 Whistle
C
4 728 GuiroShort
D 4 727 GuiroLong
D
4 762 ClaveT8
E 4 736 WoodBlock
F 4 736 WoodBlock
F
4 674 CuicaHi
G 4 673 CuicaLo
G
4 741 TriangleMt
A 4 740 TriangleOp
A
4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C
5 1041 SdHipStk8
D 5 1090 SdJngl3
D
5 744 HandClapR
E 5 1107 SdHipRm5
F 5 573 Scratch H
F
5 574 Scratch L
G 5 575 ScratchDwn
G
5 577 ScratchHiR
A 5 580 ScratchBdF
A
5 590 ScratchCmb
B 5 585 ScratchVoR
C 6 839 BdBreak2
Note Wave
No. Wave Name
C 0 822 BdT8-3
C
0 1081 SdT8Rim
D 0 1099 SdHip1
D
0 752 ClapT9
E 0 1124 SdSyn
F 0 1055 SnLvRolR
F
0 1035 SdHpStk4
G 0 368 DjembeEd
G
0 1037 SdHpStk6St
A 0 820 BdT8-1
A
0 1097 SdR&B1Rm
B 0 840 BdBreakHvy
C 1 836 BdHipDp
C
1 1079 SdT8-4
D 1 1101 SdHip3
D
1 742 HandClapSt
E 1 1129 SdLofi
F 1 1229 TomFlR
F
1 1211 HHClLoFi
G 1 1225 TomLoL
G
1 1200 HHClBreak
A 1 1225 TomLoL
A
1 1212 HHOpLoFi
B 1 1225 TomLoL
C 2 1219 TomHiL
C
2 1256 Crash
D 2 1219 TomHiL
D
2 1277 RideT9
E 2 1270 China
F 2 1265 CupMono
F
2 759 TambrnRX5
G 2 1256 Crash
G
2 756 CowBelRX11
A 2 1255 CrashR
A
2 755 CowBelT8
B 2 1277 RideT9
C 3 676 BongoHi1
C
3 679 BongoLo1-3
D 3 663 CongaTip
D
3 662 CongaSlp
E 3 661 CongaOp
F 3 524 RadioNz
F
3 524 RadioNz
G 3 725 AgogoLo
G
3 725 AgogoLo
A 3 699 Cabasa1
A
3 761 MarcsT8
B 3 557 FxGun2
C 4 558 FxGun1
C
4 587 ScratchSpn
D 4 586 ScratchStp
D4 762 ClaveT8
E 4 562 DoorSqk
F 4 553 HiQ2
F4 580 ScratchBdF
G 4 581 ScratchBdR
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 715 TambrnHit
C 5 751 BellTree
C5 1087 SdHuman2
D 5 1112 SdBreakRol
D5 540 StabHard
E 5 1088 SdJngl1
F 5 797 BdRk1St
F5 575 ScratchDwn
G 5 367 Wataiko
G5 511 HH Hit
A 5 541 StabOrgan2
A5 534 Sonar1
B 5 560 TurnTable
C 6 561 Police
Note Wave
No. Wave Name
C 0 1106 SdHipRm4
C0 552 HiQ1
D 0 560 TurnTable
D0 536 HitOrch1
E 0 581 ScratchBdR
F 0 1055 SnLvRolR
F0 763 AnaClick
G 0 1105 SdHipRm3
G0 1085 SdAnCRRim
A 0 836 BdHipDp
A0 1083 SdAnSmRim
B 0 822 BdT8-3
C 1 821 BdT8-2
C1 1081 SdT8Rim
D 1 1032 SdHpStk1
D1 744 HandClapR
E 1 1033 SdHpStk2
F 1 1247 TomT8
F1 1193 HHClT8-1
G 1 1247 TomT8
G1 1194 HHOpT8-1
A 1 1247 TomT8
A1 1194 HHOpT8-1
B 1 1247 TomT8
C 2 1247 TomT8
C2 1257 Crash2
D 2 1247 TomT8
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1082 SdAnSm
D 5 1046 SdClRim3
D5 763 AnaClick
E 5 1045 SdClRim2
F 5 573 Scratch H
F5 574 Scratch L
G 5 575 ScratchDwn
G5 577 ScratchHiR
A 5 580 ScratchBdF
A5 590 ScratchCmb
B 5 585 ScratchVoR
C 6 830 BdJngl2
Note Wave
No. Wave Name
C 0 762 ClaveT8
C0 1073 SdT9-5
D 0 560 TurnTable
D0 532 Quiek
E 0 592 ScratchCb3
F 0 1054 SnLvRolL
F0 763 AnaClick
G 0 1074 SdT9Gate
G0 1130 SdRimSE
A 0 815 BdT9-3
A0 1071 SdT9-3
B 0 814 BdT9-2
C 1 813 BdT9-1
C1 1075 SdT9Rim
D 1 1073 SdT9-5
D1 752 ClapT9
E 1 1072 SdT9-4
F 1 1246 TomT9Lo
F1 1191 HHClT9
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 1246 TomT9Lo
C 2 1245 TomT9Hi
C2 1274 CrashT9
D 2 1245 TomT9Hi
D2 1277 RideT9
E 2 1274 CrashT9
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1274 CrashT9
G2 757 CowBelAnCR
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1075 SdT9Rim
D 5 1074 SdT9Gate
D5 742 HandClapSt
E 5 1073 SdT9-5
F 5 573 Scratch H
F5 574 Scratch L
G 5 575 ScratchDwn
G5 576 ScratchHiF
A 5 577 ScratchHiR
A5 578 ScratchLoF
B 5 579 ScratchLoR
C 6 817 BdT9Hd1
Note Wave
No. Wave Name
C 0 819 BdT9Hd3
C0 1084 SdAnCR
D 0 1083 SdAnSmRim
D0 1117 SdClpAna
E 0 1074 SdT9Gate
F 0 1056 SdRollMono
F0 1126 SdTimber
G 0 1123 SdFMRim
G0 1091 SdJnglFx
A 0 806 BdVar1
A0 1103 SdHipRm1
B 0 821 BdT8-2
C 1 851 BdZapMid
C1 1081 SdT8Rim
D 1 1104 SdHipRm2
D1 742 HandClapSt
E 1 1084 SdAnCR
F 1 822 BdT8-3
F1 1195 HHClT8-2
G 1 822 BdT8-3
G1 1198 HHClAnCR
A 1 822 BdT8-3
A1 1196 HHOpT8-2
B 1 822 BdT8-3
C 2 822 BdT8-3
C2 1256 Crash
D 2 822 BdT8-3
D2 1277 RideT9
E 2 1270 China
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1274 CrashT9
A2 755 CowBelT8
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 552 HiQ1
F3 552 HiQ1
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 758 AnaShaker
A3 696 MaracasSlr
B 3 545 VoxDrum
C 4 545 VoxDrum
C4 552 HiQ1
D 4 553 HiQ2
D4 762 ClaveT8
E 4 552 HiQ1
F 4 587 ScratchSpn
F4 577 ScratchHiR
G 4 576 ScratchHiF
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 715 TambrnHit
C 5 751 BellTree
C5 1112 SdBreakRol
D 5 520 Mother
D5 502 VoxBell
E 5 1096 SdR&B1
F 5 512 VoxAlk
F5 377 Udo Hi
G 5 507 TranCho
G5 519 Swarm
A 5 805 BdPop
A5 1097 SdR&B1Rm
B 5 835 BdR&B2
C 6 1256 Crash
MR_DL1.book Page 12 Monday, January 6, 2003 11:10 AM
13
PRE 11 R&B Kit2 PRE 12 AnalogT9 PRE 13 AnalogT8 PRE 14 Tekno Kit PRE 15 House Kit1
Note Wave
No. Wave Name
C 0 808 BdRoom1
C0 763 AnaClick
D 0 614 PlayFxABa4
D0 1035 SdHpStk4
E 0 667 QuintTip
F 0 594 PickNoise1
F0 1075 SdT9Rim
G 0 860 SdNmSt1-4
G0 1097 SdR&B1Rm
A 0 764 BdNmSt1-2
A0 894 SdFk3R
B 0 822 BdT8-3
C 1 834 BdR&B1
C1 1046 SdClRim3
D 1 1014 SdPcRim
D1 742 HandClapSt
E 1 1097 SdR&B1Rm
F 1 822 BdT8-3
F1 1195 HHClT8-2
G 1 822 BdT8-3
G1 1193 HHClT8-1
A 1 822 BdT8-3
A1 1196 HHOpT8-2
B 1 822 BdT8-3
C 2 1247 TomT8
C2 1253 CrashSt
D 2 1247 TomT8
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 714 TambrnSw
G 2 1256 Crash
G2 745 Cowbel1
A 2 1274 CrashT9
A2 755 CowBelT8
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 552 HiQ1
F3 552 HiQ1
G 3 725 AgogoLo
G3 758 AnaShaker
A 3 758 AnaShaker
A3 696 MaracasSlr
B 3 545 VoxDrum
C 4 545 VoxDrum
C4 552 HiQ1
D 4 553 HiQ2
D4 762 ClaveT8
E 4 552 HiQ1
F 4 587 ScratchSpn
F4 577 ScratchHiR
G 4 576 ScratchHiF
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 715 TambrnHit
C 5 751 BellTree
C5 1129 SdLofi
D 5 1029 SdRkStk2St
D5 1013 SdPicol
E 5 1098 SdR&B2
F 5 835 BdR&B2
F5 1122 SdFM
G 5 836 BdHipDp
G5 1128 SdHammer
A 5 859 BdSlimy
A5 511 HH Hit
B 5 822 BdT8-3
C 6 560 TurnTable
Note Wave
No. Wave Name
C 0 814 BdT9-2
C0 1084 SdAnCR
D 0 1073 SdT9-5
D0 753 ClapAnSm
E 0 1074 SdT9Gate
F 0 1047 SdRkRolSt
F0 1071 SdT9-3
G 0 1072 SdT9-4
G0 1074 SdT9Gate
A 0 816 BdT9-4
A0 1073 SdT9-5
B 0 813 BdT9-1
C 1 815 BdT9-3
C1 1075 SdT9Rim
D 1 1069 SdT9-1
D1 752 ClapT9
E 1 1070 SdT9-2
F 1 1246 TomT9Lo
F1 1191 HHClT9
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 1245 TomT9Hi
C 2 1245 TomT9Hi
C2 1274 CrashT9
D 2 1245 TomT9Hi
D2 1277 RideT9
E 2 1270 China
F 2 1265 CupMono
F2 759 TambrnRX5
G 2 1256 Crash
G2 745 Cowbel1
A 2 1257 Crash2
A2 755 CowBelT8
B 2 1260 RideR
C 3 754 CongaT8
C3 754 CongaT8
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 763 AnaClick
G3 754 CongaT8
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 552 HiQ1
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1013 SdPicol
D 5 1080 SdT8-5
D5 1050 SdRkRolDSt
E 5 1060 SdBrMt2St
F 5 828 BdBlpHd
F5 1088 SdJngl1
G 5 852 BdSus
G5 1092 SdD&B1
A 5 839 BdBreak2
A5 1118 SdDist
B 5 853 BdTekPower
C 6 847 BdDistRM
Note Wave
No. Wave Name
C 0 820 BdT8-1
C0 1084 SdAnCR
D 0 1079 SdT8-4
D0 1117 SdClpAna
E 0 1078 SdT8-3
F 0 1247 TomT8
F0 1080 SdT8-5
G 0 822 BdT8-3
G0 1079 SdT8-4
A 0 821 BdT8-2
A0 1078 SdT8-3
B 0 436 T8KickBass
C 1 820 BdT8-1
C1 1081 SdT8Rim
D 1 1077 SdT8-2
D1 752 ClapT9
E 1 1076 SdT8-1
F 1 1247 TomT8
F1 1195 HHClT8-2
G 1 1247 TomT8
G1 1194 HHOpT8-1
A 1 1247 TomT8
A1 1194 HHOpT8-1
B 1 1247 TomT8
C 2 1247 TomT8
C2 1275 CrashT8
D 2 1247 TomT8
D2 1277 RideT9
E 2 1270 China
F 2 1265 CupMono
F2 759 TambrnRX5
G 2 1273 SplashR
G2 755 CowBelT8
A 2 1257 Crash2
A2 737 Vibraslap
B 2 1260 RideR
C 3 754 CongaT8
C3 754 CongaT8
D 3 754 CongaT8
D3 754 CongaT8
E 3 754 CongaT8
F 3 684 TimbaleHi1
F3 688 TimbaleLo1
G 3 547 Glass
G3 547 Glass
A 3 698 Cabasa1-2
A3 761 MarcsT8
B 3 557 FxGun2
C 4 558 FxGun1
C4 758 AnaShaker
D 4 758 AnaShaker
D4 762 ClaveT8
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1099 SdHip1
D 5 1100 SdHip2
D5 1102 SdHipGate
E 5 1108 SdBreak1
F 5 827 BdBlip
F5 1113 SdFx1
G 5 849 BdFxHmr
G5 1128 SdHammer
A 5 850 BdZapHrd
A5 1121 SdDodgL
B 5 853 BdTekPower
C 6 859 BdSlimy
Note Wave
No. Wave Name
C 0 859 BdSlimy
C0 1075 SdT9Rim
D 0 1080 SdT8-5
D0 752 ClapT9
E 0 1071 SdT9-3
F 0 1086 SdHuman1
F0 1101 SdHip3
G 0 1072 SdT9-4
G0 1100 SdHip2
A 0 858 BdThkSkn
A0 1070 SdT9-2
B 0 845 BdDist4
C 1 851 BdZapMid
C1 1081 SdT8Rim
D 1 1080 SdT8-5
D1 752 ClapT9
E 1 1124 SdSyn
F 1 1247 TomT8
F1 1211 HHClLoFi
G 1 1247 TomT8
G1 1212 HHOpLoFi
A 1 1247 TomT8
A1 1212 HHOpLoFi
B 1 1247 TomT8
C 2 1247 TomT8
C2 1275 CrashT8
D 2 1247 TomT8
D2 1277 RideT9
E 2 1256 Crash
F 2 1265 CupMono
F2 760 TambrnAnCR
G 2 1254 CrashL
G2 755 CowBelT8
A 2 1274 CrashT9
A2 755 CowBelT8
B 2 1276 CrashSyn
C 3 754 CongaT8
C3 754 CongaT8
D 3 754 CongaT8
D3 754 CongaT8
E 3 754 CongaT8
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 547 Glass
G3 547 Glass
A 3 699 Cabasa1
A3 761 MarcsT8
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 552 HiQ1
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 368 DjembeEd
D 5 367 Wataiko
D5 540 StabHard
E 5 536 HitOrch1
F 5 541 StabOrgan2
F5 575 ScratchDwn
G 5 797 BdRk1St
G5 511 HH Hit
A 5 367 Wataiko
A5 534 Sonar1
B 5 560 TurnTable
C 6 561 Police
Note Wave
No. Wave Name
C 0 816 BdT9-4
C0 1081 SdT8Rim
D 0 1080 SdT8-5
D0 742 HandClapSt
E 0 1121 SdDodgL
F 0 1053 SnLvRolSt
F0 1071 SdT9-3
G 0 1076 SdT8-1
G0 1073 SdT9-5
A 0 813 BdT9-1
A0 1074 SdT9Gate
B 0 814 BdT9-2
C 1 815 BdT9-3
C1 1075 SdT9Rim
D 1 1069 SdT9-1
D1 752 ClapT9
E 1 1070 SdT9-2
F 1 1246 TomT9Lo
F1 1193 HHClT8-1
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 1245 TomT9Hi
C 2 1245 TomT9Hi
C2 1274 CrashT9
D 2 1245 TomT9Hi
D2 1277 RideT9
E 2 1256 Crash
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1253 CrashSt
A2 755 CowBelT8
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 684 TimbaleHi1
F3 684 TimbaleHi1
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 545 VoxDrum
C 4 545 VoxDrum
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1112 SdBreakRol
D 5 520 Mother
D5 502 VoxBell
E 5 1096 SdR&B1
F 5 512 VoxAlk
F5 377 Udo Hi
G 5 507 TranCho
G5 519 Swarm
A 5 805 BdPop
A5 1097 SdR&B1Rm
B 5 835 BdR&B2
C 6 1256 Crash
MR_DL1.book Page 13 Monday, January 6, 2003 11:10 AM
14
PRE 16 House Kit2 PRE 17 Big Kit PRE 18 Break Kit PRE 19 Drum’nBass PRE 20 Acid Kit
Note Wave
No. Wave Name
C 0 814 BdT9-2
C0 1081 SdT8Rim
D 0 618 PlayFxABa8
D0 752 ClapT9
E 0 1070 SdT9-2
F 0 1074 SdT9Gate
F0 1087 SdHuman2
G 0 1113 SdFx1
G0 1129 SdLofi
A 0 818 BdT9Hd2
A0 1075 SdT9Rim
B 0 815 BdT9-3
C 1 817 BdT9Hd1
C1 1075 SdT9Rim
D 1 1127 SdWood
D1 549 NzBurst
E 1 551 Zap2
F 1 1124 SdSyn
F1 1191 HHClT9
G 1 1124 SdSyn
G1 1192 HHOpT9
A 1 1124 SdSyn
A1 1192 HHOpT9
B 1 1124 SdSyn
C 2 1124 SdSyn
C2 1274 CrashT9
D 2 1124 SdSyn
D2 1277 RideT9
E 2 1276 CrashSyn
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1275 CrashT8
G2 745 Cowbel1
A 2 1256 Crash
A2 755 CowBelT8
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 664 CongaHeel
D3 662 CongaSlp
E 3 661 CongaOp
F 3 1248 TomSyn1
F3 1248 TomSyn1
G 3 763 AnaClick
G3 1130 SdRimSE
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 545 VoxDrum
C 4 545 VoxDrum
C4 760 TambrnAnCR
D 4 758 AnaShaker
D4 762 ClaveT8
E 4 759 TambrnRX5
F 4 756 CowBelRX11
F4 758 AnaShaker
G 4 576 ScratchHiF
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 372 TabraBya
D 5 373 TabraNah
D5 374 TablaMut
E 5 502 VoxBell
F 5 805 BdPop
F5 377 Udo Hi
G 5 812 BdFXGate
G5 520 Mother
A 5 813 BdT9-1
A5 1112 SdBreakRol
B 5 1256 Crash
C 6 560 TurnTable
Note Wave
No. Wave Name
C 0 812 BdFXGate
C0 681 BongoLo2
D 0 1025 SdGM
D0 742 HandClapSt
E 0 1020 SdGate2
F 0 1047 SdRkRolSt
F0 998 SdRkRim1St
G 0 1013 SdPicol
G0 1010 SdRkFlmSt
A 0 809 BdRoom2
A0 1026 SdRkStk1St
B 0 810 BdRoom3
C 1 811 BdGate
C1 1017 SdMdRim
D 1 1019 SdGate1
D1 753 ClapAnSm
E 1 1018 SdAmb
F 1 1244 TomAmbLo
F1 1202 HHClD&B
G 1 1244 TomAmbLo
G1 1203 HHPdlD&B
A 1 1244 TomAmbLo
A1 1204 HHOpD&B
B 1 1243 TomAmbHi
C 2 1243 TomAmbHi
C2 1253 CrashSt
D 2 1243 TomAmbHi
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 848 Bd+HH
F3 848 Bd+HH
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 751 BellTree
C5 1118 SdDist
D 5 1122 SdFM
D5 1123 SdFMRim
E 5 1125 SdClappy
F 5 810 BdRoom3
F5 1126 SdTimber
G 5 797 BdRk1St
G5 1130 SdRimSE
A 5 800 BdRk2St
A5 1112 SdBreakRol
B 5 832 BdD&B1
C 6 809 BdRoom2
Note Wave
No. Wave Name
C 0 837 BdBrkDp
C0 984 SdHip1St
D 0 1129 SdLofi
D0 1125 SdClappy
E 0 1021 SdLdwHMono
F 0 1050 SdRkRolDSt
F0 1019 SdGate1
G 0 1016 SdMid
G0 1022 SdBrRim
A 0 840 BdBreakHvy
A0 1106 SdHipRm4
B 0 839 BdBreak2
C 1 838 BdBreak1
C1 1103 SdHipRm1
D 1 1110 SdBreak3
D1 1108 SdBreak1
E 1 1109 SdBreak2
F 1 1224 TomLoSt
F1 1167 HHClRkSR
G 1 1224 TomLoSt
G1 1178 HHPdlRkR
A 1 1224 TomLoSt
A1 1187 HHHlfOpRkR
B 1 1218 TomHiSt
C 2 1218 TomHiSt
C2 1254 CrashL
D 2 1218 TomHiSt
D2 1259 RideL
E 2 1268 ChinaL
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1255 CrashR
A2 756 CowBelRX11
B 2 1264 RideMono
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 675 BongoHi1-2
F3 679 BongoLo1-3
G 3 661 CongaOp
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 684 TimbaleHi1
C 4 688 TimbaleLo1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 560 TurnTable
C5 1112 SdBreakRol
D 5 520 Mother
D5 528 Mind Bell
E 5 1113 SdFx1
F 5 800 BdRk2St
F5 533 LfoSeq
G 5 546 Ripper
G5 549 NzBurst
A 5 561 Police
A5 526 Fairwave
B 5 519 Swarm
C 6 524 RadioNz
Note Wave
No. Wave Name
C 0 836 BdHipDp
C0 681 BongoLo2
D 0 1098 SdR&B2
D0 1126 SdTimber
E 0 1094 SdD&B3
F 0 1128 SdHammer
F0 547 Glass
G 0 833 BdD&B2
G0 1146 HHPdlSt
A 0 836 BdHipDp
A0 1158 HHOp2St
B 0 832 BdD&B1
C 1 833 BdD&B2
C1 1017 SdMdRim
D 1 1092 SdD&B1
D1 549 NzBurst
E 1 1093 SdD&B2
F 1 1244 TomAmbLo
F1 1202 HHClD&B
G 1 1244 TomAmbLo
G1 1203 HHPdlD&B
A 1 1244 TomAmbLo
A1 1204 HHOpD&B
B 1 1243 TomAmbHi
C 2 1243 TomAmbHi
C2 1254 CrashL
D 2 1243 TomAmbHi
D2 1258 RideSt
E 2 1270 China
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 1095 SdD&B4
F3 1205 HHRvD&B
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 495 Sine
F 4 495 Sine
F4 462 P50-1
G 4 653 PlyFxSl17S
G4 560 TurnTable
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 751 BellTree
C5 1118 SdDist
D 5 1122 SdFM
D5 1123 SdFMRim
E 5 1125 SdClappy
F 5 832 BdD&B1
F5 1126 SdTimber
G 5 846 BdDist5
G5 1130 SdRimSE
A 5 845 BdDist4
A5 1101 SdHip3
B 5 859 BdSlimy
C 6 848 Bd+HH
Note Wave
No. Wave Name
C 0 855 BdATite
C0 1081 SdT8Rim
D 0 1090 SdJngl3
D0 742 HandClapSt
E 0 1076 SdT8-1
F 0 1053 SnLvRolSt
F0 955 SdBhL1-3
G 0 962 SdBh3R
G0 914 SdSonSt1-3
A 0 773 BdFkSt1-2
A0 898 SdBsSt1-3
B 0 770 BdNm1R
C 1 780 BdFkHL
C1 1031 SdRkStk2R
D 1 974 SdLdwR1-4
D1 752 ClapT9
E 1 973 SdLdwL1-4
F 1 1246 TomT9Lo
F1 1167 HHClRkSR
G 1 1246 TomT9Lo
G1 1175 HHClRk2R
A 1 1246 TomT9Lo
A1 1187 HHHlfOpRkR
B 1 1245 TomT9Hi
C 2 1245 TomT9Hi
C2 1254 CrashL
D 2 1245 TomT9Hi
D2 1260 RideR
E 2 1256 Crash
F 2 1262 CupL
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1254 CrashL
A2 755 CowBelT8
B 2 1264 RideMono
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 684 TimbaleHi1
F3 684 TimbaleHi1
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 552 HiQ1
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1073 SdT9-5
D 5 1073 SdT9-5
D5 1073 SdT9-5
E 5 1073 SdT9-5
F 5 773 BdFkSt1-2
F5 1092 SdD&B1
G 5 788 BdHSonSt
G5 1102 SdHipGate
A 5 812 BdFXGate
A5 1108 SdBreak1
B 5 829 BdJngl1
C 6 840 BdBreakHvy
MR_DL1.book Page 14 Monday, January 6, 2003 11:10 AM
15
PRE 21 Jungle Kit PRE 22 Electric PRE 23 Human Kit PRE 24 Hard Kit PRE 25 DistrtdKit
Note Wave
No. Wave Name
C 0 830 BdJngl2
C0 1017 SdMdRim
D 0 1090 SdJngl3
D0 1090 SdJngl3
E 0 1014 SdPcRim
F 0 1056 SdRollMono
F0 1127 SdWood
G 0 1098 SdR&B2
G0 1093 SdD&B2
A 0 830 BdJngl2
A0 1091 SdJnglFx
B 0 831 BdJngl3
C 1 829 BdJngl1
C1 1106 SdHipRm4
D 1 1089 SdJngl2
D1 1091 SdJnglFx
E 1 1088 SdJngl1
F 1 1228 TomFlL
F1 1165 HHClRkRSw
G 1 1225 TomLoL
G1 1172 HHPdlRkRSw
A 1 1223 TomMdR
A1 1183 HHOpRkRSw
B 1 1223 TomMdR
C 2 1220 TomHiR
C2 1254 CrashL
D 2 1220 TomHiR
D2 1260 RideR
E 2 1270 China
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 745 Cowbel1
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 373 TabraNah
F3 372 TabraBya
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 684 TimbaleHi1
C 4 688 TimbaleLo1
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 751 BellTree
C5 1205 HHRvD&B
D 5 572 RainLoop
D5 573 Scratch H
E 5 574 Scratch L
F 5 828 BdBlpHd
F5 1124 SdSyn
G 5 548 IndusTom
G5 717 PandieroOp
A 5 546 Ripper
A5 567 TelRing
B 5 579 ScratchLoR
C 6 556 TapeRewnd
Note Wave
No. Wave Name
C 0 824 BdAnCR
C0 827 BdBlip
D 0 1080 SdT8-5
D0 753 ClapAnSm
E 0 1104 SdHipRm2
F 0 1056 SdRollMono
F0 1076 SdT8-1
G 0 1084 SdAnCR
G0 1077 SdT8-2
A 0 820 BdT8-1
A0 1079 SdT8-4
B 0 827 BdBlip
C 1 821 BdT8-2
C1 1081 SdT8Rim
D 1 1078 SdT8-3
D1 752 ClapT9
E 1 753 ClapAnSm
F 1 1249 TomSyn2
F1 1195 HHClT8-2
G 1 1249 TomSyn2
G1 1194 HHOpT8-1
A 1 1249 TomSyn2
A1 1196 HHOpT8-2
B 1 1249 TomSyn2
C 2 1249 TomSyn2
C2 1274 CrashT9
D 2 1249 TomSyn2
D2 1277 RideT9
E 2 1256 Crash
F 2 1276 CrashSyn
F2 1275 CrashT8
G 2 1256 Crash
G2 1130 SdRimSE
A 2 1253 CrashSt
A2 755 CowBelT8
B 2 1276 CrashSyn
C 3 1247 TomT8
C3 1247 TomT8
D 3 1247 TomT8
D3 1247 TomT8
E 3 1247 TomT8
F 3 571 Applause
F3 566 Telephone
G 3 563 Heartbeat
G3 555 Bomb
A 3 1212 HHOpLoFi
A3 696 MaracasSlr
B 3 551 Zap2
C 4 550 Zap1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 552 HiQ1
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 544 HitOrch2
G4 1215 HHClFx
A 4 1216 HHOpFx
A4 758 AnaShaker
B 4 758 AnaShaker
C 5 560 TurnTable
C5 1112 SdBreakRol
D 5 520 Mother
D5 528 Mind Bell
E 5 1113 SdFx1
F 5 800 BdRk2St
F5 533 LfoSeq
G 5 546 Ripper
G5 549 NzBurst
A 5 561 Police
A5 526 Fairwave
B 5 519 Swarm
C 6 524 RadioNz
Note Wave
No. Wave Name
C 0 825 BdHuman1
C0 584 ScratchVoF
D 0 543 Hit Uhh
D0 585 ScratchVoR
E 0 1091 SdJnglFx
F 0 1047 SdRkRolSt
F0 1108 SdBreak1
G 0 1084 SdAnCR
G0 1069 SdT9-1
A 0 852 BdSus
A0 1032 SdHpStk1
B 0 825 BdHuman1
C 1 826 BdHuman2
C1 1127 SdWood
D 1 1086 SdHuman1
D1 1120 SdDodgH
E 1 1087 SdHuman2
F 1 825 BdHuman1
F1 1217 HHOpHuman
G 1 825 BdHuman1
G1 1217 HHOpHuman
A 1 825 BdHuman1
A1 1217 HHOpHuman
B 1 825 BdHuman1
C 2 825 BdHuman1
C2 549 NzBurst
D 2 825 BdHuman1
D2 1275 CrashT8
E 2 1270 China
F 2 1265 CupMono
F2 583 ScratchSdR
G 2 1271 SplashSt
G2 545 VoxDrum
A 2 1257 Crash2
A2 755 CowBelT8
B 2 542 StabAah
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 578 ScratchLoF
E 4 579 ScratchLoR
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 560 TurnTable
C5 1000 SdRkRim1R
D 5 564 Helicopter
D5 540 StabHard
E 5 1019 SdGate1
F 5 797 BdRk1St
F5 575 ScratchDwn
G 5 823 BdAnSm
G5 534 Sonar1
A 5 367 Wataiko
A5 367 Wataiko
B 5 511 HH Hit
C 6 541 StabOrgan2
Note Wave
No. Wave Name
C 0 844 BdDist3
C0 1127 SdWood
D 0 1019 SdGate1
D0 742 HandClapSt
E 0 1020 SdGate2
F 0 1056 SdRollMono
F0 1117 SdClpAna
G 0 1101 SdHip3
G0 546 Ripper
A 0 847 BdDistRM
A0 1081 SdT8Rim
B 0 843 BdDist2
C 1 842 BdDist1
C1 1017 SdMdRim
D 1 1118 SdDist
D1 549 NzBurst
E 1 1114 SdFx2
F 1 1252 TomDistLo
F1 1191 HHClT9
G 1 1252 TomDistLo
G1 1192 HHOpT9
A 1 1252 TomDistLo
A1 1192 HHOpT9
B 1 1251 TomDistHi
C 2 1251 TomDistHi
C2 1274 CrashT9
D 2 1251 TomDistHi
D2 1277 RideT9
E 2 1270 China
F 2 1265 CupMono
F2 760 TambrnAnCR
G 2 1256 Crash
G2 755 CowBelT8
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 1126 SdTimber
C3 1126 SdTimber
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 848 Bd+HH
F3 848 Bd+HH
G 3 547 Glass
G3 547 Glass
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 557 FxGun2
C 4 558 FxGun1
C4 573 Scratch H
D 4 575 ScratchDwn
D4 552 HiQ1
E 4 552 HiQ1
F 4 553 HiQ2
F4 574 Scratch L
G 4 574 Scratch L
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1118 SdDist
D 5 1122 SdFM
D5 1123 SdFMRim
E 5 1125 SdClappy
F 5 849 BdFxHmr
F5 548 IndusTom
G 5 832 BdD&B1
G5 548 IndusTom
A 5 810 BdRoom3
A5 548 IndusTom
B 5 816 BdT9-4
C 6 1128 SdHammer
Note Wave
No. Wave Name
C 0 763 AnaClick
C0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F0 734 Castanet
G 0 866 SdNm1St
G0 732 Stick
A 0 802 BdRk2R
A0 969 SdLdw1St
B 0 838 BdBreak1
C 1 802 BdRk2R
C1 1031 SdRkStk2R
D 1 925 SdSon1L
D1 743 HandClapL
E 1 1014 SdPcRim
F 1 1244 TomAmbLo
F1 1175 HHClRk2R
G 1 1244 TomAmbLo
G1 1178 HHPdlRkR
A 1 1244 TomAmbLo
A1 1185 HHOpRkR
B 1 1243 TomAmbHi
C 2 1243 TomAmbHi
C2 1254 CrashL
D 2 1243 TomAmbHi
D2 1260 RideR
E 2 1268 ChinaL
F 2 1263 CupR
F2 714 TambrnSw
G 2 1273 SplashR
G2 747 MamboBel
A 2 1254 CrashL
A2 737 Vibraslap
B 2 1258 RideSt
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 591 ScratchCb2
G 4 577 ScratchHiR
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1013 SdPicol
D 5 1024 SdHeavy
D5 1117 SdClpAna
E 5 1014 SdPcRim
F 5 809 BdRoom2
F5 1016 SdMid
G 5 810 BdRoom3
G5 1017 SdMdRim
A 5 811 BdGate
A5 1019 SdGate1
B 5 812 BdFXGate
C 6 832 BdD&B1
MR_DL1.book Page 15 Monday, January 6, 2003 11:10 AM
16
PRE 26 AmbientKit PRE 27 Jazz Kit PRE 28 Hip Hop3 PRE 29 Hip Hop4 PRE 30 HipStick2
Note Wave
No. Wave Name
C 0 827 BdBlip
C0 553 HiQ2
D 0 1015 SdPcRim2
D0 552 HiQ1
E 0 1084 SdAnCR
F 0 1248 TomSyn1
F0 1213 HHClSyn
G 0 1248 TomSyn1
G0 1215 HHClFx
A 0 1249 TomSyn2
A0 1214 HHOpSyn
B 0 824 BdAnCR
C 1 813 BdT9-1
C1 1034 SdHpStk3
D 1 1088 SdJngl1
D1 752 ClapT9
E 1 1088 SdJngl1
F 1 1247 TomT8
F1 1195 HHClT8-2
G 1 1247 TomT8
G1 1194 HHOpT8-1
A 1 1247 TomT8
A1 1196 HHOpT8-2
B 1 1247 TomT8
C 2 1247 TomT8
C2 1276 CrashSyn
D 2 1247 TomT8
D2 1277 RideT9
E 2 1256 Crash
F 2 1265 CupMono
F2 715 TambrnHit
G 2 1256 Crash
G2 755 CowBelT8
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 547 Glass
G3 547 Glass
A 3 699 Cabasa1
A3 761 MarcsT8
B 3 568 Bird
C 4 569 Stream
C4 559 Thunder
D 4 570 Gunshot
D4 762 ClaveT8
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 760 TambrnAnCR
G 4 757 CowBelAnCR
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 1080 SdT8-5
D 5 534 Sonar1
D5 1080 SdT8-5
E 5 523 Resonator
F 5 518 Bubble
F5 1080 SdT8-5
G 5 518 Bubble
G5 1080 SdT8-5
A 5 509 Eery
A5 1080 SdT8-5
B 5 504 WindChime
C 6 504 WindChime
Note Wave
No. Wave Name
C 0 809 BdRoom2
C0 1059 SdBrMtR
D 0 1066 SdBSwrAtSt
D0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F0 734 Castanet
G 0 984 SdHip1St
G0 732 Stick
A 0 778 BdFkML
A0 1029 SdRkStk2St
B 0 794 BdFkSonSt
C 1 773 BdFkSt1-2
C1 1042 SdClRmSt
D 1 969 SdLdw1St
D1 742 HandClapSt
E 1 948 SdBhSt1-3
F 1 1227 TomFlSt
F1 1152 HHClFtSt
G 1 1227 TomFlSt
G1 1146 HHPdlSt
A 1 1224 TomLoSt
A1 1158 HHOp2St
B 1 1221 TomMdSt
C 2 1221 TomMdSt
C2 1253 CrashSt
D 2 1218 TomHiSt
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 715 TambrnHit
G 2 1271 SplashSt
G2 745 Cowbel1
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1258 RideSt
C 3 676 BongoHi1
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 684 TimbaleHi1
F3 684 TimbaleHi1
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 699 Cabasa1
A3 696 MaracasSlr
B 3 1063 SdBrSwrSt
C 4 1063 SdBrSwrSt
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 706 Shaker2
B 4 750 SleighBel
C 5 751 BellTree
C5 940 SdBlL1-3
D 5 895 SdFkAySt
D5 956 SdBhR1-3
E 5 934 SdBlSt1-2
F 5 786 BdLoL
F5 1021 SdLdwHMono
G 5 804 BdDry2
G5 1066 SdBSwrAtSt
A 5 859 BdSlimy
A5 1056 SdRollMono
B 5 772 BdNm2R
C 6 1256 Crash
Note Wave
No. Wave Name
C 0 1081 SdT8Rim
C0 554 VoxHitRev
D 0 560 TurnTable
D0 540 StabHard
E 0 585 ScratchVoR
F 0 1056 SdRollMono
F0 762 ClaveT8
G 0 989 SdHip1R
G0 1035 SdHpStk4
A 0 824 BdAnCR
A0 1105 SdHipRm3
B 0 815 BdT9-3
C 1 836 BdHipDp
C1 1036 SdHpStk5
D 1 1102 SdHipGate
D1 744 HandClapR
E 1 1129 SdLofi
F 1 1247 TomT8
F1 1208 HHClHip
G 1 1247 TomT8
G1 1209 HHPdlHip
A 1 1247 TomT8
A1 1210 HHOpHip
B 1 1247 TomT8
C 2 1247 TomT8
C2 1257 Crash2
D 2 1247 TomT8
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1032 SdHpStk1
D 5 1088 SdJngl1
D5 744 HandClapR
E 5 1111 SdBreakHvy
F 5 574 Scratch L
F5 575 ScratchDwn
G 5 576 ScratchHiF
G5 578 ScratchLoF
A 5 579 ScratchLoR
A5 580 ScratchBdF
B 5 581 ScratchBdR
C 6 840 BdBreakHvy
Note Wave
No. Wave Name
C 0 1033 SdHpStk2
C0 553 HiQ2
D 0 560 TurnTable
D0 536 HitOrch1
E 0 587 ScratchSpn
F 0 1049 SdRkRolR
F0 762 ClaveT8
G 0 1110 SdBreak3
G0 1040 SdHpStk7
A 0 835 BdR&B2
A0 1097 SdR&B1Rm
B 0 816 BdT9-4
C 1 814 BdT9-2
C1 1034 SdHpStk3
D 1 1105 SdHipRm3
D1 744 HandClapR
E 1 1106 SdHipRm4
F 1 822 BdT8-3
F1 1191 HHClT9
G 1 822 BdT8-3
G1 1192 HHOpT9
A 1 822 BdT8-3
A1 1192 HHOpT9
B 1 822 BdT8-3
C 2 822 BdT8-3
C2 1257 Crash2
D 2 822 BdT8-3
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1042 SdClRmSt
D 5 1091 SdJnglFx
D5 744 HandClapR
E 5 1112 SdBreakRol
F 5 577 ScratchHiR
F5 578 ScratchLoF
G 5 579 ScratchLoR
G5 580 ScratchBdF
A 5 581 ScratchBdR
A5 582 ScratchSdF
B 5 583 ScratchSdR
C 6 841 BdBreakHrd
Note Wave
No. Wave Name
C 0 1106 SdHipRm4
C0 549 NzBurst
D 0 560 TurnTable
D0 543 Hit Uhh
E 0 581 ScratchBdR
F 0 1055 SnLvRolR
F0 762 ClaveT8
G 0 1083 SdAnSmRim
G0 1102 SdHipGate
A 0 815 BdT9-3
A0 1081 SdT8Rim
B 0 821 BdT8-2
C 1 813 BdT9-1
C1 1105 SdHipRm3
D 1 1034 SdHpStk3
D1 744 HandClapR
E 1 1035 SdHpStk4
F 1 1246 TomT9Lo
F1 1191 HHClT9
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 1245 TomT9Hi
C 2 1245 TomT9Hi
C2 1257 Crash2
D 2 1245 TomT9Hi
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1083 SdAnSmRim
D 5 1044 SdClRmR
D5 1106 SdHipRm4
E 5 1046 SdClRim3
F 5 574 Scratch L
F5 575 ScratchDwn
G 5 576 ScratchHiF
G5 578 ScratchLoF
A 5 581 ScratchBdR
A5 591 ScratchCb2
B 5 586 ScratchStp
C 6 828 BdBlpHd
MR_DL1.book Page 16 Monday, January 6, 2003 11:10 AM
17
PRE 31 Garage PRE 32 ALL-ROUND PRE 33 Rock Multi PRE 34 Hip Multi PRE 35 Percussion
Note Wave
No. Wave Name
C 0 854 BdHardLong
C0 813 BdT9-1
D 0 859 BdSlimy
D0 856 BdAnHard
E 0 845 BdDist4
F 0 835 BdR&B2
F0 836 BdHipDp
G 0 849 BdFxHmr
G0 817 BdT9Hd1
A 0 822 BdT8-3
A0 852 BdSus
B 0 851 BdZapMid
C 1 821 BdT8-2
C1 859 BdSlimy
D 1 1076 SdT8-1
D1 1081 SdT8Rim
E 1 1125 SdClappy
F 1 939 SdBl3St
F1 1149 HHOpSt
G 1 1195 HHClT8-2
G1 1149 HHOpSt
A 1 1196 HHOpT8-2
A1 1149 HHOpSt
B 1 1196 HHOpT8-2
C 2 753 ClapAnSm
C2 1253 CrashSt
D 2 1274 CrashT9
D2 1258 RideSt
E 2 1277 RideT9
F 2 763 AnaClick
F2 762 ClaveT8
G 2 753 ClapAnSm
G2 752 ClapT9
A 2 758 AnaShaker
A2 754 CongaT8
B 2 754 CongaT8
C 3 1084 SdAnCR
C3 1047 SdRkRolSt
D 3 724 AgogoHi
D3 1308 ChinaRL
E 3 553 HiQ2
F 3 552 HiQ1
F3 551 Zap2
G 3 550 Zap1
G3 551 Zap2
A 3 562 DoorSqk
A3 592 ScratchCb3
B 3 597 FretNoise
C 4 602 PlayFxGt5
C4 576 ScratchHiF
D 4 60 Wurli+
D4 60 Wurli+
E 4 60 Wurli+
F 4 531 ResoXFade
F4 534 Sonar1
G 4 545 VoxDrum
G4 545 VoxDrum
A 4 545 VoxDrum
A4 1214 HHOpSyn
B 4 1213 HHClSyn
C 5 464 TriWv
C5 464 TriWv
D 5 464 TriWv
D5 464 TriWv
E 5 464 TriWv
F 5 464 TriWv
F5 464 TriWv
G 5 464 TriWv
G5 464 TriWv
A 5 464 TriWv
A5 464 TriWv
B 5 464 TriWv
C 6 464 TriWv
Note Wave
No. Wave Name
C 0 854 BdHardLong
C0 853 BdTekPower
D 0 846 BdDist5
D0 844 BdDist3
E 0 842 BdDist1
F 0 832 BdD&B1
F0 827 BdBlip
G 0 823 BdAnSm
G0 821 BdT8-2
A 0 820 BdT8-1
A0 819 BdT9Hd3
B 0 814 BdT9-2
C 1 815 BdT9-3
C1 852 BdSus
D 1 1069 SdT9-1
D1 1075 SdT9Rim
E 1 1072 SdT9-4
F 1 1246 TomT9Lo
F1 1191 HHClT9
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 752 ClapT9
C 2 753 ClapAnSm
C2 1274 CrashT9
D 2 754 CongaT8
D2 1277 RideT9
E 2 754 CongaT8
F 2 763 AnaClick
F2 762 ClaveT8
G 2 761 MarcsT8
G2 760 TambrnAnCR
A 2 758 AnaShaker
A2 755 CowBelT8
B 2 757 CowBelAnCR
C 3 1076 SdT8-1
C3 1077 SdT8-2
D 3 1078 SdT8-3
D3 1084 SdAnCR
E 3 1088 SdJngl1
F 3 1092 SdD&B1
F3 1095 SdD&B4
G 3 1096 SdR&B1
G3 1098 SdR&B2
A 3 1099 SdHip1
A3 1127 SdWood
B 3 1126 SdTimber
C 4 1193 HHClT8-1
C4 1194 HHOpT8-1
D 4 1195 HHClT8-2
D4 1196 HHOpT8-2
E 4 1146 HHPdlSt
F 4 1149 HHOpSt
F4 1149 HHOpSt
G 4 1211 HHClLoFi
G4 1212 HHOpLoFi
A 4 1213 HHClSyn
A4 1214 HHOpSyn
B 4 758 AnaShaker
C 5 759 TambrnRX5
C5 714 TambrnSw
D 5 746 Cowbell2
D5 676 BongoHi1
E 5 684 TimbaleHi1
F 5 736 WoodBlock
F5 854 BdHardLong
G 5 669 TumbaOp
G5 665 QuintOp
A 5 557 FxGun2
A5 555 Bomb
B 5 850 BdZapHrd
C 6 589 ScratchHp2
Note Wave
No. Wave Name
C 0 764 BdNmSt1-2
C0 1026 SdRkStk1St
D 0 1001 SdRkOp2St
D0 1047 SdRkRolSt
E 0 992 SdRkOp1St
F 0 1224 TomLoSt
F0 1152 HHClFtSt
G 0 1224 TomLoSt
G0 1146 HHPdlSt
A 0 1221 TomMdSt
A0 1149 HHOpSt
B 0 1218 TomHiSt
C 1 800 BdRk2St
C1 1026 SdRkStk1St
D 1 1001 SdRkOp2St
D1 742 HandClapSt
E 1 1004 SdRkMte2St
F 1 1236 TomRkLoSt
F1 1161 HHClRkStSw
G 1 1236 TomRkLoSt
G1 1170 HHPdRkStSw
A 1 1233 TomRkMdSt
A1 1179 HHOpRkStSw
B 1 1233 TomRkMdSt
C 2 1230 TomRkHiSt
C2 1253 CrashSt
D 2 1230 TomRkHiSt
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 714 TambrnSw
G 2 1271 SplashSt
G2 745 Cowbel1
A 2 1253 CrashSt
A2 704 Shaker1-2
B 2 1258 RideSt
C 3 797 BdRk1St
C3 1029 SdRkStk2St
D 3 992 SdRkOp1St
D3 752 ClapT9
E 3 995 SdRkMte1St
F 3 1236 TomRkLoSt
F3 1161 HHClRkStSw
G 3 1236 TomRkLoSt
G3 1176 HHPdlRkSt
A 3 1233 TomRkMdSt
A3 1181 HHHfOpRkSt
B 3 1233 TomRkMdSt
C 4 1230 TomRkHiSt
C4 1253 CrashSt
D 4 1230 TomRkHiSt
D4 1259 RideL
E 4 1267 ChinaSt
F 4 1261 CupSt
F4 715 TambrnHit
G 4 1271 SplashSt
G4 747 MamboBel
A 4 1253 CrashSt
A4 711 ShekereDw
B 4 1260 RideR
C 5 773 BdFkSt1-2
C5 1026 SdRkStk1St
D 5 998 SdRkRim1St
D5 1010 SdRkFlmSt
E 5 1007 SdRkRim2St
F 5 1227 TomFlSt
F5 1135 HHCl4St
G 5 1224 TomLoSt
G5 1146 HHPdlSt
A 5 1221 TomMdSt
A5 1158 HHOp2St
B 5 1221 TomMdSt
C 6 1218 TomHiSt
Note Wave
No. Wave Name
C 0 822 BdT8-3
C0 1081 SdT8Rim
D 0 1121 SdDodgL
D0 752 ClapT9
E 0 1101 SdHip3
F 0 822 BdT8-3
F0 1206 HHClTek
G 0 822 BdT8-3
G0 1207 HHOpTek
A 0 822 BdT8-3
A0 1207 HHOpTek
B 0 822 BdT8-3
C 1 836 BdHipDp
C1 1035 SdHpStk4
D 1 1103 SdHipRm1
D1 744 HandClapR
E 1 1100 SdHip2
F 1 1247 TomT8
F1 1195 HHClT8-2
G 1 1247 TomT8
G1 1199 HHOpAnCR
A 1 1247 TomT8
A1 1194 HHOpT8-1
B 1 1247 TomT8
C 2 1247 TomT8
C2 1274 CrashT9
D 2 1247 TomT8
D2 1276 CrashSyn
E 2 1276 CrashSyn
F 2 1275 CrashT8
F2 759 TambrnRX5
G 2 1273 SplashR
G2 755 CowBelT8
A 2 1274 CrashT9
A2 757 CowBelAnCR
B 2 1277 RideT9
C 3 836 BdHipDp
C3 1036 SdHpStk5
D 3 1104 SdHipRm2
D3 743 HandClapL
E 3 1099 SdHip1
F 3 1246 TomT9Lo
F3 1197 HHClRX5
G 3 1246 TomT9Lo
G3 1198 HHClAnCR
A 3 1246 TomT9Lo
A3 1196 HHOpT8-2
B 3 1246 TomT9Lo
C 4 1245 TomT9Hi
C4 1255 CrashR
D 4 1245 TomT9Hi
D4 1275 CrashT8
E 4 1276 CrashSyn
F 4 1275 CrashT8
F4 715 TambrnHit
G 4 1269 ChinaR
G4 756 CowBelRX11
A 4 1254 CrashL
A4 745 Cowbel1
B 4 1260 RideR
C 5 836 BdHipDp
C5 1041 SdHipStk8
D 5 1102 SdHipGate
D5 1100 SdHip2
E 5 1107 SdHipRm5
F 5 1252 TomDistLo
F5 1208 HHClHip
G 5 1252 TomDistLo
G5 1209 HHPdlHip
A 5 1251 TomDistHi
A5 1210 HHOpHip
B 5 1251 TomDistHi
C 6 1250 TomAnSm
Note Wave
No. Wave Name
C 0 367 Wataiko
C0 377 Udo Hi
D 0 370 DjembeOp
D0 667 QuintTip
E 0 378 Udo Low
F 0 376 UdoFinger
F0 377 Udo Hi
G 0 372 TabraBya
G0 721 TmbourimOp
A 0 374 TablaMut
A0 373 TabraNah
B 0 374 TablaMut
C 1 92 Timpani
C1 543 Hit Uhh
D 1 594 PickNoise1
D1 752 ClapT9
E 1 741 TriangleMt
F 1 740 TriangleOp
F1 734 Castanet
G 1 734 Castanet
G1 734 Castanet
A 1 727 GuiroLong
A1 728 GuiroShort
B 1 729 GuiroSwp
C 2 737 Vibraslap
C2 735 Clave
D 2 762 ClaveT8
D2 673 CuicaLo
E 2 674 CuicaHi
F 2 687 TmbaleL1-3
F2 736 WoodBlock
G 2 689 TimbaleLo2
G2 736 WoodBlock
A 2 683 TmbaleH1-3
A2 749 ChaCha
B 2 685 TimbaleHi2
C 3 691 TmblPailaL
C3 691 TmblPailaL
D 3 690 TmblPailaH
D3 747 MamboBel
E 3 679 BongoLo1-3
F 3 682 BongoLo3
F3 745 Cowbel1
G 3 675 BongoHi1-2
G3 746 Cowbell2
A 3 678 BongoHHeel
A3 725 AgogoLo
B 3 724 AgogoHi
C 4 672 TumbaHeel
C4 671 TumbaTip
D 4 670 TumbaSlp
D4 696 MaracasSlr
E 4 669 TumbaOp
F 4 664 CongaHeel
F4 663 CongaTip
G 4 662 CongaSlp
G4 705 Shaker1
A 4 661 CongaOp
A4 699 Cabasa1
B 4 698 Cabasa1-2
C 5 668 QuintHeel
C5 667 QuintTip
D 5 666 QuintSlp
D5 706 Shaker2
E 5 665 QuintOp
F 5 702 Caxixi1
F5 716 TambrnShk
G 5 715 TambrnHit
G5 714 TambrnSw
A 5 715 TambrnHit
A5 750 SleighBel
B 5 738 Whistle
C 6 738 Whistle
MR_DL1.book Page 17 Monday, January 6, 2003 11:10 AM
18
PRE 36 Latin Perc PRE 37 Gtr/Bs Fx PRE 38 Wacko Kit PRE 39 Wood Bits PRE 40 Metal Bits
Note Wave
No. Wave Name
C 0 791 BdLSonSt
C0 1029 SdRkStk2St
D 0 883 SdFkSt1/3
D0 1253 CrashSt
E 0 1271 SplashSt
F 0 1224 TomLoSt
F0 1131 HHClSt1-4
G 0 1224 TomLoSt
G0 1146 HHPdlSt
A 0 1221 TomMdSt
A0 1149 HHOpSt
B 0 1218 TomHiSt
C 1 671 TumbaTip
C1 672 TumbaHeel
D 1 670 TumbaSlp
D1 735 Clave
E 1 669 TumbaOp
F 1 663 CongaTip
F1 664 CongaHeel
G 1 662 CongaSlp
G1 749 ChaCha
A 1 661 CongaOp
A1 748 MamboBdy
B 1 747 MamboBel
C 2 667 QuintTip
C2 668 QuintHeel
D 2 666 QuintSlp
D2 749 ChaCha
E 2 665 QuintOp
F 2 680 BongoLo1
F2 678 BongoHHeel
G 2 676 BongoHi1
G2 688 TimbaleLo1
A 2 691 TmblPailaL
A2 684 TimbaleHi1
B 2 690 TmblPailaH
C 3 736 WoodBlock
C3 736 WoodBlock
D 3 711 ShekereDw
D3 712 ShekereUp
E 3 713 ShekereSap
F 3 696 MaracasSlr
F3 697 MaracasStc
G 3 727 GuiroLong
G3 728 GuiroShort
A 3 729 GuiroSwp
A3 731 SurdoMt
B 3 730 SurdoOp
C 4 719 PandierTip
C4 720 PandroHeel
D 4 718 PandierThm
D4 717 PandieroOp
E 4 722 TmbourmFng
F 4 723 TmbourimMt
F4 721 TmbourimOp
G 4 726 AgogoLoTap
G4 725 AgogoLo
A 4 724 AgogoHi
A4 740 TriangleOp
B 4 741 TriangleMt
C 5 692 GanzaAc
C5 693 GanzaBk
D 5 694 GanzaFw
D5 699 Cabasa1
E 5 700 Cabasa2
F 5 702 Caxixi1
F5 703 Caxixi2
G 5 673 CuicaLo
G5 674 CuicaHi
A 5 738 Whistle
A5 738 Whistle
B 5 737 Vibraslap
C 6 751 BellTree
Note Wave
No. Wave Name
C 0 618 PlayFxABa8
C0 618 PlayFxABa8
D 0 601 PlayFxGt4
D0 188 PwrChdMono
E 0 188 PwrChdMono
F 0 619 PlayFxABa9
F0 595 PickNoise2
G 0 616 PlayFxABa6
G0 595 PickNoise2
A 0 616 PlayFxABa6
A0 604 PlayFxGt7
B 0 622 PlyFxSlp1H
C 1 643 PlyFxSl12S
C1 614 PlayFxABa4
D 1 600 PlayFxGt3
D1 619 PlayFxABa9
E 1 602 PlayFxGt5
F 1 623 PlyFxSlp2S
F1 595 PickNoise2
G 1 623 PlyFxSlp2S
G1 595 PickNoise2
A 1 623 PlyFxSlp2S
A1 597 FretNoise
B 1 623 PlyFxSlp2S
C 2 623 PlyFxSlp2S
C2 657 PlyFxSl19S
D 2 623 PlyFxSlp2S
D2 595 PickNoise2
E 2 657 PlyFxSl19S
F 2 595 PickNoise2
F2 624 PlyFxSlp2H
G 2 657 PlyFxSl19S
G2 609 PlayFxGt12
A 2 657 PlyFxSl19S
A2 655 PlyFxSl18S
B 2 595 PickNoise2
C 3 614 PlayFxABa4
C3 614 PlayFxABa4
D 3 612 PlayFxABa2
D3 613 PlayFxABa3
E 3 611 PlayFxABa1
F 3 618 PlayFxABa8
F3 618 PlayFxABa8
G 3 618 PlayFxABa8
G3 618 PlayFxABa8
A 3 603 PlayFxGt6
A3 601 PlayFxGt4
B 3 610 PlayFxGt13
C 4 609 PlayFxGt12
C4 615 PlayFxABa5
D 4 616 PlayFxABa6
D4 594 PickNoise1
E 4 594 PickNoise1
F 4 596 PickNoise3
F4 604 PlayFxGt7
G 4 605 PlayFxGt8
G4 595 PickNoise2
A 4 595 PickNoise2
A4 600 PlayFxGt3
B 4 655 PlyFxSl18S
C 5 606 PlayFxGt9
C5 607 PlayFxGt10
D 5 608 PlayFxGt11
D5 598 PlayFxGt1
E 5 599 PlayFxGt2
F 5 600 PlayFxGt3
F5 601 PlayFxGt4
G 5 653 PlyFxSl17S
G5 634 PlyFxSlp7H
A 5 633 PlyFxSlp7S
A5 656 PlyFxSl18H
B 5 657 PlyFxSl19S
C 6 659 PlyFxSl20S
Note Wave
No. Wave Name
C 0 630 PlyFxSlp5H
C0 594 PickNoise1
D 0 1203 HHPdlD&B
D0 743 HandClapL
E 0 584 ScratchVoF
F 0 548 IndusTom
F0 1127 SdWood
G 0 548 IndusTom
G0 1117 SdClpAna
A 0 548 IndusTom
A0 1123 SdFMRim
B 0 812 BdFXGate
C 1 849 BdFxHmr
C1 614 PlayFxABa4
D 1 1122 SdFM
D1 743 HandClapL
E 1 1126 SdTimber
F 1 1249 TomSyn2
F1 1213 HHClSyn
G 1 1249 TomSyn2
G1 1214 HHOpSyn
A 1 1249 TomSyn2
A1 1214 HHOpSyn
B 1 1249 TomSyn2
C 2 1249 TomSyn2
C2 1189 HHOpMono
D 2 534 Sonar1
D2 1194 HHOpT8-1
E 2 1189 HHOpMono
F 2 1262 CupL
F2 750 SleighBel
G 2 1196 HHOpT8-2
G2 531 ResoXFade
A 2 1254 CrashL
A2 572 RainLoop
B 2 1263 CupR
C 3 516 AirHoseL
C3 516 AirHoseL
D 3 377 Udo Hi
D3 426 MgBass2
E 3 427 MgBass3
F 3 618 PlayFxABa8
F3 618 PlayFxABa8
G 3 725 AgogoLo
G3 725 AgogoLo
A 3 1217 HHOpHuman
A3 554 VoxHitRev
B 3 552 HiQ1
C 4 552 HiQ1
C4 533 LfoSeq
D 4 533 LfoSeq
D4 505 BellAir
E 4 511 HH Hit
F 4 511 HH Hit
F4 525 OohFB
G 4 525 OohFB
G4 528 Mind Bell
A 4 547 Glass
A4 519 Swarm
B 4 557 FxGun2
C 5 521 Lektronica
C5 609 PlayFxGt12
D 5 570 Gunshot
D5 561 Police
E 5 546 Ripper
F 5 604 PlayFxGt7
F5 556 TapeRewnd
G 5 558 FxGun1
G5 555 Bomb
A 5 551 Zap2
A5 549 NzBurst
B 5 539 StabGiant
C 6 538 StabOrch
Note Wave
No. Wave Name
C 0 762 ClaveT8
C0 1038 SdHpStk6L
D 0 727 GuiroLong
D0 1039 SdHpStk6R
E 0 727 GuiroLong
F 0 619 PlayFxABa9
F0 734 Castanet
G 0 618 PlayFxABa8
G0 732 Stick
A 0 617 PlayFxABa7
A0 614 PlayFxABa4
B 0 1245 TomT9Hi
C 1 596 PickNoise3
C1 1046 SdClRim3
D 1 733 Stick2
D1 727 GuiroLong
E 1 733 Stick2
F 1 614 PlayFxABa4
F1 1083 SdAnSmRim
G 1 614 PlayFxABa4
G1 753 ClapAnSm
A 1 614 PlayFxABa4
A1 737 Vibraslap
B 1 614 PlayFxABa4
C 2 614 PlayFxABa4
C2 565 Seashore
D 2 614 PlayFxABa4
D2 1029 SdRkStk2St
E 2 571 Applause
F 2 1027 SdRkStk1L
F2 716 TambrnShk
G 2 565 Seashore
G2 736 WoodBlock
A 2 571 Applause
A2 564 Helicopter
B 2 1031 SdRkStk2R
C 3 613 PlayFxABa3
C3 613 PlayFxABa3
D 3 734 Castanet
D3 734 Castanet
E 3 736 WoodBlock
F 3 691 TmblPailaL
F3 691 TmblPailaL
G 3 732 Stick
G3 733 Stick2
A 3 701 Caxixi1-2
A3 703 Caxixi2
B 3 562 DoorSqk
C 4 562 DoorSqk
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 562 DoorSqk
G 4 562 DoorSqk
G4 736 WoodBlock
A 4 735 Clave
A4 562 DoorSqk
B 4 743 HandClapL
C 5 749 ChaCha
C5 1001 SdRkOp2St
D 5 831 BdJngl3
D5 666 QuintSlp
E 5 809 BdRoom2
F 5 788 BdHSonSt
F5 1024 SdHeavy
G 5 614 PlayFxABa4
G5 1026 SdRkStk1St
A 5 859 BdSlimy
A5 1019 SdGate1
B 5 794 BdFkSonSt
C 6 811 BdGate
Note Wave
No. Wave Name
C 0 755 CowBelT8
C0 1145 HHCl4R
D 0 1263 CupR
D0 1214 HHOpSyn
E 0 1262 CupL
F 0 1261 CupSt
F0 446 FMMetal2
G 0 1258 RideSt
G0 1258 RideSt
A 0 746 Cowbell2
A0 1132 HHCl1St
B 0 749 ChaCha
C 1 746 Cowbell2
C1 1213 HHClSyn
D 1 1207 HHOpTek
D1 1195 HHClT8-2
E 1 1197 HHClRX5
F 1 746 Cowbell2
F1 1194 HHOpT8-1
G 1 746 Cowbell2
G1 1213 HHClSyn
A 1 746 Cowbell2
A1 1214 HHOpSyn
B 1 746 Cowbell2
C 2 746 Cowbell2
C2 1216 HHOpFx
D 2 746 Cowbell2
D2 1261 CupSt
E 2 1199 HHOpAnCR
F 2 1261 CupSt
F2 714 TambrnSw
G 2 1216 HHOpFx
G2 747 MamboBel
A 2 1216 HHOpFx
A2 750 SleighBel
B 2 1264 RideMono
C 3 78 Vibraphone
C3 78 Vibraphone
D 3 82 Tubular
D3 83 Bell
E 3 86 BrBell
F 3 690 TmblPailaH
F3 691 TmblPailaL
G 3 83 Bell
G3 83 Bell
A 3 1132 HHCl1St
A3 1199 HHOpAnCR
B 3 505 BellAir
C 4 504 WindChime
C4 1184 HHOpRkL
D 4 521 Lektronica
D4 725 AgogoLo
E 4 745 Cowbel1
F 4 746 Cowbell2
F4 513 HiLo
G 4 513 HiLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 504 WindChime
B 4 750 SleighBel
C 5 751 BellTree
C5 87 SmBell
D 5 87 SmBell
D5 86 BrBell
E 5 88 Hibasi
F 5 76 Harpsicord
F5 1021 SdLdwHMono
G 5 78 Vibraphone
G5 1022 SdBrRim
A 5 358 Gamelan2
A5 376 UdoFinger
B 5 89 FingerCym
C 6 83 Bell
MR_DL1.book Page 18 Monday, January 6, 2003 11:10 AM
19
PRE 41 Hands Kit PRE 42 Scratches PRE 43 AcstSnares PRE 44 StSnares PRE 45 AllKicks
Note Wave
No. Wave Name
C 0 374 TablaMut
C0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 657 PlyFxSl19S
F0 614 PlayFxABa4
G 0 718 PandierThm
G0 374 TablaMut
A 0 648 PlyFxSl14H
A0 614 PlayFxABa4
B 0 375 TabraCmb
C 1 367 Wataiko
C1 667 QuintTip
D 1 1060 SdBrMt2St
D1 742 HandClapSt
E 1 895 SdFkAySt
F 1 378 Udo Low
F1 374 TablaMut
G 1 378 Udo Low
G1 372 TabraBya
A 1 377 Udo Hi
A1 373 TabraNah
B 1 377 Udo Hi
C 2 376 UdoFinger
C2 1260 RideR
D 2 376 UdoFinger
D2 1261 CupSt
E 2 1266 CupMono2
F 2 1261 CupSt
F2 715 TambrnHit
G 2 1261 CupSt
G2 745 Cowbel1
A 2 1264 RideMono
A2 737 Vibraslap
B 2 1259 RideL
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 722 TmbourmFng
A3 722 TmbourmFng
B 3 743 HandClapL
C 4 743 HandClapL
C4 727 GuiroLong
D 4 727 GuiroLong
D4 376 UdoFinger
E 4 372 TabraBya
F 4 663 CongaTip
F4 377 Udo Hi
G 4 377 Udo Hi
G4 376 UdoFinger
A 4 89 FingerCym
A4 374 TablaMut
B 4 750 SleighBel
C 5 751 BellTree
C5 614 PlayFxABa4
D 5 613 PlayFxABa3
D5 613 PlayFxABa3
E 5 612 PlayFxABa2
F 5 613 PlayFxABa3
F5 618 PlayFxABa8
G 5 669 TumbaOp
G5 611 PlayFxABa1
A 5 617 PlayFxABa7
A5 378 Udo Low
B 5 371 DjembeCmb
C 6 670 TumbaSlp
Note Wave
No. Wave Name
C 0 573 Scratch H
C0 574 Scratch L
D 0 575 ScratchDwn
D0 576 ScratchHiF
E 0 577 ScratchHiR
F 0 578 ScratchLoF
F0 579 ScratchLoR
G 0 580 ScratchBdF
G0 581 ScratchBdR
A 0 582 ScratchSdF
A0 583 ScratchSdR
B 0 584 ScratchVoF
C 1 573 Scratch H
C1 574 Scratch L
D 1 575 ScratchDwn
D1 576 ScratchHiF
E 1 577 ScratchHiR
F 1 578 ScratchLoF
F1 579 ScratchLoR
G 1 580 ScratchBdF
G1 581 ScratchBdR
A 1 582 ScratchSdF
A1 583 ScratchSdR
B 1 584 ScratchVoF
C 2 585 ScratchVoR
C2 586 ScratchStp
D 2 587 ScratchSpn
D2 588 ScrathcHip
E 2 589 ScratchHp2
F 2 590 ScratchCmb
F2 591 ScratchCb2
G 2 592 ScratchCb3
G2 593 ScratchCb4
A 2 573 Scratch H
A2 574 Scratch L
B 2 575 ScratchDwn
C 3 576 ScratchHiF
C3 577 ScratchHiR
D 3 578 ScratchLoF
D3 579 ScratchLoR
E 3 580 ScratchBdF
F 3 581 ScratchBdR
F3 582 ScratchSdF
G 3 583 ScratchSdR
G3 584 ScratchVoF
A 3 585 ScratchVoR
A3 586 ScratchStp
B 3 587 ScratchSpn
C 4 588 ScrathcHip
C4 589 ScratchHp2
D 4 590 ScratchCmb
D4 591 ScratchCb2
E 4 592 ScratchCb3
F 4 593 ScratchCb4
F4 573 Scratch H
G 4 574 Scratch L
G4 575 ScratchDwn
A 4 576 ScratchHiF
A4 577 ScratchHiR
B 4 578 ScratchLoF
C 5 579 ScratchLoR
C5 580 ScratchBdF
D 5 581 ScratchBdR
D5 582 ScratchSdF
E 5 583 ScratchSdR
F 5 584 ScratchVoF
F5 585 ScratchVoR
G 5 586 ScratchStp
G5 587 ScratchSpn
A 5 588 ScrathcHip
A5 589 ScratchHp2
B 5 590 ScratchCmb
C 6 591 ScratchCb2
Note Wave
No. Wave Name
C 0 866 SdNm1St
C0 867 SdNm2St
D 0 868 SdNm3St
D0 869 SdNm4St
E 0 884 SdFk1St
F 0 885 SdFk2St
F0 886 SdFk3St
G 0 895 SdFkAySt
G0 902 SdBs1St
A 0 903 SdBs2St
A0 904 SdBs3St
B 0 919 SdSon1St
C 1 920 SdSon2St
C1 921 SdSon3St
D 1 922 SdSon4St
D1 937 SdBl1St
E 1 938 SdBl2St
F 1 939 SdBl3St
F1 952 SdBh1St
G 1 953 SdBh2St
G1 954 SdBh3St
A 1 969 SdLdw1St
A1 970 SdLdw2St
B 1 971 SdLdw3St
C 2 972 SdLdw4St
C2 984 SdHip1St
D 2 985 SdHip2St
D2 992 SdRkOp1St
E 2 995 SdRkMte1St
F 2 998 SdRkRim1St
F2 1001 SdRkOp2St
G 2 1004 SdRkMte2St
G2 1007 SdRkRim2St
A 2 1010 SdRkFlmSt
A2 992 SdRkOp1St
B 2 995 SdRkMte1St
C 3 998 SdRkRim1St
C3 1001 SdRkOp2St
D 3 1004 SdRkMte2St
D3 1007 SdRkRim2St
E 3 1010 SdRkFlmSt
F 3 868 SdNm3St
F3 895 SdFkAySt
G 3 904 SdBs3St
G3 921 SdSon3St
A 3 954 SdBh3St
A3 971 SdLdw3St
B 3 980 SdLdw3R
C 4 1013 SdPicol
C4 1014 SdPcRim
D 4 1015 SdPcRim2
D4 1016 SdMid
E 4 1017 SdMdRim
F 4 1018 SdAmb
F4 1019 SdGate1
G 4 1021 SdLdwHMono
G4 1022 SdBrRim
A 4 1023 SdDry
A4 1024 SdHeavy
B 4 1025 SdGM
C 5 1026 SdRkStk1St
C5 1029 SdRkStk2St
D 5 1042 SdClRmSt
D5 1045 SdClRim2
E 5 1046 SdClRim3
F 5 1047 SdRkRolSt
F5 1001 SdRkOp2St
G 5 1053 SnLvRolSt
G5 920 SdSon2St
A 5 1056 SdRollMono
A5 971 SdLdw3St
B 5 1057 SdBrMtSt
C 6 1066 SdBSwrAtSt
Note Wave
No. Wave Name
C 0 860 SdNmSt1-4
C0 861 SdNmSt1-3
D 0 862 SdNmSt2-4
D0 863 SdNmSt1-2
E 0 864 SdNmSt2-3
F 0 865 SdNmSt3-4
F0 866 SdNm1St
G 0 867 SdNm2St
G0 868 SdNm3St
A 0 869 SdNm4St
A0 880 SdFkSt1-3
B 0 881 SdFkSt1-2
C 1 882 SdFkSt2-3
C1 883 SdFkSt1/3
D 1 884 SdFk1St
D1 885 SdFk2St
E 1 886 SdFk3St
F 1 895 SdFkAySt
F1 898 SdBsSt1-3
G 1 899 SdBsSt1-2
G1 900 SdBsSt2-3
A 1 901 SdBsSt1/3
A1 902 SdBs1St
B 1 903 SdBs2St
C 2 904 SdBs3St
C2 913 SdSonSt1-4
D 2 914 SdSonSt1-3
D2 915 SdSonSt2-4
E 2 916 SdSonSt1-2
F 2 917 SdSonSt2-3
F2 918 SdSonSt3-4
G 2 919 SdSon1St
G2 920 SdSon2St
A 2 921 SdSon3St
A2 922 SdSon4St
B 2 933 SdBlSt1-3
C 3 934 SdBlSt1-2
C3 935 SdBlSt2-3
D 3 936 SdBlSt1/3
D3 937 SdBl1St
E 3 938 SdBl2St
F 3 939 SdBl3St
F3 948 SdBhSt1-3
G 3 949 SdBhSt1-2
G3 950 SdBhSt2-3
A 3 951 SdBhSt1/3
A3 952 SdBh1St
B 3 953 SdBh2St
C 4 954 SdBh3St
C4 963 SdLdwSt1-4
D 4 964 SdLdwSt1-3
D4 965 SdLdwSt2-4
E 4 966 SdLdwSt1-2
F 4 967 SdLdwSt2-3
F4 968 SdLdwSt3-4
G 4 969 SdLdw1St
G4 970 SdLdw2St
A 4 971 SdLdw3St
A4 972 SdLdw4St
B 4 984 SdHip1St
C 5 992 SdRkOp1St
C5 995 SdRkMte1St
D 5 998 SdRkRim1St
D5 1001 SdRkOp2St
E 5 1004 SdRkMte2St
F 5 1007 SdRkRim2St
F5 1010 SdRkFlmSt
G 5 1047 SdRkRolSt
G5 992 SdRkOp1St
A 5 1050 SdRkRolDSt
A5 1001 SdRkOp2St
B 5 1053 SnLvRolSt
C 6 868 SdNm3St
Note Wave
No. Wave Name
C 0 764 BdNmSt1-2
C0 765 BdNm1St
D 0 766 BdNm2St
D0 767 BdNmL1-2
E 0 773 BdFkSt1-2
F 0 774 BdFk1St
F0 775 BdFk2St
G 0 782 BdHiSt
G0 785 BdLoSt
A 0 788 BdHSonSt
A0 791 BdLSonSt
B 0 794 BdFkSonSt
C 1 797 BdRk1St
C1 800 BdRk2St
D 1 803 BdDry1
D1 804 BdDry2
E 1 805 BdPop
F 1 806 BdVar1
F1 807 BdVar2
G 1 808 BdRoom1
G1 809 BdRoom2
A 1 810 BdRoom3
A1 811 BdGate
B 1 812 BdFXGate
C 2 813 BdT9-1
C2 814 BdT9-2
D 2 815 BdT9-3
D2 816 BdT9-4
E 2 817 BdT9Hd1
F 2 818 BdT9Hd2
F2 819 BdT9Hd3
G 2 820 BdT8-1
G2 821 BdT8-2
A 2 822 BdT8-3
A2 823 BdAnSm
B 2 824 BdAnCR
C 3 825 BdHuman1
C3 826 BdHuman2
D 3 827 BdBlip
D3 828 BdBlpHd
E 3 829 BdJngl1
F 3 830 BdJngl2
F3 831 BdJngl3
G 3 832 BdD&B1
G3 833 BdD&B2
A 3 834 BdR&B1
A3 835 BdR&B2
B 3 836 BdHipDp
C 4 837 BdBrkDp
C4 838 BdBreak1
D 4 839 BdBreak2
D4 840 BdBreakHvy
E 4 841 BdBreakHrd
F 4 842 BdDist1
F4 843 BdDist2
G 4 844 BdDist3
G4 845 BdDist4
A 4 846 BdDist5
A4 847 BdDistRM
B 4 848 Bd+HH
C 5 849 BdFxHmr
C5 850 BdZapHrd
D 5 851 BdZapMid
D5 852 BdSus
E 5 853 BdTekPower
F 5 854 BdHardLong
F5 855 BdATite
G 5 856 BdAnHard
G5 857 BdLofi
A 5 858 BdThkSkn
A5 859 BdSlimy
B 5 859 BdSlimy
C 6 859 BdSlimy
MR_DL1.book Page 19 Monday, January 6, 2003 11:10 AM
20
PRE 46 DanceKicks PRE 47 Snare & Fx PRE 48 EasySnares USER 1 RockMono2 USER 2 RockMono3
Note Wave
No. Wave Name
C 0 813 BdT9-1
C0 813 BdT9-1
D 0 814 BdT9-2
D0 815 BdT9-3
E 0 815 BdT9-3
F 0 816 BdT9-4
F0 817 BdT9Hd1
G 0 818 BdT9Hd2
G0 819 BdT9Hd3
A 0 819 BdT9Hd3
A0 854 BdHardLong
B 0 824 BdAnCR
C 1 813 BdT9-1
C1 814 BdT9-2
D 1 815 BdT9-3
D1 816 BdT9-4
E 1 817 BdT9Hd1
F 1 818 BdT9Hd2
F1 819 BdT9Hd3
G 1 820 BdT8-1
G1 821 BdT8-2
A 1 822 BdT8-3
A1 823 BdAnSm
B 1 824 BdAnCR
C 2 825 BdHuman1
C2 826 BdHuman2
D 2 827 BdBlip
D2 828 BdBlpHd
E 2 829 BdJngl1
F 2 830 BdJngl2
F2 831 BdJngl3
G 2 832 BdD&B1
G2 833 BdD&B2
A 2 834 BdR&B1
A2 835 BdR&B2
B 2 836 BdHipDp
C 3 837 BdBrkDp
C3 838 BdBreak1
D 3 839 BdBreak2
D3 840 BdBreakHvy
E 3 841 BdBreakHrd
F 3 842 BdDist1
F3 843 BdDist2
G 3 844 BdDist3
G3 845 BdDist4
A 3 846 BdDist5
A3 847 BdDistRM
B 3 848 Bd+HH
C 4 849 BdFxHmr
C4 850 BdZapHrd
D 4 851 BdZapMid
D4 852 BdSus
E 4 853 BdTekPower
F 4 854 BdHardLong
F4 855 BdATite
G 4 856 BdAnHard
G4 857 BdLofi
A 4 858 BdThkSkn
A4 859 BdSlimy
B 4 811 BdGate
C 5 812 BdFXGate
C5 813 BdT9-1
D 5 814 BdT9-2
D5 815 BdT9-3
E 5 816 BdT9-4
F 5 817 BdT9Hd1
F5 818 BdT9Hd2
G 5 819 BdT9Hd3
G5 828 BdBlpHd
A 5 835 BdR&B2
A5 851 BdZapMid
B 5 854 BdHardLong
C 6 855 BdATite
Note Wave
No. Wave Name
C 0 1113 SdFx1
C0 1114 SdFx2
D 0 1115 SdFx3
D0 1116 SdFx4
E 0 1118 SdDist
F 0 1119 SdCut
F0 1120 SdDodgH
G 0 1121 SdDodgL
G0 1122 SdFM
A 0 1124 SdSyn
A0 1128 SdHammer
B 0 1129 SdLofi
C 1 1069 SdT9-1
C1 1070 SdT9-2
D 1 1071 SdT9-3
D1 1072 SdT9-4
E 1 1073 SdT9-5
F 1 1074 SdT9Gate
F1 1076 SdT8-1
G 1 1077 SdT8-2
G1 1078 SdT8-3
A 1 1079 SdT8-4
A1 1080 SdT8-5
B 1 1082 SdAnSm
C 2 1084 SdAnCR
C2 1086 SdHuman1
D 2 1088 SdJngl1
D2 1089 SdJngl2
E 2 1090 SdJngl3
F 2 1091 SdJnglFx
F2 1092 SdD&B1
G 2 1093 SdD&B2
G2 1094 SdD&B3
A 2 1095 SdD&B4
A2 1096 SdR&B1
B 2 1097 SdR&B1Rm
C 3 1098 SdR&B2
C3 1099 SdHip1
D 3 1100 SdHip2
D3 1101 SdHip3
E 3 1102 SdHipGate
F 3 1103 SdHipRm1
F3 1104 SdHipRm2
G 3 1105 SdHipRm3
G3 1106 SdHipRm4
A 3 1107 SdHipRm5
A3 1109 SdBreak2
B 3 1111 SdBreakHvy
C 4 598 PlayFxGt1
C4 602 PlayFxGt5
D 4 609 PlayFxGt12
D4 611 PlayFxABa1
E 4 618 PlayFxABa8
F 4 596 PickNoise3
F4 573 Scratch H
G 4 574 Scratch L
G4 575 ScratchDwn
A 4 576 ScratchHiF
A4 586 ScratchStp
B 4 587 ScratchSpn
C 5 546 Ripper
C5 549 NzBurst
D 5 550 Zap1
D5 551 Zap2
E 5 552 HiQ1
F 5 553 HiQ2
F5 555 Bomb
G 5 558 FxGun1
G5 510 Electer
A 5 511 HH Hit
A5 520 Mother
B 5 544 HitOrch2
C 6 539 StabGiant
Note Wave
No. Wave Name
C 0
C0
D 0
D0
E 0
F 0
F0
G 0
G0
A 0
A0
B 0
C 1 1053 SnLvRolSt
C1 1066 SdBSwrAtSt
D 1 1063 SdBrSwrSt
D1 1060 SdBrMt2St
E 1 1057 SdBrMtSt
F 1 1042 SdClRmSt
F1 1042 SdClRmSt
G 1 884 SdFk1St
G1 884 SdFk1St
A 1 884 SdFk1St
A1 885 SdFk2St
B 1 885 SdFk2St
C 2 886 SdFk3St
C2 886 SdFk3St
D 2 937 SdBl1St
D2 938 SdBl2St
E 2 938 SdBl2St
F 2 939 SdBl3St
F2 939 SdBl3St
G 2 866 SdNm1St
G2 867 SdNm2St
A 2 867 SdNm2St
A2 868 SdNm3St
B 2 868 SdNm3St
C 3 869 SdNm4St
C3 869 SdNm4St
D 3 984 SdHip1St
D3 984 SdHip1St
E 3 984 SdHip1St
F 3 985 SdHip2St
F3 985 SdHip2St
G 3 919 SdSon1St
G3 920 SdSon2St
A 3 920 SdSon2St
A3 921 SdSon3St
B 3 921 SdSon3St
C 4 922 SdSon4St
C4 922 SdSon4St
D 4 902 SdBs1St
D4 903 SdBs2St
E 4 903 SdBs2St
F 4 904 SdBs3St
F4 904 SdBs3St
G 4 969 SdLdw1St
G4 970 SdLdw2St
A 4 970 SdLdw2St
A4 971 SdLdw3St
B 4 971 SdLdw3St
C 5 972 SdLdw4St
C5 972 SdLdw4St
D 5 952 SdBh1St
D5 953 SdBh2St
E 5 953 SdBh2St
F 5 954 SdBh3St
F5 954 SdBh3St
G 5 742 HandClapSt
G5 752 ClapT9
A 5 753 ClapAnSm
A5 732 Stick
B 5 733 Stick2
C 6 895 SdFkAySt
Note Wave
No. Wave Name
C 0 763 AnaClick
C0 1058 SdBrMtL
D 0 1064 SdBrSwrL
D0 1061 SdBrMt2L
E 0 1067 SdBrSwrAtL
F 0 1054 SnLvRolL
F0 734 Castanet
G 0 978 SdLdw2R
G0 732 Stick
A 0 805 BdPop
A0 981 SdLdw4L
B 0 772 BdNm2R
C 1 803 BdDry1
C1 1044 SdClRmR
D 1 941 SdBlR1-3
D1 743 HandClapL
E 1 974 SdLdwR1-4
F 1 1237 TomRkLoL
F1 1175 HHClRk2R
G 1 1237 TomRkLoL
G1 1178 HHPdlRkR
A 1 1234 TomRkMdL
A1 1185 HHOpRkR
B 1 1234 TomRkMdL
C 2 1232 TomRkHiR
C2 1254 CrashL
D 2 1232 TomRkHiR
D2 1260 RideR
E 2 1269 ChinaR
F 2 1263 CupR
F2 759 TambrnRX5
G 2 1273 SplashR
G2 745 Cowbel1
A 2 1254 CrashL
A2 737 Vibraslap
B 2 1264 RideMono
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1030 SdRkStk2L
D 5 1017 SdMdRim
D5 991 SdHip2R
E 5 1016 SdMid
F 5 808 BdRoom1
F5 979 SdLdw3L
G 5 836 BdHipDp
G5 982 SdLdw4R
A 5 790 BdHSonR
A5 993 SdRkOp1L
B 5 805 BdPop
C 6 809 BdRoom2
Note Wave
No. Wave Name
C 0 763 AnaClick
C0 1058 SdBrMtL
D 0 1064 SdBrSwrL
D0 1061 SdBrMt2L
E 0 1067 SdBrSwrAtL
F 0 1054 SnLvRolL
F0 734 Castanet
G 0 973 SdLdwL1-4
G0 732 Stick
A 0 803 BdDry1
A0 1017 SdMdRim
B 0 807 BdVar2
C 1 810 BdRoom3
C1 1044 SdClRmR
D 1 1016 SdMid
D1 743 HandClapL
E 1 1024 SdHeavy
F 1 1242 TmDryLo
F1 1188 HHClMono
G 1 1242 TmDryLo
G1 1190 HHPdlMono
A 1 1241 TomDryHi
A1 1189 HHOpMono
B 1 1241 TomDryHi
C 2 1241 TomDryHi
C2 1254 CrashL
D 2 1241 TomDryHi
D2 1260 RideR
E 2 1267 ChinaSt
F 2 1263 CupR
F2 759 TambrnRX5
G 2 1273 SplashR
G2 745 Cowbel1
A 2 1254 CrashL
A2 737 Vibraslap
B 2 1264 RideMono
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1032 SdHpStk1
D 5 1024 SdHeavy
D5 1013 SdPicol
E 5 1021 SdLdwHMono
F 5 802 BdRk2R
F5 1017 SdMdRim
G 5 835 BdR&B2
G5 1019 SdGate1
A 5 773 BdFkSt1-2
A5 1014 SdPcRim
B 5 778 BdFkML
C 6 809 BdRoom2
MR_DL1.book Page 20 Monday, January 6, 2003 11:10 AM
21
USER 3 Hip Hop5 USER 4 Hip Hop6 USER 5 T9HipKit2 USER 6 HipStick3 USER 7 HipStick4
Note Wave
No. Wave Name
C 0 1032 SdHpStk1
C0 552 HiQ1
D 0 560 TurnTable
D0 543 Hit Uhh
E 0 586 ScratchStp
F 0 1054 SnLvRolL
F0 762 ClaveT8
G 0 1119 SdCut
G0 1028 SnRkStk1R
A 0 814 BdT9-2
A0 1103 SdHipRm1
B 0 820 BdT8-1
C 1 837 BdBrkDp
C1 1046 SdClRim3
D 1 1104 SdHipRm2
D1 744 HandClapR
E 1 1096 SdR&B1
F 1 754 CongaT8
F1 1202 HHClD&B
G 1 754 CongaT8
G1 1203 HHPdlD&B
A 1 754 CongaT8
A1 1204 HHOpD&B
B 1 754 CongaT8
C 2 754 CongaT8
C2 1257 Crash2
D 2 754 CongaT8
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1044 SdClRmR
D 5 1083 SdAnSmRim
D5 742 HandClapSt
E 5 1101 SdHip3
F 5 583 ScratchSdR
F5 588 ScrathcHip
G 5 581 ScratchBdR
G5 585 ScratchVoR
A 5 589 ScratchHp2
A5 591 ScratchCb2
B 5 593 ScratchCb4
C 6 836 BdHipDp
Note Wave
No. Wave Name
C 0 1032 SdHpStk1
C0 551 Zap2
D 0 560 TurnTable
D0 546 Ripper
E 0 589 ScratchHp2
F 0 1054 SnLvRolL
F0 762 ClaveT8
G 0 1109 SdBreak2
G0 1030 SdRkStk2L
A 0 808 BdRoom1
A0 1101 SdHip3
B 0 815 BdT9-3
C 1 834 BdR&B1
C1 1030 SdRkStk2L
D 1 1099 SdHip1
D1 744 HandClapR
E 1 1100 SdHip2
F 1 754 CongaT8
F1 1208 HHClHip
G 1 754 CongaT8
G1 1209 HHPdlHip
A 1 754 CongaT8
A1 1210 HHOpHip
B 1 754 CongaT8
C 2 754 CongaT8
C2 1257 Crash2
D 2 754 CongaT8
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1046 SdClRim3
D 5 1082 SdAnSm
D5 742 HandClapSt
E 5 1098 SdR&B2
F 5 573 Scratch H
F5 574 Scratch L
G 5 575 ScratchDwn
G5 576 ScratchHiF
A 5 577 ScratchHiR
A5 578 ScratchLoF
B 5 579 ScratchLoR
C 6 830 BdJngl2
Note Wave
No. Wave Name
C 0 762 ClaveT8
C0 1073 SdT9-5
D 0 560 TurnTable
D0 532 Quiek
E 0 592 ScratchCb3
F 0 1054 SnLvRolL
F0 763 AnaClick
G 0 1074 SdT9Gate
G0 1085 SdAnCRRim
A 0 819 BdT9Hd3
A0 1070 SdT9-2
B 0 818 BdT9Hd2
C 1 817 BdT9Hd1
C1 1075 SdT9Rim
D 1 1069 SdT9-1
D1 752 ClapT9
E 1 1073 SdT9-5
F 1 1246 TomT9Lo
F1 1191 HHClT9
G 1 1246 TomT9Lo
G1 1192 HHOpT9
A 1 1246 TomT9Lo
A1 1192 HHOpT9
B 1 1246 TomT9Lo
C 2 1245 TomT9Hi
C2 1274 CrashT9
D 2 1245 TomT9Hi
D2 1277 RideT9
E 2 1274 CrashT9
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1274 CrashT9
G2 757 CowBelAnCR
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1075 SdT9Rim
D 5 1073 SdT9-5
D5 752 ClapT9
E 5 1072 SdT9-4
F 5 573 Scratch H
F5 574 Scratch L
G 5 575 ScratchDwn
G5 576 ScratchHiF
A 5 577 ScratchHiR
A5 578 ScratchLoF
B 5 579 ScratchLoR
C 6 813 BdT9-1
Note Wave
No. Wave Name
C 0 1123 SdFMRim
C0 555 Bomb
D 0 560 TurnTable
D0 545 VoxDrum
E 0 580 ScratchBdF
F 0 1055 SnLvRolR
F0 736 WoodBlock
G 0 1085 SdAnCRRim
G0 1101 SdHip3
A 0 822 BdT8-3
A0 1075 SdT9Rim
B 0 820 BdT8-1
C 1 814 BdT9-2
C1 1106 SdHipRm4
D 1 1036 SdHpStk5
D1 744 HandClapR
E 1 1037 SdHpStk6St
F 1 822 BdT8-3
F1 1208 HHClHip
G 1 822 BdT8-3
G1 1209 HHPdlHip
A 1 822 BdT8-3
A1 1210 HHOpHip
B 1 822 BdT8-3
C 2 822 BdT8-3
C2 1257 Crash2
D 2 822 BdT8-3
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1083 SdAnSmRim
D 5 1044 SdClRmR
D5 1106 SdHipRm4
E 5 1045 SdClRim2
F 5 574 Scratch L
F5 575 ScratchDwn
G 5 576 ScratchHiF
G5 578 ScratchLoF
A 5 581 ScratchBdR
A5 591 ScratchCb2
B 5 586 ScratchStp
C 6 827 BdBlip
Note Wave
No. Wave Name
C 0 1130 SdRimSE
C0 752 ClapT9
D 0 560 TurnTable
D0 555 Bomb
E 0 590 ScratchCmb
F 0 1056 SdRollMono
F0 1075 SdT9Rim
G 0 1105 SdHipRm3
G0 1088 SdJngl1
A 0 810 BdRoom3
A0 1038 SdHpStk6L
B 0 815 BdT9-3
C 1 816 BdT9-4
C1 1106 SdHipRm4
D 1 1040 SdHpStk7
D1 744 HandClapR
E 1 1041 SdHipStk8
F 1 754 CongaT8
F1 1206 HHClTek
G 1 754 CongaT8
G1 1198 HHClAnCR
A 1 754 CongaT8
A1 1207 HHOpTek
B 1 754 CongaT8
C 2 754 CongaT8
C2 1257 Crash2
D 2 754 CongaT8
D2 1260 RideR
E 2 1275 CrashT8
F 2 1277 RideT9
F2 759 TambrnRX5
G 2 1273 SplashR
G2 748 MamboBdy
A 2 1274 CrashT9
A2 737 Vibraslap
B 2 1277 RideT9
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 707 ShakerHip1
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 1083 SdAnSmRim
D 5 1073 SdT9-5
D5 1105 SdHipRm3
E 5 1043 SdClRmL
F 5 578 ScratchLoF
F5 579 ScratchLoR
G 5 580 ScratchBdF
G5 581 ScratchBdR
A 5 582 ScratchSdF
A5 583 ScratchSdR
B 5 584 ScratchVoF
C 6 821 BdT8-2
MR_DL1.book Page 21 Monday, January 6, 2003 11:10 AM
22
USER 8 R&B Kit3 USER 9 Motor City USER 10 MW AmpSim GM Drum 1 Stereo GM
Note Wave
No. Wave Name
C 0 610 PlayFxGt13
C0 613 PlayFxABa3
D 0 614 PlayFxABa4
D0 615 PlayFxABa5
E 0 651 PlyFxSl16S
F 0 621 PlyFxSlp1S
F0 1279 HHClRL1-4
G 0 764 BdNmSt1-2
G0 1146 HHPdlSt
A 0 860 SdNmSt1-4
A0 1149 HHOpSt
B 0 822 BdT8-3
C 1 834 BdR&B1
C1 1046 SdClRim3
D 1 1014 SdPcRim
D1 742 HandClapSt
E 1 1097 SdR&B1Rm
F 1 822 BdT8-3
F1 1195 HHClT8-2
G 1 822 BdT8-3
G1 1193 HHClT8-1
A 1 822 BdT8-3
A1 1196 HHOpT8-2
B 1 822 BdT8-3
C 2 1247 TomT8
C2 1253 CrashSt
D 2 1247 TomT8
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 714 TambrnSw
G 2 1256 Crash
G2 758 AnaShaker
A 2 758 AnaShaker
A2 761 MarcsT8
B 2 761 MarcsT8
C 3 692 GanzaAc
C3 693 GanzaBk
D 3 694 GanzaFw
D3 695 Maracas1-2
E 3 696 MaracasSlr
F 3 698 Cabasa1-2
F3 699 Cabasa1
G 3 700 Cabasa2
G3 701 Caxixi1-2
A 3 758 AnaShaker
A3 703 Caxixi2
B 3 704 Shaker1-2
C 4 705 Shaker1
C4 707 ShakerHip1
D 4 710 ShakerHip4
D4 762 ClaveT8
E 4 666 QuintSlp
F 4 587 ScratchSpn
F4 577 ScratchHiR
G 4 576 ScratchHiF
G4 741 TriangleMt
A 4 740 TriangleOp
A4 719 PandierTip
B 4 715 TambrnHit
C 5 854 BdHardLong
C5 1129 SdLofi
D 5 1029 SdRkStk2St
D5 1013 SdPicol
E 5 560 TurnTable
F 5 1098 SdR&B2
F5 1152 HHClFtSt
G 5 836 BdHipDp
G5 1155 HHHlf2St
A 5 859 BdSlimy
A5 1158 HHOp2St
B 5 507 TranCho
C 6 822 BdT8-3
Note Wave
No. Wave Name
C 0 735 Clave
C0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F0 734 Castanet
G 0 863 SdNmSt1-2
G0 732 Stick
A 0 773 BdFkSt1-2
A0 866 SdNm1St
B 0 804 BdDry2
C 1 778 BdFkML
C1 1045 SdClRim2
D 1 864 SdNmSt2-3
D1 743 HandClapL
E 1 902 SdBs1St
F 1 1227 TomFlSt
F1 1131 HHClSt1-4
G 1 1224 TomLoSt
G1 1146 HHPdlSt
A 1 1224 TomLoSt
A1 1149 HHOpSt
B 1 1221 TomMdSt
C 2 1221 TomMdSt
C2 1253 CrashSt
D 2 1218 TomHiSt
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 716 TambrnShk
G 2 1271 SplashSt
G2 746 Cowbell2
A 2 1305 CrashRL
A2 737 Vibraslap
B 2 1306 RideRL
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 661 CongaOp
E 3 669 TumbaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 714 TambrnSw
D 5 719 PandierTip
D5 720 PandroHeel
E 5 675 BongoHi1-2
F 5 678 BongoHHeel
F5 679 BongoLo1-3
G 5 682 BongoLo3
G5 695 Maracas1-2
A 5 696 MaracasSlr
A5 697 MaracasStc
B 5 752 ClapT9
C 6 752 ClapT9
Note Wave
No. Wave Name
C 0 822 BdT8-3
C0 1084 SdAnCR
D 0 1077 SdT8-2
D0 752 ClapT9
E 0 1076 SdT8-1
F 0 1047 SdRkRolSt
F0 1001 SdRkOp2St
G 0 1069 SdT9-1
G0 1035 SdHpStk4
A 0 824 BdAnCR
A0 1123 SdFMRim
B 0 1247 TomT8
C 1 816 BdT9-4
C1 1032 SdHpStk1
D 1 1072 SdT9-4
D1 752 ClapT9
E 1 1070 SdT9-2
F 1 1247 TomT8
F1 1195 HHClT8-2
G 1 1247 TomT8
G1 1196 HHOpT8-2
A 1 1247 TomT8
A1 1196 HHOpT8-2
B 1 1247 TomT8
C 2 1247 TomT8
C2 1253 CrashSt
D 2 1247 TomT8
D2 1258 RideSt
E 2 1270 China
F 2 1265 CupMono
F2 759 TambrnRX5
G 2 1271 SplashSt
G2 745 Cowbel1
A 2 1253 CrashSt
A2 737 Vibraslap
B 2 1260 RideR
C 3 754 CongaT8
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 662 CongaSlp
E 3 661 CongaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 763 AnaClick
G3 754 CongaT8
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 558 FxGun1
C 4 507 Me TranCho
C4 507 Me TranCho
D 4 553 HiQ2
D4 546 Ripper
E 4 550 Zap1
F 4 595 PickNoise2
F4 666 QuintSlp
G 4 666 QuintSlp
G4 741 TriangleMt
A 4 740 TriangleOp
A4 758 AnaShaker
B 4 750 SleighBel
C 5 751 BellTree
C5 763 AnaClick
D 5 1079 SdT8-4
D5 1092 SdD&B1
E 5 1082 SdAnSm
F 5 828 BdBlpHd
F5 1089 SdJngl2
G 5 849 BdFxHmr
G5 1121 SdDodgL
A 5 839 BdBreak2
A5 1111 SdBreakHvy
B 5 840 BdBreakHvy
C 6 966 SdLdwSt1-2
Note Wave
No. Wave Name
C 0 735 Clave
C0 1057 SdBrMtSt
D 0 1063 SdBrSwrSt
D0 1060 SdBrMt2St
E 0 1066 SdBSwrAtSt
F 0 1053 SnLvRolSt
F0 734 Castanet
G 0 866 SdNm1St
G0 732 Stick
A 0 773 BdFkSt1-2
A0 900 SdBsSt2-3
B 0 782 BdHiSt
C 1 764 BdNmSt1-2
C1 1042 SdClRmSt
D 1 860 SdNmSt1-4
D1 752 ClapT9
E 1 899 SdBsSt1-2
F 1 1227 TomFlSt
F1 1131 HHClSt1-4
G 1 1224 TomLoSt
G1 1146 HHPdlSt
A 1 1224 TomLoSt
A1 1149 HHOpSt
B 1 1221 TomMdSt
C 2 1221 TomMdSt
C2 1253 CrashSt
D 2 1218 TomHiSt
D2 1258 RideSt
E 2 1267 ChinaSt
F 2 1261 CupSt
F2 714 TambrnSw
G 2 1271 SplashSt
G2 746 Cowbell2
A 2 1305 CrashRL
A2 737 Vibraslap
B 2 1306 RideRL
C 3 675 BongoHi1-2
C3 679 BongoLo1-3
D 3 663 CongaTip
D3 661 CongaOp
E 3 669 TumbaOp
F 3 683 TmbaleH1-3
F3 687 TmbaleL1-3
G 3 724 AgogoHi
G3 725 AgogoLo
A 3 698 Cabasa1-2
A3 696 MaracasSlr
B 3 738 Whistle
C 4 738 Whistle
C4 728 GuiroShort
D 4 727 GuiroLong
D4 735 Clave
E 4 736 WoodBlock
F 4 736 WoodBlock
F4 674 CuicaHi
G 4 673 CuicaLo
G4 741 TriangleMt
A 4 740 TriangleOp
A4 704 Shaker1-2
B 4 750 SleighBel
C 5 751 BellTree
C5 940 SdBlL1-3
D 5 963 SdLdwSt1-4
D5 956 SdBhR1-3
E 5 983 SdHipSt1-2
F 5 785 BdLoSt
F5 1021 SdLdwHMono
G 5 834 BdR&B1
G5 1024 SdHeavy
A 5 808 BdRoom1
A5 1018 SdAmb
B 5 794 BdFkSonSt
C 6 809 BdRoom2
MR_DL1.book Page 22 Monday, January 6, 2003 11:10 AM
23
Wave List
No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name
1 Ap Piano1 St 101 Or Jazz 201 Ba PrecRW 301 Br F.Horn 401 Wv VPStrngSt 501 Me OrchHit 601 Se PlayFxGt4
2 Ap Piano1 L 102 Or Jazz+ 202 Ba PrecRW+ 302 Br F.Horn+ 402 Wv VPStrngL 502 Me VoxBell 602 Se PlayFxGt5
3 Ap Piano1 R 103 Or Jazz- 203 Ba PrecRW- 303 Br F.Horn- 403 Wv VPStrngR 503 Me Melow 603 Se PlayFxGt6
4 Ap Piano1Mono 104 Or Full 204 Ba PrecFW 304 Br Tuba 404 Wv OBStrings 504 Me WindChime 604 Se PlayFxGt7
5 Ap Piano1 St+ 105 Or Full+ 205 Ba PrecFW+ 305 Br Combi1 405 Wv SyzleStrng 505 Me BellAir 605 Se PlayFxGt8
6 Ap Piano1 L+ 106 Or Full- 206 Ba PrecFW- 306 Br Combi2 406 Wv Padd 506 Me BigSyn 606 Se PlayFxGt9
7 Ap Piano1 R+ 107 Or Swish 207 Ba FingerWW 307 Br Combi3 407 Wv Darklight 507 Me TranCho 607 Se PlayFxGt10
8 Ap Piano1 St- 108 Or Swish- 208 Ba FingerWW+ 308 Br Combi4 408 Wv OBBrass 508 Me StabOrgLP 608 Se PlayFxGt11
9 Ap Piano1 L- 109 Or Compact 209 Ba FingerWW- 309 Rd SopranoSax 409 Wv Sync 509 Me Eery 609 Se PlayFxGt12
10 Ap Piano1 R- 110 Or Compact- 210 Ba SlapThmbmf 310 Rd SopranSax+ 410 Wv SyncLd 510 Me Electer 610 Se PlayFxGt13
11 Ap Piano2 St 111 Or Portable 211 Ba SlapThmbff 311 Rd SopranSax- 411 Wv PWMfast 511 Me HH Hit 611 Se PlayFxABa1
12 Ap Piano2 L 112 Or Portable- 212 Ba SlapPull 312 Rd AltoSaxVb 412 Wv PWMslow 512 Me VoxAlk 612 Se PlayFxABa2
13 Ap Piano2 R 113 Or BowNv 213 Ba SlapHarm 313 Rd AltoSaxNv 413 Wv CS80Brass 513 Me HiLo 613 Se PlayFxABa3
14 Ap Piano2Mono 114 Or BowVb 214 Ba SlapFxSoft 314 Rd AltoSaxNv+ 414 Wv P5Saw 514 Me MultiPiano 614 Se PlayFxABa4
15 Ap Piano2 St+ 115 Or Gospel 215 Ba SlapFxHard 315 Rd AltoSaxNv- 415 Wv OBSaw 515 Me AirHoseSt 615 Se PlayFxABa5
16 Ap Piano2 L+ 116 Or Soul 216 Ba Thmb&Fx-mf 316 Rd TenorSax 416 Wv Saw2 516 Me AirHoseL 616 Se PlayFxABa6
17 Ap Piano2 R+ 117 Or 1stFour 217 Ba Thmb&Fx-ff 317 Rd TenorSax+ 417 Wv 3o3Saw 517 Me AirHoseR 617 Se PlayFxABa7
18 Ap Piano2 St- 118 Or Draw 16' 218 Ba Pull&Fx 318 Rd TenorSax- 418 Wv 3o3Saw2 518 Me Bubble 618 Se PlayFxABa8
19 Ap Piano2 L- 119 Or Draw 5 1/3 219 Ba Fretless 319 Rd BaritonSax 419 Wv 3o3Squ 519 Me Swarm 619 Se PlayFxABa9
20 Ap Piano2 R- 120 Or Draw 8' 220 Ba Fretless+ 320 Rd Clarinet 420 Wv 1o1Saw 520 Me Mother 620 Se PlyFxABa10
21 Ap Brite Pno 121 Or Draw 4' 221 Ba Fretless- 321 Rd Oboe 421 Wv 1o1Sub 521 Me Lektronica 621 Se PlyFxSlp1S
22 Ap Brite Pno- 122 Or Draw 2 2/3 222 St ViolinVb 322 Rd EnglishHrn 422 Wv SawSqu 522 Me SpaceScrem 622 Se PlyFxSlp1H
23 Ap CP80 123 Or Draw 2' 223 St ViolinVb+ 323 Rd Basoon 423 Wv SquSaw 523 Me Resonator 623 Se PlyFxSlp2S
24 Ap CP80+ 124 Or Draw 1 3/5 224 St ViolinVb- 324 Rd Bagpipe1 424 Wv MgRamp 524 Me RadioNz 624 Se PlyFxSlp2H
25 Ap CP80- 125 Or Draw 1 1/3 225 St ViolinSpc 325 Rd Bagpipe2 425 Wv MgBass1 525 Me OohFB 625 Se PlyFxSlp3S
26 Ep EP1 Soft 126 Or Draw 1' 226 St ViolinSpc+ 326 Rd SaxBreath 426 Wv MgBass2 526 Me Fairwave 626 Se PlyFxSlp3H
27 Ep EP1 Soft+ 127 Or Draw 1+3 227 St ViolinSpc- 327 Rd Harmonica 427 Wv MgBass3 527 Me Hoo 627 Se PlyFxSlp4S
28 Ep EP1 Soft- 128 Or Draw 1+3+ 228 St ViolaVb 328 Pi FluteVb 428 Wv ModBass 528 Me Mind Bell 628 Se PlyFxSlp4H
29 Ep EP1 Med 129 Or Draw 1+3- 229 St ViolaVb+ 329 Pi FluteVbAtk 429 Wv AnaBass1 529 Me Loop145 629 Se PlyFxSlp5S
30 Ep EP1 Med+ 130 Or Draw 2+4 230 St ViolaVb- 330 Pi Flute 430 Wv AnaBass2 530 Me X-Fade 630 Se PlyFxSlp5H
31 Ep EP1 Med- 131 Or Draw 2+4+ 231 St ViolaSpc 331 Pi Flute+ 431 Wv UniBass 531 Me ResoXFade 631 Se PlyFxSlp6S
32 Ep EP1 Hard 132 Or Draw 2+4- 232 St ViolaSpc+ 332 Pi Flute- 432 Wv AnaBass3 532 Me Quiek 632 Se PlyFxSlp6H
33 Ep EP1 Hard+ 133 Or Draw Even 233 St ViolaSpc- 333 Pi PanFlute 433 Wv AnaBass4 533 Me LfoSeq 633 Se PlyFxSlp7S
34 Ep EP1 Hard- 134 Or Draw Even+ 234 St CelloVb 334 Pi PanFlute- 434 Wv AnaBass5 534 Me Sonar1 634 Se PlyFxSlp7H
35 Ep EP2 Soft1 135 Or Draw Even- 235 St CelloVb+ 335 Pi Shakuhachi 435 Wv AnaBass6 535 Me Sonar2 635 Se PlyFxSlp8S
36 Ep EP2 Soft1+ 136 Or Draw Odd 236 St CelloVb- 336 Pi Recorder 436 Wv T8KickBass 536 Me HitOrch1 636 Se PlyFxSlp8H
37 Ep EP2 Soft1- 137 Or Draw Odd+ 237 St CelloSpc 337 Pi Bottle 437 Wv FMBass1 537 Me HitBrass 637 Se PlyFxSlp9S
38 Ep EP2 Soft2 138 Or Draw Odd- 238 St CelloSpc+ 338 Pi Ocarina 438 Wv FMBass2 538 Me StabOrch 638 Se PlyFxSlp9H
39 Ep EP2 Soft2+ 139 Or Perc 239 St CelloSpc- 339 Pi Whistle 439 Wv FMBass3 539 Me StabGiant 639 Se PlyFxSl10S
40 Ep EP2 Soft2- 140 Or Perc+ 240 St SoloVbCmb 340 Pi BreathO.S. 440 Wv FMBass4 540 Me StabHard 640 Se PlyFxSl10H
41 Ep EP2 Hard1 141 Or Perc- 241 St SoloVbCmb+ 341 Cp SteelDrum 441 Wv FMBass5 541 Me StabOrgan2 641 Se PlyFxSl11S
42 Ep EP2 Hard1+ 142 Or Rotar 242 St SoloVbCmb- 342 Gt Sitar 442 Wv FMBass6 542 Me StabAah 642 Se PlyFxSl11H
43 Ep EP2 Hard1- 143 Or Clack 243 St SoloSpcCmb 343 Gt SitarWv1 443 Wv FMSquare 543 Me Hit Uhh 643 Se PlyFxSl12S
44 Ep EP2 Hard2 144 Or RotarWhstl 244 St SoloSpCmb+ 344 Gt SitarWv2 444 Wv FMShaper 544 Me HitOrch2 644 Se PlyFxSl12H
45 Ep EP2 Hard2+ 145 Or RotarGrit 245 St SoloSpCmb- 345 Gt SitarWv3 445 Wv FMMetal1 545 Me VoxDrum 645 Se PlyFxSl13S
46 Ep EP2 Hard2- 146 Or RotarGrit2 246 St ContraBass 346 Gt SitarWv4 446 Wv FMMetal2 546 Se Ripper 646 Se PlyFxSl13H
47 Ep EP3 Soft1 147 Or SftTmp 247 St EnsMix 347 Gt SitarWv5 447 Wv FMOrgan1 547 Se Glass 647 Se PlyFxSl14S
48 Ep EP3 Soft1+ 148 Or Pipe1St 248 St EnsMixSt 348 Gt SitarWv6 448 Wv FMOrgan2 548 Se IndusTom 648 Se PlyFxSl14H
49 Ep EP3 Soft1- 149 Or Pipe1L 249 St EnsMixL 349 Gt Tambura 449 Wv FMOrgan3 549 Se NzBurst 649 Se PlyFxSl15S
50 Ep EP3 Soft2 150 Or Pipe1R 250 St EnsMixR 350 Gt TamburaWv1 450 Wv FMOrgan4 550 Se Zap1 650 Se PlyFxSl15H
51 Ep EP3 Soft2+ 151 Or Pipe2 251 St EnsMute 351 Gt TamburaWv2 451 Wv FMFunk 551 Se Zap2 651 Se PlyFxSl16S
52 Ep EP3 Soft2- 152 Or Pipe3St 252 St EnsMute- 352 Gt TamburaWv3 452 Wv FMGuitar 552 Se HiQ1 652 Se PlyFxSl16H
53 Ep EP3 Hard1 153 Or Pipe3L 253 St EnsMuteSt 353 Cp HmDulcimar 453 Wv FSBuzz 553 Se HiQ2 653 Se PlyFxSl17S
54 Ep EP3 Hard1+ 154 Or Pipe3R 254 St HardEnsSt 354 Gt Shamisen 454 Wv WetPluck 554 Se VoxHitRev 654 Se PlyFxSl17H
55 Ep EP3 Hard1- 155 Or Pipe4 255 St HardEnsSt+ 355 Gt Koto 455 Wv Lately-S 555 Se Bomb 655 Se PlyFxSl18S
56 Ep EP3 Hard2 156 Or Pipe5 256 St HardEnsSt- 356 Cp Kalimba 456 Wv Lately-L 556 Se TapeRewnd 656 Se PlyFxSl18H
57 Ep EP3 Hard2+ 157 Or Pipe6 257 St HardEnsL 357 Cp Gamelan1 457 Wv P10-1 557 Se FxGun2 657 Se PlyFxSl19S
58 Ep EP3 Hard2- 158 Or Pipe7 258 St HardEnsL+ 358 Cp Gamelan2 458 Wv P10-2 558 Se FxGun1 658 Se PlyFxSl19H
59 Ep Wurli 159 Or Accordion 259 St HardEnsL- 359 Pi Didgerido1 459 Wv P10-3 559 Se Thunder 659 Se PlyFxSl20S
60 Ep Wurli+ 160 Or TangoAcd 260 St HardEnsR 360 Pi Didgerido2 460 Wv P25-1 560 Se TurnTable 660 Se PlyFxSl20H
61 Ep Wurli- 161 Gt Nylon 261 St HardEnsR+ 361 Pi Didgerido3 461 Wv P25-2 561 Se Police 661 Pc CongaOp
62 Ep DX1 162 Gt Nylon Hi 262 St HardEnsR- 362 Pi DidgCmb1 462 Wv P50-1 562 Se DoorSqk 662 Pc CongaSlp
63 Ep DX2 163 Gt NylonHarm 263 St EnsMxLPSt 363 Pi DidgCmb2 463 Wv P50-2 563 Se Heartbeat 663 Pc CongaTip
64 Ep DX3 164 Gt Steel Gtr1 264 St EnsMxLP L 364 Pi Sho 464 Wv TriWv 564 Se Helicopter 664 Pc CongaHeel
65 Ep DX4 165 Gt SteelGtrHi 265 St EnsMxLP R 365 Pc Log1 465 Wv Digi01 565 Se Seashore 665 Pc QuintOp
66 Ep DX5 166 Gt SteelGtrLo 266 St EnsMuteLP 366 Pc Log2 466 Wv Digi02 566 Se Telephone 666 Pc QuintSlp
67 Kb Clav1 167 Gt SteelHarm 267 St EnsMuteLP- 367 Pc Wataiko 467 Wv Digi03 567 Se TelRing 667 Pc QuintTip
68 Kb Clav1+ 168 Gt Steel Gtr2 268 St EnsMutLPSt 368 Pc DjembeEd 468 Wv Digi04 568 Se Bird 668 Pc QuintHeel
69 Kb Clav1- 169 Gt SteelGt2St 269 St HrdEnsLPSt 369 Pc DjembeMt 469 Wv Digi05 569 Se Stream 669 Pc TumbaOp
70 Kb Clav2 170 Gt SteelGt2Hi 270 St HrdEnsLP L 370 Pc DjembeOp 470 Wv Digi06 570 Se Gunshot 670 Pc TumbaSlp
71 Kb Clav2+ 171 Gt SteelGtr2- 271 St HrdEnsLP R 371 Pc DjembeCmb 471 Wv Digi07 571 Se Applause 671 Pc TumbaTip
72 Kb Clav2- 172 Gt Jazz Gtr 272 St Pizzicato 372 Pc TabraBya 472 Wv Digi08 572 Se RainLoop 672 Pc TumbaHeel
73 Kb Clav3 173 Gt VintAmpA 273 St PopPizz 373 Pc TabraNah 473 Wv Digi09 573 Se Scratch H 673 Pc CuicaLo
74 Kb Clav3+ 174 Gt VintAmpB 274 St Harp 374 Pc TablaMut 474 Wv Digi10 574 Se Scratch L 674 Pc CuicaHi
75 Kb Clav3- 175 Gt Strat 275 Br BrsSctSt 375 Pc TabraCmb 475 Wv Digi11 575 Se ScratchDwn 675 Pc BongoHi1-2
76 Kb Harpsicord 176 Gt StratN 276 Br BrsSctSt+ 376 Pc UdoFinger 476 Wv Digi12 576 Se ScratchHiF 676 Pc BongoHi1
77 Cp Celeste 177 Gt StratF 277 Br BrsSctSt- 377 Pc Udo Hi 477 Wv Bel1Wv 577 Se ScratchHiR 677 Pc BongoHi2
78 Cp Vibraphone 178 Gt StratSl 278 Br BrsSctL 378 Pc Udo Low 478 Wv Bel2Wv 578 Se ScratchLoF 678 Pc BongoHHeel
79 Cp Mairmba 179 Gt StratSp 279 Br BrsSctL+ 379 Pc UduCombi 479 Wv DigiVox1 579 Se ScratchLoR 679 Pc BongoLo1-3
80 Cp Glocken 180 Gt StratMute 280 Br BrsSctL- 380 Vo Aahs St 480 Wv DigiVox2 580 Se ScratchBdF 680 Pc BongoLo1
81 Cp Xylophone 181 Gt StratHarm 281 Br BrsSctR 381 Vo Aahs L 481 Wv DigiVox3 581 Se ScratchBdR 681 Pc BongoLo2
82 Cp Tubular 182 Gt Front 282 Br BrsSctR+ 382 Vo Aahs R 482 Wv DigiVox4 582 Se ScratchSdF 682 Pc BongoLo3
83 Cp Bell 183 Gt Dist Gtr 1 283 Br BrsSctR- 383 Vo Ooh St 483 Wv DigiVox5 583 Se ScratchSdR 683 Pc TmbaleH1-3
84 Cp BellSt1 184 Gt Dist2 284 Br Trumpet 384 Vo Ooh L 484 Wv VoxG2 584 Se ScratchVoF 684 Pc TimbaleHi1
85 Cp BellSt2 185 Gt DistMt 285 Br Trumpet+ 385 Vo Ooh R 485 Wv VoxE3 585 Se ScratchVoR 685 Pc TimbaleHi2
86 Cp BrBell 186 Gt Feedback 286 Br Trumpet- 386 Vo ChoBreathL 486 Wv EP Wave 1 586 Se ScratchStp 686 Pc TimbaleHi3
87 Cp SmBell 187 Gt PwrChrdSt 287 Br Trumpet2 387 Vo ChoBreathR 487 Wv EP Wave 2 587 Se ScratchSpn 687 Pc TmbaleL1-3
88 Cp Hibasi 188 Gt PwrChdMono 288 Br Trumpet2+ 388 Vo ChoAahLPSt 488 Wv EP Wave 3 588 Se ScrathcHip 688 Pc TimbaleLo1
89 Cp FingerCym 189 Gt PlayFx 289 Br Trumpet2- 389 Vo ChoAahLPL 489 Wv EP Wave 4 589 Se ScratchHp2 689 Pc TimbaleLo2
90 Cp StoneH 190 Gt PChdSt&Fx 290 Br Trombone 390 Vo ChoAahLPR 490 Wv EP Wave 5 590 Se ScratchCmb 690 Pc TmblPailaH
91 Cp StoneS 191 Gt PChd&Fx 291 Br Trombone- 391 Vo ChoOohLPSt 491 Wv EP Wave 6 591 Se ScratchCb2 691 Pc TmblPailaL
92 Cp Timpani 192 Gt Banjo 292 Br Trombone2 392 Vo ChoOohLPL 492 Wv Org Wave1 592 Se ScratchCb3 692 Pc GanzaAc
93 Or RockVb 193 Ba A Bass 293 Br SiftTrb 393 Vo ChoOohLPR 493 Wv Org Wave2 593 Se ScratchCb4 693 Pc GanzaBk
94 Or RockPc 194 Ba A Bass+ 294 Br SoftFlugel 394 Vo SynVox 494 Wv Org Wave3 594 Se PickNoise1 694 Pc GanzaFw
95 Or Click 195 Ba A Bass- 295 Br SoftFlugl- 395 Vo VoxNoiz 495 Wv Sine 595 Se PickNoise2 695 Pc Maracas1-2
96 Or Rock2 196 Ba A Bass FX 296 Br TrmptMute 396 Vo Itopia 496 Wv Noise 596 Se PickNoise3 696 Pc MaracasSlr
97 Or Rock2+ 197 Ba PickBass 297 Br TrmptMute2 397 Wv ModSaw 497 Wv Mallet 597 Se FretNoise 697 Pc MaracasStc
98 Or Rock2- 198 Ba FingerMM 298 Br TrumptMed 398 Wv FatSaw 498 Wv PnoNP 598 Se PlayFxGt1 698 Pc Cabasa1-2
99 Or JazzPrc 199 Ba FingerMM+ 299 Br TrumptSoft 399 Wv FatSaw- 499 Wv EPNP 599 Se PlayFxGt2 699 Pc Cabasa1
100 Or JazzPrc- 200 Ba FingerMM- 300 Br PicolTrmpt 400 Wv OBModSaw 500 Wv VibeNP 600 Se PlayFxGt3 700 Pc Cabasa2
MR_DL1.book Page 23 Monday, January 6, 2003 11:10 AM
24
No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name No.
Category
Wave Name
701 Pc Caxixi1-2 801 Dr BdRk2L 901 Dr SdBsSt1/3 1001 Dr SdRkOp2St 1101 Dr SdHip3 1201 Dr HHPdlBreak 1301 Dr TomFlRL
702 Pc Caxixi1 802 Dr BdRk2R 902 Dr SdBs1St 1002 Dr SdRkOp2L 1102 Dr SdHipGate 1202 Dr HHClD&B 1302 Dr TomRkHiRL
703 Pc Caxixi2 803 Dr BdDry1 903 Dr SdBs2St 1003 Dr SdRkOp2R 1103 Dr SdHipRm1 1203 Dr HHPdlD&B 1303 Dr TomRkMdRL
704 Pc Shaker1-2 804 Dr BdDry2 904 Dr SdBs3St 1004 Dr SdRkMte2St 1104 Dr SdHipRm2 1204 Dr HHOpD&B 1304 Dr TomRkLoRL
705 Pc Shaker1 805 Dr BdPop 905 Dr SdBsL1-3 1005 Dr SdRkMte2L 1105 Dr SdHipRm3 1205 Dr HHRvD&B 1305 Dr CrashRL
706 Pc Shaker2 806 Dr BdVar1 906 Dr SdBsR1-3 1006 Dr SdRkMte2R 1106 Dr SdHipRm4 1206 Dr HHClTek 1306 Dr RideRL
707 Pc ShakerHip1 807 Dr BdVar2 907 Dr SdBs1L 1007 Dr SdRkRim2St 1107 Dr SdHipRm5 1207 Dr HHOpTek 1307 Dr CupRL
708 Pc ShakerHip2 808 Dr BdRoom1 908 Dr SdBs1R 1008 Dr SdRkRim2L 1108 Dr SdBreak1 1208 Dr HHClHip 1308 Dr ChinaRL
709 Pc ShakerHip3 809 Dr BdRoom2 909 Dr SdBs2L 1009 Dr SdRkRim2R 1109 Dr SdBreak2 1209 Dr HHPdlHip 1309 Dr SplashRL
710 Pc ShakerHip4 810 Dr BdRoom3 910 Dr SdBs2R 1010 Dr SdRkFlmSt 1110 Dr SdBreak3 1210 Dr HHOpHip
711 Pc ShekereDw 811 Dr BdGate 911 Dr SdBs3L 1011 Dr SdRkFlmL 1111 Dr SdBreakHvy 1211 Dr HHClLoFi
712 Pc ShekereUp 812 Dr BdFXGate 912 Dr SdBs3R 1012 Dr SdRkFlmR 1112 Dr SdBreakRol 1212 Dr HHOpLoFi
713 Pc ShekereSap 813 Dr BdT9-1 913 Dr SdSonSt1-4 1013 Dr SdPicol 1113 Dr SdFx1 1213 Dr HHClSyn
714 Pc TambrnSw 814 Dr BdT9-2 914 Dr SdSonSt1-3 1014 Dr SdPcRim 1114 Dr SdFx2 1214 Dr HHOpSyn
715 Pc TambrnHit 815 Dr BdT9-3 915 Dr SdSonSt2-4 1015 Dr SdPcRim2 1115 Dr SdFx3 1215 Dr HHClFx
716 Pc TambrnShk 816 Dr BdT9-4 916 Dr SdSonSt1-2 1016 Dr SdMid 1116 Dr SdFx4 1216 Dr HHOpFx
717 Pc PandieroOp 817 Dr BdT9Hd1 917 Dr SdSonSt2-3 1017 Dr SdMdRim 1117 Dr SdClpAna 1217 Dr HHOpHuman
718 Pc PandierThm 818 Dr BdT9Hd2 918 Dr SdSonSt3-4 1018 Dr SdAmb 1118 Dr SdDist 1218 Dr TomHiSt
719 Pc PandierTip 819 Dr BdT9Hd3 919 Dr SdSon1St 1019 Dr SdGate1 1119 Dr SdCut 1219 Dr TomHiL
720 Pc PandroHeel 820 Dr BdT8-1 920 Dr SdSon2St 1020 Dr SdGate2 1120 Dr SdDodgH 1220 Dr TomHiR
721 Pc TmbourimOp 821 Dr BdT8-2 921 Dr SdSon3St 1021 Dr SdLdwHMono 1121 Dr SdDodgL 1221 Dr TomMdSt
722 Pc TmbourmFng 822 Dr BdT8-3 922 Dr SdSon4St 1022 Dr SdBrRim 1122 Dr SdFM 1222 Dr TomMdL
723 Pc TmbourimMt 823 Dr BdAnSm 923 Dr SdSonL1-4 1023 Dr SdDry 1123 Dr SdFMRim 1223 Dr TomMdR
724 Pc AgogoHi 824 Dr BdAnCR 924 Dr SdSonR1-4 1024 Dr SdHeavy 1124 Dr SdSyn 1224 Dr TomLoSt
725 Pc AgogoLo 825 Dr BdHuman1 925 Dr SdSon1L 1025 Dr SdGM 1125 Dr SdClappy 1225 Dr TomLoL
726 Pc AgogoLoTap 826 Dr BdHuman2 926 Dr SdSon1R 1026 Dr SdRkStk1St 1126 Dr SdTimber 1226 Dr TomLoR
727 Pc GuiroLong 827 Dr BdBlip 927 Dr SdSon2L 1027 Dr SdRkStk1L 1127 Dr SdWood 1227 Dr TomFlSt
728 Pc GuiroShort 828 Dr BdBlpHd 928 Dr SdSon2R 1028 Dr SnRkStk1R 1128 Dr SdHammer 1228 Dr TomFlL
729 Pc GuiroSwp 829 Dr BdJngl1 929 Dr SdSon3L 1029 Dr SdRkStk2St 1129 Dr SdLofi 1229 Dr TomFlR
730 Pc SurdoOp 830 Dr BdJngl2 930 Dr SdSon3R 1030 Dr SdRkStk2L 1130 Dr SdRimSE 1230 Dr TomRkHiSt
731 Pc SurdoMt 831 Dr BdJngl3 931 Dr SdSon4L 1031 Dr SdRkStk2R 1131 Dr HHClSt1-4 1231 Dr TomRkHiL
732 Pc Stick 832 Dr BdD&B1 932 Dr SdSon4R 1032 Dr SdHpStk1 1132 Dr HHCl1St 1232 Dr TomRkHiR
733 Dr Stick2 833 Dr BdD&B2 933 Dr SdBlSt1-3 1033 Dr SdHpStk2 1133 Dr HHCl2St 1233 Dr TomRkMdSt
734 Pc Castanet 834 Dr BdR&B1 934 Dr SdBlSt1-2 1034 Dr SdHpStk3 1134 Dr HHCl3St 1234 Dr TomRkMdL
735 Pc Clave 835 Dr BdR&B2 935 Dr SdBlSt2-3 1035 Dr SdHpStk4 1135 Dr HHCl4St 1235 Dr TomRkMdR
736 Pc WoodBlock 836 Dr BdHipDp 936 Dr SdBlSt1/3 1036 Dr SdHpStk5 1136 Dr HHClL1-4 1236 Dr TomRkLoSt
737 Pc Vibraslap 837 Dr BdBrkDp 937 Dr SdBl1St 1037 Dr SdHpStk6St 1137 Dr HHClR1-4 1237 Dr TomRkLoL
738 Pc Whistle 838 Dr BdBreak1 938 Dr SdBl2St 1038 Dr SdHpStk6L 1138 Dr HHCl1L 1238 Dr TomRkLoR
739 Pc TriangleSw 839 Dr BdBreak2 939 Dr SdBl3St 1039 Dr SdHpStk6R 1139 Dr HHCl1R 1239 Dr TomMonoHi
740 Pc TriangleOp 840 Dr BdBreakHvy 940 Dr SdBlL1-3 1040 Dr SdHpStk7 1140 Dr HHCl2L 1240 Dr TomMonoLo
741 Pc TriangleMt 841 Dr BdBreakHrd 941 Dr SdBlR1-3 1041 Dr SdHipStk8 1141 Dr HHCl2R 1241 Dr TomDryHi
742 Pc HandClapSt 842 Dr BdDist1 942 Dr SdBl1L 1042 Dr SdClRmSt 1142 Dr HHCl3L 1242 Dr TmDryLo
743 Pc HandClapL 843 Dr BdDist2 943 Dr SdBl1R 1043 Dr SdClRmL 1143 Dr HHCl3R 1243 Dr TomAmbHi
744 Pc HandClapR 844 Dr BdDist3 944 Dr SdBl2L 1044 Dr SdClRmR 1144 Dr HHCl4L 1244 Dr TomAmbLo
745 Pc Cowbel1 845 Dr BdDist4 945 Dr SdBl2R 1045 Dr SdClRim2 1145 Dr HHCl4R 1245 Dr TomT9Hi
746 Pc Cowbell2 846 Dr BdDist5 946 Dr SdBl3L 1046 Dr SdClRim3 1146 Dr HHPdlSt 1246 Dr TomT9Lo
747 Pc MamboBel 847 Dr BdDistRM 947 Dr SdBl3R 1047 Dr SdRkRolSt 1147 Dr HHPdlL 1247 Dr TomT8
748 Pc MamboBdy 848 Dr Bd+HH 948 Dr SdBhSt1-3 1048 Dr SdRkRolL 1148 Dr HHPdlR 1248 Dr TomSyn1
749 Pc ChaCha 849 Dr BdFxHmr 949 Dr SdBhSt1-2 1049 Dr SdRkRolR 1149 Dr HHOpSt 1249 Dr TomSyn2
750 Pc SleighBel 850 Dr BdZapHrd 950 Dr SdBhSt2-3 1050 Dr SdRkRolDSt 1150 Dr HHOpL 1250 Dr TomAnSm
751 Pc BellTree 851 Dr BdZapMid 951 Dr SdBhSt1/3 1051 Dr SdRkRolDL 1151 Dr HHOpR 1251 Dr TomDistHi
752 Pc ClapT9 852 Dr BdSus 952 Dr SdBh1St 1052 Dr SdRkRolDR 1152 Dr HHClFtSt 1252 Dr TomDistLo
753 Pc ClapAnSm 853 Dr BdTekPower 953 Dr SdBh2St 1053 Dr SnLvRolSt 1153 Dr HHClFtL 1253 Dr CrashSt
754 Pc CongaT8 854 Dr BdHardLong 954 Dr SdBh3St 1054 Dr SnLvRolL 1154 Dr HHClFtR 1254 Dr CrashL
755 Pc CowBelT8 855 Dr BdATite 955 Dr SdBhL1-3 1055 Dr SnLvRolR 1155 Dr HHHlf2St 1255 Dr CrashR
756 Pc CowBelRX11 856 Dr BdAnHard 956 Dr SdBhR1-3 1056 Dr SdRollMono 1156 Dr HHHlf2L 1256 Dr Crash
757 Pc CowBelAnCR 857 Dr BdLofi 957 Dr SdBh1L 1057 Dr SdBrMtSt 1157 Dr HHHlf2R 1257 Dr Crash2
758 Pc AnaShaker 858 Dr BdThkSkn 958 Dr SdBh1R 1058 Dr SdBrMtL 1158 Dr HHOp2St 1258 Dr RideSt
759 Pc TambrnRX5 859 Dr BdSlimy 959 Dr SdBh2L 1059 Dr SdBrMtR 1159 Dr HHOp2L 1259 Dr RideL
760 Pc TambrnAnCR 860 Dr SdNmSt1-4 960 Dr SdBh2R 1060 Dr SdBrMt2St 1160 Dr HHOp2R 1260 Dr RideR
761 Pc MarcsT8 861 Dr SdNmSt1-3 961 Dr SdBh3L 1061 Dr SdBrMt2L 1161 Dr HHClRkStSw 1261 Dr CupSt
762 Pc ClaveT8 862 Dr SdNmSt2-4 962 Dr SdBh3R 1062 Dr SdBrMt2R 1162 Dr HHClRkSSt 1262 Dr CupL
763 Pc AnaClick 863 Dr SdNmSt1-2 963 Dr SdLdwSt1-4 1063 Dr SdBrSwrSt 1163 Dr HHClRkHSt 1263 Dr CupR
764 Dr BdNmSt1-2 864 Dr SdNmSt2-3 964 Dr SdLdwSt1-3 1064 Dr SdBrSwrL 1164 Dr HHClRkLSw 1264 Dr RideMono
765 Dr BdNm1St 865 Dr SdNmSt3-4 965 Dr SdLdwSt2-4 1065 Dr SdBrSwrR 1165 Dr HHClRkRSw 1265 Dr CupMono
766 Dr BdNm2St 866 Dr SdNm1St 966 Dr SdLdwSt1-2 1066 Dr SdBSwrAtSt 1166 Dr HHClRkSL 1266 Dr CupMono2
767 Dr BdNmL1-2 867 Dr SdNm2St 967 Dr SdLdwSt2-3 1067 Dr SdBrSwrAtL 1167 Dr HHClRkSR 1267 Dr ChinaSt
768 Dr BdNmR1-2 868 Dr SdNm3St 968 Dr SdLdwSt3-4 1068 Dr SdBrSwrAtR 1168 Dr HHClRkHL 1268 Dr ChinaL
769 Dr BdNm1L 869 Dr SdNm4St 969 Dr SdLdw1St 1069 Dr SdT9-1 1169 Dr HHClRkHR 1269 Dr ChinaR
770 Dr BdNm1R 870 Dr SdNmL1-4 970 Dr SdLdw2St 1070 Dr SdT9-2 1170 Dr HHPdRkStSw 1270 Dr China
771 Dr BdNm2L 871 Dr SdNmR1-4 971 Dr SdLdw3St 1071 Dr SdT9-3 1171 Dr HHPdlRkLSw 1271 Dr SplashSt
772 Dr BdNm2R 872 Dr SdNm1L 972 Dr SdLdw4St 1072 Dr SdT9-4 1172 Dr HHPdlRkRSw 1272 Dr SplashL
773 Dr BdFkSt1-2 873 Dr SdNm1R 973 Dr SdLdwL1-4 1073 Dr SdT9-5 1173 Dr HHClRk2St 1273 Dr SplashR
774 Dr BdFk1St 874 Dr SdNm2L 974 Dr SdLdwR1-4 1074 Dr SdT9Gate 1174 Dr HHClRk2L 1274 Dr CrashT9
775 Dr BdFk2St 875 Dr SdNm2R 975 Dr SdLdw1L 1075 Dr SdT9Rim 1175 Dr HHClRk2R 1275 Dr CrashT8
776 Dr BdFkL1-2 876 Dr SdNm3L 976 Dr SdLdw1R 1076 Dr SdT8-1 1176 Dr HHPdlRkSt 1276 Dr CrashSyn
777 Dr BdFkR1-2 877 Dr SdNm3R 977 Dr SdLdw2L 1077 Dr SdT8-2 1177 Dr HHPdlRkL 1277 Dr RideT9
778 Dr BdFkML 878 Dr SdNm4L 978 Dr SdLdw2R 1078 Dr SdT8-3 1178 Dr HHPdlRkR 1278 Dr RevCymbal
779 Dr BdFkMR 879 Dr SdNm4R 979 Dr SdLdw3L 1079 Dr SdT8-4 1179 Dr HHOpRkStSw 1279 Dr HHClRL1-4
780 Dr BdFkHL 880 Dr SdFkSt1-3 980 Dr SdLdw3R 1080 Dr SdT8-5 1180 Dr HHOpRkSt 1280 Dr HHCl1RL
781 Dr BdFkHR 881 Dr SdFkSt1-2 981 Dr SdLdw4L 1081 Dr SdT8Rim 1181 Dr HHHfOpRkSt 1281 Dr HHCl2RL
782 Dr BdHiSt 882 Dr SdFkSt2-3 982 Dr SdLdw4R 1082 Dr SdAnSm 1182 Dr HHOpRkLSw 1282 Dr HHCl3RL
783 Dr BdHiL 883 Dr SdFkSt1/3 983 Dr SdHipSt1-2 1083 Dr SdAnSmRim 1183 Dr HHOpRkRSw 1283 Dr HHCl4RL
784 Dr BdHiR 884 Dr SdFk1St 984 Dr SdHip1St 1084 Dr SdAnCR 1184 Dr HHOpRkL 1284 Dr HHPdlRL
785 Dr BdLoSt 885 Dr SdFk2St 985 Dr SdHip2St 1085 Dr SdAnCRRim 1185 Dr HHOpRkR 1285 Dr HHOpRL
786 Dr BdLoL 886 Dr SdFk3St 986 Dr SdHipL1-2 1086 Dr SdHuman1 1186 Dr HHHlfOpRkL 1286 Dr HHClFtRL
787 Dr BdLoR 887 Dr SdFkL1-3 987 Dr SdHipR1-2 1087 Dr SdHuman2 1187 Dr HHHlfOpRkR 1287 Dr HHHlf2RL
788 Dr BdHSonSt 888 Dr SdFkR1-3 988 Dr SdHip1L 1088 Dr SdJngl1 1188 Dr HHClMono 1288 Dr HHOp2RL
789 Dr BdHSonL 889 Dr SdFk1L 989 Dr SdHip1R 1089 Dr SdJngl2 1189 Dr HHOpMono 1289 Dr HHClRkRLSw
790 Dr BdHSonR 890 Dr SdFk1R 990 Dr SdHip2L 1090 Dr SdJngl3 1190 Dr HHPdlMono 1290 Dr HHClRkSRL
791 Dr BdLSonSt 891 Dr SdFk2L 991 Dr SdHip2R 1091 Dr SdJnglFx 1191 Dr HHClT9 1291 Dr HHClRkHRL
792 Dr BdLSonL 892 Dr SdFk2R 992 Dr SdRkOp1St 1092 Dr SdD&B1 1192 Dr HHOpT9 1292 Dr HHPdRkRLSw
793 Dr BdLSonR 893 Dr SdFk3L 993 Dr SdRkOp1L 1093 Dr SdD&B2 1193 Dr HHClT8-1 1293 Dr HHClRk2RL
794 Dr BdFkSonSt 894 Dr SdFk3R 994 Dr SdRkOp1R 1094 Dr SdD&B3 1194 Dr HHOpT8-1 1294 Dr HHPdlRkRL
795 Dr BdFkSonL 895 Dr SdFkAySt 995 Dr SdRkMte1St 1095 Dr SdD&B4 1195 Dr HHClT8-2 1295 Dr HHOpRkRLSw
796 Dr BdFkSonR 896 Dr SdFkAyL 996 Dr SdRkMte1L 1096 Dr SdR&B1 1196 Dr HHOpT8-2 1296 Dr HHOpRkRL
797 Dr BdRk1St 897 Dr SdFkAyR 997 Dr SdRkMte2R 1097 Dr SdR&B1Rm 1197 Dr HHClRX5 1297 Dr HHHfOpRkRL
798 Dr BdRk1L 898 Dr SdBsSt1-3 998 Dr SdRkRim1St 1098 Dr SdR&B2 1198 Dr HHClAnCR 1298 Dr TomHiRL
799 Dr BdRk1R 899 Dr SdBsSt1-2 999 Dr SnRkRim1L 1099 Dr SdHip1 1199 Dr HHOpAnCR 1299 Dr TomMdRL
800 Dr BdRk2St 900 Dr SdBsSt2-3 1000 Dr SdRkRim1R 1100 Dr SdHip2 1200 Dr HHClBreak 1300 Dr TomLoRL
MR_DL1.book Page 24 Monday, January 6, 2003 11:10 AM
25
Multi List
User Multi (Factory default setting)
Multi Library List
Perf Bank Multi Bank
No. Name No. Name
1 Procession 65 MO's Song
2 GuitarRox 66 Sea Chill
3 SoulSpirit 67 RnB
4 LittleBear 68 R&B 1
5 BluesCruis 69 R&B 2
6 SmoothMood 70 Honeyz
7 PopR&B 71 M.T.
8 Iron Dance 72 Hip Hop 1
9 Futurism 73 Hip Hop 2
10 LittleFox 74 Rap
11 Big Jon 75 Top 40
12 Wnds&Strgs 76 New Pop
13 Waterfowl 77 Hip Folk
14 AN Split 78 DnB
15 Ba-PnoCmp 79 Dance
16 Funk Jam 80 House
17 Genesis 81 LDNhous
18 Race 82 UK House
19 Generation 83 Con.Disco
20 HopStringy 84 Disco
21 Minoru 85 Wonder
22 Utopia 86 SunRealxns
23 Islands 87 Club Chill
24 Ana Love 88 Ambi Pop
25 Superstrgs 89 Ballad
26 JazzGtTrio 90 Romance
27 AsianPad 91 EP Ballad
28 Grand+Dyno 92 80's AOR
29 Another 93 Americana1
30 HiPa Gruv 94 Americana2
31 Incomplete 95 NewCountry
32 ActionFlik 96 AcCountry
33 4x4 97 Fly Away
34 Hot Chili 98 Pop Rock
35 Grand+FM 99 NU-META
36 My House 100 Hard Rock
37 Paranoid 101 Prog Rock
38 80CompSplt 102 Altnativ 1
39 Warm Bell 103 Altnativ 2
40 Nobody 104 Forget.
41 Mukaiya 105 Syn-Girl
42 Pleiades 106 UK Rock
43 Mantra 107 Clean Rock
44 Quartet 108 Lush
45 LoneGitars 109 60's-ish
46 Tranzlot 110 Piano Rock
47 StringSect 111 Tech-Tranc
48 Hop It 112 Electronic
49 OnTheEarth 113 Psycho
50 UTAGE 114 Syn Motion
51 Romantic 2 115 Soundtrack
52 Talitha 116 Moody
53 MM Brass 117 Orchestral
54 Bebop Trio 118 Retro
55 Freedom 119 Funk Band
56 Philharmnc 120 Nu Brazil
57 Mo's SciFi 121 Acid Jazz
58 Lover 122 UK Soul
59 Ethno Jam 123 SmoothJazz
60 Coal 124 PianoTrio+
61 Velomuv 125 OrganTrio+
62 GuitarPad 126 Ethno Pop
63 Classical 127 French Pop
64 GreatWall 128 Clsicl Pop
No.
Category
Name No. Name
1 Br 2001BrsOrc 1 MO's Song
2 Co GuitarRox 2 Sea Chill
3 Co SoulSpirit 3 RnB
4 Me SynHeaven 4 R&B 1
5 Co BluesCruis 5 R&B 2
6 Co SmoothMood 6 Honeyz
7 Co Futurism 7 M.T.
8 St Wnds&Strgs 8 Hip Hop 1
9 Gt Rockn'Hill 9 Hip Hop 2
10 Me Waterfowl 10 Hip Hop 3
11 Co JourneyMan 11 Rap
12 Co Ba-PnoCmp 12 Top 40
13 Co Funk Jam 13 New Pop
14 Co ChinaEns 14 Hip Folk
15 Me Genesis 15 DnB
16 Co A Visit 16 Dance
17 Co Race 17 House
18 Co Generation 18 LDNhous
19 Co Heavy Jam 19 UK House
20 St Minoru 20 Con.Disco
21 Me Utopia 21 Disco
22 Co Islands 22 Wonder
23 Kb Romantic 1 23 SunRealxns
24 Co Afro/House 24 Club Chill
25 Pd Ana Love 25 Ambi Pop
26 St Superstrgs 26 Ballad
27 Co A dream 27 Romance
28 Gt VintString 28 EP Ballad
29 Co JazzGtTrio 29 80's AOR
30 Me AsianPad 30 Americana1
31 Ap Grand+Dyno 31 Americana2
32 St ActionFlik 32 NewCountry
33 Co Hot Chili 33 AcCountry
34 Ap Grand+FM 34 Fly Away
35 Co 80CompSplt 35 Pop Rock
36 Pd Warm Bell 36 NU-META
37 Co Nobody 37 Hard Rock
38 Kb Mukaiya 38 Prog Rock
39 St Quartet 39 Altnativ 1
40 Gt LoneGitars 40 Altnativ 2
41 Me Tranzlot 41 Forget.
42 St StringSect 42 Syn-Girl
43 Co Hop It 43 UK Rock
44 Co UTAGE 44 Clean Rock
45 Ap Romantic 2 45 Lush
46 Br MM Brass 46 60's-ish
47 Co Bebop Trio 47 Piano Rock
48 Co Freedom 48 Tech-Tranc
49 St Philharmnc 49 Syn Motion
50 Co GuitarMood 50 Soundtrack
51 Co Groovin'EP 51 Moody
52 Br BrassChord 52 Orchestral
53 Rp Sweet Ens 53 Retro
54 Br LatinBrass 54 Funk Band
55 Co Ethno Jam 55 Nu Brazil
56 Co Raga #5 56 Acid Jazz
57 Gt GuitarPad 57 UK Soul
58 Co Classical 58 SmoothJazz
59 Co GreatWall 59 PianoTrio+
60 OrganTrio+
61 Ethno Pop
62 Jpns Pop
63 French Pop
64 Clsicl Pop
65 GM set
MR_DL1.book Page 25 Monday, January 6, 2003 11:10 AM
26
Effect Type List
Effect Category Effect Name LCD MIDI(HEX) No.
MSB LSB REV CHO Ins1 Ins2
--- NO EFFECT off 00 00 0 0
--- THRU Thru 00 00 0 0
REV
HALL 1 Hall 1 01 00 9111
HALL 2 Hall 2 01 01 10 2 2 2
ROOM 1 Room 1 01 10 11 3 3 3
ROOM 2 Room 2 01 11 12 4 4 4
ROOM 3 Room 3 01 12 13 5 5 5
STAGE 1 Stage 1 01 20 14 6 6 6
STAGE 2 Stage 2 01 21 15 7 7 7
PLATE Plate 01 30 16 8 8 8
WHITE ROOM White Room 01 40 17
TUNNEL Tunnel 01 41 18
BASEMENT Basement 01 42 19
CANYON Canyon 01 43 20
R3 HALL R3 Hall 01 02 6
R3 ROOM R3 Room 01 13 7
R3 PLATE R3 Plate 01 31 8
LARGE HALL Large Hall 01 08 1
MIDIUM HALL MidiumHall 01 09 2
WARM ROOM Warm Room 01 18 3
WOODY ROOM Woody Room 01 19 4
RICH PLATE Rich Plate 01 38 5
DLY
DELAY L, C, R Delay LCR 02 00 9 9 9
DELAY L, R Delay L,R 02 10 10 10 10
DELAY L, R (STEREO) DelayLR St 02 18 11 11 11
ECHO Echo 02 20 12 12 12
CROSS DELAY CrossDelay 02 30 13 13 13
CONTROL DELAY (MONO) CtrlDelay1 02 40 14 14 14
CONTROL DELAY (STEREO) CtrlDelay2 02 48 15 15 15
TEMPO DELAY (MONO) TempoDly 1 02 50 16 16 16
TEMPO DELAY (STEREO) TempoDly 2 02 58 17 17 17
TEMPO CROSS DELAY TempoCrDly 02 60 18 18 18
ER
EARLY REFLECTION 1 EarlyRef 1 03 00 19 19 19
EARLY REFLECTION 2 EarlyRef 2 03 01 20 20 20
GATE REVERB Gate Rev 03 10 21 21 21
REVERSE GATE Revrs Gate 03 20 22 22 22
KAR
KARAOKE 1 Karaoke 1 04 00 23 23 23
KARAOKE 2 Karaoke 2 04 01 24 24 24
KARAOKE 3 Karaoke 3 04 02 25 25 25
CHO
CHORUS 1 Chorus 1 05 00 26 26 26
CHORUS 2 Chorus 2 05 01 27 27 27
CHORUS 3 Chorus 3 05 02 28 28 28
CHORUS 4 Chorus 4 05 08 29 29 29
CHORUS 5 Chorus 5 05 09 30 30 30
CELESTE 1 Celeste 1 05 10 31 31 31
CELESTE 2 Celeste 2 05 11 32 32 32
CELESTE 3 Celeste 3 05 12 33 33 33
CELESTE 4 Celeste 4 05 18 34 34 34
SYMPHONIC Symphonic 05 20 35 35 35
ENSEMBLE DETUNE Ensemble 05 30 36 36 36
FLG
FLANGER 1 Flanger 1 06 00 37 37 37
FLANGER 2 Flanger 2 06 01 38 38 38
FLANGER 3 Flanger 3 06 08 39 39 39
V-FLANGER V-Flanger 06 10 40 40 40
TEMPO FLANGER TmpFlanger 06 50 41 41 41
DYNAMIC FLANGER DynFlanger 06 60 42 42
PHA
PHASER 1 Phaser 1 07 00 42 43 43
PHASER 2 Phaser 2 07 08 43 44 44
TEMPO PHASER TmpPhaser 07 50 44 45 45
DYNAMIC PHASER DynPhaser 07 60 46 46
MR_DL1.book Page 26 Monday, January 6, 2003 11:10 AM
27
MOD
TREMOLO Tremolo 08 00 47 47
AUTO PAN Auto Pan 08 10 48 48
AUTO PAN2 Auto Pan 2 08 11 49 49
ROTARY SPEAKER RotarySp 1 08 50 50 50
DISTORTION+ROTARY SPEAKER Dist+Rot 1 08 51 51 51
OVERDRIVE+ROTARY SPEAKER Odrv+Rot 1 08 52 52 52
AMP SIM.+ROTARY SPEAKER Amp+Rot 1 08 53 53 53
2WAY ROTARY SPEAKER RotarySp 2 08 60 54 54
DISTORTION+2WAY ROTARY SPEAKER Dist+Rot 2 08 61 55 55
OVERDRIVE+2WAY ROTARY SPEAKER Odrv+Rot 2 08 62 56 56
AMP SIM.+2WAY ROTARY SPEAKER Amp+Rot 2 08 63 57 57
DUAL ROTOR SPEAKER1 DualRot 1 08 70 58 58
DUAL ROTOR SPEAKER2 DualRot 2 08 71 59 59
DUAL ROTOR SPEAKER3 DualRot 3 08 72 60 60
DST
DISTORTION Distortion 09 00 61 61
COMP DISTORTION Comp+Dist 09 01 62 62
VL DISTORTION V-Dist 09 10 63 63
OVER DRIVE Overdrive 09 20 64 64
AMP SIMULATOR AmpSim 09 30 65 65
AMP SIMULATOR2 AmpSim 2 09 31 66 66
DIST+DELAY Dist+Delay 09 40 67 67
OVERDRIVE+DELAY Odrv+Delay 09 41 68 68
DYN
COMPRESSOR Compressor 0A 00 69 69
MONO COMPRESSOR MonoComp 0A 08 70 70
NOISE GATE Noise Gate 0A 20 71 71
COMP+DIST+DELAY CmpDistDly 0A 40 72 72
COMP+OVERDRIVE+DELAY CmpOdrvDly 0A 41 73 73
MULTI BAND COMP 1 MltBndCmp1 0A 50 74 74
MULTI BAND COMP 2 MltBndCmp2 0A 51 75 75
PCH
PITCH CHANGE 1 PitchCng 1 0B 00 76 76
PITCH CHANGE 2 PitchCng 2 0B 01 77 77
WAH
AUTO WAH Auto Wah 0C 00 78 78
AUTO WAH + DIST A.Wah+Dist 0C 01 79 79
AUTO WAH + OVERDRIVE A.Wah+Odrv 0C 02 80 80
TOUCH WAH Touch Wah 0C 10 81 81
TOUCH WAH + DIST T.Wah+Dist 0C 11 82 82
TOUCH WAH + OVERDRIVE T.Wah+Odrv 0C 12 83 83
WAH+DIST+DELAY WahDistDly 0C 40 84 84
WAH+OVERDRIVE+DELAY WahOdrvDly 0C 41 85 85
L-F
LO-FI Lo-Fi 0D 00 86 86
LOW RESOLUTION Resolution 0D 10 87 87
NOISY Noisy 0D 20 88 88
ATTACK LOFI AttackLoFi 0D 30 89 89
DIGITAL TURNTABLE D.Turntbl 0D 50 90 90
TEC
DIGITAL SCRATCH D.Scratch 0E 00 91 91
AUTO SYNTH Auto Synth 0E 10 92 92
TECH MODULATION Tech Mod 0E 20 93 93
JUMP Jump 0E 30 94 94
ISOLATOR Isolator 0E 40 95 95
SLICE Slice 0E 50 96 96
MSC
3-BAND EQ 3 Band EQ 0F 00 97 97
2-BAND EQ 2 Band EQ 0F 01 98 98
HARMONIC ENHANCER Enhancer 0F 10 99 99
MONO HARMONIC ENHANCER MonoEnhanc 0F 18 100 100
VOICE CANCEL Voic Cancl 0F 20 101 101
AMBIENCE Ambience 0F 30 102 102
TALKING MODULATOR TalkingMod 0F 40 103 103
BEAT CHANGE BeatChange 0F 50 104 104
RING MODULATOR Ring Mod 0F 70 105 105
DYNAMIC RING MODULATOR DynRingMod 0F 71 106 106
DYNAMIC FILTER DynFilter 0F 78 107 107
Effect Category Effect Name LCD MIDI(HEX) No.
MSB LSB REV CHO Ins1 Ins2
MR_DL1.book Page 27 Monday, January 6, 2003 11:10 AM
28
Effect Parameter List
1. Reverb
Items indicated with a dot (●) in the CtrlSet Dest column are parameters that can
be controlled by external MIDI controllers (such as modulation wheel, aftertouch,
etc.) set in Control Set Destination.
[1] LARGE HALL – [5] RICH PLATE
[6] R3 HALL – [8] R3 PLATE, [9] HALL1 – [16] PLATE
[17] WHITE ROOM – [20] CANYON
2. Chorus/Insertion 1, 2
MIDI Parameter No.10 is available only for the Insertion Effects.
[1] HALL1 – [8] PLATE
[9] DELAY L, C, R
[10] DELAY L, R
[11] DELAY L, R (Stereo)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Reverb Time 0.3 – 30.0s 0 – 69 1 4
2 Diffusion 0 – 10 0 – 10 2
3 Initial Delay 0.1ms – 200.0ms 0 – 127 3 5
4 HPF Cutoff Frequency 20Hz – 8.0kHz 0 – 52 4 3
5 LPF Cutoff Frequency 1.0kHz – 20.0kHz 34 – 60 5 3
6 Room Size 0 – 31 0 – 31 6
7 High Ratio 0.1 – 1.0 1 – 10 7
8 Low Ratio 0.1 – 1.4 1 – 14 8
9 Decay 0 – 63 0 – 63 9
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Reverb time 0.3s – 30.0s 0 – 69 1 4
2 Diffusion 0 – 10 0 – 10 2
3 Initial delay 0.1ms – 200.0ms 0 – 127 3 5
4 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 4 3 ●
5 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 5 3 ●
6 Reverb delay 0.1ms – 200.0ms 0 – 127 11 5
7 Density 0 – 4 0 – 4 12
8 ER / rev balance E63>R – E=R – E<R63 1 – 127 13 ●
9 Feedback high damp 0.1 – 1.0 1 – 10 14
10 Feedback level -63 – +63 1 – 127 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Reverb time 0.3s – 30.0s 0 – 69 1 4
2 Diffusion 0 – 10 0 – 10 2
3 Initial delay 0.1ms – 200.0ms 0 – 127 3 5
4 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 4 3 ●
5 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 5 3 ●
6 Width 0.5m – 30.2m 0 – 104 6 11
7 Height 0.5m – 30.2m 0 – 104 7 11
8 Depth 0.5m – 30.2m 0 – 104 8 11
9 Wall vary 0 – 30 0 – 30 9
10 Reverb delay 0.1ms – 200.0ms 0 – 127 11 5
11 Density 0 – 4 0 – 4 12
12 ER / rev balance E63>R – E=R – E<R63 0 – 127 13 ●
13 Feedback high damp 0.1 – 1.0 1 – 10 14
14 Feedback level -63 – +63 0 – 127 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Reverb time 0.3s – 30.0s 0 – 69 1 4
3 Diffusion 0 – 10 0 – 10 2
4 Initial delay 0.1ms – 99.3ms 0 – 63 3 5
5 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 4 3 ●
6 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 5 3 ●
7 Reverb delay 0.1ms – 99.3ms 0 – 63 11 5
8 Density 0 – 4 0 – 4 12
9 ER / rev balance E63>R – E=R – E<R63 1 – 127 13 ●
10 Feedback high damp 0.1 – 1.0 1 – 10 14
11 Feedback level -63 – +63 1 – 127 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L 0.1ms – 1486.0ms 1 – 14860 1
3 Delay time R 0.1ms – 1486.0ms 1 – 14860 2
4 Delay time C 0.1ms – 1486.0ms 1 – 14860 3
5 Feedback time 0.1ms – 1486.0ms 1 – 14860 4
6 Feedback level -63 – +63 1 – 127 5 ●
7 Delay level C 0 – 127 0 – 127 6 ●
8 Feedback high damp 0.1 – 1.0 1 – 10 7 ●
9 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
10 EQ low gain -12dB – +12dB 52 – 76 14 ●
11 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
12 EQ high gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L 0.1ms – 1486.0ms 1 – 14860 1
3 Delay time R 0.1ms – 1486.0ms 1 – 14860 2
4 Feedback time 1 0.1ms – 1486.0ms 1 – 14860 3
5 Feedback time 2 0.1ms – 1486.0ms 1 – 14860 4
6 Feedback level -63 – +63 1 – 127 5 ●
7 Feedback high damp 0.1 – 1.0 1 – 10 6 ●
8 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
9 EQ low gain -12dB – +12dB 52 – 76 14 ●
10 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
11 EQ high gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L 0.1ms – 1486.0ms 1 – 14860 1
3 Delay time R 0.1ms – 1486.0ms 1 – 14860 2
4 Feedback time L 0.1ms – 1486.0ms 1 – 14860 3
5 Feedback time R 0.1ms – 1486.0ms 1 – 14860 4
6 Feedback level -63 – +63 1 – 127 5 ●
7 Feedback high damp 0.1 – 1.0 1 – 10 6 ●
8 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
9 EQ low gain -12dB – +12dB 52 – 76 14 ●
10 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
11 EQ high gain -12dB – +12dB 52 – 76 16 ●
MR_DL1.book Page 28 Monday, January 6, 2003 11:10 AM
29
[12] ECHO
[13] CROSS DELAY
[14] CONTROL DELAY 1 (mono)
[15] CONTROL DELAY 2 (stereo)
[16] TEMPO DELAY 1 (mono)
[17] TEMPO DELAY 2 (stereo)
[18] TEMPO CROSS DELAY
[19] – [20] EARLY REF 1 – 2
[21] GATE REVERB
[22] REVERSE GATE
[23] – [25] KARAOKE 1 – 3
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L1 0.1ms – 743.0ms 1 – 7430 1
3 Feedback level L -63 – +63 1 – 127 2 ●
4 Delay time R1 0.1ms – 743.0ms 1 – 7430 3
5 Feedback level R -63 – +63 1 – 127 4 ●
6 Feedback high damp 0.1 – 1.0 1 – 10 5 ●
7 Delay time L2 0.1ms – 743.0ms 1 – 7430 6
8 Delay time R2 0.1ms – 743.0ms 1 – 7430 7
9 Delay level 2 0 – 127 0 – 127 8 ●
10 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
11 EQ low gain -12dB – +12dB 52 – 76 14 ●
12 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
13 EQ high gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L>R 0.1ms – 743.0ms 1 – 7430 1
3 Delay time R>L 0.1ms – 743.0ms 1 – 7430 2
4 Feedback level -63 – +63 1 – 127 3 ●
5 Input select L, R, L&R 0 – 2 4
6 Feedback high damp 0.1 – 1.0 1 – 10 5 ●
7 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
8 EQ low gain -12dB – +12dB 52 – 76 14 ●
9 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
10 EQ high gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.1ms – 1486.0ms 1 – 14860 1 ●
3 Delay transition rate 1 – 48 1 – 48 2 ●
4 Feedback level -63 – +63 1 – 127 3 ●
5 Feedback high damp 0.1 – 1.0 4 ●
6 Delay time offset 0 – 127 0 – 127 5
7 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ low gain -12dB – +12dB 52 – 76 7 ●
9 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
10 EQ high gain -12dB – +12dB 52 – 76 9 ●
11 Control Type normal, scratch 0 – 1 11 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.1ms – 743.0ms 1 – 7430 1 ●
3 Delay transition rate 1 – 48 1 – 48 2 ●
4 Feedback level -63 – +63 1 – 127 3 ●
5 Feedback high damp 0.1 – 1.0 1 – 10 4 ●
6 Delay time offset 0 – 127 0 – 127 5
7 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ low gain -12dB – +12dB 52 – 76 7 ●
9 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
10 EQ high gain -12dB – +12dB 52 – 76 9 ●
11 Control Type normal, scratch 0 – 1 11 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay Time 64th/3 – 4thx6 0 – 19 1 12
3 Feedback Level -63 – +63 1 – 127 2 ●
4 Feedback High Dump 0.1 – 1.0 1 – 10 3 ●
5 L/R Diffusion -63ms – +63ms 1 – 127 4
6 Lag -63ms – +63ms 1 – 127 5
7 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
8 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
9 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
10 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay Time 64th/3 – 4thx6 0 – 19 1 12
3 Feedback Level -63 – +63 1 – 127 2 ●
4 Feedback High Dump 0.1 – 1.0 1 – 10 3 ●
5 L/R Diffusion -63ms – +63ms 1 – 127 4
6 Lag -63ms – +63ms 1 – 127 5
7 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
8 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
9 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
10 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay Time L>R 64th/3 – 4thx6 0 – 19 1 12
3 Delay Time R>L 64th/3 – 4thx6 0 – 19 2 12
4 Feedback Level -63 – +63 1 – 127 3 ●
5 45. Input Select L, R, L&R 0 – 2 4
6 Feedback High Dump 0.1 – 1.0 1 – 10 5 ●
7 Lag -63ms – +63ms 1 – 127 6
8 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
9 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
10 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
11 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Type S-hall, L-hall, random,
reverse, plate, spring
0 – 5 1
3 Room size 0.1 – 20.0 0 – 127 2 6
4 Diffusion 0 – 10 0 – 10 3
5 Initial delay 0.1ms – 200.0ms 0 – 127 4 5
6 Feedback level -63 – +63 1 – 127 5 ●
7 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 6 3 ●
8 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 7 3 ●
9 Liveness 0 – 10 0 – 10 11
10 Density 0 – 3 0 – 3 12
11 Feedback high damp 0.1 – 1.0 1 – 10 13
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Type type-A, type-B 0 – 1 1
3 Room size 0.1 – 20.0 0 – 127 2 6
4 Diffusion 0 – 10 0 – 10 3
5 Initial delay 0.1ms – 200.0ms 0 – 127 4 5
6 Feedback level -63 – +63 1 – 127 5 ●
7 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 6 3 ●
8 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 7 3 ●
9 Liveness 0 – 10 0 – 10 11
10 Density 0 – 3 0 – 3 12
11 Feedback high damp 0.1 – 1.0 1 – 10 13
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.1ms – 400.0ms 0 – 127 1 7
3 Feedback level -63 – +63 1 – 127 2 ●
4 HPF cutoff frequency 20Hz – 8.0kHz 0 – 52 3 3 ●
5 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 4 3 ●
6 Density 0 – 3 0 – 3 11
MR_DL1.book Page 29 Monday, January 6, 2003 11:10 AM
30
[26] – [30] CHORUS 1 – 5
[31] – [34] CELESTE 1 – 4
[35] SYMPHONIC
[36] ENSEMBLE DETUNE
[37] – [39] FLANGER 1 – 3
[40] V-FLANGER
[41] TEMPO FLANGER
[42] DYNAMIC FLANGER (Insertion Block Only)
[43] PHASER 1
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Feedback level -63 – +63 1 – 127 3 ●
5 Delay offset 0.0ms – 50.0ms 0 – 127 4 2
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
10 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
11 EQ mid gain -12dB – +12dB 52 – 76 12 ●
12 EQ mid width 0.1 – 12.0 1 – 120 13 ●
13 Input mode mono/stereo 0 – 1 15
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Delay offset 0.0ms – 50.0ms 0 – 127 3 2
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 7 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 9 ●
9 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
10 EQ mid gain -12dB – +12dB 52 – 76 12 ●
11 EQ mid width 0.1 – 12.0 1 – 120 13 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Detune -50cent – +50cent 14 – 114 1
3 Initial delay Lch 0.0ms – 50.0ms 0 – 127 2 2
4 Initial delay Rch 0.0ms – 50.0ms 0 – 127 3 2
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 11 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 12 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 13 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 14 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Feedback level -63 – +63 1 – 127 3 ●
5 Delay offset 0.0ms – 50.0ms 0 – 127 4 2
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
10 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
11 EQ mid gain -12dB – +12dB 52 – 76 12 ●
12 EQ mid width 0.1 – 12.0 1 – 120 13 ●
13 LFO phase difference -180deg – +180deg 4 – 124 14
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 LFO Wave Triangle, Sine, Random 0 – 2 3
5 Delay offset 0.09 – 36.21ms 0 – 139 4
6 Feedback Level -100 – +100% 0 – 200 5 ●
7 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ low gain -12dB – +12dB 52 – 76 7 ●
9 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
10 EQ high gain -12dB – +12dB 52 – 76 9 ●
11 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
12 EQ mid gain -12dB – +12dB 52 – 76 12 ●
13 EQ mid width 0.1 – 12.0 1 – 120 13 ●
14 Modulation Phase -180 – +180 0 – 16 14 13
15 Feedback high damp 0.1 – 1.0 1 – 10 15 ●
16 Analog Feel 0 – 10 0 – 10 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 16th, 8th/3, 16th., 8th,
4th/3, 8th., 4th, 2nd/3,
4th., 2nd, Whole/3, 2nd.,
4thx4, 4thx5, 4thx6,
4thx7, 4thx8
5 – 21 1 12 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 feedback level -63 – +63 1 – 127 3 ●
5 delay offset 0.0ms – 50.0ms 0 – 127 4 2
6 LFO Phase Reset off (free run),
KeyOnReset,
SEQ Start Reset
0 – 2 5
7 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
9 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
10 EQ High Gain -12dB – +12dB 52 – 76 9 ●
11 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
12 EQ mid gain -12dB – +12dB 52 – 76 12 ●
13 EQ mid width 0.1 – 12.0 1 – 120 13 ●
14 LFO phase difference -180deg – +180deg 4 – 124 14
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / Wet Balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitivity 0 – 127 0 – 127 1 ●
3 Delay Time Offset 0 – 127 0 – 127 2
4 Feedback Level -63 – +63 1 – 127 3 ●
5 Attack Time 0.3ms – 227ms 0 – 127 4 ●
6 Release Time 2.6ms – 2171ms 0 – 127 5 ●
7 Release Curve 0 – 127 0 – 127 6
8 Direction up, down 0 – 1 7
9 Dyna Threshold Level 0 – 127 0 – 127 8 ●
10 Dyna Level Offset 0 – 127 0 – 127 9 ●
11 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
12 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
13 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
14 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Phase shift offset 0 – 127 0 – 127 3
5 Feedback level -63 – +63 1 – 127 4 ●
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
10 Stage 4 – 22 4 – 22 11 ●
11 Diffusion mono/stereo 0 – 1 12
MR_DL1.book Page 30 Monday, January 6, 2003 11:10 AM
31
[44] PHASER 2
[45] TEMPO PHASER
[46] DYNAMIC PHASER (Insertion Block Only)
[47] TREMOLO (Insertion Block Only)
[48] AUTO PAN (Insertion Block Only)
[49] AUTO PAN 2 (Insertion Block Only)
[50] ROTARY SPEAKER 1 (Insertion Block Only)
[51] DISTORTION + ROTARY SPEAKER (Insertion Block Only)
[52] OVERDRIVE + ROTARY SPEAKER (Insertion Block Only)
[53] AMP SIMULATOR + ROTARY SPEAKER (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Phase shift offset 0 – 127 0 – 127 3
5 Feedback level -63 – +63 1 – 127 4 ●
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
10 Stage 3 – 11 3 – 11 11 ●
11 LFO phase difference -180deg – +180deg 4 – 124 13
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 16th, 8th/3, 16th., 8th,
4th/3, 8th., 4th, 2nd/3,
4th., 2nd, Whole/3, 2nd.,
4thx4, 4thx5, 4thx6,
4thx7, 4thx8
5 – 21 1 12 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Phase shift offset 0 – 127 0 – 127 3
5 Feedback level -63 – +63 1 – 127 4 ●
6 LFO Phase Reset off (free run),
KeyOnReset,
SEQ Start Reset
0 – 2 5
7 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
9 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
10 EQ High Gain -12dB – +12dB 52 – 76 9 ●
11 Stage 3 – 11 3 – 11 11 ●
12 LFO phase difference -180deg – +180deg 4 – 124 13
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / Wet Balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitivity 0 – 127 0 – 127 1 ●
3 Dyna Level Offset 0 – 127 0 – 127 2 ●
4 Feedback Level -63 – +63 1 – 127 3 ●
5 Attack Time 0.3ms – 227ms 0 – 127 4 ●
6 Release Time 2.6ms – 2171ms 0 – 127 5 ●
7 Release Curve 0 – 127 0 – 127 6
8 Direction up, down 0 – 1 7
9 Dyna Threshold Level 0 – 127 0 – 127 8 ●
10 Stage 4, 5, 6 4 – 6 11
11 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
12 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
13 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
14 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 AM depth 0 – 127 0 – 127 2 ●
3 PM depth 0 – 127 0 – 127 3 ●
4 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
5 EQ low gain -12dB – +12dB 52 – 76 7 ●
6 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
7 EQ high gain -12dB – +12dB 52 – 76 9 ●
8 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
9 EQ mid gain -12dB – +12dB 52 – 76 12 ●
10 EQ mid width 0.1 – 12.0 1 – 120 13 ●
11 LFO phase difference -180deg – +180deg 4 – 124 14
12 Input mode mono/stereo 0 – 1 15
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 L/R depth 0 – 127 0 – 127 2 ●
3 F/R depth 0 – 127 0 – 127 3 ●
4 PAN direction L<>R, L>>R, L<<R,
Lturn, Rturn, L/R (0 – 5)
0 – 5 4
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 7 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 9 ●
9 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
10 EQ mid gain -12dB – +12dB 52 – 76 12 ●
11 EQ mid width 0.1 – 12.0 1 – 120 13 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 L/R depth 0 – 127 0 – 127 2 ●
3 F/R depth 0 – 127 0 – 127 3 ●
4 PAN direction L<>R, L>>R, L<<R,
Lturn, Rturn, L/R (0 – 5)
0 – 5 4
5 LFO Wave 0 – 28 0 – 28 5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ High Gain -12dB – +12dB 52 – 76 9 ●
10 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
11 EQ mid gain -12dB – +12dB 52 – 76 12 ●
12 EQ mid width 0.1 – 12.0 1 – 120 13 ●
13 Input Mode Mono/Stereo 0 – 1 15
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
5 EQ low gain -12dB – +12dB 52 – 76 7 ●
6 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
7 EQ high gain -12dB – +12dB 52 – 76 9 ●
8 EQ mid frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
9 EQ mid gain -12dB – +12dB 52 – 76 12 ●
10 EQ mid width 0.1 – 12.0 1 – 120 13 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 LFO Depth 0 – 127 0 – 127 2 ●
3 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
4 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
5 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
6 EQ High Gain -12dB – +12dB 52 – 76 9 ●
7 Dist. Drive 0 – 127 0 – 127 14 ●
8 Dist. LPF Cutoff Freq 1.0kHz – 20.0kHz 34 – 60 15 3 ●
9 Dist. Output Level 0 – 127 0 – 127 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 LFO Depth 0 – 127 0 – 127 2 ●
3 AMP Type off, stack, combo, tube 0 – 3 3
4 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 ●
5 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
6 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
7 EQ High Gain -12dB – +12dB 52 – 76 9 ●
8 AMP Drive 0 – 127 0 – 127 14 ●
9 AMP LPF Cutoff Freq 1.0kHz – 20.0kHz 34 – 60 15 3 ●
10 AMP Output Level 0 – 127 0 – 127 16 ●
MR_DL1.book Page 31 Monday, January 6, 2003 11:10 AM
32
[54] 2WAY ROTARY SPEAKER 1 (Insertion Block Only)
[55] DISTORTION + 2WAY ROTARY SPEAKER (Insertion Block Only)
[56] OVERDRIVE + 2WAY ROTARY SPEAKER (Insertion Block Only)
[57] AMP SIM. + 2WAY ROTARY SPEAKER (Insertion Block Only)
[58] 2WAY ROTARY SPEAKER 2 (DUAL ROTARY SPEAKER 1) (Insertion Block Only)
[59] 2WAY ROTARY SPEAKER 3 (DUAL ROTARY SPEAKER 2) (Insertion Block Only)
[60] DUAL ROTARY SPEAKER 3 (Insertion Block Only)
[61] DISTORTION (Insertion Block Only)
[64] OVERDRIVE (Insertion Block Only)
[62] COMP DISTORTION (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 Drive low 0 – 127 0 – 127 2 ●
3 Drive high 0 – 127 0 – 127 3 ●
4 Low / high balance L63>H – L=H – L<H63 1 – 127 4 ●
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 7 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 9 ●
9 Divide frequency 100Hz – 10.0kHz 14 – 54 11 3
10 Mic L-R angle (0 – 60)*3 12
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor Speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 Drive Low 0 – 127 0 – 127 2 ●
3 Drive High 0 – 127 0 – 127 3 ●
4 Low/High Balance L63>H – L=H – L<H63 1 – 127 4 ●
5 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
7 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ High Gain -12dB – +12dB 52 – 76 9 ●
9 Divide frequency 100Hz – 10.0kHz 14 – 54 11 3
10 Mic L-R Angle 0deg – 180deg 0 – 60 12
11 Dist. Drive 0 – 127 0 – 127 14 ●
12 Dist. LPF Cutoff Freq 1.0kHz – 20.0kHz 34 – 60 15 3 ●
13 Dist. Output Level 0 – 127 0 – 127 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor Speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
2 Drive Low 0 – 127 0 – 127 2 ●
3 Drive High 0 – 127 0 – 127 3 ●
4 Low/High Balance L63>H – L=H – L<H63 1 – 127 4 ●
5 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ Low Gain -12dB – +12dB 52 – 76 7 ●
7 EQ High Frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ High Gain -12dB – +12dB 52 – 76 9 ●
9 Divide Frequency 100Hz – 10.0kHz 14 – 54 11 3
10 Mic L-R Angle 0deg – 180deg 0 – 60 12
11 AMP Type off, stack, combo, tube 0 – 3 13
12 AMP Drive 0 – 127 0 – 127 14 ●
13 AMP LPF Cutoff Freq 1.0kHz – 20.0kHz 34 – 60 15 3 ●
14 AMP Output Level 0 – 127 0 – 127 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor Speed Slow 0.0Hz – 2.65Hz 0 – 63 1 1 ●
2 Horn Speed Slow 0.0Hz – 2.65Hz 0 – 63 2 1 ●
3 Rotor Speed Fast 2.69Hz – 39.70Hz 64 – 127 3 1 ●
4 Horn Speed Fast 2.69Hz – 39.70Hz 64 – 127 4 1 ●
5 Slow-Fast Time of R 0 – 127 0 – 127 5 ●
6 Slow-Fast Time of H 0 – 127 0 – 127 6 ●
7 Drive Low 0 – 127 0 – 127 7 ●
8 Drive High 0 – 127 0 – 127 8 ●
9 Low/High Balance L63>H – L=H – L<H63 1 – 127 9 ●
10 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 11 3 ●
11 EQ Low Gain -12dB – +12dB 52 – 76 12 ●
12 EQ High Frequency 500Hz – 16.0kHz 28 – 58 13 3 ●
13 EQ High Gain -12dB – +12dB 52 – 76 14 ●
14 Mic L-R Angle 0deg – 180deg 0 – 60 15
15 Speed Control slow, fast 0 – 1 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor Speed Slow 0.0Hz – 2.65Hz 0 – 63 1 1 ●
2 Horn Speed Slow 0.0Hz – 2.65Hz 0 – 63 2 1 ●
3 Rotor Speed Fast 2.69Hz – 39.70Hz 64 – 127 3 1 ●
4 Horn Speed Fast 2.69Hz – 39.70Hz 64 – 127 4 1 ●
5 Slow-Fast Time of R 0 – 127 0 – 127 5 ●
6 Slow-Fast Time of H 0 – 127 0 – 127 6 ●
7 Drive Low 0 – 127 0 – 127 7 ●
8 Drive High 0 – 127 0 – 127 8 ●
9 Low/High Balance L63>H – L=H – L<H63 1 – 127 9 ●
10 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 11 3 ●
11 EQ Low Gain -12dB – +12dB 52 – 76 12 ●
12 EQ High Frequency 500Hz – 16.0kHz 28 – 58 13 3 ●
13 EQ High Gain -12dB – +12dB 52 – 76 14 ●
14 Mic L-R Angle 0deg – 180deg 0 – 60 15
15 Speed Control slow, fast 0 – 1 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Rotor Speed Slow 0.0Hz – 2.65Hz 0 – 63 1 1 ●
2 Horn Speed Slow 0.0Hz – 2.65Hz 0 – 63 2 1 ●
3 Rotor Speed Fast 2.69Hz – 39.70Hz 64 – 127 3 1 ●
4 Horn Speed Fast 2.69Hz – 39.70Hz 64 – 127 4 1 ●
5 Slow-Fast Time of R 0 – 127 0 – 127 5 ●
6 Slow-Fast Time of H 0 – 127 0 – 127 6 ●
7 Drive Low 0 – 127 0 – 127 7 ●
8 Drive High 0 – 127 0 – 127 8 ●
9 Low/High Balance L63>H – L=H – L<H63 1 – 127 9 ●
10 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 11 3 ●
11 EQ Low Gain -12dB – +12dB 52 – 76 12 ●
12 EQ High Frequency 500Hz – 16.0kHz 28 – 58 13 3 ●
13 EQ High Gain -12dB – +12dB 52 – 76 14 ●
14 Mic L-R Angle 0deg – 180deg 0 – 60 15
15 Speed Control slow, fast 0 – 1 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Drive 0 – 127 0 – 127 1 ●
3 EQ low frequency 32Hz – 2.0kHz 4 – 40 2 3 ●
4 EQ low gain -12dB – +12dB 52 – 76 3 ●
5 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 4 3 ●
6 Output level 0 – 127 0 – 127 5 ●
7 EQ mid frequency 100Hz – 10.0kHz 14 – 54 7 3 ●
8 EQ mid gain -12dB – +12dB 52 – 76 8 ●
9 EQ mid width 0.1 – 12.0 1 – 120 9 ●
10 Edge 0 – 127 0 – 127 11 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Drive 0 – 127 0 – 127 1 ●
3 EQ low frequency 32Hz – 2.0kHz 4 – 40 2 3 ●
4 EQ low gain -12dB – +12dB 52 – 76 3 ●
5 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 4 3 ●
6 Output level 0 – 127 0 – 127 5 ●
7 EQ mid frequency 100Hz – 10.0kHz 14 – 54 7 3 ●
8 EQ mid gain -12dB – +12dB 52 – 76 8 ●
9 EQ mid width 0.1 – 12.0 1 – 120 9 ●
10 Edge 0 – 127 0 – 127 11 ●
11 Attack 1ms – 40ms 0 – 19 12 8 ●
12 Release 10ms – 680ms 0 – 15 13 9 ●
13 Threshold -48dB – '-6dB 79 – 121 14 ●
14 Ratio 1 – 20.0 0 – 7 15 10 ●
MR_DL1.book Page 32 Monday, January 6, 2003 11:10 AM
33
[63] V-Distortion (Insertion Block Only)
[65] AMP SIMULATOR (Insertion Block Only)
[66] AMP SIMULATOR 2 (Insetion Block Only)
[67] DIST + DELAY (Insertion Block Only)
[68] OVERDRIVE + DELAY (Insertion Block Only)
[69] COMPRESSOR (Insertion Block Only)
[70] MONO COMPRESSOR (Insertion Block Only)
[71] NOISE GATE (Insertion Block Only)
[72] COMP + DIST + DELAY (Insertion Block Only)
[73] COMP + ODRV + DELAY (Insertion Block Only)
[74] MULTI BAND COMP 1 (Insertion Block Only)
[75] MULTI BAND COMP 2 (Insertion Block Only)
[76] PITCH CHANGE 1 (Insertion Block Only)
[77] PITCH CHANGE 2 (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Over Drive 0 – 100% 0 – 100 1 ●
3 Device tr, tube, dist1, dist2, fuzz 0 – 4 2
4 Speaker Type Flat, Stack, Combo, Twin,
Radio, Megaphone
0 – 5 3
5 Presence -10 – 10 0 – 20 4 ●
6 Output Level 0 – 100% 0 – 100 5 ●
7 Delay Time L 0.1ms – 1486.0ms 1 – 14860 6
8 Delay Time R 0.1ms – 1486.0ms 1 – 14860 7
9 Feedback Time 0.1ms – 1486.0ms 1 – 14860 8
10 Feedback Level -63 – +63 1 – 127 9 ●
11 Delay Mix 0 – 127 0 – 127 11 ●
12 Feedback High Damp 0.1 – 1.0 1 – 10 12 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Drive 0 – 127 0 – 127 1 ●
3 AMP type off, stack, combo, tube 0 – 3 2
4 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 3 3 ●
5 Output level 0 – 127 0 – 127 4 ●
6 Edge 0 – 127 0 – 127 11 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Drive 0 – 127 0 – 127 1 ●
3 AMP type off, stack, combo, tube,
crunch, hi gain, british
0 – 6 2
4 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 3 3 ●
5 Output level 0 – 127 0 – 127 4 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time L 0.1ms – 1486.0ms 1 – 14860 1
3 Delay time R 0.1ms – 1486.0ms 1 – 14860 2
4 Delay feedback time 0.1ms – 1486.0ms 1 – 14860 3
5 Delay feedback level -63 – +63 1 – 127 4 ●
6 Delay mix 0 – 127 0 – 127 5 ●
7 Dist. drive 0 – 127 0 – 127 6 ●
8 Dist output level 0 – 127 0 – 127 7 ●
9 Dist. EQ low gain -12dB – +12dB 52 – 76 8 ●
10 Dist. EQ mid gain -12dB – +12dB 52 – 76 9 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Attack 1ms – 40ms 0 – 19 1 8 ●
2 Release 10ms – 680ms 0 – 15 2 9 ●
3 Threshold -48dB – -6dB 79 – 121 3 ●
4 Ratio 1 – 20.0 0 – 7 4 10 ●
5 Output level 0 – 127 0 – 127 5 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Attack 1ms – 40ms 0 – 19 1 8 ●
2 Release 10ms – 680ms 0 – 15 2 9 ●
3 Threshold -48dB – -6dB 79 – 121 3 ●
4 Ratio 1 – 20.0 0 – 7 4 10 ●
5 Output level 0 – 127 0 – 127 5 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Attack 1ms – 40ms 0 – 19 1 8 ●
2 Release 10ms – 680ms 0 – 15 2 9 ●
3 Threshold -72dB – -30dB 55 – 97 3 ●
4 Output level 0 – 127 0 – 127 4 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.1ms – 1486.0ms 1 – 14860 1
3 Delay feedback level -63 – +63 1 – 127 2 ●
4 Delay mix 0 – 127 0 – 127 3 ●
5 Dist. drive 0 – 127 0 – 127 4 ●
6 Dist output level 0 – 127 0 – 127 5 ●
7 Dist. EQ low gain -12dB – +12dB 52 – 76 6 ●
8 Dist. EQ mid gain -12dB – +12dB 52 – 76 7 ●
9 Comp. attack 1ms – 40ms 0 – 19 11 8 ●
10 Comp. release 10ms – 680ms 0 – 15 12 9 ●
11 Comp. threshold -48dB – -6dB 79 – 121 13 ●
12 Comp. ratio 1 – 20.0 0 – 7 14 10 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Type
Normal, Low, Mid, High,
Low/High, Low/Mid, Mid/
High, Full Bit, Wild, Attacky,
Low End, Hard, Basic
0 – 12 1
2 Threshold Offset -32 – +32 32 – 96 2 ●
3 Low Gain Offset -63 – +63 1 – 127 3 ●
4 Mid Gain Offset -63 – +63 1 – 127 4 ●
5 High Gain Offset -63 – +63 1 – 127 5 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Mid Gain -∞ – +18dB 0 – 55 10 14 ●
2 Low Attack 1ms – 200ms 0 – 29 1 8 ●
3 Low Release 10ms – 3000ms 0 – 23 2 9 ●
4 Low Threshold -54dB – -6dB 73 – 121 3 ●
5 Low Ratio 1 – 20.0 0 – 7 4 10 ●
6 Low Gain -∞ – +18dB 0 – 55 5 14 ●
7 Mid Attack 1ms – 200ms 0 – 29 6 8 ●
8 Mid Release 10ms – 3000ms 0 – 23 7 9 ●
9 Mid Threshold -54dB – -6dB 73 – 121 8 ●
10 Mid Ratio 1 – 20.0 0 – 7 9 10 ●
11 High Attack 1ms – 200ms 0 – 29 11 8 ●
12 High Release 10ms – 3000ms 0 – 23 12 9 ●
13 High Threshold -54dB – -6dB 73 – 121 13 ●
14 High Ratio 1 – 20.0 0 – 7 14 10 ●
15 High Gain -∞ – +18dB 0 – 55 15 14 ●
16 Divide Freq 0 – 89 0 – 89 16 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Pitch -24 – +24 40 – 88 1
3 Initial delay 0.1ms – 400.0ms 0 – 127 2 7
4 Fine1 -50 – +50 14 – 114 3
5 Fine2 -50 – +50 14 – 114 4
6 Feedback level -63 – +63 1 – 127 5 ●
7 PAN1 L63 – C – R63 1 – 127 11 ●
8 Output level1 0 – 127 0 – 127 12 ●
9 PAN2 L63 – C – R63 1 – 127 13 ●
10 Output level2 0 – 127 0 – 127 14 ●
MR_DL1.book Page 33 Monday, January 6, 2003 11:10 AM
34
[78] AUTO WAH (Insertion Block Only)
[79] AUTO WAH DISTORTION (Insertion Block Only)
[80] AUTO WAH OVERDRIVE (Insertion Block Only)
[81] TOUCH WAH (Insertion Block Only)
[82] TOUCH WAH DISTORTION (Insertion Block Only)
[83] TOUCH WAH OVERDRIVE (Insertion Block Only)
[84] WAH + DIST + DELAY (Insertion Block Only)
[85] WAH + ODRV + DELAY (Insertion Block Only)
[86] LO-FI (Insertion Block Only)
[87] LOW RESOLUTION (Insertion Block Only)
[88] NOISY (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Cutoff frequency offset 0 – 127 0 – 127 3 ●
5 Resonance 1 – 12.0 10 – 120 4 ●
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 LFO speed 0.0Hz – 39.70Hz 0 – 127 1 1 ●
3 LFO depth 0 – 127 0 – 127 2 ●
4 Cutoff frequency offset 0 – 127 0 – 127 3 ●
5 Resonance 1 – 12.0 10 – 120 4 ●
6 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
7 EQ low gain -12dB – +12dB 52 – 76 7 ●
8 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
9 EQ high gain -12dB – +12dB 52 – 76 9 ●
10 Drive 0 – 127 0 – 127 11 ●
11 Dist low gain -12dB – +12dB 52 – 76 12 ●
12 Dist mid gain -12dB – +12dB 52 – 76 13 ●
13 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 14 3 ●
14 Output level 0 – 127 0 – 127 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitive 0 – 127 0 – 127 1 ●
3 Cutoff frequency offset 0 – 127 0 – 127 2 ●
4 Resonance 1 – 12.0 10 – 120 3 ●
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 7 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 9 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitive 0 – 127 0 – 127 1 ●
3 Cutoff frequency offset 0 – 127 0 – 127 2 ●
4 Resonance 1 – 12.0 10 – 120 3 ●
5 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
6 EQ low gain -12dB – +12dB 52 – 76 7 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
8 EQ high gain -12dB – +12dB 52 – 76 9 ●
9 Drive 0 – 127 0 – 127 11 ●
10 Dist low gain -12dB – +12dB 52 – 76 12 ●
11 Dist mid gain -12dB – +12dB 52 – 76 13 ●
12 LPF cutoff frequency 1.0kHz – 20.0kHz 34 – 60 14 3 ●
13 Output level 0 – 127 0 – 127 15 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.1ms – 1486.0ms 1 – 14860 1
3 Delay feedback level -63 – +63 1 – 127 2 ●
4 Delay mix 0 – 127 0 – 127 3 ●
5 Dist. drive 0 – 127 0 – 127 4 ●
6 Dist output level 0 – 127 0 – 127 5 ●
7 Dist. EQ low gain -12dB – +12dB 52 – 76 6 ●
8 Dist. EQ mid gain -12dB – +12dB 52 – 76 7 ●
9 Wah sensitive 0 – 127 0 – 127 11 ●
10 Wah cutoff frequency 0 – 127 0 – 127 12 ●
11 Wah resonance 1 – 12.0 10 – 120 13 ●
12 Wah release 10ms – 680ms 52 – 67 14 9 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sampling Freq. Control 44.1kHz – 344Hz 0 – 127 1 ●
3 Word Length 1 – 127 1 – 127 2 ●
4 Output Gain -6dB – +36dB 0 – 42 3 ●
5 Pre-LPF Cutoff Frequency 63Hz – 20.0kHz 10 – 60 4 3 ●
6 Filter Type thru, PowerBass, Radio,
Telephone, Clean, Low
0 – 5 5
7 Pre-LPF Resonance 1 – 12.0 10 – 120 6 ●
8 Bit Assign 0 – 6 0 – 6 7
9 Emphasis off/on 0 – 1 8
10 Input mode mono/stereo 0 – 1 15
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Mod Depth 0 – 127 0 – 127 1 ●
3 Mod Delay Offset 1 – 127 1 – 127 2
4 Mod Feedback -63 – +63 1 – 127 3 ●
5 Resolution 1, 1/2 – 1/128 0 – 7 4
6 Mod Mix Balance 0 – 127 0 – 127 5 ●
7 Phase Inverse R off, wet, wet+dry 0 – 2 6
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Mod Depth 0 – 10 0 – 10 1 ●
3 Mod Speed 0 – 127 0 – 127 2 ●
4 Mod Feedback -63 – +63 1 – 127 3 ●
5 Mod Mix Balance 1 – 127 1 – 127 4 ●
6 Drive 0 – 127 0 – 127 5 ●
7 AM Speed 0.00Hz – 39.7Hz 0 – 127 6 1 ●
8 AM Depth 0 – 127 0 – 127 7 ●
9 LPF Frequency 1.0kHz – 20.0kHz 34 – 60 8 3 ●
10 LPF Resonance 1.0 – 12.0 10 – 120 9 ●
11 EQ Frequency 100Hz – 10.0kHz 14 – 54 11 3 ●
12 EQ Gain -12 – +12dB 52 – 76 12 ●
13 EQ Width 1.0 – 12.0 10 – 120 13 ●
MR_DL1.book Page 34 Monday, January 6, 2003 11:10 AM
35
[89] ATTACK LOFI (Insertion Block Only)
[90] DIGITAL TURNTABLE (Insertion Block Only)
[91] DIGITAL SCRATCH (Insertion Block Only)
[92] AUTO SYNTH (Insertion Block Only)
[93] TECH MODULATION (Insertion Block Only)
[94] JUMP (Insertion Block Only)
[95] ISOLATOR (Insertion Block Only)
[96] SLICE (Insertion Block Only)
[97] 3BAND EQ (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitive 0 – 127 0 – 127 1 ●
3 Resolution 1,1/2 – 1/32 0 – 5 2
4 Peak Frequency 100Hz – 10.0kHz 14 – 54 3 3 ●
5 LPF Frequency 1.0kHz – 20.0kHz 34 – 60 4 3 ●
6 Flanger Speed 0.00Hz – 39.7Hz 0 – 127 5 1 ●
7 Flanger LFO Wave tri, sine, saw up, saw
down
0 – 3 6
8 Flanger Depth 0 – 127 0 – 127 7 ●
9 Flg Depth Ofst R -63 – +63 1 – 127 8 ●
10 Flg Mix Balance 1 – 127 1 – 127 9 ●
11 Flanger Delay 0.1 – 650.0ms 1 – 6500 11
12 Flg Delay Ofst R 0 – -884(*) 0 – 884 12
13 Flanger Feedback -63 – +63 1 – 127 13 ●
14 Flanger FB Ofst R -63 – +63 1 – 127 14 ●
15 Flanger FB HiDamp 0.1 – 1.0 1 – 10 15 ●
16 FB HiDamp Ofst R -0.9 – +0.9 1 – 19 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Click Density 0 – 5 0 – 5 1
2 Click Level 0 – 127 0 – 127 2 ●
3 Noise Tone 0 – 6 0 – 6 3
4 Noise Mod Speed 0.00Hz – 39.7Hz 0 – 127 4 1 ●
5 Noise Mod Depth 0 – 127 0 – 127 5 ●
6 Dry Send to Noise 0 – 127 0 – 127 6 ●
7 Noise LPF Freq 1.0kHz – 20.0kHz 34 – 60 7 3 ●
8 Noise LPF Q 1.0 – 12.0 10 – 120 8 ●
9 Noise Level 0 – 127 0 – 127 9 ●
10 Dry Level 0 – 127 0 – 127 11 ●
11 Dry LPF Frequency 1.0kHz – 20.0kHz 34 – 60 12 3 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Input Level 0 – 127 0 – 127 1 ●
3 Initial Delay 0.1 – 460.0ms 1 – 4600 2
4 Scratch Speed 1 – 127 1 – 127 3 ●
5 Scratch Depth 0 – 127 0 – 127 4 ●
6 Auto Pan Speed 0.00Hz – 39.7Hz 0 – 127 5 1 ●
7 Auto Pan Depth 0 – 127 0 – 127 6 ●
8 EQ Frequency 100Hz – 10.0kHz 14 – 54 7 3 ●
9 EQ Gain -12 – +12dB 52 – 76 8 ●
10 EQ Width 1.0 – 12.0 10 – 120 9 ●
11 HPF Frequency 20Hz – 8.0kHz 0 – 52 11 3 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry Mix Level 0 – 127 0 – 127 10 ●
2 Mod Speed 0 – 127 0 – 127 1 ●
3 Mod Wave Type typeA, typeB, typeC,
typeD
0 – 3 2
4 Mod Depth 0 – 127 0 – 127 3 ●
5 Mod Depth Ofst R -63 – +63 1 – 127 4 ●
6 HPF Frequency 20Hz – 8.0kHz 0 – 52 5 3 ●
7 LPF Frequency 1.0kHz – 20.0kHz 34 – 60 6 3 ●
8 Delay Time 0.1 – 370.0ms 1 – 3700 7
9 Delay Time Ofst R 0 – 884 0 – 884 8
10 Delay Level 0 – 127 0 – 127 9 ●
11 Feedback Level -63 – +63 1 – 127 11 ●
12 FB Level Ofst R -63 – +63 1 – 127 12 ●
13 AM Speed 0.00Hz – 39.7Hz 0 – 127 13 1 ●
14 AM Wave tri, sine, saw up, saw
down
0 – 3 14
15 AM Depth 0 – 127 0 – 127 15 ●
16 AM Inverse R normal, inverse 0 – 1 16
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Mod Speed 0 – 127 0 – 127 1 ●
3 Mod Depth 0 – 127 0 – 127 2 ●
4 Mod Gain -12 – +12dB 52 – 76 3 ●
5 Mod Mix Balance D63>W – D=W – D<W63 1 – 127 4 ●
6 Pre Mod HPF Freq 20Hz – 8.0kHz 0 – 52 5 3 ●
7 Mod LPF Frequency 1.0kHz – 20.0kHz 34 – 60 6 3 ●
8 Mod LPF Resonance 1.0 – 12.0 10 – 120 7 ●
9 Delay Time 0.1 – 740.0ms 1 – 7400 8
10 Delay Time Ofst R 0 – 884 0 – 884 9
11 Feedback Level -63 – +63 1 – 127 11 ●
12 FB Level Ofst R -63 – +63 1 – 127 12 ●
13 Feedback Hi Damp 0.1 – 1.0 1 – 10 13 ●
14 FB Hi Damp Ofst R -0.9 – +0.9 1 – 19 14 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Depth 0 – 127 0 – 127 1 ●
3 Speed 0 – 127 0 – 127 2 ●
4 Direction L<>R, L>>R 0 – 1 3
5 Type typeA, typeB, typeC 0 – 2 4
6 Jump Wave Type typeA, typeB, typeC,
typeD
0 – 3 5
7 Resolution 1, 1/2 – 1/256 0 – 8 6
8 HPF Frequency 20Hz – 8.0kHz 0 – 52 7 3 ●
9 LPF Frequency 1.0kHz – 20.0kHz 34 – 60 8 3 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 On/off SW on, off 0 – 1 1 ●
2 Low Level -63 – +63 0 – 127 2 ●
3 Mid Level -63 – +63 0 – 127 3 ●
4 High Level -63 – +63 0 – 127 4 ●
5 Low Mute off/on 0 – 1 5 ●
6 Mid Mute off/on 0 – 1 6 ●
7 High Mute off/on 0 – 1 7 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Divide Type 16th – 4th 5 – 11 1 12
3 Gate Time 0 – 100% 0 – 100 2 ●
4 Pan AEG Type A – E 0 – 4 3
5 Pan AEG Min Level 0 – 127 0 – 127 4 ●
6 Pan Depth -63 – +63 1 – 127 5 ●
7 Divide Min Level 0 – 127 0 – 127 6 ●
8 Pan Type A – J 0 – 9 7
9 Drive 0 – 127 0 – 127 8 ●
10 AEG Phase 0 – 15 (x16th note) 0 – 15 9
11 Set Slice Tempo --- --- 12
12 EQ low frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
13 EQ low gain -12dB – +12dB 52 – 76 14 ●
14 EQ high frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
15 EQ high gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 EQ low gain -12dB – +12dB 52 – 76 1 ●
2 EQ mid frequency 100Hz – 10.0kHz 14 – 54 2 3 ●
3 EQ mid gain -12dB – +12dB 52 – 76 3 ●
4 EQ mid width 0.1 – 12.0 1 – 120 4 ●
5 EQ high gain -12dB – +12dB 52 – 76 5 ●
6 EQ low frequency 50Hz – 2.0kHz 8 – 40 6 3 ●
7 EQ high frequency 500Hz – 16.0kHz 28 – 58 7 3 ●
8 Input mode mono/stereo 0 – 1 15
MR_DL1.book Page 35 Monday, January 6, 2003 11:10 AM
36
[98] 2BAND EQ (Insertion Block Only)
[99] HARMONIC ENHANCER (Insertion Block Only)
[100] MONO HARMONIC ENHANCER (Insertion Block Only)
[101] VOICE CANCEL (Insertion Block Only)
[102] AMBIENCE (Insertion Block Only)
[103] TALKING MODULATOR (Insertion Block Only)
[104] BEAT CHANGE (Insertion Block Only)
[105] RING MODULATOR (Insertion Block Only)
[106] DYNAMIC RING MODULATOR (Insertion Block Only)
[107] DYNAMIC FILTER (Insertion Block Only)
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 EQ low frequency 32Hz – 2.0kHz 4 – 40 1 3 ●
2 EQ low gain -12dB – +12dB 52 – 76 2 ●
3 EQ high frequency 500Hz – 16.0kHz 28 – 58 3 3 ●
4 EQ high gain -12dB – +12dB 52 – 76 4 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 HPF cutoff frequency 500Hz – 16.0kHz 28 – 58 1 3 ●
2 Drive 0 – 127 0 – 127 2 ●
3 Mix level 0 – 127 0 – 127 3 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 HPF cutoff frequency 500Hz – 16.0kHz 28 – 58 1 3 ●
2 Drive 0 – 127 0 – 127 2 ●
3 Mix level 0 – 127 0 – 127 3 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Low adjust 0 – 26 0 – 26 11 ●
2 High adjust 0 – 26 0 – 26 12 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Delay time 0.0ms – 50.0ms 0 – 127 1 2
3 Wet output phase normal/inverse 0 – 1 2 ●
4 EQ low frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
5 EQ low gain -12dB – +12dB 52 – 76 7 ●
6 EQ high frequency 500Hz – 16.0kHz 28 – 58 8 3 ●
7 EQ high gain -12dB – +12dB 52 – 76 9 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Vowel a/i/u/e/o 0 – 4 1 ●
2 Move speed 1 – 62 1 – 62 2 ●
3 Drive 0 – 127 0 – 127 3 ●
4 Output Level 0 – 127 0 – 127 4 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 BeatChange -63 – +63 1 – 127 1 ●
3 Beat Range 0 – 12 0 – 12 2 ●
4 PitchChange -63 – +63 1 – 127 3 ●
5 Pitch Range 0 – 12 0 – 12 4 ●
6 Accuracy Type sound4 – normal – rythm4 0 – 8 5
7 EQ Frequency 32Hz – 2.0kHz 4 – 40 6 3 ●
8 EQ Gain -12dB – +12dB 52 – 76 7 ●
9 EQ Width 1.0 – 12.0 10 – 120 8 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Carrier Freq Course 0.5-5kHz 0 – 127 1 ●
3 Carrier Freq Fine 0 – 127 0 – 127 2 ●
4 LFO Wave tri, sine 0 – 1 3
5 LFO Depth 0 – 127 0 – 127 4 ●
6 LFO Speed 0.0Hz – 39.70Hz 0 – 127 5 1 ●
7 HPF Cutoff Frequency 20Hz – 8.0kHz 0 – 52 6 3 ●
8 LPF Cutoff Frequency 1.0kHz – 20.0kHz 34 – 60 7 3 ●
9 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
10 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
11 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
12 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / Wet Balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Sensitivity 0 – 127 0 – 127 1 ●
3 HPF Cutoff Frequency 20Hz – 8.0kHz 0 – 52 2 3 ●
4 LPF Cutoff Frequency 1.0kHz – 20.0kHz 34 – 60 3 3 ●
5 Attack Time 0.3ms – 227ms 0 – 127 4 ●
6 Release Time 2.6ms – 2171ms 0 – 127 5 ●
7 Release Curve 0 – 127 0 – 127 6
8 Direction up, down 0 – 1 7
9 Dyna Threshold Level 0 – 127 0 – 127 8 ●
10 Dyna Level Offset 0 – 127 0 – 127 9 ●
11 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
12 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
13 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
14 EQ High Gain -12dB – +12dB 52 – 76 16 ●
No. Parameter Range Value
MIDI
Parameter
No.
Table CtrlSet
Dest
1 Dry / wet balance D63>W – D=W – D<W63 1 – 127 10 ●
2 Filter Type LPF(12dB), LPF(18dB),
LPF(24dB), HPF, BPF,
BEF
0 – 5 1
3 Sensitivity 0 – 127 0 – 127 2 ●
4 Dyna Level Offset 0 – 127 0 – 127 3 ●
5 Resonance -16 – +111 0 – 127 4 ●
6 Attack Time 0.3ms – 227ms 0 – 127 5 ●
7 Release Time 2.6ms – 2171ms 0 – 127 6 ●
8 Release Curve 0 – 127 0 – 127 7
9 Direction up, down 0 – 1 8
10 Dyna Threshold Level 0 – 127 0 – 127 9 ●
11 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 13 3 ●
12 EQ Low Gain -12dB – +12dB 52 – 76 14 ●
13 EQ High Frequency 500Hz – 16.0kHz 28 – 58 15 3 ●
14 EQ High Gain -12dB – +12dB 52 – 76 16 ●
MR_DL1.book Page 36 Monday, January 6, 2003 11:10 AM
37
Effect Data Assign Table
Table#1
LFO Frequency
Data Value Data Value
0 0.00 64 2.69
1 0.04 65 2.78
2 0.08 66 2.86
3 0.13 67 2.94
4 0.17 68 3.03
5 0.21 69 3.11
6 0.25 70 3.20
7 0.29 71 3.28
8 0.34 72 3.37
9 0.38 73 3.45
10 0.42 74 3.53
11 0.46 75 3.62
12 0.51 76 3.70
13 0.55 77 3.87
14 0.59 78 4.04
15 0.63 79 4.21
16 0.67 80 4.37
17 0.72 81 4.54
18 0.76 82 4.71
19 0.80 83 4.88
20 0.84 84 5.05
21 0.88 85 5.22
22 0.93 86 5.38
23 0.97 87 5.55
24 1.01 88 5.72
25 1.05 89 6.06
26 1.09 90 6.39
27 1.14 91 6.73
28 1.18 92 7.07
29 1.22 93 7.40
30 1.26 94 7.74
31 1.30 95 8.08
32 1.35 96 8.41
33 1.39 97 8.75
34 1.43 98 9.08
35 1.47 99 9.42
36 1.51 100 9.76
37 1.56 101 10.1
38 1.60 102 10.8
39 1.64 103 11.4
40 1.68 104 12.1
41 1.72 105 12.8
42 1.77 106 13.5
43 1.81 107 14.1
44 1.85 108 14.8
45 1.89 109 15.5
46 1.94 110 16.2
47 1.98 111 16.8
48 2.02 112 17.5
49 2.06 113 18.2
50 2.10 114 19.5
51 2.15 115 20.9
52 2.19 116 22.2
53 2.23 117 23.6
54 2.27 118 24.9
55 2.31 119 26.2
56 2.36 120 27.6
57 2.40 121 28.9
58 2.44 122 30.3
59 2.48 123 31.6
60 2.52 124 33.0
61 2.57 125 34.3
62 2.61 126 37.0
63 2.65 127 39.7
Table#2
Modulation Delay Offset
Data Value Data Value
0 0.0 64 6.4
1 0.1 65 6.5
2 0.2 66 6.6
3 0.3 67 6.7
4 0.4 68 6.8
5 0.5 69 6.9
6 0.6 70 7.0
7 0.7 71 7.1
8 0.8 72 7.2
9 0.9 73 7.3
10 1.0 74 7.4
11 1.1 75 7.5
12 1.2 76 7.6
13 1.3 77 7.7
14 1.4 78 7.8
15 1.5 79 7.9
16 1.6 80 8.0
17 1.7 81 8.1
18 1.8 82 8.2
19 1.9 83 8.3
20 2.0 84 8.4
21 2.1 85 8.5
22 2.2 86 8.6
23 2.3 87 8.7
24 2.4 88 8.8
25 2.5 89 8.9
26 2.6 90 9.0
27 2.7 91 9.1
28 2.8 92 9.2
29 2.9 93 9.3
30 3.0 94 9.4
31 3.1 95 9.5
32 3.2 96 9.6
33 3.3 97 9.7
34 3.4 98 9.8
35 3.5 99 9.9
36 3.6 100 10.0
37 3.7 101 11.1
38 3.8 102 12.2
39 3.9 103 13.3
40 4.0 104 14.4
41 4.1 105 15.5
42 4.2 106 17.1
43 4.3 107 18.6
44 4.4 108 20.2
45 4.5 109 21.8
46 4.6 110 23.3
47 4.7 111 24.9
48 4.8 112 26.5
49 4.9 113 28.0
50 5.0 114 29.6
51 5.1 115 31.2
52 5.2 116 32.8
53 5.3 117 34.3
54 5.4 118 35.9
55 5.5 119 37.5
56 5.6 120 39.0
57 5.7 121 40.6
58 5.8 122 42.2
59 5.9 123 43.7
60 6.0 124 45.3
61 6.1 125 46.9
62 6.2 126 48.4
63 6.3 127 50.0
Table#3
EQ Frequency
Data Value
0 THRU(20)
122
225
328
432
536
640
745
850
956
10 63
11 70
12 80
13 90
14 100
15 110
16 125
17 140
18 160
19 180
20 200
21 225
22 250
23 280
24 315
25 355
26 400
27 450
28 500
29 560
30 630
31 700
32 800
33 900
34 1.0k
35 1.1k
36 1.2k
37 1.4k
38 1.6k
39 1.8k
40 2.0k
41 2.2k
42 2.5k
43 2.8k
44 3.2k
45 3.6k
46 4.0k
47 4.5k
48 5.0k
49 5.6k
50 6.3k
51 7.0k
52 8.0k
53 9.0k
54 10.0k
55 11.0k
56 12.0k
57 14.0k
58 16.0k
59 18.0k
60 THRU(20.0k)
Table#4
Reverb Time
Data Value Data Value
0 0.3 64 17.0
1 0.4 65 18.0
2 0.5 66 19.0
3 0.6 67 20.0
4 0.7 68 25.0
5 0.8 69 30.0
6 0.9
7 1.0
8 1.1
9 1.2
10 1.3
11 1.4
12 1.5
13 1.6
14 1.7
15 1.8
16 1.9
17 2.0
18 2.1
19 2.2
20 2.3
21 2.4
22 2.5
23 2.6
24 2.7
25 2.8
26 2.9
27 3.0
28 3.1
29 3.2
30 3.3
31 3.4
32 3.5
33 3.6
34 3.7
35 3.8
36 3.9
37 4.0
38 4.1
39 4.2
40 4.3
41 4.4
42 4.5
43 4.6
44 4.7
45 4.8
46 4.9
47 5.0
48 5.5
49 6.0
50 6.5
51 7.0
52 7.5
53 8.0
54 8.5
55 9.0
56 9.5
57 10.0
58 11.0
59 12.0
60 13.0
61 14.0
62 15.0
63 16.0
Table#5
Delay Time (0.1~200.0 [ms])
Data Value Data Value
0 0.1 64 100.8
1 1.7 65 102.4
2 3.2 66 104.0
3 4.8 67 105.6
4 6.4 68 107.1
5 8.0 69 108.7
6 9.5 70 110.3
7 11.1 71 111.9
8 12.7 72 113.4
9 14.3 73 115.0
10 15.8 74 116.6
11 17.4 75 118.2
12 19.0 76 119.7
13 20.6 77 121.3
14 22.1 78 122.9
15 23.7 79 124.4
16 25.3 80 126.0
17 26.9 81 127.6
18 28.4 82 129.2
19 30.0 83 130.7
20 31.6 84 132.3
21 33.2 85 133.9
22 34.7 86 135.5
23 36.3 87 137.0
24 37.9 88 138.6
25 39.5 89 140.2
26 41.0 90 141.8
27 42.6 91 143.3
28 44.2 92 144.9
29 45.7 93 146.5
30 47.3 94 148.1
31 48.9 95 149.6
32 50.5 96 151.2
33 52.0 97 152.8
34 53.6 98 154.4
35 55.2 99 155.9
36 56.8 100 157.5
37 58.3 101 159.1
38 59.9 102 160.6
39 61.5 103 162.2
40 63.1 104 163.8
41 64.6 105 165.4
42 66.2 106 166.9
43 67.8 107 168.5
44 69.4 108 170.1
45 70.9 109 171.7
46 72.5 110 173.2
47 74.1 111 174.8
48 75.7 112 176.4
49 77.2 113 178.0
50 78.8 114 179.5
51 80.4 115 181.1
52 81.9 116 182.7
53 83.5 117 184.3
54 85.1 118 185.8
55 86.7 119 187.4
56 88.2 120 189.0
57 89.8 121 190.6
58 91.4 122 192.1
59 93.0 123 193.7
60 94.5 124 195.3
61 96.1 125 196.9
62 97.7 126 198.4
63 99.3 127 200.0
MR_DL1.book Page 37 Monday, January 6, 2003 11:10 AM
38
Table#6
Room Size
Data Value
0 0.1
1 0.3
2 0.4
3 0.6
4 0.7
5 0.9
6 1.0
7 1.2
8 1.4
9 1.5
10 1.7
11 1.8
12 2.0
13 2.1
14 2.3
15 2.5
16 2.6
17 2.8
18 2.9
19 3.1
20 3.2
21 3.4
22 3.5
23 3.7
24 3.9
25 4.0
26 4.2
27 4.3
28 4.5
29 4.6
30 4.8
31 5.0
32 5.1
33 5.3
34 5.4
35 5.6
36 5.7
37 5.9
38 6.1
39 6.2
40 6.4
41 6.5
42 6.7
43 6.8
44 7.0
Table#7
Delay Time (0.1~400.0 [ms])
Data Value Data Value
0 0.1 64 201.6
1 3.2 65 204.8
2 6.4 66 207.9
3 9.5 67 211.1
4 12.7 68 214.2
5 15.8 69 217.4
6 19.0 70 220.5
7 22.1 71 223.7
8 25.3 72 226.8
9 28.4 73 230.0
10 31.6 74 233.1
11 34.7 75 236.3
12 37.9 76 239.4
13 41.0 77 242.6
14 44.2 78 245.7
15 47.3 79 248.9
16 50.5 80 252.0
17 53.6 81 255.2
18 56.8 82 258.3
19 59.9 83 261.5
20 63.1 84 264.6
21 66.2 85 267.7
22 69.4 86 270.9
23 72.5 87 274.0
24 75.7 88 277.2
25 78.8 89 280.3
26 82.0 90 283.5
27 85.1 91 286.6
28 88.3 92 289.8
29 91.4 93 292.9
30 94.6 94 296.1
31 97.7 95 299.2
32 100.9 96 302.4
33 104.0 97 305.5
34 107.2 98 308.7
35 110.3 99 311.8
36 113.5 100 315.0
37 116.6 101 318.1
38 119.8 102 321.3
39 122.9 103 324.4
40 126.1 104 327.6
41 129.2 105 330.7
42 132.4 106 333.9
43 135.5 107 337.0
44 138.6 108 340.2
45 141.8 109 343.3
46 144.9 110 346.5
47 148.1 111 349.6
48 151.2 112 352.8
49 154.4 113 355.9
50 157.5 114 359.1
51 160.7 115 362.2
52 163.8 116 365.4
53 167.0 117 368.5
54 170.1 118 371.7
55 173.3 119 374.8
56 176.4 120 378.0
57 179.6 121 381.1
58 182.7 122 384.3
59 185.9 123 387.4
60 189.0 124 390.6
61 192.2 125 393.7
62 195.3 126 396.9
63 198.5 127 400.0
Table#8
Compressor Attack Time
Table#9
Compressor Release Time
Table#10
Compressor Ratio
Data Value
01
12
23
34
45
56
67
78
89
910
10 12
11 14
12 16
13 18
14 20
15 23
16 26
17 30
18 35
19 40
Data Value
010
115
225
335
445
555
665
775
885
9 100
10 115
11 140
12 170
13 230
14 340
15 680
Data Value
0 1.0
1 1.5
2 2.0
3 3.0
4 5.0
5 7.0
6 10.0
7 20.0
Table#11
Reverb Width; Depth; Height
Data Value Data Value
0 0.5 64 17.6
1 0.8 65 17.9
2 1.0 66 18.2
3 1.3 67 18.5
4 1.5 68 18.8
5 1.8 69 19.1
6 2.0 70 19.4
7 2.3 71 19.7
8 2.6 72 20.0
9 2.8 73 20.2
10 3.1 74 20.5
11 3.3 75 20.8
12 3.6 76 21.1
13 3.9 77 21.4
14 4.1 78 21.7
15 4.4 79 22.0
16 4.6 80 22.4
17 4.9 81 22.7
18 5.2 82 23.0
19 5.4 83 23.3
20 5.7 84 23.6
21 5.9 85 23.9
22 6.2 86 24.2
23 6.5 87 24.5
24 6.7 88 24.9
25 7.0 89 25.2
26 7.2 90 25.5
27 7.5 91 25.8
28 7.8 92 26.1
29 8.0 93 26.5
30 8.3 94 26.8
31 8.6 95 27.1
32 8.8 96 27.5
33 9.1 97 27.8
34 9.4 98 28.1
35 9.6 99 28.5
36 9.9 100 28.8
37 10.2 101 29.2
38 10.4 102 29.5
39 10.7 103 29.9
40 11.0 104 30.2
41 11.2
42 11.5
43 11.8
44 12.1
45 12.3
46 12.6
47 12.9
48 13.1
49 13.4
50 13.7
51 14.0
52 14.2
53 14.5
54 14.8
55 15.1
56 15.4
57 15.6
58 15.9
59 16.2
60 16.5
61 16.8
62 17.1
63 17.3
Table#12
Tempo
Data Value Data Value
0 32th/3 64 4thX51
1 64th. 65 4thX52
2 32nd 66 4thX53
3 16th/3 67 4thX54
4 32nd. 68 4thX55
5 16th 69 4thX56
6 8th/3 70 4thX57
7 16th. 71 4thX58
8 8th 72 4thX59
9 4th/3 73 4thX60
10 8th. 74 4thX61
11 4th 75 4thX62
12 2nd/3 76 4thX63
13 4th. 77 4thX64
14 2nd
15 1st/3
16 2nd.
17 4thX4
18 4thX5
19 4thX6
20 4thX7
21 4thX8
22 4thX9
23 4thX10
24 4thX11
25 4thX12
26 4thX13
27 4thX14
28 4thX15
29 4thX16
30 4thX17
31 4thX18
32 4thX19
33 4thX20
34 4thX21
35 4thX22
36 4thX23
37 4thX24
38 4thX25
39 4thX26
40 4thX27
41 4thX28
42 4thX29
43 4thX30
44 4thX31
45 4thX32
46 4thX33
47 4thX34
48 4thX35
49 4thX36
50 4thX37
51 4thX38
52 4thX39
53 4thX40
54 4thX41
55 4thX42
56 4thX43
57 4thX44
58 4thX45
59 4thX46
60 4thX47
61 4thX48
62 4thX49
63 4thX50
MR_DL1.book Page 38 Monday, January 6, 2003 11:10 AM
39
Table#13
Modulation Phase
Data Value
0 -180
1 -158
2 -135
3 -113
4 -90
5 -68
6 -45
7 -23
80
923
10 45
11 68
12 90
13 113
14 135
15 158
16 180
Table#14
Multi Compressor Gain (dB)
Data Value
0-∞
1 -60
2 -57
3 -54
4 -51
5 -48
6 -45
7 -42
8 -39
9 -36
10 -33
11 -30
12 -27
13 -24
14 -23
15 -22
16 -21
17 -20
18 -19
19 -18
20 -17
21 -16
22 -15
23 -14
24 -13
25 -12
26 -11
27 -10
28 -9
29 -8
30 -7
31 -6
32 -5
33 -4
34 -3
35 -2
36 -1
37 0
38 1
39 2
40 3
41 4
42 5
43 6
44 7
45 8
46 9
47 10
48 11
49 12
50 13
51 14
52 15
53 16
54 17
55 18
Table#15
Divide Frequency (Hz)
Data Value 1 Value 2 Data Value 1 Value 2
0 32 1.2k 64 315 3.2k
1 32 1.6k 65 315 4.0k
2 32 2.0k 66 315 5.0k
3 32 2.5k 67 315 6.3k
4 32 3.2k 68 315 8.0k
5 32 4.0k 69 315 10.0k
6 32 5.0k 70 500 1.2k
7 32 6.3k 71 500 1.6k
8 32 8.0k 72 500 2.0k
9 32 10.0k 73 500 2.5k
10 63 1.2k 74 500 3.2k
11 63 1.6k 75 500 4.0k
12 63 2.0k 76 500 5.0k
13 63 2.5k 77 500 6.3k
14 63 3.2k 78 500 8.0k
15 63 4.0k 79 500 10.0k
16 63 5.0k 80 630 1.2k
17 63 6.3k 81 630 1.6k
18 63 8.0k 82 630 2.0k
19 63 10.0k 83 630 2.5k
20 80 1.2k 84 630 3.2k
21 80 1.6k 85 630 4.0k
22 80 2.0k 86 630 5.0k
23 80 2.5k 87 630 6.3k
24 80 3.2k 88 630 8.0k
25 80 4.0k 89 630 10.0k
26 80 5.0k
27 80 6.3k
28 80 8.0k
29 80 10.0k
30 125 1.2k
31 125 1.6k
32 125 2.0k
33 125 2.5k
34 125 3.2k
35 125 4.0k
36 125 5.0k
37 125 6.3k
38 125 8.0k
39 125 10.0k
40 160 1.2k
41 160 1.6k
42 160 2.0k
43 160 2.5k
44 160 3.2k
45 160 4.0k
46 160 5.0k
47 160 6.3k
48 160 8.0k
49 160 10.0k
50 250 1.2k
51 250 1.6k
52 250 2.0k
53 250 2.5k
54 250 3.2k
55 250 4.0k
56 250 5.0k
57 250 6.3k
58 250 8.0k
59 250 10.0k
60 315 1.2k
61 315 1.6k
62 315 2.0k
63 315 2.5k
MR_DL1.book Page 39 Monday, January 6, 2003 11:10 AM
40
Control List
Assign A/B DESTINATION VOICE CONTROL SET DESTINATION
No. Display Description
0 off off
1 EQLow-G MEQ Low Gain
2 EQLow-F MEQ Low Frequency
3 EQLow-Q MEQ Low Q
4 EQLoM-G MEQ Low Mid Gain
5 EQLoM-F MEQ Low Mid Frequency
6 EQLoM-Q MEQ Low Mid Q
7 EQMid-G MEQ Mid Gain
8 EQMid-F MEQ Mid Frequency
9 EQMid-Q MEQ Mid Q
10 EQHiM-G MEQ High Mid Gain
11 EQHiM-F MEQ High Mid Frequency
12 EQHiM-Q MEQ High Mid Q
13 EQHighG MEQ High Gain
14 EQHighF MEQ High Frequency
15 EQHighQ MEQ High Q
16 REV-P1 Reverb Parameter 1
: : :
31 REV-P16 Reverb Parameter 16
32 REV-Rtn Reverb Return
33 REV-Pan Reverb Pan
34 CHO-P1 Chorus Parameter 1
: : :
49 CHO-P16 Chorus Parameter 16
50 CHO-Rtn Chorus Return
51 CHO-Pan Chorus Pan
52 Cho>Rev Send Chorus To Reverb
53 ARP-Typ Arpeggio Type
54 ARP-Unt Arpeggio Unit Multiply
55 ARP-Vel Arpeggio Velocity Rate
56 ARP-Gat Arpeggio Gate Time Rate
57 Tempo Arpeggio Tempo
58 AEG-Atk AEG Attack Time
59 AEG-Dcy AEG Decay Time
60 AEG-Sus AEG Sustain Level
61 AEG-Rel AEG Release Time
62 FEG-Atk FEG Attack Time
63 FEG-Dcy FEG Decay Time
64 FEG-Rel FEG Release Time
65 FEG-Dpt FEG Depth
66 Cutoff Cutoff Frequency
67 Reso Resonance
No. Display Description Normal Other
0 ------- off ●●
1 Volume Voice Volume ●●
2 RevSend Reverb Send ●●
3 ChoSend Chorus Send ●●
4 INS1-P1 Insertion Effect 1 Parameter 1 ●●
: : : : :
19 INS1P16 Insertion Effect 1 Parameter 16 ●●
20 INS2-P1 Insertion Effect 2 Parameter 1 ●●
: : : : :
35 INS2P16 Insertion Effect 2 Parameter 16 ●●
36 CLFOSpd Common LFO Speed ●–
37 CLFO-D1 Common LFO Depth1 ●–
38 CLFO-D2 Common LFO Depth2 ●–
39 CLFO-D3 Common LFO Depth3 ●–
40 PorTime Portamento Time ●–
41 ELM-Lvl Element Level ●–
42 ELM-Pan Element Pan ●–
43 ELM-Dly Element Key On Delay ●–
44 ELFOSpd Element LFO Speed ●–
45 ELFO-PM Element LFO Pitch Modulation Depth ●–
46 ELFO-AM
Element LFO Amplitude Modulation Depth
●–
47 ELFO-FM Element LFO Filter Modulation Depth ●–
48 PCH-Crs Element Pitch Coarse ●–
49 PCH-Fin Element Pitch Fine ●–
50 PEG-Dpt Element Pitch EG Depth ●–
51 PEG-Hld Element Pitch EG Hold Time ●–
52 PEG-Atk Element Pitch EG Attack Time ●–
53 PEG-D1 Element Pitch EG Decay1 Time ●–
54 PEG-D2 Element Pitch EG Decay2 Time ●–
55 PEG-Rel Element Pitch EG Release Time ●–
56 AEG-Atk Element Amplitude EG Attack Time ●–
57 AEG-D1 Element Amplitude EG Decay1 Time ●–
58 AEG-D2 Element Amplitude EG Decay2 Time ●–
59 AEG-Rel Element Amplitude EG Release Time ●–
60 FEG-Dpt Element Filter EG Depth ●–
61 FEG-Hld Element Filter EG Hold Time ●–
62 FEG-Atk Element Filter EG Attack Time ●–
63 FEG-D1 Element Filter EG Decay1 Time ●–
64 FEG-D2 Element Filter EG Decay2 Time ●–
65 FEG-Rel Element Filter EG Release Time ●–
66 FLT-Frq Element Filter Cutoff Frequency ●–
67 FLT-Rez Element Filter Resonance ●–
68 HPF-Frq Element HPF Cutoff Frequency ●–
MR_DL1.book Page 40 Monday, January 6, 2003 11:10 AM
41
Arpeggio Type List
Preset1 Preset2
No. Name Type No. Name Type
1 UpOct1 Sq 65 SuperArp Ph
2 UpOct2 Sq 66 MuteArpA Ph
3 UpOct4 Sq 67 MuteArpB Ph
4 DownOct1 Sq 68 VelGruvA Ph
5 DownOct2 Sq 69 VelGruvB Ph
6 DownOct4 Sq 70 SpaceArp Ph
7 U/DAOct1 Sq 71 MuteLine Ph
8 U/DAOct2 Sq 72 StepLine Ph
9 U/DAOct4 Sq 73 AcidLine Ph
10 U/DBOct1 Sq 74 SplitArp Ph
11 U/DBOct2 Sq 75 Step Seq Ph
12 U/DBOct4 Sq 76 PolyArpA Ph
13 RndmOct1 Sq 77 PolyArpB Ph
14 RndmOct2 Sq 78 Ana Seq Ph
15 RndmOct4 Sq 79 Planet Ph
16 Oct2Up Sq 80 Rosync Ph
17 Oct4Up Sq 81 StrumArp Ph
18 UnisonUp Sq 82 Guit1Arp Ph
19 Up&Down1 Sq 83 RolliArp Ph
20 Up&Down2 Sq 84 Guit2Arp Ph
21 Up&Down4 Sq 85 Guit3Arp Ph
22 Up&Alt1 Sq 86 Guit4Arp Ph
23 Up&Rndm1 Sq 87 Harp Arp Ph
24 Up&Rndm2 Sq 88 BigBeatA Dr
25 Up&Rndm4 Sq 89 BigBeatB Dr
26 ChdAltB1 Sq 90 BigBeatC Dr
27 ChdAltB2 Sq 91 BigBeatD Dr
28 ChdAltB4 Sq 92 Rock A Dr
29 ChdRndm1 Sq 93 Rock B Dr
30 ChdRndm2 Sq 94 Rock C Dr
31 ChdRndm4 Sq 95 BigBeatE Dr
32 Techno A Ph 96 BigBeatF Dr
33 Techno B Ph 97 BigBeatG Dr
34 Techno C Ph 98 BigBeatH Dr
35 DAHouse Ph 99 BigBeatI Dr
36 SyncopaA Ph 100 BrkTrnce Dr
37 SyncopaB Ph 101 House A Dr
38 SyncpEco Ph 102 House B Dr
39 TekEchoA Ph 103 House C Dr
40 TekEchoB Ph 104 Garage Dr
41 PulsLine Ph 105 House D Dr
42 SeqS&H A Ph 106 House E Dr
43 SeqS&H B Ph 107 HipHop A Dr
44 CleanGtA Ph 108 JazzHop Dr
45 CleanGtB Ph 109 Abstract Dr
46 CleanGtC Ph 110 LoBeat A Dr
47 CleanGtD Ph 111 LoBeat B Dr
48 Pno16Bt Ph 112 LoBeat C Dr
49 PnoLatin Ph 113 LoBeat D Dr
50 GruvBass Ph 114 LoBeat E Dr
51 Ocean Ph 115 LoBeat F Dr
52 Orbit Ph 116 DrumnBsA Dr
53 X-SweepA Ph 117 DrumnBsB Dr
54 X-SweepB Ph 118 Linear Dr
55 X-SweepC Ph 119 08beat A Sp
56 Lamb Ph 120 08beat B Sp
57 Thips Ph 121 08beat C Sp
58 Hardcore Ph 122 16beat A Sp
59 Harmo Ph 123 16beat B Sp
60 Ascorbic Ph 124 1Bar Sp
61 Doves Ph 125 1BarRndm Sp
62 Chodal Ph 126 GateCutA Ct
63 Simple Ph 127 GateCutB Ct
64 Waggle Ph 128 GateCutC Ct
No. Name Type No. Name Type
1 Strum A Ph 65 FlipHopA Dr
2 Strum B Ph 66 FlipHopB Dr
3 Strum C Ph 67 FlipHopC Dr
4 Strum D Ph 68 FlipHopD Dr
5 Strum E Ph 69 GangstaA Dr
6 Strum F Ph 70 GangstaB Dr
7 Strum G Ph 71 GangstaC Dr
8 Strum H Ph 72 GangstaD Dr
9 Strum I Ph 73 i-Hop A Dr
10 Strum J Ph 74 i-Hop B Dr
11 LatinPHA Ph 75 i-Hop C Dr
12 LatinPHB Ph 76 i-Hop D Dr
13 LatinPHC Ph 77 R&BSmthA Dr
14 Funky A Ph 78 R&BSmthB Dr
15 Funky B Ph 79 R&BSmthC Dr
16 Funky C Ph 80 R&BSmthD Dr
17 Funky D Ph 81 House F Dr
18 RockGtrA Ph 82 House G Dr
19 RockGtrB Ph 83 House H Dr
20 RockGtrC Ph 84 Funk A Dr
21 Lick A Ph 85 Funk B Dr
22 Lick B Ph 86 Funk C Dr
23 Lick C Ph 87 Funk D Dr
24 Lick D Ph 88 Gospel A Dr
25 Lick E Ph 89 Gospel B Dr
26 Lick F Ph 90 Bebop A Dr
27 News A Ph 91 Bebop B Dr
28 News B Ph 92 PopRckAA Dr
29 Fugue Ph 93 PopRckAB Dr
30 AcidBs A Ph 94 PopRckAC Dr
31 AcidBs B Ph 95 PopRckAD Dr
32 SlapBs A Ph 96 PopRckBA Dr
33 SlapBs B Ph 97 PopRckBB Dr
34 Walkin Ph 98 PopRckBC Dr
35 Trill A Ph 99 PopRckBD Dr
36 Trill B Ph 100 MondoRkA Dr
37 Trill C Ph 101 MondoRkB Dr
38 FlutterA Ph 102 MondoRkC Dr
39 FlutterB Ph 103 MondoRkD Dr
40 FlutterC Ph 104 BalladAA Dr
41 Flute A Ph 105 BalladAB Dr
42 Flute B Ph 106 BalladAC Dr
43 Flute C Ph 107 BalladAD Dr
44 Cresendo Ph 108 BalladBA Dr
45 MOD A Ph 109 BalladBB Dr
46 MOD B Ph 110 Roll A Dr
47 MOD C Ph 111 Roll B Dr
48 Pickin A Ph 112 Roll C Dr
49 Pickin B Ph 113 Roll D Dr
50 Pickin C Ph 114 Latin A Dr
51 ArmDown Ct 115 Latin B Dr
52 BendVib Ct 116 Latin C Dr
53 BotDwVib Ct 117 Latin D Dr
54 BotUpVib Ct 118 Latin E Dr
55 CHVib Ct 119 DrumnBsC Dr
56 HamVib Ct 120 DrumnBsD Dr
57 PullVibA Ct 121 DrumnBsE Dr
58 PullVibB Ct 122 DrumnBsF Dr
59 SlideVib Ct 123 DrumnBsG Dr
60 Trill D Ct 124 EuroTekA Dr
61 Trill E Ct 125 EuroTekB Dr
62 UDCHVib Ct 126 EuroTekC Dr
63 Vibra A Ct 127 EuroTekD Dr
64 Vibra B Ct 128 EuroTekE Dr
MR_DL1.book Page 41 Monday, January 6, 2003 11:10 AM
42
Audition Phrase List
No. Name
1 Ap Balld1
2 Ap Balld2
3 Ap Balld3
4 Ap Clasic
5 Ap Houze
6 Ap House
7 Ap Hntonk
8 Ap Jazz1
9 Ap Jazz2
10 Ap Rock1
11 Ba Acoust
12 Ba Analog
13 Ba BoomBx
14 Ba Brief
15 Ba Dark
16 Ba Frtles
17 Ba Gnarl
18 Ba OldHse
19 Ba R'n'B
20 Ba Rock1
21 Ba Rock2
22 Ba Seq1
23 Ba Seq2
24 Ba Seq3
25 Ba Seq4
26 Ba Seq5
27 Ba Slap
28 Ba Smooth
29 Ba Techno
30 Ba Termin
31 Br FanFr1
32 Br FanFr2
33 Br FanFr3
34 Br Horn
35 Br Sect
36 Br SftEns
37 Br Synth
38 Br Tbone
39 Br Trmpet
40 Br Trpmte
41 Br Tuba
42 Br Tutti
43 Co AhDnce
44 Co BassLd
45 Co Holidy
46 Co JapnAp
47 Co MGulAp
48 Co MinArp
49 Co PingPg
50 Co Rabbit
51 Co ShprAp
52 Co Sorted
53 Co SpcRun
54 Co TitnAp
55 Co VceCui
56 Co VinArp
57 Co WscrAp
58 Cp Steel
59 Dr 16bt1
60 Dr 16bt2
61 Dr AfroAp
62 Dr Agogo
63 Dr Bossa
64 Dr Brush
65 Dr D'n'B1
66 Dr D'n'B2
67 Dr D'n'B3
68 Dr Dub
69 Dr DubKit
70 Dr Esnare
71 Dr EthnAp
72 Dr Funk1
73 Dr Funk2
74 Dr Hhop1
75 Dr Hhop2
76 Dr Hhop3
77 Dr Hhop4
78 Dr Hhop5
79 Dr House
80 Dr Jazz1
81 Dr Jazz2
82 Dr Latin1
83 Dr Latin2
84 Dr Latin3
85 Dr Orch
86 Dr Percus
87 Dr R'n'B1
88 Dr R'n'B2
89 Dr R'n'B3
90 Dr Rock1
91 Dr Rock2
92 Dr Rock3
93 Dr Rock4
94 Dr Snares
95 Dr Techno
96 Dr Toms
97 Dr TribAp
98 Ep Acid
99 Ep Ballad
100 Ep County
101 Ep DXbal1
102 Ep DXbal2
103 Ep Dyna
104 Ep IcePno
105 Ep epPad
106 Ep Rhodes
107 Ep Wurly1
108 Ep Wurly2
109 Gt 12strg
110 Gt Banjo
111 Gt BassLd
112 Gt ChsAp2
113 Gt ChsAp1
114 Gt ChStrt
115 Gt Clean
116 Gt FlkApg
117 Gt FnkApg
118 Gt FunkAp
119 Gt Grung1
120 Gt Grung2
121 Gt Grung3
122 Gt Jazz1
123 Gt Jazz2
124 Gt Latin
125 Gt Lead1
126 Gt Lead2
127 Gt Lead3
128 Gt Lead4
No. Name
129 Gt Mute1
130 Gt Mute2
131 Gt Nylapg
132 Gt RckaBl
133 Gt Sitar
134 Gt Spank
135 Gt Spansh
136 Gt StrApg
137 Gt Strum
138 Gt TexMex
139 Gt Thug
140 Gt WahWah
141 Kb Clav1
142 Kb Clav2
143 Kb Clav3
144 Kb Comp
145 Ld Lead1
146 Ld Lead2
147 Ld Lead3
148 Ld Lead4
149 Ld Lead5
150 Ld Lead6
151 Ld Lead7
152 Me Champ1
153 Me D or A
154 Me EtnlAp
155 Me SiamAp
156 Or Barock
157 Or Bird
158 Or Bossa1
159 Or Church
160 Or Circus
161 Or Funk
162 Or Gospl1
163 Or House
164 Or Jazz1
165 Or Jazz2
166 Or Ohpipe
167 Or Pipe
168 Or Rock1
169 Or Rock2
170 Or Shufle
171 Or Tango
172 Pc BaliAp
173 Pc Celest
174 Pc Dulcim
175 Pc Glock
176 Pc Harpsi
177 Pc IndApg
178 Pc Kalmba
179 Pc Koto
180 Pc Mbox1
181 Pc Mbox2
182 Pc Marmb1
183 Pc Marmb2
184 Pc Shami1
185 Pc Tbell1
186 Pc Tbell2
187 Pc TripAp
188 Pc Vibe
189 Pc Xylo
190 Pd Bronx
191 Pd Chord1
192 Pd Chord2
No. Name
193 Pd Chord3
194 Pd Ethnic
195 Pd FstAk1
196 Pd FstAk2
197 Pd FstAk3
198 Pd Glass1
199 Pd Glass2
200 Pd Glass3
201 Pd NewAge
202 Pd PrcVox
203 Pd Slow1
204 Pd Slow2
205 Pd Slow3
206 Pd Swell1
207 Pd Swell2
208 Pd Vox1
209 Pd Vox2
210 Pd withMW
211 Ph Seq1
212 Ph Seq2
213 Ph Seq3
214 Ph Seq4
215 Ph Seq5
216 Ph Seq6
217 Ph Seq7
218 Ph Seq8
219 Ph Seq9
220 Ph Seq10
221 Ph Seq11
222 Ph Seq12
223 Pk Harp
224 Rd AltSax
225 Rd BarSax
226 Rd Clarin
227 Rd Harp1
228 Rd Harp2
229 Rd SaxEns
230 Rd SprSax
231 Rp Shanai
232 Sc Poly1
233 Sc Poly2
234 Sc Poly3
235 Sc Poly4
236 Se Amoeba
237 Se Choper
238 Se Frets
239 Se Goa
240 Se Gunsht
241 Se Phone
242 Se Racer
243 Se S'n'H
244 Se Tweet
245 St BckGnd
246 St BigEn1
247 St BigEn2
248 St Bigfst
249 St BigStr
250 St BrsStr
251 St Cbass1
252 St Cbass2
253 St Cello
254 St Fiddle
255 St Pizz
256 St Quart1
No. Name
257 St Quart2
258 St Sitar
259 St Viola
260 St Violn1
261 St Violn2
262 Ww BagPip
263 Ww Bottle
264 Ww Ensble
265 Ww Flute1
266 Ww Flute2
267 Ww Flute3
268 Ww Shaka1
269 Ww Shaka2
270 Ww Whstle
271 Cd 1 note
272 Cd maj
273 Cd maj6
274 Cd maj7
275 Cd maj9
276 Cd min
277 Cd min7
278 Cd 7
279 Cd 7+9
280 Cd 7-9
281 Cd 79+11
282 Cd 11
283 Cd 13
284 Cd dim
285 Cd sus4
No. Name
MR_DL1.book Page 42 Monday, January 6, 2003 11:10 AM
43
MIDI Data Format
(1) TRANSMIT FLOW
MIDI <- +-[SW1]--+--------- NOTE ON/OFF 9nH
OUT | |
| +--[SW5]-- BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
||
| +--[SW6]-- PROGRAM CHANGE CnH
|
+--[SW2]----------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
+------------------- ACTIVE SENSING FEH
|
+--[SW3]-+--[SW4]-- <BULK DUMP> F0H 43H 0nH 6FH bhH blH ahH amH alH
| | ddH – ddH ccH F7H
||
| +--[SW4]-- <PARAMETER CHANGE> F0H 43H 1nH 6FH ahH amH alH ddH – ddH
| F7H
|
+------------------- SYSTEM EXCLUSIVE MESSAGE
IDENTITY REPLY F0H 7EH 7FH 06H 02H 43H 00H
41H 58H 04H 00H 00H 00H 7FH F7H
[SW1] MIDI Transmit Channel
[SW2] MIDI Sync
[SW3] MIDI Device Number
When set to all, data is transmitted only via Device Number 1.
[SW4] In the Voice mode, only Voice-related data can be transmitted.
In the Multi mode, only Multi-related data can be transmitted.
The System data can be transmitted/recognized in any mode.
[SW5] SYSTEM Bank Select Switch
[SW6] SYSTEM Program Change Switch
(2) RECEIVE FLOW
MIDI >- +-[SW8]--+--------- NOTE OFF 8nH
||
| +--------- NOTE ON/OFF 9nH
||
| +--------- CONTROL CHANGE
| | MODULATION BnH,01H
| | PORTAMENTO TIME BnH,05H
| | DATA ENTRY MSB BnH,06H
| | DATA ENTRY LSB BnH,26H
| | MAIN VOLUME BnH,07H
| | PAN BnH,0AH
| | EXPRESSION BnH,0BH
| | SUSTAIN SWITCH BnH,40H
| | PORTAMENTO SWITCH BnH,41H
| | SOSTENUTO BnH,42H
| | HARMONIC CONTENT BnH,47H
| | EG RELEASE TIME BnH,48H
| | EG ATTACK TIME BnH,49H
| | BRIGHTNESS BnH,4AH
| | EG DECAY TIME BnH,4BH
| | EFFECT1 DEPTH BnH,5BH
| | EFFECT3 DEPTH BnH,5DH
| | DATA ENTRY INC BnH,60H
| | DATA ENTRY DEC BnH,61H
| | ALL SOUND OFF BnH,78H
| | ASSIGNABLE CONTROLLER BnH,(00H – 5FH)
| | NRPN BnH,62H,63H *2
| | RPN
| | PITCH BEND SENS. BnH,64H,00H,65H,00H,06H,mmH
| | FINE TUNING BnH,64H,01H,65H,00H,06H,mmH,26H,llH *1
| | COARSE TUNING BnH,64H,02H,65H,00H,06H,mmH *1
| | RPN RESET BnH,64H,7FH,65H,7FH
||
| +--[SW1]-- EG SUSTAIN LEVEL BnH,1FH
||
| +--[SW5]-- BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
| |
| +--------- CHANNEL MODE MESSAGE
| | RESET ALL CONTROLLERS BnH,79H
| | OMNI MODE OFF BnH,7CH
| | OMNI MODE ON BnH,7DH
| | MONO MODE ON BnH,7EH
| | POLY MODE ON BnH,7FH
||
| +--[SW6]-- PROGRAM CHANGE CnH
||
| +--------- CHANNEL AFTER TOUCH DnH
||
| +--------- PITCH BEND CHANGE EnH
|
+--[SW2]----------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
+------------------ ACTIVE SENSING FEH
|
+--[SW3]-+--------- SYSTEM EXCLUSIVE MESSAGE
| | MIDI MASTER VOLUME F0H 7FH 7FH 04H 01H llH mmH F7H
||
| +--[SW7]-- <BULK DUMP> F0H 43H 0nH 6FH bhH blH ahH amH alH
| | ddH – ddH ccH F7H *3
| | F0H 43H 0nH 6BH bhH blH ahH amH alH
| | ddH – ddH ccH F7H
||
| +--[SW4]-- <PARAMETER CHANGE> F0H 43H 1nH 6FH ahH amH alH ddH – ddH
| | F7H
||
| +--[SW4]-- <BULK DUMP REQUEST> F0H 43H 2nH 6FH ahH amH alH ddH – ddH
| | F7H
||
| +--[SW4]-- <PARAMETER REQUEST> F0H 43H 3nH 6FH ahH amH alH F7H
||
| +--[SW9]-- XG SYSTEM ON F0H 43H 1nH 4CH 00H 00H 7EH 00H F7H
||
| +--[SW9]-- GM MODE ON F0H 7EH 7FH 09H 01H F7H
|
|
+------------------ SYSTEM EXCLUSIVE MESSAGE
IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H
[SW1] MIDI Control Mode
[SW2] MIDI Sync (can be set to “internal” or “MIDI”)
[SW3] MIDI Device Number
When this is not set to off, the MIDI Master Volume can be recognized in any mode.
[SW4] In the Voice mode, only Voice-related data can be transmitted.
In the Multi mode, only Multi-related data can be transmitted.
The System data can be transmitted/recognized in any mode.
[SW5] SYSTEM Bank Select Switch
[SW6] SYSTEM Program Change Switch
[SW7] SYSTEM Bulk Protect and same as SW6.
[SW8] MIDI Receive Channel and Receive Filter
In the Multi mode, this is the same as the Part Receive Channel and Part Receive Switch settings.
In other modes, this is the same as the Basic Receive Channel setting.
[SW9] SYSTEM Receive GM/XG On
*1: Multi Mode Only
*2: Available only for the Plug-in voices
*3: The messages of CS6x Plug-in voice (Model ID=0x64) can be recognized.
MR_DL1.book Page 43 Monday, January 6, 2003 11:10 AM
44
(3) TRANSMIT/RECEIVE DATA
(3-1) CHANNEL VOICE MESSAGES
(3-1-1) NOTE OFF
STATUS 1000nnnn(8nH) n = 0 – 15 CHANNEL NUMBER
NOTE No. 0kkkkkkk k = 0(C-2) – 127(G8)
VELOCITY 0vvvvvvv v: ignored
Receive only.
(3-1-2) NOTE ON/OFF
STATUS 1001nnnn(9nH) n = 0 – 15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0(C-2) – 127(G8)
VELOCITY NOTE ON 0vvvvvvv(v≠0)
NOTE OFF 0vvvvvvv(v=0)
(3-1-3) CONTROL CHANGE
STATUS 1011nnnn(BnH) n = 0 – 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc
CONTROL VALUE 0vvvvvvv
* TRANDMITTED CONTROL NUMBER
c = 0 BANK SEL MSB ;v = 0 – 127 *3
c = 32 BANK SEL LSB ;v = 0 – 127 *3
* RECEIVED CONTROL NUMBER
c = 0 BANK SEL MSB ;v = 0 – 127 *3
c = 32 BANK SEL LSB ;v = 0 – 127 *3
c = 1 MODULATION ;v = 0 – 127
c = 5 PORTAMENTO TIME ;v = 0 – 127 *2
c = 6 DATA ENTRY MSB ;v = 0 – 127 *1
c = 38 DATA ENTRY LSB ;v = 0 – 127 *1
c = 7 MAIN VOLUME ;v = 0 – 127
c = 10 PAN ;v = 0 – 127
c = 11 EXPRESSION ;v = 0 – 127
c = 31 EG SUSTAIN LEVEL ;v = 0:-64 – 64:0 – 127:+63 *2,*5
c = 64 SUSTAIN SWITCH ;v = 0 – 63:OFF, 64 – 127:ON
c = 65 PORTAMENTO SWITCH ;v = 0 – 63:OFF, 64 – 127:ON *2
c = 66 SOSTENUTO ;v = 0 – 63:OFF, 64 – 127:ON
c = 71 HARMONIC CONTENT ;v = 0:-64 – 64:0 – 127:+63
c = 72 EG RELEASE TIME ;v = 0:-64 – 64:0 – 127:+63 *2
c = 73 EG ATTACK TIME ;v = 0:-64 – 64:0 – 127:+63
c = 74 BRIGHTNESS ;v = 0:-64 – 64:0 – 127:+63
c = 75 EG DECAY TIME ;v = 0:-64 – 64:0 – 127:+63
c = 91 EFFECT1 DEPTH ;v = 0 – 127
c = 93 EFFECT3 DEPTH ;v = 0 – 127
c = 96 DATA ENTRY INC ;v = 127 *1
c = 97 DATA ENTRY DEC ;v = 127 *1
c = 0..95 ASSIGNABLE CONTROLLER ;v = 0 – 127 *6
c = 0..95 ARPEGGIO SW ;v = 0 – 63:OFF, 64 – 127:ON *6
c = 0..95 ARPEGGIO HOLD ;v = 0 – 63:OFF, 64 – 127:ON *6
*1 Used only when a value is set using RPN
*2 Invalid with Drum Voices
*3 Relation between BANK CHANGE and PROGRAM is as follows:
*4 Can be selected only when the corresponding Plug-in board has been installed.
*5 Transmitted/received only when MODE2 is selected in CONTROL CHANGE MODE.
*6 The default CONTROL NUMBERs of ASSIGNABLE CONTROLLER are as follows:
BREATH CONTROLLER 2
FOOT CONTROLLER 4
Assign 1 16
Assign 2 17
Assign A 18
Assign B 19
FOOT SWITCH 88
ARPEGGIO HOLD 89
ARPEGGIO SWITCH 90
PORTAMENTO TIME sets the time it takes for the pitch to reach the next note played when PORTAMENTO SWITCH
is set to on.
PAN position relatively changes according to the preset value for each voice.
EFFECT1 DEPTH controls reverb send level.
EFFECT3 DEPTH controls chorus send level.
HARMONIC CONTENT adjusts the resonance preset for each voice.
Setting a value adds to or subtracts from the center value 64, since this is an offset parameter.
The larger the value, the more resonance in the sound. The effective range may be narrower than the range you
can specify, depending on the selected voice.
The parameters, EG ATTACK TIME, EG DECAY TIME, EG SUSTAIN LEVEL, EG RELEASE TIME adjust the
envelopes that are preset for each voice.
Setting these values adds to or subtracts from the center value 64, since these are offset parameters.
BRIGHTNESS adjusts the cutoff frequency preset for each voice.
Setting a value adds to or subtracts from the center value 64, since it is an offset parameter.
The smaller the value, the lower the cutoff frequency. The effective range may be narrower than the range you can
specify, depending on the selected voice.
Bank Select will be actually executed when the Program Change message is received.
Bank Select and Program Change numbers that are not supported by Yamaha will be ignored, but transmitted to
the Plug-in board.
(3-1-4) PROGRAM CHANGE
STATUS 1100nnnn(CnH) n = 0 – 15 CHANNEL NUMBER
PROGRAM NUMBER 0ppppppp p = 0 – 127
(3-1-5) CHANNEL AFTER TOUCH
STATUS 1101nnnn(DnH) n = 0 – 15 CHANNEL NUMBER
VALUE 0vvvvvvv v = 0 – 127 AFTER TOUCH VALUE
(3-1-6) PITCH BEND CHANGE
STATUS 1110nnnn(EnH) n = 0 – 15 CHANNEL NUMBER
LSB 0vvvvvvv PITCH BEND CHANGE LSB
MSB 0vvvvvvv PITCH BEND CHANGE MSB
Transmitted with a resolution of 7 bit.
(3-2) CHANNEL MODE MESSAGES
STATUS 1011nnnn(BnH) n = 0 – 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc c = CONTROL NUMBER
CONTROL VALUE 0vvvvvvv v = DATA VALUE
(3-2-1) ALL SOUND OFF (CONTROL NUMBER = 78H , DATA VALUE = 0)
All the sounds currently played including the channel messages such as note-on in a certain channel are muted
when receiving this message.
(3-2-2) RESET ALL CONTROLLERS (CONTROL NUMBER = 79H , DATA VALUE = 0)
Resets the values set for the following controllers.
PITCH BEND CHANGE 0 (center)
CHANNEL AFTER TOUCH 0 (minimum)
MODULATION 0 (minimum)
EXPRESSION 127 (maximum)
BREATH CONTROLLER 127 (maximum)
FOOT CONTROLLER 127 (maximum)
Assign A 0 (center)
Assign B 0 (center)
Assign 1 0 (center)
Assign 2 0 (center)
SUSTAIN SWITCH 0 (off)
SOSTENUTO SWITCH 0 (off)
RPN Not assigned; No change
The following data is not reset:
PROGRAM CHANGE, BANK SELECT MSB/LSB, VOLUME, PAN, HARMONIC CONTENT, SUSTAIN LEVEL,
RELEASE TIME, ATTACK TIME, DECAY TIME, BRIGHTNESS, EFFECT SEND LEVEL 1, EFFECT SEND LEVEL 3,
PORTAMENTO SWITCH, PITCH BEND SENSITIVITY, FINE TUNING, COARSE TUNING
(3-2-3) ALL NOTE OFF (CONTROL NUMBER = 7BH, DATA VALUE = 0)
All the notes currently set to on in certain channel(s) are muted when receiving this message.
However, if Sustain or Sostenuto is on, notes will continue to sound until these are turned off.
(3-2-4) OMNI MODE OFF (CONTROL NUMBER = 7CH, DATA VALUE = 0)
Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to “OMNI OFF,” channel 1.
(3-2-5) OMNI MODE ON (CONTROL NUMBER = 7DH, DATA VALUE = 0)
Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to “OMNI ON.”
(3-2-6) MONO (CONTROL NUMBER = 7EH, DATA VALUE = 0..16)
Performs the same function as when receiving ALL SOUNDS OFF. If the 3rd byte (mono) is within 0 through 16, the
channel will be set to Mode4 (m=1).
In the Voice mode, the mode can be Mode2 (m=1) according to VOICE RECEIVE CHANNEL.
(3-2-7) POLY (CONTROL NUMBER = 7FH, DATA VALUE = 0)
Performs the same function as when receiving ALL SOUNDS OFF. The channel will be Mode3.
In the Voice mode, the mode can be set to Mode1 according to VOICE RECEIVE CHANNEL.
(3-3) REGISTERED PARAMETER NUMBER
STATUS 1011nnnn(BnH) n = 0~15 CHANNEL NUMBER
LSB 01100100(64H)
RPN LSB 0ppppppp p = RPN LSB
(Refer to the table as shown below)
MSB 01100101(65H)
RPN MSB 0qqqqqqq q = RPN MSB
(Refer to the table as shown below)
DATA ENTRY MSB 00000110(06H)
DATA VALUE 0mmmmmmm m = Data Value
DATA ENTRY LSB 00100110(26H)
DATA VALUE 0lllllll l = Data Value
First, sepcify the parameter using RPN MSB/LSB numbers. Then, set its value with data entry MSB/LSB.
RPN D.ENTRY
LSB MSB MSB LSB PARAMETER NAME DATA RANGE
00H 00H mmH --- PITCH BEND SENSITIVITY 00H – 18H (0 – 24 semitones)
01H 00H mmH llH MASTER FINE TUNE {mmH,llH}
={00H,00H} – {40H,00H} – {7FH,7FH}
(-8192*100/8192) – 0 – (+8192*100/8192)
02H 00H mmH --- MASTER COARSE TUNE 28H – 40H – 58H
(-24 – 0 – +24 semitones)
7FH 7FH --- --- RPN RESET
RPN numbers will be left not specified.
The internal values are not affected.
(3-4) NON-REGISTERED PARAMETER NUMBER
There are no applicable parameters.
These are transmitted to the Plug-in board.
CATEGORY MSB LSB PROGRAM No.
GM Voice 0 0 0 – 127 (1 – 128)
GM Drum Voice 127 0 0 (1)
Normal Voice Preset 1 63 0 0 – 127 (1 – 128)
Preset 2 63 1 0 – 127 (1 – 128)
Preset 3 63 2 0 – 127 (1 – 128)
Preset 4 63 3 0 – 127 (1 – 128)
Preset 5 63 4 0 – 127 (1 – 128)
User1 63 8 0 – 127 (1 – 128)
User2 63 9 0 – 127 (1 – 128)
Drum Voice Preset 63 32 0 – 47 (1 – 48)
User 63 40 0 – 31 (1 – 32)
Plug-in Voice User 1 63 24 0 – 63 (1 – 64)
User 2 63 25 0 – 63 (1 – 64)
Multi User 63 65 0 – 127 (1 – 128)
Plug-in Voice Preset 1(Slot1) 63 70 0 – 63 (1 – 64) *4
Preset 2(Slot1) 63 71 0 – 63 (1 – 64) *4
Preset 3(Slot1) 63 72 0 – 63 (1 – 64) *4
Preset 1(Slot2) 63 73 0 – 63 (1 – 64) *4
Preset 2(Slot2) 63 74 0 – 63 (1 – 64) *4
Preset 3(Slot2) 63 75 0 – 63 (1 – 64) *4
MR_DL1.book Page 44 Monday, January 6, 2003 11:10 AM
45
(3-5) SYSTEM REAL TIME MESSAGES
(3-5-1) ACTIVE SENSING
STATUS 11111110(FEH)
Transmitted every 200 msec.
Once this code is received, the instrument starts sensing. When no status nor data is received for over
approximately 350 ms, MIDI receiving buffer will be cleared, and the sounds currently played and the sustain
switch are forcibly turned off. In this case, each control data will be reset to a certain value.
(3-6) SYSTEM EXCLUSIVE MESSAGE
(3-6-1) UNIVERSAL NON REALTIME MESSAGE
(3-6-1-1) GENERAL MIDI MODE ON
F0H 7EH 7FH 09H 01H F7H
Received only when SYSTEM Receive GM/XG on is set to on in MULTI MODE.
The Part values will be reset according to the SYSTEM Internal Part settings.
(3-6-1-2) IDENTITY REQUEST (Receive only)
F0H 7EH 0nH 06H 01H F7H
(“n” = Device No. However, this instrument receives under “omni.”)
(3-6-1-3) IDENTITY REPLY (Transmit only)
F0H 7EH 7FH 06H 02H 43H 00H 41H ddH ddH 00H 00H 00H 7FH F7H
dd: Device Number Code
MOTIF-RACK: 58 04
(3-6-2) UNIVERSAL REALTIME MESSAGE
(3-6-2-1) MIDI MASTER VOLUME
F0H 7FH 7FH 04H 01H llH mmH F7H
Sets the MASTER VOLUME value.
The value “mm” is used to set the master volume (the value “ll” should be ignored).
(3-6-3) PARAMETER CHANGE
(3-6-3-1) XG SYSTEM ON
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n Device Number
01001100 4C Model ID
0aaaaaaa 0 Address High
0aaaaaaa 0 Address Mid
0aaaaaaa 7E Address Low
0 0 Data
11110111 F7 End of Exclusive
Received only when SYSTEM Receive GM/XG on is set to on in MULTI MODE.
Be aware that executing this message takes about 170 ms and that, therefore, a certain interval before executing
the following message is needed.
(3-6-3-2) NATIVE PARAMETER CHANGE, MODE CHANGE
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n Device Number
01101111 6F Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0ddddddd ddddddd Data
||
11110111 F7 End of Exclusive
For parameters with data size of 2 or more, the appropriate number of data bytes will be transmitted.
See the following MIDI Data Table for Address.
(3-6-4) BULK DUMP
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0000nnnn 0n Device Number
01101111 6F Model ID
0bbbbbbb bbbbbbb Byte Count
0bbbbbbb bbbbbbb Byte Count
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0 0 Data
||
0ccccccc ccccccc Check-sum
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address and Byte Count.
The Check sum is the value that results in a value of 0 for the lower 7 bits when the Byte Count, Start Address, Data
and Check sum itself are added.
Bulk Dump data of the MOTIF (Model ID=0x6B) can be received.
(3-6-5) DUMP REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0010nnnn 2n Device Number
01101111 6F Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address and Byte Count.
(3-6-6) PARAMETER REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0011nnnn 3n Device Number
01101111 6F Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
See the following MIDI Data Table for Address.
MR_DL1.book Page 45 Monday, January 6, 2003 11:10 AM
46
MIDI Data Table
Bank Select
Available Bank Select/Program Change
When only a Program Change message is received after entering any of the
modes, the corresponding voice in the currently selected Type/Memory is called
up.
The Multi/Voice mode can be changed only via the Parameter Change.
<Table 1>
Parameter Base Address MODEL ID = 0x6F
*By using this message, you can store the received Bulk data (including User
Voice/Multi data and System data) and prevent it from being lost, even when the
power is turned off.
MSB (HEX) LSB (HEX) Program No. Type Memory Description
0 00 0 00 0 – 127 Normal Voice GM Voice
127 7F 0 00 0 Drum Voice GM Drum
63 3F 0 00 0 – 127 Normal Voice Preset 1
1 01 0 – 127 Preset 2
2 02 0 – 127 Preset 3
3 03 0 – 127 Preset 4
4 04 0 – 127 Preset 5
8 08 0 – 127 User 1
9 09 0 – 127 User 2
32 20 0 – 47 Drum Voice Preset
40 28 0 – 15 User
24 18 0 – 63 Plug-in Voice User 1 (PLG1)
25 19 0 – 63 User 2 (PLG2)
70 46 0 – 63 Preset 1 (PLG1) Plug-in Board installed to
PLG1 can be selected.
71 47 0 – 63 Preset 2 (PLG1)
72 48 0 – 63 Preset 3 (PLG1)
73 49 0 – 63 Preset 1 (PLG2) Plug-in Board installed to
PLG2 can be selected.
74 4A 0 – 63 Preset 2 (PLG2)
75 4B 0 – 63 Preset 3 (PLG2)
Depending on the installed Plug-in Board. Plug-in Direct -
63 3F 65 41 0 – 127 Multi User (Internal)
Parameter Block Description
Top Address
H M L
SYSTEM 00 00 00 System
00 10 00 Plug-in Board Native System
00 20 00 Master EQ for Voice
MODE CHANGE 0A 00 00 Mode Change
BULK CONTROL 0E 00 00 Header
0F 00 00 Footer
MULTIPLE BULK CONTROL 10 00 00 Header
11 00 00 Footer*
NORMAL VOICE COMMON 40 00 00 Common1
40 00 40 Common2
40 01 00 Reverb
40 02 00 Chorus
40 03 00 Insertion 1
40 04 00 Insertion 2
40 05 00 Controller
40 06 00 LFO
40 07 00 Audition
40 70 00 Extra
NORMAL VOICE ELEMENT GROUP1 41 ee 00 ee: Element No.
NORMAL VOICE ELEMENT GROUP2 42 ee 00 ee: Element No.
NORMAL VOICE ELEMENT GROUP3 43 ee 00 ee: Element No.
NORMAL VOICE ELEMENT GROUP4 44 ee 00 ee: Element No.
DRUM COMMON 46 00 00 Common1
46 00 40 Common2
46 01 00 Reverb
46 02 00 Chorus
46 03 00 Insertion 1
46 04 00 Insertion 2
46 05 00 Controller
46 06 00 Audition
46 70 00 Extra
DRUM ELEMENT GROUP1 47 ee 00 ee: Element No.
DRUM ELEMENT GROUP2 48 ee 00 ee: Element No.
DRUM ELEMENT GROUP3 49 ee 00 ee: Element No.
DRUM ELEMENT GROUP4 4A ee 00 ee: Element No.
VOICE PLUG-IN 4C 00 00 Common
4C 01 00 Reverb
4C 02 00 Chorus
4C 03 00 Insertion 1
4C 04 00 Insertion 2
4C 05 00 Controller
4C 06 00 Audition
4C 10 00 Plug-in XG Part
4C 20 00 Native
4C 70 00 Extra
Multi 36 00 00 Multi Common
37 00 00 Part 1
:
37 0F 00 Part 16
37 60 00 Plug-in 1 Part
37 61 00 Plug-in 2 Part
MR_DL1.book Page 46 Monday, January 6, 2003 11:10 AM
47
<Table 2>
Bulk Dump Block MODEL ID = 0x6F
“Top Address” indicates the top address of each block designated by bulk dump
operation.
“Byte Count” indicates the data size contained in each block designated by bulk
dump operation.
To execute 1 Multi / 1 Voice bulk dump request, specify its corresponding Bulk
Header address.
For the information about “mm” and “nn” shown in the following list, refer to MIDI
PARAMETER CHANGE TABLE (BULK CONTROL) below.
Parameter Block Description Byte Count Top Address
Dec Hex H M L
SYSTEM System 60 003C 00 00 00
Plug-in Board Native System 48 0030 00 10 00
Master EQ (for Voice Mode) 20 0014 00 20 00
VOICE (NORMAL) Bulk Header 0 00 0E mm nn
COMMON Extra 66 0042 40 70 00
Common 1 15 000F 40 00 00
Common 2 4 0004 40 00 40
Reverb 36 0024 40 01 00
Chorus 37 0025 40 02 00
Insertion 1 34 0022 40 03 00
Insertion 2 34 0022 40 04 00
Controller 30 001E 40 05 00
LFO 38 0026 40 06 00
Audition 4 0004 40 07 00
ELEMENT 1 Oscillator 29 001D 41 00 00
Amplitude 30 001E 41 00 20
Pitch 30 001E 42 00 00
Filter 50 0032 43 00 00
EQ 8 0008 44 00 00
LFO 8 0008 44 00 40
ELEMENT 2 Oscillator 29 001D 41 01 00
Amplitude 30 001E 41 01 20
Pitch 30 001E 42 01 00
Filter 50 0032 43 01 00
EQ 8 0008 44 01 00
LFO 8 0008 44 01 40
ELEMENT 3 Oscillator 29 001D 41 02 00
Amplitude 30 001E 41 02 20
Pitch 30 001E 42 02 00
Filter 50 0032 43 02 00
EQ 8 0008 44 02 00
LFO 8 0008 44 02 40
ELEMENT 4 Oscillator 29 001D 41 03 00
Amplitude 30 001E 41 03 20
Pitch 30 001E 42 03 00
Filter 50 0032 43 03 00
EQ 8 0008 44 03 00
LFO 8 0008 44 03 40
Bulk Footer 0 00 0F mm nn
VOICE (DRUM) Bulk Header 0 00 0E mm nn
COMMON Extra 66 0042 46 70 00
Common 1 8 0008 46 00 00
Common 2 4 0004 46 00 40
Reverb 36 0024 46 01 00
Chorus 37 0025 46 02 00
Insertion 1 34 0022 46 03 00
Insertion 2 34 0022 46 04 00
Controller 30 001E 46 05 00
Audition 4 0004 46 06 00
KEY C 0 Oscillator 19 0013 47 00 00
Amplitude 12 000C 47 00 20
Pitch 3 0003 48 00 00
Filter 8 0008 49 00 00
EQ 8 0008 4A 00 00
: 73 Blocks : : :
KEY C 6 Oscillator 19 0013 47 48 00
Amplitude 12 000C 47 48 20
Pitch 3 0003 48 48 00
Filter 8 0008 49 48 00
EQ 8 0008 4A 48 00
Bulk Footer 0 00 0F mm nn
VOICE (PLUG-IN) Bulk Header 0 00 0E mm nn
COMMON
*The messages of the
Plug-in Voice of the
CS6x (MODEL ID
=0x64) can be
recognized.
Extra 66 0042 4C 70 00
Common 13 000D 4C 00 00
Reverb 36 0024 4C 01 00
Chorus 37 0025 4C 02 00
Insertion 1 34 0022 4C 03 00
Insertion 2 34 0022 4C 04 00
Controller 10 000A 4C 05 00
Audition 4 0004 4C 06 00
Plug-in XG Part 35 0023 4C 10 00
Native 68 0044 4C 20 00
Bulk Footer 0 00 0F mm nn
MULTI Bulk Header 0 00 0E mm nn
COMMON Common 88 0058 36 00 00
Reverb 36 0024 36 01 00
Chorus 37 0025 36 02 00
Master EQ 20 0014 36 10 00
PART Part 1 58 003A 37 00 00
: 16 Blocks : : :
Part 16 58 003A 37 0F 00
PLUG-IN PART Plug-in 1 Part 58 003A 37 60 00
: 2 Blocks : : :
Plug-in 2 Part 58 003A 37 61 00
Bulk Footer 0 00 0F mm nn
Parameter Block Description Byte Count Top Address
Dec Hex H M L
MR_DL1.book Page 47 Monday, January 6, 2003 11:10 AM
48
<Table 3-1>
MIDI PARAMETER CHANGE TABLE (Mode Change)
MODEL ID = 0x6F
<Table 3-2>
MIDI PARAMETER CHANGE TABLE (BULK CONTROL)
<Table 4>
MIDI PARAMETER CHANGE TABLE (SYSTEM)
MODEL ID = 0x6F
TOTAL SIZE = 60 3C (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
0A 00 00 1 00 – 7F reserved 0 – 127
01 1 00 – 04 MODE CHANGE 0: Voice, 1: Reserved, 2: Reserved,
3: Multi
Address Size Data
Range
(HEX)
Parameter Name Description Notes
0E 00 nn 1 - Bulk Header Normal Voice PRE1 (nn = 0 – 127)
01 nn 1 - Normal Voice PRE2 (nn = 0 – 127)
02 nn 1 - Normal Voice PRE3 (nn = 0 – 127)
03 nn 1 - Normal Voice PRE4 (nn = 0 – 127)
04 nn 1 - Normal Voice PRE5 (nn = 0 – 127)
08 nn 1 - Normal Voice USER1 (nn = 0 – 127)
09 nn 1 - Normal Voice USER2 (nn = 0 – 127)
0F nn 1 - Normal Voice Edit Buffer (nn = 0)
18 nn 1 - Plug-in Voice PLG1 (nn = 0 – 63)
19 nn 1 - Plug-in Voice PLG2 (nn = 0 – 63)
1A nn 1 - reserved
1F nn 1 - Plug-in Voice Edit Buffer (nn = 0)
20 nn 1 - Drum Voice PRE (nn = 0 – 47)
28 nn 1 - Drum Voice USER (nn = 0 – 31)
29 nn 1 - reserved
2F nn 1 - Drum Voice Edit Buffer (nn = 0)
40 nn 1 - reserved
41 nn 1 - Multi USER (nn = 0 – 127)
4F nn 1 - reserved
5F nn 1 - Multi Edit Buffer (nn = 0)
68 nn 1 - reserved
6F nn 1 - reserved
70 nn 1 - reserved
7F nn 1 - reserved
0F 00 nn 1 - Bulk Footer Normal Voice PRE1 (nn = 0 – 127)
01 nn 1 - Normal Voice PRE2 (nn = 0 – 127)
02 nn 1 - Normal Voice PRE3 (nn = 0 – 127)
03 nn 1 - Normal Voice PRE4 (nn = 0 – 127)
04 nn 1 - Normal Voice PRE5 (nn = 0 – 127)
08 nn 1 - Normal Voice USER1 (nn = 0 – 127)
09 nn 1 - Normal Voice USER2 (nn = 0 – 127)
0F nn 1 - Normal Voice Edit Buffer (nn = 0)
18 nn 1 - Plug-in Voice PLG1 (nn = 0 – 63)
19 nn 1 - Plug-in Voice PLG2 (nn = 0 – 63)
1A nn 1 - reserved
1F nn 1 - Plug-in Voice Edit Buffer (nn = 0)
20 nn 1 - Drum Voice PRE (nn = 0 – 47)
28 nn 1 - Drum Voice USER (nn = 0 – 31)
29 nn 1 - reserved
2F nn 1 - Drum Voice Edit Buffer (nn = 0)
40 nn 1 - reserved
41 nn 1 - Multi USER (nn = 0 – 127)
4F nn 1 - reserved
5F nn 1 - Multi Edit Buffer (nn = 0)
68 nn 1 - reserved
6F nn 1 - reserved
70 nn 1 - reserved
7F nn 1 - reserved
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
00 00 00 1 00 – 7F Master Volume 0 – 127 7F
01 1 28 – 58 Master Note Shift -24 – +24 [semitones] 40
02 4 00 – 0F
00 – 0F
00 – 0F
00 – 0F
Master Tune -102.4 – +102.3 [cent]
1st bit3-0 → bit15-12
2nd bit3-0 → bit11-8
3rd bit3-0 → bit7-4
4th bit3-0 → bit3-0
00
04
00
00
(0400)
06 1 00 – 01 Controller Reset hold, reset 01
07 1 35 – 4B reserved 40
08 1 3D – 43 reserved 40
09 1 reserved
0A 1 00 – 10,
7F
Basic Receive Channel 1 – 16, omni, off 00
0B 1 00 – 0F,
7F
Transmit Channel 1 – 16, off 00
0C 1 reserved
0D 1 00 – 01 reserved 00
0E 1 00 – 01 Stereo L&R Output Gain 00: 0dB, 01: +6dB 01
0F 1 00 – 01 Assignable Out 1/2 Output
Gain
00: 0dB, 01: +6dB 01
10 1 00 – 01 Assignable Out 3/4 Output
Gain
00: 0dB, 01: +6dB 01
11 1
12 1 00 – 04 reserved 00
13 1 01 – 7F reserved 40
14 1 00 – 01 Receive GM/XG On for Multi
Part PB
off, on 01
15 1 00 – 01
Receive/Transmit Bank Select
off, on 01
16 1 00 – 01 Receive/Transmit Program
Change
off, on 01
17 1 00 – 01 MIDI Control Mode mode 1, mode 2 00
18 1 00 – 07 Thru Port for USB 1 – 8 00
19 1 00 – 01 MIDI In/Out MIDI, USB 00
1A 1 00 – 03 Effect Bypass for System Effect bit0: Reverb,
bit1: Chorus
03
1B 1 reserved 01
1C 1 00 – 01 Effect Bypass for Insertion
Effect
bit0: Internal 01
1D 1 00 – 01 reserved 00
1E 1 00 – 01 reserved 00
1F 1 00 – 03 Power on Mode Multi, Voice (INT),
Voice (PRE1), GM
02
20 1 reserved 00
21 1 00 – 02 reserved 00
22 1 00 – 02 reserved 00
23 1 00 – 01 reserved 00
24 1 00 – 01 reserved 00
25 1 00 – 01 reserved 01
26 1 reserved
27 1 00 – 01 reserved 00
28 1 00 – 01 reserved 00
29 1 reserved
2A 1 00 – 43 Assign A Destination off, 1 – 67 3B
2B 1 00 – 43 Assign B Destination off, 1 – 67 3C
2C 1 reserved
2D 1 00 – 5F Assign A Control Number off, 1 – 95 12
2E 1 00 – 5F Assign B Control Number off, 1 – 95 13
2F 1 reserved 01
30 1 reserved 01
31 1 00 – 5F FS Assign 0 – 95 58
32 1 00 – 5F ARP Switch Control Number off, 1 – 95 5A
33 1 00 – 5F ARP Hold Control Number off, 1 – 95 59
34 1 00 – 01 ARP MIDI Out Switch off, on 00 For Voice
Mode
35 1 00 – 0F ARP MIDI Out Channel 1 – 16 00 :
36 1 00 – 5F Assign 1 Control Number off, 1 – 95 10 :
37 1 00 – 5F Assign 2 Control Number off, 1 – 95 11 :
38 1 00 – 5F BC Control Number off, 1 – 95 02 :
39 1 00 – 5F FC2 Control Number off, 1 – 95 04 :
3A 1 00 – 5F FC1 Control Number off, 1 – 95 0B
3B 1 reserved
MR_DL1.book Page 48 Monday, January 6, 2003 11:10 AM
49
TOTAL SIZE = 48 30 (HEX)
TOTAL SIZE = 20 14 (HEX)
<Table 5-1>
MIDI PARAMETER CHANGE TABLE
(NORMAL VOICE COMMON) MODEL IDE = 0x6F
TOTAL SIZE = 66 42 (HEX)
TOTAL SIZE = 15 0F (HEX)
TOTAL SIZE = 4 04 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
00 10 00 16 00 – 7F Plug-in 1 Native System
Parameter
Depends on Plug-in
Board
Depends on Plug-in
Board
10 16 00 – 7F Plug-in 2 Native System
Parameter
Depends on Plug-in
Board
Depends on Plug-in
Board
20 16 reserved
00 20 00 1 34 -4C EQ Low Gain -12 – +12 [dB] 40 For Voice
Mode
01 1 04 – 28 EQ Low Frequency 32 – 2000 [Hz] 0C :
02 1 01 – 78 EQ Low Q 0. 1 – 12.0 07 :
03 1 00 – 01 EQ Low Shape shelv, peak 00 :
04 1 34 – 4C EQ Low-Mid Gain -12 – +12 [dB] 40 :
05 1 0E – 36 EQ Low-Mid Frequency 100 – 10.0 [kHz] 14 :
06 1 01 – 78 EQ Low-Mid Q 0.1 – 12.0 07 :
1 01 reserved 01
08 1 34 – 4C EQ Mid Gain -12 – +12 [dB] 40 :
09 1 0E – 36 EQ Mid Frequency 100 – 10.0 [kHz] 1C :
0A 1 01 – 78 EQ Mid Q 0.1 – 12.0 07 :
1 NOT USED :
0C 1 34 – 4C EQ High-Mid Gain -12 – +12 [dB] 40 :
0D 1 0E – 36 EQ High-Mid Frequency 100 – 10.0 [kHz] 2C :
0E 1 01 – 78 EQ High-Mid Q 0.1 – 12.0 07 :
1 NOT USED :
10 1 34 – 4C EQ High Gain -12 – +12 [dB] 40 :
11 1 1C – 3A EQ High Frequency 0.5 – 16.0 [kHz] 34 :
12 1 01 – 78 EQ High Q 0.1 – 12.0 07 :
13 1 00 – 01 EQ High Shape shelv, peak 00 :
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
40 70 00 1 20 – 7E Voice Name 1 32 – 126 (ASCII) Init Voice
40 70 01 1 20 – 7E Voice Name 2 32 – 126 (ASCII) ˝
40 70 02 1 20 – 7E Voice Name 3 32 – 126 (ASCII) ˝
40 70 03 1 20 – 7E Voice Name 4 32 – 126 (ASCII) ˝
40 70 04 1 20 – 7E Voice Name 5 32 – 126 (ASCII) ˝
40 70 05 1 20 – 7E Voice Name 6 32 – 126 (ASCII) ˝
40 70 06 1 20 – 7E Voice Name 7 32 – 126 (ASCII) ˝
40 70 07 1 20 – 7E Voice Name 8 32 – 126 (ASCII) ˝
40 70 08 1 20 – 7E Voice Name 9 32 – 126 (ASCII) ˝
40 70 09 1 20 – 7E Voice Name 10 32 – 126 (ASCII) ˝
40 70 0A 1 reserved
40 70 0B 1 reserved
40 70 0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) 00 (--) Ap, Kb, Or,
Gt, Ba, St,
Br, Rp, Ld,
Pd, Sc, Cp,
Dr, Se, Me,
Co
40 70 0D 1 00 – 03 reserved 00
40 70 0E 1 reserved
40 70 0F 1 reserved
40 70 10 1 reserved
40 70 11 1 reserved
40 70 12 1 reserved
40 70 13 1 00 – 01 ARP Type Bank pre1, pre2 00
40 70 14 1 00 – 7F ARP Type UpOct1 – GateCutC 1D
40 70 15 1 00 – 01 ARP Switch off, on 00
40 70 16 1 00 – 02 ARP Hold sync-off, off, on 01
40 70 17 1 00 – 06 ARP Unit Multiply
50%, 66%, 75%, 100%,
133%, 150%, 200%
03
40 70 18 1 00 – 7F ARP Note Limit Low C-2 – G8 00
40 70 19 1 00 – 7F ARP Note Limit High C-2 – G8 7F
40 70 1A 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
40 70 1B 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
40 70 1C 1 00 – 02 ARP Key Mode sort, thru, direct 00
40 70 1D 1 00 – 01 ARP Vel Mode original, thru 00
40 70 1E 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200% 64
40 70 20 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate TIme Rate LSB
0 – 200% 64
40 70 22 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300 8A
40 70 24 1 00 – 04 reserved 02
40 70 25 1 01 – 7F Pan L63 – C – R63 40
40 70 26 1 40 reserved 40
40 70 27 1 00 – 7F Decay Time -64 – +63 40
40 70 28 1 00 – 7F Sustain Level -64 – +63 40
40 70 29 1 00 – 7F FEG Attack Time -64 – +63 40
40 70 2A 1 00 – 7F FEG Decay Time -64 – +63 40
40 70 2B 1 00 – 7F FEG Release Time -64 – +63 40
40 70 2C 1 reserved
40 70 2D 1 00 – 7F FEG Depth -64 – +63 40
40 70 2E 1 00 – 7F Assign A -64 – +63 40
40 70 2F 1 00 – 7F Assign B -64 – +63 40
40 70 30 1 reserved
40 70 31 1 00 – 7F EQ Low Gain -64 – +63 40
40 70 32 1 00 – 7F EQ Low Mid Gain -64 – +63 40
40 70 33 1 00 – 7F EQ High Mid Gain -64 – +63 40
40 70 34 1 00 – 7F EQ High Gain -64 – +63 40
40 70 35 1 00 – 7F Assign 1 -64 – +63 40
40 70 36 1 00 – 7F Assign 2 -64 – +63 40
40 70 37 1 00 – 7F Cutoff Frequency -64 – +63 40
40 70 38 1 00 – 7F Resonance -64 – +63 40
40 70 39 1 00 – 7F Attack Time -64 – +63 40
40 70 3A 1 00 – 7F Release Time -64 – +63 40
40 70 3B 1 reserved
40 70 3C 1 reserved
40 70 3D 1 reserved
40 70 3E 1 reserved
40 70 3F 1 reserved
40 70 40 1 reserved
40 70 41 1 reserved
40 00 00 1 reserved (02)
40 00 01 1 00 – 7F Volume 0 – 127 7F
40 00 02 1 00 – 01 Same Note Number Key On
Assign
single, multi 01
40 00 03 1 00 – 01 Mono/Poly Mode mono, poly 01
40 00 04 1 00 – 1F Micro Tuning Equal – Indian 00
40 00 05 1 10 – 58 Pitch Bend Range Upper -48 – +24 [semitones] 42
40 00 06 1 10 – 58 Pitch Bend Range Lower -48 – +24 [semitones] 3E
40 00 07 1 00 – 01 Portamento Mode fingered, fulltime 01
40 00 08 1 00 – 01 Portamento Switch off, on 00
40 00 09 1 00 – 7F Portamento Time 0 – 127 40
40 00 0A 1 00 – 01 Portamento Time Mode rate, time 00
40 00 0B 1 00 – 7F Reverb Send -∞dB – 0dB 0C
40 00 0C 1 00 – 7F Chorus Send -∞dB – 0dB 00
40 00 0D 1 reserved (00)
40 00 0E 1 reserved (7F)
40 00 40 1 00 – 02 Insertion Connect Type Para, 1→2, 2→101
40 00 41 1 reserved (00)
40 00 42 1 reserved (00)
40 00 43 1 reserved (00)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
MR_DL1.book Page 49 Monday, January 6, 2003 11:10 AM
50
TOTAL SIZE = 36 24 (HEX)
TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 34 22 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
40 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to Effect
Parameter List
0100
40 01 02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
˝ init value for
hall1
40 01 04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
˝ init value for
hall1
40 01 06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
˝ init value for
hall1
40 01 08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
˝ init value for
hall1
40 01 0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
˝ init value for
hall1
40 01 0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
˝ init value for
hall1
40 01 0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
˝ init value for
hall1
40 01 10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
˝ init value for
hall1
40 01 12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
˝ init value for
hall1
40 01 14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
˝ init value for
hall1
40 01 16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
˝ init value for
hall1
40 01 18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
˝ init value for
hall1
40 01 1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
˝ init value for
hall1
40 01 1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
˝ init value for
hall1
40 01 1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
˝ init value for
hall1
40 01 20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
˝ init value for
hall1
40 01 22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
40
40 01 23 1 01 – 7F Reverb Pan L63 – C – R63 40
40 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to Effect
Parameter List
0500
40 02 02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
˝ init value for
chorus1
40 02 04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
˝ init value for
chorus1
40 02 06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
˝ init value for
chorus1
40 02 08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
˝ init value for
chorus1
40 02 0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
˝ init value for
chorus1
40 02 0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
˝ init value for
chorus1
40 02 0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
˝ init value for
chorus1
40 02 10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
˝ init value for
chorus1
40 02 12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
˝ init value for
chorus1
40 02 14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
˝ init value for
chorus1
40 02 16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
˝ init value for
chorus1
40 02 18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
˝ init value for
chorus1
40 02 1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
˝ init value for
chorus1
40 02 1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
˝ init value for
chorus1
40 02 1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
˝ init value for
chorus1
40 02 20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
˝ init value for
chorus1
40 02 22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
60
40 02 23 1 01 – 7F Chorus Pan L63 – C – R63 40
40 02 24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127) 00
Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
40 03 00 2 00 – 7F
00 – 7F
Insertion 1 Type MSB
Insertion 1 Type LSB
Refer to Effect
Parameter List
0000
40 03 02 2 00 – 7F
00 – 7F
Insertion 1 Parameter 1 MSB
Insertion 1 Parameter 1 LSB
˝ 0000
40 03 04 2 00 – 7F
00 – 7F
Insertion 1 Parameter 2 MSB
Insertion 1 Parameter 2 LSB
˝ 0000
40 03 06 2 00 – 7F
00 – 7F
Insertion 1 Parameter 3 MSB
Insertion 1 Parameter 3 LSB
˝ 0000
40 03 08 2 00 – 7F
00 – 7F
Insertion 1 Parameter 4 MSB
Insertion 1 Parameter 4 LSB
˝ 0000
40 03 0A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 5 MSB
Insertion 1 Parameter 5 LSB
˝ 0000
40 03 0C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 6 MSB
Insertion 1 Parameter 6 LSB
˝ 0000
40 03 0E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 7 MSB
Insertion 1 Parameter 7 LSB
˝ 0000
40 03 10 2 00 – 7F
00 – 7F
Insertion 1 Parameter 8 MSB
Insertion 1 Parameter 8 LSB
˝ 0000
40 03 12 2 00 – 7F
00 – 7F
Insertion 1 Parameter 9 MSB
Insertion 1 Parameter 9 LSB
˝ 0000
40 03 14 2 00 – 7F
00 – 7F
Insertion 1 Parameter 10 MSB
Insertion 1 Parameter 10 LSB
˝ 0000
40 03 16 2 00 – 7F
00 – 7F
Insertion 1 Parameter 11 MSB
Insertion 1 Parameter 11 LSB
˝ 0000
40 03 18 2 00 – 7F
00 – 7F
Insertion 1 Parameter 12 MSB
Insertion 1 Parameter 12 LSB
˝ 0000
40 03 1A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 13 MSB
Insertion 1 Parameter 13 LSB
˝ 0000
40 03 1C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 14 MSB
Insertion 1 Parameter 14 LSB
˝ 0000
40 03 1E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 15 MSB
Insertion 1 Parameter 15 LSB
˝ 0000
40 03 20 2 00 – 7F
00 – 7F
Insertion 1 Parameter 16 MSB
Insertion 1 Parameter 16 LSB
˝ 0000
40 04 00 2 00 – 7F
00 – 7F
Insertion 2 Type MSB
Insertion 2 Type LSB
Refer to Effect
Parameter List
0000
40 04 02 2 00 – 7F
00 – 7F
Insertion 2 Parameter 1 MSB
Insertion 2 Parameter 1 LSB
˝ 0000
40 04 04 2 00 – 7F
00 – 7F
Insertion 2 Parameter 2 MSB
Insertion 2 Parameter 2 LSB
˝ 0000
40 04 06 2 00 – 7F
00 – 7F
Insertion 2 Parameter 3 MSB
Insertion 2 Parameter 3 LSB
˝ 0000
40 04 08 2 00 – 7F
00 – 7F
Insertion 2 Parameter 4 MSB
Insertion 2 Parameter 4 LSB
˝ 0000
40 04 0A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 5 MSB
Insertion 2 Parameter 5 LSB
˝ 0000
40 04 0C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 6 MSB
Insertion 2 Parameter 6 LSB
˝ 0000
40 04 0E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 7 MSB
Insertion 2 Parameter 7 LSB
˝ 0000
40 04 10 2 00 – 7F
00 – 7F
Insertion 2 Parameter 8 MSB
Insertion 2 Parameter 8 LSB
˝ 0000
40 04 12 2 00 – 7F
00 – 7F
Insertion 2 Parameter 9 MSB
Insertion 2 Parameter 9 LSB
˝ 0000
40 04 14 2 00 – 7F
00 – 7F
Insertion 2 Parameter 10 MSB
Insertion 2 Parameter 10 LSB
˝ 0000
40 04 16 2 00 – 7F
00 – 7F
Insertion 2 Parameter 11 MSB
Insertion 2 Parameter 11 LSB
˝ 0000
40 04 18 2 00 – 7F
00 – 7F
Insertion 2 Parameter 12 MSB
Insertion 2 Parameter 12 LSB
˝ 0000
40 04 1A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 13 MSB
Insertion 2 Parameter 13 LSB
˝ 0000
40 04 1C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 14 MSB
Insertion 2 Parameter 14 LSB
˝ 0000
40 04 1E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 15 MSB
Insertion 2 Parameter 15 LSB
˝ 0000
40 04 20 2 00 – 7F
00 – 7F
Insertion 2 Parameter 16 MSB
Insertion 2 Parameter 16 LSB
˝ 0000
MR_DL1.book Page 50 Monday, January 6, 2003 11:10 AM
51
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 38 26 (HEX)
TOTAL SIZE = 4 04 (HEX)
<Table 5-2>
MIDI PARAMETER CHANGE TABLE
(NORMAL VOICE ELEMENT)
TOTAL SIZE = 29 1D (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
40 05 00 1 00 – 09 Controller Set 1 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
01
40 05 01 2 00
00 – 44
Controller Set 1 Destination MSB
Controller Set 1 Destination LSB
0 – 68 00
40 05 03 1 00 – 7F Controller Set 1 Depth -64 – +63 40
40 05 04 1 reserved (00)
40 05 05 1 00 – 09 Controller Set 2 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
01
40 05 06 2 00
00 – 44
Controller Set 2 Destination MSB
Controller Set 2 Destination LSB
0 – 68 00
40 05 08 1 00 – 7F Controller Set 2 Depth -64 – +63 40
40 05 09 1 reserved (00)
40 05 0A 1 00 – 09 Controller Set 3 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
01
40 05 0B 2 00
00 – 44
Controller Set 3 Destination MSB
Controller Set 3 Destination LSB
0 – 68 00
40 05 0D 1 00 – 7F Controller Set 3 Depth -64 – +63 40
40 05 0E 1 reserved (00)
40 05 0F 1 00 – 09 Controller Set 4 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
08
40 05 10 2 00
00 – 44
Controller Set 4 Destination MSB
Controller Set 4 Destination LSB
0 – 68 00
40 05 12 1 00 – 7F Controller Set 4 Depth -64 – +63 40
40 05 13 1 reserved (00)
40 05 14 1 00 – 09 Controller Set 5 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
09
40 05 15 2 00
00 – 44
Controller Set 5 Destination MSB
Controller Set 5 Destination LSB
0 – 68 00
40 05 17 1 00 – 7F Controller Set 5 Depth -64 – +63 40
40 05 18 1 reserved (00)
40 05 19 1 00 – 09 Controller Set 6 Source PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
03
40 05 1A 2 00
00 – 44
Controller Set 6 Destination MSB
Controller Set 6 Destination LSB
0 – 68 00
40 05 1C 1 00 – 7F Controller Set 6 Depth -64 – +63 40
40 05 1D 1 reserved (00)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
40 06 00 1 00 – 05 LFO Phase 0, 90, 120, 180, 240,
270
00
40 06 01 1 00 – 0C LFO Wave
tri, tri+, sawup, sawdwn,
squ1/4, squ1/3, squ,
squ2/3, squ3/4, trpzd,
S/H1, S/H2, user
00
40 06 02 1 00 – 3F LFO Speed 0 – 63 (available only
when Tempo Sync is
set to Off)
20
40 06 03 1 05 – 15 LFO TEMPO SPEED 5 – 21 (available only
when Tempo Sync is
set to on)
0B 16th, 8th/3,
16th., 8th,
4th/3, 8th.,
4th, 2th/3,
4th., 2nd,
Whole/3,
2nd., 4thX4,
4thX6, 4thX6,
4thX7, 4thX8
40 06 04 1 00 – 01 LFO TEMPO SYNC OFF, ON 00
40 06 05 1 00 – 7F LFO Delay Time 0 – 127 00
40 06 06 1 00 – 7F LFO Fade In Time 0 – 127 00
40 06 07 1 00 – 7F LFO Hold Time 0 – 127 7F
40 06 08 1 00 – 7F LFO Fade Out Time 0 – 127 40
40 06 09 1 00 – 02 LFO Key On Reset off, each-on, 1st-on 02
40 06 0A 1 00 – 05 LFO Box 1 Destination AMD, PMD, FMD,
RESO, PAN, ELEMENT
LFO SPEED
02
40 06 0B 1 00 – 7F LFO Box 1 Depth 0 – 127 00
40 06 0C 1 reserved (00)
40 06 0D 1 00 – 05 LFO Box 2 Destination AMD, PMD, FMD,
RESO, PAN, ELEMENT
LFO SPEED
04
40 06 0E 1 00 – 7F LFO Box 2 Depth 0 – 127 00
40 06 0F 1 reserved (00)
40 06 10 1 00 – 05 LFO Box 3 Destination AMD, PMD, FMD,
RESO, PAN, ELEMENT
LFO SPEED
04
40 06 11 1 00 – 7F LFO Box 3 Depth 0 – 127 00
40 06 12 1 reserved (00)
40 06 13 1 00 – 06 USER WAVE TOTAL STEP 2, 3, 4, 6, 8, 12, 16 06
40 06 14 1 00 – 03 USER WAVE SLOPE OFF, UP, DOWN,
UP&DOWN
00
40 06 15 1 00 – 7F USER WAVE STEP VALUE 1 0 – 127 40
40 06 16 1 00 – 7F USER WAVE STEP VALUE 2 0 – 127 40
40 06 17 1 00 – 7F USER WAVE STEP VALUE 3 0 – 127 40
40 06 18 1 00 – 7F USER WAVE STEP VALUE 4 0 – 127 40
40 06 19 1 00 – 7F USER WAVE STEP VALUE 5 0 – 127 40
40 06 1A 1 00 – 7F USER WAVE STEP VALUE 6 0 – 127 40
40 06 1B 1 00 – 7F USER WAVE STEP VALUE 7 0 – 127 40
40 06 1C 1 00 – 7F USER WAVE STEP VALUE 8 0 – 127 40
40 06 1D 1 00 – 7F USER WAVE STEP VALUE 9 0 – 127 40
40 06 1E 1 00 – 7F USER WAVE STEP VALUE 10 0 – 127 40
40 06 1F 1 00 – 7F USER WAVE STEP VALUE 11 0 – 127 40
40 06 20 1 00 – 7F USER WAVE STEP VALUE 12 0 – 127 40
40 06 21 1 00 – 7F USER WAVE STEP VALUE 13 0 – 127 40
40 06 22 1 00 – 7F USER WAVE STEP VALUE 14 0 – 127 40
40 06 23 1 00 – 7F USER WAVE STEP VALUE 15 0 – 127 40
40 06 24 1 00 – 7F USER WAVE STEP VALUE 16 0 – 127 40
40 06 25 1 reserved (00)
40 07 00 2 00 – 02
00 – 7F
Audition Phrase Number MSB
Audition Phrase Number LSB
000 – 285 00 00
40 07 02 1 28 – 58 Audition Note Shift -24 – 24 40
40 07 03 1 reserved
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
41 ee 00 1 00 – 01 ELEMENT ASSIGN 0: OFF, 1: ON 01
(EL1 only)
41 ee 01 1 00 reserved 00
41 ee 02 1 reserved 00
41 ee 03 2 00 – 7F
00 – 7F
Wave Number MSB
Wave Number LSB
0 – 1309
1st bit6-0 → bit13-7
00 01
41 ee 05 1 reserved (01)
41 ee 06 1 reserved (01)
41 ee 07 1 reserved (00)
41 ee 08 1 01 – 7F Pan L63 – C – R63 40
41 ee 09 1 00 – 7F Random Pan Depth 0 – 127 00
41 ee 0A 1 00 – 7F Alternate Pan Depth L64 – 0 – R63 40
41 ee 0B 1 00 – 7F Scaling Pan Depth -64 – +63 40
41 ee 0C 1 00 – 7F Note Limit Low 0 – 127 00
41 ee 0D 1 00 – 7F Note Limit High 0 – 127 7F
41 ee 0E 1 01 – 7F Velocity Limit Low 1 – 127 01
41 ee 0F 1 01 – 7F Velocity Limit High 1 – 127 7F
41 ee 10 1 00 – 7F VELOCITY CROSS FADE 0 – 127 00
41 ee 11 1 00 – 7F Key On Delay 0 – 127 00
41 ee 12 1 reserved (00)
41 ee 13 1 reserved (7F)
41 ee 14 1 reserved (7F)
41 ee 15 1 00 reserved 00
41 ee 16 1 00 – 02 Insertion Effect Switch thru, ins1, ins2 00
41 ee 17 1 reserved (00)
41 ee 18 2 00 – 00
00 – 3F
CONTROL BOX SW BIT 0 – 6: RESERVE
BIT 0 – 5: BOX 1 – BOX
6, BIT 6: RESERVE
00
20
41 ee 1A 2 00 – 00
00 – 07
LFO BOX SW BIT 0 – 6: RESERVE
BIT 0 – 2: BOX 1 – BOX
3, BIT 3 – 6: RESERVE
00
07
41 ee 1C 1 reserved (0B)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
MR_DL1.book Page 51 Monday, January 6, 2003 11:10 AM
52
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 50 32 (HEX)
TOTAL SIZE = 8 08 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
41 ee 20 1 00 – 7F Element Level 0 – 127 7F
41 ee 21 1 00 – 7F Level Velocity Sensitivity -64 – +63 40
41 ee 22 1 00 – 04 LEVEL SENS VELOCITY
CURVE
00 – 04 03
41 ee 23 1 reserved (00)
41 ee 24 1 00 – 7F AEG Attack Time 0 – 127 00
41 ee 25 1 00 – 7F AEG Decay1 Time 0 – 127 40
41 ee 26 1 00 – 7F AEG Decay2 Time 0 – 127 40
41 ee 27 1 00 – 7F AEG Release Time 0 – 127 32
41 ee 28 1 00 – 7F AEG Init Level 0 – 127 00
41 ee 29 1 reserved (7F)
41 ee 2A 1 00 – 7F AEG Decay1 Level 0 – 127 7F
41 ee 2B 1 00 – 7F AEG Decay2 Level 0 – 127 7F
41 ee 2C 1 reserved (00)
41 ee 2D 1 00 – 04 AEG Time Velocity Segment ATK, ATK+DCY, DCY,
ATK+RLS, ALL
04
41 ee 2E 1 00 – 7F AEG Time Velocity Sensitivity -64 – +63 40
41 ee 2F 1 00 – 7F Level Key Follow Sensitivity -200% – +200% 40
41 ee 30 1 00 – 7C Level Scaling Break Point 1 C -2 – E8 24 BP1<BP2<
BP3<BP4
41 ee 31 1 01 – 7D Level Scaling Break Point 2 C-2 – F8 30 BP1<BP2<
BP3<BP4
41 ee 32 1 02 – 7E Level Scaling Break Point 3 D -2 – F8 3C BP1<BP2<
BP3<BP4
41 ee 33 1 03 – 7F Level Scaling Break Point 4 D-2 – G8 48 BP1<BP2<
BP3<BP4
41 ee 34 2 00 – 01
00 – 7F
Level Scaling Offset 1 -128 – +127 01 00
41 ee 36 2 00 – 01
00 – 7F
Level Scaling Offset 2 -128 – +127 01 00
41 ee 38 2 00 – 01
00 – 7F
Level Scaling Offset 3 -128 – +127 01 00
41 ee 3A 2 00 – 01
00 – 7F
Level Scaling Offset 4 -128 – +127 01 00
41 ee 3C 1 00 – 7F AEG Time Key Follow
Sensitivity
-64 – +63 40
41 ee 3D 1 00 – 7F AEG Time Key Follow Center
Note
C-2 – G8 18
42 ee 00 1 10 – 70 Coarse Tune -48 – +48 40
42 ee 01 1 00 – 7F Fine Tune -64 – +63 40
42 ee 02 1 00 – 7F VELOCITY
→ PITCH SENSITIVITY
-64 – +63 40
42 ee 03 1 reserved (02)
42 ee 04 1 00 – 7F Random Pitch Depth 0 – 127 00
42 ee 05 1 00 – 7F PEG Hold Time 0 – 127 00
42 ee 06 1 00 – 7F PEG Attack Time 0 – 127 28
42 ee 07 1 00 – 7F PEG Decay 1 Time 0 – 127 40
42 ee 08 1 00 – 7F PEG Decay 2 Time 0 – 127 40
42 ee 09 1 00 – 7F PEG Release Time 0 – 127 40
42 ee 0A 2 00 – 01
00 – 7F
PEG Hold Level -128 – +127
(-4800 – +4800 [cent])
01 00
42 ee 0C 2 00 – 01
00 – 7F
PEG Attack Level -128 – +127
(-4800 – +4800 [cent])
01 00
42 ee 0E 2 00 – 01
00 – 7F
PEG Decay 1 Level -128 – +127
(-4800 – +4800 [cent])
01 00
42 ee 10 2 00 – 01
00 – 7F
PEG Decay 2 Level -128 – +127
(-4800 – +4800 [cent])
01 00
42 ee 12 2 00 – 01
00 – 7F
PEG Release Level -128 – +127
(-4800 – +4800 [cent])
01 00
42 ee 14 1 00 – 7F PEG Depth -64 – +63 54
42 ee 15 1 00 – 04 PEG Time Velocity Segment ATK, ATK+DCY, DCY,
ATK+RLS, ALL
04
42 ee 16 1 00 – 7F PEG Time Velocity Sensitivity -64 – +63 40
42 ee 17 1 00 – 7F PEG Level Velocity Sensitivity -64 – +63 40
42 ee 18 1 00 – 04 PEG LEVEL SENS VELOCITY
CURVE
00 – 04 02
42 ee 19 1 00 – 7F Pitch Key Follow Sensitivity -200% – +200% 60
42 ee 1A 1 00 – 7F Pitch Key Follow Center Note C-2 – G8 3C
42 ee 1B 1 00 – 7F PEG Time Key Follow
Sensitivity
-64 – +63 40
42 ee 1C 1 00 – 7F PEG Time Key Follow Center
Note
C-2 – G8 3C
42 ee 1D 1 reserved (40)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
43 ee 00 1 00 – 15 Filter Type LPF24D, LPF24A,
LPF18, LPF18s, LPF12,
LPF6, HPF24D, HPF12,
BPF12D, BPF12s,
BPF6, BPFw, BEF12,
BEF6, DualLPF,
DualHPF, DualBPF,
DualBEF,
LPF12+HPF12,
LPF12+BPF6,
HPF12+BPF6, THRU
04
43 ee 01 2 00 – 01
00 – 7F
Filter Cutoff Frequency 0 – 255 01 0C
(02)
43 ee 03 1 00 – 7F Filter Cutoff Velocity Sensitivity -64 – +63 40
43 ee 04 1 reserved 02
43 ee 05 1 00 – 46 Filter Resonance/Width/Band 0 – 70 04
43 ee 06 1 00 – 7F Filter Resonance Velocity
Sensitivity
-64 – +63 40
43 ee 07 2 00 – 01
00 – 7F
HPF Cutoff Frequency 0 – 255 00 00
43 ee 09 1 40 reserved (40)
43 ee 0A 2 00 – 01
00 – 7F
DISTANCE 0 – 255 (available with
Dual filters)
00 00
43 ee 0C 2 00 – 01
00 – 7F
Filter Gain 0 – 255 01 6E
43 ee 0E 1 00 – 7F FEG Hold Time 0 – 127 00
43 ee 0F 1 00 – 7F FEG Attack Time 0 – 127 00
43 ee 10 1 00 – 7F FEG Decay 1 Time 0 – 127 40
43 ee 11 1 00 – 7F FEG Decay 2 Time 0 – 127 40
43 ee 12 1 00 – 7F FEG Release Time 0 – 127 50
43 ee 13 2 00 – 01
00 – 7F
FEG Hold Level -128 – +127
(-9600 – +9600 [cent])
01 00
43 ee 15 2 00 – 01
00 – 7F
FEG Attack Level -128 – +127
(-9600 – +9600 [cent])
01 7F
43 ee 17 2 00 – 01
00 – 7F
FEG Decay 1 Level -128 – +127
(-9600 – +9600 [cent])
01 7F
43 ee 19 2 00 – 01
00 – 7F
FEG Decay 2 Level -128 – +127
(-9600 – +9600 [cent])
01 7F
43 ee 1B 2 00 – 01
00 – 7F
FEG Release Level -128 – +127
(-9600 – +9600 [cent])
01 00
43 ee 1D 1 00 – 7F FEG Depth -64 – +63 68
43 ee 1E 1 00 – 04 FEG Time Velocity Segment ATK, ATK+DCY, DCY,
ATK+RLS, ALL
04
43 ee 1F 1 00 – 7F FEG Time Velocity Sensitivity -64 – +63 40
43 ee 20 1 00 – 7F FEG Level Velocity Sensitivity -64 – +63 40
43 ee 21 1 00 – 04 FEG LEVEL VELOCITY CURVE 00 – 04 02
43 ee 22 1 00 – 7F Filter Cutoff Key Follow
Sensitivity
-200% – +200% 4A
43 ee 23 1 00 – 7C Filter Cutoff Scaling Break
Point 1
C -2 – E8 24 BP1<BP2<
BP3<BP4
43 ee 24 1 01 – 7D Filter Cutoff Scaling Break
Point 2
C-2 – F8 30 BP1<BP2<
BP3<BP4
43 ee 25 1 02 – 7E Filter Cutoff Scaling Break
Point 3
D -2 – F8 3C BP1<BP2<
BP3<BP4
43 ee 26 1 03 – 7F Filter Cutoff Scaling Break
Point 4
D-2 – G8 48 BP1<BP2<
BP3<BP4
43 ee 27 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 1 -128 – +127 01 00
43 ee 29 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 2 -128 – +127 01 00
43 ee 2B 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 3 -128 – +127 01 00
43 ee 2D 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 4 -128 – +127 01 00
43 ee 2F 1 00 – 7F HPF Cutoff Key Follow
Sensitivity
-200% – +200% 40
43 ee 30 1 00 – 7F FEG Time Key Follow
Sensitivity
-64 – +63 40
43 ee 31 1 00 – 7F FEG Time Key Follow Center
Note
C-2 – G8 18
44 ee 00 1 00 – 05 EQ Type EQ L/H, P.EQ, Boost6,
Boost12, Boost18, thru
00
44 ee 01 1 00 – 1F EQ Resonance 0 – 31 00
44 ee 02 2 00 – 01
00 – 7F
EQ 1 Frequency EQ L/H: 46 – 182,
P.EQ: 83 – 251
00 36
44 ee 04 1 20 – 60 EQ 1 Gain -32 – +32 40
44 ee 05 2 00 – 01
00 – 7F
EQ 2 Frequency EQ L/H: 131 – 241 01 67
44 ee 07 1 20 – 60 EQ 2 Gain -32 – +32 40
MR_DL1.book Page 52 Monday, January 6, 2003 11:10 AM
53
TOTAL SIZE = 8 08 (HEX)
ee = Element Number (00 – 03: Element1 – 4)
<Table 6-1>
MIDI PARAMETER CHANGE TABLE
(DRUM VOICE COMMON) MODEL ID = 0x6F
TOTAL SIZE = 66 42 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 4 04 (HEX)
TOTAL SIZE = 36 24 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
44 ee 40 1 00 – 02 LFO Wave saw, tri, squ 01
44 ee 41 1 00 – 01 LFO Key On Sync off, on 01
44 ee 42 1 00 – 7F LFO KEY ON DELAY TIME 0 – 127 00
44 ee 43 1 00 – 3F LFO Speed 0 – 63 26
44 ee 44 1 00 – 7F LFO AMod Depth 0 – 127 00
44 ee 45 1 00 – 7F LFO PMod Depth 0 – 127 00
44 ee 46 1 00 – 7F LFO FMod Depth 0 – 127 00
44 ee 47 1 reserved --
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
46 70 00 1 20 – 7E Voice Name 1 32 – 126 (ASCII) Init Voice
46 70 01 1 20 – 7E Voice Name 2 32 – 126 (ASCII) ˝
46 70 02 1 20 – 7E Voice Name 3 32 – 126 (ASCII) ˝
46 70 03 1 20 – 7E Voice Name 4 32 – 126 (ASCII) ˝
46 70 04 1 20 – 7E Voice Name 5 32 – 126 (ASCII) ˝
46 70 05 1 20 – 7E Voice Name 6 32 – 126 (ASCII) ˝
46 70 06 1 20 – 7E Voice Name 7 32 – 126 (ASCII) ˝
46 70 07 1 20 – 7E Voice Name 8 32 – 126 (ASCII) ˝
46 70 08 1 20 – 7E Voice Name 9 32 – 126 (ASCII) ˝
46 70 09 1 20 – 7E Voice Name 10 32 – 126 (ASCII) ˝
46 70 0A 1 reserved
46 70 0B 1 reserved
46 70 0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) 0D (Dr) Ap, Kb,
Or, Gt, Ba,
St, Br, Rp,
Ld, Pd,
Sc, Cp, Dr,
Se, Me,
Co
46 70 0D 1 00 – 03 reserved 00
46 70 0E 1 reserved
46 70 0F 1 reserved
46 70 10 1 reserved
46 70 11 1 reserved
46 70 12 1 reserved
46 70 13 1 00 – 01 ARP Type Bank pre1, pre2 01
46 70 14 1 00 – 7F ARP Type Strum A – EuroTekE 00
46 70 15 1 00 – 01 ARP Switch off, on 00
46 70 16 1 00 – 02 ARP Hold sync-off, off, on 01
46 70 17 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%, 100%,
133%, 150%, 200%
03
46 70 18 1 00 – 7F ARP Note Limit Low C-2 – G8 00
46 70 19 1 00 – 7F ARP Note Limit High C-2 – G8 7F
46 70 1A 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
46 70 1B 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
46 70 1C 1 00 – 02 ARP Key Mode sort, thru, direct 00
46 70 1D 1 00 – 01 ARP Vel Mode original, thru 00
46 70 1E 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200% 64
46 70 20 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate TIme Rate LSB
0 – 200% 64
46 70 22 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300 8A
46 70 24 1 00 – 03 reserved 02
46 70 25 1 01 – 7F Pan L63 – C – R63 40
46 70 26 1 40 reserved 40
46 70 27 1 00 – 7F Decay Time -64 – +63 40
46 70 28 1 reserved
46 70 29 1 reserved
46 70 2A 1 reserved
46 70 2B 1 reserved
46 70 2C 1 reserved
46 70 2D 1 reserved
46 70 2E 1 00 – 7F Assign A -64 – +63 40
46 70 2F 1 00 – 7F Assign B -64 – +63 40
46 70 30 1 reserved
46 70 31 1 00 – 7F EQ Low Gain -64 – +63 40
46 70 32 1 00 – 7F EQ Low Mid Gain -64 – +63 40
46 70 33 1 00 – 7F EQ High Mid Gain -64 – +63 40
46 70 34 1 00 – 7F EQ High Gain -64 – +63 40
46 70 35 1 00 – 7F Assign 1 -64 – +63 40
46 70 36 1 00 – 7F Assign 2 -64 – +63 40
46 70 37 1 00 – 7F Cutoff Frequency -64 – +63 40
46 70 38 1 00 – 7F Resonance -64 – +63 40
46 70 39 1 00 – 7F Attack Time -64 – +63 40
46 70 3A 1 reserved
46 70 3B 1 reserved
46 70 3C 1 reserved
46 70 3D 1 reserved
46 70 3E 1 reserved
46 70 3F 1 reserved
46 70 40 1 reserved
46 70 41 1 reserved
46 00 00 1 00 – 7F Volume 0 – 127 7F
46 00 01 1 reserved
46 00 02 1 10 – 58 Pitch Bend Range Upper -48 – +24 [semitones] 42
46 00 03 1 10 – 58 Pitch Bend Range Lower -48 – +24 [semitones] 3E
46 00 04 1 00 – 7F Reverb Send -∞dB – 0dB 7F
46 00 05 1 00 – 7F Chorus Send -∞dB – 0dB 7F
46 00 06 1 reserved
46 00 07 1 reserved
46 00 40 1 00 – 02 Insertion Connect Type Para, 1→2, 2→100
46 00 41 1 00 – 7F Ins-EF Reverb Send Level 0 – 127 40
46 00 42 1 00 – 7F Ins-EF Chorus Send Level 0 – 127 00
46 00 43 1 reserved
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
46 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to Effect
Parameter List
0100
46 01 02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
˝ init value for
hall1
46 01 04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
˝ init value for
hall1
46 01 06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
˝ init value for
hall1
46 01 08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
˝ init value for
hall1
46 01 0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
˝ init value for
hall1
46 01 0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
˝ init value for
hall1
46 01 0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
˝ init value for
hall1
46 01 10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
˝ init value for
hall1
46 01 12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
˝ init value for
hall1
46 01 14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
˝ init value for
hall1
46 01 16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
˝ init value for
hall1
46 01 18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
˝ init value for
hall1
46 01 1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
˝ init value for
hall1
46 01 1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
˝ init value for
hall1
46 01 1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
˝ init value for
hall1
46 01 20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
˝ init value for
hall1
46 01 22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
40
46 01 23 1 01 – 7F Reverb Pan L63 – C – R63 40
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
MR_DL1.book Page 53 Monday, January 6, 2003 11:10 AM
54
TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 4 04 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
46 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to Effect
Parameter List
0500
46 02 02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
˝ init value for
chorus1
46 02 04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
˝ init value for
chorus1
46 02 06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
˝ init value for
chorus1
46 02 08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
˝ init value for
chorus1
46 02 0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
˝ init value for
chorus1
46 02 0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
˝ init value for
chorus1
46 02 0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
˝ init value for
chorus1
46 02 10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
˝ init value for
chorus1
46 02 12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
˝ init value for
chorus1
46 02 14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
˝ init value for
chorus1
46 02 16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
˝ init value for
chorus1
46 02 18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
˝ init value for
chorus1
46 02 1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
˝ init value for
chorus1
46 02 1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
˝ init value for
chorus1
46 02 1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
˝ init value for
chorus1
46 02 20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
˝ init value for
chorus1
46 02 22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
60
46 02 23 1 00 – 7F Chorus Pan L63 – C – R63 40
46 02 24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127) 00
46 03 00 2 00 – 7F
00 – 7F
Insertion 1 Type MSB
Insertion 1 Type LSB
Refer to Effect
Parameter List
0000
46 03 02 2 00 – 7F
00 – 7F
Insertion 1 Parameter 1 MSB
Insertion 1 Parameter 1 LSB
˝ 0000
46 03 04 2 00 – 7F
00 – 7F
Insertion 1 Parameter 2 MSB
Insertion 1 Parameter 2 LSB
˝ 0000
46 03 06 2 00 – 7F
00 – 7F
Insertion 1 Parameter 3 MSB
Insertion 1 Parameter 3 LSB
˝ 0000
46 03 08 2 00 – 7F
00 – 7F
Insertion 1 Parameter 4 MSB
Insertion 1 Parameter 4 LSB
˝ 0000
46 03 0A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 5 MSB
Insertion 1 Parameter 5 LSB
˝ 0000
46 03 0C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 6 MSB
Insertion 1 Parameter 6 LSB
˝ 0000
46 03 0E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 7 MSB
Insertion 1 Parameter 7 LSB
˝ 0000
46 03 10 2 00 – 7F
00 – 7F
Insertion 1 Parameter 8 MSB
Insertion 1 Parameter 8 LSB
˝ 0000
46 03 12 2 00 – 7F
00 – 7F
Insertion 1 Parameter 9 MSB
Insertion 1 Parameter 9 LSB
˝ 0000
46 03 14 2 00 – 7F
00 – 7F
Insertion 1 Parameter 10 MSB
Insertion 1 Parameter 10 LSB
˝ 0000
46 03 16 2 00 – 7F
00 – 7F
Insertion 1 Parameter 11 MSB
Insertion 1 Parameter 11 LSB
˝ 0000
46 03 18 2 00 – 7F
00 – 7F
Insertion 1 Parameter 12 MSB
Insertion 1 Parameter 12 LSB
˝ 0000
46 03 1A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 13 MSB
Insertion 1 Parameter 13 LSB
˝ 0000
46 03 1C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 14 MSB
Insertion 1 Parameter 14 LSB
˝ 0000
46 03 1E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 15 MSB
Insertion 1 Parameter 15 LSB
˝ 0000
46 03 20 2 00 – 7F
00 – 7F
Insertion 1 Parameter 16 MSB
Insertion 1 Parameter 16 LSB
˝ 0000
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
46 04 00 2 00 – 7F
00 – 7F
Insertion 2 Type MSB
Insertion 2 Type LSB
Refer to Effect
Parameter List
0000
46 04 02 2 00 – 7F
00 – 7F
Insertion 2 Parameter 1 MSB
Insertion 2 Parameter 1 LSB
˝ 0000
46 04 04 2 00 – 7F
00 – 7F
Insertion 2 Parameter 2 MSB
Insertion 2 Parameter 2 LSB
˝ 0000
46 04 06 2 00 – 7F
00 – 7F
Insertion 2 Parameter 3 MSB
Insertion 2 Parameter 3 LSB
˝ 0000
46 04 08 2 00 – 7F
00 – 7F
Insertion 2 Parameter 4 MSB
Insertion 2 Parameter 4 LSB
˝ 0000
46 04 0A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 5 MSB
Insertion 2 Parameter 5 LSB
˝ 0000
46 04 0C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 6 MSB
Insertion 2 Parameter 6 LSB
˝ 0000
46 04 0E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 7 MSB
Insertion 2 Parameter 7 LSB
˝ 0000
46 04 10 2 00 – 7F
00 – 7F
Insertion 2 Parameter 8 MSB
Insertion 2 Parameter 8 LSB
˝ 0000
46 04 12 2 00 – 7F
00 – 7F
Insertion 2 Parameter 9 MSB
Insertion 2 Parameter 9 LSB
˝ 0000
46 04 14 2 00 – 7F
00 – 7F
Insertion 2 Parameter 10 MSB
Insertion 2 Parameter 10 LSB
˝ 0000
46 04 16 2 00 – 7F
00 – 7F
Insertion 2 Parameter 11 MSB
Insertion 2 Parameter 11 LSB
˝ 0000
46 04 18 2 00 – 7F
00 – 7F
Insertion 2 Parameter 12 MSB
Insertion 2 Parameter 12 LSB
˝ 0000
46 04 1A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 13 MSB
Insertion 2 Parameter 13 LSB
˝ 0000
46 04 1C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 14 MSB
Insertion 2 Parameter 14 LSB
˝ 0000
46 04 1E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 15 MSB
Insertion 2 Parameter 15 LSB
˝ 0000
46 04 20 2 00 – 7F
00 – 7F
Insertion 2 Parameter 16 MSB
Insertion 2 Parameter 16 LSB
˝ 0000
46 05 00 1 00 – 09
Controller Set 1 Source
PB, MW, ---, AT,FC2,
FS,FC1, BC, AS1, AS2
01
46 05 01 2 00
00 – 23
Controller Set 1 Destination MSB
Controller Set 1 Destination LSB
0 – 35 00
46 05 03 1 00 – 7F
Controller Set 1 Depth
-64 – +63 40
46 05 04 1 reserved
46 05 05 1 00 – 09
Controller Set 2 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
01
46 05 06 2 00
00 – 23
Controller Set 2 Destination MSB
Controller Set 2 Destination LSB
0 – 35 00
46 05 08 1 00 – 7F
Controller Set 2 Depth
-64 – +63 40
46 05 09 1 reserved
46 05 0A 1 00 – 09
Controller Set 3 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
01
46 05 0B 2 00
00 – 23
Controller Set 3 Destination MSB
Controller Set 3 Destination LSB
0 – 35 00
46 05 0D 1 00 – 7F
Controller Set 3 Depth
-64 – +63 40
46 05 0E 1 reserved
46 05 0F 1 00 – 09
Controller Set 4 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
08
46 05 10 2 00
00 – 23
Controller Set 4 Destination MSB
Controller Set 4 Destination LSB
0 – 35 00
46 05 12 1 00 – 7F
Controller Set 4 Depth
-64 – +63 40
46 05 13 1 reserved
46 05 14 1 00 – 09
Controller Set 5 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
09
46 05 15 2 00
Controller Set 5 Destination MSB
0 – 35 00
00 – 23
Controller Set 5 Destination LSB
46 05 17 1 00 – 7F
Controller Set 5 Depth
-64 – +63 40
46 05 18 1 reserved
46 05 19 1 00 – 09
Controller Set 6 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
03
46 05 1A 2 00
00 – 23
Controller Set 6 Destination MSB
Controller Set 6 Destination LSB
0 – 35 00
46 05 1C 1 00 – 7F
Controller Set 6 Depth
-64 – +63 40
46 05 1D 1 reserved
46 06 00 2 00 – 02 Audition Phrase Number MSB 000 – 285 00 00
46 06 00 – 7F Audition Phrase Number LSB
46 06 02 1 28 – 58 Audition Note Shift -24 – 24 40
46 06 03 1 reserved
MR_DL1.book Page 54 Monday, January 6, 2003 11:10 AM
55
<Table 6-2>
MIDI PARAMETER CHANGE TABLE (DRUM VOICE KEY)
TOTAL SIZE = 19 13 (HEX)
TOTAL SIZE = 12 0C (HEX)
TOTAL SIZE = 3 03 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 8 08 (HEX)
ee = Element Number (00 – 48: C0 – C6)
*1: When the Wave/Voice type is set to “voice”, only these parameters are available.
<Table 7>
MIDI PARAMETER CHANGE TABLE (PLUG-IN VOICE)
MODEL ID = 0x6F
TOTAL SIZE = 66 42 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
47 ee 00 1 00 – 01 Element Assign off, on 01
47 ee 01 1 00 – 01 Wave Type 0: PresetWave 1: Voice 00
47 ee 02 1 reserved
47 ee 03 1 00 – 01 Receive Note Off off, on 00
47 ee 04 1 00 – 01 Assign Mode single, multi 01 *1
47 ee 05 1 00 – 7F Alternate Group 0: off, 1 – 127 00
47 ee 06 2 00 – 7F Wave Number MSB 1st bit6-0 → bit13-7
(User: 256)
05
00 – 7F Wave Number LSB 2nd bit6-0 → bit6-0 7C
47 ee 08 3 00 – 7F Voice Bank Number MSB 3F *1
00 – 7F Voice Bank Number LSB PRE1 – PRE5, GM,
USR1, USR2
00 *1
00 – 7F Voice Number 0 – 127 00 *1
47 ee 0B 1 01 – 7F Pan L63 – C – R63 40 *1
47 ee 0C 1 00 – 7F Random Pan Depth 0 – 127 00
47 ee 0D 1 00 – 7F Alternate Pan Depth L64 – 0 – R63 40
47 ee 0E 1 00 – 7F Reverb Send Level 0 – 127 00 *1
47 ee 0F 1 00 – 7F Chorus Send Level 0 – 127 00 *1
47 ee 10 1 reserved
47 ee 11 1 00 – 02 Insertion Effect Switch thru, ins1, ins2 00 *1
47 ee 12 1 00 – 43 Output Select 0: L&R
8: asn1&2, 9: asn3&4,
64 – 67: asn1, asn2,
asn3, asn4
00 *1
47 ee 20 1 00 – 7F Element Level 0 – 127 7F *1
47 ee 21 1 00 – 7F Level Velocity Sensitivity -64 – +63 40
47 ee 22 1 reserved
47 ee 23 1 00 – 7F AEG Attack Time 0 – 127 00
47 ee 24 1 00 – 7F AEG Decay 1 Time 0 – 127 60
47 ee 25 1 00 – 7F AEG Decay 2 Time 0 – 126, hold 50
47 ee 26 1 reserved
47 ee 27 1 reserved
47 ee 28 1 reserved
47 ee 29 1 00 – 7F AEG Decay 1 Level 0 – 127 7F
47 ee 2A 1 reserved
47 ee 2B 1 reserved
48 ee 00 1 10 – 70 Coarse Tune -48 – +48 40 *1
48 ee 01 1 00 – 7F Fine Tune -64 – +63 40 *1
48 ee 02 1 00 – 7F Pitch Velocity Sensitivity -64 – +63 40
49 ee 00 1 reserved
49 ee 01 2 00 – 01
00 – 7F
LPF Cutoff Frequency MSB
LPF Cutoff Frequency LSB
0 – 255 01 7F
49 ee 03 1 00 – 7F LPF Cutoff Velocity Sensitivity -64 – +63 40
49 ee 04 1 00 – 46 LPF Resonance 0 – 70 04
49 ee 05 1 reserved
49 ee 06 2 00 – 01
00 – 7F
HPF Cutoff Frequency MSB
HPF Cutoff Frequency LSB
0 – 255 00 00
4A ee 00 1 00 – 05 EQ Type EQ L/H, P.EQ, Boost6,
Boost12, Boost18, thru
00
4A ee 01 1 00 – 1F EQ Resonance 0 – 31 00
4A ee 02 2 00 – 01
00 – 7F
EQ 1 Frequency MSB
EQ 1 Frequency LSB
EQ L/H: 46 – 182,
P.EQ: 83 – 251
00 36
4A ee 04 1 20 – 60 EQ 1 GAIN -32 – +32 40
4A ee 05 2 00 – 01
00 – 7F
EQ 2 Frequency MSB
EQ 2 Frequency LSB
EQ L/H: 131 – 241 01 67
4A ee 07 1 20 – 60 EQ 2 GAIN -32 – +32 40
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
4C 70 00 1 20 – 7E Voice Name 1 32 – 126 (ASCII) -
4C 70 01 1 20 – 7E Voice Name 2 32 – 126 (ASCII) -
4C 70 02 1 20 – 7E Voice Name 3 32 – 126 (ASCII) -
4C 70 03 1 20 – 7E Voice Name 4 32 – 126 (ASCII) -
4C 70 04 1 20 – 7E Voice Name 5 32 – 126 (ASCII) -
4C 70 05 1 20 – 7E Voice Name 6 32 – 126 (ASCII) -
4C 70 06 1 20 – 7E Voice Name 7 32 – 126 (ASCII) -
4C 70 07 1 20 – 7E Voice Name 8 32 – 126 (ASCII) -
4C 70 08 1 20 – 7E Voice Name 9 32 – 126 (ASCII) -
4C 70 09 1 20 – 7E Voice Name 10 32 – 126 (ASCII) -
4C 70 0A 1 reserved
4C 70 0B 1 reserved
4C 70 0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) 00 (--) Ap, Kb,
Or, Gt, Ba,
St, Br, Rp,
Ld, Pd,
Sc, Cp, Dr,
Se, Me,
Co
4C 70 0D 1 00 – 03 reserved 00
4C 70 0E 1 reserved
4C 70 0F 1 reserved
4C 70 10 1 reserved
4C 70 11 1 reserved
4C 70 12 1 reserved
4C 70 13 1 00 – 01 ARP Type Bank pre1, pre2 00
4C 70 14 1 00 – 7F ARP Type UpOct1 – GateCutC 1D
4C 70 15 1 00 – 01 ARP Switch off, on 00
4C 70 16 1 00 – 02 ARP Hold sync-off, off, on 01
4C 70 17 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%, 100%,
133%, 150%, 200%
03
4C 70 18 1 00 – 7F ARP Note Limit Low C-2 – G8 00
4C 70 19 1 00 – 7F ARP Note Limit High C-2 – G8 7F
4C 70 1A 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
4C 70 1B 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
4C 70 1C 1 00 – 02 ARP Key Mode sort, thru, direct 00
4C 70 1D 1 00 – 01 ARP Vel Mode original, thru 00
4C 70 1E 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200% 64
4C 70 20 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate TIme Rate LSB
0 – 200% 64
4C 70 22 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300 8A
4C 70 24 1 00 – 04 reserved 02
4C 70 25 1 01 – 7F Pan L63 – C – R63 40
4C 70 26 1 40 reserved -64 – +63 40
4C 70 27 1 00 – 7F Decay Time -64 – +63 40
4C 70 28 1 reserved
4C 70 29 1 reserved
4C 70 2A 1 reserved
4C 70 2B 1 reserved
4C 70 2C 1 reserved
4C 70 2D 1 reserved
4C 70 2E 1 00 – 7F Assign A -64 – +63
4C 70 2F 1 00 – 7F Assign B -64 – +63
4C 70 30 1 reserved
4C 70 31 1 00 – 7F EQ Low Gain -64 – +63 40
4C 70 32 1 00 – 7F EQ Low Mid Gain -64 – +63 40
4C 70 33 1 00 – 7F EQ High Mid Gain -64 – +63 40
4C 70 34 1 00 – 7F EQ High Gain -64 – +63 40
4C 70 35 1 00 – 7F Assign 1 -64 – +63 40
4C 70 36 1 00 – 7F Assign 2 -64 – +63 40
4C 70 37 1 00 – 7F Cutoff Frequency -64 – +63 40
4C 70 38 1 00 – 7F Resonance -64 – +63 40
4C 70 39 1 00 – 7F Attack Time -64 – +63 40
4C 70 3A 1 00 – 7F Release Time -64 – +63 40
4C 70 3B 1 reserved
4C 70 3C 1 reserved
4C 70 3D 1 reserved
4C 70 3E 1 reserved
4C 70 3F 1 reserved
4C 70 40 1 reserved
4C 70 41 1 reserved
MR_DL1.book Page 55 Monday, January 6, 2003 11:10 AM
56
TOTAL SIZE = 13 0D (HEX)
TOTAL SIZE = 36 24 (HEX)
TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 34 22 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
4C 00 00 1 00 – 7F Volume 0 – 127 64
4C 00 01 1 reserved
4C 00 02 1 00 – 01 Same Note Number Key On
Assign
single, multi 01
4C 00 03 1 00 – 01 Mono/Poly Mode mono, poly 01
4C 00 04 1 reserved
4C 00 05 1 28 – 58 Pitch Bend Range -24 – +24 [semitones] 42
4C 00 06 1 reserved
4C 00 07 1 reserved
4C 00 08 1 00 – 01 Portamento Switch off, on 00
4C 00 09 1 00 – 7F Portamento Time 0 – 127 40
4C 00 0A 1 01 – 02 Insertion Connect Type 1→2, 2→101
4C 00 0B 1 00 – 7F Reverb Send -∞dB – 0dB 00
4C 00 0C 1 00 – 7F Chorus Send -∞dB – 0dB 00
Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
4C 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to Effect
Parameter List
0100
4C 01 02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
˝ init value for
hall1
4C 01 04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
˝ init value for
hall1
4C 01 06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
˝ init value for
hall1
4C 01 08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
˝ init value for
hall1
4C 01 0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
˝ init value for
hall1
4C 01 0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
˝ init value for
hall1
4C 01 0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
˝ init value for
hall1
4C 01 10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
˝ init value for
hall1
4C 01 12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
˝ init value for
hall1
4C 01 14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
˝ init value for
hall1
4C 01 16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
˝ init value for
hall1
4C 01 18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
˝ init value for
hall1
4C 01 1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
˝ init value for
hall1
4C 01 1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
˝ init value for
hall1
4C 01 1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
˝ init value for
hall1
4C 01 20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
˝ init value for
hall1
4C 01 22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
40
4C 01 23 1 01 – 7F Reverb Pan L63 – C – R63 40
4C 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to Effect
Parameter List
0500
4C 02 02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
˝ init value for
chorus1
4C 02 04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
˝ init value for
chorus1
4C 02 06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
˝ init value for
chorus1
4C 02 08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
˝ init value for
chorus1
4C 02 0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
˝ init value for
chorus1
4C 02 0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
˝ init value for
chorus1
4C 02 0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
˝ init value for
chorus1
4C 02 10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
˝ init value for
chorus1
4C 02 12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
˝ init value for
chorus1
4C 02 14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
˝ init value for
chorus1
4C 02 16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
˝ init value for
chorus1
4C 02 18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
˝ init value for
chorus1
4C 02 1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
˝ init value for
chorus1
Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
4C 02 1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
˝ init value for
chorus1
4C 02 1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
˝ init value for
chorus1
4C 02 20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
˝ init value for
chorus1
4C 02 22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
60
4C 02 23 1 01 – 7F Chorus Pan L63 – C – R63 40
4C 02 24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127) 00
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
4C 03 00 2 00 – 7F
00 – 7F
Insertion 1 Type MSB
Insertion 1 Type LSB
Refer to Effect
Parameter List
0000
4C 03 02 2 00 – 7F
00 – 7F
Insertion 1 Parameter 1 MSB
Insertion 1 Parameter 1 LSB
˝ 0000
4C 03 04 2 00 – 7F
00 – 7F
Insertion 1 Parameter 2 MSB
Insertion 1 Parameter 2 LSB
˝ 0000
4C 03 06 2 00 – 7F
00 – 7F
Insertion 1 Parameter 3 MSB
Insertion 1 Parameter 3 LSB
˝ 0000
4C 03 08 2 00 – 7F
00 – 7F
Insertion 1 Parameter 4 MSB
Insertion 1 Parameter 4 LSB
˝ 0000
4C 03 0A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 5 MSB
Insertion 1 Parameter 5 LSB
˝ 0000
4C 03 0C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 6 MSB
Insertion 1 Parameter 6 LSB
˝ 0000
4C 03 0E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 7 MSB
Insertion 1 Parameter 7 LSB
˝ 0000
4C 03 10 2 00 – 7F
00 – 7F
Insertion 1 Parameter 8 MSB
Insertion 1 Parameter 8 LSB
˝ 0000
4C 03 12 2 00 – 7F
00 – 7F
Insertion 1 Parameter 9 MSB
Insertion 1 Parameter 9 LSB
˝ 0000
4C 03 14 2 00 – 7F
00 – 7F
Insertion 1 Parameter 10 MSB
Insertion 1 Parameter 10 LSB
˝ 0000
4C 03 16 2 00 – 7F
00 – 7F
Insertion 1 Parameter 11 MSB
Insertion 1 Parameter 11 LSB
˝ 0000
4C 03 18 2 00 – 7F
00 – 7F
Insertion 1 Parameter 12 MSB
Insertion 1 Parameter 12 LSB
˝ 0000
4C 03 1A 2 00 – 7F
00 – 7F
Insertion 1 Parameter 13 MSB
Insertion 1 Parameter 13 LSB
˝ 0000
4C 03 1C 2 00 – 7F
00 – 7F
Insertion 1 Parameter 14 MSB
Insertion 1 Parameter 14 LSB
˝ 0000
4C 03 1E 2 00 – 7F
00 – 7F
Insertion 1 Parameter 15 MSB
Insertion 1 Parameter 15 LSB
˝ 0000
4C 03 20 2 00 – 7F
00 – 7F
Insertion 1 Parameter 16 MSB
Insertion 1 Parameter 16 LSB
˝ 0000
4C 04 00 2 00 – 7F
00 – 7F
Insertion 2 Type MSB
Insertion 2 Type LSB
Refer to Effect
Parameter List
0000
4C 04 02 2 00 – 7F
00 – 7F
Insertion 2 Parameter 1 MSB
Insertion 2 Parameter 1 LSB
˝ 0000
4C 04 04 2 00 – 7F
00 – 7F
Insertion 2 Parameter 2 MSB
Insertion 2 Parameter 2 LSB
˝ 0000
4C 04 06 2 00 – 7F
00 – 7F
Insertion 2 Parameter 3 MSB
Insertion 2 Parameter 3 LSB
˝ 0000
4C 04 08 2 00 – 7F
00 – 7F
Insertion 2 Parameter 4 MSB
Insertion 2 Parameter 4 LSB
˝ 0000
4C 04 0A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 5 MSB
Insertion 2 Parameter 5 LSB
˝ 0000
4C 04 0C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 6 MSB
Insertion 2 Parameter 6 LSB
˝ 0000
4C 04 0E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 7 MSB
Insertion 2 Parameter 7 LSB
˝ 0000
4C 04 10 2 00 – 7F
00 – 7F
Insertion 2 Parameter 8 MSB
Insertion 2 Parameter 8 LSB
˝ 0000
4C 04 12 2 00 – 7F
00 – 7F
Insertion 2 Parameter 9 MSB
Insertion 2 Parameter 9 LSB
˝ 0000
4C 04 14 2 00 – 7F
00 – 7F
Insertion 2 Parameter 10 MSB
Insertion 2 Parameter 10 LSB
˝ 0000
4C 04 16 2 00 – 7F
00 – 7F
Insertion 2 Parameter 11 MSB
Insertion 2 Parameter 11 LSB
˝ 0000
4C 04 18 2 00 – 7F
00 – 7F
Insertion 2 Parameter 12 MSB
Insertion 2 Parameter 12 LSB
˝ 0000
4C 04 1A 2 00 – 7F
00 – 7F
Insertion 2 Parameter 13 MSB
Insertion 2 Parameter 13 LSB
˝ 0000
4C 04 1C 2 00 – 7F
00 – 7F
Insertion 2 Parameter 14 MSB
Insertion 2 Parameter 14 LSB
˝ 0000
4C 04 1E 2 00 – 7F
00 – 7F
Insertion 2 Parameter 15 MSB
Insertion 2 Parameter 15 LSB
˝ 0000
4C 04 20 2 00 – 7F
00 – 7F
Insertion 2 Parameter 16 MSB
Insertion 2 Parameter 16 LSB
˝ 0000
MR_DL1.book Page 56 Monday, January 6, 2003 11:10 AM
57
TOTAL SIZE = 10 0A (HEX)
TOTAL SIZE = 4 04 (HEX)
TOTAL SIZE = 35 23 (HEX)
TOTAL SIZE = 68 44 (HEX)
<Table 8-1>
MIDI PARAMETER CHANGE TABLE (MULTI COMMON)
MODEL ID = 0x6F
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
4C 05 00 1 00 – 09
Controller Set 1 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
08
4C 05 01 2 00
00 – 23
Controller Set 1 Destination MSB
Controller Set 1 Destination LSB
0 – 35 00
00
4C 05 03 1 00 – 7F
Controller Set 1 Depth
-64 – +63 40
4C 05 04 1 reserved
4C 05 05 1 00 – 09
Controller Set 2 Source
PB, MW, ---, AT, FC2,
FS, FC1, BC, AS1, AS2
09
4C 05 06 2 00
00 – 23
Controller Set 2 Destination
Controller Set 2 Destination MSB
0 – 35 00
00
4C 05 08 1 00 – 7F
Controller Set 2 Depth
-64 – +63 40
4C 05 09 1 reserved
4C 06 00 2 00 – 02 Audition Phrase Number MSB 000 – 285 00 00
4C 06 00 – 7F Audition Phrase Number LSB
4C 06 02 1 28 – 58 Audition Note Shift -24 – 24 40
4C 06 03 1 reserved
4C 10 00 1 00 – 7F Voice Bank MSB 0 – 127 Depends
on plug-
in board
4C 10 01 1 00 – 7F Voice Bank LSB 0 – 127 Depends
on plug-
in board
4C 10 02 1 00 – 7F Voice Number 0 – 127 Depends
on plug-
in board
4C 10 03 1 28 – 58 Note Shift -24 – 0 – +24
[semitones]
40
4C 10 04 1 00 – 7F Velocity Sense Depth 0 – 127 40
4C 10 05 1 00 – 7F Velocity Sense Offset 0 – 127 40
4C 10 06 1 00 – 7F (Vibrato Rate) LFO Speed -64 – +63 40
4C 10 07 1 00 – 7F (Vibrato Depth) LFO Pitch
Depth
-64 – +63 40
4C 10 08 1 00 – 7F (Vibrato Delay) LFO Delay -64 – +63 40
4C 10 09 1 00 – 7F MW Filter Control -64 – +63 40
4C 10 0A 1 reserved
4C 10 0B 1 00 – 7F MW LFO Pitch Modulation
Depth
0 – 127 0A
4C 10 0C 1 00 – 7F MW LFO Filter Modulation
Depth
0 – 127 00
4C 10 0D 1 00 – 7F MW LFO Amplitude Modulation
Depth
0 – 127 00
4C 10 0E 1 28 – 58 CAT Pitch Control -24 – +24 [semitones] 40
4C 10 0F 1 00 – 7F CAT Filter Control -64 – +63 40
4C 10 10 1 reserved
4C 10 11 1 00 – 7F CAT LFO Pitch Modulation
Depth
0 – 127 00
4C 10 12 1 00 – 7F CAT LFO Filter Modulation
Depth
0 – 127 00
4C 10 13 1 00 – 7F CAT LFO Amplitude
Modulation Depth
0 – 127 00
4C 10 14 1 00 – 5F AC1 Controller Number 0 – 95 10
4C 10 15 1 00 – 7F AC1 Filter Control -64 – +63 40
4C 10 16 1 reserved
4C 10 17 1 00 – 7F AC1 LFO Pitch Modulation
Depth
0 – 127 00
4C 10 18 1 00 – 7F AC1 LFO Filter Modulation
Depth
0 – 127 00
4C 10 19 1 00 – 7F AC1 LFO Amplitude
Modulation Depth
0 – 127 00
4C 10 1A 1 00 – 7F Pitch EG Initial Level -64 – +63 40
4C 10 1B 1 00 – 7F Pitch EG Attack Time -64 – +63 40
4C 10 1C 1 00 – 7F Pitch EG Release Level -64 – +63 40
4C 10 1D 1 00 – 7F Pitch EG Release Time -64 – +63 40
4C 10 1E 1 00 – 7F EQ Low Gain -64 – +63
(-12 – +12 [dB])
40
4C 10 1F 1 00 – 7F EQ High Gain -64 – +63
(-12 – +12 [dB])
40
4C 10 20 1 04 – 28 EQ Low Frequency 32 – 2.0k [Hz] 0C
4C 10 21 1 1C – 3A EQ High Frequency 500 – 16.0k [Hz] 36
4C 10 22 1 00 – 7F HPF Cutoff Frequency -64 – 0 – +63 40
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
4C 20 00 64 00 – 7F Plug-in Board Native
Parameter
Depends on Plug-in
Board
00
4C 20 40 3 00 – 7F Plug-in Board Type MSB Depends
on plug-
in board
00 – 7F Plug-in Board Type LSB Depends
on plug-
in board
00 – 7F Plug-in Board Version Number Depends
on plug-
in board
43 1 00 – 7F reserved 00
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
36 00 00 1 20 – 7E Multi Name 1 32 – 126 (ASCII) Init Multi
36 00 01 1 20 – 7E Multi Name 2 32 – 126 (ASCII) ˝
36 00 02 1 20 – 7E Multi Name 3 32 – 126 (ASCII) ˝
36 00 03 1 20 – 7E Multi Name 4 32 – 126 (ASCII) ˝
36 00 04 1 20 – 7E Multi Name 5 32 – 126 (ASCII) ˝
36 00 05 1 20 – 7E Multi Name 6 32 – 126 (ASCII) ˝
36 00 06 1 20 – 7E Multi Name 7 32 – 126 (ASCII) ˝
36 00 07 1 20 – 7E Multi Name 8 32 – 126 (ASCII) ˝
36 00 08 1 20 – 7E Multi Name 9 32 – 126 (ASCII) ˝
36 00 09 1 20 – 7E Multi Name 10 32 – 126 (ASCII) ˝
36 00 0A 1 reserved
36 00 0B 1 reserved
36 00 0C 1 00 – 16 Multi Category 0 – 16 (-- – Co) 00 (--)
36 00 0D 1 00 – 03 reserved 00
36 00 0E 1 reserved
36 00 0F 1 reserved
36 00 10 1 reserved
36 00 11 1 00 – 01 ARP MIDI Out Switch off, on 00
36 00 12 1 00 – 10 ARP MIDI Out Channel 1..16, kbd-ch 00
36 00 13 1 00 – 02 ARP Type Bank pre1, pre2, user 00
36 00 14 1 00 – 7F ARP Type UpOct1 – GateCut3 1D
36 00 15 1 00 – 01 ARP Switch off, on 00
36 00 16 1 00 – 02 ARP Hold sync-off, off, on 01
36 00 17 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%, 100%,
133%, 150%, 200%
03
36 00 18 1 00 – 7F ARP Note Limit Low C-2 – G8 00
36 00 19 1 00 – 7F ARP Note Limit High C-2 – G8 7F
36 00 1A 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
36 00 1B 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
36 00 1C 1 00 – 02 ARP Key Mode sort, thru, direct 00
36 00 1D 1 00 – 01 ARP Vel Mode original, thru 00
36 00 1E 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200% 64
36 00 20 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate Time Rate LSB
0 – 200% 64
36 00 22 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300 8A
36 00 24 1 00 – 04 reserved 04
36 00 25 1 40 reserved 40
36 00 26 1 40 reserved 40
36 00 27 1 40 reserved 40
36 00 28 1 40 reserved 40
36 00 29 1 40 reserved 40
36 00 2A 1 40 reserved 40
36 00 2B 1 40 reserved 40
36 00 2C 1 40 reserved 40
36 00 2D 1 40 reserved 40
36 00 2E 1 00 – 7F Assign A -64 – +63 40
36 00 2F 1 00 – 7F Assign B -64 – +63 40
36 00 30 1 reserved
36 00 31 1 00 – 7F EQ Low Gain -64 – +63 40
36 00 32 1 00 – 7F EQ Low Mid Gain -64 – +63 40
36 00 33 1 00 – 7F EQ High Mid Gain -64 – +63 40
36 00 34 1 00 – 7F EQ High Gain -64 – +63 40
36 00 35 1 00 – 7F Assign 1 -64 – +63 40
36 00 36 1 00 – 7F Assign 2 -64 – +63 40
36 00 37 1 reserved
36 00 38 1 reserved
MR_DL1.book Page 57 Monday, January 6, 2003 11:10 AM
58
TOTAL SIZE = 88 58 (HEX)
TOTAL SIZE = 36 24 (HEX)
TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 20 14 (HEX)
36 00 39 1 reserved
36 00 3A 1 reserved
36 00 3B 1 reserved
36 00 3C 1 reserved
36 00 3D 1 reserved
36 00 3E 1 reserved
36 00 3F 1 reserved
36 00 40 1 reserved
36 00 41 1 reserved
36 00 42 1 00 – 7F reserved 7F
36 00 43 1 00 – 7F reserved 40
36 00 44 1 00 – 01 reserved 00
36 00 45 1 00 – 7F reserved 28
36 00 46 1 00 – 7F reserved 00
36 00 47 1 reserved 00
36 00 48 1 00 – 5F Assign 1 Control Number off, 1 – 95 10
36 00 49 1 00 – 5F Assign 2 Control Number off, 1 – 95 11
36 00 4A 1 00 – 5F BC Control Number off, 1 – 95 02
36 00 4B 1 00 – 5F FC2 Control Number off, 1 – 95 04
36 00 4C 1 00 – 5F FC1 Control Number off, 1 – 95 0B
36 00 4D 1 00 – 7F Voice Insertion Effect 1 Part 0 – 15: Part 1 – 16
96 – 97: PB Part 1, 2
127: off
00
36 00 4E 1 00 – 7F Voice Insertion Effect 2 Part ˝ 01
36 00 4F 1 00 – 7F Voice Insertion Effect 3 Part ˝ 02
36 00 50 1 00 – 7F Voice Insertion Effect 4 Part ˝ 03
36 00 51 1 00 – 7F reserved 64
36 00 52 1 01 – 7F reserved 40
36 00 53 1 00 – 7F reserved 28
36 00 54 1 00 – 7F reserved 00
36 00 55 1 00 – 7F reserved 00
36 00 56 1 00 – 7F reserved 7F
36 00 57 1 00 – 71 reserved 00
Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
36 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to Effect
Parameter List
0100
36 01 02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
˝ init value for
hall1
36 01 04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
˝ init value for
hall1
36 01 06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
˝ init value for
hall1
36 01 08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
˝ init value for
hall1
36 01 0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
˝ init value for
hall1
36 01 0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
˝ init value for
hall1
36 01 0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
˝ init value for
hall1
36 01 10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
˝ init value for
hall1
36 01 12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
˝ init value for
hall1
36 01 14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
˝ init value for
hall1
36 01 16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
˝ init value for
hall1
36 01 18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
˝ init value for
hall1
36 01 1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
˝ init value for
hall1
36 01 1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
˝ init value for
hall1
36 01 1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
Refer to Effect
Parameter List
init value for
hall1
36 01 20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
˝ init value for
hall1
36 01 22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
40
36 01 23 1 01 – 7F Reverb Pan L63 – C – R63 40
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes Address Size Data
Range
(HEX)
Parameter Name Description Default (HEX) Notes
36 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to Effect
Parameter List
0500
36 02 02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
˝ init value for
chorus1
36 02 04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
˝ init value for
chorus1
36 02 06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
˝ init value for
chorus1
36 02 08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
˝ init value for
chorus1
36 02 0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
˝ init value for
chorus1
36 02 0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
˝ init value for
chorus1
36 02 0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
˝ init value for
chorus1
36 02 10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
˝ init value for
chorus1
36 02 12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
˝ init value for
chorus1
36 02 14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
˝ init value for
chorus1
36 02 16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
˝ init value for
chorus1
36 02 18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
˝ init value for
chorus1
36 02 1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
˝ init value for
chorus1
36 02 1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
˝ init value for
chorus1
36 02 1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
˝ init value for
chorus1
36 02 20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
˝ init value for
chorus1
36 02 22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
60
36 02 23 1 01 – 7F Chorus Pan L63 – C – R63 40
36 02 24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127) 00
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
36 10 00 1 34 – 4C EQ Gain 1 -12 – +12 [dB] 40
36 10 01 1 04 – 28 EQ Frequency 1 32 – 2000 [Hz] 0C
36 10 02 1 01 – 78 EQ Q1 0.1 – 12.0 07
36 10 03 1 00 – 01 EQ Shape 1 shelv, peak 00
36 10 04 1 34 – 4C EQ Gain2 -12 – +12 [dB] 40
36 10 05 1 0E – 36 EQ Frequency2 100 – 10.0 [kHz] 14
36 10 06 1 01 – 78 EQ Q2 0.1 – 12.0 07
1 01 reserved
36 10 08 1 34 – 4C EQ Gain3 -12 – +12 [dB] 40
36 10 09 1 0E – 36 EQ Frequency3 100 – 10.0 [kHz] 1C
36 10 0A 1 01 – 78 EQ Q3 0.1- 12.0 07
1 reserved
36 10 0C 1 34 – 4C EQ Gain4 -12 – +12 [dB] 40
36 10 0D 1 0E – 36 EQ Frequency4 100 – 10.0 [kHz] 2C
36 10 0E 1 01 – 78 EQ Q4 0.1 – 12.0 07
1 reserved
36 10 10 1 34 – 4C EQ Gain5 -12 – +12 [dB] 40
36 10 11 1 1C – 3A EQ Frequency5 0.5 – 16.0 [kHz] 34
36 10 12 1 01 – 78 EQ Q5 0.1 – 12.0 07
36 10 13 1 00 – 01 EQ Shape5 shelv, peak 00
MR_DL1.book Page 58 Monday, January 6, 2003 11:10 AM
59
<Table 8-2>
MIDI PARAMETER CHANGE TABLE (MULTI PART)
MODEL ID = 06xF
TOTAL SIZE = 58 3A (HEX)
pp = part number
00 – 0F Part 1-16 (Normal, Drum)
60 Part Plug-in 1 (User, Preset, Direct)
61 Part Plug-in 2 (User, Preset, Direct)
10 – 1F Multi Plug-in Board Part
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
37 pp 00 1 00 – 7F Bank Select MSB 0 – 127 3F
37 pp 01 1 00 – 7F Bank Select LSB 0 – 127 00
37 pp 02 1 00 – 7F Program Number 1 – 128 00
37 pp 03 1 00 – 0F,
7F
Receive Channel 1 – 16, off (7F) Part No.
37 pp 04 1 00 – 01 Part Mode mono, poly 01
37 pp 05 1 01 – 7F Velocity Limit Low 1 – 127 01
37 pp 06 1 01 – 7F Velocity Limit High 1 – 127 7F
37 pp 07 1 00 – 7F Note Limit Low C-2 – G8 00
37 pp 08 1 00 – 7F Note Limit High C-2 – G8 7F
37 pp 09 1 10 – 58 Pitch Bend Range Upper -48 – +24
(PB Part: -24 – +24)
42
37 pp 0A 1 10 – 58 Pitch Bend Range Lower -48 – +24 3E
37 pp 0B 1 00 – 7F Velocity Sense Depth 0 – 127 40
37 pp 0C 1 00 – 7F Velocity Send Offset 0 – 127 40
37 pp 0D 1 00 – 7F Volume 0 – 127 64
37 pp 0E 1 01 – 7F Pan L63 – C – R63 40
37 pp 0F 1 reserved
37 pp 10 2 00 – 0F
00 – 0F
Detune MSB
Detune LSB
-12.8 – +12.7 [Hz]
1st bit3 – 0 → bit7 – 4
2nd bit3 – 0 → bit3 – 0
08 00
(80)
37 pp 12 1 00 – 7F Reverb Send 0 – 127 0C
37 pp 13 1 00 – 7F Chorus Send 0 – 127 00
37 pp 14 1 00 – 7F reserved 00
37 pp 15 1 00 – 7F Dry Level 0 – 127 7F
37 pp 16 1 28 – 58 Note Shift -24 – +24 [semitones] 40
37 pp 17 1 00 – 7F Filter Cutoff Frequency -64 – +63 40
37 pp 18 1 00 – 7F Filter Resonance/Width -64 – +63 40
37 pp 19 1 reserved
37 pp 1A 1 00 – 01 Portamento Switch off, on 00
37 pp 1B 1 00 – 7F Portamento Time 0 – 127 40
37 pp 1C 1 00 – 01 Portamento Mode fingered, fulltime 01
37 pp 1D 1 reserved
37 pp 1E 1 00 – 7F Output Select 0: L&R
8: asn1&2, 9: asn3&4
64 – 67: asn1, asn2, asn3,
asn4
127: drum (or L&R)
00 "L&R" for
parts
17–32
37 pp 1F 1 00 – 7F reserved
Arpeggio Sw
Receive Control Change
Receive Bank Select
Receive Program Change
Receive AT
Receive PB
bit0: reserved
bit1: Arpeggio Sw off, on
bit2: off, on Control
Change
bit3: off, on Bank Select
bit4: off, on Program
Change
bit5: off, on AT
bit6: off, on PB
7C
37 pp 20 1 00 – 7F Receive Volume/Expression
Receive Pan
Receive Sustain/Sostenuto
Receive MW
bit0: off, on Volume/
Expression
bit1: off, on Pan
bit2: reserved
bit3: off, on Sustain/
Sostenuto
bit4: reserved
bit5: off, on MW
bit6: reserved
7F
37 pp 21 1 00 – 7F Receive FC2
Receive FS
Receive FC1
Receive BC
Receive Assign 1
Receive Assign 2
bit0: off, on FC2
bit1: off, on FS
bit2: off, on FC1
bit3: off, on BC
bit4: off, on AS1
bit5: off, on AS2
bit6: reserved
7F
37 pp 22 1 00 – 7F AEG Sustain Level -64 – +63 40
37 pp 23 1 00 – 7F AEG Attack Time -64 – +63 40
37 pp 24 1 00 – 01 Voice Pan on/off off, on 01 Part 1 – 16
37 pp 25 1 00 – 7F AEG Decay Time -64 – +63 40
37 pp 26 1 00 – 7F AEG Release Time -64 – +63 40
37 pp 27 1 00 – 7F FEG Sustain Level -64 – +63 40
37 pp 28 1 00 – 7F FEG Attack Time -64 – +63 40
37 pp 29 1 reserved
37 pp 2A 1 00 – 7F FEG Decay Time -64 – +63 40
37 pp 2B 1 00 – 7F FEG Release Time -64 – +63 40
37 pp 2C 1 00 – 7F FEG Depth -64 – +63 40
37 pp 2D 1 00 reserved 00
37 pp 2E 2 002E –
0136
Low Frequency MSB
Low Frequency LSB
50.1 – 2.00k 00
36
Part 1 – 16
37 pp 30 1 20 – 60 Low Gain -32 – +32 40 Part 1 – 16
37 pp 31 1 00 reserved 00
37 pp 32 2 0053 –
0171
Mid Frequency MSB
Mid Frequency LSB
139.7 – 10.1k 01
0D
Part 1 – 16
37 pp 34 1 20 – 60 Mid Gain -32 – +32 40 Part 1 – 16
37 pp 35 1 00 – 1F Mid Resonance 0 – 31 40 Part 1 – 16
37 pp 36 2 0103 –
017F
High Frequency MSB
High Frequency LSB
503.8 – 14k 01
67
Part 1 – 16
37 pp 38 1 20 – 60 High Gain -32 – +32 40 Part 1 – 16
37 pp 39 1 00 reserved 00
Address Size Data
Range
(HEX)
Parameter Name Description Default
(HEX)
Notes
MR_DL1.book Page 59 Monday, January 6, 2003 11:10 AM
TransmittedFunction... Recognized Remarks
Basic
Channel
Note
Number : True voice
Velocity
After
Touch
Pitch Bend
Control
Change
Prog
Change : True #
System Exclusive
Common : Song Pos.
: Song Sel.
: Tune
System : Clock
Real Time : Commands
: All Sound Off
Aux :
Reset
All
Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset
Notes:
Mode
Default
Changed
Note ON
Note OFF
Key's
Ch's
0,32
1,7,10,11
6,38
64
65
66
71-75
91,93
96-97
100-101
1-95
1 - 16
1 - 16
˛
˛
˛
˛
Ø *1
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø 0 - 127 *1
**************
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
*1 receive/transmit if switch is on.
*2 m is always treated as "1" regardless of its value.
˛
˛
**************
˛
**************
Ø
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO
˛
1 - 16
1 - 16
Ø v=1-127
˛
˛
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
˛
˛
˛
Ø
˛
Ø (120,126,127)
Ø (121)
˛
Ø (123-125)
Ø
˛
1
1 - 4 (m=1) *2
˛
0 - 127
0 - 127
Ø
Ø *1
Ø : Yes
˛ : No
Default
Messages
Altered
YAMAHA [ Tone Generator ] Date :31-OCT-2002
Model MOTIF-RACK MIDI Implementation Chart Version : 1.0
Memorized
Memorized
Bank Select
Data Entry
Sustain Sw
Portamento Sw
Sosutenuto
Sound Controller
Effect Depth
RPN Inc,Dec
RPN LSB,MSB
Assignable Cntrl
Ø0 - 127 *1
0 - 127 *1
MR_DL1.book Page 60 Monday, January 6, 2003 11:10 AM
