INTRODUCTION
PREPARATION
- CONNECTIONS
BASIC OPERATION
ADVANCED OPERATION
ADDITIONAL INFORMATION
- TROUBLESHOOTING
- SPECIFICATIONS
LIST OF REMOTE CONTROL CODES

RX-797

Stereo Receiver

OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS

• Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert you to the

presence of uninsulated “dangerous voltage” within

the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle

is intended to alert you to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

6Clean only with dry cloth.

7Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers)

that produce heat.

9Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided plug

does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when

unused for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in any

way, such as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

IMPORTANT SAFETY INSTRUCTIONS

Note to CATV system installer:

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the NEC that

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building, as

close to the point of cable entry as practical.

IMPORTANT

Please record the serial number of this unit in the space

below.

MODEL:

Serial No.:

The serial number is located on the rear of the unit.

Retain this Owner’s Manual in a safe place for future

reference.

CAUTION

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

We Want You Listening For A Lifetime

YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your

equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or

distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is

often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group

recommend you to avoid prolonged exposure from excessive volume levels.

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1 IMPORTANT NOTICE: DO NOT MODIFY THIS

UNIT!

This product, when installed as indicated in the

instructions contained in this manual, meets FCC

requirements. Modifications not expressly approved by

Yamaha may void your authority, granted by the FCC, to

use the product.

2 IMPORTANT: When connecting this product to

accessories and/or another product use only high quality

shielded cables. Cable/s supplied with this product MUST

be used. Follow all installation instructions. Failure to

follow instructions could void your FCC authorization to

use this product in the USA.

3 NOTE: This product has been tested and found to comply

with the requirements listed in FCC Regulations, Part 15

for Class “B” digital devices. Compliance with these

requirements provides a reasonable level of assurance that

your use of this product in a residential environment will

not result in harmful interference with other electronic

devices.

This equipment generates/uses radio frequencies and, if

not installed and used according to the instructions found

in the users manual, may cause interference harmful to the

operation of other electronic devices.

Compliance with FCC regulations does not guarantee that

interference will not occur in all installations. If this

product is found to be the source of interference, which

can be determined by turning the unit “OFF” and “ON”,

please try to eliminate the problem by using one of the

following measures:

Relocate either this product or the device that is being

affected by the interference.

Utilize power outlets that are on different branch (circuit

breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient

the antenna. If the antenna lead-in is 300 ohm ribbon lead,

change the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory

results, please contact the local retailer authorized to

distribute this type of product. If you can not locate the

appropriate retailer, please contact Yamaha Electronics

Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA

90620.

The above statements apply ONLY to those products

distributed by Yamaha Corporation of America or its

subsidiaries.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

iii

1To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2Install this sound system in a well ventilated, cool, dry, clean

place – away from direct sunlight, heat sources, vibration,

dust, moisture, and/or cold. Allow ventilation space of at least

30 cm on the top, 20 cm on the left and right, and 20 cm on

the back of this unit.

3Locate this unit away from other electrical appliances, motors,

or transformers to avoid humming sounds.

4Do not expose this unit to sudden temperature changes from

cold to hot, and do not locate this unit in an environment with

high humidity (i.e. a room with a humidifier) to prevent

condensation inside this unit, which may cause an electrical

shock, fire, damage to this unit, and/or personal injury.

5Avoid installing this unit where foreign objects may fall onto

this unit and/or this unit may be exposed to liquid dripping or

splashing. On the top of this unit, do not place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall and liquid

may cause electrical shock to the user and/or damage to

this unit.

6Do not cover this unit with a newspaper, tablecloth, curtain,

etc. in order not to obstruct heat radiation. If the temperature

inside this unit rises, it may cause fire, damage to this unit,

and/or personal injury.

7Do not plug in this unit to a wall outlet until all connections

are complete.

8Do not operate this unit upside-down. It may overheat,

possibly causing damage.

9Do not use force on switches, knobs and/or cords.

10 When disconnecting the power cable from the wall outlet,

grasp the plug; do not pull the cable.

11 Do not clean this unit with chemical solvents; this might

damage the finish. Use a clean, dry cloth.

12 Only voltage specified on this unit must be used. Using this

unit with a higher voltage than specified is dangerous and may

cause fire, damage to this unit, and/or personal injury.

YAMAHA will not be held responsible for any damage

resulting from use of this unit with a voltage other than

specified.

13 To prevent damage by lightning, keep the power cord and

outdoor antennas disconnected from a wall outlet or the unit

during a lightning storm.

14 Do not attempt to modify or fix this unit. Contact qualified

YAMAHA service personnel when any service is needed. The

cabinet should never be opened for any reasons.

15 When not planning to use this unit for long periods of time

(i.e. vacation), disconnect the AC power plug from the wall

outlet.

16 Install this unit near the AC outlet and where the AC power

plug can be reached easily.

17 Be sure to read the “TROUBLESHOOTING” section on

common operating errors before concluding that this unit is

faulty.

18 Before moving this unit, press MASTER ON/OFF to release it

outward to the OFF position, and disconnect the AC power

plug from the wall outlet.

19 VOLTAGE SELECTOR (Asia and General models only)

The VOLTAGE SELECTOR on the rear panel of this unit

must be set for your local main voltage BEFORE plugging

into the AC main supply. Voltages are:

General model .............AC 110/120/220/230–240 V, 50/60 Hz

Asia model ................................ AC 220/230–240 V, 50/60 Hz

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN

OR MOISTURE.

As long as this unit is connected to the AC wall outlet,

it is not disconnected from the AC power source even

if you turn off this unit by MASTER ON/OFF, or

MAIN ZONE ON/OFF and ZONE 2 ON/OFF. In this

state, this unit is designed to consume a very small

quantity of power.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to

wide slot and fully insert.

This Class B digital apparatus complies with Canadian

ICES-003.

POUR LES CONSOMMATEURS CANADIENS

Pour éviter les chocs électriques, introduire la lame la

plus large de la fiche dans la borne correspondante de

la prise et pousser jusqu’au fond.

Cet appareil numérique de la classe B est conforme à

la norme NMB-003 du Canada.

PREPARATIONINTRODUCTION

BASIC

OPERATION

ADDITIONAL

INFORMATION

ADVANCED

OPERATION

FEATURES............................................................. 2

SUPPLIED ACCESSORIES ................................. 2

CONTROLS AND FUNCTIONS ......................... 3

Front panel ................................................................. 3

Front panel display .................................................... 5

Rear panel .................................................................. 6

Remote control........................................................... 7

Zone 2 remote control................................................ 9

Installing batteries in the remote controls................ 11

Using the remote controls........................................ 11

CONNECTIONS .................................................. 12

Connecting speakers ................................................ 12

Connecting audio and video components ................ 13

Connecting the AM and FM antennas ..................... 14

Connecting the power supply cord .......................... 16

Turning on and off this unit ..................................... 17

PLAYING AND RECORDING .......................... 18

Playing a source....................................................... 18

Adjusting the tonal quality....................................... 20

Recording a source .................................................. 21

Using the sleep timer ............................................... 22

Muting the sound output.......................................... 23

FM/AM TUNING ................................................. 24

Automatic tuning ..................................................... 24

Manual tuning .......................................................... 25

Automatic preset tuning........................................... 26

Manual preset tuning ............................................... 28

Selecting preset stations........................................... 29

Exchanging preset stations ...................................... 29

XM SATELLITE RADIO TUNING .................. 30

What is XM Satellite Radio? ................................... 30

XM Satellite Radio connections .............................. 30

XM Satellite Radio functions .................................. 31

Activating XM Satellite Radio ................................ 33

Basic XM Satellite Radio operations....................... 34

XM Satellite Radio search modes............................ 35

Setting XM Satellite Radio preset channels ............ 37

ADVANCED SETUP ............................................39

Changing the ADVANCED SETUP menu

parameters ........................................................... 39

Switching the remote control ID ............................. 40

ZONE 2 ..................................................................41

Connecting the Zone 2 components ........................ 41

Controlling Zone 2................................................... 42

REMOTE CONTROL FEATURES ...................43

Control area ............................................................. 43

Controlling other components ................................. 44

Setting remote control codes ................................... 45

TROUBLESHOOTING .......................................46

SPECIFICATIONS...............................................49

CONTENTS

INTRODUCTION

PREPARATION

BASIC OPERATION

ADVANCED OPERATION

ADDITIONAL INFORMATION

FEATURES

Built-in 2-channel power amplifier

◆Minimum RMS output power

100 W + 100 W (8 Ω), 0.019% THD, 20 Hz to 20 kHz

◆Highly dynamic power, low impedance drive

capability

Sophisticated AM/FM tuner

◆40-station random access preset tuning

◆Automatic preset tuning

◆Preset station exchanging capability

◆Radio Data System tuning capability

(Europe model only)

XM Satellite Radio

(U.S.A. model only)

◆XM Satellite Radio tuning capability using the XM

Connect-and-Play™ digital antenna accessory (sold

separately)

Other features

◆PURE DIRECT button used to reproduce the purest

source sound

◆CD DIRECT AMP button used to reproduce the purest

CD sound

◆REC OUT selector independent of input source

selection

◆Continuously variable loudness control

◆Sleep timer

◆Remote control capability

◆Zone 2 remote control supplied

◆Zone 2 custom installation facility

•y indicates a tip for your operation.

• Some operations can be performed by using either the buttons on the front panel of this unit or those on the remote controls. In case

the button names differ between this unit and the remote controls, the names of the buttons on the remote controls are given in

parentheses.

• In case the buttons on the remote control and the Zone 2 remote control have certain functions in common, the illustrations of the

buttons on the remote control are used for explanation throughout the manual.

• This manual is printed prior to production. Design and specifications are subject to change in part as a result of improvements, etc. In

case of differences between the manual and the product, the product has priority.

Please check that you received all of the following parts.

FEATURES

SUPPLIED ACCESSORIES

PHONO

ZONE 2

TUNER

MD/TAPE

VCR

DTV/CBL

ENT

DVD

890

POWER

STANDBY

–

lA-E/CAT. k

A-E/CAT.h

CAT.

DISC

ALL

PRESET

PRESET/CH

NUMBER

A/B/C/D/E

MUTE

PRESET VOLUME

XMCDID2ID1

DISPLAY

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

VOL CH

Remote control

Batteries (x2)

(AA, R6, UM-3)

Indoor FM antenna

(U.S.A., Canada and

General models)

AM loop antenna

Indoor FM antenna

(Europe and Australia

models)

Zone 2 remote control Power cable

Batteries (x2)

(AAA, R03, UM-4)

CONTROLS AND FUNCTIONS

INTRODUCTION

1MASTER ON/OFF

Press inward to the ON position to turn on the power of

this unit. Press again to release it outward to the OFF

position to turn off this unit.

See page 17 for details.

Even when this unit is turned off, this unit consumes a small

amount of power to preserve the memory.

2MAIN ZONE ON/OFF

Turns on Main Zone of this unit or sets it to the standby

mode.

See page

for details.

• This switch is operational only when MASTER ON/OFF is

pressed inward to the ON position.

• In the standby mode, this unit consumes a small amount of

power to receive infrared signals from the remote control.

3SPEAKERS A/B

Turns on or off the speaker set connected to the

SPEAKERS A and/or SPEAKERS B terminals on the rear

panel each time the corresponding button is pressed (see

page 18).

4ZONE 2 ON/OFF

Turns on Zone 2 or set it to the standby mode. When Zone

2 is turned on, signals are output at the ZONE 2 OUT

jacks.

This switch is operational only when MASTER ON/OFF is

pressed inward to the ON position.

5ZONE CONTROL

Press to control the input source of Zone 2.

• This button is operational only when Zone 2 is turned on.

• When you press this button, the ZONE 2 indicator flashes in the

front panel display for approximately 5 seconds. Select the

input source of Zone 2 while the indicator is flashing.

• You can select the preset station or channel when TUNER or

XM is selected as the input source of Zone 2.

6Remote control sensor

Receives infrared signals from the remote control.

Switch the remote control ID between ID1 and ID2 when using

multiple YAMAHA receivers or amplifiers (see pages 9, 39 and

40).

7Front panel display

Shows information about the operational status of this

unit.

CONTROLS AND FUNCTIONS

Front panel

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

XM/ANT

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

3 9

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

∞

-dB

DISPLAY

6312 5498AB7DC0

HGFIJKLMN

(U.S.A. model)

Note

Memory back-up

The memory back-up circuit prevents the stored data

from being lost. However, the stored data will be lost if

the power cord is disconnected from the AC wall outlet

for more than one week.

Notes

Note

Notes

Note

CONTROLS AND FUNCTIONS

8EDIT, SEARCH MODE

Exchanges the assignment of two preset stations with each

other when TUNER is selected as the input source (see

page 29).

Switches between search modes when XM is selected as

the input source (see page 33).

9FM/AM, XM ANT (ANTENNA)

Switches the reception band between AM and FM when

TUNER is selected as the input source (see page 24).

Shows the reception level of the XM Connect-and-Play

digital antenna (sold separately) when XM is selected as

the input source (see page 31).

0TUNING/CH l / h

Selects the tuning frequency when TUNER is selected as

the input source (see page 24).

Searches for a radio channel or selects the preset channel

number when XM is selected as the input source (see page

31).

ATUN (TUNING) MODE/DISP (DISPLAY)

Switches the tuning mode between automatic (the AUTO

indicator turns on as a result) and manual (the AUTO

indicator turns off as a result) when TUNER is selected as

the input source.

Switches the XM Satellite Radio information shown in the

front panel display between channel number/name,

category and artist name/song title when XM is selected as

the input source (see page 34).

BMEMORY

Stores a station in the system memory (see page 28).

Sets this unit to the automatic preset tuning mode (see

page 26).

Stores a radio channel in the system memory when XM is

selected as the input source (see page 37).

CPURE DIRECT and indicator

Allows you to listen to a source in the purest possible

sound. The indicator above it lights up when this function

is turned on.

See page 20 for details.

DCD DIRECT AMP and indicator

Allows you to listen to a CD source in the purest possible

sound. The indicator above it lights up and the front panel

display turns off when this function is turned on.

See page 20 for details.

EVOLUME

Increases or decreases the sound output level.

This does not affect the OUT (REC) level.

FINPUT selector

Selects the input source you want to listen to or watch.

GA/B/C/D/E, CATEGORY

Selects the preset station group (A to E) when TUNER is

selected as the input source (see page 27).

Switches between channel categories or selects the preset

channel group when XM is selected as the input source

(see page 35).

HPHONES jack

Outputs audio for private listening with your headphones.

Press SPEAKER A/B so that the SP A/B indicators turn off

before you connect your headphones to the PHONES jack.

IREC OUT selector

Selects a source for recording to the MD recorder or the

tape deck independently of the INPUT selector setting,

allowing you to record the selected source while listening

to another source (see page 21).

JBASS

Increases or decreases the low frequency response. The 0

position produces a flat response (see page 20).

KTREBLE

Increases or decreases the high frequency response. The 0

position produces a flat response (see page 20).

LBALANCE

Adjusts the sound output balance of the left and right

speakers to compensate for sound imbalances caused by

speaker locations or listening room conditions (see page

20).

MLOUDNESS

Retains a full tonal range at any volume level to

compensate for the human ears’ loss of sensitivity to high

and low-frequency ranges at a low volume level (see page

20).

NPreset station/channel number buttons

(1 to 8)

Selects the preset station/channel number (1 to 8) directly

when TUNER or XM is selected as the input source (see

page 29).

The XM Satellite Radio features (XM ANT, CH, SEARCH

MODE, DISP, CATEGORY, MEMORY and the preset channel

number buttons) are only applicable to the U.S.A. model and are

operational only when XM is selected as the input source. For

details, see “XM SATELLITE RADIO TUNING” on page 30.

Note

CONTROLS AND FUNCTIONS

INTRODUCTION

1SP (SPEAKERS) A/B indicators

Light up according to the set of speakers selected.

Both indicators light up when both sets of speakers are

selected.

2ZONE 2 indicator

Lights up when Zone 2 is turned on.

3Input source indicators

Light up when this unit is in the corresponding mode.

The XM indicator is only applicable to the U.S.A. model.

4MEMORY indicator

Flashes for approximately 5 seconds after MEMORY on

the front panel is pressed. While the MEMORY indicator

is flashing, store the displayed station in the system

memory by using A/B/C/D/E and one of the preset station

number buttons on the front panel.

5AUTO indicator

Lights up when this unit is in the automatic tuning mode.

6STEREO indicator

Lights up when this unit is receiving a strong signal for an

FM stereo broadcast while the AUTO indicator is lit.

7SLEEP indicator

Lights up when the sleep timer is turned on.

8MUTE indicator

Flashes while the MUTE function is turned on.

9Multi-information display

Shows information when adjusting or changing settings.

0TUNED indicator

Lights up when this unit is tuned into a station.

■Europe model only

ARadio Data System indicators

The box-shaped indicator beside the name of each Radio

Data System mode lights up when the corresponding

Radio Data System mode is selected.

PTY HOLD indicator

Lights up while searching for stations in the PTY

SEEK mode.

EON indicator

Lights up when the Radio Data System station that

offers the EON data service is being received.

Front panel display

DVD VCR CD TUNER PHONO

HOLDPTY

DTV/CBL

MD/TAPE

A B

ZONE2 ZONE3 MEMORY AUTO

TUNED STEREO

SLEEP

EON

PTY

MUTE

0A9

12 4 5 6 738

Note

CONTROLS AND FUNCTIONS

1Antenna terminals

Connect FM and AM antennas.

See page 14 for connections information.

2AUDIO/VIDEO jacks

Connect audio and video components.

See page 13 for connection information.

3REMOTE jacks

These jacks are used to input/output remote control

signals.

See page 41 for connection information.

4CONTROL OUT jack

This is a control expansion jack. Consult your nearest

authorized YAMAHA dealer or service center about this

jack.

5XM jack

(U.S.A. model only)

Connect XM Connect-and-Play digital antenna accessory.

See page 30 for connection information.

6AC IN

Use to plug in the supplied power cable.

See page 16 for connection information.

7CD jacks

Connect a CD player.

See page 13 for connection information.

8PHONO jacks and GND terminal

Connect a turntable.

See page 13 for connection information.

9ZONE 2 jacks

Connect a Zone 2 component.

See page 41 for connection information.

0SUBWOOFER OUTPUT jack

Connect a subwoofer with built-in amplifier.

ACOUPLER jacks

Connect an external unit.

See page 16 for connection information.

BSPEAKERS terminals

Connect speakers.

See page 12 for connection information.

CIMPEDANCE SELECTOR switch

Switches the impedance setting.

See page 16 for details.

DAC OUTLET(S) (SWITCHED)

Use to supply power to your other audio and video

components.

See page 16 for details.

■Asia and General models only

VOLTAGE SELECTOR

See page 16 for details.

Rear panel

AC OUTLETS

SWITCHED

IMPEDANCE SELECTOR

SET BEFORE POWER ON

SELECTEUR D'IMPEDANCE

SPEAKERS

CLASS 2 WIRING

AC IN

XMREMOTE

OUT

DVD

DTV/

CBL

(PLAY)

OUT

(REC)

OUT

MD/

TAP E

ZONE 2

OUT

ZONE 2

OUT

MONITOR

OUT

VCR

DVD

GND

ANT

75Ω

UNBAL.

DTV/

CBL

OUT

PHONO

VCR

MAIN

PRE

OUT

SUB

WOOFER

+12V 15mA MAX.

CONTROL OUT

COUPLER

OUTPUTAUDIOAUDIO

VIDEO

TUNER

A OR B: 4ΩMIN. /SPEAKER

A+B: 8ΩMIN. /SPEAKER A OR B: 6ΩMIN. /SPEAKER

70 CD8AB

1235 6

(U.S.A. model)

CONTROLS AND FUNCTIONS

INTRODUCTION

This section describes the function of each button on the

remote control used to control this unit or other

components made by YAMAHA or other manufacturers.

The functions of the buttons used to control your other

audio and video components are the same as those of the

corresponding buttons on those components. Refer to

those components’ instruction manuals for details. To

operate other components using this remote control, see

“REMOTE CONTROL FEATURES” on page 43.

1Infrared signal transmitter

Sends infrared signals.

2Input selector buttons

Select the desired input source and change the control area

(see page 43).

3Numeric buttons

Select the preset station number (1 to 8) when TUNER is

selected as the input source.

Select the preset channel number when XM is selected as

the input source.

4BAND

Switches to the previously used reception band (FM or

AM) when TUNER is selected as the input source.

The frequency of the previously received station is automatically

recalled.

5A-E/CAT. (CATEGORY) j / i

Selects the preset station group (A to E) when TUNER

is selected as the input source (see page 29).

Switches between channel categories or selects the

preset channel group (A to E) when XM is selected as

the input source (see page 35).

PRESET/CH u / d

Selects the preset station number (1 to 8) when

TUNER is selected as the input source (see page 29).

Searches for a radio channel or selects the preset

channel number (1 to 8) when XM is selected as the

input source (see page 33).

6MEMORY

Stores a radio channel in the system memory when XM is

selected as the input source (see page 37).

7STANDBY

Sets this unit to the standby mode.

• This button is operational only when MASTER ON/OFF on the

front panel is pressed inward to the ON position.

• In the standby mode, this unit consumes a small amount of

power to receive infrared signals from the remote control.

• This button does not set Zone 2 to the standby mode.

8POWER

Turns on this unit.

• This button is operational only when MASTER ON/OFF on the

front panel is pressed inward to the ON position.

• This button does not turn on Zone 2.

Remote control

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

VOL CH

(U.S.A. model)

Note

Notes

CONTROLS AND FUNCTIONS

9SPEAKERS A/B

Turns on or off the set of speakers connected to the

SPEAKERS A and/or SPEAKERS B terminals on the rear

panel of this unit when the corresponding button is

pressed each time.

0CODE SET

Use to set up remote control codes (see page 45).

ASLEEP

Sets the sleep timer.

BVOLUME +/–

Increases or decreases the sound output level.

• This does not affect the OUT (REC) level.

• When you press VOLUME +/– to control the sound output

level of this unit, VOLUME on the front panel rotates.

CMUTE

Mutes the sound output. Press again to restore the sound

output to the previous volume level (see page 23).

The sound output to Zone 2 is not muted.

DENT. (ENTER)

Confirms an entered channel number during the Direct

Number Access mode when XM is selected as the input

source.

ESRCH (SEARCH) MODE

Switches between the XM Satellite Radio search modes

(see page 35) when XM is selected as the input source.

FDISPLAY

Switches the XM Satellite Radio information shown in the

front panel display between channel number/name,

category and artist name/song title when XM is selected as

the input source.

The XM Satellite Radio features (XM, SRCH MODE, DISPLAY,

A-E/CAT. j / i, PRESET/CH u / d, MEMORY and ENT.) are

only applicable to the U.S.A. model and are operational only

when XM is selected as the input source. For details, see “XM

SATELLITE RADIO TUNING” on page 30.

Notes

Note

CONTROLS AND FUNCTIONS

INTRODUCTION

This section describes the function of each button on the

Zone 2 remote control used to control Zone 2. You can

also use the Zone 2 remote control to control the XM

Satellite Radio features and YAMAHA CD players.

1Infrared signal transmitter

Sends infrared signals.

2Input selector/numeric buttons

Select the desired input source of Zone 2.

Enter a channel number or preset channel number when

XM is selected as the input source.

You must press and hold NUMBER before you press any of these

buttons to enter numbers.

3PRESET u / d

Selects the preset station number (1 to 8) when TUNER is

selected as the input source.

4A/B/C/D/E

Selects the preset station group (A to E) when TUNER is

selected as the input source.

5XM Satellite Radio control buttons

Controls the XM Satellite Radio features when the

CD/XM switch is slid to the XM position.

A-E/CAT. (CATEGORY) l / h

Switches between channel categories or selects the

preset channel group (A to E) when XM is selected as

the input source.

PRESET/CH k / n

Searches for a radio channel or selects the preset

channel number (1 to 8) when XM is selected as the

input source.

ALL

Selects the All Channel Search mode.

PRESET

Selects the Preset Search mode.

CAT. (CATEGORY)

Selects the Category Search mode.

6ID1/ID2 switch

Switches the remote control ID between ID1 and ID2 (see

page 40).

7POWER

Turns on Zone 2.

8STANDBY

Sets Zone 2 to the standby mode.

9ENT (ENTER)

Confirms an entered channel number during the Direct

Number Access mode when XM is selected as the input

source.

0VOLUME +/–

Increases or decreases the sound output level of Zone 2.

This does not affect the OUT (REC) level.

Zone 2 remote control

Note

PHONO

ZONE 2

TUNER

MD/TAPE

VCR

DTV/CBL

ENT

DVD

890

POWER

STANDBY

–

lA-E/CAT. k

A-E/CAT.h

CAT.

DISC

ALL

PRESET

PRESET/CH

NUMBER

A/B/C/D/E

MUTE

PRESET VOLUME

XMCDID2ID1

DISPLAY

(U.S.A. model)

Note

CONTROLS AND FUNCTIONS

AMUTE

Mutes the sound output to Zone 2. Press again to restore

the sound output to the previous volume level.

BDISPLAY

Switches the XM Satellite Radio information displayed in

the front panel display between channel number/name,

category and artist name/song title when XM is selected as

the input source.

CCD/XM switch

Switches the function of the control buttons numbered 5,

B and D between controlling YAMAHA CD players and

controlling the XM Satellite Radio features.

DNUMBER

Press and hold before you press the input selector/numeric

buttons to enter numbers to control the XM Satellite Radio

features.

The XM Satellite Radio features (XM, ENT, DISPLAY and the

XM Satellite Radio control buttons) are only applicable to the

U.S.A. model and are operational only when XM is selected as

the input source and the CD/XM switch is slid to the XM

position. For details, see “XM SATELLITE RADIO TUNING”

on page 30.

Note

CONTROLS AND FUNCTIONS

INTRODUCTION

■Notes on batteries

• Change all of the batteries if the operation range of the remote controls decreases.

• Use AA, R6, UM-3 batteries for the remote control and AAA, R03, UM-4 batteries for the Zone 2 remote control.

• Make sure that the polarities are correct. See the illustration inside the battery compartment of each remote control.

• Remove the batteries if the remote controls are not used for an extended period of time.

• Do not use old batteries together with new ones.

• Do not use different types of batteries (such as alkaline and manganese batteries) together. Read the packaging carefully as these

different types of batteries may have the same shape and color.

• We strongly recommend using alkaline batteries.

• If the batteries have leaked, dispose of them immediately. Avoid touching the leaked material or letting it come into contact with

clothing, etc. Clean the battery compartment thoroughly before installing new batteries.

• Do not throw away batteries with general house waste; dispose of them correctly in accordance with your local regulations.

Remote control Zone 2 remote control

1Open the battery compartment cover.

2Insert the supplied batteries in each remote

control according to the polarity markings (+

and –) on the inside of the battery

compartment.

3Close the cover back.

The remote controls transmit a directional infrared beam.

Be sure to aim the remote controls directly at the remote control sensor on the front panel of this unit or on the infrared

signal receiver in Zone 2 during operation.

■Handling the remote controls

• The area between the remote controls and this unit (or the

infrared signal receiver in Zone 2) must be clear of large

obstacles.

• Do not spill water or other liquids on the remote controls.

• Do not drop the remote controls.

• Do not leave or store the remote controls in the following types

of conditions:

– places of high humidity, such as near a bath

– places of high temperature, such as near a heater or a stove

– places of extremely low temperatures

– dusty places

• Do not expose the remote control sensor to strong lighting, in

particular, an inverter type fluorescent lamp; otherwise, the

remote controls may not work properly. If necessary, position

this unit away from direct lighting.

Installing batteries in the remote controls

Using the remote controls

VOLUME

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

30 30

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

AUDIO

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODEBAND

PRESET/CH

4321

ENT.

DISPLAYRETURN

A-E/CAT. A-E/CAT.

MEMORY

MUTE INPUT

VOL CH

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

Approximately 6 m (19.7 ft)

CONNECTIONS

Be sure to connect the left channel (L), right channel (R), “+” (red) and “–” (black) properly. If the connections are faulty,

no sound will be heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be

unnatural and lack bass.

• Before connecting the speakers, make sure that the power of this unit is turned off.

• Do not let the bare speaker wires touch each other or do not let them touch any metal part of this unit. This could

damage this unit and/or the speakers.

• Use magnetically shielded speakers. If this type of speakers still creates the interference with the monitor, place the

speakers away from the monitor.

1Remove approximately 10 mm (3/8 in) of

insulation from the end of each speaker

cable and twist the exposed wires of the

cable together to eliminate the risk of a

short-circuit.

2Unscrew the knob.

3Insert one bare wire into the hole in the side

of each terminal.

4Tighten the knob to secure the wire.

■Notes on the speaker cord

A speaker cord is actually a pair of insulated cables

running side by side. One cable is colored or shaped

differently, perhaps with a stripe, groove or ridge. Connect

the striped, grooved or ridged cable to the “+” (red)

terminals on this unit and your speaker. Connect the plain

cable to the “–” (black) terminals on this unit and your

speaker.

■Connecting the banana plug

(U.S.A., Canada, Australia and General

models only)

First, tighten the knob and then insert the banana plug into

the end of the corresponding terminal.

• One or two speaker sets can be connected to this unit. If you use

only one speaker set, connect it to either the SPEAKERS A or

SPEAKERS B terminals.

• Use speakers with the specified impedance shown on the rear

panel of this unit.

CONNECTIONS

Connecting speakers

CAUTION

10 mm (3/8 in)

Red: positive (+)

Black: negative (–)

Red: positive (+)

Black: negative (–)

Notes

Red: positive (+)

Black: negative (–)

Banana plug

CONNECTIONS

PREPARATION

• Do not connect this unit or other components to the main power until all connections between components are complete.

• All connections must be correct: L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. Also, refer to the owner’s manual for each of

your components.

• Use the RCA type pin plug cables for audio and video components except speakers.

• The PHONO jacks are designed to connect a turntable with an MM or high-output MC cartridge. If you have a turntable with a low-

output MC cartridge, use an in-line boosting transformer or an MC-head amplifier when connecting your turntable to the PHONO

jacks.

• Connect your turntable to the GND terminal to reduce noise in the signal. However, you may hear less noise without the connection to

the GND terminal for some record players.

Connecting audio and video components

CAUTION

DVD

DTV/

CBL

(PLAY)

OUT

(REC)

OUT

MD/

TAPE

ZONE 2

OUT

VCR

GND

ANT

75Ω

UNBAL.

PHONO

AUDIOAUDIO

VIDEO

TUNER

LR LR

LRLR

V V

MONITOR

OUT

DVD

DTV/

CBL

OUT

VCR

ZONE 2

OUT

Turntable

DVD player

Audio in

VCR, etc.

CD player

MD recorder,

Tape deck, etc.

Audio out

GND

Audio out

Audio in Audio out

Digital TV,

Cable TV

Video out

Audio out

Video out

Video in

Video

monitor

Video in

CONNECTIONS

Both AM and FM indoor antennas are included with this unit. In general, these antennas should provide sufficient signal

strength. Connect each antenna correctly to the designated terminals.

• A properly installed outdoor antenna provides clearer reception than an indoor one. If you experience poor reception quality, an

outdoor antenna may improve the quality. Consult your nearest authorized YAMAHA dealer or service center about outdoor antennas.

• If you connect an outdoor FM antenna to this unit, do not connect the indoor FM antenna to this unit.

• To minimize interference from automobile ignition, locate the antenna as far from heavy traffic as possible.

• Keep the feeder cable or coaxial cable as short as possible. Do not bundle or roll up excess cable.

• The antenna should be placed at least 2 meters from reinforced concrete walls or metal structures.

Connecting the AM and FM antennas

Notes

GND

ANT

75Ω

UNBAL.

TUNER

AM loop antenna

(included)

Indoor FM antenna

(included)

Outdoor AM antenna

Use a 5 to 10 m of vinyl-

covered wire extended

outdoors from a window. Outdoor FM antenna

Ground (GND terminal)

For maximum safety and

minimum interference, connect

the antenna GND terminal to a

good earth ground. A good earth

ground is a metal stake driven into

moist earth.

CONNECTIONS

PREPARATION

■Connecting the AM loop antenna

1Set up the AM loop antenna.

2Press and hold the tab.

3Insert the AM loop antenna lead wires into

the AM ANT terminal.

4Release the tab.

5Repeat steps 2 to 4 to insert the AM loop

antenna lead wires into the GND terminal.

6Orient the AM loop antenna for the best

reception.

• The AM loop antenna should be placed away from this unit.

• A properly installed outdoor antenna provides clearer reception

than an indoor one. If you experience poor reception quality, an

outdoor antenna may improve the quality. It is recommended

that you should connect a 5 to 10 m of vinyl-covered wire to the

AM ANT terminal and extend it outdoors from a window.

Consult your nearest authorized YAMAHA dealer or service

center about outdoor antennas.

• The AM loop antenna should always be connected, even if an

outdoor AM antenna is connected to this unit.

Notes

CONNECTIONS

Plug the power cable into the AC IN on the rear panel of

this unit and then plug the power supply cord into the AC

wall outlet after all other connections are complete.

■COUPLER jacks

Removing the jumper pins from the PRE OUT/MAIN IN

jacks enables this unit to operate separately as a control

amplifier or a power amplifier. These jacks are used to

connect a signal-processing system such as a graphic

equalizer or a surround-sound processor to this unit. If

such an external unit is connected to these jacks, the

VOLUME control of this unit can be used to adjust the

overall sound output level.

To connect an external unit, first remove the jumper pins

from the PRE OUT/MAIN IN jacks and then connect the

input jacks of that external unit to the PRE OUT jacks or

its output jacks to the MAIN IN jacks. For details, refer to

the owner’s manual included with the external unit to be

connected.

• When you do not use the COUPLER jacks, never remove the

jumper pins from these jacks. If removed, no sound will be

output from this unit.

• When you use this unit with an external unit connected to the

COUPLER jacks, make sure that the CD DIRECT AMP button

and the PURE DIRECT button on the front panel are turned off.

• When you use this unit as a power amplifier, connect the output

jacks of an external control amplifier, etc. to the MAIN IN jacks

of this unit. In this case, the controls of this unit will not

function except the PHONES jack and the SPEAKERS A/B

buttons. Use the controls on the external control amplifier to

make volume adjustments, etc.

■AC OUTLET(S) (SWITCHED)

Australia model ......................................................1 outlet

Other models ....................................................... 2 outlets

Use these outlets to connect the power supply cords from

your other components to this unit. The outlets supply

power to any connected components whenever the power

of this unit is turned on. For information on the maximum

power (total power consumption of components), see

“SPECIFICATIONS” on page 49.

■VOLTAGE SELECTOR

(Asia and General models only)

VOLTAGE SELECTOR on the rear panel of this unit must

be set for your local main voltage BEFORE plugging the

power supply cord into the AC wall outlet.

Voltages are as follows:

Asia model ......................... AC 220/230–240 V, 50/60 Hz

General model...... AC 110/120/220/230–240 V, 50/60 Hz

■IMPEDANCE SELECTOR switch

Do not slide the IMPEDANCE SELECTOR switch while the

power of this unit is turned on, as doing so may damage the unit.

Select the switch position (left or right) according to the

impedance of the speakers in your system.

• The Canada model cannot use two separate speaker sets (A and

B) simultaneously when the IMPEDANCE SELECTOR switch

is slid to the 6 Ω position.

• If this unit fails to turn on, the IMPEDANCE SELECTOR

switch may not be fully slid to either position. If this is the case,

slide the switch all the way to either position when the power

supply to this unit is completely cut off.

Connecting the power supply cord

Notes

AC OUTLETS

SWITCHED

IMPEDANCE SELECTOR

SET BEFORE POWER ON

SELECTEUR D'IMPEDANCE

AC IN

A OR B: 4ΩMIN. /SPEAKER

A+B: 8ΩMIN. /SPEAKER A OR B: 6ΩMIN. /SPEAKER

VOLTAGE

SELECTOR

(General model)

IMPEDANCE SELECTOR

switch

Power cable

VOLTAGE SELECTOR

AC OUTLET(S) Switch

position Impedance level

Right

If you use one set (A or B), the impedance of

each speaker must be 6 Ω or higher.

If you use two sets (A and B), the impedance

of each speaker must be 12 Ω or higher.

Left

If you use one set (A or B), the impedance of

each speaker must be 4 Ω or higher.

If you use two sets (A and B), the impedance

of each speaker must be 8 Ω or higher.

Notes

CAUTION

CONNECTIONS

PREPARATION

When all connections are complete, turn on the power of

this unit.

1Press MASTER ON/OFF on the front panel

inward to the ON position to turn on the

power of this unit.

Main Zone of this unit turns on.

You can set Main Zone of this unit to the standby

mode by pressing MAIN ZONE ON/OFF on the front

panel or STANDBY on the remote control.

Press MAIN ZONE ON/OFF on the front panel or

POWER on the remote control to turn Main Zone of

this unit on again.

Press MASTER ON/OFF on the front panel again to

release it outward to the OFF position to turn off this

unit.

While MASTER ON/OFF on the front panel is pressed inward to

the ON position, you can turn on Zone 2 or set it to the standby

mode independently (see page 42).

Turning on and off this unit

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

MASTER

ON OFF

PLAYING AND RECORDING

Extreme caution should be exercised when you play back CDs encoded in DTS.

If you play back a CD encoded in DTS on a DTS-incompatible CD player, you will only hear some unwanted noise that may damage

your speakers. Check whether your CD player supports CDs encoded in DTS. Also, check the sound output level of your CD player

before you play back a CD encoded in DTS.

1Rotate the INPUT selector on the front panel

(or press one of the input selector buttons on

the remote control) to select the desired

input source.

2Press SPEAKERS A and/or SPEAKERS B on

the front panel or on the remote control to

select speakers A and/or speakers B.

• Both SPEAKERS A and B can be selected.

• Make sure that the IMPEDANCE SELECTOR switch is

correctly set (see page 16).

3Play the source.

4Rotate VOLUME on the front panel (or press

VOLUME +/– on the remote control) to adjust

the sound output level.

PLAYING AND RECORDING

CAUTION

Playing a source

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

654

2 5 5

∞

-dB

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

VOLUME

DISC SKIP

AVTV

VCR

DTV/CBL

SPEAKERS

VOL CH

INPUT

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

POWER POWER

AVTV

VCR

DTV/CBL

Front panel Remote control

Notes

SPEAKERS

Front panel Remote control

∞

-dB

VOLUME

Remote control

Front panel

PLAYING AND RECORDING

BASIC

OPERATION

5Adjust the tonal quality by using the BASS,

TREBLE, BALANCE and LOUDNESS controls

or the CD DIRECT AMP and the PURE

DIRECT buttons on the front panel.

6Press MAIN ZONE ON/OFF on the front panel

again (or press STANDBY on the remote

control) to finish using this unit and set it to

the standby mode.

BASS

101

–

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

PURE DIRECT CD DIRECT AMP

ON/OFF

MAIN ZONE

STANDBY

Remote control

Front panel

PLAYING AND RECORDING

■Adjusting the BALANCE control

Adjusts the sound output balance of the left and right

speakers to compensate for sound imbalance caused by

speaker locations or listening room conditions.

■Using the CD DIRECT AMP button

Routes input signals from your CD player directly to the

specially built-in amplifier for the CD player. As a result,

the input signals bypass the INPUT selector and the

BASS, TREBLE, BALANCE and LOUDNESS controls

and then sent to the power amplifier, thus eliminating any

alterations to the CD signals and creating the purest

possible sound. The CD DIRECT AMP indicator lights up

and the front panel display turns off after a few seconds.

■Using the PURE DIRECT button

Routes input signals from your audio sources so that the

input signals bypass the BASS, TREBLE, BALANCE and

LOUDNESS controls, thus eliminating any alterations to

the audio signals and creating the purest possible sound.

If both the CD DIRECT AMP and the PURE DIRECT buttons

are turned on, only the CD DIRECT AMP button will function.

■Adjusting the BASS and TREBLE

controls

Adjust the high and low frequency response.

BASS

Increases or decreases the low frequency response.

TREBLE

Increases or decreases the high frequency response.

■Adjusting the LOUDNESS control

Retains a full tonal range at any volume level, thus

compensating for the human ears’ loss of sensitivity to

high and low-frequency ranges at a low volume level.

If the CD DIRECT AMP or the PURE DIRECT button is turned

on with the LOUDNESS control set at a certain level, the input

signals bypass the LOUDNESS control, resulting in a sudden

increase in the sound output level. To prevent your ears or the

speakers from being undesirably damaged, be sure to press the

CD DIRECT AMP or the PURE DIRECT button after lowering

the sound output level or after checking that the LOUDNESS

control is properly set.

1Rotate the LOUDNESS control on the front

panel to the FLAT position.

2Rotate VOLUME on the front panel (or press

VOLUME +/– on the remote control) to set the

sound output level to the loudest listening

level that you would listen to.

3Rotate the LOUDNESS control until the

desired volume is obtained.

Adjusting the tonal quality

Note

BALANCE

101

CD DIRECT AMP

PURE DIRECT

BASS

101

–

TREBLE

101

–

CAUTION

LOUDNESS

1FLAT

210

–

30dB

∞

-dB

VOLUME

Remote control

Front panel

LOUDNESS

1FLAT

210

–

30dB

PLAYING AND RECORDING

BASIC

OPERATION

• The VOLUME, BASS, TREBLE, BALANCE and

LOUDNESS controls and the CD DIRECT AMP and the PURE

DIRECT buttons have no effect on the source being recorded.

• Check the copyright laws in your country to record from

records, CDs, radio, etc. Recording copyright-protected

material may infringe on copyright laws.

1Rotate the REC OUT selector on the front

panel to select the source you want to record

from.

2Play the selected source to record from.

3Rotate the INPUT selector on the front panel

to confirm the selected source to record

from.

4Rotate VOLUME on the front panel (or press

VOLUME +/– on the remote control) to adjust

the sound output level of the selected source

to record from.

5Begin recording on the MD recorder, the tape

deck or the VCR connected to this unit.

Selecting another source with the INPUT selector on the front

panel (or the corresponding input selector button on the remote

control) while recording is in progress will not affect the

recording.

You can monitor the sound and/or picture being recorded by

rotating the INPUT selector on the front panel (or pressing MD/

TAPE or VCR on the remote control) to select the MD recorder,

the tape deck or the VCR used for recording.

Recording a source

Notes

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

341

∞

-dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

INPUT

Note

∞

-dB

VOLUME

Remote control

Front panel

PLAYING AND RECORDING

Use this feature to automatically set this unit to the

standby mode after a certain amount of time. The sleep

timer is useful when you are going to sleep while this unit

is playing or recording a source. The sleep timer also

automatically turns off any external components

connected to the AC OUTLETS.

• The sleep timer can only be set with the remote control.

• The sleep timer automatically turns off Zone 2. However, the

power of Zone 2 components are not turned off.

1Press one of the input selector buttons on

the remote control to select an input source.

2Start playback on the selected input source.

3Press SLEEP repeatedly to set the amount of

time before this unit is set to the standby

mode.

Each time you press SLEEP, the front panel display

changes as shown below.

The SLEEP indicator flashes while switching the

amount of time for the sleep timer.

4Press SLEEP repeatedly so that SLEEP OFF

appears in the front panel display.

After a few seconds, SLEEP OFF disappears from the

front panel display, and the SLEEP indicator turns

off.

The sleep timer setting can also be canceled by pressing

STANDBY on the remote control (or MAIN ZONE ON/OFF or

MASTER ON/OFF on the front panel) to set this unit to the

standby mode.

Using the sleep timer

Notes

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

VOLUME

DISC SKIP

AVTV

VCR

DTV/CBL

SPEAKERS

VOL CH

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

POWER POWER

AVTV

VCR

DTV/CBL

SLEEP

SLEEP 120 min SLEEP 90 min

SLEEP 60 minSLEEP 30 minSLEEP OFF

SLEEP

PLAYING AND RECORDING

BASIC

OPERATION

1Press MUTE on the remote control to mute

the sound output.

The MUTE indicator flashes in the front panel

display and MUTE ON appears in the front panel

display.

After a few seconds, MUTE ON disappears from the

front panel display.

2Press MUTE on the remote control again to

resume the sound output.

The MUTE indicator disappears from the front panel

display.

Muting the sound output

MUTE

FM/AM TUNING

There are 2 tuning methods; automatic and manual. Select either method according to your preference and the strength of

station signals.

Automatic tuning is effective when station signals are

strong and there is no interference.

1Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER as

the input source.

2Press FM/AM on the front panel to select the

reception band (FM or AM).

FM or AM appears in the front panel display.

3Press TUN MODE on the front panel so that

the AUTO indicator lights up in the front

panel display.

4Press TUNING/CH l / h once to begin

automatic tuning.

Press h to tune into a higher frequency.

Press l to tune into a lower frequency.

• When you tune into a station, the frequency of the received

station is shown in the front panel display.

• To search for another station, press TUNING/CH l / h once

more.

• If the tuning search does not stop at the desired station because

the station signals are weak, try using the manual tuning

method.

FM/AM TUNING

Automatic tuning

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

2 4 3

∞

-dB

INPUT

TUNER

Front panel Remote control

FM/AM

XM/ANT

TUN MODE/DISP

AUTO/MAN'L

AUTO

Lights up

Notes

TUNING/CH

FM/AM TUNING

BASIC

OPERATION

Manual tuning is effective when station signals are weak.

1Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER as

the input source.

2Press FM/AM on the front panel to select the

reception band (FM or AM).

FM or AM appears in the front panel display.

3Press TUN MODE on the front panel so that

the AUTO indicator disappears from the front

panel display.

4Press TUNING/CH l / h to manually tune

into the desired station.

Hold down the button to continue tuning search.

• When you tune into a station, the frequency of the received

station is shown in the front panel display.

• If you tune into an FM station, it is automatically received in the

monaural mode to increase signal quality.

Manual tuning

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

2 4 3

∞

-dB

INPUT

TUNER

Front panel Remote control

FM/AM

XM/ANT

TUN MODE/DISP

AUTO/MAN'L

AUTO

Disappears

Notes

TUNING/CH

FM/AM TUNING

You can use the automatic preset tuning method to

automatically store FM stations. This function enables this

unit to automatically tune into FM stations with strong

signals and store up to 40 (8 stations in each of the 5

groups, A1 to E8) of those received stations in order. You

can then easily recall any preset stations by selecting the

preset station numbers where they are stored.

• Any station data stored under a preset station number is cleared

when you store a new station under that preset station number.

• If the number of received stations does not reach 40 (E8),

automatic preset tuning automatically stops once searching all

available stations are tuned into and stored.

• Only FM stations with sufficient signal strength are stored

automatically by automatic preset tuning. If the station you

want to store is weak in signal strength, try using the manual

preset tuning method.

1Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER.

2Press FM/AM on the front panel to select FM

as the reception band.

FM appears in the front panel display.

3Press and hold MEMORY on the front panel

for more than 3 seconds.

The preset station group and the MEMORY and

AUTO indicators flash in the front panel display.

4Press TUNING/CH l / h once to begin

automatic preset tuning.

Press h to tune into higher frequencies.

Press l to tune into lower frequencies.

When automatic preset tuning is complete, the

frequency of the last preset station is shown in the

front panel display.

• If TUNING/CH l / h is not pressed within approximately 5

seconds while the MEMORY and AUTO indicators are

flashing, automatic preset tuning automatically begins from the

currently displayed frequency and proceeds toward higher

frequencies.

• Received stations are sequentially programmed to 8 stations in

each preset station group. If 8 stations are all programmed in a

preset station group, another 8 stations are sequentially

programmed in the next preset station group.

Automatic preset tuning

Notes

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

INPUT

TUNER

Front panel Remote control

Notes

FM/AM

XM/ANT

MEMORY

MAN'L/AUTO FM

TUNING/CH

FM/AM TUNING

BASIC

OPERATION

■Customized automatic preset tuning

You can specify a preset station group and a preset station

number from which this unit stores the FM stations

received by automatic preset tuning.

1Press and hold MEMORY on the front panel

for more than 3 seconds.

2Press A/B/C/D/E and then press one of the

preset station/channel number buttons on

the front panel to select the preset station

group and the preset station number where

the first received station will be stored.

For example, if you select C5, the first received

station is automatically programmed to C5 and the

next received stations are sequentially programmed

to C6, C7, etc.

3Press TUNING/CH l / h on the front panel to

begin automatic preset tuning.

Press h to tune into higher frequencies.

Press l to tune into lower frequencies.

When automatic preset tuning is complete, the

frequency of the last preset station is shown in the

front panel display.

Automatic preset tuning stops when the received stations have all

been stored up to E8.

MEMORY

MAN'L/AUTO FM

A/B/C/D/E

CATEGORY

12345678

Note

TUNING/CH

FM/AM TUNING

You can also manually store up to 40 stations (8 stations in

each of the 5 groups, A1 to E8). You can then easily recall

any preset stations by selecting the preset station numbers

where they are stored.

1Repeat steps 1 to 4 in “Automatic tuning” or

in “Manual tuning” to tune into a station.

When you tune into a station, the frequency of the

received station is shown in the front panel display.

2Press MEMORY on the front panel.

The MEMORY indicator flashes in the front panel

display for approximately 5 seconds.

3Press A/B/C/D/E on the front panel

repeatedly to select a preset station group (A

to E).

The selected preset station group is shown in the front

panel display.

4Press one of the preset station/channel

number buttons on the front panel to select a

preset station number (1 to 8) where you

want to store the station.

This operation must be done within 5 seconds while the

MEMORY indicator is flashing in the front panel display.

Otherwise, the manual preset tuning process is automatically

canceled.

5Press MEMORY on the front panel to store

the station.

6Repeat steps 1 to 5 to store other stations.

• Any station data stored under a preset station number is cleared

when you store a new station under that preset station number.

• The reception mode (stereo or monaural) is stored along with

the station frequency.

Manual preset tuning

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

MEMORY

MAN'L/AUTO FM

MEMORY

Flashes

A/B/C/D/E

CATEGORY

Note

Notes

12345678

FM/AM TUNING

BASIC

OPERATION

You can tune into the desired station simply by selecting

the preset station number where it is stored.

1Press A/B/C/D/E on the front panel

repeatedly (or press A-E/CAT. j / i on the

remote control) to select a preset station

group (A to E).

The selected preset station group is shown in the front

panel display.

2Press one of the preset station/channel

number buttons on the front panel (or

PRESET/CH u / d on the remote control) to

select a preset station number (1 to 8).

The preset station number appears in the front panel

display along with the reception band and the

frequency.

You can exchange the assignment of two preset stations

with each other. The following procedure describes an

example where a preset station E1 is exchanged with

another preset station A5.

1Repeat steps 1 and 2 in “Selecting preset

stations” to select a preset station E1.

2Press EDIT on the front panel.

E1 and the MEMORY indicator flash in the front

panel display.

3Repeat steps 1 and 2 in “Selecting preset

stations” to select another preset station A5.

A5 and the MEMORY indicator flash in the front

panel display.

4Press EDIT on the front panel again.

E1-A5 appears in the front panel display, indicating

that the two preset station assignments have been

exchanged.

Selecting preset stations

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

∞

-dB

XM/ANT

A/B/C/D/E

CATEGORY

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel

Remote control

12345678

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel

Remote control

Exchanging preset stations

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

2,4

∞

-dB

EDIT

SEARCH MODE

MEMORY

Flashes

MEMORY

Flashes

EDIT

SEARCH MODE

XM SATELLITE RADIO TUNING

XM Satellite Radio is the satellite radio service with

millions of listeners across the United States broadcasting

live daily. The XM Satellite Radio channel lineup includes

more than 150 digital channels of choice from coast to

coast: 67 commercial-free music channels, featuring hip

hop to opera, classical to country, bluegrass to blues; 64

channels of premier sports, talk, comedy, children’s and

entertainment programming; and more than 26 channels

of the traffic and weather information for major

metropolitan areas nationwide.

Because XM Satellite Radio is a subscription service, you

will need to set up an account and activate service with

XM using your XM Satellite Radio ID number. To check

your ID number, follow “Activating XM Satellite Radio”

on page 33. For further information on XM Satellite Radio

services, visit the XM Satellite Radio website at

“http://www.xmradio.com”.

• The XM Satellite Radio service is only available in the 48

contiguous United States (not available in Alaska and Hawaii).

• XM Connect-and-Play digital antenna accessory and monthly

subscription are sold separately. For details, visit the XM

Satellite Radio website at “http://www.xmradio.com”.

Information from XM Satellite Radio, Inc.

Hardware and required basic monthly subscription sold

separately. Premium Channel available at additional monthly

cost. Installation costs and other fees and taxes, including a one-

time activation fee may apply. Subscription fee is consumer

only. All fees and programming subject to change.

Subscriptions subject to Customer Agreement available at

xmradio.com. Only available in the 48 contiguous United

States.

trademarks are the property of their respective owners.

Connect the XM Connect-and-Play digital antenna

accessory (sold separately) to the XM jack on the rear of

this unit. (For details, refer to the operating instructions

provided with the XM Connect-and-Play digital antenna

accessory).

• For information on obtaining the XM Connect-and-Play digital

antenna accessory, visit the XM Satellite Radio website at

“http://www.xmradio.com” or consult your local retailer that

sells XM Ready products.

• To ensure the optimal reception of the XM Satellite Radio

signals, the XM Connect-and-Play digital antenna accessory

must be placed at or near a southerly facing window with no

obstacles in the path to the sky. You can mount it indoors or

outdoors.

XM SATELLITE RADIO TUNING

What is XM Satellite Radio?

Notes

XM Satellite Radio connections

Notes

SPEAKERS

CLASS 2 WIRING

XMREMOTE

OUT

DVD

DTV/

CBL

PLAY)

OUT

(

REC)

OUT

MD/

APE

ONE 2

OUT

VCR

MAIN

PRE

OUT

SUB

WOOFER

+12V 15mA MAX.

CONTROL OUT

COUPLER

OUTPUT

XM jack

XM SATELLITE RADIO TUNING

BASIC

OPERATION

This section describes the functions of each control used

for the XM Satellite Radio tuning.

The following controls on the front panel and the remote controls

are only available when XM is selected as the input source and

the XM Connect-and-Play digital antenna accessory is connected

to the XM jack on the rear panel of this unit (see “XM Satellite

Radio connections”).

■Controls on the front panel

1SEARCH MODE

Switches between the All Channel Search, Category

Search, and Preset Search modes (see page 35).

2XM ANT (ANTENNA)

Shows the reception level of the XM Connect-and-Play

digital antenna (sold separately).

3TUNING/CH l / h

All Channel Search mode

Searches for a radio channel within all channels.

Press and hold for quick search.

Category Search mode

Searches for a radio channel within the selected

category. Press and hold for quick search.

Preset Search mode

Selects the preset channel number (1 to 8).

4DISP (DISPLAY)

Switches the XM Satellite Radio information shown in the

front panel display between channel number/name,

category and artist name/song title (see page 34).

5INPUT selector

Selects XM as the input source.

6CATEGORY

All Channel Search mode

Switches between channel categories while staying in

the All Channel Search mode.

Category Search mode

Switches between channel categories.

Preset Search mode

Selects the preset channel group (A to E).

7Preset channel number buttons

Selects the preset channel number (1 to 8) directly.

Pressing these buttons switches the search mode to the

Preset Search mode.

8MEMORY

Stores a radio channel in the system memory.

XM Satellite Radio functions

Note

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

6 75

134

∞

-dB

XM SATELLITE RADIO TUNING

■Controls on the remote controls

1Numeric buttons

All Channel Search or Category Search mode

Use 1 to 9 and 0 to enter a channel number directly.

Preset Search mode

Use 1 to 8 to enter a preset channel number directly.

2A-E/CAT. (CATEGORY) j / i (l / h)

All Channel Search mode

Switches between channel categories while staying in

the All Channel Search mode.

Category Search mode

Switches between channel categories.

Preset Search mode

Selects the preset channel group (A to E).

PRESET/CH u / d (k / n)

All Channel Search mode

Searches for a radio channel within all channels. Press

and hold for quick search.

Category Search mode

Searches for a radio channel within the selected

category. Press and hold for quick search.

Preset Search mode

Selects the preset channel number (1 to 8).

3MEMORY

Stores a radio channel in the system memory.

4XM

Selects XM as the input source.

5ENT. (ENT) (ENTER)

Confirms an entered channel number when this unit is in

the Direct Number Access mode (see page 37).

6SRCH (SEARCH) MODE

Switches between the All Channel Search, Category

Search, and Preset Search modes (see page 35).

7DISPLAY

Switches XM information such as channel number/name,

category, or artist name/song title displayed in the front

panel display and on-screen display (see page 34).

8Input selector/numeric buttons

All Channel Search or Category Search mode

Use 1 to 9 and 0 to enter a channel number directly.

Also refer to 0 NUMBER.

Preset Search mode

Use 1 to 8 to enter a preset channel number directly.

Also refer to 0 NUMBER.

You must press and hold 0 NUMBER before you press any of

these buttons to enter numbers.

9ALL

Selects the All Channel Search mode.

0NUMBER

Press and hold before you press the input selector/numeric

buttons to switch the function to enter numbers.

ACAT. (CATEGORY)

Selects the Category Search mode.

BPRESET

Selects the Preset Search mode.

CCD/XM switch

Switches the function of the control buttons on the Zone 2

remote control numbered 2, 7, 9, 0, A and B

between controlling YAMAHA CD players and

controlling the XM Satellite Radio features.

STANDBY

SYSTEM

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

VOL CH

PHONO

ZONE 2

TUNER

MD/TAPE

VCR

DTV/CBL

DVD

8 9 0

POWER

STANDBY

–

lA-E/CAT. k

A-E/CAT.h

CAT.

DISC

ALL

PRESET

PRESET/CH

NUMBER

A/B/C/D/E

MUTE

PRESET VOLUME

XMCDID2ID1

DISPLAY

ENT

Note

XM SATELLITE RADIO TUNING

BASIC

OPERATION

To sign up for an account with the XM Satellite Radio

service, an XM Satellite Radio ID number is required.

Follow the procedure below to check your ID number, and

then visit the website at “http://activate.xmradio.com” or

call “1-800-XM-RADIO (1-800-967-2346)” to sign up

with your major credit card handy.

1Rotate the INPUT selector on the front panel

(or press XM on the remote control) to select

XM as the input source.

If CHECK ANTENNA appears in the front panel

display, the XM Connect-and-Play digital antenna

accessory may not be connected to the XM jack on

the rear panel of this unit properly. See “XM Satellite

Radio connections” on page 30 and check the

connection.

2Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control)

repeatedly to select the All Channel Search

mode.

ALL CH SEARCH appears in the front panel display.

3Press TUNING/CH l / h on the front panel

(or PRESET/CH u / d on the remote control)

to select channel 0.

4Check the XM Satellite Radio ID number

shown in the front panel display and write it

down.

ID:_____________________________________

Activating XM Satellite Radio

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

2 3

∞

-dB

INPUT

Front panel Remote control

EDIT

SEARCH MODE

SRCH MODE

Front panel Remote control

TUNING/CH

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

XM SATELLITE RADIO TUNING

1Rotate the INPUT selector on the front panel

(or press XM on the remote control) to select

XM as the input source.

The XM information (channel number/name,

category or artist name/song title) for the currently

selected channel appears in the front panel display.

Selecting XM as the input source automatically recalls the

previously selected channel.

2Press DISP on the front panel (or DISPLAY on

the remote control) repeatedly to toggle

between the following channel information

display modes.

When the channel number and the channel name

are displayed:

When the channel category is displayed:

When the artist name and the song title are

displayed:

• Up to 14 alphanumeric characters can be shown in the front

panel display at once. If the information contains more than 14

characters, the information scrolls from the right to the left.

• If the information contains a character that cannot be

recognized by this unit, the character will be shown with an

underbar “_”.

If a status message or an error message appears in the front panel

display, see “XM Satellite Radio” on page 48.

Basic XM Satellite Radio

operations

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

∞

-dB

XM/ANT

INPUT

Front panel Remote control

Note

TUN MODE/DISP

AUTO/MAN'L

DISPLAY

Channel name

Channel number

Channel category

Artist name

Song title

Front panel Remote control

XM SATELLITE RADIO TUNING

BASIC

OPERATION

You can search for the desired channel by using one of the

three search modes (All Channel Search mode, Category

Search mode or Preset Search mode). You can also enter

the number directly to select the desired channel (For

details, see “Direct Number Access mode” on page 37).

■All Channel Search mode

1Repeat step 1 in “Basic XM Satellite Radio

operations”.

2Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control)

repeatedly to select the All Channel Search

mode.

ALL CH SEARCH appears in the front panel display.

3Press CATEGORY on the front panel (or A-E/

CAT. j / i on the remote control) repeatedly to

switch between channel categories.

4Press TUNING/CH l / h on the front panel

(or PRESET/CH u / d on the remote control)

repeatedly to search for a channel within all

channels.

To quickly search for a channel, press and hold

TUNING/CH l / h on the front panel (or PRESET/CH u / d

on the remote control).

XM Satellite Radio search modes

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

SRCH MODE

EDIT

SEARCH MODE

Front panel Remote control

A/B/C/D/E

CATEGORY

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel Remote control

TUNING/CH

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel Remote control

XM SATELLITE RADIO TUNING

■Category Search mode

1Repeat step 1 in “Basic XM Satellite Radio

operations”.

2Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control)

repeatedly to select the Category Search

mode.

CAT SEARCH appears in the front panel display.

3Press CATEGORY on the front panel (or A-E/

CAT. j / i on the remote control) repeatedly to

switch between channel categories.

4Press TUNING/CH l / h on the front panel

(or PRESET/CH u / d on the remote control)

repeatedly to search for a channel within the

selected channel category.

To quickly search for a channel, press and hold

TUNING/CH l / h (or PRESET/CH u / d on the remote

control).

■Preset Search mode

Prior to selecting a preset channel in the Preset Search

mode, you must preset the XM Satellite Radio channels

(see page 37). All preset channels (A1 to E8) recall “001

Preview” as the factory setting.

1Repeat step 1 in “Basic XM Satellite Radio

operations”.

2Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control)

repeatedly to select the Preset Search mode.

PRESET SEARCH appears in the front panel display.

3Press CATEGORY on the front panel (or A-E/

CAT. j / i on the remote control) repeatedly to

select the preset channel group (A to E).

4Press TUNING/CH l / h on the front panel

(or PRESET/CH u / d on the remote control)

repeatedly to select the preset channel

number (1 to 8).

You can also select the preset channel number directly by

pressing the preset channel number buttons (1 to 8) on the front

panel or the numeric buttons (1 to 8) on the remote control.

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

Front panel Remote control

SRCH MODE

EDIT

SEARCH MODE

Front panel Remote control

A/B/C/D/E

CATEGORY

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel Remote control

TUNING/CH

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

Front panel Remote control

SRCH MODE

EDIT

SEARCH MODE

Front panel Remote control

A/B/C/D/E

CATEGORY

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel Remote control

TUNING/CH

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

XM SATELLITE RADIO TUNING

BASIC

OPERATION

■Direct Number Access mode

1Repeat step 1 in “Basic XM Satellite Radio

operations”.

2Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control)

repeatedly to select the All Channel Search

mode or the Category Search mode.

ALL CH SEARCH or CAT SEARCH appears in the

front panel display.

3Press numeric buttons on the remote control

sequentially to enter the desired channel

number.

4Press ENT. on the remote control to

immediately tune into the channel with fewer

than three digits for the channel number.

• If no button is pressed within a few seconds after entering one-

digit or two-digit channel number, this unit automatically

confirms the entered channel number and tunes into the selected

channel.

• Pressing a button other than the numeric buttons or ENT. on the

remote control cancels the Direct Number Access procedure.

You can use this feature to store up to 40 XM Satellite

Radio channels (8 preset channel numbers in each of the 5

preset channel groups, A1 to E8). You can then easily

recall any preset channel by selecting the preset channel

group and the preset channel number as described in

“Preset Search mode” on page 36.

1Search for the XM Satellite Radio channel

you want to set as a preset channel.

To search for the desired channel, perform the steps

in “All Channel Search mode”, “Category Search

mode” or “Direct Number Access mode”.

2Press MEMORY on the front panel or on the

remote control.

The MEMORY indicator flashes in the front panel

display for approximately 5 seconds.

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

∞

-dB

Front panel Remote control

SRCH MODE

EDIT

SEARCH MODE

MENUTITLE

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

ENTER

ENT.

Setting XM Satellite Radio preset

channels

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

3 4

2,5

∞

-dB

MEMORY

MAN'L/AUTO FM

RETURN

MEMORY

Flashes

Front panel Remote control

XM SATELLITE RADIO TUNING

Press CATEGORY on the front panel (or A-E/

CAT.

on the remote control) to select the

preset channel group (A to E).

The preset channel group letter appears.

4Press one of the preset station/channel

number buttons on the front panel (or

PRESET/CH u / d on the remote control) to

select the preset channel number (1 to 8).

5Press MEMORY on the front panel or on the

remote control to preset the selected XM

Satellite Radio channel.

A colon appears next to the preset channel number

for confirmation, and the MEMORY indicator turns

off.

• Steps 3 to 5 must be done respectively within 5 seconds while

the MEMORY indicator is flashing in the front panel display.

Otherwise, the XM Satellite Radio channel presetting procedure

is automatically canceled.

• Presetting a new channel clears the former preset channel stored

in the same preset channel group and number.

Notes

A/B/C/D/E

CATEGORY

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel Remote control

A-E/CAT. A-E/CAT.

PRESET/CH

ENTER

Front panel

Remote control

12345678

MEMORY

MAN'L/AUTO FM

RETURN

MEMORY

Front panel Remote control

ADVANCED SETUP

ADVANCED

OPERATION

■ADVANCED SETUP menu parameters

Change the initial settings (indicated in bold under each

parameter) to reflect the needs of your listening

environment.

Factory presets PRESET

Use to reset all parameters to the factory presets.

Choices: CANCEL, RESET

• Select CANCEL if you do not want the parameters of

this unit to be initialized when you reset the factory

presets.

• Select RESET if you want all of the parameters of this

unit to be initialized when you reset the factory presets.

• This setting does not affect the parameters in the ADVANCED

SETUP menu.

• The resetting process starts next time you turn on the power of

this unit.

Remote REMOTE

Use to switch the remote control ID of this unit.

Choices: ID1, ID2

• Select ID1 to operate this unit using an alternative

code.

• Select ID2 to operate this unit using the default code.

You must also make settings for the remote control (see page 40)

and the Zone 2 remote control (see page 9).

Tuner TU

(Asia and General models only)

Use to switch the frequency step selection according to the

frequency spacing in your area.

Choices: AM10/FM100, AM9/FM50

• North, Central and South America:

AM10/FM100 (kHz)

• Other areas: AM9/FM50 (kHz)

The ADVANCED SETUP menu is displayed in the front

panel display.

• During the ADVANCED SETUP procedure, audio output is

muted.

• During the ADVANCED SETUP procedure, only MASTER

ON/OFF, A/B/C/D/E and the preset station/channel number

buttons (1 and 2) on the front panel are operational.

1Press MASTER ON/OFF on the front panel to

release it outward to the OFF position.

2Press and hold A/B/C/D/E on the front panel

and then press MASTER ON/OFF inward to

the ON position.

The power of this unit is turned on, and the

ADVANCED SETUP menu appears in the front

panel display.

ADVANCED SETUP

Notes

Note

Changing the ADVANCED SETUP

menu parameters

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER SPEAKERS

ON OFF

CD DIRECT AMPPURE DIRECT

101

–

VOLUME

TUNING/CH

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

SEARCH MODE

A/B/C/D/E

12345678

CATEGORY

MEMORY

MAN'L/AUTO FM

TUN MODE/DISP

AUTO/MAN'L

TREBLE

101

–

BALANCE

101

LOUDNESS

1FLAT

210

–

30dB

REC OUT

MD/TAPE

DVD

VCR TUNER

DTV/CBL PHONO

XM/ANT

2,4 3

1,2,5

∞

-dB

MASTER

ON OFF

While holding down,

press

A/B/C/D/E

CATEGORY

MASTER

ON OFF

ADVANCED SETUP

3Press the preset station/channel number

buttons (1 and 2) on the front panel

repeatedly to move through the menu and

select the parameter you want to adjust.

See page 39 for a complete list of available

parameters.

4Press A/B/C/D/E on the front panel

repeatedly to toggle between the available

parameters.

5Press MASTER ON/OFF to release it outward

to the OFF position to confirm your setting.

The settings you made are reflected next time you turn on the

power of this unit.

You can select the unit you want to operate with the

remote control by switching the remote control ID.

1Press and hold CODE SET on the remote

control and then press TUNER on the remote

control.

2While holding down CODE SET on the

remote control, use the numeric buttons on

the remote control to enter the three-digit

code number listed in the table below.

*When you change the remote control ID, you must switch

the remote control ID of this unit (see page 39).

When using multiple YAMAHA receivers or

amplifiers with the same default code setting, you

may unwantedly operate those components

simultaneously. In this case, set one of the alternative

codes for this unit to operate this unit separately.

Also change the remote control ID of the Zone 2 remote control

(see page 9).

Note

1 2

A/B/C/D/E

CATEGORY

MASTER

ON OFF

Switching the remote control ID

Remote

control ID*

(this unit’s

setting)

Function Code number

ID1

To operate this

unit using an

alternative code.

801

ID2

(default setting)

To operate this

unit using the

default code.

802

Note

CODE SET

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

POWER POWER

AVTV

VCR

DTV/CBL

CODE SET MENUTITLE

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

ENTER

ZONE 2

ADVANCED

OPERATION

This unit allows you to configure a multi-room audio and video system. The Zone 2 feature enables you to set this unit to

reproduce separate input sources in the main room and in Zone 2 (the second room) simultaneously. You can also control

this unit from the second room using the supplied Zone 2 remote control.

You need the following additional equipment to use the multi-room system of this unit:

• An infrared signal receiver for the second room.

• An infrared emitter for the main room. This emitter transmits the infrared signals sent by the Zone 2 remote control in

Zone 2 to the components in the main room.

• An amplifier and speakers for the second room.

• A video monitor for the second room.

Some YAMAHA models are able to connect directly to the REMOTE OUT jack on the rear panel of this unit. If you own these

products, you may not need to use an infrared emitter. Up to six YAMAHA components can be connected as shown below.

■Multi-room configuration and connections

The following illustration shows an example of the multi-room system configuration and connections.

Since there are many possible ways to connect and use this unit in a multi-room configuration, we recommend that you consult with

your nearest authorized YAMAHA dealer or service center for the Zone 2 connections that best meet your requirements.

If you want to adjust the Zone 2 volume level by using the amplifier in the second room, we recommend setting the Zone 2 volume level

to or near –16 dB.

ZONE 2

Connecting the Zone 2 components

Note

OUTOUT IN

REMOTE

OUT IN

REMOTE REMOTE

This unit YAMAHA

component

YAMAHA

component

Infrared signal

receiver

REMOTE OUT

VIDEO IN

MONITOR OUT

SPEAKERS

REMOTE IN

ZONE 2 AUDIO OUT

MAIN

ZONE 2

AUDIO IN

ZONE 2 VIDEO OUT

Infrared emitter

DVD player

(or other components)

Amplifier

Zone 2

remote control

Infrared signal

receiver

Second room

(Zone 2)

Main room

(Main Zone)

This unit Video monitor

ZONE 2

Use the supplied Zone 2 remote control to control the

input source or adjust the sound output level of Zone 2

independently of the listening conditions in the main

room.

1Press POWER on the Zone 2 remote control

(or ZONE 2 ON/OFF on the front panel) to

turn on Zone 2.

2Press one of the input selector buttons on

the ZONE 2 remote control to select the input

source of Zone 2.

You can also control the input source by using the control buttons

on the front panel.

Press ZONE CONTROL on the front panel, and then rotate the

INPUT selector on the front panel to select the desired input

source of Zone 2.

3Press VOLUME +/– on the Zone 2 remote

control to adjust the sound output level of

Zone 2.

You can mute the sound output to Zone 2 by pressing MUTE on

the ZONE 2 remote control. Press again to restore the sound

output to the previous volume level.

Controlling Zone 2

POWER

ZONE 2 ON/OFF

Zone 2 remote

control

Front panel

PHONO

ZONE 2

TUNER

MD/TAPE

VCR

DTV/CBL

ENT

DVD

890

POWER

STANDBY

–

VOLUME

REMOTE CONTROL FEATURES

ADVANCED

OPERATION

■Controlling this unit

The shaded areas below can be used to control this unit.

■Controlling other components

The shaded areas below can be used to control other

audio and video components made by YAMAHA and

other manufacturers. Each button has a different

function depending on the selected component. Select

the component you want to control by pressing one of

the input selector buttons. The name of the selected

component appears in the front panel display.

REMOTE CONTROL FEATURES

Control area

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

VOL CH

The buttons inside the

dotted lines control this

unit in any mode

(POWER, STANDBY,

SLEEP, the input

selector buttons,

VOLUME +/– and

MUTE).

STANDBY

POWER

MD/TAPE

TUNER

PHONODVD

SLEEP

POWER POWER

REC

CODE SET

MUTE

MENUTITLE

VOLUME

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

AVTV

ENTER

VCR

DTV/CBL

SPEAKERS

VOL CH

REC

CODE SET

MENUTITLE

DISC SKIP

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

ENTER

VOL CH

Component

control area

You can control up

to 6 different

components by

setting the

appropriate remote

control codes (see

page 45).

The input selector

buttons switch the

function of the

component control

area below.

REMOTE CONTROL FEATURES

In addition to controlling this unit, you can also control

other audio and video components made by YAMAHA

and other manufacturers using the supplied remote

control. To control other components, you must set the

appropriate remote control codes.

*1 This button functions only when the original remote control of the component has the POWER button.

*2 These buttons function for Europe model only.

Controlling other components

STANDBY

POWER

MD/TAPE

TUNER

PHONODV D

SLEEP

POWER POWER

REC

CODE SET

MUTE

VOLUME

DISC SKIP

MUTE INPUT

AVTV

VCR

DTV/CBL

SPEAKERS

VOL CH

MUTE

MENUTITLE

SRCH MODE

BAND

A-E/CAT. A-E/CAT.

PRESET/CH

4321

ENT.

DISPLAYRETURN

MEMORY

MUTE INPUT

ENTER

DVD player VCR Digital TV/

Cable TV TV CD player Tape deck MD recorder Tuner

1AV P OW ER Power *1Power *1Power *1VCR power Power *1Power *1Power *1Power *1

2TV POWER TV power TV power TV power Power *1TV power TV power TV power TV power

3ll Search backward Search backward VCR search

backward

VCR search

backward Search backward Search backward Search backward PTY MODE *2

hh Search forward Search forward VCR search

forward

VCR search

forward Search forward Search forward Search forward PTY START *2

bSkip backward Skip backward Direction A Skip backward FREQ/TEXT *2

aSkip forward Skip forward Direction B Skip forward EON *2

REC/

DISC SKIP Disc skip Rec VCR rec VCR rec Disc skip Rec Rec

sStop Stop VCR stop VCR stop Stop Stop Stop

ePause Pause VCR pause VCR pause Pause Deck A/B Pause

hPlay Play VCR play VCR play Play Play Play

4TV VOL + TV volume + TV volume + TV volume + Volume + TV volume + TV volume + TV volume + TV volume +

TV VOL – TV volume – TV volume – TV volume – Volume – TV volume – TV volume – TV volume – TV volume –

5TV CH +

TV channel + Channel + Channel + Channel + TV channel + TV channel + TV channel + TV channel +

TV CH –

TV channel – Channel – Channel – Channel – TV channel – TV channel – TV channel – TV channel –

6TV MUTE TV mute TV mute TV mute Mute TV mute TV mute TV mute TV mute

7TITLE Title Title Title Title Band

8ENTER Menu enter Menu select Menu select

PRESET/CH

Menu up Menu up Menu up Preset up

(1 to 8)

PRESET/CH

Menu down Menu down Menu down Preset down

(1 to 8)

A-E/CAT. jMenu left Menu left Menu left Preset down

(A to E)

A-E/CAT. iMenu right Menu right Menu right Preset up

(A to E)

9RETURN Return Return Return Return

0TV INPUT TV input TV input TV input Input TV input TV input TV input TV input

A1-9, 0, +10

Numeric buttons Numeric buttons Numeric buttons Numeric buttons Numeric buttons Numeric buttons

Preset stations (1-8)

BENT. Enter Enter/recall Enter/

numeric button Index

CMENU Menu Menu Menu

DDISPLAY Display Display Display Display Display

REMOTE CONTROL FEATURES

ADVANCED

OPERATION

You can control other components by setting the

appropriate remote control codes. Codes can be set up for

each input source. For a complete list of available remote

control codes, refer to “LIST OF REMOTE CONTROL

CODES” at the end of this manual.

The following table show the default component category

(library) and the remote control code for each input

source.

Remote control code default settings

*You can only set the TV remote control codes for the DTV/

CBL button. However, other remote control codes can be set

for any input selector buttons except DTV/CBL.

You may not be able to operate your other YAMAHA

components even if the YAMAHA remote control code is

initially set as listed above. In this case, try setting other

YAMAHA remote control codes.

1Press and hold CODE SET on the remote

control and then press one of the input

selector buttons on the remote control to

select the input source you want to set up.

You must press and hold CODE SET throughout this

operation.

2While holding down CODE SET on the

remote control, use the numeric buttons on

the remote control to enter the three-digit

remote control code for the selected input

source.

When the setting succeeds, “PRESET OK” appears;

however, when it does not, “PRESET NG” appears in

the front panel display.

To reset the code, enter the default code for each

input source listed in the remote control code default

settings table.

• If the manufacturer of your component has more than one

code, try setting each of them until you find the correct

one.

• You can only assign one remote control code to each input

selector button.

Setting remote control codes

Input

source

Default

component

Yamaha RX 797 Manual E U P

Navigation menu

Versions of this User Manual:

Views

Navigation
